Introduction
Introduction
CALIFORNIA Proposition 65 Warning
WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to
the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com • In Canada: www.ford.ca • In Australia: www.ford.com.au • In Mexico: www.ford.com.mx Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available. Remember to pass on this Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.
Fuel pump shut-off switch: In the event of an accident the safety switch will automatically cut off the fuel supply to the
engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Introduction
SAFETY AND ENVIRONMENT PROTECTION
Warning symbols in this guide
How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Warning symbols on your vehicle
When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.
Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.
BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed to allow parts to adjust themselves to other parts. Drive your new vehicle at least 500 miles (800 km) before towing a trailer. Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Introduction
SPECIAL NOTICES
Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide. Service Data Recording Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle. Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: • how various systems in your vehicle were operating; • whether or not the driver and passenger seatbelts were buckled; • how far (if at all) the driver was depressing the accelerator and/or the • how fast the vehicle was traveling; and • where the driver was positioning the steering wheel.
brake pedal;
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Introduction
To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.
Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls.
Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.
Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.
MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this Owner’s Guide for all other required information and warnings.
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Introduction
These are some of the symbols you may see on your vehicle.
Vehicle Symbol Glossary
Safety Alert
See Owner’s Guide
Fasten Safety Belt
Air Bag-Front
Air Bag-Side
Child Seat
Child Seat Installation Warning
Child Seat Tether Anchor
Anti-Lock Brake System
Child Seat Lower Anchor
Brake System
Brake Fluid - Non-Petroleum Based
Traction Control
AdvanceTrac娂
Master Lighting Switch
Hazard Warning Flasher
Fog Lamps-Front
Fuse Compartment
Fuel Pump Reset
Windshield Wash/Wipe
Windshield Defrost/Demist
Rear Window Defrost/Demist
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Introduction
Vehicle Symbol Glossary
Power Windows Front/Rear
Child Safety Door Lock/Unlock
Power Window Lockout
Interior Luggage Compartment Release Symbol
Panic Alarm
Engine Oil
Engine Coolant
Engine Coolant Temperature
Do Not Open When Hot
Battery
Avoid Smoking, Flames, or Sparks
Battery Acid
Explosive Gas
Fan Warning
Power Steering Fluid
Maintain Correct Fluid Level
MAX MIN
Emission System
Engine Air Filter
Passenger Compartment Air Filter
Jack
Check fuel cap
Low tire warning
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Instrument Cluster
WARNING LIGHTS AND CHIMES
Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately. Check engine: The Check Engine indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.
Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
10
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Check engine warning light to come on, refer to Fuel filler cap in the Maintenance and Specification chapter. Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.
Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may
occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.
ABS
Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated. Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.
11
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.
Check transaxle: Illuminates when a transaxle problem has been detected and shifting may be restricted. If the light remains on, have the system serviced immediately.
Charging system: Illuminates when the battery is not charging properly.
Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in the Maintenance and specifications chapter. Engine coolant temperature: Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible, switch off the engine and let cool. Refer to Engine coolant in the Maintenance and specifications chapter. • Without Message Center
• With Message Center
Never remove the coolant recovery cap while the
engine is running or hot.
12
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Traction Control娂 or AdvanceTrac娂 active (if equipped): Illuminates when the Traction Control娂 is active, refer to the Driving chapter for more information. • Without Message Center
TRAC ACTIVE
• With Message Center
TRAC OFF
Traction Control娂 or AdvanceTrac娂 off light (if equipped): Illuminates when the Traction Control娂 has been disabled (by the driver or as a result of a system failure). Refer to the Driving chapter for more information. Low tire warning: Illuminates when the low tire warning system is enabled. If the light remains on while driving, the tire pressure should be checked, refer to Low tire warning in the Maintenance and Specifications chapter. Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).
Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged.
13
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Low washer fluid: Illuminates when the windshield washer fluid is low. • Without Message Center
• With Message Center
Door ajar: Illuminates when the ignition is in the ON position and any door is open. • Without Message Center
• With Message Center Displays which door or the liftgate is open.
Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. Bulb warning: Illuminates when one of the exterior front turn lamps or rear brake/turn/tail lamps bulb has burned out. • Without Message Center
14
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
• With Message Center Displays which bulb is burned out. Depress the RESET control to clear.
High beams: Illuminates when the high beam headlamps are turned on.
Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. Turn signal warning chime: Sounds when the turn signal lever has been activated to signal a turn and not turned off after the vehicle is driven more than 0.8 km (1/2 mile).
GAUGES
15
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Speedometer: Indicates the current vehicle speed.
Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Never remove the coolant reservoir cap while the engine is running or hot.
Odometer: Registers the total kilometers (miles) of the vehicle. • Without Message Center To switch the display from Metric to English, press and hold the button on the cluster for three seconds. The temperature display in the overhead console (if equipped) will also be changed. • With Message Center Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English.
16
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Instrument Cluster
Trip odometer: Registers the kilometers (miles) of individual journeys. • Without Message Center Press and release the button on the cluster to toggle between odometer and trip odometer display. To reset, press the button again until the trip reading is 000000.0 miles. To switch the odometer display and temperature from english to metric. With the milage displayed press and hold the button on the cluster for three seconds this will change the units. • With Message Center To reset, press and hold the message center RESET button for three seconds to reset.
Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.
Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The arrow near the fuel pump icon indicates which side of the vehicle the fuel filler door is located. Refer to Filling the tank in the Maintenance and Specifications chapter for more information.
17
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
Entertainment Systems
AM/FM STEREO SYSTEM (IF EQUIPPED)
Tuner: Press to
1. manually go up or down the radio frequency. Also use in menu mode to select various settings.
2. Audio: Press to access select various settings.
Treble: Press to adjust the treble setting. Use SEEK
SEEK,
Bass: Press to adjust the bass setting. Use SEEK Balance: Press to adjust the audio between the left and right speakers. Use
SEEK, SEEK
SEEK,
Fade: Press to adjust the audio between the front and rear speakers. Use
SEEK, SEEK
18
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
3. Seek: Press to access the next/previous strong station or track. 4. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 5. AM/FM: Press to select AM/FM frequency band.
6. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 7. CLK (Clock): Press to toggle between the clock and radio display. To set the clock: Press and hold CLK until the hours begin to flash. Press again to set the minutes. When this audio is used in cargo vans where no rear speakers are installed in the vehicle, fading to the rear speakers will result in no audio output.
to manually decrease / increase the hours. Press CLK
19
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
AM/FM STEREO/ SINGLE CD SOUND SYSTEM (IF EQUIPPED)
Tuner: Press to
1. manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media. 3. Menu: Press to toggle through the following modes:
Treble: Press to adjust the treble setting. Use
SEEK
Bass: Press to adjust the bass setting. Use Balance: Press to adjust the audio between the left and right speakers. Use Fade: Press to adjust the audio between the front and rear speakers. Use
SEEK
SEEK
SEEK
20
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
Speed sensitive volume (if equipped): Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Press MENU to access and use
to adjust.
SEEK
to manually increase/decrease Press
Setting the clock: Press MENU until SELECT HOUR or SELECT MINUTE is displayed. Use MENU again to disengage clock mode. If your vehicle is equipped with an in-dash clock, refer to “Setting the clock” in the Driver Controls chapter. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press MENU to access. Use When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. 4. Aux: Press to toggle between FES/DVD and AUX modes. If no auxiliary sources are available, NO AUX AUDIO will be displayed. 5. Seek: Press to access the next strong station or track.to set.
SEEK
6. Text: In CD mode, this feature reads track name, artist name, and disc name (if available). 7. Shuffle: Press to play tracks in random order.
8. Comp (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level. 9. Repeat: Press to repeat the current CD track.
10. Fast forward: Press to manually advance in a CD track.
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
21
Entertainment Systems
11. Rewind: Press to manually reverse in a CD track.
12. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 13. Scan: Press for a brief sampling of radio stations or CD tracks. Press again to stop. 14. Seek: Press to access the previous strong station or track.
15. AM/FM: Press to select AM/FM frequency band.
16. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 17. CD: Press to enter CD mode. If a CD is already loaded into the system, CD play will begin where it ended last. 18. CD eject: Press to eject a CD.
19. CD slot: Insert a CD label side up.
22
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
PREMIUM IN-DASH SIX CD SOUND SYSTEM (IF EQUIPPED)
Entertainment Systems
Tuner: Press to
1. manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media. 3. Menu: Press to toggle through the following modes:
Treble: Press to adjust the treble setting. Use
Bass: Press to adjust the bass setting. Use
SEEK
SEEK
Balance: Press to adjust the audio between the left and right speakers. Use
SEEK
Fade: Press to adjust the audio between the front and rear speakers. Use
SEEK
23
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
Speed sensitive volume (if equipped): Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Press MENU to access and use
to adjust.
SEEK
Setting the clock: Press MENU until SELECT HOUR or SELECT MINUTE is displayed. Press
to adjust the hours/minutes.
SEEK
SEEK
If your vehicle is equipped with an in-dash clock, refer to “Setting the clock” in the Driver Controls chapter. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press MENU to access. Use When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. 4. Aux: Press to toggle between FES/DVD and AUX modes. If no auxiliary sources are available, NO AUX AUDIO will be displayed. 5. Seek: Press to access the next strong station or track.to set.
6. Text: In CD mode, press to display the track name, artist name and disc name (if available). 7. Shuffle: Press to play tracks in random order.
8. Comp (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level. 9. Repeat: Press to repeat the current CD track.
10. Fast forward: Press to manually advance in a CD track.
24
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
11. Rewind: Press to manually reverse in a CD track.
12. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 13. Scan: Press for a brief sampling of radio stations or CD tracks. Press again to stop. 14. Seek: Press to access the previous strong station or track.
15. AM/FM: Press to select AM/FM frequency band.
16. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 17. CD: Press to enter CD mode. If a CD is already loaded into the system, CD play will begin where it ended last. 18. LOAD: Press to load a CD, then select a slot number using the radio presets 1 through 6. If you don’t select a slot within 5 seconds, the radio shall choose the first available slot for you. Press and hold for 2 seconds to auto load up to six CDs. 19. CD eject: Press to eject a CD, then select the desired CD slot using the radio presets 1 through 6. If a slot is not selected within 5 seconds, the radio shall eject the current disc. Press and hold for 2 seconds to auto eject all CDs present in the radio mechanism.
25
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
20. CD slot: Insert a CD label side up.
AM/FM STEREO CASSETTE/SINGLE CD SOUND SYSTEM (IF EQUIPPED)
Tuner: Press to
1. manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Seek: Press to access the next strong station or track.
3. Phone/mute: Press to mute the playing media. Press again to return to the playing media. 4. Menu: Press to toggle through the following modes:
Treble: Press to adjust the treble setting. Use
SEEK
26
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
Bass: Press to adjust the bass setting. Use
SEEK
Balance: Press to adjust the audio between the left and right speakers. Use
SEEK
Fade: Press to adjust the audio between the front and rear speakers. Use
SEEK
Speed sensitive volume (if equipped): Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Press MENU to access and use
to adjust.
SEEK
SEEK
to adjust the
Setting the clock: Press MENU until SELECT HOUR or SELECT MINUTE is displayed. Press hours/minutes. If your vehicle is equipped with an in-dash clock, refer to “Setting the clock” in the Driver Controls chapter. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press MENU to access. Use When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Clean tape reminder: After 20 hours of cassette operation, the radio will notify you that it is time to clean the cassette player head. After cleaning the player head, you can clear the reminder through menu control and selecting YES. 5. AUX: Press to toggle between FES/DVD and AUX modes. If no auxiliary sources are available, NO AUX AUDIO will be displayed. To return to radio mode, press AM/FM. 6. Tape eject: Press to eject a tape.to set.
SEEK
7. Text: In CD mode, displays track title, artist name, and disc title (if available).
27
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
8. Shuffle: Press to play CD tracks in random order.
9. Compress (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level. 10. Repeat: Press to repeat the current CD track.
11. Fast forward: Press to manually advance in a CD track or cassette. 12. Rewind: Press to manually reverse in a CD track or cassette.
13. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 14. Tape: Insert a tape facing to the right.
15. Tape direction: Press to enter tape mode. Press while in play mode to change which side of the tape is playing. 16. AM/FM: Press to select AM/FM frequency band.
17. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 18. CD: Press to enter CD mode. If a CD is already loaded into the system, CD play will begin where it ended last.
28
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
19. CD eject: Press to eject a CD.
20. CD slot: Insert a CD label side up.
21. Seek:Press to access the previous strong station or track.
22. Scan: Press for a brief sampling of radio stations or CD tracks. Press again to stop. When this radio is used in cargo vans where no rear speakers are installed in the vehicle, fading to the rear speakers will result in no audio output.
FAMILY ENTERTAINMENT DVD SYSTEM (IF EQUIPPED) Your vehicle may be equipped with a Family Entertainment System (FES), refer to the DVD System Supplement for further information.
AUXILIARY AUDIO CONTROLS (IF EQUIPPED) Your vehicle may be equipped with auxiliary audio controls. This feature allows the front and middle seat passengers to listen to different media sources (radio, cassette, CD or DVD) simultaneously. (However, the front and middle-seat passengers cannot listen to two different radio stations at the same time.) 1. Volume: Press to increase/decrease volume control. 2. Media: Press to select from different playing medias. 3. play mode and enable the rear seat passengers to hear audio through the headphones. Press again to deactivate. 4. MEM: Press consecutively to scroll through the preset stations, change tape side (if equipped), or to change discs on multiple disc radios (if equipped).
: Press to activate dual
29
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
to access the next/previous strong radio station,
5. SEEK: Press cassette selection or CD track. When the rear seat controls are activated, rear seat passengers can use the controls to change the playing media for all passengers (Single Play mode). In this mode, all speakers will play audio from the same media source for all passengers to hear. If there is a discrepancy between the rear seat controls and the front audio controls (such as both trying to listen to the same playing media), the front audio system will receive the desired selection. To activate Dual Play mode (rear seat passengers listen to a different playing media than the front seat passengers): • Press the speaker/headphone control. • Press MEDIA to change audio sources (for headphone mode only). • Use the SEEK, VOLUME and MEMORY controls to make adjustments
to the playing media.
PARENTAL CONTROL Simultaneously press the radio preset controls 3 and 5 to enable/disable the rear seat audio controls as well as the Family Entertainment DVD system (if equipped).
COMPRESS
COMPRESS
DUAL PLAY MODE Press on the rear seat audio controls or simultaneously press the radio preset controls 2 and 4 to enable/disable dual play. During dual play, the rear vehicle speakers will be deactivated and the wired headphones (if equipped) will become active. Two different medias can be played in the vehicle simultaneously: • The driver can select a media from the main radio face (radio, tape, • Rear seat passengers may listen to a different media source than the front passengers (radio, tape, CD or DVD if equipped) using 3.5 mm wired headphones (not included) that shall be plugged into the headphone icon jacks on the rear audio control face. Infrared headphones are included in vehicles equipped with the Family Entertainment System and shall only be used to listed to the media
CD or DVD if equipped) and listen using the front speakers.
30
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
(DVD or CD) that is playing in the Family Entertainment System. Wireless headphones will not play audio from any other sources (AM, FM, tape, or Radio CD).
The front and rear seat passengers cannot listen to two different radio stations at the same time.
RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz
weaker the signal and the weaker the reception.
RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception. • Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.
turning the hub.
CASSETTE/PLAYER CARE Do: • Tighten very loose tapes by inserting a pen or pencil into the hole and • Remove loose labels before inserting tapes. • Allow tapes which have been subjected to extreme heat, humidity or • Clean the cassette player head with a cassette cleaning cartridge after
cold to reach a moderate temperature before playing.
10–12 hours of play to maintain good sound/operation.
Don’t: • Use cassettes that are longer than 90 minutes. • Expose tapes to direct sunlight, extreme humidity, heat or cold. • Leave tapes in the cassette player for a long time when not being
played.
31
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Entertainment Systems
CD/CD PLAYER CARE Do: • Handle discs by their edges only. Never touch the playing surface. • Inspect discs before playing. Clean only with an approved CD cleaner
and wipe from the center out.
of time.
than one disc into each slot of the CD changer magazine.
Don’t: • Expose discs to direct sunlight or heat sources for extended periods • For vehicles equipped with a six disc CD changer, don’t insert more • Clean using a circular motion. CD units are designed to play commercially pressed 12 cm (4.75 in) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ball point pens may damage CDs. Please contact your dealer for further information.
AUDIO SYSTEM WARRANTY AND SERVICE Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.
32
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
Climate Controls
MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Distributes recirculated air through the instrument panel vents only to cool the vehicle. This re-cooling of the interior air is more economical and efficient. Recirculated air may also help reduce undesirable odors from entering the vehicle.
: Distributes air through the instrument panel vents.
: Distributes air through the instrument panel vents and the floor vents.
O (OFF): Outside air is shut out and the fan will not operate.
: Distributes air through the floor vents. : Distributes air through the windshield defroster vents and floor vents. : Distributes outside air through the windshield defroster vents. Can
Recirculated air: Press to activate/deactivate air recirculation
Rear defrost: Press to defrost the rear window. Refer to Rear
be used to clear ice or fog from the windshield. 3. R window defroster later in this chapter for more information. 4. in cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculation engages automatically with selection of MAX A/C or can be engaged manually in any other airflow selection except defrost. Recirculation may turn off automatically in all airflow selections except MAX A/C. 5. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in MAX A/C, 6. Fan speed adjustment: Controls the volume of air circulated in the vehicle.
and
33
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
position.
airflow to the back seats.
the air flow selector in the
airflow selector in the OFF or with recirculated air engaged.
Operating tips • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of • For maximum cooling performance (MAX A/C): In the MAX A/C mode: • Move the temperature control selector to the coldest setting. • Set the fan to the highest speed initially, then adjust to maintain
the windshield.
passenger comfort.
and
modes:
In the • Move the temperature control selector to the coldest setting. • Select A/C and recirculated air • Set the fan to the highest speed initially, then adjust to maintain
colder airflow.
. Use
with A/C to provide
passenger comfort.
To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C. 3. Set the temperature control to full heat. 4. Set the fan speed to the highest setting. 5. Direct the outer instrument panel vents towards the side windows.
Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
34
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
DUAL ZONE MANUAL HEATING AND AIR CONDITIONING SYSTEM WITH REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) 1. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Distributes recirculated air through the instrument panel vents only to cool the vehicle. This re-cooling of the interior air is more economical and efficient. Recirculated air may also help reduce undesirable odors from entering the vehicle.
: Distributes air through the instrument panel vents. : Distributes air through the instrument panel vents and the floor vents.
O (OFF): Outside air is shut out and the climate system is turned off.
: Distributes air through the floor vents. : Distributes air through the windshield defroster vents and floor vents. : Distributes outside air through the windshield defroster vents. Can
Rear fan speed control: Press to enable the auxiliary system
be used to clear thin ice or fog from the windshield. Auxiliary climate control operation: Turn the front air flow control (1) to any position except O (OFF). 2. R or to adjust the rear fan speed from the front control. The rear fan speed settings available are 4, 3, 2, 1 and O (OFF). 3. REAR: Press to enable the control located in the rear seat. Press again to turn the auxiliary system off. 4. auxiliary system and to set the desired rear cabin airflow temperature with the front control. The rear cabin airflow temperature will match the driver airflow temperature setting when only the center rear temperature light ) is illuminated. The rear cabin airflow temperature will be warmer or cooler than the driver airflow temperature setting when ) is illuminated. more than one rear temperature light (
Rear temperature control: Press to enable the
REAR
REAR
REAR
35
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
Rear defrost: Press to activate/deactivate rear window defrost.
5. R Refer to Rear window defroster later in this chapter for more information. Recirculated air: Press to activate/deactivate air recirculation 6. in cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculation engages automatically with selection of MAX A/C or can be engaged manually in any other airflow selection except automatically in all airflow selections except MAX A/C. 7. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in MAX A/C, 8. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 9. Left temperature selection: Controls the temperature of the airflow to the driver in the front of the vehicle. 10. Right temperature selection: Controls the temperature of the airflow to the passenger in the front of the vehicle.
. Recirculation may turn off
and
position.
the air flow selector in the
airflow selector in the OFF or with recirculated air engaged.
Operating tips • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of • For maximum cooling performance (MAX A/C): In the MAX A/C mode: • Move the temperature control selector to the coldest setting. • Set the fan to the highest speed initially, then adjust to maintain
airflow to the back seats.
the windshield.
passenger comfort.
and
In the • Move the temperature control selector to the coldest setting. • Select A/C and recirculated air
modes:
. Use
with A/C to provide
colder airflow.
36
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
• Set the fan to the highest speed initially, then adjust to maintain
passenger comfort.
To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C. 3. Set the temperature control to full heat. 4. Set the fan speed to the highest setting. 5. Direct the outer instrument panel vents towards the side windows.
Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED)
Defrost: Distributes outside air through the windshield defroster
1. vents. Can be used to clear thin ice or fog from the windshield. 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control. The rear cabin airflow temperature will match the driver airflow temperature setting when only the center rear temperature bar (REAR) is illuminated. The rear cabin airflow temperature will be warmer or cooler than the driver airflow temperature setting when more than one rear temperature bar (REAR) is illuminated.
37
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
Rear defrost: Press to activate/deactivate the rear window
Rear fan speed control: Press to enable the auxiliary system
3. Passenger temperature control: Press to increase/decrease the temperature for the passenger in the front of the vehicle. 4. R defroster. Refer to Rear window defroster later in this chapter for more information. 5. R or to adjust the rear fan speed from the front control. The rear fan speed settings available are 4, 3, 2, 1 and O (OFF). Recirculated air: Press to activate/deactivate air recirculation 6. in the vehicle cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculated air can be engaged manually in any airflow selection except . Recirculated air may turn off automatically in all airflow selections. 7. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, 8. vents. 9. 10. vents. 11. 12. Manual override controls: Allows you to change the system operation. To return to full automatic control, press AUTO. 13. F decrease the fan speed. To return to full automatic control, press AUTO. 14. OFF: Outside air is shut out and the climate system is turned off. 15. Driver temperature control: Press to increase or decrease the temperature on the driver side of the cabin. Sets the passenger side temperature also when DUAL is disengaged. Note: The recommended vehicle cabin setting is between 72°F (22°C) and 75°F (24°C). • Dual temperature control: Press and hold AUTO to
: Distributes air through the instrument panel vents and the floor
: Distributes air through the windshield defroster vents and floor
Front fan speed control: Press to manually increase or
: Distributes air through the instrument panel vents.
: Distributes air through the floor vents.
, and
engage/disengage separate passenger side temperature control.
16. AUTO: Press to engage full automatic operation, and select the desired temperature using the temperature control. The system will
38
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature. 17. REAR: Press to enable the control located in the rear seat. Press again to turn the auxiliary system off.
DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH HEATED SEATS AND REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED)
Defrost: Distributes outside air through the windshield defroster
1. vents. Can be used to clear thin ice or fog from the windshield. 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control. The rear cabin airflow temperature will match the driver airflow temperature setting when only the center rear temperature bar (REAR) is illuminated. The rear cabin airflow temperature will be warmer or cooler than the driver airflow temperature setting when more than one rear temperature bar (REAR) is illuminated. 3. Passenger temperature control: Press to increase/decrease the temperature for the passenger in the front of the vehicle. 4. R defroster. Refer to Rear window defroster later in this chapter for more information.
Rear defrost: Press to activate/deactivate the rear window
39
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
: Distributes air through the instrument panel vents.
Rear fan speed control: Press to enable the auxiliary system
:Distributes air through the windshield defroster vents and the
Passenger heated seat control: Press once to activate the high
: Distributes air through the floor vents. : Distributes air through the instrument panel vents and the floor
5. R or to adjust the rear fan speed from the front control. The rear fan speed settings available are 4, 3, 2, 1 and O (OFF). 6. heat setting (2 indicator lights). Press again to activate the low heat setting (1 indicator light). Press again to deactivate the passenger heated seat. 7. floor vents. 8. 9. vents. 10. 11. Manual override controls: Allows you to change the system operation. To return to full automatic control, press AUTO. Driver heated seat control: Press once to activate the high 12. heat setting (2 indicator lights). Press again to activate the low heat setting (1 indicator light). Press again to deactivate the passenger heated seat. 13. F decrease the fan speed. To return to full automatic control, press AUTO. 14. recirculation in the vehicle cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculated air can be engaged manually in any airflow selection except selections. 15. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, 16. OFF: Outside air is shut out and the climate system is turned off. 17. Driver temperature control: Press to increase or decrease the temperature on the driver side of the cabin. Sets the passenger side temperature also when DUAL is disengaged. Note: The recommended vehicle cabin setting is between 72°F (22°C) and 75°F (24°C).
Front fan speed control: Press to manually increase or
. Recirculated air may turn off automatically in all airflow
Recirculated air: Press to activate/deactivate air
, and
40
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
• Dual temperature control: Press and hold AUTO to
engage/disengage separate passenger side temperature control.
18. AUTO: Press to engage full automatic operation, and select the desired temperature using the temperature control. The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature. 19. REAR: Press to enable the control located in the rear seat. Press again to turn the auxiliary system off.
position.
airflow to the back seats.
the air flow selector in the
airflow selector in the OFF or with recirculated air engaged.
OPERATING TIPS • To reduce fog build up on the windshield during humid weather, place • To reduce humidity build up inside the vehicle: do not drive with the • Do not put objects under the front seats that will interfere with the • Remove any snow, ice or leaves from the air intake area at the base of • For maximum cooling performance (MAX A/C): In AUTO mode, press AUTO control and set to desired temperature. In manual override control, select , A/C and recirculated air and set the temperature to 60°F (16°C). Set the fan to the highest speed initially, then adjust to maintain passenger comfort. • To improve the A/C cool down, drive with the windows slightly open
the windshield.
or
for 2–3 minutes after starting the vehicle or until the vehicle has “aired out.”
To aid in side window defogging/demisting in cold weather: 1. Select 2. Select A/C. 3. Modulate the temperature control to maintain comfort. 4. Set the fan to the highest speed. 5. Direct the outer instrument panel vents towards the side windows.
Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
41
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Climate Controls
AUXILIARY CLIMATE CONTROL (IF EQUIPPED) 1. Fan speed: Turn to select the desired fan speed. 2. Temperature/mode selection: The distribution of air from the overhead and floor registers is based on the temperature selected. Turn to select for comfort. To use the rear climate controls, ensure that REAR is pressed on the main climate control face.
TEMPERATURE SENSOR (IF EQUIPPED) Your vehicle may be equipped with a temperature sensor grid. This sensor works together with the Automatic Temperature Control system (if equipped) to help ensure the cabin remains at the desired temperature. Do not place items over the temperature sensor grid. This may cause improper operation of the system.
REAR WINDOW DEFROSTER R The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice. If equipped, the heated outside mirrors also operate with this control to remove snow, mist and ice from the side mirrors. Do not use razor blades or other sharp objects to clean the inside of the rear window or to remove decals from the inside of the rear window. This may cause damage to the heated grid lines and will not be covered by your warranty.
CABIN AIR FILTER Your vehicle is equipped with a Cabin air filter. The cabin air filter restricts the entry of airborne dust and pollen particles. The filter is located just in front of the windshield under the cowl vent screen on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer.
42
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Lights
HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps.
Turns the headlamps on.
Lights
Note: Some vehicles may be equipped with a headlamps on with wipers feature. In order for this feature to work: • the igniton must be in run and the front wipers must be on greater
than 10 seconds except during a mist wipe or while the wipers are on to clear washer fluid during a wash condition. • the headlamps and park lamps must be turned off when the ignition is in off or accessory position, or the front wipers are off for more than 30 seconds while the ambient light level is at daytime brightness.
Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for a fixed period of time after the ignition switch is turned to OFF. • To turn autolamps on, rotate the • To turn autolamps off, rotate the control clockwise to OFF. Autolamps - Programmable exit delay Programmable exit delay allows for the change of the length of the autolamp exit delay. Once in the programming mode, the headlamps and parklamps will turn on to indicate the start of the time desired. To program the auto lamp exit time delay: 1. Start with the ignition in OFF and the autolamps selected.
control counterclockwise.
43
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Lights
2. Deselect the auto lamps. 3. Put the ignition in RUN. 4. Put the ignition in OFF. 5. Select the autolamps. • Note: Steps 2 through 5 must be performed within a 10 second • At this point, the headlamps and park lamps will turn on. 6. Deselect the auto lamps after the desired auto lamp delay time (maximum of 3 minutes). • At this point, the headlamps and park lamps will turn off.
period.
Daytime running lamps (DRL) (if equipped) Turns the lowbeam headlamps on with a reduced output. To activate: • the key must be in the ON position, • the headlamp control is in the OFF, parking lamps or autolamp • and the transmission must be out of PARK.
position,
Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System
does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate.
44
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Flash to pass Pull toward you slightly to activate and release to deactivate.
Lights
Battery saver The battery saver will shut off the exterior lamps and interior lamps, except the hazard warning lamps if activated, 10 minutes after the ignition control has been turned off. The battery saver will extend the time-out period for courtesy lamps to 30 minutes if the liftgate is ajar or the dome lamp is on via manual activation using the dome lamp switch or the headlamp switch, whichever is provided. The system will not turn off the parking lamps if the headlamp control is in the PARK position. For interior lights, refer to Illuminated entry in the Locks and security chapter.
PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. • Rotate the thumbwheel from left
to right to brighten the instrument panel.
• Rotate the thumbwheel from right
to left to dim the instrument panel.
Your vehicle also contains a feature called “sleeping baby mode” — in which the dome lamps will remain off and only the lower lamps will illuminate. This lighting mode can be activated by rotating the thumbwheel to the first left detent position (as denoted by the half filled circle above).
45
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Lights
Domelamp Control The panel dimmer control also controls the domelamp operation. • Rotate the thumbwheel fully to the right, past detent to activate the • In order to turn off the domelamp, rotate the thumbwheel to the left. The dome lamp will not illuminate if the control switch is in the OFF position.
domelamp.
AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. You will need one #2 Phillips screwdriver to make the adjustments.
Vertical aim adjustment 1. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from a vertical wall or screen directly in front of it. • (1) Eight feet • (2) Center height of lamp to • (3) Twenty five feet • (4) Horizontal reference line
ground
2. Measure the height from the center of your headlamp to the ground and mark a 2.4 meter (8 foot) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well). The center of the lamp is marked by a 0.5 mm circle on the headlamp lens. 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood.
46
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Lights
4. On the wall or screen you will observe a light pattern with high intensity flat segments at the top edge of the pattern. If the flat edges are not at the horizontal reference line, the beam will need to be adjusted. 5. Locate the vertical adjuster on each headlamp, then use a No. 2
Phillips screwdriver to turn the adjuster either counterclockwise (to adjust up) or clockwise (to adjust down) positioning the horizontal edge of the high intensity light on the horizontal reference line. 6. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE. 7. Close the hood and turn off the lamps.TURN SIGNAL CONTROL • Push down to activate the left • Push up to activate the right turn
turn signal.
signal.
The cornering lamps feature (if equipped) automatically illuminates the left or right cornering lamps, located at the front corners of the vehicle, when the left or right turn signal, is activated. Cornering lamps are to provide better visibility of the area where the driver intends to turn.
INTERIOR LAMPS The interior lights illuminate when: • any door is opened (and the operation switch is in the middle • the instrument panel dimmer switch is moved to the passenger side • any of the remote entry controls are pressed and the ignition is OFF
position (right position).
position).
(an the operation switch is in the middle position).
47
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Lights
Map lamps (if equipped) The map lamps and controls are located on the center overhead console. Press the raised portion on each lens to activate the lamps.
Second row & third row dome and map lamps (if equipped) The second row dome and map lamps are located overhead, above the second row passenger seats. The dome lamp will stay on if the panel dimmer control is moved to the passenger side position. When the control is in the middle position, the lamp will only come on when a door is opened. If the control is moved to the driver’s side position, the lamp will not come on at all. The dome lamp will illuminate whenever a front door is opened. If either front door has been opened from the outside, the lamp will remain on for 20 seconds after the door is shut. If any other door has been opened from the inside, the lamp will shut off immediately after the door is closed. To activate the map lamps, press the control on either side of the center operation switch.
48
2004 Freestar (win) Owners Guide (post-2002-fmt) USA English (fus)
Lights
Dome lamps (if equipped) The front dome lamp is located overhead between the driver and passenger seats. The dome lamp will stay on if the panel dimmer control is moved to the passenger side position. When the control is in the middle position, the lamp will only come on when a door is opened. If the control is moved to the driver’s side position, the lamp will not come on at all. The dome lamp will illuminate whenever a front door is opened. If either front door has been opened from the outside, the lamp will remain on for 20 seconds after the door is shut. If any other door has been opened from the inside, the lamp will shut off immediately after the door is closed.
Cargo lamp The cargo lamp will stay on if the control is moved to the driver side position. When the control is in the middle position, the lamp will only come on when a door is opened. If the control is moved to the passenger’s side position, the lamp will not come on at all. With the ignition key in the ACCESSORY or ON position, the rear cargo lamp can be turned ON or OFF by sliding the control.
BULBS
Replacing exterior bulbs Check the operation of all the bulbs frequently.
Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn
