13 CR-Z-31SZT6200.book 0 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Contents
3 CR-Z
201 Online Reference Owner's Manual This owner’s manual should be considered a permanent part of the vehicle and should remain with the vehicle when it is sold.
2 Safe Driving P. 27
For Safe Driving P. 28Seat Belts P. 32
Airbags P. 39
2 Instrument Panel P. 65
Indicators P. 66Gauges and Multi-Information Display P. 81
This owner’s manual covers all models of your vehicle. You may find descriptions of equipment and features that are not on your particular model.
2 Controls P. 97
Setting the Clock P. 98
Operating the Switches Around the Steering Wheel P. 110
Interior Lights/Interior Convenience Items P. 126Locking and Unlocking the Doors P. 99
Images throughout this owner’s manual (including the front cover) represent features and equipment that are available on some, but not all, models. Your particular model may not have some of these features.
This owner's manual is for vehicles sold in the United States and Canada.
The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.
Navigation Key
2 Features P. 137
Audio System P. 138Audio Error Messages P. 153
2 Driving P. 171
Before Driving P. 172
Multi-View Rear Camera P. 213
Refueling P. 216Towing a Trailer P. 177
Fuel Economy P. 219
2 Maintenance P. 221
Before Performing Maintenance P. 222 Maintenance Minder™ P. 225
Checking and Maintaining Wiper Blades P. 250
Climate Control System Maintenance P. 264QRG Quick Reference Guide
TOC
Chapter Table of Contents
2 Handling the Unexpected P. 269
Tools P. 270
Overheating P. 290If a Tire Goes Flat P. 271
Indicator, Coming On/Blinking P. 292Index
Index
Home Book Table of Contents
2 Information P. 305
Specifications P. 306
Emissions Testing P. 311Identification Numbers P. 308
Warranty Coverages P. 31300X31-SZT-6200 © 2012 American Honda Motor Co., Inc. - All Rights Reserved 13 CR-Z-31SZT6200.book 1 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Child Safety P. 54
Exhaust Gas Hazard P. 62
Safety Labels P. 63
Opening and Closing the Hatch P. 104
Adjusting the Mirrors P. 119
Climate Control System P. 134Security System P. 106
Opening and Closing the Windows P. 108
Adjusting the Seats P. 121General Information on the Audio System P. 155
Bluetooth® HandsFreeLink® P. 158
When Driving P. 178
Rearview Camera P. 214
Accessories and Modifications P. 220Braking P. 208
Parking Your Vehicle P. 212
Contents
2013 CR-Z
Quick Reference Guide P. 2
Safe Driving P. 27
Instrument Panel P. 65
Controls P. 97
Features P. 137
Driving P. 171
Maintenance P. 221
Maintenance Under the Hood P. 229
Checking and Maintaining Tires P. 253
Cleaning P. 265Replacing Light Bulbs P. 242
12 Volt Battery P. 262Remote Transmitter Care P. 263
Handling the Unexpected P. 269
Engine Does Not Start P. 286
Fuses P. 297Jump Starting P. 287
Emergency Towing P. 301Shift Lever Does Not Move P. 289
When You Cannot Open the Hatch P. 303Information P. 305
Index P. 317
Devices that Emit Radio Waves P. 309
Authorized Manuals P. 315Reporting Safety Defects P. 310
Customer Service Information P. 316QRG Quick Reference Guide
Index
Index
Navigation Key
TOC
Chapter Table of Contents
Home Book Table of Contents
13 CR-Z-31SZT6200.book 2 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Quick Reference Guide Visual Index
(Vehicle Stability Assist (VSA®) System OFF) Button (P 204)
❙ ❙ km/h/mph Change Button (P81)
❙ System Indicators (P 66) ❙ Gauges (P 81) ❙ Multi-Information Display (P 83)
❙ Climate Control System (P134 ) ❙ Hazard Warning Button
❙ Audio System (P 138) ❙ Navigation System * () See Navigation System Manual
❙ Rear Window Defogger (P 117) ❙ Heated Mirror Button * (P 117)
❙ Seat Heater Switches * (P133) ❙ Ignition Switch (P 110)
❙ Steering Wheel Adjustments (P 118)
❙ SPORT Mode Button (P 197) ❙ NORMAL Mode Button (P 197) ❙ ECON Mode Button (P 197)
* Not available on all models
QRG QRG
Index Index
Home Home
13 CR-Z-31SZT6200.book 3 ページ ２０１２年１０月２５日 木曜日 午後９時９分
QRG
Index
Home
❙ Headlights/Turn Signals (P 111) ❙ Fog Lights * (P 113)
❙ Paddle Shifter (Shift down) * (P186) ❙ Remote Audio Control Buttons (P 142) ❙ Brightness Control (P 116) ❙ Paddle Shifter (Shift up) * (P 186) ❙ Wipers/Washers (P 114)
❙ Cruise Control Buttons (P 200) ❙ SEL/RESET Button (P 83) ❙ ❙ Plus Sport Button (P198)
(Information) Button (P 83)
❙ Horn (Press an area around
.)
❙ Bluetooth® HandsFreeLink® System Voice Control Buttons * (P 158) ❙ Navigation System Voice Control Buttons * () See Navigation System Manual
* Not available on all models
13 CR-Z-31SZT6200.book 4 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Visual Index
❙ Driver’s Door Lock Switch (P 102) ❙ Door Mirror Controls (P 120) ❙ Driver's Front Airbag (P 42)
❙ Passenger's Front Airbag (P 42)
❙ Center Pocket ❙ USB Adapter Cable (P 129) ❙ Auxiliary Input Jack (P 140) ❙ Accessory Power Socket (P 129)
❙ Glove Box (P 127)
❙ Shift Lever Automatic Transmission (CVT) (P 183) Manual Transmission (P 188)
❙ Parking Brake (P 208)
❙ Interior Fuse Box (P 298) ❙ Hood Release Handle (P 230) ❙ Power Door Lock Master Switch (P 102) ❙ Power Window Switches (P 108)
QRG
Index
Home
13 CR-Z-31SZT6200.book 5 ページ ２０１２年１０月２５日 木曜日 午後９時９分
QRG
❙ Cargo Area Light
Index
Home
❙ Interior Lights (Rear) (P 126)
❙ Side Curtain Airbags (P 49)
❙ Seat Belts (P 32)
❙ Sun Visors ❙ Vanity Mirrors * ❙ Interior Lights/Map Lights (P 126) ❙ Rearview Mirror (P 119)
❙ Upper Instrument Panel Storage
❙ Seats (P 121)
❙ Side Airbags (P 46)
❙ Rear Cargo Console (P 130)
❙ Cargo Area (P 130)
* Not available on all models
13 CR-Z-31SZT6200.book 6 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Visual Index
❙ Maintenance Under the Hood (P 229)
QRG
Index
Home
❙ Windshield Wipers (P 114)
(P 250) ❙ Door Mirrors (P 120) ❙ Side Turn Signal Lights (P 111)
(P 246)
❙ Door Lock/Unlock Control (P 100)
❙ Tires (P 253) ❙ Fog Lights * (P 113)
(P 271)
❙ Headlights (P 111) (P 242) ❙ Front Turn Signal/Parking/ Side Marker Lights (P 111)
(P 246)
❙ How to Refuel (P 217)
❙ Rear Wiper (P115)
(P252)
❙ High-Mount Brake Light (P 249)
❙ Opening/Closing the Hatch (P 104) ❙ Hatch Release (P105)
❙ Rear License Plate Lights (P 249) ❙ Rearview Camera (P214)
❙ Back-Up Lights (P 247) ❙ Brake/Taillights (P 248) ❙ Rear Side Marker Lights (P 248) ❙ Rear Turn Signal Lights (P 247)
* Not available on all models
13 CR-Z-31SZT6200.book 7 ページ ２０１２年１０月２５日 木曜日 午後９時９分
QRG
Index
Home
3-Mode Drive System There are three driving modes for your vehicle: SPORT, NORMAL and ECON. Each mode offers a different level of driving performance. The mode buttons are located on the control panel. NORMAL mode, which is most suitable for all-purpose driving, is the default setting for your vehicle.
SPORT Mode Increases engine performance and handling. Suitable for driving at hills or curves in a mountain, or driving in a suburb.
NORMAL Mode Balances driving performance and fuel economy. Best for most driving situations.
ECON Mode Maximizes fuel economy. Provides longer Auto Idle Stop operating time when the climate control system is in use.
The indicator of the selected mode comes on.
Plus Sport System Helps the vehicle to momentarily accelerate with more engine and electric motor assist power when you depress the accelerator pedal.
Plus Sport Button
The indicator blinks when the Plus Sport System stands by to be activated, and when the system is in operation.
button, then depress the
Press the accelerator pedal to activate the Plus Sport System in any driving mode (SPORT, NORMAL, or ECON). This helps you to momentarily accelerate with more power when you depress the accelerator pedal.
Plus Sport System (P198)
13 CR-Z-31SZT6200.book 8 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Eco Assist System
QRG
Canadian models
Index
Home
The Shift UP/DOWN Indicators * (P189) ● These indicators alert you when it is appropriate to
shift to attain better fuel economy.
Displays when shifting up is recommended.
Displays when shifting down is recommended.
The indicators do not come on in SPORT mode.
Ambient Meter ● Changes color to reflect your driving style.
Green: Fuel efficient driving Blue green: Moderate acceleration/deceleration Blue: Aggressive acceleration/deceleration
● Changes to constant red when SPORT mode is
selected.
● The ambient meter color changes in accordance with:
Automatic transmission (CVT) models Your brake or accelerator pedal operation. Manual transmission models Your brake or accelerator pedal operation, and shift changes based on the shift up indicator.
* Not available on all models
13 CR-Z-31SZT6200.book 9 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Drive Cycle Score/Lifetime Points ● Comes on when the ignition switch is in LOCK (0.
Drive Cycle Score
Advancing to Second Stage
Advancing to Third Stage
Receding to First Stage
Receding to Second Stage
QRG
Real Time Score (represents your current trip) (P86) ● Each time you turn the ignition switch to ON (w, the Ecological Drive display starts without any leaves on the plants. Leaves
Lifetime Points
accumulate or diminish based on your driving style during the current trip.
First Stage
Second Stage
Third Stage Ecological Guide Display Feedback with Eco Drive Bar (P87) ● Keep the bar from extending too much to the left or right side. The shorter the bar is while driving, the higher the fuel economy becomes.
The bar extends to the right when you press the accelerator pedal.
Slow, steady acceleration/ Maximizes fuel economy
Moderate acceleration
Aggressive/Inconsistent acceleration
Index
Home
The bar extends to the left when you press the brake pedal.
Slow deceleration/ Maximizes fuel economy
Moderate deceleration
Aggressive deceleration
QRG
13 CR-Z-31SZT6200.book 10 ページ ２０１２年１０月２５日 木曜日 午後９時９分
The Honda IMA System
The main power source for the Honda IMA system is the gasoline engine. The electric motor assists the engine to improve fuel economy, based on current operating conditions.
Tips to Improve Fuel Economy To help your vehicle’s fuel economy: ● Avoid aggressive acceleration/braking ● Monitor the ambient meter and the Eco drive bar
Start-up/Low speed cruise/ Aggressive acceleration ● The electric motor assists the
engine.
Vehicle Speed
Time
IMA System
Electric Motor Assist
Engine
ON
IMA Battery
Fuel
Slow acceleration/High speed cruise ● Only the engine powers
the vehicle.
displayed on the multi-information display. It reflects your driving style. (P8)
(P86)
Deceleration ● The IMA system charges
the IMA battery.
IMA System
Electric Motor OFF
IMA Battery
Engine
ON
Fuel
IMA System
Stop ● Auto Idle Stop is in
operation.
Charging
Engine
OFF
IMA Battery
Fuel
IMA System
Electric Motor OFF
IMA Battery
Engine
OFF
Fuel
Eco Drive Bar Display
Index
Home
10
13 CR-Z-31SZT6200.book 11 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Auto Idle Stop Function To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the AUTO STOP indicator blinks. (P191) At
Manual transmission
Engine status
(P194)
Automatic transmission (CVT) Depress the brake pedal. The vehicle speed goes below 6 mph (10 km/h).
Deceleration
Stop
Start-up
Continue to depress the brake pedal.
Release the brake pedal.
QRG
Index
Home
1. Depress the brake pedal. The vehicle speed goes below 19 mph (30 km/h). 2. Fully depress the
clutch pedal.
• Continue to depress the brake pedal.
• Move the shift
lever to (N. • Release the clutch pedal.
1. Fully depress
the clutch pedal again.
2. Move the shift
lever to (1. 3. Depress the accelerator pedal to resume driving.
Turning off
Off
Restarting
11
13 CR-Z-31SZT6200.book 12 ページ ２０１２年１０月２５日 木曜日 午後９時９分
To Keep the IMA Battery in Good Condition Drive your vehicle at least once a month, and drive for more than 30 minutes at a time. Parking your vehicle for an extended period can cause the IMA battery to weaken or decrease the IMA battery life.
Safety Precautions Do not cover the air intake.
Do not touch the Honda IMA System A high voltage current runs through Honda IMA System. Consult your authorized dealer when maintenance or repair is needed.
Do not spill any liquids on or around the IMA battery, as they can damage the IMA battery. If you accidentally spill liquids on or around the battery, ensure that the spill is completely wiped up as soon as possible. The IMA system indicator may come on.
IMA Battery
IMA Power Cable
QRG
Air Intake
If the air intake is obstructed during vehicle operation, the IMA battery can become too hot. To protect the battery, the system may start limiting IMA battery output power and cause the IMA system and 12 volt battery charging system indicators to come on.
If a crash occurs ● Be careful of electric shock hazard.
u If a crash severely damaged your vehicle, there is a possibility of electrical shock. Do not
touch the IMA system components or its wiring (orange).
● Avoid contact with IMA battery fluid.
u The battery fluid may leak as a result of a severe crash. Avoid any skin or eye contact with
the fluid. The battery fluid is corrosive. If you accidentally touch it, flush the affected area(s) with a large quantity of water for at least five minutes, and seek medical attention immediately.
IMA System Indicator (P86)
● Use a fire extinguisher for an electrical fire.
12 Volt Battery Charging System Indicator (P67)
u Attempting to extinguish an electrical fire with a small quantity of water can be
dangerous.
When the vehicle is disposed ● The IMA battery is a Lithium ion battery. Honda collects and recycles used IMA batteries –
consult with your dealer for proper battery disposal in the event your vehicle is not repairable.
Index
Home
12
13 CR-Z-31SZT6200.book 13 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Safe Driving (P27)
QRG
Index
Home
Airbags (P39) ● Your vehicle is fitted with airbags to help protect you and
your passenger during a moderate-to-severe collision.
Child Safety (P54) ● Your vehicle is not recommended for child passengers. If you decide to
disregard our recommendations and transport a child passenger, the child should be properly restrained. Never put a rear-facing child seat in the passenger's seat.
Exhaust Gas Hazard (P62) ● Your vehicle emits dangerous exhaust gases that contain carbon
monoxide. Do not run the engine in confined spaces where carbon monoxide gas can accumulate.
Seat Belts (P32) ● Fasten your seat belt and sit upright well
back in the seat.
● Check that your passenger is wearing their
Before Driving Checklist (P172) ● Before driving, check that the seats, steering wheel, and
mirrors have been properly adjusted.
seat belt correctly.
Fasten your lap belt as low as possible.
13
13 CR-Z-31SZT6200.book 14 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Instrument Panel (P65) Gauges (P81)/Multi-Information Display (P83)/System Indicators (P66)
Lights Reminders
Lights On Indicator
High Beam Indicator
Fog Light Indicator *
System Indicators
CHRG/ASST Indicators IMA Battery Charge Level Indicator
Ambient Meter
Tachometer
Speedometer
Fuel Gauge
Malfunction Indicator Lamp Low Oil Pressure Indicator 12 Volt Battery Charging System Indicator Anti-lock Brake System (ABS) Indicator Vehicle Stability Assist (VSA®) System Indicator
VSA® OFF Indicator
Turn Signal and Hazard Warning Indicators Electric Power Steering (EPS) System Indicator Immobilizer System Indicator
IMA System Indicator
Auto Idle Stop Indicator
7-Speed Manual Shift Mode Indicator *
Security System Alarm Indicator
Shift Lever Position Indicator
Shift UP/DOWN Indicator *
Instant Fuel Economy Gauge
Multi-Information Display
System Indicators
High Temperature Indicator
Low Temperature Indicator
Low Fuel Indicator
SPORT Mode Indicator
NORMAL Mode Indicator
ECON Mode Indicator
System Indicators
Seat Belt Reminder Indicator
Parking Brake and Brake System Indicator (Red)
Supplemental Restraint System Indicator
Side Airbag Off Indicator
U.S. models only Low Tire Pressure/ TPMS Indicator Door/Hatch Open Indicator CRUISE MAIN Indicator CRUISE CONTROL Indicator System Message Indicator Plus Sport System Indicator Plus Sport READY Indicator
Plus Sport Indicator
QRG
Index
Home
14
13 CR-Z-31SZT6200.book 15 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Controls (P97) Clock (P98)
Models without navigation system
Turn Signals (P111)
Turn Signal Control Lever
Right
Wipers and Washers (P114)
Wiper/Washer Control Lever
Adjustment Ring
: Long Delay : Short Delay
QRG
Index
Home
a beep. The displayed time begins flashing.
a Press the FM/AM button until you hear b Press (1 (Hour) or (2 (Minute) to set c Press the FM/AM button again to set
the time. Press (3 (Reset) to set the time to the nearest hour.
the time.
Models with navigation system The navigation system receives signals from GPS satellites, updating the clock automatically.
Left
Lights (P111)
Light Control Switches
High Beam
Low Beam
Flashing
Pull toward you to spray washer fluid.
MIST OFF INT: Low speed with intermittent LO: Low speed wipe HI: High speed wipe
15
13 CR-Z-31SZT6200.book 16 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Steering Wheel (P118) ● To adjust, pull the adjustment lever
towards you, adjust to the desired position, then lock the lever back in place.
Hatch (P104)
QRG
Index
Home
16
● With the doors unlocked, press the hatch
release button on the hatch to open it.
Power Door Mirrors (P120) ● With the ignition switch in ON (w, move
the selector switch to L or R.
● Push the appropriate edge of the
adjustment switch to adjust the mirror.
Selector Switch
Adjustment Switch
Power Windows (P108) ● With the ignition switch in ON (w, open
and close the power windows.
● If the power window lock button is in the off position, the passenger's window can be opened and closed with its own switch.
● If the power window lock button is in the
on position, the passenger's window switch is disabled.
Power Window Lock Button
Window Switch
13 CR-Z-31SZT6200.book 17 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Climate Control System (P134) ● Press the AUTO button to activate the climate control system. ● Press the ● Press the
button to turn the system on or off.
button to defrost the windshield.
QRG
Index
Home
Models with navigation system The climate control system is voice operable. See the navigation system manual for complete details.
(MODE Control) Button
Air flows from floor and windshield defroster vents.
Air flows from floor vents.
Air flows from floor and dashboard vents.
Air flows from dashboard vents.
A/C (Air Conditioning) Button
AUTO Button
Temperature Control Dial
(ON/OFF) Button
(Windshield Defroster) Button
(Rear Window Defogger/ Heated Mirror*) Button
(Recirculation) Button
(Fan Control) Button
* Not available on all models
17
13 CR-Z-31SZT6200.book 18 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Features (P137) Audio System (P138) For navigation system operation () See Navigation System Manual
● Audio Remote Controls (P142)
MODE Button
CH Button
VOL Button
CD Slot
Button
Audio Display
FM/AM Button
(CD Eject) Button
(Power) Button
VOL/SELECT (Volume/Select) Knob
SEEK Button
Auxiliary Input Jack
CD Button
AUX Button
Preset Buttons (1-6) TITLE Button
RDM/A.SEL (Random/ Auto Select) Button
RPT (Repeat) Button
SCAN Button
(Sound) Button
SEEK Button
Button
● VOL (volume) Button
Press and release volume up/down.
3 4
to adjust the
● MODE Button
Press and release to change the audio mode: FM1/FM2/AM/CD/AUX.
● CH (channel) Button
Radio:Press and release to change the
preset station. Press and hold to select the next or previous strong station.
CD/USB device:
Press and release to skip to the beginning of the next song or return to the beginning of the current song. Press and hold to change a folder.
QRG
Index
Home
18
13 CR-Z-31SZT6200.book 19 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Driving (P171) Manual Transmission (P188) Automatic Transmission (CVT) (P183) ● Shift to (P and depress the brake pedal when
starting the engine.
● Shifting
Park Turn off or start the engine. Transmission is locked. Reverse
Neutral Transmission is not locked.
Drive Normal driving. 7-speed manual shift mode can be used. L mode is available.
Depress the brake pedal and press the release button to move out of (P.
Move the shift lever without pressing the release button.
Press the release button to move the shift lever.
QRG
Index
Home
7-Speed Manual Shift Mode (P185) ● Allows you to manually shift the transmission up or down without
removing your hands from the steering wheel.
Release Button
Shift Lever
Shift Indicator
(M Indicator
Shift Down (- Paddle Shifter
Shift Up (+ Paddle Shifter
SPORT Mode ● Pulling a paddle shifter changes the
mode from automatic transmission (CVT) to 7-speed manual shift mode. The M indicator and the selected speed number are displayed in the shift indicator.
NORMAL Mode/ECON Mode ● Pulling a paddle shifter temporarily changes the mode from automatic transmission (CVT) to 7-speed manual shift mode. The selected speed number is displayed in the shift indicator.
L (Low) Mode (P187) ● Use Low to get more power when
climbing steep hills.
● Pull the (+ and (- paddle shifters at the same time until the shift indicator display changes to L.
Ignition Switch
19
13 CR-Z-31SZT6200.book 20 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Refueling (P216) Fuel recommendation: Unleaded gasoline with a pump octane number 87 or
Fuel tank capacity: 10.6 US gal (40 L)
higher required
a Press and release the
center of the rear edge of the fuel fill door. You hear a click. The door pops open slightly.
b Turn the fuel fill cap
slowly to remove the cap.
c Place the cap in the
holder on the fuel fill door.
d After refueling, screw
the cap back on until it clicks at least once.
VSA® OFF Button (P204) ● The vehicle stability assist (VSA®) system
helps stabilize the vehicle during cornering, and helps maintain traction while accelerating on loose or slippery road surfaces.
● VSA® comes on automatically every time
you start the engine.
● To turn VSA® on or off, press and hold
the
button until you hear a beep.
Cruise Control (P200) ● Cruise control allows you to maintain a set speed without keeping your foot on the accelerator pedal.
● To use cruise control, press the CRUISE button, then press DECEL/SET once you have achieved the desired speed above 25 mph or 40 km/h.
Tire Pressure Monitoring System (TPMS) (P205) U.S. models only ● TPMS monitors tire pressure. ● TPMS is turned on automatically every
time you start the engine.
QRG
Index
Home
20
13 CR-Z-31SZT6200.book 21 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Maintenance (P221) Under the Hood (P229) ● Check engine oil, engine coolant, and window washer fluid.
Add when necessary.
● Check transmission fluid (CVT). ● Check brake fluid and clutch fluid. ● Check the 12 volt battery regularly.
a Pull the hood release handle under the corner of the
dashboard.
QRG
Wiper Blades (P250) ● Replace blades if they leave streaks
across the windshield.
b Locate the hood latch lever, pull the lever up, and lift up
the hood.
Index
Home
c When finished, close the hood and make sure it is firmly
locked in place.
Tires (P253) ● Inspect tires and wheels regularly. ● Check tire pressures regularly. ● Install snow tires for winter driving.
Lights (P242) ● Inspect all lights regularly.
21
13 CR-Z-31SZT6200.book 22 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Handling the Unexpected (P269) Flat Tire (P271) ● Park in a safe place and repair the flat tire
Engine Won't Start (P286) ● If the battery is dead, jump start using a
booster battery.
using the temporary tire repair kit.
Models with an optional compact spare tire ● Park in a safe place and replace the flat
tire with the compact spare tire in the cargo area.
QRG
Overheating (P290) ● Park in a safe location. If you do not see steam under the hood, open the hood, and let the engine cool down.
Indicators Come On (P292) ● Identify the indicator and consult the
owner's manual.
Blown Fuse (P297) ● Check for a blown fuse if an electrical
device does not operate.
Emergency Towing (P301) ● Call a professional towing service if you
need to tow your vehicle.
Index
Home
22
13 CR-Z-31SZT6200.book 23 ページ ２０１２年１０月２５日 木曜日 午後９時９分
What to Do If
QRG
Index
Home
The ignition switch does not turn from (0 to (q. Why?
● The steering wheel may be locked. ● Move the steering wheel left and right
while turning the ignition key.
The ignition switch does not turn from (q to (0 and I cannot remove the key. Why?
The shift lever should be moved to (P on the automatic transmission (CVT) model.
Why does the brake pedal pulsate slightly when applying the brakes?
This can occur when the ABS activates, and does not indicate a problem. Apply firm, steady pressure on the brake pedal. Never pump the brake pedal.
Why do the doors lock after I unlocked the doors using a remote transmitter?
If you do not open the doors within 30 seconds, the doors are relocked automatically for security.
23
13 CR-Z-31SZT6200.book 24 ページ ２０１２年１０月２５日 木曜日 午後９時９分
Why does the beeper sound when I open the driver's door?
