CUSTOMER EXPERIENCE CENTER


1-800-331-4331


AVALON


2 0 1 0


QUICK REFERENCE GUIDE


Printed in U.S.A. 7/09
08-TCS-03068


10%


Cert no. SGS-COC-005612


00505-QRG10-AVA


2010
Avalon


Trunk-Internal release


This Quick Reference Guide is a summary of basic vehicle operations. It contains brief descriptions of fundamental operations so you can locate and use the vehicle’s main equipment quickly and easily.


The Quick Reference Guide is not intended as a substitute for the Owner’s Manual located in your vehicle’s glove box. We strongly encourage you to review the Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations.


Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Avalon.


! A word about safe vehicle operations


This Quick Reference Guide is not a full description of Avalon operations. Every Avalon owner should review the Owner’s Manual that accompanies this vehicle. Pay special attention to the boxed information highlighted in color throughout the Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.


Pull


Luggage floor cover


Wheel nut wrench


Jack


(3)


Spare tire & tools Tool location


Spare tire cover


Jack handle


Spare tire


Removing the spare tire (1) (2)


(1) Remove the luggage cover. (2) Loosen and remove the center fastener. (3) Remove the spare tire cover. Refer to the Owner’s Manual for tire changing and jack positioning procedures.


25


INDEX


OVERVIEW


FEATURES/OPERATIONS


Engine maintenance Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry1
Light control-Instrument panel Smart Key system2
Trunk release


Air Conditioning/Heating Audio Auto lock functions2
Automatic Transmission Center display Clock Cruise control Cup holders Door locks Dynamic Laser Cruise Control Garage door opener (HomeLink®)3
Lights1 & turn signals Moonroof Parking brake Power outlets Seat adjustments-Front Seat adjustments-Rear Seat ventilators/Heaters Seats-Head restraints Steering lock release Steering wheel switches Sunshade-Rear1
Telephone controls (Bluetooth®) Tilt and telescopic steering wheel Windows-Power Windshield wipers & washers1


4-5
2-3


20
18
10
10
19
22
16
22
21
17
16
13
14
11
22
12
12
21
11
10
19
14
15
11
14
12


SAFETY AND EMERGENCY FEATURES


Doors-Child safety locks 23
Seatbelt comfort guide 24
Seatbelts 23
Seatbelts-Shoulder belt anchor 23
Spare tire & tools 25
Tire Pressure Monitoring (warning) System 24
Trunk-Internal release 25


1 Visit your Toyota dealer for information on customizing this feature. 2 Programmable by customer. Refer to the Owner’s Manual for instructions and more information. 3 HomeLink® is a registered trademark of Johnson Controls, Inc.


OVERVIEW


Instrument panel Steering wheel controls


Steering wheel audio controls Telephone controls1
Steering wheel climate controls Voice command button1,2
Distance button1
Driving position memory switches1
Headlight, turn signal and front fog light1 controls Ignition switch (standard key)1
Wiper and washer controls “ENGINE START STOP” button (Smart Key)1
Clock Center display1/Navigation system1,2
Emergency flasher button “AIR BAG ON” and “AIR BAG OFF” indicator and front passenger seatbelt reminder lights Air Conditioning controls


O


Trunk opener main switch Audio system Storage compartment1/Navigation system switches1,2
Outside rearview mirror1/Rear window defogger button Cruise control Tilt lock release lever Tire Pressure Monitoring (warning) System reset Telescopic lock release Power rearview mirror control Glass breakage sensor1
Rear sunshade switch1
Trunk opener Fuel filler door opener


1 If equipped 2 For vehicles with a navigation system, refer to the “Navigation System


Owner’s Manual.”


OVERVIEW


Instrument cluster


Engine coolant temperature Service indicator and reminder Tachometer Speedometer Fuel gauge Odometer/Trip meter and trip meter reset button Odometer/Trip meter display Automatic Transmission shift range display Automatic Transmission shift position indicator Dynamic laser cruise control display


Indicator symbols For details, refer to “Indicators and warning lights,” Section 2-2, 2010
Owner’s Manual.


Brake system warning1
Driver seatbelt reminder (alarm will sound if speed is over 9 mph) Front passenger seatbelt reminder (alarm will sound if speed is over 9 mph) Charging system warning1
Front passenger occupant classification indicator/ Front passenger airbag ON/OFF indicator1


Low engine oil pressure warning1


1 If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer.


Malfunction/Check Engine indicator1


Engine oil replacement reminder1


Low fuel level warning


Open door warning


Airbag SRS warning1


Tire Pressure Warning1


Low windshield washer fluid level warning1


Security indicator


Headlight low/high beam indicator


Turn signal indicator


Automatic headlight leveling system warning1


Slip indicator


Vehicle Stability Control system warning1


Cruise control indicator2


Ready mode indicator1


Conventional cruise


Dynamic Laser Cruise Control master warning light1


Anti-lock Brake System warning1


Smart Key system warning1


2 If this light flashes, refer to “Cruise control,” Section 2-4, 2010 Owner’s Manual.


OVERVIEW


Keyless entry Locking operation


Without Smart Key system


With Smart Key system


Unlocking operation


Without Smart Key system


With Smart Key system


Push


Push ONCE: Driver door


TWICE: All doors


NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. Trunk lid operation


Without Smart Key system


With Smart Key system


Panic button


Push and hold


Push and hold


Smart Key system (if equipped) Start function


Green indicator ON


Carrying


Depress brake pedal


Push


NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from:


ACC


ON


Accessories such as the radio will operate.


Power ON; the engine not running.


All systems OFF.


OFF Locking operation


Unlocking operation


Front door lock


Front door unlock*


Push


Grasp


Carry remote to lock/unlock


Carry remote to lock/unlock Trunk access Opening trunk


Carry remote to lock/unlock


Push


* Driver door unlocking function can be programmed to unlock driver door only, or all doors. Grasping passenger door handle will unlock all doors.


NOTE: Doors may also be locked/unlocked using remote.


OVERVIEW


Fuel tank door release and cap


Turn


Push


Store


NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ indicator may illuminate.



Light control-Instrument panel


Brightness control


Trunk release Trunk opener


Main switch


Push


ON


OFF


Hood release


Pull


Engine maintenance


Pull up latch and raise hood


Engine coolant reservoir Power steering fluid reservoir Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank


NOTE: Regularly scheduled maintenance, including oil changes, will


help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”


FEATURES/OPERATIONS


Auto lock functions Automatic door locks can be programmed to operate in two different modes, or turned OFF. 1. Doors lock: when shifting from Park.


Doors unlock: when shifting into Park.


2. Doors lock: when the vehicle speed goes above 12 mph.


Doors unlock: when the driver’s door is opened within 10 seconds after turning the “ENGINE START STOP” switch or the engine switch OFF.


Refer to the Owner’s Manual for more details.


Automatic Transmission


“D”


Park* Reverse Neutral Drive “S” mode


“S”


* The “ENGINE START STOP” switch/engine must be “ON” and the brake


pedal depressed to shift from Park. “S” (Sequential) mode Shift the shift lever to “S” position from “D” position.


Floor shift type:


+: Upshift (push and release) -: Downshift (pull and release)


Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D” position.


Steering lock release Smart Key system


Turn


Without Smart Key system


Turn


Turn


Push


10


Tilt and telescopic steering wheel


Angle


Length


Lock release lever


Lock release lever


Hold wheel, push lever down, set angle and length, and return lever. NOTE: Do not attempt to adjust while the vehicle is in motion.


Parking brake


Seats-Head restraints


Set: Depress Release: Depress again


Lock release button


11


FEATURES/OPERATIONS


Seat adjustments-Front Manual seat


Power seat


Seatback angle Seat position (forward/backward) Leg support (if equipped) Lumbar support (if equipped) Position, cushion angle (if equipped) and height (if equipped)


Seat adjustments-Rear


Seatback angle lever


Refer to the Owner’s Manual for more details.


Windshield wipers & washers With interval wiper


Adjust frequency*


Single wipe


With AUTO rain-sensing wiper


Adjust sensor sensitivity


Single wipe


Interval wipe Slow


Pull to wash and wipe * Intermittent windshield wiper frequency adjustment


Pull to wash and wipe


Rotate to increase/decrease wipe frequency.


Fast


12


Auto wipe


Slow


Fast


Lights & turn signals Headlights


Headlights Parking lights


Auto DRL OFF


Low beam


High beam


High beam flasher


-Daytime Running Light system (DRL) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Automatically turns lights off after a delay of 30 seconds, or the lock switch on remote may be pushed after locking.


Front fog lights (if equipped)


Turn


Front fog lights come on only when the headlights are on low beam.


Turn signals


Right turn


Lane change


Lane change


Left turn


13


FEATURES/OPERATIONS


Windows-Power Driver side


Up


Down


Window lock switch


Automatic operation Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction. Window lock switch Deactivates all passenger windows. Driver’s window remains operable.


NOTE: If battery is disconnected, the window needs to be reinitialized. Refer to the Owner’s Manual for more details.


Moonroof (if equipped) Sliding operation


Tilting operation


Push once to open partway; again to open completely.


Open


Close


Recommended driving position to minimize wind noise.


Close


Tilt


NOTE: If battery is disconnected, the moonroof needs to be reinitialized. Refer to the Owner’s Manual for more details.


Sunshade-Rear (if equipped)


When shifting to reverse, sunshade retracts automatically, and then rises again when driving forward.


Push


14


Telephone controls (Bluetooth®) (if equipped)


Audio unit


Steering wheel telephone switches


Microphone


Volume


End call Start call


Voice command button


Bluetooth® technology allows dialing or receipt of calls without taking hands from the steering wheel or using a cable to connect the compatible telephone and the system. Refer to “Hands-free system (for cellular phone),” Section 3-3 in the Owner’s Manual for more details, or go to Toyota.com and enter “Bluetooth” in the keyword search.


15


FEATURES/OPERATIONS


Garage door opener (HomeLink®)* (if equipped)


Garage door openers manufactured under license from HomeLink®* can be programmed to operate garage doors, estate gates, security lighting, etc.


Refer to “Garage door opener,” Section 3-6 in the Owner’s Manual for more details. For programming assistance, contact HomeLink® at 1-800-355-3515, or visit http://www.homelink.com.


* HomeLink® is a registered trademark of Johnson Controls, Inc.


Cruise control Turning system ON/OFF


System ON/OFF


Resume2


Increase speed


Functions


Cancel1


Set


Decrease speed


1 The set speed may also be cancelled by depressing the brake pedal. 2 The set speed may be resumed once vehicle speed exceeds 25 mph.


16


Dynamic Laser Cruise Control (if equipped) Refer to the Owner’s Manual for more details and complete safety precautions before attempting to use “Dynamic Laser Cruise Control.” Fixed speed mode


(1) To select conventional/fixed speed control Push the ON-OFF button. Push the lever forward and hold until the “NORM.” indicator appears.


(2) To set, cancel and resume a speed Refer to instructions for Cruise


Control on the previous page.


Distance control mode


Distance control mode will cruise at a set speed, decelerate to maintain selected distance from a slower vehicle traveling in front of you, and accelerate back up to the selected speed if the vehicle in front of you changes lanes or speeds up. (1) To select distance control mode Push the ON-OFF button. The


“READY” and “CRUISE” indicator will come on.


(2) To set, cancel and resume a speed Refer to instructions for Cruise


Control on the previous page.


NOTE: Once vehicle speed is set, pushing lever up toward “+ RES” will increase speed to the nearest 5 mph, and then in 5 mph increments. Pushing lever down toward “- SET” will reduce speed in the same way.


LONG


MIDDLE


SHORT


(3) To change the vehicle-to-vehicle distance


Push the distance button to cycle through the settings, which will change progressively from LONG to MIDDLE to SHORT.


17


Load CD(s)


Push to adjust tone & balance


FEATURES/OPERATIONS


Audio


Eject CD


Seek station/ CD track select


Preset buttons - functions in other modes indicated above number


Push to skip up/down folder and radio category type


Push to turn ON/OFF


Select CD


Mode


Station/CD track scan


View CD text


AM/Satellite Radio


CD PLAYER To scan tracks on a disc Push “SCAN.” Push again to hold selection. CD changer -To load one disc Push “LOAD” and insert one disc. -To load multiple discs Push and hold “LOAD” until you hear a beep. Insert one disc. Shutter will close and then re-open for next disc. To select a CD Push “DISC ” or “DISC .” To select a file (MP3/WMA only) Turn “TUNE.FILE.” To select a folder (MP3/WMA only) Push either side of “FOLDER.” RADIO To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push and hold “SCAN” to scan preset stations. Push again to hold selection. AUX audio jack


By inserting a mini plug into the AUX audio jack, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode.


18


Steering wheel switches


Audio control


Climate control


Volume control


Temperature selector Auto A/C ON System OFF



v v “ Use to search within the selected audio medium (radio, CD, iPod, etc.). “MODE” Push to turn audio ON and select an audio mode. Push and hold to turn audio system OFF.


Center display Without navigation system


Audio display Air Conditioning display Outside temperature Trip information display Pattern selector knob Display item can be switched by pushing the knob: (1) Entire display (2) Audio display and Air Conditioning display (3) OFF


With navigation system Refer to the “Navigation System Owner’s Manual.”


19


FEATURES/OPERATIONS


Air Conditioning/Heating


Without navigation system


With navigation system


Display


Control


” mode, use fresh air (“


Temperature selector (driver side) Temperature selector (passenger side) Climate control OFF Air Conditioning ON/OFF Fresh or recirculated cabin air Automatic climate control ON Outside rearview mirror*/Rear defogger Airflow vent In “ window fogging. Fan speed “DUAL” button Indicator ON: Separate temperature settings for driver and passenger. Indicator OFF: Synchronize temperature settings for driver and passenger. Windshield defogger * If equipped


” indicator OFF) to reduce


20


Seat ventilators/Heaters (if equipped)


With ventilator


Push


Turn


OFF


Heater


Heater only


Ventilator


Push


Turn


Push knob to pop the controller out. Turn clockwise for heater, counter-clockwise for ventilator.


Door locks


Lock


Unlock


21


FEATURES/OPERATIONS


Power outlets Auxiliary box


Console box


The “ENGINE START STOP” switch/engine switch must be in the “ACC” or “ON” position to be used.


Cup holders Front


Rear (type A)


Rear (type B)


Clock Without navigation system


H-Hour set M-Minute set :00-Round off minutes


With navigation system Refer to the “Navigation System Owner’s Manual.”


22


SAFETY AND EMERGENCY FEATURES


Doors-Child safety locks Rear door


Moving the lever to “LOCK” will allow the door to be opened only from the outside.


Seatbelts


Take up slack


Too high


Keep as low on hips as possible


If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely.


To find more information about seatbelts, and how to install a child restraint system, refer to the Owner's Manual.


Seatbelts-Shoulder belt anchor


Push up, or squeeze lock release to lower


23


SAFETY AND EMERGENCY FEATURES


Seatbelt comfort guide


Rear seat outside position guides provide added comfort for children who have outgrown child restraints.


Tire Pressure Monitoring (warning) System


System reset initialization 1. Push and hold “


until the indicator blinks three times.


SET” button


2. Wait a few minutes to allow


initialization to complete.


SET” button until indicator blinks three times. Let the vehicle sit for a


After adjusting tire pressures, or after tires have been rotated or replaced, turn the ignition switch to “ON” and press and hold the “ few minutes to allow initialization to complete. Refer to the load label on the door jamb or the Owner’s Manual for tire inflation specifications. If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. NOTE: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light.


24


TABLE OF CONTENTS


Index


1 Before driving


1-1. Key information


Keys ..................................... 22


1-2. Opening, closing and locking


the doors and trunk Smart key system................. 24
Wireless remote control ....... 36
Doors.................................... 40
Trunk .................................... 46


1-3. Adjustable components (seats, steering wheel, mirrors) Front seats ........................... 50
Rear seats............................ 53
Driving position memory system................................ 55
Head restraints..................... 59
Seat belts ............................. 61
Steering wheel ..................... 68
Inside rear view mirror.......... 70
Outside rear view mirrors ..... 72


1-4. Opening and closing the windows and moon roof Power windows .................... 74
Moon roof ............................. 77


1-5. Refueling


Opening the fuel tank cap ..................................... 80


1-6. Theft deterrent system


Engine immobilizer system ................................ 83
Alarm .................................... 85
Theft prevention labels (U.S.A.)............................... 87


1-7. Safety information


Correct driving posture ......... 88
SRS airbags ......................... 90
Front passenger occupant classification system......... 103
Child restraint systems ....... 109
Installing child restraints ..... 113


2 When driving


2-1. Driving procedures


Driving the vehicle .............. 124
Engine (ignition) switch (with smart key system)............................. 133
Engine (ignition) switch (without smart key system)............................. 137
Automatic transmission ...... 140
Turn signal lever ................. 145
Parking brake ..................... 146
Horn.................................... 147


2-2.


Instrument cluster Gauges and meters ............ 148
Indicators and warning lights ................................. 151
Center display..................... 154


AVALON_U (OM41437U)


2-3. Operating the lights and


windshield wipers Headlight switch.................. 156
Fog light switch ................... 159
Windshield wipers and washer .............................. 160


2-4. Using other driving systems


Cruise control...................... 165
Dynamic laser cruise control............................... 168
Driving assist systems ........ 181


2-5. Driving information


Cargo and luggage ............. 184
Vehicle load limits ............... 188
Winter driving tips ............... 189
Trailer towing ...................... 194
Dinghy towing ..................... 195


3 Interior features


3-1. Using the air conditioning


system and defogger Automatic air conditioning system .............................. 198
Using the steering wheel climate control switches............................ 206
Rear window and outside rear view mirror defoggers.......................... 208


3-2. Using the audio system


Audio system type.............. 210
Audio cover ........................ 212
Using the radio ................... 213
Using the CD player ........... 220
Playing MP3 and WMA discs ....................... 228
Optimal use of the audio system.............................. 236
Using the AUX adapter....... 238
Using the steering wheel audio switches.................. 239


3-3. Using the hands-free system


(for cellular phone) Hands-free system (for cellular phone) ........... 242
Using the hands-free system.............................. 246
Making a phone call ........... 254
Setting a cellular phone...... 259
Security and system setup ................................ 264
Using the phone book ........ 267


3-4. Using the interior lights


Interior lights list ................. 275


3-5. Using the storage features


List of storage features....... 278


AVALON_U (OM41437U)


TABLE OF CONTENTS


Index


3-6. Other interior features


4-3. Do-it-yourself maintenance


Sun visors .......................... 286
Vanity mirrors ..................... 287
Clock .................................. 288
Outside temperature display.............................. 289
Ashtrays ............................. 290
Power outlets ..................... 291
Seat heaters/ventilators ..... 293
Armrest............................... 295
Rear sunshade................... 296
Floor mats .......................... 298
Trunk features .................... 299
Garage door opener........... 301
Compass ............................ 306


4 Maintenance and care


4-1. Maintenance and care


Cleaning and protecting the vehicle exterior................. 312
Cleaning and protecting the vehicle interior.................. 315


4-2. Maintenance Maintenance requirements .................... 318
General maintenance......... 320
Emission inspection and maintenance (I/M) programs.......................... 323


Do-it-yourself service precautions....................... 324
Hood ................................... 327
Positioning a floor jack........ 328
Engine compartment .......... 330
Tires.................................... 345
Tire inflation pressure ......... 354
Wheels................................ 358
Air conditioning filter ........... 360
Key battery ......................... 363
Checking and replacing fuses................................. 367
Headlight aim (with discharge headlights)........................ 376
Light bulbs .......................... 378


5 When trouble arises


5-1. Essential information


Emergency flashers............ 384
If your vehicle needs to be towed................................ 385
If you think something is wrong................................ 389
Fuel pump shut off system .............................. 390
Event data recorder ............ 391


AVALON_U (OM41437U)


5-2. Steps to take in an emergency


If a warning light turns on or a warning buzzer sounds... ........................... 393
If you have a flat tire............ 405
If the engine will not start................................... 414
If the shift lever cannot be shifted from P.................... 416
If you lose your keys ........... 417
If the electronic key does not operate properly (with smart key system)....................... 418
If the vehicle battery is discharged ........................ 420
If your vehicle overheats..... 424
If the vehicle becomes stuck ................................. 427


6 Vehicle specifications


6-1. Specifications


Maintenance data (fuel, oil level, etc.)............ 430
Fuel information .................. 439
Tire information................... 442


6-2. Customization


Customizable features ........ 454


6-3.


Initialization Items to initialize ................. 458


7 For owners


Reporting safety defects for U.S. owners ................ 460
Seat belt instructions for Canadian owners (in French)........................ 461


Index


Abbreviation list ................ 466


Alphabetical index............. 467


What to do if....................... 474


AVALON_U (OM41437U)


For your information


Main Owner’s Manual


Please note that this manual applies to all models and explains all equip- ment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustration may differ from your vehicle in terms of equipment.


Noise from under vehicle after turning off the engine


Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.


Accessories, spare parts and modification of your Toyota


A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Mod- ification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addi- tion, damage or performance problems resulting from the modification may not be covered under warranty.


16


AVALON_U (OM41437U)


Installation of a mobile two-way radio system


As the installation of a mobile two-way radio system in your vehicle could affect electronic systems such as the multiport fuel injection system/sequen- tial multiport fuel injection system, electronic throttle control system, cruise control system, dynamic laser cruise control system, vehicle stability control system, SRS airbag system and seat belt pretensioner system, be sure to check with your Toyota dealer for precautionary measures or special instruc- tions regarding installation.


Scrapping of your Toyota


The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.


Perchlorate Material


Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.


17


AVALON_U (OM41437U)


CAUTION


■General precautions while driving


Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.


■General precautions regarding children’s safety


Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the cigarette lighter, the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.


18


AVALON_U (OM41437U)


Symbols used throughout this manual


Cautions & Notices


CAUTION


This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.


NOTICE


This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.


Symbols used in illustrations


Safety symbol The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.


Arrows indicating operations


Indicates the action (pushing, turn- ing, etc.) used to operate switches and other devices. Indicates the outcome of an opera- tion (e.g. a lid opens).


19


AVALON_U (OM41437U)


20


AVALON_U (OM41437U)


TABLE OF CONTENTS


1 Before driving


Adjusting and operating features such as door locks, mirrors, and steering column.


2 When driving


Driving, stopping and safe-driving information.


3 Interior features


Air conditioning and audio systems, as well as other interior features for a comfortable driving experience.


4 Maintenance


and care


Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information.


5 When trouble


arises


What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident.


6 Vehicle


specifications


Detailed vehicle information.


7 For owners


Reporting safety defects for U.S. owners and seat belt instructions for Canadian owners.


Index


Alphabetical listing of information contained in this manual.


AVALON_U (OM41437U)


Pictorial index


Exterior


Windshield wiper P. 160


Moon roof∗ P. 77


Outside rear view


mirror P. 72


Hood P. 327


Side marker light P. 156


Headlight (low beam) P. 156


Turn signal light P. 145


Fog light∗ P. 159


Headlight (high beam) P. 156


AVALON_U (OM41437U)


Rear window defogger P. 208


Tail/stop light P. 156


Fuel filler door P. 80


Door P. 40


Tail lights P. 156


Trunk P. 46


Tire ●Rotation ●Replacement ●Inflation pressure ●Information


P. 345
P. 405
P. 437
P. 442


Back-up light


Turn signal light P. 145


Side marker light P. 156


∗: If equipped


AVALON_U (OM41437U)


Pictorial index


Interior


Head restraint P. 59


Seat belt P. 61


Power window switch P. 74


Door pocket P. 285


Console box P. 280


SRS driver airbag P. 90


SRS knee airbag


P. 90


Front passenger airbag P. 90


Floor mat P. 298
Front seat P. 50


SRS side airbag P. 90


Storage compartment ∗ P. 283
Armrest P. 295


Cup holders P. 284


AUX adapter P. 238


Power outlets P. 291


AVALON_U (OM41437U)


A


Inside rear view mirror P. 70


Interior light P. 277


Personal light P. 277


Personal light P. 277


SRS curtain shield airbag P. 90


Moon roof switch∗ P. 77
Vanity mirror P. 287


Sun visor P. 286
Garage door opener switches∗ P. 301
Compass∗ P. 306


∗: If equipped


AVALON_U (OM41437U)


Pictorial index


Interior


Door lock switch P. 40


Window lock switch P. 74

Loading...
x
