2012 Toyota Prius Owners Manual

Abbreviation list Abbreviation/Acronym list

ABBREVIATIONS A/C ABS ALR APGS CRS DISP ECO ECU EDR ELR EPS EV GAWR GPS GVWR I/M LATCH LED MMT M + S MTBE

MEANING

Air Conditioning Anti-lock Brake System Automatic Locking Retractor Advanced Parking Guidance System Child Restraint System Display Economy/Ecology Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Electric Vehicle Gross Axle Weight Ratings Global Positioning System Gross Vehicle Weight Rating Emission Inspection and Maintenance Lower Anchors and Tethers for Children Light Emitting Diode Methylcyclopentadienyl Manganese Tricarbonyl Mud and Snow Methyl Tertiary Butyl Ether

616

Abbreviation list

ABBREVIATIONS OBD PCS PWR SRS TIN TPMS TRAC TWI VIN VSC

MEANING

On Board Diagnostics Pre-Collision System Power Supplemental Restraint System Tire Identification Number Tire Pressure Monitoring (Warning) System Traction Control Treadwear Indicator Vehicle Identification Number Vehicle Stability Control

617

For your information

Main Owner’s Manual

Please note that this manual applies to all models and explains all equip- ment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of color and equipment.

Noise from under vehicle after turning off the hybrid system

Approximately five hours after the hybrid system is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.

Accessories, spare parts and modification of your Toyota

A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Mod- ification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addi- tion, damage or performance problems resulting from the modification may not be covered under warranty.

22

Installation of a mobile two-way radio system

The installation of a mobile two-way radio system in your vehicle could affect electronic systems such as: ● Multiport fuel injection system/sequential multiport fuel injection system ● Cruise control system ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation. High voltage parts and cables on the hybrid vehicles emit approximately the same amount of electromagnetic waves as the conventional gasoline pow- ered vehicles or home electronic appliances despite of their electromagnetic shielding. Unwanted noise may occur in the reception of the mobile two-way radio.

23

Vehicle control and operation data recording

Your Toyota is equipped with sophisticated computers that record certain information about your vehicle’s operation, such as: • Engine speed • Electric motor speed (traction motor speed) • Accelerator status • Brake status • Vehicle speed • Shift position The data recorded varies according to the grade level and options the vehi- cle is equipped with. The computers do not record conversations, sound or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if

the vehicle is leased In response to an official request by the police, a court of law or a govern- ment agency

• For research purposes where the data is not tied to a specific vehicle or

•

vehicle owner

● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.

24

Event data recorder

This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as: • How various systems in your vehicle were operating; • Whether or not the driver and passenger safety belts were buckled/fas-

• How far (if at all) the driver was depressing the accelerator and/or brake

tened;

pedal; and,

• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ- ation occurs; no data are recorded by the EDR under normal driving condi- tions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

25

● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle)

is obtained In response to official request by the police, a court of law or a govern- ment agency.

• For use by Toyota in a law suit However, if necessary, Toyota may: • Use the data for research on vehicle safety performance • Disclose the data to a third party for research purposes without disclosing

•

information about the specific vehicle or vehicle owner

Scrapping of your Toyota

The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.

Perchlorate Material

Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.

26

CAUTION

■General precautions while driving

Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.

■General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

■Disposal of the hybrid battery (traction battery)

If your vehicle is disposed of without the hybrid battery (traction battery) hav- ing been removed, there is a danger of serious electric shock if high voltage parts, cables and their connectors are touched. In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery (traction battery) is not disposed of properly, it may cause electric shock that can result in death or serious injury.

27

Symbols used throughout this manual

Cautions & Notices

CAUTION

This is a warning against something which, if ignored, may cause death or serious injury to people. You are informed about what you must or must not do in order to reduce the risk of death or serious injury to yourself and others.

NOTICE

This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.

Symbols used in illustrations

Safety symbol

The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.

Arrows indicating operations

Indicates the action (pushing, turn- ing, etc.) used to operate switches and other devices. Indicates the outcome of an opera- tion (e.g. a lid opens).

ITOPP105

28

TABLE OF CONTENTS

1 Before driving

Information on the hybrid system and adjusting and op- erating features such as door locks, mirrors, and steer- ing column

2 When driving

Driving, stopping and safe-driving information

3 Interior features

Air conditioning and audio systems, as well as other in- terior features for a comfortable driving experience

4 Maintenance

and care

Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information

5 When trouble

arises

What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident

6 Vehicle

specifications

Detailed vehicle information

7 For owners

Reporting safety defects for U.S. owners, and seat belt and SRS airbag instructions for Canadian owners

Index

Alphabetical listing of information contained in this manual

1-1. Hybrid system Hybrid system features

Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.

Gasoline engine Electric motor (traction motor)

30

1-1. Hybrid system

■ When stopped/during start off

The gasoline engine stops* when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped* and the electric motor (traction motor) is used. When shift position is in N, the hybrid battery (traction battery) will not be charged. Thus, shift to P when the vehicle is stopped. In addition, when driving in heavy traffic, use D or B. *: However, when the hybrid battery (traction battery) need to be charged or while the engine is being warmed up, the gasoline engine may not stop automatically. (→P. 33)

■ During normal driving

The gasoline engine is predominantly used. The electric motor (traction motor) charges the hybrid battery (traction battery) as necessary.

■ When accelerating sharply

When the accelerator pedal is depressed heavily, the power of the hybrid battery (traction battery) is added to that of the gaso- line engine via the electric motor (traction motor).

■ When braking (regenerative braking)

The electric motor (traction motor) charges the hybrid battery (traction battery).

31

1-1. Hybrid system

Vehicle proximity notification system

When driving with the gasoline engine stopped, a sound, which changes in accordance with the driving speed, will be played in order to warn people nearby of the vehicle’s approach. The sound will stop when the vehicle speed exceeds approximately 15 mph (25 km/h).

■Regenerative braking

In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery). ●The accelerator pedal is released while driving with the shift position in D

or B.

●The brake pedal is depressed while driving with the shift position in D or

B.

■Hybrid System Indicator

Hybrid System Indicator represents the hybrid system power output and regener- ative charging. (→P. 225)

32

1-1. Hybrid system

■Conditions in which the gasoline engine may not stop

The gasoline engine starts and stops automatically. However, it may not stop automatically in the following conditions*: ●During gasoline engine warm-up ●When the temperature of the hybrid battery (traction battery) is high or

low

●During hybrid battery (traction battery) charging ●When the heater is switched on *: Depending on the circumstances, the gasoline engine may also not stop

automatically in situations other than those above.

■Charging the hybrid battery (traction battery)

●As the gasoline engine charges the hybrid battery (traction battery), the battery does not need to be charged from an outside source. However, if the vehicle is left parked for a long time the hybrid battery (traction bat- tery) will slowly discharge. For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 10 miles (16 km). If the hybrid battery (traction battery) becomes fully discharged and you are unable to jump-start the vehicle with the 12-volt battery, contact your Toyota dealer.

●If the shift position is in N, the hybrid battery (traction battery) will not be charged. Always shift the shift position in P when the vehicle is stopped. When driving in heavy traffic, operate the vehicle with the shift position in D or B to avoid discharging the hybrid battery (traction battery).

■Charging the 12-volt battery

→P. 546

■After the 12-volt battery has discharged or has been changed or

removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer.

33

1-1. Hybrid system

■Sounds and vibrations specific to a hybrid vehicle

There may be no engine sounds or vibration even though the vehicle is able to move. For safety, apply the parking brake and make sure to shift the shift position to P when parked. The following sounds or vibrations may occur when the hybrid system is operating and are not a malfunction: ●The brake system operation sound heard from the front of the vehicle

when the driver’s door is opened.

●Motor sounds may be heard from the engine compartment. ●Sounds may be heard from the hybrid battery (traction battery) when the

hybrid system starts or stops.

●Sounds may be heard from the transmission when the gasoline engine

starts or stops, when driving at low speeds, or during idling.

●Engine sounds may be heard when accelerating sharply. ●Sounds may be heard due to regenerative braking when the brake pedal

is depressed and accelerator is loosened.

●Other sounds, such as motors and mechanical noises, may be heard

from the brake system when the brake pedal is depressed.

●Vibration may be felt when the gasoline engine starts or stops. ●Cooling fan sounds may be heard from the air intake vent. (→P. 37) ●The operation sound of the air conditioning system (air conditioning com-

pressor, blower motor).

34

1

1-1. Hybrid system

■Vehicle proximity notification system

In the following cases, the vehicle proximity notification system may be diffi- cult for surrounding people to hear. ●In very noisy areas ●In the wind or the rain Also, as the vehicle proximity notification system is installed on the front of the vehicle, it may be more difficult to hear from the rear of the vehicle com- pared to the front.

■Maintenance, repair, recycling, and disposal

Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself.

35

1-1. Hybrid system Hybrid system precautions

Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle.

Air conditioning compressor High voltage cables (orange) Power control unit and DC/ DC converter Caution label

Service plug Electric motor motor) Hybrid battery (traction bat- tery)

(traction

36

1

1-1. Hybrid system

Hybrid battery (traction battery) air vent

There is an air intake vent on the right side of the rear seatback for the purpose of cooling the hybrid battery (traction battery). If the vent becomes blocked, the hybrid battery (traction battery) may overheat, to a reduction in hybrid battery (trac- tion battery) output.

leading

Emergency shut off system

When a certain level of impact is detected by the impact sensor, the emergency shut off system blocks off the high voltage current and stops the fuel pump to minimize the risk of electrocution and fuel leakage. If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer.

Hybrid warning message

A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.

If a warning message is shown on the multi-information display, read the message and follow the instructions. (→P. 507)

37

1-1. Hybrid system

■If a warning light comes on, a warning message is displayed or the 12-

volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer.

■Running out of fuel

When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (→P. 498) go off. If there is only a small amount of fuel, the hybrid system may not be able to start. (The minimum amount of fuel to add to make the low fuel level warning light go out is about 1.9 gal. [7.1 L, 1.6 Imp.gal.], when the vehicle is on a level surface. This value may vary when the vehicle is on a slope.)

■Electromagnetic waves

●High voltage parts and cables on the hybrid vehicles incorporate electro- magnetic shielding, and therefore emit approximately the same amount of electromagnetic waves as conventional gasoline powered vehicles or home electronic appliances.

●Your vehicle may cause sound interference in some third party-produced

radio parts.

■Hybrid battery (traction battery)

The hybrid battery (traction battery) has a limited service life. The lifespan of the hybrid battery (traction battery) can change in accordance with driving style and driving conditions.

38

1

1-1. Hybrid system

CAUTION

■High voltage precautions

The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●Never touch, disassemble, remove or replace the high voltage parts,

cables or their connectors.

●The hybrid system will become hot after starting as the system uses high voltage. Be careful of both the high voltage and the high temperature, and always obey the caution labels attached to the vehicle.

●Never try to open the service plug access hole located in the luggage compartment. The service plug is used only when the vehicle is serviced and is subject to high voltage.

39

1-1. Hybrid system

CAUTION

■Road accident cautions

If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury: ●Stop the vehicle in a safe place to prevent subsequent accidents.

While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off. Then, slowly release the brake pedal.

●Do not touch the high voltage parts, cables and connectors. ●If electric wires are exposed inside or outside your vehicle, an electric

shock may occur. Never touch exposed electric wires.

●If a fluid leak occurs, do not touch the fluid as it may be strong alkaline electrolyte from the hybrid battery (traction battery). If it comes into contact with your skin or eyes, wash it off immediately with a large amount of water or, if possible, boric acid solution. Seek immediate medical attention.

●If a fire occurs in the hybrid vehicle, leave the vehicle as soon as possible. Never use a fire extinguisher that is not meant for electric fires. Using even a small amount of water may be dangerous.

●If your vehicle needs to be towed, do so with front wheels raised. If the wheels connected to the electric motor (traction motor) are on the ground when towing, the motor may continue to generate electricity. This may cause an electricity leakage leading to a fire. (→P. 485)

●Carefully inspect the ground under the vehicle. If you find that liquid has leaked onto the ground, the fuel system may have been damaged. Leave the vehicle as soon as possible. ■Hybrid battery (traction battery)

Your vehicle contains a sealed nickel-metal hydride battery. If disposed of improperly, it is hazardous to the environment and there is a risk of severe burns and electrical shock that may result in death or serious injury.

40

1-1. Hybrid system

NOTICE

■Hybrid battery (traction battery) air vent

●Do not put foreign objects near the air vent. The hybrid battery (traction

battery) may overheat and be damaged.

●Clean the air vent regularly to prevent the hybrid battery (traction battery)

from overheating.

●Do not wet or allow foreign substances to enter the air vent as this may

cause a short circuit and damage the hybrid battery (traction battery).

●Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer.

●If the rear seat belt becomes separated from the guide (→P. 103), it could obstruct the hybrid battery (traction battery) air vent. Set the rear seat belt into the guide to use.

41

1-1. Hybrid system Energy monitor/consumption screen

You can view the status of your hybrid system on the Display Audio system screen, the navigation system screen or the multi-informa- tion display.

Audio

Display system screen or navigation system screen Multi-information display

Energy monitor

Displays the flow of energy as it changes in accordance with driving conditions. Display Audio system

Press “CAR”.

If the “Consumption” screen is displayed, touch “Energy”.

42

Condition

Display

When the vehicle is powered by the electric motor (traction motor)

When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)

When the vehicle is powered by the gasoline engine

1-1. Hybrid system

43

1-1. Hybrid system

Condition

Display

When the vehicle is charging the hybrid battery (traction battery)

When there is no energy flow

Hybrid battery (traction battery) status

Low

Full

These images are examples only, and may vary slightly from actual conditions.

44

1-1. Hybrid system

Navigation system

STEP 1

Press “INFO APPS” or “INFO”.

STEP 2

Touch “Fuel Consumption” on the “Information” screen.

If the “Consumption” screen is displayed, touch “Energy”.

45

1-1. Hybrid system

Condition

Display

When the vehicle is powered by the electric motor (traction motor)

When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)

When the vehicle is powered by the gasoline engine

46

Condition

Display

1-1. Hybrid system

When the vehicle is charging the hybrid battery (traction battery)

When there is no energy flow

Hybrid battery (traction battery) status

Low

Full

These images are examples only, and may vary slightly from actual conditions.

47

1-1. Hybrid system

Multi-information display

Press the “DISP” button to dis- play the energy monitor.

■ Names and meaning of each icons

Gasoline engine Hybrid battery (traction bat- tery) Electric motor (traction motor)

Condition

Display

When the vehicle is powered by the electric motor (traction motor)

When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)

48

1-1. Hybrid system

Condition

Display

When the vehicle is powered by the gasoline engine

When the vehicle is charging the hybrid battery (traction battery)

When there is no energy flow

Hybrid battery (traction battery) status

Low

Full

These images are examples only, and may vary slightly from actual conditions.

49

1-1. Hybrid system

Consumption screen

Display Audio system Press “CAR”.

If the “Energy Monitor” screen is displayed, touch “Consumption”.

Fuel consumption in the past 30 minutes Cruising range (→P. 55) Regenerated energy past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown.

the

in

The image is example only, and may vary slightly from actual conditions. Navigation system

STEP 1

STEP 2

Press “INFO APPS” or “INFO”. Touch “Fuel Consumption” on the “Information” screen. If the “Energy Monitor” screen is displayed, touch “Consumption”.

Fuel consumption in the past 30 minutes Regenerated energy past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown. Cruising range (→P. 55)

the

in

The image is example only, and may vary slightly from actual conditions.

50

1

Multi-information display

1-1. Hybrid system

Press the “DISP” button to dis- play the 5-minute or 1-minute fuel consumption display.

Press and hold the “DISP” button to switch between 5-minute and 1-minute fuel consumption dis- plays. The display will alternate with each press of the button.

5-minute interval fuel consumption

1-minute interval fuel consumption

Fuel consumption Displays the average fuel con- sumption for the last 30 minutes in intervals of 5 minutes or the last 15 minutes in intervals of 1
minute. Regenerated energy Displays the amount of energy generated over the last 30 min- utes in intervals of 5 minutes or the last 15 minutes in intervals of 1 minute. One symbol indicates 50 Wh (5- minute interval display) or 30 Wh (1-minute interval display). Up to 8 symbols are shown.

51

EV indicator*1
Eco Driving Indicator Light*1
Average speed*2
Average fuel consumption/eco savings*2
Use the displayed average fuel consumption as a reference.

*1: →P. 225
*2:The current amount since the trip meter was reset will be displayed. These functions can be reset by pressing and holding the “TRIP” button when either the 5-minute or 1-minute fuel con- sumption display is being shown. The display can be switched between average fuel consump- tion/average speed and eco sav- ings. (→P. 232)

interval

1-1. Hybrid system

52

1

1-1. Hybrid system

Monthly fuel consumption record/Eco savings record (multi- information display only)

Press the “DISP” button to dis- play the monthly fuel consump- tion record or eco savings record.

Press and hold the “DISP” button to switch the display between monthly fuel consumption record and eco savings record. The display will alternate with each press of the button.

Monthly fuel consumption record display Displays the average fuel consumption for the previous 6 months.

Average fuel consumption for the previous 6 months EV indicator* Eco Driving Indicator Light* Driving distance month *: →P. 225

for each

53

1-1. Hybrid system

Eco savings record display By setting the comparison consumption and the gasoline value beforehand (→P. 231), the difference is calculated when the actual consumption is less than the comparison consumption, and the amount of money saved is displayed*1. If the comparison consumption is set to 0, the consumption cost is displayed*1. *1: The displayed amount is intended only as a guide and may differ from

the actual amount.

Savings or consumption costs for the previous 6 months EV indicator*2
Eco Driving Indicator Light*2
Driving distance month

for each

*2: →P. 225

■Remaining hybrid battery (traction battery) charge display

The charge amount of the hybrid battery (traction battery) is automatically controlled by the hybrid system. For this reason, even if electricity is recov- ered via the regenerative braking, or electricity is generated via the gasoline engine, the displayed hybrid battery (traction battery) charge amount may not reach the highest level (level 8). However, this does not indicate a mal- function.

54

1

1-1. Hybrid system

■Resetting the consumption data

Display Audio system Selecting “Clear” on the “Consumption” screen will reset the fuel consump- tion and the regenerated energy for the past 30 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data. Navigation system Selecting “Clear” on the “Consumption” screen will reset the fuel consump- tion and the regenerated energy for the past 30 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data. Multi-information display If the “POWER” switch is turned OFF, average fuel consumption and regen- erated energy data will be reset.

■Resetting the monthly fuel consumption/eco savings record

Press and hold the “TRIP” button while the monthly fuel consumption/eco savings record is displayed. A confirmation message will be displayed. Press and hold the “TRIP” button to reset the data. Press the “DISP” button to cancel the reset operation. The screen will return to the previous display if no buttons are pressed for approximately 10 sec- onds.

■Cruising range

Displays the estimated maximum distance that can be driven with the quan- tity of fuel remaining. This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that dis- played.

■Odometer/trip meter/distance to empty

The odometer/trip meter/distance to empty will not be displayed while the monthly fuel consumption record or the eco savings record is being dis- played.

55

1-1. Hybrid system Hybrid vehicle driving tips

For economical and ecological driving, pay attention to the following points: ■ Using Eco drive mode

When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions. In addition, the opera- tion of the air conditioning system (heating/cooling) will be mini- mized, improving the fuel economy. (→P. 204)

■ Use of Hybrid System Indicator

Eco-friendly driving is possible by keeping the indicate of Hybrid System Indicator within Eco area. (→P. 225)

■ When braking the vehicle

Make sure to operate the brakes gently and in good time. A greater amount of electrical energy can be retained when slow- ing down.

■ Delays

Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel consumption. Check traffic reports before leaving and avoid delays as much as possible. When encountering a delay, gently release the brake pedal to allow the vehicle to move forward slightly while avoiding overuse of the accelerator pedal. Doing so can help control excessive gasoline consumption.

■ Highway driving

Control your speed and keep at a constant speed. Also, before stopping at a toll booth or similar, allow plenty of time to release the accelerator and gently apply the brakes. A greater amount of electrical energy can be retained when slowing down.

56

1-1. Hybrid system

■ Air conditioning on/off

) to off when it is not needed.

Switch the air conditioning ( Doing so can help control excessive gasoline consumption. In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well. In winter: Because the gasoline engine will not automatically cut out until the gasoline engine and the interior of the vehicle are warm, it will consume fuel. Also, fuel consumption can be improved by avoiding overuse of the heater.

■ Checking tire inflation pressure

Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel consump- tion. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel consumption. Use a tire that is appropriate for the season.

■ Luggage

Carrying heavy luggage can lead to poor fuel consumption. Avoid carrying unnecessary luggage. Installing a large roof rack can also cause poor fuel consumption.

■ Warming up before driving

Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary. Moreover, frequently driving short distances will cause the engine to repeatedly warm up, which can lead to poor fuel consumption.

57

1-2. Key information Keys

The following keys are provided with the vehicle.

Electronic keys • Operating

the smart key

system (→P. 61, 79)

• Operating

the wireless

• Operating the Remote Air

remote control function (→P. 85) Conditioning System* (→P. 342)

Mechanical keys Key number plate

Using the mechanical key

*: If equipped

To take out the mechanical key, push the release button and take the key out.

After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (→P. 541)

58

1-2. Key information

■Key number plate

Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 540)

■When riding in an aircraft

When bringing an electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying an electronic key in your bag etc., ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the elec- tronic key to emit radio waves that could interfere with the operation of the aircraft.

59

1-2. Key information

NOTICE

■To prevent key damage

Observe the following: ●Do not drop the keys, subject them to strong shocks or bend them. ●Do not expose the keys to high temperatures for long periods of time. ●Do not get the keys wet or wash them in an ultrasonic washer etc. ●Do not attach metallic or magnetic materials to the keys or place the keys

close to such materials.

●Do not disassemble the keys. ●Do not attach a sticker or anything else to the surface of the electronic key. ●Do not place the keys near objects that produce magnetic fields, such as TVs, audio systems and glass top ranges, or medical electrical equipment, such as low-frequency therapy equipment.

■Carrying the electronic key on your person

Carry the electronic key 3.9 in. (10 cm) or more away from electric appli- ances that are turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the electronic key may interfere with the key, causing the key to not function properly.

■In case of a smart key system malfunction or other key-related prob-

lems Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer.

■When a vehicle key is lost

If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.

60

1-3. Opening, closing and locking the doors Smart key system (with entry function)

The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.)

Unlocks and locks the side doors (→P. 62) Unlocks and locks the back door (→P. 63) Starts and stops the hybrid system (→P. 192)

61

1-3. Opening, closing and locking the doors

Unlocking and locking the doors

Front door handles (including front passenger door handle if equipped with entry function)

Grip the driver’s door handle to unlock the door. Grip the passen- ger’s door handle to unlock all the doors.*

Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.

*: The door unlock settings can be

changed. (→P. 70)

the

lock sensor

Touch (the indentation on the upper part of the door handle) to lock the doors.

62

1-3. Opening, closing and locking the doors

Back door (vehicles with entry function of front and back doors) to

the unlock button

Press unlock all the doors.

The doors cannot be unlocked for 3 seconds after the doors are locked.

Press the lock button to lock all the doors.

63

1-3. Opening, closing and locking the doors

Antenna location and effective range

■ Antenna location Vehicles with entry function of driver’s door

Antennas outside cabin Antennas inside cabin

Vehicles with entry function of front and back doors

Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment

64

1

1-3. Opening, closing and locking the doors

■ Effective range (areas within which the electronic key is

detected)

Vehicles with entry function of driver’s door

When locking or unlocking the door The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of driver’s door handle. When starting the hybrid system changing “POWER” switch modes The system can be operated when the electronic key is inside the vehicle.

or

Vehicles with entry function of front and back doors

When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handle and back door opener switch. the doors detecting the key can be operated.) When starting the hybrid system changing “POWER” switch modes The system can be operated when the electronic key is inside the vehicle.

(Only

or

65

1-3. Opening, closing and locking the doors

■Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)

■When the door cannot be locked by the lock sensor on the upper part

of the door handle

If the door will not lock even when the topside sensor area is touched, try touch- ing both the topside and underside sen- sor areas at the same time.

66

1

1-3. Opening, closing and locking the doors

■Alarms and warning lights

A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures in response to any warning message shown on the multi-information display. (→P. 517) The following table describes circumstances and correction procedures when only alarms are sounded.

Alarm

Situation

Correction procedure

An attempt was made to lock the doors using the entry function while the electronic key was still inside the passenger com- partment An attempt was made to exit the vehicle and lock the doors without first turn- ing the “POWER” switch off An attempt was made to lock the vehicle while a door is open

Retrieve the elec- tronic key from the passenger compart- ment and lock the doors again

Turn the “POWER” switch off and lock the doors again

Close all of the doors and lock the doors again

Interior alarm pings once and exterior alarm sounds once for 5 seconds*1

Exterior alarm sounds once for 5 seconds

67

1-3. Opening, closing and locking the doors

Alarm

Situation

Correction procedure

Interior alarm pings continu- ously*1

Interior alarm sounds continu- ously*1

Interior and exte- rior alarms sound continuously*1

The “POWER” switch was turned to ACCESSORY mode while the driver’s door was open (or the driver’s door was opened while the “POWER” switch was in ACCESSORY mode) When the “POWER” switch is in ON mode or ACCESSORY mode, an attempt was made to open the door and exit the vehi- cle, and the shift position was not in P When the “POWER” switch is in ON mode or ACCESSORY mode, the driver’s door was closed after the key was carried outside the vehicle, and the shift position not in P

Turn the “POWER” switch off and close the driver’s door

Shift the shift position to P and turn the “POWER” switch off

Shift the shift position to P, turn the “POWER” switch off and close the driver’s door again

68

1

1-3. Opening, closing and locking the doors

Alarm

Situation

Interior alarm pings once*1

Interior alarm pings once and exterior alarm sounds 3 times*1

The electronic key has a low battery An attempt was made to start the hybrid system without the electronic key being present, or the elec- tronic key was not func- tioning normally The driver’s door was closed after the key was carried outside the vehicle, and the “POWER” switch was not turned OFF An occupant carried the electronic key outside the vehicle and closed the door while the “POWER” switch was not OFF

Correction procedure Replace the electronic key battery

Start the hybrid sys- tem with the elec- tronic key present*2

Turn the “POWER” switch off and close the driver’s door again

Bring the electronic key back into the vehi- cle

*1: A message will be shown on the multi-information display in the instru-

ment cluster.

*2: If the hybrid system does not start when the electronic key is inside the vehicle, the electronic key battery may be depleted or there may be dif- ficulties receiving signal from the key. (→P. 541)

69

1-3. Opening, closing and locking the doors

■Security feature

If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.

■Switching the door unlock function

It is possible to set which doors the entry function unlocks.

STEP 1

Turn the “POWER” switch off.

STEP 2

When the indicator on the key surface is turned off, push and hold but-

for approximately 5 seconds while pushing the

or

ton on the key.

The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat

STEP 2

.)

Multi-information

display

Unlocking doors

Beep

Hold the driver’s door handle to unlock only the driver’s door. Hold the passenger’s door handle or back door opener to unlock all the doors. Hold the front door handle or back door opener to unlock all the doors.

Exterior: Beeps three times Interior: Pings once

Exterior: Beeps twice Interior: Pings once

70

1

1-3. Opening, closing and locking the doors

■Battery-saving function

The battery-saving function will be activated in order to prevent the elec- tronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time. ●In the following situations, the smart key system may take some time to

unlock the doors. • The electronic key has been left in an area of approximately 6 ft. (2 m)

of the outside of the vehicle for 10 minutes or longer.

• The smart key system has not been used for 5 days or longer.

●If the smart key system has not been used for 14 days or longer, the doors cannot be unlocked at any doors except the driver’s door. In this case, take hold of the driver’s door handle, or use the wireless remote control or the mechanical key, to unlock the doors.

71

1-3. Opening, closing and locking the doors

■Conditions affecting operation

The smart key system, wireless remote control and immobilizer system use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly. (Ways of coping: →P. 541) ●When the electronic key battery is depleted ●Near a TV tower, electric power plant, gas station, radio station, large dis- play, airport or other facility that generates strong radio waves or electri- cal noise

●When carrying a portable radio, cellular phone, cordless phone or other

wireless communication devices

●When the electronic key is in contact with, or is covered by the following

metallic objects • Cards to which aluminum foil is attached • Cigarette boxes that have aluminum foil inside • Metallic wallets or bags • Coins • Hand warmers made of metal • Media such as CDs and DVDs

●When other wireless key (that emit radio waves) is being used nearby ●When carrying the electronic key together with the following devices that

emit radio waves • Another vehicle’s electronic key or a wireless key that emits radio

waves

• Personal computers or personal digital assistants (PDAs) • Digital audio players • Portable game systems

●If window tint with a metallic content or metallic objects are attached to

the rear window

72

1-3. Opening, closing and locking the doors

■Note for the entry function

●Even when the electronic key is within the effective range (detection

areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is on the instrument panel, luggage cover, floor, or in the door pockets or glove box when the hybrid system is started or “POWER” switch modes are changed.

●Do not leave the electronic key on top of the instrument panel or near the door pockets when exiting the vehicle. Depending on the radio wave reception conditions, it may be detected by the antenna outside the cabin and the door will become lockable from the outside, possibly trapping the electronic key inside the vehicle.

●As long as the electronic key is within the effective range, the doors may

be locked or unlocked by anyone.

●Even if the electronic key is not inside the vehicle, it may be possible to

start the hybrid system if the electronic key is near the window.

●The doors may unlock if a large amount of water splashes on the door handle, such as in the rain or in a car wash when the electronic key is within the effective range. (The door will automatically be locked after approximately 60 seconds if the doors are not opened and closed.)

●If the wireless remote control is used to lock the doors when the elec- tronic key is near the vehicle, there is a possibility that the door may not be unlocked by the entry function. (Use the wireless remote control to unlock the doors.)

73

1-3. Opening, closing and locking the doors

■Note for locking the doors

●Touching the door lock sensor while wearing gloves may delay or prevent

lock operation. Remove the gloves and touch the lock sensor again.

●When the lock operation is performed using the lock sensor, recognition signals will be shown up to two consecutive times. After this, no recogni- tion signals will be given.

●If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the vehi- cle is being washed. (Take care to ensure that the key is not stolen.)

●If the electronic key is inside the vehicle and a door handle becomes wet during a car wash, a buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors.

●The lock sensor may not work properly if it comes into contact with ice, snow, mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock sensor on the lower part of the door handle.

●Fingernails may scrape against the door during operation of the door handle. Be careful not to injure fingernails or damage the surface of the door.

74

1

1-3. Opening, closing and locking the doors

■Note for the unlocking function

●A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.

●Gripping the door handle when wearing a glove may not unlock the door. Remove the gloves and touch the sensor on the back of the door handle again.

●If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the vehi- cle is being washed. (Take care to ensure that the key is not stolen.)

●If there is another electronic key in the detection area, it may take slightly

longer to unlock the doors after the door handle is gripped.

●Fingernails may scrape against the door during operation of the door handle. Be careful not to injure fingernails or damage the surface of the door.

■When the vehicle is not driven for extended periods

●To prevent theft of the vehicle, do not leave the electronic key within 6 ft.

(2 m) of the vehicle.

●The smart key system can be deactivated in advance. (→P. 590)

■To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle. Depending on the position and holding condition of the electronic key, the key may not be detected correctly and the system may not operate properly. (The door lock prevention may not operate.)

75

1-3. Opening, closing and locking the doors

■If the smart key system does not operate properly

●Locking and unlocking the doors: Use the mechanical key. (→P. 541) ●Starting the hybrid system: →P. 542

■Electronic key battery depletion

●The standard battery life is 1 to 2 years. ●If the battery becomes low, an alarm will sound in the cabin when the

hybrid system stops. (→P. 67)

●As the electronic key always receives radio waves, the battery will become depleted even if the electronic key is not used. The following symptoms indicate that the electronic key battery may be depleted. Replace the battery when necessary. (→P. 454) • The smart key system or the wireless remote control does not operate. • The detection area becomes smaller. • The LED indicator on the key surface does not turn on.

●To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the following electrical appliances that produce a magnetic field: • TVs • Personal computers • Cellular phones, cordless phones and battery chargers • Recharging cellular phones or cordless phones • Glass top ranges • Table lamps

■When the electronic key battery is fully depleted

→P. 454

■Customization

Settings (e.g. smart key system) can be changed. (Customizable features →P. 590)

76

1

1-3. Opening, closing and locking the doors

■Certification for the smart key system

For vehicles sold in the U.S.A. FCC ID: NI4TMLF8-2
FCC ID: HYQ14ACX FCC ID: HYQ14ADF FCC ID: HYQ13CZD FCC ID: HYQ13CZE NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. For vehicles sold in Canada NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.

77

1-3. Opening, closing and locking the doors

CAUTION

■Caution regarding interference with electronic devices

●People with implanted pacemakers or cardiac defibrillators should keep

away from the smart key system antennas. (→P. 64) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
