Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Contents


Introduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 28
Seats and Restraints . . . . . . . . . . . 52
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 99
Instruments and Controls . . . . . . 103
Lighting . . . . . . . . . . . . . . . . . . . . . . . 148
Infotainment System . . . . . . . . . . 155
Climate Controls . . . . . . . . . . . . . . 181
Driving and Operating . . . . . . . . . 190
Vehicle Care . . . . . . . . . . . . . . . . . . 248
Service and Maintenance . . . . . 324
Technical Data . . . . . . . . . . . . . . . . 337
Customer Information . . . . . . . . . 341
Reporting Safety Defects . . . . . . 351
OnStar . . . . . . . . . . . . . . . . . . . . . . . . 355
Index . . . . . . . . . . . . . . . . . . . . 365


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Introduction


Introduction


The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CHEVROLET, the CHEVROLET Emblem, IMPALA, and the IMPALA Emblem are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors. For vehicles first sold in Canada, substitute the name "General Motors of Canada Limited" for Chevrolet Motor Division wherever it appears in this manual. This manual describes features that may or may not be on the vehicle because of optional equipment that Litho in U.S.A. Part No. 23179989 A First Printing


was not purchased on the vehicle, model variants, country specifications, features/applications that may not be available in your region, or changes subsequent to the printing of this owner manual. If the vehicle has the bi-fuel engine, see the Impala Bi-Fuel supplement for additional and specific information on this engine. Refer to the purchase documentation relating to your specific vehicle to confirm the features. Keep this manual in the vehicle for quick reference.


Canadian Vehicle Owners


Propriétaires Canadiens A French language manual can be obtained from your dealer, at www.helminc.com, or from:


On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse savant: Helm, Incorporated Attention: Customer Service 47911 Halyard Drive Plymouth, MI 48170


Using this Manual To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found.


Danger, Warning, and Caution Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them.


©2015 General Motors LLC. All Rights Reserved.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


{ Danger


Danger indicates a hazard with a high level of risk which will result in serious injury or death.


{ Warning


Warning indicates a hazard that could result in injury or death.


Caution


Caution indicates a hazard that could result in property or vehicle damage.


A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.”


Symbols The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or information relating to a specific component, control, message, gauge, or indicator. M : Shown when the owner manual has additional instructions or information. * : Shown when the service manual has additional instructions or information. 0 : Shown when there is more information on another page — “see page.”


Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the Index.


Introduction


9 : Airbag Readiness Light ! : Antilock Brake System (ABS) g : Audio Steering Wheel Controls or OnStar® $ : Brake System Warning Light " : Charging System I : Cruise Control ` : Do Not Puncture ^ : Do Not Service B : Engine Coolant Temperature O : Exterior Lamps g : First Responder _ : Flame/Fire Prohibited . : Fuel Gauge + : Fuses 3 : Headlamp High/Low-Beam Changer ( : Heated Steering Wheel j : LATCH System Child Restraints * : Malfunction Indicator Lamp : : Oil Pressure O : Power


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Introduction


/ : Remote Vehicle Start > : Safety Belt Reminders 7 : Tire Pressure Monitor d : Traction Control/StabiliTrak® a : Under Pressure M : Windshield Washer Fluid


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


In Brief


Driving for Better Fuel


Economy . . . . . . . . . . . . . . . . . . . . . 26


Roadside Assistance


Program . . . . . . . . . . . . . . . . . . . . . . 27


In Brief


Instrument Panel


Instrument Panel . . . . . . . . . . . . . . . . 6


Initial Drive Information


Initial Drive Information . . . . . . . . . . 8
Stop/Start System . . . . . . . . . . . . . . . 8
Remote Keyless Entry (RKE)


System . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Vehicle Start . . . . . . . . . . . 8
Door Locks . . . . . . . . . . . . . . . . . . . . . 9
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Windows . . . . . . . . . . . . . . . . . . . . . . . 10
Seat Adjustment . . . . . . . . . . . . . . . 10
Memory Features . . . . . . . . . . . . . . 12
Second Row Seats . . . . . . . . . . . . 13
Heated and Ventilated Seats . . . 13
Head Restraint Adjustment . . . . 13
Safety Belts . . . . . . . . . . . . . . . . . . . . 13
Passenger Sensing System . . . 14
Mirror Adjustment . . . . . . . . . . . . . . 14
Steering Wheel Adjustment . . . . 15
Interior Lighting . . . . . . . . . . . . . . . . 15
Exterior Lighting . . . . . . . . . . . . . . . 16
Windshield Wiper/Washer . . . . . . 17
Climate Controls . . . . . . . . . . . . . . . 17
Transmission . . . . . . . . . . . . . . . . . . 19


Vehicle Features


Infotainment System . . . . . . . . . . . 20
Radio(s) . . . . . . . . . . . . . . . . . . . . . . . 20
Satellite Radio . . . . . . . . . . . . . . . . . 20
Portable Audio Devices . . . . . . . . 21
Bluetooth® . . . . . . . . . . . . . . . . . . . . . 21
Steering Wheel Controls . . . . . . . 21
Cruise Control . . . . . . . . . . . . . . . . . 22
Driver Information


Center (DIC) . . . . . . . . . . . . . . . . . 22


Forward Collision Alert (FCA)


System . . . . . . . . . . . . . . . . . . . . . . . 22


Front Automatic Braking (FAB)


System . . . . . . . . . . . . . . . . . . . . . . . 23


Lane Departure


Warning (LDW) . . . . . . . . . . . . . . . 23
Lane Change Alert (LCA) . . . . . . 23
Rear Vision Camera (RVC) . . . . 23
Rear Cross Traffic Alert (RCTA)


System . . . . . . . . . . . . . . . . . . . . . . . 23
Parking Assist . . . . . . . . . . . . . . . . . 23
Power Outlets . . . . . . . . . . . . . . . . . 24
Universal Remote System . . . . . 24
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 24
Performance and Maintenance


Traction Control/Electronic


Stability Control . . . . . . . . . . . . . . 25
Tire Pressure Monitor . . . . . . . . . . 25
Engine Oil Life System . . . . . . . . 26
E85 or FlexFuel . . . . . . . . . . . . . . . . 26


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


In Brief


Instrument Panel


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


1.


Instrument Panel Illumination Control 0 151.


2. Air Vents 0 188. 3. Trunk Release. See Trunk


0 41. Parking Assist Button. See Assistance Systems for Parking or Backing 0 228 (If Equipped). Lane Departure Warning (LDW) Button. See Lane Departure Warning (LDW) 0 235.


9. Storage Area with USB Port


Inside (If Equipped). See Instrument Panel Storage 0 99
and USB Port 0 164. Infotainment 0 155.


10. 11. Climate Control Systems


0 181. Dual Automatic Climate Control System 0 184.


12. Storage Area with Accessory


Power Outlet Inside. See Center Console Storage 0 100
and Power Outlets 0 108.


4. Turn Signal Lever. See Turn


13. Heated and Ventilated Front


5.


and Lane-Change Signals 0 151. Instrument Cluster 0 112. Driver Information Center (DIC) 0 127.


6. Windshield Wiper/Washer


16.


0 106.


7. Hazard Warning Flashers


0 150.


8. Light Sensor. See Automatic


Headlamp System 0 150.


Seats 0 60 (If Equipped).


14. Traction Control/Electronic


Stability Control 0 216.


15. Shift Lever. See Automatic


Transmission 0 211. Ignition Positions (Keyless Access) 0 201 or Ignition Positions (Key Access) 0 203.


17. Steering Wheel Controls 0 105.


Driver Information Center Buttons. See Driver Information Center (DIC) 0 127.


In Brief


18. Steering Wheel Controls 0 105


(Out of View).


19. Horn 0 105. 20. Steering Wheel Adjustment


0 104.


21. Cruise Control 0 218 (If


Equipped). Adaptive Cruise Control 0 220
(If Equipped). Heated Steering Wheel 0 105
(If Equipped). Forward Collision Alert (FCA) System 0 230 (If Equipped). Instrument Panel Storage 0 99
(If Equipped). Fuse Cover. See Instrument Panel Fuse Block 0 280. 23. Hood Release. See Hood


22.


0 250.


24. Data Link Connector (Out of


View). See Malfunction Indicator Lamp (Check Engine Light) 0 120.


25. Electric Parking Brake. See


Parking Brake 0 214.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


In Brief


Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual.


Stop/Start System The vehicle may have a fuel saving stop/start system to shut off the engine and help conserve fuel. When the brakes are applied and the vehicle is at a complete stop, the engine may turn off. When the brake pedal is released or the accelerator pedal pushed, the engine will restart. See Starting the Engine 0 204.


Remote Keyless Entry (RKE) System The RKE transmitter may work up to 60 m (197 ft) away from the vehicle.


RKE with Remote Start Shown,


without Similar


Press the button to extend the key. The key can be used for all locks. This key is also used for the ignition, if the vehicle does not have pushbutton start. K : Press to unlock the driver door or all doors. Q : Press to lock all doors.


Lock and unlock feedback can be personalized. Y : Press and hold to release the trunk. 7 : Press and release one time to initiate vehicle locator. Press and hold for at least three seconds to sound the panic alarm. Press again to cancel the panic alarm. See Keys 0 28 and Remote Keyless Entry (RKE) System Operation 0 30.


Remote Vehicle Start If equipped, the engine can be started from outside of the vehicle. Starting the Vehicle 1. Press and release Q on the


2.


RKE transmitter. Immediately press and hold / for at least four seconds or until the turn signal lamps flash.


3. Start the vehicle normally after


entering.


When the vehicle starts, the parking lamps will turn on.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Remote start can be extended. Canceling a Remote Start To cancel a remote start, do one of the following: . Press and hold / until the


parking lamps turn off.


. Turn on the hazard warning


flashers.


. Turn the vehicle on and then off. See Remote Vehicle Start 0 35.


Door Locks


Keyless Access


If equipped, use the Keyless Access system to lock and unlock the door. When the doors are locked and the Remote Keyless Entry (RKE) transmitter is within 1 m (3 ft) of the driver door handle, press the lock/ unlock button. When unlocking from the driver door, the first press unlocks that door; press again within five seconds to unlock all passenger doors. See Remote Keyless Entry (RKE) System Operation 0 30.


Key Cylinder Access Use the key in the driver door. The key cylinder is covered by a cap. See Door Locks 0 37.


Inside the Vehicle Push down on the door lock knob to lock that door. Pull once on the door handle to unlock the door and again to open the door. Press the power door lock switch to lock or unlock all doors. See Door Locks 0 37 and Power Door Locks 0 39.


In Brief


Power Door Locks


K : Press to unlock. Q : Press to lock. See Power Door Locks 0 39.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


10


In Brief


Trunk


To open the trunk: . Press | with the transmission


in (P) Park.


. Press and hold Y on the RKE


transmitter. If equipped, press the touch pad on the underside of the trunk lid after unlocking all doors.


If equipped with Keyless Access, the RKE transmitter must be within 1 m (3 ft) of the trunk. Press the touch pad on the underside of the


trunk and lift to open. See Remote Keyless Entry (RKE) System Operation 0 30. When closing the trunk, use the pull cup. See Trunk 0 41.


Windows


The power window switches on the driver door control all the windows. Each passenger door has a switch that controls only that window. Press the switch to lower the window. Pull the switch up to raise it. See Power Windows 0 47.


Seat Adjustment


Manual Front Seats


The power windows only operate with the ignition in ACC/ ACCESSORY or ON/RUN/START, or when Retained Accessory Power (RAP) is active. See Retained Accessory Power (RAP) 0 208.


To adjust a manual seat: 1. Pull the handle at the front of


the seat.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Power Seats


Lumbar Adjustment


In Brief


11


2. Slide the seat to the desired


position and release the handle.


3. Try to move the seat back and


forth to be sure it is locked in place.


Seat Height Adjuster


To adjust the seat: . Move the seat forward or


rearward by sliding the control forward or rearward.


. Raise or lower the front part of the seat cushion by moving the front of the control up or down.


. Raise or lower the seat by


moving the rear of the control up or down.


See Power Seat Adjustment 0 56.


Lumbar with Power Recline


Shown, Manual Recline Similar


To adjust the lumbar support: . Press and hold the control


forward to increase or rearward to decrease lumbar support. If equipped with manual recline, press and hold the top of the control to increase or the bottom of the control to decrease lumbar support.


See Lumbar Adjustment 0 56.


Press and hold the top or bottom of the switch to raise or lower the seat. Release the switch when the desired height is reached. See Seat Adjustment 0 55.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


12


In Brief


Reclining Seatbacks


Manual Reclining Seatbacks


Memory Features


1. Lift the lever fully without applying pressure to the seatback, and the seatback will return to the upright position.


2. Push and pull on the seatback


to make sure it is locked.


Power Reclining Seatbacks


To recline a manual seatback: 1. Lift the lever. 2. Move the seatback to the desired position, and then release the lever to lock the seatback in place.


3. Push and pull on the seatback


to make sure it is locked.


To return the seatback to the upright position:


To adjust a power seatback: . Tilt the top of the control


rearward to recline.


. Tilt the top of the control forward


to raise.


See Reclining Seatbacks 0 57.


If equipped, the 1, 2, SET, and B (Exit) buttons on the driver door are used to manually store and recall memory settings for the driver seat, outside mirrors, and power tilt and telescoping steering column (if equipped). Automatic Memory Recall and/or Easy Exit Recall features may be enabled in the vehicle personalization menus. See Memory Seats 0 58 and Vehicle Personalization 0 138.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Second Row Seats The rear seatbacks can be folded down to increase cargo space. See Rear Seats 0 61.


Heated and Ventilated Seats


Heated and Ventilated Seat Buttons Shown, Heated Seat


Buttons Similar


If available, the buttons are on the center console. To operate, the ignition must be on. I : If available, press to heat the driver or passenger seatback only.


J : Press to heat the driver or passenger seat cushion and seatback. C : If available, press to ventilate the driver or passenger seat. A ventilated seat has a fan that pulls or pushes air through the seat. The air is not cooled. An indicator light on the button turns on when the heated or ventilated seat is on. See Heated and Ventilated Front Seats 0 60.


Head Restraint Adjustment Do not drive until the head restraints for all occupants are installed and adjusted properly. To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position. See Head Restraints 0 53 and Seat Adjustment 0 55.


In Brief


13


Safety Belts


Refer to the following sections for important information on how to use safety belts properly: . Safety Belts 0 63. . How to Wear Safety Belts


Properly 0 64.


. Lap-Shoulder Belt 0 65. . Lower Anchors and Tethers for Children (LATCH System) 0 88.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


14


In Brief


Passenger Sensing System


United States


The passenger airbag status indicator lights on the overhead console when the vehicle is started. See Passenger Airbag Status Indicator 0 118.


Mirror Adjustment


Exterior Mirrors


Canada


The passenger sensing system will turn off the front outboard passenger frontal airbag and knee airbag under certain conditions. No other airbag is affected by the passenger sensing system. See Passenger Sensing System 0 75.


1. Move the selector switch to L (Left) or R (Right) to choose the driver or passenger mirror. 2. Press one of the four arrows to


move the mirror.


3. Move the selector switch to )


to deselect the mirror.


The vehicle has manual folding mirrors. See Folding Mirrors 0 46. Interior Mirrors


Adjustment Adjust the rearview mirror for a clear view of the area behind the vehicle.


Manual Rearview Mirror For vehicles with a manual rearview mirror, push the tab forward for daytime use and pull it for nighttime use to avoid glare from the headlamps from behind. See Manual Rearview Mirror 0 47.


Automatic Dimming Rearview Mirror For vehicles with an automatic dimming rearview mirror, the mirror will automatically reduce the glare from the headlamps from behind. The dimming feature comes on when the vehicle is started. See Automatic Dimming Rearview Mirror 0 47.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Steering Wheel Adjustment


Power Tilt and Telescoping Wheel


Interior Lighting


Dome Lamps


In Brief


15


If equipped with this feature, press the control to move the steering wheel up and down or forward and rearward. Do not adjust the steering wheel while driving.


To adjust the steering wheel: 1. Pull the lever down. 2. Move the steering wheel up


or down.


3. Pull or push the steering wheel


closer or away from you.


4. Pull the lever up to lock the


steering wheel in place.


The interior lamps control in the overhead console controls both the front and rear interior lamps. To change the dome lamp settings, press the following: OFF : Turns the lamp off, even when a door is open. DOOR : The lamp comes on automatically when a door is opened. ON : Turns the lamp on.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


16


In Brief


Reading Lamps


Exterior Lighting


Front Reading Lamps


Rear Reading Lamps


There are front and rear reading lamps in the overhead console and the headliner. # or $ : Press the button near each lamp to turn it on or off.


The exterior lamp control is on the turn signal lever. There are four positions. O : Turns off the exterior lamps. The knob returns to the AUTO position after it is released. Turn to O again to reactivate the AUTO mode. AUTO : Automatically turns the exterior lamps on and off, depending on outside lighting. ; : Turns on the parking lamps including all lamps, except the headlamps. 2 : Turns on the headlamps together with the parking lamps and instrument panel lights.


In Brief


17


Climate Controls The heating, cooling, and ventilation for the vehicle can be controlled with these systems.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


See: . Exterior Lamp Controls 0 148


Windshield Wiper/Washer


The windshield wiper/washer lever is on the right side of the steering column. With the ignition in ACC/ ACCESSORY or ON/RUN, move the windshield wiper lever to select the wiper speed. HI : Use for fast wipes. LO : Use for slow wipes.


INT : Move the lever up to INT for intermittent wipes, then turn the x INT band up for more frequent wipes or down for less frequent wipes. OFF : Use to turn the wipers off. 1X : For a single wipe, briefly move the wiper lever down. For several wipes, hold the wiper lever down. n L : Pull the windshield wiper lever toward you to spray windshield washer fluid and activate the wipers. See Windshield Wiper/Washer 0 106.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


18


In Brief


Climate Control System


1. Fan Control 2. Air Conditioning or Comfort/ Eco Air Conditioning (Stop/ Start Only)


3. Air Delivery Modes 4. Defrost 5. TEMP (Temperature Control) 6. Rear Window Defogger 7. Recirculation


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Dual Automatic Climate Control System


10. AUTO (Automatic Operation) See Climate Control Systems 0 181
or Dual Automatic Climate Control System 0 184, if equipped.


1. Driver and Passenger Temperature Controls


2. Air Conditioning or Comfort/ Eco Air Conditioning (Stop/ Start Only) 3. Fan Control 4. Defrost 5. SYNC 6. Rear Window Defogger 7. Air Delivery Modes 8. O (Fan On/Off) 9. Recirculation


In Brief


19


Transmission


Driver Shift Control (DSC) This feature allows for changing gears similar to a manual transmission. To use this feature: 1. Move the shift lever from


D (Drive) rearward to M (Manual Mode).


2. Using the button on the top of


the shift lever, press the + (plus) end of the button to upshift, or press the − (minus) end of the button to downshift.


See Manual Mode 0 212.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


20


In Brief


Vehicle Features


Infotainment System The base radio information is included in this manual. See the infotainment manual for information on the uplevel radios, audio players, phone, navigation system, and voice or speech recognition. There is also information on settings and downloadable applications (if equipped).


Radio(s) O : Press to turn the system on. Press and hold to turn it off. When on, press to mute; press again to unmute. Turn to increase or decrease the volume. RADIO : Press to choose between FM, AM, and SiriusXM®, if equipped. MEDIA : Press to change the audio source between USB, SD card, and AUX. { : Press to go to the Home Page. MENU : Press to select a menu.


g : Press to seek the previous station or track. l : Press to seek the next station or track. See Overview 0 157 about these and other radio features. Storing Radio Station Presets Up to 25 preset stations from all bands can be stored in the favorite lists in any order. Up to five stations can be stored in each favorite page and the number of favorite pages can be set. To store the station to a position in the list, while on the active source main page, such as AM, FM, or SiriusXM (if equipped), press and hold a favorites/soft key button on the faceplate. See “Storing Radio Station Presets” under AM-FM Radio 0 161. Setting the Clock See Clock (Base Radio) 0 107 or Clock (Uplevel Radio) 0 108.


Satellite Radio Vehicles with a SiriusXM® satellite radio tuner and a valid SiriusXM satellite radio subscription can receive SiriusXM programming. SiriusXM Satellite Radio Service SiriusXM is a satellite radio service based in the 48 contiguous United States and 10 Canadian provinces. SiriusXM satellite radio has a wide variety of programming and commercial-free music, coast to coast, and in digital-quality sound. A fee is required to receive the SiriusXM service. For more information refer to: . www.siriusxm.com or call


1-866-635-2349 (U.S.). . www.xmradio.ca or call


1-877-209-0079 (Canada).


See Satellite Radio 0 162.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Portable Audio Devices This vehicle has a 3.5 mm (1/8 in) auxiliary input jack. If equipped, there are up to two USB ports in the center console and one in the storage behind the radio. External devices such as iPods®, laptop computers, MP3 players, CD changers, and USB storage devices may be connected, depending on the audio system. See Auxiliary Jack 0 167 and USB Port 0 164.


Bluetooth® The Bluetooth® system allows users with a Bluetooth-enabled cell phone to make and receive hands-free calls using the vehicle audio system and controls. The Bluetooth-enabled cell phone must be paired with the in-vehicle Bluetooth system before it can be used in the vehicle. Not all phones will support all functions.


See Bluetooth (Overview) 0 168 or Bluetooth (Infotainment Controls - Base Radio) 0 170 or Bluetooth (Voice Recognition - Base Radio) 0 174.


Steering Wheel Controls


In Brief


21


c : Press to reject an incoming call, or end a current call. Press to mute or unmute the infotainment system when not on a call.


Some audio controls can be adjusted at the steering wheel. g : For vehicles with OnStar® or a Bluetooth® system, press to interact with those systems. See OnStar Overview 0 355 or “Bluetooth (Overview)” in the infotainment manual.


The favorite and volume switches are on the back of the steering wheel. 1. Favorites: Press to select the


next or previous favorite.


2. Volume: Press to increase or


decrease the volume.


See Steering Wheel Controls 0 105.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


22


In Brief


Cruise Control


5 : Press to turn cruise control on or off. A white indicator comes on in the instrument cluster when cruise is on. +RES : If there is a set speed in memory, press briefly to resume to that speed or press and hold to accelerate. If cruise control is already active, use to increase vehicle speed. SET– : Press briefly to set the speed and activate cruise control. If cruise control is already active, use to decrease vehicle speed.


* : Press to disengage cruise control without erasing the set speed from memory. See Cruise Control 0 218 or Adaptive Cruise Control 0 220 (if equipped).


Driver Information Center (DIC) The DIC display is in the instrument cluster. It shows the status of many vehicle systems.


w or x : Press to move up or down in a list, or on the main view press to cycle through the different Info app pages. o or p : Press o to open application menus on the left. Press p to open interaction menus on the right. V : Press to select a menu item. Press and hold to reset values on certain screens, or on the main view reset info pages to the original setting. See Instrument Cluster 0 112 and Driver Information Center (DIC) 0 127.


Forward Collision Alert (FCA) System If equipped, FCA may help avoid or reduce the harm caused by front-end crashes. FCA provides a green indicator, V, when a vehicle is detected ahead. This indicator displays amber if you follow a vehicle much too closely. When approaching a vehicle ahead too


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


quickly, FCA provides a red flashing alert on the windshield and rapidly beeps. See Forward Collision Alert (FCA) System 0 230.


Front Automatic Braking (FAB) System If the vehicle has Adaptive Cruise Control (ACC), it also has FAB. When the system detects a vehicle ahead in your path that is traveling in the same direction that you may be about to crash into, it can automatically brake the vehicle. This can help avoid or lessen the severity of crashes when driving in a forward gear. See Front Automatic Braking (FAB) System 0 232.


Lane Departure Warning (LDW) If equipped, LDW may help avoid unintentional lane departures at speeds of 56 km/h (35 mph) or greater. LDW uses a camera sensor to detect the lane markings. The


LDW light, @, is green if a lane marking is detected. If the vehicle departs the lane without using a turn signal in that direction, the light will change to amber and flash. In addition, beeps will sound. See Lane Departure Warning (LDW) 0 235.


Lane Change Alert (LCA) If equipped, the LCA system is a lane-changing aid that assists drivers with avoiding lane change crashes that occur with moving vehicles in the side blind zone (or spot) areas or with vehicles rapidly approaching these areas from behind. The LCA warning display will light up in the corresponding outside side mirror and will flash if the turn signal is on. The Side Blind Zone Alert (SBZA) system is included as part of the LCA system. See Side Blind Zone Alert (SBZA) 0 233 and Lane Change Alert (LCA) 0 233.


In Brief


23


Rear Vision Camera (RVC) If equipped, RVC displays a view of the area behind the vehicle on the center stack display when the vehicle is shifted into R (Reverse) to aid with parking and low-speed backing maneuvers. See Assistance Systems for Parking or Backing 0 228.


Rear Cross Traffic Alert (RCTA) System If equipped, the RCTA system uses a triangle with an arrow displayed on the RVC screen to warn of traffic behind your vehicle that may cross your vehicle's path while in R (Reverse). In addition, beeps will sound. See Assistance Systems for Parking or Backing 0 228.


Parking Assist If equipped, Rear Parking Assist (RPA) uses sensors on the rear bumper to assist with parking and


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


24


In Brief


avoiding objects while in R (Reverse). It operates at speeds less than 8 km/h (5 mph). RPA may display a warning triangle on the Rear Vision Camera screen and/or a graphic on the instrument cluster to provide the object distance. In addition, multiple beeps may occur if very close to an object. See Assistance Systems for Parking or Backing 0 228.


Power Outlets The accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. The vehicle has three accessory power outlets:


Inside the front storage area below the climate control system. Inside the center console. . On the rear of the center


console.


Lift the cover to access the accessory power outlet. See Power Outlets 0 108.


Universal Remote System


Sunroof If equipped, the ignition must be in ON/RUN or ACC/ACCESSORY, or in Retained Accessory Power (RAP) to operate the sunroof and power sunshade. See Retained Accessory Power (RAP) 0 208.


This system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices. Read the instructions completely before attempting to program the Universal Remote system. Because of the steps involved, it may be helpful to have another person available to assist with programming the Universal Remote system. See Universal Remote System 0 144.


1. ~ Sunroof Switch 2. Q Sunshade Switch


Sunroof Switch Open/Close : Press and hold the front or rear of ~ to open or close the sunroof. Release ~ at the desired position to stop movement.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Vent Feature : Press the front or rear of ~ to the first detent to open and close the vent feature. The sunshade partially opens and closes automatically during the vent operation. Express Open/Express Close : Fully press and release the front or rear of ~. The sunroof opens and closes automatically.


Sunshade Switch Open/Close : Press and hold the front or rear of Q to open or close the sunshade to the desired position. Express Open/Express Close : Fully press and release the front or rear of Q to express open or express close the sunshade. If the sunroof is open, the sunshade will express close just short of the open sunroof. See Sunroof 0 50.


Performance and Maintenance


Traction Control/ Electronic Stability Control The Traction Control System (TCS) limits wheel spin. The system turns on automatically every time the vehicle is started. The StabiliTrak system assists with directional control of the vehicle in difficult driving conditions. The system also turns on automatically every time the vehicle is started. . To turn off traction control, press and release the g button on the center console. The Traction Off light i illuminates.


. To turn off both traction control and StabiliTrak, press and hold the g button, until the Traction Off light i and the StabiliTrak Off light g illuminate.


In Brief


25


. Press and release the g button again to turn on both systems.


See Traction Control/Electronic Stability Control 0 216.


Tire Pressure Monitor This vehicle may have a Tire Pressure Monitor System (TPMS).


The low tire pressure warning light alerts to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and Loading Information label. See Vehicle Load Limits 0 198. The warning light will remain on until the tire pressure is corrected.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


26


In Brief


The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This may be an early indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure. The TPMS does not replace normal monthly tire maintenance. Maintain the correct tire pressures. See Tire Pressure Monitor System 0 292.


Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays the CHANGE ENGINE OIL SOON message when it is time to change the engine oil and filter. The oil life system should be reset to 100% only following an oil change.


Resetting the Oil Life System 1. Using the DIC controls on the


right side of the steering wheel, display REMAINING OIL LIFE on the DIC. See Driver


Information Center (DIC) 0 127. When remaining oil life is low, the CHANGE ENGINE OIL SOON message will appear on the display. See Engine Oil Messages 0 132.


2. Press V on the DIC controls


and hold down for a few seconds to clear the CHANGE ENGINE OIL SOON message and reset the oil life at 100%. Be careful not to reset the oil life display accidentally at any time other than after the oil is changed. It cannot be reset accurately until the next oil change.


The oil life system can also be reset as follows: 1. Turn the ignition on with the


engine off.


2. Fully press and release the


accelerator pedal three times within five seconds. If the CHANGE ENGINE OIL SOON message is not on, the system is reset.


See Engine Oil Life System 0 257.


E85 or FlexFuel Vehicles with a yellow fuel cap can use either unleaded gasoline or ethanol fuel containing up to 85% ethanol (E85). See E85 or FlexFuel 0 239. For all other vehicles, use only the unleaded gasoline described under Fuel 0 237.


Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. . Avoid fast starts and accelerate


smoothly.


. Brake gradually and avoid


abrupt stops.


. Avoid idling the engine for long


periods of time.


. When road and weather


conditions are appropriate, use cruise control.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


In Brief


27


. Always follow posted speed


limits or drive more slowly when conditions require.


. Keep vehicle tires properly


inflated.


. Combine several trips into a


single trip.


. Replace the vehicle's tires with


the same TPC Spec number molded into the tire's sidewall near the size.


. Follow recommended scheduled


maintenance.


Roadside Assistance Program U.S.: 1-800-243-8872
TTY Users (U.S. Only): 1-888-889-2438
Canada: 1-800-268-6800
As the owner of a new Chevrolet, you are automatically enrolled in the Roadside Assistance program. See Roadside Assistance Program 0 345.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Keys, Doors, and Windows


28
Keys, Doors, and Windows


Exterior Mirrors


Convex Mirrors . . . . . . . . . . . . . . . . 45
Power Mirrors . . . . . . . . . . . . . . . . . . 45
Folding Mirrors . . . . . . . . . . . . . . . . . 46
Heated Mirrors . . . . . . . . . . . . . . . . . 46
Reverse Tilt Mirrors . . . . . . . . . . . . 46


Interior Mirrors


Interior Rearview Mirrors . . . . . . . 47
Manual Rearview Mirror . . . . . . . . 47
Automatic Dimming Rearview


Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 47


Windows


Windows . . . . . . . . . . . . . . . . . . . . . . . 47
Power Windows . . . . . . . . . . . . . . . 47
Sun Visors . . . . . . . . . . . . . . . . . . . . . 49


Roof


Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 50


Keys and Locks


Keys


{ Warning


Leaving children in a vehicle with an ignition key or Remote Keyless Entry (RKE) transmitter is dangerous and children or others could be seriously injured or killed. They could operate the power window or other controls or make the vehicle move. The windows will function with the key in the ignition or with the RKE transmitter in the vehicle, and children or others could be caught in the path of a closing window. Do not leave children in a vehicle with the ignition key or an RKE transmitter.


Keys and Locks


Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Remote Keyless Entry (RKE)


System . . . . . . . . . . . . . . . . . . . . . . . 30


Remote Keyless Entry (RKE)


System Operation . . . . . . . . . . . . 30
Remote Vehicle Start . . . . . . . . . . 35
Door Locks . . . . . . . . . . . . . . . . . . . . 37
Power Door Locks . . . . . . . . . . . . . 39
Delayed Locking . . . . . . . . . . . . . . . 39
Automatic Door Locks . . . . . . . . . 39
Lockout Protection . . . . . . . . . . . . . 40
Safety Locks . . . . . . . . . . . . . . . . . . . 40


Doors


Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 41


Vehicle Security


Vehicle Security . . . . . . . . . . . . . . . . 42
Vehicle Alarm System . . . . . . . . . 42
Immobilizer . . . . . . . . . . . . . . . . . . . . 43
Immobilizer Operation (Key


Access) . . . . . . . . . . . . . . . . . . . . . . 43


Immobilizer Operation (Keyless


Access) . . . . . . . . . . . . . . . . . . . . . . 44


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Keys, Doors, and Windows


29


Warning (Continued)


impacted, and airbags may not deploy. To reduce the risk of unintentional rotation of the ignition key, do not change the way the ignition key and Remote Keyless Entry (RKE) transmitter, if equipped, are connected to the provided key rings.


If the vehicle is equipped with a keyed ignition, the ignition key, key rings, and RKE transmitter, if equipped, are designed to work together. As a system, it reduces the risk of unintentionally moving the key out of the RUN position. If replacements or additions are required, see your dealer. Limit added items to a few essential keys or small, light items no larger than an RKE transmitter. The key that is part of the Remote Keyless Entry (RKE) transmitter can be used for the ignition and all locks if the vehicle is a Key Access


vehicle. If the vehicle has the keyless ignition, the key can be used for the locks.


RKE With Remote Start Shown,


Without Similar


Press the button on the RKE transmitter to extend the key. Press the button and the key blade to retract the key. If the vehicle has an ignition and it becomes difficult to turn the key, inspect the key blade for debris. Periodically clean with a brush or pick. See your dealer if a new key is needed.


{ Warning


If the key is unintentionally rotated while the vehicle is running, the ignition could be moved out of the RUN position. This could be caused by heavy items hanging from the key ring, or by large or long items attached to the key ring that could be contacted by the driver or steering wheel. If the ignition moves out of the RUN position, the engine will shut off, braking and steering power assist may be (Continued)


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


30


Keys, Doors, and Windows


With an active OnStar subscription, an OnStar Advisor may remotely unlock the vehicle. See OnStar Overview 0 355.


Remote Keyless Entry (RKE) System See Radio Frequency Statement 0 351. If there is a decrease in the RKE operating range: . Check the distance. The


transmitter may be too far from the vehicle.


. Check the location. Other vehicles or objects may be blocking the signal.


. Check the transmitter's battery. See “Battery Replacement” later in this section. If the transmitter is still not working correctly, see your dealer or a qualified technician for service.


Remote Keyless Entry (RKE) System Operation The transmitter functions may work up to 60 m (197 ft) away from the vehicle. Keep in mind that other conditions, such as those previously stated, can impact the performance of the transmitter.


With Remote Start Shown


Q (Lock) : Press to lock all doors. The turn signal indicators may flash and/or the horn may sound on the second press to indicate locking. See Vehicle Personalization 0 138.


If Unlocked Door Anti-Lockout is enabled through vehicle personalization and the driver door is open when Q is pressed, all doors lock and the driver door will immediately unlock. See Vehicle Personalization 0 138. If the passenger door is open when Q is pressed, all doors lock. Pressing Q may also arm the alarm system. See Vehicle Alarm System 0 42. K (Unlock) : Press to unlock the driver door or all doors. See Vehicle Personalization 0 138. The turn signal indicators may flash to indicate unlocking. See Vehicle Personalization 0 138. Pressing K will disarm the alarm system. See Vehicle Alarm System 0 42. Y (Remote Trunk Release) : Press and hold to release the trunk.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Keys, Doors, and Windows


31


transmitter from your pocket, purse, briefcase, etc. The RKE transmitter must be within 1 m (3 ft) of the door being unlocked. If the vehicle has this feature, there will be a button on the outside door handles. The Keyless Access can be programmed to unlock all doors on the first unlock/lock button press from the driver door. See Vehicle Personalization 0 138.


Keyless Unlocking/Locking from the Driver Door When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the driver door handle, pressing the lock/unlock button on the driver door handle will unlock the driver door. If the lock/unlock button is pressed again within five seconds, all passenger doors will unlock. Pull the door handle to unlatch the door.


7 (Vehicle Locator/Panic Alarm) : Press and release one time to initiate vehicle locator. The exterior lamps flash and the horn chirps three times. Press and hold 7 for at least three seconds to sound the panic alarm. The horn sounds and the turn signals flash for about 30 seconds until 7 is pressed again or the vehicle is started. / (Remote Vehicle Start) : If equipped, press Q and release and then immediately press and hold / for at least four seconds to start the engine from outside the vehicle using the RKE transmitter. See Remote Vehicle Start 0 35. If equipped with a keyed ignition, the RKE transmitter buttons will not operate when the key is in the ignition. Keyless Access Operation Some vehicles have the Keyless Access system that lets you lock and unlock the doors and access the trunk without removing the RKE


Driver Side Shown, Passenger


Similar


Pressing the lock/unlock button will cause all doors to lock if any of the following occur:


It has been more than five seconds since the first lock/ unlock button press.


. Two lock/unlock button presses


were used to unlock all doors. . Any vehicle door has opened and all doors are now closed.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


32


Keys, Doors, and Windows


Keyless Unlocking/Locking from Passenger Doors When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the door handle, pressing the lock/unlock button on that door handle will unlock all doors. Pressing the lock/unlock button will cause all doors to lock if any of the following occur: . The lock/unlock button was used


to unlock all doors.


. Any vehicle door has opened and all doors are now closed.


Passive Locking If equipped with Keyless Access, the vehicle will lock several seconds after all doors are closed if the vehicle is off and at least one transmitter has been removed or none remain in the vehicle. If other electronic devices interfere with the RKE transmitter signal, the vehicle may not detect the RKE transmitter inside the vehicle. If passive locking is enabled, the doors may lock with the RKE


transmitter inside the vehicle. Do not leave the RKE transmitter in an unattended vehicle. Temporarily Disable Passive Locking Feature Temporarily disable the locking feature by pressing and holding K on the door for several seconds with a door open. Passive locking will then remain disabled until Q is pressed, or until the vehicle is turned on. To customize whether the doors automatically lock when you exit the vehicle, see Vehicle Personalization 0 138. Keyless Trunk Opening Press the touch pad on the trunk lid to open the trunk if the RKE transmitter is within 1 m (3 ft) of the trunk. Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a


replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Any remaining transmitters will need to be reprogrammed. Each vehicle can have up to eight transmitters matched to it.


Programming with a Recognized Transmitter (Key Vehicles Only) To program a new key: 1.


Insert the original, already programmed key in the ignition and turn the key to the ON/ RUN position.


2. Turn the key to LOCK/OFF,


3.


and remove the key. Insert the new key to be programmed and turn it to the ON/RUN position within five seconds. The security light will turn off once the key has been programmed.


4. Repeat Steps 1–3 if additional


keys are to be programmed.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Keys, Doors, and Windows


33


If a key is lost or damaged, see your dealer to have a new key made.


Programming without a Recognized Transmitter (Key Vehicles Only) Program a new key to the vehicle when a recognized key is not available. Canadian regulations require that owners see their dealer. If there are no currently recognized keys available, follow this procedure to program the first key. This procedure will take approximately 30 minutes to complete for the first key. The vehicle must be off and all of the keys you wish to program must be with you. 1.


Insert the new vehicle key into the ignition.


2. Turn to ON/RUN. The security


light will come on.


3. Wait 10 minutes until the


security light turns off.


4. Turn the ignition to LOCK/OFF.


5. Repeat Steps 2–4 two more


times. After the third time, turn to ON/RUN; the key is learned and all previously known keys will no longer work with the vehicle.


Remaining keys can be learned by following the procedure in “Programming with a Recognized Transmitter.”


Programming with a Recognized Transmitter (Keyless Access Vehicles Only) A new transmitter can be programmed to the vehicle when there is one recognized transmitter. To program, the vehicle must be off and at least one currently recognized transmitter and all new transmitters, must be with you. 1. Place the recognized


transmitter(s) in the cupholder. 2. Remove the key lock cylinder


cap. See Door Locks 0 37. Then insert the vehicle key into the key lock cylinder on the driver door handle and turn the


key, counterclockwise, to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays READY FOR REMOTE #2, 3, 4 or 5.


3. Place the new transmitter into


the transmitter pocket. The transmitter pocket is inside the center console storage area.


4. Press the ENGINE START/


STOP button. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


34


Keys, Doors, and Windows


5. Remove the transmitter from


the transmitter pocket and press K. To program additional transmitters, repeat Steps 3–5. When all additional transmitters are programmed, press and hold the ENGINE START/ STOP button for 12 seconds to exit programming mode.


Programming without a Recognized Transmitter (Keyless Access Vehicles Only) If there are no currently recognized transmitters available, follow this procedure to program up to eight transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters you wish to program must be with you. 1. Remove the key lock cylinder


cap. See Door Locks 0 37. Then insert the vehicle key into the key lock cylinder on the driver door handle and turn the


key, counterclockwise, to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays REMOTE LEARN PENDING, PLEASE WAIT.


2. Wait for 10 minutes until the


DIC displays PRESS ENGINE START BUTTON TO LEARN and then press the ENGINE START/STOP button. The DIC displays will again show REMOTE LEARN PENDING, PLEASE WAIT.


3. Repeat Step 2 two additional times. After the third time, all previously known transmitters will no longer work with the vehicle. Remaining transmitters can be relearned during the next steps. The DIC display should now show READY FOR REMOTE # 1.


4. Place the new transmitter into


the transmitter pocket. The transmitter pocket is inside the center console storage area.


5. Press the ENGINE START/


STOP button. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter. 6. Remove the transmitter from


the transmitter pocket and press K. To program additional transmitters, repeat Steps 4–6. When all additional transmitters are programmed, press and hold the ENGINE START/ STOP button for 12 seconds to exit programming mode.


Starting the Vehicle with a Low Transmitter Battery or Wireless Interference If the transmitter battery is weak or there is wireless interference, the DIC may display NO REMOTE DETECTED or PLACE TRANSMITTER IN POCKET TO


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


Keys, Doors, and Windows


35


Replace the transmitter battery as soon as possible. Battery Replacement Replace the battery if the DIC indicates that battery replacement is necessary. See Key and Lock Messages 0 133.


Caution


When replacing the battery, do not touch any of the circuitry on the transmitter. Static from your body could damage the transmitter.


The battery is not rechargeable. To replace the battery: 1. Press the button on the


transmitter to extend the key blade.


START when you try to start the vehicle. The REPLACE BATTERY IN REMOTE KEY message may also be displayed at this time. To start the vehicle:


1. Open the center console and


place the transmitter in the transmitter pocket with the buttons facing the front of the vehicle.


2. With the vehicle in P (Park) or


N (Neutral), press the brake pedal and press the ENGINE START/STOP button. See Starting the Engine 0 204.


2. Remove the battery cover by


prying it with a finger.


3. Remove the battery by pushing


4.


on the battery and sliding it toward the key blade. Insert the new battery, positive side facing up. Push the battery down until it is held in place. Replace with a CR2032
or equivalent battery.


5. Snap the battery cover back on


to the transmitter.


Remote Vehicle Start This feature allows the engine to be started from outside the vehicle.


Chevrolet Impala Owner Manual (GMNA-Localizing-U.S/Canada-9086448) - 2016 - CRC - 5/20/15


36


Keys, Doors, and Windows


/ (Remote Vehicle Start) : This button will be on the RKE transmitter if the vehicle has remote start. The climate control system will use the previous settings during a remote start. The rear window defogger may come on during a remote start based on cold ambient conditions. The rear defog indicator light does not come on during a remote start. If the vehicle has heated and/or ventilated seats, they may come on during a remote start. See Heated and Ventilated Front Seats 0 60. Laws in some local communities may restrict the use of remote starters. For example, some laws require a person using remote start to have the vehicle in view. Check local regulations for any requirements. Other conditions can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System 0 30.


Starting the Vehicle To start the engine using the remote start feature: 1. Aim the RKE transmitter at the


vehicle.


2. Press and release Q. 3.


Immediately after completing Step 2, press and hold / for at least four seconds or until the turn signal lamps flash. The turn signal lamps flashing confirms the request to remote start the vehicle has been received.


When the engine starts, the parking lamps will turn on and remain on as long as the engine is running. The doors will be locked and the climate control system may come on. The engine will continue to run for 10 minutes. After 30 seconds, repeat the steps if a 10-minute extension is desired. Remote start can be extended only once.


To drive the vehicle, turn the ignition to ON/RUN for Key Access vehicles, or press the brake pedal and the ENGINE START/STOP button for Keyless Access vehicles.


Extending Engine Run Time The engine run time can also be extended by another 10 minutes, if during the first 10 minutes Steps 1–3 are repeated while the engine is still running. An extension can be requested, 30 seconds after starting. This provides a total of 20 minutes. The remote start can only be extended once. When the remote start is extended, the second 10-minute period is added on to the first 10 minutes and the engine will run for a total of 20 minutes. A maximum of two remote starts, or a remote start with an extension, is allowed between ignition cycles. The vehicle's ignition must be changed to ON/RUN/START and

Loading...
x
