How to Use This Manual

How to Use This Manual

Many people read their owner’s manual from beginning to end when they first receive their new vehicle. This will help you learn about the features and controls for your vehicle. In this manual, you’ll find that pictures and words work together to explain things quickly. Index: A good place to look for what you need is the Index in back of the manual. It’s an alphabetical list of all that’s in the manual, and the page number where you’ll find it. Parts 1-8: Each part of this manual begins with a brief list of its contents, so you can often find at a glance if a part contains the information you want.

How to Use This Manual This part tells you how to use your manual and includes safety and vehicle damage warnings and symbols. Part 1: Seats & Safety Belts This part tells you how to use your seats and safety belts properly. Part 2: Features & Controls This part explains how to start and operate your Chevrolet. Part 3: Comfort Controls & Audio Systems This part tells you how to adjust the ventilation and comfort controls and how to operate your sound system.

Part 4: Your Driving and the Road Here you’ll find helpful information and tips about the road and how to drive under different conditions. Part 5: Problems on the Road This part tells you what to do if you have a problem while driving, such as a flat tire or engine overheating. Part 6: Service & Appearance Care Here the manual tells you how to keep your Chevrolet running properly and looking good. Part 7: Maintenance Schedule This part tells when to perform vehicle maintenance and what fluids and lubricants to use.

1

These mean there is something

- :hat could hurt you or other people.

Part 8: Customer Assistance Information This part includes important information about reporting safety defects and gives you details about the “Roadside Assistance” program. You will also find customer satisfaction phone numbers (including customer satisfaction numbers for the hearing and speech impaired), as well as the mediation/arbitration procedure. We’ve also included ordering information for service publications in this part.

Service Station Information This is a quick reference of service information. You can find it on the last page of this manual.

Safety Warnings and Symbols You will find a number of safety cautions in this book. We use yellow and the word CAUTION to tell you about things that could hurt you if you were to ignore the warning. In the yellow caution area, we tell you what the hazard is. Then we tell you what to do to help avoid or reduce the hazard. Please read these cautions. If you don’t, you or others could be hurt.

How to Use This Manual

Tou will also find a red circle with a lash through it in this book. This safety ymbol means “Don’t, ” “Don’t do lis,” or “Don’t let this happen.”

these

Vehicle Damage Warnings Also, in this book you will find blue notices, In the blue notice area, we tell you about something that can damage your vehicle. Many times, this damage would not be covered by your warranty, and it could be costly. But the notice will tell you what to do to help avoid the damage.

When you read other manuals, you might see CAUTION and NOTICE warnings in different colors or in different words. In this manual, we’ve used the familiar words and colors that Chevrolet has used for years. You’ll also see warning labels on your vehicle. They use the same colors, and the words CAUTION or NOTICE.

I

Vehicle Symbok These are some of the symbols you will find on your vehicle. For example, these symbols are used on an original battery:

These symbols are important for you and your passengers whenever your vehicle is driven:

Caution Possible Injury

Fasten Safety Belts

Hazard Warning Flasher

Protect Eyes by Shielding

Door LocWUnlock

Caustic Battery Acid Could Cause Burns

These symbols have to do with your lights:

Avoid Sparks or Flames

Sparks or Flame Could Explode Battery

Master Lighting Switch

Turn Signal Direction

Headlight High Beam

Parking Lights

Courtesy Lights

Fog Lights

p f

%O

9 . . .

How to Use This Manual

These symbols are on some of your controls:

These symbols are used on warning and indicator lights:

Windshield Wiper

Windshield Washer

Windshield Defroster

Rear Window Defogger

Ventilating Fan

Engine Coolant Temperature

9 0 -

Engine Oil Pressure

Battery Charging System El

Brake (Canada)

Fuel

Hood Release

Hatchback Release

Lighter

Anti-Lock Brake System (Canada)

Low Coolant h

Horn

Speaker

Here are some other symbols you may See:

p3

C H E V

O L

M A R

. .

0 W N E R ' S

M A N U A L

How to Use This Manual

These symbols are on some of your controls:

These symbols are used on warning and indicator lights:

Windshield Wiper

Windshield Washer

Windshield Defroster

Rear Window Defogger

Ventilating Fan

Engine Coolant Temperature

9 0 -

Engine Oil Pressure

Battery Charging System El

Brake (Canada)

Fuel

Hood Release

Hatchback Release

Lighter

Anti-Lock Brake System (Canada)

Low Coolant h

Horn

Speaker

Here are some other symbols you may See:

p3

Part 1 Seats & Safety Belts

H e r e YOU’II find information about the seats in your Chevrolet and how to use your safety belts properly . You can also learn about some things you should not do with safety belts .

Seats and Seat Controls .............................................. 12 Safety Belts: They’re for Everyone ..................................... 15 Why Safety Belts Work .............................................. 17 Here Are Questions Many People Ask about Safety Belts - and the Answers ... 19 Safety Belt Reminder Light ........................................... 20 How to Wear Safety Belts Properly ..................................... 21 Children .......................................................... 34 Child Restraints .................................................... 36 LargerChildren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Safety Belt Extender ................................................ 44 Checking Your Restraint Systems ...................................... 45 Replacing Safety Belts after a Crash .................................... 45

l l . . .

Seats & Safety Belts

Seats and Seat Controls This section tells you about the seats - how to adjust them, and also about reclining front seatbacks, seatback latches and the folding rear seatback.

Manual Front Seat Move the lever under the passenger's front seat to unlock it. Slide the seat to where you want it. Then release the lever and try to move the seat with your body, to make sure the seat is locked into place.

Four- Way Manual Seat To move the driver's seat forward or backward, lift the lever under the left front of the seat. To tilt the entire seat, lift the lever under the right front of the seat.

. 12

. . .

You can lose control of the h vehicle if you try to adjust a

manual driver's seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you don't want to. Adjust the driver's seat only when the vehicle is not moving.

Six- Way Power Seat ( o p m v ) The driver's seat has three controls on the left side. The front control makes the front of the seat go up and down. The back control makes the back of the seal go up and down. The center control makes the whole seat go up and down or forward and backward.

Reclining Front Seatbacks To adjust the seatback, lift the lever on the outer side of the seat. Release the lever to lock the seatback where you want it. Pull up on the lever, and the seat will go to its original upright position. But don't have the seatback reclined if your vehicle is moving.

Seats 8t Safety Belts

II

Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when

you’re reclined like this. The shoulder belt can’t do its job because it won’t be against your body. Instead, it will be in front of you. In a crash you could go into it, receiving neck or other injuries. The lap belt can’t do its job either. In a crash the belt could go up over your abdomen. The belt forces would be there, not at your pelvic bones. This could cause serious internal injuries. For proper protection when the vehicle is in motion, have the seatback upright. Then sit well back in the seat and wear your safety belt properly.

Front Seatback latches The front seatbacks fold forward to let people get into the back seat. To fold a seatback forward, push the seatback toward the rear as you lift this latch. Then the seatback will fold forward.

14

When you return the seatback to its original position, make sure the seatback is locked. The latch must be down for the seat to work properly. I CAUTlON: Fh it could move forward in a

If the seatback isn’t locked,

sudden stop or crash. That could cause injury to the person sitting there. Always press rearward on the seatback to be sure it is locked.

Safety Belts: They’re for Everyone

This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts. And it explains the Supplemental Inflatable Restraint, or “air bag” system.

Folding Rear Seatback The rear seatback in your Chevrolet folds down to provide more storage space. To fold the seatback down: 1. Pull forward on both levers. 2. Fold the seatback down. To raise the seatback: 1. Pull it up to the locked, upright

position.

2. Be sure both latches hold the seatback

in place. Have them fixed if they don’t.

1 5 . 9 .

Seats & Safety Belts

I bU u I IUIV.’

Don’t let anyone rid6 where h they can? wear a safety belt properIy. If YOU are in a crash and you’re not wearing a safety belt, your injuries can be much worse. You can hit things inside the vehicle or be ejected from it. You can be seriously injured or killed. In the same crash, you might not k if you are buckled up. Always fasten your safety belt, and check that your passengers” belts are fastened properly too.

This figure lights up when you turn the key to Run or Start when your safety belt isn‘t buckled, and you’ll hear a chime, too. It’s the reminder to buckle up. In many states and Canadian provinces, the law says to wear safety belts. Mere’s why: They work.

You never know if you’ll be in a crash. If you do have a crash, you don’t know if it will be a bad one. A few crashes are very mild. In them, you won‘t get hurt even if you’re not buckled up. And some crashes can be so serious, like being hit by a train, that even buckled up a person wouldn’t survive. But most crashes are in between. In many of them, people who buckle up can survive and sometimes walk away. Without belts they could be badly hurt or killed. After 25 years of safety belts in vehicles, the fxts are clear. In most crashes buckling up does matter ... a lot!

~. Why Safety Belts Work When you ride in or on anything, you go as fast as it goes. For example, if the bike is going IO mph (16 km/h), so is the child.

When the bike hits the block, it stops. But the child keeps going!

Take the simplest "car." Suppose it's just a seat on wheels.

Seats 8t Safety Belts

Put someone on it.

Get it up to speed. Then stop the "car." The rider doesn't stop.

The person keeps going until stopped by something. In a real vehicle, it could be the windshield ...

9 9 9 18

1

or the instrument panel ...

or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense.

Here Are Questions Many People Ask about Safety Belts - and the Answers

Q: Won’t I be trapped in the vehicle after an accident if I’m wearing a safety belt?

A: You could be - whether you’re

wearing a safety belt or not. But you can easily unbuckle a safety belt, even if you’re upside down. And your chance of being conscious during and after an accident, so you can unbuckle and get out, is much greater if you are belted.

Seats & Safety Belts

Safety Belt Reminder Light

When the key is turned to Run or Start, a light will come on for about eight seconds to remind people to fasten their safety belts. Unless the driver’s safety belt is buckled, a chime will also sound.

Q: Why don’t they just put in air bags so people won’t have to wear safety belts?

A: “Air bags,” or Supplemental Intlatable

Restraint systems, are in some vehicles today and will be in more of them in the future. But they are supplemental systems only - so they work with safety belts, not instead of them. Every “air bag” system ever offered for sale has required the use of safety belts. Even if you’re in a vehicle that has “air bags,” you still have to buckle up to get the most protection. That’s true not only in frontal collisions, but especially in side and other collisions.

Q: If I’m a good driver, and I never

drive far from home, why should I wear safety belts?

A: You may be an excellent driver, but if you’re in an accident - even one that isn’t your fault - you and your passengers can be hurt. Being a good driver doesn’t protect you from things beyond your control, such as bad drivers.

Most accidents occur within 25 miles (40 km) of home. And the greatest number of serious injuries and deaths occur at speeds of less than 40 mph (65 km/h). Safety belts are for everyone.

- - - 2 o

How to Wear Safety Belts Properly

Adults This section is only for people of adult size. 1 CAUTION: 11 A There are special things to A know about safety belts and children. And there are different rules for babies and smaller children. If a child will be riding in your Chevrolet, see the section after this one, called “Children.” Follow those rules for everyone’s protection.

First, you’ll want to know which restraint systems your vehicle has. We’ll start with the driver position. Driver Position This section describes the driver’s -%raint system.

Lap-Shoulder Belt The driver has a lap-shoulder belt. Here’s how to wear it properly. 1. Close and lock the door. 2. Adjust the seat (to see how, see

“Seats” in the Index) so you can sit up straight.

Seats 8t Safety Belts

3. Pick up the latch plate and pull the belt across you. Don’t let it get twisted.

4. Push the latch plate into the buckle

until it clicks. If the belt isn’t long enough, see “Safety Belt Extender’’ at the end of this section. Make sure the release button on the buckle faces upward or outward so you would be able to unbuckle it quickly if you ever had to.

5. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder belt.

If the shoulder belt is too tight, move the shoulder belt to the upper or lower guide loop. Choose the one that makes the shoulder belt more comfortable.

r

Q: What’s wrong with this? A: The shoulder belt is too loose. It won’t

give nearly as much protection this way.

The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force tc the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen. This could cause serious or even fatal injuries. shoulder belt should go over the shoulder I I - lur shoulder belt is too loose. and across the chest. These parts of the In a &ash you would move forward body are best able to take belt restraining forces. The safety belt locks if stop or crash.

hurt if I I too much, which could increase your

II CAUTION: You can be seriously

injury. The shoulder belt should fit against

body. there’s a sudden

The

Q: What’s wrong with this? A: The belt is buckled in the wrong

place.

if

A You can be seriously injured L your belt is buckled in the

wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones. This could cause serious internal injuries. Always buckle your belt into the buckle nearest you.

Selts & 9 f e t y Belts

Q: What’s wrong with this? A: The shoulder belt is worn under the

arm. It should be worn over the shoulder at all times.

Q: What’s wrong with this? A: The belt is twisted across the body.

P A I I T l n N ~ A You can be seriously q u r e a 11

&-

you wear the shoulder belt under your arm. In a crash, your body would move too far fo-rward, increase the chance of which would head and neck injury. would apply too much force to the as strong as ribs, which aren’t shoulder bones. You could also severely injure internal organs like

your liver

or spleen.

’r, You can be seriously injured by Also, the belt - a twisted belt. In a crash, you wouldn-t have the full width of the If a belt belt to spread impact forces. is twisted, make it straight so it can work properly, or ask your dealer to fix it.

AN AIR BAG. -

YOU NEED YOUR ! AND HERE’S WHY:

ELT, EVEN W

To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.

Supplemental Inflatable Restraint System (Air Bags) This section explains the Supplemental Inflatable Restraint (SIR), or “air bag,” system. Your Chevrolet has an air bag for both the driver and the right-front passenger.

~~

Here’s the most important thing to know: I A Even with an air bag, if you’re - L not wearing a safety belt and you’re in a crash, your injuries may be much worse. Air bags are not designed to inflate in rollovers or in rear, side or low-speed frontal crashes. You need to wear your safety belt to reduce the chance of hitting things inside the vehicle or being ejected from it. Always wear your safety belt, even with an air

2 5 . - -

Seats & Safety Belts

A m r Dags inflate wltn great

L force, faster than the blink of

ull eye. If you’re too close to an inflating air bag, it could seriously injure you. Safety belts help keep you in position for an air bag inflation in a crash. Always wear your safety belt, even with an air bag, and the driver should sit as far back as possible while still maintaining control of the vehicle.

An mtlating air bag can

L seriously injure small children. Always secure chiidren properly in your vehicle. To read how, see the “‘Children and Safety Belts” section of this manual, and read the caution label on the front-passenger’s safety belt.

Air Bag System Light There is an air bag readiness light on the instrument panel, which has AIR BAG on it. The system checks itself and the light tells you if there is a problem. You will see this light flash for a few seconds when you turn your ignition to Run or Start. Then the light should go out, which means the system is ready.

1

How the Air Rag System Works Where is the air bag? The driver’s air bag is in the middle of the steering wheel.

The right-front passenger’s air bag is located in the instrument panel on the passenger’s side.

If the air bag readiness light

b doesn’t come on when you start your vehicle, or stays on, or comes on when you are driving, your air bag system may not work properly. Have your vehicle serviced right away.

Seats & Safety Belts

When is an air bag expected to inflate? The air bag is designed to inflate in moderate to severe frontal or near-frontal crashes. The air bag will only inflate if the velocity of the impact is above the designed threshold level. When impacting straight into a wall that does not move or deform, the threshold level for most GM vehicles is between 9 and 14 mph (14 and 23 km/h). However, this velocity threshold depends on the vehicle design and may be several miles-per-hour faster or slower. In addition, this threshold velocity will be considerably higher if the vehicle strikes an object such as a parked car which will move and deform on impact. The air bag is also not designed to

inflate in rollovers, side impacts, or rear impacts where the inflation would provide no occupant protection benefit. In any particular crash, the determination of whether the air bag should have inflated cannot be based solely on the level of damage on the vehicle(s). Inflation is determined by the angle of the impact and the vehicle’s deceleration, of which vehicle damage is only one indication. Repair cost is not a good indicator of whether an air bag should have deployed.

What makes an air bag inflate? In a frontal or near-frontal impact of sufficient severity, sensors strategical located on the vehicle detect that the vehicle is suddenly stopping as a result of a crash. These sensors complete an electrical circuit, triggering a chemical reaction of the sodium azide sealed in the inflator. The reaction produces nitrogen gas, which inflates a cloth bag. The inflator, cloth bag, and related hardware are all part of the air bag inflator modules packed inside the steering wheel and in the instrument panel in front of the passenger.

How does an air bag restrain? [n moderate to severe frontal or near-frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. The air bag supplements the protection provided by safety belts. Air bags distribute the force of the impact more evenly over the occupant’s upper body, stopping the occupant more gradually. But air bags would not provide protection in many types of collisions, including rollovers and rear and side impacts, primarily because an occupant’s motion is not toward the air bag. Air bags should never be regarded as anything more than a supplement to safety belt protection in

moderate to severe frontal and near-frontal collisions. What will you see after an air bag inflation? After the air bag has inflated, it will then quickly deflate. This occurs so quickly that some people may not even realize that the air bag inflated. The air bag will not impede the driver’s vision or ability to steer the vehicle, nor will it hinder the occupants from exiting the vehicle. There will be small amounts of smoke coming from vents in the deflated air bags. Some components of the air bag module in the steering wheel hub for the driver’s air bag or the instrument panel for the passenger’s bag may be hot for a short

_._ .~

ime, but the portion of the bag that comes nto contact with you will not be hot to he touch. The nitrogen gas used to inflate he air bag will have vented into the Iassenger compartment, and the bag will Je deflated within seconds after the :ollision. Nitrogen makes up about 80% 3f the air we breathe and is not hazardous. As the nitrogen vents from the bag, small particles are also vented into the passenger compartment. In many crashes severe enough to inflate an air bag, windshields are broken by vehicle deformation. Additional windshield breakage may occur in vehicles with passenger air bags because the windshield acts as a reaction surface ~ for the inflating air bag.

.~~

2 9 - 9 .

Seats & Safety Belts

CAUTlON;

on’t attach anything to It

steering wheel pad.

:e

might injure thedriver if the air bag inflates. Don’t set anything on or attach anything to the instrument panel. It might injure the passenger if the air bag inflates. The air bags are designed to inflate only once. After they inflate, you’ll need some new parts for your air bag system. If you don’t get them, the air bag system won’t be there to help protect you in another crash. A new system will include air bag modules and possibly other parts. Let only qualified technicians work on you# air bag system. Improper service can mean that your air bag system won’t work properly. See your dealer for service. 30

-*

regular maintenance. Your Chevrolet dealer and the 1993 Camaro Service Manual have information about the air bag system, including repair or disposal.

I A For up to 2 minutes after the L ignition key is turned off and

the battery disconnected, an air bag can still inflate during improper service. You can be injured if you are close to an air bag when it inflates. Be sure to follow the proper service procedures.

may not work properly. You may have to replace both the air bag a

: instrument panel. Don’

%ak the air bag cover.

pen or

Servicing Your Chevrolet with the Air Bag System Please tell or remind anyone who works on your Chevrolet that it has the air bag system. There are parts of the air bag system in several places around your vehicle. You don’t want the system to inflate while someone is working on your vehicle. The air bag system does not need

When electrical work is done under the hood or inside your vehicle, the ignition should be in LOCK if possible. Avoid wires wrapped with yellow tape, or yellow connectors. They are probably part of the air bag system. Your vehicle has a driver’s air bag and a right-front passenger’s air bag. Both bags must be disconnected if the ignition has to be on for electrical work or if the steering column is to be disassembled. First, disconnect the driver’s air bag like this: 1. Turn off the ignition. 2. Remove the SIR (air bag) fuse.

(See “Fuses and Circuit Breakers” in the Index.)

3. Disconnect the yellow connector at the

base of the steering column.

After you follow this procedure for the jriver ’s air bag, then disconnect the right-front passenger’s air bag like this: 1. Remove the cover under the instrument

panel.

2. Disconnect the small yellow connector

below the glove box.

When the work is complete, if the air bag system was disconnected, be sure to reattach everything and replace the fuse before turning the ignition on. When you turn the ignition key on, be sure you see the air bag readiness light on the instrument panel. If you don’t see this lighl flash and then go out as usual, have your air bag system repaired.

Safety Belt Use dumg Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts. A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible throughout the pregnancy. The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key to making safety belts effective is wearing them properly.

31 = = =

Seats 8t Safety Belts

Passenger Positions Right Front Passenger Position The right front passenger’s safety belt works the same way as the driver’s safety belt. See “Driver Position,” earlier in this part.

1.

2.

Pick up the latch plate and pull the belt across you. Don’t let it get twisted. Push the latch plate into the buckle until it clicks.

Rear Seat Passengers It’s very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seal are hurt more often in crashes than those who are wearing safety belts. Rear passengers who aren’t safety belted can be thrown out of the vehicle in a crash. And they can strike others in the vehicle who are wearing safety belts. The rear seats have lap-shoulder belts. Here’s how to wear one properly.

> a i

r ’

If the belt stops before it reaches the buckle, tilt the latch plate and keep pulling until you can buckle it. If the belt is not long enough, see “Safety Belt Extender” at the end of this section. Make sure the release button on the buckle Paces upward or outward so you would be able to unbuckle it quickly if you ever had to.

3. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part.

The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you‘d be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen. This could cause serious or even fatal injuries. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.

33.

Seats & Safety Belts r

The safety belt locks if there's a sudden stop or a crash.

To unlatch the belt, just push the button on the buckle.

You can be seriously hurt if

1 4 your shoulder belt is too loose. I In a crash you would move forward I InJury. The shoulder belt should fit

3 much, which could increase

children

Everyone in a vehicle needs protection! That includes infants and all children smaller than adult size. In fact, the law in every state and Canadian province says children up to some age must be restrained while in a vehicle.

Smaller Children and Babies

Smaller children and babies should always be restrained in

a child or infant restraint. The instructions for the restraint will say whether it is the right type and size for your child. A very young child’s hip bones are so small that a regular h-lt might not stay low on the hips, uu it should. Instead, the belt will likely be over the child’s abdomen. In a crash the belt would apply force right on the child3 abdomen, which could cause serious or fatal injuries. So, be sure that any child small enough for one is always properly

itrained in a child or infant

ldraint.

A Never hold a baby in your arms while riding in a vehicle. A baby doesn’t

weigh much - until a crash. During a crash a baby will become so heavy you can’t hold it. For example, in a crash at only 25 mph (40 km/h>, a I2-pound (5.5 kg) baby will suddenly become a 240-pound ( I 10 kg) force on your arms. The baby would be almost impossible to hold. Secure the baby in an infant restraint.

I,

Seats & Safety Belts

CAUTION:

Child Restraints

Be sure to follow the instructions for the restraint. You may find these instructions on the restraint itself or in a booklet, or both. These restraints use the belt system in your vehicle, but the child also has to be secured within the restraint to help reduce the chance of personal injury. The instructions that come with the infant or child restraint will show you how to do that.

Where to Put the Restraint Accident statistics show that children are safer if they are restrained in the rear rather than the front seat. We at General Motors therefore recommend that you put your child restraint in the rear seat. If you are using a rear-facing child restraint, don’t put it in the front seat. Here’s why:

Wherever you install it. be sure to secure he child restraint properly.

CAUTION:

~~ A An unsecured child restraint can

move around in a collision or den stop and injure people

in the vehicle. Be sure to properly secure any child restraint in your vehicle - even when no child is in it.

Top Strap If your child restraint has a top strap, it should be anchored. If you need to have an anchor installed. you can ask your Chevrolet dealer to put it in for you. If you want to install an anchor yourself, your dealer can tell you how to do it.

to gd is quite close to your fuel

tam. If the anchor isn’t put in correctly, it can make a hole in the fuel tank - either then, or in a later collision. Gasoline could leak out and be ignited, and people in the vehicle or outside it could be badly burned. Don’t put in the anchor yourself unless you know you can do it correctly.

Seats & Safety Belts

Vehicles first sold in Canada have child restraint anchor bracket hardware in the glove box, along with instructions for installing it. This should be used only with a child restraint, and only to secure a child restraint at a rear seating position. An additional anchor bracket for a child restraint at the other rear seating position is available at Chevrolet dealerships in Canada.

Securing a Child Restraint in the Rear Seat You’ll be using the lap-shoulder belt. See the earlier section about the top strap if the child restraint has one. 1. Put the restraint on the seat. Follow

the instructions for the child restraint.

2. Secure the child in the child restraint

as the instructions say.

3. Pull out the vehicle’s safety belt and run the lap part through or around the restraint. The child restraint instructions will show you how. Tilt the latch plate to adjust the belt if needed. See if the shoulder belt would go in front of the child’s face or neck. If so, put it behind the child restraint.

I

4. Buckle the belt. Make sure the release

button faces upward or outward, so you'll be able to unbuckle it quickly if you ever need to.

5. To tighten the belt, pull up on the

shoulder belt while you push down on the child restraint.

6. Push and pull the child restraint

in different directions to be sure it is secure.

To remove the child restraint, just unbuckle the vehicle's safety belt and let it go back all the way. The safety belt will move freely again and be ready to work for an adult or larger child passenger.

Seats & Safety Belts

Securing a Child Restraint in the Right Front Seat Your vehicle has a right-front passenger’s air bag. NEVER put a rear-facing child restraint in this position. Here’s why:

* A rear-facing child restraint in 1 the front seat could be pushed into the seatback by the right-front passenger’s air bag if it inflates. A child in a rear-facing child restraint can be seriously injured if this happens. Always secure a

rr-facing child restraint in the rear

I I

atat.

99940

You’ll be using the lap-shoulder belt. See the earlier section about the top strap if the child restraint has one. You’ll need a safety locking clip to properly secure a child restraint in this position. You can get a locking clip where child restraints are sold, or from your Chevrolet dealer (GM Part No. 94844571). The locking clip must be the same as the one shown here.

Until you have this clip, secure a child restraint only in the rear seat. See the earlier section about securing a child restraint in the rear seat. Once you have the clip, follow these instructions: 1. Move the seat as far back as it will go

before securing a front-facing child restraint.

2. Put the restraint on the seat. Follow

the instructions for the child restraint.

3. Secure the child in the child restraint

as the instructions say.

4. Pull out the vehicle's safety belt and

run the lap part through or around the restraint. The child restraint instructions will show you how. See if the shoulder belt would go in front of the child's face or neck. If so, put it behind the child restraint.

5. Buckle the belt.

Make sure the release button faces upward or outward, so you'll be able to unbuckle it quickly if you ever need to.

A. Lap Belt Portion B. Latch Plate C. Buckle D. Shoulder Belt Portion E. Locking Clip

6. Then thread both lap and shoulder belt

portions through the locking clip.

Seats & Safety Belts

If a hocking clip is not used or is not installed properIy, the

wlld restraint may move or tip over when your vehicle turns or stops quickly. The child or others could be injured. When you secure a child restraint with a lap-shoulder belt, always thread both the lap and shoulder belt portions through a locking clip.

7. Push and pull the child restraint in different directions to be sure it is secure.

To remove the child restraint, just unbuckle the vehicle's safety belt and remove the locking clip. Let the safety belt go back all the way.

L restraint seat, a safety belt with When not used with a child a child restraint locking clip still I a crash. AIways remove the clip attached can cause serious injury in when you are not using it with a child restraint.

The safety belt will move freely again and be ready to work for an adult or larger child passenger.

Lurger Children

Children who have outgrown child restraints should wear the vehicle’s safety belts. Accident statistics show that children are safer if they are restrained in the rear seat. But they need to use the safety belts properly.

Children who aren’t buckled up can be thrown out in a crash.

Children who aren’t buckled up can strike other people who are.

r/nu I I V I V . \ Never do this. - Here two children are wearing the same belt. The belt can’t properly spread the impact forces. In a crash, the two children can be crushed together and seriously injured. A belt must be used by only one person at a time.

Seats & Safety Belts

Q. What if a child is wearing a

lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child's face or neck? A: Move the child toward the center of

the vehicle, but be sure that the shoulder belt still is on the child's shoulder, so that in a crash the child's upper body would have the restraint that belts provide,

II

' Never do this.

Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt. The belt's force would then be applied right on the child's abdomen. That could cause serious or fatal injuries.

Wherever the child sits, the lap portion 01 he belt should be worn low and snug on he hips, just touching the child's thighs. rhis applies belt force to the child's Jelvic bones in a crash.

Safety Belt Extender If the vehicle's safety belt will faten around you, you should use it. But ifa safety belt isn't long enough to fasten, your dealer will order you an extender. It's free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you. The extender will be -just for you, and just for the seat in your vehicle that you choose. Don't let someone else use it, and use it only for the seat it is made to fit. To wear it, just attach it to the regular safety belt.

Checking Your Restraint Systems

Vow and then, make sure all your belts, mckles, latch plates, retractors, Inchorages and reminder systems are working properly. Look for any loose ?arts or damage. If you see anything that night keep a restraint system from doing Its job, have it repaired.

Replacing Safety Belts after a Crash

if worn during

If you’ve had a crash, do you need new belts? After a very minor collision, nothing may be necessary. But if the belts were stretched, as they would be a more severe crash, then you need new belts. right If belts are cut or damaged, replace them. Collision damage also may mean you will have to have safety belt parts, like the retractor, replaced or anchorage locations repaired - even if the belt wasn’t being used at the time of the collision.

away.

Q: What’s wrong with A: The belt is torn.

this?

L/mu I I V l V , Torn or frayed belts may not IF can rip apart under impact forces. 1 protect you L a belt-is torn or frayed, get a new

in a crash. They

one

If

’

The model number on the replacement belt must be listed on the safety belt you want to replace.

Notes

Part 2 Features & Controls

H e r e you can learn about the many standard and optional features on your Chevrolet. and information on starting. shifting and braking . Also explained are the instrument panel and the warning systems that tell you if everything is working properly - and what to do if you have a problem .

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 .... DoorLocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Theft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 PASS-Key II@ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . New Vehicle "Break-In" 55 Ignitionswitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Starting Your Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Driving through Deep Standing Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Engine Block Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Automatic Transmission ManualTransmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Limited-Slip Rear Axle Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 EngineExhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 Tiltwheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . The Turn Signal/Headlight Beam Lever 77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 Operation of Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Interior Lights 86 Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 Twin Lift-off Roof Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Storage and Compartments Sunvisors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ashtray and Lighter 94 FloorMats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Instrument Panel and Cluster Warning Lights . Gages and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 47

Features & Controls

4 Keys

The ignition keys are for the ignition only.

The door keys are for the doors and a l l other locks.

Leaving young children in a

L vehicle with the ignition key is

dangerous for many reasons. A child or others could be badly injured or even killed. They could operate power windows other controls or even make the :hick move. Don't leave the keys 111 a vehicle with young children.

I or

I.

When a new Camaro is delivered, the dealer removes the plugs from the keys, and gives them to the first owner. However, the ignition key may not have a Plug.

If the ignition key doesn't have a plug, there will be a bar-coded key tag instead. Each plug or tag has a code on it that tells your dealer or a qualified locksmith how to make extra keys. Keep the plugs in a safe place. If you lose your keys, you'll be able to have new ones made easily using these plugs. If your ignition keys don't have plugs, go to your Chevrolet dealer for the correct key code if you need a new ignition key.

NOTICE: Your Chevrolet has a number of new features that can help prevent theft. But you can have a lot of trouble getting into your vehicle if you ever lock your keys inside. You may even have to darnage \'our vehicle to get in. So be s YOU have extra keys.

Features & Controls

Door Locks A Unlocked doors can be I CAUTION:

dangerous.

Passengers - especially children - can easily open the doors and fall out. When a door is locked, the inside handle won’t open it. Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. This may not be so obvious: You increase the chance of‘ being thrown out of the vehicle in a crash if the doors aren’t locked. Wear safety belts properly, lock your doors, and you will be far better off whenever you drive your vehicle.

I . . . 50

There are several ways to lock and unlock your vehicle: From the outside: Use your door key.

From the inside: To lock the door, move the lock control on the door back. To unlock the door. move the lock control on the door forward.

Hatch Release Your door key opens the hatch.

Power Door Locks (Option) Push the power door lock switch to lock or unlock both doors at once. The switch only works when the ignition switch is in Run or Acc, or when RAP is present. (See "Retained Accessory Power" in the Index.)

Leaving Your Vehicle If you are leaving the vehicle, take your keys, open your door and set the locks from inside. Then get out and close the door.

Remote Hatch Release (Option) Press the switch in your glove box to unlock the hatch from inside your vehicle. If you have an automatic transmission, your shift lever must be in P (Park) or N (Neutral) to use the switch. If you have a manual transmission and the ignition switch is in Run. you must set the parking brake before you can use the switch. The switch only works when Ihe ignition switch is in Run or Acc. or when RAP is present. (See "Retained Accessory Power" in the Index.)

Features & Controls

A It can be dangerous to drive

with the hatch open. Carbon monoxide (CO) gas can come into your vehicle. You can’t see or smell CO. It can cause unconsciousness and even death. If you must drive with the hatch open:

Make sure all other windows are shut. Turn the fan on your heating or cooling system to its highest speed with the setting on 9 . That will force outside air into your vehicle. See “Comfort Controls” in the Index. If you have air vents on or under the instrument panel, open them all the way.

NOTICE: you put things in the hatchback area, be sure they won’t break the glass when you close it. Never slam the hatch down. You could break thL glass or damage the defogper grid (if equipped).

- 9 . 5 2

Theft

Vehicle theft is big business, especially in some cities. Although your Chevrolet has a number of theft-deterrent features, we know that nothing we put on it can make it impossible to steal. However, there are ways you can help. Key in the ignition: If you walk away from your vehicle with the keys inside, it’s an easy target for joy riders or professional thieves - so don’t do it.

,I

When you park your Chevrolet and open the driver’s door, you’ll hear a tone reminding you to remove your key from the ignition and take it with you. Always do this. Your steering wheel will be locked, and so will your ignition. If you have an automatic transmission, taking your key out also locks your transmission. And remember to lock the doors. Parking at Night: Park in a lighted spot, close all windows and lock your vehicle. Remember to keep your valuables out of sight. Put them in a storage area, or take them with you.

Parking Lots: If you park in a lot where someone will be watching your vehicle, it’s best to lock it up and take your keys. But what if you have to leave your ignition key? What if you have to leave something valuable in your vehicle? 0 Put your valuables in a storage area,

like your glove box. 0 Lock the glove box. 0 Lock all the doors except the driver’s.

Then take the door key with you.

Your vehicle is equipped with the PASS-Key II@ (Personalized Automotive Security System) theft-deterrent system. PASS-Key II@ is a passive theft-deterrent system. This means you don’t have to do anything different to arm or disarm the system. It works when you insert or remove the ke from the PASS-Key I1 uses a resistor pellet in the ignition key that matches a decoder in your vehicle. When the PASS-Key II@ system senses that someone is using the wrong key, it shuts down the vehicle‘s starter and fuel systems. For about three minutes, the starter won’t work and fuel won’t go to

ignition.

5 3 -

Features & Controls

the engine. If someone tries to start your vehicle again or uses another key during this time, the vehicle will not start. This discourages someone from randomly trying different keys with different resistor pellets in an attempt to make a match. The ignition key must be clean and dry before it’s inserted in the ignition or the engine may not start. If the engine does not start and the SECURITY light stays on when you try to start the vehicle, the key may be dirty or wet. Turn the ignition off. Zlean and dry the key. Wait about three ninutes and try again. The SECURITY ight will remain on during this time. If

the starter still won’t work, and the key appears to be clean and dry, wait about three minutes and try the other ignition key. At this time, you may also want to check the fuses (see “Fuses and Circuit Breakers” in the Index). If the starter won’t work with the other key, your vehicle needs service. If your vehicle does start, the first ignition key may be faulty. See your Chevrolet dealer or a locksmith who can service the PASS-Key II@. [f you accidentally use a key that has a lamaged or missing resistor pellet, the ;tarter won’t work and the security light will flash. But you don’t have to wait hree minutes before trying one of the Ither ignition keys.

See your Chevrolet dealer or a locksmith who can service the PASS-Key II@ to have a new key made. If you’re ever driving and the SECURITY light comes on and stays on, you will be able to restart your en ine if you turn it off. Your PASS-Key I1 % ;ystem, however, is not working properly md must be serviced by your Chevrolet lealer. Your vehicle is not protected by :he PASS-Key 11’ system. :f you lose or damage a PASS-Key 11’ gnition key, see your Chevrolet lealer or a locksmith who can service ’ASS-Key 11’

to have a new key made.

Off (C): Unlocks the steering wheel, ignition and automatic transmission, but does not send electrical power to any accessories. Use this position if your vehicle must be pushed or towed. A warning tone will sound if you open the driver’s door when the ignition is in Off and the key is in the ignition. Run (D): Position to which the switch returns after you start your engine and release the switch. The switch stays in the Run position when the engine is running. But even when the engine is not running, you can use Run to operate your electrical power accessories and to display some instrument panel warning and indicator lights.

Features & Controls

Start (E): Starts the engine. When the engine starts, release the key. The ignition switch will return to Run for normal driving. Note that even if the engine is not running, Acc and Run allow you to operate your electrical accessories. such as the radio and ventilation fan.

Key Release Button: I 1 you have a manual transmission, your ignition lock has a key release button. You must press the button before you can take your key out of the ignition lock.

On manual transmission

1 vehicles, turning the key to LOCK will lock the steering column and result in a loss of ability to steer the vehicle. This could cause a collision. If you need to turn the engine off while the vehicle is moving, turn the key only to Off. Don't press the key release button while the vehicle is moving.

... 56

rn

it is all

in LOCK

NOTICE: If your key seems stuck and you can’t turn it, be sure the way in. If it is, then turn the steering wheel left and right whil you turn the key hard. But turn tt key only with your hand. Usir tool to force it could break the key or the ignition switch. If none of thi: works, then your vehicle n v A r service.

T i

ietained Accessory Power (RAP) f you have power door locks, your lehicle has a feature called Retained kcessory Power (RAP). With RAP your

power door locks, electric mirrors, power windows, audio system and remote hatch release will continue to work up to 10 minutes after the ignition key is turned to Off and neither door is opened. If a door is opened, the audio system and power windows will shut off. The power door locks, electric mirrors and remote hatch release will work until you shut the door. Once you have shut the door, these accessories will continue to work for approximately 35 seconds. After this time you will not be able to use these accessories until the next time you open a door or turn on the ignilion.

Starting Your Engine Automatic Transmission: Move your shift lever to P (Park) or N (Neutral). Your engine won’t start in any other position - that’s a safety feature. To restart when you’re already moving, use N (Neutral) only.

NOTICE: Don‘t try to shilt to P (Park) if your Chevrolet is moving. If you do, vou could damage the transmission, Shift to P (Park) o

Features & Controls

NOTICE:

Manual Transmission: Shift your gear selector to neutral and hold the clutch pedal to the floor while starting the engine. Your vehicle won’t start if the clutch pedal is not all the way down - that’s a safety feature. To start your V6 engine: 1. Don’t push the accelerator pedal

before starting your engine. In some other vehicles you might need to do this, but because of your vehicle’s computer systems, you don’t.

2. Turn your ignition key

to Start. When the engine starts, let go of the key. The idle speed will go down as your engine gets warm.

3. If your engine won’t start (or starts but

then stops), it could be flooded with too much gasoline. Try pushing your accelerator pedal all the way to the floor and holding it there as you hold the key in Start for about three seconds. If the vehicle starts briefly but then stops again, do the same thing, but this time keep the pedal down for five or six seconds. This clears the extra gasoline from the engine.

1.

2.

Don't push the accelerator pedal before starting your engine. In some other vehicles you might need to do this, but because of your vehicle's computer systems, you don't. Turn the ignition key to Start. When the engine starts, let go of the key. The idle speed will go down as your engine gets warm.

3. If it doesn't start within 10 seconds,

push the accelerator pedal all the way to the floor, while you hold the ignition key in Start. When the engine starts, let go of the key and let up on the accelerator pedal. Wait about 15 seconds between each try to help avoid draining your battery.

NOTICE: Holding your kev in Start for longer than 15 siconds at a time will cause your battery to be drained much sooner. And the excessive _ , ~ ~ _ _ _ ~- . beat can damage your starter motor.

. .~ ,........,.,.. .

..,." _...

,~~ "~~~

II

Features 8t Controls

When starting your engine in very cold weather (below 0°F or - I SOC), do this: 1. With your foot off the accelerator

pedal, turn the ignition key to Start and hold it there. When the engine starts, let go of the key. Use the accelerator pedal to maintain engine speed, if you have to, until your engine has run for a while.

2. If your engine still won’t start (or starts but then stops), it could be flooded with too much gasoline. Try pushing your accelerator pedal all the way to the floor and holding it there as you hold the key in Start for about three seconds. If the vehicle starts briefly but then stops again, do the same thing, but this time keep the pedal down for five or six seconds. This clears the extra gasoline from the engine.
