2010 Toyota RAV4 Owners Manual

CUSTOMER EXPERIENCE CENTER

1-800-331-4331

RAV4

2 0 1 0

QUICK REFERENCE GUIDE

Printed in U.S.A. 8/09
08-TCS-03075

10%

Cert no. SGS-COC-005612

00505-QRG10-RAV4

2010
RAV4

This Quick Reference Guide is a summary of basic vehicle operations. It contains brief descriptions of fundamental operations so you can locate and use the vehicle’s main equipment quickly and easily.

The Quick Reference Guide is not intended as a substitute for the Owner’s Manual located in the vehicle’s glove box. We strongly encourage you to review the Owner’s Manual and supplementary manuals so you will have a better understanding of the vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new RAV4.

! A word about safe vehicle operations

This Quick Reference Guide is not a full description of RAV4
operations. Every RAV4 owner should review the Owner’s Manual that accompanies this vehicle.

Pay special attention to the boxed information highlighted in color throughout the Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction.

All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.

Luggage compartment Inside right side box

Jack

Spare tire (if equipped) & tools Tool location

Luggage compartment Inside left side box

Tool bag

Removing the spare tire

(1)

(2)

(1) To remove the spare tire cover,* open the back door. Unhook the latch on the bottom of the cover. Close the back door. Remove the spare tire cover by holding the bottom and lifting it up and away from the vehicle.

(2) To remove the spare tire, turn the wheel nuts counterclockwise with

the wheel nut wrench and remove.

Refer to the Owner’s Manual for tire changing and jack positioning procedures.

* If equipped

25

INDEX

OVERVIEW

FEATURES/OPERATIONS

Engine maintenance Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry* Smart Key system*

4-5
2-3

Active torque control 4WD (4WD models) Air Conditioning/Heating Audio Automatic Transmission Clock Cruise control Door locks Downhill Assist Control system (DAC) Hill-start Assist Control (HAC) Light control-Instrument panel Lights & turn signals Moonroof Parking brake Power outlets-12V DC Power outlets-120V AC Seat adjustments-Front Seat adjustments-Second row seats Seat heaters Seats-Head restraints Seats-Folding down second row seats Seats-Stowing third row seats Telephone controls (Bluetooth®) Tilt and telescopic steering wheel VSC OFF button Windows Windshield wipers & washers

11

18-19
20-21

10
19
23
16
22
23
19
14
16
10
22
22
12
12
18
11
13
13
17
17
16
15
15

SAFETY AND EMERGENCY FEATURES

24
Doors-Child safety locks 24
Seatbelts 24
Seatbelts-Shoulder belt anchor Spare tire & tools 25
Tire Pressure Monitoring (warning) System 24

* Visit your Toyota dealer for information on customizing this feature.

OVERVIEW

Instrument panel Steering wheel controls Without telephone controls

With telephone controls

Steering wheel audio controls1
Telephone controls1
Multi-information display switch Speech command button1
Cruise control Headlight, turn signal and front fog light1 control Wiper and washer controls Four-wheel drive lock switch (4WD models) Audio system/Navigation system1,2
Emergency flasher switch Air Conditioning controls “ENGINE START STOP” button (Smart Key)1
Engine immobilizer indicator Front passenger seatbelt reminder light Clock and Air Conditioning display

With manual Air Conditioning system

With automatic Air Conditioning system

Front passenger occupant classification indicator Rear window and outside rearview mirror defogger switch1
12V DC Power outlet Seat heater switch1
VSC OFF switch Ignition switch (standard key) Tilt and telescopic steering release Downhill Assist Control switch1
120V AC Power outlet ON/OFF switch1
Instrument panel light control

1 If equipped 2 Vehicles with navigation system: for details, refer to the “Navigation System Owner’s Manual.”

OVERVIEW

Instrument cluster

Tachometer Service indicator and reminder Speedometer Engine coolant temperature Fuel gauge Odometer, two trip meters and trip information display Odometer/trip meter switch and trip meter reset button

Indicator symbols

Brake system warning1

Driver/Front passenger seatbelt reminder (alarm will sound if speed is over 12 mph)

Charging system warning1

Low engine oil pressure warning1

Malfunction/Check Engine indicator1

Low fuel level warning

Engine oil replacement reminder1

Open door warning

1 If indicator does not turn off within a few seconds of starting engine, there may be a

malfunction. Have vehicle inspected by your Toyota dealer.

2 For details, refer to “Four-wheel drive lock switch,” Section 2-4, 2010 Owner’s Manual.

Airbag SRS warning1

Automatic Transmission fluid temperature warning1

Low Tire Pressure Warning1

4WD warning1

Electric power steering system warning1

Low windshield washer fluid level warning

Front passenger occupant classification indicator1

Headlight low/high beam indicator

Turn signal indicator

Front fog light indicator

Automatic Transmission indicator (4-speed)

Automatic Transmission indicator (5-speed)

Four-wheel drive lock indicator1,2

Vehicle Stability Control OFF indicator1
Slip indicator/Hill-start Assist Control indicator/Downhill Assist Control indicator1
AUTO Limited Slip Differential indicator1

Downhill Assist Control indicator1

Cruise control indicator3

Anti-lock Brake System warning1

Smart Key system warning

Traction Control OFF indicator1

3 If this light flashes, refer to “Cruise control,” Section 2-4, 2010 Owner’s Manual.

OVERVIEW

Keyless entry Beep sound can be switched ON or OFF. Refer to the Owner’s Manual for more details. Locking operation

Without Smart Key system

With Smart Key system

Unlocking operation

Without Smart Key system

With Smart Key system

Push

Push ONCE: Driver door

TWICE: All doors

NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. Panic button

Push and hold

Smart Key system* (if equipped) Start function

Green indicator ON

Carrying

Depress brake pedal

Push

NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from: ACCESSORY

Accessories such as the radio will operate.

ON

Power ON; the engine not running.

All systems OFF.

OFF Locking operation

Front door lock

Unlocking operation

Front door unlock*

Grasp

Push

Carry remote to lock/unlock Back door lock/unlock

Carry remote to lock/unlock

Push

Carry remote to lock/unlock * Driver door unlocking function can be programmed to unlock driver door only, or all doors. Grasping passenger door handle will unlock all doors.

Grasp

NOTE: Doors may also be locked/unlocked using remote.

OVERVIEW

Fuel tank door release and cap

Driver seat

Turn

Pull up

Store

NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “

” indicator may illuminate.

Hood release

Pull

Pull up latch and raise hood

Engage support rod

Engine maintenance 4 cylinder (2AR-FE) engine

6 cylinder (2GR-FE) engine

Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Windshield and back window washer fluid tank

NOTE: Regularly scheduled maintenance, including oil changes, will

help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”

FEATURES/OPERATIONS

Automatic Transmission 4-speed models

5-speed models

Park*

Reverse

Neutral

Drive

Third gear

Second gear

First gear

Park* Reverse Neutral Drive Fourth gear

Third gear Second gear

First gear

* The engine/“ENGINE START STOP” switch must be “ON” and the brake

pedal depressed to shift from Park.

Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D” position.

Parking brake Set

Release

Pull

(2) Push

(1) Pull slightly

(3) Lower

10

Active torque control 4WD Auto lock functions (4WD models) Four-wheel drive lock switch

Push the switch to ensure that the engine torque is applied to the four wheels. NOTE: Should ONLY be used when wheel spinning occurs on loose or unpaved surfaces. Refer to the Owner’s Manual for more details.

Seats-Head restraints Front seats

Second row seats

Lock release button

Lock release button

Third row seats (if equipped)

Lock release button

11

FEATURES/OPERATIONS

Seat adjustments-Front Manual seat

Power seat

Seat position (forward/backward) Height crank (driver side only) Seatback angle Driver seat: seat position, cushion angle and height Passenger seat: seat position only Seatback angle Lumbar support

Seat adjustments-Second row seats Vehicles with third row seats

Vehicles without third row seats

Seat position (forward/backward) Seatback angle Seatback lock release

12

Seats-Folding down second row seats From inside

(2) Lower

(1) Push

(3) Pull down

From outside (vehicles without third row seats)

Seats-Stowing third row seats (if equipped)

(2) Lower

(4) Fold down

(1) Push

(3) Pull

(6) Lift up

(5) Pull up

(8) Push to lock in

(7) Push down

(9) Push to lock in

13

FEATURES/OPERATIONS

Lights & turn signals Headlights

Auto (if equipped) Headlights Parking lights

Low beam

High beam

High beam flasher

-Daytime Running Light system (DRL) (if equipped) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Will automatically turn lights off after a delay of 30 seconds.

Turn signals

Right turn

Lane change

Lane change

Left turn

Front fog lights (if equipped)

Turn

Front fog lights come on only when the headlights are on low beam.

14

Windshield wipers & washers Front

Adjust frequency*

Single wipe

Pull to wash and wipe

Interval wipe

Slow

Fast

* Intermittent windshield wiper frequency adjustment

Rotate to increase/decrease wipe frequency.

Rear

Wash and wipe Wipe Interval wipe

Wash and wipe

Windows lock switch

Windows Driver side

Up

Down

Automatic operation (driver side only) Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction. Window lock switch Deactivates all passenger windows. Driver’s window remains operable. NOTE: If the battery is disconnected, the window needs to be reinitialized. Refer to the Owner’s Manual for more details.

15

FEATURES/OPERATIONS

Moonroof (if equipped) Sliding operation

Push once to open partway; again to open completely.

Tilting operation

Open

Close

Close

Tilt

Recommended driving position to minimize wind noise

NOTE: If battery is disconnected, the moonroof needs to be reinitialized. Refer to the Owner’s Manual for more details.

Door locks

Unlock

Lock

VSC OFF button

VSC OFF button

The VSC OFF button is used to switch between modes related to the TRAC, VSC and Auto LSD functions (2WD models.)

Refer to Section 2-4 of the Owner’s Manual for more information.

16

Telephone controls (Bluetooth®) (if equipped) Audio unit

Microphone

Steering wheel telephone switches

End call

Volume

Voice command button

Start call

Bluetooth® technology allows dialing or receipt of calls without taking hands from the steering wheel or using a cable to connect the compatible telephone and the system. Refer to “Using the hands-free phone system (for cellular phone),” Section 3-3 in the Owner’s Manual for more details, or go to Toyota.com and enter “Bluetooth” in the keyword search. Tilt and telescopic steering wheel

Lock release lever

Angle

Length

Hold wheel, push lever down, set angle and length, and return lever.

NOTE: Do not attempt to adjust while the vehicle is in motion.

17

FEATURES/OPERATIONS

Seat heaters (if equipped)

Air Conditioning/Heating Automatic Air Conditioning

Left front seat

Right front seat

” mode, use fresh air (“

” indicator OFF) to reduce window

” mode uses fresh air only.

Temperature selector (driver side) Fresh or recirculated cabin air Airflow vent In “ fogging. “ Air Conditioning ON/OFF “DUAL” button Indicator ON: Separate temperature settings for driver and passenger. Indicator OFF: Synchronize temperature settings for driver and passenger. Temperature selector (front passenger side) Micro dust and pollen filter ON/OFF Rear defogger Fan speed Climate control OFF Automatic climate control ON Adjust the temperature setting, and airflow vents and fan will adjust automatically.

18

Manual Air Conditioning

” indicator “OFF”) to

” mode uses fresh air only (“

Airflow vent “ ” or “ reduce window fogging. Fan speed Temperature selector Air Conditioning ON/OFF Select for maximum cooling. Air intake will automatically be set to recirculate. Rear defogger Fresh or recirculated cabin air

Clock Manual Air Conditioning system

Automatic Air Conditioning system

H- Hour set M- Minute set :00- Round off minutes

Light control-Instrument panel

Brightness control

With the dial turned fully up, instrument panel lights will not dim when the headlights are turned ON.

19

FEATURES/OPERATIONS

Audio Type 1

Push to turn ON/OFF

Eject CD

Seek station/ CD track select

Preset buttons - functions in other modes indicated above number.

Station/CD track scan

Mode

View CD text

Type 2 additional functions

AM/Satellite radio

Type 2 (with JBL speakers)

Push to adjust tone & balance

Push to skip up/down folder

Load CD(s)

View genre/Push to skip up/down folder

CD PLAYER To scan tracks on a disc Push “SCAN.” Push again to hold selection. CD Changer (Type 2) -To load one disc Push “LOAD” and insert one disc. -To load multiple discs Push and hold “LOAD” until you hear a beep. Insert one disc. Wait until the green indicator illuminates and shutter opens to insert next disc. To select a file (MP3/WMA only) Turn “TUNE.FILE.” To select a folder (MP3/WMA only) Push either side of “TYPE/FOLDER.”

20

RADIO To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push “SCAN.” Push and hold to scan preset stations. Push again to hold selection. Steering wheel controls (if equipped)

Volume control

“MODE” Push to turn audio ON and select an audio mode. Push and hold to turn the audio OFF. ” “ >> Use to search within the selected audio medium (radio, CD, iPod, etc.).

AUX audio jack

By inserting a mini plug into the AUX audio jack, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode.

21

FEATURES/OPERATIONS

Power outlets-12V DC Instrument panel

Inside center console

Luggage compartment

NOTE: Designed for car accessories. Engine switch/“ENGINE START STOP” switch must be in the “ACC” or “ON” position to be used. Power outlets-120V AC (if equipped)

ON/OFF switch

Push

Rear console

NOTE: Engine switch/“ENGINE START STOP” switch must be in the “ON” position to be used. Downhill Assist Control system (DAC)

DAC helps the vehicle to descend steep hills while maintaining a low speed without brake pedal operation. Press the “DAC” button (indicator will blink). Shift into L or R to activate (indicator will be solid). Pressing the button again will turn system off. Refer to the Owner’s Manual for more details.

22

Hill-start Assist Control (HAC) (if equipped)

Brake pedal

HAC helps prevent rolling backwards on an incline. To engage, push further down on brake pedal while at a complete stop until a beep sounds and slip indicator illuminates. HAC holds for approximately 2 seconds after releasing brake pedal. Refer to the Owner’s Manual for more details.

Cruise control Turning system ON/OFF

Functions

Cancel1

System ON/OFF

Resume2/Increase speed

Set/Decrease speed

1 The set speed may also be cancelled by depressing the brake pedal. 2 The set speed may be resumed once vehicle speed exceeds 25 mph. Refer to the Owner’s Manual for more details.

23

SAFETY AND EMERGENCY FEATURES

Doors-Child safety locks Rear door

Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seatbelts

Take up slack

Too high

Keep as low on hips as possible

If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely.

To find more information about seatbelts, and how to install a child restraint system, refer to the Owner’s Manual. Seatbelts-Shoulder belt anchor Up

Down

Push up or squeeze lock release to lower

Tire Pressure Monitoring (warning) System If tire pressure becomes critically low on any of the tires (including the spare), “ turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details.

” indicator will come on. Correctly adjusting tire inflation will

24

Abbreviation list Abbreviation/Acronym list

ABBREVIATIONS MEANING

2WD 4WD A/C ABS ACC ALR

AUTO LSD

AVG CRS DAC DISP ECU EDR ELR EPS GAWR GVWR

I/M

LATCH LED MMT M+S MTBE OBD RFT SRS TIN

498

2 Wheel Drive 4 Wheel Drive Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Automatic Limited Slip Differential Average Child Restraint System Downhill Assist Control Display Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Gross Axle Weight Rating Gross Vehicle Weight Rating Emission Inspection and Maintenance Lower Anchors and Tethers for Children Light Emitting Diode Methylcyclopentadienyl Manganese Tricarbonyl Mud and Snow Methyl Tertiary Butyl Ether On Board Diagnostics Run-Flat Tire Supplemental Restraint System Tire Identification Number

Abbreviation list

ABBREVIATIONS MEANING

TPMS TRAC VIN VSC

Tire Pressure Warning System Traction control Vehicle Identification Number Vehicle Stability Control

499

For your information

Main Owner’s Manual

Please note that this manual covers all models and all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.

Noise from under vehicle after turning off the engine

Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and it does not indicate a malfunction.

Accessories, spare parts and modification of your Toyota

A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Modification with non-genuine Toyota products may affect performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.

18

Installation of a mobile two-way radio system

As the installation of a mobile two-way radio system in your vehicle may affect electronic systems such as the multi-port fuel injection system/sequen- tial multi-port fuel injection system, cruise control system, anti-lock brake system, SRS airbag system or seat belt pretensioner system, be sure to check with your Toyota dealer for precautionary measures or special instruc- tions regarding installation.

Scrapping of your Toyota

The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.

Perchlorate Material

Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.

19

CAUTION

■General precautions while driving

Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.

■General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

20

Symbols used throughout this manual

Cautions & Notices

CAUTION

This is a warning against anything which may cause death or injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.

NOTICE

This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.

Symbols used in illustrations

Safety symbol The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.

Arrows indicating operations

Indicates the action (pushing, turning, etc.) used to operate switches and other devices. Indicates the outcome of an operation (e.g. a lid opens).

21

22

TABLE OF CONTENTS

1 Before driving

Adjusting and operating features such as door locks, mirrors, and steering column.

2 When driving

Driving, stopping and safe-driving information.

3 Interior features

Air conditioning and audio systems, as well as other interior features for a comfortable driving experience.

4 Maintenance

and care

Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information.

5 When trouble

arises

What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident.

6 Vehicle

specifications

Detailed vehicle information.

7 For owners

Reporting safety defects for U.S. owners and seat belt instructions for Canadian owners

Index

Alphabetical listing of information contained in this manual.

Pictorial index

Exterior

Headlights (high beam) P. 165

Hood P. 346

Headlights (low beam) P. 165

Moon roof ∗ P. 84

Outside rear view mirrors P. 79

Turn signal lights ∗ P. 153

Front turn signal/parking and front

side marker lights P. 153, 165

Front fog lights ∗ P. 168

Windshield wipers P. 169

With spare tire

Spare tire P. 430

Roof luggage carrier ∗ P. 198

Side doors P. 42

License plate light P. 165

Rear window defogger P. 233

Rear window wiper P. 171

Back door P. 46

License plate lights P. 165

Rear turn signal lights P. 153
∗: If equipped

Fuel filler door P. 88

Tires ●Rotation ●Replacement ●Inflation pressure ●Information

P. 365
P. 430
P. 472
P. 477

Stop/tail and rear side marker lights P. 165

Pictorial index

Interior

Seat belts P. 68

Power window switches P. 81

Bottle holders P. 309

Head restraints P. 65

SRS driver airbag P. 98

SRS front passenger airbag P. 98

Cup holders P. 308

Rear seats P. 54

Console box P. 306

Front seats P. 49

Glove box

P. 305

Floor mat P. 322

SRS side airbags ∗ P. 98

A

Vanity mirrors P. 313

Sun visors P. 312

Overhead console P. 307

Moon roof switches ∗ P. 84

SRS curtain shield airbags ∗ P. 98

Interior light P. 302

Coat hooks P. 321

Personal/interior lights P. 301

Rear view monitor system ∗ P. 175

Anti-glare inside rear view mirror P. 77

∗: If equipped

Pictorial index

Interior

Door lock switch P. 43

Inside door lock buttons P. 43

Window lock switch P. 81

Power window switches P. 81

10

C

Parking brake lever

P. 154

Cup holders P. 308

Shift lever P. 150

AUX adapter

P. 262

Outside rear view mirror switches P. 79

11

Pictorial index

Instrument panel

Horn P. 155

Gauges and meters P. 156

Four-wheel drive lock switch ∗ P. 192

Headlight switch Turn signal lever Fog light switch ∗

P. 165
P. 153
P. 168

Audio system P. 236
Navigation system *

Emergency flasher switch P. 406

Fuel filler door opener

P. 88

Hood release lever P. 346

Windshield wiper and washer switch Rear window wiper and washer switch

P. 169

P. 171

Tilt and telescopic steering lock release lever P. 76

12

A

Instrument panel light control dial P. 157

“DAC” switch ∗ P. 189

Power outlet main switch ∗ P. 315

∗: If equipped *: Refer to “Navigation System Owner’s Manual”.

13

Pictorial index

Instrument panel

Without hands-free phone system

Audio remote control switches ∗,* P. 263

“DISP” switch P. 163

Engine (ignition) switch (without smart key system) P. 147

With hands-free phone system

Cruise control switch P. 172

Audio remote control switches P. 263

Telephone switch P. 271

“DISP” switch P. 163

Engine (ignition) switch (without smart key system) P. 147

Talk switch P. 271

Cruise control switch P. 172

14

C

With a manual air conditioning system

Air conditioning system P. 220

Security indicator P. 92

Rear window defogger switch Outside rear view mirror defogger switch ∗

P. 233

P. 233

With an automatic air conditioning system

Engine (ignition) switch (with smart key system) P. 143

Security indicator P. 92

Air conditioning system P. 225

Rear window and outside rear view mirror defogger switch P. 233

∗: If equipped *: Refer to “Navigation System Owner’s Manual”.

15

Pictorial index

Instrument panel

Seat heater switch ∗ P. 318

Windshield wiper de-icer switch ∗ P. 235

Enhanced VSC OFF switch P. 183

Power outlet P. 315

Cup holders P. 308

16

Pictorial index

Luggage compartment

Luggage cover ∗ P. 325

Second seatback release lever ∗ P. 57

Grocery bag hooks

P. 323

Storage boxes ∗ P. 323

Cargo hooks P. 323

Power outlet P. 315

∗: If equipped

17

1-1. Key information Keys

The following keys are provided with the vehicle.

Vehicles without smart key system

Master keys Operating the wireless remote control function (→P. 38) Valet key Key number plate

Vehicles with smart key system

Electronic keys • Operating

system (→P. 26)

the smart key

• Operating

the wireless

remote control function (→P. 38)

Mechanical keys Key number plate

Using the mechanical key (vehicles with smart key system)

Take out the mechanical key.

After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (→P. 451)

24

1

1-1. Key information

■When required to leave a key to the vehicle with a parking attendant

Lock the glove box as circumstances demand. (→P. 305) Vehicles without smart key system: Carry the master key for your own use and leave the valet key only with the attendant. Vehicles with smart key system: Remove the mechanical key for your own use and provide the attendant with the electronic key only.

■Key number plate

Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 450)

■When riding in an aircraft

When bringing a key with wireless remote control function onto an aircraft, make sure you do not press any buttons on the key while inside the aircraft cabin. If you are carrying the key in your bag etc, ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the key to emit radio waves that could interfere with the operation of the aircraft.

NOTICE

■To prevent key damage

●Do not subject the keys to strong shocks, expose them to high tempera-

tures by placing them in direct sunlight, or get them wet.

●Do not expose the keys to electromagnetic materials or attach any mate-

rial that blocks electromagnetic waves to the key surface.

●Do not disassemble the key.

25

1-2. Opening, closing and locking the doors
