Introduction

Instrument Cluster

Warning and control lights Gauges

Entertainment Systems

AM/FM stereo AM/FM stereo with CD AM/FM stereo with CD/MP3
AM/FM stereo with CD6/MP3

Climate Controls

Heater only Manual heating and air conditioning

Lights

Headlamps Turn signal control Bulb replacement Driver Controls

Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control

Locks and Security

Keys Locks Anti-theft system

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

60

60
62
73
83
96

96
100
103
118
122
132
134

134
135
135
136
146
154
160
161

169
170

Table of Contents

Seating and Safety Restraints

Seating Safety restraints Air bags Child restraints

Driving

Starting Brakes Transmission operation Vehicle loading Trailer towing Recreational towing

Roadside Emergencies

Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing

Customer Assistance

Reporting safety defects (U.S. only)

Cleaning

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Maintenance and Specifications

Engine compartment Engine oil Battery Fuel information Air filter(s) Tire Information Part numbers Refill capacities Lubricant specifications

Accessories

Index

Table of Contents

176

178
182
188
197
214
216
228
229
232
240

243

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Copyright © 2004 Ford Motor Company

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to

the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com • In Canada: www.ford.ca • In Australia: www.ford.com.au • In Mexico: www.ford.com.mx Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on this Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the safety switch will automatically cut off the fuel supply to the

engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in. Drive your new vehicle at least 500 miles (800 km) before towing a trailer. Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

SPECIAL NOTICES

Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle. Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: • how various systems in your vehicle were operating; • whether or not the driver and passenger seatbelts were buckled; • how far (if at all) the driver was depressing the accelerator and/or the • how fast the vehicle was traveling; and • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

brake pedal;

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.

Notice to owners of pickup trucks and utility type vehicles

Utility vehicles have a significantly higher rollover rate than other types of vehicles.

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death. Be sure to read Driving off road in the Driving chapter.

Using your vehicle with a snowplow Do not use this vehicle for snowplowing. Your vehicle is not equipped with a snowplowing package.

Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package.

Middle East/North Africa vehicle specific information For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner’s Guide for all other required information and warnings.

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

See Owner’s Guide

Fasten Safety Belt

Air Bag-Front

Air Bag-Side

Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Child Seat Lower Anchor

Brake System

Brake Fluid - Non-Petroleum Based

Traction Control

AdvanceTrac娂

Master Lighting Switch

Hazard Warning Flasher

Fog Lamps-Front

Fuse Compartment

Fuel Pump Reset

Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Vehicle Symbol Glossary

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm

Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot

Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas

Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

MAX MIN

Emission System

Engine Air Filter

Passenger Compartment Air Filter

Jack

Check fuel cap

Low tire warning

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Instrument Cluster

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, refer to the respective system warning light for additional information. Check engine: The Check Engine indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Check Engine warning light to come on.

10

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

It may take a long period of time for the system to detect an improperly installed or properly re-installed fuel filler cap depending on driving and fuel tank level conditions. Refer to Fuel filler cap in the Maintenance and Specifications chapter. Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level or a failure to brake proportioning and the brake system should be inspected immediately by your servicing dealership.

BRAKE

Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may

occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

ABS

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected; have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated. Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.

11

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

Charging system: Illuminates when the battery is not charging properly.

Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in the Maintenance and specifications chapter. Engine coolant temperature (if equipped): Illuminates when the engine coolant temperature is high during fail-safe cooling on the 2.3L I4 engine. Stop the vehicle as soon as possible , switch off the engine and let cool. Refer to Engine coolant in the Maintenance and specifications chapter.

Never remove the coolant recovery cap while the engine is running or hot.

Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).

Door ajar: Illuminates when the ignition is in the ON position and any door is open.

Overdrive off (if equipped): Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur.

O/D OFF

12

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Four wheel drive low (if equipped): Illuminates when four-wheel drive low is engaged.

4x4
LOW

Four wheel drive high (if equipped): Illuminates when four-wheel drive high is engaged. It may also illuminate when the 4WD LOW is engaged, refer to the Driving chapter for more information. Anti-theft system: Flashes when the Securilock娂 Passive Anti-theft System has been activated.

4x4

Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged.

Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on.

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. Door ajar warning chime: Sounds when any door is opened (or not fully closed).

13

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

GAUGES

Speedometer: Indicates the current vehicle speed.

Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is running or hot.

Odometer: Registers the total kilometers (miles) of the vehicle.

14

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Trip odometer: Registers the kilometers (miles) of individual journeys. Press the button once until “TRIP” appears in the display (this represents the trip mode). To reset the trip, press the control again until the trip reading is 0.0
miles. Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The arrow near the fuel pump icon indicates which side of the vehicle the fuel filler door is located. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

15

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Entertainment Systems

AM/FM STEREO (IF EQUIPPED)

1. AM/FM: Press to select AM/FM1/FM2 frequency bands.

AUDIO

to adjust the

2. CLK: Press until SELECT HOUR / SELECT MINS appears. Press hours/minutes. Press CLK to display the time when the ignition is off. 3. AUDIO: Press AUDIO to toggle through the following modes and use those modes.

to make adjustments in

Bass: Press

AUDIO

to decrease/increase the bass setting.

Treble: Press

AUDIO

to decrease/increase the treble setting.

AUDIO

to adjust the audio between the left and

Balance: Press right speakers.

16

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

) the radio frequency

4. Tune: Press to manually go down/up ( and in audio mode to select various settings. 5. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To tune a preset station, press the desired memory preset. 6. SEEK: Press to SEEK access the previous or next radio station. If pressed for less than .5
seconds, the system will seek to the next or previous station. 7. ON/OFF/Volume: Press to turn the system ON/OFF. Turn to adjust the volume levels. If the volume is set above a certain level, and the ignition is turned off, the volume will come back to a “nominal” listening level when the ignition is turned back on.

AM/FM STEREO SINGLE CD SYSTEM (IF EQUIPPED)

17

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

1. CD eject: Press to eject the CD.

2. CLK (Clock):Press CLK until SELECT HOUR or SELECT MINS is displayed. Press

TUNE

to adjust the

hours/minutes. Press CLK to display the time when the ignition is off. 3. MUTE:Press to mute the playing media. Press again to return to the playing media.

4. MENU: Press MENU repeatedly to toggle through the following to make modes and use adjustment in those modes. Autoset: Press MENU set the strongest local radio stations for AM/FM1/FM2 without losing your original manually set preset stations. When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.

to

Bass: Press

MENU

to decrease/increase the bass setting.

Treble: Press

MENU

to decrease/increase the treble setting.

Balance: Press right speakers.

MENU

to adjust the audio between the left and

to adjust the audio between the front and

MENU

Fade: Press rear speakers. 5. TUNE: Press to manually go down/up ( frequency and also to select various settings in menu mode.

) the radio

18

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

6. SHUFF (Shuffle): Press to play the tracks on the current CD in random order. 7. REPEAT: Press to repeat the current CD track. The selection will repeat continuously until deactivated. Press REPEAT again to deactivate. 8. FF (Fast forward): Press to manually advance in a CD track.

9. REW (Rewind): Press to manually reverse in a CD track.

10. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To recall a previously set station, press the desired memory preset button briefly.

) strong

11. SEEK/TRACK: Press to access the previous/next ( station. In CD mode, press to advance to the previous/next ( track. 12. SCAN: Press to toggle between SCAN ON and SCAN OFF. When activated, the system scans up through and plays a brief sampling of available radio stations or CD tracks. Press again to stop. 13. AM/FM:Press to select AM/FM1/FM2 frequency band.

14. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.

19

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

15. CD: Press to enter CD mode. If a CD is already present in the system, the disc will begin to play. 16. CD slot: Insert a CD label side up.

CD units are designed to play commercially pressed 12 cm (4.75
in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information.

AM/FM STEREO CASSETTE, CD/MP3 SOUND SYSTEM (IF EQUIPPED)

20

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

1. CD eject: Press to eject the CD.

Entertainment Systems

MENU

2. CLK (Clock): Press CLK until SELECT HOUR or SELECT MINS is displayed. Press adjust the hours/minutes. Press CLK to display the time of day when the ignition is off. 3. MUTE: Press to mute the playing media. Press again to return to the playing media.

to

4. MENU: Press MENU repeatedly to toggle through the following to make modes and use adjustment in those modes. Autoset: Press MENU to access the autoset setting. Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Use set. When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Press again to disengage. Bass: Press

to decrease/increase the level of bass.

MENU

MENU

to

Treble: Press

MENU

to decrease/increase the level of treble.

to adjust the audio between the left and

to adjust the audio between the front and

MENU

MENU

Balance: Press right speakers. Fade: Press rear speakers. Next/previous directory: In MP3 mode, press the previous or next MP3 directory. Flat file/directory mode: Press or Directory mode.

MENU

MENU

to go to

to select Flat file mode

21

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

to cycle Dolby ON/OFF. The Dolby威 noise

Track number/music name/file name: In MP3 mode, press to view by track number, music name or file name. MENU Dolby威 noise reduction: Reduces tape noise and hiss. Dolby: Press MENU reduction system is manufactured under license from Dolby Laboratories Licensing Corporation. Dolby威 and the double-D symbol are registered trademarks of Dolby威 Laboratories Licensing Corporation. 5. TUNE: Press to manually go down/up ( frequency and also to select various settings in menu mode. 6. Tape eject: Press to eject the tape.

) the radio

7. Tape 1–2: Press to change playing sides of the tape.

8. TEXT: In MP3 mode, press to view the next 12 characters in the MP3 Music name/file name of the current MP3 track and directory. 9. SHUFF (Shuffle): In CD or MP3
mode, press to play the tracks on the current CD/MP3 in random order. In MP3 directory mode, press to play the tracks within the current directory in random order. 10. REPEAT: Press to repeat the current CD/MP3 track. The selection will repeat continuously until deactivated. Press REPEAT again to deactivate. 11. FF (Fast forward): In tape mode, press to fast forward the tape. In CD mode, press to manually advance in a CD track. 12. REW (Rewind): In tape mode, press to rewind the tape. In CD mode, press to manually reverse in a CD track.

22

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

13. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To select a preset station, press the desired memory preset button. 14. AM/FM: Press to select AM/FM1/FM2 frequency band.

to access the

15. SEEK/TRACK: In radio mode, press previous/next strong station. In CD and MP3 flat file mode, press to access the next track. In MP3 directory mode, press to select the next/previous track in the current directory. 16. Scan: In radio mode, scan through the available stations. In tape mode, you may set SCAN on or off. If activated, the player will scan the tape and plays a short Introduction of each song. In CD and MP3 flat file mode, you may set the scan on or off. If activated, the system will scan through each track. In MP3 directory mode, you may set scan on or off. If activated, the system will scan in the current directory. 17. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 18. CD: Press to enter CD mode. If a CD is already in the system, the disc will begin play. 19. CD slot: Insert a CD, label side up.

CD units are designed to play commercially pressed 12 cm (4.75
in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to

23

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information.

PREMIUM/AUDIOPHILE IN-DASH CD6/MP3 DISC PIONEER AUDIO SYSTEM (IF EQUIPPED)

19

18

17

16
15

14

COMP

13

12

11

10

1. AM/FM: Press to select AM/FM1/FM2 frequency bands.

2. CD: Press to enter CD mode. If a CD is already in the system, the disc will start playing. 3. EJ (CD eject): Press to eject the CD. Press and hold to eject all CDs.

4. CLK (Clock): Press CLK until SELECT HOUR or SELECT MINS is displayed. Press adjust the hours/minutes. Press CLK to display the time when the ignition is off.

MENU

to

24

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

5. MUTE: Press to mute the playing media. Press again to return to the playing media.

6. MENU: Press MENU repeatedly to toggle through the following to make modes and use adjustment in those modes. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press MENU to access. Use When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Bass: Press

to decrease/increase the bass setting.

MENU

MENU

to set.

Treble: Press

MENU

to decrease/increase the treble setting.

MENU

MENU

to go to

to adjust the audio between the left and

to adjust the audio between the front and

Balance: Press right speakers. Fade: Press rear speakers. Next/previous directory: In MP3 mode, press MENU the previous/next directory. Flat file/directory mode: In MP3 mode, press MENU to access this to select flat file mode or directory mode. feature. Use Track #/normal music name/file name: Press MENU to access and use name or file name). 7. TUNE/DISC: Press to manually go down/up ( frequency, select the previous/next CD or to select various settings in menu mode. 8. TEXT: In MP3 music name/file name mode, press to view the next 12
characters in the MP3 music name/filename of the current MP3 track and directory.

to scroll through MP3 display options (track #, normal music

) the radio

MENU

25

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

9. SHUFF (Shuffle): Press to play the tracks on the current CD/MP3 in random order. In MP3 directory mode, press to play the tracks within the current directory in random order. 10. Compression (Audiophile audios only): In CD/MP3 modes, press to bring loud and soft passages together for a more consistent listening level. 11. REPEAT: Press to repeat the current CD/MP3 track. The selection will repeat continuously until deactivated. Press REPEAT again to deactivate. 12. FF (Fast forward): Press to manually advance in a CD track.

13. REW (Rewind): Press to manually reverse in a CD track.

14. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To select a preset station, press the desired memory preset. 15. SEEK/TRACK: In radio, CD and MP3 flat file mode, press to access the previous/next strong station or track. In MP3 directory mode, press to select the next/previous track in the current directory. 16. SCAN: In radio, CD and MP3
flat file mode, press for a brief sampling of radio stations or CD/MP3 tracks. In MP3 directory mode, press to hear a brief sampling of all tracks in the current directory. Press again to stop. 17. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.

26

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

18. LOAD: Press to load a CD. Press and hold to autoload up to six discs. 19. CD slot: Insert a CD, label side up. CD units are designed to play commercially pressed 12 cm (4.75
in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information.

TREMOR IV CD/MP3 AUDIO SYSTEM (IF EQUIPPED)

1. EJ (CD eject): To eject an individual CD, press CD and select the correct slot number by pressing the Memory Preset buttons. Press and hold EJ (eject) to eject all loaded CDs.

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

27

Entertainment Systems

2. CD: Press to enter CD mode. If a CD is already present in the system, the disc will begin play.

3. CLK (Clock): Press CLK until SELECT HOUR/SELECT MINUTE is ) to displayed. Press TUNE ( adjust the hours/minutes. Press CLK to display the time when the ignition is off. 4. TUNE: In radio mode, press to manually go up or down the radio frequency, or to access another CD. Also use in menu mode to select various settings. 5. TEXT: In MP3 music name/file name mode, press to view the next 12 characters in the MP3 music name/file name of the current MP3 track and directory. 6. SHUF (Shuffle): Press to play the tracks on the current CD/MP3 in random order. In MP3 directory mode, press to play the tracks within the current directory in random order. 7. COMP (Compression): In CD/MP3 modes, press to bring soft and loud passages together for a more consistent listening level. 8. MENU: Press MENU to toggle through the following modes to make and adjustments in these modes. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2. Press MENU to access, use stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Press

to set. When the six strongest

again to disengage.

TUNE

TUNE

TUNE

BASS: Press

TUNE

to decrease/increase the bass levels.

28

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

TUNE

to decrease/increase the treble

TUNE

to adjust the audio between the

TREB (treble): Press levels.

BAL (Balance):Press left and right speakers.

FADE: Press rear speakers.

TUNE

to adjust the audio between the front and

Flat file/directory mode: In MP3 mode, press Flat file mode or Directory mode.

TUNE

to select

TUNE

Track number/normal music name/file name: Press view by track number, music name or file name. 9. ON/OFF/VOL (Volume): Press to turn the system ON/OFF. Turn to adjust the volume levels. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition is turned back on. 10. SCAN: In radio, CD and MP3
flat file mode, press for a brief sampling of radio stations or CD/MP3 tracks. In MP3 directory mode, press to hear a brief sampling of all tracks in the current directory. Press again to stop. 11. REPEAT: Press to repeat the current CD/MP3 track. The selection will repeat continuously until deactivated. Press REPEAT again to deactivate. 12. FF (fast forward): Press to manually advance in a CD track.

13. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To select a preset station, press the desired memory preset button.

to

29

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

14. MUTE: Press to mute the playing media. Press again to return to the playing media. 15. REW (rewind): Press to manually reverse a CD track.

16. SEEK: In radio, CD and MP3
to flat file mode, press access the previous/next strong station or track. In MP3 directory mode, press to select the next/previous track in the current directory. 17. AM/FM: Press to select AM/FM1/FM2 frequency band.

18. LOAD: To load a CD/MP3 disc to a specific slot, press LOAD and select the slot number by pressing the Memory Preset buttons. Press and hold LOAD to autoload up to six discs. 19. CD slot: Insert a CD, label side up.

RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz

30

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

weaker the signal and the weaker the reception.

RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception. • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.

CASSETTE/PLAYER CARE Do: • Use only cassettes that are 90 minutes long or less. • Tighten very loose tapes by inserting a finger or pencil into the hole • Remove loose labels before inserting tapes. • Allow tapes which have been subjected to extreme heat, humidity or • Clean the cassette player head with a cassette cleaning cartridge after

cold to reach a moderate temperature before playing.

and turning the hub.

10–12 hours of play to maintain good sound/operation.

Don’t: • Expose tapes to direct sunlight, extreme humidity, heat or cold. • Leave tapes in the cassette player for a long time when not being

played.

CD/CD PLAYER CARE Do: • Handle discs by their edges only. Never touch the playing surface. • Inspect discs before playing. Clean only with an approved CD cleaner

and wipe from the center out.

31

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

of time.

Don’t: • Expose discs to direct sunlight or heat sources for extended periods • Insert more than one disc into each slot of the CD changer magazine. • Clean using a circular motion. CD units are designed to play commercially pressed 12 cm (4.75
in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.

AUDIO SYSTEM WARRANTY AND SERVICE Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.

32

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

Climate Controls

HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. : Distributes outside air through the instrument panel vents.

OFF: Outside air is shut out and the fan will not operate.

: Distributes outside air through the instrument panel vents and the

floor vents.

: Distributes outside air through the floor vents. : Distributes outside air through the windshield defroster vents and

floor vents.

: Distributes outside air through the windshield defroster vents.

position.

the air flow selector in the

OPERATING TIPS • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle during cold or warm weather, do not drive with the air flow selector in the OFF position. • Under normal weather conditions, do not leave the air flow selector in OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the air • Remove any snow, ice or leaves from the air intake area at the base of

flow to the back seats.

the windshield.

33

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

To aid in side window defogging/demisting in cold weather: 1. Select 2. Adjust the temperature control to maintain comfort. 3. Set the fan speed to the highest setting. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Uses recirculated air to cool the vehicle. Air flows from the instrument panel vents only. Temperature of airflow not adjustable. A/C: Uses outside air to cool the vehicle. Air flows from the instrument panel vents only.

: Distributes outside air through the instrument panel vents.

OFF: Outside air is shut out and the fan will not operate.

: Distributes outside air through the instrument panel vents and the

floor vents.

: Distributes outside air through the floor vents. : Distributes outside air through the windshield defroster vents and

floor vents.

: Distributes outside air through the windshield defroster vents.

34

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

position.

the air flow selector in the

air flow selector in the OFF position.

OPERATING TIPS • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of

airflow to the back seats.

the windshield.

To aid in side window defogging/demisting in cold weather: 1. Select 2. Adjust the temperature control to maintain comfort. 3. Set the highest fan speed. 4. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

35

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Lights

HEADLAMP CONTROL

Turns the lamps off.

Turns on the parking

lamps, instrument panel lamps, license plate lamps and tail lamps.

Turns the headlamps on.

OFF

Foglamp control (if equipped) The foglamps can be turned on when the ignition is in the ON position and the headlamp control is in either of the following positions: • Parking lamps • Low beams Press the foglamp control to activate the foglamps. Press the foglamp control again to deactivate the foglamps. When the highbeams are activated, the foglamps will not operate.

Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be in the ON position and • the headlamp control is in the OFF or parking lamp.

Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system

does not activate your parking lights or side marker lights and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.

36

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate.

Flash to pass Pull toward you slightly to activate and release to deactivate.

PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control up or down to adjust the intensity of the panel lighting. Move the control to the full upright position, past detent, to turn on the interior lamps. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed before leaving the assembly plant. If your vehicle is involved in an accident or if you have problems fixing the alignment of your headlamps, have them checked by a qualified service technician.

DIM

37

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

ground

HEADLAMP AIM ADJUSTMENT The headlamps on your vehicle can only be vertically adjusted. Your vehicle does not require horizontal aim adjustments. To adjust the headlamps: 1. Park your vehicle on a level surface about 7.6 meters (25 feet) away from a vertical plain surface (3). Check your headlamp alignment at night or in a dark area so that you can see the headlamp beam pattern. • (1) Eight feet • (2) Center height of lamp to • (3) Twenty-five feet • (4) Horizontal reference line • (5) Center of headlamps • (6) Center line of the vehicle 2. The center of the headlamp is marked either on the lens (a circle or cross marker) or on the bulb shield, internal to the lamp (mark or feature). Measure the height from the center of your headlamp to the ground (2) and mark a 2.4 meter (8 foot) long horizontal line on the wall or screen (1) at this height (masking tape works well). 3. Locate the high intensity area of the beam pattern and place the top edge of the intensity zone even with the horizontal reference line (4). If the bottom pattern is above the line, the headlamp will need to be adjusted. 4. Turn on the low beam headlamps and open the hood. 5. Locate the vertical adjuster for each headlamp. Adjust the aim by turning the adjuster control either clockwise (to adjust down) or counterclockwise (to adjust up).

38

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

39

6. In addition to the horizontal line marked in step 2, a pair of vertical lines (5) must be marked at the center line of the headlamps on the wall or screen. 7. On the wall or screen, locate the high intensity area of the beam pattern. Place the left edge of the high intensity area even with the vertical line corresponding to the headlamp under adjustment.

TURN SIGNAL CONTROL • Push down to activate the left • Push up to activate the right turn

turn signal.

signal.

INTERIOR LAMPS

COURTESY/READING LAMPS (IF EQUIPPED) The courtesy lamp lights when: • any door is opened. • the instrument panel dimmer

switch is held up until the courtesy lamps come on.

• the remote entry controls are

pressed and the ignition is OFF.

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

BULBS

Replacing exterior bulbs Check the operation of all the bulbs frequently.

Number of bulbs

Trade number 3457AK (amber)

Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time. Function Park/turn(front) Side marker lamps Headlamps Foglamps (if equipped) Hi-mount brakelamp Rear stop/turn/tail lamps Rear license plate lamps Backup lamp Dome lamp Map/dome-SuperCab (if equipped) Map/dome-Regular Cab (if equipped) All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer.

194
9007

904
904

3157K

3156K

9145

194

904

922

912

Replacing the interior bulbs Check the operation of all bulbs frequently.

40

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure the headlamp switch is in the OFF position, then open the hood. 2. Remove two screws and cover (if equipped). 3. At the back of the headlamp, pry up the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward.

4. Disconnect the electrical connector from the bulb by pulling rearward.

5. Remove the bulb retaining ring by rotating it counterclockwise and slide the ring off the plastic base.

6. Remove the old bulb by pulling it straight out of the lamp.

Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.

Install the new bulb(s) in reverse order.

41

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing front side marker /turn signal/ sidemarker bulbs 1. Turn the headlamp switch to the OFF position and then open the hood. 2. Remove two screws and cover (if equipped). 3. At the back of the headlamp, pry up the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward.

4. Remove screw(s) from lamp assembly and disengage lamp assembly (it has a snap fit).

5. Rotate bulb socket counterclockwise and remove from lamp assembly. 6. Carefully pull bulb straight out of socket and push in the new bulb. 7. Install the bulb socket in lamp assembly by turning clockwise.

Install the new bulb in reverse order.

42

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing tail lamp/backup lamp bulbs 1. Make sure the headlamp switch is in the OFF position and the open the tailgate to expose the lamp assemblies. 2. Remove the four screws and the lamp assembly from vehicle.

3. Rotate bulb socket counterclockwise turn and remove from lamp assembly. 4. Carefully pull the bulb straight out of the socket

Install the new bulb(s) in reverse order.

43

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Replacing foglamp bulbs (if equipped) 1. Make sure the headlamp switch is in the OFF position and remove the bulb socket from the foglamp by turning counterclockwise. 2. Disconnect the electrical connector.

Install the new bulb in reverse order. Replacing high-mount brakelamp bulb 1. Make sure the headlamp switch is in the OFF position and remove the two screws and lamp assembly from vehicle. 2. Remove the bulb socket from lamp assembly by rotating it counterclockwise. 3. Carefully pull bulb straight out of socket. Install the new bulb in reverse order. Replacing license plate lamp bulbs 1. Make sure the headlamp switch is in the OFF position and reach behind the rear bumper to locate the bulb socket. 2. Twist the socket counterclockwise and remove. 3. Carefully pull the bulb straight out of the socket.

Install the new bulb(s) in reverse order.

44

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers (from desired interval to low or high speed position); rotate towards you to decrease the speed of the wipers.

Driver Controls

Windshield washer: Push the end of the stalk: • briefly: causes a single swipe of the wipers without washer fluid. • a quick push and hold: the wipers

will swipe three times with washer fluid.

• a long push and hold: the wipers and washer fluid will be activated for up to ten seconds.

Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm. 2. Attach the new wiper to the wiper arm and press it into place until a click is heard. 3. Replace wiper blades every 6 months for optimum performance.

45

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

TILT STEERING WHEEL (IF EQUIPPED) To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control. This will lock the steering wheel in position.

Never adjust the steering wheel when the vehicle is moving.

AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plugs. Improper use of the power outlets can cause damage not covered by your warranty. The auxiliary power points are located on the instrument panel. Do not plug optional electrical accessories into the cigarette lighter. Use the power points. Do not use the power points for operating the cigarette lighter element. The Maximum power each power point can supply depends on the fuse rating. For example: a 20A fuse should supply a maximum of 240 Watts, a 15A fuse should supply a maximum of 180 Watts and a 10A fuse should supply a maximum of 120 Watts. Exceeding these limits will result in a blown fuse. Refer to Passenger Compartment Fuse Panel in the Roadside Emergencies chapter for fuse ratings in your vehicle. Always keep the power point caps closed when not being used.

46

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

POWER WINDOWS (IF EQUIPPED)

When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.

Press and hold the bottom part of the rocker switch to open the window. Press and hold the top part of the rocker switch to close the window.

One touch down Allows the driver’s window to open fully without holding the control down. Press completely down on AUTO and release quickly. Press again to stop.

to adjust the left to adjust the right

POWER SIDE VIEW MIRRORS (IF EQUIPPED) To adjust your mirrors: 1. Select mirror or mirror. 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to lock mirrors in place.

47

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

FOLD-AWAY MIRRORS Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash.

SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h).

Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved.

Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release it. 2. Accelerate to the desired speed.

3. Press the SET + control and release it. 4. Take your foot off the accelerator pedal. 5. The indicator light instrument cluster will turn on. Note: • Vehicle speed may vary momentarily when driving up and down a • If the vehicle speed increases above the set speed on a downhill, you • If the vehicle speed decreases more than 10 mph (16 km/h) below

may want to apply the brakes to reduce the speed.

steep hill.

on the

your set speed on an uphill, your speed control will disengage.

48

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

• If the vehicle speed decreases to 30 mph (48 km/h) or less, your

speed control will disengage Disengaging speed control To disengage the speed control: • Depress the brake pedal or • Depress the clutch pedal (if equipped). Disengaging the speed control will not erase previous set speed. Note: When you use the clutch pedal to disengage the speed control, the engine speed may briefly increase, this is normal. Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h).

Increasing speed while using speed control There are three ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control. • Press and release the SET + control to operate the Tap-Up function. Each tap will increase the set speed by 1 mph (1.6 km/h).

• Use the accelerator pedal to get to the desired speed. When the vehicle reaches that speed press and release the SET + control.

Reducing speed while using speed control There are three ways to reduce a set speed: • Press and hold the CST - control until you get to the desired speed, then release the control. • Press and release the CST -

control to operate the Tap-Down function. Each tap will decrease the set speed by 1 mph (1.6 km/h).

49

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls • Depress the brake pedal or the clutch pedal (if equipped) until the desired vehicle speed is reached, press the SET + control.

control.

Turning off speed control There are two ways to turn off the speed control: • Press the speed control OFF • Turn OFF the ignition. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. CENTER CONSOLE (IF EQUIPPED) Your vehicle may be equipped with a variety of console features. These include: • Utility compartment with • Cupholders • Coin holder slots • Flip up armrest • Passenger airbag on/off switch (if equipped)

cassette/compact disc storage

Use only soft cups in the cupholder. Hard objects can injure you in a collision.

Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.

50

2004 Ranger (ran) Owners Guide (post-2002-fmt) USA English (fus)

Driver Controls

Mobile Communication Equipment includes, but is not limited to cellular phones, pagers, portable email devices, in vehicle communications systems, telematics devices and portable two-way radios.

A driver’s first responsibility is the safe operation of the vehicle. The most important thing you can do to prevent a crash is to
