2012 Nissan Quest Owners Manual

. Push and hold the ACCEL/RES switch. When the vehicle attains the desired speed, release the switch.

. Push, then quickly release the ACCEL/RES switch. Each time you do this, the set speed will increase by about 1 MPH (1.6 km/h).

To reset at a slower cruising speed, use one of the following methods:

Lightly tap the brake pedal. When the vehicle attains the desired speed, push the COAST/SET switch and release it.

. Push and hold the COAST/SET switch. Release the switch when the vehicle slows down to the desired speed.

. Push, then quickly release the COAST/SET switch. Each time you do this, the set speed will decrease by about 1 MPH (1.6 km/h).

To resume the preset speed, push and release the ACCEL/RES switch. The vehicle will resume the last set cruising speed when the vehicle speed is over 25 MPH (40 km/h).

Starting and driving 5-25

accelerator pedal. Your vehicle will maintain the set speed.

To pass another vehicle, depress the accelerator pedal. When you release the pedal, the vehicle will return to the previously set speed. The vehicle may not maintain the set speed on winding or hilly roads. If this happens, drive without the cruise control.

To cancel the preset speed, use one of the following methods: 1. Push the CANCEL switch. 2. Tap the brake pedal. 3. Turn the MAIN switch off. The CRUISE light

the cruising speed,

will turn off. If you depress the brake pedal while pushing the ACCEL/RES or COAST/SET switch and reset at the cruise control will disengage. Turn the MAIN switch off once and then turn it on again. The cruise control will automatically cancel if the vehicle slows more than 8 MPH (13
km/h) below the set speed. If you move the selector lever to the N (Neutral) position, the cruise control will be canceled.

SSD0694

ACCEL/RES switch COAST/SET switch CANCEL switch MAIN (ON·OFF) switch

1. 2. 3. 4. CRUISE CONTROL OPERATIONS GUID-83F79638-F960-44C4-A666-8D4BEB19D2B3
The cruise control allows driving at a speed between 25 to 89 MPH (40 to 144 km/h) without keeping your foot on the accelerator pedal. To turn on the cruise control, push the MAIN switch on. The CRUISE indicator light will illuminate. To set cruising speed, accelerate the vehicle to the desired speed, push the COAST/SET switch and release it. Take your foot off the

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (366,1)

BREAK-IN SCHEDULE

INCREASING FUEL ECONOMY

GUID-5F34BB14-0AD3-407E-B5FE-890E39D7A505

CAUTION

During the first 1,200 miles (2,000 km), follow these recommendations to ob- tain maximum engine performance and ensure the future reliability and econo- my of your new vehicle. Failure to follow these recommendations may result in shortened engine life and reduced engine performance.

. Avoid driving for long periods at constant speed, either fast or slow. Do not run the engine over 4,000 rpm.

. Do not accelerate at full throttle in any gear. . Avoid quick starts. . Avoid hard braking as much as possible. . Do not tow a trailer for the first 500 miles (800 km). Your engine, axle or other parts could be damaged.

GUID-5E00DC84-545E-418E-AA38-0C660DE98E0B . Accelerate slowly and smoothly. Maintain cruising speeds with a constant accelerator position.

. Drive at moderate speeds on the highway. Driving at high speed lowers fuel economy. . Avoid unnecessary stopping and braking. Keep a safe distance behind other vehicles. . Select a gear range suitable to road condi-

tions.

. Avoid unnecessary engine idling. . Keep your engine tuned up.

Follow the recommended periodic mainte- nance schedule.

. Keep the tires inflated to the correct pressure. Low tire pressure increases tire wear and lowers fuel economy.

. Keep the wheels in correct alignment. Improper alignment increases tire wear and lowers fuel economy.

. Air conditioner operation lowers fuel econ- omy. Use the air conditioner only when necessary.

. When cruising at highway speeds, it is more economical to use the air conditioner and leave the windows closed to reduce drag.

. Use the recommended viscosity engine oil. (See “Engine oil and oil filter recommenda- tion” (P.9-5).)

5-26 Starting and driving

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (367,1)

3. To help prevent the vehicle from rolling into traffic when parked on an incline, it is a good practice to turn the wheels as illustrated. . HEADED DOWNHILL WITH CURB: *1
Turn the wheels into the curb and move the vehicle forward until the curb side wheel gently touches the curb.

. HEADED UPHILL WITH CURB: *2

Turn the wheels away from the curb and move the vehicle back until the curb side wheel gently touches the curb.

. HEADED UPHILL OR DOWNHILL, NO

CURB: *3
Turn the wheels toward the side of the road so the vehicle will move away from the center of the road if it moves.

4. Push the ignition switch to the LOCK

position.

PARKING/PARKING ON HILLS

GUID-E91CA1F5-1350-43A4-9AE7-64AFEAB8AABC

WARNING

. Do not stop or park the vehicle over flammable materials such as dry grass, waste paper or rags. They may ignite and cause a fire.

. Safe parking procedures require that both the parking brake be set and the transmission placed into P (Park). Failure to do so could cause the vehicle to move unexpectedly or roll away and result in an accident. Make sure the selector lever has been pushed as far forward as it can

SSD0488

go and cannot be moved without depressing the foot brake pedal.

. Never leave the engine running

while the vehicle is unattended.

. Do not leave children unattended inside the vehicle. They could un- knowingly activate switches or con- trols. Unattended children could become involved in serious acci- dents.

1. Firmly apply the parking brake. 2. Move the selector lever

to the P (Park)

position.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Starting and driving 5-27

Black plate (368,1)

HYDRAULIC PUMP ELECTRIC POWER STEERING SYSTEM

GUID-9D8CF7E0-F426-465B-A617-7E3E20C8EDA3

WARNING

If the engine is not running or is turned off while driving, the power assist for the steering will not work. Steering will be harder to operate.

. When the hydraulic pump electric power steering warning light illumi- nates with the engine running, the power assist for the steering will cease operation. You will still have control of the vehicle, but the steer- ing will be much harder to operate.

The hydraulic pump electric power steering system is designed to provide power assistance while driving to operate the steering wheel with light force. When the steering wheel is operated repeatedly or continuously while parking or driving at a very low speed, the power assist for the steering wheel will be reduced. This is to prevent the hydraulic pump electric overheating of from power steering system and protect getting damaged. While the power assist is reduced, steering wheel operation will become heavy. If the steering wheel operation is still performed, the power steering may stop and the

it

5-28 Starting and driving

hydraulic pump electric power steering warning light will illuminate. Stop the engine and push the ignition switch to the OFF position. The temperature of the hydraulic pump electric power steering system will go down and the power assist level will return to normal after starting the engine. The hydraulic pump electric power steering warning light will go off. Avoid repeating such steering wheel operations that could cause the hydraulic pump electric power steering system to overheat. You may hear a noise from the front of the vehicle when the steering wheel is operated. This is not a malfunction. If the hydraulic pump electric power steering illuminates while the engine is warning light running, it may indicate the hydraulic pump electric power steering system is not functioning properly and may need servicing. Have the hydraulic pump electric power steering system checked by a NISSAN dealer. When the hydraulic pump electric power steer- ing warning light illuminates with the engine running, the power assist for the steering will cease operation but you will still have control of the vehicle. At this time, greater steering efforts are required to operate the steering wheel, especially in sharp turns and at low speeds.

BRAKE SYSTEM

GUID-2DB11889-CD89-463C-B59E-B8C2FC42DC45

BRAKING PRECAUTIONS GUID-683CD5A7-20F8-4E5C-98DB-AC5501CC6F13
The brake system has two separate hydraulic circuits. If one circuit malfunctions, you will still have braking at two wheels.

Vacuum assisted brakes GUID-B2E796C9-1505-4EB1-BD23-C73EBDA2C5AA The brake booster aids braking by using engine vacuum. If the engine stops, you can stop the vehicle by depressing the brake pedal. However, greater foot pressure on the brake pedal will be required to stop the vehicle and the stopping distance will be longer.

Using the brakes GUID-FA2F592C-B612-4C3B-9601-F47DA772DB87
Avoid resting your foot on the brake pedal while driving. This will cause overheating of the brakes, wearing out the brake and pads faster and reduce gas mileage. To help reduce brake wear and to prevent the brakes from overheating, reduce speed and downshift to a lower gear before going down a slope or long grade. Overheated brakes may reduce braking performance and could result in loss of vehicle control.

WARNING

. While driving on a slippery surface, be careful when braking, accelerat-

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (369,1)

ing or downshifting. Abrupt braking or accelerating could cause the wheels to skid and result in an accident.

If the engine is not running or is turned off while driving, the power assist for the brakes will not work. Braking will be harder.

Wet brakes GUID-9AF26F3B-B107-4A13-A29D-5F951B691E1F When the vehicle is washed or driven through water, the brakes may get wet. As a result, your braking distance will be longer and the vehicle may pull to one side during braking. To dry brakes, drive the vehicle at a safe speed while lightly tapping the brake pedal to heat-up the brakes. Do this until the brakes return to normal. Avoid driving the vehicle at high speeds until the brakes function correctly. PARKING BRAKE BREAK-IN GUID-8712E161-8980-4FB3-ACDA-F64534A1E2E1
Break in the parking brake shoes whenever the stopping effect of the parking brake is weakened or whenever the parking brake shoes and/or drums/rotors are replaced, in order to assure the best braking performance. This procedure is described in the vehicle service manual and can be performed by a NISSAN dealer.

ANTI-LOCK BRAKING SYSTEM (ABS)

GUID-E8F8B8CF-A4A2-4A1F-8F91-60B7A7D2AABD

WARNING

The Anti-lock Braking System (ABS) is a sophisticated device, but it cannot prevent accidents resulting from careless or dangerous driving techniques. It can help maintain vehicle control during braking on slippery surfaces. Remember that stopping distances on slippery sur- faces will be longer than on normal surfaces even with ABS. Stopping distances may also be longer on rough, gravel or snow covered roads, or if you are using tire chains. Always maintain a safe distance from the vehicle in front of you. Ultimately, the driver is responsible for safety.

Tire type and condition may also affect braking effectiveness.

— When replacing tires, install the specified size of tires on all four wheels.

— When installing a spare tire, make sure that it is the proper size and type as specified on the

Tire and Loading Information label. See “Tire and Loading Information label” (P.9-10).

— For detailed information, see

“Wheels and tires” (P.8-29).

The Anti-lock Braking System (ABS) controls the brakes so the wheels do not lock during hard braking or when braking on slippery surfaces. The system detects the rotation speed at each wheel and varies the brake fluid pressure to prevent each wheel from locking and sliding. By preventing each wheel from locking, the system helps the driver maintain steering control and helps to minimize swerving and spinning on slippery surfaces.

Using the system GUID-B662EE8A-6201-4BFE-B6AB-A3A5DBB9F5D4
Depress the brake pedal and hold it down. Depress the brake pedal with firm steady pressure, but do not pump the brakes. The ABS will operate to prevent the wheels from locking up. Steer the vehicle to avoid obstacles.

WARNING

Do not pump the brake pedal. Doing so may result in increased stopping dis- tances.

Starting and driving 5-29

[ Edit: 2011/ 10/ 27 Model: E52-D ]

operating. This is normal and indicates that the ABS is operating properly. However, the pulsa- tion may indicate that road conditions are hazardous and extra care is required while driving.

Black plate (370,1)

VEHICLE DYNAMIC CONTROL (VDC) SYSTEM

GUID-04F84935-B6BE-42D1-9A6C-259F5346A37C The Vehicle Dynamic Control (VDC) system uses various sensors to monitor driver inputs and vehicle motion. Under certain driving con- ditions, the VDC system helps to perform the following functions. . Controls brake pressure to reduce wheel slip on one slipping drive wheel so power is transferred to a non slipping drive wheel on the same axle.

. Controls brake pressure and engine output to reduce drive wheel slip based on vehicle speed (traction control function).

. Controls brake pressure at individual wheels and engine output to help the driver maintain control of the vehicle in the following conditions: — understeer (vehicle tends to not follow the steered path despite increased steering input)

— oversteer (vehicle tends to spin due to

certain road or driving conditions).

The VDC system can help the driver to maintain control of the vehicle, but it cannot prevent loss of vehicle control in all driving situations. When the VDC system operates, warning light so note the following:

the VDC in the instrument panel flashes

The road may be slippery or the system may determine some action is required to help

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Self-test feature GUID-E008EA25-09A5-48D6-BDF0-5DADBCE33BA9
The ABS includes electronic sensors, electric pumps, hydraulic solenoids and a computer. The computer has a built-in diagnostic feature that tests the system each time you start the engine and move the vehicle at a low speed in forward or reverse. When the self-test occurs, you may hear a “clunk” noise and/or feel a pulsation in the brake pedal. This is normal and does not indicate a malfunction. If the computer senses a malfunction, it switches the ABS off and illuminates the ABS warning light on the instrument panel. The brake system then oper- ates normally, but without anti-lock assistance. If the ABS warning light illuminates during the self-test or while driving, have the vehicle checked by a NISSAN dealer.

Normal operation GUID-EA99FC08-2EFF-4D78-8864-83EAB1C00AA9
The ABS operates at speeds above 3 to 6 MPH (5 to 10 km/h). The speed varies according to road conditions. When the ABS senses that one or more wheels are close to locking up, the actuator rapidly applies and releases hydraulic pressure. This action is similar to pumping the brakes very quickly. You may feel a pulsation in the brake pedal and hear a noise from under the hood or feel a vibration from the actuator when it is

5-30 Starting and driving

Black plate (371,1)

keep the vehicle on the steered path.

. You may feel a pulsation in the brake pedal and hear a noise or vibration from under the hood. This is normal and indicates that the VDC system is working properly.

. Adjust your speed and driving to the road

conditions.

See “Vehicle Dynamic Control (VDC) warning light” (P.2-16). If a malfunction occurs in the system, the VDC warning light illuminates in the instrument panel. The VDC system automatically turns off. The VDC OFF switch is used to turn off the VDC system. The VDC off indicator illuminates to indicate the VDC system is off. When the VDC switch is used to turn off the system, the VDC system still operates to prevent one drive wheel from slipping by transferring power to a non slipping drive wheel. The VDC warning light flashes if this occurs. All other VDC functions are off, and the VDC warning light will not flash. The VDC system is automatically reset to on when the ignition switch is placed in the off position then back to the on position. See “Vehicle Dynamic Control (VDC) warning light” (P.2-16) and “Vehicle Dynamic Control (VDC) off indicator light” (P.2-18). The computer has a built-in diagnostic feature that tests the system each time you start the

engine and move the vehicle forward or in reverse at a slow speed. When the self-test occurs, you may hear a “clunk” noise and/or feel a pulsation in the brake pedal. This is normal and is not an indication of a malfunction.

WARNING

The VDC system is designed to help the driver maintain stability but does not prevent accidents due to abrupt steering operation at high speeds or by careless or dangerous driving techniques. Reduce vehicle speed and be especially careful when driving and cornering on slip- pery surfaces and always drive care- fully.

. Do not modify the vehicle’s suspen- sion. If suspension parts such as shock absorbers, struts, springs, stabilizer bars, bushings and wheels are not NISSAN recom- mended for your vehicle or are extremely deteriorated, the VDC system may not operate properly. This could adversely affect vehicle handling performance, and the VDC warning light

may illuminate.

If brake related parts such as brake pads, rotors and calipers are not NISSAN recommended or are extre- mely deteriorated, the VDC system may not operate properly and the VDC warning light may illumi- nate.

If engine control related parts are not NISSAN recommended or are extremely deteriorated, the VDC warning light

may illuminate.

. When driving on extremely inclined surfaces such as higher banked corners, the VDC system may not operate properly and the VDC warn- ing light may illuminate. Do not drive on these types of roads.

. When driving on an unstable sur- face such as a turntable, ferry, elevator or ramp, the VDC warning light may illuminate. This is not a malfunction. Restart the engine after driving onto a stable surface.

If wheels or tires other than the NISSAN recommended ones are used, the VDC system may not operate properly and the VDC warn- ing light

may illuminate.

Starting and driving 5-31

[ Edit: 2011/ 10/ 27 Model: E52-D ]

.

The VDC system is not a substitute for winter tires or tire chains on a snow covered road.

COLD WEATHER DRIVING

GUID-348F0E28-6B84-46C8-BB6D-AFE840F7A7C6

is anticipated that

FREEING A FROZEN DOOR LOCK GUID-BF844EE8-8879-4D9E-A0D8-6BDA69A4766D To prevent a door lock from freezing, apply deicer through the key hole. If the lock becomes frozen, heat the key before inserting it into the key hole or use the remote keyless entry keyfob. ANTI-FREEZE GUID-382CA52B-F6BA-4172-888D-0B88818F7A48
In the winter when it the outside temperature will drop below 328F (08C), check the anti-freeze to assure proper winter protection. For additional information, see “En- gine cooling system” (P.8-7). BATTERY GUID-7E1806A3-BEC0-4F76-AA10-15C013CA97DD If fully charged during extremely cold weather conditions, the battery fluid may freeze and damage the battery. To maintain maximum efficiency, the battery should be checked regularly. For additional information, see “Battery” (P.8-13). DRAINING OF COOLANT WATER GUID-65229154-25AF-41A0-8FA9-2ECBCB7CFCDD If the vehicle is to be left outside without anti- freeze, drain the cooling system, including the engine block. Refill before operating the vehicle. For details, see “Engine cooling system” (P.8-7).

the battery is not

Black plate (372,1)

the performance of

TIRE EQUIPMENT GUID-CFE2B762-0CDA-4F82-B772-E8834079FBB4
SUMMER tires have a tread designed to provide superior performance on dry pavement. How- ever, these tires will be substantially reduced in snowy and icy condi- tions. If you operate your vehicle on snowy or icy roads, NISSAN recommends the use of MUD & SNOW or ALL SEASON tires on all four wheels. Consult a NISSAN dealer for the tire type, size, speed rating and availability information. For additional traction on icy roads, studded tires may be used. However, some U.S. states and Canadian provinces prohibit their use. Check local, state and provincial laws before installing studded tires. Skid and traction capabilities of studded snow tires, on wet or dry surfaces, may be poorer than that of non-studded snow tires. Tire chains may be used. For details, see “Tire chains” (P.8-35). SPECIAL WINTER EQUIPMENT GUID-70D53D25-FE2C-49C0-A2CB-99E59866FD06
It is recommended that the following items be carried in the vehicle during winter: . A scraper and stiff-bristled brush to remove ice and snow from the windows and wiper blades.

5-32 Starting and driving

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (373,1)

. A sturdy, flat board to be placed under the

jack to give it firm support.

. A shovel to dig the vehicle out of snow-

drifts.

. Extra window washer

fluid to refill

the

reservoir tank.

DRIVING ON SNOW OR ICE

GUID-0551BFA7-5FD7-4661-BF82-81E90DC69701

WARNING

. Wet ice (328F, 08C and freezing rain), very cold snow or ice can be slick and very hard to drive on. The vehicle will have much less traction or “grip” under these conditions. Try to avoid driving on wet ice until the road is salted or sanded.

. Whatever the condition, drive with caution. Accelerate and slow down with care. If accelerating or down- shifting too fast, the drive wheels will lose even more traction.

. Allow more stopping distance under these conditions. Braking should be started sooner than on dry pave- ment.

. Allow greater following distances

on slippery roads.

. Watch for slippery spots (glare ice). These may appear on an otherwise clear road in shaded areas. If a patch of ice is seen ahead, brake before reaching it. Try not to brake while on the ice, and avoid any sudden steering maneuvers.

. Do not use cruise control on slip-

pery roads.

. Snow can trap dangerous exhaust gases under your vehicle. Keep snow clear of the exhaust pipe and from around your vehicle.

ENGINE BLOCK HEATER (if so equipped) GUID-3A4E6BF1-CDA5-41B6-8CF5-3E0F85D0390F Engine block heaters are used to assist with cold temperature starting. The engine block heater should be used when the outside temperature is 208F (−78C) or lower.

To use the engine block heater 1. Turn the engine off. 2. Open the hood and unwrap the engine

GUID-63380EA2-4604-4472-B461-319C10F0DD95

block heater cord.

3. Plug the engine block heater cord into a grounded 3-wire, 3-pronged extension cord.

4. Plug the extension cord into a Ground Fault Interrupt (GFI) protected, grounded 110- volt AC (VAC) outlet.

5. The engine block heater must be plugged in for at least 2 - 4 hours, depending on outside temperatures, to properly warm the engine coolant. Use an appropriate timer to turn the engine block heater on.

6. Before starting the engine, unplug and properly store the cord to keep it away from moving parts.

WARNING

. Do not use your engine block heater with an ungrounded electrical sys- tem or a 2-pronged adapter. You can be seriously injured by an electrical shock if you use an ungrounded connection.

. Disconnect and properly store the engine block heater cord before starting the engine. Damage to the cord could result in an electrical shock and can cause serious injury. . Use a heavy-duty 3-wire, 3-pronged extension cord rated for at least 10A. Plug the extension cord into a

Starting and driving 5-33

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (374,1)

Ground Fault Interrupt (GFI) pro- tected, grounded 110-VAC outlet. Failure to use the proper extension cord or a grounded outlet can result in a fire or electrical shock and cause serious personal injury.

5-34 Starting and driving

[ Edit: 2011/ 10/ 27 Model: E52-D ]

6 In case of emergency

Black plate (375,1)

...

Emergency engine shut off Flat tire ...

..................................................... 6-2
......................................................................................... 6-2
.................... 6-2
............................................................. 6-3
.............................................................................. 6-9

Tire Pressure Monitoring System (TPMS) Changing a flat tire ...

Jump starting ...

...

Push starting ... If your vehicle overheats ... Towing your vehicle ...

........................................................................... 6-11
...................................................... 6-11
.............................................................. 6-13
........................... 6-14
............... 6-15

Towing recommended by NISSAN ... Vehicle recovery (freeing a stuck vehicle)

...

[ Edit: 2011/ 10/ 27 Model: E52-D ]

EMERGENCY ENGINE SHUT OFF

FLAT TIRE

Black plate (376,1)

GUID-0E4C54B4-2114-44F8-B325-BF9D4DF5FAF5
To shut off the engine in an emergency situation while driving perform the following procedure: . Rapidly push the push-button ignition switch 3 consecutive times in less than 1.5
seconds, or

. Push and hold the push-button ignition

switch for more than 2 seconds.

GUID-AC1D0281-335C-4108-853B-8A1B546B4579

TIRE PRESSURE MONITORING SYS- TEM (TPMS) GUID-DEB6C221-1388-45A8-A56A-12AE327CD076
This vehicle is equipped with the Tire Pressure Monitoring System (TPMS). It monitors tire pressure of all tires except the spare. When the low tire pressure warning light is lit and the CHECK TIRE PRESSURE warning appears on the dot matrix liquid crystal display, one or more of your tires is significantly under-inflated. If the vehicle is being driven with low tire pressure, the TPMS will activate and warn you of it by the low tire pressure warning light. This system will activate only when the vehicle is driven at speeds above 16 MPH (25 km/h). For more details, see “Warning/indicator lights and audi- ble reminders” (P.2-11) and “Tire Pressure Monitoring System (TPMS)” (P.5-3).

WARNING

If the low tire pressure warning light illuminates while driving, avoid sud- den steering maneuvers or abrupt braking, reduce vehicle speed, pull off the road to a safe location and stop the vehicle as soon as possi- ble. Driving with under-inflated tires may permanently damage the tires and increase the likelihood of tire

failure. Serious vehicle damage could occur and may lead to an accident and could result in serious personal injury. Check the tire pres- sure for all four tires. Adjust the tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light OFF. illuminates while driving after adjusting the tire pressure, a tire may be flat. If you have a flat tire, replace it with a spare tire as soon as possible.

If the light still

. When a spare tire is mounted or a wheel is replaced, the TPMS will not function and the low tire pressure warning light will flash for approxi- mately 1 minute. The light will remain on after 1 minute. Contact your NISSAN dealer as soon as possible for tire replacement and/ or system resetting.

. Replacing tires with those not ori- ginally specified by NISSAN could affect the proper operation of the TPMS.

. Do not

inject any tire liquid or aerosol tire sealant into the tires,

6-2 In case of emergency

[ Edit: 2011/ 10/ 27 Model: E52-D ]

as this may cause a malfunction of the tire pressure sensors.

CHANGING A FLAT TIRE If you have a flat tire, below.

GUID-9C3D8FB6-951A-4EDB-A38A-8CFC44DDD5C4
follow the instructions

Stopping the vehicle GUID-3C04CDD2-4FF2-4546-BEAF-E86E1FD31ECB 1. Safely move the vehicle off the road and

away from traffic.

2. Turn on the hazard warning flashers. 3. Park on a level surface and apply the parking brake. Move the selector lever to the P (Park) position.

4. Turn off the engine. 5. Raise the hood to warn other traffic, and to signal professional road assistance person- nel that you need assistance.

6. Have all passengers get out of the vehicle and stand in a safe place, away from traffic and clear of the vehicle.

WARNING

. Make sure the parking brake is securely applied and the transmis- sion is shifted into the P (Park) position.

Black plate (377,1)

. Never change tires when the vehicle is on a slope, ice or slippery areas. This is hazardous.

. Never change tires if oncoming traffic is close to your vehicle. Wait for professional road assistance.

MCE0001A

GUID-93D9DEE9-EDED-416B-B0EB-4D9AEC85C652

Blocking wheels Place suitable blocks *1 at both the front and back of the wheel diagonally opposite the flat tire to prevent the vehicle from moving when it is jacked up.

WARNING

Be sure to block the wheel as the vehicle may move and result in personal injury.

In case of emergency 6-3

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (378,1)

4. Remove tools *A and jack *B located as

illustrated.

JVE0027X

JVE0031X

Getting the tools and jack 1. Open the lift gate. 2. Open the cargo floor box. (See “Cargo floor

GUID-3E8604EA-97F9-4AB5-AC55-2A26F0E2DDB8

box” (P.2-47).)

3. Remove the cargo floor board (if so

equipped).

6-4 In case of emergency

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (379,1)

4. When the spare tire is completely lowered,

carefully slide it from under the vehicle.

5. Remove the suspending plate *E from the

spare tire.

6. After removing the spare tire, raise the spare tire cable completely by turning the spare tire lowering mechanism clockwise using the tool *D .

7. Before moving or jacking up the vehicle, check under the vehicle to make sure the cable is stored properly.

JVE0032X

WARNING

SCE0630

Getting the spare tire GUID-1FB755FE-1FC8-43E1-AE9C-801B417FB7E4
The spare tire is located under the center of the vehicle. 1. Lift up the floor carpeting flap behind the front center console, then remove insulation piece to access the spare tire lowering mechanism *C .

2. Loosen the spare tire lowering mechanism

*C with the wheel nut wrench.

3. Using the assembled socket tool *D , turn the spare tire lowering mechanism *C counterclockwise as illustrated to lower the spare tire.

. Never jack up the vehicle before removing the spare tire from under the vehicle. This may lead to an accident could result in serious personal injury.

. Do not move the vehicle with the spare tire cable lowered. The cable could hit or become tangled with an object on the road. Serious vehicle damage could occur and may lead to an accident and could result in serious personal injury.

Removing wheel cover (if so equipped)

GUID-B6BFF967-EFDB-4567-8417-F7BC9FA8200E

WARNING

Never use your hands to remove the wheel cover. This may cause personal injury.

To remove the wheel cover, use the jack rod *1
as illustrated. Apply cloth *2 between the wheel and jack rod to prevent damaging the wheel and wheel cover.

In case of emergency 6-5

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (380,1)

SCE0585

Jack-up point

1. Place the jack directly under the jack-up point as illustrated so the top of the jack contacts the vehicle at the jack-up point. Align the jack head between the two notches in the front or the rear as shown. Also fit the groove of the jack head between the notches as shown. The jack should be used on level firm ground.

Jacking up the vehicle and removing the flat tire

GUID-5487C985-0D22-41CC-A2C6-8E2BCAAA97BC

Carefully read the caution label attached to the jack body and the following instruc- tions.

WARNING

. Never get under the vehicle while it is supported only by the jack. If it is necessary to work under the vehicle, support it with safety stands.

. Use only the jack provided with your vehicle to lift the vehicle. Do not use the jack provided with your vehicle on other vehicles. The jack is de- signed for lifting only your vehicle during a tire change.

. Use the correct

jack-up points. Never use any other part of the vehicle for jack support.

. Never jack up the vehicle more than

necessary.

. Never use blocks on or under the

jack.

. Do not start or run the engine while vehicle is on the jack, as it may cause the vehicle to move.

. Do not allow passengers to stay in

the vehicle while it is on the jack.

6-6 In case of emergency

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (381,1)

2. Loosen each wheel nut one or two turns by turning counterclockwise with the wheel nut wrench. Do not remove the wheel nuts until the tire is off the ground.

3. To lift the vehicle, securely hold the jack lever and rod with both hands as shown above. Carefully raise the vehicle until the tire clears the ground. Remove the wheel nuts, and then remove the tire.

SCE0504

SCE0039

Installing the spare tire GUID-C0B9D734-710A-481A-86B0-9913DBADEB35
The spare tire is designed for emergency use. (See specific instructions under the heading “Wheels and tires” (P.8-29).) 1. Clean any mud or dirt

from the surface

between the wheel and hub.

2. Carefully put the spare tire on and tighten the wheel nuts finger tight. Check that all the wheel nuts contact the wheel surface horizontally.

3. With the wheel nut wrench, tighten wheel nuts alternately and evenly in the sequence as illustrated (*1 , *2 , *3 , *4 , *5 ), more than 2 times, until they are tight.

In case of emergency 6-7

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (382,1)

tened to specification at all times. It is recommended that wheel nuts be tightened to specifications at each lubrication interval.

. Adjust tire pressure to the COLD

gency use. See specific instructions under the heading “Wheels and tires” (P.8-29).

4. Lower

the vehicle slowly until

the tire touches the ground. Then, with the wheel nut wrench, tighten the wheel nuts securely in the sequence as illustrated. Lower the vehicle completely.

5. Securely store the flat tire, jack and tools in

pressure.

the vehicle.

WARNING

Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose or come off. This could cause an accident.

. Do not use oil or grease on the wheel studs or nuts. This could cause the nuts to become loose.

. Retighten the wheel nuts when the vehicle has been driven for 600
miles (1,000 km) (also in cases of a flat tire, etc.).

. As soon as possible, tighten the wheel nuts to the specified torque with a torque wrench.

Wheel nut tightening torque:

80 ft-lb (108 N·m)

The wheel nuts must be kept tigh-

6-8 In case of emergency

COLD pressure:

After the vehicle has been parked for three hours or more or driven less than 1 mile (1.6 km).

COLD tire pressures are shown on the Tire and Loading Information label affixed to the driver side center pillar.

Stowing the spare tire and the tools GUID-D067B480-FEC0-4ABB-8FD0-F9C4BA40EABA Securely store the spare tire, jack and tools in their original location.

WARNING

. Always make sure that the spare tire and jacking equipment are properly secured after use. Such items can become dangerous projectiles in an accident or sudden stop.

The T-type spare tire and small size spare tire are designed for emer-

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (383,1)

JUMP STARTING

GUID-F0C70992-E39E-439F-A298-885A33CD0F7D To start your engine with a booster battery, the instructions and precautions below must be followed.

WARNING

If done incorrectly, jump starting can lead to a battery explosion, resulting in severe injury or death. It could also damage your vehicle.

. Explosive hydrogen gas is always present in the vicinity of the battery. Keep all sparks and flames away from the battery.

. Do not allow battery fluid to come into contact with eyes, skin, clothing or painted surfaces. Battery fluid is a corrosive sulfuric acid solution which can cause severe burns. If the fluid should come into contact with anything, immediately flush the contacted area with water.

. Keep the battery out of the reach of

children.

The booster battery must be rated at 12 volts. Use of an improperly rated battery can damage your vehicle.

In case of emergency 6-9

. Do not use an impact wrench when tightening or loosening the spare tire lowering mechanism.

. When raising the spare tire, tighten the spare tire lowering mechanism until three clicks are heard.

. After storing the spare tire, check under the vehicle to make sure it is stored properly.

SCE0978

WARNING

. When storing the spare tire, make sure that the outer side of the spare tire *A is facing up and that the hanging plate *B is in the center of the wheel as illustrated. Failure to store the spare tire properly could result in serious vehicle damage and may lead to an accident and could result in serious personal injury.

. Do not store any tire with the cable

except the spare tire.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

. Whenever working on or near a battery, always wear suitable eye protectors (for example, goggles or industrial safety spectacles) and remove rings, metal bands, or any other jewelry. Do not lean over the battery when jump starting.

. Do not attempt to jump start a It could explode

frozen battery. and cause serious injury.

. Your vehicle has an automatic en- gine cooling fan. It could come on at any time. Keep hands and other objects away from it.

Black plate (384,1)

2. Apply the parking brake. Move the selector lever to the P (Park) position. Switch off all unnecessary electrical systems (lights, hea- ter, air conditioner, etc.).

3. Remove vent caps on the battery (if so equipped). Cover the battery with a firmly wrung out moist cloth to reduce explosion hazard.

4. Connect jumper cables in the sequence as

illustrated (*1 ? *2 ? *3 ? *4 ). If the battery is discharged, the ignition switch cannot be moved from the OFF position. Connect the jumper cables to the booster vehicle *B before pushing the ignition switch.

CAUTION

. Always connect positive (+) to posi- tive (+) and negative (−) to body ground (for example, as illustrated), not to the battery.

. Make sure the jumper cables do not touch moving parts in the engine compartment and that the cable clamps do not contact any other metal.

SCE0969

WARNING

Always follow the instructions below. Failure to do so could result in damage to the charging system and cause personal injury.

1.

If the booster battery is in another vehicle *B , position the two vehicles (*A and *B ) to bring their batteries into close proximity to each other. Do not allow the two vehicles to touch.

6-10 In case of emergency

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (385,1)

PUSH STARTING

IF YOUR VEHICLE OVERHEATS

5. Start the engine of the booster vehicle *B

GUID-AF8EBCAC-D95B-46B0-8FB6-7D559960C8C6
Do not attempt to start the engine by pushing.

CAUTION

Continuously Variable Transmission (CVT) models cannot be push-started or tow-started. Attempting to do so may cause transmission damage.

and let it run for a few minutes.

the booster 6. Keep the engine speed of vehicle *B at about 2,000 rpm, and start the engine of the vehicle *A being jump started.

CAUTION

Do not keep the starter motor engaged for more than 10 seconds. If the engine does not start right away, place the ignition switch in the OFF position and wait 10 seconds before trying again.

7. After starting your engine, carefully discon- nect the negative cable and then the positive cable (*4 ? *3 ? *2 ? *1 ).

8. Replace the vent caps (if so equipped). Be sure to dispose of the cloth used to cover the vent holes as it may be contaminated with corrosive acid.

GUID-7BE274CB-4547-414A-A0AB-1E92E044A439

CAUTION

. Do not continue to drive if your vehicle overheats. Doing so could cause engine damage or a vehicle fire.

To avoid the danger of being scalded, never remove the radiator cap while the engine is still hot. When the radiator cap is removed, pressurized hot water will spurt out, possibly causing serious injury.

. Do not open the hood if steam is

coming out.

If your vehicle is overheating (indicated by an extremely high temperature gauge reading), or if you feel a lack of engine power, detect abnormal noise, etc., take the following steps: 1. Move the vehicle safely off the road, apply the parking brake and move the selector lever to the P (Park) position. Do not stop the engine.

2. Turn off the air conditioner. Open all the windows, move the heater or air conditioner temperature control to maximum hot and fan control to high speed.

In case of emergency 6-11

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (386,1)

3. Get out of the vehicle. Look and listen for steam or coolant escaping from the radiator before opening the hood. (If steam or coolant is escaping, turn off the engine.) Do not open the hood further until no steam or coolant can be seen. 4. Open the engine hood.

cooling fan can start at any time.

6. After

the engine cools down, check the coolant level in the reservoir tank with the engine running. Add coolant to the reservoir tank if necessary. Have your vehicle repaired at a NISSAN dealer.

WARNING

If steam or water is coming from the engine, stand clear to prevent getting burned.

5. Visually check drive belts for damage or looseness. Also check if the cooling fan is running. The radiator hoses and radiator should not leak water. If coolant is leaking, the water pump belt is missing or loose, or the cooling fan does not run, stop the engine.

WARNING

Be careful not to allow your hands, hair, jewelry or clothing to come into contact with, or get caught in, engine belts or the engine cooling fan. The engine

6-12 In case of emergency

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (387,1)

. Always attach safety chains before

towing.

For information about towing your vehicle behind a recreational vehicle (RV), see “Flat towing” (P.9-24) of this manual.

TOWING YOUR VEHICLE

GUID-80738224-7F1F-4B4C-8893-BF5FD3490F0F When towing your vehicle, all State (Provincial in Canada) and local regulations for towing must be followed. Incorrect towing equipment could damage your vehicle. Towing instructions are available from a NISSAN dealer. Local service operators are familiar with the applicable laws and procedures for towing. To assure proper towing and to prevent accidental damage to your vehicle, NISSAN recommends that you have a service operator tow your vehicle. It is advisable to have the service operator carefully read the following precautions.

WARNING

. Never ride in a vehicle that is being

towed.

. Never get under your vehicle after it

has been lifted by a tow truck.

CAUTION

. When towing, make sure that the transmission, axles, steering system and drivetrain are in working condi- tion. If any unit is damaged, dollies must be used.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

In case of emergency 6-13

Black plate (388,1)

. When towing a CVT model with the rear wheels on the ground (if you do not use towing dollies): Always release the parking brake.

TOWING RECOMMENDED BY NISSAN GUID-DAEEA07F-BA1F-4483-BBDA-83F786579A9F NISSAN recommends that your vehicle be towed with the driving (front) wheels off the ground or place the vehicle on a flat bed truck as illustrated.

CAUTION

. Never tow Continuously Variable Transmission (CVT) models with the front wheels on the ground or four wheels on the ground (forward or backward), as this may cause

6-14 In case of emergency

SCE0976

serious and expensive damage to the drivetrain. If it is necessary to tow the vehicle with the rear wheels raised, always use towing dollies under the front wheels.

. When towing CVT models with the

front wheels on towing dollies:

— Push the ignition switch to the ACC or ON position, and secure the steering wheel in a straight- ahead position with a rope or similar device.

— Move the selector lever to the N

(Neutral) position.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (389,1)

Pulling a stuck vehicle GUID-357A4B24-B4C1-41A1-9CFA-159462B213B3
If your vehicle is stuck in sand, snow, mud, etc., use a tow strap or other device designed specifically for vehicle recovery. Always follow the manufacturer’s instructions for the recovery device.

Front: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Using a suitable tool wrapped with a cloth, remove the cover from the bumper. Securely install the vehicle recovery hook (stored in the cargo area) as illustrated. Make sure that the hook is properly secured in the original place after use.

CAUTION

Tow chains or cables must be at- tached only to the main structural members of the vehicle or the recovery hook. Otherwise, the vehi- cle body will be damaged.

. Never tow a vehicle using the vehi-

cle tie downs or recovery hooks.

. Always pull the cable straight out from the front of the vehicle. Never pull on the vehicle at an angle.

In case of emergency 6-15

SCE0971

Rear (tie down and recovery hook)

VEHICLE RECOVERY (freeing a stuck vehicle)

GUID-B41CE403-0FA7-4B6B-B314-6F097C555CBF

WARNING

. Stand clear of a stuck vehicle. . Do not spin your tires at high speed. This could cause them to explode and result in serious injury. Parts of your vehicle could also overheat and be damaged.

SCE0970

Front

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (390,1)

. Do not spin the tires above 35 MPH (55

km/h).

5.

If the vehicle cannot be freed after a few tries, contact a professional towing service to remove the vehicle.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

. Pulling devices should be routed so they do not touch any part of the suspension, steering, brake or cool- ing systems.

. Pulling devices such as ropes or canvas straps are not recommended for use in vehicle towing or recov- ery.

Rocking a stuck vehicle GUID-80608F11-4F10-4FDC-B323-F0062D15C0B6
If your vehicle is stuck in sand, snow, mud, etc., use the following procedure: 1. Turn off the Vehicle Dynamic Control (VDC)

system.

2. Make sure the area in front and behind the

vehicle is clear of obstructions.

3. Turn the steering wheel right and left to clear

an area around the front tires.

4. Slowly rock the vehicle forward and back-

ward. . Shift back and forth between R (Reverse)

and D (Drive).

. Apply the accelerator as little as possible

to maintain the rocking motion.

. Release the accelerator pedal before

shifting between R and D.

6-16 In case of emergency

7 Appearance and care

Black plate (391,1)

Cleaning exterior

....................................................................... 7-2
... ................................................................................. 7-2
................................................................................... 7-2
................................................................... 7-3
............................................................................. 7-3
...................................................................................... 7-3
................................................................................... 7-3
....................................................................... 7-3
......................................................................... 7-4

Washing ... Waxing ... Removing spots ... Underbody ... Glass ... Wheels ... Chrome parts ... Tire dressing ...

Cleaning interior

Air fresheners ... Floor mats ... Seat belts ...

... ....................................................................... 7-4
..................................................................... 7-4
........................................................................... 7-5
............................................................................ 7-6
................................................................ 7-6

Corrosion protection ...

Most common factors contributing to vehicle corrosion ... Environmental factors influence the rate of corrosion ... To protect your vehicle from corrosion ...

........................................................................ 7-6
....................... 7-7

............................................................... 7-6

[ Edit: 2011/ 10/ 27 Model: E52-D ]

CLEANING EXTERIOR

GUID-4EA9B7EB-CDA1-47FB-A2C3-26532BE42047
In order to maintain the appearance of your vehicle, it is important to take proper care of it. To protect the paint surface, wash your vehicle as soon as you can:

after a rainfall to prevent possible damage from acid rain after driving on coastal roads

. when contaminants such as soot, bird droppings, tree sap, metal particles or bugs get on the paint surface

. when dust or mud builds up on the surface Whenever possible, store or park your vehicle inside a garage or in a covered area. When it is necessary to park outside, park in a shady area or protect the vehicle with a body cover. Be careful not to scratch the paint surface when putting on or removing the body cover. WASHING GUID-815A82D3-09BB-4DBF-A23B-ADF010BCEEA1
Wash dirt off the vehicle with a wet sponge and plenty of water. Clean the vehicle thoroughly using a mild soap, a special vehicle soap or general purpose dishwashing liquid mixed with clean, lukewarm (never hot) water.

7-2 Appearance and care

Black plate (392,1)

CAUTION

. Do not use car washes that use acid in the detergent. Some car washes, especially brushless ones, use some acid for cleaning. The acid may react with some plastic vehicle compo- nents, causing them to crack. This could affect their appearance, and also could cause them not to func- tion properly. Always check with your car wash to confirm that acid is not used.

. Do not wash the vehicle with strong household soap, strong chemical detergents, gasoline or solvents.

. Do not wash the vehicle in direct sunlight or while the vehicle body is hot, as the surface may become water-spotted.

. Avoid using tight-napped or rough cloths, such as washing mitts. Care must be taken when removing caked-on dirt or other foreign sub- stances so the paint surface is not scratched or damaged.

Rinse the vehicle again with plenty of clean

water. Inside flanges, seams and folds on the doors, hatches and hood are particularly vulnerable to the effects of road salt. Therefore, these areas must be regularly cleaned. Make sure that the drain holes in the lower edge of the door are open. Spray water under the body and in the wheel wells to loosen the dirt and wash away road salt. Avoid leaving water spots on the paint surface by using a damp chamois to dry the vehicle. WAXING GUID-C68617DB-C1BC-44F1-817C-50A9A77A3E14
Regular waxing protects the paint surface and helps retain new vehicle appearance. Polishing is recommended to remove built-up wax residue and to avoid a weathered appearance before reapplying wax. A NISSAN dealer can assist you in choosing the proper product. . Wax your vehicle only after a thorough washing. Follow the instructions supplied with the wax.

. Do not use a wax containing any abrasives, cutting compounds or cleaners that may damage the vehicle finish.

Machine compound or aggressive polishing on a base coat/clear coat paint finish may dull the finish or leave swirl marks.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

REMOVING SPOTS GUID-57B8CB18-D0F1-4EAC-B30A-339E0909CB06
Remove tar and oil spots, industrial dust, insects, and tree sap as quickly as possible from the paint surface to avoid lasting damage or staining. Special cleaning products are available at a NISSAN dealer or any automotive accessory stores. UNDERBODY GUID-66FD4980-F058-4863-8334-834568E87693
In areas where road salt is used in winter, the underbody must be cleaned regularly. This will prevent dirt and salt from building up and causing the acceleration of corrosion on the underbody and suspension. Before the winter period and again in the spring, the underseal must be checked and, if necessary, re-treated. GLASS GUID-255CF50C-C324-4858-A02A-623C8703750B Use glass cleaner to remove smoke and dust film from the glass surfaces. It is normal for glass to become coated with a film after the vehicle is parked in the hot sun. Glass cleaner and a soft cloth will easily remove this film.

CAUTION

When cleaning the inside of the win- dows, do not use sharp-edged tools, abrasive cleaners or chlorine-based disinfectant cleaners. They could da-

mage the electrical conductors, radio antenna elements or rear window defroster elements.

WHEELS GUID-F809DD45-EBD7-42F6-B309-BAAB1202BB9C Wash the wheels when washing the vehicle to maintain their appearance. . Clean the inner side of the wheels when the is changed or the underside of the

wheel vehicle is washed. Inspect wheel rims regularly for dents or corrosion. Such damage may cause loss of pressure or poor seal at the tire bead.

. NISSAN recommends that the road wheels be waxed to protect against road salt in areas where it is used during winter.

CAUTION

Do not use abrasive cleaners when washing the wheels.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (393,1)

Aluminum alloy wheels GUID-0FAB7E05-1389-4006-962C-8433F84BF2D7
Wash regularly with a sponge dampened in a mild soap solution, especially during winter months in areas where road salt is used. Salt could discolor the wheels if not removed.

CAUTION

Follow the directions below to avoid staining or discoloring the wheels: . Do not use a cleaner that uses strong acid or alkali contents to clean the wheels.

. Do not apply wheel cleaners to the wheels when they are hot. The wheel temperature should be the same as ambient temperature.

. Rinse the wheel to completely re- move the cleaner within 15 minutes after the cleaner is applied.

CHROME PARTS GUID-F0E6C391-DF9E-4FEE-B561-AAEE76E9011F Clean chrome parts regularly with a non- abrasive chrome polish to maintain the finish.

Appearance and care 7-3

TIRE DRESSING GUID-C26535EC-C58B-48C4-93B4-03AF1ECC26A2
NISSAN does not recommend the use of tire dressings. Tire manufacturers apply a coating to the tires to help reduce discoloration of the rubber. If a tire dressing is applied to the tires, it may react with the coating and form a com- pound. This compound may come off the tire while driving and stain the vehicle paint. If you choose to use a tire dressing, take the following precautions: . Use a water-based tire dressing. The coat- ing on the tire dissolves more easily with an oil-based tire dressing.

. Apply a light coat of tire dressing to help from entering the tire tread/ to

prevent grooves (where it would be difficult remove).

it

CLEANING INTERIOR

GUID-78FD329D-FA3A-4374-B648-446134031193
Occasionally remove loose dust from the interior trim, plastic parts and seats using a vacuum cleaner or soft bristled brush. Wipe the vinyl and leather surfaces with a clean, soft cloth dam- pened in mild soap solution, then wipe clean with a dry soft cloth. Regular care and cleaning is required in order to maintain the appearance of the leather. Before using any fabric protector, read the manufacturer’s recommendations. Some fabric protectors contain chemicals that may stain or bleach the seat material. Use a cloth dampened only with water, to clean the meter and gauge lens.

WARNING

. Wipe off excess tire dressing using a dry towel. Make sure the tire dressing is completely removed from the tire tread/ grooves.

. Allow the tire dressing to dry as recom-

mended by tire dressing manufacturer.

Do not use water or acidic cleaners (hot steam cleaners) on the seat. This can damage the seat or occupant classifica- tion sensor. This can also affect the operation of the air bag system and result in serious personal injury.

7-4 Appearance and care

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (394,1)

CAUTION

. Never use benzine, thinner, or any

similar material.

. Small dirt particles can be abrasive and damaging to the leather sur- faces and should be removed promptly. Do not use saddle soap, car waxes, polishes, oils, cleaning fluids, solvents, detergents or am- monia-based cleaners as they may damage the leather’s natural finish. . Never use fabric protectors unless recommended by the manufacturer. . Do not use glass or plastic cleaner on meter or gauge lens covers. It may damage the lens cover.

the vehicle interior.

AIR FRESHENERS GUID-156AFC7C-18DA-4F6C-94E2-538B2692E7C7
Most air fresheners use a solvent that could affect If you use an air freshener, take the following precautions: . Hanging-type air

fresheners can cause permanent discoloration when they contact vehicle interior surfaces. Place the air freshener in a location that allows it to hang free and not contact an interior surface.

.

Liquid-type air fresheners typically clip on the ventilators. These products can cause immediate damage and discoloration when spilled on interior surfaces.

Carefully read and follow the manufacturer’s instructions before using air fresheners. FLOOR MATS

GUID-6BCE0CFC-5A34-4DDB-A379-848EA4E0189D

WARNING

interference

To avoid potential pedal that may result in a collision or injury: . NEVER place a floor mat on top of another floor mat in the driver front position.

. Use only genuine NISSAN floor mats specifically designed for use in your vehicle model. See your NISSAN dealer for more informa- tion.

. Properly position the mats in the floorwell using the floor mat posi- tioning aid. See “Floor mat posi- tioning aid” (P.7-5).

The use of genuine NISSAN floor mats can extend the life of your vehicle carpet and make it easier to clean the interior. Mats should be

Black plate (395,1)

maintained with regular cleaning and replaced if they become excessively worn.

SAI0038

Front (example)

Floor mat positioning aid GUID-5CC94A77-7199-415F-920B-4ABB39D763BA This vehicle includes front floor mat brackets to act as floor mat positioning aid. NISSAN floor mats have been specially designed for your vehicle model. The front floor mats have grommet holes in them. Position the mat by placing the floor mat bracket hook through the floor mat grommet hole while centering the mat in the floorwell. Periodically check to make certain that the mats are properly positioned.

Appearance and care 7-5

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (396,1)

CORROSION PROTECTION

GUID-14BA8034-9973-4F4C-A4F3-E1D69D9F18F0

MOST COMMON FACTORS CONTRI- BUTING TO VEHICLE CORROSION

GUID-FDA56B33-019D-4844-B3A0-83EA863BEA0F The accumulation of moisture-retaining dirt and debris in body panel sections, cavities, and other areas.

. Damage to paint and other protective coat- ings caused by gravel and stone chips or minor traffic accidents.

ENVIRONMENTAL FACTORS INFLU- ENCE THE RATE OF CORROSION

GUID-4F502838-DDCE-43B1-9F12-78EF5B138FEF

Moisture GUID-3CE9F892-5C05-4FB5-8BAF-3846686E0203
Accumulation of sand, dirt and water on the vehicle body underside can accelerate corro- sion. Wet floor coverings will not dry completely inside the vehicle, and should be removed for drying to avoid floor panel corrosion.

Relative humidity GUID-25D1E76B-60F9-4A6C-9722-7A22749068B8
Corrosion will be accelerated in areas of high relative humidity, especially those areas where the temperatures stay above freezing where atmospheric pollution exists, or where road salt is used.

belts, since these materials may se- verely weaken the seat belt webbing.

SAI0058

Bracket positions

The illustration shows the location of the floor mat brackets. SEAT BELTS GUID-54C9C999-A355-4B29-99B0-6F8D2941E223
The seat belts can be cleaned by wiping them with a sponge dampened in a mild soap solution. Allow the belts to dry completely before using them. See “Seat belts” (P.1-16).

WARNING

Do not allow wet seat belts to roll up in the retractor. NEVER use bleach, dye, or chemical solvents to clean the seat

7-6 Appearance and care

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Black plate (397,1)

Remove dirt with a vacuum cleaner. . Never allow water or other liquids to come in contact with electronic components inside the vehicle as this may damage them.

Chemicals used for road surface deicing are extremely corrosive. They accelerate corrosion and deterioration of underbody components such as the exhaust system, fuel and brake lines, brake cables, floor pan and fenders. In winter, the underbody must be cleaned periodically. For additional protection against rust and corrosion, which may be required in some areas, consult a NISSAN dealer.

Temperature GUID-CDF5FBA1-A705-4AAD-A67B-BA35229970EB A temperature increase will accelerate the rate of corrosion to those parts which are not well ventilated.

Air pollution GUID-6BF1E123-A934-4049-A3DA-7CE3944CCFBF Industrial pollution, the presence of salt in the air in coastal areas, or heavy road salt use will accelerate the corrosion process. Road salt will also accelerate the disintegration of paint surfaces. TO PROTECT YOUR VEHICLE FROM CORROSION GUID-3DEDDCC2-5871-4ED1-8E35-3D07DA497BC8
. Wash and wax your vehicle often to keep the

vehicle clean.

. Always check for minor damage to the paint

and repair it as soon as possible.

. Keep drain holes at the bottom of the doors

open to avoid water accumulation.

. Check the underbody for accumulation of sand, dirt or salt. If present, wash with water as soon as possible.

CAUTION

. NEVER remove dirt, sand or other debris from the passenger compart- ment by washing it out with a hose.

[ Edit: 2011/ 10/ 27 Model: E52-D ]

Appearance and care 7-7

Black plate (398,1)

MEMO

7-8 Appearance and care

[ Edit: 2011/ 10/ 27 Model: E52-D ]

8 Maintenance and do-it-yourself

Black plate (399,1)
