2000 Toyota Sienna Owners Manual

SECTION 7− 3

DO−IT−YOURSELF MAINTENANCE Electrical components Checking battery condition Battery recharging precautions Checking and replacing fuses Adding washer fluid Replacing light bulbs

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

256
257
258
259
259

255

00 SIENNA(U)

D If electrolyte gets on your skin, thoroughly wash the contact area. If you feel pain or burning, get medi- cal attention immediately.

D If electrolyte gets on your clothes, there is a possibility of its soaking through to your skin, so immediate- ly take off the exposed clothing and follow the procedure above, if nec- essary.

D If you happen to swallow electro- lyte, drink a large quantity of water or milk. Follow with milk of magne- sia, beaten raw egg or vegetable oil. Then go immediately for emer- gency help.

Checking battery condition— —Precautions

CAUTION

BATTERY PRECAUTIONS The battery produces flammable and explosive hydrogen gas. D Do not cause a spark from the bat-

tery with tools.

D Do not smoke or light a match near

the battery.

The electrolyte contains poisonous and corrosive sulfuric acid. D Avoid contact with eyes, skin or

clothes.

D Never ingest electrolyte. D Wear protective safety glasses when

working near the battery.

D Keep children away from the bat-

tery.

EMERGENCY MEASURES D If electrolyte gets

in your eyes, flush your eyes with clean water immediately immediate medical attention. If possible, con- tinue to apply water with a sponge or cloth while en route to the medi- cal office.

and get

256

—Checking battery exterior

Terminals

Ground cable

Hold−down clamp

Check the battery for corroded or loose terminal connections, cracks, or loose hold−down clamp. a. If the battery is corroded, wash it off with a solution of warm water and bak- ing soda. Coat the outside of the termi- nals with grease to prevent further cor- rosion.

b. If the terminal connections are loose, their clamp nuts—but do not

tighten overtighten.

c. Tighten

the hold−down clamp only enough to keep the battery firmly in place. Overtightening may damage the battery case.

NOTICE

z Be sure the engine and all accesso- ries are off before performing main- tenance.

z When checking the battery, remove the ground cable from the negative terminal (“−” mark) first and rein- stall it last.

z Be careful not to cause a short cir-

cuit with tools.

z Take care no solution gets into the

battery when washing it.

00 SIENNA(U)

—Checking battery fluid

Type A

Green

Dark

Clear or light yellow

Type B

Blue

White

Red

CHECKING BY THE HYDROMETER Check the battery condition by hydrometer color.

the

Hydrometer color

Type A

Type B

GREEN

BLUE

DARK WHITE

Condition

Good

Charging necessary. Have battery checked by your Toyota dealer.

CLEAR or LIGHT YELLOW

RED

Have battery checked by your Toyota dealer.

Battery recharging precautions During recharging, the battery is pro- ducing hydrogen gas. Therefore, before recharging: 1. If recharging with the battery installed on the vehicle, be sure to disconnect the ground cable.

2. Be sure the power switch on the re- charger the charger cables to the battery and when disconnecting them.

is off when connecting

CAUTION

D Always charge the battery in an un- confined area. Do not charge the battery in a garage or closed room where there is not sufficient ventila- tion.

D Only do a slow charge (5 A or less). Charging at a quicker rate is dangerous. The battery may ex- plode, causing personal injuries.

NOTICE

Never recharge the battery while the engine is running. Also, be sure all accessories are turned off.

257

00 SIENNA(U)

Checking and replacing fuses

Type A

Type B

Type C

258

Good

Blown

Good

Blown

Good

Blown

Type A fuses can be pulled out by the pull−out tool. The location of the pull−out tool is shown in the illustration. If you are not sure whether the fuse has blown, try replacing the suspected fuse with one that you know is good. If the fuse has blown, push a new fuse into the clip. Only install a fuse with the amperage rat- ing designated on the fuse box lid. If you do not have a spare fuse, in an the “A/C”, emergency you can pull out “RADIO NO.1” or fuse, which may be dispensable for normal driving, and use it if its amperage rating is the same. If you cannot use one of the same amper- age, use one that is lower,but as close as possible to, the rating. If the amperage is lower than that specified, the fuse might blow out again but this does not indicate anything wrong. Be sure to get the correct fuse as soon as possible and return the substitute to its original clip. It is a good idea to purchase a set of spare fuses and keep them in your ve- hicle for emergencies.

“RADIO NO.2”

If the headlights or other electrical components do not work, check the fuses. If any of the fuses are blown, they must be replaced. See “Fuse locations” in Section 7−1 for locations of the fuses. Turn the ignition switch and inoperative component off. Pull a suspected fuse straight out and check it. Determine which fuse may be causing the problem. The lid of the fuse box shows the name of the circuit for each fuse. See Section 8 of this manual for the functions controlled by each circuit.

the new

If fuse immediately blows out, there is a problem with the electrical sys- tem. Have your Toyota dealer correct it as soon as possible.

CAUTION

Never use a fuse with a higher am- perage rating, or any other object, in place of a fuse. This may cause ex- tensive damage and possibly a fire.

00 SIENNA(U)

Adding washer fluid If any washer does not work or low windshield washer fluid level warning light comes on, the washer tank may be empty. Add washer fluid. You may use plain water as washer fluid. in cold areas where tempera- However, tures freezing point, use fluid containing antifreeze. This washer product is available at your Toyota dealer and most auto parts stores. Follow the manufacturer’s directions for how much to mix with water.

range below

NOTICE

Do not use engine antifreeze or any other substitute because it may dam- age your vehicle’s paint.

following

illustrations show how

Replacing light bulbs— The to gain access to the bulbs. When replacing a bulb, make sure the ignition switch and light switch are off. Use bulbs with the wattage ratings given in the table.

CAUTION

Halogen bulbs have pressurized gas inside and require special handling. They can burst or shatter if scratched or dropped. Hold a bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands.

NOTICE

Only use a bulb of the listed type.

259

00 SIENNA(U)

—Headlights

1. Open the hood. Unplug the connec-

tor. Remove the rubber cover. If the connector is tight, wiggle it.

2. Release

the bulb retaining spring and remove the bulb. Install a new bulb and the bulb retaining spring.

To install a bulb, align the tabs of the bulb with the mounting hole.

the cutouts of

W Type

Bulb No. HB2 60/55

Light bulbs

Headlights

Parking, front turn signal and side marker lights Rear turn signal lights Stop and tail lights

Back−up lights

License plate lights

1157

27/8

1156

27

1157

27/8

921

168

18

18

High mounted stoplight Front personal lights —

921

Front interior light

—

Rear personal lights —

Rear interior light

Vanity mirror lights

—

—

Door courtesy lights

194

3.8

Luggage compartment light

—

A: HB2 halogen bulbs B: Single end bulbs C: Wedge base bulbs D: Double end bulbs 260

00 SIENNA(U)

—Parking, front turn signal and side marker lights

Use a Phillips−head screwdriver.

261

3. Install

the rubber cover with

the “TOP” mark upward, and snuggle on the boss. Then insert the connector. Make sure the rubber cover fits snugly on the connector and the headlight body. Aiming is not necessary after replacing the bulb. When aiming adjustment is nec- essary, contact your Toyota dealer.

00 SIENNA(U)

—Rear turn signal and, stop and tail lights

—Stop and tail, and back−up lights

Left side of the vehicle

Remove the bolts.

a: Rear turn signal light b: Stop and tail light

Right side of the vehicle

262

Remove the strap and handle.

00 SIENNA(U)

—License plate lights

a: Stop and tail light b: Back−up light

Use a Phillips−head screwdriver.

263

00 SIENNA(U)

—High mounted stoplight

Use a Phillips−head screwdriver.

264

00 SIENNA(U)

SECTION 8

SPECIFICATIONS Dimensions and weight Engine Fuel Service specifications Tires Fuses

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

266
266
267
267
269
270

265

00 SIENNA(U)

Engine Model:

1MZ−FE

Type:

6 cylinder V type 4 cycle, gasoline

Bore and stroke, mm (in.):

87.5 83.0 (3.44 3.27)

Displacement, cm3 (cu. in.):

2995 (182.8)

mm (in.)

mm (in.)

mm (in.)

mm (in.)

mm (in.)

mm (in.)

kg (lb.)

4915 (193.5)

1865

1710

(73.4) (67.3)∗1

2900 (114.2)

1565

(61.6)

1610
(63.4) 526 (1160)∗2
574 (1265)∗3
612 (1350)∗4

Dimensions and weight

Overall length

Overall width

Overall height

Wheelbase

Front tread

Rear tread

Vehicle capacity weight (occupants + luggage)

∗1: Unladen vehicle ∗2: Wagon ∗3: Van with rear seat ∗4: Van without rear seat

266

00 SIENNA(U)

Fuel Fuel type:

Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher. For improved vehicle performance, the use of premium unleaded gasoline with an Octane Rating of 91 (Research Oc- tane Number 96) or higher is recom- mended.

Fuel tank capacity, L (gal., Imp. gal.):

79 (21, 17.5)

Service specifications ENGINE Valve clearance (engine cold), mm (in.):

Intake Exhaust

0.15—0.25 (0.006—0.010) 0.25—0.35 (0.010—0.014)

Spark plug type:

DENSO NGK

Spark plug gap, mm(in.):

1.1 (0.043)

PK20TR11
BKR6EKPB11

Recommended oil viscosity (SAE):

Drive belt roughs No.BT−33−73F (used belt), Ibf:

tension measured with Bor- gauge

tension

drive

belt

Generator belt Power steering pump belt

125"10
115"20

ENGINE LUBRICATION Oil capacity (drain and refill), L (qt., Imp. qt.):

With filter Without filter

Oil grade:

4.7 (5.0, 4.1) 4.5 (4.8, 4.0)

API grade SJ, “Energy−Conserving” or ILSAC multigrade engine oil is recom- mended.

COOLING SYSTEM Total capacity, L (qt., Imp. qt.):

With rear heater Without rear heater

10.4 (11.0, 9.2) 9.5 (10.0, 8.4)

Coolant type:

“TOYOTA Long Life Coolant” or equiva- lent With ethylene−glycol type coolant for a proper corrosion protection of aluminum components Do not use alcohol type antifreeze or plain water alone.

267

00 SIENNA(U)

BRAKES Minimum pedal clearance when depressed with the pressure of 490 N (50 kgf, 110
lbf) with the engine running, mm (in.):

96 (3.8)

Pedal free play, mm (in.):

1—6 (0.04—0.24)

Pad wear limit, mm (in.):

1.0 (0.04)

Lining wear limit, mm (in.):

1.0 (0.04)

Parking brake adjustment when depressed with the pressure of 294 N (30 kgf, 66
lbf):

3—5 clicks

Fluid type:

SAE J1703 or FMVSS No.116 DOT 3

STEERING Wheel free play:

Less than 30 mm (1.2 in.)

Power steering fluid type:

Automatic transmission fluid DEXRONrII or III

BATTERY Open voltage∗ at 20_C (68_F):

12.6—12.8 V 12.2—12.4 V 11.8—12.0 V

Fully charged Half charged Discharged

∗: Voltage that is checked 20 minutes af- the

is removed with all

the key

ter lights turned off

Charging rates:

5 A max.

AUTOMATIC TRANSAXLE Automatic transmission

Fluid capacity (drain and refill), L (qt., Imp. qt.):

Up to 3.5 (3.7, 3.1)

Fluid type:

Automatic transmission fluid D−ll or DEXRONrIII (DEXRONrII)

Differential

Fluid capacity L (qt., Imp. qt.):

0.8 (0.8, 0.7)

Fluid type:

Automatic transmission fluid D−II or DEXRONrIII (DEXRONrII)

268

00 SIENNA(U)

Wheel nut torque, N·m (kgf·m, ft·lbf):

104 (10.5, 77)

Tires Tire size and pressure: Normal driving

Tire size

Tire pressure,

kPa (kgf/cm2 or bar, psi)

Wheel size

P205/70R15 95S

240 (2.4, 35)

15 6.5JJ

P215/65R15 95S

220 (2.2, 32)∗1
240 (2.4, 35)∗2

15 6.5JJ

T145/80D16

420 (4.2, 60)

16 4T

∗1: Vehicle load up to 6 passengers ∗2: Up to vehicle capacity weight

Trailer towing

Tire size

Tire pressure,

kPa (kgf/cm2 or bar, psi)

Wheel size

P205/70R15 95S

240 (2.4, 35)

15 6.5JJ

P215/65R15 95S

240 (2.4, 35)

15 6.5JJ

When driving under the above vehicle load conditions at sustained high speeds above 160 km/h (100 mph), in countries where such speeds are permitted by−law, inflate the front and rear tires to 240 kPa (2.4 kgf/cm2
or bar, 35 psi) provided that it does not exceed the maximum cold tire pressure molded on the tire sidewall.

269

00 SIENNA(U)

Fuses

Engine compartment (without daytime running light system)

Fuses (type A) 1. SPARE 10 A: Spare fuse 2. SPARE 15 A: Spare fuse 3. SPARE 30 A: Spare fuse 4. ALT−S 5 A: Charging system 5. H−LP RH 15 A: Right−hand headlight 6. EFI 15 A: Multiport fuel injection sys- injection

tem/sequential multiport system

fuel

Engine compartment (with towing package)

270

Engine compartment (without towing package)

7. HORN 10 A: Horn, theft deterrent sys-

tem

8. HAZ 10 A: Emergency flashers

00 SIENNA(U)

Engine compartment (with daytime running light system)

Instrument panel

Instrument panel

9. AM2 30 A:

“IGN” and

“STARTER”

15. H−LP LH (LWR) 10 A: Left−hand head-

19. WIPER 25 A: Windshield wipers and

fuses

light (low beam)

washer

10. H−LP LH 15 A: Left−hand headlight 11. RADIO NO.1 20 A: Car audio system 12. DOME 10 A: Clock, personal lights, vanity mirror lights, door courtesy lights, luggage compartment light, open door warning light, ignition switch light, theft deterrent system, daytime running light system, interior lights

13. ECU−B 10 A: Cruise control system, SRS warning light, power sliding door 14. DRL 5 A: Daytime running light system

16. H−LP RH

(LWR) 10 A: Right−hand

headlight (low beam)

17. HEATER 10 A: Air conditioning system,

rear window defogger

18. GAUGE 10 A: Gauges and meters, service reminder indicators and warning buzzers (except discharge and open door warning light), power windows, daytime running light system, back−up lights

20. MIRROR−HEATER 10 A: Multiport fuel injection system/sequential multiport fuel injection system, outside rear view mirror defogger

21. ECU−IG 15 A: Cruise control system, locking with theft

anti−lock brake system, wireless remote control system, deterrent system

271

Fuses (type C) 46. ALT 140 A: Charging system,

ABS”, fuses

“INP”,

“HTR” and

“FL “R/R A/C”

47. INP 100 A: “AM1” and “DEF” fuses 48. FL ABS 60 A: Anti−lock brake system

00 SIENNA(U)

31. TURN 7.5 A: Turn signal lights, emer-

gency flashers

32. RADIO NO.2 7.5 A: Car audio system 33. CIG 15 A: Cigarette lighter, clock, pow- er rear view mirror controls, SRS air- bag system, seat belt pretensioners, back−up lights, theft deterrent system

34. A/C 5 A: Air conditioning system 35. A/F HTR 25 A: EFI system Fuses (type B) 36. CDS FAN 40 A: Electric cooling fans 37. RDI FAN 40 A: Electric cooling fans 38. CDS FAN 30 A: Electric cooling fans 39. RDI FAN 30 A: Electric cooling fans 40. MAIN 40 A: “DRL”, “H−LP RH” and

“H−LP LH” fuses

41. R/R A/C 40 A: Rear air conditioning

system

42. HTR 50 A: Air conditioning system 43. DEF 30 A: Rear window defogger,

“MIRROR−HEATER” fuse

44. AM1 40 A: “INP” fuse 45. PWR 30 A: Power windows, electric moon roof, power seat, power sliding door, “PWR−VENT” fuse

22. IGN 5 A: Gauges and meters, charging system, SRS airbag system, seat belt injection pretensioners, multiport system/sequential multiport injec- tion system

fuel

fuel

23. STOP 15 A: Stop lights, cruise control tail

system, high−mounted stoplight, lights

24. TAIL 10 A: Parking lights, front side marker lights, license plate lights, tail lights

25. PWR−VENT 15 A: Power rear quarter

windows

26. OBD 7.5 A: On−board diagnosis sys-

tem

27. PWR−OUTLET 15 A: Power outlet 28. STARTER 5 A: Gauges and meters, SRS airbag system, seat belt preten- sioners, multiport fuel injection system/ sequential multiport fuel injection sys- tem

29. DOOR 20 A: Power door lock system,

theft deterrent system

30. PANEL 7.5 A: Gauge and meter, car audio system, clock, air conditioning system, instrument panel light control, rear window defogger, electronically controlled automatic transmission sys- tem, emergency flashers, parking lights

272

00 SIENNA(U)

SECTION 9

REPORTING SAFETY DEFECTS FOR U.S. OWNERS AND UNIFORM TIRE QUALITY GRADING Reporting safety defects for U.S. owners Uniform tire quality grading

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

274
274

273

00 SIENNA(U)

To contact NHTSA, you may either call the Auto Safety Hotline toll− at free (or 1−800−424−9393 366−0123 in Washington, D.C. area) or write to: NHTSA. U.S.De- partment of Transportation. Wash- ington, D.C. 20590. You can also obtain other information about mo- tor vehicle safety from the Hotline.

Reporting safety defects for U.S. owners If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately in- form the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll−free: 1−800−331−4331). If NHTSA receives similar com- plaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of ve- hicles, it may order a recall and remedy However, NHTSA cannot become involved in individual problems between you, your dealer, or Toyota Motor Sales, U.S.A., Inc.

campaign.

274

Uniform tire quality grading This information has been prepared in ac- cordance with regulations issued by the National Highway Traffic Safety Adminis- tration of the U.S. Department of Trans- portation. It provides the purchasers and/ or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades—All passenger car tires must conform to Federal Safety these Requirements grades. These quality grades are molded on the sidewall. Treadwear—The is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150
would wear one and a half (1−1/2) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual condi- tions of their use, however, and may de- part significantly the norm due to variations in driving habits, service prac- tices and differences in road characteris- tics and climate.

treadwear grade

in addition

from

to

00 SIENNA(U)

Warning: The temperature grades for this tire are established for a tire that is prop- erly inflated and not overloaded. Exces- sive speed, underinflation, or excessive loading, either separately or in combina- tion, can cause heat buildup and possible tire failure.

tire

Traction AA, A, B, C—The traction grades, from highest to lowest, are AA, A, B, and C, and they represent the tire’s ability to stop on wet pavement as mea- sured under controlled conditions on spe- cified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance. Warning: The traction grade assigned to this is based on braking (straight ahead) traction tests and does not include cornering (turning) traction. Temperature A, B, C—The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to de- generate and reduce tire life, and exces- sive temperature can lead to sudden tire failure. The grade C corresponds to a lev- el of performance which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No.109. Grades B and A represent higher levels of perfor- mance on the laboratory test wheel than the minimum required by law.

275

00 SIENNA(U)

276
