2004 Toyota Avalon Owners Manual

’04 AVALON U (L/O 0408)

SECTION 1− 1

OPERATION OF INSTRUMENTS AND CONTROLS Overview of instruments and controls Instrument panel overview Instrument cluster overview Indicator symbols on the instrument panel

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Instrument panel overview "With bucket front seat (view A)

1. Side vents 2. Side defroster outlets 3. Instrument cluster and/or multi−information display

4. Garage door opener 5. Center vents 6. Auxiliary boxes 7. Front personal light, interior light and/or

electric moon roof switch 8. Power door lock switches 9. Power window switches 10. Glove box 11. Trunk opener main switch 12. Rear vents 13. Power outlet (115 VAC) 14. Power outlet (12 VDC) 15. Cup holder 16. Automatic transmission selector lever 17. Hood lock release lever 18. Parking brake pedal 19. Window lock switch

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"With bucket front seat (view B with manual air conditioning controls)

1. Power rear view mirror control switches 2. Headlight, turn signal and front fog

light switches

3. Wiper and washer switches 4. Emergency flasher switch 5. Car audio 6. Air conditioning controls 7. Rear window and outside rear view

mirror defogger switch

8. Cigarette lighter and ashtray 9. Ignition switch 10. Power outlet main switch 11. Traction control system off switch 12. Cruise control switch 13. Tilt steering lock release lever 14. Trunk lid lock release switch 15. Instrument panel light control knob

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"With bucket front seat (view B with automatic air conditioning controls)

1. Power rear view mirror control switches 2. Headlight, turn signal and front fog

light switches

3. Wiper and washer switches 4. Emergency flasher switch 5. Car audio 6. Air conditioning controls 7. Rear window and outside rear view

mirror defogger switch

8. Cigarette lighter and ashtray 9. Seat heater switches 10. Ignition switch 11. Power outlet main switch 12. Traction control system off switch 13. Cruise control switch 14. Tilt steering lock release lever 15. Trunk lid lock release switch 16. Instrument panel light control knob

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"With bench type front seat (view A)

1. Side vents 2. Side defroster outlets 3. Instrument cluster and/or multi−information display

4. Automatic transmission selector lever 5. Garage door opener 6. Center vents 7. Auxiliary boxes 8. Front personal light, interior light and/or

electric moon roof switch 9. Power door lock switches 10. Power window switches 11. Glove box 12. Cup holder 13. Trunk opener main switch 14. Hood lock release lever 15. Parking brake pedal 16. Window lock switch

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"With bench type front seat (view B with manual air conditioning controls)

1. Power rear view mirror control switches 2. Headlight and turn signal switch and

front fog light switch

3. Wiper and washer switches 4. Emergency flasher switch 5. Car audio 6. Air conditioning controls 7. Rear window and outside rear view

mirror defogger switch

8. Cigarette lighter and ashtray 9. Power outlet (115 VAC) 10. Power outlet (12 VDC) 11. Ignition switch 12. Power outlet main switch 13. Traction control system off switch 14. Cruise control switch 15. Tilt steering lock release lever 16. Trunk lid lock release switch 17. Instrument panel light control knob

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"With bench type front seat (view B with automatic air conditioning controls)

1. Power rear view mirror control switches 2. Headlight and turn signal switch and

front fog light switch

3. Wiper and washer switches 4. Emergency flasher switch 5. Car audio 6. Air conditioning controls 7. Rear window and outside rear view

mirror defogger switch

8. Seat heater switches 9. Cigarette lighter and ashtray 10. Power outlet (115 VAC) 11. Power outlet (12 VDC) 12. Ignition switch 13. Power outlet main switch 14. Traction control system off switch 15. Cruise control switch 16. Tilt steering lock release lever 17. Trunk lid lock release switch 18. Instrument panel light control knob

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Instrument cluster overview "Type A

1. Engine coolant temperature gauge 2. Tachometer 3. Service reminder indicators and

indicator lights

5. Engine immobilizer system indicator

light

6. Odometer and two trip meters 7. Clock 8. Outside temperature display

4. Speedometer ∗: This button is used to adjust the clock. For details, see “Clock” in Section 1−10.

9. “ADJ” button∗ 10. “MODE” button∗ 11. “ODO/TRIP” button 12. Fuel gauge

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"Type B

1. Engine coolant temperature gauge 2. Tachometer 3. Service reminder indicators and

indicator lights

4. Speedometer 5. Theft deterrent system/engine

immobilizer system indicator light

6. Clock∗ 7. Outside temperature display∗ 8. Multi−information display 9. “LIGHT” button∗ 10. “MODE” button∗

11. “RESET/ADJ” button∗ 12. “DISPLAY” button∗ 13. Odometer and two trip meters 14. “ODO/TRIP” button 15. Fuel gauge

∗: This button is used to operate the multi−information display. For details, see “Multi−information display” in Section 1−10.

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

"Type C

1. Engine coolant temperature gauge 2. Tachometer 3. Service reminder indicators and

indicator lights

6. Clock∗ 7. Outside temperature display∗ 4. Speedometer 8. Odometer and two trip meters ∗: For details, please refer to the separate “Navigation system Owner’s manual”.

5. Theft deterrent system/engine

immobilizer system indicator light

10

9. “ODO/TRIP” button 10. Fuel gauge

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Indicator symbols on the instrument panel

or

Brake system warning light∗1

or

Anti−lock brake system warning light∗1

Driver’s seat belt reminder light∗1

Open door warning light∗1

Front outside passenger’s seat belt reminder light∗1

Rear light failure warning light∗1

Discharge warning light∗1

SRS warning light∗1

Low engine oil pressure warning light∗1

Malfunction indicator lamp∗1

Low fuel level warning light∗1

Vehicle stability control system and traction control system warning light∗1

Low windshield washer fluid level warning light∗1

Headlight high beam indicator light

11

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Turn signal indicator lights

Automatic transmission indicator lights

Overdrive−off indicator light

Slip indicator light

Traction control system off indicator light

Cruise control indicator light∗2

∗1: For details, see “Service reminder indicators and warning

buzzers” in Section 1−6.

∗2: If this light flashes, see “Cruise control” in Section 1−7.

12

2004 AVALON from Aug. ’04 Prod. (OM41412U)

188

’04 AVALON U (L/O 0408)

SECTION 1− 10

OPERATION OF INSTRUMENTS AND CONTROLS Other equipment Multi−information display Clock Outside temperature display Cigarette lighter and ashtray Power outlet Glove box Garage door opener Auxiliary box Front cup holder Rear cup holder Floor mat

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

189
198
198
198
199
202
202
205
207
208
210

2004 AVALON from Aug. ’04 Prod. (OM41412U)

Multi−information display—

’04 AVALON U (L/O 0408)

1. Outside temperature display 2. Clock 3. Compass 4. Calendar 5. Cruise information display 6. “LIGHT” button 7. “MODE” button 8. “RESET/ADJ” button 9. “DISPLAY” button

189

2004 AVALON from Aug. ’04 Prod. (OM41412U)

is

the

turned

ignition switch

the multi−information display

—Before using the multi−information display Operate with the ignition switch on. to When “ON”, the last previously used mode dis- played just before the ignition switch is turned off will appear. If the electrical power source has been disconnected the multi−information display, the display will automatically be set to the initial mode. When lights are turned on, the brightness of the display will be reduced.

instrument panel

from

the

190

’04 AVALON U (L/O 0408)

“LIGHT” button This button is used to select the illumi- nation pattern of the display. Every time you push the “LIGHT” button, the display illuminates in the following or- der. 1. All the parts of the display are illumi-

nated.

2. Clock, outside temperature display and

compass are illuminated.

3. Illumination is off. “MODE” and “RESET/ADJ” buttons These buttons are used to select the item to be reset or adjusted. Every time you push the “MODE” button, the display toggles in the following order. 1. Hour 2. Minute 3. Year 4. Month 5. Day 6. English or metric unit selection of the outside temperature display and cruise information display

7. Compass deviation calibration (zone) 8. Compass circling calibration

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

—Clock

—Calendar

When the item desired to be corrected appears, reset or adjust it by pushing the “RESET/ADJ” button. “DISPLAY” button This button is used to toggle the func- tions of the cruise information display. Every time you push the “DISPLAY” but- ton, the display toggles. For more information display”.

“—Cruise

details,

see

CAUTION

Do not adjust the display while the vehicle is moving. Be sure to adjust the display only when the vehicle is stopped.

The digital clock indicates the time. If the electrical power source has been disconnected, the time display will auto- matically be set to 1:00 a.m. To reset the hour: Push the “MODE” but- ton until the hour display appears and blinks. Then push the “RESET/ADJ” but- ton. To reset the minutes: Push the “MODE” button until the minute display appears and blinks. Then push the “RESET/ADJ” button. After resetting the clock, push the “MODE” button until the display returns to normal calendar mode.

The digital calendar indicates the date. If the electrical power source has been disconnected, the calendar display will au- tomatically be set to “THU JAN 1”. To reset the year: Push the “MODE” but- ton until the year display appears and blinks. Then push the “RESET/ADJ” but- ton. (After the number returns to 2002.) To reset the “MODE” button until the month display appears and blinks. Then push the “RESET/ADJ” but- ton. To reset the day: Push the “MODE” button until the day display appears and blinks. Then push the “RESET/ADJ” button.

the year 2021 appears,

the month: Push

191

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

—Outside temperature display

—Cruise information display

resetting

After the “MODE” button until the display returns to normal calendar mode.

the calendar, push

indi-

The outside temperature display cates outside air temperatures. To set the unit, push the “MODE” button until the unit display appears and blinks. Then push the “RESET/ADJ” button to se- lect “_C” or “_F”. (At time, cruise information and air conditioning displays also change.) After setting the unit, push the “MODE” button until the display returns to normal calendar mode.

this

192

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

1. Instantaneous fuel consumption

(“INST ECON”)

The instantaneous fuel consumption is calculated and displayed based on driv- ing distance and fuel consumption for 2 seconds with the engine running. The displayed value is updated every 2
seconds. Note that an accurate figure may not be shown in the following cases. D When the vehicle is stopped with the engine running, the display will indicate the extremely high fuel consumption.

D When

the vehicle

is driving down a long slope, applying the engine brake, the display will indicate the extremely low fuel consumption.

The calculation is reset when the ignition switch is turned off.

The cruise information display indicates the following information. 1. Instantaneous fuel consumption 2. Average fuel consumption after refuel-

ing

3. Average vehicle speed 4. Driving range 5. Driving time Every time you push the “DISPLAY” but- ton, the display toggles through this infor- mation. The displayed values in the cruise infor- mation display indicate general driving conditions. Accuracy varies with driving habits and road conditions. If the electrical power source has been disconnected, the display will automatically be set to instantaneous fuel consumption. To set the unit, push the “MODE” button until the unit display appears and blinks. Then push the “RESET/ADJ” button to se- lect km/liter or mile/gallon. (At this time, the outside temperature and air condition- ing displays also change.) After setting the unit, push the “MODE” button until the display returns to normal calendar mode.

2. Average fuel consumption after re-

fueling (“AVG ECON”)

Average fuel consumption after refuel- ing is calculated and displayed based on total driving distance and total fuel consumption with the engine running. The displayed value is updated every 10
seconds. Every time you refuel the vehicle, the av- erage refueling (“AVG ECON”) calculation is automatically reset. 3. Average vehicle speed

fuel consumption after

(“AVG SPEED”)

Average vehicle speed is calculated and displayed based on total driving dis- tance and total driving time with the engine running. The displayed value is updated every 10
seconds. To “RESET/ADJ” button. The calculation is reset when the ignition switch is turned off.

calculations, push

reset

the

the

193

2004 AVALON from Aug. ’04 Prod. (OM41412U)

4. Driving range

(“FUEL RANGE”)

fuel

The distance the vehicle can travel with the remaining is calculated and displayed based on the quantity of re- maining fuel and past fuel consumption. The displayed value is updated every time when the fuel equivalent for 1 km is con- sumed. Every the driving range calculation is automatically reset. The actual driving range varies with driv- ing habits and road conditions. If fuel con- sumption is good, the driving range will be longer. If fuel consumption is poor, the driving range will be shorter. 5. Driving time

time you refuel

the vehicle,

(“TRIP TIME”)

The elapsed time after the engine starts is displayed. When the engine is started, driving time is counted from 0:00. Up to 99:59 (99
hours, 59 minutes) can be displayed. When the driving time exceeds 99:59, the counter returns to 0:00.

194

’04 AVALON U (L/O 0408)

—Compass

the

reset

calculations, push

To “RESET/ADJ” button. The calculation is reset when the ignition switch is turned off.

the

indicates

the vehicle

the direction The compass that the above case, it shows that the vehicle is heading south.

is heading.

In

Displays

NE SE SW NW

Directions

North

Northeast

East

Southeast

South

Southwest

West

Northwest

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

the

from

CALIBRATING THE COMPASS (deviation calibration) the compass The direction display on deviates true direction deter- mined by the earth’s magnetic field. The angle of deviation varies according to the geographic position of the vehicle. To adjust for this deviation, stop the ve- hicle and push the “MODE” button several times until “ZONE XX” appears on the calendar display. Then push the “RESET/ ADJ” button, referring to the following map to select the number of the zone where the vehicle is.

The compass may not show the correct direction in the following conditions: D The vehicle is stopped immediately af-

ter turning. The compass does not adjust while the vehicle is stopped.

D The ignition switch is turned off imme-

diately after turning.

D The vehicle is on an inclined surface. D The vehicle is in a place where the earth’s magnetic field is subject to in- terference by artificial magnetic fields (underground parking, under a steel tower, between buildings, roof parking, near a crossing, near a large vehicle, etc.).

D The vehicle is magnetized. (There is a magnet or a metal object on or near the roof.)

is small,

the deviation

D The battery has been disconnected. If the compass works to calibrate the direction automati- cally while the vehicle is in motion. For additional precision or see calibrating, COMPASS” below.

for complete THE

“CALIBRATING

Compass sensor

NOTICE

Do not put magnets or a metal object on or near the roof of the vehicle. Doing this may cause malfunction of the compass sensor.

195

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Hawaii, Samoa: 5
Guam, Saipan: 8

After calibration, push the “MODE” button several the calendar display returns to the normal mode.

times until

CAUTION

Do not adjust the display while the vehicle is moving. Be sure to adjust the display only when the vehicle is stopped.

Zone number

196

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Drive the vehicle in a circle until the blink- ing stops. If there is not enough space to drive in a circle, drive around the block until the blinking stops. When the compass and the calendar dis- play return to normal mode, calibration is complete. If you want to cancel the calibration be- fore it is complete, push the “MODE” but- ton again.

Perform circling calibration just after you have purchased your Toyota. And then always perform circling calibration after the battery has been removed, re- placed or disconnected. D Do not perform circling calibration of the compass the earth’s magnetic field is subject to in- terference by artificial magnetic fields (underground parking, under a steel tower, between buildings, roof parking, near a crossing, near a large vehicle, etc.).

in a place where

D During calibration, do not operate elec- tric systems (moon roof, power win- dows, etc.) as they may interfere with the calibration.

CAUTION

D When doing the circling calibration, be sure to secure a wide space, and watch out for people and ve- hicles in the neighborhood. Do not violate any local traffic rules while performing circling calibration.

D Do not adjust the display while the vehicle is moving. Be sure to adjust the display only when the vehicle is stopped.

197

2004 AVALON from Aug. ’04 Prod. (OM41412U)

the direction display on

CALIBRATING THE COMPASS (circling calibration) Sometimes the compass may not change after a turn. To rectify this, stop the vehicle and push the until “MODE” “COMPASS” appears and blinks on the display. Then push the “RESET/ADJ” but- ton. “CALIBRATE” appears and blinks to- gether with the compass display.

several

button

times

’04 AVALON U (L/O 0408)

Clock

Outside temperature display

Cigarette lighter and ashtray

the

instrument panel

The key must be in the “ON” position. When lights are turned on, the brightness of the display will be reduced. To change the display between “_C” to “_F”, push the “MODE” button until the display blinks. Then push the “ADJ” button to select “_C” or “_F”.

To reset the hour: Push the “MODE” but- ton until the hour display blinks. Then push the “ADJ” button. To reset the minutes: Push the “MODE” button until the minute display blinks. Then push the “ADJ” button. The key must be in the “ON” position. If the electrical power source has been disconnected from the clock, the time dis- play will automatically be set to 1:00 (one o’clock). When lights are turned on, the brightness of the time in- dication will be reduced.

instrument panel

the

198

With bucket front seat

With bench type front seat

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Power outlet (12 VDC)

CAUTION

To reduce the chance of in case of an accident or sudden stop while driving, always completely close the ashtray after use.

injury

With bucket front seat

CIGARETTE LIGHTER To use the cigarette lighter, first open the ashtray lid, then press in the light- er. After it finishes heating up, it auto- matically pops out ready for use. If the engine is not running, the key must be in the “ACC” position. Do not hold the cigarette lighter pressed in. Use a Toyota genuine cigarette lighter or equivalent for replacement. ASHTRAY With bucket front seat—To use the ash- tray, push the lid to open. With bench type front seat—To use the ashtray, pull the lid to open. When finished with your cigarette, thor- oughly extinguish it in the ashtray to pre- vent other cigarette butts from catching fire. After using the ashtray, push it back in completely. To remove the ashtray, open the ashtray lid and pull it out.

With bench type front seat

199

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Power outlet (115 VAC)

The power outlet is designed for power supply for car accessories. The key must be in the “ACC” or “ON” position for the power outlet to be used.

NOTICE

the

fuse

z To prevent

from being blown, do not use the electricity over the total vehicle capacity of 12
VDC/120W.

z To prevent the battery from being discharged, do not use the power outlet longer than necessary when the engine is not running.

z Close the power outlet lid when the power outlet is not in use. Inserting anything other than an appropriate plug that fits the outlet, or allowing any liquid to get into the outlet may cause electrical failure or short cir- cuits.

With bucket front seat

200

With bench type front seat

This power outlet is designed for use as a power supply for electric ap- pliances in the vehicle. The key must be in the “ON” position for the power outlet to be used. The maximum capacity for this power out- let is 115 VAC/100W. If you attempt to use an appliance that requires more than 115 VAC or 100W, the protection circuit will activate and cut the power supply. The power supply will restart automatically when you use an appliance that operates within the 115 VAC/100W limits.

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

D Appliances with high initial peak watt- age: cathode−ray tube type televisions, compressor−driven refrigerators, electric pumps, electric tools, etc.

D Measuring devices which process pre- cise data: medical equipment, measur- ing instruments, etc.

D Other appliances requiring an extremely stable power supply: microcomputer− controlled electric blankets, touch sen- sor lamps, etc.

Certain electrical appliances may cause radio noise.

NOTICE

z To prevent the battery from being discharged, do not use the power outlet longer than necessary when the engine is not running.

z Close the power outlet lid when the power outlet is not in use. Inserting anything other than an appropriate plug that fits the outlet, or allowing any liquid to get into the outlet may cause electrical failure or short cir- cuits.

The power outlet is not designed for the following electric appliances even though their power consumption is un- der 115 VAC/100W. These appliances may not operate properly.

201

2004 AVALON from Aug. ’04 Prod. (OM41412U)

To use the power outlet, push the main switch on the instrument panel. An indicator light will illuminate to indicate that the power outlet is ready for use. Push the main switch once again to turn the power outlet off. When the power out- let is not in use, make sure that the main switch is turned off.

’04 AVALON U (L/O 0408)

Glove box

Garage door opener

The garage door opener ( Universal Transceiver) is manufactured under license from HomeLinkR and can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, etc.

To use the glove box, do this. To open: Pull the lever. With the instrument panel lights on, the glove box light will come on when the glove box is open. To lock: Insert the master key and turn it clockwise.

CAUTION

To reduce the chance of in case of an accident or a sudden stop, always keep the glove box door closed while driving.

injury

202

transmitter prior

(a) Programming the HomeLinkR The HomeLinkR in your vehicle has 3
buttons and you can store one program for each button. To ensure correct programming into the HomeLinkR, install a new battery in the hand−held to program- ming. The battery side of the hand−held trans- mitter must be pointed away the HomeLinkR during the programming pro- cess. For Canadian users, follow the procedure “Programming an entrance gate/Pro- in gramming all devices the Canadian market”. 1. Decide which of 3 HomeLinkR buttons

from

in

you want to program.

2. Place your hand−held garage transmit- ter 25 to 75 mm (1 to 3 in.) away from the surface of the HomeLinkR.

Keep the indicator light on the HomeLinkR in view while programming.

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

3. Simultaneously press and hold

the hand−held garage transmitter button along with the selected HomeLinkR but- ton.

4. When

the

indicator

the HomeLinkR changes from a slow to a rapid flash after 20 seconds, you can release both buttons.

light on

5. Test the operation of the HomeLinkR by pressing the newly programmed button. If programming a garage door opener, check to see if the garage door opens and closes.

(on

light

indicator

If the garage door does not operate, iden- tify if your garage transmitter is of the “Rolling Code” type. Press and hold the programmed HomeLinkR button. The ga- rage door has the rolling code feature if the HomeLinkR) the flashes rapidly and then remains lit after 2 seconds. If your garage transmitter is the “Rolling Code” type, proceed to the heading “Programming a rolling code sys- tem”. 6. Repeat steps 2 through 5 for each re- maining HomeLinkR button to program another device.

it

is

to

is necessary

Programming a rolling code system “Rolling Code” If your device follow equipped, steps 1 through 4 under the heading “Programming the HomeLinkR” before proceeding with the steps listed below. 1. Locate the “training” button on the ceil- ing mounted garage door opener motor. The exact the button may vary by brand of garage door opener. Refer the owner’s guide supplied by the garage door opener manufacturer for the location of this “training” button.

location and color of

to

2. Press the “training” button on the ceil- ing mounted garage door opener motor. Following this step, you have 30 seconds in which to initiate step 3 below. 3. Press and release the vehicle’s pro- grammed HomeLinkR button twice. The garage door may open. the door does open, the programming process is complete. If the door does not open, press and release the button a third time. This third press and release will complete the programming process by opening the garage door.

If

now

should

recognize

The ceiling mounted garage door opener motor the HomeLinkR unit and be able activate the garage door up/down. 4. Repeat steps 1 through 3 for each re- maining HomeLinkR button to program another rolling code system.

Programming an entrance gate/Program- ming all devices in the Canadian market 1. Decide which of the 3 HomeLinkR but-

2. Place

your

tons you want to program. hand−held

gate/device transmitter 25 to 75 mm (1 to 3 in.) away the from HomeLinkR.

surface

the

of

Keep the indicator light on the HomeLinkR in view while programming. 3. Press

selected

hold

and

the

HomeLinkR button.

4. Continuously press and release (cycle) transmitter the hand−held gate/device button every two seconds until step 5
is complete. the

the HomeLinkR changes from a slow to a rapid flash after 20 seconds, you can release both buttons.

light on

5. When

indicator

203

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

(c) Erasing

the

entire HomeLinkR

memory (all three programs)

To erase all previously programmed codes at one time, press and hold down the 2
outside buttons for 20 seconds until the indicator light flashes. If you sell your vehicle, be sure to erase the HomeLinkR the programs stored memory.

in

6. Test the operation of the HomeLinkR by pressing the newly programmed button. Check to see if the gate/device oper- ates correctly.

7. Repeat steps 1 through 6 for each re- maining HomeLinkR button to program another device.

Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button Individual HomeLinkR buttons cannot be erased, however, to reprogram a single button, follow the procedure “Programming the HomeLinkR”. (b) Operating the HomeLinkR To operate the appropriate HomeLinkR button to activate the programmed device. The HomeLinkR indicator light should come on. The HomeLinkR continues to send the signal for up the button is pressed.

the HomeLinkR, press

to 20 seconds as

long as

204

CAUTION

D When programming the HomeLinkR Universal Transceiver, you may be operating a garage door or other device. Make sure people and ob- jects are out of the way of the ga- rage door or other device to pre- vent potential harm or damage.

D Do not use this HomeLinkR Univer- sal Transceiver with any garage door opener that lacks the safety stop and reverse feature as re- quired by federal safety standards. (This includes any garage door opener model manufactured before April 1, 1982.) A garage door open- er which cannot detect an object (signaling the door to stop and re- verse), does not meet current feder- al safety standards. Using a garage door opener without these features increases risk of serious injury or death.

2004 AVALON from Aug. ’04 Prod. (OM41412U)

that may be received,

This device complies with FCC Rules Part 15. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interfer- ence including interference that may cause undersired operation. WARNING: This transmitter has been tested and complies with FCC and DOC/MPAC rules. Changes or modifi- cations not expressly approved by the party compliance could void the user’s authority to op- erate the device.

responsible

for

’04 AVALON U (L/O 0408)

Auxiliary box (type A)

NOTICE

During hot weather, the interior of the vehicle becomes very hot. Do not leave anything flammable or deform- able such as a lighter, glasses, etc. inside.

To use the box, push the lid to open.

CAUTION

To reduce the chance of in case of an accident or a sudden stop, always keep the auxiliary box closed while driving.

injury

205

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Auxiliary box (type B)

Auxiliary box (type C)

Auxiliary box (type D)

To use the box, pull on the handle.

CAUTION

To reduce the chance of in case of an accident or a sudden stop, always keep the auxiliary box closed while driving.

injury

To use the box, pull down the armrest, pull up the lock release lever and open the lid.

To use the box, pull up the lock release lever and open the lid.

CAUTION

To reduce the chance of in case of an accident or a sudden stop, always keep the auxiliary box closed while driving.

injury

CAUTION

To reduce the chance of in case of an accident or a sudden stop, always keep the auxiliary box closed while driving.

injury

206

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Front cup holder (type A)

To maximize the storage room, remove the cup holder by pushing the side fac- ing at its upright position.

The cup holder is designed for holding cups or drink−cans securely. To use the cup holder, push on the lid.

CAUTION

D Do not place anything else other than cups or drink−cans on the cup items may be holder, as such thrown about in the compartment and possibly injure people in the vehicle during sudden braking or in an accident.

D To reduce the chance of injury in case of an accident or sudden stop while driving, keep the cup holder closed when it is not in use.

207

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Front cup holder (type B)

Rear cup holder (type A)

CAUTION

D Do not place anything else other than cups or drink−cans in the cup items may be holder, as such thrown about in the compartment and possibly injure people in the vehicle during sudden braking or in an accident.

D To reduce the chance of injury in case of an accident or sudden stop while driving, keep the cup holder closed when it is not in use.

D Do not lift the armrest upright when

the cup holder is pulled out.

The cup holder is designed for holding cups or drink−cans securely. To use the cup holder, pull down the arm- rest.

2004 AVALON from Aug. ’04 Prod. (OM41412U)

The cup holder is designed for holding cups or drink−cans securely. To use the cup holder, pull down the arm- rest, pull up the lock release lever and open the lid.

208

CAUTION

D Do not place anything else other than cups or drink−cans in the cup items may be holder, as such thrown about in the compartment and possibly injure people in the vehicle during sudden braking or in an accident.

D To reduce the chance of injury in case of an accident or sudden stop while driving, keep the cup holder closed when it is not in use.

D Do not lift the armrest upright when

the cup holder is pulled out.

’04 AVALON U (L/O 0408)

Rear cup holder (type B)

The cup holder is designed for holding cups or drink−cans securely. To use the cup holder, open the armrest lid by pulling up the lock release lever and pull out the cup holder. Then close the armrest lid.

CAUTION

D Do not leave the armrest lid open, especially when the cup holder holds a scalding hot drink. If the lid is forcibly pulled up, the drink may spill over the seat occupants.

D When the cup holder is in use, the armrest lid must be securely closed with the lock engaged.

D Do not place anything else other than cups or drink−cans in the cup items may be holder, as such thrown about in the compartment and possibly injure people in the vehicle during sudden braking or in an accident.

209

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Floor mat

D To reduce the chance of injury in case of an accident or sudden stop while driving, keep the cup holder closed when it is not in use.

D Do not lift the armrest upright when

the cup holder is pulled out.

Use a floor mat of the correct size. If the floor carpet and floor mat have a hole, then it is designed for use with a locking clip. Fix the floor mat with locking clip into the hole in the floor carpet.

CAUTION

Make sure the floor mat is properly placed on the floor carpet. If the floor mat slips and the movement of the pedals during driv- ing, it may cause an accident.

interferes with

210

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

211

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

SECTION 1− 2

OPERATION OF INSTRUMENTS AND CONTROLS Keys and Doors Keys Engine immobilizer system Side doors Power windows Trunk lid Hood Theft deterrent system Fuel tank cap Electric moon roof

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

14
17
18
27
29
34
35
37
38

13

2004 AVALON from Aug. ’04 Prod. (OM41412U)

’04 AVALON U (L/O 0408)

Keys (without engine immobilizer system)

Keys (with engine immobilizer system)

Your vehicle is supplied with two kinds of keys. 1. Master key—This key works in every

lock.

2. Sub key—This key will not work in the glove box, trunk and armrest door in the rear seat.

To protect items locked in the trunk or glove box when using valet parking, leave the sub key with the attendant. Since lid can be locked without a key, you should always carry a spare master key in case you accidentally lock your keys inside the ve- hicle.

the doors and

trunk

14

KEY NUMBER PLATE Your key number is shown on the plate. Keep the plate in a safe place such as your wallet, not in the vehicle. If you should lose your keys or if you need additional keys, duplicates can be made by a Toyota dealer using the key number. We recommend writing down the key num- ber and storing it in a safe place.

Your vehicle is supplied with two kinds of keys. 1. Master keys (black)—These keys work in every lock. Your Toyota dealer will need one of them to make a new key with a built−in transponder chip.

2. Sub key (gray)—This key will not work trunk and armrest

the glove box,

in door in the rear seat.
