2002 Toyota Prius Owners Manual

to the number of additional keys your Toyota dealer can make for you. If you make your own duplicate key, you will not be able to cancel the sys- tem or start the hybrid system.

For vehicles sold in U.S.A.

For vehicles sold in Canada

FCC ID: MOZ RI–9BTY–1
MADE IN JAPAN This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause unde- sired operation.

This device complies with RSS–210 of industry Canada. Operation is subject to the following two conditions: (1) This device may not cause interfer- ence, and (2) this device must accept any interference that may cause undesired operation of the device.

interference,

including

NOTICE

CAUTION

Do not modify, remove or disas- semble the hybrid vehicle immobiliser system. If any unauthorized changes or modifications are made, the proper operation of the system cannot be guaranteed.

Changes or modifications not ex- pressly approved by the party respon- sible for compliance could void the user’s authority to operate the equip- ment.

21

Side doors—

21p008

The driver’s window can be opened and closed from outside the vehicle using a key. For details, see “Power windows” on page 28 in this section.

LOCKING AND UNLOCKING WITH KEY Insert the key into the keyhole and turn it. To lock: Turn the key forward. To unlock: Turn the key backward. All lock and unlock simulta- neously with either front door. In the driv- er’s door lock, turning the key once will unlock the driver’s door and twice in suc- cession will unlock all the doors simulta- neously.

the doors

22

21p009

IN-

LOCKING AND UNLOCKING WITH SIDE LOCK KNOB Move the lock knob. To lock: Push the knob forward. To unlock: Pull the knob backward. The driver’s door can be opened by pull- ing the inside door handle even if the lock knob is depressed. Closing the door with the lock knob in the lock position will also lock the door. Be careful not to lock your keys in the ve- hicle. The door cannot be locked if you leave the key in the ignition switch.

21p010

Driver’s side

21p011

Passenger’s side

LOCKING AND UNLOCKING WITH POWER DOOR LOCK SWITCH Push the switch. To lock: Push the switch on the front side. To unlock: Push the switch on the rear side. All the doors lock or unlock simultaneous- ly.

21p012a

to

the

lock

lever

the “LOCK”

REAR DOOR CHILD–PROTECTORS Move position as shown on the label. This feature allows you to lock a rear door so it can be opened from the outside only, not from inside. We recommend us- ing this feature whenever small children are in the vehicle.

23

CAUTION

Before driving, be sure that the doors are closed and locked, especially when small children are in the ve- hicle. Along with the proper use of seat belts, locking the doors helps prevent the driver and passengers from being thrown out from the ve- hicle during an accident. It also helps prevent the doors from being opened unintentionally.

24

—Wireless remote control

21p013e

Locking operation

21p014d

Unlocking operation

THE

AND

UNLOCKING

The wireless remote control system is designed to lock or unlock both doors, or activate the theft deterrent system from a distance within approximately 1
m (3 ft.) of the vehicle. LOCKING DOORS To lock and unlock all the doors, push the switches of the transmitter slowly and securely. To lock: Push the “LOCK” switch. All the doors are locked simultaneously. At this time the parking lights, side marker lights, license plate lights and tail lights will flash once. Check to see that the doors are securely locked. If either door is not securely closed, lock- ing cannot be performed by the “LOCK” switch.

the

to unlock

the “UNLOCK” switch

“UNLOCK” switch To unlock: Push once the only driver’s door. Pushing the switch twice within 3 seconds unlocks all the doors simultaneously. Each time the “UNLOCK” switch is pushed, the parking lights, side marker lights, license plate lights and tail lights will flash twice. When is pressed the interior light comes on. The lights re- mains on for about 15 seconds unless either door is opened then and closed. (For “Interior lights” on page 84 in Section 2–3.) You have 30 seconds to open a door after using the wireless remote unlock feature. If a door is not opened by then, all the doors will be automatically locked again. If the “LOCK” or “UNLOCK” switch is kept pressed in, the locking or unlocking opera- tion is not repeated. Release the button and then push again.

information,

further

see

21p015

WIRELESS REMOTE CONTROL TRANS- MITTER The wireless remote control transmitter is an electronic component. Observe the fol- lowing instructions in order not to cause damage to the transmitter. (cid:1) Do not leave the transmitter on places the temperature becomes high

where such as on the dashboard.

(cid:1) Do not disassemble it. (cid:1) Avoid knocking

it hard against other

objects or dropping it.

flashes

to break

“PANIC” SWITCH Pushing the “PANIC” switch blows the horn intermittently and the headlights and tail lights. The “PANIC” switch is used to deter ve- hicle theft when you witness anyone at- tempting into or damage your vehicle. The alarm will have for one minute. To stop alarm midway, push the “PANIC” or “UNLOCK” switch once again, unlock any door with the key or transmitter, or turn the ignition key from the “LOCK” to “ON” position. The “PANIC” mode does not work when the ignition key is in the “ON” position.

for

transmitters

(cid:1) Avoid putting it in water. You can use up to 4 wireless remote con- the same vehicle. trol Contact your Toyota dealer for detailed information. If the wireless remote control transmitter does not actuate the doors or alarm, or operate from a normal distance. (cid:1) Check for closeness to a radio trans- mitter such as a radio station or an airport which can interfere with normal operation of the transmitter.

(cid:1) The batteries may have been con- sumed. Check the battery in the trans- mitter. To replace the battery, see “RE- PLACING TRANSMITTER BATTERY” below.

25

interference

NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc- tions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer- ence television reception, which can be determined by turning the equipment off and on, the user is en- couraged to try to correct the interfer- ence by one or more of the following measures:

to radio or

If you lose your transmitter, contact your Toyota dealer as soon as possible to avoid the possibility of theft, or an acci- dent. (See “If you lose your wireless re- mote control transmitter” on page 183 in Section 5.) For vehicles sold in U.S.A.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause unde- sired operation.

26

(cid:1) Reorient or relocate the receiving an-

tenna.

(cid:1) Increase the separation between the

equipment and receiver.

(cid:1) Connect the equipment into an outlet to

on a circuit different which the receiver is connected.

from

that

(cid:1) Consult the dealer or an experienced

radio/TV technician for help.

FCC WARNING: Changes or modifications not ex- pressly approved by the party respon- sible for compliance could void the user’s authority to operate the equip- ment.

For vehicles sold in Canada

(1)

Operation is subject to the following two conditions: this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

REPLACING TRANSMITTER BATTERY For replacement, use CR2016 lithium bat- tery or equivalent.

CAUTION

Special care should be that small children do not swallow the re- moved transmitter battery or compo- nents.

taken

NOTICE

(cid:2) During replacing the transmitter battery, do not push the “LOCK” and “UNLOCK” switches many times.

(cid:2) When replacing the transmitter bat- tery, be careful not to lose the components.

(cid:2) Replace only with the same or equivalent type recommended by a Toyota dealer.

(cid:2) Dispose of used batteries according

to the local laws.

Replace the transmitter battery by the fol- lowing procedures.

21p016b

21p017b

1. Using a coin or equivalent, open the

2. Remove the discharged transmitter bat-

transmitter case.

tery.

NOTICE

Do not bend the terminals.

27

21p018b

3. Put a new transmitter battery with posi-

tive (+) side up.

Close the transmitter case securely.

NOTICE

(cid:2) Make sure the positive side and negative side of the transmitter bat- tery should be faced correctly.

(cid:2) Do not replace the battery with wet hands. Water may cause unexpected rust.

(cid:2) Do not touch or move any compo- nents inside the transmitter, or it may interfere with proper operation. (cid:2) Be careful not to bend the electrode of the transmitter battery insertion and that dust or oils do not adhere to the transmitter case.

(cid:2) Close the transmitter case securely.

replacing battery, check

After the transmitter operates properly. If the trans- mitter still does not operate properly, con- tact your Toyota dealer.

that

28

Power windows

21p019

The windows can be operated with the switch on each door. The power windows work when the ignition switch is in the “ON” position. Key off operation: If both front doors are closed, they work for 45 seconds even after the ignition switch is turned off. They stop working when either is opened. OPERATING THE DRIVER’S WINDOW Use the switch on the driver’s door. Normal operation: The window moves as long as you hold the switch. To open: Lightly push down the switch. To close: Lightly pull up the switch.

front door

21p020a

Automatic operation: Push the switch completely down or pull it completely up, and then release it. The window will fully open or close. To stop the window part- way, lightly move the switch in the oppo- site direction and then release it. Jam protection function: During automat- ic closing operation or key off closing op- eration, the window stops and opens half– way if something gets caught between the window and window frame. If the window receives a strong impact, this function may work even if nothing is caught.

CAUTION

(cid:1) Never try jamming any part of your jam protection

body to make the function work intentionally.

(cid:1) The

jam protection

function may not work if something gets caught just before fully closed.

the window

is

Window lock switch

21p021

OPERATING THE PASSENGERS’ WINDOWS Use the switch on each passenger’s door or the switches on the driver’s door that control each passengers’ win- dow. The window moves as long as you hold the switch. To open: Push down the switch. To close: Pull up the switch. If you push in the window lock switch on the driver’s door, the passengers’ windows cannot be operated.

29

CAUTION

To avoid serious personal injury, you must do the following. (cid:1) Always make sure the head, hands and other parts of the body of all occupants are kept completely in- side the vehicle before you close the power windows. If someone’s neck, head or hands gets caught in a closing window, it could result in a serious injury. When anyone closes the power windows, be sure that they operate the windows safe- ly.

(cid:1) When small children are in the ve- hicle, never let them use the power window switches without supervi- sion. Use the window lock switch to prevent from making unex- pected use of the switches.

them

(cid:1) Never leave small children alone in the vehicle, especially with the igni- tion key still inserted. They could use the power window switches and in a window. Unat- get tended children can become in- volved in serious accidents.

trapped

21p023

the

into

the key

OPERATING THE DRIVER’S WINDOW FROM OUTSIDE THE VEHICLE The driver’s window can be raised or low- ered using an ignition key. Insert ignition key hole. To close the window: Turn the key in the locking direction and hold it. After the door is locked, the window be- gins to close. To stop in the middle, return the key. To open the window: Turn the key in the unlocking direction and hold it. After the window begins to open. To stop in the middle, return the key.

is unlocked,

the door

21p022b

30

Trunk lid—

—Lock release lever

CAUTION

Keep the trunk lid closed while driv- ing. This not only keeps the luggage from being thrown out, but also pre- vents exhaust gases from entering the vehicle. (cid:1) Always lock the trunk lid and all doors, and keep away the vehicle keys out of children’s reaches.

(cid:1) Never leave children unattended in the vehicle. Unsupervised children may lock themselves in the vehicle or trunk and suffer serious injuries or death.

21p025a

To open the trunk lid from the driver’s seat, pull up on the lock release lever.

21p024a

To open the trunk lid from the outside, insert the key and turn it clockwise. See “Luggage stowage precautions” on page 156 in Section 3 for precautions to observe in loading luggage. To close the trunk lid, lower it and press down on it. After closing the trunk lid, try pulling it up to make sure it is securely closed.

31

—Lock release lever cancelling system

—Internal trunk release handle

Hood

21p042

21p033c

21p026a

After closing the trunk lid, insert the master key and turn it counterclockwise to deactivate the lock release lever. After closing the trunk lid, try pulling it up to make sure it is securely locked.

If a person is locked in the trunk, he or she can pull down the phosphores- cent handle on the inside of trunk lid in case of emergency to open the trunk lid. The (glow–in–the–dark) handle will continue to glow for a time after the trunk lid is closed. Exposing the handle to stronger light will cause it to glow longer.

phosphorescent

To open the hood: 1. Pull the hood lock release lever. The

hood will spring up slightly.

CAUTION

Before driving, be sure that the hood is closed and securely locked. Other- wise, the hood may open unexpected- ly while driving and an accident may occur.

32

21p027c

21p032c

NOTICE

Be sure to return the support rod to its clip before closing the hood. Clos- ing the hood with the support rod inserted into the slot could cause the hood to bend.

2. In front of the vehicle, pull up the the

lever and

lift

auxiliary catch hood.

3. Hold the hood open by inserting the

support rod into the slot.

Before closing the hood, check to see that you have not forgotten any tools, rags, etc. and return its clip—this prevents rattles. Then lower the hood and make sure it locks into place. If necessary, press down gently on the front edge to lock it.

the support rod

to

CAUTION

After inserting the support rod into the slot, make sure the rod supports the hood securely from falling down on to your head or body.

33

Theft deterrent system

21p028

21p029a

To deter the vehicle theft, the system is designed to give an alarm if any of the doors, trunk or hood is forcibly un- locked or the battery terminal is discon- nected and then reconnected when the vehicle is locked. The alarm blows the horn intermittently and flashes the headlights and tail lights.

34

SETTING THE SYSTEM 1. Turn

the ignition key position and remove it.

to the ”LOCK”

is

removed

The indicator light will start flashing when the key ignition switch. (See ”Hybrid vehicle immobiliser system” on page 20 for details.) 2. Have all passengers get out of

from

the

the

vehicle.

3. Close and lock all the doors, trunk and

hood.

The indicator light will come on when all the doors, trunk and hood are closed and locked.

The system will automatically be set after 30 seconds. When the system is set, the indicator light will start flashing again. 4. After making sure

light starts flashing, you may leave the ve- hicle.

indicator

the

Never leave anyone in the vehicle when you set the system, because unlocking from the inside will activate the system. WHEN THE SYSTEM IS SET Activating the system The system will give the alarm under the following conditions: (cid:1) If any of the doors is unlocked or if the trunk or hood is forcibly opened without the key or wireless remote con- trol transmitter.

(cid:1) If the battery terminal is disconnected

and then reconnected.

The indicator light will come on when the system is activating.

indicator

If any of the doors are unlocked without the key or wireless remote control trans- mitter and the key is not in the ignition switch, all the doors will be automatically locked again. After 1 minute, the alarm will automatically stop and the light will starts flashing again. Reactivating the alarm Once set, the system automatically resets the alarm after the alarm stops. The alarm will activate again under the same in circumstances ”Activating the system”. Stopping the alarm The alarm will be stopped by the following three ways: (cid:1) Turn the ignition key from the ”LOCK”

described

to ”ON” position.

(cid:1) Unlock any of the doors with the key or wireless remote control transmitter.

(cid:1) Open the trunk with the key. CANCELLING THE SYSTEM The system will be cancelled by above mentioned three ways.

the

there

to see

If the tail lights come on for 2 seconds, theft deterrent system has been the alarmed. Check if is any abnormality on your vehicle. TESTING THE SYSTEM 1. Open all the windows. 2. Set

the system as described above. The doors should be locked with the key or wireless remote control transmit- ter. Be sure to wait until the indicator light goes off or starts flashing.

3. Unlock any door from the inside. The

system should activate the alarm.

for

this operation

4. Stopping the alarm as described above. 5. Repeat the other doors, trunk and hood. When testing on the trunk, also check that the system is activated when the auxiliary battery terminal is disconnected and then re- connected. When testing on the hood, release the hood lock release lever and raise the hood. the system does not work properly,

If have it checked by your Toyota dealer.

lock with

the

Fuel tank cap

21p030c

1. To open the fuel filler door, pull the

lever up. When refueling, turn off the hybrid system.

35

CAUTION

(cid:1) Do not smoke, cause spark or allow flames when refueling. The

open fumes are flammable.

(cid:1) When opening the cap, do not re- move the cap quickly. In hot weath- er, fuel under pressure could cause injury by spraying out filler neck is suddenly re- moved.

the cap

the

if

21p031c

CAUTION

(cid:1) Make sure the cap is tightened se- in

curely to prevent fuel spillage case of an accident.

(cid:1) Use only a genuine Toyota fuel tank cap for replacement. It is designed to regulate fuel tank pressure.

(cid:1) Insert the fuel nozzle fully, or fuel

may splash out.

2. To remove the fuel tank cap, turn the cap slowly counterclockwise, then pause slightly before removing it. After removing the cap, hang it on the cap hanger.

the cap clockwise

It is not unusual to hear a slight swoosh when the cap is opened. When installing, turn till you hear a click. If the cap is not tightened securely, the malfunction lamp comes on. Make sure the cap is tightened securely. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible.

indicator

36

SECTION 2– 2

OPERATION OF INSTRUMENTS AND CONTROLS Seats, Seat belts, Steering wheel and mirrors Seats Front seatss Head restraints Seat belts SRS driver and front passenger airbags SRS side airbags Child restraint Tilt steering wheel Outside rear view mirrors Anti–glare inside rear view mirror Vanity mirror

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

38
38
40
40
48
55
61
76
76
78
79

37

Seats While the vehicle is being driven, all ve- hicle occupants should have the seatback upright, sit well back in the seat and prop- erly wear the seat belts provided.

CAUTION

in

(cid:1) Do not drive the vehicle unless the occupants are properly seated. Do not allow them to sit on top of a folded–down seatback, or the luggage compartment or cargo area. Persons not properly seated and/or properly restrained by seat belts can be severely injured in the event of emergency braking or a collision. (cid:1) During driving, do not allow pas- to stand up or move sengers around between seats. Severe inju- ries can occur in the event of emer- gency braking or a collision.

38

Front seats— —Front seat precautions (on vehicles with SRS side airbags)

CAUTION

The SRS side airbags are installed in the driver and front passenger seats. Observe the following precautions. (cid:1) Do not lean against the front door when the vehicle is in use. Other- wise you may be killed or seriously injured when in- flates with considerable speed and force.

the side airbag

(cid:1) Do not modify or replace the seats or surface of the front seats with the side airbags. Such changes may disable the system or cause the side airbags to inflate, resulting in death or serious injury. Consult your Toyota dealer.

for

(cid:1) Do not use accessories

the seats which cover the parts where the side airbags should inflate. Such accessories may prevent the side airbags from activating correct- ly, causing death or serious injury.

—Seat adjustment precautions Adjust the driver’s seat so that the foot pedals, steering wheel and instrument panel controls are within easy reach of the driver.

CAUTION

(cid:1) Adjustments should not be made while the vehicle is moving, as the seat may unexpectedly move and cause the driver to lose control of the vehicle.

(cid:1) When adjusting the seat, be careful not to hit the seat against a pas- senger or luggage.

(cid:1) After adjusting the seat position, try sliding it forward and backward to make sure it is locked in posi- tion.

(cid:1) After adjusting the seatback, exert body pressure to make sure it is locked in position.

(cid:1) Do not put objects under the seats. The objects may interfere with the seat–lock mechanism or unexpect- edly push up the seat position ad- justing the seat may suddenly move, causing the driver to lose control of the vehicle.

lever. Otherwise,

—Adjusting front seats

(cid:1) While adjusting the seat, do not put your hands under the seat or near the moving parts. Otherwise, you may catch and injure your hands or fingers.

22p001c

1. SEAT POSITION ADJUSTING LEVER Hold the center of the lever and pull it up. Then slide the seat to the desired position with slight body pressure and release the lever. 2. SEATBACK ANGLE ADJUSTING

LEVER

lever up. lean back to the desired angle

Lean forward and pull the Then and release the lever.

CAUTION

To reduce the risk of sliding under the lap belt during a collision, avoid reclining the seatback any more than needed. The seat belts provide maxi- mum protection in a frontal or rear collision when the driver and the pas- senger are sitting up straight and well back If you are reclined, the lap belt may slide past your hips and apply restraint forces directly to the abdomen. Therefore, in the event of a frontal collision, the risk of personal injury may increase with increasing recline of the seat- back.

in the seats.

39

For your safety and comfort, adjust the head restraint before driving, To raise: Pull it up. To lower: Push it down while pressing the lock release button. The head restraint is most effective when it is close to your head. Therefore, using a cushion on the seatback is not recom- mended.

CAUTION

(cid:1) Adjust the center of the head re- straint so that it is closest to the top of your ears.

(cid:1) After adjusting the head restraint, make sure it is locked in position. the head re-

(cid:1) Do not drive with

straints removed.

Seat belts— —Seat belt precautions Toyota strongly urges that the driver and passengers in the vehicle be properly re- strained at all times with the seat belts provided. Failure to do so could increase the chance of injury and/or the severity of injury in accidents. Child. Use a child restraint system ap- propriate for the child until the child be- comes large enough to properly wear the vehicle’s seat belts. (For details, see “Child restraint—” on page 61 in this sec- tion.) If a child is too large for a child restraint system, the child should sit in the rear seat and must be restrained using the vehicle’s seat belt. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat. If a child must sit in the front seat, the seat belts should be worn properly. If an accident occurs and seat belts are not worn properly, the force of the rapid infla- tion of the airbag may cause death or serious injury to the child.

Head restraints

22p002a

22p003a

Front

Rear

40

Do not allow the child to stand up or kneel on either rear or front seats. An unrestrained child could suffer serious in- jury or death during emergency braking or a collision. Also, do not let the child sit on your lap. It does not provide sufficient restraint. Pregnant woman. Toyota recommends the use of a seat belt. Ask your doctor for specific lap belt should be worn securely and as low as possible over the hips and not on the waist. Injured person. Toyota recommends the use of a seat belt. Depending on the inju- ry, first check with your doctor for specific recommendations.

recommendations. The

(cid:1) Inspect the belt system periodically. Check for cuts, fraying, and loose parts. Damaged parts should be re- placed. Do not disassemble or modify the system.

(cid:1) Keep the belts clean and dry.

If they need cleaning, use a mild soap solution or lukewarm water. Never use bleach, dye or abrasive clean- ers—they may severely weaken the belts. (See “Cleaning the interior” on page 189 in Section 6.)

(cid:1) Replace the belt assembly (includ- ing bolts) if it has been used in a severe impact. The entire assembly should be replaced even if damage is not obvious.

CAUTION

the vehicle

in their seats Persons should ride their seat belts properly wearing whenever is moving. Otherwise, they are much more likely to suffer serious bodily injury or death in the event of sudden braking or a collision. When using the seat belts, observe the following: (cid:1) Use the belt for only one person at a time. Do not use a single belt for two or more people—even children. (cid:1) Avoid reclining the seatbacks too much. The seat belts provide maxi- mum protection when the seatbacks are in the upright position. (Refer to the seat adjustment instructions.) (cid:1) Be careful not to damage the belt webbing or hardware. Take care that they do not get caught or pinched in the seat or doors.

41

—Front and rear seat belts

22p004a

If the seat belt cannot be pulled out of the retractor, firmly pull the belt and release it. You will then be able to smoothly pull the belt out of the retractor. When a passenger’s shoulder belt is com- pletely extended and retracted even slightly, the belt is locked in that position and cannot be extended. This fea- ture is used to hold the child restraint system securely. (For details, see “Child restraint—” on page 61 in this Section.) To free the belt again, fully retract the belt and then pull the belt out once more.

then

is

Adjust the seat as needed (Front seats only) and sit up straight and well back in the seat. To fasten your belt, pull it out of the retractor and insert the tab into the buckle. You will hear a click when the tab locks into the buckle. The seat belt length automatically adjusts to your size and the seat position. The retractor will lock the belt during a sudden stop or on impact. It also may lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around freely.

CAUTION

(cid:1) After inserting the tab, make sure the tab and buckle are locked and that the belt is not twisted.

(cid:1) Do not insert coins, clips, etc. in the buckle as this may prevent you from properly latching the tab and buckle.

(cid:1) If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed. It cannot protect an adult occupant or your child from injury.

42

22p005a

Seat belts with an adjustable shoulder anchor— Adjust the shoulder anchor position to your size. To raise: Slide the anchor up. To lower: Push in the lock release button and slide the anchor down. After adjustment, make sure the anchor is locked in position.

CAUTION

Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause serious injuries in a collision.

Take up slack

22p006a

Too high

Keep as low on hips as possible

CAUTION

(cid:1) Both high–positioned lap belts and loose–fitting belts could cause seri- ous injuries due to sliding under the lap belt during a collision or other unintended result. Keep the lap belt positioned as low on hips as possible.

(cid:1) For your safety, do not place the

shoulder belt under your arm.

the

lap and

the position of

Adjust shoulder belts. Position the lap belt as low as possible on your hips—not on your waist, then ad- just it to a snug fit by pulling the shoulder portion upward through the latch plate.

43

from your Toyota dealer

—Seat belt extender If your seat belts cannot be fastened se- curely because they are not long enough, a personalized seat belt extender is avail- able free of charge Please contact your local Toyota dealer to order the proper required length for the extender. Bring the heaviest coat you ex- pect to wear for proper measurement and selection of length. Additional ordering in- formation is available at your Toyota deal- er.

CAUTION

(cid:1) Remember that the extender pro- vided for you may not be safe when used on a different vehicle, for another person, or at a different seating position than the one origi- nally intended.

the

When using the seat belt extender, following precautions. observe Failure to follow these instructions could reduce the effectiveness of the seat belt restraint system in case of vehicle the chance of personal injury. (cid:1) Never use the seat belt extender if you can fasten the seat belt without it.

increasing

accident,

22p007

To release the belt, press the buckle–re- lease button and allow the belt to re- tract. If the belt does not retract smoothly, pull it out and check for kinks or twists. Then make sure it remains untwisted as it re- tracts.

44

CAUTION

(cid:1) After inserting the tab, make sure the tab and buckle are locked and that the lap and shoulder portions of the belt is not twisted.

(cid:1) Do not insert coins, clips, etc. in the buckle as this may prevent you from properly latching the tab and buckle.

(cid:1) If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed. It cannot protect an adult occupant or your child from injury.

22p008

To connect the extender to the seat belt, insert the tab into the seat belt buckle so that the ”PRESS” signs on the buckle–release buttons of the ex- tender and the seat belt are both facing outward as shown. You will hear a click when the tab locks into the buckle. When releasing the seat belt, press on the buckle–release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and extend- er itself. When not and store in the vehicle for future use.

in use, remove the extender

—Front seat belt pretensioners

22p009

The driver and front passenger’s seat belts pretensioners are designed to be activated in response to a severe fron- tal impact. When the airbag sensor detects the shock of a severe frontal impact, the front seat belts are quickly drawn back in by the retractor so that the belts snugly restrain the front seat occupants. The front seat belt pretensioners are acti- vated even with no passenger in the front seat. Collisions occurring at certain speeds and angles may cause the seat belt preten- sioners and SRS airbags not to operate all together.

45

When the front seat belt pretensioners are activated, an operating noise may be heard and a small amount of smoke–like gas may be released. This gas is harm- less and does not indicate that a fire is occurring. Once front seat belt pretensioners the have been activated, the seat belt retrac- tors remain locked.

CAUTION

Do not modify, remove, strike or open the front seat belt pretensioner as- semblies, airbag sensor or surround- ing area or wiring. Doing any of these may cause sudden operation of the front seat belt pretensioners or disable the system, which could re- sult in death or serious injury. Failure to follow these instructions can result in death or serious inju- ries.

22p010

22p011

This indicator comes on when the igni- tion key is turned to the “ACC” or “ON” position. It goes off after about 6 seconds. This means the front seat belt pretensioners are operating proper- ly. The warning light system monitors the air- bag sensor assembly, front airbag sen- sors, side airbag sensors, front seat belt pretensioner assemblies, warning light, in- terconnecting wiring and power sources. (For details, see “Service reminder indica- tors and warning buzzers” on page 91 in Section 2–4.)

The front seat belt pretensioner system mainly consists of the following compo- nents and their locations are shown in the illustration. 1. Front airbag sensors 2. SRS warning light 3. Front seat belt pretensioner assemblies 4. Airbag sensor assembly The front seat belt pretensioners are con- trolled by the airbag sensor assembly. The airbag sensor assembly consists of a saf- ing sensor and airbag sensor.

46

NOTICE

Do not perform any of the following changes without consulting your Toyota dealer. Such changes can in- terfere with proper operation of the front seat belt pretensioners in some cases. (cid:2) Installation of electronic devices such as a mobile two–way radio, cassette tape player or compact disc player

(cid:2) Repairs on or near the front seat

belt retractor assemblies

(cid:2) Modification of the suspension sys-

tem

(cid:2) Modification of the front end struc-

ture

(cid:2) Attachment of a grille guard (bull bar, kangaroo bar, etc.), snowplow, winches or any other equipment to the front end

(cid:2) Repairs made on or near the front fenders, front end structure or con- sole

22p010

22p012

This front seat belt pretensioner system has a service reminder indicator to inform the driver of operating problems. If either of the following conditions occurs, this in- dicates a malfunction of the airbags or pretensioners. Contact your Toyota dealer as soon as possible to service the ve- hicle. (cid:1) The light does not come on when the ignition key is turned to the “ACC” or “ON” position, or remains on.

(cid:1) The light comes on or flashes while

driving.

(cid:1) If either front seat belt does not retract or can not be pulled out due to a malfunction or activation of the relevant front seat pretensioner.

In the following cases, contact your Toyota dealer as soon as possible: (cid:1) The front seat belt pretensioner assem- bly or surrounding area has been dam- aged.

(cid:1) The front part of the vehicle (shaded in the illustration) was involved in an accident that was not severe enough to cause the front seat belt pretensioners to operate.

(cid:1) Either front seat belt pretensioner as- sembly is scratched, cracked, or otherwise dam- aged.

surrounding

area

or

47

SRS driver and front passenger airbags

22p013

The SRS (Supplemental Restraint Sys- tem) front airbags are designed to pro- vide further protection for the driver and front passenger in addition to the primary safety protection provided by the seat belts. In response to a severe frontal impact, the SRS front airbags work together with the seat belts to help reduce injury by inflating. The SRS front airbags help to reduce injuries mainly to the driver’s or front passenger’s head or chest directly hitting the steering wheel or dashboard. The is activated even with no passenger in the front seat. Be sure to wear your seat belt properly.

front passenger airbag

48

Your vehicle is equipped with a crash sensing and diagnostic module, which will record the use of the seat belt restraint system by the driver and passenger when the SRS airbags are inflated.

CAUTION

A driver or front passenger who is too close to the steering wheel or dashboard during airbag deployment can be killed or seriously injured. To- yota strongly recommends that: (cid:1) The driver sit as far back as pos- sible from the steering wheel while still maintaining control of the ve- hicle.

(cid:1) The front passenger sit as far back

as possible from the dashboard.

(cid:1) All vehicle occupants be properly restrained using the available seat belts.

22p010

This indicator comes on when the igni- tion key is turned to the “ACC” or “ON” position. It goes off after about 6 seconds. This means the SRS front airbags are operating properly. The warning light system monitors the air- bag sensor assembly, front airbag sen- sors, side airbag sensors, front seat belt pretensioner assemblies, warning light, in- terconnecting wiring and power sources. (For details, see “Service reminder indica- tors and warning buzzers” on page 91 in Section 2–4.)

this

If the severity of the impact is below the above threshold level, the SRS front air- bags may not deploy. However, threshold velocity will be considerably higher if the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact, or if it is involved in an underride collision (e.g. a collision in which the nose of the vehicle “underrides”, or goes under, the bed of a truck, etc.). It is possible that in some collisions at the lower zone of airbag sensor detection and activation, the SRS airbags and seat belt pretensioners will not operate all together. For the safety of all occupants, always wear your seat belts properly.

22p015b

Collision from the rear

Collision from the side

Vehicle rollover

The SRS front airbags are not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low–speed frontal collision.

22p014

The SRS front airbag system is de- signed to activate in response to a se- vere frontal impact within the shaded area between the arrows in the illustra- tion. The SRS front airbags will deploy if the severity of the impact is above the de- signed threshold level, comparable to an approximate 25 km/h (15 mph) collision when impacting straight into a fixed barrier that does not move or deform.

49

22p017a

The SRS airbag system consists mainly of the following components and their loca- tions are shown in the illustration. 1. Front airbag sensors 2. SRS warning light 3. Airbag module for front passenger (air-

bag and inflator)

4. Airbag sensor assembly 5. Airbag module for driver (airbag and

inflator)

The airbag sensor assembly consists of a safing sensor and airbag sensor.

In a severe frontal impact, the sensors detect deceleration and the system trig- gers the airbag inflators. At this time a chemical reaction in the inflators quickly fills the airbags with non–toxic gas to help restrain the forward motion of the occu- pants. When the airbags inflate, they produce a fairly loud noise and release some smoke and residue along with non–toxic gas. This does not indicate a fire. This gas is nor- mally harmless; however, for those who have delicate skin, it may cause a minor skin irritation. Be sure to wash off any residue as soon as possible to prevent any potential skin irritation. Deployment of the airbags happens in a fraction of a second, so the airbags must inflate with considerable force. While the system is designed to reduce serious inju- ries, it may also cause minor burns or abrasions and swelling. Parts of the airbag module (steering wheel hub, dashboard) may be hot for several minutes, but the airbags themselves will not be hot. The airbags are designed to inflate only once.

Hitting a curb, edge of pavement or hard material

22p016b

Falling into or jump- ing over a deep hole

Landing hard or vehicle falling

The SRS front airbags may deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.

50

the windshield as

A crash severe enough to inflate the air- bags may break the vehicle buckles. In vehicles with a pas- senger airbag the windshield may also be damaged by absorbing some of the force of the inflating airbag.

CAUTION

(cid:1) The SRS airbag system is designed only as a supplement to the prima- ry protection of the driver side and front passenger side seat belt sys- tems. The front seat occupants can be killed or seriously injured by the inflating airbags if they do not wear the available seat belts properly. During sudden braking just before a collision, an unrestrained driver or front passenger can move for- ward into direct contact with or close proximity to the airbag which may then deploy during the colli- sion. To ensure maximum protection in an accident, the driver and all passengers the vehicle must wear their seat belts properly. Wear- ing a seat belt during an accident reduces the chances of death or serious injury or being thrown out of the vehicle. For instructions and precautions concerning the seat belt system, see “Seat belts—” on page 40 in this section.

in

restraint

(cid:1) Improperly seated and/or restrained infants and children can be killed or seriously injured by the deploy- ing front airbags. An infant or child who is too small to use a seat belt should be properly secured using a child Toyota strongly recommends in- fants and children be placed in the rear seat of the vehicle and proper- ly restrained. The rear seat is the safest for infants and children. For instructions concerning the installa- tion of a child restraint system, see “Child restraint—” on page 61 in this section.

that all

system.

51

(cid:1) For

instructions concerning

the installation of a child restraint sys- tem, see “Child restraint—” on page 61 in this section.

22p018a

22p019

Move seat fully back

(cid:1) Never put a rear–facing child re- straint system on the front passen- ger seat because the force of the rapid inflation of the front passen- ger airbag can cause death or seri- ous injury to the child.

52

(cid:1) A

forward–facing child

restraint system should be allowed to be put on the front seat only when it is unavoidable. Always move the seat as far back as possible, because the force of the deploying front air- bag could cause death or serious injury to the child.

(cid:1) On vehicles with side airbags, do not allow the child to lean against the front door or around the front door even if the child is seated in the child restraint system. It is dan- gerous if the side airbag inflates, because impact could cause death or serious injury to the child.

the

22p020a

22p021a

22p022b

is

in use, since

(cid:1) Do not sit on the edge of the seat lean over the dashboard when or the vehicle the front airbags inflate with consider- able speed and force. Otherwise, you may be killed or seriously in- jured. Sit up straight and well back in the seat, and always use your seat belt properly.

the

(cid:1) Do not allow a child to stand up or to kneel on front passenger seat, since the front airbag inflates with considerable speed and force. Otherwise, the child may be killed or seriously injured.

(cid:1) Do not hold a child on your lap or in your arms. Use a child restraint system in the rear seat. For instruc- tions concerning the installation of a child restraint system, see “Child restraint—” on page 61 in this sec- tion.

(cid:1) Do not put objects or your pets on or in front of the dashboard or steering wheel pad that houses the front airbag system. They might re- strict inflation or cause death or serious injury as they are projected rearward by the force of deploying airbags. Likewise, the driver and front passenger should not hold ob- jects their knees.

their arms or on

in

53

(cid:1) Do not modify or remove any wir- ing. Do not modify, remove, strike or open any components, such as the steering wheel pad, steering wheel, column cover, front passen- ger airbag cover, front passenger airbag or airbag sensor assembly. Doing any of these may cause sud- den SRS front airbag inflation or disable the system, which could re- sult in death or serious injury.

instructions Failure to follow these can result in death or serious injury.

NOTICE

Do not perform any of the following changes without consulting your Toyota dealer. Such changes can in- terfere with proper operation of the SRS front airbag system in some cases. (cid:2) Installation of electronic devices such as a mobile two–way radio, cassette tape player or compact disc player

(cid:2) Modification of the suspension sys-

tem

(cid:2) Modification of the front end struc-

ture

(cid:2) Attachment of a grille guard (bull bar, kangaroo bar, etc.), snowplow, winches or any other equipment to the front end

(cid:2) Repairs made on or near the front fenders, front end structure, con- sole, steering column, steering wheel or dashboard near the front passenger airbag

22p010

This SRS front airbag system has a ser- vice reminder indicator to inform the driver of operating problems. If either of the fol- lowing conditions occurs, this indicates a malfunction of the airbags. Contact your Toyota dealer as soon as possible to ser- vice the vehicle. (cid:1) The light does not come on when the ignition key is turned to the “ACC” or “ON” position, or the light remains on.

(cid:1) The light comes on while driving.

54

SRS side airbags

NOTICE

Do not disconnect the battery cables before contacting your Toyota dealer.

22p023a

22p024a

In the following cases, contact your Toyota dealer as soon as possible: (cid:1) The SRS front airbags have been in-

flated.

(cid:1) The front of the vehicle (shaded in the illustration) was involved in an accident that was not severe enough to cause the SRS front airbags to inflate.

(cid:1) The pad section of the steering wheel or cover (shaded in the illustration) is scratched, cracked, or otherwise damaged.

passenger

airbag

front

The SRS (Supplemental Restraint Sys- tem) side airbags are designed to pro- vide further protection for the driver and front passenger in addition to the primary safety protection provided by the seat belts. In response to a severe side impact, the SRS side airbags work together with the seat belts to help reduce injury by inflat- ing. The SRS side airbags help to reduce injuries mainly to the driver’s or front pas- senger’s chest. The SRS side airbag on the passenger seat is activated even with no passenger in the front seat. Be sure to wear your seat belt properly.

55

Your vehicle is equipped with a crash sensing and diagnostic module, which will record the use of the seat belt restraint system by the driver and passenger when the SRS side airbags are inflated.

CAUTION

SRS side airbags inflate with consid- erable force. To avoid potential death or serious injury when they inflate, the driver and front passenger must: (cid:1) Wear their seat belts properly. (cid:1) Remain properly seated with their back upright and against the seat at all times.

56

22p010

22p025

This indicator comes on when the igni- tion key is turned to the “ACC” or “ON” position. It goes off after about 6 seconds. This means the SRS side airbags are operating properly. The warning light system monitors the air- bag sensor assembly, front airbag sen- sors, side airbag sensors, front seat belt pretensioner assemblies, warning light, in- terconnecting wiring and power sources. (For details, see “Service reminder indica- tors and warning buzzers” on page 91 in Section 2–4.)

from

The SRS side airbag system may not inflate if the vehicle is subjected to a collision the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment as shown in the illustra- tion. The SRS side airbags are designed to inflate when the passenger compartment area suffers a severe the side. For the safety of all occupants, always wear your seat belts properly.

impact

from

Collision from the rear

22p026b

22p027

Collision from the front

Vehicle rollover

The SRS side airbags are not designed to inflate if the vehicle is involved in a front or rear collision, if it rolls over, or if it is involved in a low–speed side collision.

The SRS side airbag system consists mainly of the following components, and their locations are shown in the illustra- tion. 1. SRS warning light 2. Side airbag modules

(airbag and inflator) 3. Side airbag sensors 4. Airbag sensor assembly The SRS side airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sen- sor and airbag sensor.

In a severe side impact, the side airbag sensor triggers the side airbag inflators. Then a chemical reaction in the inflators quickly fills the airbags with non–toxic gas to help restrain the lateral motion of the occupants. When the airbags inflate, they produce a fairly loud noise and release some smoke and residue along with non–toxic gas. This does not indicate a fire. This gas is nor- mally harmless; however, for those who have delicate skin, it may cause a minor skin irritation. Be sure to wash off any residue as soon as possible to prevent any potential skin irritation. Deployment of the airbags happen in a fraction of a second, so the airbags must inflate with considerable force. While the system is designed to reduce serious inju- ries, it may also cause minor burns or abrasions and swelling. Front seats may be hot for several min- utes, but the airbags themselves will not be hot. The airbags are designed to inflate only once.

57

CAUTION

(cid:1) The SRS side airbag system is de- signed only as a supplement to the primary protection of the driver side and front passenger side seat belt systems. To ensure maximum protection in an accident, the driver and all passengers in the vehicle must wear their seat belts properly. Wearing a seat belt properly during an accident reduces the chances of death or serious injury or being thrown out of the vehicle. For in- structions and precautions concern- ing the seat belt system, see “Seat belts” on page 40 in this section.

58

restraint

(cid:1) Improperly seated and/or restrained infants and children can be killed or seriously injured by the deploy- ing airbags. An infant or child who is too small to use a seat belt should be properly secured using a child Toyota strongly recommends in- fants and children be placed in the rear seat of the vehicle and proper- ly restrained. The rear seat is the safest for infants and children. For instructions concerning the installa- tion of a child restraint system, see “Child restraint” on page 61 in this section.

that all

system.

if he/she

(cid:1) Do not allow a child to lean his/her head or any part of his/her body against the front door or the area of the seat from which the side air- bag deploys even is seated in the child restraint system. It is dangerous if the side airbag inflates, and the impact could cause death or serious injury to the child. For the installation of a child restraint sys- tem, see “Child restraint” on page 61 in this section.

instructions concerning

22p028b

(cid:1) Do not lean against the front door when the vehicle is in use, since the side airbag inflates with consid- erable speed and force. Otherwise, you may be killed or seriously in- jured.

(cid:1) Sit up straight and well back in the seat, distributing your weight even- ly in the seat. Do not apply exces- sive weight to the outer side of the front seats on vehicles with side airbags.

for

(cid:1) Do not use accessories

the seats which cover the parts where the side airbags inflate. Such acces- sories may prevent the side airbags from activating correctly, causing death or serious injury.

(cid:1) Do not modify or replace the seats or upholstery of front seats with the side airbags. Such changes may disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury. Failure to follow these instructions can result in death or serious injury. Consult your Toyota dealer about any
