2015 Ford Transit Owners Manual

Download PDF Manual
2015 TRANSIT Owner’s Manual ’ fordowner.com ford.ca October 2014 Third Printing Owner’s Manual Transit Litho in U.S.A. FK3J 19A321 AB The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2014 All rights reserved. Part Number: 03/2014 20140915160737 Table of Contents Introduction About This Manual...........................................7 Symbols Glossary.............................................7 Data Recording..................................................9 California Proposition 65.............................10 Perchlorate........................................................10 Ford Credit.........................................................10 Replacement Parts Recommendation......................................10 Special Notices.................................................11 Mobile Communications Equipment......................................................11 Export Unique Options...................................11 Child Safety General Information.......................................13 Installing Child Seats.....................................14 Booster Seats..................................................22 Child Seat Positioning..................................24 Child Safety Locks..........................................25 Safety Belts Principle of Operation..................................26 Fastening the Safety Belts..........................27 Safety Belt Height Adjustment.................29 Safety Belt Warning Lamp and Indicator Chime.............................................................29 Safety Belt Minder.........................................30 Child Restraint and Safety Belt Maintenance.................................................31 Supplementary Restraints System Principle of Operation...................................32 Driver and Passenger Airbags....................33 Side Airbags.....................................................39 Safety Canopy™............................................40 Crash Sensors and Airbag Indicator.........41 Airbag Disposal...............................................42 Keys and Remote Controls Principle of Operation..................................43 General Information on Radio Frequencies..................................................43 Remote Control..............................................43 Replacing a Lost Key or Remote Control...........................................................45 MyKey™ Principle of Operation..................................46 Creating a MyKey............................................47 Clearing All MyKeys.......................................48 Checking MyKey System Status..............49 Using MyKey With Remote Start Systems.........................................................50 MyKey Troubleshooting................................51 Locks Locking and Unlocking.................................53 Security Passive Anti-Theft System........................58 Anti-Theft Alarm............................................59 Steering Wheel Adjusting the Steering Wheel...................60 Audio Control - Vehicles Without: Touchscreen Display................................60 Audio Control - Vehicles With: Touchscreen Display..................................61 Voice Control - Vehicles Without: Touchscreen Display..................................61 Voice Control - Vehicles With: Touchscreen Display..................................61 Cruise Control..................................................62 Information Display Control.......................62 Wipers and Washers Windshield Wipers.........................................63 Autowipers.......................................................63 Windshield Washers.....................................64 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Table of Contents Lighting General Information......................................65 Lighting Control..............................................65 Autolamps........................................................66 Instrument Lighting Dimmer......................67 Daytime Running Lamps.............................67 Direction Indicators.......................................68 Interior Lamps.................................................68 Windows and Mirrors Power Windows.............................................69 Exterior Mirrors................................................70 Interior Mirror...................................................70 Rear Quarter Windows..................................71 Instrument Cluster Gauges................................................................72 Warning Lamps and Indicators.................74 Audible Warnings and Indicators.............76 Information Displays General Information......................................78 Trip Computer..................................................81 Personalized Settings...................................82 Information Messages.................................83 Climate Control Principle of Operation..................................88 Air Vents............................................................88 Manual Climate Control..............................89 Hints on Controlling the Interior Climate..........................................................90 Rear Passenger Climate Controls.............91 Heated Windows and Mirrors....................92 Seats Sitting in the Correct Position...................93 Head Restraints..............................................93 Manual Seats..................................................94 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Power Seats.....................................................96 Rear Seats.........................................................97 Auxiliary Power Points Auxiliary Power Points.................................101 Cigar Lighter...................................................102 Storage Compartments Cup Holders....................................................103 Overhead Console.......................................103 Bottle Holder..................................................103 Starting and Stopping the Engine General Information....................................104 Ignition Switch..............................................104 Starting a Gasoline Engine.......................104 Starting a Diesel Engine............................105 Diesel Particulate Filter..............................106 Switching Off the Engine...........................107 Engine Block Heater....................................107 Fuel and Refueling Safety Precautions......................................109 Fuel Quality - Gasoline................................110 Fuel Quality - Diesel......................................111 Fuel Filler Funnel Location.........................113 Running Out of Fuel......................................113 Catalytic Converter.......................................114 Selective Catalytic Reduction System...........................................................115 Refueling...........................................................118 Fuel Consumption.......................................120 Emission Control System...........................122 Transmission Automatic Transmission............................132 Brakes General Information....................................136 Table of Contents Reduced Engine Performance.................172 Economical Driving.......................................172 Cold Weather Precautions.........................173 Driving Through Water................................173 Floor Mats........................................................173 Roadside Emergencies Roadside Assistance...................................175 Hazard Warning Flashers...........................176 Fuel Shutoff....................................................176 Jump Starting the Vehicle..........................177 Post-Crash Alert System...........................179 Customer Assistance Getting the Services You Need...............180 In California (U.S. Only)..............................181 The Better Business Bureau (BBB) Auto Line Program (U.S. Only)......................182 Utilizing the Mediation/Arbitration Program (Canada Only)........................182 Getting Assistance Outside the U.S. and Canada.........................................................183 Ordering Additional Owner's Literature.....................................................184 Reporting Safety Defects (U.S. Only).............................................................184 Reporting Safety Defects (Canada Only).............................................................185 Fuses Fuse Box Locations.....................................186 Fuse Specification Chart...........................187 Changing a Fuse...........................................198 Maintenance General Information..................................200 Opening and Closing the Hood.............200 Under Hood Overview - 3.5L....................201 Under Hood Overview - 3.7L...................202 Under Hood Overview - 3.2L Power Stroke Diesel.............................................203 Hints on Driving With Anti-Lock Brakes...........................................................136 Parking Brake..................................................137 Traction Control Principle of Operation.................................138 Using Traction Control................................138 Stability Control Principle of Operation................................140 Using Stability Control.................................141 Parking Aids Principle of Operation.................................142 Parking Aid......................................................142 Rear View Camera........................................143 Cruise Control Principle of Operation................................146 Using Cruise Control...................................146 Driving Aids Speed Limiter................................................148 Driver Alert......................................................148 Lane Keeping System.................................149 Load Carrying Load Retaining Fixtures..............................152 Load Limit........................................................152 Towing Towing a Trailer.............................................160 Trailer Sway Control.....................................161 Recommended Towing Weights.............161 Essential Towing Checks...........................163 Transporting the Vehicle...........................169 Towing the Vehicle on Four Wheels......170 Driving Hints Breaking-In......................................................172 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Table of Contents Wheels and Tires General Information...................................233 Tire Care..........................................................234 Using Winter Tires.......................................250 Using Snow Chains......................................251 Tire Pressure Monitoring System............251 Changing a Road Wheel...........................256 Lug Nuts..........................................................264 Capacities and Specific- ations Engine Specifications - 3.5L....................265 Engine Specifications - 3.7L....................265 Engine Specifications - 3.2L Power Stroke Diesel.............................................266 Motorcraft Parts - 3.5L..............................267 Motorcraft Parts - 3.7L..............................268 Motorcraft Parts - 3.2L Power Stroke Diesel...........................................................269 Vehicle Identification Number................270 Vehicle Certification Label.......................270 Transmission Code Designation..............271 Capacities and Specifications - 3.5L......271 Capacities and Specifications - 3.7L.....274 Capacities and Specifications - 3.2L Power Stroke Diesel................................278 Audio System General Information...................................282 Audio Unit - Vehicles With: AM/FM......283 Audio Unit - Vehicles With: Premium AM/ FM/CD.........................................................286 Audio Unit - Vehicles With: AM/FM/CD/ SYNC............................................................288 Audio Unit - Vehicles With: AM/FM/CD/ SYNC/Satellite Radio............................290 Digital Radio..................................................292 Satellite Radio..............................................294 Audio Input Jack...........................................297 USB Port..........................................................297 Media Hub......................................................298 Engine Oil Dipstick - 3.5L.........................204 Engine Oil Dipstick - 3.7L..........................204 Engine Oil Dipstick - 3.2L Power Stroke Diesel...........................................................204 Engine Oil Check..........................................204 Changing the Engine Oil and Oil Filter.............................................................205 Oil Change Indicator Reset......................206 Engine Coolant Check...............................206 Automatic Transmission Fluid Check...........................................................209 Brake Fluid Check.........................................210 Power Steering Fluid Check.....................210 Washer Fluid Check.....................................210 Draining the Fuel Filter Water Trap........210 Fuel Filter - Gasoline....................................212 Changing the 12V Battery..........................213 Checking the Wiper Blades.......................215 Changing the Wiper Blades......................215 Adjusting the Headlamps..........................215 Removing a Headlamp...............................216 Changing a Bulb............................................217 Bulb Specification Chart............................221 Changing the Engine Air Filter - 3.5L.....223 Changing the Engine Air Filter - 3.7L......224 Changing the Engine Air Filter - 3.2L Power Stroke Diesel................................225 Vehicle Care Cleaning Products........................................227 Cleaning the Exterior...................................227 Waxing.............................................................228 Cleaning the Engine....................................228 Cleaning the Windows and Wiper Blades..........................................................229 Cleaning the Interior...................................229 Cleaning the Instrument Panel and Instrument Cluster Lens.......................229 Repairing Minor Paint Damage..............230 Cleaning the Alloy Wheels.......................230 Vehicle Storage..............................................231 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Table of Contents Audio Troubleshooting..............................299 SYNC™ General Information..................................300 Using Voice Recognition...........................302 Using SYNC™ With Your Phone...........304 SYNC™ Applications and Services.......318 Using SYNC™ With Your Media Player...........................................................329 SYNC™ Troubleshooting.........................339 MyFord Touch™ General Information...................................348 Settings...........................................................356 Entertainment..............................................369 Phone..............................................................388 Information....................................................395 Navigation......................................................405 Accessories Accessories.....................................................414 Auxiliary Switches........................................415 Appendices End User License Agreement..................416 Extended Service Plan (ESP) Extended Service Plan (ESP).................438 Scheduled Maintenance General Maintenance Information.......440 Normal Scheduled Maintenance..........443 Special Operating Conditions Scheduled Maintenance.............................................445 Scheduled Maintenance Record...........448 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing 6 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Introduction Note: Either Ford Motor Company or an authorized Ford dealer may have originally sold this incomplete vehicle to a vehicle modifier who upfitted it. As a result, some of the options and features on this vehicle may differ from what we describe in this manual. This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat. Right-hand side Left-hand side Protecting the Environment You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim. SYMBOLS GLOSSARY These are some of the symbols you may see on your vehicle. Safety alert See Owner's Manual ABOUT THIS MANUAL Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it. WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any handheld device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. Note: This manual describes product features and options available throughout the range of available models, sometimes even before they are generally available. It may describe options not fitted to your vehicle. Note: Some of the illustrations in this manual may show features as used in different models, so may appear different to you on your vehicle. However, the essential information in the illustrations is always correct. Note: Always use and operate your vehicle in line with all applicable laws and regulations. Note: Pass on this manual when selling your vehicle. It is an integral part of the vehicle. Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E154903Introduction Air conditioning system Anti-lock braking system Engine air filter Engine coolant Avoid smoking, flames or sparks Engine coolant temperature Battery Battery acid Brake fluid - non petroleum based Brake system Cabin air filter Check fuel cap Engine oil Explosive gas Fan warning Fasten safety belt Front airbag Front fog lamps Child safety door lock or unlock Fuel pump reset Child seat lower anchor Fuse compartment Child seat tether anchor Hazard warning flashers Cruise control Heated rear window Do not open when hot Heated windshield Interior luggage compartment release Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E162384E71340Introduction Jack Shield the eyes Keep out of reach of children Stability control Lighting control Windshield wash and wipe Low tire pressure warning Maintain correct fluid level Note operating instructions Panic alarm Parking aid Parking brake Power steering fluid Power windows front/rear Power window lockout Service engine soon Side airbag DATA RECORDING A large number of electronic components of your vehicle contain data storage modules temporarily or permanently storing technical data about the condition of the vehicle, events and errors. In general, this technical information documents the condition of parts, modules, systems or the environment: • Operating conditions of system components (e.g. filling levels). Status messages of the vehicle and its individual components (e.g. number of wheel revolutions/rotational speed, deceleration, lateral acceleration). • • Malfunction and defects in important system components (e.g. lighting and brake system). • Vehicle reactions in particular driving situations (e.g. inflation of an airbag, activation of the stability regulation system). Environmental conditions (e.g. temperature). • These data are exclusively technical and help identification and correction of errors as well as optimisation of vehicle functions. Motion profiles indicating travelled routes cannot be created with these data. Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E161353E139213E167012E138639Introduction Web Address www.dtsc.ca.gov/hazardouswaste/ perchlorate FORD CREDIT (U.S. Only) Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business. For your convenience we offer a number of ways to contact us, as well as to help manage your account. Phone: 1-800-727-7000 For more information regarding Ford Credit, as well as to access Account Manager, please go to www.fordcredit.com. REPLACEMENT PARTS RECOMMENDATION Your vehicle has been built to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging. If services are used (e.g. repair works, service processes, warranty cases, quality assurance), employees of the service network (including manufacturers) are able to read out this technical information from the event and error data storage modules using special diagnostic devices. If required, you will receive further information. After an error has been corrected, these data are deleted from the error storage module or they are constantly overwritten. When using the vehicle, situations may occur in which these technical data related to other information (accident report, damages on the vehicle, witness statements etc.) may be associated with a specific person - possibly, with the assistance of an expert. Additional functions contractually agreed upon with the client (e.g. vehicle location in emergency cases) allow the transmission of particular vehicle data from the vehicle. CALIFORNIA PROPOSITION 65 WARNING Some constituents of engine exhaust, certain vehicle components, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. PERCHLORATE Certain components in your vehicle such as airbag modules, safety belt pretensioners and remote control batteries may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal. For more information visit: 10 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Introduction Scheduled Maintenance and Mechanical Repairs One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this Owner’s Manual. Genuine Ford and Motorcraft parts meet or exceed these specifications. Collision Repairs We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development we validate these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts. Warranty on Replacement Parts Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, refer to the terms and conditions of the Ford Warranty. SPECIAL NOTICES If converting or modifying your vehicle from production specification, refer to the Body and Equipment Mounting Manual at www.etis.ford.com/fordservice. MOBILE COMMUNICATIONS EQUIPMENT Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits. Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios. WARNING Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. EXPORT UNIQUE OPTIONS For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this Owner’s Manual. A market unique supplement may be supplied that complements this book. By referring to the market unique supplement, if provided, you can properly identify those features, recommendations and specifications that 11 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Introduction are unique to your vehicle. This Owner’s Manual is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for Export. Refer to this Owner’s Manual for all other required information and warnings. 12 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Child Safety WARNINGS requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle. To locate a child seat fitting station and CPST, contact the NHTSA toll free at 1-888-327-4236 or go to http://www.nhtsa.dot.gov. In Canada, check with your local St. John Ambulance office for referral to a CPST or for further information, contact your provincial ministry of transportation, locate your local St. John Ambulance office by searching for St. John Ambulance on the internet, or Transport Canada at 1-800-333-0371 (http://www.tc.gc.ca). Failure to properly restrain children in safety seats made especially for their height, age, and weight may result in an increased risk of serious injury or death to your child. GENERAL INFORMATION See the following sections for directions on how to properly use safety restraints for children. WARNINGS Always make sure your child is secured properly in a device that is appropriate for their height, age and weight. Child safety restraints must be bought separately from your vehicle. Failure to follow these instructions and guidelines may result in an increased risk of serious injury or death to your child. All children are shaped differently. The recommendations for safety restraints are based on probable child height, age and weight thresholds from National Highway Traffic Safety Administration and other safety organizations, or are the minimum 13 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Child Safety Recommendations for Safety Restraints for Children Child Child size, height, weight, or age Recommended restraint type Infants or toddlers Children weighing 40 lb (18 kg) or less (generally age four or younger). Small children Larger children Children who have outgrown or no longer properly fit in a child safety seat (gener- ally children who are less than 4 ft. 9 in. (1.45 m) tall, are greater than age four and less than age 12, and between 40 lb (18 kg) and 80 lb (36 kg) and upward to 100 lb (45 kg) if recommended by your child restraint manufacturer). Children who have outgrown or no longer properly fit in a belt-positioning booster seat (generally children who are at least 4 ft. 9 in. (1.45 m) tall or greater than 80 lb (36 kg) or 100 lb (45 kg) if recom- mended by child restraint manufacturer). Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat). Use a belt-positioning booster seat. Use a vehicle safety belt having the lap belt snug and low across the hips, shoulder belt centered across the shoulder and chest, and seat back upright. INSTALLING CHILD SEATS Child Seats • You are required by law to properly use safety seats for infants and toddlers in the United States and Canada. • Many states and provinces require that small children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms). Check your local and state or provincial laws for specific requirements about the safety of children in your vehicle. • When possible, always properly restrain children 12 years of age and under in a rear seating position of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position. 14 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142594Child Safety Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers, or children weighing 40 pounds (18 kilograms) or less (generally age four or younger). Using Lap and Shoulder Belts WARNINGS Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat upon which the child seat is installed all the way back. Airbags can kill or injure a child in a child seat. Children 12 and under should be correctly restrained in the rear seat whenever possible. Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain safety belt buckle assemblies and LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be correctly restrained. When installing a child safety seat with combination lap and shoulder belts: • Use the correct safety belt buckle for that seating position. Insert the belt tongue into the correct buckle until you hear a distinct click and feel it latch. Make sure the tongue is securely fastened in the buckle. Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling. • • • Place the vehicle seat upon which the child seat will be installed in the upright position. • Put the safety belt in the automatic locking mode. See Step 5. Your vehicle does not require the use of a locking clip. Perform the following steps when installing the child seat with combination lap and shoulder belts: Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat. 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 15 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142528E142529Child Safety 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out. Note: The automatic locking mode is available on the front passenger and rear seats. 6. Allow the belt to retract to remove slack. The belt will click as it retracts to indicate it is in the automatic locking mode. 7. Try to pull the belt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer's instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the correct buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a distinct click and feel the latch engage. Make sure the tongue is latched securely by pulling on it. 16 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142530E142531E142875E142533Child Safety Using Lower Anchors and Tethers for Children (LATCH) WARNINGS Never attach two child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death. Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain safety belt buckle assemblies or LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be correctly restrained. The LATCH system is composed of three vehicle anchor points: two lower anchors located where seat back and seat cushion meet (called the seat bight) and one top tether anchor located behind that seating position. LATCH compatible child safety seats have two rigid or webbing mounted attachments that connect to the two lower anchors at the LATCH equipped seating positions in your vehicle. This type of attachment method eliminates the need to use safety belts to attach the child seat, however the safety belt can still be used to attach the child seat. For forward-facing child seats, the top tether strap must also be attached to the correct top tether anchor, if a top tether strap has been provided with your child seat. 8. Remove remaining slack from the belt. Force the seat down with extra weight, for example, by pressing down or kneeling on the child restraint while pulling up on the shoulder belt in order to force slack from the belt. This is necessary to remove the remaining slack that will exist once the extra weight of the child is added to the child restraint. It also helps to achieve the correct snugness of the child seat to your vehicle. Sometimes, a slight lean toward the buckle will additionally help to remove remaining slack from the belt. 9. Attach the tether strap (if the child seat is equipped). 10. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back. There should be no more than 1 inch (2.5 centimeters) of movement for correct installation. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is correctly installed. In Canada, check with your local St. John Ambulance office for referral to a Certified Passenger Seat Technician. 17 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142534Child Safety Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. 18 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E184881E178551E178552E178553E177639Child Safety Combining Safety Belt and LATCH Lower Anchors for Attaching Child Safety Seats When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a correct installation is achieved. Attach the tether strap afterward, if included with the child seat. Using Tether Straps Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap, or to obtain a longer tether strap if the tether strap on your safety seat does not reach the appropriate top tether anchor in your vehicle. Once the child safety seat has been installed using either the safety belt, the lower anchors of the LATCH system, or both, you can attach the top tether strap. The tether strap anchors in your vehicle are in the following positions (shown from top view): The LATCH anchors are located at the rear section of the rear seat between the cushion and seat back above the symbols as shown. Follow the child seat manufacturer's instructions to correctly install a child seat with LATCH attachments. Follow the instructions on attaching child safety seats with tether straps. Attach LATCH lower attachments of the child seat only to the anchors shown. Use of Inboard Lower Anchors from the Outboard Seating Positions (Center Seating Use) WARNING The standardized spacing for LATCH lower anchors is 11 inches (28 centimeters) center to center. Do not use LATCH lower anchors for the center seating position unless the child seat manufacturer's instructions permit and specify using anchors spaced at least as far apart as those in your vehicle. Do not attach a child seat to any lower anchor if an adjacent child seat is attached to that anchor. Each time you use the safety seat, check that the seat is correctly attached to the lower anchors and tether anchor, if applicable. Tug the child seat from side to side and forward and back where it is secured to your vehicle. The seat should move less than one inch when you do this for a correct installation. If the safety seat is not anchored correctly, the risk of a child being injured in a crash greatly increases. 19 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E184881Child Safety Perform the following steps to install a child safety seat with tether anchors: Note: If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off your vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat. Keeping the child seat just touching your vehicle seat gives the best protection in a severe crash. Front Passenger Seating Position 1. Adjust the front passenger seat fully forward. 2. Route the child safety seat tether strap over the back of the seat, under the head restraint and between the head restraint posts. 20 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E178551E178552E178553Child Safety 4. Clip the tether strap to the anchor as shown. 5. Adjust the front passenger seat full rearward. 6. Tighten the child safety seat tether strap according to the manufacturer's instructions. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. Rear Seats 1. Route the child safety seat tether strap over the back of the seat, under the head restraint and between the head restraint posts. 3. Locate the correct anchor on the back panel of the rear seat for the selected seating position. The anchors are labeled with the tether strap symbol and are partially covered by the gap panel. Pull the panel back to fully expose the anchors. 21 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E178096E177640Child Safety WARNING • 2. Locate the correct anchor on the back panel of the rear seat for the selected seating position. The anchors are labeled with the tether strap symbol and are partially covered by the gap panel. Pull the panel back to fully expose the anchors. 3. Clip the tether strap to the anchor as shown. 4. Tighten the child safety seat tether strap according to the manufacturer's instructions. If your child restraint system is equipped with a tether strap, and the child restraint manufacturer recommends its use, Ford also recommends its use. BOOSTER SEATS Never place, or allow a child to place, the shoulder belt under a child's arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash. Use a belt-positioning booster seat for children who have outgrown or no longer properly fit in a child safety seat (generally children who are less than 4 feet 9 inches (1.45 meters) tall, are greater than age four (4) and less than age twelve (12), and between 40 pounds (18 kilograms) and 80 pounds (36 kilograms) and upward to 100 pounds (45 kilograms) if recommended by your child restraint manufacturer). Many state and provincial laws require that children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms). Booster seats should be used until you can answer YES to ALL of these questions when seated without a booster seat: • Can the child sit all the way back against their vehicle seat back with knees bent comfortably at the edge of the seat cushion? • Can the child sit without slouching? • Does the lap belt rest low across the hips? Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? Always use booster seats in conjunction with your vehicle lap and shoulder belt. Types of Booster Seats • Backless booster seats 22 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142595E68924Child Safety If your backless booster seat has a removable shield, remove the shield. If a vehicle seating position has a low seat back or no head restraint, a backless booster seat may place your child's head (as measured at the tops of the ears) above the top of the seat. In this case, move the backless booster to another seating position with a higher seat back or head restraint and lap and shoulder belts, or consider using a high back booster seat. • High back booster seats If, with a backless booster seat, you cannot find a seating position that adequately supports your child's head, a high back booster seat would be a better choice. Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder. The following drawings compare the ideal fit (center) to a shoulder belt uncomfortably close to the neck and a shoulder belt that could slip off the shoulder. The drawings also show how the lap belt should be low and snug across the child's hips. 23 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E70710E142596Child Safety WARNINGS warnings provided by your vehicle manufacturer. A safety seat that is improperly installed or utilized, is inappropriate for your child's height, age, or weight or does not properly fit the child may increase the risk of serious injury or death. Never let a passenger hold a child on his or her lap while your vehicle is moving. The passenger cannot protect the child from injury in a crash, which may result in serious injury or death. Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a crash. Always restrain an unoccupied child seat or booster seat. These objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury. Never place, or allow a child to place, the shoulder belt under a child's arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash. To avoid risk of injury, do not leave children or pets unattended in your vehicle. If the booster seat slides on the vehicle seat upon which it is being used, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition. Do not introduce any item thicker than this under the booster seat. Check with the booster seat manufacturer's instructions. CHILD SEAT POSITIONING WARNINGS Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the child seat is installed all the way back. When possible, all children age 12 and under should be properly restrained in a rear seating position. If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat. Always carefully follow the instructions and warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child's size, height, weight, or age. Follow the child restraint manufacturer's instructions and warnings provided for installation and use in conjunction with the instructions and 24 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142597Child Safety Recommendations for attaching child safety restraints for children Restraint Use any attachment method as indicated below by X type Combined weight of child and restraint child seat LATCH (lower anchors only) Safety belt and top tether anchor LATCH (lower anchors and top tether anchor) Safety belt only Safety belt and LATCH (lower anchors and top tether anchor) Rear facing child seat Rear facing child seat Forward facing child seat Forward facing Up to 65 lb (29.5 kg) Over 65 lb (29.5 kg) Up to 65 lb (29.5 kg) Over 65 lb (29.5 kg) child seat Note: The child seat must rest tightly against the vehicle seat upon which it is installed. It may be necessary to lift or remove the head restraint. See Seats (page 93). CHILD SAFETY LOCKS WARNING You cannot open the rear side door from inside if you have put the child safety lock on. A child safety lock is on the rear side door. Left-Hand Side Turn it counterclockwise to switch the child lock on and clockwise to switch it off. Right-Hand Side Turn it clockwise to switch the child lock on and counterclockwise to switch it off. 25 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E176718Safety Belts WARNINGS When possible, all children 12 years old and under should be properly restrained in a rear seating position. Failure to follow this could seriously increase the risk of injury or death. Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Front and rear seat occupants, including pregnant women, should wear safety belts for optimum protection in an accident. All seating positions in this vehicle have lap and shoulder safety belts. All occupants of the vehicle should always properly wear their safety belts, even when an airbag supplemental restraint system is provided. The safety belt system consists of: Lap and shoulder safety belts. • Shoulder safety belt with automatic • locking mode, (except driver safety belt). • Height adjuster at the front outboard seating positions. Safety belt pretensioner at the front outboard seating positions. Safety belt warning light and chime. • Crash sensors and monitoring system with readiness indicator. PRINCIPLE OF OPERATION WARNINGS Always drive and ride with the seat backrest upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit where they can be properly restrained. Never let a passenger hold a child on his or her lap while your vehicle is moving. The passenger cannot protect the child from injury in a crash which may result in serious injury or death. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an airbag supplemental restraint system is provided. Failure to properly wear your safety belt could seriously increase the risk of injury or death. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a crash, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Be sure everyone in your vehicle is in a seat and using a safety belt properly. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only. Never wear the shoulder belt under the arm. 2) Never swing the safety belt around your neck over the inside shoulder. 3) Never use a single belt for more than one person. 26 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing • • Safety Belts The safety belt pretensioners at the front seating positions are designed to tighten the safety belts when activated. In frontal and near-frontal crashes, side crashes and rollovers, the safety belt pretensioners may be activated alone or, if the crash is of sufficient severity, together with the front airbags. FASTENING THE SAFETY BELTS The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. 2. To unfasten, press the release button and remove the tongue from the buckle. Using Safety Belts During Pregnancy WARNING Always ride and drive with your seat back upright and the safety belt properly fastened. The lap portion of the safety belt should fit snug and be positioned low across the hips. The shoulder portion of the safety belt should be positioned across the chest. Pregnant women should also follow this practice. See the following figure. 1. Insert the safety belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. Pregnant women should always wear their safety belt. The lap belt portion of a combination lap and shoulder belt should be positioned low across the hips below the belly and worn as tight as comfort will allow. The shoulder belt should be positioned to cross the middle of the shoulder and the center of the chest. 27 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142587E142588E170730Safety Belts Automatic Locking Mode In this mode, the shoulder belt is automatically pre-locked. The safety belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to Use the Automatic Locking Mode This mode should be used any time a child safety seat, except a booster, is installed in passenger front or rear seating positions. Children 12 years old and under should be correctly restrained in a rear seating position whenever possible. See Child Safety (page 13). How to Use the Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire safety belt is pulled out. Allow the safety belt to retract. As the safety belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. Safety Belt Locking Modes WARNINGS After any vehicle crash, the safety belt system at all passenger seating positions must be checked by an authorized dealer to verify that the automatic locking retractor feature for child seats is still functioning properly. In addition, all safety belts should be checked for proper function. Safety belt and retractor assemblies must be replaced if the safety belt assembly automatic locking retractor feature, or any other safety belt function is not operating correctly when checked by an authorized dealer. Failure to replace the safety belt and retractor assembly could increase the risk of injury in a crash. All safety belts in your vehicle are combination lap and shoulder belts. The driver safety belt has the first type of locking mode, and the front outboard passenger and rear seat safety belts have both types of locking modes described as follows: Vehicle Sensitive Mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 5 mph (8 km/h) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers. In addition, the retractor is designed to lock if the webbing is pulled out too quickly. If this occurs, let the safety belt retract slightly and pull webbing out again in a slow and controlled manner. 28 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E142591Safety Belts How to Disengage the Automatic Locking Mode Unbuckle the combination lap and shoulder belt and allow it to retract completely to disengage the automatic locking mode and return the safety belt to the vehicle sensitive (emergency) locking mode. Safety Belt Extension Assembly WARNING Do not use extensions to change the fit of the shoulder belt across the torso. If the safety belt is too short when fully extended, a safety belt extension assembly can be obtained from an authorized dealer. Only use extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label or the retractor behind the trim. Only use an extension if the safety belt is too short for you when fully extended. SAFETY BELT HEIGHT ADJUSTMENT WARNING Position the safety belt height adjuster so that the safety belt rests across the middle of your shoulder. Failure to adjust the safety belt correctly could reduce its effectiveness and increase the risk of injury in a crash. 29 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing 1. Press the button. 2. Slide the height adjuster up or down. 3. Release the button and pull down on the height adjuster to make sure it is locked in place. SAFETY BELT WARNING LAMP AND INDICATOR CHIME This lamp illuminates and an audible warning will sound if the driver's safety belt has not been fastened when the vehicle's ignition is turned on. E1650221223Safety Belts Conditions of operation If... Then... The driver's safety belt is not buckled before the ignition switch is turned to the on position... The driver's safety belt is buckled while the indicator light is illuminated and the warning chime is sounding... The safety belt warning light illuminates 1- 2 minutes and the warning chime sounds 4-8 seconds. The safety belt warning light and warning chime turn off. The driver's safety belt is buckled before the ignition switch is turned to the on posi- tion... The safety belt warning light and indicator chime remain off. SAFETY BELT MINDER Belt-Minder® This feature supplements the safety belt warning function by providing additional reminders by intermittently sounding a chime and illuminating the safety belt warning light when the driver seat is occupied and the safety belt is unbuckled. If... Then... The driver safety belt is buckled before the ignition is switched on or less than two minutes have elapsed since the ignition was switched on. The driver safety belt is not buckled when the vehicle has reached at least 6 mph (9.7 km/h) and two minutes have elapsed since the ignition was switched on. The driver safety belt becomes unbuckled for about one minute while the vehicle is traveling at least 6 mph (9.7 km/h) and more than two minutes have elapsed since the ignition was switched on. The Belt-Minder feature will not turn on. The Belt-Minder feature is turned on - the safety belt warning light illuminates and the warning chime sounds for six seconds every 25 seconds, repeating for about five minutes or until the driver safety belt is buckled. The Belt-Minder feature is turned on - the safety belt warning light illuminates and the warning chime sounds for six seconds every 25 seconds, repeating for about five minutes or until the driver safety belt is buckled. 30 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Safety Belts • • This will disable the feature if it is currently enabled. This will enable the feature if it is currently disabled. CHILD RESTRAINT AND SAFETY BELT MAINTENANCE Inspect the vehicle safety belts and child safety seat systems periodically to make sure they work properly and are not damaged. Inspect the vehicle and child seat safety belts to make sure there are no nicks, tears or cuts. Replace if necessary. All vehicle safety belt assemblies, including retractors, buckles, front safety belt buckle assemblies, buckle support assemblies (slide bar-if equipped), shoulder belt height adjusters (if equipped), shoulder belt guide on seat back (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a crash. Read the child restraint manufacturer's instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a crash be replaced. However, if the crash was minor and an authorized dealer finds that the belts do not show damage and continue to operate properly, they do not need to be replaced. Safety belt assemblies not in use during a crash should also be inspected and replaced if either damage or improper operation is noted. Properly care for safety belts. See Vehicle Care (page 227). Switching the Belt-Minder on and off WARNING While the system allows you to switch it off, this system is designed to improve your chances of being safely belted and surviving a crash. We recommend you leave the system switched on. To reduce the risk of injury, do not switch the system on or off while driving your vehicle. Read Steps 1 - 4 thoroughly before proceeding with the programming procedure. The system can be switched on and off by carrying out the following procedure: Before following the procedure, make sure that: • • The parking brake is set. The transmission selector lever is in position park (P). The ignition is switched off. The driver safety belt is unbuckled. • • 1. Switch the ignition on. Do not start the engine. 2. Wait until the safety belt warning light turns off (about one minute). After Step 2, wait an additional five seconds before proceeding with Step 3. Once Step 3 is started, the procedure must be completed within 30 seconds. 3. Buckle then unbuckle the driver safety belt three times at a moderate speed, ending in the unbuckled state. After Step 3, the safety belt warning light will illuminate. 4. While the safety belt warning light is illuminated, buckle then unbuckle the driver safety belt. After Step 4, the safety belt warning light will flash for confirmation. 31 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Supplementary Restraints System The airbags are a supplemental restraint system and are designed to work with the safety belts to help protect the driver and right front passenger from certain upper body injuries. Airbags do not inflate slowly; there is a risk of injury from a deploying airbag. Note: You will hear a loud bang and see a cloud of harmless powdery residue if an airbag deploys. This is normal. The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (for example, baking soda) that result from the combustion process that inflates the airbag. Small amounts of sodium hydroxide may be present which may irritate the skin and eyes, but none of the residue is toxic. While the system is designed to help reduce serious injuries, contact with a deploying airbag may also cause abrasions or swelling. Temporary hearing loss is also a possibility as a result of the noise associated with a deploying airbag. Because airbags must inflate rapidly and with considerable force, there is the risk of death or serious injuries such as fractures, facial and eye injuries or internal injuries, particularly to occupants who are not properly restrained or are otherwise out of position at the time of airbag deployment. Thus, it is extremely important that occupants be properly restrained as far away from the airbag module as possible while maintaining vehicle control. Routine maintenance of the airbags is not required. PRINCIPLE OF OPERATION WARNINGS Airbags do not inflate slowly or gently, and the risk of injury from a deploying airbag is the greatest close to the trim covering the airbag module. All occupants of your vehicle, including the driver, should always properly wear their safety belts, even when an airbag supplemental restraint system is provided. Failure to properly wear your safety belt could seriously increase the risk of injury or death. Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. Failure to follow this could seriously increase the risk of injury or death. Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries. Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat upon which the child seat is installed all the way back. Do not attempt to service, repair, or modify the airbag supplemental restraint systems or its fuses as you could be seriously injured or killed. Contact your authorized dealer as soon as possible. Several airbag system components get hot after inflation. Do not touch them after inflation as this may result in serious injury. If the airbag has deployed, the airbag will not function again and must be replaced immediately. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a crash. 32 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing Supplementary Restraints System DRIVER AND PASSENGER AIRBAGS WARNINGS Never place your arm or any objects over an airbag module. Placing your arm over a deploying airbag can result in serious arm fractures or other injuries. Objects placed on or over the airbag inflation area may cause those objects to be propelled by the airbag into your face and torso causing serious injury. Airbags can kill or injure a child in a child seat. Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat upon which the child seat is installed all the way back. Passenger Airbag On and Off Switch (If Equipped) WARNINGS Even with Advanced Restraints Systems, children 12 and under should be properly restrained in a rear seating position. Failure to follow this could seriously increase the risk of injury or death. The front passenger airbag is not designed to offer protection to an occupant in the center seating position. An airbag ON and OFF switch may be installed in this vehicle. Before driving, always look at the face of the switch to be sure the switch is in the proper position in accordance with these instructions and warnings. Failure to put the switch in a proper position can increase the risk of serious injury or death in a crash. The driver and front passenger airbags will deploy during significant frontal and near frontal crashes. The driver and passenger front airbag system consists of: • Driver and passenger airbag modules. • Crash sensors and monitoring system with readiness indicator. See Crash Sensors and Airbag Indicator (page 41). High-series vehicles (if equipped) The front passenger airbag on and off switch has indicators that will illuminate, indicating that the front passenger frontal airbag is either on or off. The indicator lamp is located on the radio. Note: The passenger airbag status indicator OFF and ON lamps will illuminate for a short period of time when the ignition is first turned on to confirm it is functional. 33 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E151127E181532Supplementary Restraints System Switch position Off On Passenger airbag status indicator OFF: Lit ON: Unlit OFF: Unlit ON: Lit Passenger airbag Disabled Enabled WARNINGS An infant in a rear-facing seat faces a high risk of serious or fatal injuries from a deploying passenger airbag. Rear facing infant seats should never be placed in the front seats, unless the passenger airbag is turned off. Low-series vehicles (if equipped) The front passenger airbag on and off switch has an indicator that will illuminate and stay lit to remind you that the front passenger frontal airbag is off. The indicator lamp is located by the radio. Note: The indicator lamp will illuminate for a short period of time when the ignition is first turned on to confirm it is functional. Turning the Passenger Airbag Off WARNINGS If the light fails to illuminate when the passenger airbag switch is off and the ignition is on, have the passenger airbag switch serviced at your authorized dealer immediately. In order to avoid inadvertent activation of the switch, always remove the ignition key from the passenger airbag on and off switch. 34 Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing E170613E181523Supplementary Restraints System WARNINGS If your vehicle has rear seats, always transport children who are 12 years and under in the rear seat. Always use safety belts and child restraints correctly. Do not place a child in a rear facing infant seat in the front seat unless your vehicle is equipped with an airbag on and off switch and the passenger airbag is turned off. This is because the back of the infant seat is too close to the inflating airbag and the risk of a fatal injury to the infant when the airbag inflates is substantial. If the pass airbag off light is illuminated when the passenger airbag switch is on and the ignition is on, have the passenger airbag switch serviced at your authorized dealer immediately. The passenger airbag remains off until you turn it back on. 1. Insert the ignition key and turn the switch to ON. 2. The pass airbag off light will briefly illuminate when the ignition is turned to on. This indicates that the passenger
