1.


Insert the key in the ignition switch, and unlock the steering column.


2.


Push the lever under the steering column all the way down.


Instruments and Controls


81


Main MenuTable of Contentsst 02/11/18 22:39:40 31SDP600 0085


Keys and Locks


Keys


KEY NUMBER TAG


MASTER KEY WITH REMOTE TRANSMITTER


VALET KEY (LIGHT GREY)


Your car comes with two master keys and a valet key. The master key fits all the locks on your car: (cid:127) Ignition (cid:127) Doors (cid:127)Glovebox (cid:127) Trunk release handle (cid:127) Rear seat trunk access • Trunk


82


Instruments and Controls


The valet key works only in the ignition and the driver’s door lock. You can keep the trunk release handle, rear seat trunk access, and glove box locked when you leave your car and the valet key at a parking facility.


Youshouldhavereceivedakey number tag with your keys. You will need this key number if you ever have to get a lost key replaced. Keep the tag stored in a safe place. If you need to replace a key, use only Honda-approved key blanks.


These keys contain electronic circuits that are activated by the Immobilizer System. They will not work to start the engine if the circuits are damaged.


Protect the keys from direct sunlight, high temperature, and high humidity.


Donotdropthekeysorsetheavy objects on them.


Keep the keys away from liquids. If they get wet, dry them immediately with a soft cloth.


RemoteTransmitter Your car also comes with two remote transmitters built into the master keys; see page for an explanation of the remote transmitter operation.


87


Main MenuTable of Contentsst 02/11/18 22:39:51 31SDP600 0086


Immobilizer System The Immobilizer System protects your car from theft. A properly- coded master or valet key must be used in the ignition switch for the engine to start. If an improperly- coded key (or other device) is used, the engine’s fuel system is disabled.


When you turn the ignition switch to ON (II), the Immobilizer System indicator should come on for a few seconds, then go out. If the indicator starts to blink, it means the system does not recognize the coding of the key. Turn the ignition switch to LOCK (0), remove the key, reinsert it, and turn the switch to ON (II) again.


The system may not recognize your key’s coding if another immobilizer key or other metal object is near the ignition switch when you insert the key. To make sure the system recognizes the key code:


Do not keep other immobilizer keys on the same key ring.


Use a plastic or leather key fob, not metal.


Keep other keys away from your car’s key and the ignition switch while trying to start the engine.


If the system repeatedly does not recognize the coding of your key, contact your Honda dealer.


Keys and Locks


The Immobilizer System indicator will also blink several times when you turn the ignition switch from ON (II) to ACCESSORY (I) or LOCK (0).


Do not attempt to alter this system or add other devices to it. Electrical problems could result that may make your car undriveable.


If you have lost your key and you cannot start the engine, contact your Honda dealer.


CONTINUED


Instruments and Controls


83


Main MenuTable of Contentsst 02/11/18 22:40:00 31SDP600 0087


Keys and Locks


AsrequiredbytheFCC: ThisdevicecomplieswithPart15ofthe FCCrules.Operationissubjecttothe followingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and (2)thisdevicemustacceptany interferencereceived,including interferencethatmaycauseundesired operation.


Changesormodificationsnotexpressly approvedbythepartyresponsiblefor compliancecouldvoidtheuser’s authoritytooperatetheequipment.


ThisdevicecomplieswithIndustry CanadaStandardRSS-210. Operationissubjecttothefollowingtwo conditions:(1)thisdevicemaynotcause interference,and(2)thisdevicemust acceptanyinterferencethatmaycause undesiredoperationofthedevice.


84


Instruments and Controls


Ignition Switch


The ignition switch is on the right side of the steering column. It has four positions: (cid:127) LOCK (0) (cid:127) ACCESSORY (I) (cid:127) ON (II) (cid:127) START (III)


− You can insert or


LOCK (0) remove the key only in this position. To switch from ACCESSORY to LOCK, you must push the key in slightly as you turn it. If your car has an automatic transmission, the shift lever must also be in Park. The anti- theft lock will lock the steering column when you remove the key.


If the front wheels are turned, the anti-theft lock may sometimes make it difficult to turn the key from LOCK to ACCESSORY. Firmly turn the steering wheel to the left or to the right as you turn the key.


Main MenuTable of Contentsst 02/11/18 22:40:08 31SDP600 0088


Removing the key from the ignition switch while driving locks the steering. This can cause you to lose control.


Remove the key from the ignition switch only when parked.


ACCESSORY (I) you can operate the audio system and the accessory power sockets.


In this position,




ON (II) This is the normal key position when driving. All features and accessories on the car are usable. Several of the lights on the instru- ment panel come on as a test when you turn the ignition switch from ACCESSORY to ON.



Use this position


START (III) only to start the engine. The switch returns to ON (II) when you let go of the key.


Keys and Locks


The engine will not start if the Immobilizer System does not recognize the key’s coding (see page 83


).


You will hear a reminder beeper if you leave the key in the ignition switch in the LOCK (0) or ACCESSORY (I) position and open the driver’s door. Remove the key to turn off the beeper.


Instruments and Controls


85


Main MenuTable of Contentsst 02/11/18 22:40:18 31SDP600 0089


Keys and Locks


Power Door Locks


MASTER DOOR LOCK SWITCH


LOCK TAB


Each door has a master door lock switch. Either switch locks and unlocks both doors. Push the top of the switch to lock both doors; push the bottom to unlock them.


Each door has a lock tab at the top of the door. When you push down the lock tab on the driver’s door, both doors lock. Pulling up the lock tab on the driver’s door only unlocks that door. The lock tab on the passenger’s door only locks and unlocks that door.


86


Instruments and Controls


To lock the passenger’s door when getting out of the car, push the lock tab down and close the door. To lock the driver’s door, remove the key from the ignition switch and push the lock tab down or push the top of the master switch, then close the door.


Both doors can be locked from the outsidebyusingthekeyinthe driver’s door. To unlock just the driver’s door, turn the key and releaseit.Ifyouturnthekeyand hold it, both doors will unlock.


You can also open or close the windows by turning the key in the driver’s door (see page 106).


Main MenuTable of Contentsst 02/11/18 22:40:28 31SDP600 0090


LockoutPrevention If you forget and leave the key in the ignition switch, Lockout Prevention will not allow you to lock the driver’s door. With the driver’s door open andthekeyintheignition,both master door lock switches are disabled. However, if the driver’s door is not open, the master door lock switches are not disabled. Pushing the top of the switch on the open passenger’s door will lock both doors. If you try to lock an open driver’s door by pushing down the lock tab, the tabs on both doors pop up. Pushing down the lock tab on the passenger’s door only locks that door.


Remote Transmitter


UNLOCK BUTTON


PANIC BUTTON


LOCK BUTTON


LED


TRUNK RELEASE BUTTON


You can lock and unlock your car with the remote transmitter. When you push the LOCK button, both doors lock. The parking lights, side marker lights, and taillights flash once.


Keys and Locks


When you push the LOCK button a second time within 5 seconds after you have locked the doors, you will hear a beep to verify that the doors are locked and (if equipped) that the security system has set.


When you push the UNLOCK button once, only the driver’s door unlocks. The passenger’s door unlocks when you push the button a second time. The parking lights, side marker lights, and taillights flash twice each time you push the button.


You can also open both power windows from outside the car with theremotetransmitter(seepage 106).


CONTINUED


Instruments and Controls


87


Main MenuTable of Contentsst 02/11/18 22:40:38 31SDP600 0091


If you unlock the doors with the remote transmitter, but do not open either door within 30 seconds, the doors automatically relock and the security system sets (except for 4-cylinder LX model).


To open the trunk, push the Trunk Release button for approximately one second.


The trunk will not open if the key is in the ignition switch.


PanicMode Panic mode allows you to remotely activate your car’s horn and exterior lights to attract attention. The horn sounds and the exterior lights flash for about 30 seconds. To activate panic mode, press and hold the PANIC button for about two seconds.


To cancel Panic mode before 30
seconds, press any button on the remote transmitter. You can also turn the ignition switch to ON (II).


Panic mode will not activate if the ignition switch is in the ON (II) position.


Keys and Locks


The ceiling light (if the ceiling light switch is in the center position) and the spotlights (if the switch is in the Door position) will come on when you press the UNLOCK button. If you do not open either door, the lights stay on for about 30 seconds, then fade out. If you relock the doors with the remote transmitter before 30 seconds have elapsed, the lights will go off immediately.


You cannot lock the doors with the remote transmitter if either door is not fully closed or the key is in the ignition switch. You cannot unlock the doors with the key in the ignition switch.


88


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:40:49 31SDP600 0092


ReplacingtheBattery When the remote transmitter’s battery begins to get weak, it may take several pushes on the button to lock or unlock the doors, and the LED will not light. Replace the battery as soon as possible.


Battery type: CR1616


Keys and Locks


BATTERY


SCREW


TAB


To replace the battery:


1.


2.


Remove the screw at the base of the transmitter with a small Phillips-head screwdriver.


Separate the transmitter by prying its middle seam with your fingernail.


3.


Inside the transmitter, separate the inner cover from the keypad by releasing the two tabs on the cover.


CONTINUED


Instruments and Controls


89


Main MenuTable of Contentsst 02/11/18 22:40:59 31SDP600 0093


Keys and Locks


4.


Remove the old battery from the back of the inner cover, and note the polarity. Make sure the polarity of the new battery is the same ( side facing down), then insert it into the back of the cover.



5.


Install the parts in reverse order.


90


Instruments and Controls


AsrequiredbytheFCC: ThisdevicecomplieswithPart15ofthe FCCrules.Operationissubjecttothe followingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and (2)thisdevicemustacceptany interferencereceived,including interferencethatmaycauseundesired operation.


Changesormodificationsnotexpressly approvedbythepartyresponsiblefor compliancecouldvoidtheuser’s authoritytooperatetheequipment.


ThisdevicecomplieswithIndustry CanadaStandardRSS-210. Operationissubjecttothefollowingtwo conditions:(1)thisdevicemaynotcause interference,and(2)thisdevicemust acceptanyinterferencethatmaycause undesiredoperationofthedevice.


TransmitterCare Avoid severe shock to the trans- mitter, such as dropping or throwing it. Also, protect it from extreme hot or cold temperatures.


Clean the transmitter case with a soft cloth. Do not use strong cleaners or solvents that could harm the case. Immersing the transmitter in any liquid will harm the trans- mitter and cause it to not function properly.


If you lose a transmitter, you will need to have the replacement programmed to your car’s system by your Honda dealer. Any other transmitters you have will also need to be reprogrammed.


Main MenuTable of Contentsst 02/11/18 22:41:09 31SDP600 0094


Trunk


To close the trunk, press down on the trunk lid.


Keys and Locks


234


See page for cargo loading and weight limit information. Keep the trunk lid closed at all times while driving to avoid damaging the lid, and to prevent exhaust gas from getting into the interior. See Monoxide Hazard on page


Carbon 56


Pull


TRUNK RELEASE HANDLE


Youcanopenthetrunkintwoways:


Pull the trunk release handle to the left of the driver’s seat.


Press and hold the trunk release button on the remote transmitter.


MASTER KEY


To protect items in the trunk when you need to give the key to someone else:


1.


Lock the trunk release handle with the master key.


2.


Give the person the valet key.


Instruments and Controls


91


Main MenuTable of Contentsst 02/11/18 22:41:16 31SDP600 0095


To open the trunk, push the release lever to the left.


Parents should decide if their children should be shown how to use this feature.


For more information about child safety, see page


.25


Keys and Locks


Emergency Trunk Opener


As a safety feature, your car has a release lever on the trunk latch so the trunk can be opened from the inside.


92


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:41:23 31SDP600 0096


Keys and Locks


An open glove box can cause serious injury to your passenger in a crash, even if the passenger is wearing the seat belt.


Always keep the glove box closed while driving.


Glove Box


GLOVE BOX


Open the glove box by pulling the handle to the left. Close it with a firm push. Lock or unlock the glove box with the master key.


The glove box light comes on when the parking lights are on.


Instruments and Controls


93


Main MenuTable of Contentsst 02/11/18 22:41:34 31SDP600 0097


Seat Adjustments


All V6 models, and the 4-cylinder EX model with leather interior have a power adjustable driver’s seat.


The 4-cylinder EX model without leather interior has a power seat bottom height adjustment. All other driver’s seat adjustments in this model are manual.


The 4-cylinder LX model has manual driver’s seat adjustments (see next column).


The front passenger’s seat in all models adjusts manually.


94


Instruments and Controls



14 15


Front Seat Adjustments Seepages forimportantsafety informationandwarningsabouthowto properlypositionseatsandseat-backs. Make all seat adjustments before you start driving.


To change the angle of the seat-back, pull up on the lever on the outside of the seat bottom. Move the seat-back to the desired position and release the lever. Let the seat-back latch into the new position.


To adjust the seat forward and backward, pull up on the bar under the seat cushion’s front edge. Move the seat to the desired position and releasethebar.Trytomovetheseat to make sure it is locked in position.


Main MenuTable of Contentsst 02/11/18 22:41:43 31SDP600 0098


Driver’s Seat Manual Height Adjustment


Make sure to pull the lever upward or downward to its full range.


Driver’s Seat Power Height Adjustment


Seat Adjustments


On4-cylinderLXmodel The height of your driver’s seat is adjustable. To raise the seat bottom, repeatedly pull up the lever on the outside of the seat cushion. To lower the seat, push down the lever repeatedly.


Make all seat adjustments before you start driving.


On4-cylinderEXmodelwithoutleather interior The height of your driver’s seat is power adjustable. Pull up on the switch to raise the seat. Push it down to lower the seat.


Make all seat adjustments before you start driving.


Instruments and Controls


95


Main MenuTable of Contentsst 02/11/18 22:41:51 31SDP600 0099


Seat Adjustments


Driver’s Seat Power Adjustments OnallV6models,andthe4-cylinder EXmodelwithleatherinterior Seepages forimportantsafety informationandwarningsabouthowto properlypositionseatsandseat-backs.


15


14



The two power seat adjustment switches are on the outside edge of the seat bottom. The horizontal switch adjusts the seat bottom in several directions. The short vertical switch adjusts the seat-back angle.


You can adjust the seat with the ignition switch in any position. Make all seat adjustments before you start driving.


96


Instruments and Controls


Push the horizontal switch forward or backward to move the seat forward or backward.


Pull up or push down on the front of the switch to move the seat bottom’s front edge up or down. Pull up or push down on the rear of the switch to move the rear of the seat bottom up or down.


Main MenuTable of Contentsst 02/11/18 22:42:00 31SDP600 0100


Pull the center of the horizontal switch up to raise the seat. Push it down to lower the seat.


Adjust the seat-back angle by pushing the rear switch in the direction you want to move.


Seat Adjustments


Driver’s Lumbar Support


OnallEXandEX-V6models Vary the lumbar support by moving the lever on the right side of the seat-back. Move the lever forward to increase support and backward to decrease it.


Instruments and Controls


97


Main MenuTable of Contentsst 02/11/18 22:42:10 31SDP600 0101


Seat Adjustments


Rear Seat Access Driver’sSide


Passenger’sSide


RELEASE LEVER


SEAT-BACK ADJUSTMENT LEVER


RELEASE LEVER


OnallV6modelsandthe4-cylinderEX modelwithleatherinterior To get into the rear seat on the driver’s side, open the door and pull the release lever up on the side of the seat-back. The seat-back will tilt forward to allow easier entry to the rear seat.


OnLXandEXmodels To get into the rear seat on the driver’s side, open the door and pull up on the seat-back adjustment lever. The seat-back will tilt forward to allow easier entry to the rear seat.


To get into the rear seat on the passenger’s side, push downward on the release lever at the base of the seat-back. The seat-back will tilt forward and the entire seat will move forward to allow easier entry to the rear seat.


98


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:42:20 31SDP600 0102


After a passenger gets into the back seat, push the seat-back to the upright position and push the whole seat backwards until it latches. Make sure the seat is fully latched before sitting in it.


Head Restraints See page for important safety informationandawarningabouthowto properlypositiontheheadrestraints.


16


Your car has adjustable head restraints on the front seats. They are also on the outside positions of the rear seat.


The head restraints help protect you and your passengers from whiplash and other injuries. They are most effective when you adjust them so the back of the occupant’s head rests against the center of the restraint. A taller person should adjust the restraint as high as possible.


Seat Adjustments


FRONT


RELEASE BUTTON


The head restraints adjust for height. You need both hands to adjust the restraint. Do not attempt to adjust it while driving. To raise it, pull upward. To lower the restraint, push the release button sideways, and push the restraint down.


CONTINUED


Instruments and Controls


99


Main MenuTable of Contentsst 02/11/18 22:42:27 31SDP600 0103


Seat Adjustments


REAR


To remove a head restraint for cleaning or repair, pull it up as far as it will go. Push the release button and pull the restraint out of the seat- back.


100


Instruments and Controls


Folding Rear Seat The back of the rear seat folds down to give you direct access to the trunk. Each side folds down separately. With only half the seat folded, you can still carry a passenger in the back seat. The seat-back can be released from inside the car or inside the trunk.


MASTER KEY


To fold down either side of the seat- back from inside the car, insert the master key in the lock on the rear shelf. To fold down the driver’s side, turn the key clockwise, pull down the top of the seat-back, then release the key. To fold down the passenger’s side, turn the key counterclockwise and perform the same procedure.


Main MenuTable of Contentsst 02/11/18 22:42:37 31SDP600 0104


Seat Adjustments


Make sure all rear shoulder belts are positioned in front of the rear seat- back whenever the seat-back is in its upright position.


GUIDE


CENTER SHOULDER BELT


Pull


Make sure all items in the trunk, or items extending through the opening into the back seat, are secured. Loose items can fly forward and cause injury if you have to brake hard. See 234


Carrying Cargo


on page


When storing cargo, you can move therearcentershoulderbeltoutof the way by removing the belt from the guide.


To release the seat-back from inside the trunk, pull the release under the trunk panel. Push the seat-back down, then let go of the release.


Never drive with the seat-back folded down and the trunk lid open. See on page


Carbon Monoxide Hazard .56


To lock the seat-back upright, push it firmly against the trunk panel. Make sure it is latched in place by pulling on the top of the seat.


Do not put any heavy items on the seat-back when it is folded.


Instruments and Controls 101


Main MenuTable of Contentsst 02/11/18 22:42:46 31SDP600 0105


Seat Heaters


The HI or LO indicator lights and remains lit until you turn it off by pushing the opposite side of the switch lightly. The indicator will turn off.


In HI, the heater turns off when the seat gets warm, and turns back on after the seat’s temperature drops. It continues to cycle as long as you leave it set on HI. The HI indicator remains lit as a reminder that you have the heater on.


In LO, the heater runs continuously. It does not cycle with temperature changes.


Follow these precautions whenever you use the seat heaters:


Use the HI setting only to heat the seats quickly. Select the LO setting when the seats feel warm. The HI setting draws large amounts of current from the battery.


Do not use the seat heaters, even on the LO setting, if the engine is left idling for an extended period. They can weaken the battery, causing hard starting.


SEAT HEATER SWITCH


OnEX-V6modelandEXmodelwith leatherinterior Both front seats are equipped with seat heaters. Because of the sensors for the side airbag system, there is no heater in the passenger’s seat- back. The ignition switch must be ON (II) to use the heaters. Push the front of the switch, HI, to rapidly heat up the seat. After the seat reaches a comfortable temperature, select LO by pushing the back of the switch. This will keep the seat warm.


102


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:42:54 31SDP600 0106


Your car’s windows are electrically- powered. Turn the ignition switch to ON (II) to raise or lower either window.


Each door has a switch that controls its window. To open the window, push the switch down and hold it. Release the switch when you want the window to stop. Close the window by pulling back on the switch and holding it.


MAIN SWITCH


DRIVER’S WINDOW SWITCH The driver’s armrest has a master power window control panel. To open the passenger’s window, push down on the switch and hold it down until the window reaches the desired position. To close the window, pull back on the window switch. Release the switch when the window gets to the position you want.


Power Windows


Closing a power window on someone’s hands or fingers can cause serious injury.


Make sure your passengers are away from the windows before closing them.


CONTINUED


Instruments and Controls


103


Main MenuTable of Contentsst 02/11/18 22:43:04 31SDP600 0107


The MAIN switch controls power to the passenger’s window. When you push in the MAIN switch, the passenger’s window cannot be raised or lowered. The MAIN switch does not affect the driver’s window. To cancel this feature, push on the switch again to get it to pop out. Keep the MAIN switch off when you have children in the car so they do not injure themselves by operating the window unintentionally.


Auto Reverse If the driver’s window runs into any obstacle while it is closing automatically, it will reverse direction, and then stop. To close the window, remove the obstacle, then use the window switch again.


Auto reverse stops sensing when the window is almost closed. You should always check that all passengers and objects are away from the window before closing it.


Power Windows


The master control panel also con- tains these extra features:



AUTO To open the driver’s window fully, push the window switch firmly down, then release it. The window automatically goes down all the way. To stop the window from going all the way down, pull back on the window switch briefly.


To close the driver’s window fully, pull back the window switch firmly, then release it. The window automatically goes all the way up. To stop the window from going all the way up, push down on the window switch briefly.


To open or close the driver’s window partially, push down or pull back on the window switch lightly and hold it. The window will stop when you release the switch.


104


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:43:11 31SDP600 0108


Power Windows


The power window system has a key- off delay function. The windows will still operate for up to ten minutes after you turn off the ignition. Opening either door cancels the delay function. You must turn the ignition switch ON (II) again before you can raise or lower the windows.


If your car’s battery is disconnected or goes dead, or the driver’s window fuse is removed, the AUTO function will be disabled. The power window system needs to be reset after reconnecting the battery or installing the fuse. You should do the following.


1.


2.


Start the engine. Push down on the driver’s window switch until the window is fully open.


Pull back on the driver’s window switch to close the window completely, then hold the switch for a second or two more.


If the power windows do not operate properly after resetting, have your car checked by a Honda dealer.


Instruments and Controls 105


Main MenuTable of Contentsst 02/11/18 22:43:24 31SDP600 0109


Power Windows


Opening the Windows with the Remote Transmitter You can open both windows from the outside with the remote transmitter.


1.


Press the UNLOCK button once to unlock the driver’s door.


2.


Press the UNLOCK button a second time, and hold it. The passenger’s door unlocks, and both windows start to open. To stop the windows, release the button.


3.


To open the windows further, press the button again.


You cannot close the windows with the remote transmitter.


106


Instruments and Controls


UNLOCK BUTTON


3.


Turn the key clockwise again, and hold it. Both windows start to open. To stop the windows, release the key.


4.


To open the windows further, turn and hold the key again (within 10 seconds).


NOTE: If the window stops before the desired position, repeat steps 2
and 3.


Open


Close


Opening/Closing the Windows with the Key You can open and close the windows with the key in the driver’s door lock.


To open: 1.


Insert the key in the driver’s door lock.


2.


Turn the key clockwise, then release it.


Main MenuTable of Contentsst 02/11/18 22:43:37 31SDP600 0110


To close: 1.


Insert the key in the driver’s door lock.


2.


Turn the key counterclockwise, then release it.


3.


Turn the key counterclockwise again, and hold it. Both windows start to close. To stop the windows, release the key.


4.


To close the windows further, turn and hold the key again (within 10 seconds).


NOTE: If the window stops before the desired position, repeat steps 2
and 3.


Moonroof


MOONROOF SWITCH


OnallEXandEX-V6models The moonroof has two positions: it can be tilted up in the back for ventilation, or it can be slid back into the roof. Use the switch under the left dashboard vent to operate the moonroof. The ignition switch must be ON (II).


Power Windows, Moonroof


). To open the


To tilt up the back of the moonroof, press and hold the center button ). To close the moonroof, press and hold the upper part of the switch ( moonroof, press and hold the lower part of the switch ( ). Release the switch when the moonroof gets to the desired position. Make sure everyone’s hands are away from the moonroof before opening or closing it.


Opening or closing the moonroof on someone’s hands or fingers can cause serious injury.


Make sure all hands and fingers are clear of the moonroof before opening or closing it.


CONTINUED


Instruments and Controls


107


Main MenuTable of Contentsst 02/11/18 22:43:50 31SDP600 0111


Moonroof, Mirrors


The moonroof has a key-off delay. You can still open and close the moonroof for up to ten minutes after you turn off the ignition. The key-off delay cancels as soon as you open either door. You must then turn the ignition ON (II) for the moonroof to operate.


If you try to open the moonroof in below-f reezing temperatures, or when it is covered with snow or ice, you can damage the moonroof panel or motor.


108


Instruments and Controls


Mirrors


AdjustingthePowerMirrors


ADJUSTMENT KNOB


TAB


Keep the inside and outside mirrors clean and adjusted for best visibility. Be sure to adjust the mirrors before you start driving.


The inside mirror has day and night positions. The night position reduces glare from headlights behind you. Flip the tab on the bottom edge of the mirror to select the day or night position.


Adjust the outside mirrors with the adjustment knob on the driver’s door armrest:


1.


Turn the ignition switch ON (II).


2.


Turn the adjustment knob to L (driver’s side) or R (passenger’s side).


Main MenuTable of Contentsst 02/11/18 22:43:59 31SDP600 0112


Mirrors


HEATED MIRROR BUTTON


ADJUSTMENT KNOB


3.


4.


Push or pull the adjustment knob in the appropriate direction to move the mirror right, left, up, or down.


When you finish, turn the adjustment knob to the center (off) position. This turns off the adjustment knob so you can’t move a mirror out of position by accidentally bumping the knob.


OnallCanadianmodels The outside mirrors are heated to re- move fog and frost. With the ignition switch ON (II), turn on the heaters by pressing the button. The light in the button comes on as a reminder. Press the button again to turn the heaters off.


Instruments and Controls 109


Main MenuTable of Contentsst 02/11/18 22:44:04 31SDP600 0113


Parking Brake


Driving the car with the parking brake applied can damage the rear brakes and axles.


PARKING BRAKE LEVER


To apply the parking brake, pull the lever up fully. To release it, pull up slightly, push the button, and lower the lever. The parking brake light on the instrument panel should go out when the parking brake is fully released with the engine running (see page


63


).


110


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:44:14 31SDP600 0114


Console Compartment


Armrest


RIGHT LEVER


LEFT LEVER


Console Compartment, Armrest


CONSOLE COMPARTMENT


To open the console compartment, pull up on the right lever and lift the armrest.


To close, lower the armrest and push it down until it latches.


You can put small items in the tray located in the console compartment lid. To use the tray, pull up on the left lever and lift up the armrest.


The tray in the console compartment has a coin holder.


To use the console lid as an armrest, slide it to the desired position.


Make sure the passenger’s hands or fingers are away from the armrest before moving it.


Instruments and Controls 111


Main MenuTable of Contentsst 02/11/18 22:44:22 31SDP600 0115


Beverage Holders


DOOR


Spilled liquids can also damage the upholstery, carpeting, and electrical components in the interior.


The rear seat also has a beverage holder in the side panel.


Be careful when you are using the beverage holders. A spilled liquid that is very hot can scald you or your passengers. Liquid can also spill from the door pocket beverage holders when you open or close the doors. Use only resealable containers in the door pockets.


112


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:44:30 31SDP600 0116


Center CD Pocket


Coin Pocket


Push


Center CD Pocket, Coin Pocket


Oncarswithoutnavigationsystem To open the center CD pocket, push- down on the center of the lid to unlatch it. It will swing open automatically. To close it, push the lid down until it latches. This pocket can store up to 12 CDs.


To open the coin pocket, pull the lid up. To close it, push the lid down until it latches. The compartment cannot be used as an ashtray.


Instruments and Controls 113


Main MenuTable of Contentsst 02/11/18 22:44:38 31SDP600 0117


Sun Visor


To use the sun visor, pull it down. You can also use the sun visor at the side window. Remove the support rod from the clip and swing the sun visor toward the side window.


EXTENSION


SUN VISOR


Make sure you put the sun visor back in place when you are getting into or out of the car.


Oncarswithsidecurtainairbags In this position, the sun visor can be adjusted by moving it on its slider. Do not use the sun visor over the rear view mirror.


Oncarswithoutsidecurtainairbags In this position, the sun visor can be extended by sliding out the extension. Do not use the sun visor extension over the rear view mirror.


114


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:44:47 31SDP600 0118


Vanity Mirror


Coat Hook


COAT HOOK


Vanity Mirror, Coat Hook


To use a vanity mirror on the back of the sun visor, pull up the cover.


To use a coat hook, pull it down. Close it with a firm push.


The lights beside the mirror come on when you pull up the cover.


Make sure the coat hook is closed when you are not using it. This hook is not designed for large or heavy items.


Instruments and Controls


115


Main MenuTable of Contentsst 02/11/18 22:44:59 31SDP600 0119


Sunglasses Holder, Accessory Power Sockets


Sunglasses Holder


Accessory Power Sockets


COVER


To open the sunglasses holder, push on the front edge. It will unlatch and swing down. To close it, push it until it latches. Make sure the holder is closed while you are driving.


ACCESSORY POWER SOCKET


Some larger styles of sunglasses may not fit in the holder.


You may also store small items in this holder. Make sure they are small enough to let the holder close and latch, and that they are not heavy enough to cause the holder to pop open while driving.


Your car has two accessory power sockets, one is located in the front of the center console, and the other is in the center console compartment. To use an accessory power socket, the ignition switch must be in ACCESSORY (I) or ON (II).


To open the socket, pull the cover up.


116


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:45:09 31SDP600 0120


Accessory Power Sockets, Interior Lights


Ceiling Light


DOOR ACTIVATED


OONN


OOFFFF


After both doors are closed tightly, the light dims slightly, then fades out in about 30 seconds. In the ON position, the ceiling light stays on continuously.


The ceiling light (with the switch in the center position) also comes on when you unlock the door with the remote transmitter (see page ). The light fades out after both doors are closed.


88


The ceiling light has a three-position switch. In the OFF position, the light does not come on. In the center position, the ceiling light comes on when you open either door.


ACCESSORY POWER SOCKET


These sockets are intended to supply power for 12 volt DC accessories that are rated 120 watts or less (10
amps).


When both sockets are being used, the combined power rating of both accessories should be 120 watts or less (10 amps).


They will not power an automotive type cigarette lighter element.


CONTINUED


Instruments and Controls


117


Main MenuTable of Contentsst 02/11/18 22:45:16 31SDP600 0121


Spotlights


Interior Lights


The ceiling light (with the switch in the center position) comes on when you remove the key from the ignition switch. If you do not open a door, the light stays on, then fades out in about 30 seconds.


If you leave either door open with the key not in the ignition switch, the ceiling light will go off after three minutes.


LX and LX-V6 models


EX and EX-V6 models


Turn on a spotlight by pushing the lens. Push the lens again to turn it off. You can use the spotlights at all times.


118


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:45:26 31SDP600 0122


Interior Lights


DOOR ACTIVATED


OFF


The spotlights (with the switch in the DOOR position) also come on when you unlock the door with the remote transmitter, and when you remove the key from the ignition switch.(See Ceiling Light on page 117


.)


Courtesy Lights


IGNITION SWITCH LIGHT


OnEXandEX-V6models The spotlights have a two-position switch. In the DOOR position, the lights come on when you open either door. In the OFF position, the lights do not come on.


DOOR LIGHT


The courtesy light in each door comes on when the door is opened, and goes out when the door is closed.


Your car also has a courtesy light in the ignition switch. This light comes on when you open the driver’s door. It fades out in about 30 seconds after the door is closed.


CONTINUED


Instruments and Controls


119


Main MenuTable of Contentsst 02/11/18 22:45:31 31SDP600 0123


Interior Lights


COURTESY LIGHT


OnEXandEX-V6models The courtesy light between the spotlights comes on when you turn the parking lights on. To adjust its brightness, turn the Select/Reset knob on the instrument panel.


120


Instruments and Controls


Main MenuTable of Contentsst 02/11/18 22:45:36 31SDP600 0124


Comfort and Convenience Features


Heating and Cooling


What Each Control Does How to Use the System To Turn Everything Off


Climate Control System


..................... ......... ............ .......... ...............


. 122
. 122
. 125
. 128
. 129


WithoutNavigationSystem Fully-automatic Operation Semi-automatic Operation Dual Temperature Control WithNavigationSystem Fully-automatic Operation Semi-automatic Operation Dual Temperature Control Sunlight Sensor/


....... ....... ......


. 131
. 132
. 137


....... ....... ......


. 138
. 139
. 145


Audio System (LX)


Temperature Sensor


. 147
. 148
AM/FM/CD Audio System . 148
. 148
Operating the Radio . 152
Adjusting the Sound Digital Clock . 153
. 154
Operating the CD Player . 156
Operating the CD Changer CD Player Error Indications . 158
CD Changer Error


............ ....................... .... ................. ................. .............................. ......... ..... ....


Indications


.............................


. 159


Operating the Cassette


Player


Tape Search Functions


.................................... ...........


. 160
. 161


Audio System


(EX, EX-V6, LX-V6)


..............


. 163


System


WithoutNavigationSystem AM/FM/CD Changer Audio .................................... ................. ................. .............................. .....


Operating the Radio Adjusting the Sound Digital Clock Operating the CD Changer CD Changer Error


. 163
. 164
. 169
. 171
. 173


Indications


.............................


. 182


Operating the Cassette


Player


Tape Search Functions


.................................... ...........


. 183
. 185


(U.S. 4-cylinder EX with leather interior, U.S.


EX-V6)


............................


. 187


WithNavigationSystem AM/FM/CD Changer Audio .................................... ................. ................


Operating the Radio Adjusting the Sound


System


. 187
. 188
. 191


Audio System


Digital Clock Radio Frequencies Radio Reception Operating the CD Changer CD Changer Error


............................. ................... ....................... .....


. 193
. 194
. 194
. 196


Indications


............................. ......


. 204
. 205


Protecting Compact Discs Operating the Cassette


Player


.................................... ...........


. 206
. 208


Tape Search Functions Caring for the Cassette


Player


Remote Audio Controls Theft Protection


.................................... ........... ....................... ............................ ...............................


Security System Cruise Control Homelink Wireless Control


. 210
. 211
. 212
. 213
. 214


System


........................................


. 218


Comfort and Convenience Features 121


Main Menust 02/11/18 22:45:49 31SDP600 0125


Heating and Cooling


OnLX,EXandLX-V6models Proper use of the Heating and Cooling system can make the interior dry and comfortable, and keep the windows clear for the best visibility.


What Each Control Does


Fan Control Dial Turning this dial clockwise increases the fan’s speed, which increases air flow.


Temperature Control Dial Turning this dial clockwise increases the temperature of the air flow.


Air Conditioning (A/C) Button This button turns the air condi- tioning ON and OFF. The indicator above the button lights when the A/C is on.


122


Comfort and Convenience Features


FAN CONTROL DIAL


RECIRCULATION BUTTON


AIR CONDITIONING (A/C) BUTTON


TEMPERATURE CONTROL DIAL


REAR WINDOW DEFOGGER BUTTON


MODE BUTTONS


Rear Window Defogger Button This button turns the rear window defogger on and off (see page 79


).


Recirculation Button This button controls the source of air going into the system. When the indicator above this button is lit, air from the car’s interior is sent through the system again (Recircula- tion mode). When the indicator is off, air is brought in from outside the car (Fresh Air mode).


Main MenuTable of Contentsst 02/11/18 22:46:06 31SDP600 0126


Heating and Cooling


Mode Buttons Use the MODE buttons to select the vents the air flows from. Some air will flow from the dashboard corner vents in all modes.


Air flows from the center and corner vents in the dashboard.


Air flow is divided between the vents in the dashboard and the floor vents.


Air flows from the floor


vents.


When you select automatically switches to Fresh Air mode.


, the system


Air flow is divided between


the floor vents and the defroster vents at the base of the windshield.


Air flows from the defroster vents at the base of the windshield, and the corner vents in the dashboard. When you select


or


, the system


automatically switches to Fresh Air mode. In these two modes, the A/C stays on with the indicator off.


The system automatically turns on the A/C and switches to Recirculation mode. Air flows from the center and side vents in the dashboard.


Comfort and Convenience Features


123


Main MenuTable of Contentsst 02/11/18 22:46:14 31SDP600 0127


Heating and Cooling


Vent Controls


CENTER VENTS


TABS


SIDE VENT


TAB


The direction of air flow from the vents in the center and each side of the dashboard is adjustable.


The vents in the corners of the dashboard can be opened and closed with the dials underneath them.


Close


Open


To adjust the air flow from each vent, move the tab in the center of each vent up-and-down and side-to-side.


124


Comfort and Convenience Features


Main MenuTable of Contentsst 02/11/18 22:46:27 31SDP600 0128


How to Use the System This section covers how to set up the system controls for ventilation, heating, cooling, dehumidifying, and defrosting.


The engine must be running for the heater and air conditioning to generate hot and cold air. The heater uses engine coolant to warm the air. If the engine is cold, it will be several minutes before you feel warm air coming from the system. The air conditioning does not rely on engine temperature.


It is best to leave the system in Fresh Air mode under almost all conditions. Keeping the system in Recirculation mode, particularly with the A/C off, can cause the windows to fog up. Switch to Recirculation mode when you are driving through smoky or dusty conditions, then switch back to Fresh Air mode when the condition clears.


Heating and Cooling


RECIRCULATION BUTTON


FAN CONTROL DIAL


TEMPERATURE CONTROL DIAL


AIR CONDITIONING (A/C) BUTTON


MODE BUTTONS


The outside air intakes for the heating and cooling system are at the base of the windshield. Keep these clear of leaves and other debris.


Ventilation The flow-through ventilation system draws in outside air, circulates it through the interior, then exhausts it through vents near the rear window.


1.


2. 3.


Turn the temperature control dial all the way to the left. Make sure the A/C is off. Select Set the fan to the desired speed.


and Fresh Air mode.


CONTINUED


Comfort and Convenience Features


125


Main MenuTable of Contentsst 02/11/18 22:46:38 31SDP600 0129


Heating and Cooling


ToCoolwithA/C 1.


Turn on the A/C by pressing the A/C button. The light above the button comes on when a fan speed is selected. Make sure the temperature control dial is all the way to the left. Select If the outside air is humid, select Recirculation mode. If the outside air is dry, select Fresh Air mode. Set the fan to the desired speed.


2.


3. 4.


5.


FAN CONTROL DIAL


AIR CONDITIONING (A/C) BUTTON


RECIRCULATION BUTTON


TEMPERATURE CONTROL DIAL


MODE BUTTONS


To cool the interior with MAX A/C:


1. 2.


3.


Set the fan to the desired speed. Select the MAX A/C mode. The system automatically turns on the A/C, selects switches to Recirculation mode. Make sure the temperature control dial is all the way to the left.


and


If the interior is very warm from being parked in the sun, you can cool it down more rapidly by setting up the controls this way:


1. 2.


3. 4.


Start the engine. Turn on the A/C by pressing the A/C button. Make sure the tem- perature control dial is turned all the way to the left. Set the fan to maximum speed. Open the windows partially. Select


and Fresh Air mode.


126


Comfort and Convenience Features


When the interior has cooled down to a more comfortable temperature, close the windows and set the controls as described for normal cooling.


Main MenuTable of Contentsst 02/11/18 22:46:52 31SDP600 0130


) when driving in stop-and-go


Air conditioning places an extra load on the engine. Watch the engine coolant temperature gauge (see page 70
traffic or climbing a long, steep hill. If it moves near the red zone, turn off the A/C until the gauge reads normally.


ToHeat To warm the interior:


1. 2.


3. 4.


Start the engine. Select When you select system automatically switches to Fresh Air mode. Set the fan to the desired speed. Adjust the warmth of the air with the temperature control dial.


, the


ToHeatandDehumidifywithAir Conditioning Air conditioning, as it cools, removes moisture from the air. When used in combination with the heater, it makes the interior warm and dry.


1. 2. 3. 4.


Set the fan to the desired speed. Turn on the air conditioning. Select Adjust the temperature control dial so the mixture of heated and cooled air feels comfortable.


and Fresh Air mode.


Once the engine is warmed up, this setting is suitable for all driving conditions.


Heating and Cooling


ToDefogandDefrost To remove fog from the inside of the windows:


1. 2.


3.


4.


, the


Set the fan to the desired speed. Select When you select system automatically switches to Fresh Air mode and turns on the A/C. (The indicator above the

Loading...
x
