1998 Chevrolet Camaro Owners Manual

I Supplement to the 1998 Chevrolet Camaro Owner’s Manual

This information is in addition to the “Removing the Spare Ere and Tools” located in Section 5 on page 28 and “Storing a Flat or Spare Tire and Tools” portion located in Section 5 on page 37 in your owner’s manual. Removing the Spare Tire and Tools On convertible models, you must also remove the trunk access panel. It’s at the upper back of the trunk. Turn the two screw knobs under the trunk edge a quarter turn counterclockwise to remove the panel.

Part No. 98CAM002

Storing a Flat or Spare Tire and Tools

Replace the jack, wheel wrench and flat tire using the storage instructions. When you replace the trim panel, be sure to tuck it under the weatherstrip. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12.

Trim Panel Bolt Cover Jack Wing, Nut Adapter Compact Spare Tire Full-Size Tire Carpet Flap Tire Storage Bolt Trunk Access Panel (Convertible Only) Knob

NOTE: For Convertible only, remove trunk access panel by turning two knobs before removing spare tire. For Coupe model, be sure trim panel is positioned under weather stripping.

NOTICE:

Tire must fit in molded area to avoid damaging glass when closing hatch/trunk.

NOTES

Supplement to the 1998 Chevy Camaro and Pontiac Firebird Owner’s Manuals

This is a correction to the ‘%lorsepower” information listed under “Capacities and Specifications” in the rear “Quick Guide” pages of the owner’s manual.

Camaro only:

Horsepower

V6 200 @ 5200 rpm V8 305 @ 5200 rpm V8-SS 320 @ 5200 rpm

Firebird only:

Horsepower

V6 200 @ 5200 rpm V8 305 @ 5200 rpm V8-WS6 320 @ 5200 rpm

Part Number 98CAM/FIR001

I

I Tr

'I o set the clock, press ana nola 1 and hold MN until the correct minuw

PS and

0 The 1998 Chevrolet Camaro Owner’s Manual

1-1

2-1

3-1

4-1

5-1

6-1

7-1

8-1

9-1

Seats and Restraint Systems This section tells you how to use your seats and safety belts properly. It also explains the air bag system. Features and Controls This section explains how to start and operate your vehicle. Comfort Controls and Audio Systems This section tells you how to adjust the ventilation and comfort controls and how to operate your audio system. Your Driving and the Road Here you’ll find helpful information and tips about the road and how to drive under different conditions. Problems on the Road This section tells what to do if you have a problem while driving, such as a flat tire Service and Appearance Care Here the manual tells you how to keep your vehicle running properly and looking good. Maintenance Schedule This section tells you when to perform vehicle maintenance and what fluids and lubricants to use. Customer Assistance Information This section tells you how to contact Chevrolet for assistance and how to get service and owner publications. It also gives you information on “Reporting Safety Defects” on page 8- 10. Index Here’s an alphabetical listing of almost every subject in this manual. You can use it to quickly find something you want to read.

or overheated engine, etc.

GENERAL MOTORS, GM, the GM Emblem, CHEVROLET, the CHEVROLET Emblem and the name CAMARO are registered trademarks of General Motors Corporation. This manual includes the latest information at the time it was printed. We reserve the right to make changes in the product after that time without further notice. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division whenever it appears in this manual. Please keep this manual in your vehicle, so it will be there if you ever need it when you’re on the road. If you sell the vehicle, please leave this manual in it so the new owner can use it.

We support voluntary technician certification.

WE SUPPORT

VOLUNTARY TECHNICIAN CERTIFICATION THROUGH

National Institute for

A U T O M O T I V E

S E R V I C E

E X C E L L E N C E

For Canadian Owners Who Prefer a French Language Manual: Aux propriktaires canadiens: Vous pouvez vous procurer un exemplaire de ce guide en frangais chez votre concessionaire ou au:

DGN Marketing Services Ltd. 1500 Bonhill Rd. Mississauga, Ontario L5T 1C7

Litho in U.S.A. Part No. 10284871 A First Edition

@Copyright General Motors Corporation 1997

All Rights Reserved

The Heritage of Chevrolet

The dynamic William C. “Billy” Durant shifed gears from making carriages to making cars, forming half the team that gave birth to Chevrole;

._I,

Louis Chevrolet, the other half of the team, at the wheel of his experimental “Classic Six, ” which entered production in I91 2. That year 2999 vehicles were produced.

p " " " " " ~ ~ " " ~ ~ ' " ~ ~ - ~ ~ ~ ~ ~ '

'I

The Chevrolet blend of

created for the pleasure of the

value and performance has open road. become an American tradition -- whether bred for the racetrack like the legendary Corvette and Camaro, or

Every decade, Chevrolet

has reinforced its heritage

of affordable performance with quality and value crafted

into each vehicle. It's not surprising that for 80 years "Genuine Chevrolet" has been America's automobile.

We're proud to continue that

heritage in your Chevrolet,

, r ! r . .. &-*.6 .~ & : t i ::

e $

In 1932 Chevrolet introduced the Synchro-Mesh transmission and ofSered a host of accessories -- including such niceties as a clock!

iv

The legacy of America S favorite sportscar began in 1953, when 319 hand-assembled white Corvettes launched first use of a fiberglass body in a production cal: - - ' - ' ' ' ' ' ' ' ' 1

the

I

60 S automotive excitement included Chevrolet landmarks like the Corvette Sting Ray, the sporty Camaro, and powerplants like the legendary 327 V8.

The 1957 Chevy started a romance with the American public -- and was powered by an available fuel-injected V8.

Your new Chevrolet continues a tradition of quality and value.

_ _

How to Use this Manual Many people read their owner’s manual from beginning to end when they first receive their new vehicle. If you do this, it will help you learn about the features and controls for your vehicle. In this manual, you’ll find that pictures and words work together to explain things quickly. Index A good place to look for what you need is the Index in back of the manual. It’s an alphabetical list of what’s in the manual, and the page number where you’ll find it. Safety Warnings and Symbols You will find a number of safety cautions in this book. We use a box and the word CAUTION to tell you about things that could hurt you if you were to ignore the warning.

These mean there is something that could hurt you or other people.

In the caution area, we tell you what the hazard is. Then we tell you what to do to help avoid or reduce the hazard. Please read these cautions. If you don’t, you or others could be hurt.

You will also find a circle with a slash through it in this book. This safety symbol means “Don’t,’’ “Don’t do this’’ or “Don’t let this happen.”

vi

Vehicle Damage Warnings Also, in this book you will find these notices:

I NOTICE:

These mean there is something that could damage your vehicle.

In the notice area, we tell you about something that can damage your vehicle. Many times, this damage would not be covered by your warranty, and it could be costly. But the notice will tell you what to do to help avoid the damage. When you read other manuals, you might see CAUTION and NOTICE warnings in different colors or in different words. You’ll also see warning labels on your vehicle. They use the same words, CAUTION or NOTICE.

vii

Vehicle Symbols These are some of the symbols you may find on your vehicle.

For example, these symbols are used on an original battery:

These symbols are important for you and your passengers whenever your vehicle is driven:

UNLOCK IziI

FASTEN SEAT BELTS

These symbols have to do with your lamps:

These symbols are on some of your controls:

WINDSHIELD WIPER

WINDSHIELD DEFROSTER

TURN SIGNALS

PAMNpZ pf

HAZARD WARNING FLASHER

,111,

FOG LAMPS

WINDOW DEFOGGER

$0

VENTILATING FAN

CAUTION POSSIBLE INJURY

PROTECT EYES BY SHIELDING

CAUSTIC BAllERY ACID COULD CAUSE BURNS

AVOID SPARKS OR FLAMES

SPARK OR FLAME COULD EXPLODE BATTERY

viii

Here are some other symbols you may see:

These symbols are used on warning and indicator lights:

CHARGING 1-1

COOLANT TEMP

BAllERY

SYSTEM

FUSE

LIGHTER rl (0) HORN )cr SPEAKER Ez e,

FUEL

BRAKE

COOLANT

ENGINE OIL PRESSURE

ANTI-LOCK (@)

BRAKES

Section 1 Seats and Restraint Systems

Here you’ll find information about the seats in your Chevrolet and how to use your safety belts properly. You can also learn about some things you should not do with air bags and safety belts.

1-2 1-6 1-11

1-12 1- 12 1-19 1-20 1-20

Seats and Controls Safety Belts: They’re for Everyone Here are Questions Many People Ask About Safety Belts-- and the Answers How to Wear Safety Belts Properly Driver Position Safety Belt Use During Pregnancy Right Front Passenger Position Air Bag System

1-26 1-30 1-33 1-43 1-46 1-46 1-46

Rear Seat Passengers Children Child Restraints Larger Children Safety Belt Extender Checking Your Restraint Systems Replacing Restraint System Parts After a Crash

1-1

Seats and Seat Controls This section tells you about the seats -- how to adjust them, and also about reclining front seatbacks, seatback latches and the folding rear seatback. Manual Front Seat

A CAUTION:

You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you don’t want to. Adjust the driver’s seat only when the vehicle is not moving.

1-2

Move the lever under the passenger’s front seat to unlock it. Slide the seat to where you want it. Then release the lever and try to move the seat with your body to make sure the seat is locked into place. Be sure the lever returns to its original position after moving the seat.

4-Way Manual Seat

&Way Power Seat (If Equipped)

There are two levers at the front of the driver’s seat. The left lever adjusts the seat forward and rearward. The right lever adjusts the angle of the front of the seat. To adjust the seats forward and rearward, lift the lever under the left front of the seat. Slide the seat to where you want it. Then release the lever and try to move the seat with your body to make sure the seat is locked into place. To raise or lower the front of the seat, lift the right lever and lean forward or backward.

The driver’s seat has three controls on the left side. A: The front control makes the front of the seat go up and down. B: The back control makes the back of the seat go up and down. C: The center control makes the whole seat go up and down or forward and backward.

1-3

To adjust the seatback, lift the lever on the outer side of the seat. Release the lever to lock the seatback where you want it. Pull up on the lever, and the seat will go to its original upright position.

But don't have a seatback reclined if your vehicle is moving.

1-4

Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when you’re reclined like this. The shoulder belt can’t do its job, In a crash you could go into it, receiving neck or other injuries. The lap belt can’t do its job either. In a crash the belt could go up over your abdomen. The belt forces would be there, not at your pelvic bones. This could cause serious internal injuries. For proper protection when the vehicle is in motion, have the seatback upright. Then sit well back in the seat and wear your safety belt properly.

Front Seatback Latches

The front seatbacks fold forward to let people get into the back seat.

To fold a seatback forward, lift the latch located on the lower backside of the seatback. Then the seatback will fold forward. When you return the seatback to its original position, make sure the seatback is locked. The latch must be down for the seat to work properly.

If the seatback isn’t locked, it could move forward in a sudden stop or crash. That could cause injury to the person sitting there. Always press rearward on the seatback to be sure it is locked.

1-5

Folding Rear Seatback

The rear seatback in your vehicle folds down to provide more storage space. To fold the seatback down: 1. Pull forward on both levers. 2. Fold the seatback down. To raise the seatback: 1. Pull it up to the locked, upright position. 2. Be sure both latches hold the seatback in place. Have

them fixed if they don’t.

Safety Belts: They’re for Everyone This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts. And it explains the air bag system.

Don’t let anyone ride where he or she can’t wear a safety belt properly. If you are in a crash and you’re not wearing a safety belt, your injuries can be much worse. You can hit things inside the vehicle or be ejected from it. You can be seriously injured or killed. In the same crash, you might not be if you are buckled up. Always fasten your safety belt, and check that your passengers’ belts are fastened properly too.

I

In most states and Canadian provinces, the law says to wear safety belts. Here’s why: They work. You never know if you’ll be in a crash. If you do have a crash, you don’t know if it will be a bad one. A few crashes are mild, and some crashes can be so serious that even buckled up a person wouldn’t survive. But most crashes are in between. In many of them, people who buckle up can survive and sometimes walk away. Without belts they could have been badly hurt or killed. After more than 30 years of safety belts in vehicles, the facts are clear. In most crashes buckling up does matter ... a lot!

It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts. Be sure everyone in your vehicle is in a seat and using a safety belt properly.

4 Your vehicle has a light that

comes on as a reminder to buckle up. (See “Safety Belt Reminder Light” in the Index.)

1-7

Why Safety Belts Work When you ride in or on anything, you go as fast as it goes.

Take the simplest vehicle. Sumose it's just a seat on wheels.

Put someone on it.

1-8

r

...

Get it up to speed. Then stop the vehicle. The rider doesn't stop.

The person keeps going until stopped by something. In a real vehicle, it could be the windshield ...

1-9

3

or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense.

or the instrument panel ...

1-10

Q.’ If I’m a good driver, and I never drive far from

home, why should I wear safety belts?

A: You may be an excellent driver, but if you’re in an accident -- even one that isn’t your fault -- you and your passengers can be hurt. Being a good driver doesn’t protect you from things beyond your control, such as bad drivers. Most accidents occur within 25 miles (40 km) of home. And the greatest number of serious injuries and deaths occur at speeds of less than 40 mph (65 lunih). Safety belts are for everyone.

accident if I’m wearing a safety belt?

Here Are Questions Many People Ask About Safety Belts -- and the Answers e.’ Won’t I be trapped in the vehicle after an A: You could be -- whether you’re wearing a safety belt or not. But you can unbuckle a safety belt, even if you’re upside down. And your chance of being conscious during and after an accident, so you can unbuckle and get out, is much greater if you are belted.

&.’ If my vehicle has air bags, why should I have to A: Air bags are in many vehicles today and will be in

wear safety belts?

most of them in the future. But they are supplemental systems only; so they work with safety belts -- not instead of them. Every air bag system ever offered for sale has required the use of safety belts. Even if you’re in a vehicle that has air bags, you still have to buckle up to get the most protection. That’s true not only in frontal collisions, but especially in side and other collisions.

1-11

Lap-Shoulder Belt The driver has a lap-shoulder belt. Here’s how to wear it properly. 1. Close and lock the door. 2. Adjust the seat (to see how, see “Seats” in the Index)

so you can sit up straight.

How to Wear Safety Belts Properly Adults This part is only for people of adult size. Be aware that there are special things to know about safety belts and children. And there are different rules for smaller children and babies. If a child will be riding in your vehicle, see the part of this manual called “Children.” Follow those rules for everyone’s protection. First, you’ll want to know which restraint systems your vehicle has. We’ll start with the driver position. Driver Position This part describes the driver’s restraint system.

1-12

3.

4.

Pick up the latch plate and pull the belt across you. Don’t let it get twisted. On convertible models, the shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly. Push the latch plate into the buckle until it clicks.

If the belt stops before it reaches the buckle, tilt the latch plate and keep pulling until you can buckle the belt. Pull up on the latch plate to make sure it is secure. If the belt isn’t long enough, see “Safety Belt Extender” at the end of this section. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

1-13

5. To make the lap part tight, pull down on the buckle

end of the belt as you pull up on the shoulder belt.

The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen. This could cause serious or even fatal injuries. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The safety belt locks if there’s a sudden stop or crash. On convertible models, the safety belt also locks if you pull the belt very quickly out of the retractor.

Q." What's wrong with this?

CAUTION:

is You can be seriously hurt if your shoulder belt too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body.

A: The shoulder belt is too loose. It won't give nearly

as much protection this way.

1-15

What’s wrong with this?

CAUT IN:

You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen, The belt forces would be there, not at the pelvic bones, This could cause serious internal injuries. Always buckle your belt into the buckle nearest you,

~~

A: The belt is buckled in the wrong place.

1-16

@ What's wrong with this?

A: The shoulder belt is worn under the arm. It should

be worn over the shoulder at all times.

You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury. Also, the belt would apply too much force to the ribs, which aren't as strong as shoulder bones. You could also severely injure internal organs like your liver or spleen.

1-17

You can be seriously injured by a twisted belt. In a crash, you wouldn’t have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to fix it.

e.’ What’s wrong with this?

A: The belt is twisted across the body.

1-18

Safety Belt Use During Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts.

To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.

A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible, below the rounding, throughout the pregnancy.

1-19

to making

The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key safety belts effective is wearing them properly. Right Front Passenger Position The right front passenger’s safety belt works the same way as the driver’s safety belt. See “Driver Position” earlier in this section. Air Bag System This part explains the air bag system. Your vehicle has two air bags -- one air bag for the driver and another air bag for the right front passenger.

1-20

the air

Here are the most important things to know about bag system:

- - - A CAUTION: you aren’t wearing your safety belt -- even if you

You can be severely injured or killed in a crash if

have air bags. Wearing your safety belt during a crash helps reduce your chance of hitting things inside the vehicle or being ejected from it. Air bags are “supplemental restraints” to the safety belts. All air bags are designed to work with safety belts, but don’t replace them. Air bags are designed to work only in moderate to severe crashes where the front of your vehicle hits something. They aren’t designed to inflate at all in rollover, rear, side or low-speed frontal safety belt properly -- whether or not there’s an crashes. Everyone in your vehicle should wear a air bag for that person.

Air bags inflate with great force, faster than the blink of an eye. If you’re too close to an inflating air bag, it could seriously injure you. Safety belts help keep you in position before and during a crash. Always wear your safety belt, even with air bags. The driver should sit as far back as possible while still maintaining control of the vehicle.

Children who are up against, or very close to, an air bag when it inflates can be seriously injured or killed. Air bags plus lap-shoulder belts offer the best protection for adults and older children, but not for young children and infants. Neither the vehicle’s safety belt system nor its air bag system is designed for them. Young children and infants need the protection that a child restraint system can provide. Always secure children properly in your vehicle. To read how, see the part of this manual called “Children” and see the caution labels on the sunvisors and the right front passenger’s safety belt.

AIR BAG

There is an air bag readiness , light on the instrument panel, which shows AIR BAG.

1-21

The system checks the air bag electrical system for malfunctions. The light tells you if there is an electrical problem. See “Air Bag Readiness Light” in the Index for more information. How the Air Bag System Works

. ”

The right front passenger’s air bag is in the instrument panel on the passenger’s side.

Where are the air bags? The driver’s air bag is in the middle of the steering wheel. 1-22

If something is between an occupant and an air bag, the bag might not inflate properly or it might force the object into that person. The path of an inflating air bag must be kept clear. Don’t put anything between an occupant and an air bag, and don’t attach or put anything on the steering wheel hub or on or near any other air bag covering.

When should an air bag inflate? An air bag is designed to inflate in a moderate to severe frontal or near-frontal crash. The air bag will inflate only if the impact speed is above the system’s designed “threshold level.” If your vehicle goes straight into a wall that doesn’t move or deform, the threshold level is about 9 to 15 mph (14 to 24 k d h ) . The threshold level can vary, however, with specific vehicle design, so that

it can be somewhat above or below this range. If your vehicle strikes something that will move or deform, such as a parked car, the threshold level will be higher. The air bag is not designed to inflate in rollovers, side impacts or rear impacts, because inflation would not help the occupant. In any particular crash, no one can say whether an air bag should have inflated simply because of the damage to a vehicle or because of what the repair costs were. Inflation is determined by the angle of the impact and how quickly the vehicle slows down in frontal or near-frontal impacts. What makes an air bag inflate? In an impact of sufficient severity, the air bag sensing system detects that the vehicle is in a crash. The sensing system triggers a release of gas from the inflator, which inflates the air bag. The inflator, air bag and related hardware are all part of the air bag modules inside the steering wheel and in the instrument panel in front of the right front passenger.

1-23

How does an air bag restrain? In moderate to severe frontal or near-frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. Air bags supplement the protection provided by safety belts. Air bags distribute the force of the impact more evenly over the occupant’s upper body, stopping the occupant more gradually. But air bags would not help you in many types of collisions, including rollovers, rear impacts and side impacts, primarily because an occupant’s motion is not toward those air bags. Air bags should never be regarded as anythmg more than a supplement to safety belts, and then only in moderate to severe frontal or near-frontal collisions. What will you see after an air bag inflates? After an air bag inflates, it quickly deflates, so quickly that some people may not even realize the air bag inflated. Some components of the air bag module -- the steering wheel hub for the driver’s air bag, or the instrument panel for the right front passenger’s bag -- will be hot for a short time. The parts of the bag that come into contact with you may be warm, but not

too hot to touch. There will be some smoke and dust coming from vents in the deflated air bags. Air bag inflation doesn’t prevent the driver from seeing or from being able to steer the vehicle, nor does it stop people from leaving the vehicle.

When an air bag inflates, there is dust in the ai This dust could cause breathing problems for people with a history of asthma or other breathing trouble. To avoid this, everyone in the vehicle should get out as soon as it is safe to do so. If you have breathing problems but can’t get out of the vehicle after an air bag inflates, then get fresh air by opening a window or door.

1-24

In many crashes severe enough to inflate an air bag, windshields are broken by vehicle deformation. Additional windshield breakage may also occur from the right front passenger air bag.

Air bags are designed to inflate only once. After they inflate, you’ll need some new parts for your air bag system. If you don’t get them, the air bag system won’t be there to help protect you in another crash. A new system will include air bag modules and possibly other parts. The service manual for your vehicle covers the need to replace other parts. Your vehicle is equipped with a crash sensing and diagnostic module, which records infomation about the air bag system. The module records information about the readiness of the system, when the sensors are activated and driver’s safety belt usage at deployment. Let only qualified technicians work on your air bag system. Improper service can mean that your air bag system won’t work properly. See your dealer for service.

NOTICE:

If you damage the covering for the driver’s or the right front passenger’s air bag, the bag may not work properly. You may have to replace the air bag module in the steering wheel or both the air bag module and the instrument panel for the right front passenger’s air bag. Do not open or break the air bag coverings.

Servicing Your Air Bag-Equipped Vehicle Air bags affect how your vehicle should be serviced. There are parts of the air bag system in several places around your vehicle. You don’t want the system to inflate while someone is working on your vehicle. Your dealer and the Service Manual have information about servicing your vehicle and the air bag system. To purchase a service manual, see “Service and Owner Publications” in the Index.

1-25

For up to 10 minutes after the ignition key is turned off and the battery is disconnected, an air bag can still inflate during improper service. You can be injured if you are close to an air bag when it inflates. Avoid wires wrapped with yellow tape or yellow connectors. They are probably part of the air bag system. Be sure to follow proper service procedures, and make sure the person performing work for you is qualified to do so.

The air bag system does not need regular maintenance.

Rear Seat Passengers It’s very important for rear seat passengers to buckle up! in the rear Accident statistics show that unbelted people seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who aren I safety belted can be thrown out of the vehicle in a crash. And they can strike others in the vehicle who are wearing safety belts.

Lap-Shoulder Belt The rear seats have lap-shoulder belts. Here’s how to wear one properly.

1-26

1. Pick up the latch plate and pull the belt across you.

Don’t let it get twisted. On convertible models, the shoulder belt may lock if you pull the belt across you very quickly. If this happens, let the belt go back slightly to unlock it. Then pull the belt across you more slowly.

2. Push the latch plate into the buckle until it clicks.

If the belt stops before it reaches the buckle, tilt the latch plate and keep pulling until you can buckle it. Pull up on the latch plate to make sure it is secure. If the belt is not long enough, see “Safety Belt Extender” at the end of this section. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

1-27

3. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part.

The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen. This could cause serious or even fatal injuries. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces. The safety belt locks if there’s a sudden stop or a crash.

1-28

On convertible models, the safety belt also locks if you pull the belt very quickly out of the retractor.

You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body.

To unlatch the belt, just push the button on the buckle.

1-29

Smaller Children and Babies

' A 4UTION:

Children who are up against, or very close to, an air bag when it inflates can be seriously injured or killed. Air bags plus lap-shoulder belts offer the best protection for adults and older children, but not for young children and infants. Neither the vehicle's safety belt system nor its air bag system is designed for them. Young children and infants need the protection that a child restraint system can provide. Always secure children properly in your vehicle.

en

Ch Everyone in a vehicle needs protection! That includes infants and all children smaller than adult size. Neither the distance traveled nor the age and size of the traveler changes the need, for everyone, to use safety restraints. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.

1-30

‘ A CAUTION:

Smaller children and babies should always be restrained in a child or infant restraint. The instructions for the restraint will say whether it is the right type and size for your child. A very young child’s hip bones are so small that a regular belt might not stay low on the hips, as it should. Instead, the belt will likely be over the child’s abdomen. In a crash, the belt would apply force right on the child’s abdomen, which could cause serious or fatal injuries. So, be sure that any child small enough for one is always properly restrained in a child or infant restraint.

Infants need complete support, including support for the head and neck. This is necessary because an infant’s neck is weak and its head weighs so much compared with the rest of its body. In a crash, an infant in a rear-facing restraint settles into the restraint, so the crash forces can be distributed across the strongest part of the infant’s body, the back and shoulders. A baby should be secured in an appropriate infant restraint. This is so important that many hospitals today won’t release a newborn infant to its parents unless there is an infant restraint available for the baby’s first trip in a motor vehicle.

1-31

I

at only 25 mph (40 km/h), a 124b. (5.5 kg) baby will suddenly become a 2404b. (110 kg) force on your arms. The baby would be almost impossible to hold. Secure the baby in an infant restraint.

Never hold a baby in your arms while riding in a vehicle. A baby doesn’t weigh much -- until a crash. During a crash a baby will become so heavy you can’t hold it. For example, in a crash

CAUTION: (Continued)

1-32

Child Restraints Every time infants and young children ride in vehicles, they should have protection provided by appropriate restraints. @ What are the different types of add-on

child restraints?

A: Add-on child restraints are available in four basic types. When selecting a child restraint, take into consideration not only the child’s weight and size, but also whether or not the restraint will be compatible with the motor vehicle in which it will be used.

An infant car bed (A) is a special bed made for use in a motor vehicle. It’s an infant restraint system designed to restrain or position a child on a continuous flat surface. With an infant car bed, make sure that the infant’s head rests toward the center of the vehicle.

1-33

A rear-facing infant restraint (B) positions an infant to face the rear of the vehicle. Rear-facing infant restraints are designed for infants of up to about 20 lbs. (9 kg) and about one year of age. This type of restraint faces the rear so that the infant’s head, neck and body can have the support they need in a crash. Some infant seats come in two parts -- the base stays secured in the vehicle and the seat part is removable.

1-34

A forward-facing child restraint (C-E) positions a child upright to face forward in the vehicle. These forward-facing restraints are designed to help protect children who are from 20 to 40 lbs. (9 to 18 kg) and about 26 to 40 inches (66 to 102 cm) in height, or up to around four years of age. One type, a convertible restraint, is designed to be used either as a rear-facing infant seat or a forward-facing child seat.

1-35

A booster seat (F, G) is designed for children who are about 40 to 60 lbs. (18 to 27 kg) and about four to eight years of age. It’s designed to improve the fit of the vehicle’s safety belt system. Booster seats with shields use lap-only belts; however, booster seats without shields use lap-shoulder belts. Booster seats can also help a child out the window.

to see

1-36

When choosing a child restraint, be sure the child restraint is designed to be used in a vehicle. If it is, it will have a label saying that it meets Federal Motor Vehicle Safety Standards. Then follow the instructions for the restraint. You may find these instructions on the restraint itself or in a booklet, or both. These restraints use the belt system in your vehicle, but the child also has to be secured within the restraint to help reduce the chance of personal injury. The instructions that come with the infant or child restraint will show you how to do that. Both the owner’s manual and the child restraint instructions are important, so if either one of these is not available, obtain a replacement copy from the manufacturer. Where to Put the Restraint Accident statistics show that children are safer if they are restrained in the rear rather than the front seat. We at General Motors therefore recommend that you put your child restraint in the rear seat. Never put a rear-facing child restraint in the front passenger seat. Here’s why:

’ &% CAUTION:

I - A child in a rear-facing child restraint can be seriously injured if the right front passenger’s air bag inflates. This is because the back of a rearfacing child restraint would be very close to the inflating air bag. Always secure a rear-facing child restraint in the rear seat. You may, however, secure a forward-facing child restraint in the right front seat. Before you secure a forward-facing child restraint, always move the front passenger seat as far back as it will go. Or, secure the child restraint in the rear seat.

Wherever you install it, be sure to secure the child restraint properly. Keep in mind that an unsecured child restraint can move around in a collision or sudden stop and injure people in the vehicle. Be sure to properly secure any child restraint in your vehicle -- even when no child is in it.

1-37

Top Strap

If your child restraint has a top strap, it should be anchored. If you need to have an anchor installed, you can ask your Chevrolet dealer to put it in for you. If you want to install an anchor yourself, your dealer can tell you how to do it. If you have a convertible, don’t use a restraint that has a top strap in your vehicle because the top strap anchor cannot be installed properly.

The place where the anchor has to go is quite close to your fuel tank. If the anchor isn’t tank -- either then, or in a later collision. installed correctly, it can make a hole in the fuel Gasoline could leak out and be ignited, and people in the vehicle or outside it could be badly burned. Don’t install the anchor yourself unless you know you can do it correctly.

Canadian law requires that child restraints have a top strap, and that the strap be anchored. If your child restraint has a top strap, your dealer can obtain a kit with anchor hardware and installation instructions specifically designed for this vehicle. The dealer can then install the anchor for you. In Canada, this work will be done for you free of charge. Or, you may install the anchor yourself using the instructions provided in the kit.

Securing a Child Restraint in a Rear Seat Position

You’ll be using the lap-shoulder belt. See the earlier part about the top strap if the child restraint has one. Be sure to follow the instructions that came with the child restraint. Secure the child in the child restraint when and as the instructions say. 1. 2.

Put the restraint on the seat. Pick up the latch plate, and run the lap and shoulder portions of the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how.

3. Tilt the latch plate to adjust the belt if needed.

If the shoulder belt goes in front of the child’s face or neck, put it behind the child restraint.

1-39

4. Buckle the belt. Make sure the release button is

positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

5.

6.

To tighten the belt, pull up on the shoulder belt while you push down on the child restraint. If you’re using a forward-facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt. Push and pull the child restraint in different directions to be sure it is secure.

To remove the child restraint, just unbuckle the vehicle’s safety belt and let it go back all the way. The safety belt will move freely again and be ready to work for an adult or larger child passenger.

1-40

You’ll be using the lap-shoulder belt. See the earlier part about the top strap if the child restraint has one. Be sure to follow the instructions that came with the child restraint. Secure the child in the child restraint when and as the instructions say. 1. Because your vehicle has a right front passenger air bag, always move the seat as far back as it will go before securing a forward-facing child restraint. (See “Seats” in the Index.)

2. Put the restraint on the seat. 3. Pick up the latch plate, and run the lap and shoulder

portions of the vehicle’s safety belt through or around the restraint. The child restraint instructions will show you how.

Securing a Child Restraint in the Right Front Seat Position

Your vehicle has a right front passenger air bag. Never put a rear-facing child restraint in this seat. Here’s why:

A child in a rear-facing child restraint can be seriously injured if the right front passenger’s air bag inflates. This is because the back of a rearfacing child restraint would be very close to the inflating air bag. Always secure a rear-facing child restraint in the rear seat.

1-41

4. Tilt the latch plate to adjust the belt if needed.

If the shoulder belt goes in front of the child's face or neck, put it behind the child restraint.

5. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.

P

Larger Children

To tighten the belt, pull up on the shoulder belt while You Push down On the find it helpful to use your knee to push down on the child restraint as you tighten the belt. Push and pull the child restraint in different directions to be sure it is secure.

restraint. you

6.

7.

To remove the child restraint, just unbuckle the vehicle's safety belt and let it go back all the way. The safety belt will move freely again and be ready to work for an adult or larger child passenger.

Children who have outgrown child restraints should wear the vehicle's safety belts. Accident statistics show that children are safer if they are restrained in the rear seat. But they need to use the safety belts properly.

Children who aren't buckled up can be thrown out in a crash. Children who aren't buckled up can strike other people who are.

1-43

Never do this. Here two children are wearing the same belt. The belt can’t properly spread the impact forces. ’In a crash, the two children can be crushed together and seriously injured. A belt must be used by only one person at a time.

&= What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? Move the child toward the center of the vehicle, but be sure that the shoulder belt still is on the child’s shoulder, so that in a crash the child’s upper body would have the restraint that belts provide.

A:

I

‘ A CAUTION:

Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt. The belt’s force would then be applied right on the child’s abdomen. That could cause serious or fatal injuries.

Wherever the child sits, the lap portion of the belt should be worn low and snug on the hips, just touching ta - &e child’s the child’s thighs. This applies belt force pelvic bones in a crash.

.. .

1-45

Replacing Restraint System Parts After a Crash If you’ve had a crash, do you need new belts? After a very minor collision, nothing may be necessary. But if the belts were stretched, as they would be if worn during a more severe crash, then you need new belts. If belts are cut or damaged, replace them. Collision damage also may mean you will need to have safety belt or seat parts repaired or replaced. New parts and repairs may be necessary even if the belt wasn’t being used at the time of the collision. If an air bag inflates, you’ll need to replace air bag system parts. See the part on the air bag system earlier in this section.

Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender. It’s free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you. The extender will be just for you, and just for the seat in your vehicle that you choose. Don’t let someone else use it, and use it only for the seat it is made to fit. To wear it, just attach it to the regular safety belt. Checking Your Restraint Systems Now and then, make sure the safety belt reminder light and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired. Torn or frayed safety belts may not protect you in a crash. They can rip apart under impact forces. If a belt is torn or frayed, get a new one right away. Also look for any opened or broken air bag covers, and have them repaired or replaced. (The air bag system does not need regular maintenance.) 1-46

b% NOTES

1-47

1-48

0 Section 2 Features and Controls

Here you can learn about the many standard and optional features on your vehicle, and information on starting, shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is working properly -- and what to do if you have a problem.

2-2 2-4 2-7 2- 12 2- 13 2- 15

2-18 2-19 2-24 2-25 2-27 2-28 2-30

Keys Door Locks Keyless Entry (If Equipped) Hatch Theft Vehicle and Content Theft-DeterrenVAlarm System (If Equipped) PASS-Key@ I1 Feature Customization (if Equipped) New Vehicle “Break-In” Ignition Positions Starting Your Engine Engine Coolant Heater (Canada Only) Automatic Transmission Operation

2-34 2-37 2-39 2-4 1 2-4 1 2-43 2-43 2-44 2-45 2-50 2-52 2-54 2-72 2-75

Manual Transmission Operation Parking Brake Shifting Into PARK (P) Parking Over Things That Bum Engine Exhaust Shifting Out of PARK (P) Windows Tilt Steering Wheel Turn SignaVMultifunction Lever Exterior Lamps Interior Lamps Mirrors Instrument Panel Warning Lights, Gages and Indicators

2-1

Keys .A CAUTION:

Leaving young children in a vehicle with the ignition key is dangerous for many reasons. A child or others could be badly injured or even killed. They could operate power windows or other controls or even make the vehicle move. Don't leave the keys in a vehicle with young children.

2-2

The ignition keys are for the ignition only.

The ignition keys don’t have plugs. Instead, they have bar-coded key tags. These tags may be removed by your dealer or even before the vehicle is delivered to your dealer. Each plug has a code on it that tells your dealer or a qualified locksmith how to make extra door keys. Keep the plugs in a safe place. If you lose your door keys, you’ll be able to have new ones made using these plugs. If you need a new ignition key, go to your dealer, who can obtain the correct key code. In an emergency, call Chevrolet Roadside Assistance at 1 -800-CHEV-USA. (In Canada call 1-800-268-2800.)

I NOTICE:

The door keys are for the doors and all other locks.

When a new vehicle is delivered, the dealer removes the plugs from the keys, and gives them to the first owner.

Your vehicle has a number of features that can help prevent theft. But you can have a lot of trouble getting into your vehicle if you ever lock your keys inside. You may even have to damage your vehicle to get in. So be sure you have extra keys.

2-3

Door Locks

Unlocked doors can be dangerous.

Passengers -- especially children -- can easily

open the doors and fall out. When a door is locked, the inside handle won’t open it. Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. This may not be so obvious: You increase the chance of being thrown out of the vehicle in a crash if the doors aren’t locked. Wear safety belts properly, lock your doors, and you will be far better off whenever you drive your vehicle.

(If your vehicle has From the outside, use your door key. the Vehicle and Content Theft-DeterrentlAlarm System and it is armed, unlocking and opening a door this way will set off the alarm. See “Vehicle and Content Theft-DeterrenVAlarm System” in the Index.)

There are several ways to lock and unlock your vehicle.

2-4

U

From the inside, to lock the door, move the lock control on the door backward. To unlock the door, move the lock control on the door forward.

Power Door Locks (If Equipped)

Press the power door lock switch to lock or unlock both doors at once. Note: Operating the power locks may affect the Vehicle and Content Theft-DeterrenUAlarm System (if you have this option). See “Vehicle and Content Theft-Deterrent /Alarm System” in the Index. The lock switch works at all times, except during “Lockout Prevention” (if that feature is programmed). The unlock switch only works in RUN, ACC and RAP. (See “Retained Accessory Power” in the Index.)

2-5

Last Door Closed Locking (If Equipped) If you have power door locks, you can program your vehicle to have a delayed locking of the doors. This lets you or your passengers exit the vehicle after you’ve pressed the power door lock switch. All the doors will lock once everyone has gotten out of the vehicle and closed their doors.. When the power door lock switch is pressed, a chime will sound three times, indicating that the Last Door Closed Locking feature has been activated. Pressing the LOCK switch again will lock the doors immediately. Pressing the UNLOCK switch will cancel a previously requested Last Door Closed Locking. This feature is shipped from the factory with the ignition position in OFF. To turn this feature on, see “Feature Customization” in the Index.

Lockout Prevention (If Equipped) To protect you from locking your keys in the vehicle, this feature stops the power door locks from locking when the keys are in the ignition and a door is open. If the power lock switch is pressed when a door is open, a chime will sound five times as a reminder to take the keys out of the ignition before locking the door. This feature is shipped from the factory with the ignition position in ON. If you would like to turn this feature off, see “Feature Customization” in the Index. Leaving Your Vehicle If you are leaving the vehicle, take your keys, open your door and set the locks from inside. Then get out and close the door.

2-6

Keyless Entry System (If Equipped) If your vehicle has this option, you can lock and unlock your doors or unlock your hatch from about 3 feet (1 m) up to 30 feet (9 m) away using the keyless entry transmitter supplied with your vehicle.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. Changes or modifications to this system by other than an authorized service facility could void authorization to use this equipment.

3-Button Transmitter

4-Button Transmitter

Your keyless entry system operates on a radio frequency subject to Federal Communications Commission (FCC) Rules and with Industry Canada.

2-7

This system has a range of about 3 feet (1 m) up to 30 feet (9 m). At times you may notice a decrease in range. This is normal for any keyless entry system. If the transmitter does not work or if you have to stand closer to your vehicle for the transmitter to work, try this:

Check to determine if battery replacement is necessary. See the instructions that follow. Check the distance. You may be too far from your vehicle. You may need to stand closer during rainy or snowy weather. Check the location. Other vehicles or objects may be blocking the signal. Take a few steps to the left or right, hold the transmitter higher, and try again. If you’re still having trouble, see your dealer or a qualified technician for service.

Operation The driver’s door will unlock automatically when UNLOCK is pressed. If UNLOCK is pressed again within five seconds, the passenger’s door will also is pressed. unlock. All doors will lock when LOCK The hatch will unlock when the button with the trunk symbol is pressed twice within five seconds, as long as the ignition is turned to OFF. If the ignition is on, the trunk button will only work if the transmission is in PARK (P) for an automatic transmission, or if the parking brake is. set on a manual transmission. The system will turn on the interior lamps for about 40 seconds (or until the ignition is turned to RUN), when you unlock the doors or hatch. The interior lamps will go off when you lock the doors. Operating the keyless entry transmitter may interact with the Vehicle and Content Theft-DeterrendAlarm System (if you have this option). See “Vehicle and Content Theft-DeterrendAlarm System’’ in the Index.

2-8

Alardanic Mode If your vehicle is equipped with the Vehicle and Content Theft-DeterrenVAlarm System, you will have a fourth button on your transmitter. This button is the panic button. If you are involved in a panic situation, press this button and your vehicle’s horn will sound and the headlamps will flash. This will draw needed attention to you and your vehicle. To turn this feature off, either push the panic button again or turn the ignition to the RUN position. Note: This feature will not work if your ignition is on or if the transmitter is 30 feet (9 m) or more away from your vehicle. Transmitter Range The range of your keyless entry system should be about 30 feet (9 m). At times you may notice a decrease in the range. This is normal for any keyless entry system. If the transmitter does not work, or you have to stand closer to your vehicle for the transmitter to work: 0 You may have to replace the battery in your transmitter.

See the instructions for battery replacement.

0 You may be too far from your vehicle. Check your

distance. You may have to stand closer to your vehicle in rain or snow. Check the location. Other vehicles or objects may be blocking the signal, Take a few steps to the right or left.

You may have to synchronize your transmitter to the receiver in your vehicle. See the instructions for synchronization.

0 You may have to match the transmitters to your

vehicle. See instructions. If none of the above apply, see your dealer or qualified technician for service.

Synchronization Synchronization may be necessary due to the security method used by the keyless entry system. The transmitter does not send the same signal twice to the receiver. The receiver will not respond to a signal it has been sent previously. This prevents anyone from recoding and playing back the signal from the transmitter. To resynchronize the transmitter with the receiver: 0 While standing close to your vehicle, at the same

time press and hold the LOCK and UNLOCK buttons on the transmitter for about eight seconds. The door locks should cycle and the parking lamps should flash to confirm synchronization. If this does not happen, you may need to replace the battery in your transmitter or match the transmitter to vour vehicle.

2 -9

Transmitter Verification (If Equipped) This feature provides feedback to the holder of the keyless entry transmitter that a command has been received by the keyless entry receiver. The parking lamps will flash on every lock and unlock command and the horn will sound only if the LOCK button is pressed twice within five seconds. This allows for silent operation of locking and unlocking, unless a confirming horn chirp is desired. Other options may be selected for this feature (see “Feature Customization” in the Index). Matching Transmitter(s) To Your Vehicle Each keyless entry transmitter is coded to prevent another transmitter from unlocking your vehicle. If a transmitter is lost or stolen, a replacement can be purchased through your dealer. Remember to bring any remaining transmitters with you when you go to your dealer. When the dealer matches the replacement transmitter to your vehicle, any remaining transmitters must also be matched. Once your dealer has coded the new transmitter, the lost transmitter will not unlock your vehicle. Each vehicle can have only four transmitters matched to it. Have each transmitter you intend to match ready for the next steps. To match transmitters to your vehicle: 1. Turn the ignition to RUN, then to OFF. This

will disarm the Vehicle and Content

Theft-DeterrenVAlann System (if your vehicle has this option).

2. Remove the RADIO fuse. This fuse is located in the

main fuse block which is located on the left side of your main instrument panel. When the fuse block is open the radio fuse is located on the lower right hand corner of your instrument panel. See “Fuses and Circuit Breakers’’ in the Index.

3. Turn the ignition from OFF to RUN three times quickly (within five seconds). The vehicle will respond by locking the doors, unlocking the driver’s doors and releasing the hatch. Your transmitter is now ready to match the vehicle.

4. Press and hold the LOCK and UNLOCK buttons on the first transmitter for 15 seconds. The vehicle will respond as in Step 3.

5. Repeat Step 4 for the remaining transmitters. 6. When you have finished matching all of your

transmitters, replace the RADIO fuse.

7. Check that all transmitters work by pressing

their buttons.

If the transmitters don’t work, or if you’d rather not match the transmitters yourself, see your dealer.

2-10

Battery Replacement Under normal use, the battery in your keyless entry transmitter should last about two years. You can tell the battery is weak if the transmitter won’t work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it’s probably time to change the battery. Use one battery, type CR2032, or a similar type.

NOTICE:

When replacing the battery, use care not to touch any of the circuitry. Static from your body transferred to these surfaces may damage the transmitter.

To replace the battery in the keyless entry transmitter: 1.

Carefully pry off the cover by inserting a dime (or similar object) in the slot between the covers and twist. Lift off the back cover. Remove and replace the battery. Use one battery, type CR2032, or a similar type. Put the new battery in printed side down. Replace the front cover. Make sure the cover is on tightly so water won’t get in. Check the transmitter operation. If the transmitter does not work after battery replacement, it may need to be resynchronized or matched to your vehicle. See “Synchronization” in the Index.

2. 3.

4.

5.

2-11

Hatch

Hatch Release

It can be dangerous to drive with the hatch open because carbon monoxide (CO) gas can come into your vehicle. You can’t see or smell CO. It can cause unconsciousness and even death. If you must drive with the hatch open or if electrical wiring or other cable connections must pass through the seal between the body and the hatch: 0 Make sure all windows are shut.

%rn the fan on your heating or cooling system to its highest speed with the setting on VENT. That will force outside air into your vehicle. See “Comfort Controls” in the Index. If you have air outlets on or under the instrument panel, open them all the way.

See ‘(Engine Exhaust’’ in the Index.

2-12

Your door key opens the hatch from the outside. If your vehicle has the Vehicle and Content Theft-DeterrendAlarm System and it is armed, use the transmitter, not the key to open the hatch or the alarm will sound.

Remote Hatch Release (If Equipped)

Press the switch under the lamp control below the instrument panel to unlock the hatch from inside your vehicle.

If you have an automatic transmission, your shift lever must be in PARK (P) or NEUTRAL (N) to use the switch. If you have a manual transmission and the ignition switch is in RUN, you must set the parking brake before you can use the switch. The switch only works when the ignition is in RUN, ACC or when RAP is present. (See “Retained Accessory Power” in the Index.)

I NOTICE:

If you put things in the hatchback area, be sure they won’t break the glass when you close it. Never slam the hatch down. You could break the glass or damage the defogger grid (if equipped).

On vehicles with the Vehicle and Content Theft-DeterrenUAlarm System: The hatch switch will not work while the system is armed. See “Vehicle and Content Theft-Deteuent/Alarm System” in the Index. Theft Vehicle theft is big business, especially in some cities. Although your vehicle has a number of theft-deterrent features, we know that nothing we put on it can make it impossible to steal. However, there are ways you can help.

2-13

Key in the Ignition If you leave your vehicle with the keys inside, it’s an easy target for joy riders or professional thieves -- so don’t do it. When you park your vehicle and open the driver’s door, you’ll hear a chime reminding you to remove your key from the ignition and take it with you. Always do this. Your steering wheel will be locked, and so will your ignition. If you have an automatic transmission, taking your key out also locks your transmission. And remember to lock the doors. Parking at Night Park in a lighted spot, close all windows and lock your vehicle. Remember to keep your valuables out of sight. Put them in a storage area, or take them with you.

Parking Lots If you park in a lot where someone will be watching your vehicle, it’s best to lock it up and take your keys. But what if you have to leave your ignition key?

If possible, park in a busy, well lit area. Put your valuables in a storage area, like your glove box. Be sure to close and lock the storage area. Close all windows. Lock the glove box. Lock all the doors except the driver’s. Then take the door key and keyless entry with you.

transmitter

2-14

Vehicle and Content Theft-DeterrenUAlarm System (If Equipped) If your vehicle has this option, it has a theft-deterrent alarm system. Once armed, the system will sound the horn and flash the parking lamps if the vehicle is broken into. Shock Sensor

Coupe

Convertible

The shock sensor is what triggers the alarm when it detects a blow to your vehicle. It is located over the right rear wheelhouse near the spare tire in the hatch area. There are two levels of alarms via the shock sensor: Two horn blasts and parking lamp flashes for non-threatening blows to the vehicle and a full two-minute alarm for harder blows to the vehicle. Its sensitivity can be adjusted if more or less sensitivity is desired. (Note: If sensitivity is increased too much, it may give false alarms caused by gusts of wind or other natural events that may shake the vehicle.) To adjust, remove the label covering the adjustment knob and adjust as desired. Turn to the right (clockwise) to increase sensitivity and turn to the left (counterclockwise) to decrease sensitivity. The shock sensor is ignored by the alarm system when the ignition is on, when the hatch is open, when the alarm is disarmed, when customized to be ignored and for five seconds after the horn sounds an alarm or chirp. The shock sensor is ignored after triggering three full alarms until the system is rearmed.

2-15

Arming the System

The alarm system can be armed to detect break-ins by locking your vehicle using the keyless entry or by locking the doors with the power door lock switch.

Passive arming is also available, if you would like the system to arm all by itself after the doors have been closed for a short time. When the system is armed, a red light will flash briefly once every two seconds. (Note: If you return to your vehicle and the red light is flashing two brief flashes every two seconds, the system is armed and the shock sensor had triggered a two minute alarm. If the red light is flashing three times every two seconds, the system is armed and there was an intrusion that sounded the alarm.) Horn chirps and parking lamp flashes can be set to your choice.

2-16

Keyless Entry Transmitter Locking If all the doors are closed, locking the vehicle with the transmitter will immediately arm the system. The horn will chirp twice and the parking lamps will flash, confirming that the system is armed. If any door is open when the transmitter LOCK button is pressed, the system goes into an armed wait mode, waiting for the doors to close. Once they are closed, the system will arm, the horn chirps twice and the parking lamps will flash. If the hatch is open or ajar at the time the system is arming, the horn will only chirp once.

Power Door Lock Switch Locking If any door is open when the power door lock switch is pressed, the system goes into an armed wait mode, waiting for the doors to close. Once they are closed, the system will arm and the parking lamps will flash. If both of the doors are closed when the lock switch is pressed, the system assumes you are inside the vehicle, so it will not arm. Note: Locking the doors by using the manual door locks will not arm the system.

Passive Arming If the ignition was just turned off and a door was opened, the system will arm six seconds after both doors are closed, whether or not you lock them. In all other cases, the system will wait 30 seconds after both doors are closed before arming, allowing you time to get into the vehicle and put the key in the ignition. The parking lamps will flash when the system arms. Passive arming is not enabled from the factory. Disarming the System There are two ways to disarm the system: 1. Press the UNLOCK button on the keyless entry transmitter. If the horn chirps two or three times when you unlock the car, the alarm sounded in your absence. Two chirps means that the shock sensor was set off and three chirps means hatch was opened.

that a door or the

2. Turn the ignition to RUN with the proper key. For more information on customizing the features mentioned here, see “Feature Customization” in the Index. ’Ibrning Off the Alarm If you started the alarm by pressing the panic button on the keyless entry transmitter, you must either push that

button again or turn the ignition switch to RUN to stop the alarm. If the alarm is sounding due to the shock sensor or a door or hatch opening, it can be turned off by either turning the ignition switch with a proper key inserted or by pressing any button on the keyless entry transmitter. If you use your keyless entry transmitter to silence the alarm, additional things will happen depending upon which button you press.

Pressing the UNLOCK button will turn the alarm off, unlock the driver’s door and disarm the system. Pressing the LOCK button will turn the alarm off, keep the doors locked and keep the system armed. Pressing the trunk symbol button will turn the alarm off and keep the system armed. A second push of the button (within five seconds) will unlock and disarm the hatch only. Pressing the panic button will turn the alarm off, keep the doors locked and keep the system armed. If the alarm is sounding because an incorrect ignition key was used, press any button on the keyless entry transmitter to turn the alarm off. The alarm will stop by itself after two minutes.

2-17

PASS-Key@ I1 1 Your vehicle is equipped

with the PASS-Key I1 (Personalized Automotive Security System) theft-deterrent system. PASS-Key I1 is a passive theft-deterrent system. It works when you insert or remove the key from the ignition.

PASS-Key I1 uses a resistor pellet in the ignition key that matches a decoder in your vehicle. When the PASS-Key I1 system senses that someone is using the wrong key, it shuts down the vehicle’s starter and fuel systems. For about three minutes, the starter won’t work and fuel won’t go to the engine. If someone tries to start your vehicle again or uses another key during this time, the vehicle will not start. This discourages someone from randomly trying different keys with different resistor pellets in an attempt to make a match.

2-18

The ignition key must be clean and dry before it’s inserted in the ignition or the engine may not start. If the engine does not start and the SECURITY light stays on when you try to start the vehicle, the key may be dirty or wet. Turn the ignition off. three minutes and try Clean and dry the key. Wait about again. The SECURITY light may remain on during this time. If the starter still won’t work, and the key appears to be clean and dry, wait about three minutes and try another ignition key. At this time, you may also want to check the fuses (see “Fuses and Circuit Breakers” in the Index). If the starter won’t work with the other key, your vehicle needs service. If your vehicle does start, the first ignition key may be faulty. See your dealer or a locksmith who can service the PASS-Key 11. If you accidentally use a key that has a damaged or missing resistor pellet, the starter won’t work. The SECURITY light will flash. But you don’t have to wait three minutes before trying another ignition key. See your dealer or a locksmith who can service the PASS-Key I1 to have a new key made.

If you’re ever driving and the SECURITY light comes on and stays on, you will be able to restart your engine if you turn it off. Your PASS-Key I1 system, however, is not working properly and must be serviced by your dealer. Your vehicle is not protected by the PASS-Key I1 system. If you lose or damage a PASS-Key I1 ignition key, see your dealer or a locksmith who can service PASS-Key I1 to have a new key made. In an emergency, call the Chevrolet Roadside Assistance Center at 1 -800-CHEV-USA (1 -800-243-8872). Feature Customization (If Equipped) Your vehicle’s locks and lighting systems can be programmed with several different features. The features you can program depend upon the options that came with your vehicle. The following list tells you the features that can be programmed. Listed next to each feature is the option you need to have on your vehicle in order to be able to program that particular feature. 0 Exit Lighting (available for all) 0 Delayed Illumination (available for all)

Last Door Closed Locking (if equipped with power door locks) Lockout Prevention (if equipped with power door locks) Keyless Entry Verification (if equipped with Vehicle and Content Theft-DeterrendAlarm System) Theft-Deterrent Arming Method (if equipped with Vehicle and Content Theft-DeterrenUAlarm System) Theft-Deterrent Arming Verification (if equipped with Vehicle and Content Theft-Deterrent/Alarm System) Driver’s Door Alarm Delay (if equipped with Vehicle and Content Theft-DeterrenUAlann System) Shock Sensor Enable (if equipped with Vehicle and Content Theft-DeterrendAlarm System)
