Foreword


Welcome to the growing group of value−conscious people who drive Toyotas. We are proud of the advanced engineering and quality construction of each vehicle we build. This Owner’s Manual explains the operation of your new Toyota. Please read it thoroughly and have all the occupants follow the instructions carefully. Doing so will help you enjoy many years of safe and trouble−free motoring. For important information about this manual and your Toyota, read the following pages carefully. When it comes to service, remember that your Toyota dealer knows your vehicle best and is interested in your complete satisfaction. He will provide quality maintenance and any other assistance you may require. If there is not a Toyota dealer near you, or you need emergency assistance for any reason, please call the following number:


D U.S. OWNERS: D CANADIAN OWNERS: Toyota Canada Customer Interaction Centre


Toyota Customer Assistance Center


Toll−free: 1−800−331−4331
Toll−free: 1−888−TOYOTA−8 (1−888−869−6828)


Please leave this Owner’s Manual in this vehicle at the time of resale. The next owner will need this information also. All information and specifications in this manual are current at the time of printing. However, because of Toyota’s policy of continual product improvement, we reserve the right to make changes at any time without notice. Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.


© 2002 TOYOTA MOTOR CORPORATION All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyota Motor Corporation.


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Important information about this manual


Safety and vehicle damage warnings


Safety symbol


Throughout this manual, you will see safety and vehicle dam- age warnings. You must follow these warnings carefully to avoid possible injury or damage. The types of warnings, what they look like, and how they are used in this manual are explained as follows:


CAUTION


This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.


NOTICE


This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. Yu are informed about what you must or must not do in order to avoid or reduce the risk of damage to your vehicle and its equipment.


the safety symbol When you see shown above, it means: “Do not...”; “Do not do this”; or “Do not let this happen”.


ii


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Important information about your Toyota


New vehicle warranty


Your new vehicle is covered by the following Toyota limited warranties:


D New vehicle warranty D Emission control systems warranty D Others further


information, please refer


Information Booklet” or


For Warranty Supplement”.


to the “Owner’s “Owner’s Manual


Your responsibility for


maintenance


It is the owner’s responsibility to make sure that the speci- fied maintenance is performed. Section 6 gives details of these maintenance requirements. Also included in Section 6 is general maintenance. For scheduled maintenance in- formation, please refer to the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.


Accessories, spare parts and modification of your Toyota


A wide variety of non−genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these prod- ucts and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.


This vehicle should not be modified with non−genuine Toyota products. Modification with non−genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addi- tion, damage or performance problems resulting from the modification may not be covered under warranty.


iii


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Spark ignition system of your


Scrapping of your Toyota


If


The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. is scrapped with the airbags and pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt preten- sioner removed and disposed of by a qualified service shop or by your Toyota dealer before you dispose of your vehicle.


the vehicle


Toyota


The spark ignition system in your Toyota meets all require- ments of the Canadian Interference−Causing Equipment Standard.


Installation of a mobile two−way radio system


As the installation of a mobile two−way radio system in your vehicle could affect electronic systems such as multi- port fuel injection system/sequential multiport fuel injection system, cruise control system, anti−lock brake system, SRS airbag system and seat belt pretensioner system, be sure to check with your Toyota dealer for precautionary measures or special instructions regarding installation.


iv


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


SECTION 1− 1


OPERATION OF INSTRUMENTS AND CONTROLS Overview of instruments and controls Instrument panel overview Instrument cluster overview Indicator symbols on the instrument panelel


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Instrument panel overview


1. Side defroster outlets 2. Side vents 3. Instrument cluster 4. Center vents 5. Electric moon roof switches 6. Personal lights 7. Power door lock switches 8. Power window switches 9. Glove box 10. Portable ashtray 11. Rear console box 12. Cup holders 13. Power outlet 14. Parking brake lever 15. Automatic transmission selector lever


or manual transmission gear shift lever


16. Hood lock release lever 17. Window lock switch


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


1. Headlight and turn signal switch and


front fog light switch


2. Wiper and washer switches 3. Emergency flasher switch 4. Car audio 5. Clock 6. Front passenger’s seat belt reminder


light


7. Rear window defogger switch 8. Auxiliary boxes 9. Power outlet or cigarette lighter 10. Air conditioning controls 11. Ignition switch 12. Cruise control switch 13. Tilt steering lock release lever 14. Interior/instrument panel light control


dial


15. Power rear view mirror control switches 16. Toyota vehicle intrusion protection


system indicator light


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Instrument cluster overview "Type A


1. Service reminder indicators and


indicator lights


2. Tachometer 3. Speedometer


4. Engine coolant temperature gauge 5. Fuel gauge 6. Trip meter reset knob


7. Odometer, two trip meters and outside


temperature display


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


"Type B


1. Service reminder indicators and


indicator lights


2. Tachometer 3. Speedometer


4. Engine coolant temperature gauge 5. Fuel gauge 6. Trip meter reset knob


7. Odometer, two trip meters and outside


temperature display


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Indicator symbols on the instrument panel


or


Brake system warning light∗1


Driver’s seat belt reminder light∗1


Low engine oil pressure warning light∗1


or


Anti−lock brake system warning light∗1


Front passenger’s seat belt reminder light∗1


Open door warning light∗1


Discharge warning light∗1


SRS warning light∗1


or


Malfunction indicator lamp∗1


Low windshield washer fluid level warning light ∗1,


∗3


Headlight high beam indicator light


Low fuel level warning light∗1


Turn signal indicator lights


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Overdrive−off indicator light


Cruise control indicator light∗2


∗1: For details, see “Service reminder indicators and warning


buzzers” on page 85 in Section 1−5.


∗2: If this light flashes, see “Cruise control” on page 99 in Sec-


tion 1−6.


∗3: This symbol equipped only on vehicles sold in Canada.


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


SECTION 1− 2


OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys Side doors Power windows Trunk lid Toyota vehicle intrusion protection system (TVIP) Hood Fuel tank cap Electric moon roof


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


10
10
17
18
20
22
23
25


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Keys


Side doors—


Your vehicle is supplied with two kinds of keys. 1. Master key—This key works in every


lock.


2. Sub key—This key will not work in the


trunk.


leave


To protect items locked in the trunk when using valet parking, the sub key with the attendant. Since all the doors and trunk lid can be locked without a key, you should always carry a spare master key in case you accidentally lock your keys inside the ve- hicle.


KEY NUMBER PLATE Your key number is shown on the plate. Keep the plate in a safe place such as your wallet, not in the vehicle. If you should lose your keys or if you need additional keys, duplicates can be made by a Toyota dealer using the key number. We recommend writing down the key num- ber and storing it in a safe place.


LOCKING AND UNLOCKING WITH KEY Insert the key into the keyhole and turn it. To lock: Turn the key forward. To unlock: Turn the key backward. Vehicles with power door lock system— All lock and unlock simulta- neously with either front door. In the driv- er’s door lock, turning the key once will unlock the driver’s door and twice in suc- cession will unlock all the doors simulta- neously.


the doors


10


2003 MY COROLLA_U (OM12744U)


is


in


the


interior


light dial


When the DOOR position, and all doors are un- locked simultaneously using either the key or the wireless remote control transmitter, the interior light will come on and remain on for about 15 seconds before fading out. (For further information, see “Interior/ instrument panel light control” on page 77
in Section 1−4.)


’03 Corolla U (L/O 0201)


CAUTION


Do not pull the inside handle of the front doors while driving. The doors will open and an accident may occur. Toyota strongly recommends that all children be placed in the rear seat of the vehicle.


Closing the door with the lock knob in the lock position will also lock the door. Be careful not to lock your keys in the ve- hicle. Vehicles with power door lock system— Doors cannot be locked when either front door is open and the key is in the igni- tion.


LOCKING AND UNLOCKING WITH INSIDE LOCK KNOB Move the lock knob. To lock: Push the knob forward. To unlock: Pull the knob backward. The front doors can be opened by pulling the inside handle even if the lock knobs are in the locked position.


2003 MY COROLLA_U (OM12744U)


11


’03 Corolla U (L/O 0201)


lock: Push the switch down on the


LOCKING AND UNLOCKING WITH POWER DOOR LOCK SWITCH Push the switch. To front side. To unlock: Push the switch down on the rear side. Operating the switch simultaneously locks or unlocks all the doors. If you do either of the following, no door can be unlocked with the power door lock switch. D Lock all the doors with the key or wire- less remote control transmitter when all the doors are closed.


D Open the driver’s door or front passen- ger’s door and move the inside lock knobs of both front doors to the lock position, then close the front doors.


The power door lock switch can be reset in the following ways. D Turn the ignition key to “ON”. D Unlock all the doors with the key or


wireless remote control transmitter.


D Unlock the driver’s door or front pas- lock the doors


senger’s door with knob, and then unlock all with the power door lock switch.


inside


the


2003 MY COROLLA_U (OM12744U)


Driver’s side


Passenger’s side


12


to


the


lock


lever


the “LOCK”


REAR DOOR CHILD−PROTECTORS Move position as shown on the label. This feature allows you to lock a rear door so it can be opened from the outside only, not from inside. We recommend us- ing this feature whenever small children are in the vehicle.


’03 Corolla U (L/O 0201)


—Wireless remote control


CAUTION


Before driving, be sure that the doors are closed and locked, especially when small children are in the ve- hicle. Along with the proper use of seat belts, locking the doors helps prevent the driver and passengers from being thrown out from the ve- hicle during an accident. It also helps prevent the doors from being opened unintentionally.


Locking operation


to


THE


AND


UNLOCKING


lock or unlock all


The wireless remote control system is designed the doors or activate the “PANIC” mode from a distance within approximately 1
m (3 ft.) of the vehicle. LOCKING DOORS To lock and unlock all the doors, push the switches of the transmitter slowly and securely. To lock: Push the “LOCK” switch. All the doors are locked simultaneously. At this time the turn signal lights will flash once. Check to see that the doors are securely locked. If any door is not securely closed, locking cannot be performed by “LOCK” switch. “UNLOCK” switch To unlock: Push once to unlock the driver’s door alone. Pushing the switch twice within 3 seconds unlocks all the doors simultaneously. Each time the “UNLOCK” switch is pushed, the turn signal lights will flash twice.


the


the


Unlocking operation


2003 MY COROLLA_U (OM12744U)


13


’03 Corolla U (L/O 0201)


When the “UNLOCK” switch is pressed, the interior light comes on. The light re- mains on for about 15 seconds unless any door is opened and closed. (For further information, see “Interior/instrument panel light control” on page 77 in Section 1−4.) You have 30 seconds to open a door after using the wireless remote unlock feature. If a door is not opened by then, all the doors will be automatically locked again. If the “LOCK” or “UNLOCK” switch is kept pressed in, the locking or unlocking opera- tion is not repeated. Release the button and then push again.


REMOTE


CONTROL


WIRELESS TRANSMITTER The wireless remote control transmitter is an electronic component. Observe the fol- lowing instructions in order not to cause damage to the transmitter. D Do not leave the transmitter on places the temperature becomes high


where such as on the dashboard.


D Do not disassemble it. D Avoid knocking


it hard against other


objects or dropping it.


for


transmitters


D Avoid putting it in water. You can use up to 4 wireless remote con- the same vehicle. trol Contact your Toyota dealer for detailed information. If the wireless remote control transmitter does not actuate the doors or alarm, or operate from a normal distance: D Check for closeness to a radio trans- mitter such as a radio station or an airport which can interfere with normal operation of the transmitter.


D The battery may have been consumed. Check the battery in the transmitter. To replace the battery, see “REPLACING TRANSMITTER BATTERY”.


flashes


intermittently and


“PANIC” SWITCH Pushing the “PANIC” switch blows the horn the headlights, tail lights, turn signal lights and interior light. The “PANIC” switch is used to deter ve- hicle theft when you witness anyone at- tempting into or damage your vehicle. The alarm will last for one minute. To stop the alarm midway, push any switch on the transmitter or turn the ignition key from the “LOCK” to “ON” position. The “PANIC” mode does not work when the ignition key is in the “ON” position.


to break


14


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


If you lose your transmitter, contact your Toyota dealer as soon as possible to avoid the possibility of theft, or an acci- dent. (See “If you lose your wireless re- mote control transmitter” on page 186 in Section 4.)


MODEL/FCC ID: GQ43VT27R CAN: 1470 104 105A MADE IN U.S.A. This complies with Part 15 of the FCC rules. Operation is subject to the follow- ing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ- ing interference that may cause unde- sired operation.


REPLACING TRANSMITTER BATTERY For replacement, use a CR2032 lithium battery or equivalent.


CAUTION


Special care should be that small children do not swallow the re- moved transmitter battery or compo- nents.


taken


NOTICE


z When replacing the transmitter bat- tery, be careful not to lose the com- ponents.


z Replace only with


the same or equivalent type recommended by a Toyota dealer.


z Dispose of used batteries according


to the local laws.


Replace the transmitter battery by the fol- lowing procedures:


1. Using a coin or equivalent, open the


transmitter case.


2003 MY COROLLA_U (OM12744U)


15


’03 Corolla U (L/O 0201)


z Be careful not to bend the electrode of the transmitter battery insertion and that dust or oils do not adhere to the transmitter case.


z Close the transmitter case securely.


replacing battery, check


the After transmitter operates properly. If the trans- mitter still does not operate properly, con- tact your Toyota dealer.


that


2. Remove the discharged transmitter bat-


3. Put a new transmitter battery with posi-


tery.


NOTICE


Do not bend the terminals.


tive (+) side up.


Close the transmitter case securely.


NOTICE


z Make sure


the positive side and negative side of the transmitter bat- tery should be faced correctly.


z Do not replace the battery with wet hands. Water may cause unexpected rust.


z Do not touch or move any compo- nents inside of the transmitter, or it may interfere with proper opera- tion.


16


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Power windows


Window lock switch


Automatic operation (to open only): Push the switch completely down and then release it. The window will fully open. To stop the window partway, lightly pull the switch up and then release it.


The windows can be operated with the switch on each door. The power windows work when the ignition switch is in the “ON” position. OPERATING THE DRIVER’S WINDOW Use the switch on the driver’s door. Normal operation: The window moves as long as you hold the switch. To open: Lightly push down the switch. To close: Pull up the switch.


THE


PASSENGERS’


OPERATING WINDOWS Use the switches on the passengers’ doors. The driver’s door also has switches that control the passengers’ windows. The window moves as long as you hold the switch. To open: Push down the switch. To close: Pull up the switch. If you push in the window lock switch on the driver’s door, the passengers’ windows cannot be operated.


2003 MY COROLLA_U (OM12744U)


17


’03 Corolla U (L/O 0201)


Trunk lid—


CAUTION


To avoid serious personal injury, you must do the following. D Always make sure the heads, hands and other parts of the bodies of all occupants are kept completely in- side the vehicle before you close the power windows. If someone’s neck, head or hands get caught in a closing window, it could result in a serious injury. When anyone closes the power windows, make sure that he/she operates the win- dows safely.


D When small children are in the ve- hicle, never let them use the power window switches without supervi- sion. Use the window lock switch to prevent from making unex- pected use of the switches.


them


D Never leave small children alone in the vehicle, especially with the igni- tion key still inserted. They could use the power window switches and get in a window. Unat- tended children can be involved in serious accidents.


trapped


To open the trunk lid from the outside, insert the master key and turn it clock- wise. “Luggage stowage precautions” on See page 153 in Section 2 for precautions in loading luggage. To close the trunk lid, lower it and press down on it. After closing the trunk lid, try pulling it up to make sure it is securely closed.


18


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


—Lock release lever


—Lock release lever cancelling system


CAUTION


Keep the trunk lid closed while driv- ing. This not only keeps the luggage from being thrown out but also pre- vents exhaust gases from entering the vehicle.


To open the trunk lid from the driver’s seat, pull up on the lock release lever.


After closing the trunk lid, insert the master key and turn it counterclockwise to deactivate the lock release lever. After closing the trunk lid, try pulling it up to make sure it is securely locked.


2003 MY COROLLA_U (OM12744U)


19


’03 Corolla U (L/O 0201)


—Internal trunk release handle


Toyota vehicle intrusion protection system (TVIP)


CAUTION


D Always lock the trunk lid and all doors, and keep away the vehicle keys out of children’s reaches.


D Never leave children unattended in the vehicle. Unsupervised children may lock themselves in the vehicle or trunk and suffer serious injuries or death.


is a


theft deterrent system.


TVIP If someone attempts to damage or break into your vehicle, the system sounds the alarm while flashing the lights.


If a person is locked in the trunk, he or she can pull down the phosphores- cent handle on the inside of trunk lid to open the trunk lid. The (glow−in−the−dark) handle will continue to glow for a time after the trunk lid is closed. Exposing the handle to stronger light will cause it to glow longer.


phosphorescent


20


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


5. Make sure


light flashes. Then you may leave the ve- hicle.


indicator


that


the


lights. Also,


Never leave anyone in the vehicle when you set the system because unlocking from the inside activates the alarm. Activating the alarm If the system detects a threat to the it sounds the alarm for one vehicle, flashing headlights and minute while turn signal interior light turns on when the interior light dial is in the DOOR position. The system detects a threat under any of the following conditions: D Either of the front doors is unlocked by means other than the key or wireless remote control transmitter. If the key is not in the ignition switch, all the doors will be automatically locked again.


the


D Any of the doors or trunk lid are forci-


bly opened. The alarm will activate when the trunk lid is opened with a key. Cancel the system before opening the trunk lid.


D The side windows are tapped or bro-


ken.


D The battery


terminal and then reconnected.


is disconnected


D The ignition is hotwired. After one minute, the alarm automatically stops and the indicator light starts flashing again. Reactivating the alarm Once set, until you cancel the system, the system automatically resets the alarm af- ter the alarm has stopped. The alarm will activate again under the same circumstances described in “Activat- ing the alarm”. Stopping the alarm You can stop the alarm in either of the following ways: D Unlock any of the doors with the key or wireless remote control transmitter. D Place the ignition switch in the “ON”


position.


2003 MY COROLLA_U (OM12744U)


21


SETTING THE SYSTEM You can set the system as follows. 1. Remove


the key


from


the


ignition


switch.


2. Have all passengers get out of


the


vehicle.


3. Close all the doors and trunk lid secu-


rely.


the TVIP


4. Lock all the doors with the key or wire- less remote control transmitter. At this time, light comes on. The system will be set in 30 seconds. When the system is set, the indicator light will start to flash.


indicator


’03 Corolla U (L/O 0201)


Hood


CANCELLING THE SYSTEM You can cancel the system as described in “Stopping the alarm”. If you cancel the system by unlocking any of the doors but no door is opened within 30 seconds, all the doors lock automati- cally and the system will be set again. TESTING THE SYSTEM You can check the system operation as follows. 1. Open all the windows. 2. Set


system as described


the


in


“SETTING THE SYSTEM”.


3. Unlock the driver’s door with the inside lock knob. The system should activate and the alarm should sound.


4. Stop the alarm as described in “Stop-


ping the alarm”.


for


to 4


5. Repeat steps 2


the other doors. (For rear doors, unlock and then open the doors as described in step 3.) the system does not work properly,


If have it checked by your Toyota dealer.


To open the hood: 1. Pull the hood lock release lever. The


hood will spring up slightly.


CAUTION


Before driving, be sure that the hood is closed and securely locked. Other- wise, the hood may open unexpected- ly while driving and an accident may occur.


22


2003 MY COROLLA_U (OM12744U)


2. In front of the vehicle, pull up the the


lever and


lift


auxiliary catch hood.


’03 Corolla U (L/O 0201)


Fuel tank cap


CAUTION


After inserting the support rod into the slot, make sure the rod supports the hood securely from falling down on to your head or body.


NOTICE


Be sure to return the support rod to its clip before closing the hood. Clos- ing the hood with the support rod up could cause the hood to bend.


3. Hold the hood open by inserting the


support rod into the slot.


This indicates that the fuel filler door is on the left side of your vehicle.


To insert the support rod into the slot, move it straight up. If it is moved to the side or toward the inside of the vehicle, it may become detached. Before closing the hood, check to see that you have not forgotten any tools, rags, etc. and return its clip—this prevents rattles. Then lower the hood and make sure it locks into place. If necessary, press down gently on the front edge to lock it.


the support rod


to


2003 MY COROLLA_U (OM12744U)


23


’03 Corolla U (L/O 0201)


The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible.


CAUTION


D Make sure the cap is tightened se- in


curely to prevent fuel spillage case of an accident.


D Use only a genuine Toyota fuel tank cap for replacement. It is designed to regulate fuel tank pressure.


2. To remove the fuel tank cap, turn the cap slowly counterclockwise, then pause slightly before removing it. After removing the cap, hang it on the cap hanger.


the cap clockwise


It is not unusual to hear a slight swoosh when the cap is opened. When installing, turn till you hear a click. If the cap is not tightened securely, the malfunction lamp comes on. Make sure the cap is tightened securely.


indicator


1. To open the fuel filler door, pull the


lever up. When refueling, turn off the engine.


CAUTION


D Do not smoke, cause sparks or al- flames when refueling.


low open The fumes are flammable.


D When opening the cap, do not re- move the cap quickly. In hot weath- er, fuel under pressure could cause injury by spraying out of the filler neck is suddenly re- moved.


the cap


if


24


2003 MY COROLLA_U (OM12744U)


Electric moon roof


Sliding operation


Tilting operation


’03 Corolla U (L/O 0201)


the


To operate the moon roof, use switches beside the personal light. The moon roof works when the ignition switch is in the “ON” position. Sun shade operation— The sun shade can be opened or closed by hand. Sliding operation— To open: Push side. The sun shade will be opened together with the roof. To close: Push the switch on the front side. As a precaution when closing, the roof stops at the half closed position before fully closing. Therefore, release the switch and then push it again to close it com- pletely.


the switch on


the rear


Tilting operation— To tilt up: Push the switch on the “UP” side. To lower: Push the switch on the opposite side of the “UP” side. You may stop the moon roof at any de- sired position. The roof will move while the switch is being pushed and stop when released.


CAUTION


To avoid serious personal injury, you must do the following. D While the vehicle is moving, always keep the heads, hands and other parts of the bodies of all occupants away from the roof opening. Other- wise, they could be seriously in- jured if the vehicle stops suddenly or if the vehicle is involved in an accident.


2003 MY COROLLA_U (OM12744U)


25


’03 Corolla U (L/O 0201)


D Always make sure nobody places his/her head, hands and other parts of the body in the roof opening be- fore you close the roof. If some- one’s neck, head or hands get caught in the closing roof, it could result injury. When anyone closes the roof, first make sure it is safe to do so.


in a serious


D Never leave small children alone in the vehicle, especially with the igni- tion key still inserted. They could use the moon roof switches and get trapped in the roof opening. Unat- tended children can be involved in serious accidents.


D Never sit on


top of


the vehicle


around the roof opening.


26


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


SECTION 1− 3


OPERATION OF INSTRUMENTS AND CONTROLS Seats, Seat belts, Steering wheel and Mirrors Seats Front seats Fold−down rear seat Head restraints Seat belts SRS driver airbag and front passenger airbag SRS side airbags Child restraint Tilt steering wheel Outside rear view mirrors Anti−glare inside rear view mirroror Auto anti−glare inside rear view mirror Vanity mirrors


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .


28
28
30
31
32
40
47
53
68
69
70
71
72


2003 MY COROLLA_U (OM12744U)


27


Seats While the vehicle is being driven, all ve- hicle occupants should have the seatback upright, sit well back in the seat and prop- erly wear the seat belts provided.


CAUTION


in


D Do not drive the vehicle unless the occupants are properly seated. Do top of a not allow sitting on folded−down seatback, or the luggage compartment or cargo area. Persons not properly seated and/or properly restrained by seat belts can be severely injured in the event of emergency braking or a collision. D During driving, do not allow pas- to stand up or move sengers around between seats. Severe inju- ries can occur in the event of emer- gency braking or a collision.


’03 Corolla U (L/O 0201)


Front seats— —Front seat precautions (on vehicles with SRS side airbags)


CAUTION


The SRS side airbags are installed in the driver and front passenger seats. Observe the following precautions. D Do not lean against the front door when the vehicle is in use, since the side airbag inflates with consid- erable speed and force. Otherwise, you may be killed or seriously in- jured.


D Do not use seat accessories which cover the parts where the side air- bags inflate. Such accessories may prevent the side airbags from acti- vating correctly, causing death or serious injury.


the


D Do not modify or replace the seats or upholstery of front seats with the side airbags. Such changes may disable the system or cause the side airbags to inflate acciden- tally, resulting in death or serious injury. Consult your Toyota dealer if you insist on modifications of this kind.


—Seat adjustment precautions Adjust the driver’s seat so that the foot pedals, steering wheel and instrument panel controls are within easy reach of the driver.


CAUTION


D Adjustments should not be made while the vehicle is moving, as the seat may unexpectedly move and cause the driver to lose control of the vehicle.


D When adjusting the seat, be careful that the seat does not hit a passen- ger or luggage.


D After adjusting the seat position, try sliding it forward and backward to make sure it is locked in posi- tion.


D After adjusting the seatback, push back your body to make sure it is locked in position.


D Do not put objects under the seats. Otherwise, the objects may interfere with the seat−lock mechanism or unexpectedly push up the seat posi- tion adjusting lever and the seat may suddenly move, causing the driver to lose control of the vehicle.


28


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


—Adjusting front seats


D While adjusting the seat, do not put your hands under the seat or near the moving parts. Otherwise, you may catch and injure your hands or fingers.


1. SEAT POSITION ADJUSTING LEVER Hold the center of the lever and pull it up. Then slide the seat to the desired position with slight body pressure and release the lever. 2. SEAT HEIGHT ADJUSTING KNOB Turn the knob either way. ANGLE 3. SEATBACK


ADJUSTING


LEVER


lever up. lean back to the desired angle


Lean forward and pull the Then and release the lever.


2003 MY COROLLA_U (OM12744U)


29


CAUTION


To reduce the risk of sliding under the lap belt during a collision, avoid reclining the seatback any more than needed. The seat belts provide maxi- mum protection in a frontal or rear collision when the driver and the pas- senger are sitting up straight and well back If you are reclined, the lap belt may slide past your hips and apply restraint forces directly to the abdomen. In the event of a frontal collision, the more the seat is reclined, the greater the risk of personal injury.


in the seats.


’03 Corolla U (L/O 0201)


Fold−down rear seat


FOLDING DOWN REAR SEAT 1. To unlock the seatback, pull the le-


ver in the trunk.


2. Fold down the seatback. Each seatback can be folded separately. This will enlarge the trunk as far as the seatbacks. See “Luggage stowage precau- tions” on page 153 in Section 2 for pre- cautions in loading luggage.


NOTICE


Make sure the luggage loaded in the enlarged trunk will not damage the webbing of the rear center seat belt when folded down.


the right seatback


is


30


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Head restraints


CAUTION


When returning the seatback to the upright position, observe the follow- ing precautions in order to prevent personal injury in a collision or sud- den stop: D Make sure the seatback is securely locked by pushing forward and rear- ward on the top of the seatback. Failure to do so will prevent the seat belt from operating properly.


D Make sure the seat belts are not twisted or caught in the seatback and are arranged the proper position and are ready to use.


in


BEFORE RETURNING REAR SEAT Make sure the shoulder belt pass through the guide when returning the seatback up.


Front


Rear


2003 MY COROLLA_U (OM12744U)


31


’03 Corolla U (L/O 0201)


For your safety and comfort, adjust the head restraint before driving. To raise: Pull it up. To lower: Push it down while pressing the lock release button. The head restraint is most effective when it is close to your head. Therefore, using a cushion on the seatback is not recom- mended.


CAUTION


D Adjust the center of the head re- straint so that it is closest to the top of your ears.


D After adjusting the head restraint, make sure it is locked in position. the head re-


D Do not drive with


straints removed.


Seat belts— —Seat belt precautions Toyota strongly urges that the driver and passengers in the vehicle be properly re- strained at all times with the seat belts provided. Failure to do so could increase the chance of injury and/or the severity of injury in accidents. Child. Use a child restraint system ap- propriate for the child until the child be- comes large enough to properly wear the vehicle’s seat belts. See “Child restraint” on page 53 for details. If a child is too large for a child restraint system, the child should sit in the rear seat and must be restrained using the vehicle’s seat belt. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat. If a child must sit in the front seat, the seat belts should be worn properly. If an accident occurs and the seat belts are not worn properly, the force of the rapid infla- tion of the airbag may cause death or serious injury to the child.


Do not allow the child to stand up or kneel on either rear or front seats. An unrestrained child could suffer serious in- jury or death during emergency braking or a collision. Also, do not let the child sit on your lap. It does not provide sufficient restraint. Pregnant woman. Toyota recommends the use of a seat belt. Ask your doctor for specific lap belt should be worn securely and as low as possible over the hips and not on the waist. Injured person. Toyota recommends the use of a seat belt. Depending on the inju- ry, first check with your doctor for specific recommendations.


recommendations. The


CAUTION


the vehicle


Persons should ride in their seats properly wearing their seat belts whenever is moving. Otherwise, they are much more likely to suffer serious bodily injury or death in the event of sudden braking or a collision.


32


2003 MY COROLLA_U (OM12744U)


When using the seat belts, observe the following: D Use the belt for only one person at a time. Do not use a single belt for two or more people—even children. D Avoid reclining the seatbacks too much. The seat belts provide maxi- mum protection when the seatbacks are in the upright position. (Refer to the seat adjustment instructions.) D Be careful not to damage the belt webbing or hardware. Take care that they do not get caught or pinched in the seat or doors.


D Inspect the belt system periodically. Check for cuts, fraying, and loose parts. Damaged parts should be re- placed. Do not disassemble or modify the system.


D Keep the belts clean and dry.


If they need cleaning, use a mild soap solution or lukewarm water. Never use bleach, dye, or abrasive clean- ers—they may severely weaken the belts. (See “Cleaning the interior” on page 191 in Section 5.)


’03 Corolla U (L/O 0201)


—Front and rear seat belts


D Replace the belt assembly (includ- ing bolts) if it has been used in a severe impact. The entire assembly should be replaced even if damage is not obvious.


Adjust the seat as needed (front seats only) and sit up straight and well back in the seat. To fasten your belt, pull it out of the retractor and insert the tab into the buckle. You will hear a click when the tab locks into the buckle. The seat belt length automatically adjusts to your size and the seat position. The retractor will lock the belt during a sudden stop or on impact. It also may lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around freely.


2003 MY COROLLA_U (OM12744U)


33


’03 Corolla U (L/O 0201)


CAUTION


Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause serious injuries in a collision.


If the seat belt cannot be pulled out of the retractor, firmly pull the belt and release it. You will then be able to smoothly pull the belt out of the retractor. When a passenger’s shoulder belt is com- pletely extended and retracted even slightly, the belt is locked in that position and cannot be extended. This fea- ture is used to hold the child restraint system securely. (For details, see “Child restraint” on page 53 in this section.) To free the belt again, fully retract the belt and then pull the belt out once more.


then


is


Seat belts with an adjustable shoulder anchor— Adjust the shoulder anchor position to your size. To raise: Slide the anchor up. To lower: Push in the lock release button and slide the anchor down. After adjustment make sure the anchor is locked in position.


CAUTION


D After inserting the tab, make sure that the tab and buckle are locked, and the belt is not twisted.


D Do not insert coins, clips, etc. in the buckle as this may prevent you from properly latching the tab and buckle.


D If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed. It cannot protect an adult occupant or your child from injury.


34


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


Take up slack


Too high


CAUTION


D Both high−positioned lap belts and loose−fitting belts could cause seri- ous injuries due to sliding under the lap belt during a collision or other unintended result. Keep the lap belt positioned as low on hips as possible.


D For your safety, do not place the


shoulder belt under your arm.


Keep as low on hips as possible


the


lap and


the position of


Adjust shoulder belts. Position the lap belt as low as possible on your hips—not on your waist, then ad- just it to a snug fit by pulling the shoulder portion upward through the latch plate.


To release the belt, press the buckle−re- lease button and allow the belt to re- tract. If the belt does not retract smoothly, pull it out and check for kinks or twists. Then make sure it remains untwisted as it re- tracts.


2003 MY COROLLA_U (OM12744U)


35


’03 Corolla U (L/O 0201)


from your Toyota dealer


—Seat belt extender If your seat belts cannot be fastened se- curely because they are not long enough, a personalized seat belt extender is avail- able free of charge. Please contact your local Toyota dealer so that the dealer can order the proper re- quired length for the extender. Bring the heaviest coat you expect to wear for prop- er measurement and selection of length. Additional ordering information is available at your Toyota dealer.


CAUTION


D Remember that the extender pro- vided for you may not be safe when used on a different vehicle, for another person, or at a different seating position than the one origi- nally intended.


the


When using the seat belt extender, following precautions. observe Failure to follow these instructions could reduce the effectiveness of the seat belt restraint system in case of vehicle the chance of personal injury. D Never use the seat belt extender if you can fasten the seat belt without it.


increasing


accident,


Make sure the shoulder belt pass through the guide when using the seat belt for rear outside seat.


36


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


—Front seat belt pretensioners


CAUTION


D After inserting the tab, make sure that the tab and buckle are locked, and the seat belt extender is not twisted.


D Do not insert coins, clips, etc. in the buckle as this may prevent you from properly latching the tab and buckle.


D If the seat belt does not function normally, immediately contact your Toyota dealer. Do not use the seat until the seat belt is fixed. It cannot protect an adult occupant or your child from injury.


The driver and front passenger’s seat belt pretensioners are designed to be activated in response to a severe fron- tal impact. When the airbag sensor detects the shock of a severe frontal impact, the front seat belts are quickly drawn back in by the retractors so that the belts snugly restrain the front seat occupants. The front seat belt pretensioners are acti- vated even with no passenger in the front seat.


2003 MY COROLLA_U (OM12744U)


37


To connect the extender to the seat belt, insert the tab into the seat belt buckle so that the “PRESS” signs on the buckle−release buttons of the ex- tender and the seat belt are both facing outward as shown. You will hear a click when the tab locks into the buckle. When releasing the seat belt, press on the buckle−release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and extend- er itself. When not and store in the vehicle for future use.


in use, remove the extender


’03 Corolla U (L/O 0201)


When the front seat belt pretensioners are activated, an operating noise may be heard and a small amount of smoke−like gas may be released. This gas is harm- less and does not indicate that a fire is occurring. Once front seat belt pretensioners the have been activated, the seat belt retrac- tors remain locked.


CAUTION


Do not modify, remove, strike or open the front seat belt pretensioner as- semblies, airbag sensor or surround- ing area or wiring. Doing so may cause sudden operation of the front seat belt pretensioners or disable the system, which could result in death or serious injury. Failure to follow these instructions can result in death or serious inju- ries. Consult your Toyota dealer about any repairs and modifications.


The front seat belt pretensioner system mainly consists of the following compo- nents and their locations are shown in the illustration. 1. Front airbag sensors 2. Front seat belt pretensioner assemblies 3. Airbag sensor assembly 4. SRS warning light The front seat belt pretensioners are con- trolled by the airbag sensor assembly. The airbag sensor assembly consists of a saf- ing sensor and airbag sensor.


light system monitors


This indicator comes on when the igni- tion key is turned to the “ON” position. It goes off after about 6 seconds. This means the front seat belt pretensioners are operating properly. This warning the airbag sensor assembly, front airbag sen- sors, side airbag sensors, driver’s seat position sensor, driver’s seat belt buckle switch, front seat belt pretensioner assem- blies, inflators, warning light, interconnect- ing wiring and power sources. (For details, see indicators and warning buzzers” on page 85 in Section 1−5.)


reminder


“Service


38


2003 MY COROLLA_U (OM12744U)


’03 Corolla U (L/O 0201)


NOTICE


consulting


Do not perform any of the following changes without your Toyota dealer. Such changes can interfere with proper operation of the front seat belt pretensioners in some cases. z Installation of electronic devices such as a mobile two−way radio, cassette tape player or compact disc player


z Repairs on or near the front seat


belt retractor assemblies


z Modification of the suspension sys-


tem


z Modification of the front end struc-


ture


z Attachment of a grille guard (bull bar, kangaroo bar, etc.), snowplow, winches or any other equipment to the front end


z Repairs made on or near the front fenders, front end structure or con- sole


following


conditions occurs,


This front seat belt pretensioner system has a service reminder indicator to inform the driver of operating problems. If any of the this indicates a malfunction of the airbags or pretensioners. Contact your Toyota dealer as soon as possible the vehicle. D The light does not come on when the ignition key is turned to the “ON” posi- tion, or the light remains on.


to service


In the following cases, contact your Toyota dealer as soon as possible: D The front of the vehicle (shaded in the illustration) was involved in an accident that was not severe enough to cause the front seat belt pretensioners to op- erate.


D Either front seat belt pretensioner as- sembly is scratched, cracked, or otherwise dam- aged.


surrounding


area


or


D The light comes on or flashes while


driving.


D If either front seat belt does not retract or cannot be pulled out due to a mal- function or activation of the relevant front seat belt pretensioner.


2003 MY COROLLA_U (OM12744U)


39


’03 Corolla U (L/O 0201)


SRS driver airbag and front passenger airbag


The SRS (Supplemental Restraint Sys- tem) front airbags are designed to pro- vide further protection for the driver and front passenger in addition to the primary safety protection provided by the seat belts. In response to a severe frontal impact, the SRS front airbags work together with the seat belts to help reduce injury by inflating. The SRS front airbags help to reduce injuries mainly to the driver’s or front passenger’s head or chest caused by directly hitting the steering wheel or dash- board. The front passenger airbag is acti- vated even with no passenger in the front seat. Be sure to wear your seat belt properly. 40


Your vehicle is equipped with a crash sensing and diagnostic module, which will record the use of the seat belt restraint system by the driver and front passenger when the SRS airbags are inflated.


CAUTION


The driver or front passenger who is too close to the steering wheel or dashboard during airbag deployment can be killed or seriously injured. Toyota strongly recommends that: D The driver sit as far back as pos- sible from the steering wheel while still maintaining control of the ve- hicle.


D The front passenger sit as far back


as possible from the dashboard.


D All vehicle occupants be properly restrained using the available seat belts.


2003 MY COROLLA_U (OM12744U)


light system monitors


This indicator comes on when the igni- tion key is turned to the “ON” position. It goes off after about 6 seconds. This means the SRS front airbags are oper- ating properly. This warning the airbag sensor assembly, front airbag sen- sors, side airbag sensors, driver’s seat position sensor, driver’s seat belt buckle switch, front seat belt pretensioner assem- blies, inflators, warning light, interconnect- ing wiring and power sources. (For details, see indicators and warning buzzers” on page 85 in Section 1−5.)


reminder


“Service


’03 Corolla U (L/O 0201)


this


However, threshold velocity will be considerably higher if the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact, or if it is involved in an underride collision (e.g. a collision in which the nose of the vehicle “underrides”, or goes under, the bed of a truck, etc.). For the safety of all occupants, always wear your seat belts properly.


Collision from the rear


Collision from the side


Vehicle rollover


The SRS front airbags are not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low−speed frontal collision.


2003 MY COROLLA_U (OM12744U)


41


The SRS front airbag system is de- signed to activate in response to a se- vere frontal impact within the shaded area between the arrows in the illustra- tion. The SRS front airbags will deploy if the severity of the impact is above the de- signed threshold level, comparable to an approximate 25 km/h (15 mph) collision when impacting straight into a fixed barrier that does not move or deform. If the severity of the impact is below the above threshold level, the SRS front air- bags may not deploy.


’03 Corolla U (L/O 0201)


Hitting a curb, edge of pavement or hard material


Falling into or jumping over a deep hole


Landing hard or vehicle falling


The SRS front airbags may deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.


In a severe frontal impact, the sensor de- tects deceleration and the system triggers the airbag inflators. At this time a chemi- cal reaction in the inflators quickly fills the airbags with non−toxic gas to help restrain the forward motion of the occupants. When the airbags inflate, they produce a fairly loud noise and release some smoke and residue along with non−toxic gas. This does not indicate a fire. This gas is nor- mally harmless; however, for those who have delicate skin, it may cause a minor skin irritation. Be sure to wash off any residue as soon as possible to prevent any potential skin irritation. Deployment of the airbags happens in a fraction of a second, so the airbags must inflate with considerable force. While the system is designed to reduce serious inju- ries, it may also cause minor burns or abrasions and swelling. Parts of the airbag module (steering wheel hub, dashboard) may be hot for several minutes, but the airbags themselves will not be hot. The airbags are designed to inflate only once.


The SRS airbag system consists mainly of the following components, and their loca- tions are shown in the illustration. 1. Front airbag sensors 2. Airbag module for front passenger


(airbag and inflator)


3. Driver’s seat belt buckle switch 4. Driver’s seat position sensor 5. Airbag sensor assembly 6. Airbag module for driver


Loading...
x
