1996 Toyota Corolla Owners Manual

matic transmission system

Fuses (type B) 29. POWER 30 A: Power windows, pow- er door lock system, electric sun roof 30. DEF 30 A: Rear window defogger 31. HEATER 40 A: Air conditioning sys- tem 32. AM 2 30 A: Starting system and “IGN” fuse 33. FAN 30 A: Electric cooling fan and “FAN-I/UP” fuse 34. CDS 30 A: Electric cooling fan

14. FAN-I/UP 7.5 A: Multiport fuel injec- tion system/sequential multiport fuel in- jection system 15. SPARE 7.5 A: Spare fuse 16. SPARE 15 A: Spare fuse 17. SPARE 20 A: Spare fuse 18. HEAD (RH) 15 A: Right-hand head- light 19. HEAD (LH) 15 A: Left-hand headlight 20. ALT-S 7.5 A: Charging system 21. EFI, F-HTR 15 A: Multiport fuel injec- tion system/sequential multiport fuel in- jection system, electronically controlled automatic transmission system 22. DRL 7.5 A: Daytime running light sys- tem

186

Fuses (type C) 35. AM1 40 A: “CIG & RADIO”, “GAUGE”, “TURN”, “ECU-IG”, “WIP”, “DEF” and “OBD” fuses 36. ALT 100 A: Tail lights, “DEF”, “STOP”, “ECU-B” and “AM 1” fuses 37. ABS 50 A: Anti-lock brake system

187

188

Part 9
REPORTING SAFETY DEFECTS FOR U.S. OWNERS AND UNIFORM TIRE QUALITY GRADING

(cid:1) Reporting safety defects for

U.S. owners

(cid:1) Uniform tire quality grading

Reporting safety defects for U.S. owners If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the Na- tional Highway Traffic Safety Admin- istration (NHTSA) in addition to noti- fying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar com- plaints, it may open an investigation, and if it finds that a safety defect ex- ists in a group of vehicles, it may or- der a recall and remedy campaign. However, NHTSA cannot become in- volved in individual problems be- tween you, your dealer, or Toyota Motor Sales, U.S.A., Inc. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123
in Washington D.C. area) or write to: NHTSA. U.S. Department of Transportation. Washington D.C. 20590. You can also obtain other in- formation about motor vehicle safe- ty from the Hotline.

Uniform tire quality grading

This consumer information has been pre- pared in accordance with regulations is- sued by the National Highway Traffic Safety Administration of the U.S. Depart- ment of Transportation. It provides the purchasers and/or prospective purchas- ers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades—All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades. These quality grades are molded on the sidewall. Treadwear—The treadwear grade is a comparative rating based on the wear rate of the tire when tested under con- trolled conditions on a specified govern- ment test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices and differences in road characteristics and climate.

189

Warning: The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive load- ing, either separately or in combination, can cause heat buildup and possible tire failure.

Traction A, B, C—The traction grades, from highest to lowest, are A, B, and C, and they represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified govern- ment test surfaces of asphalt and con- crete. A tire marked C may have poor trac- tion performance. Warning: The traction grade assigned to this tire is based on braking (straight ahead) traction tests and does not include cornering (turning) traction. Temperature A, B, C—The temperature grades are A (the highest), B, and C, rep- resenting the tire’s resistance to the gen- eration of heat and its ability to dissipate heat when tested under controlled condi- tions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degener- ate and reduce tire life, and excessive temperature can lead to sudden tire fail- ure. The grade C corresponds to a level of performance which all passenger car tires must meet under the Federal Motor Ve- hicle Safety Standard No. 109. Grades B and A represent higher levels of perfor- mance on the laboratory test wheel than the minimum required by law.

190
