2004 Ford Taurus Owners Manual

Table of Contents

Introduction

Instrument Cluster

Warning and control lights Gauges

Entertainment Systems

AM/FM stereo AM/FM stereo cassette AM/FM stereo with CD CD changer

Climate Controls

Manual heating and air conditioning Electronic automatic temperature control Rear window defroster

Lights

Headlamps Turn signal control Bulb replacement Driver Controls

Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Message center

10

10
13
15

15
16
19
21
24

24
26
28
30

30
33
35
46

46
47
49
49
51
58

Table of Contents

Locks and Security

Keys Locks Anti-theft system

Seating and Safety Restraints

Seating Safety restraints Air bags Child restraints

Driving

Starting Brakes Traction control Transmission operation Vehicle loading Trailer towing Recreational towing

Roadside Emergencies

Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing

Customer Assistance

Reporting safety defects (U.S. only)

73

73
73
83
87

87
91
107
115
128

128
132
134
136
140
143
146
148

148
149
149
151
157
162
168
170

178

Cleaning

Maintenance and Specifications

Engine compartment Engine oil Battery Fuel information Tire Information Part numbers Refill capacities Lubricant specifications

Accessories

Index

Table of Contents

179

185

187
190
194
201
217
229
230
232
240

242

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Copyright © 2003 Ford Motor Company

Introduction

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to

the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS Congratulations on acquiring your new Ford Motor Company product. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com • In Canada: www.ford.ca • In Mexico: www.ford.com.mx • In Australia: www.ford.com.au Additional owner information is given in separate publications. This vehicle’s Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on this vehicle’s Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the safety switch will automatically cut off the fuel supply to the

engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,600 km (1,000 miles) of new vehicle operation. Vary your speed to allow parts to adjust themselves to other parts. Drive your new vehicle at least 800 km (500 miles) before towing a trailer. Do not add friction modifier compounds or special break-in oils during the first few thousand kilometers (miles) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

SPECIAL NOTICES

Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle. Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: • how various systems in your vehicle were operating; • whether or not the driver and passenger seatbelts were buckled; • how far (if at all) the driver was depressing the accelerator and/or the • how fast the vehicle was traveling; and • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

brake pedal;

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.

MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner’s Guide for all other required information and warnings.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

See Owner’s Guide

Fasten Safety Belt

Air Bag-Front

Air Bag-Side

Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Child Seat Lower Anchor

Brake System

Brake Fluid - Non-Petroleum Based

Traction Control

AdvanceTrac娂

Master Lighting Switch

Hazard Warning Flasher

Fog Lamps-Front

Fuse Compartment

Fuel Pump Reset

Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Vehicle Symbol Glossary

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm

Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot

Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas

Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

MAX MIN

Emission System

Engine Air Filter

Passenger Compartment Air Filter

Jack

Check fuel cap

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Instrument Cluster

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately. Service engine soon: The Service engine soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon warning light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter.

10

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.

BRAKE

Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may

occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

ABS

Anti-lock brake system (if equipped): If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated. Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected. Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

Charging system: Illuminates when the battery is not charging properly.

11

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in the Maintenance and specifications chapter. Traction Control娂 active (if equipped): Flashes when the Traction Control娂 is active. If the light remains on a malfunction has been detected; have the system serviced immediately, refer to the Driving chapter for more information. Speed control (if equipped): Illuminates when the speed control is activated. Turns off when the speed control system is deactivated. Securilock娂 Anti-theft system: Flashes when the Securilock娂 Passive Anti-theft System has been activated. Refer to Securilock娂 Passive Anti-theft System in the Locks and Security chapter. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on.

CRUISE

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.

12

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

GAUGES

Instrument Cluster

Speedometer: Indicates the current vehicle speed.

Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is running or hot.

Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.

13

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The FUEL icon and arrow indicates which side of the vehicle the fuel filler door is located. Refer to Filling the tank in the Maintenance and Specifications chapter for more information. Odometer: Registers the total kilometers (miles) of the vehicle. Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English. Trip odometer: Registers the kilometers (miles) of individual journeys. Press and release the message center INFO button until “TRIP” appears in the display (this represents the trip mode). Press and hold the RESET button for three seconds to reset.

14

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

AM/FM STEREO (IF EQUIPPED)

Entertainment Systems

1. Clock: To set the hour, press and hold the H control. When the desired hour appears, release the control. To set the minute, press and hold the M control. When the desired minute appears, release the control.

BASS

TREB

BAL

FADE

15

2. Bass: Press decrease/increase the bass output.

to

3. Treble: Press decrease/increase the treble output.

to

4. Balance: Press sound to the left/right speakers.

to shift

5. Fade: Press sound to the rear/front speakers.

to shift

6. Scan: Press SCAN to hear a brief sampling of all listenable radio stations. Press again to stop.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

7. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 8. Tune: Press frequency down/up.

to change

9. Seek: Press and release for previous/next listenable station.

10. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

11. AM/FM: Press to choose a frequency band AM/FM1/FM2.

VOL PUSH ON

AM

FM

AM/FM STEREO CASSETTE/MACH姞 AUDIO SYSTEM WITH AM/FM STEREO CASSETTE (IF EQUIPPED)

1. Tape: Insert the cassette with the opening to the right. If a tape is already inserted into the system, press TAPE to begin tape play.

16

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

2. Clock: To set the hour, press and hold the H control. When the desired hour appears, release the control. To set the minute, press and hold the M control. When the desired minute appears, release the control.

3. CD: Press to play the CD (if equipped). Note: This system is CDDJ compatible, but CDDJ is an option with limited availability as defined in the order guide. 4. Bass: Press decrease/increase the bass output.

to

BASS

TREB

BAL

FADE

17

5. Treble: Press decrease/increase the treble output.

to

6. Balance: Press sound to the left/right speakers.

to shift

7. Fade: Press sound to the rear/front speakers.

to shift

8. Scan: Press SCAN to hear a brief sampling of all listenable radio stations, tape or CD selections. Press again to stop. 9. Shuffle: Press to play CD tracks in random order.

10. COMP (compression): While playing a CD, press to bring soft and loud passages together for a more consistent listening level.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Dolby威 noise reduction: 11. Reduces tape noise and hiss while playing a tape, press to activate/deactivate. 12. Side 1–2: Press to change tape direction.

13. FF (fast forward): Press to advance the tape or CD.

14. REW (rewind): Press to rewind the tape or reverse the CD.

15. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 16. Tune: Works in radio mode or to change CD mode. Press frequency down/up or previous/next disc. 17. Cassette door: Insert a cassette into the cassette door.

for previous/next

18. Seek: Press and release listenable radio station, tape selection or CD track. 19. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

20. AM/FM: Press to choose a frequency band in radio mode (AM/FM1/FM2).

18

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

VOL PUSH ON

AM

FM

Entertainment Systems

21. EJ (Eject): Press to eject a tape.

AUDIO SYSTEM WITH AM/FM STEREO/SINGLE CD PLAYER (IF EQUIPPED)

16

17

15

14

13

12

11

10

1. Clock: To set the hour, press and hold the H control. When the desired hour appears, release the control. To set the minute, press and hold the M control. When the desired minute appears, release the control.

2. Bass: Press decrease/increase the bass output.

to

3. Treble: Press decrease/increase the treble output.

to

4. Balance: Press sound to the left/right speakers.

to shift

BASS

TREB

BAL

19

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

FADE

Entertainment Systems

5. Fade: Press sound to the rear/front speakers.

to shift

6. Scan: Press to hear a brief sampling of all listenable radio stations or CD tracks. Press again to stop. 7. CD: Press to play a CD. Press again to toggle between single CD mode and CD Changer mode (if equipped). 8. Shuffle: Press to play CD tracks in random order.

9. COMP (compression): Press to bring soft and loud passages together for a more consistent listening level. 10. FF (fast forward): Press and hold until desired selection is reached. 11. REW (rewind): Press and hold until desired selection is reached.

12. Memory preset buttons: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 13. Tune: Press to change radio frequency down/up. With CD changer (if equipped), press to select the previous/next CD. 14. Seek: Press and release listenable radio station or previous/next CD track.

for previous/next

20

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

15. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

16. EJ (Eject): Press to eject a CD.

17. AM/FM: Press to choose a frequency band (AM/FM1/FM2).

VOL PUSH ON

AM

FM

CD CHANGER (IF EQUIPPED) Your CD changer is either located in the trunk, the console or the right side cargo area storage compartment. 1. Slide the door to access the CD changer magazine. 2. Press

to eject the magazine.

3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine.

Do not pull too hard on the disc holder as the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine while pressing on the lever.

21

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

5. Line up the CD with the groove of the disc holder. Ensure that the label on the CD faces downwards. 6. Press the disc holder until it locks securely into the magazine.

Ensure that the disc holder is evenly inserted and at the same level as the magazine (A). The unit will not operate if the disc holder is not inserted at the same level (B).

RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz

weaker the signal and the weaker the reception.

RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception. • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.

CASSETTE/PLAYER CARE Do: • Use only cassettes that are 90 minutes long or less.

22

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

and turning the hub.

Entertainment Systems • Tighten very loose tapes by inserting a finger or pencil into the hole • Remove loose labels before inserting tapes. • Allow tapes which have been subjected to extreme heat, humidity or • Clean the cassette player head with a cassette cleaning cartridge after

cold to reach a moderate temperature before playing.

10–12 hours of play to maintain good sound/operation.

Don’t: • Expose tapes to direct sunlight, extreme humidity, heat or cold. • Leave tapes in the cassette player for a long time when not being

played.

CD/CD PLAYER CARE Do: • Handle discs by their edges only. Never touch the playing surface. • Inspect discs before playing. Clean only with an approved CD cleaner

and wipe from the center out.

of time.

Don’t: • Expose discs to direct sunlight or heat sources for extended periods • Insert more than one disc into each slot of the CD changer magazine. • Clean using a circular motion. CD units are designed to play commercially pressed 12 cm (4.75
in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.

AUDIO SYSTEM WARRANTY AND SERVICE Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.

23

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

Climate Controls

MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Passenger airbag indicator light: Indicates whether the Passenger air bag is currently ON or OFF. Refer to Front passenger sensing system in the Seating and Safety Restraints chapter. 3. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Uses recirculated air through the instrument panel registers to cool the vehicle. This mode maximizes the airflow and as it is re-cooling the interior air, it is more economical and efficient. May reduce undesirable odors from entering the vehicle. A/C: Uses outside air to cool the vehicle. Air flows from the instrument panel register vents only.

: Distributes outside air through the instrument panel vents.

OFF: Outside air is shut out and the fan will not operate.

: Distributes outside air through the instrument panel and floor

vents.

: Distributes outside air through the floor vents. : Distributes outside air through the windshield defroster vents and

floor vents.

: Distributes outside air through the windshield defroster vents.

4. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 5. Rear defrost control: Press to defrost the rear window.

24

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

position.

the air flow selector in the

air flow selector in the OFF or MAX A/C position.

OPERATING TIPS • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of

airflow to the back seats.

the windshield.

To aid in side window defogging/demisting in cold weather: 1. Select 2. Adjust the temperature control to maintain comfort. 3. Set the fan speed to the highest setting. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

25

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM (IF EQUIPPED)

11

12

13

14

OFF

A/C

10

AUTO

TEMP

PASS

AIRBAG

OFF

1. OFF: Outside air is shut out and the fan will not operate.

2. A/C: Press to turn on and manually control the air conditioning in all (Defrost). Press again to disengage. Press AUTO for modes except the system to automatically control the temperature. 3. Passenger airbag off: Indicates whether the passenger airbag is ON or OFF. Refer to Front passenger sensing system in the Seating and safety restraints chapter. Recirculation control: Used to manually enable or disable 4. recirculated air operation. When activated, recirculates air in the cabin thereby reducing the amount of time to cool down the interior of the vehicle. May also help reduce undesired odors from reaching the interior of the vehicle. Will work in all modes except Defrost. Recirculation turns off automatically when Floor, Floor/Defrost or Defrost is selected to reduce the humidity inside the vehicle. 5. Temperature control: Press this control to select the temperature. The display window indicates the selected temperature.

26

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

6. Auto: To engage automatic temperature control, press AUTO to select the desired temperature using the temperature control. The system will automatically determine fan speed, airflow location, outside or recirculated air to heat or cool the vehicle to reach the desired temperature. 7. Fan Speed: Press to manually increase/decrease fan speed. In manual mode, the display will show with a bar graph to indicate fan speed. When in AUTO mode, the system will automatically control fan speed to achieve the desired temperature. 8. Manual override controls: Allows you to manually determine where airflow is directed. To return to full automatic control, press AUTO. 9. F : Distributes outside air through the windshield defroster ducts. Can be used to clear ice or fog from the windshield. Outside air and A/C will be automatically engaged to assist in clearing the windshield. 10. Rear defrost control: Press to defrost the rear window.

: Distributes air through the instrument panel and center console

: Distributes air through the windshield defroster ducts and floor

: Distributes air through the floor and rear seat floor ducts (if

11. ducts. The system will automatically provide outside air to reduce window fogging. 12. equipped). 13. registers (if equipped), the front and rear seat floor ducts. 14. registers (if equipped). Fahrenheit/Celsius temperature: Press A/C and F same time, to toggle between Fahrenheit and Celsius temperature. The set point temperatures in Celsius will be displayed in one degree increments.

: Distributes air through the instrument panel and center console

controls at the

27

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

OPERATING TIPS • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the

the air flow selector in the

position.

control in the OFF mode or in recirculation mode without the A/C engaged.

• Under normal weather conditions, do not leave the air flow selector in OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of

airflow to the back seats.

the windshield.

To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C. 3. Adjust the temperature control to maintain comfort. 4. Set the fan speed to the highest setting. 5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when

the rear defroster is activated.

The ignition must be in the ON position to operate the rear window defroster.

28

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

The defroster turns off automatically after 10 minutes or when the ignition is turned to the OFF position. To manually turn off the defroster before 10 minutes have passed, push the control again. Do not use razor blades or other sharp objects to clean the inside of the rear window or to remove decals from the inside of the rear window. This may cause damage to the heated grid lines and will not be covered by your warranty. Activating the rear window defroster will also activate the heated mirrors (if equipped). For more information refer to Heated outside mirrors in the Driver controls chapter.

CABIN AIR FILTER (IF EQUIPPED) Your vehicle may be equipped with a Cabin air filter. The particulate air filtration system is designed to reduce the concentration of airborne particles such as dust, spores and pollen in the air being supplied to the interior of the vehicle. The particulate filtration system gives the following benefits to customers: • Improves the customer’s driving comfort by reducing particle • Improves the interior compartment cleanliness • Protects the climate control components from particle deposits The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer.

concentration

29

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Lights

HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps.

Turns the headlamps on.

Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for a fixed period of time after the ignition switch is turned to OFF. • To turn autolamps on, rotate the control counterclockwise. • To turn autolamps off, rotate the control clockwise to OFF.

Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be in the ON position, • the headlamp control is set to OFF or parking lamp position and • the parking brake must be disengaged.

Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate with your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.

30

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate.

Flash to pass Pull toward you slightly to activate and release to deactivate.

PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control to the full upright position, past detent, to turn on the interior lamps.

AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician.

31

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Vertical aim adjustment 1. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from a vertical wall or screen directly in front of it. • (1) Eight feet • (2) Center height of lamp to • (3) Twenty five feet • (4) Horizontal reference line

ground

2. Measure the height of the headlamp bulb center from the ground and mark a 2.5 meter (8 foot) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well). 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. 4. On the wall or screen you will observe an area of high intensity light. The top of the high intensity area should touch the horizontal reference line, if not, the beam will need to be adjusted.

32

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

33

To see a clearer light pattern for adjusting, you may want to block the light from one headlamp while adjusting the other. 5. Locate the vertical adjuster on each headlamp. Using a 4 mm wrench, turn the adjuster either clockwise (to adjust down) or counterclockwise (to adjust up). The horizontal edge of the brighter light should touch the horizontal reference line. 6. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 7. Close the hood and turn off the lamps.

TURN SIGNAL CONTROL • Push down to activate the left • Push up to activate the right turn

turn signal.

signal.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

INTERIOR LAMPS

REPLACING THE INTERIOR BULBS Check the operation of all bulbs frequently.

Dome lamps and map lamps • ON or D : The dome light will • DOOR or middle position: The

stay on.

dome light will only come on if a door is opened.

• OFF or

: The lamp will not

come on at all.

With the control in the middle position, the dome lamp will illuminate whenever a front door is opened. If either front door has been opened from the outside, the lamp will remain on for 25 seconds after the door is shut. If any other door has been opened from the inside, the lamp will shut off immediately after the door is closed. The map lamp controls (if equipped) are located on the dome lamp. Press the controls on either side of each lens on each map lamp to activate the lamps.

If equipped with a moon roof, the map lamps are located on the moon roof control panel. Press the controls on either side of each map lamp to activate the lamps.

34

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Rear dome lamp (if equipped) The dome lamp lights when: • any door is opened with the control in the middle position. • the instrument panel dimmer

switch is held up until the courtesy lamps come on.

• any of the remote entry controls are pressed and the ignition is OFF.

• the lamp control is moved to the passenger side position. With the ignition key in the ACC or ON position, the rear dome lamp can be turned ON or OFF by sliding the control.

BULBS

Replacing exterior bulbs Check the operation of all the bulbs frequently.

Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time. Function

Number of bulbs

Trade number 3457 AK (amber) 9007 QL (9007
LL optional) 3157K 3057K 3456K 921
3156

35

Front park/turn lamp

Headlamp

Tail lamp/brake/turn lamp Tail lamp/brake lamp (wagon) Rear turn lamp (wagon) Backup lamp Backup lamp (wagon)

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Function License plate lamp High-mount brake lamp (wagon)

High-mount brake lamp (sedan)

Number of bulbs

Trade number 168

912

Must replace the hi-mount brake

lamp assembly 194
578
12V6W 578

Rear side marker lamp (wagon) Cargo lamp (wagon) Dome lamp Dome/map lamp Visor vanity lamp (passenger/driver) Luggage compartment lamp 212–2
All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer.

DE 3021

Replacing the interior bulbs Check the operation of all bulbs frequently.

36

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

37

Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position. 2. Remove the bolt from the headlamp housing. 3. At the back of the headlamp, pry up and remove the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward.

4. Remove the protective dust shield from the housing by turning the dust shield counterclockwise (when viewed from the rear).

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

5. Disconnect the electrical connector from the bulb by pulling rearward.

6. Remove the bulb retaining ring by rotating it counterclockwise.

7. Remove the old bulb from the lamp assembly by pulling it straight out of the lamp assembly.

To install the new bulb:

Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.

1. Install the new bulb in lamp assembly by pushing straight in with the flat surface of the bulb’s plastic base facing upward. You may need to turn the bulb slightly to align the grooves in the plastic base with the tabs in the lamp assembly.

38

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

2. Install the bulb retaining ring over the plastic base and lock the ring by rotating clockwise until it snaps into place. 3. Connect the electrical connector to the bulb. 4. Install the protective dust shield and lock the shield by rotating it clockwise until it locks into position. 5. Carefully position the headlamp assembly onto the vehicle. 6. Hold the headlamp assembly snugly against the vehicle and install the retainer pins straight down to lock the lamp into place. 7. Before reinstalling the bolt, make sure the retainer pins are fully seated, and install bolt on headlamp housing. 8. Turn the headlamps on and make sure they work properly. If the headlamp was correctly aligned before you changed the bulb, you should not need to align it again. Replacing front parking lamp/turn signal/cornering lamp bulbs 1. Make sure the headlamp control is in the OFF position. 2. Remove the bolt from the headlamp housing. 3. At the back of the headlamp, pry up and remove the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward. 4. Rotate the bulb socket counterclockwise and remove it from the lamp assembly.

39

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

5. Carefully pull bulb straight out of the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly by rotating it clockwise. 7. Carefully position the headlamp assembly onto the vehicle. 8. Hold the headlamp assembly snugly against the vehicle and install the retainer pins straight down to lock the lamp into place. 9. Before reinstalling the bolt, make sure the retainer pins are fully seated, and install bolt on headlamp housing. 10. Turn the headlamps on and make sure they work properly. If the headlamp was correctly aligned before you changed the bulb, you should not need to align it again. Replacing high-mount brakelamp assembly — Sedan only To change the high-mount brake lamp assembly: 1. Pry the light assembly away from its housing and push rearward to disengage it from the retaining clips. 2. Lift the front of the light assembly from the parcel shelf. 3. Disconnect the light assembly wiring and replace the light assembly.

40

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing high-mount brakelamp bulbs — Wagon only 1. Open liftgate. 2. Remove two screw covers, screws and handle from liftgate. 3. Remove two screws and the lower trim panel from the liftgate. 4. Remove the upper trim panel.

5. Remove the rubber plug from the lower access hole in the upper portion of the liftgate.

6. Remove four nuts from the lamp assembly.

41

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

7. Carefully lift the lamp assembly away from the liftgate. 8. Remove the bulb socket by rotating it counterclockwise and pulling it out from the lamp assembly. 9. Carefully pull the bulb straight out of the socket and push in the new bulb. 10. To complete installation, follow the removal procedure in reverse order. Replacing high-mount brakelamp bulbs — Decklid spoiler Your vehicle may be equipped with a decklid spoiler that has a high mount stop lamp module containing integral multiple light emitting diodes (LED). If one or more LEDs burn out, the complete lamp module has to be replaced. See your dealer for the replacement LED module. To replace the LED module: 1. Remove the two outboard grommets from the inside of the decklid 2. On the inside of the decklid, remove the three nuts that hold the spoiler on and remove the spoiler.

3. On the underside of the spoiler, remove the two decorative screw covers (on the LED module). 4. Remove the two screws that are holding the LED module in place. 5. Remove the wiring harness grommet and disengage the electrical connector. 6. Replace the LED module. 7. To complete installation, follow the removal procedure in reverse order.

42

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing license plate lamp bulbs Wagon 1. Make sure headlamp switch is in OFF position and remove screw and the license plate lamp assembly from liftgate. 2. Remove bulb socket by turning counterclockwise. 3. Carefully pull the bulb out from the socket and push in the new bulb. 4. Install the lamp assembly on liftgate with screw.

Sedan 1. Make sure headlamp switch is in OFF position and remove two screws, grommets and the license plate lamp assembly from the trunk lid. 2. Carefully pull the bulb from the socket and push in the new bulb. 3. Install the lamp assembly on trunk lid with two grommets, ensuring the grommets are pushed all the way in to the trunk lid and secure with two screws.

43

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing tail/brake/turn signal/backup lamp bulbs Sedan The tail lamp, brake lamp, turn signal lamp and backup lamp bulbs are located in the same portion of the tail lamp assembly. Follow the same steps to replace either bulb. 1. Make sure headlamp switch is in OFF position and open trunk and remove two plastic mushroom nuts, five push pins and the plastic cover from inside the trunk to access the lamp assembly. 2. Carefully pull the carpet away to expose the lamp assembly hardware. 3. Remove three nut and washer assemblies and the lamp assembly from the vehicle.

4. Remove the bulb socket by rotating it counterclockwise, then pulling it out of the lamp assembly. 5. Pull the bulb from the socket and push in the new bulb. 6. Install the bulb socket into the lamp assembly by rotating it clockwise. 7. Install the lamp assembly on the vehicle with three nut and washer assemblies ensuring the washers on the nuts are flush with the body to prevent water from entering the trunk. 8. Carefully push the carpet back in to place and install the plastic cover inside the trunk with five push pins and two plastic mushroom nuts.

44

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Wagon The tail lamp/turn lamp bulbs/brake/backup are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb: 1. Make sure headlamp switch is in OFF position and open the liftgate to expose the lamp assemblies. 2. Remove the two bolts from the tail lamp assembly. 3. Carefully pull the lamp assembly from the tailgate. 4. Twist the bulb socket counterclockwise and remove from lamp assembly. 5. Pull the bulb straight out of the socket and push in the new bulb. 6. Install bulb socket in lamp assembly by turning clockwise. 7. Carefully install the tail lamp assembly on tailgate and secure with two bolts.

45

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

Driver Controls

MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers.

Windshield washer: Push the end of the stalk: • briefly: causes a single swipe of the wipers without washer fluid. • a quick push and hold: the wipers

will swipe three times with washer fluid.

• a long push and hold: the wipers and washer fluid will be activated for

up to ten seconds.

Rear window wiper and washer (wagon only) The rear wiper control is located under the headlamp controls. Press the wiper control to activate the rear wiper. Press again to turn off the wiper.

46

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

47

Press the washer control to activate the rear washer. The wiper will come on when the washer control is pressed, if it is not already on.

Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm. 2. Attach the new wiper to the wiper arm and press it into place until a click is heard. 3. Replace wiper blades every 6
months for optimum performance.

TILT STEERING WHEEL To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control. This will lock the steering wheel in position.

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

Never adjust the steering wheel when the vehicle is moving.

ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamp. The visor will slide back and forth on the rod for increased sunlight coverage.

AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. Do not plug optional electrical accessories into the cigarette lighter. Use the power point. Do not use the power point for operating the cigarette lighter element. The Maximum power each power point can supply depends on the fuse rating. For example: a 20A fuse should supply a maximum of 240 Watts, a 15A fuse should supply a maximum of 180 Watts and a 10A fuse should supply a maximum of 120 Watts. Exceeding these limits will result in a blown fuse. Always keep the power point caps closed when not being used. The auxiliary power point is located on the instrument panel below the optional cigarette lighter (if equipped).

48

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

POWER WINDOWS

When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.

Press and hold the bottom part of the rocker switch to open the window. Press and hold the top part of the rocker switch to close the window. One touch down Allows the driver’s window to open fully without holding the control down. Press completely down on AUTO and release quickly. Press again to stop.

Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the left side of the control. Press the right side to restore the window controls. Accessory delay (if equipped) With accessory delay, the window switches may be used for up to ten minutes after the ignition switch is turned to the OFF position or until any door is opened. MIRRORS

Automatic dimming inside rear view mirror (if equipped) Your vehicle is equipped with an inside rear view mirror which has an auto-dimming function. The electronic day/night mirror will automatically

49

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

change from the normal, clear state to the darkened, non-glare state when bright light (glare) reaches the mirror from behind the vehicle at night. Do not block the sensor (1) on the either side of the mirror since this will impair proper mirror performance (i.e. hangtags, parking stickers, aftermarket window-tint etc.). Use the control located on the mirror to turn the auto-dimming feature OFF or return it to AUTO. A LED (2) will light when the mirror is in AUTO mode. When the auto-dimming feature is OFF the mirror will remain in the normal. clear state. When the mirror is in AUTO mode it will automatically return to the normal, clear state whenever the vehicle is placed in R (Reverse). This is to ensure a clear view when backing up.

Power side view mirrors To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to disable the adjust function.

(if equipped)

Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place. These actions could cause damage to the glass and mirrors.

50

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED) The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position. Press and hold the rocker control (located on the instrument panel) to adjust accelerator and brake pedal. • Press the right side of the control to adjust the pedals toward you. • Press the left side of the control to adjust the pedals away from you. The adjustment allows for approximately 76 mm (3 inches) of maximum travel.

Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving.

SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 48 km/h (30 mph) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 48 km/h (30 mph).

Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved.

Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release it. 2. Accelerate to the desired speed.

51

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

3. Press the SET ACC control and release it. 4. Take your foot off the accelerator pedal. 5. The CRUISE indicator light on the instrument cluster will turn on.

steep hill.

Note: • Vehicle speed may vary momentarily when driving up and down a • If the vehicle speed increases above the set speed on a downhill, you • If the vehicle speed decreases more than 16 km/h (10 mph) below • If the vehicle speed decreases to 40 km/h (25 mph) or less, your

your set speed on an uphill, your speed control will disengage.

may want to apply the brakes to reduce the speed.

speed control will disengage

Disengaging speed control To disengage the speed control: • Depress the brake pedal Disengaging the speed control will not erase previous set speed. Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 48 km/h (30 mph).

52

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

Increasing speed while using speed control There are three ways to set a higher speed: • Press and hold the SET ACC control until you get to the desired speed, then release the control. • Press and release the SET ACC control to operate the Tap-Up function. Each tap will increase the set speed by 1.6 km/h (1 mph).

• Use the accelerator pedal to get to the desired speed. When the

vehicle reaches that speed press and release the SET ACC control.

Reducing speed while using speed control There are three ways to reduce a set speed: • Press and hold the CST control until you get to the desired speed, then release the control.

• Press and release the CST control to operate the Tap-Down function. Each tap will decrease the set speed by 1.6 km/h (1 mph). • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACC control.

53

2004 Taurus (tau) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will

not erase your vehicle’s previously set speed.

• Press the speed control OFF

control.

Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. MOON ROOF (IF EQUIPPED) You can move the glass panel of the moon roof back to open or tilt up to ventilate the vehicle. To open the moon roof: The moon roof is equipped with an automatic, one-touch, express opening feature. Press and release the rear portion of the control. To close, press and hold the front portion of the control. The moon roof has a sliding shade that can be opened or closed when the glass panel is shut. To close the shade, pull it toward the front of the vehicle
