2 0 0 9

Q u i c k

R e f e r e n c e

G u i d e

MN 00505-QRG09-CAMH Printed in the USA 1/08

Interactive Owner’s Guide

Have a question about the main features of your new Toyota? Find the answers quickly and easily in this Quick Reference Guide, which includes highlights from the Owner’s Manual. For more detailed information, and helpful interactive demonstrations and tips, visit www.Toyotaiguide.com. This user-friendly website makes learning all about your new vehicle fun and easy.

Trunk-Internal release

Pull up

www.ToyotaiGuide.com

This iGuide is not intended as a substitute for the Owner’s Manual located in the vehicle’s glove box. We strongly encourage you to review the Owner’s Manual and supplementary manuals so you will have a better understanding of the vehicle’s capabilities and limitations. Important Cautions, to help you avoid injuries, and Notices, to help you avoid equipment damage or malfunction, can also be found in the Owner’s Manual.

Spare tire & tools Tool location

Jack handle

Removing the spare tire

(1)

Transport eyelet (if equipped)

Wheel nut wrench

Jack

Spare tire

(2)

(3)

(4)

(1) Loosen and remove the nut. (2) Remove the spare tire cover. (3) Loosen and remove the bolt. (4) Remove the jack tray. Refer to the Owner’s Manual for tire changing and jack positioning procedures.

25

O V E R V I E W

F E A T U R E S / O P E R A T O N S

I

S A F E T Y

A N D

E M E R G E N C Y

F E A T U R E S

2009 Camry Hybrid Quick Reference Guide

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND EMERGENCY FEATURES

Engine maintenance Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry1 Light control-Instrument panel Smart Key system1,2

Air Conditioning/Heating Audio Auto lock functions2 Clock Cruise control Cup holders Door locks Garage door opener (HomeLink®)3 Hybrid Synergy Drive System Lights1 & turn signals Moonroof Multi-information display Parking brake Power outlets Seat adjustments-Front Seat heaters Seats-Folding rear seats Seats-Head restraints Steering lock release Steering wheel switches Telephone controls (Bluetooth®) Tilt and telescopic steering wheel Transmission Windows-Power Windshield wipers & washers

Child comfort guide Doors-Child safety locks Fuel filler door-Internal release Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Warning System Trunk-Internal release

9 8 9 5 4 2-3 6 8 7

20-21 18-19

11 21 15 22 22 15 10 13 17 17 12 22 14 21 14 14 11 19 16 12 11 12 13

24 23 23 23 24 25 24 25

1 Visit your Toyota dealer for information on customizing this feature. 2 Programmable by customer. Refer to the Owner’s Manual for instructions and

more information. 3 HomeLink® is a registered trademark of Johnson Controls, Inc.

1

O V E R V I E W

F E A T U R E S / O P E R A T O N S

I

S A F E T Y

A N D

E M E R G E N C Y

F E A T U R E S

OVERVIEW

Instrument panel Steering wheel controls

Steering wheel audio controls Steering wheel climate controls Multi-information display button Voice command button1,2 Telephone controls1,2 Headlight and turn signal controls Wiper and washer controls Emergency flasher button Audio system or navigation system with integrated audio system1,2 Air Conditioning controls Tire Pressure Warning System reset (in glove box) Rear window and outside rearview mirror defogger switch1 12V DC Power outlet

2

O V E R V I E W

F E A T U R E S / O P E R A T O N S

I

S A F E T Y

A N D

E M E R G E N C Y

F E A T U R E S

AUX audio jack Seat heater controls1 “POWER” switch Cruise control Tilt and telescopic steering lock release Auxiliary boxes Air Conditioning/Heating economy (ECO) mode switch Fuel filler door opener Power outside rearview mirror controls

1 If equipped 2 For details, refer to the “Navigation System Owner’s Manual.”

3

OVERVIEW

Instrument cluster

Engine coolant temperature Service indicator and reminder Fuel economy meter Gear shift position indicator Speedometer Fuel gauge Trip meter reset knob/Instrument panel light control Multi-information display Driving ready light

4

Indicator symbols For details, refer to “Indicators and warning lights,” Section 2-2, 2009 Owner’s Manual.

Brake system warning1

Brake system warning light1 Driver seat belt reminder (alarm will sound if speed is over 12 mph) Front passenger seat belt reminder (alarm will sound if speed is over 12 mph) Charging system warning1 Front passenger occupant classification or front passenger air bag ON/OFF indicator1 Driving ready light

Malfunction/Check Engine indicator1

Low fuel level warning

Open door warning

Airbag SRS warning1

Master warning

Low Tire Pressure Warning1

Electric power steering system warning1

Theft deterrent/Engine immobilizer system indicator

Headlight low/high beam indicator

Turn signal indicator

Slip indicator1

Cruise control indicator2

Anti-lock Brake System warning1

1 If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. 2 If this light flashes, refer to “Cruise control,” Section 2-4, 2009 Owner’s Manual.

5

O V E R V I E W

F E A T U R E S / O
