2004 Ford Crown Victoria Owners Manual

Table of Contents

Introduction

Instrument Cluster

Warning and control lights Gauges

Entertainment Systems

AM/FM stereo cassette with CD AM/FM stereo with CD AM/FM stereo AM/FM stereo cassette CD changer

Climate Controls

Manual heating and air conditioning Electronic automatic temperature control Rear window defroster

Lights

Headlamps Turn signal control Bulb replacement Driver Controls

Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Message center

Locks and Security

Keys Locks Anti-theft system

10

10
15
20

20
23
26
28
30
34

34
35
37
38

38
40
41
47

47
48
57
58
60
68
73

73
73
75

Table of Contents

Seating and Safety Restraints

Seating Safety restraints Air bags Child restraints

Driving

Starting Brakes Traction control Air suspension Transmission operation Vehicle loading Trailer towing Recreational towing

Roadside Emergencies

Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing

Customer Assistance

Reporting safety defects (U.S. only)

Cleaning

87

87
91
105
112
124

124
128
131
133
134
139
141
144
145

145
146
146
147
155
161
167
168

176
177

Maintenance and Specifications

Engine compartment Engine oil Battery Fuel information Air filter(s) Tire Information Part numbers Refill capacities Lubricant specifications

Accessories

Index

Table of Contents

183

185
186
190
198
212
214
226
227
228
235

237

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Copyright © 2003 Ford Motor Company

Introduction

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to

the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com • In Canada: www.ford.ca • In Australia: www.ford.com.au • In Mexico: www.ford.com.mx Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on this Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the safety switch will automatically cut off the fuel supply to the

engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed to allow parts to adjust themselves to other parts. Drive your new vehicle at least 500 miles (800 km) before towing a trailer. Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

SPECIAL NOTICES

Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide. Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle. Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: • how various systems in your vehicle were operating; • whether or not the driver and passenger seatbelts were buckled; • how far (if at all) the driver was depressing the accelerator and/or the • how fast the vehicle was traveling; and • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

brake pedal;

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.

Notice to owners of natural gas fueled vehicles Before you drive your vehicle, be sure to read the Dedicated Natural Gas Vehicle supplement. This book contains important operation and maintenance information.

Notice to owners of Severe Duty vehicles Before you drive your vehicle, be sure to read the Severe Duty Owner’s Guide supplement. This book contains important operation and maintenance information.

MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner’s Guide for all other required information and warnings.

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

See Owner’s Guide

Fasten Safety Belt

Air Bag-Front

Air Bag-Side

Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Child Seat Lower Anchor

Brake System

Brake Fluid - Non-Petroleum Based

Traction Control

AdvanceTrac娂

Master Lighting Switch

Hazard Warning Flasher

Fog Lamps-Front

Fuse Compartment

Fuel Pump Reset

Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Vehicle Symbol Glossary

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm

Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot

Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas

Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

MAX MIN

Emission System

Engine Air Filter

Passenger Compartment Air Filter

Jack

Check fuel cap

Low tire warning

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Instrument Cluster

WARNING LIGHTS AND CHIMES

Standard instrument cluster

Optional instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately. Check engine: The Check engine indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine

CHECK ENGINE

10

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon warning light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter. Brake system warning light: • Standard instrument cluster

CHECK FUEL CAP

BRAKE

• Optional instrument cluster To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.

Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may

occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

11

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

ABS

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated. Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected. Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt, refer to the Seating and Safety Restraints chapter. Charging system: Illuminates when the battery is not charging properly.

AIR BAG

Engine oil pressure (if equipped): Illuminates when the oil pressure falls below the normal range. Check the oil level and add oil if needed. Refer to Engine oil in the Maintenance and specifications chapter. Traction control娂 AdvanceTrac active (if equipped): Illuminates when the Traction control娂 system is active. It will be lit for a minimum of four seconds or for the duration of the Traction Control娂 event, refer to the Driving chapter for more information. Air suspension (if equipped): • Standard instrument cluster

AIR SUSP

12

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

• Optional instrument cluster Illuminates when the air suspension is turned OFF, the load limit is exceeded or the air suspension system requires servicing.

Low fuel (if equipped): Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter for more information). O/D off: • Standard instrument cluster

Instrument Cluster

CHECK

AIR SUSPENSION OVERDRIVE OFF

DOOR AJAR

LOW WASHER FLUID TRUNK AJAR

km MILES /GAL LTR/100 km

LOW FUEL

O/D OFF

CHECK

AIR SUSPENSION OVERDRIVE OFF

• Optional instrument cluster Illuminates when the overdrive function of the transmission has been turned OFF using the transmission control switch (TCS), refer to the Driving chapter. If the light flashes steadily, have the system serviced immediately. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on.

LOW WASHER FLUID TRUNK AJAR

DOOR AJAR

km MILES /GAL LTR/100 km

13

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

SPEED CONTROL

MESSAGE CENTER INDICATOR LIGHTS (IF EQUIPPED) Speed control: This light comes on when either the SET/ACCEL or RESUME controls are pressed. It turns off when the speed control OFF control is pressed, the brake is applied or the ignition is turned to the OFF position. Door ajar: Illuminates when one of the doors is not completely shut and the ignition is turned to ON. With the ignition ON, this light will flash six times (if a door is open). With the ignition in RUN position, a tone will sound for one second (if a door is open). Low washer fluid: Momentarily illuminates when the ignition is turned to ON and will stay on when the windshield washer fluid is low.

LOW WASHER FLUID TRUNK AJAR

AIR SUSPENSION OVERDRIVE OFF

AIR SUSPENSION OVERDRIVE OFF

km MILES /GAL LTR/100 km

DOOR AJAR

DOOR AJAR

CHECK

CHECK

LOW WASHER FLUID TRUNK AJAR

km MILES /GAL LTR/100 km

CHECK

DOOR AJAR

AIR SUSPENSION OVERDRIVE OFF

Trunk ajar: If the trunk is not completely closed, this light comes on when you turn the ignition to ON. With the ignition ON, this light will flash five times and sound a tone for one second, then the light remains on (if the trunk is open). Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened.

LOW WASHER FLUID TRUNK AJAR

km MILES /GAL LTR/100 km

14

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

GAUGES

Instrument Cluster

Standard instrument cluster gauges

Optional instrument cluster gauges Speedometer: Indicates the current vehicle speed. • Standard instrument cluster

50

80

40

60 70

100

120

80

140

90

60

40

20

30
20
10

0 0 0 0 0 0 0

100

160

000

MPH

km/h

200

180

110
120

15

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster • Optional instrument cluster

Engine coolant temperature gauge: • Standard instrument cluster

km km/h MPH

TEMP

• Optional instrument cluster Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool, refer to What you should know about fail-safe cooling in the Maintenance and specifications chapter.

Never remove the coolant reservoir cap while the engine is running or hot.

16

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Odometer: Registers the total kilometers (miles) of the vehicle. • Standard instrument cluster

50

80

40

60 70

100

120

80

140

90

60

40

20

30
20
10

0 0 0 0 0 0 0

100

160

000

MPH

km/h

200

180

110
120

• Optional instrument cluster Refer to Electronic Message Center in the Driver Controls chapter on how to switch the display from Metric to English.

km km/h MPH

Trip odometer: Registers the kilometers (miles) of individual journeys. • Standard instrument cluster To reset, depress the control.

60 70

40

60

40

20

30
20
10

50

80

100

80

120

140

0 0 0 0 0 0 0

90

100

160

000

MPH

km/h

200

180

110
120

17

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster • Optional instrument cluster Refer to Electronic Message Center in the Driver Controls chapter for Trip A and Trip B features.

km km/h MPH

VOLTS

OIL

Battery voltage gauge (if equipped): Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the vehicle’s electrical system checked as soon as possible.

Engine oil pressure gauge (if equipped): Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level. Add oil if needed. If the oil level is correct, have your vehicle checked at your dealership or by a qualified technician.

18

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. • Standard instrument cluster

FUEL

/21

19

• Optional instrument cluster A minimum of four gallons must be added or removed from the fuel tank in order for the gauge to instantaneously update. If less than four gallons is added, the gauge will take between five and ten minutes to update. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Entertainment Systems

PREMIUM AM/FM STEREO/CASSETTE/SINGLE CD (IF EQUIPPED)

16

15

14

13

17

18

19

MUTE

AM/FM

CD

TAPE

TUNE

SEEK

SCAN

AUTO SET

BASS

TREB

RDS

SEL

BAL

FADE

REW

FF

SIDE

COMP

SHUF

12

11

10

1. Eject: Press to eject a tape.

2. Eject: Press to eject a CD.

or increase

3. Bass: Allows you to increase or decrease the audio system’s bass output. Press BASS then press SEL to decrease Treble: Allows you to increase or decrease the audio system’s treble output. Press TREB then press SEL to decrease 4. Balance: Allows you to shift speaker sound between the right and left speakers. Press BAL then press SEL to shift sound to the left

or increase

the bass levels.

the treble levels.

or right

20

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

or the front

Fade: Allows you to shift speaker sound between the front and rear speakers. Press FADE then press SEL to shift the sound to the rear 5. COMP (Compression): In CD mode, press to bring soft and loud passages together for a more consistent listening level. SHUF (Shuffle): Press to play CD tracks in random order.

6. Select: Use to adjust bass, treble, balance and fade levels.

7. Side 1–2: Press to change sides on the tape.

Dolby威 noise

Dolby: reduction: Reduces tape noise and hiss; press to activate/deactivate. The Dolby威 noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation. Dolby威 and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. 8. REW (Rewind): Works in tape and CD modes. In tape mode, radio play continues until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. In CD mode, REW control reverses the CD within the current track. FF (fast forward): Works in tape and CD modes. In the tape mode, tape direction automatically reverses when the end of the tape is reached. In CD mode, FF advances the CD within the current track.

21

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

) or decrease (

9. RDS: (Radio Data System): Allows you to access FM stations which are RDS- equipped. Press RDS then SEL to select from: Traffic — Allows you to receive traffic announcements and control their volume level. Traffic information is not available in most U.S. markets. Show — Allows you to view the frequency and program type of the chosen radio station. The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend that FM radio broadcasters use RDS technology to transmit information. FM radio stations are independently operated and individually elect to use RDS technology to transmit station ID and program type as desired. Setting the clock: Press RDS until SELECT HOUR or SELECT MINS is displayed. Press SEL to increase ( 10. Autoset: Press to set first six strong stations into AM, FM1 or FM2 memory buttons; press again to return to normal stations. 11. Scan: Works in radio, tape and CD modes. Press SCAN for a brief sampling of radio stations, tape selections or CD tracks. 12. Seek: Works in radio, tape and CD modes. Press to access the previous radio station, tape selection or CD track. 13. Tune: Works in radio mode. Press to manually advance up or down the frequency band. 14. AM/FM/CD: Press AM/FM to select a radio frequency. Press while in tape or CD mode to return to radio mode. Press CD to enter CD mode and to play a CD already in the system. 15. Mute mode: Press to mute the playing media.

listenable

or next

).

22

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

16. Power/volume: Press to turn the system on/off. Turn to raise/lower the volume.

17. Tape: Press to play the tape.

18. CD door: Insert the disc with the playing side down and printed side up. 19. Tape door: Insert the tape facing the right.

AM/FM STEREO / SINGLE CD RADIO (IF EQUIPPED)

13

14 15 16 17 18

VOL - PUSH ON

12

11

SEEK

TUNE

AM FM

CD

BASS

TREB

FM1

ST

BAL

FADE

DISC

SCN

CLK

EJ

COMP

CD

CD

SHUFFLE

10

1. Balance: Press sound to the left/right speakers.

to shift

23

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

2. Fade: Press sound to the front/rear speakers.

to shift

3. SCN (Scan): Press to hear a brief sampling of all listenable stations or CD tracks. Press again to stop. 4. CLK: To set the hour, press and hold CLK and press SEEK to decrease hours. To set the minute, press and hold CLK and press TUNE to decrease or increase 5. EJ (eject): Press to eject a CD.

the minutes.

or increase

the

CLK

SHUFFLE

CD

6. COMP (Compression): In CD mode, press to bring louder and softer levels into more comfortable listening level. The compression icon (c) will appear in the display. 7. Shuffle: Press to listen to the tracks on the CD in random order. Press again to turn off. 8. Memory presets: To set a station: Select frequency band AM/FM; tune to a station. Press and hold a preset button until sound returns. This radio is equipped with six station memory preset controls which allow you to set up to six AM stations and 12 FM stations (six in FM1 and six in FM2). 9. CD: desired point of a selection is reached. 10. desired point of a selection is reached. 11. Tune: In radio mode, press to move up or down the frequency band in individual increments.

CD: Press and hold until

Press and hold until

CD

SHUFFLE

24

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

12. Seek: Press and release for previous/next SEEK strong station, selection or track. 13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

14. CD: Press to enter CD mode or to play a CD already loaded into the system. 15. AM/FM: Press to choose a frequency band in radio mode.

16. Bass: Press increase/decrease the bass output.

to

17. Treble: Press increase/decrease the treble output.

to

DISC

18. CD door: Insert a CD printed side up. CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information.

25

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

AM/FM STEREO (IF EQUIPPED)

VOL PUSH ON

TONE

CLK

TONE VOL

ST DX FM

12

SEEK

TUNE

AM/FM

to find the

1. Seek: Press next strong station down/up the frequency band. 2. Tune: Press change radio frequency down/up.

to manually

3. AM/FM: Press to choose a frequency band in radio mode.

AM/FM

4. Memory preset buttons: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.

26

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

5. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

CLK

TONE

VOL PUSH ON

6. Tone: Press TONE until the desired level — Bass, Treble, Fade appears on the display. Turn the volume control to raise/lower the levels, or to move the audio sound from the right to left or the front to back (if equipped). 7. CLK (Clock): To set the hour, press and hold CLK until CLOCK SET appears in the display. Press SEEK to decrease increase To set the minute, press and hold CLK until CLOCK set appears in the display. Press TUNE to decrease

the minutes.

or increase

the hours.

or

TONE

CLK

27

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

AM/FM STEREO CASSETTE (IF EQUIPPED)

12

13

14 15 16 17

VOL - PUSH ON

AM

FM

BASS

TREB

FM1

ST

BAL

FADE

CLK

TAPE AMS

SIDE REW

1 - 2
FF

11

10

SEEK

TUNE

SCAN

EJ

1. Balance: Press to shift sound to the left/right speakers.

2. Fade: Press to shift sound to the rear/front speakers.

3. CLK: To set the hour, press and hold CLK. Then press SEEK to decrease hours. To set the minute, press and hold CLK and press TUNE to decrease or increase

the minutes.

or increase

the

CLK

28

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

TAPE AMS

4. Tape AMS: In tape mode, press and hold to activate Automatic Music Search (allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection). Then, press REW (for the beginning of the current selection) or FF (to advance to the next selection). The tape MUST have a blank section of at least four seconds duration between programs. 5. Side 1–2: Press to change tape direction.

SIDE

1 - 2

6. REW (rewind): Press to rewind the tape.

FF (fast forward): Press to advance the tape.

REW

FF

Dolby威 noise reduction: Works in tape mode only. Reduces tape

7. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 8. noise and hiss; press to activate/deactivate. 9. Scan: Press SCAN to hear a brief sampling of all listenable radio stations or all tape selections. Press again to stop. 10. Tune: Works in radio mode only. Press TUNE frequency down/up 11. Seek: Press and for previous/next release strong station, selection or track. 12. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

to change

29

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

13. AM/FM: Press to choose a frequency band in radio mode.

14. Bass: Press decrease/increase the bass output.

to

15. Treble: Press decrease/increase the treble output.

to

16. EJ (Eject): Press to eject a tape.

EJ

17. Cassette door: Insert a cassette into the cassette door.

CD CHANGER (IF EQUIPPED) Your CD changer is either located in the trunk, the console or the right side cargo area storage compartment. 1. Slide the door to access the CD changer magazine. 2. Press

to eject the magazine.

30

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine.

Entertainment Systems

Do not pull too hard on the disc holder as the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever. 5. Line up the CD with the groove of the disc holder. Ensure that the label on the CD faces downwards. 6. Press the disc holder until it locks securely into the magazine.

Ensure that the disc holder is evenly inserted and at the same level as the magazine (A). The unit will not operate if the disc holder is not inserted at the same level (B).

RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz

31

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

weaker the signal and the weaker the reception.

RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception. • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.

CASSETTE/PLAYER CARE Do: • Use only cassettes that are 90 minutes long or less. • Tighten very loose tapes by inserting a finger or pencil into the hole • Remove loose labels before inserting tapes. • Allow tapes which have been subjected to extreme heat, humidity or • Clean the cassette player head with a cassette cleaning cartridge after

cold to reach a moderate temperature before playing.

and turning the hub.

10–12 hours of play to maintain good sound/operation.

Don’t: • Expose tapes to direct sunlight, extreme humidity, heat or cold. • Leave tapes in the cassette player for a long time when not being

played.

CD/CD PLAYER CARE Do: • Handle discs by their edges only. Never touch the playing surface. • Inspect discs before playing. Clean only with an approved CD cleaner

and wipe from the center out.

of time.

Don’t: • Expose discs to direct sunlight or heat sources for extended periods • Insert more than one disc into each slot of the CD changer magazine. • Clean using a circular motion. 32

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.

AUDIO SYSTEM WARRANTY AND SERVICE Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.

33

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

Climate Controls

HI

MIX

LO

OFF

VENT

FLOOR

MAX A/C

NORM A/C

MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Uses recirculated air to cool the vehicle. Air flows from the instrument panel vents only. This mode will help prevent unpleasant odors from entering the vehicle. NORM A/C: Uses outside air to cool the vehicle. Air flows from the instrument panel vents only. VENT: Distributes outside air through the instrument panel vents. OFF: Outside air is shut out and the fan will not operate. FLOOR: Distributes outside air through the floor vents. MIX: Distributes outside air through the windshield defroster vents, floor vents and side window demisters.

: Distributes outside air through the windshield defroster vents and

the side window demisters.

position.

the air flow selector in the

air flow selector in the OFF or MAX A/C position.

Operating tips • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of

airflow to the back seats.

the windshield.

34

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

To aid in side window defogging/demisting in cold weather: 1. Select NORM A/C. 2. Modulate the temperature control to maintain comfort. 3. Set the fan speed to HI. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM (IF EQUIPPED)

10

11

OUTSIDE TEMP

AUTO

OFF

AUTOMATIC

MAX A/C

NORM A/C

VENT

FLOOR

FLR • DEF

DEF

HI

LO

1. OFF: Outside air is shut out and the fan will not operate.

2. AUTOMATIC: Press AUTOMATIC and select the desired temperature using the temperature controls. The system will automatically determine fan speed, airflow location, and outside or recirculated air to heat or cool the vehicle to the selected temperature. The fan speed will remain automatic unless the thumbwheel is turned.

35

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

3. Fan speed: Turn to manually increase or decrease fan speed.

Distributes outside air through the windshield defroster

4. Defrost: vents and the side window demisters. 5. Floor/defrost: Distributes outside air through the windshield defroster vents, floor vents and the side window demisters. 6. Floor: Distributes outside air through the floor vents. 7. Vent: Distributes outside air through the instrument panel vents. 8. Norm A/C: Uses outside air to cool the vehicle . Air flows from the instrument panel vents only. 9. Max A/C: Uses recirculated air to cool the vehicle. Air flows from the instrument panel vents only. This mode will help prevent unpleasant odors from entering the vehicle. 10. Outside Temp: Press to display the outside temperature. It will remain in the display until pressed again. The temperature will be most accurate when the vehicle is in motion. 11. Temperature control: Press this control to select the temperature. The display window indicates the selected temperature. Fahrenheit/Celsius temperature: Press MAX A/C and DEF simultaneously to toggle between Fahrenheit and Celsius temperature. The set point temperatures in Celsius will be displayed in half-degree increments.

the air flow selector in the

Operating tips • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the

air flow selector in the OFF or MAX A/C position.

position.

airflow to the back seats.

36

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls • Remove any snow, ice or leaves from the air intake area at the base of

the windshield.

To aid in side window defogging/demisting in cold weather: 1. Select NORM A/C. 2. Modulate the temperature control to maintain comfort. 3. Set the fan speed to HI. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. A small LED will illuminate when the rear defroster is activated.

The ignition must be in the ON position to operate the rear window defroster. The defroster turns off automatically after a predetermined amount of time or when the ignition is turned to the OFF position. To manually turn off the defroster, press the control again. Activating the rear window defroster will also activate the heated mirrors (if equipped). For more information refer to Heated outside mirrors in the Driver controls chapter. Do not use razor blades or other sharp objects to clean the inside of the rear window or to remove decals from the inside of the rear window. This may cause damage to the heated grid lines and will not be covered by your warranty.

37

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Lights

HEADLAMP CONTROL Turns the lamps off.

Turns on the parking

lamps, instrument panel lamps, license plate lamps and tail lamps.

Turns the headlamps on.

Autolamp control The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for a predetermined period of time after the ignition switch is turned to OFF. • To turn autolamps on, rotate the control counterclockwise to the next position from OFF.

• To turn autolamps off, rotate the control clockwise past OFF to the

parking lamp position

, then back to OFF.

The headlamps will turn on under the following conditions: 1. Headlamp switch is turned to the “headlamps on position” 2. With the ignition in run or start, wipers turned on and the headlamp switch in the autolamp position.

Daytime running lamps (DRL) (if equipped) Turns the highbeam headlamps on with a reduced output. To activate: • the key must be in the ON position, • the parking brake released, and • the headlamp control is in the OFF or Parking lamps position.

38

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System

does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.

High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate.

Flash to pass Pull toward you slightly to activate and release to deactivate.

PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. • Rotate the thumbwheel from left

to right to brighten the instrument panel.

• Rotate the thumbwheel from right

to left to dim the instrument panel.

Domelamp Control The panel dimmer control also controls the domelamp operation. • Rotate the thumbwheel fully to the right, past detent to activate the • In order to turn off the domelamp, rotate the thumbwheel to the left. 39

domelamp.

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Lights

AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician.

TURN SIGNAL CONTROL • Push down to activate the left • Push up to activate the right turn

turn signal.

signal.

The flash rate of the turn signal will speed up considerably if the left or right turn lamp bulb (front or rear) is burned out.

MAP/COURTESY LAMPS Without a moon roof

With a moon roof To turn on the map lamps, press the map lamp control.

40

2004 Crown Victoria (cro) Owners Guide (post-2002-fmt) USA English (fus)

Lights

BULBS

Replacing exterior bulbs Check the operation of all the bulbs frequently.

Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time. Function Headlamp Park lamp and turn lamp (front) Side marker (front) Tail, stop, turn (rear) Side marker (rear) Backup lamp License plate lamp High-mount brakelamp Luggage compartment lamp Dome lamp Rear reading lamp Map lamp Dual floorwell lamp Glove compartment Visor vanity lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer.

Trade Number 9007
3457 AK (amber) 194 AK (amber) 3157K 194
3156K 168
912
212-2
906
211-2
168
906
168
7065
