TABLE OF CONTENTS


1 Before driving


Information on the hybrid system and adjusting and op- erating features such as door locks, mirrors, and steer- ing column


2 When driving


Driving, stopping and safe-driving information


3 Interior features


Air conditioning and audio systems, as well as other in- terior features for a comfortable driving experience


4 Maintenance


and care


Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information


5 When trouble


arises


What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident


6 Vehicle


specifications


Detailed vehicle information


7 For owners


Reporting safety defects for U.S. owners, and seat belt and SRS airbag instructions for Canadian owners


Index


Alphabetical listing of information contained in this manual


PRIUS_OM_OM47A17U_DVD_(U)


TABLE OF CONTENTS


Index


1 Before driving


1-1. Hybrid system


Hybrid system features ........ 32
Hybrid system precautions ........................ 38
Energy monitor/ consumption screen........... 44
Hybrid vehicle driving tips ..................................... 58


1-2. Key information


Keys ..................................... 60


1-3. Opening, closing and locking


the doors Smart key system (with entry function)............ 63
Smart key system (without entry function)....... 80
Wireless remote control ....... 86
Side doors ............................ 88
Back door ............................. 94


1-4. Adjustable components (seats, mirrors, steering wheel) Front seats.......................... 100
Rear seats .......................... 103
Head restraints ................... 106
Seat belts............................ 110
Steering wheel.................... 118
Inside rear view mirror ........ 119
Outside rear view mirrors .............................. 123


1-5. Opening and closing the windows and moon roof Power windows................... 125
Moon roof with Solar Panel....................... 128


1-6. Refueling


Opening the fuel tank cap.................................... 133


1-7. Theft deterrent system


Immobilizer system............. 137


1-8. Safety information


Correct driving posture ....... 139
SRS airbags ....................... 141
Front passenger occupant classification system......... 156
Child restraint systems ....... 162
Installing child restraints ..... 167


PRIUS_OM_OM47A17U_DVD_(U)


2-4. Using other driving systems


Cruise control ..................... 269
Dynamic radar cruise control .............................. 273
LKA (Lane-Keeping Assist)...... 290
Driving assist systems........ 301
Hill-start assist control ........ 306
PCS (Pre-Collision System) ..... 308


2-5. Driving information


Cargo and luggage............. 317
Vehicle load limits............... 322
Winter driving tips............... 323
Trailer towing...................... 328
Dinghy towing..................... 329


2 When driving


2-1. Driving procedures


Driving the vehicle............... 182
Power (ignition) switch........ 195
EV drive mode .................... 202
Hybrid transmission ............ 205
Turn signal lever ................. 214
Parking brake...................... 215
Horn .................................... 216


2-2.


Instrument cluster Gauges and meters ............ 217
Indicators and warning lights ................................. 222
Multi-information display ..... 226
Head-up display.................. 246


2-3. Operating the lights and


windshield wipers Headlight switch.................. 253
Fog light switch ................... 259
Windshield wipers and washer .............................. 261
Rear window wiper and washer .............................. 265
Headlight cleaner switch..... 268


PRIUS_OM_OM47A17U_DVD_(U)


TABLE OF CONTENTS


Index


3 Interior features


3-1. Using the air conditioning


system and defogger Air conditioning system ...... 332
Using the steering wheel climate remote control switches ........................... 343
Solar Ventilation System ............................. 345
Remote Air Conditioning System ............................. 348
Rear window and outside rear view mirror defoggers switch .............. 352


3-2. Using the audio system


Audio system types ............ 353
Using the AUX port/ USB port .......................... 358


3-3. Using the interior lights


Interior lights list ................. 359
• Front interior lights ........... 360
• Personal lights ................. 361
• Rear interior light.............. 361


3-4. Using the storage features


List of storage features ....... 363
• Glove boxes ..................... 364
• Console box ..................... 365
• Cup holders ...................... 366
• Bottle holders ................... 368
• Auxiliary boxes ................. 369


3-5. Other interior features


Sun visors........................... 370
Vanity mirrors ..................... 371
Outside temperature display .............................. 372
Power outlets...................... 373
Seat heaters ....................... 375
Armrest ............................... 377
Assist grips ......................... 378
Floor mats........................... 379
Luggage compartment features ............................ 381
Garage door opener ........... 387
Safety Connect ................... 395


PRIUS_OM_OM47A17U_DVD_(U)


4 Maintenance and care


5 When trouble arises


4-1. Maintenance and care Cleaning and protecting the vehicle exterior............ 404
Cleaning and protecting the vehicle interior............. 407


4-2. Maintenance Maintenance requirements..................... 411
General maintenance.......... 414
Emission inspection and maintenance (I/M) programs........................... 418


4-3. Do-it-yourself maintenance


Do-it-yourself service precautions ....................... 419
Hood ................................... 422
Positioning a floor jack........ 425
Engine compartment........... 428
12-volt battery ..................... 440
Tires.................................... 446
Tire inflation pressure ......... 457
Wheels................................ 461
Electronic key battery.......... 464
Checking and replacing fuses ................................. 466
Light bulbs........................... 478


5-1. Essential information


Emergency flashers............ 494
If your vehicle needs to be towed....................... 495
If you think something is wrong ............................... 502


5-2. Steps to take in an emergency


If a warning light turns on or a warning buzzer sounds.............................. 503
If a warning message is displayed .......................... 517
If you have a flat tire........... 537
If the hybrid system will not start ............................ 550
If you lose your keys........... 552
If the electronic key does not operate properly ......... 553
If the 12-volt battery is discharged........................ 555
If your vehicle overheats .... 561
If the vehicle becomes stuck................................. 567
If your vehicle has to be stopped in an emergency ....................... 569


PRIUS_OM_OM47A17U_DVD_(U)


TABLE OF CONTENTS


Index


6 Vehicle specifications


Index


6-1. Specifications


Abbreviation list ............... 628


Alphabetical index............ 630


What to do if... .................. 641


Maintenance data (fuel, oil level, etc.) ........... 572
Fuel information ................. 583
Tire information .................. 587


6-2. Customization


Customizable features ....... 602


6-3.


Initialization Items to initialize................. 609


7 For owners


Reporting safety defects for U.S. owners ................ 612
Seat belt instructions for Canadian owners (in French)........................ 613
SRS airbag instructions for Canadian owners (in French)........................ 615


PRIUS_OM_OM47A17U_DVD_(U)


1


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Exterior


Windshield wipers P. 261


Hood P. 422


Moon roof with Solar Panel P. 128


Outside rear view mirrors P. 123


Side turn signal lights P. 214


Front turn signal lights P. 214


Daytime running lights (for the U.S.A.) P. 256


Daytime running lights(for Canada) and headlights Parking lights Front side marker lights


P. 253, 256
P. 253
P. 253


Fog lights P. 259


PRIUS_OM_OM47A17U_DVD_(U)


Back door P. 94


Rear window defoggers P. 352


Rear window wiper P. 265


Fuel filler door P. 133


Side doors P. 88


Tires ●Rotation ●Replacement ●Inflation pressure ●Information


P. 446
P. 537
P. 581
P. 587


License plate lights


P. 253


Camera*


Rear turn signal lights


P. 214


Tail lights P. 253


Rear side marker lights


P. 253
: If equipped *: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”


or “NAVIGATION SYSTEM OWNER’S MANUAL”.


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Interior


Head restraints P. 106


Seat belts P. 110


Cup holders P. 366


Armrest P. 377


SRS front passenger airbag P. 141


Glove boxes P. 364


Rear seats P. 103


SRS side airbags P. 141


Front seats P. 100


Floor mat P. 379


10


PRIUS_OM_OM47A17U_DVD_(U)


A


Sun visors P. 370


Front interior/personal lights P. 360
Microphone* P. 395
Assist grips P. 378


Rear interior light P. 361


SRS curtain shield airbags P. 141


Vanity mirrors P. 371
“SOS” button


Moon roof switch Auxiliary box


P. 395
P. 128
P. 369


Anti-glare inside rear view mirror Garage door opener switches


P. 119
P. 387


: If equipped *: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”


or “NAVIGATION SYSTEM OWNER’S MANUAL”.


11


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Interior


Window lock switch P. 125


Door lock switch P. 88


Inside lock button P. 88


12


PRIUS_OM_OM47A17U_DVD_(U)


Power window switches P. 125


C


AUX port/USB port* P. 358


Console box P. 365


Power outlet P. 373


Cup holders P. 366


*: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”


or “NAVIGATION SYSTEM OWNER’S MANUAL”.


13


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Interior


Seat heater switches P. 375


Auxiliary box P. 369


Power outlet P. 373


14


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Instrument panel


SRS driver airbag Horn


P. 141
P. 216


Headlight switch


P. 253


Turn signal lever


P. 214
Fog light switch P. 259


Windshield wipers and washer switch P. 261
Rear window wiper and washer switch


P. 265


Gauges and meters Multi-information display


P. 217


P. 226
Navigation system*1 Audio system*2 P. 353


Fuel filler door opener P. 133


SRS knee airbag P. 141


Pre-collision braking off switch P. 309


Tire pressure warning reset switch P. 448


Parking brake pedal P. 215


Tilt and telescopic steering control lever P. 118


: If equipped *1: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”. *2: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”.


15


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Instrument panel


Outside rear view mirror switches P. 123


Headlight cleaner switch P. 268


Ventilation switch P. 345


Instrument panel light control dial P. 220


Hood lock release lever P. 422


16


PRIUS_OM_OM47A17U_DVD_(U)


B


“TRIP” button P. 227, 231


Climate remote control switches P. 343


“DISP” button P. 227


Audio remote control switches*1, 2


Talk switch*1, 2
Telephone switches*1, 2


Cruise control switch


P. 269
Dynamic radar cruise control P. 273


switch


LKA (Lane-Keeping Assist) switch P. 290


Vehicle-to-vehicle distance button P. 273


: If equipped *1: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”. *2: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”.


17


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Instrument panel


Clock adjustment buttons P. 233


MPH or km/h button P. 219


Head-up display switches P. 246


Power (ignition) switch P. 195


18


PRIUS_OM_OM47A17U_DVD_(U)


D


Air conditioning system P. 332


Rear window and outside rear view mirror defoggers switch P. 352


Emergency flasher switch P. 494


EV drive mode switch Eco drive mode switch Power mode switch


P. 202
P. 207


P. 207


Shift lever P. 205


P position switch P. 208


: If equipped


19


PRIUS_OM_OM47A17U_DVD_(U)


Pictorial index


Luggage compartment


Luggage compartment light P. 95


Luggage cover P. 384


Auxiliary boxes P. 383


Cargo hooks P. 381


20


PRIUS_OM_OM47A17U_DVD_(U)


: If equipped


21


PRIUS_OM_OM47A17U_DVD_(U)


For your information


Main Owner’s Manual


Please note that this manual applies to all models and explains all equip- ment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of color and equipment.


Noise from under vehicle after turning off the hybrid system


Approximately five hours after the hybrid system is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.


Accessories, spare parts and modification of your Toyota


A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Mod- ification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addi- tion, damage or performance problems resulting from the modification may not be covered under warranty.


22


PRIUS_OM_OM47A17U_DVD_(U)


Installation of a mobile two-way radio system


The installation of a mobile two-way radio system in your vehicle could affect electronic systems such as: ● Multiport fuel injection system/sequential multiport fuel injection system ● Cruise control system ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the same amount of electromagnetic waves as the conventional gasoline pow- ered vehicles or home electronic appliances despite of their electromagnetic shielding. Unwanted noise may occur in the reception of the mobile two-way radio.


23


PRIUS_OM_OM47A17U_DVD_(U)


Vehicle data recordings


Your Toyota is equipped with several sophisticated computers that will record certain data, such as: • Engine speed • Electric motor speed (traction motor speed) • Accelerator status • Brake status • Vehicle speed • Shift position • Hybrid battery (traction battery) status The recorded data varies according to the vehicle grade level and options with which it is equipped. Furthermore, these computers do not record con- versations, sounds or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if


the vehicle is leased In response to an official request by the police, a court of law or a govern- ment agency


• For use by Toyota in a lawsuit • For research purposes where the data is not tied to a specific vehicle or



vehicle owner


● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.


24


PRIUS_OM_OM47A17U_DVD_(U)


Event data recorder


This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as: • How various systems in your vehicle were operating; • Whether or not the driver and passenger safety belts were buckled/fas-


• How far (if at all) the driver was depressing the accelerator and/or brake


tened;


pedal; and,


• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a nontrivial crash situa- tion occurs; no data are recorded by the EDR under normal driving condi- tions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.


25


PRIUS_OM_OM47A17U_DVD_(U)


● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle)


is obtained In response to an official request by the police, a court of law or a govern- ment agency


• For use by Toyota in a lawsuit However, if necessary, Toyota may: • Use the data for research on vehicle safety performance • Disclose the data to a third party for research purposes without disclosing



information about the specific vehicle or vehicle owner


Scrapping of your Toyota


The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.


Perchlorate Material


Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.


26


PRIUS_OM_OM47A17U_DVD_(U)


CAUTION


■General precautions while driving


Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.


■General precaution regarding children’s safety


Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.


27


PRIUS_OM_OM47A17U_DVD_(U)


CAUTION


■Hybrid battery (traction battery)


Never resell, hand over or modify the hybrid battery (traction battery). To pre- vent accidents, hybrid batteries (traction batteries) that have been removed from a disposed vehicle are collected through Toyota dealers. Do not dis- pose of the battery yourself. Unless the battery is properly collected, the following may occur, resulting in death or serious injury: • The hybrid battery (traction battery) may be illegally disposed of or dumped, and someone may touch a high voltage part, resulting in an electric shock.


• The hybrid battery (traction battery) is intended to be used exclusively with your hybrid vehicle. If the hybrid battery (traction battery) is used outside of your vehicle or modified in any way, accidents such as electric shock, heat generation, smoke generation, an explosion and electrolyte leakage may occur.


When reselling or handing over your vehicle, the possibility of an accident is extremely high because the person receiving the vehicle may not be aware of these dangers.


■Disposal of the hybrid battery (traction battery)


If your vehicle is disposed of without the hybrid battery (traction battery) hav- ing been removed, there is a danger of serious electric shock if high voltage parts, cables and their connectors are touched. In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery (traction battery) is not disposed of properly, it may cause electric shock that can result in death or serious injury.


28


PRIUS_OM_OM47A17U_DVD_(U)


Symbols used throughout this manual


Cautions & Notices


CAUTION


This is a warning against something which, if ignored, may cause death or serious injury to people. You are informed about what you must or must not do in order to reduce the risk of death or serious injury to yourself and others.


NOTICE


This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.


Symbols used in illustrations


Safety symbol The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.


Arrows indicating operations


Indicates the action (pushing, turn- ing, etc.) used to operate switches and other devices. Indicates the outcome of an opera- tion (e.g. a lid opens).


ITOPP105


29


PRIUS_OM_OM47A17U_DVD_(U)


30


PRIUS_OM_OM47A17U_DVD_(U)


Before driving


1-1. Hybrid system


Hybrid system features ...... 32
Hybrid system precautions ...................... 38
Energy monitor/ consumption screen......... 44
Hybrid vehicle driving tips ................................... 58


1-2. Key information


Keys................................... 60


1-3. Opening, closing and locking


the doors Smart key system (with entry function) ......... 63
Smart key system (without entry function) .... 80
Wireless remote control .............................. 86
Side doors.......................... 88
Back door........................... 94


1-4. Adjustable components (seats, mirrors, steering wheel) Front seats ....................... 100
Rear seats........................ 103
Head restraints................. 106
Seat belts ......................... 110
Steering wheel ................. 118
Inside rear view mirror ..... 119
Outside rear view mirrors............................ 123


1-5. Opening and closing the windows and moon roof Power windows ................ 125
Moon roof with Solar Panel .................... 128


1-6. Refueling


Opening the fuel tank cap ................................. 133


1-7. Theft deterrent system


Immobilizer system .......... 137


1-8. Safety information


Correct driving posture..... 139
SRS airbags..................... 141
Front passenger occupant classification system ...... 156
Child restraint systems..... 162
Installing child restraints ........................ 167


31


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system Hybrid system features


Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.


Gasoline engine Electric motor (traction motor)


32


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


■ When stopped/during start off


The gasoline engine stops* when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped* and the electric motor (traction motor) is used. When shift position is in N, the hybrid battery (traction battery) will not be charged. Thus, shift to P when the vehicle is stopped. In addition, when driving in heavy traffic, use D or B. *: However, when the hybrid battery (traction battery) need to be charged or while the engine is being warmed up, the gasoline engine may not stop automatically. (P. 35)


■ During normal driving


The gasoline engine is predominantly used. The electric motor (traction motor) charges the hybrid battery (traction battery) as necessary.


■ When accelerating sharply


When the accelerator pedal is depressed heavily, the power of the hybrid battery (traction battery) is added to that of the gaso- line engine via the electric motor (traction motor).


■ When braking (regenerative braking)


The electric motor (traction motor) charges the hybrid battery (traction battery).


33


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Vehicle proximity notification system


When driving with the gasoline engine stopped, a sound, which changes in accordance with the driving speed, will be played in order to warn people nearby of the vehicle’s approach. The sound will stop when the vehicle speed exceeds approximately 15 mph (25 km/h).


■Regenerative braking


In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery). ●The accelerator pedal is released while driving with the shift position in D


or B.


●The brake pedal is depressed while driving with the shift position in D or


B.


■Hybrid System Indicator


Hybrid System Indicator represents the hybrid system power output and regener- ative charging. (P. 227)


34


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


■Conditions in which the gasoline engine may not stop


The gasoline engine starts and stops automatically. However, it may not stop automatically in the following conditions*: ●During gasoline engine warm-up ●When the temperature of the hybrid battery (traction battery) is high or


low


●During hybrid battery (traction battery) charging ●When the heater is switched on *: Depending on the circumstances, the gasoline engine may also not stop


automatically in situations other than those above.


■Charging the hybrid battery (traction battery)


●As the gasoline engine charges the hybrid battery (traction battery), the battery does not need to be charged from an outside source. However, if the vehicle is left parked for a long time the hybrid battery (traction bat- tery) will slowly discharge. For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 10 miles (16 km). If the hybrid battery (traction battery) becomes fully discharged and you are unable to jump-start the vehicle with the 12-volt battery, contact your Toyota dealer.


●If the shift position is in N, the hybrid battery (traction battery) will not be charged. Always shift the shift position in P when the vehicle is stopped. When driving in heavy traffic, operate the vehicle with the shift position in D or B to avoid discharging the hybrid battery (traction battery).


■Charging the 12-volt battery


P. 558


■After the 12-volt battery has discharged or has been changed or


removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer.


35


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


■Sounds and vibrations specific to a hybrid vehicle


There may be no engine sounds or vibration even though the vehicle is able to move. For safety, apply the parking brake and make sure to shift the shift position to P when parked. The following sounds or vibrations may occur when the hybrid system is operating and are not a malfunction: ●The brake system operation sound heard from the front of the vehicle


when the driver’s door is opened.


●Motor sounds may be heard from the engine compartment. ●Sounds may be heard from the hybrid battery (traction battery) when the


hybrid system starts or stops.


●Sounds may be heard from the transmission when the gasoline engine


starts or stops, when driving at low speeds, or during idling.


●Engine sounds may be heard when accelerating sharply. ●Sounds may be heard due to regenerative braking when the brake pedal


is depressed and accelerator is loosened.


●Other sounds, such as motors and mechanical noises, may be heard


from the brake system when the brake pedal is depressed.


●Vibration may be felt when the gasoline engine starts or stops. ●Cooling fan sounds may be heard from the air intake vent. (P. 39) ●The operation sound of the air conditioning system (air conditioning com-


pressor, blower motor).


36


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


■Vehicle proximity notification system


In the following cases, the vehicle proximity notification system may be diffi- cult for surrounding people to hear. ●In very noisy areas ●In the wind or the rain Also, as the vehicle proximity notification system is installed on the front of the vehicle, it may be more difficult to hear from the rear of the vehicle com- pared to the front.


■Maintenance, repair, recycling, and disposal


Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself.


37


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system Hybrid system precautions


Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle.


Air conditioning compressor High voltage cables (orange) Power control unit and DC/ DC converter Caution label


Service plug Electric motor motor) Hybrid battery (traction bat- tery)


(traction


38


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


Hybrid battery (traction battery) air vent


There is an air intake vent on the right side of the rear seatback for the purpose of cooling the hybrid battery (traction battery). If the vent becomes blocked, the hybrid battery (traction battery) may overheat, to a reduction in hybrid battery (trac- tion battery) output.


leading


Emergency shut off system


When a certain level of impact is detected by the impact sensor, the emergency shut off system blocks off the high voltage current and stops the fuel pump to minimize the risk of electrocution and fuel leakage. If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer.


Hybrid warning message


A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.


If a warning message is shown on the multi-information display, read the message and follow the instructions. (P. 517)


39


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


■If a warning light comes on, a warning message is displayed or the 12-


volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer.


■Running out of fuel


When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (P. 508) go off. If there is only a small amount of fuel, the hybrid system may not be able to start. (The minimum amount of fuel to add to make the low fuel level warning light go out is about 1.9 gal. [7.1 L, 1.6 Imp.gal.], when the vehicle is on a level surface. This value may vary when the vehicle is on a slope.)


■Electromagnetic waves


●High voltage parts and cables on the hybrid vehicles incorporate electro- magnetic shielding, and therefore emit approximately the same amount of electromagnetic waves as conventional gasoline powered vehicles or home electronic appliances.


●Your vehicle may cause sound interference in some third party-produced


radio parts.


■Hybrid battery (traction battery)


The hybrid battery (traction battery) has a limited service life. The lifespan of the hybrid battery (traction battery) can change in accordance with driving style and driving conditions.


40


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


CAUTION


■High voltage precautions


The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●Never touch, disassemble, remove or replace the high voltage parts,


cables or their connectors.


●The hybrid system will become hot after starting as the system uses high voltage. Be careful of both the high voltage and the high temperature, and always obey the caution labels attached to the vehicle.


●Never try to open the service plug access hole located in the luggage compartment. The service plug is used only when the vehicle is serviced and is subject to high voltage.


41


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


CAUTION


■Road accident cautions


If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury: ●Stop the vehicle in a safe place to prevent subsequent accidents.


While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off. Then, slowly release the brake pedal.


●Do not touch the high voltage parts, cables and connectors. ●If electric wires are exposed inside or outside your vehicle, an electric


shock may occur. Never touch exposed electric wires.


●If a fluid leak occurs, do not touch the fluid as it may be strong alkaline electrolyte from the hybrid battery (traction battery). If it comes into contact with your skin or eyes, wash it off immediately with a large amount of water or, if possible, boric acid solution. Seek immediate medical attention.


●If a fire occurs in the hybrid vehicle, leave the vehicle as soon as possible. Never use a fire extinguisher that is not meant for electric fires. Using even a small amount of water may be dangerous.


●If your vehicle needs to be towed, do so with front wheels raised. If the wheels connected to the electric motor (traction motor) are on the ground when towing, the motor may continue to generate electricity. This may cause a fire. (P. 495)


●Carefully inspect the ground under the vehicle. If you find that liquid has leaked onto the ground, the fuel system may have been damaged. Leave the vehicle as soon as possible.


42


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


CAUTION


■Hybrid battery (traction battery)


Your vehicle contains a sealed nickel-metal hydride battery. If disposed of improperly, it is hazardous to the environment and there is a risk of severe burns and electrical shock that may result in death or serious injury.


NOTICE


■Hybrid battery (traction battery) air vent


●Do not put foreign objects near the air vent. The hybrid battery (traction


battery) may overheat and be damaged.


●Clean the air vent regularly to prevent the hybrid battery (traction battery)


from overheating.


●Do not wet or allow foreign substances to enter the air vent as this may


cause a short circuit and damage the hybrid battery (traction battery).


●Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer.


●If the rear seat belt becomes separated from the guide (P. 104), it could obstruct the hybrid battery (traction battery) air vent. Set the rear seat belt into the guide to use.


43


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system Energy monitor/consumption screen


You can view the status of your hybrid system on the Display Audio system screen, the navigation system screen or the multi-informa- tion display.


Audio


Display system screen or navigation system screen Multi-information display


Energy monitor


Displays the flow of energy as it changes in accordance with driving conditions. Display Audio system


Press “CAR”.


If the “Consumption” screen is displayed, touch “Energy”.


44


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Condition


Display


When the vehicle is powered by the electric motor (traction motor)


When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)


When the vehicle is powered by the gasoline engine


45


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Condition


Display


When the vehicle is charging the hybrid battery (traction battery)


When there is no energy flow


Hybrid battery (traction battery) status


Low


Full


These images are examples only, and may vary slightly from actual conditions.


46


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Navigation system


STEP 1


Press “INFO APPS” or “INFO”.


STEP 2


Touch “Fuel Consumption” on the “Information” screen.


If the “Consumption” screen is displayed, touch “Energy”.


47


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Condition


Display


When the vehicle is powered by the electric motor (traction motor)


When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)


When the vehicle is powered by the gasoline engine


48


PRIUS_OM_OM47A17U_DVD_(U)


Condition


Display


1-1. Hybrid system


When the vehicle is charging the hybrid battery (traction battery)


When there is no energy flow


Hybrid battery (traction battery) status


Low


Full


These images are examples only, and may vary slightly from actual conditions.


49


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Multi-information display


Press the “DISP” button to dis- play the energy monitor.


■ Names and meaning of each icons


Gasoline engine Hybrid battery (traction bat- tery) Electric motor (traction motor)


Condition


Display


When the vehicle is powered by the electric motor (traction motor)


When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)


50


PRIUS_OM_OM47A17U_DVD_(U)


Condition


Display


When the vehicle is powered by the gasoline engine


1-1. Hybrid system


When the vehicle is charging the hybrid battery (traction battery)


When there is no energy flow


Hybrid battery (traction battery) status


Low


Full


These images are examples only, and may vary slightly from actual conditions.


51


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Consumption screen


Display Audio system Press “CAR”.


If the “Energy Monitor” screen is displayed, touch “Consumption”.


Fuel consumption in the past 30 minutes Cruising range (P. 57) Regenerated energy past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown.


the


in


The image is example only, and may vary slightly from actual conditions. Navigation system


STEP 1


STEP 2


Press “INFO APPS” or “INFO”. Touch “Fuel Consumption” on the “Information” screen. If touch Consumption”.


“Energy Monitor” screen


is displayed,


the


“Fuel


Fuel consumption in the past 30 minutes Regenerated energy past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown. Cruising range (P. 57)


the


in


The image is example only, and may vary slightly from actual conditions.


52


PRIUS_OM_OM47A17U_DVD_(U)


1


Multi-information display


1-1. Hybrid system


Press the “DISP” button to dis- play the 5-minute or 1-minute fuel consumption display.


Press and hold the “DISP” button to switch between 5-minute and 1-minute fuel consumption dis- plays. The display will alternate with each press of the button.


5-minute interval fuel consumption


1-minute interval fuel consumption


Fuel consumption Displays the average fuel con- sumption for the last 30 minutes in intervals of 5 minutes or the last 15 minutes in intervals of 1
minute. Regenerated energy Displays the amount of energy generated over the last 30 min- utes in intervals of 5 minutes or the last 15 minutes in intervals of 1 minute. One symbol indicates 50 Wh (5- minute interval display) or 30 Wh (1-minute interval display). Up to 8 symbols are shown.


53


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


EV indicator*1
Eco Driving Indicator Light*1
Average speed*2
Average fuel consumption/eco savings*2
Use the displayed average fuel consumption as a reference.


*1: P. 227
*2:The current amount since the trip meter was reset will be displayed. These functions can be reset by pressing and holding the “TRIP” button when either the 5-minute or 1-minute fuel con- sumption display is being shown. The display can be switched between average fuel consump- tion/average speed and eco sav- ings. (P. 235)


interval


54


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


Monthly fuel consumption record/Eco savings record (multi- information display only)


Press the “DISP” button to dis- play the monthly fuel consump- tion record or eco savings record.


Press and hold the “DISP” button to switch the display between monthly fuel consumption record and eco savings record. The display will alternate with each press of the button.


Monthly fuel consumption record display Displays the average fuel consumption for the previous 6 months.


Average fuel consumption for the previous 6 months EV indicator* Eco Driving Indicator Light* Driving distance month *: P. 227


for each


55


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system


Eco savings record display By setting the fuel consumption for comparison and the gasoline price beforehand (P. 234), when the actual fuel consumption is less than the fuel consumption for comparison, the difference is calculated and the amount of money saved or spent is displayed*1. *1: The displayed amount is intended only as a guide and may differ from


the actual amount.


Savings or consumption costs for the previous 6 months Press the “TRIP” button to switch between the amount of money saved and spent. EV indicator*2
Eco Driving Indicator Light*2
Driving distance month


for each


*2: P. 227


■Remaining hybrid battery (traction battery) charge display


The charge amount of the hybrid battery (traction battery) is automatically controlled by the hybrid system. For this reason, even if electricity is recov- ered via the regenerative braking, or electricity is generated via the gasoline engine, the displayed hybrid battery (traction battery) charge amount may not reach the highest level (level 8). However, this does not indicate a mal- function.


56


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


■Resetting the consumption data


Display Audio system Selecting “Clear” on the “Consumption” screen will reset the fuel consump- tion and the regenerated energy for the past 30 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data. Navigation system Selecting “Clear” on the “Consumption” screen will reset the fuel consump- tion and the regenerated energy for the past 30 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data. Multi-information display If the “POWER” switch is turned OFF, average fuel consumption and regen- erated energy data will be reset.


■Resetting the monthly fuel consumption/eco savings record


Press and hold the “TRIP” button while the monthly fuel consumption/eco savings record is displayed. A confirmation message will be displayed. Press and hold the “TRIP” button to reset the data. Press the “DISP” button to cancel the reset operation. The screen will return to the previous display if no buttons are pressed for approximately 10 sec- onds.


■Cruising range


Displays the estimated maximum distance that can be driven with the quan- tity of fuel remaining. This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that dis- played.


■Odometer/trip meter/distance to empty


The odometer/trip meter/distance to empty will not be displayed while the monthly fuel consumption record or the eco savings record is being dis- played.


57


PRIUS_OM_OM47A17U_DVD_(U)


1-1. Hybrid system Hybrid vehicle driving tips


For economical and ecological driving, pay attention to the following points: ■ Using Eco drive mode


When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions. In addition, the opera- tion of the air conditioning system (heating/cooling) will be mini- mized, improving the fuel economy. (P. 207)


■ Use of Hybrid System Indicator


Eco-friendly driving is possible by keeping the Hybrid System Indicator within Eco area. (P. 227)


■ When braking the vehicle


Make sure to operate the brakes gently and in good time. A greater amount of electrical energy can be retained when slow- ing down.


■ Delays


Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel consumption. Check traffic reports before leaving and avoid delays as much as possible. When encountering a delay, gently release the brake pedal to allow the vehicle to move forward slightly while avoiding overuse of the accelerator pedal. Doing so can help control excessive gasoline consumption.


■ Highway driving


Control your speed and keep at a constant speed. Also, before stopping at a toll booth or similar, allow plenty of time to release the accelerator and gently apply the brakes. A greater amount of electrical energy can be retained when slowing down.


58


PRIUS_OM_OM47A17U_DVD_(U)


1


1-1. Hybrid system


■ Air conditioning on/off


) to off when it is not needed.


Switch the air conditioning ( Doing so can help control excessive gasoline consumption. In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well. In winter: Because the gasoline engine will not automatically cut out until the gasoline engine and the interior of the vehicle are warm, it will consume fuel. Also, fuel consumption can be improved by avoiding overuse of the heater.


■ Checking tire inflation pressure


Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel consump- tion. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel consumption. Use a tire that is appropriate for the season.


■ Luggage


Carrying heavy luggage can lead to poor fuel consumption. Avoid carrying unnecessary luggage. Installing a large roof rack can also cause poor fuel consumption.


■ Warming up before driving


Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary. Moreover, frequently driving short distances will cause the engine to repeatedly warm up, which can lead to poor fuel consumption.


59


PRIUS_OM_OM47A17U_DVD_(U)


1-2. Key information Keys


The following keys are provided with the vehicle.


Electronic keys • Operating


the smart key


system (P. 63, 80)


• Operating


the wireless


• Operating the Remote Air


remote control function (P. 86) Conditioning System* (P. 348)


Mechanical keys Key number plate


Using the mechanical key


*: If equipped


To take out the mechanical key, push the release button and take the key out.


After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (P. 553)


60


PRIUS_OM_OM47A17U_DVD_(U)


1


1-2. Key information


■Key number plate


Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 552)


■When riding in an aircraft


When bringing an electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying an electronic key in your bag etc., ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the elec- tronic key to emit radio waves that could interfere with the operation of the aircraft.


61


PRIUS_OM_OM47A17U_DVD_(U)


1-2. Key information


NOTICE


■To prevent key damage


Observe the following: ●Do not drop the keys, subject them to strong shocks or bend them. ●Do not expose the keys to high temperatures for long periods of time. ●Do not get the keys wet or wash them in an ultrasonic washer etc. ●Do not attach metallic or magnetic materials to the keys or place the keys


close to such materials.


●Do not disassemble the keys. ●Do not attach a sticker or anything else to the surface of the electronic key. ●Do not place the keys near objects that produce magnetic fields, such as TVs, audio systems and induction cookers, or medical electrical equip- ment, such as low-frequency therapy equipment.


■Carrying the electronic key on your person


Carry the electronic key 3.9 in. (10 cm) or more away from electric appli- ances that are turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the electronic key may interfere with the key, causing the key to not function properly.


■In case of a smart key system malfunction or other key-related prob-


lems Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer.


■When a vehicle key is lost


If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.


62


PRIUS_OM_OM47A17U_DVD_(U)


1-3. Opening, closing and locking the doors

Loading...
x
