TABLE OF CONTENTS


1 Before driving


Adjusting and operating features such as door locks, mirrors, and steering column.


2 When driving


Driving, stopping and safe-driving information.


3 Interior and


exterior features


Air conditioning and multimedia systems, as well as other interior features for a comfortable driving experi- ence.


4 Maintenance


and care


Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information.


5 When trouble


arises


What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident.


6 Vehicle


specifications


Detailed vehicle information.


7 For owners


Reporting safety defects for U.S. owners, seat belt and SRS airbag instructions for Canadian owners and camper information.


Index


Alphabetical listing of information contained in this manual.


TABLE OF CONTENTS


Index


1 Before driving


1-1. Key information


Keys ..................................... 30


1-2. Opening, closing and locking


the doors Wireless remote control ....... 32
Side doors ............................ 35
Access doors (Access Cab models only)....................... 39
Tailgate ................................ 40


1-3. Adjustable components (seats, mirrors, steering wheel) Front seats ........................... 45
Rear seats............................ 49
Head restraints..................... 53
Seat belts ............................. 57
Steering wheel ..................... 63
Anti-glare inside rear view mirror.................................. 64
Outside rear view mirrors ..... 68


1-4. Opening and closing


the windows Power windows .................... 71
Back window (vehicles with sliding type)........................ 73


1-5. Refueling


Opening the fuel tank cap..... 74


1-6. Theft deterrent system


Engine immobilizer system... 77


1-7. Safety information


Correct driving posture ......... 80
SRS airbags ......................... 82
Front passenger occupant classification system........... 95
Child restraint systems ....... 100
Installing child restraints ..... 104


2 When driving


2-1. Driving procedures


Driving the vehicle .............. 120
Engine (ignition) switch....... 131
Automatic transmission ...... 134
Manual transmission........... 138
Turn signal lever ................. 141
Parking brake ..................... 142
Horn.................................... 144


2-2. Gauges and meters


Gauges and meters ............ 145
Indicators and warning lights ................................. 148


2-3. Operating the lights and


wipers Headlight switch.................. 152
Fog light switch ................... 155
Windshield wipers and washer .............................. 156


2-4. Using other driving systems


Cruise control...................... 162
Rear view monitor system... 166
Four-wheel drive system..... 177
Active traction control system .............................. 181
AUTO LSD system.............. 183
Rear differential lock system .............................. 185
Downhill Assist Control system .............................. 188
Clutch start cancel switch ... 190
Driving assist systems ........ 191


2-5. Driving information


Off-road precautions (4WD models and PreRunner).... 197
Cargo and luggage ............. 202
Vehicle load limits ............... 207
Winter driving tips ............... 209
Trailer towing ...................... 213
Dinghy towing ..................... 233


3 Interior and exterior


features


3-1. Using the air conditioning


system and defogger Air conditioning system ...... 236


3-2. Using the multimedia system Multimedia system types.... 243
Entune Audio...................... 245
USB port/AUX port ............. 249
Setup menu........................ 250
Basic audio operations....... 256
Using the radio ................... 261
Playing an audio CD and MP3/WMA/AAC discs ...... 263
Listening to an iPod............ 270
Listening to a USB memory device................. 276
Using the AUX port............. 281
Connecting Bluetooth®....... 282
Listening to Bluetooth® audio ................................ 304
Using a Bluetooth® phone ............................... 305
Operating the sub woofer (on some Access Cab models) ............................ 334
Detachable pole antenna ... 335


TABLE OF CONTENTS


Index


3-3. Using the interior lights


Interior lights list ................. 338
• Interior light ...................... 339
• Personal lights ................. 339


3-4. Using the storage features


List of storage features....... 340
• Glove box......................... 341
• Front console box ............ 341
• Cup holders...................... 342
• Bottle holders ................... 344
• Auxiliary boxes................. 345
• Overhead console............ 348


3-5. Other interior features


Sun visors .......................... 349
Vanity mirrors ..................... 350
Clock .................................. 351
Power outlets (12 VDC) ..... 352
Power outlet (120 VAC) ..... 353
Seat heaters....................... 359
Seatback table ................... 361
Floor mat ............................ 362
Luggage compartment features ............................ 364
Garage door opener........... 373
Compass (vehicles with auto anti-glare inside rear view mirror)............... 381


4 Maintenance and care


4-1. Maintenance and care Cleaning and protecting the vehicle exterior ........... 388
Cleaning and protecting the vehicle interior ............ 391


4-2. Maintenance Maintenance requirements .................... 394
General maintenance ......... 396
Emission inspection and maintenance (I/M) programs............................. 399


4-3. Do-it-yourself maintenance


Do-it-yourself service precautions....................... 400
Hood ................................... 404
Engine compartment .......... 406
Tires.................................... 422
Tire inflation pressure ......... 431
Wheels................................ 436
Air conditioning filter ........... 439
Wireless remote control battery .............................. 442
Checking and replacing fuses................................. 444
Light bulbs .......................... 454


5 When trouble arises


6 Vehicle specifications


5-1. Essential information


6-1. Specifications


Emergency flashers ............ 466
If your vehicle needs to be towed ........................... 467
If you think something is wrong ................................ 474
Fuel pump shut off system .............................. 475


5-2. Steps to take in an emergency


Maintenance data (fuel, oil level, etc.) ........... 516
Fuel information.................. 537
Tire information .................. 540


6-2. Customization


Customizable features........ 551
Items to initialize................. 552


If a warning light turns on or a warning buzzer sounds... ........................... 476
If you have a flat tire............ 486
If the engine will not start .... 501
If the shift lever cannot be shifted from P (vehicles with an automatic transmission) .................... 502
If you lose your keys ........... 503
If the vehicle battery is discharged ........................ 504
If your vehicle overheats..... 508
If the vehicle becomes stuck ................................. 511
If your vehicle has to be stopped in an emergency ................... 513


7 For owners


Reporting safety defects for U.S. owners ................ 554
Seat belt instructions for Canadian owners (in French)........................ 555
SRS airbag instructions for Canadian owners (in French)........................ 557
Camper information............ 567


Index


Abbreviation list........................ 574


Alphabetical index .................... 576


What to do if... ........................... 585


Pictorial index


Exterior


Access Cab models


Windshield wipers P. 156


Hood P. 404


Detachable pole antenna P. 335


Outside rear view mirrors P. 68
Outside rear view mirrors P. 68


Side turn signal lights P. 141


Front side marker lights P. 152


Headlights P. 152
Fog lights P. 155


Front turn signal lights/parking lights/ daytime running lights P. 141, 152, 154


Fuel filler door P. 74


Access doors P. 39


Side doors P. 35


Rear turn signal lights P. 141


Stop/tail lights P. 152


Tailgate P. 40


Tires ●Rotation ●Replacement ●Inflation pressure ●Information


P. 422
P. 486
P. 431
P. 540


License plate lights P. 152


Rear side marker lights P. 152


: If equipped


Pictorial index


Exterior


Double Cab models


Windshield wipers P. 156


Hood P. 404


Outside rear view mirrors P. 68


Detachable pole antenna P. 335


Side turn signal lights P. 141


Front side marker lights P. 152


Headlights P. 152


Fog lights P. 155


Front turn signal lights/parking lights/ daytime running lights


P. 141, 152, 154


Fuel filler door P. 74


Side doors P. 35


Rear turn signal lights P. 141


Stop/tail lights P. 152


Tailgate P. 40


Tires ●Rotation ●Replacement ●Inflation pressure ●Information


P. 422
P. 486
P. 431
P. 540


License plate lights P. 152


Rear side marker lights P. 152


: If equipped


Pictorial index


Interior


Seat belts P. 57


Bottle holders1 P. 344


Head restraints P. 53


Front console box1 P. 341


P. 144


Horn SRS driver airbag


P. 82


SRS front passenger airbag P. 82


Rear seats1 P. 49


Seatback table1 P. 361


Glove box P. 341


Floor mats P. 362


Front seats P. 45


SRS side airbags P. 82


10


Vanity mirrors P. 350


Overhead consoles P. 348


Interior light P. 339


SRS curtain shield


airbags P. 82


Sun visors


P. 349


Personal lights


P. 339


Anti-glare inside rear view mirror P. 64
Garage door opener2 P. 373
Compass2 P. 381


1: If equipped 2: Vehicles with auto anti-glare inside rear view mirror 11


Pictorial index


Interior


Window lock switch P. 71


Inside door lock button P. 36


Power window switches P. 71


Door lock switch P. 36


12


Vehicles with an automatic transmission


Shift lever P. 134


Cup holders P. 342


Cup holders P. 342


Shift lock override button P. 502


Vehicles with a manual transmission


Shift lever P. 138


Cup holders P. 342


13


Pictorial index


Interior


Access Cab models


Sub woofer P. 334


Back window lock release lever P. 73


Auxiliary boxes P. 345


14


: If equipped


Double Cab models


Bottle holders P. 344


Grocery bag hooks P. 371


Back window lock release lever1 P. 73


Flashlight holder P. 370


Storage boxes P. 369


Cargo net hooks2 P. 372


1: If equipped 2: Vehicles with sub woofer


15


Pictorial index


Instrument panel


Gauges and meters P. 145


Tilt and telescopic steering lock release lever P. 63


Tire pressure warning reset switch P. 423


Hood lock release lever P. 404


Parking brake pedal P. 142


Auxiliary box P. 345


Bottle holders P. 344


: Vehicles with an automatic transmission


16


Pictorial index


Instrument panel


Multimedia system2 P. 243
Rear view monitor system2


P. 166


Front-wheel drive control switch1 P. 177


Air conditioning system P. 236
Emergency flasher switch P. 466


A-TRAC switch2 P. 181


AUX port/USB port P. 249


Seat heater switches2 P. 359


Power outlets P. 352


1: 4WD models only 2: If equipped


17


Pictorial index


Instrument panel


Windshield wipers and washer switch P. 156


Engine (ignition) switch P. 131


Parking brake lever3 P. 142


Audio remote control switches*


Telephone switches*


Talk switch* Cruise control switch1 P. 162


18


Fog light switch1 P. 155


RR DIFF LOCK switch1 P. 185


Instrument panel light control dial P. 146


Power outlet main switch1 P. 353


Headlight switch P. 152


Turn signal lever P. 141
RSCA OFF switch2 P. 94


CLUTCH START CANCEL switch1 P. 190
DAC switch1 P. 188
VSC OFF switch P. 183, 192, 193


Outside rear view mirror switches1 P. 68


1: If equipped 2: 4WD models only


3:Vehicles with a manual transmission *: Refer to “NAVIGATION SYSTEM OWNER’S


MANUAL”.


19


Pictorial index


Luggage compartment


Back window P. 73


20


: If equipped


Pictorial index


Luggage compartment


Deck rails P. 202


Tie-down cleats P. 367


Deck hooks P. 366


Deck hooks P. 366


Auxiliary boxes P. 365


Deck hooks P. 366


Tie-down cleats P. 367


Deck rails P. 202


Auxiliary boxes P. 365


Power outlet P. 353


Deck hooks P. 366


: If equipped


21


For your information


Main Owners Manual


Please note that this manual applies to all models explains and all equip- ment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.


Noise from under vehicle after turning off the engine


Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.


Accessories, spare parts and modification of your Toyota


is not responsible


these products and


A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Modification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.


for


22


Installation of a mobile two-way radio system


The installation of a mobile two-way radio system in your vehicle could affect electronic systems such as: ● Multiport fuel injection system/sequential multiport fuel injection system ● Cruise control system ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system.


Vehicle data recordings


Your Toyota is equipped with several sophisticated computers that will record certain data, such as: • Engine speed • Accelerator status • Brake status • Vehicle speed • Shift position (except manual transmission) The recorded data varies according to the vehicle grade level and options with which it is equipped. Furthermore, these computers do not record con- versations, sounds or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if


the vehicle is leased In response to an official request by the police, a court of law or a govern- ment agency


• For use by Toyota in a lawsuit • For research purposes where the data is not tied to a specific vehicle or



vehicle owner


23


Event data recorder


This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as: • How various systems in your vehicle were operating; • Whether or not the driver and passenger safety belts were buckled/fas-


tened;


pedal; and,


• How far (if at all) the driver was depressing the accelerator and/or brake


• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ- ation occurs; no data are recorded by the EDR under normal driving condi- tions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.


24


● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle)


is obtained In response to an official request by the police, a court of law or a govern- ment agency



• For use by Toyota in a lawsuit However, if necessary, Toyota may: • Use the data for research on vehicle safety performance • Disclose the data to a third party for research purposes without disclosing


information about the specific vehicle or vehicle owner


Scrapping of your Toyota


The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.


Perchlorate Material


Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.


25


CAUTION


■General precautions while driving


Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.


■General precaution regarding children’s safety


Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.


26


Symbols used throughout this manual


Cautions & Notices


CAUTION


This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.


NOTICE


This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.


Symbols used in illustrations


The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.


Arrows indicating operations


Indicates the action (pushing, turning, etc.) used to operate switches and other devices. Indicates the outcome of an operation (e.g. a lid opens).


27


28


Before driving


1-1. Key information


Keys................................... 30


1-2. Opening, closing and locking


the doors Wireless remote control ..... 32
Side doors.......................... 35
Access doors (Access Cab models only) .................... 39
Tailgate .............................. 40


1-3. Adjustable components (seats, mirrors, steering wheel) Front seats......................... 45
Rear seats.......................... 49
Head restraints................... 53
Seat belts........................... 57
Steering wheel ................... 63
Anti-glare inside rear view mirror ....................... 64
Outside rear view mirrors... 68


1-4. Opening and closing


the windows Power windows .................. 71
Back window (vehicles with sliding type) .............. 73


1-5. Refueling


Opening the fuel tank cap ................................... 74


1-6. Theft deterrent system


Engine immobilizer system ............................. 77


1-7. Safety information


Correct driving posture....... 80
SRS airbags....................... 82
Front passenger occupant classification system ........ 95
Child restraint systems..... 100
Installing child restraints... 104


29


1-1. Key information Keys


The following keys are provided with the vehicle.


Vehicles without engine immobilizer system


Master keys Key number plate


Vehicles with engine immobilizer system


Master keys Key number plate


■Key number plate


Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (P. 503)


30


1-1. Key information


NOTICE


■To prevent key damage (vehicles with engine immobilizer system)


●Do not subject the keys to strong shocks, expose them to high tempera-


tures by placing them in direct sunlight, or get them wet.


●Do not expose the keys to electromagnetic materials or attach any mate-


rial that blocks electromagnetic waves to the key surface.


31


1-2. Opening, closing and locking the doors Wireless remote control


The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle.


is


that


the door


Locks all doors Check securely locked. Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3
seconds unlocks the other doors. Sounds alarm (push and hold)


■Operation signals


A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)


■ Panic mode


When is pushed for longer than about 1 second, an alarm will sound for about 60 seconds and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, push any button on the wireless remote control.


■Door lock buzzer


If a door is not fully closed, a buzzer sounds for 10 seconds if an attempt to lock the door is made. Fully close the door to stop the buzzer, and lock the vehicle once more.


: If equipped


32


1-2. Opening, closing and locking the doors


■Wireless remote control depletion


The standard battery life is 1 to 2 years. (The battery becomes depleted even if the key is not used.) If the wireless remote control function does not operate, the battery may be depleted. Replace the battery when necessary. (P. 442)


■If the wireless remote control does not operate


Locking and unlocking the doors: Use the key. (P. 35)


■Security feature


If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.


■Conditions affecting operation


The wireless remote control function may not operate normally in the follow- ing situations. ●Near a TV tower, radio station, electric power plant, airport or other facil-


ity that generates strong radio waves


●When carrying a portable radio, cellular phone or other wireless commu-


nication device


●When multiple wireless keys are in the vicinity ●When the wireless key has come into contact with, or is covered by a


metallic object


●When a wireless key (that emits radio waves) is being used nearby ●When the wireless key has been left near an electrical appliance such as


a personal computer


■When riding in an aircraft


When bringing a wireless remote control onto an aircraft, make sure you do not press any buttons on the wireless remote control while inside the aircraft cabin. If you are carrying a wireless remote control in your bag etc, ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the wireless remote control to emit radio waves that could inter- fere with the operation of the aircraft.


■Customization that can be configured at Toyota dealer


Settings (Customizable features P. 551)


(e.g. wireless


remote control system) can be changed.


33


1-2. Opening, closing and locking the doors


■ Certification for wireless remote control


MODEL/FCC IDs: Transmitter: GQ43VT20T Receiver: GQ4-34R IC (Canada) IDs: Transmitter: 1470A-1T Receiver: 1470A-6R MADE IN USA This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.


34


1-2. Opening, closing and locking the doors Side doors


The vehicle can be locked/unlocked using the wireless remote con- trol, key or door lock switch. ■ Wireless remote control (if equipped)


P. 32


■ Key


Locks all doors Unlocks all doors Turning the key a single time in the driver’s door unlocks the driver’s door, and turning the key again unlocks the other doors.


35


1-2. Opening, closing and locking the doors


■ Door lock switch (if equipped)


Driver’s door lock switch


Locks all doors Unlocks all doors


Passenger’s door lock switch


Locks all doors Unlocks all doors


■ Inside door lock button


Locks the door Unlocks the door Pulling the inside handle can open the front door even if the inside door lock button is in the lock position.


36


1


1-2. Opening, closing and locking the doors


Locking the front doors from the outside without a key


Move the inside door lock button to the lock position. Close the door.


Vehicles with power door lock system The door cannot be locked if a front door is open and the key is in the engine switch.


Rear door child-protector lock (Double Cab models only)


The door cannot be opened from inside the vehicle when the locks are set.


These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.


■Key reminder buzzer


A buzzer sounds if the driver’s door is opened, while the engine switch is in the ACC or LOCK position to remind you to remove the key.


37


1-2. Opening, closing and locking the doors


CAUTION


■To prevent an accident


Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●Always use a seat belt. ●Always lock all doors. ●Ensure that all doors are properly closed. ●Do not pull the inside handle of the doors while driving.


The doors may be opened and the passengers are thrown out of the vehi- cle and it may result in serious injury or death. Be especially careful for the front doors, as the doors may be opened even if the inside lock buttons are in locked position.


●Set the rear door child protector locks when children are seated in the rear


seat.


38


1


1-2. Opening, closing and locking the doors Access doors (Access Cab models only)


The access door (rear door) can be opened using the inside handle.


Open the front door widely Pull (from the outside) or push (from the inside) the inside handle of the access door. Open the access door You can open and close the access door only when the front door is widely opened.


NOTICE


■When opening or closing the front door and access door


The front door and access door could be damaged if they hit each other when being opened or closed.


39


1-2. Opening, closing and locking the doors Tailgate


The tailgate can be opened.


Pull the handle Open the tailgate slowly The support cables will hold the tailgate horizontal. After closing the tailgate, try pulling it toward you to make sure it is securely locked.


Removing the tailgate


■ Before removing the tailgate (vehicles with rear view monitor


system) These connector covers are used when removing the tailgate, to prevent the back-up camera wire harness connectors from being contaminated.


Connector cover (Gray) Connector cover (White) Store the connector covers in the glove box in a plastic bag when not using.


40


1-2. Opening, closing and locking the doors


and


To disconnect the wire harness connectors ( ), press and hold the lock of the tailgate wire harness connector (White) and pull apart.


Tailgate wire harness connec- tor (White) Frame wire harness connector (Gray)


Attach the connector cover (white) to the frame wire harness connector (Gray).


Connector cover (White) Frame wire harness connector (Gray)


Pull out the plastic wire protector located in the vehicle bed by pressing the tabs and pulling the protector.


Be careful not to pull out all of the tailgate wire harness. Doing so may result in damage to vehicle components. Plastic wire protector


Open the tailgate.


41


1-2. Opening, closing and locking the doors


■ Removing the tailgate


42


Pull out the wire harness from the vehicle bed.


Attach the connector cover (Gray) to the tailgate wire har- ness connector (White).


Tailgate wire harness connec- tor (White) Connector cover (Gray)


release


Open the tailgate to the angle where you can the brackets on the support cables from the lugs on both sides. Lift the support cable bracket up and slide it off.


Support cable bracket


Tilt the tailgate to about 30° from vertical and pull up the right side of the tailgate to unhook the right side.


1-2. Opening, closing and locking the doors


Slide the tailgate a little to the right to unhook the left side.


To attach the tailgate, follow the removal procedure in reverse order.


Rear step bumper


For rear end protection and eas- ier step-up loading.


To get on the rear step bumper, use the shaded area in the illus- tration.


CAUTION


■Before removing the tailgate (vehicles with rear view monitor system) Disconnect the wire harness between the back-up camera and the vehicle. Failure to do so may result in serious injury or damage to the vehicle compo- nents.


■Caution while driving


Observe the following precautions. Failure to do so may result in death or serious injury. ●Do not drive with the tailgate open. ●Do not let anyone ride on the rear step bumper.


43


1-2. Opening, closing and locking the doors


NOTICE


■To prevent damage to the tailgate wire harness (vehicles with rear view


monitor system) Do not pull out all of the tailgate wire harness before open the tailgate.


■To prevent damage to the camera lens (vehicles with rear view monitor


system) Store the removed tailgate with the back-up camera lens facing upward.


■After closing the tailgate


Try pulling it toward you to make sure it is securely locked.


■To prevent damage to the rear step bumper


Do not allow more than one person to get on the rear step bumper at a time.


44


1-3. Adjustable components (seats, mirrors, steering wheel) Front seats


Seat position adjustment lever Driver’s seat lumbar sup- port adjustment knob (if equipped) Seatback angle adjustment lever


45


1-3. Adjustable components (seats, mirrors, steering wheel)


Moving passenger’s seat for rear seat entry (if equipped)


Lift the seatback angle adjusting lever or press the pedal behind the seatback. The seat will slide forward. Move the seat to the front-most position.


■ After passengers are in the vehicle


Lift the seatback and return the seat until it locks.


Folding passenger’s seat


Pull the seatback angle adjusting lever and raise the seatback to its upright position.


Pull the seatback folding lever and fold the seatback down.


46


1-3. Adjustable components (seats, mirrors, steering wheel)


Active head restraints


When the occupant’s back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward to help reduce the risk of whiplash on the seat occupant.


■Active head restraints


Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may show the head restraint inner structure. These do not indicate problems.


During rear-end collision


Inner structure


■Waterproof and water-repellent seats (if equipped)


Waterproof and water-repellent seats are installed in your vehicle; however, the water-repellent effect does not last forever.


47


1-3. Adjustable components (seats, mirrors, steering wheel)


CAUTION


■Seat adjustment


●Be careful that the seat does not hit passengers or luggage. ●Do not recline the seat more than necessary when the vehicle is in motion


to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.


●After adjusting the seat, make sure that the seat is locked in position.


■After returning the seatback to the upright position


Observe the following precautions. Failure to do so may result in death or serious injury. ●Make sure the seatback is securely locked. ●Check that the seat belts are not twisted or caught in the seatback. ●Arrange the seat belts in the proper positions for ready use.


■Caution while driving


●Vehicles with seatback table: Do not sit on or place anything on the folded


seatback.


●Access Cab models only: Do not rest your foot on the press pedal behind


the passenger seat.


48


1


1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats


Access Cab models


The bottom cushion of the rear seats can be raised and lowered. ■ Before raising the bottom cushion


Stow the seat belt buckles.


This prevents the seat belt buckles from falling out when you fold the seatback.


■ Raising the bottom cushion


Raise the bottom cushion up while pulling the lever until it locks.


■ Lowering the bottom cushion


Push the bottom cushion down while pulling the lever until the bottom cushion locks into the seat position.


: If equipped 49


1-3. Adjustable components (seats, mirrors, steering wheel)


Double Cab models


The seatback of the rear seat can be folded. ■ Before folding rear seats


Stow the rear seat belt buck- les.


This prevents the seat belt buckles from falling out when you fold the seatback.


Pass the seat belts through the seat belt hangers.


This prevents the shoulder belt from being damaged. Make sure that the seat belts are removed from the hangers before using them.


Remove the head restraint Swing the bottom cushion up by pulling lock release strap


the


■ Folding rear seats


50


1-3. Adjustable components (seats, mirrors, steering wheel)


Attach the head restraints to the holders located on the back sides of the bottom cush- ions.


Fold down the seatback by pulling the lock release strap.


■Waterproof and water-repellent seats (if equipped)


Waterproof and water-repellent seats are installed in your vehicle; however, the water-repellent effect does not last forever.


51


1-3. Adjustable components (seats, mirrors, steering wheel)


CAUTION


■When the seatback is folded/the bottom cushion is raised


Do not sit on or place anything on the seatback or auxiliary box while driving.


■When returning the seats to their original position


Observe the following precautions. Failure to do so may result in death or serious injury. ●Be careful not to get your hands or feet pinched in the seat. ●Make sure the seatbacks and bottom cushions are securely locked. Fail-


ure to do so will prevent the seat belt from operating properly.


●Check that the seat belts are not twisted or caught under the seat. ●Arrange the seat belts in the proper positions for ready use.


NOTICE


■Before folding the seats


The seat belts buckles must be stowed.


52


1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints


Head restraints are provided for all seats. ■ Adjusting the head restraints


Front seat


Up Pull the head restraints up. Down Push the head restraint down while pushing the lock release button.


Lock release button


Rear seat (Double Cab models only)


Up Pull the head restraints up. Down Push the head restraint down while pushing the lock release button.


Lock release button


53


1-3. Adjustable components (seats, mirrors, steering wheel)


■ When using the rear head restraints


Access Cab models (vehicles with rear seats)


Double Cab models


To use Lift up the head restraint until it locks. To fold Pull the head restraint lock release lever to fold the head restraint.


To use Lift up the head restraint until it locks. To fold Pull the head restraint lock release lever to fold the head restraint.


54


1-3. Adjustable components (seats, mirrors, steering wheel)


■Removing the front head restraints


Pull the head restraint up while pushing the lock release button.


■Removing the rear head restraints (Double Cab models only)


Pull the head restraint up while pushing the lock release button.


■Installing the front head restraints


Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.


■Installing the rear head restraints (Double Cab models only)


Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.


55


1-3. Adjustable components (seats, mirrors, steering wheel)


■When installed the rear outboard head restraints to opposite direction


(Double Cab models only)


Push a flathead screwdriver into the slot. The slot is located on the left side of the right head restraint anchor.


While pressing in the screwdriver, pull up the head restraint.


■Adjusting the height of the head restraints


Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.


■Adjusting the rear center seat head restraints (Double Cab models)


Always raise the head restraint one level from the stowed position when using.


CAUTION


■Head restraint precautions


Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ●Use the head restraints designed for each respective seat. ●Adjust the head restraints to the correct position at all times. ●After adjusting the head restraints, push down on them and make sure


they are locked in position.


●Do not drive with the head restraints removed.


56


1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts


Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts


● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoul- der.


● Position the lap belt as low


as possible over the hips.


● Adjust the position of the seatback. Sit up straight and well back in the seat. ● Do not twist the seat belt.


■ Fastening and releasing the seat belt


Fastening the belt Push the tab into the buckle until a clicking sound is heard. Releasing the belt Press the release button.


Release button


57


1-3. Adjustable components (seats, mirrors, steering wheel)


■ Adjusting the height of the belt (front seats)


Up Move the height adjuster up as needed until you hear a click. Down Push the lock release button and slide the height adjuster down.


Seat belt pretensioners (front seats)


The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision or a vehicle rollover.


The pretensioner may not acti- vate in the event of a minor frontal impact, a side impact or a rear impact.


58


1-3. Adjustable components (seats, mirrors, steering wheel)


■Emergency locking retractor (ELR)


The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.


■Automatic locking retractor (ALR)


When a passenger’s shoulder belt is completely extended and then retracted even slightly, the belt is locked in that position and cannot be extended. This feature is used to hold the child restraint system (CRS) firmly. To free the belt again, fully retract the belt and then pull the belt out once more. (P. 104)


■Pregnant women


Obtain medical advice and wear the seat belt in the proper way. (P. 57) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants. Extend the shoulder belt com- pletely over the shoulder and position the belt across the chest. Avoid belt contact over the rounding of the abdominal area. If the seat belt is not worn properly, not only a pregnant woman, but also the fetus could suffer death or serious injury as a result of sudden braking or a collision.


■People suffering illness


Obtain medical advice and wear the seat belt in the proper way.


■Child seat belt usage


The seat belts of your vehicle were principally designed for persons of adult size. ●Use a child restraint system appropriate for the child, until the child become large enough to properly wear the vehicle’s seat belt. (P. 100) ●When the child becomes large enough to properly wear the vehicle’s


seat belt, follow the instructions on P. 57 regarding seat belt usage.


59


1-3. Adjustable components (seats, mirrors, steering wheel)


■Replacing the belt after the pretensioner has been activated


If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent colli- sions.


■Seat belt extender


If your seat belts cannot be fastened securely because long enough, a personalized seat belt extender is available from your Toyota dealer free of charge.


they are not


CAUTION


Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failing to do so may cause death or severe injury. ■Wearing a seat belt


●Ensure that all passengers wear a seat belt. ●Always wear a seat belt properly. ●Each seat belt should be used by one person only. Do not use a seat belt


for more than one person at once, including children.


●Toyota recommends that children be seated in the rear seat and always


use a seat belt and/or an appropriate child restraint system.


●Do not recline the seat any more than necessary to achieve a proper seat- ing position. The seat belt is most effective when the occupants are sitting up straight and well back in the seats.


●Do not wear the shoulder belt under your arm. ●Always wear your seat belt low and snug across your hips.


60


1


1-3. Adjustable components (seats, mirrors, steering wheel)


CAUTION


■When children are in the vehicle


Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to chocking or other serious inju- ries that could result in death. If this occurs and the buckle cannot be unfas- tened, scissors should be used to cut the belt.


■Seat belt pretensioners


●Do not place anything, such as a cushion, on the front passenger’s seat.


Doing so will disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the seat belt pretensioner for the front passenger’s seat may not activate in the event of a collision.


●If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer.


■Adjustable shoulder anchor


Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (P. 58)


■Seat belt damage and wear


●Do not damage the seat belts by allowing the belt, plate, or buckle to be


jammed in the door.


●Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from death or serious injury.


●Ensure that the belt and tab are locked and the belt is not twisted.


If the seat belt does not function correctly, immediately contact your Toyota dealer.


●Replace the seat assembly, including the belts, if your vehicle has been


involved in a serious accident, even if there is no obvious damage.


61


1-3. Adjustable components (seats, mirrors, steering wheel)


CAUTION


■Seat belt damage and wear


●Do not attempt to install, remove, modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.


■Using a seat belt extender


●Do not wear the seat belt extender, if you can fasten the seat belt without


the extender.


●Do not use the seat belt extender when installing a child restraint system, because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.


●The personalized extender may not be safe on another vehicle, when used by another person, or at a different seating position other than the one originally intended.


NOTICE


■When using a seat belt extender


When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself.


62


1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel


The steering wheel can be adjusted to a comfortable position.


Hold the steering wheel and press the lever down.


Adjust to the ideal position by moving the steering wheel horizontally and vertically.


After adjustment, pull the lever up the steering wheel.


to secure


CAUTION


■Caution while driving


Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious injury.


■After adjusting the steering wheel


Make sure that the steering wheel is securely locked. Otherwise, the steering wheel may move suddenly, possibly causing an accident and resulting in death or serious injury.


63


1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror


Glare from the headlights of vehicles behind can be reduced by using the following functions.


Manual anti-glare inside rear view mirror


Normal position Anti-glare position


64


1-3. Adjustable components (seats, mirrors, steering wheel)


Auto anti-glare inside rear view mirror (type A)

Loading...
x
