2009 Toyota Tacoma Owners Manual

MN 00505-QRG09-TAC Printed in the USA 5/08

2009 Tacoma

This Quick Reference Guide is a summary of basic vehicle operations. It contains brief descriptions of fundamental operations so you can locate and use the vehicle’s main equipment quickly and easily. The Quick Reference Guide is not intended as a substitute for the Owner’s Manual located in your vehicle’s glove box. We strongly encourage you to review the Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Tacoma.

! A word about safe vehicle operations

This Quick Reference Guide is not a full description of Tacoma operations. Every Tacoma owner should review the Owner’s Manual that accompanies this vehicle. Pay special attention to the boxed information highlighted in color throughout the Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.

Doors-Child safety locks (double cab only) Rear door

Moving the lever to “LOCK” will allow the door to be opened only from the outside.

Spare tire & tools Tool location Regular cab models -behind the seatback

Double cab models -under the rear seat

Jack

Tool bag

Access cab models -under the rear seat

Tool bag

Front

Jack

Removing the spare tire (1)

Tool bag

Front

Jack

(2)

(1) Assemble the jack handle. (2) Insert the jack handle end into the lowering screw. (3) Turn the jack handle counterclockwise. Refer to the Owner’s Manual for tire changing and jack positioning procedures.

(3)

21

INDEX

OVERVIEW

FEATURES/OPERATIONS

Engine maintenance Fuel tank door and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry

Accessory meter Air Conditioning/Heating Audio Automatic Transmission Clock Cruise control Door locks-Power Four-wheel drive Lights & turn signals Light control-Instrument panel Parking brake Power outlets Rear differential lock Seat adjustments-Front Seats-Folding rear Seats-Head restraints Telephone controls (Bluetooth®) Tilt and telescopic steering wheel “VSC OFF” button Windows-Power Windshield wipers & washers

4-5
2-3

14-15

15
16

10
19
18
17
13
13
16
10
11
10
18
19
12
12

SAFETY AND EMERGENCY FEATURES

21
Doors-Child safety locks 20
Seat belts 20
Seat belts-Shoulder belt anchor Spare tire & tools 21
Tire Pressure Monitoring (warning) System 20

OVERVIEW

Instrument panel

Steering wheel controls (if equipped)

Volume control buttons (for audio) “ ” buttons (for audio) >> “MODE” button (for audio) Front fog light switch1
Rear differential lock switch1
115V AC Power outlet ON/OFF switch1
Instrument panel light control Headlight and turn signal controls Windshield wiper and washer controls Two-wheel/Four-wheel drive selector1
Audio system Clock Theft deterrent system/Engine immobilizer indicator1
Front passenger seat belt reminder Front passenger occupant classification indicator1 or front passenger airbag ON/OFF indicator1

O

Parking brake lever

Front passenger airbag manual ON/OFF switch1
Air Conditioning controls 12V DC Power outlet Emergency flasher button 12V DC Power outlet/Cigarette lighter Parking brake lever (stick type)2
Cruise control1
Engine ignition switch Parking brake pedal3
“RSCA OFF” (Roll Sensing Curtain shield Airbags OFF) switch “DAC” (Downhill Assist Control) button1 or clutch start cancel switch1
“VSC OFF” (Vehicle Stability Control OFF) switch1
Power rearview mirror control switches1

1 If equipped 2 Manual Transmission only 3 Automatic Transmission only

OVERVIEW

Instrument cluster

Tachometer Speedometer Odometer and two trip meters Service indicator and reminder Engine coolant temperature Fuel gauge Trip meter reset knob Gear shift position indicator (if equipped)

Indicator symbols

Brake system warning1

Driver/Front passenger seat belt reminder1

Charging system warning1
Front passenger occupant classification indicator/ Front passenger airbag ON/OFF indicator Low engine oil pressure warning1

Malfunction/Check Engine indicator1

Engine oil replacement reminder1

Open door warning1

1 For details, refer to “Indicators and warning lights,” Section 2-2, 2009 Owner’s Manual. 2 If this light flashes, refer to “SRS airbag,” Section 1-7-, 2009 Owner’s Manual. 3 If this light flashes, refer to “Four-wheel drive system,” Section 2-4, 2009 Owner’s Manual.

Airbag SRS warning1

Automatic Transmission fluid temperature warning1

Low Tire Pressure Warning1

Theft deterrent/Engine immobilizer system indicator

Roll Sensing Curtain shield Airbags OFF indicator2

Headlight low beam indicator

Headlight high beam indicator

Turn signal indicator

Automatic Transmission indicator (5-speed)/(4-speed)

Four-wheel drive indicator3

Low speed four-wheel drive indicator3

Rear differential lock indicator4

Slip indicator

Vehicle Stability Control “OFF” indicator warning1

Downhill assist control system indicator

AUTO Limited Slip Differential indicator

Cruise control indicator5

Anti-lock Brake System warning1

4 If this light flashes, refer to “Rear differential lock system,” Section 2-4, 2009 Owner’s

Manual.

5 If this light flashes, refer to “Cruise control,” Section 2-4, 2009 Owner’s Manual.

OVERVIEW

Keyless entry (if equipped) Locking operation

Unlocking operation

Push ONCE: Driver door

TWICE: All doors

NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety.

Push

Panic button

Fuel tank door and cap

Pull

Push and hold

Turn

NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “

” indicator may illuminate.

Hood release

Pull

Pull up latch and raise hood

Engine maintenance 4 cylinder (2TR-FE) engine

6 cylinder (1GR-FE) engine

Windshield washer fluid tank Engine coolant reservoir Engine oil filler cap Power steering fluid reservoir Engine oil level dipstick

Note: Regularly scheduled maintenance, including oil changes, will

help extend the life of your vehicle and maintain performance. Please refer to the “Owner’s Warranty Information Booklet,” “Scheduled Maintenance Guide” or “Owner’s Manual Supplement.”

FEATURES/OPERATIONS

Automatic Transmission (if equipped) 5-speed models

4-speed models

Park1
Park* Reverse Reverse Neutral Neutral Drive Drive Fourth gear Fourth gear Third gear Third gear Second gear Second gear First gear First gear

Park* Reverse Neutral Drive Third gear Second gear First gear

* The engine switch must be “ON” and the brake pedal depressed to shift

from Park.

Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D” position. Light control-Instrument panel

Brightness control

Four-wheel drive (if equipped)

Turn

Turn

Push and turn

High speed (2WD) High speed (4WD) Shift when speed is below 62 mph. Low speed (4WD) Shift into neutral while stopped, or depress clutch pedal at speeds below 2 mph.

For best fuel economy and performance under normal driving conditions, keep in “H2” position.

Tilt and telescopic steering wheel

Angle

Length

Lock release lever

Hold wheel, push lever down, set angle and length, and return lever. Note: Do not attempt to adjust while the vehicle is in motion.

FEATURES/OPERATIONS

Seat adjustments-Front Separate seat

Bench seat

Position Driver’s seat lumbar support (if equipped) Seatback angle

Seats-Head restraints Separate seats-Front

Bench seat-Front

(2)

(1)

Lock release button

Lock release button

Clock

H- Hour set M- Minute set

10

Seats-Folding rear Access cab (1)

(2)

(3)

Double cab (1)

(3)

(5)

Pull

(1) Stow the seat belt buckles. (2) Raise the bottom cushion up while

pulling the lever until it locks. (3) Push the bottom cushion down.

(2)

(4)

(1) Stow the seat belt buckles. (2) Pass the seat belt through the seat

belt hangers.

(3) Remove the head restraint and

swing the bottom cushion. (4) Attach the head restraints. (5) Fold down the seatback.

11

FEATURES/OPERATIONS

Windshield wipers & washers With intermittent wiper

Adjust interval*

Single wipe

Pull to wash and wipe

Interval wipe

Slow

Fast

* Intermittent windshield

wiper interval adjustment Rotate up to increase interval, down to decrease interval.

Without intermittent wiper

Pull to wash and wipe

Windows-Power (if equipped) Access cab models Driver side

Single wipe

Slow

Fast

Window lock switch

Up

Down

Up

Down

Double cab models Driver side

Up

Down

Window lock switch

Up Down

Automatic down operation (driver side only) Push the switch completely down and release to fully open. To stop window midway, lightly pull up on the switch. Window lock switch Deactivates all passenger windows. Driver’s window remains operable.

12

Parking brake Automatic Transmission

Manual Transmission Set

Release

(1) Push button

Power outlets 12V DC

Set: Depress Release: Depress again

(2) Turn and

push in lever

Key must be in the “ACC” or “ON” position to be used. 115V AC (if equipped)

ON/OFF switch

Green indicator

Push

Yellow indicator

The engine must be running for use.

Yellow Light Only Max Capacity 115V AC/100W Green & Yellow Lights Max Capacity 115V AC/400W Refer to the Owner’s Manual for more details.

13

Right side of bed

FEATURES/OPERATIONS

Audio

Type 1

Eject CD

Preset buttons - functions in other modes indicated below number

Push to turn ON/OFF

Station/ Search playback

Seek station/ CD track select

Type 2 additional functions

Mode

Playback

Push to adjust tone & balance

View text

Load CD(s)

CD PLAYER To scan tracks on a disc Push and hold “SCAN.” Push again to hold selection. CD changer (Type 2 only) -To load one disc Push “LOAD” and insert one disc. -To load multiple discs Push and hold “LOAD” until you hear a beep. Insert one disc. Shutter will close and then re-open for next disc. RADIO To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push and hold “SCAN” to scan preset stations. Push again to hold selection.

14

Steering wheel switches (if equipped)

Volume control

“ ” >> -In radio mode Push to select a preset station; push and hold to seek the next strong station. -In CD mode Push to skip up or down to the next/previous track. “MODE” Push to turn audio ON and select an audio mode. Push and hold to turn the audio system OFF.

AUX audio jack

Push “DISK/AUX” button after inserting a mini plug into the AUX audio jack to listen to music from a portable audio device through the vehicle’s speaker system.

Accessory meter (if equipped)

Display button Outside temperature Compass

15

FEATURES/OPERATIONS

Air Conditioning (if equipped)/Heating

Fan speed Temperature Airflow vent In “ ” or “ reduce window fogging. Fresh or recirculated cabin air Air Conditioning ON/OFF (if equipped) Use fresh air to quickly cool interior, then change to recirculate for cooler air.

” mode, use fresh air (“

” indicator OFF) to

Rear differential lock (if equipped)

Rear differential Lock/Unlock

Use ONLY when wheel spinning occurs in a ditch, or on slippery or unpaved surfaces. DO NOT USE THE REAR DIFFERENTIAL LOCK IN CONDITIONS OTHER THAN SPECIFIED IN THE OWNER’S MANUAL. UNLOCK THE DIFFERENTIAL ONCE THE VEHICLE MOVES OUT OF THE TROUBLE SPOT.

Refer to your Owner’s Manual for complete details on this system before attempting to use it.

16

Lights & turn signals Headlights

Headlights

Parking lights

Low beam

High beam

High beam flasher

-Daytime Running Light system (if equipped) Automatically turns on the turn signal lights at a reduced intensity. -Automatic light cutoff system Automatically turns lights off when driver’s door is opened with the engine switch in the “ACC” or “LOCK” position. Front fog lights (if equipped)

Front fog lights come on only when the headlights are on low beam.

Turn signals

Right turn

Lane change

Lane change

Left turn

17

FEATURES/OPERATIONS

Telephone controls (Bluetooth®) (if equipped) Audio unit

Microphone

Steering wheel telephone switches

Volume

OFF/Ends a call ON/Starts a call

Voice command system

Bluetooth® technology allows you to place or receive calls without taking your hands from the steering wheel or using a cable to connect the telephone and the system. Refer to “Using the hands-free phone system (for cellular phone),” Section 3-3 in the Owner’s Manual for more details.

Door locks-Power (if equipped)

Unlock

Lock

18

“VSC OFF” button

VSC OFF

The “VSC OFF” button is used to switch between modes related to the TRAC, VSC and Auto LSD functions. Refer to the Owner’s Manual for more information.

Cruise control (if equipped) Turning system ON/OFF

System ON/OFF

Functions

Cancel1

Resume2/Increase speed

Set/Decrease speed

1 The set speed may also be cancelled by depressing the brake pedal. 2 The set speed may be resumed once vehicle speed exceeds 25 mph.

19

SAFETY AND EMERGENCY FEATURES Seat belts

Take up slack

Too high

Keep as low on hips as possible

If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely.

To find more information about seat belts, and how to install a child restraint system, refer to the Owner's Manual. Seat belts-Shoulder belt anchor

Push up, or squeeze lock release to lower

Tire Pressure Monitoring (warning) System

If tire pressure indicator light is on, check/adjust each tire.

SET” button until indicator blinks three times. Let the vehicle sit for a

After adjusting tire pressures, or after tires have been rotated or replaced, turn the ignition switch to “ON” and press and hold the “ few minutes to allow initialization to complete. Refer to the load label on the door jamb or the Owner’s Manual for tire inflation specifications. If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer.

20

TACOMA_U.book Page 506 Tuesday, April 8, 2008 9:01 AM

Abbreviation list Abbreviation/Acronym list

ABBREVIATIONS MEANING

Two Wheel Drive Four Wheel Drive Anti-Lock Brake System Accessory Automatic Locking Retractor Active Traction Control Automatic Limited Slip Differential Child Restraint System Downhill assist control Electronic Control Unit Event Data Recorder Emergency Locking Retractor Gross Axle Weight Rating Gross Vehicle Weight Rating Emission inspection and maintenance Intermittent Light Emitting Diode Light truck Mud + Snow Methylcy clopentadienyl Manganese Tricarbonyl Methyl Tertiary Butyl Ether On Board Diagnostics Resume Rear differential lock Roll sensing of curtain shield airbag Supplemental Restraint System Tire Identification Number

2WD 4WD ABS ACC ALR

A-TRAC AUTO LSD

CRS DAC ECU EDR ELR GAWR GVWR

I/M INT LED LT

M + S MMT MTBE OBD RES

RR DIFF LOCK

RSCA SRS TIN

506

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 507 Tuesday, April 8, 2008 9:01 AM

ABBREVIATIONS MEANING

TPMS TRAC TWI VIN VSC

Tire Pressure Warning System Traction Control Treadwear indicators Vehicle Identification Number Vehicle Stability Control

507

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 24 Tuesday, April 8, 2008 9:01 AM

For your information

Main Owners Manual

Please note that this manual applies to all models explains and all equip- ment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.

Accessories, spare parts and modification of your Toyota

is not responsible

these products and

A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Modification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.

for

Installation of a mobile two-way radio system

As the installation of a mobile two-way radio system in your vehicle could affect electronic systems such as the multiport fuel injection system/sequen- tial multiport fuel injection system, cruise control system, anti-lock brake sys- tem, SRS airbag system and seat belt pretensioner system, be sure to check with your Toyota dealer for precautionary measures or special instructions regarding installation.

24

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 25 Tuesday, April 8, 2008 9:01 AM

Scrapping your Toyota

The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.

Perchlorate Material

Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.

CAUTION

n General precautions while driving

Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.

25

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 26 Tuesday, April 8, 2008 9:01 AM

CAUTION

n General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the cigarette lighter, the windows, or other features of the vehicle. In addi- tion, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

26

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 27 Tuesday, April 8, 2008 9:01 AM

Symbols used throughout this manual

Cautions & Notices

CAUTION

This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.

NOTICE

This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.

Safety symbol

The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.

Arrows indicating operations

Indicates the action (pushing, turning, etc.) used to operate switches and other devices. Indicates the outcome of an operation (e.g. a lid opens).

27

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 28 Tuesday, April 8, 2008 9:01 AM

28

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 1 Tuesday, April 8, 2008 9:01 AM

TABLE OF CONTENTS

1 Before driving

Adjusting and operating features such as door locks, mirrors, and steering column.

2 When driving

Driving, stopping and safe-driving information.

3 Interior and

exterior features

Air conditioning and audio systems, as well as other in- terior features for a comfortable driving experience.

4 Maintenance

and care

Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information.

5 When trouble

arises

What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident.

6 Vehicle

specifications

Detailed vehicle information.

7 For owners

Reporting safety defects for U.S. owners, seat belt in- structions for Canadian owners and camper informa- tion.

Index

Alphabetical listing of information contained in this manual.

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 6 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Exterior

Regular Cab models

Windshield wipers P. 160

Outside rear view mirrors P. 66

Hood P. 353

Parking and front side marker lights P. 157

Headlights P. 157

Front turn signal lights P. 147

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 7 Tuesday, April 8, 2008 9:01 AM

Back window∗ P. 71

Fuel filler door P. 72

Side doors P. 35

Rear turn signal lights P. 147

Stop/tail lights P. 157

Tailgate P. 40

Tires l Rotation l Replacement l Inflation pressure l Information

P. 373
P. 433
P. 381
P. 482

License plate lights P. 157

Rear side marker lights P. 157

∗: If equipped

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 8 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Exterior

Access Cab models

Windshield wipers P. 160

Outside rear view mirrors P. 66

Hood P. 353

Parking and front side marker lights P. 157

Headlights P. 157
Fog lights∗ P. 159

Front turn signal lights P. 147

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 9 Tuesday, April 8, 2008 9:01 AM

Back window∗ P. 71

Fuel filler door P. 72

Access doors P. 39

Side doors P. 35

Rear turn signal lights P. 147

Stop/tail lights P. 157

Tailgate P. 40

License plate lights P. 157

Rear side marker lights P. 157

∗: If equipped

Tires l Rotation l Replacement l Inflation pressure l Information

P. 373
P. 433
P. 381
P. 482

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 10 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Exterior

Double Cab models

Windshield wipers P. 160

Outside rear view mirrors P. 66

Hood P. 353

Parking and front side marker lights P. 157

Headlights P. 157
Fog lights∗ P. 159

Front turn signal lights P. 147

10

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 11 Tuesday, April 8, 2008 9:01 AM

Back window∗ P. 71

Fuel filler door P. 72

Side doors P. 35

Tires l Rotation l Replacement l Inflation pressure l Information

P. 373
P. 433
P. 381
P. 482

TACOMA_U_(L/O_0805)

Rear turn signal lights P. 147

Stop/tail lights P. 157

Tailgate P. 40

License plate lights P. 157

Rear side marker lights P. 157

∗: If equipped

11

TACOMA_U.book Page 12 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Interior

Seat belts P. 56

Head restraints P. 54

Bottle holders∗2 P. 300

Front console box∗2 P. 297
SRS driver airbag P. 81

SRS front passenger airbag P. 81

Rear seats∗2 P. 50

Seatback table∗1 P. 317

Glove box P. 296

Floor mats P. 318

Front seats P. 45

SRS side airbags P. 81

12

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 13 Tuesday, April 8, 2008 9:01 AM

Accessory meter ∗1 Outside temperature display ∗1 Compass ∗1 Garage door opener box ∗1

P. 156

P. 308

P. 332

P. 328

Personal lights∗1

P. 295

Overhead console∗1

P. 304

Interior light

P. 295

SRS curtain shield airbags P. 81

Sun visors P. 305

Anti-glare inside rear view mirror P. 63
Rear view monitor system∗3 P. 166
Vanity mirrors P. 306

∗1: If equipped ∗2: Access Cab and Double Cab models

∗3: Vehicles with auto anti-glare inside

rear view mirror

13

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 14 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Interior

Door lock switch∗1 P. 36

Inside door lock button P. 36

Power window switches∗1 P. 69

Window lock switch∗1 P. 69

14

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 15 Tuesday, April 8, 2008 9:01 AM

Bench type front seat

Shift lever P. 141, 144

Cup holders P. 298

Shift lock override button∗2 P. 450

Separated type front seats with an automatic transmission

Shift lever P. 141

Cup holders P. 298

Cup holders P. 298

Shift lock override button P. 450

∗1: If equipped

∗2: Vehicles with an automatic transmission 15

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 16 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Interior

Separated type front seats with a manual transmission

Shift lever P. 144

Cup holders P. 298

16

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 17 Tuesday, April 8, 2008 9:01 AM

Access Cab models

Sub woofer∗ P. 256

Back window lock release lever∗ P. 71

Auxiliary boxes P. 302

Rear console box P. 297

∗: If equipped

17

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 18 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Interior

Double Cab models

Grocery bag hooks P. 326

Bottle holders P. 300

Back window lock release lever∗1 P. 71

Flashlight holder P. 325

Storage boxes P. 324

Cargo net hooks∗2 P. 327

∗1: If equipped ∗2: Vehicles with sub woofer

18

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 19 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Instrument panel

Gauges and meters P. 150

Tilt and telescopic steering lock release lever P. 62
Tire pressure warning reset switch P. 373
Hood lock release lever P. 353
Parking brake pedal∗ P. 148
Auxiliary box P. 302

Bottle holders P. 300

∗: Vehicles with an automatic transmission 19

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 20 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Instrument panel

Audio system P. 228

Passenger airbag off switch∗1 P. 93

Front-wheel drive control switch∗2 P. 170

Air conditioning system P. 220
Emergency flasher switch

A-TRAC switch∗3 P. 174

AUX adapter P. 257

Cigarette lighter P. 309

Power outlet P. 310

20

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 21 Tuesday, April 8, 2008 9:01 AM

Windshield wipers and washer switch P. 160

Engine (ignition) switch P. 138

Parking brake lever∗4 P. 148

Audio remote control switches∗3 P. 259

Telephone switches∗3 P. 267

Talk switch∗3 P. 267

Cruise control switch∗3 P. 163

∗1: Access Cab models only ∗2: 4WD models

∗3: If equipped ∗4: Vehicles with a manual transmission 21

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 22 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Instrument panel

Fog light switch∗ P. 159

RR DIFF LOCK switch∗ P. 178

Instrument panel light control dial P. 151

Power outlet main switch∗ P. 311

Headlight switch P. 157
Turn signal lever P. 147

RSCA OFF switch P. 95

CLUTCH START CANCEL switch∗ P. 183
DAC switch∗ P. 181

VSC OFF switch P. 176, 185

Outside rear view mirror switches∗ P. 66

22

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 23 Tuesday, April 8, 2008 9:01 AM

Pictorial index

Luggage compartment

Deck rails P. 195

Tie-down cleats P. 322

Power outlet∗ P. 311

Auxiliary boxes P. 320

Deck hooks P. 321

∗: If equipped

23

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 30 Tuesday, April 8, 2008 9:01 AM

1-1. Key information Keys

The following keys are provided with the vehicle.

Vehicles without engine immobilizer system

Master keys Key number plate

Vehicles with engine immobilizer system

Master keys Valet key Key number plate

n Key number plate

Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 451)

30

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 31 Tuesday, April 8, 2008 9:01 AM

1-1. Key information

NOTICE

n To prevent key damage (vehicles with engine immobilizer system)

l Do not subject the keys to strong shocks, expose them to high tempera-

tures by placing them in direct sunlight, or get them wet.

l Do not expose the keys to electromagnetic materials or attach any mate-

rial that blocks electromagnetic waves to the key surface.

31

TACOMA_U_(L/O_0805)

TACOMA_U.book Page 32 Tuesday, April 8, 2008 9:01 AM

1-2. Opening, closing and locking the doors Wireless remote control (if equipped)

The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle.

Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3
seconds unlocks the other doors. Sounds alarm (push and hold)

n Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)

n Panic mode

When is pushed for longer than about one second, an alarm will sound for about 60 seconds and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, push any button on the wireless remote control.

n Door lock buzzer

If a door is not fully closed, a buzzer sounds for 10 seconds if an attempt to lock the door is made. Fully close the door to stop the buzzer, and lock the vehicle once more.
