2003 Chevrolet Tracker Owners Manual

The 2003 Chevrolet Tracker Owner Manual

(SRS)

Seats and Restraint Systems

............................ ..................................... ........................................................ .......................................

Front Seats Rear Seats Safety Belts Child Restraints Supplemental Restraint System Restraint System Check Features and Controls

........................... ............................................... ............................................... ............................................. .......................................

1-1 1-2 1-7 1-10 1-30 ......... 1-51 1-59 2-1 2-2 2-7 2-1 1 ........... 2-14 2-32 2-34 2-37 2-39 3-1 3-2 3-1 8 ......... 3-25 ....................................... 3-37

Keys Doors and Locks Windows Starting and Operating Your Vehicle Mirrors Storage Areas Sunroof Convertible Top

.................................................... ......................................... .................................................. ....................................... Instrument Panel ............................................. .......................... ......................................

Instrument Panel Overview Climate Controls Warning Lights, Gages and Indicators Audio System(s)

.................................................

the Hood

and Your Vehicle

.......................................

Service and Appearance Care

Driving Your Vehicle Your Driving, the Road, Towing

.......................... ..................................................... .........................................................

4-1 ..... 4-2 ................................................... 4-44 5-1 5-3 5-5 ............... 5-10 5-51 ............................................... ..................................... 5-52 .................................... 5-54 ...................................................... 5-59 5-78 5-87 5-88 5-92 ...... 5-95 6-1 6-2

Service Fuel Checking Things Under Rear Axle Four-wheel Drive Bulb Replacement Tires Appearance Care Vehicle Identification Electrical System Capacities and Specifications Normal Maintenance Replacement Parts

..................................... ................................. ...................................... .....................

Maintenance Schedule ..................................... ................................

Maintenance Schedule Customer Assistance

Information .................... 7-1

Customer Assistance Information Reporting Safety Defects

...........................

.................. 7-2 7-10

Index ............................................................

Canadian Owners YOU can obtain a French copy of this manual from your dealer or from: Helm, Incorporated P.O. Box 07130 Detroit, MI 48207 About Driving Your Vehicle As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or an accident. Be sure to read the “on-pavement” and “off-road” driving guidelines in this manual. See Your Driving, the Road, and Your Vehicle on page 4-2 and Off-Road Driving with Your Four-Wheel-Drive Vehicle on page 4-15. How to Use This Manual Many people read their owner’s manual from beginning to end when they first receive their new vehicle. If you do this, it will help you learn about the features and controls for your vehicle. In this manual, you’ll find that pictures and words work together to explain things.

GENERAL MOTORS, GM, the GM Emblem, CHEVROLET, the CHEVROLET Emblem and the name TRACKER are registered trademarks of General Motors Corporation. This manual includes the latest information at the time it was printed. We reserve the right to make changes after that time without further notice. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division whenever it appears in this manual. Please keep this manual in your vehicle, so it will be there if you ever need it when you’re on the road. If you sell the vehicle, please leave this manual in it so the new owner can use it.

Litho in U.S.A. Part No. 22683299 A First Edition

‘Copyright General Motors Corporation 07/15/02 All Rights Reserved

I You will also find a circle

with a slash through it in this book. This safety symbol means “Don’t,’’ “Don’t do this” or “Don’t let this happen.”

Index

A good place to look for what you need is the Index in back of the manual. It’s an alphabetical list of what’s in the manual, and the page number where you’ll find it.

Safety Warnings and Symbols

You will find a number of safety cautions in this book. We use a box and the word CAUTION to tell you about things that could hurt you if you were to ignore the warning.

These mean there is something that could hurt you or other people.

In the caution area, we tell you what the hazard is. Then we tell you what to do to help avoid or reduce the hazard. Please read these cautions. If you don’t, you or others could be hurt.

Vehicle Damage Warnings

Also, in this book you will find these notices:

Notice: These mean there is something that could damage your vehicle. A notice will tell you about something that can damage your vehicle. Many times, this damage would not be covered by your warranty, and it could be costly. But the notice will tell you what to do to help avoid the damage. When you read other manuals, you might see CAUTION and NOTICE warnings in different colors or in different words. You’ll also see warning labels on your vehicle. They use the same words, CAUTION or NOTICE.

Vehicle Symbols Your vehicle has components and labels that use symbols instead of text. Symbols, used on your vehicle, are shown along with the text describing the operation or information relating to a specific component, control, message, gage or indicator. If you need help figuring out a specific name of a component, gage or indicator reference the following topics:

Seats and Restraint Systems in Section 1 Features and Controls in Section 2 Instrument Panel Overview in Section 3 Climate Controls in Section 3 Warning Lights, Gages and Indicators in Section 3 Audio System(s) in Section 3 Engine Compartment Overview in Section 5

iv

These are some examples of vehicle symbols you may find on your vehicle:

LATCH BOTH LAP AND SHOULDER BELTS TO PROTECT OCCUPANT

DO NOT TWIST SAFETY BELT WHEN ATTACHING

MOVE SEAT

/= FULLY \!f%

FASTEN SEAT BELTS

REARWARD* SECURE CHILD SEAT

PULL BELT

COMPLETELY rHEN SECURE CHILD SEAT

POWER WINDOW

DO NOT INSTALL A REAR-FACING CHILD RESTRAINT IN THIS SEATING POSITION

DO NOT INSTALL A 'ORWARD-FACING CHILD RESTRAINT IN THIS SEATING POSITION

DOOR LOCK UNLOCK

CAUTION POSSIBLE INJURY

PROTECT EYES BY SHIELDING

CAUSTIC BAlTERY 4CID COULD CAUSE BURNS

AVOID SPARKS OR FLAMES

'\I1'

SPARK OR FLAME COULD EXPLODE BATTERY

LIGHTING -

MASTER SWITCH

8- / , \

ENGINE COOLANT TEMP

FUSE BOX ACCESS

ENGINE COOLANT FAN

COOLANT a

BAlTERY CHARGING SYSTEM

PARKING pf LAMPS A {{io $0

DAYTIME RUNNING LAMPS

ENGINE OIL

FLASHER

PRESSURE Y W ANTI-LOCK (@)

BRAKES

LAMPS

OWNERS MANUAL

SERVICE

SERVICE MANUAL

Section

Seats and Restraint Systems

Front Seats .....................................................

-1-2

Manual Seats ................................................ 1.2 Manual Lumbar .............................................. 1.3 Reclining Seatbacks ........................................ 1-3 Head Restraints ............................................. 1.5 ............................................. 1-5 Easy Entry Seat Rear Seats ....................................................... 1-7 Rear Seat Operation ....................................... 1-7 Safety Belts ................................................... 1-1 0 Safety Belts: They Are for Everyone ................ 1-10 Questions and Answers About Safety Belts ...... 1-14 How to Wear Safety Belts Properly ................. 1-16 Driver Position .............................................. 1-1 6 Safety Belt Use During Pregnancy .................. 1-24 Right Front Passenger Position ....................... 1-25 Center Passenger Position ............................. 1-25 .................................. 1-26 Rear Seat Passengers Safety Belt Extender ..................................... 1-29 Child Restraints ............................................. 1-30 Older Children .............................................. 1-30 Infants and Young Children ............................ 1-32 Child Restraint Systems ................................. 1-36 Where to Put the Restraint ............................. 1-39 Top Strap ............ 1-39

.............................

Top Strap Anchor Location ............................. 1.41 Lower Anchorages and Top Tethers for

Children (LATCH System) ........................... 1-42

Securing a Child Restraint Designed for the

LATCH System ......................................... 1-44

Securing a Child Restraint in a Rear Outside Seat Position ............................................

1.44

Securing a Child Restraint in a Center Rear

Seat Position ............................................ 1-46

Securing a Child Restraint in the Right Front

Seat Position ............................................ 1.48

Supplemental Restraint

System (SRS) ............................................. 1-51 ............................... 1-53 Where Are the Air Bags? Inflate? .................... 1-54 When Should an Air Bag What Makes an Air Bag Inflate? ..................... 1-55 How Does an Air Bag Restrain? ..................... 1-55 What Will You See After an Air Bag Inflates? ... 1-56 Servicing Your Air Bag-Equipped Vehicle ......... 1-58 Adding Equipment to Your Air Bag-Equipped

Vehicle .................................................... 1-58 Restraint System Check .................................. 1-59 Checking Your Restraint Systems ................... 1-59 Replacing Restraint System Parts

After a Crash .......................

, ................. 1-59

1-1

Front Seats

Manual Seats

Lift the lever located under the front seat to unlock it.

to You can lose control of the veh....e if ,au adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you don’t want to. Adjust the driver’s seat only when the vehicle is not moving.

Slide the seat to where you want it and release the lever. Then try to move the seat with your body to make sure the seat is locked into place.

1-2

Manual Lumbar

Reclining Seatbacks

If your vehicle has this feature, turn the knob located on the driver’s side seatback clockwise or counterclockwise to adjust support of the lower back.

To adjust the seatback, lift the lever on the outboard side of the seat cushion. Release the lever to lock the seatback where you want it. Pull up on the lever, and the seat will go to its original upright position.

1 -3

PO

rec

ion when your vehicle

Sitting in a is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when you’re reclined like this. The shoulder belt can’t do its job because it won’t be against your body. Instead, it will be in front of you. In a crash you could go into it, receiving neck or other injuries. The lap belt can’t do its job either. In a crash the belt could go up over your abdomen. The belt forces would be there, not at your pelvic bones. This could cause serious internal injuries. For proper protection when the vehicle is in motion, have the seatback upright. Then sit well back in the seat and wear your safety belt properly.

1 -4

Head Restraints

Easy Entry Seat

For two-door models, the front seats of your vehicle make it easy to get in and out of the rear seat area.

Adjust your head restraint so that the top of the restraint When you pull up on the recliner release lever, is closest to the top of your head. This position reduces the chance of a neck injury in a crash. The head restraint can be adjusted to four positions. To raise the restraint, pull up on the restraint. To lower the restraint, push in the release button while you push down on the restraint.

the seatback will tilt forward and the whole seat can slide forward when pushed by hand.

1 -5

After someone gets into the rear seat area, move the seat rearward until it locks. Then move the seatback to its original position.

led,

can move.

-y easy e --y seat isn’t IC

If In a sudden stop or crash, the person sitting there could be injured. And, even if there is no crash or sudden stop, a driver sitting in an unlocked easy entry seat could be startled by the sudden movement and hit the wrong control or pedal, causing an accident. After you’ve used it, be sure to push rearward on any easy entry seat to be sure it is locked.

1 -6

To get out of the rear seat area, push the release pedal on the rear of the front passenger’s side front seat. Then tilt the seatback forward, and slide the whole seat forward.

Rear Seats

Rear Seat Operation

Folding the Seatback The rear seat in your vehicle folds to provide more cargo space. To fold the rear seats do the following:

If a head restraint is not installed on the seatback or stored in the vehicle properly, it could be thrown about the vehicle in a crash or sudden maneuver. People in the vehicle could be injured. Remove the head restraints only when you need to fold the seat, and be sure that the head restraints are stored securely in their proper storage location. When the seat is returned to the passenger position, be sure the head restraints are installed properly.

1. Fold the safety belt buckles and center safety belt (if equipped) into the pocket of the rear seatback.

1 -7

2. Pull the release straps located near the center of the vehicle to release the seat cushion. Fold the seat cushion forward.

3. Remove the head restraint from the seatback by raising the head restraint fully. Press the release button and remove the head restraint from the seatback.

1 -8

4. Store the head restraint in the top of the folded seat cushion.

6. Secure the two black straps attached to the back of the folded seat cushion by hooking them onto the knobs on the back of the seatback when folded down.

5.

Pull up on the seatback release knob(s) on top of the seatback and fold the seatback down.On two-door models, pull up on both release knobs at the same time to lower the seatback.

To raise the rear seat do the following: 1. Unhook the two black straps from the buttons on

the seatback.

2. Fold the rear seatback up. Push and pull on the

seatback to ensure it’s locked in position.

3. Reinstall the head restraints by inserting them into

the seatback. Make sure the head restraints are secure in the seatback.

4. Insert the plates of the two black straps into their storage slots on the bottom of the seat cushion. 5. Fold the seat cushion back and make sure it is

locked into position.

6. Remove the safety belt buckles and center safety

belt (if equipped) from the seatback pocket.

1-9

Safety Belts

Safety Belts: They Are for Everyone

This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts.

e can’t Dc.. - .A anyone ride where he or wear a safety belt properly. If you are in a crash and you’re not wearing a safety belt, your injuries can be‘much worse. You can hit things inside the vehicle or be ejected from it. You can be seriously injured or killed. In the same crash, you might not be, if you are buckled up. Always fasten your safety belt, and check that your passengers’ belts are fastened properly too.

1-10

,mgerous to ri in a cargo

- .L extrem, area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Be sure everyone in your vehicle is in a seat and using a safety belt properly.

Your vehicle has a light that comes on as a reminder to buckle up. See Safety Belt Reminder Light on page 3-27.

In most states and in all Canadian provinces, the law says to wear safety belts. Here’s why: They work.

Why Safety Belts Work When you ride in or on anything, you go as fast as it goes.

You never know if you’ll be in a crash. If you do have a crash, you don’t know if it will be a bad one. A few crashes are mild, and some crashes can be so serious that even buckled up, a person wouldn’t survive. But most crashes are in between. In many of them, people who buckle up can survive and sometimes walk away. Without belts they could have been badly hurt or killed. After more than 30 years of safety belts in vehicles, the facts are clear. In most crashes buckling up does matter ... a lot!

Take the simplest vehicle. Suppose it’s just a seat on wheels.

The person keeps going until stopped by something. In a real vehicle, it could be the windshield ...

or the instrument panel ...

1-13

or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense.

1-14

Q: If my vehicle has air bags, why should I have to A: Air bags are in many vehicles today and will be in

wear safety belts?

most of them in the future. But they are supplemental systems only; so they work with safety belts - not instead of them. Every air bag system ever offered for sale has required the use of safety belts. Even if you’re in a vehicle that has air bags, you still have to buckle up to get the most protection. That’s true not only in frontal collisions, but especially in side and other collisions.

home, why should I wear safety belts?

Q: If I’m a good driver, and I never drive far from A: You may be an excellent driver, but if you’re in an accident - even one that isn’t your fault - you and your passengers can be hurt. Being a good driver doesn’t protect you from things beyond your control, such as bad drivers. Most accidents occur within 25 miles (40 km) of home. And the greatest number of serious injuries and deaths occur at speeds of less than 40 mph (65 km/h). Safety belts are for everyone.

1-15

How to Wear Safety Belts Properly This part is only for people of adult size. Be aware that there are special things to know about safety belts and children. And there are different rules for smaller children and babies. If a child will be riding in your vehicle, see Older Children on page 7-30 or lnfants and Young Children on page 1-32. Follow those rules for everyone’s protection. First, you’ll want to know which restraint systems your vehicle has. We’ll start with the driver position. Driver Position This part describes the driver’s restraint system. Lap-Shoulder Belt The driver has a lap-shoulder belt. Here’s how to wear it properly. 1. Close and lock the door. 2. Adjust the seat so you can sit up straight. To see

how, see “Seats” in the Index.

1-16

3. Pick up the latch plate and pull the belt across you.

Don’t let it get twisted. The shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly.

4. Push the latch plate into the buckle until it clicks.

Pull up on the latch plate to make sure it is secure. If the belt isn’t long enough, see Safety Belt Extender on page 1-29. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

5. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder belt.

The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen. This could cause serious or even fatal injuries. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The safety belt locks if there’s a sudden stop or crash, or if you pull the belt very quickly out of the retractor.

1-17

Shoulder Belt Height Adjuster Before you begin to drive, move the shoulder belt adjuster to the height that is right for you.

To move it down, pull the knob and move the height adjuster to the desired position. You can move the adjuster up just by pulling out the knob and sliding the adjuster up. After you move the adjuster to where you want it, try to move it down without pulling out the knob to make sure it has locked into position. Adjust the height so that the shoulder portion of the belt is centered on your shoulder. The belt should be away from your face and neck, but not falling off your shoulder.

1-18

Q: What's wrong with this?

You can be seriously hurt if y8- -.r shol-. . is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body.

A: The shoulder belt is too loose. It won't give nearly

as much protection this way.

1-19

You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones. This could cause serious internal injuries. Always buckle your belt into the buckle nearest you.

Q: What's wrong with this?

A: The belt is buckled in the wrong place.

1-20

Q: What’s wrong with this?

A: The belt is over an armrest.

if 1

lr bell -Des You can be seriously injured over an armrest like this. The belt would be much too high. In a crash, you can slide under the belt. The belt force would then be applied at the abdomen, not at the pelvic bones, and that could cause serious or fatal injuries. Be sure the belt goes under the armrests.

1-21

Q: What’s wrong with this?

You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury. Also, the belt would apply too much force to the ribs, which aren’t as strong as shoulder bones. You could also severely injure internal organs like your liver or spleen.

A: The shoulder belt is worn under the arm. It should

be worn over the shoulder at all times.

1-22

0: What’s wrong with this?

V A can be seriously injL. ,d by a twisted belt. In a crash, you wouldn’t have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to fix it.

A: The belt is twisted across the body.

1-23

Safety Belt Use During Pregnancy

Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts.

To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.

1-24

A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout the pregnancy.

The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key to making safety belts effective is wearing them properly. Right Front Passenger Position To learn how to wear the right front passenger’s safety belt properly, see Driver Position on page I- 16. The right front passenger’s safety belt works the same way as the driver’s safety belt - except for one thing. If you ever pull the shoulder portion of the belt out all the way, you will engage the child restraint locking feature. If this happens, just let the belt go back all the way and start again. Center Passenger Position 4-Door Models

Lap Belt

When you sit in the center seating position, you have a lap safety belt, which has no retractor. The word “CENTER” is on both the buckle and latch plate. Also, the center buckle and latch plate are a different color than the two outboard buckles and latch plates. To make the belt longer, tilt the latch plate and pull it along the belt.

1-25

Rear Seat Passengers It’s very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who aren’t safety belted can be thrown out of the vehicle in a crash. And they can strike others in the vehicle who are wearing safety belts.

Rear Seat C 3 rutside Passenger D Positions

To make the belt shorter, pull its free end as shown until the belt is snug. Buckle, position and release it the same way as the lap part of a lap-shoulder belt. If the belt isn’t long enough, see Safety Belt Extender on page 1-29. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

1-26

Lap-Shoulder Belt The positions next to the windows have lap-shoulder belts. Here’s how to wear one properly.

2. Push the latch plate into the buckle until it clicks.

Pull up on the latch plate to make sure it is secure. When the shoulder belt is pulled out all the way, it will lock. If it does, let it go back all the way and start again. If the belt is not long enough, see Safety Belt Extender on page 7-29. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

1. Pick up the latch plate and pull the belt across you.

Don’t let it get twisted. The shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly.

1-27

3. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part.

1-28

The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under the belt would apply force at your abdomen. This could cause serious or even fatal injuries. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The safety belt locks if there’s a sudden stop or a crash, or if you pull the belt very quickly out of the retractor.

it,

~. usly hurt if your shoulder belt

is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body.

Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender. It’s free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you. The extender will be just for you, and just for the seat in your vehicle that you choose. Don’t let someone else use it, and use it only for the seat it is made to fit. To wear it, just attach it to the regular safety belt.

To unlatch the belt, just push the button on the buckle.

1-29

Child Restraints

Older Children

Q: What is the proper way to wear safety belts? A: If possible, an older child should wear a

lap-shoulder belt and get the additional restraint a shoulder belt can provide. The shoulder belt should not cross the face or neck. The lap belt should fit snugly below the hips, just touching the top of the thighs. It should never be worn over the abdomen, which could cause severe or even fatal internal injuries in a crash.

Accident statistics show that children are safer if they are restrained in the rear seat. In a crash, children who are not buckled up can strike other people who are buckled up, or can be thrown out of the vehicle. Older children need to use safety belts properly.

Older children who have outgrown booster seats should wear the vehicle’s safety belts.

1 -30

Never do this. Here two children are wearing the same belt. The belt can’t properly spread the impact forces. In a crash, the two children can becrushed together and seriously injured. A belt must be used by only one person at

Q: What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? A: Move the child toward the center of the vehicle, but be sure that the shoulder belt still is on the child’s shoulder, so that in a crash the child’s upper body would have the restraint the belt provides. If the child is so small that the shoulder belt is still very close to the child’s face or neck, you might want to place the child in a seat that has a lap belt, if your vehicle has one.

1-31

behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt. The belt’s force would then be applied right on the child’s abdomen. That could cause serious or fatal injuries.

Wherever the child sits, the lap portion of the belt should be worn low and snug on the hips, just touching the child’s thighs. This applies belt force to the child’s pelvic bones in a crash. Infants and Young Children Everyone in a vehicle needs protection! This includes infants and all other children. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle. Every time infants and young children ride in vehicles, they should have the protection provided by appropriate restraints. Young children should not use the vehicle’s adult safety belts alone, unless there is no other choice. Instead, they need to use a child restraint.

In fact,

Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is

CAUTION:

(Continued)

1 -32

People should never hold a baby in their arms while riding in a vehicle. A baby doesn’t weigh much -- until a crash. During a crash a baby will become so heavy it is not possible to holdit. For example, in a crash at only 25 mph (40 km/h), a 12-lb. (5.5 kg) baby will suddenly become a 240-lb. (1 10 kg) force on a person’s arms. A baby should be secured in an appropriate restraint.

1-33

m

Children who are up against, or very close to, any air bag when it inflates can be seriously injured or killed. Air bags plus lap-shoulder belts offer outstanding protection for adults and older children, but not for young children and infants. Neither the vehicle’s safety belt system nor its air bag system is designed for them. Young children and infants need the protection that a child restraint system can provide.

Q: What are the different types of add-on child

restraints?

A: Add-on child restraints, which are purchased by the vehicle’s owner, are available in four basic types. Selection of a particular restraint should take into consideration not only the child’s weight, height, and age but also whether or not the restraint will be compatible with the motor vehicle in which it will be used.

1 -34

I

I The body structure of a young child is quite ’ unlike that of an adult or older child, for whom the safety belts are designed. A young child’s hip bones are still so small that the vehicle’s regular safety belt may not remain low on the hip bones, as it should. Instead, it may settle

’ up around the child’s abdomen. In a crash, the 1 belt would apply force on a body area that’s

unprotected by any bony structure. This alone could cause serious or fatal injuries. Young children always should be secured in appropriate child restraints.

For most basic types of child restraints, there are many different models available. When purchasing a child restraint, be sure it is designed to be used in a motor vehicle. If it is, the restraint will have a label saying that it meets federal motor vehicle safety standards. The restraint manufacturer’s instructions that come with the restraint state the weight and height limitations for a particular child restraint. In addition, there are many kinds of restraints available for children with special needs.

Newborn infants need complete support, including support for the head and neck. This is necessary because a newborn infant’s neck is weak and its head weighs so much compared with the rest of its body. In a crash, an infant in a rear-facing seat settles into the restraint, so the crash forces can be distributed across the strongest part of an infant’s body, the back and shoulders. Infants always should be secured in appropriate infant restraints.

Child Restraint Systems

An infant car bed (A), a special bed made for use in a motor vehicle, is an infant restraint system designed to restrain or position a child on a continuous flat surface. Make sure that the infant’s head rests toward the center of the vehicle.

A rear-facing infant seat (B) provides restraint with the seating surface against the back of the infant. The harness system holds the infant in place and, in a crash, acts to keep the infant positioned in the restraint.

1-36

A forward-facing child seat (C-E) provides restraint for the child’s body with the harness and also sometimes with surfaces such as T-shaped or shelf-like shields.

A booster seat (F-G) is a child restraint designed to improve the fit of the vehicle’s safety belt system. Some booster seats have a shoulder belt positioner, and some high-back booster seats have a five-point harness. A booster seat can also help a child to see out the window.

1-37

When choosing a child restraint, be sure the child restraint is designed to be used in a vehicle. If it is, it will have a label saying that it meets federal motor vehicle safety standards. Then follow the instructions for the restraint. You may find these instructions on the restraint itself or in a booklet, or both. These restraints use the belt system in your vehicle, but the child also has to be secured within the restraint to help reduce the chance of personal injury. When securing an add-on child restraint, refer to the instructions that come with the restraint which may be on the restraint itself or in a booklet, or both, and to this manual. The child restraint instructions are important, so if they are not available, obtain a replacement copy from the manufacturer.

Q: How do child restraints work? A: A child restraint system is any device designed for use in a motor vehicle to restrain, seat, or position children. A built-in child restraint system is a permanent part of the motor vehicle. An add-on child restraint system is a portable one, which is purchased by the vehicle’s owner. For many years, add-on child restraints have used the adult belt system in the vehicle. To help reduce the chance of injury, the child also has to be secured within the restraint. The vehicle’s belt system secures the add-on child restraint in the vehicle, and the add-on child restraint’s harness system holds the child in place within the restraint. One system, the three-point harness, has straps that come down over each of the infant’s shoulders and buckle together at the crotch. The five-point harness system has two shoulder straps, two hip straps and a crotch strap. A shield may take the place of hip straps. A T-shaped shield has shoulder straps that are attached to a flat pad which rests low against the child’s body. A shelf- or armrest-type shield has straps that are attached to a wide, shelf-like shield that swings up or to the side.

1-38

Where to Put the Restraint

Accident statistics show that children are safer if they are restrained in the rear rather than the front seat. General Motors, therefore, recommends that child restraints be secured in a rear seat, including an infant riding in a rear-facing infant seat, a child riding in a forward-facing child seat and an older child riding in a booster seat. Never put a rear-facing child restraint in the front passenger seat. Here’s why:

A child in a rear-facing child restraint can be seriously injured or killed if the right front passenger’s air bag inflates. This is because the back of the rear-facing child restraint would be very close to the inflating air bag. Always secure a rear-facing child restraint in a rear seat. You may secure a forward-facing child restraint in the right front seat, but before you do, always move the front passenger seat as far back as it will go. It’s better to secure the child restraint in a rear seat.

Wherever you install it, be sure to secure the child restraint properly. Keep in mind that an unsecured child restraint can move around in a collision or sudden stop and injure people in the vehicle. Be sure to properly secure any child restraint in your vehicle - even when no child is in it. Top Strap Some child restraints have a top strap, or “top tether.” It can help restrain the child restraint during a collision. For it to work, a top strap must be properly anchored to the vehicle. Some top strap-equipped child restraints are designed for use with or without the top strap being anchored. Others require the top strap always to be anchored. Be sure to read and follow the instructions for your child restraint. If yours requires that the top strap be anchored, don’t use the restraint unless it is anchored properly.

1-39

If the child restraint does not have a top strap, one can be obtained, in kit form, for many child restraints. Ask the child restraint manufacturer whether or not a kit is available.

Anchor the top strap to one of the following anchor points. Be sure to use an anchor point located on the same side of the vehicle as the seating position where the child restraint will be placed. Raise the head restraint and route the top strap under it. See Head Restraints on page 1-5. Once you have the top strap anchored, you’ll be ready to secure the child restraint itself. Tighten the top strap when and as the child restraint manufacturer’s instructions say.

In Canada, the law requires that forward-facing child restraints have a top strap, and that the strap be anchored. In the United States, some child restraints also have a top strap. If your child restraint has a top strap, it should be anchored.

1-40

Top Strap Anchor Location

Your vehicle’s top strap anchors for the rear seating positions are located on the floor of the rear cargo area, along the outside edge. If your vehicle is equipped with a luggage compartment cover, remove it before using the top strap. When routing the top strap at an outboard seating position, pass it between the head restraint and the rear seatback.

When routing the top strap at the center seating position, be sure to pass it between the rear seatbacks if the top strap connection to the child restraint is below the top of the rear seatback.

1-41

Lower Anchorages and Top Tethers for Children (LATCH System) Your vehicle has the LATCH system. You'll find anchors (A) in the rear outside seat positions. To assist you in locating the anchors for this child restraint system, each seating position with the LATCH system will have a label applied to the seatback at

In order to use the system, you need either a forward-facing child restraint that has attaching points (B) at its base and a top tether anchor (C), or a rear-facing child restraint that has attaching points (B), as shown here.

each anchor position. I The labels are located

near the base of the seatbacks.

I -42

With this system, use the LATCH system instead of the vehicle’s safety belts to secure a child restraint.

If a LA1 bd-type child restraint isn’t attached to its anchorage points, the restraint won’t be able to protect the child correctly. In a crash, the child could be seriously injured or killed. Make sure that a LATCH-type child restraint is properly installed using the anchorage points, or use the vehicle’s safety belts to secure the restraint. See “Securing a Child Restraint Designed for the LATCH System’’ or “Securing a Child Restraint in a Rear Outside Seat Position” in the Index for information on how to secure a child restraint in your vehicle.

1-43

Securing a Child Restraint Designed for the LATCH System 1.

Find the anchors for the seating position you want to use, where the bottom of the seatback meets the back of the seat cushion. Put the child restraint on the seat. Attach the anchor points on the child restraint to the anchors in the vehicle. The child restraint instructions will show you how. If the child restraint is forward-facing, attach the top strap to the top strap anchor. See Top Strap on page 1-39. Tighten the top strap according to the child restraint instructions. Push and pull the child restraint in different directions to be sure it is secure.

2. 3.

4.

5.

To remove the child restraint, simply unhook the top strap from the top tether anchor and then disconnect the anchor points.

1-44

Securing a Child Restraint in a Rear Outside Seat Position

If your child restraint is equipped with the LATCH system, see Lower Anchorages and Top Tethers for Children (LATCH System) on page 1-42. You’ll be using the lap-shoulder belt. See Top Strap on page 7-39 if the child restraint has one. Be sure to follow the instructions that came with the child restraint. Secure the child in the child restraint when and as the instructions say. 1. Put the restraint on the seat. 2. Pick up the latch plate, and run the lap and shoulder

portions of the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how.

To remove the child restraint, just unbuckle the vehi safety belt and let it go back all the way. The safety belt will move freely again and be ready to work for adult or larger child passenger. Securing a Child Restraint in a Center Rear Seat Position 4-Door Models

cle’s

an

5.

6.

To tighten the belt, feed the shoulder belt back into the retractor while you push down on the child restraint. If you’re using a forward-facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt. Push and pull the child restraint in different directions to be sure it is secure.

You’ll be using the lap belt. The word “CENTER is on both the buckle and latch plate. Also, the center buckle and latch plate are a different color than the two outboard buckles and latch plates. Be sure to follow the instructions that came with the child restraint. Secure the child restraint when and as the instructions say. See Top Strap on page 1-39 if the child has one.

1 -46

1.

2. 3.

Make the belt as long as possible by tilting the latch plate and pulling it along the belt. Put the restraint on the seat. Run the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how.

4. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

5. To tighten the belt, pull its free end while you push

down on the child restraint. If you’re using a forward-facing child restraint, you may find it helpful to use your knee to push the child restraint as you tighten the belt.

6. Push and pull the child restraint in different

directions to be sure it is secure.

1 -47

To remove the child restraint, just unbuckle the vehicle’s safety belt. It will be ready to work for an adult or larger child passenger. Securing a Child Restraint in the Right Front Seat Position

Your vehicle has a right front passenger air bag. Never put a rear-fapiqg child r e s t + % in this seat. Here’s why:

A child in a rear-facing child restraint can be seriously injured or killed if the right front passenger’s air bag inflates. This is because the (Continued)

CAUTION:

1-48

CAUTION

(Continued)

back of the rear-facing child restraint would be very close to the inflating air bag. Always secure a rear-facing child restraint in a rear seat.

Although a rear seat is a safer place, you can secure a forward-facing child restraint in the right front seat. You’ll be using the lap-shoulder belt. See Top Strap on page 1-39 if the child restraint has one. Be sure to follow the instructions that came with the child restraint. Secure the child in the child restraint when and as the instructions say. 1. Because your vehicle has a right front passenger

air bag, always move the seat as far back as it will go before securing a forward-facing child restraint. See Manual Seats on page 1-2.

2. Put the restraint on the seat. 3. Pick up the latch plate, and run the lap and shoulder

portions of the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how.

4. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

5. Pull the rest of the shoulder belt all the way out of

the retractor to set the lock.

1-49

7. Push and pull the child restraint in different

directions to be sure it is secure.

To remove the child restraint, just unbuckle the vehicle’s safety belt and let it go back all the way. The safety belt will move freely again and be ready to work for an adult or larger child passenger.

6. To tighten the belt, feed the shoulder belt back into

the retractor while you push down on the child restraint. You may find it helpful to use your knee to push down on the child restraint as you tighten the belt.

1-50

Supplemental Restraint System (SRS) This part explains the Supplemental Restraint System (SRS) or air bag system. Your vehicle has air bags - one air bag for the driver and another air bag for the right front passenger. Frontal air bags are designed to help reduce the risk of injury from the force of an inflating air bag. But these air bags must inflate very quickly to do their job and comply with federal regulations.

Here are the most important things to know about the air bag system:

You can be severely injured or killed in a crash if you aren’t wearing your safety belt - even if you have air bags. Wearing your safety belt i during a crash helps reduce your chance of

hitting things inside the vehicle or being ejected from it. Air bags are designed to workwith safety belts, but don’t replace them. Airbags are designed to deploy only in moderate to severe frontal and near frontal crashes. They aren’t designed to inflate at all low-speed frontal crashes, or in many side crashes. And, for some unrestrained occupants, air bags may provide less protection crashes than more forceful air bags have provided in the past. Everyone in your vehicle should wear a safety belt properly - whether or not there’s an air bag for that person.

in rollover, rear or

in frontal

1-51

II Anyone who is up against, or very close to, any air bag when it inflates can be seriously injured or killed. Air bags plus lap-shoulder belts offer the best protection for adults, but not for young children and infants. Neither thevehicle’s safety belt system nor its air bag system is designed for them. Young children and infants need the protection that a child restraint system can provide. Always secure children properly in your vehicle. To read how, see the parts of this manual called “Older Children” and “Infants and Young Children”.

- - - _.

._I

Air bags inflate w---- grea’ wce, faster an the blink of an eye. If you’re too close to an inflating air bag, as you would be if you were leaning forward, it could seriously injure you. Safety belts help keep you in position before and during a crash. Always wear your safety belt, even with air bags. The driver should sit as far back as possible while still maintaining control of the vehicle.

1-52

AIR BAG

There is a air bag readiness light on the instrument panel, which shows AIR BAG.

Where Are the Air Bags?

The system checks the air bag electrical system for malfunctions. The light tells you if there is an electrical problem. See Air Bag Readiness Light on page 3-28 for more information.

The driver’s air bag is in the middle of the steering wheel.

1-53

If something is between an occupant and an air bag, the bag might not inflate properly or it might force the object into that person causing severe injury or even death. The path of an inflating air bag must be kept clear. Don’t put anything between an occupant and an air bag, and don’t attach or put anything on the steering wheel hub or on or near any other air bag covering.

When Should an Air Bag Inflate? An air bag is designed to inflate in a moderate to severe frontal, or near-frontal crash. The air bag will inflate only if the impact speed is above the system’s designed “threshold level.” If your vehicle goes straight into a wall that doesn’t move or deform, the threshold level is about 9 to 13 mph (14 to 21 km/h). The threshold level can vary, however, with specific vehicle design, so that it can be somewhat above or below this range.

The right front passenger’s air bag is in the instrument panel on the passenger’s side.

1-54

If your vehicle strikes something that will move or deform, such as a parked car, the threshold level will be higher. The air bag is not designed to inflate in rollovers, rear impacts, or in many side impacts because inflation would not help the occupant. In any particular crash, no one can say whether an air bag should have inflated simply because of the damage to a vehicle or because of what the repair costs were. Inflation is determined by the angle of the impact and how quickly the vehicle slows down in frontal or near-frontal impacts. The air bag system is designed to work properly under a wide range of conditions, including off-road usage. Observe safe driving speeds, especially on rough terrain. As always, wear your safety belt. See Off-Road Driving with Your Four-Wheel-Drive Vehicle on page 4-15 for more tips on off-road driving.

What Makes an Air Bag Inflate? In an impact of sufficient severity, the air bag sensing system detects that the vehicle is in a crash. The sensing system triggers a release of gas from the inflator, which inflates the air bag. The inflator, air bag, and related hardware are all part of the air bag modules inside the steering wheel and in the instrument panel in front of the right front passenger. How Does an Air Bag Restrain? In moderate to severe frontal or near-frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. Air bags supplement the protection provided by safety belts. Air bags distribute the force of the impact more evenly over the occupant’s upper body, stopping the occupant more gradually. But air bags would not help you in many types of collisions, including rollovers, rear impacts and many side impacts, primarily because an occupant’s motion is not toward those air bags. Air bags should never be regarded as anything more than a supplement to safety belts, and then only in moderate to severe frontal or near-frontal collisions.

1-55

What Will You See After an Air Bag Inflates? After the air bag inflates, it quickly deflates, so quickly that some people may not even realize the air bag inflated. Some components of the air bag module - the steering wheel hub for the driver’s air bag, or the instrument panel for the right front passenger’s bag - will be hot for a short time. The parts of the bag that come into contact with you may be warm, but not too hot to touch. There will be some smoke and dust coming from the vents in the deflated air bags. Air bag inflation doesn’t prevent the driver from seeing or being able to steer the vehicle, nor does it stop people from leaving the vehicle.

When an air bag inflates, there is ,..st air. This dust could cause breathing problems for people with a history of asthma or other breathing trouble. To avoid this, everyone in

in the

CAUTION:

(Continued)

1-56

t out as I

I n as it is safe

the vehicle sh Id to do so. If you have breathing problems but can’t get out of the vehicle after an air bag inflates, then get fresh air by opening a window or a door. If you experience breathing problems following an air bag deployment, you should seek medical attention.

In many crashes severe enough to inflate the air bag, windshields are broken by vehicle deformation. Additional windshield breakage may also occur from the right front passenger air bag.

Air bags are designed to inflate only once. After they inflate, you’ll need some new parts for your air bag system. If you don’t get them, the air bag system won’t be there to help protect you in another crash. A new system will include air bag modules and possibly other parts. The service manual for your vehicle covers the need to replace other parts.

e

Your vehicle is equipped with a crash sensing and diagnostic module, which records information about the air bag system. The module records information about the readiness of the system, when the system commands air bag driver’s safety belt usage at deployment. Let only qualified technicians work on your air bag systems. Improper service can mean that an air bag system won’t work properly. See your dealer for service.

inflation and

Notice: If you damage the covering for the driver’s or the right front passenger’s air bag, the bag may not work properly. You may have to replace the air bag module in the steering wheel or both the air bag module and the instrument panel for the right front passenger’s air bag. Do not open or break the air bag coverings.

If your vehicle ever gets into a lot of water - such as water up to the carpeting or higher - or if water enters your vehicle and soaks the carpet, the air bag controller can be soaked and ruined. If this ever happens, and then you start your vehicle, the damage could make the air bags inflate, even if there’s no crash. You would have to replace the air bags as well as the sensors and related parts. If your vehicle is ever in a flood, or if it is exposed to water that soaks the carpet, you can avoid needless repair costs by turning off the vehicle immediately and disconnecting the battery cables. Don’t let anyone start the vehicle under any circumstances. See your dealer for service.

1-57

Servicing Your Air Bag-Equipped Vehicle

Air bags affect how your vehicle should be serviced. There are parts of the air bag system in several places around your vehicle. You don’t want the system to inflate while someone is working on your vehicle. Your dealer and the service manual have information about servicing your vehicle and the air bag system. To purchase a service manual, see Service Publications Orderinn lnformation on page 7- I 1.

Adding Equipment to Your Air Bag-Equipped Vehicle Q: If I add a push bumper or a bicycle rack to the

front of my vehicle, will it keep the air bags from working properly? A: As long as the push bumper or bicycle rack is attached to your vehicle so that the vehicle’s basic structure isn’t changed, it’s not likely to keep the air bags from working properly in a crash.

For up to 15 seconds after the ignition key is turned off and the battery is disconnected, an air bag can still inflate during improper service. You can be injured if you are close to an air bag when it inflates. Avoid wires wrapped with yellow tape or yellow connectors. They are probably part of the air bag system. Be sure to follow proper service procedures, and make sure the person performing work for you is qualified to do so.

The air bag system does not need regular maintenance.

1-58

Q: Is there anything I might add to the front of the

vehicle that could keep the air bags from working properly?

A: Yes. If you add things that change your vehicle’s frame, bumper system, front end sheet metal or height, they may keep the air bag system from working properly. Also, the air bag system may not work properly if you relocate any of the air bag sensors. If you have any questions about this, you should contact Customer Assistance before you modify your vehicle. The phone numbers and addresses for Customer Assistance are in Step Two of the Customer Satisfaction Procedure on page 7-2.

Restraint System Check

Checking Your Restraint Systems

Now and then, make sure the safety belt reminder light . and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired. Torn or frayed safety belts may not protect you in a crash. They can rip apart under impact forces. If a belt is torn or frayed, get a new one right away. Also look for any opened or broken air bag covers, and have them repaired or replaced. (The air bag system does not need regular maintenance.)

Replacing Restraint System Parts After a Crash

A crash can damage the restraint systems in your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or even death in a crash. To help make sure your restraint systems are working properly after a crash, have them inspected and any necessary replacements made as soon as possible.

If you’ve had a crash, do you need new belt or LATCH system parts? After a very minor collision, nothing may be necessary. But if the belts were stretched, as they would be if worn during a more severe crash, then you need new parts.

1 -59

If the LATCH system was being used during a more severe crash, you may need new LATCH system parts. If belts are cut or damaged, replace them. Collision damage also may mean you will need to have LATCH system, safety belt or seat parts repaired or replaced. New parts and repairs may be necessary even if the belt or LATCH system wasn’t being used at the time of the collision.

If an air bag inflates, you’ll need to replace air bag system parts. See the part on the air bag system earlier in this section.

1-60

Section 2

Features and Controls

Keys ............................................................... 2-2 Remote Keyless Entry System ......................... 2-3 Remote Keyless Entry System Operation ........... 2-4 Doors and Locks ............................................. 2-7 Door Locks .................................................... 2-7 Power Door Locks .......................................... 2-7 Rear Door Security Locks ................................ 2-9 Leaving Your Vehicle ...................................... 2-9 Tailgate ....................................................... 2-10 Windows ........................................................ 2-11 Manual Windows .......................................... 2-11 Power Windows ............................................ 2-12 Sun Visors ................................................... 2-13 Starting and Operating Your Vehicle ................ 2-14 New Vehicle Break-In ......................... .... 2-14 Ignition Positions .......................................... 2-14 Starting Your Engine ..................................... 2-16 .................................. 2-17 Engine Coolant Heater Automatic Transmission Operation ................... 2-18 Manual Transmission Operation ...................... 2-22 Four-wheel Drive .......................................... 2-24 Parking Brake .............................................. 2-26 Shifting Into Park (P) ..................................... 2-26 Shifting Out of Park (P) ................................. 2-28

Parking Your Vehicle ..................................... 2.29 Parking Over Things That Burn ....................... 2-29 Engine Exhaust ............................................ 2-30 Running Your Engine While You Are Parked .... 2-30 Mirrors ........................................................... 2-32 Manual Rearview Mirror ................................. 2-32 Outside Manual Mirrors .............................. 2-32 ............ 2-32 Outside Power Mirrors ........... Outside Convex Mirror ....................... ..... 2-33 Storage Areas ................................................ 2-34 Glove Box ................................................... 2-34 Cupholder(s) ................................................ 2-34 Coinholder(s) ................................................ 2-34 Luggage Carrier ........................................... 2-34 Convenience Net .......................................... 2-36 Cargo Cover ................................................ 2-36 Sunroof ......................................................... 2-37 Opening and Closing the Sunroof ................... 2-37 Convertible Top .............................................. 2-39 ........ 2-39 Removing and Installing the Rear Window Removing and Installing the Side Window ........ 2-40 Lowering and Raising the

Canvas Top .............................................. 2-42

2- 1

Keys

Leaving children in a vehicle with the ignition key is dangerous for many reasons. A child or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. Don’t leave the keys in a vehicle with children.

2-2

One key is used for the ignition, the doors and all other locks.

When a new vehicle is delivered, the dealer removes the metal plate from the key ring and gives it to the first owner. The metal plate has a code on it that tells your dealer or a qualified locksmith how to make extra keys. Keep the code in a safe place. If you lose your keys, you’ll be able to have new ones made easily using this code.

If you need a new key, contact your dealer who can obtain the correct key code. See Roadside Assistance Program on page 7-6 for more information. Notice: Your vehicle has a number of features that can help prevent theft. You can have a lot of trouble getting into your vehicle if you ever lock your keys inside. You may even have to damage your vehicle to get in. So be sure you have spare keys. Remote Keyless Entry System If equipped, the remote keyless entry system operates on a radio frequency subject to Federal Communications Commission (FCC) Rules and with Industry Canada. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference received,

including interference that may cause undesired operation of the device.

This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference received,

including interference that may cause undesired operation of the device.

2-3

Changes or modifications to this system by other than an authorized service facility could void authorization to use this equipment. At times you may notice a decrease in range. This is normal for any remote keyless entry system. If the transmitter does not work or if you have to stand closer to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your vehicle. You may need to stand closer during rainy or snowy weather. Check the location. Other vehicles or objects may be blocking the signal. Take a few steps to the left or right, hold the transmitter higher, and try again. Check to determine if battery replacement or resynchronization is necessary. See “Battery Replacement” and “Resynchronization” under Remote Keyless Entry System Operation on page 2-4. If you are still having trouble, see your dealer or a qualified technician for service.

2-4

Remote Keyless Entry System Operation If your vehicle has this feature, you can lock and unlock your doors from about 3 feet (1 m) up to 30 feet (9 m) away using the remote keyless entry transmitter supplied with your vehicle. With the remote keyless entry system, your vehicle will have an entry lighting feature. See “Entry Lighting” under Interior Lamps on page 3-14.

The following functions are available with the remote keyless entry system:

LOCK: All doors will automatically lock when the LOCK button on the transmitter is pressed.

UNLOCK: The driver’s door will unlock automatically when the UNLOCK button on the transmitter is pressed. If the UNLOCK button is pressed again within five seconds, all remaining doors will be unlocked. Matching Transmitter@) to Your Vehicle Each remote keyless entry transmitter is coded to prevent another transmitter from unlocking your vehicle. If a transmitter is lost or stolen, a replacement can be purchased through your dealer. Remember to bring any remaining transmitters with you when you go to your dealer. When the dealer matches the replacement transmitter to your vehicle, any remaining transmitters must also be matched. Once your dealer has coded the new transmitter, the lost transmitter will not unlock your vehicle. Each vehicle can have a maximum of two transmitters matched to it. Battery Replacement Under normal use, the battery in your remote keyless entry transmitter should last about two years. You can tell the battery is weak if the transmitter won’t work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it’s probably time to change the battery.

Notice: When replacing the battery, use care not to touch any of the circuitry. Static from your body transferred to these surfaces may damage the transmitter.

To replace the battery in the transmitter do the following: 1. Use a coin or similar object to separate the

bottom half from the top half of the transmitter. 2. Remove the battery and replace it with the new one. Make sure the positive side of the battery faces down. For battery replacement, use a 3-volt battery, type CR2032 or equivalent.

2-5

3. Read the instructions inside the case. 4. Put the two halves back together. Make sure the

cover is on tight so water won’t get in.

5. Check the operation of the transmitter with your

vehicle. If the transmitter does not work, try resynchronizing the transmitter with the receiver. See “Resynchronization” following.

Resynchronization Your remote keyless entry system is equipped with a security system that prevents anyone from recording and playing back your signal. The transmitter does not send the same signal twice to the receiver. The receiver will not respond to a signal that has been sent to it more than once.

To resynchronize your transmitter and receiver, follow these directions:

1. Stand close to your vehicle. 2. Press and hold the LOCK and UNLOCK buttons on

the transmitter at the same time.

3. Hold the buttons for at least seven seconds. During

this time, the doors should lock and unlock once. This confirms the resynchronization. If the doors do not lock and unlock, see your dealer for service.

2-6

Doors and Locks

Door Locks

There are several ways to lock and unlock your vehicle. From the outside, use your key. To lock the door, turn the key toward the front of the vehicle. To unlock the door, turn the key toward the rear.

Unlocked doors can be dangerous.

Passengers - especially children - can easily open the doors and fall out of a moving vehicle. When a door is locked, the handle won’t open it. You increase the chance of being thrown out of the vehicle in a crash if the doors aren’t locked. So, wear safety belts properly and lock the doors whenever you drive. Young children who get into unlocked vehicles may be unable to get out. A child can be overcome by extreme heat and can suffer permanent injuries or even death from heat stroke. Always lock your vehicle whenever you leave it. Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. Locking your doors can help prevent this from happening.

To lock the door from the inside, push down on the manual lock rod located on the door. To unlock it, pull up on the manual

If your vehicle is equipped with the remote keyless entry system, you can use the transmitter to lock and unlock the doors. See “Remote Keyless Entry System” later in this section.

2-7

Power Door Locks

If your four-door model has power door locks, the switch is located on the driver’s door armrest.

To lock all the doors and the tailgate, press the right side of the switch. To unlock the doors and the tailgate, press the left side of the switch.

Four-Door Models

You can lock all doors from the outside by inserting the key into either front door lock cylinder, and turning it toward the front of the vehicle. If your vehicle is equipped with the remote keyless entry system, you can also-lock and unlock all doors using the remote keyless entry transmitter. See Remote Keyless Entry System Operation on page 2-4. If your two-door model has power door locks, the switch is located on the driver’s door armrest.

2-8

Two-Door Models

the switch rearward. The tailaate

To lock both side doors, push the switch forward. To unlock the doors ~ u l l does not have a power lock, and will need to be manually locked and unlocked with a key. You can lock both side doors from the outside by inserting the key into either front door lock cylinder, and turning it toward the front of the vehicle. If your vehicle is equipped with the remote keyless entry system, you can also lock and unlock the side doors using the remote keyless entry transmitter. See Remote Keyless Entry System Operation on page 2-4.

Rear Door Security Locks

Your vehicle may be equipped with rear door security locks that help prevent passengers from opening the rear doors of your vehicle from the inside.

The rear security door locks are located on the inside of the rear doors.

Using the Rear Door Security Lock 1. Move the lever down to engage the lock. 2. Close the door. 3. Do the same to the other rear door lock. The rear doors of your vehicle cannot be opened from the inside when this feature is in use.

Opening a Rear Door When the Security Lock Is On If you want to open a rear door when the security lock is on, unlock the door, then open the door from the outside. If you don’t cancel the security lock feature, adults or older children who ride in the rear won’t be able to open the rear door from the inside. You should let adults and older children know how these security locks work, and how to cancel the locks. Canceling a Rear Door Security Lock 1. Unlock the door from the inside and open the door

from the outside.

2. Move the lever up to disengage the lock. 3. Do the same for the other rear door. The rear door locks will now work normally.

Leaving Your Vehicle

If you are leaving the vehicle, take your keys, open your door and set the locks from inside. Then get out and close the door.

2-9

Tailgate Lock Release Use your key to lock or unlock your tailgate. If you have a convertible, you can still open or close the tailgate with the rear window closed.

Tailmate

__ can be dangerous to c. - Je with the tai - ite

open because carbon monoxide (CO) gas can come into your vehicle. You can’t see or smell ’ CO. It can cause unconsciousness and even

death. If you must drive with the tailgate open or if electrical wiring or other cable connections must pass through the seal between the body and the tailgate:

Make sure all other windows are shut. Turn the fan on your heating or cooling system to its highest speed and select the control setting that that will force outside air into your vehicle. See ”Comfort Controls” in the Index. If you have air outlets on or under the instrument panel, open them all the way. See ”Engine Exhaust” in the Index.

2-1 0

Windows

Leaving children in a vehicle with the windows closed is dangerous. A child can be overcome by the extreme heat and can suffer permanent injuries or even death from heat stroke. Never leave a child alone in a vehicle, especially with the windows closed in warm or hot weather.

Manual Windows Use the window crank to open and close each window.

2-1 1

Power Windows

Four-Door Models

Two-Door Models

With power windows, switches on the driver’s door operate each window when the ignition is on. Push down on the front of the switch to lower a window and lift up the front of the switch to raise a window. There is an individual control near each window.

2-1 2

Sun Visors To block out glare, you can swing down the visors. You can also swing them to the side. The visors may have extensions to give additional sun blockage. Visor Vanity Mirror If your vehicle has this feature, pull down the visor to expose the passenger’s side vanity mirror.

Express-Down Window The AUTO switch for the driver’s window has an express down feature. To use express down, push the switch all the way down. Release the switch and the window will lower completely. Pull up on the switch lightly and release it to stop the window partway. Window Lock Out On four-door models, press the right side of the switch to activate the lock-out feature. The passenger windows will not operate when this feature is active. Press the left side of the switch to return to normal window operation. On two-door models, press the WINDOW LOCK button to activate the lock-out feature. The passenger
