sensor, the SRS indicator will come on and the airbag will inflate with full (normal) force, regardless of the driver's seating position.

For both advanced front airbags to work properly: • Do not spill any liquid on or under the seats. • Do not put any object under the passenger’s seat. • Make sure any objects are positioned properly on

the floor. Improperly positioned objects can interfere with the advanced airbag sensors.

• All occupants should sit upright and wear their seat

belts properly.

• Do not place any cover over the passenger side

dashboard.

Make sure the floor mat behind the front passenger’s seat is hooked to the floor mat anchor. An improperly placed mat can interfere with the advanced airbag sensors.

2 Floor Mats P. 378



S a f e D r i v i n g

45

uuAirbagsuSide Airbags

Side Airbags The side airbags help protect the upper torso of the driver or a front passenger during a moderate to severe side impact.

■ Housing Locations

1Side Airbags

Do not attach accessories on or near the side airbags. They can interfere with the proper operation of the airbags, or hurt someone if an airbag inflates.

The side airbags are housed in the outside edge of the driver's and passenger's seat- backs.

If the impact is on the passenger side, the airbag may not deploy when there is no passenger in the front passenger seat.

Both are marked SIDE AIRBAG.

Do not cover or replace the front seat-back covers without consulting a dealer. Improperly replacing or covering front seat-back covers can prevent your side airbags from properly deploying during a side impact.

When the sensors detect a moderate-to- severe side impact, the control unit signals the side airbag on the impact side to immediately inflate.

■ Operation

Housing Location

When inflated

Side Airbag



S a f e D r i v i n g

46

■ When a side airbag deploys with little or no visible damage Because the airbag systems senses sudden acceleration, a strong impact to the side of the vehicle's framework can cause a side airbag to deploy. In such cases, there may be little or no damage, but the side impact sensors detected a severe enough impact to deploy the airbag.

■ When a side airbag may not deploy, even though visible damage appears

severe

It is possible for a side airbag to not deploy during an impact that results in apparently severe damage. This can occur when the point of impact was towards the far front or rear of the vehicle, or when the vehicle's crushable body parts absorbed most of the crash energy. In either case, the side airbag would not have been needed nor provided protection even if it had deployed.

uuAirbagsuSide Airbags



S a f e D r i v i n g

Continued

47

uuAirbagsuSide Airbags



S a f e D r i v i n g

■ Side Airbag Cutoff System To reduce the likelihood that a front passenger may be injured by an inflating side airbag, the passenger side airbag is automatically turned off when: • The height sensors detect a child or short-statured adult is seated in the front

passenger seat.

• The position sensor detects that the front passenger is leaning into the

deployment path of the side airbag.

When the side airbag cutoff system is activated, the side airbag off indicator comes on.

2 Side Airbag Off Indicator P. 52

■ Side Airbag Off Indicator If the side airbag off indicator comes on, have the passenger sit upright. A few seconds after the passenger is sitting properly, the side airbag will automatically be turned on, and the indicator will go off.

If the front passenger is a child, stop when it is safe to do so, and have the child sit properly restrained in a rear seat.

1Side Airbag Cutoff System

Sensor that monitors the passenger’s height.

Sensor that monitors the passenger’s position.

The sensors that monitor the front passenger's height and body position may not work if: • The seat-back is wet • The passenger is touching a metal or other

electrical conductive object

• A seat cushion is on the seat • The passenger is wearing excessively thick clothing

48

uuAirbagsuSide Curtain Airbags

Side Curtain Airbags The side curtain airbags help protect the heads of the driver and passengers in outer seating positions during a moderate-to-severe side impact.

■ Housing Locations

1Side Curtain Airbags

The side curtain airbags are most effective when an occupant is wearing their seat belt properly and sitting upright, well back in their seat.

The side curtain airbags are located in the ceiling above the side windows on both sides of the vehicle.

Do not attach any objects to the side windows or roof pillars as they can interfere with the proper operation of the side curtain airbags.

Side Curtain Airbag Storage

■ Operation

The side curtain airbag is designed to deploy in a moderate-to-severe side impact.

Deployed Side Curtain Airbag

■ When side curtain airbags deploy in a frontal collision One or both side curtain airbags may inflate in a moderate to severe angled frontal collision. In this case, the side curtain airbags will deploy slightly after the front airbags.



S a f e D r i v i n g

49

uuAirbagsuAirbag System Indicators

Airbag System Indicators If a problem occurs in the airbag system, the SRS indicator will come on and a message appears on the multi-information display *.

■ SRS (Supplemental Restraint System) Indicator

*

■ When the ignition switch is turned to

ON (w

The indicator comes on for a few seconds, then goes off. This tells you the system is working properly.



S a f e D r i v i n g

1SRS (Supplemental Restraint System) Indicator 3WARNING

Ignoring the SRS indicator can result in serious injury or death if the airbag systems or tensioners do not work properly.

Have your vehicle checked by a dealer as soon as possible if the SRS indicator alerts you to a possible problem.

If the indicator comes on at any other time, or does not come on at all, have the system checked by a dealer as soon as possible. If you don't, your airbags and seat belt tensioners may not work properly when they are needed.

50

* Not available on all models

■ Passenger Airbag Off Indicator

U.S.

Canada

■ When the passenger airbag off

indicator comes on

The indicator comes on to alert you that the passenger's front airbag has been turned off. This occurs when the weight sensors detect 65 lbs (29 kg) or less, the weight of an infant or small child, on the seat.

Infants and small children should always ride properly restrained in a back seat.

2 Child Safety P. 54

Objects placed on the seat can also cause the indicator to come on.

If the front passenger seat is empty, the passenger's front airbag will not deploy and the indicator will not come on.

uuAirbagsuAirbag System Indicators



S a f e D r i v i n g

1Passenger Airbag Off Indicator

If the indicator comes on with no front passenger and no objects on the passenger’s seat, or with an adult riding there, something may be interfering with the weight sensors. Such as:

• An object hanging on the seat or in the seat-back

pocket.

• A child seat or other object pressing against the

rear of the seat-back.

• A rear passenger pushing or pulling on the back of

the front passenger's seat.

• The front seat or seat-back is forced back against

an object on the seat or floor behind it.

• An object placed under the front passenger's seat.

If none of these conditions exist, have your vehicle checked by a dealer as soon as possible.

The passenger airbag off indicator may come on and goes off repeatedly if the total weight on the seat is near the airbag cutoff threshold.

Continued

51

uuAirbagsuAirbag System Indicators

■ Side Airbag Off Indicator ■ When the side airbag off indicator comes on



S a f e D r i v i n g

U.S.

Canada

*

*

U.S.

Canada

1Side Airbag Off Indicator

When you turn the ignition switch to ON (w, the indicator should come on for a few seconds and then go out. If it doesn't come on, stays on, or comes on while driving without a passenger in the front seat, have the system checked by a dealer as soon as possible.

This indicator comes on if the passenger's side airbag has been turned off because the passenger is too small to be sitting in the front seat, is slouching or not sitting upright, or has leaned into the airbag's deployment path.

Unless the passenger is a smaller statured adult or a child, the indicator should go off when the passenger returns to a proper upright sitting position.

52

* Not available on all models

uuAirbagsuAirbag Care

1Airbag Care

We recommend against the use of salvaged airbag system components, including the airbag, tensioners, sensors, and control unit.

Airbag Care You do not need to, and should not, perform any maintenance on or replace any airbag system components yourself. However, you should have your vehicle inspected by a dealer in the following situations:

■ When the airbags have deployed If an airbag has inflated, the control unit and other related parts must be replaced. Similarly, once an automatic seat belt tensioner has been activated, it must be replaced.

■ When the vehicle has been in a moderate-to-severe collision Even if the airbags did not inflate, have your dealer inspect the following: the driver’s seat position sensor, weight sensors in the passenger’s seat, front seat belt tensioners, and each seat belt that was worn during the crash.

■ Do not remove or modify a front seat without consulting a dealer This would likely disable the driver's seat position sensor or the passenger's weight sensor. If it is necessary to remove or modify a front seat to accommodate a person with disabilities, contact a Honda dealer, or for U.S. vehicles, American Honda Automobile Customer Service at 800-999-1009 and for Canadian vehicles, Honda Canada Customer Relations at 888-9-HONDA-9.



S a f e D r i v i n g

53

Child Safety

Protecting Child Passengers Each year, many children are injured or killed in vehicle crashes because they are either unrestrained or not properly restrained. In fact, vehicle accidents are the number one cause of death of children age 12 and under.

To reduce the number of child deaths and injuries, every state, Canadian province and territory requires that infants and children be properly restrained when they ride in a vehicle.

Children should sit properly restrained in a rear seat. This is because:

• An inflating front or side airbag can injure

or kill a child sitting in the front seat.

• A child in the front seat is more likely to interfere with the driver's ability to safely control the vehicle.
