2004 Ford Mustang Owners Manual

Table of Contents

Table of Contents

12

12
16
20

20
27
35

35
36
37

37
40
40
45

45
46
47
48
48
56

56
56
58

Introduction

Instrument Cluster

Warning and control lights Gauges Entertainment Systems

AM/FM stereo with CD AM/FM stereo with in-dash six CD Climate Controls

Manual heating and air conditioning Rear window defroster Lights

Headlamps Turn signal control Bulb replacement Driver Controls

Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Locks and Security

Keys Locks Anti-theft system

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Table of Contents

Seating and Safety Restraints

Seating Safety restraints Air bags Child restraints Driving

Starting Brakes Traction control Transmission operation Vehicle loading Trailer towing Recreational towing Roadside Emergencies

Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance

Reporting safety defects (U.S. only) Cleaning

66

66
70
81
86
100

100
105
108
109
118
121
121
123

123
125
125
126
131
138
144
145

155
156

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Table of Contents

Maintenance and Specifications

Engine compartment Engine oil Battery Fuel information Tire Information Part numbers Refill capacities Lubricant specifications Accessories

Index

164

167
170
174
185
206
220
221
223
229

232

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Copyright © 2004 Ford Motor Company

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and certain vehicle

components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com • In Canada: www.ford.ca • In Australia: www.ford.com.au • In Mexico: www.ford.com.mx Additional owner information is given in separate publications.

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on this Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the safety switch will

automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in. Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

SPECIAL NOTICES

Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS) in the Seating and

Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should NEVER be placed in

front of an active passenger air bag.

Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: • how various systems in your vehicle were • whether or not the driver and passenger seatbelts • how far (if at all) the driver was depressing the • how fast the vehicle was traveling; and • where the driver was positioning the steering

accelerator and/or the brake pedal;

were buckled;

operating;

wheel.

To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Notice to owners of Cobra vehicles Before you drive your vehicle, be sure to read the SVT Cobra Owner’s Guide supplement. This book contains important operation and maintenance information.

MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner’s Guide for all other required information and warnings.

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

See Owner’s Guide

Fasten Safety Belt

Air Bag-Front

Air Bag-Side

Child Seat

Child Seat Installation Warning

Child Seat Lower Anchor

Child Seat Tether Anchor

Anti-Lock Brake System

Brake System

Brake Fluid - Non-Petroleum Based

Traction Control

AdvanceTrac娂

Master Lighting Switch

Hazard Warning Flasher

Fog Lamps-Front

Fuse Compartment

Windshield Wash/Wipe

Rear Window Defrost/Demist

Power Window Lockout

Fuel Pump Reset

Windshield Defrost/Demist

Power Windows Front/Rear

10

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Introduction

Vehicle Symbol Glossary

Child Safety Door Lock/Unlock

Interior Luggage Compartment Release Symbol

Panic Alarm

Engine Oil

Engine Coolant

Do Not Open When Hot

Avoid Smoking, Flames, or Sparks

Engine Coolant Temperature

Battery

Battery Acid

Explosive Gas

Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

MAX MIN

Emission System

Engine Air Filter

Passenger Compartment Air Filter

Jack

Check fuel cap

Low tire warning

11

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Instrument Cluster

WARNING LIGHTS AND CHIMES Base instrument cluster

60

40

20

30

20

10

60 70

50

80 100 120

40

80

140

90
100

110

160
180

120

MPH

km/h

FUEL DOOR

RPMX1000

SELECT/RESET 0 0 0 0 0 00

AIR BAG

THEFT

SERVICE ENGINE SOON

LOW FUEL

O/D OFF

ABS

BRAKE

CHECK FUEL CAP

Optional instrument cluster

60

80

50

60
40

40
30
20
10

90

80

70
100120 140

160

100
110
180

200

120
130
140

220
240
150

20

MPH

FUEL DOOR

km/h

RPMX1000

SELECT/RESET 0 0 0 0 0 00

AIR BAG

THEFT

SERVICE ENGINE SOON

LOW FUEL

O/D OFF

ABS

BRAKE

CHECK FUEL CAP

Mach 1 instrument cluster

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately.

12

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

SERVICE ENGINE SOON

Service engine soon: The Service engine soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

Under engine misfire conditions, excessive exhaust temperatures could damage the

catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

CHECK FUEL CAP

Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter. Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking

BRAKE

13

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.

Driving a vehicle with the brake system warning light on is dangerous. A significant

decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

ABS

AIR BAG

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated. Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected. Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt. Charging system: Illuminates when the battery is not charging properly. Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty. Refer to Fuel gauge in this chapter).

LOW FUEL

14

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

O/D OFF

Overdrive off: Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur. Traction Control娂 active: Illuminates when the Traction Control娂 system is active. If the light remains on, have the system serviced immediately. Anti-theft system: Flashes when the Securilock娂 Passive Anti-theft System has been activated. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on. Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.

15

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

GAUGES Base instrument cluster gauges

60

40

20

30

20

10

60 70

50

80 100 120

40

80

140

90
100

110

160
180

RPMX1000

120

MPH

km/h

FUEL DOOR

SELECT/RESET 0 0 0 0 0 00.

AIR BAG

THEFT

SERVICE ENGINE SOON

LOW FUEL

O/D OFF

ABS

BRAKE

CHECK FUEL CAP

Optional instrument cluster gauges

60

80

50

60
40

40
30
20
10

90

80

70
100120 140

160

100
110
180

200

120
130
140

220
240
150

20

MPH

FUEL DOOR

km/h

RPMX1000

SELECT/RESET 0 0 0 0 0 00

AIR BAG

THEFT

SERVICE ENGINE SOON

LOW FUEL

O/D OFF

ABS

BRAKE

CHECK FUEL CAP

Mach 1 instrument cluster gauges

Speedometer: Indicates the current vehicle speed. • Base instrument cluster

16

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

• Optional instrument cluster

• Mach 1 instrument cluster

Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is running or hot.

Odometer: Registers the total kilometers (miles) of the vehicle.

Trip odometer: Registers the kilometers (miles) of individual journeys. Press and release the reset button until a “T” appears in the display. Press and hold the button for three seconds to reset.

SELECT/RESET 0 0 0 0 0 00

RPMX1000

17

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. • Base instrument cluster

• Optional instrument cluster

• Mach 1 instrument cluster

Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked as soon as possible.

18

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Instrument Cluster

Engine oil pressure gauge: Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level. Add oil if needed. If the oil level is correct, have your vehicle checked at your dealership or by a qualified technician. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

19

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Entertainment Systems

AM/FM STEREO / SINGLE CD RADIO

13

14 15 16 17 18

VOL - PUSH ON

12

11

SEEK

TUNE DISCS

AM FM

CD

BASS

TREB

FM1

ST

BAL

FADE

DISC

SCN

CLK

EJ

COMP

CD

CD

SHUFFLE

10

1. Balance: to shift Press sound to the left/right speakers. 2. Fade: Press to shift sound to the front/rear speakers. 3. SCN (Scan): Press to hear a brief sampling of all listenable stations or CD tracks. Press again to stop. 4. CLK: To set the hour, press and hold CLK and press SEEK to decrease

or increase

CLK

the hours.

To set the minute, press and hold CLK and press TUNE to decrease 5. EJ (eject): Press to eject a CD.

or increase

the minutes.

20

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

SHUFFLE

SHUFFLE

CD

CD

6. COMP (Compression): In CD mode, press to bring louder and softer levels into more comfortable listening level. The compression icon (c) will appear in the display. 7. Shuffle: Press to listen to the tracks on the CD in random order. Press again to turn off. 8. Memory presets: To set a station: Select frequency band AM/FM; tune to a station. Press and hold a preset button until sound returns. This radio is equipped with six station memory preset controls which allow you to set up to six AM stations and 12 FM stations (six in FM1 and six in FM2). 9. CD: hold until desired selection is reached. CD:Press 10. and hold until desired selection is reached. 11. Tune / Discs: In radio mode, press to move up or down the frequency band in individual increments. 12. Seek: Press and release SEEK for previous/next strong station, selection or track. 13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

Press and

21

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

14. CD: Press to enter CD mode or to play a CD already loaded into the system. 15. AM/FM: Press to choose a frequency band in radio mode. 16. Bass: Press increase/decrease the bass output. 17. Treble: Press increase/decrease the treble output. 18. CD door: Insert a CD printed side up.

to

to

DISC

MACH姞 MP3 AUDIO SYSTEM (IF EQUIPPED)

1. Balance: to shift Press sound to the left/right speakers. 2. Fade: Press to shift sound to the rear/front speakers.

22

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

to

control to

3. Scan: Press to hear a brief sampling of all listenable radio stations, CD or MP3 tracks. Press again to stop. 4. CLK: To set the clock press and hold the CLK control for the following functions: • To set the hour, press SEEK decrease or increase to the hours. • To set the minutes, press TUNE DIR decrease or increase the minutes. Release CLK to save the clock settings. Press CLK again to return the display to radio mode. 5. EJ (Eject): Press to stop and eject a disc. If a disc is ejected and not removed, the player will automatically reload the disc and return to radio mode. 6. COMP (Compression): In CD and MP3 mode, press to adjust the soft and loud sounds together for a more consistent listening level. The compression icon (c) will illuminate in the display. 7. Shuffle: Press to engage random play on the CD or MP3 disc. SHF then ON will briefly appear in the display. Press SEEK to select another random track on the disc. Press shuffle again to disable. 8. Repeat: Press to repeat the current track. 9. CD forward): Press and hold until the desired selection point is reached. This function is not enabled in MP3 mode.

(Fast

23

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

CD (Rewind):

10. Press and hold until the desired selection point is reached. This function is not enabled in MP3
mode. 11. MP3 directory: Allows you to listen to songs in MP3 flat file mode and MP3 directory mode. • Insert a MP3 disc to engage in the flat file mode. • While in the MP3 flat file mode, press the MP3
DIR control to enter into the directory mode. Press the TUNE DIR control to change directories. The MP3 icon and the DIR icon will be displayed.

The MP3 icon will be displayed.

12. Track: Press to locate a specific MP3
track or directory. TRAC will appear in the display. Rotate volume control to advance or reverse through the tracks or directories. The MP3 icon will flash in the display while the MACH威 track function is enabled. 13. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 14. CD door: Insert a CD with the label side up. 15. Tune/Directory: Press TUNE DIR the radio frequency down/up or change the MP3
directories. 16. Seek: Press and release SEEK for previous/next strong station selection or CD and MP3 tracks.

to change

24

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

17. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

18. CD: Press CD to play a CD or MP3 disc. When the MP3 disc is loaded, CD and LOAD will appear on the display. The display will briefly show the total number of tracks on the disc as TXXX (XXX=number of tracks). 19. AM/FM: Press to select a frequency band in radio mode. 20. Bass: Press decrease/increase the bass output. 21. Treble: Press decrease/increase the treble output.

to

to

MP3 FUNCTIONS Your audio system is equipped with MP3 capability which allows you to listen to songs in MP3 flat file mode and MP3 directory mode. To engage MP3 flat file mode, insert an MP3 disc. If an MP3 disc is already present in the player, press the CD control. The MP3 icon will display while the player is in MP3 mode. While in MP3 flat file mode, press the MP3
DIR control to enter into MP3 directory mode. The MP3 icon and the DIR icon will display while the player is in directory mode.

25

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

Your MACH威 MP3 player is also equipped with an anti-shock buffer for MP3 discs.

MP3 FILE DIRECTORY STRUCTURE The MACH威 MP3 music system recognizes MP3 disc file and directory (folder) structure as follows: • There are two different modes for MP3 disc

playback: MP3 flat file mode (default) and MP3
directory mode.

• MP3 flat file mode ignores any directory structure present on the MP3 disc. The player sequentially numbers each MP3 track on the disc (denoted by the .mp3 file extension) from T001 to T255. • MP3 directory mode represents a directory

structure consisting of one level of directories (folders). The CD player sequentially numbers all MP3 tracks on the disc (denoted by .mp3
extension) and all directories containing MP3
files, from 01–01 to 99–99. The first two digits denote the directory number and the last two digits denote the track number within that directory.

• Creating discs with only one level of

subdirectories will help with navigation through the disc files.

ERROR MESSAGES You may experience an error message for the following situations: • NO DISC when the CD control is pressed and • DISC ERR when there is a damaged or unreadable disc. Such as, data discs containing no .mp3 files, or for data discs containing more than 255 files or directories.

there is not a CD present.

• CD ERR for any other disc malfunction.

26

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

MACH姞 460 SATELLITE READY SOUND SYSTEM RADIO — CD CHANGER COMPATIBLE (IF EQUIPPED)

MACH姞 1000 SATELLITE READY SOUND SYSTEM RADIO — CD CHANGER COMPATIBLE (IF EQUIPPED)

Your vehicle may be equipped with the MACH 1000威 audio system. This system is equipped with a rack of amplifiers and subwoofers in the trunk of the vehicle. Do not store or rest items on the amplifier rack, as this could cause damage to the amplifiers and void your warranty. The MACH 1000威 audio system is capable of producing very high sound pressure levels. For your

27

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

listening comfort and protection, it is not recommended to listen to the MACH 1000威 audio system at high volume levels for extended periods of time. 1. Seek: Press and release SEEK for previous/next strong station, selection or track. 2. Rewind: In CD mode, press until desired selection is reached. Fast forward: In CD mode, press until desired selection is reached. TEXT: TEXT is only available when equipped with Satellite radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Ford dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer installed satellite kit not available in Canada. 3. DSP (Digital Signal Processing): Press DSP to access the Ambiance menu. Ambiance gives the feeling of “being there” to your music, creating increased clarity as well as an open and spacious feel to the music. Press SEL to engage/disengage. Turn the volume control to increase/decrease the level of ambiance. Occupancy: Press DSP again to change the occupancy mode to optimize sound for: • ALL SEATS — Enhances acoustic sound for all • DRIVER SEAT — Enhances acoustic sound for

seating locations.

the driver. Rear seat and passenger seat performance may be compromised in favor of the driver.

28

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems • REAR SEAT - Enhances acoustic sound for the

rear seat passengers. 4. MACH (MACH 1000
only): Press to engage MACH 1000 mode. MACH 1000 mode enhances acoustic sound for all seating locations and increases the signal to the trunk mounted speakers and amplifiers for enhanced bass performance. Press again to return to previously set occupancy mode. Mute: (MACH 460
only): Press to mute the playing media. 5. Eject: Press EJ and choose the corresponding preset (1–6) to eject the desired CD. Press and hold to eject all loaded discs. 6. Bass: Press BASS; then press SEL decrease/increase the bass output. Treble: Press TREB; then press SEL decrease/increase the treble output. 7. Select: Use with Bass, Treble, Balance and Fade controls to adjust levels. 8. Balance: Press BAL; then press SEL sound to the right/left speakers. Fade: Press FADE; then press SEL sound to the front/rear speakers.

to shift

to shift

to

to

29

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

9. Menu: Press MENU and SEL to access clock mode, RDS on/off, Traffic, Program type, Show type and Compression modes. Traffic: Allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station broadcasting a traffic report (if it is broadcasting RDS data).Traffic information is not available in most U.S. markets. FIND Program type: Allows you to search RDS-equipped stations for a certain category of music format: Classic, Country, Info, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40. Show TYPE: Displays the station’s call letters and format. Compression: Brings soft and loud CD passages together for a more consistent listening level. Setting the clock: Press MENU until SELECT HOUR or SELECT MINS is displayed. Use SEL to manually increase ( hours/minutes. Press MENU again to disengage clock mode. 10. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. In CD mode, press to access the desired disc. 11. SAT (if equipped): Your Audiophile radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your Ford dealer. Detailed satellite instructions are included with the dealer installed kit. Dealer installed satellite kit not available in Canada.

) or decrease (

) the

30

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

12. AM/FM: Press to select AM/FM frequency band. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press and momentarily hold AM/FM. AUTOSET will flash on the display. When the six strongest stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Press again to disengage. 13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels. Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7
is the maximum setting. Press and hold the volume control for five seconds. Then press SEL to increase ( ) or decrease ( the volume setting. The level will appear in the display. 14. Load: Press LOAD and the corresponding preset (1–6) to load a CD into the desired slot. Press and hold to load up to six discs at once. 15. CD AUX: Press to access CD or AUX mode. CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with

31

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information. 16. Scan: Press to move up the radio frequency band. SCAN automatically finds a station, plays it for five seconds seconds, then moves to the next station. Press again to stop. CD: Press to sample CD selections for eight seconds. Press again to stop. 17. Disc/Tune: Radio: Press manually tune down or up the radio frequency band. CD: Press to select the next disc. the previous disc or CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Ford dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer installed satellite kit not available in Canada. 18. CD door: Insert disc label side up. For information regarding SIRIUS Satellite Radio, please call toll-free 888-539-SIRIUS (888-539-7474) or visit the SIRIUS website at www.siriusradio.com

to select

or

to

32

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1600, 1610 kHz FM- 87.7, 87.9–107.7, 107.9 MHz

RADIO RECEPTION FACTORS There are three factors that can effect radio reception: • Distance/strength: The further you travel from an FM station, the weaker the signal and the weaker the reception.

• Terrain: Hills, mountains, tall buildings, power

lines, electric fences, traffic lights and thunderstorms can interfere with your reception.

• Station overload: When you pass a broadcast

tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.

playing surface.

CD PLAYER CARE All audios are CD changer compatible. See your dealer for further details. Do: • Handle discs by their edges only. Never touch the • Inspect discs before playing. Clean only with an approved CD cleaner and wipe from the center out. Don’t: • Expose discs to direct sunlight or heat sources for • Insert more than one disc into each slot of the CD • Clean using a circular motion.

extended periods of time.

changer magazine.

33

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Entertainment Systems

CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.

AUDIO SYSTEM WARRANTY AND SERVICE Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.

34

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls

Climate Controls

MANUAL HEATING AND AIR CONDITIONING SYSTEM 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Uses recirculated air through the instrument panel registers to cool the vehicle. This mode is more noisy than A/C, but is more economical and efficient. May reduce undesirable odors from entering the vehicle. A/C: Uses outside air to cool the vehicle. Air flows from the instrument panel register vents only.

: Distributes outside air through the instrument

panel vents. O (OFF): Outside air is shut out and the fan will not operate.

: Distributes outside air through the floor vents. : Distributes outside air through the windshield

defroster vents and floor vents.

: Distributes outside air through the windshield

defroster vents.

OPERATING TIPS • To reduce fog build up on the windshield during

humid weather, place the air flow selector in the

position.

• To reduce humidity build up inside the vehicle: during cold weather, do not drive with the air flow selector in the OFF or MAX A/C position. during warm weather, do not drive with the air flow selector in the OFF position.

35

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Climate Controls • Under normal weather conditions, do not leave

the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents.

• Do not put objects under the front seats that will interfere with the air flow to the back seats. • Remove any snow, ice or leaves from the air

intake area at the base of the windshield.

Do not place objects on top of the instrument panel as these objects may

become projectiles in a collision or sudden stop.

REAR WINDOW DEFROSTER Ensure that the ignition is in the ON position. Press the control to clear the rear window of thin ice and fog. The LED will illuminate. The defroster turns off automatically after 10
minutes or when the ignition is turned OFF. To manually turn off the defroster before 10 minutes, push the control again. Do not use razor blades or other sharp objects to clean the inside of the rear window or to remove decals from the inside of the rear window. This may cause damage to the heated grid lines and will not be covered by your warranty.

36

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Lights

HEADLAMP CONTROL • The first position

turns on the parking, tail, license plate and side marker lamps. • The outer position

turns on the headlamps.

Foglamp control (if equipped) The foglamps can be turned on when the ignition is in the ON position and the headlamp control is in either of the following positions: • Parking lamps • Low beams Press the foglamp control to activate the foglamps. Press the foglamp control again to deactivate the foglamps. When the highbeams are activated, the foglamps will not operate.

Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be turned on • the headlamp control is in the OFF or Parking • the high beam headlamps must be turned off • the parking brake is released

lamps position

37

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Lights

Always remember to turn on your headlamps at dusk or during inclement

weather. The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.

High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate.

Flash to pass Pull toward you slightly to activate and release to deactivate.

HI LO

OFF

HI LO

OFF

PANEL DIMMER CONTROL To adjust the brightness of the instrument panel: • Rotate

clockwise/counterclockwise when the headlamp control is in the parking lamp or low-beam position.

To turn on the courtesy lamps: • Rotate fully counterclockwise.

38

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Lights

AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician.

Headlamp vertical aim adjustment 1. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from a vertical wall or screen directly in front of it. • (1) Eight feet • (2) Center height of lamp to ground • (3) Twenty five feet • (4) Horizontal reference line

2. Measure the height from the center of your headlamp to the ground and mark a 2.4
meter (8 foot) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well). The center of the lamp is marked by a 3.0 mm circle on the headlamp lens. 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. 4. On the wall or screen you will observe a light pattern with flat edges at the top of the beam pattern. If the flat edges are not at the horizontal reference line, the beam will need to be adjusted.

39

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Lights

5. Locate the vertical adjuster on each headlamp, then use a 6
mm Allen wrench or screwdriver to adjust the headlamp up or down. 6. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 7. Close the hood and turn off the lamps.

TURN SIGNAL CONTROL • Push down to

activate the left turn signal. • Push up to activate the right turn signal.

HI LO

OFF

INTERIOR LAMPS

Map lamps (if equipped) For coupes the map lamps are located on the interior roof. Press the controls on either side of the lamp to turn the light on.

BULBS

Replacing exterior bulbs Check the operation of all the bulbs frequently.

Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized

40

2004 04- Mustang (mus) Owners Guide (post-2002-fmt) USA English (fus)

Lights

“D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.

3157 AK (amber)

Trade Number 3157K

Function Tail lamp, brakelamp, turn lamp Park lamp, turn lamp, side marker (front) Backup lamp License plate lamp High-mount brakelamp Headlamps Luggage compartment lamp Dome lamp Map lamp Visor vanity lamp Glove compartment Rearview mirror map lamps Fog lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer.
