2015 Ford F 150 Owners Manual

Download PDF Manual
2015 F-150 Owner’s Manual ’ fordowner.com ford.ca May 2015 Third Printing Owner’s Manual F-150 Litho in U.S.A. PMFL3J 19A321 AA The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2015 All rights reserved. Part Number: 20150331214252 Table of Contents Introduction About This Manual...........................................7 Symbols Glossary.............................................7 Data Recording..................................................9 California Proposition 65..............................11 Perchlorate.........................................................11 Ford Credit..........................................................11 Replacement Parts Recommendation........................................11 Special Notices................................................12 Mobile Communications Equipment.....................................................12 Export Unique Options..................................13 Environment Protecting the Environment........................14 Child Safety General Information.......................................15 Installing Child Seats.....................................16 Booster Seats..................................................28 Child Seat Positioning..................................30 Child Safety Locks...........................................31 Safety Belts Principle of Operation...................................33 Fastening the Safety Belts..........................34 Safety Belt Height Adjustment.................38 Safety Belt Warning Lamp and Indicator Chime.............................................................39 Safety Belt Minder.........................................39 Child Restraint and Safety Belt Maintenance.................................................41 Personal Safety System™ Personal Safety System™..........................42 Supplementary Restraints System Principle of Operation..................................43 Driver and Passenger Airbags...................44 Front Passenger Sensing System............45 Side Airbags.....................................................47 Safety Canopy™............................................48 Crash Sensors and Airbag Indicator.......49 Airbag Disposal..............................................50 Keys and Remote Controls General Information on Radio Frequencies...................................................51 Remote Control...............................................51 Replacing a Lost Key or Remote Control...........................................................56 MyKey™ Principle of Operation...................................57 Creating a MyKey...........................................58 Clearing All MyKeys.......................................59 Checking MyKey System Status...............59 Using MyKey With Remote Start Systems........................................................60 MyKey Troubleshooting..............................60 Locks Locking and Unlocking.................................62 Keyless Entry...................................................64 Security Passive Anti-Theft System.........................67 Anti-Theft Alarm............................................69 Power Running Boards Using Power Running Boards.....................71 Steering Wheel Adjusting the Steering Wheel....................73 Audio Control...................................................74 Voice Control....................................................75 Cruise Control..................................................75 Information Display Control.......................76 F-150 (TFC), enUSA, Third Printing Table of Contents Hints on Controlling the Interior Climate.........................................................135 Heated Windows and Mirrors...................137 Cabin Air Filter................................................137 Remote Start.................................................138 Seats Sitting in the Correct Position..................139 Head Restraints............................................139 Manual Seats..................................................141 Power Seats....................................................142 Memory Function.........................................144 Rear Seats.......................................................145 Heated Seats.................................................146 Climate Controlled Seats..........................147 Front Seat Armrest......................................148 Rear Seat Armrest........................................149 Universal Garage Door Opener Universal Garage Door Opener...............150 Auxiliary Power Points Auxiliary Power Points................................154 Storage Compartments Center Console..............................................156 Overhead Console........................................157 Starting and Stopping the Engine General Information....................................158 Ignition Switch...............................................158 Keyless Starting............................................158 Starting a Gasoline Engine.......................159 Engine Block Heater....................................162 Unique Driving Character- istics Auto-Start-Stop...........................................164 Pedals Adjusting the Pedals......................................77 Wipers and Washers Windshield Wipers.........................................78 Autowipers........................................................78 Windshield Washers.....................................79 Lighting Lighting Control..............................................80 Autolamps.......................................................80 Instrument Lighting Dimmer......................81 Daytime Running Lamps.............................82 Automatic High Beam Control..................82 Front Fog Lamps............................................84 Direction Indicators.......................................84 Spot Lamps.....................................................84 Interior Lamps.................................................85 Ambient Lighting............................................87 Windows and Mirrors Power Windows.............................................88 Exterior Mirrors................................................89 Interior Mirror...................................................93 Sun Visors.........................................................93 Moonroof...........................................................93 Instrument Cluster Gauges...............................................................95 Warning Lamps and Indicators................98 Audible Warnings and Indicators...........102 Information Displays General Information....................................103 Information Messages.................................118 Climate Control Manual Climate Control..............................131 Automatic Climate Control.......................133 F-150 (TFC), enUSA, Third Printing Table of Contents Fuel and Refueling Safety Precautions......................................166 Fuel Quality.....................................................167 Running Out of Fuel....................................168 Refueling.........................................................169 Fuel Consumption........................................170 Emission Control System............................171 Transmission Automatic Transmission............................174 Four-Wheel Drive Using Four-Wheel Drive............................180 Rear Axle Electronic Locking Differential................188 Brakes General Information....................................190 Hints on Driving With Anti-Lock Brakes...........................................................190 Parking Brake.................................................190 Electric Parking Brake..................................191 Hill Start Assist..............................................193 Traction Control Principle of Operation.................................195 Using Traction Control................................195 Stability Control Principle of Operation................................196 Using Stability Control................................197 Terrain Response Principle of Operation................................198 Using Hill Descent Control........................198 Parking Aids Parking Aid....................................................200 Active Park Assist.........................................201 Rear View Camera......................................205 360 Degree Parking Aid Camera...........208 Cruise Control Principle of Operation..................................211 Using Cruise Control.....................................211 Using Adaptive Cruise Control.................212 Driving Aids Driver Alert......................................................219 Lane Keeping System.................................219 Blind Spot Information System..............223 Cross Traffic Alert........................................225 Steering...........................................................228 Collision Warning System........................229 Load Carrying Load Limit.......................................................232 Tailgate............................................................238 Towing Towing a Trailer............................................248 Trailer Sway Control...................................249 Recommended Towing Weights...........249 Essential Towing Checks..........................260 Towing Points...............................................266 Transporting the Vehicle...........................267 Towing the Vehicle on Four Wheels......268 Driving Hints Breaking-In......................................................271 Economical Driving.......................................271 Driving Through Water...............................272 Floor Mats.......................................................272 Snowplowing.................................................273 Roadside Emergencies Roadside Assistance..................................276 F-150 (TFC), enUSA, Third Printing Table of Contents Power Steering Fluid Check.....................307 Washer Fluid Check....................................307 Fuel Filter........................................................307 Changing the 12V Battery.........................307 Checking the Wiper Blades.....................309 Changing the Wiper Blades....................309 Adjusting the Headlamps.........................310 Changing a Bulb.............................................311 Bulb Specification Chart............................315 Changing the Engine Air Filter..................317 Vehicle Care General Information....................................318 Cleaning Products........................................318 Cleaning the Exterior...................................318 Waxing..............................................................319 Cleaning the Engine.....................................319 Cleaning the Windows and Wiper Blades..........................................................320 Cleaning the Interior...................................320 Cleaning the Instrument Panel and Instrument Cluster Lens.........................321 Cleaning Leather Seats..............................321 Repairing Minor Paint Damage...............322 Cleaning the Alloy Wheels.......................323 Vehicle Storage.............................................323 Wheels and Tires General Information...................................326 Tire Care..........................................................328 Using Snow Chains.....................................343 Tire Pressure Monitoring System..........344 Changing a Road Wheel...........................349 Technical Specifications...........................357 Capacities and Specific- ations Engine Specifications................................358 Motorcraft Parts..........................................359 Vehicle Identification Number................359 Hazard Warning Flashers..........................277 Fuel Shutoff....................................................277 Jump Starting the Vehicle........................278 Post-Crash Alert System..........................280 Customer Assistance Getting the Services You Need................281 In California (U.S. Only).............................282 The Better Business Bureau (BBB) Auto Line Program (U.S. Only).....................283 Utilizing the Mediation/Arbitration Program (Canada Only).......................283 Getting Assistance Outside the U.S. and Canada........................................................284 Ordering Additional Owner's Literature....................................................285 Reporting Safety Defects (U.S. Only)............................................................285 Reporting Safety Defects (Canada Only)............................................................286 Fuses Fuse Specification Chart...........................287 Changing a Fuse..........................................295 Maintenance General Information...................................296 Opening and Closing the Hood..............296 Under Hood Overview - 2.7L EcoBoost™................................................297 Under Hood Overview - 3.5L Ecoboost™................................................298 Under Hood Overview - 3.5L..................299 Under Hood Overview - 5.0L..................300 Engine Oil Dipstick.......................................301 Engine Oil Check...........................................301 Engine Coolant Check...............................302 Automatic Transmission Fluid Check...........................................................306 Transfer Case Fluid Check.......................306 Brake Fluid Check........................................307 F-150 (TFC), enUSA, Third Printing Table of Contents Information....................................................473 Climate............................................................482 Navigation......................................................485 Accessories Accessories....................................................494 Extended Service Plan (ESP) Extended Service Plan (ESP)................496 Scheduled Maintenance General Maintenance Information.......498 Normal Scheduled Maintenance...........501 Special Operating Conditions Scheduled Maintenance.............................................504 Scheduled Maintenance Record...........507 Appendices End User License Agreement...................517 Type Approvals.............................................532 Vehicle Certification Label......................360 Transmission Code Designation.............361 Capacities and Specifications - 2.7L EcoBoost™................................................362 Capacities and Specifications - 3.5L Ecoboost™................................................366 Capacities and Specifications - 3.5L....370 Capacities and Specifications - 5.0L...............................................................375 Audio System General Information...................................380 Audio Unit - Vehicles With: AM/FM.......381 Audio Unit - Vehicles With: AM/FM/ CD..................................................................383 Audio Unit - Vehicles With: AM/FM/ SYNC...........................................................386 Audio Unit - Vehicles With: AM/FM/CD/ SYNC/Satellite Radio............................388 Audio Unit - Vehicles With: Sony AM/FM/ CD.................................................................390 Digital Radio..................................................392 Satellite Radio..............................................394 Audio Input Jack...........................................397 USB Port..........................................................397 Media Hub......................................................398 SYNC™ General Information...................................399 Using Voice Recognition............................401 Using SYNC™ With Your Phone...........403 SYNC™ Applications and Services.......413 Using SYNC™ With Your Media Player.............................................................417 SYNC™ Troubleshooting.........................424 MyFord Touch™ General Information...................................433 Settings..........................................................440 Entertainment..............................................450 Phone...............................................................467 F-150 (TFC), enUSA, Third Printing 6 F-150 (TFC), enUSA, Third Printing Introduction ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about your vehicle, the greater the safety and pleasure you will get from driving it. WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. Note: This manual describes product features and options available throughout the range of available models, sometimes even before they are generally available. It may describe options not fitted to the vehicle you have purchased. Note: Some of the illustrations in this manual may show features as used in different models, so they may appear different to you on your vehicle. Note: Always use and operate your vehicle in line with all applicable laws and regulations. Note: Pass on this manual when selling your vehicle. It is an integral part of your vehicle. This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat. F-150 (TFC), enUSA, Third Printing Right-hand side. Left-hand side. SYMBOLS GLOSSARY These are some of the symbols you may see on your vehicle. Safety alert See Owner's Manual Air conditioning system Anti-lock braking system Avoid smoking, flames or sparks Battery Battery acid Brake fluid - non petroleum based E154903E162384Introduction Brake system Cabin air filter Check fuel cap Front airbag Front fog lamps Fuel pump reset Child safety door lock or unlock Fuse compartment Child seat lower anchor Hazard warning flashers Child seat tether anchor Heated rear window Cruise control Heated windshield Do not open when hot Engine air filter Engine coolant Interior luggage compartment release Jack Keep out of reach of children Engine coolant temperature Lighting control Engine oil Explosive gas Fan warning Low tire pressure warning Maintain correct fluid level Note operating instructions Fasten safety belt Panic alarm F-150 (TFC), enUSA, Third Printing E71340E161353Introduction facilities may access or share among them vehicle diagnostic information received through a direct connection to your vehicle when diagnosing or servicing your vehicle. Additionally, when your vehicle is in for service or repair, Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them data for vehicle improvement purposes. For U.S. only (if equipped), if you choose to use the SYNC Vehicle Health Report, you consent that certain diagnostic information may also be accessed electronically by Ford Motor Company and Ford authorized service facilities, and that the diagnostic information may be used for any purpose. See SYNC™ (page 399). Event Data Recording This vehicle is equipped with an event data recorder. The main purpose of an event data recorder is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle; this data will assist in understanding how a vehicle’s systems performed. The event data recorder is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The event data recorder in this vehicle is designed to record such data as: • How various systems in your vehicle were operating; • Whether or not the driver and passenger safety belts were buckled/fastened; • How far (if at all) the driver was depressing the accelerator and/or the brake pedal; and • How fast the vehicle was traveling; and • Where the driver was positioning the steering wheel. Parking aid Parking brake Power steering fluid Power windows front/rear Power window lockout Service engine soon Side airbag Shield the eyes Stability control Windshield wash and wipe DATA RECORDING Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair F-150 (TFC), enUSA, Third Printing E139213E167012E138639Introduction This data can help provide a better understanding of the circumstances in which crashes and injuries occur. Note: Event data recorder data is recorded by your vehicle only if a non-trivial crash situation occurs; no data is recorded by the event data recorder under normal driving conditions and no personal data or information (e.g., name, gender, age, and crash location) is recorded (see limitations regarding 911 Assist and Traffic, directions and Information privacy below). However, parties, such as law enforcement, could combine the event data recorder data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an event data recorder, special equipment is required, and access to the vehicle or the event data recorder is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have such special equipment, can read the information if they have access to the vehicle or the event data recorder. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada. Note: Including to the extent that any law pertaining to Event Data Recorders applies to SYNC or its features, please note the following: Once 911 Assist (if equipped) is enabled (set ON), 911 Assist may, through any paired and connected cell phone, disclose to emergency services that the vehicle has been in a crash involving the deployment of an airbag or, in certain vehicles, the activation of the fuel pump shut-off. Certain versions or updates to 911 Assist may also be capable of being used to electronically or verbally provide to 911 operators the vehicle location (such as latitude and longitude), and/or other details about the vehicle or crash or personal information about the occupants to assist 911 operators to provide the most appropriate emergency services. If you do not want to disclose this information, do not activate the 911 Assist feature. See SYNC™ (page 399). Additionally, when you connect to Traffic, Directions and Information (if equipped, U.S. only), the service uses GPS technology and advanced vehicle sensors to collect the vehicle’s current location, travel direction, and speed (“vehicle travel information”), only to help provide you with the directions, traffic reports, or business searches that you request. If you do not want Ford or its vendors to receive this information, do not activate the service. For more information, see Traffic, Directions and Information, Terms and Conditions. See SYNC™ (page 399). 10 F-150 (TFC), enUSA, Third Printing Introduction REPLACEMENT PARTS RECOMMENDATION Your vehicle has been built to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging. Scheduled Maintenance and Mechanical Repairs One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this Owner’s Manual. Genuine Ford and Motorcraft parts meet or exceed these specifications. Collision Repairs We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development we validate these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts. CALIFORNIA PROPOSITION 65 WARNING Some constituents of engine exhaust, certain vehicle components, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. PERCHLORATE Certain components in your vehicle such as airbag modules, safety belt pretensioners and remote control batteries may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal. For more information visit: Web Address www.dtsc.ca.gov/hazardouswaste/ perchlorate FORD CREDIT (U.S. Only) Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business. For your convenience we offer a number of ways to contact us, as well as to help manage your account. Phone: 1-800-727-7000 For more information regarding Ford Credit, as well as to access Account Manager, please go to www.fordcredit.com. 11 F-150 (TFC), enUSA, Third Printing Introduction Warranty on Replacement Parts Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, refer to the terms and conditions of the Ford Warranty. SPECIAL NOTICES New Vehicle Limited Warranty For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Manual that is provided to you along with your Owner’s Manual. Special Instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. WARNINGS Failure to follow the specific warnings and instructions could result in personal injury. See Supplementary Restraints System (page 43). Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger airbag. On-board Diagnostics (OBD-II) Your vehicle’s On-board Diagnostics (OBD-II) system has a data port for diagnostics, repair and reprogramming services with diagnostic scan tools. Installing a non-Ford-approved aftermarket OBD plug-in device that uses the port during normal driving, for example remote insurance company monitoring, remote vehicle diagnostics, telematics or engine reprogramming, may cause interference or damage to vehicle systems. We do not recommend or endorse the use of any non-Ford-approved aftermarket OBD plug-in devices. The vehicle Warranty may not cover damage caused by any non-Ford-approved aftermarket OBD plug-in device. Notice to owners of pickup trucks and utility type vehicles WARNING Utility vehicles have a significantly higher rollover rate than other types of vehicles. Before you drive your vehicle, please read this Owner’s Manual carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate your vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death. Using your vehicle with a snowplow See Snowplowing (page 273). Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. MOBILE COMMUNICATIONS EQUIPMENT Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be 12 F-150 (TFC), enUSA, Third Printing Introduction paramount when using mobile communications equipment to avoid negating these benefits. Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios. WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. EXPORT UNIQUE OPTIONS For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this Owner’s Manual. A market unique supplement may be supplied that complements this book. By referring to the market unique supplement, if provided, you can properly identify those features, recommendations and specifications that are unique to your vehicle. This Owner’s Manual is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for Export. Refer to this Owner’s Manual for all other required information and warnings. 13 F-150 (TFC), enUSA, Third Printing Environment PROTECTING THE ENVIRONMENT You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim. 14 F-150 (TFC), enUSA, Third Printing Child Safety WARNINGS is compatible with and properly installed in your vehicle. To locate a child seat fitting station and CPST, contact the NHTSA toll free at 1-888-327-4236 or go to http://www.nhtsa.dot.gov. In Canada, check with your local St. John Ambulance office for referral to a CPST or for further information, contact your provincial ministry of transportation, locate your local St. John Ambulance office by searching for St. John Ambulance on the internet, or Transport Canada at 1-800-333-0371 (http://www.tc.gc.ca). Failure to properly restrain children in safety seats made especially for their height, age, and weight may result in an increased risk of serious injury or death to your child. Do not leave children or animals unattended in the vehicle. On hot days, the temperature in the trunk or vehicle interior can rise very quickly. Exposure of people or animals to these high temperatures for even a short time can cause death or serious heat-related injuries, including brain damage. Small children are particularly at risk. GENERAL INFORMATION See the following sections for directions on how to properly use safety restraints for children. WARNINGS Always make sure your child is secured properly in a device that is appropriate for their height, age and weight. Child safety restraints must be bought separately from your vehicle. Failure to follow these instructions and guidelines may result in an increased risk of serious injury or death to your child. All children are shaped differently. The recommendations for safety restraints are based on probable child height, age and weight thresholds from National Highway Traffic Safety Administration and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and 15 F-150 (TFC), enUSA, Third Printing Child Safety Recommendations for Safety Restraints for Children Child Child size, height, weight, or age Recommended restraint type Infants or toddlers Children weighing 40 lb (18 kg) or less (generally age four or younger). Small children Larger children Children who have outgrown or no longer properly fit in a child safety seat (gener- ally children who are less than 4 ft. 9 in. (1.45 m) tall, are greater than age four and less than age 12, and between 40 lb (18 kg) and 80 lb (36 kg) and upward to 100 lb (45 kg) if recommended by your child restraint manufacturer). Children who have outgrown or no longer properly fit in a belt-positioning booster seat (generally children who are at least 4 ft. 9 in. (1.45 m) tall or greater than 80 lb (36 kg) or 100 lb (45 kg) if recom- mended by child restraint manufacturer). Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat). Use a belt-positioning booster seat. Use a vehicle safety belt having the lap belt snug and low across the hips, shoulder belt centered across the shoulder and chest, and seat back upright. INSTALLING CHILD SEATS Child Seats • You are required by law to properly use safety seats for infants and toddlers in the United States and Canada. • Many states and provinces require that small children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms). Check your local and state or provincial laws for specific requirements about the safety of children in your vehicle. • When possible, always properly restrain children 12 years of age and under in a rear seating position of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position. See Front Passenger Sensing System (page 45). 16 F-150 (TFC), enUSA, Third Printing E142594Child Safety Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers, or children weighing 40 pounds (18 kilograms) or less (generally age four or younger). Using Lap and Shoulder Belts (Except Front Center Position of Super Cab and Crew Cab) WARNINGS Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the seat is installed all the way back. Airbags can kill or injure a child in a child seat. Children 12 and under should be properly restrained in the rear seat whenever possible. Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain safety belt buckle assemblies and LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained. • Place the vehicle seat upon which the child seat will be installed in the upright position. • Put the safety belt in the automatic locking mode. This vehicle does not require the use of a locking clip. Perform the following steps when installing the child seat with combination lap and shoulder belts: Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1. Position the child safety seat in a seat with a combination lap and shoulder belt. When installing a child safety seat with combination lap and shoulder belts: • Use the correct safety belt buckle for that seating position. Insert the belt tongue into the proper buckle until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling. • • F-150 (TFC), enUSA, Third Printing 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 17 E142528E142529Child Safety 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out. Note: The automatic locking mode is available on the front passenger and rear seats. This vehicle does not require the use of a locking clip. 6. Allow the belt to retract to remove slack. The belt will click as it retracts to indicate it is in the automatic locking mode. 7. Try to pull the belt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer's instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it. 18 F-150 (TFC), enUSA, Third Printing E142530E142531E142875E142533Child Safety Using Lap and Shoulder Belts (Front Center Position of Super Cab and Crew Cab) WARNINGS Airbags can kill or injure a child in a child seat. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the seat is installed all the way back. Rear facing child seats should never be placed in front of an active airbag. Always use both lap and shoulder safety belt in the center seating position. The belt webbing below the tongue is the lap portion of the combination lap and shoulder belt, and the belt webbing above the tongue is the shoulder belt portion of the combination lap and shoulder belt. 1. Position the child safety seat in the front center seat. 8. Remove remaining slack from the belt. Force the seat down with extra weight, for example, by pressing down or kneeling on the child restraint while pulling up on the shoulder belt in order to force slack from the belt. This is necessary to remove the remaining slack that will exist once the extra weight of the child is added to the child restraint. It also helps to achieve the proper snugness of the child seat to your vehicle. Sometimes, a slight lean toward the buckle will help to remove remaining slack from the belt. 9. Attach the tether strap (if the child seat is equipped). 10. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back. There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a Certified Passenger Seat Technician. 19 F-150 (TFC), enUSA, Third Printing E142534E142528Child Safety 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it. 2. Slide the tongue up the webbing. 5. While pushing down with your knee on the child seat pull up on the shoulder belt portion to tighten the lap belt portion of the combination lap and shoulder belt. 6. Allow the safety belt to retract and remove any slack in the belt to securely tighten the child safety seat in the vehicle. 7. Attach the tether strap (if the child seat is equipped). 3. While holding both shoulder and lap portions next to the tongue, route the tongue and webbing through the child seat according to the child seat manufacturer's instructions. Be sure that the belt webbing is not twisted. 20 F-150 (TFC), enUSA, Third Printing E162708E142530E142531E142533E142534Child Safety 8. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back. There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. 9. Check from time to time to be sure that there is no slack in the lap and shoulder belt. The shoulder belt must be snug to keep the lap belt tight during a crash. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a Child Passenger Safety Technician. Using Inflatable Safety Belts (Rear Seat Outboard Positions) (If Equipped) 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 21 F-150 (TFC), enUSA, Third Printing 2. After positioning the child safety seat in the proper seating position, grasp the shoulder belt and lap belt together behind the belt tongue. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer's instructions. Be sure the belt webbing is not twisted. E142528E146522E142530Child Safety 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it. Note: Unlike the standard safety belt, the inflatable safety belt's unique lap portion locks the child seat for installation. The ability for the shoulder portion of the belt to move freely is normal, even after the lap belt has been put into the automatic locking mode. Note: The lock-off device on some child restraints may not accommodate the shoulder portion of the inflatable safety belt. Follow all instructions provided by the manufacturer of the child restraint regarding the necessary and proper use of the lock-off device. In some instances, these devices have been provided only for use in vehicles with safety belt systems that would otherwise require a locking clip. 6. Allow the belt to retract to remove slack. The belt will click as it retracts to indicate it is in the automatic locking mode. 7. Try to pull the belt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6. 5. To put the retractor in the automatic locking mode, grasp the lap portion of the inflatable safety belt and pull upward until all of the belt is pulled out. Note: The automatic locking mode is available on the front passenger and rear seats. 22 F-150 (TFC), enUSA, Third Printing E146523E146524E146525Child Safety Using Lower Anchors and Tethers for CHildren (LATCH) WARNINGS Never attach two child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death. Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain safety belt buckle assemblies or LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained. The LATCH system is composed of three vehicle anchor points: two lower anchors located where the vehicle seat back and seat cushion meet (called the seat bight) and one top tether anchor located behind that seating position. LATCH compatible child safety seats have two rigid or webbing mounted attachments that connect to the two lower anchors at the LATCH equipped seating positions in your vehicle. This type of attachment method eliminates the need to use safety belts to attach the child seat, however the safety belt can still be used to attach the child seat if the lower anchors are not used. For forward-facing child seats, the top tether strap must also be attached to the proper top tether anchor, if a top tether strap has been provided with your child seat. Your vehicle is equipped with LATCH lower anchors for child seat installation at the following seating positions (LATCH is not available on Regular Cab): 8. Remove remaining slack from the belt. Force the seat down with extra weight, for example, by pressing down or kneeling on the child restraint while pulling down on the lap belt in order to force slack from the belt. This is necessary to remove the remaining slack that will exist once the extra weight of the child is added to the child restraint. It also helps to achieve the proper snugness of the child seat to your vehicle. Sometimes, a slight lean toward the buckle will additionally help to remove remaining slack from the belt. 9. Attach the tether strap (if the child seat is equipped). 10. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back. There should be no more than 1 inch (2.5 centimeters) of movement for proper installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a Certified Passenger Seat Technician. 23 F-150 (TFC), enUSA, Third Printing E142534Child Safety Crew Cab and Super Cab Use of Inboard Lower Anchors from the Outboard Seating Positions (Center Seating Use) WARNING The standardized spacing for LATCH lower anchors is 11 inches (280 millimeters) center to center. Do not use LATCH lower anchors for the center seating position unless the child seat manufacturer's instructions permit and specify using anchors spaced at least as far apart as those in this vehicle. The lower anchors at the center of the second row rear seat are spaced 25.7 inches (652 millimeters) apart. The standardized spacing for LATCH lower anchors is 11 inches (280 millimeters) center to center. A child seat with rigid LATCH attachments cannot be installed at the center seating position. LATCH compatible child seats (with attachments on belt webbing) can only be used at this seating position provided that the child seat manufacturer's instructions permit use with the anchor spacing stated. Do not attach a child seat to any lower anchor if an adjacent child seat is attached to that anchor. The lower LATCH anchors are located at the rear section of the rear seat between the cushion and seatback. Follow the child seat manufacturer's instructions to properly install a child seat with LATCH attachments. Follow the instructions later in this chapter on attaching child safety seats with tether straps. Attach LATCH lower attachments of the child seat only to the anchors shown. 24 F-150 (TFC), enUSA, Third Printing E166694E166695Child Safety Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor, if applicable. Tug the child seat from side to side and forward and back where it is secured to the vehicle. The seat should move less than one inch when you do this for a proper installation. If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. Combining Safety Belt and LATCH Lower Anchors for Attaching Child Safety Seats When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a proper installation is achieved. Attach the tether strap afterward, if included with the child seat. Using Tether Straps Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap, or to obtain a longer tether strap if the tether strap on your safety seat does not reach the appropriate top tether anchor in the vehicle. The passenger seats of your vehicle may be equipped with built-in tether strap anchors located behind the seats as described below. The tether anchors in your vehicle may be loops of webbing above the seatback or an anchor bracket behind the seat on the rear edge of the seat cushion. The rear seat in the Crew Cab and Super Cab has three straps along the top of the seat back that function as both routing loops for the tether straps and anchor loops. The tether strap anchors in your vehicle are in the following positions (shown from top view): Regular Cab 25 F-150 (TFC), enUSA, Third Printing E166696Child Safety Crew Cab and Super Cab 2. Locate the correct anchor for the selected seating position. You may need to pull the seat back forward to access the tether anchors. Make sure the seat is locked in the upright position before installing the child seat. 3. Clip the tether strap to the anchor as shown. Regular Cab passenger and center seats (located on back panel) If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a crash. 4. Tighten the child safety seat tether strap according to the manufacturer's instructions. Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor. If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat. Keeping the child seat just touching the vehicle seat gives the best protection in a severe crash. Once the child safety seat has been installed using either the safety belt, the lower anchors of the LATCH system, or both, you can attach the top tether strap. Front Seat Tether Strap Attachment (Regular Cab) 1. Route the child safety seat tether strap over the back of the seat and under the head restraint. Note: For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seat back. 26 F-150 (TFC), enUSA, Third Printing E166697E175295Child Safety If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Rear Seat Tether Strap Attachment (Crew Cab and Super Cab) 1. Route the tether strap under the head restraint and through the loop directly behind the child seat. There are three loops of webbing just above the back of the rear seat (along the bottom edge of the rear window). Use these loops as both routing loops and anchor loops for up to three child safety seat tether straps. For example, the center loop can be used as a routing loop for a child safety seat in the center rear seat and as an anchoring loop for child seats installed in the outboard rear seats. Many tether straps cannot be tightened if the tether strap is hooked to the loop directly behind the child seat. To provide a tight tether strap: 2. Route the tether strap behind the head restraint supports to a loop behind an adjacent seating position, and hook the strap hook onto the loop. If using the driver side, pass the strap behind the shoulder belt for the center seat. Always put the tether strap through the routing loop. The head restraint support post will hold the child seat tightly, but the head restraint post is not strong enough to hold the child seat during a crash. 3. Tighten the tether strap according to the child seat manufacturer's instructions. 27 F-150 (TFC), enUSA, Third Printing E167009E162714E162715Child Safety If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. BOOSTER SEATS WARNING Never place, or allow a child to place, the shoulder belt under a child's arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash. Note: Some booster seat safety belt guides may not accommodate the shoulder portion of the inflatable safety belt. Use a belt-positioning booster seat for children who have outgrown or no longer properly fit in a child safety seat (generally children who are less than 4 feet 9 inches (1.45 meters) tall, are greater than age four (4) and less than age twelve (12), and between 40 pounds (18 kilograms) and 80 pounds (36 kilograms) and upward to 100 pounds (45 kilograms) if recommended by your child restraint manufacturer). Many state and provincial laws require that children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms). Booster seats should be used until you can answer YES to ALL of these questions when seated without a booster seat: F-150 (TFC), enUSA, Third Printing • Can the child sit all the way back against their vehicle seat back with knees bent comfortably at the edge of the seat cushion? • Can the child sit without slouching? • Does the lap belt rest low across the hips? Is the shoulder belt centered on the shoulder and chest? • • Can the child stay seated like this for the whole trip? Always use booster seats in conjunction with your vehicle lap and shoulder belt. Types of Booster Seats • Backless booster seats 28 E142595E68924Child Safety If your backless booster seat has a removable shield, remove the shield. If a vehicle seating position has a low seat back or no head restraint, a backless booster seat may place your child's head (as measured at the tops of the ears) above the top of the seat. In this case, move the backless booster to another seating position with a higher seat back or head restraint and lap and shoulder belts, or consider using a high back booster seat. • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child's head, a high back booster seat would be a better choice. Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder. The following drawings compare the ideal fit (center) to a shoulder belt uncomfortably close to the neck and a shoulder belt that could slip off the shoulder. The drawings also show how the lap belt should be low and snug across the child's hips. 29 F-150 (TFC), enUSA, Third Printing E70710E142596Child Safety WARNINGS warnings provided by your vehicle manufacturer. A safety seat that is improperly installed or utilized, is inappropriate for your child's height, age, or weight or does not properly fit the child may increase the risk of serious injury or death. Never let a passenger hold a child on his or her lap while your vehicle is moving. The passenger cannot protect the child from injury in a crash, which may result in serious injury or death. Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a crash. Always restrain an unoccupied child seat or booster seat. These objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury. Never place, or allow a child to place, the shoulder belt under a child's arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash. To avoid risk of injury, do not leave children or pets unattended in your vehicle. If the booster seat slides on the vehicle seat upon which it is being used, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition. Do not introduce any item thicker than this under the booster seat. Check with the booster seat manufacturer's instructions. CHILD SEAT POSITIONING WARNINGS Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the child seat is installed all the way back. When possible, all children age 12 and under should be properly restrained in a rear seating position. If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat. Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child's size, height, weight, or age. Follow the child restraint manufacturer's instructions and warnings provided for installation and use in conjunction with the instructions and 30 F-150 (TFC), enUSA, Third Printing E142597Child Safety Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by X Restraint Type Combined weight of child and child seat LATCH (lower anchors and top tether anchor) LATCH (lower anchors only) Safety belt and top tether anchor Safety belt only Safety belt and LATCH (lower anchors and top tether anchor) Up to 65 lb (29.5 kg) Over 65 lb (29.5 kg) Up to 65 lb (29.5 kg) Rear facing child seat Rear facing child seat Forward facing child seat Forward facing Over 65 lb (29.5 kg) child seat Note: The child seat must rest tightly against the vehicle seat upon which it is installed. It may be necessary to lift or remove the head restraint. See Seats (page 139). CHILD SAFETY LOCKS (If Equipped) When these locks are set, the rear doors cannot be opened from the inside. 31 F-150 (TFC), enUSA, Third Printing E112197Child Safety The childproof locks are located on the rear edge of each rear door and must be set separately for each door. Left-Hand Side Turn counterclockwise to lock and clockwise to unlock. Right-Hand Side Turn clockwise to lock and counterclockwise to unlock. 32 F-150 (TFC), enUSA, Third Printing Safety Belts WARNINGS When possible, all children 12 years old and under should be properly restrained in a rear seating position. Failure to follow this could seriously increase the risk of injury or death. Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Front and rear seat occupants, including pregnant women, should wear safety belts for optimum protection in an accident. All seating positions in this vehicle have lap and shoulder safety belts. All occupants of the vehicle should always properly wear their safety belts, even when an airbag supplemental restraint system is provided. The safety belt system consists of: Lap and shoulder safety belts. • Shoulder safety belt with automatic • locking mode, (except driver safety belt). • Height adjuster at the front outboard seating positions. Safety belt pretensioner at the front outboard seating positions. Safety belt warning light and chime. • Crash sensors and monitoring system with readiness indicator. PRINCIPLE OF OPERATION WARNINGS Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a crash, which may result in serious injury or death. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an airbag supplemental restraint system is provided. Failure to properly wear your safety belt could seriously increase the risk of injury or death. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a crash, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Be sure everyone in your vehicle is in a seat and using a safety belt properly. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only. Never wear the shoulder belt under the arm. 2) Never swing the safety belt around your neck over the inside shoulder. 3) Never use a single belt for more than one person. 33 F-150 (TFC), enUSA, Third Printing • • Safety Belts The safety belt pretensioners at the front seating positions are designed to tighten the safety belts when activated. In frontal and near-frontal crashes, side crashes and rollovers, the safety belt pretensioners may be activated alone or, if the crash is of sufficient severity, together with the front airbags. FASTENING THE SAFETY BELTS Standard belts shown, inflatable belts similar The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure you securely fasten the tongue in the buckle. 34 F-150 (TFC), enUSA, Third Printing 2. To unfasten, press the release button and remove the tongue from the buckle. Using the Safety Belt with Cinch Tongue (Front Center Seat) The cinch tongue will slide up and down the belt webbing when the belt is stowed or while putting safety belts on. When you buckle the lap and shoulder safety belt, the cinch tongue will allow you to shorten the lap portion, but pinches the webbing to keep the lap portion from getting longer. The cinch tongue is designed to slip during a crash, so always wear the shoulder belt properly and do not allow any slack in either the lap or shoulder portions. Before you can reach and latch a lap and shoulder belt having a cinch tongue into the buckle, you may have to lengthen the lap belt portion of it. E142587E142588Safety Belts While you are fastened in the safety belt, the lap and shoulder belt with a cinch tongue adjusts to your movement. However, if you brake hard, turn hard, or if your vehicle receives an impact of 5 mph (8 km/h) or more, the safety belt will become locked and help reduce your forward movement. Using Safety Belts During Pregnancy WARNING Always ride and drive with your seatback upright and the safety belt properly fastened. The lap portion of the safety belt should fit snug and be positioned low across the hips. The shoulder portion of the safety belt should be positioned across the chest. Pregnant women should also follow this practice. Pregnant women should always wear their safety belt. Position the lap belt portion of a combination lap and shoulder belt low across the hips below the belly and worn as tight as comfort will allow. Position the shoulder belt to cross the middle of the shoulder and the center of the chest. 1. To lengthen the lap belt, pull some webbing out of the shoulder belt retractor. 2. While holding the webbing below the tongue, grasp the tip (metal portion) of the tongue so that it is parallel to the webbing and slide the tongue upward. 3. Provide enough lap belt length so that the tongue can reach the buckle. Fastening the Cinch Tongue WARNING The lap belt should fit snugly and as low as possible around the hips, not across the waist. 1. Pull the lap and shoulder belt from the retractor so that the shoulder belt portion of the safety belt crosses your shoulder and chest. 3. 2. Be sure the belt is not twisted. If the belt is twisted, remove the twist. Insert the belt tongue into the proper buckle for your seating position until you hear a snap and feel it latch. 4. Make sure you securely fasten the tongue to the buckle by pulling on the tongue. 35 F-150 (TFC), enUSA, Third Printing E162708E142590Safety Belts Safety Belt Locking Modes WARNINGS After any vehicle crash, the safety belt system at all passenger seating positions must be checked by an authorized dealer to verify that the automatic locking retractor feature for child seats is still functioning properly. In addition, all safety belts should be checked for proper function. The belt and retractor must be replaced if the safety belt assembly automatic locking retractor feature or any other safety belt function is not operating properly when checked by an authorized dealer. Failure to replace the belt and retractor assembly could increase the risk of injury in crashes. All safety restraints in the vehicle are combination lap and shoulder belts. The driver safety belt has the first type of locking mode, and the front outboard passenger and rear seat safety belts have both types of locking modes described as follows: Vehicle Sensitive Mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly, turns a corner sharply, or the vehicle receives an impact of about 5 mph (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers. In addition, the retractor is designed to lock if the webbing is pulled out too quickly. If this occurs, let the belt retract slightly and pull webbing out again in a slow and controlled manner. F-150 (TFC), enUSA, Third Printing Automatic Locking Mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to Use the Automatic Locking Mode Use this mode any time you install a child safety seat in a front outboard passenger seating position in a Regular Cab, SuperCab, SuperCrew or any rear seating position of a SuperCab or SuperCrew. The optional front seat's center safety belt has a cinch mechanism. Children 12 years old and under should be properly restrained in a rear seat whenever possible. See Child Safety (page 15). How to Use the Automatic Locking Mode Non-inflatable safety belts 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until you pull the entire belt out. 3. Allow the belt to retract. As the belt
