HIGHLANDER

2 0 1 0

QUICK REFERENCE GUIDE

Printed in U.S.A. 9/09 08-TCS-03070

10%

Cert no. SGS-COC-005612

00505-QRG10-HL

2010

Highlander

This Quick Reference Guide is a summary of basic vehicle operations. It contains brief descriptions of fundamental operations so you can locate and use the vehicle’s main equipment quickly and easily.

The Quick Reference Guide is not intended as a substitute for the Owner’s Manual located in your vehicle’s glove box. We strongly encourage you to review the Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Highlander.

! A word about safe vehicle operations This Quick Reference Guide is not a full description of Highlander operations. Every Highlander owner should review the Owner’s Manual that accompanies this vehicle. Pay special attention to the boxed information highlighted in color throughout the Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.

Seat belts-Shoulder belt anchor

Push up, or squeeze lock release to lower

Doors-Child safety locks Rear door

Moving the lever to “LOCK” will allow the door to be opened only from the outside. Spare tire & tools Tool location

Socket adapter

Jack handle

Towing eyelet Jack

Wrench

Jack handle

Spare tire

(3)

Removing the spare tire (2) (1)

(1) Remove the cover under the center deck board to find the spare tire

clamp bolt.

(2) Assemble the jack handle. (3) Put the socket adapter on the spare tire clamp bolt. Loosen the bolt

by turning it counterclockwise with the jack handle.

Refer to the Owner’s Manual for tire changing and jack positioning procedures.

29

O V E R V I E W

F E A T U R E S / O P E R A T O N S

I

S A F E T Y

A N D

E M E R G E N C Y

F E A T U R E S

INDEX

OVERVIEW

FEATURES/OPERATIONS

Engine maintenance Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry1 Light control-Instrument panel Smart Key system1,2

Air Conditioning/Heating Audio Auto lock functions1 Automatic Transmission Clock Cruise control Cup holders Door locks Door-Power back Downhill Assist Control system (DAC) Garage door opener (HomeLink®)3 Hill-start Assist Control (HAC) Lights1 & turn signals Moonroof Multi-information display2 Parking brake Power outlets-12V DC Power outlets-115V AC Rear seat entertainment system Seat adjustments-Front Seat adjustments-Rear Seat heaters Seats-Folding down second row seats Seats-Head restraints Seats-Removing Center-StowTM second row seat Seats-Stowing third row seats Steering lock release Steering wheel controls Telephone controls (Bluetooth®) Tilt and telescopic steering wheel Windows-Power Windshield wipers & washers

9 8 8 4-5 4 2-3 6 9 7

20-22 24-25

11 10 22 23 27 11 12 26 23 27 16 12 18 11 17 17 26 13 13 22 15 14 14 14 11 25 19 12 18 15

SAFETY AND EMERGENCY FEATURES

29 Doors-Child safety locks 28 Seat belts 29 Seat belts-Shoulder belt anchor Spare tire & tools 29 Tire Pressure Monitoring (warning) System 28

1 Visit your Toyota dealer for information on customizing this feature. 2 Programmable by customer. Refer to the Owner’s Manual for instructions and more information. 3 HomeLink® is a registered trademark of Johnson Controls, Inc.

1

O V E R V I E W

F E A T U R E S / O P E R A T O N S

I

S A F E T Y

A N D

E M E R G E N C Y

F E A T U R E S

OVERVIEW

Instrument panel Steering wheel controls (if equipped)

Automatic Air Conditioning

Steering wheel audio controls1 Steering wheel climate controls1 Multi-information display button1 Voice command button1 Telephone controls1,2 Headlight and turn signal controls/Headlight, turn signal and front fog light controls1 Wiper and washer controls Multi-information display1 Audio system or navigation system-integrated audio system1,2 Theft deterrent system/Engine immobilizer indicator1 Emergency flasher button “AIR BAG ON” and “AIR BAG OFF” indicator and front passenger seat belt reminder lights Power back door main switch1 “ENGINE START STOP” button (Smart Key)1 VSC/TRAC OFF switch

2

Manual Air Conditioning

Vehicles without navigation system

Vehicles with navigation system

Tire Pressure Monitoring (warning) System Cruise control Ignition (standard key) Tilt and telescopic steering lock release Power back door button1 Instrument panel light control 115V AC Power outlet ON/OFF switch1 Windshield wiper de-icer switch1 Power rearview mirror control Outside rearview mirror1/Rear window defogger button Air Conditioning controls

1 If equipped 2 For vehicles with a navigation system, refer to the “Navigation System

Owner’s Manual.”

3

O V E R V I E W

F E A T U R E S / O P E R A T O N S

I

S A F E T Y

A N D

E M E R G E N C Y

F E A T U R E S

OVERVIEW

Instrument cluster

Tachometer Engine coolant temperature Service indicator and reminder Fuel gauge Speedometer Odometer/trip meter switch and trip meter resetting button Automatic Transmission shift position indicator Odometer and two trip meters

Indicator symbols For details, refer to “Indicators and warning lights,” Section 2-2, 2010 Owner’s Manual.

Brake system warning1 Driver seat belt reminder (alarm will sound if speed is over 12 mph) Front passenger seat belt reminder (alarm will sound if speed is over 12 mph)

Charging system warning1 Front passenger occupant classification or front passenger airbag ON/OFF indicator1

Low engine oil pressure warning1

Malfunction/Check Engine indicator1

1 If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer.

4

Engine oil replacement reminder1

Low fuel level warning

Open door warning

Airbag SRS warning1

Master warning

Automatic Transmission fluid temperature warning1

Low Tire Pressure Warning1

Electric power steering system warning1

Low windshield washer fluid level warning1
