1996 Ford Taurus Owners Manual

File:01fcpit.ex Update:Mon Jan 22 15:39:52 1996

[PI00080( T)04/95]

thirty-six pica chart:

File:01fcpit.ex Update:Mon Jan 22 15:39:52 1996

*[PI00100(ALL)09/95]

thirty-six pica chart:

File:01fcpit.ex Update:Mon Jan 22 15:39:52 1996

*[PI00560(ALL)05/95]

Table of Contents

Introductory Information ............................. 1
Safety Restraints ............................................ 9
Starting Your Taurus .................................. 59
Warning Lights and Gauges ..................... 71
Instrument Panel Controls ........................ 91
Steering Column Controls ...................... 115
Features ........................................................ 125
Electronic Sound Systems ....................... 169
Driving Your Taurus ................................ 191
Roadside Emergencies .............................. 217
Customer Assistance ................................. 237
Reporting Safety Defects ......................... 244
Accessories .................................................. 249
Servicing Your Taurus ............................. 255
Quick Index ................................................ 341
Index ............................................................. 357
Service Station Information .................... 380

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

*[IN00300(ALL)04/95] *[IN00400(ALL)10/95]

*[IN00500(ALL)04/95] *[IN00600(ALL)04/95]

*[IN00700(ALL)04/95]

*[IN00750(ALL)04/95]

*[IN00800(ALL)04/95]

*[IN00900(ALL)04/95]

Introductory Information

Ford’s Commitment to You At Ford Motor Company, excellence is the continuous commitment to achieve the best result possible. It is dedication to learning what you want, determination to develop the right concept, and execution of that concept with care, precision, and attention to detail. In short, excellence means being the standard by which others are judged. Our Guiding Principles q Quality comes first. For your satisfaction, the quality of our products and services must be our number one priority.

q You are the focus of everything we do. Our

work must be done with you in mind, providing better products and services than our competition.

q Continuous improvement is essential to our

success. We must strive for excellence in everything we do: in our products — in their safety and value — and in our services, our human relations, our competitiveness, and our profitability.

q Employee involvement is our way of life. We are a team. We must treat one another with trust and respect.

q Dealers and suppliers are our partners. We

must maintain mutually beneficial relationships with dealers, suppliers, and our other business associates.

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

*[IN01000(ALL)04/95]

*[IN01100(ALL)08/95]

*[IN01200(ALL)08/95]

*[IN01300(ALL)08/95]

*[IN01400(ALL)07/95] *[IN01420(ALL)05/95]

*[IN01440(ALL)05/95]

*[IN01460(ALL)05/95]

Integrity is never compromised. Our conduct worldwide must be pursued in a manner that is socially responsible and commands respect for its integrity and for its positive contributions to society.

Things to Know About Using This Guide Congratulations on the purchase of your new vehicle. This guide has information about the equipment and the options for your new vehicle. You may not have bought all of the options available to you. If you do not know which information applies to your vehicle, talk to your dealer.

This guide describes equipment and gives specifications for equipment that was in effect when this guide was approved for printing. Ford may discontinue models or change specifications or design without any notice and without incurring obligation. NOTES and WARNINGS

NOTES give you additional information about the subject matter you are referencing.

WARNINGS remind you to be especially careful in those areas where carelessness can cause damage to your vehicle or personal injury to yourself, your passengers or other people. Please read all WARNINGS carefully.

RWARNING

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

*[IN01500(ALL)08/95] *[IN01600(ALL)04/95]

*[IN01700(ALL)08/95]

*[IN01900(ALL)08/95]

%*[IN02000(ALL)08/95] *[IN02100(ALL)08/95]

%*[IN02400(ALL)04/95]

*[IN02500(ALL)03/95]

Finding Information in This Guide

After you have read this guide once, you will probably return to it when you have a specific question or need additional information. To help you find specific information quickly, you can use the Quick Index or the Index.

The Quick Index at the end of the book provides a page number following each item which indicates where detailed information can be found.

To use the Index, turn to the back of the book and search in the alphabetical listing for the word that best describes the information you need. If the word you chose is not listed, think of other related words and look them up. We have designed the Index so that you can find information under a technical term. Canadian Owners — French Version

French Owner Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. Your Maintenance Schedule and Record Booklet The Maintenance Schedule and Record booklet lists the services that are most important for keeping your vehicle in good condition. A record log is also provided to help you keep track of all services performed.

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

%*[IN02600(ALL)01/95] *[IN02700(ALL)04/95]

%*[IN03100(ALL)03/95]

*[IN03300(ALL)03/95]

%*[IN04000(ALL)01/95] *[IN04100(ALL)01/94]

*[IN04200(ALL)01/95]

*[IN04250(ALL)01/95]

About the Warranties Your vehicle is covered by three types of warranties: Basic Vehicle Warranty, Extended Warranties on certain parts, and Emissions Warranties.

Read your Warranty Information Booklet carefully to find out about your vehicle’s warranties and your basic rights and responsibilities.

If you lose your Warranty Information Booklet, you can get a new one free of charge. Contact any Ford or Lincoln-Mercury dealer, or refer to the addresses and phone numbers on the first page of this owner guide. Buying a Ford Extended Service Plan

If you bought your vehicle in the U.S., you can buy a Ford Extended Service Plan for your vehicle. This optional contract provides service protection for a longer period of time than the basic warranty that comes with your vehicle.

You do not have to buy this option when you buy your vehicle. However, your option to purchase the Ford Extended Service Plan runs out after 18 months or 18,000 miles. See your dealer for more details about the Ford Extended Service Plan.

If you purchased a Canadian vehicle and did not take advantage of the Ford Extended Service Plan at the time of purchase, you may still be eligible. See your dealer for the details.

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

%*[IN06000(ALL)01/95] *[IN06100(ALL)03/95]

%*[IN06300(ALL)01/95]

*[IN06400(ALL)01/95] *[IN06500(ALL)01/95] *[IN06600(ALL)01/95] *[IN06700(ALL)01/95]

%*[IN06800(ALL)01/95]

[IN06810(ALL)04/95]

[IN06820(ALL)04/95]

[IN06830(ALL)04/95]

[IN06840(ALL)04/95]

[IN06850(ALL)04/95]

Breaking Your Vehicle In Your new vehicle goes through an adjustment or break-in period during the first 1,000 miles (1,600 km) that you drive it. During the break-in period, you need to pay careful attention to how you drive your vehicle. q Avoid sudden stops. Because your vehicle

has new brake linings, you should take these steps: — Watch traffic carefully so that you can

anticipate when to stop.

— Begin braking well in advance. — Apply the brakes gradually. The break-in period for new brake linings lasts for 100 miles (160 km) of city driving or 1,000 miles (1,600 km) of highway driving. q Use only the type of engine oil that Ford recommends. See Engine oil recommendations in the Index. Do not use special “break-in” oils.

Safety Labels There are labels, decals and tags on your vehicle to alert you about possible hazards. The signal word on the label tells you the degree of hazard and is used in the following ways: q DANGER: Used to indicate the presence of a

hazard which will cause severe personal injury or death if the warning is ignored.

q WARNING: Used to indicate the presence of

a hazard which can cause severe personal injury or death if the warning is ignored.

q CAUTION: Used to indicate the presence of a

hazard which will or can cause minor personal injury or property damage if the warning is ignored.

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

%*[IN06900(ALL)04/95]

*[IN07001(ALL)07/95]

*[IN07101(ALL)07/95]

*[IN07201(ALL)07/95]

%*[IN07301(ALL)04/95] [IN07401(ALL)03/95]

*[IN07501(ALL)06/95] *[IN07601(ALL)04/95] *[IN07701(ALL)04/95]

*[IN07801(ALL)04/95] *[IN07901(ALL)04/95]

Cleaning the Outside of Your Vehicle Pollen, bird droppings and tree sap can damage the paint, especially in hot weather. Wash your vehicle as often as necessary to keep it clean.

Take similar precautions if your vehicle is exposed to chemical industrial fallout.

Paint damage resulting from fallout is not related to a defect in paint materials or workmanship and therefore is not covered by warranty. Ford, however, believes that continual improvement in customer satisfaction is a high priority. For this reason, Ford has authorized its dealers to repair, at no charge to the owner, the surfaces of new vehicles damaged by environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes first. Customers may be required to bring their vehicle in for inspection by a Ford representative. Washing and Polishing Your Vehicle

Wash the outside of your vehicle, including the underside, with a cleaner made for washing cars. If your vehicle has clear-coat, make sure that the cleaner is recommended for clear-coat.

DO NOT: q Wash your vehicle with hot water q Wash your vehicle while it sits in direct

sunlight

q Wash your vehicle while the body is hot Polish your vehicle to remove harmful deposits and protect the finish.

File:02fcint.ex Update:Mon Jan 22 15:41:04 1996

%*[IN08101(ALL)04/95] *[IN08201(ALL)04/95]

%*[IN08301(ALL)04/95] *[IN08401(ALL)04/95]

*[IN08501(ALL)04/95]

%*[IN08701(ALL)04/95]

Cleaning Chrome and Aluminum Parts

Wash chrome and aluminum parts with a mild detergent. Do not use steel wool, abrasive cleaners, fuel or strong detergents. Cleaning Plastic Parts

Some of your vehicle’s exterior trim parts are plastic. Clean with a tar and road oil remover if necessary. Use a vinyl cleaner for routine cleaning.

Do not clean plastic parts with thinners, solvents or petroleum-based cleaners.

If you have your vehicle rustproofed, remove oversprayed rustproofing with a tar and road oil remover. If rustproofing is not removed from plastic and rubber parts, it can cause deterioration.

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR00500(ALL)04/95] *[SR00600(ALL)03/95]

*[SR00700(ALL)08/95] *[SR00800(ALL)08/95] *[SR00900(ALL)08/95] *[SR01000(ALL)08/95] *[SR01100(ALL)08/95] *[SR01200(ALL)08/95] *[SR02200(ALL)07/95]

*[SR02300(ALL)07/95]

Safety Restraints

Important Safety Belt Information The use of safety belts helps to restrain you and your passengers in case of a collision. In most states and in Canada the law requires their use.

Safety belts provide best restraint when:

the seatback is upright

the occupant is sitting upright (not slouched)

the lap belt is snug and low on the hips

the shoulder belt is snug against the chest

the knees are straight forward

To help you remember to fasten your safety belt, a warning light may come on and a chime may sound. See Safety Belt Warning Light and Chime in the Warning Lights and Gauges chapter.

See the following sections in this chapter for directions on how to properly use these safety belts. Also see Safety Restraints for Children in this chapter for special instructions about using safety belts for children.

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR02350(ALL)12/95]

%*[SR02400(ALL)05/95]

*[SR02700(ALL)06/95]

RWARNING

It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Be sure everyone in your vehicle is in a seat and using a safety belt properly.

RWARNING

Make sure that you and your passengers wear safety belts. Always drive and ride with your seatback upright and the lap belt snug and low across the hips.

RWARNING

Never wear the shoulder belt under the arm. Never swing it around the neck over the inside shoulder. Never use a single belt for more than one person or across more than one seating position. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. Failure to follow these precautions could increase the risk and/or severity of injury in a collision.

10

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR02850(ALL)05/95]

*[SR02900(ALL)08/95]

*[SR03000(ALL)08/95]

*[SR03200(ALL)09/95]

RWARNING

Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.

RWARNING

To reduce the risk of serious injury in a collision, children should always ride with the seatback upright.

RWARNING

Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.

RWARNING

Lock the doors of your vehicle before driving to lessen the risk of the door coming open in a collision.

11

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR03600(ALL)05/95]

*[SR03900(ALL)06/95]

*[SR04000(ALL)05/95]

*[SR04100(ALL)05/95]

*[SR04200(ALL)06/95]

quarter page art:0010018-B

*[SR04300(ALL)07/95]

Combination Lap and Shoulder Belts While your vehicle is in motion, the combination lap and shoulder belt adjusts to your movement. However, if you brake hard, turn hard, or if your vehicle receives an impact of 5 mph (8 km/h) or more, the lap/shoulder belt locks and helps reduce your forward movement.

After you get into your vehicle, close the door and lock it. Then adjust the seat to the position that suits you best.

Pull the combination lap/shoulder belt from the retractor so that the shoulder portion of the belt crosses your shoulder and chest. Be sure the belt is not twisted. If it is, remove the twist. Insert the belt tongue into the proper buckle until you hear a snap and feel it latch. Make sure the tongue is securely fastened to the buckle by pulling on tongue.

Fastening the front seat combination lap and shoulder belt

NOTE: Be sure to read and understand

Important Safety Belt Information at the beginning of this chapter.

12

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR04500(ALL)06/95]

one third page art:0000685-I

*[SR04700(ALL)07/95]

[SR05625(ALL)04/95]

*[SR05650(ALL)08/95]

*[SR05670(ALL)08/95]

*[SR05675(ALL)08/95] *[SR05700(ALL)10/95]

Unfastening the combination lap and shoulder belts — front and rear outboard seating positions

While the belt retracts, guide the tongue to its original position to prevent it from striking you or the vehicle. Safety Belts for Front Outboard Passenger and Rear Outboard Seating Positions (Except Wagon Rear-Facing Seat)

Your vehicle is equipped with a dual locking mode retractor on the shoulder belt portion of the combination lap/shoulder safety belt for the front seat outboard passenger and rear outboard passengers.

Dual locking mode retractors operate in two ways:

Vehicle sensitive (emergency) locking mode

In this operating mode, the shoulder belt retractor will allow the occupant freedom of movement, locking tight only on hard braking, hard cornering or impacts of approximately 5 mph (8 km/h) or more. The retractor can also be made to lock by pulling the belt out quickly.

13

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR05725(ALL)08/95] *[SR05750(ALL)08/95]

*[SR05775(ALL)08/95] *[SR05800(ALL)08/95] *[SR05810(ALL)08/95]

*[SR05825(ALL)09/95]

*[SR05830(ALL)08/95]

*[SR05875(ALL)08/95] *[SR05900(ALL)09/95]

*[SR05925(ALL)08/95]

Automatic locking mode

In this operating mode, the shoulder belt retractor will be automatically locked and will remain locked when the combination lap/shoulder safety belt is buckled, and does not allow the occupant freedom of movement. This mode provides the following: q A tight lap/shoulder belt on the occupant. q Child safety seat installation.

RWARNING

Rear-facing infant seats should never be placed in the front seats.

This mode must be used when installing a child safety seat on the front passenger seat and rear outboard seats where dual locking retractors are provided.

To switch the retractor from the emergency locking mode to the automatic locking mode, perform the following steps:

1. Buckle the lap/shoulder combination belt.

2. Grasp the shoulder portion of the belt and

pull downward until all of the belt is extracted and, when allowed to retract, a clicking sound is heard. At this time, the belt retractor is in the automatic locking mode (child restraint mode).

3. A clicking sound will continue to be heard

as the belt is allowed to retract. This indicates that the retractor is in the automatic locking mode.

14

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR05930(ALL)08/95]

%*[SR05940(ALL)08/95] *[SR05950(ALL)08/95] *[SR05960(ALL)06/95]

[SR05962(ALL)06/95]

*[SR05964(ALL)06/95]

[SR05966(ALL)06/95]

one third page art:0001402-B

NOTE: When the combination lap/shoulder

belt is unbuckled and allowed to retract completely, the retractor will switch to the vehicle sensitive (emergency) locking mode. See the detailed instructions under Safety Seats for Children in this chapter. Shoulder Belt Height Adjustment

Driver and right front passenger

You can adjust the shoulder belt height to one of five (5) positions.

To adjust the belt down, pinch the release button. To adjust the belt up, slide the adjuster up. (You do not have to pinch the release button.)

Make sure the adjuster is firmly in one of the five positions. The belt should be adjusted up or down until the belt rests on your shoulder near your neck.

The shoulder belt height adjuster

15

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR05968(ALL)06/95]

[SR06000(ALL)04/95]

[SR06050(ALL)05/95]

[SR06060(ALL)10/95]

[SR06075(ALL)10/95]

[SR06125(ALL)10/95]

RWARNING

Position the shoulder belt height adjuster so that the belt rests across the middle of your shoulder. Be sure the shoulder belt is properly positioned on your shoulder each time you use the belt. If the shoulder belt is off your shoulder, on your upper arm or neck, there is a greater risk of severe injury in a collision.

Safety Belts for Rear-Facing Occupants (Wagon)

RWARNING

Never use child safety seats in the third seat of a wagon.

Your vehicle is equipped with safety seat belts containing an adjust tongue at the rear-facing seating positions.

When the adjust tongue of the lap/shoulder combination seat belt is latched into the buckle, the tongue will allow the lap portion to become shorter, but locks the webbing in place to restrict it from becoming longer.

Before you can reach and latch a combination lap and shoulder belt having an adjust tongue into the buckle, you may have to lengthen the lap belt portion of it. To lengthen the lap belt, pull some webbing out of the shoulder belt retractor. While holding the webbing below the tongue, grasp the tongue so that it is parallel to the webbing and slide the tongue upward. Provide enough lap belt length so that the tongue can reach the buckle.

16

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR06175(ALL)10/95]

*[SR06201(ALL)07/95]

*[SR06225(ALL)03/95]

*[SR06251(ALL)05/95]

*[SR06275(ALL)03/95]

To fasten the belt, pull the combination lap and shoulder belt from the retractor so that the shoulder belt portion of the safety belt crosses your shoulder and chest. Be sure the belt is not twisted. If the belt is twisted remove the twist. Insert the belt tongue into the proper buckle for your seating position until you hear a snap and feel it latch. Make sure the tongue is securely fastened to the buckle by pulling on the tongue.

RWARNING

The lap belts should fit snugly and as low as possible around the hips, not around the waist.

RWARNING

All front and rear seat outboard occupants (including pregnant women) should wear lap and shoulder belts, for optimum protection in a collision.

RWARNING

Failure to follow these precautions could increase the risk and/or severity of injury in a collision. 1) Use the shoulder belt on the outside shoulder only. Never wear the shoulder belt under the arm. 2) Never swing it around your neck over the inside shoulder. 3) Never use a single belt for more than one person.

Due to folding rear seats, sometimes the buckles and tongues toward the center of the vehicle may be hidden by the rear edge of the seat cushion. Pull them out so they will be accessible.

17

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR06301(ALL)10/95]

[SR06500(ALL)03/95]

[SR06550(ALL)02/95]

one third page art:0000029-F

While you are fastened in the seat belt, the shoulder belt adjusts to your movement. However, if you brake hard, turn hard, or if your vehicle receives an impact of 5 mph (8 km/h) or more, the safety belt will become locked and help reduce your forward movement.

To unfasten the belt, push the red release button on the end of the buckle. This allows the tongue to unlatch from the buckle. While the belt retracts, guide the tongue to its original position to prevent it from striking you or the vehicle.

Unfastening the combination lap and shoulder belts for the rear-facing third seat (wagon)

18

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR06560(ALL)04/95]

[SR06565(ALL)04/95]

[SR06570(ALL)04/95]

[SR06575(ALL)04/95]

half page art:0001371-B

Center Occupant Rear Safety Belt (Sedan)

The safety belt in the center rear seating position has a detachable shoulder belt.

To attach the shoulder belt to the lap belt, pull the shoulder belt out from the retractor in the seatback and insert the lap belt connecting pin into the wide end of the key-slot on the shoulder belt as shown in Figure 1. Pull the connecting pin into the narrow end of the key-slot until you hear a snap and feel it latch. See Figure 2. Make sure the shoulder belt is securely fastened to the lap belt by pulling up on the shoulder belt.

The reverse side of the lap belt and the detachable shoulder belt

19

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR06580(ALL)05/95]

half page art:0001372-A

[SR06585(ALL)12/95]

[SR06590(ALL)04/95]

The reverse side of the shoulder belt attached to the lap belt

RWARNING

The rear center lap belt must be tightened separately from the shoulder strap. The lap belt must fit snugly, and as low as possible around the hips. Do not wear around your waist. For information about adjusting the belt, see “LAP BELTS” in this chapter.

Detach the shoulder belt before folding down the passenger side rear seat. To detach the shoulder belt, slide the connecting pin to the wide end of the key-slot and lift the shoulder belt off the connecting pin. As the shoulder belt retracts, guide the belt so that it does not strike you or the vehicle.

20

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR06601(ALL)05/95] [SR06650(ALL)10/95]

[SR06675(ALL)04/95]

*[SR06700(ALL)06/95]

%*[SR06750(ALL)06/95]

*[SR06800(ALL)06/95]

[SR06850(ALL)08/95]

one third page art:0000029-F

Lap Belts The lap belts in the center front seating position (if equipped) and center rear seat do not adjust automatically. You must adjust them to fit snugly and as low as possible around your hips. Do not wear the lap belt around your waist.

The front center seat belt buckle and tongue are stowed in a pocket between the seat cushion and seatback. Remove them from the stowage pocket before fastening.

Pull the belt across your hips and insert the tongue into the correct buckle on your seat until you hear a snap and feel it lock. Make sure the buckle is securely fastened.

If you need to lengthen the belt, unfasten it and tip the belt tongue at a right angle to the belt. Pull the belt tongue over your lap until it reaches the buckle.

If you need to shorten the belt, pull on the loose end of the webbing until the belt fits snugly.

Unfastening the lap belts for the center front and center rear seating positions

21

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR06900(ALL)08/95]

*[SR06925(ALL)07/95]

%*[SR07750(ALL)08/95] *[SR07800(ALL)07/95]

[SR07850(ALL)02/95]

[SR07900(ALL)05/95]

*[SR07924(ALL)08/95]

*[SR07925(ALL)08/95]

To unfasten the belt, push the release button on the end of the buckle. This allows the tongue to unlatch from the buckle.

RWARNING

The lap belts should fit snugly and as low as possible around the hips, not around the waist.

Safety Belt Extension Assembly

For some people, the safety belt may be too short even when it is fully extended. You can add about eight inches (20 cm) to the belt length with a safety belt extension assembly (part number 611C22). Safety belt extensions are available at no cost from your dealer.

This assembly is not for use in the wagon rear-facing seat.

RWARNING

The use of the safety belt extension in the wagon rear-facing seat will increase the risk of personal injury.

Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended. Do not use extension to change the fit of the shoulder belt across the torso.

RWARNING

Failure to follow these instructions will affect the performance of the safety belts and increase the risk of personal injury.

22

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR07950(ALL)08/95] *[SR07970(ALL)09/95]

%*[SR07980(ALL)10/95]

%*[SR08400(ALL)06/95] *[SR08500(ALL)06/95]

%*[SR14300(ALL)06/95]

*[SR14650(ALL)05/95]

Safety Belt Maintenance Check the safety belt systems periodically to make sure that they work properly and are not damaged.

All safety belt assemblies, including retractors, buckles, front seat belt buckle support assemblies (slide bar) (if equipped), child safety seat tether bracket assemblies (if equipped), and attaching hardware, should be inspected after any collision. Ford recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and a qualified technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted. Cleaning the Safety Belts

Clean the safety belts with any mild soap solution that is recommended for cleaning upholstery or carpets. Do not bleach or dye the belt webbing because this may weaken it. Air Bag Supplemental Restraint System (SRS) The driver and right front passenger air bags are Supplemental Restraint Systems (SRS), provided at these seating positions in addition to the lap/shoulder belt, and are designed to supplement the protection provided to properly belted occupants in moderate to severe frontal collisions. The supplemental air bag system does not provide restraint to the lower body.

23

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR14800(ALL)05/95] *[SR14900(ALL)06/95]

*[SR14950(ALL)05/95]

*[SR15000(ALL)01/95]

*[SR15100(ALL)01/95] *[SR15200(ALL)01/95]

*[SR15300(ALL)01/95]

*[SR15400(ALL)01/95] %*[SR15500(ALL)01/95] *[SR15600(ALL)05/95]

The Importance of Wearing Safety Belts

RWARNING

Safety belts must be worn by all vehicle occupants to be properly restrained and help reduce the risk of injury in a collision.

RWARNING

All occupants of the vehicle, including the driver, should always wear their safety belts, even when an air bag Supplemental Restraint System is provided.

There are four very important reasons to use safety belts even with an air bag system. Use your safety belts to:

help keep you in the proper position (away from the air bag) when it inflates reduce the risk of harm in rollover, side or rear impact collisions, because an air bag is not designed to inflate in such situations reduce the risk of harm in frontal collisions that are not severe enough to activate the supplemental air bag reduce the risk of being thrown from your vehicle

The Importance of Being Properly Seated In a collision, the air bag must inflate extremely fast to help provide additional protection for you. In order to do this, the air bag must inflate with considerable force. If you are not seated in a normal riding position with your back against the seatback, the air bag may not protect you properly and could possibly hurt you as it inflates.

24

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR16000(ALL)08/95]

*[SR16050(ALL)07/95]

*[SR16100(ALL)09/95]

*[SR16200(ALL)07/95]

RWARNING

If a passenger is not properly seated and restrained, an inflating air bag could cause serious injury.

Your vehicle is equipped with a right front passenger air bag. Air bags deploy with great force, faster than the blink of an eye. Front passengers, especially children and small adults, must never sit on the front edge of the seat, stand near the glove compartment of the instrument panel, or lean over near the air bag cover when the vehicle is moving. All occupants should sit with their backs against the seatback, move the seat to the most rearward position if possible and use the safety belts. Children weighing less than 40 lbs. (18 kg) always should use child or infant seats.

RWARNING

Rear-facing infant seats should never be placed in the front seat.

In rear-facing infant seats, the infant’s head is closer to the air bag. The force of the rapidly inflating air bag could push the top of the rear-facing seat against the vehicle seatback or center armrests (if so equipped), or center console (if so equipped). REAR-FACING INFANT CARRIERS MUST ALWAYS BE SECURED IN THE REAR SEAT, and other child safety seats and infant seats should be secured in the rear seat whenever possible.

25

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR16250(ALL)07/95]

*[SR16255(ALL)11/95]

*[SR16300(ALL)07/95]

*[SR16350(ALL)07/95]

*[SR16400(ALL)08/95]

RWARNING

When using forward-facing child seats move the passenger seat as far back from the instrument panel as possible. NEVER SECURE REAR-FACING INFANT SEATS IN THE FRONT SEAT.

The force of the rapidly inflating passenger air bag could push the top of the rear-facing seat against the vehicle seatback, armrests or console. Rear-facing infant seats must always be secured in the rear seat.

RWARNING

Do not place objects or mount equipment on or near the air bag cover on the steering wheel or in front seat areas that may come in contact with a deploying air bag. Failure to follow this instruction may increase the risk of personal injury in the event of a collision.

For further information about the proper mounting of equipment in the front seat of this vehicle, please refer to Ford’s brochure entitled Some Important Information About Air Bag Supplemental Restraint System which can be obtained by calling Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.

For additional important safety information on the proper use of seat belts, child seats, and infant seats, please read the other sections of this chapter of the Owner Guide, especially sections entitled Safety Belts for Children and Safety Seats for Children.

26

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR16500(ALL)01/95]

*[SR16600(ALL)06/95]

*[SR16750(ALL)06/95]

[SR16775(ALL)11/94]

half page art:0001373-A

How the Air Bag Supplemental Restraint System Operates

The Air Bag Supplemental Restraint System consists of the driver and passenger air bags, impact sensors, a system diagnostic module, a readiness light and tone, and the electrical wiring which connects the components.

The driver air bag is in the center of the steering wheel. The front passenger seat air bag is located in the center of the instrument panel ledge above the glove compartment. Both air bags are designed to stay out of sight until they are activated.

The location of air bags and warning labels

27

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR17400(ALL)07/95]

[SR17500(ALL)12/95]

*[SR17580(ALL)07/95]

If a collision occurs, the sensors sense the severity of the impact and activate the air bags if necessary. The air bag system is designed to deploy in frontal and front-angled collisions more severe than hitting a parked vehicle (of similar size and weight) head-on at about 28 mph (45 km/h). Because the system senses the crash severity rather than vehicle speed, some frontal collisions at speeds above 28 mph (45 km/h) will not inflate the air bag.

When the sensors activate the system, the air bags inflate rapidly, filling with non-toxic gas mixture in a fraction of a second. Immediately after inflation, the air bags deflate by releasing the gas mixture through vent holes. The whole process takes place in a matter of seconds.

RWARNING

Air bag system components get hot after inflation. Do not touch them after inflation.

28

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR17710(ALL)08/95]

half page art:0011063-A

[SR17730(ALL)09/95]

Inflated driver-side air bag

half page art:0011064-A

Inflated passenger-side air bag

29

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR18400(ALL)07/95]

*[SR18425(ALL)07/95]

%*[SR18450(ALL)05/95]

%*[SR18475(ALL)06/95]

*[SR18501(ALL)06/95] *[SR18525(ALL)06/95]

*[SR18550(ALL)06/95]

*[SR18575(ALL)08/95]

RWARNING

If the air bag is inflated, THE AIR BAG WILL NOT FUNCTION AGAIN AND MUST BE REPLACED IMMEDIATELY. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.

To ensure that the air bag system will operate as intended in a crash, the system is equipped with a diagnostic module, which controls a readiness lamp and a warning tone. The diagnostic module monitors its own circuits, the air bag electrical system, the air bag readiness light, the air bag power, and the air bag inflators. The air bag system uses a readiness light on the instrument cluster and a tone to indicate the condition of the system. When you turn the ignition key to the ON position, this light will illuminate for approximately six (6) seconds and then turn off. This indicates that the system is operating normally. NOTE: Maintenance of the air bag system is not required. A problem with the system is indicated by one or more of the following:

the readiness light will either flash or stay lit, or it will not light immediately after ignition is turned on, or a group of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired.

If any of these things happen, have the air bag system serviced at your Ford or Lincoln-Mercury dealer immediately. Unless serviced, the air bag Supplemental Restraint System may not function properly in the event of a collision.

30

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR18601(ALL)07/95]

%*[SR19000(ALL)05/95]

*[SR19500(ALL)06/95]

%*[SR20200(ALL)05/95] *[SR20300(ALL)02/95]

*[SR20400(ALL)08/95]

*[SR20500(ALL)07/95]

RWARNING

Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer.

Disposal of air bags or air bag equipped vehicles

For disposal of air bags or air bag equipped vehicles, see your local Ford or Lincoln-Mercury dealer. Air bags MUST be disposed of by qualified personnel. Safety Restraints for Children In the U.S. and Canada, you are required by law to use safety restraints for children. If small children ride in your vehicle — this generally includes children who are four years old or younger and who weigh 40 pounds (18 kg) or less — you must put them in safety seats that are made specially for children. Safety belts alone do not provide maximum protection for these children. Check your local and state laws for specific requirements.

RWARNING

Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.

RWARNING

To prevent the risk of injury, make sure children sit where they can be properly restrained.

31

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR20600(ALL)10/95]

*[SR20650(ALL)06/95]

*[SR20700(ALL)08/95]

*[SR20900(ALL)08/95]

*[SR21000(ALL)08/95]

RWARNING

Passengers should not be allowed to ride in the cargo area. Persons not riding in a seat with a fastened seat belt are much more likely to suffer serious injury in a collision. Cargo should always be secured to prevent it from shifting and causing damage to the vehicle or harm to passengers.

When possible, put children in the rear seat of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating positions.

RWARNING

Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.

RWARNING

Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them.

RWARNING

Never leave a child unattended in your vehicle.

32

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

%*[SR22000(ALL)01/95] *[SR22100(ALL)05/95]

*[SR22125(ALL)08/95]

*[SR22150(ALL)08/95]

*[SR22375(ALL)07/95]

%*[SR22400(ALL)07/95]

Safety Seats for Children Use a safety seat that is recommended for the size and weight of the child. Always follow the safety seat manufacturer’s instructions when installing and using the safety seat.

Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps see Attaching Safety Seats With Tether Straps in this chapter.

When installing a child safety seat, be sure to use the correct safety belt buckle for that seating position, and make sure the tongue is securely fastened in the buckle. For a shoulder/lap belt combination with a sliding tongue, make sure the retractor is in the automatic locking mode.

Your vehicle is equipped with a right front passenger air bag. Air bags deploy with great force, faster than the blink of an eye. Front passengers, especially children and small adults, must never sit on the front edge of the seat, stand near the glove compartment of the instrument panel, or lean over near the air bag cover when the vehicle is moving. All occupants should sit with their backs against the seatback, move the seat to the most rearward position if possible and use the safety belts. Children weighing less than 40 lbs. (18 kg) always should use child or infant seats.

RWARNING

When using forward-facing child seats move the passenger seat as far back from the instrument panel as possible. NEVER SECURE REAR-FACING INFANT SEATS IN THE FRONT SEAT.

33

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR22420(ALL)11/95]

*[SR22450(ALL)07/95]

*[SR22500(ALL)06/95]

*[SR22600(ALL)08/95]

[SR22700(ALL)05/95]

*[SR22720(ALL)07/95]

The force of the rapidly inflating passenger air bag could push the top of the rear-facing seat against the vehicle seatback, armrests or console. Rear-facing infant seats must always be secured in the rear seat.

All child restraint systems are designed to be secured in vehicle seats by lap belts or by the lap portion of a lap-shoulder belt.

RWARNING

If you do not properly secure the safety seat, the child occupying the seat may be injured during a collision or sudden stop. An unsecured safety seat could also injure other passengers.

RWARNING

Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.

RWARNING

Never use child safety seats in the third seat of a wagon.

RWARNING

Always keep the buckle release button pointing upward and away from the child seat, with the tongue between the child seat and the release button as shown in the following illustration.

34

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR22740(ALL)11/94]

half page art:0011286-A

%*[SR22750(ALL)11/94]

*[SR22800(ALL)06/95]

*[SR22850(ALL)09/95]

Safety belt buckle placement for child seats Installing Child Safety Seats in the Front Passenger Seat and Outer Rear Seating Positions

Your vehicle is equipped with a dual locking mode retractor on the shoulder belt portion of the combination lap/shoulder safety belt for the front passenger seat and rear outer seats. The automatic locking mode must be used when installing a child seat or infant carrier in the front passenger seat or rear outer seats.

RWARNING

Never install a rear-facing child seat or infant carrier in the right front passenger seat.

35

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR22901(ALL)03/95]

*[SR22950(ALL)12/94]

*[SR23001(ALL)09/95]

*[SR23050(ALL)09/95]

half page art:0011238-B

If you choose to install a child safety seat in the front seating position, move vehicle seat as far back as possible.

1. Position the child seat on the passenger seat

of the vehicle.

2. Pull down on shoulder belt, then grasp shoulder belt and lap belt together. See Figure 1.

Pulling out belt webbing

36

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR23100(ALL)08/95]

*[SR23150(ALL)06/95]

half page art:0011239-B

3. While holding the shoulder and lap belt

portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. See Figure 2. Be sure that the belt webbing is not twisted.

Routing the lap/shoulder belt

37

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR23200(ALL)06/95]

half page art:0011240-B

Buckling the belt

38

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR23250(ALL)08/95]

*[SR23301(ALL)06/95]

half page art:0011241-A

*[SR23350(ALL)07/95]

4. Grasp the shoulder portion of the belt and

pull downward until all of the belt is extracted and a click is heard. At this time, the retractor is in the automatic locking mode (child seat restraint mode). See Figure 4.

Setting the retractor to automatic locking mode

5. Allow the belt to retract. Pull up on the

shoulder webbing. A clicking sound will be heard as the belt retracts. This indicates the retractor is in the automatic locking mode. Push down on the child seat while you pull up on the belt to remove any slack in the belt. Figures 5 and 6.

39

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR23401(ALL)09/95]

half page art:0011242-A

*[SR23450(ALL)09/95]

Allowing shoulder belt to retract

half page art:0011243-A

Removing slack from belt

40

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR23501(ALL)07/95]

*[SR23550(ALL)06/95]

half page art:0011244-A

6. Before placing the child in the child seat, forcibly tilt the seat from side to side, and tug it forward to make sure that the seat is securely held in place, Figure 7.

Checking that the seat is secure

41

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR23601(ALL)11/94]

*[SR23650(ALL)06/95]

half page art:0011245-B

*[SR23701(ALL)05/95]

*[SR23750(ALL)05/95]

7. Double check that the retractor is in the

automatic locking mode. Try to pull more belt out of the retractor. If you cannot, the belt is in the automatic locking mode, Figure 8.

Checking the retractor

8. Check to make sure that the child seat is properly secured prior to each use. If the retractor is not locked, repeat steps 4
through 7.

NOTE: To remove the retractor from automatic

lock mode, allow seat belt to retract fully to its stowed position and the retractor will automatically switch back to the vehicle sensitive locking mode for normal adult usage.

42

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR24750(ALL)08/95]

%*[SR24800(ALL)06/95] *[SR24950(ALL)06/95]

*[SR25050(ALL)08/95] *[SR25150(ALL)08/95]

*[SR25250(ALL)08/95]

*[SR25350(ALL)07/95]

*[SR25375(ALL)08/95]

*[SR25425(ALL)08/95]

*[SR25525(ALL)08/95]

RWARNING

Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.

Attaching Safety Seats With Tether Straps

Some manufacturers make safety seats that include a tether strap that goes over the back of the vehicle seat and attaches to an anchoring point. Other manufacturers offer the tether strap as an accessory. Contact the manufacturer of your child safety seat for information about ordering a tether strap.

Front Seats

To install a tether from a child safety seat in the front seat:

1. Buckle the lap/shoulder belt (in the seat

directly behind the front passenger seat in which the child safety seat will be installed).

2. Pull all the stored belt out of the rear seat

retractor to switch the retractor to automatic locking mode.

3. Let the retractor wind up the slack from the

lap/shoulder belt.

4.

Install the child safety seat in the front seat. Refer to the previous section on Installing Safety Seats. Hook the tether strap hook around the webbing near the center of the shoulder portion of the locked lap/shoulder belt.

5. Tighten the tether strap.

43

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR25550(ALL)07/95] *[SR25600(ALL)07/95]

*[SR25725(ALL)06/95] [SR25800(ALL)06/95]

*[SR26100(ALL)06/95]

*[SR26500(ALL)06/95]

[SR26600(ALL)04/95]

*[SR26615(ALL)06/95] [SR26630(ALL)04/95]

Rear Seats

If you use a tethered safety seat on one of the rear seats, you can anchor the strap to the appropriate tether anchor directly behind that seat position. Tether anchorage hardware

Attachment holes (at each rear outboard seating position) have been provided in your vehicle to attach anchor hardware, if required. Kits can be obtained at no charge from any Ford or Lincoln-Mercury dealer.

Be sure to follow the child safety seat manufacturer’s instructions.

RWARNING

Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be injured in a sudden stop or collision.

In a station wagon, you simply attach the tether strap to one of the anchors that are already installed for you. Tether anchorage hardware

All wagons have a tether anchor installed for each of the second row seating positions.

44

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR26700(ALL)04/95]

two third page art:0000041-C

[SR26750(ALL)04/95]

*[SR26801(ALL)04/95]

[SR26850(ALL)04/95]

Finding the tether anchors in the wagon

1. Behind the second seat, find the plastic

snap-on covers for the floor anchors.

2. Use a screwdriver or coin to snap the covers

off the anchor in a rearward and upward direction. Remove the covers completely.

3. Snap the tether strap hook onto the

U-shaped tether anchor.

45

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR26900(ALL)04/95]

[SR26950(ALL)04/95]

*[SR27000(ALL)08/95]

*[SR27051(ALL)08/95]

*[SR27100(ALL)08/95] *[SR27150(ALL)08/95]

[SR27251(ALL)12/95]

Built-In Child Seat (Wagon — If equipped)

The second row seat may include an optional built-in child safety seat on the passenger side. The child restraint is to be used only by children who are at least one year old, weigh between 9
and 27 kilograms (20 and 60 pounds) and whose shoulders (top) are below the shoulder harness slots in the seatback.

If your child is less than one year old or weighs less than 9 kilograms (20 pounds), always use a rear facing infant or convertible seat because a child of that size is not sufficiently developed to withstand crash forces in a front facing position. Follow the specific manufacturer’s instructions for weight and height restrictions.

Children must be properly buckled before riding in the vehicle. It is the law in every state and province. This child seat conforms to all Federal/Canadian motor vehicle safety standards.

Built-in child seat belt retractors

The belts on the built-in child seat are equipped with a retractor that locks when both belt tongues are latched into the crotch safety belt buckle.

The retractor will automatically snug the belts around the child. Frequently check the child seat’s lap and shoulder harness belts for correct placement and tightness. Use the child seat only if the harness belts will stay snug with a child buckled in the seat. If belts do not remain snug, take the vehicle to the dealer for child seat repair.

46

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR27300(ALL)12/95]

*[SR27351(ALL)08/95]

*[SR27400(ALL)08/95]

*[SR27451(ALL)08/95]

*[SR27500(ALL)08/95] *[SR27551(ALL)05/95]

*[SR27600(ALL)08/95]

RWARNING

Always adjust the lap and shoulder harness belts provided with this child seat snugly around your child.

RWARNING

Never leave a child unattended in your vehicle.

RWARNING

Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them.

RWARNING

Failure to follow all of the instructions on the use of this child restraint system can result in your child striking the vehicle’s interior during a sudden stop or crash.

How to use the Built-In Child Seat

Read the following procedures and all of the labels on the Built-In Child Seat before using the seat.

RWARNING

Never use the Built-In Child Seat as a booster cushion with the adult safety belts. A child using the adult belts could slide forward and out from under the safety belts.

47

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR27605(ALL)12/95]

[SR27620(ALL)12/95]

[SR27630(ALL)12/95]

one third page art:0001500-A

[SR27651(ALL)12/95]

[SR27770(ALL)12/95]

one third page art:0001452-B

1. Pull and release flap from top of seatback.

See Figure 1.

NOTE: The child seat cannot be opened unless

the seatback is latched in the upright position.

Figure 1: Releasing the flap

2. Grasp the child seat at the top of the

seatback and pull the top forward to release the latch. See Figure 2.

Figure 2: Releasing the latch

48

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR27780(ALL)12/95]

[SR27801(ALL)12/95]

one third page art:0001453-B

[SR27850(ALL)12/95]

[SR27900(ALL)12/95]

one third page art:0001454-B

3. Continue to unfold the child seat until it

rests on the seat as shown in Figure 3.

Figure 3: Opening the built-in child seat

4. Read the information and warnings on the child seat cushion and shoulder safety belt. Refer to Figure 4. Check the child’s size, weight and age to be sure the child is not too small or too large for the child seat.

Figure 4: Child seat information and warnings

49

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR28000(ALL)12/95]

[SR28100(ALL)12/95]

[SR28125(ALL)12/95]

one third page art:0001456-B

[SR28150(ALL)12/95]

5.

If connected, squeeze the top and the bottom of the right half of the chest clip and pull to separate both halves.

6. Place the child on the child seat and position the shoulder belts over each shoulder. Refer to Figure 5.

Figure 5: Shoulder safety belt placement on the child

NOTE: Read the following steps carefully to

become familiar with the indicator windows located on each safety belt tongue and the chest clip. When either of the tongues or the chest clip is unbuckled, the color red appears in the window. When the tongues or chest clip are securely buckled, the color green appears.

50

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR28200(ALL)12/95]

[SR28220(ALL)12/95]

[SR28240(ALL)12/95]

*[SR28250(ALL)08/95]

7.

Insert either the left or right safety belt tongue into the single opening of the crotch safety belt buckle as shown in Figure 6. (It does not matter which tongue is inserted first.) Then insert the other tongue. Allow belts to retract and fit snugly.

NOTE: The indicator window on each tongue

must appear green when buckled.

NOTE: If a belt locks during extraction, allow

belts to retract FULLY and repeat procedure.

RWARNING

If both tongues do not latch in the buckle, do not use the child seat. See your dealer for repairs.

51

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR28300(ALL)12/95]

three fourths page art:0

Figure 6: Fastening the crotch safety belt buckle

52

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR28450(ALL)12/95]

8. Fasten both halves of the chest clip below

the child’s shoulders and adjust it to comfortably hold the shoulder belts in place on the child’s chest. The color green must appear in the indicator window when fastened. (The purpose of this clip is to position the shoulder belts correctly on the child’s shoulders. The clip can be easily pulled apart and is designed to pull apart during a collision. The clip helps keep the belts on the shoulders of a sleeping or squirming child.) Refer to Figure 7.

53

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR28500(ALL)12/95]

three fourths page art:0

Figure 7: Securing the chest clip

54

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

[SR28550(ALL)12/95]

[SR28575(ALL)12/95]

half page art:0001455-B

[SR28600(ALL)12/95]

*[SR28650(ALL)08/95]

[SR28700(ALL)12/95]

*[SR28750(ALL)08/95]

[SR28800(ALL)12/95]

9. Pull the shoulder belts out to ensure that the crotch safety belt buckle is securely fastened and the retractor is locked. Refer to Figure 8.

Figure 8: Checking for securely latched buckle and locked retractor

10. If the belts become too tight, unbuckle the

crotch safety belt buckle, allow belts to retract, then reinsert both belt tongues.

To remove the child from the built-in child seat:

1. Squeeze the tabs on the top and bottom of the chest clip and pull the halves apart to open the chest clip. Refer back to Figure 7.

2. Press the release button on the crotch safety

belt buckle.

3. Slide the shoulder belts off the child’s

shoulders and remove the child. Refer back to Figure 5.

55

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR28850(ALL)08/95] [SR28900(ALL)08/95]

[SR28950(ALL)08/95]

[SR28960(ALL)12/95]

[SR29000(ALL)03/95]

[SR29025(ALL)09/95]

*[SR29050(ALL)08/95] [SR29100(ALL)08/95]

To stow the built-in child seat: 1. Return the child seat cushion to the upright

position.

2. Press firmly in the center and top of the

child seat to place it in the stowed position. 3. Reattach the flap on the child seat to the top

of the seatback.

The seat can now be used by an adult or the seatback can be folded down. NOTE: The seatback cannot be folded down unless the child seat is fully stowed.

Inspection after a collision

RWARNING

All built-in child restraints, including seats, buckles, retractors, seat latches, interlocks, and attaching hardware should be inspected by a qualified Dealer technician after any collision. If the child seat was in use during a collision, Ford recommends replacing it. However, if the collision was minor and a qualified technician finds that the child restraints do not show damage and continue to operate properly, they do not need to be replaced. Built-in child seats not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.

56

File:03fcsrt.ex Update:Mon Jan 22 15:46:18 1996

*[SR29150(ALL)08/95] *[SR29200(ALL)08/95]

%*[SR29250(ALL)08/95] [SR29300(ALL)08/95]

%*[SR29500(ALL)07/95] *[SR29600(ALL)07/95]

*[SR29700(ALL)07/95]

*[SR29800(ALL)12/95]

Built-in child seat maintenance Regularly inspect the lap and shoulder belts system of your child seat. See your Ford dealer if the shoulder belt webbing is frayed, or if the buckle and tongue are damaged and/or do not function properly. Cleaning Your built-in child seat may be cleaned with mild soap and water. Do not use household cleaners as they may weaken the webbing or damage the plastic parts. For your convenience, the liner is removable and can be machine-washed and air-dried. Safety Belts for Children Children who are too large for child safety seats should always wear safety belts. (See instructions with your child seat, or contact its manufacturer, to determine maximum size of child that will safely fit in the seat.)

RWARNING

If safety belts are not properly worn and adjusted as described, the risk of serious injury to the child in a collision will be much greater.

If the shoulder belt portion of one of the lap and shoulder belts can be positioned so that it does not cross or rest in front of the child’s face or neck, the child should wear the lap and shoulder belt. Moving the child closer to the center of the vehicle may help provide a good shoulder belt
