Table of Contents

Introductory Information ............................... 1
Safety Restraints .............................................. 7
Starting Your Crown Victoria .................... 37
Warning Lights and Gauges ....................... 47
Instrument Panel Controls .......................... 87
Steering Column Controls ........................ 109
Features .......................................................... 121
Electronic Sound Systems ......................... 149
Driving Your Crown Victoria .................. 173
Roadside Emergencies ................................ 197
Customer Assistance ................................... 215
Reporting Safety Defects ...................... 223
Accessories .................................................... 227
Servicing Your Crown Victoria ............... 233
Quick Index .................................................. 303
Index ............................................................... 313
Service Station Information ...................... 332

File:rcinv.ex Update:Wed Jan 31 10:14:27 1996

*[IN00300( ALL)04/95] *[IN00500( ALL)04/95] *[IN00600( ALL)04/95]

*[IN00700( ALL)04/95]

*[IN00750( ALL)04/95]

*[IN00800( ALL)04/95]

*[IN00900( ALL)04/95]

*[IN01000( ALL)04/95]

Introductory Information

Ford’s Commitment to You Our Guiding Principles q Quality comes first. For your satisfaction, the quality of our products and services must be our number one priority.

q You are the focus of everything we do. Our

work must be done with you in mind, providing better products and services than our competition.

q Continuous improvement is essential to our

success. We must strive for excellence in everything we do: in our products — in their safety and value — and in our services, our human relations, our competitiveness, and our profitability.

q Employee involvement is our way of life. We are a team. We must treat one another with trust and respect.

q Dealers and suppliers are our partners. We

must maintain mutually beneficial relationships with dealers, suppliers, and our other business associates.

Integrity is never compromised. Our conduct worldwide must be pursued in a manner that is socially responsible and commands respect for its integrity and for its positive contributions to society.

File:rcinv.ex Update:Wed Jan 31 10:14:27 1996

*[IN01100( ALL)04/95]

*[IN01200( ALL)04/95]

*[IN01300( ALL)04/95]

*[IN01400( ALL)05/95] *[IN01420( ALL)05/95] *[IN01440( ALL)05/95]

*[IN01460( ALL)05/95]

*[IN01500( ALL)04/95] *[IN01600( ALL)04/95]

Things to Know About Using This Guide Congratulations on the purchase of your new vehicle. This guide has information about the equipment and the options for your new vehicle. You may not have bought all of the options available to you. If you do not know which information applies to your vehicle, talk to your dealer. This guide describes equipment and gives specifications for equipment that was in effect when this guide was approved for printing. Ford may discontinue models or change specifications or design without any notice and without incurring obligation. NOTES and WARNINGS NOTES give you additional information about the subject matter you are referencing. WARNINGS remind you to be especially careful in those areas where carelessness can cause damage to your vehicle or personal injury to yourself, your passengers or other people. Please read all WARNINGS carefully.

RWARNING

Finding Information in This Guide After you have read this guide once, you will probably return to it when you have a specific question or need additional information. To help you find specific information quickly, you can use the Quick Index or the Index.

File:rcinv.ex Update:Wed Jan 31 10:14:27 1996

*[IN01700( ALL)05/95]

*[IN01900( ALL)04/95]

%*[IN02000( ALL)04/95] *[IN02100( ALL)04/95]

*[IN02400( ALL)04/95]

*[IN02500( ALL)03/95]

%*[IN02600( ALL)01/95] [IN02700( ALL)12/94]

%*[IN03100( ALL)03/95]

*[IN03250( ALL)03/95]

The Quick Index at the end of the book provides a page number following each item which indicates where detailed information can be found. To use the Index, turn to the back of the book and search in the alphabetical listing for the word that best describes the information you need. If the word you chose is not listed, think of other related words and look them up. We have designed the Index so that you can find information under a technical term. Canadian Owners — French Version French Owner Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. Your Maintenance Schedule and Record Booklet The Maintenance Schedule and Record booklet lists the services that are most important for keeping your vehicle in good condition. A record log is also provided to help you keep track of all services performed. About the Warranties Your vehicle is covered by three types of warranties: Basic Vehicle Warranty, Extended Warranties on certain parts, and Emissions Warranties. Read your Warranty Information Booklet carefully to find out about your vehicle’s warranties and your basic rights and responsibilities. If you lose your Warranty Information Booklet, you can get a new one free of charge. Contact any Ford or Lincoln-Mercury dealer, or refer to the

File:rcinv.ex Update:Wed Jan 31 10:14:27 1996

%*[IN04000( ALL)01/95] *[IN04100( ALL)01/94]

*[IN04200( ALL)01/95]

*[IN04250( ALL)01/95]

%*[IN06000( ALL)01/95] *[IN06100( ALL)03/95]

%*[IN06300( ALL)01/95]

*[IN06400( ALL)01/95] *[IN06500( ALL)01/95] *[IN06600( ALL)01/95] *[IN06700( ALL)01/95]

addresses and phone numbers on the first page of this owner guide. Buying a Ford Extended Service Plan If you bought your vehicle in the U.S., you can buy a Ford Extended Service Plan for your vehicle. This optional contract provides service protection for a longer period of time than the basic warranty that comes with your vehicle. You do not have to buy this option when you buy your vehicle. However, your option to purchase the Ford Extended Service Plan runs out after 18 months or 18,000 miles. See your dealer for more details about the Ford Extended Service Plan. If you purchased a Canadian vehicle and did not take advantage of the Ford Extended Service Plan at the time of purchase, you may still be eligible. See your dealer for the details. Breaking Your Vehicle In Your new vehicle goes through an adjustment or break-in period during the first 1,000 miles (1,600 km) that you drive it. During the break-in period, you need to pay careful attention to how you drive your vehicle. q Avoid sudden stops. Because your vehicle

has new brake linings, you should take these steps: — Watch traffic carefully so that you can

anticipate when to stop.

— Begin braking well in advance. — Apply the brakes gradually. The break-in period for new brake linings lasts for 100 miles (160 km) of city driving or 1,000 miles (1,600 km) of highway driving.

File:rcinv.ex Update:Wed Jan 31 10:14:27 1996

%*[IN06800( ALL)01/95]

*[IN07000( ALL)04/95]

%*[IN07100( ALL)04/95]

*[IN07130( ALL)05/95]

*[IN07160( ALL)05/95] *[IN07190( ALL )05/95]

q Use only the type of engine oil that Ford recommends. See Engine oil recommendations in the Index. Do not use special “break-in” oils.

Your vehicle is equipped with an Electronic Powertrain Control Module that limits engine and/or vehicle speeds with a cut-out mode to promote durability. Cleaning the Outside of Your Vehicle Pollen, bird droppings and tree sap can damage the paint, especially in hot weather. Wash your vehicle as often as necessary to keep it clean. Take similar precautions if your vehicle is exposed to chemical industrial fallout. Paint damage resulting from fallout is not related to a defect in paint materials or workmanship and therefore is not covered by warranty. Ford, however, believes that continual improvement in customer satisfaction is a high priority. For this reason, Ford has authorized their dealers to repair, at no charge to the owner, the surfaces of new vehicles damaged by environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes first. Customers may be required to bring their vehicle in for inspection by a Ford representative.

File:rcinv.ex Update:Wed Jan 31 10:14:27 1996

%*[IN07200( ALL)04/95] *[IN07300( ALL)04/95] *[IN07400( ALL)04/95] *[IN07500( ALL)04/95] *[IN07600( ALL)04/95] *[IN07700( ALL)04/95] *[IN08100( ALL)04/95] %*[IN08200( ALL)04/95] *[IN08300( ALL)04/95]

%*[IN08400( ALL)04/95] *[IN08500( ALL)04/95]

*[IN08600( ALL)04/95] %*[IN08700( ALL)04/95]

Washing and Polishing Your Vehicle Wash the outside of your vehicle, including the underside, with a mild detergent. DO NOT: q Wash your vehicle with hot water q Wash your vehicle while it sits in direct

sunlight

q Wash your vehicle while the body is hot Polish your vehicle to remove harmful deposits and protect the finish. Cleaning Chrome and Aluminum Parts Wash chrome and aluminum parts with a mild detergent. Do not use steel wool, abrasive cleaners, fuel, or strong detergents. Cleaning Plastic Parts Some of your vehicle’s exterior trim parts are plastic. Clean with a tar and road oil remover if necessary. Use a vinyl cleaner for routine cleaning. Do not clean plastic parts with thinners, solvents or petroleum-based cleaners. If you have your vehicle rustproofed, remove oversprayed rustproofing with a tar and road oil remover. If rustproofing is not removed from plastic and rubber parts, it can cause deterioration.

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

%*[SR00500( ALL)04/95] *[SR00600( ALL)03/95]

*[SR00800( ALL)01/95] *[SR00900( ALL)01/95] *[SR01000( ALL)01/95] *[SR01100( ALL)01/95] *[SR01200( ALL)01/95] *[SR01300( ALL)01/95] *[SR02100( ALL)05/95]

*[SR02500( ALL)01/95]

%*[SR02600( ALL)05/95]

Safety Restraints

Important Safety Belt Information The use of safety belts helps to restrain you and your passengers in case of a collision. In most states and in Canada the law requires their use.

Safety belts provide best restraint when:

the seatback is upright

the occupant is sitting upright (not slouched)

the lap belt is snug and low on the hips

the shoulder belt is snug against the chest

the knees are straight forward

To help you remember to fasten your safety belt, a warning light may come on and a chime may sound. See Safety Belt Warning Light and Chime in the Warning Lights and Gauges chapter.

See the following sections in this chapter for directions on how to properly use these safety belts. Also see Safety Restraints for Children in this chapter for special instructions about using safety belts for children.

RWARNING

Make sure that you and your passengers wear safety belts. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR02700( ALL)03/95]

*[SR02801( ALL)01/95]

*[SR02901( ALL)05/95]

*[SR03001( ALL)05/95]

*[SR03200( ALL)05/95]

RWARNING

Never wear the shoulder belt under the arm. Never swing it around the neck over the inside shoulder. Never use a single belt for more than one person or across more than one seating position. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. Failure to follow these precautions could increase the risk and/or severity of injury in a collision.

RWARNING

Never drive or ride with a twisted or jammed safety belt. If you cannot untwist or unjam the safety belt, see the nearest qualified technician immediately.

RWARNING

To reduce the risk of serious injury in a collision, children should always ride with the seatback upright.

RWARNING

Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.

Lock the doors of your vehicle before driving to lessen the risk of the door coming open in a collision.

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR03700( ALL)05/95]

*[SR03800( ALL)01/95]

*[SR04100( ALL)05/95]

[SR04400( ALL)06/93]

*[SR04550( BCGV)01/95]

quarter page art:0010018-B

Combination Lap and Shoulder Belts While your vehicle is in motion, the combination lap and shoulder belt adjusts to your movement. However, if you brake hard, corner hard or if your vehicle receives an impact of 5 mph (8 km/h) or more, the lap and shoulder belt locks and helps reduce your forward movement.

After you get into your vehicle, close the door and lock it. Then adjust the seat to the position that suits you best.

To fasten the belt, pull the lap/shoulder belt from the retractor so that the shoulder portion of the belt crosses your shoulder and chest. Be sure the belt is not twisted. If it is, remove the twist. Insert the belt tongue into the proper buckle until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.

Fastening the front seat combination lap and shoulder belt

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR04600( BCGV)03/95]

one third page art:0010502-A

*[SR04675( ALL)05/95]

% [SR04676( GV)03/95]

[SR04679( GV)03/95]

*[SR04682( ALL)05/95]

*[SR04683( ALL)03/95] [SR04684( ALL)03/95]

Fastening the rear seat combination lap and shoulder belt

NOTE: Be sure to read and understand

Important Safety Belt Information at the beginning of this chapter.

Safety Belts for All Passenger Outboard Seating Positions

Your vehicle is equipped with a dual locking mode retractor on the shoulder belt portion of the combination lap/shoulder safety belt for the front and rear outboard passenger seats.

Dual locking mode retractors operate in two ways:

Vehicle sensitive (emergency) locking mode

In this operating mode, the shoulder belt retractor will allow the occupant freedom of movement, locking tight only on hard braking, hard cornering or impacts of approximately 5 mph (8 km/h) or more. The retractor can also be made to lock by pulling/jerking on the belt.

10

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

%*[SR04685( ALL)04/95] [SR04686( ALL)03/95]

[SR04687( ALL)03/95]

[SR04688( ALL)03/95]

*[SR04689( ALL)05/95]

*[SR04690( ALL)03/95]

*[SR04691( ALL)04/95]

*[SR04692( ALL)03/95] *[SR04693( ALL)03/95]

*[SR04694( ALL)05/95]

Automatic locking mode

In this operating mode, the shoulder belt retractor will be automatically locked and remain locked when the combination lap/shoulder safety belt is buckled, and does not allow the occupant freedom of movement. This mode provides the following: q A tight lap/shoulder belt fit on the occupant. q Child seat or infant carrier installation

restraint.

RWARNING

Never install a rear-facing child seat or infant carrier in the right front passenger seat.

This mode must be used when installing a child safety seat on the front passenger seat and rear outboard seats where dual locking retractors are provided.

To switch the retractor from the emergency locking mode to the automatic locking mode, perform the following steps:

1. Buckle the lap/shoulder combination belt.

2. Grasp the shoulder portion of the belt and

pull downward until all of the belt is extracted, and when allowed to retract, a clicking sound will be heard. At this time, the belt retractor is in the automatic locking mode (child restraint mode).

3. A clicking sound will contnue to be heard as

the belt is allowed to retract.

11

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR04695( ALL)03/95]

%*[SR04795( GV)05/95] *[SR04800( GV)04/95] *[SR04900( GV)01/95]

*[SR04940( GV)02/95]

[SR04950( GV)12/94]

NOTE: When the combination lap/shoulder

belt is unbuckled and allowed to retract completely, the retractor will switch back to the vehicle sensitive (emergency) locking mode. See the detailed instructions under Safety Seats for Children in this chapter. Shoulder Belt Height Adjustment

Driver and right front passenger

You can adjust the shoulder belt height to one of five (5) positions. To adjust, pinch the release button (see Figures 1 and 2) and slide it up or down until the belt rests across the middle of your shoulder. Release the button and make sure the adjuster is firmly in one of the five (5) positions.

RWARNING

If the shoulder belt is off your shoulder or on your upper arm, there is a greater risk of severe injury in a collision.

BE SURE THE BELT IS PROPERLY POSITIONED ON YOUR SHOULDER EACH TIME YOU USE THE BELT.

12

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR05200( GV)06/93]

half page art:0010701-A

[SR05300( GV)11/92]

The shoulder belt height adjuster

one third page art:0010702-A

*[SR05400( ALL)05/95]

The shoulder belt height adjuster

RWARNING

The lap belts should fit snugly and as low as possible around the hips, not around the waist.

13

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR05500( BCGV)03/95]

*[SR05600( ALL)05/95]

[SR05800( ALL)05/95]

[SR06000( GV)06/93]

[SR06300( GV)06/93]

quarter page art:0011166-A

*[SR06600( ALL)03/95]

RWARNING

All front and rear seat outboard occupants (including pregnant women) should wear lap and shoulder belts, for optimum protection in a collision.

RWARNING

Failure to follow these precautions could increase the risk and/or severity of injury in a collision. 1) Use the shoulder belt on the outside shoulder only. Never wear the shoulder belt under the arm. 2) Never swing it around your neck over the inside shoulder. 3) Never use a single belt for more than one person.

To unfasten all the belts:

1. Push the release button in the center of the

buckle. This allows the tongue to unlatch from the buckle.

Unfastening the outboard lap/shoulder belts

2. While the belt retracts, guide the tongue to its stowed position. If you do not guide the tongue, it may strike you or part of the vehicle.

14

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR09400]

*[SR09500( GV)05/95]

*[SR09701( BCGV)05/95]

%*[SR09801( BCGV)05/95]

*[SR09901( BCGV)05/95]

*[SR10300( BCGV)05/95]

[SR10500( GV)11/92]

[SR10600( GV)11/92]

quarter page art:0010022-A

Lap Belts — Center Seating Position The lap belts in the center of the front and rear seats do not adjust automatically. You must adjust them to fit snugly and as low as possible around your hips. Do not wear them around your waist.

Pull the belt across your hips and insert the tongue into the correct buckle on your seat until you hear a snap and feel it lock. Make sure the buckle is securely fastened.

If you need to lengthen the belt, unfasten it and tip the belt tongue at a right angle to the belt. Pull the belt tongue over your lap until it reaches the buckle.

If you need to shorten the belt, pull on the loose end of the webbing until the belt fits snugly.

To unfasten the belt, push the release button on the buckle. This allows the tongue to unlatch from the buckle.

Because the center lap belts do not have retractors, they should be shortened and fastened when not in use.

Unfastening center lap safety belts

15

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

%*[SR17500( ALL)05/95] *[SR17600( ALL)05/95]

*[SR17700( ALL)05/95]

*[SR17705( ALL)05/95]

[SR17710( ALL)05/95] *[SR17720(ALL )05/95]

%*[SR17730( ALL)05/95]

Safety Belt Extension Assembly For some people, the safety belt may be too short even when it is fully extended. You can add about eight inches (20 cm) to the belt length with a safety belt extension assembly (part number 611C22). Safety belt extensions are available at no cost from your dealer.

RWARNING

Failure to follow these instructions will affect the performance of the safety belts and increase the risk of personal injury.

Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended. Do not use extension to change the fit of the shoulder belt across the torso. Safety Belt Maintenance Check the safety belt systems periodically to make sure that they work properly and are not damaged.

All safety belt assemblies, including retractors, buckles, front seat belt buckle support assemblies (slide bar) (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after any collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and a qualified technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced. Safety belt assemblies not in use

16

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

%*[SR17740( ALL)05/95] *[SR17780( ALL)05/95]

*[SR17800( ALL)04/95]

*[SR18200( ALL)04/95]

*[SR18400( ALL)02/95] *[SR18425( ALL)11/93]

*[SR18450( ALL)05/95]

during a collision should also be inspected and replaced if either damage or improper operation is noted. Cleaning the Safety Belts

Clean the safety belts with any mild soap solution that is recommended for cleaning upholstery or carpets. Do not bleach or dye the belt webbing because this may weaken it. Air Bag Supplemental Restraint System (SRS) The driver and right front passenger air bags are Supplemental Restraint Systems (SRS), provided at these seating positions in addition to the lap/shoulder belt, and are designed to supplement the protection provided to properly belted occupants in moderate to severe frontal collisions. The supplemental air bag system does not provide restraint to the lower body. The Importance of Wearing Safety Belts

RWARNING

Safety belts must be worn by all vehicle occupants to be properly restrained and help reduce the risk of injury in a collision.

RWARNING

All occupants of the vehicle, including the driver, should always wear their safety belts, even when an air bag Supplemental Restraint System is provided.

17

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR18500( ALL)01/95]

*[SR18600( ALL)01/95]

*[SR18700( ALL)01/95]

*[SR18800( ALL)01/95]

*[SR18900( ALL)01/95]

%*[SR19100( ALL)01/95] *[SR19200( ALL)05/95]

*[SR19230( ALL)05/95]

*[SR19235( ALL)05/95]

There are four very important reasons to use safety belts even with an air bag system. Use your safety belts to:

help keep you in the proper position (away from the air bag) when it inflates

reduce the risk of harm in rollover, side or rear impact collisions, because an air bag is not designed to inflate in such situations

reduce the risk of harm in frontal collisions that are not severe enough to activate the supplemental air bag

reduce the risk of being thrown from your vehicle

The Importance of Being Properly Seated

In a collision, the air bag must inflate extremely fast to help provide additional protection for you. In order to do this, the air bag must inflate with considerable force. If you are not seated in a normal riding position with your back against the seatback, the air bag may not protect you properly and could possibly hurt you as it inflates.

RWARNING

If a passenger is not properly seated and restrained, an inflating air bag could cause serious injury.

RWARNING

Rear-facing infant seats should never be placed in the front seat.

18

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR19240( ALL)06/09]

*[SR19260( ALL)05/95]

%*[SR19300( ALL)05/95]

*[SR19325( GV)05/95]

In rear-facing infant seats, the infant’s head is closer to the air bag. The force of the rapidly inflating air bag could push the top of the rear-facing seat against the vehicle seatback, center console (if so equipped), or center armrests (if so equipped). REAR-FACING INFANT SEATS MUST ALWAYS BE SECURED IN THE REAR SEAT, and other child safety seats and infant seats should be secured in the rear seat whenever possible.

Your vehicle is equipped with a right front passenger air bag. Air bags deploy with great force, faster than the blink of an eye. Front passengers, especially children and small adults, must never sit on the front edge of the seat, stand near the glove compartment of the instrument panel, or lean over near the air bag cover when the vehicle is moving. All occupants should sit with their backs against the seatback, move the seat to the most rearward position if possible and use the safety belts. Children weighing less than 40 lbs. (18 kg) always should use child or infant seats.

RWARNING

When using forward-facing child seats move the passenger seat as far back from the instrument panel as possible. NEVER SECURE REAR-FACING INFANT SEATS IN THE FRONT SEAT.

THE FORCE OF THE RAPIDLY INFLATING PASSENGER AIR BAG COULD PUSH THE TOP OF THE REAR-FACING SEAT AGAINST THE VEHICLE SEATBACK, ARMRESTS OR CONSOLE. REAR-FACING INFANT SEATS MUST ALWAYS BE SECURED IN THE REAR SEAT.

19

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR19400( ALL)05/95]

*[SR19405( ALL)05/95]

*[SR19410( ALL)05/95]

%*[SR19500( ALL)01/95]

[SR19650( ALL)05/95]

RWARNING

Do not place objects or mount equipment on or near the air bag cover on the steering wheel or in front seat areas that may come in contact with a deploying air bag. Failure to follow this instruction may increase the risk of personal injury in the event of a collision.

For additional important safety information on the proper use of seat belts, child seats, and infant seats, please read the other sections of this part of the Owner Guide, especially sections entitled Safety Belts for Children and Safety Seats for Children.

For further information about the proper mounting of equipment in the front seat of this vehicle, please refer to Ford’s brochure entitled Some Important Information About Air Bag Supplemental Restraint System which can be obtained by calling Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602. How the Air Bag Supplemental Restraint System Operates

The driver air bag is in the center of the steering wheel. The right front passenger seat air bag is in the upper right hand section of the instrument panel ledge above the glove compartment. Both air bags are designed to stay out of sight until they are activated.

20

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR20200( GV)10/94]

half page art:0010671-G

*[SR20800( ALL)05/95]

*[SR20930( ALL)05/95]

The location of the air bag and warning labels

If a collision occurs, the sensors sense the severity of the impact and activates the air bags if necessary. The air bag system is designed to deploy in frontal and front-angled collisions more severe than hitting a parked vehicle (of similar size and weight) head-on at about 28 mph (45 km/h). Because the system senses the crash severity rather than vehicle speed, some frontal collisions at speeds above 28 mph (45 km/h) will not inflate the air bag.

The whole inflation and deflation process takes place in a matter of seconds.

21

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR20960( ALL)05/95]

*[SR21110( ALL)03/93]

half page art:0011063-A

RWARNING

Air bag system components get hot after inflation. Do not touch them after inflation.

Inflated driver side air bag

22

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR21130( ALL)10/94]

half page art:0011064-A

*[SR22200( ALL)05/95]

*[SR22210( ALL)05/95]

Inflated right front passenger side air bag

RWARNING

If the air bag is inflated, THE AIR BAG WILL NOT FUNCTION AGAIN AND MUST BE REPLACED IMMEDIATELY. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.

The air bag system uses a readiness light and a tone to indicate the condition of the system. The readiness light is in the instrument cluster. When you turn the ignition to the ON position, this light will illuminate for approximately six (6) seconds and then turn off. This indicates that the system is operating normally. NOTE: Maintenance of the air bag system is not required.

23

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

%*[SR22220( ALL)05/95]

[SR22225( ALL)05/95]

[SR22230( ALL)05/95]

[SR22240( ALL)05/95] *[SR22250( ALL)05/95]

*[SR22260( ALL)05/95]

%*[SR22300( ALL)05/95] *[SR22400( ALL)05/95]

%*[SR23500( ALL)05/95] *[SR23600( ALL)02/95]

A problem with the system is indicated by one or more of the following:

the readiness light will either flash or stay lit, or it will not light immediately after the ignition is turned on, or a group of five beeps will be heard.

If any of these things happen, have the air bag system serviced at your Ford or Lincoln-Mercury dealer immediately. Unless serviced, the air bag supplemental restraint system may not function properly in the event of a collision.

RWARNING

Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer.

Disposal of air bags or air bag equipped vehicles For disposal of air bags or air bag equipped vehicles, see your local Ford or Lincoln-Mercury dealer. Air bags MUST be disposed of by qualified personnel. Safety Restraints for Children In the U.S. and Canada, you are required by law to use safety restraints for children. If small children ride in your vehicle — this generally includes children who are four years old or younger and who weigh 40 pounds (18 kg) or less — you must put them in safety seats that are made specially for children. Safety belts alone do not provide maximum protection for these children. Check your local and state laws for specific requirements.

24

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR23700( ALL)05/95]

*[SR23800( ALL)05/95]

*[SR23900( ALL)05/95]

*[SR24000( ALL)05/95]

*[SR24100( ALL)05/95]

RWARNING

Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.

RWARNING

Passengers should not be allowed to ride in the cargo area. Persons not riding in a seat with a fastened seat belt are much more likely to suffer serious injury in a collision. Cargo should always be secured to prevent it from shifting and causing damage to the vehicle or harm to passengers.

When possible, put children in the rear seat of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating positions.

RWARNING

Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.

RWARNING

Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them.

25

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR24200( ALL)05/95]

%*[SR24250( ALL)05/95]

%*[SR25100( ALL)01/95] *[SR25200( ALL)05/95]

% [SR25225( ALL)04/95]

*[SR25250( ALL)02/95]

RWARNING

Never leave a child unattended in your vehicle.

RWARNING

When using forward-facing child seats move the passenger seat as far back from the instrument panel as possible. NEVER SECURE REAR-FACING INFANT SEATS IN THE FRONT SEAT.

Safety Seats for Children

Use a safety seat that is recommended for the size and weight of the child. Always follow the safety seat manufacturer’s instructions when installing and using the safety seat.

Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps see your Ford or Lincoln-Mercury dealer.

When installing a child safety seat, be sure to use the correct safety belt buckle for that seating position, and make sure the tongue is securely fastened in the buckle.

26

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR25275( ALL)05/95]

%*[SR25300( ALL)05/95]

*[SR25350( ALL)05/95]

*[SR25400( ALL)05/95]

*[SR25500( ALL)05/95]

Children weighing less than 40 lbs. (18 kg) should use child or infant seats. Forward facing child seats must have the passenger seat moved as far back from the instrument panel as possible.

RWARNING

REAR-FACING INFANT SEATS SHOULD NEVER BE USED IN THE FRONT SEAT. REAR-FACING INFANT SEATS MUST ALWAYS BE PLACED IN THE REAR SEAT. Failure to follow these instructions could result in serious injury.

All child restraint systems are designed to be secured in vehicle seats by lap belts or by the lap portion of a lap-shoulder belt.

RWARNING

If you do not properly secure the safety seat, the child occupying the seat may be injured during a collision or sudden stop. An unsecured safety seat could also injure other passengers.

RWARNING

Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.

27

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

% [SR31857( GV)03/95]

[SR31861( ALL)03/95]

[SR31865( ALL)03/95]

*[SR31870( ALL)04/95]

*[SR31875( ALL)04/95]

*[SR31880( ALL)04/95]

half page art:0011238-B

Installing Safety Seats in the Front and Rear Outboard Passenger Seating Positions

For seating positions equipped with a dual locking mode retractor, use the following procedure.

If you choose to install a child safety seat or infant carrier in the front seating positions, move vehicle seat as far back as possible.

1. Position the child seat in the center of the

passenger seat.

2. Pull down on shoulder belt, then grasp

shoulder belt and lap belt together. Figure 1.

28

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR31885( ALL)04/95]

*[SR31890( ALL)04/95]

half page art:0011239-B

3. While holding the shoulder and lap belt

portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. See Figure 2. Be sure that the belt webbing is not twisted.

Routing the lap/shoulder belt

29

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR31893( ALL)04/95]

*[SR31895( ALL)04/95]

half page art:0011240-B

4.

Insert the belt tongue into the buckle for that seating position until you hear and feel the latch engage. Figure 3. Make sure tongue is latched securely to buckle by pulling on tongue.

Buckling the belt

30

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR31900( ALL)04/95]

*[SR31902( ALL)04/95]

*[SR31905( ALL)04/95]

half page art:0011241-A

*[SR31910( ALL)04/95]

5. Grasp the shoulder portion of the belt and

pull downward until all of the belt is extracted and a click is heard. At this time, the retractor is in the automatic locking mode (child seat restraint mode). Figure 4.

NOTE: The dual-locking mode retractor must

be in the automatic locking mode to properly restrain a child.

Setting the retractor to automatic locking mode

6. Allow the belt to retract. Pull up on the

shoulder webbing. A clicking sound will be heard as the belt retracts. This indicates the retractor is in the automatic locking mode. Push down on the child seat while you pull up on the belt to remove any slack in the belt. Figures 5 and 6.

31

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR31915( ALL)04/95]

half page art:0011242-A

*[SR31920( ALL)04/95]

half page art:0011243-A

32

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR31925( ALL)04/95]

*[SR31930( ALL)04/95]

half page art:0011244-A

7. Before placing the child in the child seat, forcibly tilt the seat from side to side, and tug it forward to make sure that the seat is securely held in place, Figure 7.

*[SR31935( ALL)04/95]

Checking that the seat is secure

8. Double check that the retractor is in the

automatic locking mode. Try to pull more belt out of the retractor. If you cannot, the belt is in the automatic locking mode, Figure 8.

33

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

*[SR31940( ALL)04/95]

half page art:0011245-B

*[SR31945( ALL)04/95]

% [SR32150( BCGV)03/95]

[SR32160( BCGV)03/95]

[SR32170( BCGV)03/95]

[SR32180( BCGV)03/95]

Checking the retractor

9. Check to make sure that the child seat is properly secured prior to each use. If the retractor is not locked, repeat steps 4
through 7.

Installing a Child Safety Seat at the Rear Center Seating Position with Adjustable Lap Belt

1. Lengthen the lap belt. To lengthen the belt,

hold the tongue so that its bottom is perpendicular to the direction of webbing while sliding the tongue up the webbing.

2. Place the child safety seat in the center

seating position.

3. Route the tongue and webbing through the

child seat according to the child seat manufacturer’s instructions.

34

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR32190( BCGV)03/95]

[SR32200( BCGV)03/95]

[SR32210( BCGV)03/95]

%*[SR38300( ALL)05/95] *[SR38400( ALL)05/95]

*[SR38500( ALL)05/95]

*[SR38600(MBCGV )05/95]

4.

Insert the belt tongue into the proper buckle for the center seating position until you hear a snap and feel it latch. Make sure the tongue is securely fastened to the buckle by pulling on tongue.

5. Push down on the child seat while pulling on the loose end of the lap belt webbing to tighten the belt.

6. Before placing the child into child seat,

forcibly tilt the child seat from side-to-side and in forward direction to ensure that the seat is held securely in place. If the child seat moves excessively, repeat steps 5
through 6, or properly install the child seat in a different position.

Safety Belts for Children Children who are too large for child safety seats should always wear safety belts. (See instructions with your child seat, or contact its manufacturer, to determine maximum size of child that will safely fit in the seat.)

RWARNING

If safety belts are not properly worn and adjusted as described, the risk of serious injury to the child in a collision will be much greater.

If the shoulder belt position of one of the lap and shoulder belts can be positioned so that it does not cross or rest in front of the child’s face or neck, the child should wear the lap and shoulder belt. Moving the child closer to the center of the vehicle may help provide a good shoulder belt fit.

35

File:rcsrv.ex Update:Wed Jan 31 10:17:50 1996

[SR38800( GV)12/94]

*[SR38830( ALL)04/95]

*[SR38860( ALL)04/95]

*[SR38900( ALL)05/95]

*[SR39000( ALL)05/95]

RWARNING

If the shoulder belt cannot be properly positioned, the child should sit in the center rear seat and use the lap belt or, if that seat is unavailable, in the center front seat and use the lap belt.

To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child. A belt-positioning booster should be used if the shoulder belt rests in front of the child’s face or neck, or if the lap belt does not fit snugly on both thighs, or if the thighs are too short to let the child sit all the way back on the seat cushion when the lower legs hang over the edge of the seat cushion. You may wish to discuss the specific needs of your child with your pediatrician.

RWARNING

Do not use a belt-positioning booster with a lap-only belt.

Lap belts and the lap belt portion of lap and shoulder belts should always be worn snugly and below the hips, touching the child’s thighs.

RWARNING

To reduce the risk of serious injury in a collision, children should always ride with the seatback upright.

36

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

*[LG00400( ALL)01/95]

[LG00500( BCGV)05/94]

[LG00600( GV)05/94]

[LG00710( GV)06/92]

[LG00950( GV)05/92]

Warning Lights and Gauges

The instrument panel (dashboard) on your vehicle is divided into several different sections. The illustrations on the following pages show the major parts of the instrument panel that are described in this chapter. Some items shown may not be on all vehicles. In your vehicle, the warning lights and gauges are grouped together in the instrument cluster and the indicator lamp module. Your vehicle is equipped with one of the following clusters:

a mechanical cluster an electronic cluster

47

F

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

*[LG02700( BCGV)06/94] *[LG02800( BCGV)06/93]

%*[LG02900( ALL)03/95] *[LG03000( ALL)03/95]

[LG03035( GV)05/95]

one inch art:0010681-C

[LG03100( ALL)01/95]

*[LG03200( ALL)05/95]

The Mechanical Cluster The following warning lights and gauges are on the mechanical cluster. All of the warning lights and gauges alert you to possible problems with your vehicle. Some of the lights listed are optional. The following sections detail what each of these indicators means. Brake System Warning Light The warning light for the brakes can show two things — that the parking brake is not fully released, or that the brake fluid level is low in the master cylinder reservoir. If the fluid level is low, the brake system should be checked by a qualified service technician.

This light comes on when the parking brake is set, or if it is not set, it comes on briefly when you turn the ignition key to START. It normally goes off shortly after the engine starts and you release the parking brake. If the light stays on after you have fully released the parking brake, have the hydraulic brake system serviced.

RWARNING

The BRAKE light indicates that the brakes may not be working properly. Have the brakes checked immediately.

49

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

% [LG03475( ALL)05/94]

[LG03500( ALL)05/94]

*[LG03505( BCGV)01/95]

[LG03680( ALL)05/95]

one inch art:0011194-B

Anti-Lock Brake System Light (If equipped) This warning light will go on each time you start your vehicle. If it remains on for longer than five seconds, you should shut off your engine and restart. If the anti-lock brake light stays on, this indicates that the anti-lock feature is disabled and should receive immediate attention by a qualified service technician. Normal braking is not affected unless the brake warning light is also lit. The Anti-Lock Brake System has self-check capabilities. As previously described, the system turns on the anti-lock light each time you start your engine. After the engine is started and the anti-lock light is out, the system performs another test the first time the vehicle reaches 14 mph (22 km/h). The system turns on the Anti-Lock Brake System (ABS) pump motor for approximately 1/2 second. At this time a mechanical noise may be heard. This is a normal part of the self-check feature. If a malfunction is found during this check the anti-lock light will come on.

50

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

*[LG03700( ALL)05/95]

[LG03800( ALL)05/95]

%*[LG04300( ALL)04/95] *[LG04305( ALL)03/95]

*[LG04316( GV)03/95]

*[LG04323( GV)03/95]

*[LG04327( GV)03/95]

[LG04600( ALL)05/92]

one inch art:0010118-A

RWARNING

If the anti-lock brake system warning light remains on or comes on while driving, have the braking system checked by a qualified service technician as soon as possible.

NOTE: If a fault occurs in the anti-lock

system, and the brake warning light is not lit, the anti-lock system is disabled but normal brake function remains operational.

Safety Belt Warning Light and Chime This warning light and chime remind you to fasten your safety belt. The following conditions will take place:

If the driver’s safety belt is not buckled when the ignition is turned to the ON position, the light will turn on for 1 to 2 minutes and the chime will sound for 4 to 8 seconds. If the driver’s safety belt is buckled while the light is on or the chime is sounding, both the light and the chime will turn off. If the driver’s safety belt is buckled before the ignition is turned to the ON position, neither the light nor the chime will turn on.

51

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

%*[LG04610( ALL)01/95] [LG04620( ALL)05/94]

[LG04630( ALL)05/94]

[LG04640(M GV)05/95]

one inch art:0010578-A

%*[LG04700( ALL)01/95] *[LG04800( ALL)03/95]

[LG04900( ALL)05/92]

one inch art:0010119-A

*[LG05100( ALL)02/95]

Air Bag Readiness Light The air bag system uses a readiness light to indicate the condition of the system. If the system is functioning properly, the light will stay on for 6 seconds when the ignition switch is turned to the ON position. If there is a problem with the system, two things may happen: the readiness light will either flash or stay lit up, or you will hear a beeping sound. If either of these things happen, have the air bag system serviced at your Ford or Lincoln-Mercury dealer immediately.

Charging System Light This light indicates that your battery is not being charged and that you need to have the electrical system checked.

This light comes on every time you turn the ignition to the ON or START position (engine off). The light should go off when the engine starts and the alternator begins to charge.

52

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

*[LG05200( ALL)01/95]

%*[LG05205( BCGV)05/95] [LG05210( ALL)06/93]

one inch art:0010730-A

*[LG05220( BCGV)01/95]

*[LG05230( ALL)04/95]

If the light stays on or comes on when the engine is running, have the electrical system checked as soon as possible. Overdrive Off Indicator

This light tells you that the Transmission Control Switch (TCS) on the gearshift lever has been pushed. When the light is on, the transmission will not shift into overdrive. Depressing the button on the shifter will return the vehicle to “overdrive on” mode. The transmission will be in the “overdrive on” mode when the vehicle is started even if the O/D OFF mode was selected when the vehicle was last shut off. NOTE: If the light does not come on when the TCS is depressed or if the light flashes when you are driving, have your vehicle serviced at the first opportunity. If this condition persists, damage could occur to the transmission.

53

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

%*[LG07200( ALL)01/95] *[LG07300( ALL)03/95]

[LG07400( ALL)05/92]

one inch art:0010125-A

% [LG09200( GV)05/92]

[LG09300( GV)03/95]

[LG09405( GV)05/94]

one inch art:0010684-A

High Beam Light This light comes on when the headlamps are turned to high beam or when you flash the lights.

Low Fuel Alert Light This light comes on when your fuel gauge indicates between 1/8 and 1/16 of a tank. Your car must be turned to ON for this light to come on.

54

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

% [LG09410( GV)12/91]

[LG09420( GV)05/92]

[LG09430( GV)05/92]

one inch art:0010643-A

[LG09440( GV)05/92]

[LG09450( GV)05/92]

[LG09460( GV)05/92]

%*[LG11005( ALL)03/95] *[LG11015( ALL)03/95]

*[LG11020( ALL)03/95]

Air Suspension Light (If equipped) This light tells you if the air suspension needs repair or if the air suspension switch (in the trunk on the right side) is OFF.

Normally, the light will glow momentarily as you turn the ignition key to the ON position. If it glows continuously: 1. Safely pull off the road as soon as possible. Turn the ignition key from ON to OFF and ON again. If the light still glows, check to see if the air suspension switch is OFF. If it is OFF, push the switch ON. If it is ON, push the switch OFF and have the system checked as soon as possible.

2.

Check Engine Warning Light The Powertrain On-Board Diagnostic II (OBD II) system consists of the hardware and software necessary to monitor the operation of the powertrain. The OBD II system is designed to check the function of the vehicle’s powertrain control system during normal operation. If an emission problem is detected, the Check Engine Warning Light (in the cluster) is turned on. Modification or additions to the vehicle may cause incorrect operation of the OBD II system. Additions such as burglar alarms, cellular phones, and CB radios must be carefully

55

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

[LG11045( GV)05/94]

one inch art:0010134-A

*[LG11050( ALL)03/95]

*[LG11055( ALL)04/95]

*[LG11060( ALL)03/95]

*[LG11065( ALL)03/95]

installed. Do not install these devices by tapping into or running wires close to powertrain control system wires or components.

The light comes on briefly when you turn the ignition key to ON, but it should turn off when the engine starts. If the light does not come on when you turn the ignition to ON or if it comes on and stays on when you are driving, have your vehicle serviced as soon as possible. This indicates a possible problem with one of the vehicle’s emission control systems. You do not need to have your vehicle towed in. If the light turns on and off at one (1) second intervals while you are driving the vehicle, it means that the engine is misfiring. If this condition persists, damage could occur to the engine or catalytic convertor. Have your vehicle serviced at the first opportunity. You do not need to have your vehicle towed in. If the light turns on and off on rare occasions while you are driving, it means that a malfunction occurred and the condition corrected itself. An example of a condition which corrects itself occurs when an engine running out of fuel begins to misfire. In this case, the Check Engine Warning Light may turn on and will then set a Diagnostic Trouble Code indicating that the engine was misfiring while the last of the fuel was being consumed. After refueling, the Check

56

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

*[LG11075( ALL)03/95]

*[LG11100( BCGV)05/95]

*[LG11200( ALL)05/95]

%*[LG12910( ALL)04/95] *[LG12920( ALL)05/95] [LG12950( ALL)06/93]

one inch art:0010525-A

Engine Warning Light will turn off after the vehicle has completed three consecutive warm up cycles without a misfire condition occurring. A warm up cycle consists of engine start from a cold condition (engine at ambient temperature) and running until the engine reaches normal operating temperature. On the fourth engine start up, the Check Engine Warning Light will turn off as soon as the engine begins to crank. It is not necessary to have the engine serviced. Under certain conditions, the Check Engine Warning Light may come on if the fuel cap is not properly installed. If the Check Engine Warning Light comes on and you suspect that the fuel cap is not properly installed, pull off the road as soon as it is safely possible and turn off the engine. Remove and replace the fuel cap, making sure it is properly seated. After completing the three consecutive warm up cycles and on the fourth engine start up, the Check Engine Warning Light should turn off. If the light does not go off after the fourth engine restart, have your vehicle serviced by your dealer or a qualified technician. Turn Signal Indicator Lights The turn signal arrow will flash to indicate the direction in which you are going to be turning.

57

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

%*[LG13000( ALL)01/95] [LG13050( GV)05/95]

Fuel Gauge

one third page art:0010695-A

[LG13100( ALL)08/93]

[LG13150( ALL)08/93]

*[LG13200( ALL)08/93]

%*[LG13400( ALL)01/95] *[LG13550( ALL)03/95]

[LG13600( ALL)03/94]

The fuel gauge The fuel gauge displays approximately how much fuel is in the fuel tank only when the ignition switch is ON. For proper fuel gauge indication after adding fuel, turn the ignition switch OFF while refueling the vehicle. The fuel gauge indicator may vary slightly when the vehicle is in motion. The most accurate reading is obtained with the vehicle on level ground. With ignition switch OFF, the fuel gauge indicator may drift from the ignition switch ON position. Engine Coolant Temperature Gauge This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level or mixture, the gauge indication will not be accurate. The pointer moves from the C (cold) mark into the NORMAL band as your engine coolant warms up. Under normal driving conditions, the pointer should stay in the NORMAL band. It is acceptable for the pointer to fluctuate within the NORMAL band under normal driving

58

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

[LG13650( ALL)05/94]

% [LG13740( GV)05/94]

one third page art:0010697-C

*[LG14100( ALL)01/95] *[LG14200( ALL)03/95] *[LG14300( ALL)01/95] *[LG14400( ALL)05/95]

*[LG14500( ALL)04/95]

*[LG14600( ALL)01/95]

conditions, and under certain driving conditions such as, heavy stop and go traffic, or driving up hills in hot weather, for the pointer to indicate at the top of the NORMAL band. If, under any circumstances, the pointer moves above the NORMAL band, the engine is overheating and continued operation may cause engine damage.

The engine coolant temperature gauge If your engine coolant overheats: 1. Pull off the road as soon as safely possible. 2. Turn off the engine. 3. Let the engine cool. DO NOT REMOVE COOLANT SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.

4. Check the coolant level following the

instructions on checking and adding coolant to your engine, see Engine Coolant in the Index. If you do not follow these instructions, you or others could be injured.

If the coolant continues to overheat, have the coolant system serviced.

59

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

%*[LG14800( ALL)01/95] *[LG14900( ALL)01/95] %*[LG15000( ALL)01/95] *[LG15100( ALL)01/95] %*[LG15200( ALL)11/94] *[LG15300( ALL)03/93]

*[LG15350( ALL)01/95]

% [LG16220( ALL)05/94] *[LG16225( ALL)05/94] *[LG16230( ALL)05/94]

*[LG16260( ALL)05/94]

Speedometer The speedometer tells you how many miles (kilometers) per hour your vehicle is moving. Odometer The odometer tells you the total number of miles (kilometers) your vehicle has been driven. Trip Odometer If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply set the trip odometer to zero by pressing the reset button firmly when beginning the distance you wish to measure. Since the trip odometer displays distance independent of the odometer it will not always advance to the next mile (kilometer) at the same time as the odometer. Battery Voltage Gauge (If Equipped) This gauge shows you the battery voltage when the ignition key is in the ON position. If the battery is operating under cold weather conditions, the pointer may indicate in the upper range of the NORMAL band while the battery is charging. If you are running electrical accessories (when the engine is off, or idling at a low speed), the pointer may move toward the lower end of the NORMAL band. If it stays outside the NORMAL band, have your vehicle’s electrical system checked as soon as it is safely possible.

60

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

[LG16291( GV)05/94]

one third page art:0010699-C

%*[LG16300( ALL)05/94] [LG16500( ALL)05/94]

*[LG16600( ALL)03/95] *[LG16700( ALL)01/95] *[LG16800( ALL)04/95] [LG16900( ALL)05/94]

[LG17000( ALL)05/94]

4.

The battery voltage gauge Engine Oil Pressure Gauge This gauge indicates the engine oil pressure, not the oil level. However, if your engine’s oil level is low, it could affect the oil pressure. With the engine running, the pointer should move into the NORMAL band. If the pointer drops below the NORMAL band while the engine is running, you have lost oil pressure and continued operation will cause severe engine damage. If you lose engine oil pressure: 1. Pull off the road as soon as safely possible. 2. Shut off the engine immediately or severe

engine damage could result.

3. Check the engine’s oil level, following the

instructions on checking and adding engine oil, see the Engine Oil in the Index. If you do not follow these instructions, you or others could be injured. To assure an accurate reading, your car should be on level ground. If the level is low, add oil as necessary before you start the engine again. Do not overfill. Do not operate the engine if the pointer is below the NORMAL band, regardless of the oil level. Contact your nearest dealer for further service actions.

61

File:rclgv.ex Update:Wed Jan 31 10:21:13 1996

[LG17200( ALL)05/94]

%*[LG23800( GV)01/95] *[LG23900( GV)01/95]

*[LG24000( GV)01/95]

*[LG24100( GV)01/95] *[LG24300( GV)01/95]

For more information about adding oil, see Engine Oil Recommendations in the Index. The Electronic Cluster The electronic cluster works only when your ignition is in the ON position. Each time you start your vehicle, the displays go through a self-test by flashing on and off once before the actual readings are displayed. (Neither the turn signals nor the high beam indicator light will flash like the other indicators do for the
