2016 Chevrolet Camaro Owners Manual

2k16_CS6_Chevrolet_Camaro_23161081A.ai 1 9/23/2015 11:32:18 AM 2k16_CS6_Chevrolet_Camaro_23161081A.ai 1 9/23/2015 11:32:18 AM

CM

MY

CY

CMY

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 26
Seats and Restraints . . . . . . . . . . . 48
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 90
Instruments and Controls . . . . . . . 92
Lighting . . . . . . . . . . . . . . . . . . . . . . . 144
Infotainment System . . . . . . . . . . 150
Climate Controls . . . . . . . . . . . . . . 178
Driving and Operating . . . . . . . . . 185
Vehicle Care . . . . . . . . . . . . . . . . . . 240
Service and Maintenance . . . . . 316
Technical Data . . . . . . . . . . . . . . . . 330
Customer Information . . . . . . . . . 334
Reporting Safety Defects . . . . . . 344
OnStar . . . . . . . . . . . . . . . . . . . . . . . . 348
Index . . . . . . . . . . . . . . . . . . . . 359

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Introduction

Introduction

The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CHEVROLET, the CHEVROLET Emblem, CAMARO, and the CAMARO Emblem are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division wherever it appears in this manual.

Litho in U.S.A. Part No. 23161081 A First Printing

This manual describes features that may or may not be on the vehicle because of optional equipment that was not purchased on the vehicle, model variants, country specifications, features/applications that may not be available in your region, or changes subsequent to the printing of this owner manual. Refer to the purchase documentation relating to your specific vehicle to confirm the features. Keep this manual in the vehicle for quick reference.

Canadian Vehicle Owners

Propriétaires Canadiens A French language manual can be obtained from your dealer, at www.helminc.com, or from: On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse suivante:

Helm, Incorporated Attention: Customer Service 47911 Halyard Drive Plymouth, MI 48170

Using this Manual To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found.

Danger, Warning, and Caution Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them.

{ Danger

Danger indicates a hazard with a high level of risk which will result in serious injury or death.

©2015 General Motors LLC. All Rights Reserved.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

{ Warning

Warning indicates a hazard that could result in injury or death.

Caution

Caution indicates a hazard that could result in property or vehicle damage.

A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.”

Symbols The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or

information relating to a specific component, control, message, gauge, or indicator. M : Shown when the owner manual has additional instructions or information. * : Shown when the service manual has additional instructions or information. 0 : Shown when there is more information on another page — “see page.”

Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the Index. 9 : Airbag Readiness Light # : Air Conditioning ! : Antilock Brake System (ABS) % : Audio Steering Wheel Controls or OnStar® (if equipped) $ : Brake System Warning Light " : Charging System

Introduction

I : Cruise Control ` : Do Not Puncture ^ : Do Not Service B : Engine Coolant Temperature O : Exterior Lamps _ : Flame/Fire Prohibited # : Fog Lamps . : Fuel Gauge + : Fuses 3 : Headlamp High/Low-Beam Changer j : LATCH System Child Restraints * : Malfunction Indicator Lamp : : Oil Pressure } : Power / : Remote Vehicle Start > : Safety Belt Reminders 7 : Tire Pressure Monitor d : Traction Control/StabiliTrak® a : Under Pressure M : Windshield Washer Fluid

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Introduction

2 NOTES

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

In Brief

In Brief

Instrument Panel

Instrument Panel . . . . . . . . . . . . . . . . 6

Initial Drive Information

Initial Drive Information . . . . . . . . . . 8
Remote Keyless Entry (RKE)

System . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Vehicle Start . . . . . . . . . . . 8
Door Locks . . . . . . . . . . . . . . . . . . . . . 9
Trunk Release . . . . . . . . . . . . . . . . . . 9
Windows . . . . . . . . . . . . . . . . . . . . . . . . 9
Seat Adjustment . . . . . . . . . . . . . . . 10
Memory Features . . . . . . . . . . . . . . 10
Heated and Ventilated Seats . . . 11
Head Restraint Adjustment . . . . 11
Safety Belts . . . . . . . . . . . . . . . . . . . . 11
Passenger Sensing System . . . 12
Mirror Adjustment . . . . . . . . . . . . . . 12
Steering Wheel Adjustment . . . . 13
Interior Lighting . . . . . . . . . . . . . . . . 13
Exterior Lighting . . . . . . . . . . . . . . . 13
Windshield Wiper/Washer . . . . . . 14
Climate Controls . . . . . . . . . . . . . . . 15
Transmission . . . . . . . . . . . . . . . . . . 16

Vehicle Features

Infotainment System . . . . . . . . . . . 17
Radio(s) . . . . . . . . . . . . . . . . . . . . . . . 18

Satellite Radio . . . . . . . . . . . . . . . . . 18
Portable Audio Devices . . . . . . . . 19
Bluetooth® . . . . . . . . . . . . . . . . . . . . . 19
Steering Wheel Controls . . . . . . . 19
Cruise Control . . . . . . . . . . . . . . . . . 20
Driver Information

Center (DIC) . . . . . . . . . . . . . . . . . 21
Lane Change Alert (LCA) . . . . . . 21
Rear Vision Camera (RVC) . . . . 21
Rear Cross Traffic Alert (RCTA)

System . . . . . . . . . . . . . . . . . . . . . . . 21
Parking Assist . . . . . . . . . . . . . . . . . 21
Power Outlets . . . . . . . . . . . . . . . . . 22
Universal Remote System . . . . . 22
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 22
Performance and Maintenance

Traction Control/Electronic

Stability Control . . . . . . . . . . . . . . 23
Tire Pressure Monitor . . . . . . . . . . 23
Engine Oil Life System . . . . . . . . 24
Car Wash Guidelines . . . . . . . . . . 24
Driving for Better Fuel

Economy . . . . . . . . . . . . . . . . . . . . . 24

Roadside Assistance

Program . . . . . . . . . . . . . . . . . . . . . . 25

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

In Brief

Instrument Panel

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

1. Air Vents 0 183. 2.

Instrument Panel Illumination Control 0 147.

3. Exterior Lamp Controls 0 144.

Turn Signal Lever. See Turn and Lane-Change Signals 0 146. Headlamp High/Low-Beam Changer 0 144.

10. Shift Lever. See Automatic

Transmission 0 209 or Manual Transmission 0 213. 11. Power Outlets 0 98. 12. Electric Parking Brake 0 216. 13. Traction Control/Electronic

Stability Control 0 219. Mode Control. See Driver Mode Control 0 221.

4. Tap Shift (If Equipped). See

14. Hazard Warning Flashers

In Brief

21. Data Link Connector (DLC)

(Out of View). See Malfunction Indicator Lamp (Check Engine Light) 0 112. Hood Release (Out of View). See Hood 0 242.

Manual Mode 0 211. Active Rev Match 0 215 (if Equipped). Instrument Cluster 0 101.

5. 6. Windshield Wiper/Washer 0 95. 7. 8. Light Sensor. See Automatic

Infotainment 0 150.

Headlamp System 0 145. 9. Automatic Climate Control

System 0 178 or Dual Automatic Climate Control System 0 181 (If Equipped). Heated and Ventilated Seats 0 11 (If Equipped).

0 146.

15. Steering Wheel Controls 0 94. 16. Audio Controls. See Steering

Wheel Controls 0 94.

17. Horn 0 95. 18. Steering Wheel Adjustment

0 93.

19. Cruise Control 0 226.

Heated Steering Wheel 0 95 (If Equipped).

20. Head-Up Display (HUD) 0 121

(If Equipped).

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

In Brief

Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual.

Remote Keyless Entry (RKE) System The RKE transmitter may be used to lock and unlock the doors from up to 60 m (197 ft) away from the vehicle.

Press and release 7 to initiate vehicle locator. Press and hold 7 for at least three seconds to sound the panic alarm. Press 7 again to cancel the panic alarm. See Keys 0 26 and Remote Keyless Entry (RKE) System Operation 0 27.

Remote Vehicle Start If equipped, the engine can be started from outside of the vehicle. Starting the Vehicle 1. Press and release Q on the

2.

RKE transmitter. Immediately press and hold / for at least four seconds or until the turn signal lamps flash.

3. Start the vehicle normally after

entering.

When the vehicle starts, the parking lamps will turn on. Remote start can be extended.

With Remote Start Shown

Press the key release button near the bottom of the transmitter to remove the key. The key can be used for all locks. Press K to unlock the driver door or all doors. Press Q to lock all doors. Lock and unlock feedback can be personalized. See Vehicle Personalization 0 133. Press X twice quickly to release the trunk.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Canceling a Remote Start To cancel a remote start, do one of the following: . Press and hold / until the

parking lamps turn off.

. Turn on the hazard warning

flashers.

. Turn the vehicle on and then off. See Remote Vehicle Start 0 33.

Door Locks To lock or unlock a door from the outside, press Q or K on the Remote Keyless Entry (RKE) transmitter or use the key in the door. The key lock cylinder is covered with a cap. See Door Locks 0 34. For Keyless Access, press the button on the door handle when the RKE transmitter is within 1 m (3 ft). See Remote Keyless Entry (RKE) System Operation 0 27.

In Brief

. Press the touch pad in the area

above the license plate after unlocking all doors.

See Trunk 0 38.

Windows

To lock or unlock a door from the inside, press Q or K on the power door lock switch. Pull once on a door handle to unlock it and again to open it. See Power Door Locks 0 36.

Trunk Release To open the trunk: . Press the trunk release button

on the lower portion of the driver door.

. Press X twice quickly on the

RKE transmitter.

The power window switches on the driver door control all windows. The window switch on the passenger door is only for that window. Press the switch to open the window. Pull the switch to close it. See Windows 0 43. The switches work when the ignition is in ON/RUN or ACC/ ACCESSORY, or in Retained

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

10

In Brief

Accessory Power (RAP). See Retained Accessory Power (RAP) 0 205.

Seat Adjustment

. Raise or lower the entire seat by

moving the entire horizontal control up or down.

See Power Seat Adjustment 0 49. Reclining Seatbacks

Memory Features

To adjust the seat: . Move the seat forward or

rearward by sliding the horizontal control forward or rearward.

. Raise or lower the front part of the seat cushion by moving the front of the horizontal control up or down.

To raise or recline the seatback, tilt the vertical control forward or rearward. See Reclining Seatbacks 0 50.

If equipped, the 1, 2 SET, and B (Exit) buttons on the driver door are used to manually store and recall memory settings for the driver seat, outside mirrors, and power tilt and telescoping steering column (if equipped). Automatic Memory Recall and/or Easy Exit Recall features may be enabled in the personalization menus to automatically recall positions stored to the 1, 2, and B buttons.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

and then the off setting. Three lights indicate the highest setting, and one light indicates the lowest. See Heated and Ventilated Front Seats 0 53.

Head Restraint Adjustment Do not drive until the head restraints for all occupants are installed and adjusted properly. To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position. See Head Restraints 0 49 and Power Seat Adjustment 0 49.

See Memory Seats 0 50 and Vehicle Personalization 0 133.

Heated and Ventilated Seats

If available, the engine must be running to operate. The heated and ventilated seat buttons are on the climate control panel. Press L or M to turn on the heated seat. A light indicates this feature is on. Press { or C to turn on the ventilated seat. A light indicates this feature is on. Press the button once for the highest setting. With each press of the button, the heated or ventilated seat will change to the next lower setting,

In Brief

11

Safety Belts

Refer to the following sections for important information on how to use safety belts properly: . Safety Belts 0 54. . How to Wear Safety Belts

Properly 0 55.

. Lap-Shoulder Belt 0 56. . Lower Anchors and Tethers for Children (LATCH System) 0 79.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

12

In Brief

Passenger Sensing System

United States

The passenger airbag status indicator lights are visible on the overhead console when the vehicle is started. See Passenger Airbag Status Indicator 0 111.

Mirror Adjustment

Exterior

Canada and Mexico

The passenger sensing system will turn off the front outboard passenger frontal airbag and knee airbag under certain conditions. No other airbag is affected by the passenger sensing system. See Passenger Sensing System 0 66.

To adjust each mirror: 1. Press } or | to select the

driver or passenger side mirror. The indicator light will illuminate.

2. Press the arrows on the control

pad to move the mirror in the desired position.

See Power Mirrors 0 42. Interior Adjust the inside rearview mirror for a clear view of the area behind your vehicle. If equipped, push the tab forward for daytime use and pull it rearward for nighttime use to avoid the glare of headlamps from behind. If equipped with an automatic dimming rearview mirror, the glare of the headlamps from behind is automatically reduced. The dimming feature comes on when the vehicle is started. See Interior Rearview Mirrors 0 43.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Steering Wheel Adjustment

Interior Lighting

Reading Lamps

In Brief

13

Exterior Lighting

The reading lamps are in the overhead console. The lamps go on when a door is opened. When the doors are closed, press m or n to turn on each lamp. For more information on interior lighting, see Instrument Panel Illumination Control 0 147.

To adjust the tilt and telescoping steering wheel: 1. Pull the lever down. 2. Move the steering wheel up

or down.

3. Pull or push the steering wheel

closer or away from you.

4. Pull the lever up to lock the

steering wheel in place.

Do not adjust the steering wheel while driving.

The exterior lamp control is on the left side of the steering wheel. There are four positions: P : Briefly turn to this position to turn the automatic light control off or on again. When released, the control returns to the AUTO position. AUTO : Automatically turns the exterior lamps on and off, depending on outside lighting. ; : Turns on the parking lamps including all lamps, except the headlamps. 5 : Turns on the headlamps together with the parking lamps and instrument panel lights.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

14

In Brief

See: . Exterior Lamp Controls 0 144. . Daytime Running Lamps (DRL)

0 145.

Windshield Wiper/Washer

The windshield wiper/washer lever is on the right side of the steering column. With the ignition in ACC/ ACCESSORY or ON/RUN, move the windshield wiper lever to select the wiper speed. HI : Use for fast wipes. LO : Use for slow wipes.

INT : Move the lever up to INT for intermittent wipes, then turn the x INT band up for more frequent wipes or down for less frequent wipes. OFF : Use to turn the wipers off. 1X : For a single wipe, briefly move the wiper lever down. For several wipes, hold the wiper lever down. n L : Pull the windshield wiper lever toward you to spray windshield washer fluid and activate the wipers. See Windshield Wiper/Washer 0 95.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Climate Controls

The heating, cooling, defrosting, and ventilation for the vehicle can be controlled with this system.

In Brief

15

Automatic Climate Control System

1. Temperature Control 2. Air Delivery Mode Controls 3. O (Power) 4. AUTO (Automatic Operation) 5. A/C (Air Conditioning)

6. Recirculation 7. Fan Control 8. Rear Window Defogger 9. Defrost

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

16

In Brief

Transmission

Dual Automatic Climate Control System

9. Defrost 10. Rear Window Defogger 11. Fan Control See Automatic Climate Control System 0 178 and Dual Automatic Climate Control System 0 181 (If Equipped).

1. Driver and Passenger Temperature Controls

2. Air Delivery Mode Controls 3. O (Power) 4. SYNC (Synchronized

Temperature)

5. AUTO (Automatic Operation) 6. A/C (Air Conditioning) 7. Recirculation 8. Driver and Passenger Heated

and Ventilated Seats (If Equipped)

Automatic Transmission

Tap Shift Tap Shift allows the driver to manually control the automatic transmission. To use Tap Shift, the shift lever must be in DSC Mode. Vehicles with this feature have indicators on the steering wheel. The paddles are on the back of the steering wheel. Tap the left paddle (-) to downshift, and the right paddle (+) to upshift. A Driver Information Center (DIC) display indicates the gear the vehicle is in.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

To use this feature: 1. Move the shift lever to

M (Manual Mode).

2. Tap the left paddle (-) or right paddle (+) paddle, to increase or decrease the gear range available.

See Manual Mode 0 211. Manual Transmission

One to Four Shift Message (V8 Only)

2 (Second). The message will be displayed in the Driver Information Center (DIC). See Manual Transmission 0 213.

Active Rev Match (V8 Only) Vehicles equipped with a V8 engine and manual transmission have Active Rev Match (ARM). ARM aids in smoother shifting by matching the engine speed to the next selected gear. It is activated and deactivated by pressing either of the paddles marked REV MATCH on the steering wheel. See Active Rev Match 0 215.

When this message comes on, you can only shift from 1 (First) to 4 (Fourth) instead of 1 (First) to

In Brief

17

Vehicle Features

Infotainment System Base radio information is included in this manual. See the infotainment manual for information on other available infotainment systems. Read the following pages to become familiar with these features.

{ Warning

Taking your eyes off the road for too long or too often while using any infotainment feature can cause a crash. You or others could be injured or killed. Do not give extended attention to infotainment tasks while driving. Limit your glances at the vehicle displays and focus your attention on driving. Use voice commands whenever possible.

The infotainment system has built-in features intended to help avoid distraction by disabling some functions when driving. These

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

18

In Brief

functions may gray out when they are unavailable. Many infotainment features are also available through the instrument cluster and steering wheel controls. Before driving: . Become familiar with the

operation, faceplate buttons, and screen buttons.

. Set up the audio by presetting

favorite stations, setting the tone, and adjusting the speakers.

. Set up phone numbers in

advance so they can be called easily by pressing a single button or by using a single voice command if equipped with Bluetooth phone capability. See Defensive Driving 0 186. To play the infotainment system with the ignition off, see Retained Accessory Power (RAP) 0 205.

Radio(s)

Radio with Touchscreen O : Press to turn the system on or mute the audio. Press and hold to turn the system off. Turn to increase or decrease the volume. g : Press and release to go to the previous station, channel, or track. Press and hold to fast seek the next track or strongest previous station or channel. d : Press and release to go to the next station, channel, or track. Press and hold to fast seek the next tract or strongest station or channel. Source : Touch to choose between available sources. Menu : Touch to choose between available menus. S or T : Touch to view saved favorite stations or channels. See Overview 0 152.

Satellite Radio If equipped, vehicles with a SiriusXM® satellite radio tuner and a valid SiriusXM satellite radio subscription can receive SiriusXM programming. SiriusXM Satellite Radio Service SiriusXM is a satellite radio service based in the 48 contiguous United States and 10 Canadian provinces. SiriusXM satellite radio has a wide variety of programming and commercial-free music, coast to coast, and in digital-quality sound. A fee is required to receive the SiriusXM service. Refer to: . www.siriusxm.com or call

1-866-635-2349 (U.S.). . www.xmradio.ca or call

1-877-209-0079 (Canada).

See Satellite Radio 0 155.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Steering Wheel Controls

In Brief

19

Portable Audio Devices This vehicle has a 3.5 mm (1/8 in) auxiliary input and two USB ports in the center console. External devices such as iPods®, MP3 players, and USB storage devices may be connected. See Auxiliary Devices 0 159 and USB Port 0 158.

Bluetooth® The Bluetooth® system allows users with a Bluetooth-enabled mobile phone to make and receive hands-free calls using the vehicle audio system and controls. The Bluetooth-enabled mobile phone must be paired with the in-vehicle Bluetooth system before it can be used in the vehicle. Not all phones will support all functions. See Bluetooth (Overview) 0 160 or Bluetooth (Infotainment Controls) 0 162.

If equipped, some audio controls can be adjusted at the steering wheel.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

20

In Brief

g (1) : Press to interact with Bluetooth or OnStar, if equipped. See Bluetooth (Overview) 0 160 or Bluetooth (Infotainment Controls) 0 162 or OnStar Overview 0 348. R (1) : Press to decline an incoming call or end a current call. Press to mute or unmute the infotainment system when not on a call. e + or e − (2) : Press to increase or decrease volume. R FAV or FAV Q (3) : Press to display a list of favorites. Press again to select the next or previous favorite when listening to the radio. See Steering Wheel Controls 0 94.

Cruise Control

Cruise Control without Heated

Steering Wheel

Cruise Control with Heated

Steering Wheel

1 : Press to turn the system on and off. A white indicator appears in the instrument cluster when cruise is turned on. * : If equipped, press to disengage cruise control without erasing the set speed from memory. RES+ : If there is a set speed in memory, press briefly to resume to that speed or hold upward to accelerate. If cruise control is already active, use to increase vehicle speed.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

SET− : Press briefly to set the speed and activate cruise control. If cruise control is already active, use to decrease speed. See Cruise Control 0 226.

Driver Information Center (DIC) The DIC display is in the instrument cluster. It shows the status of many vehicle systems.

w or x : Press to move up or down in a list.

o or p : Press o to open application menus on the left. Press p to open interaction menus on the right. SEL : Press to select a menu item. Press and hold to reset values on certain screens. See Driver Information Center (DIC) 0 119.

Lane Change Alert (LCA) If equipped, the LCA system is a lane-changing aid that assists drivers with avoiding lane change crashes that occur with moving vehicles in the side blind zone (or spot) areas or with vehicles rapidly approaching these areas from behind. The LCA warning display will light up in the corresponding outside side mirror and will flash if the turn signal is on. The Side Blind Zone Alert (SBZA) system is included as part of the LCA system. See Side Blind Zone Alert (SBZA) 0 232 and Lane Change Alert (LCA) 0 232.

In Brief

21

Rear Vision Camera (RVC) RVC displays a view of the area behind the vehicle on the center stack display when the vehicle is shifted into R (Reverse) to aid with parking and low-speed backing maneuvers. See Assistance Systems for Parking or Backing 0 230.

Rear Cross Traffic Alert (RCTA) System If equipped, the RCTA system uses a triangle with an arrow displayed on the RVC screen to warn of traffic behind your vehicle that may cross your vehicle's path while in R (Reverse). In addition, beeps will sound. See Assistance Systems for Parking or Backing 0 230.

Parking Assist If equipped, Rear Parking Assist (RPA) uses sensors on the rear bumper to assist with parking and

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

22

In Brief

avoiding objects while in R (Reverse). It operates at speeds less than 8 km/h (5 mph). RPA may display a warning triangle on the Rear Vision Camera screen and/or a graphic on the instrument cluster to provide the object distance. In addition, multiple beeps may occur if very close to an object. See Assistance Systems for Parking or Backing 0 230.

Power Outlets The vehicle has an accessory power outlet on the center floor console in front of the cupholders. It can be used to plug in electrical equipment, such as a cell phone or an MP3 player. The accessory power outlet does not work when the ignition is turned off and the driver door is opened. This helps to preserve the battery life of the vehicle. See Power Outlets 0 98.

Universal Remote System

If equipped, this system, in the overhead console, provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices. Read the instructions completely before attempting to program the Universal Remote system. Because of the steps involved, it may be helpful to have another person available to assist you with programming the Universal Remote system. See Universal Remote System 0 141.

Sunroof The ignition must be in ON/RUN, ACC/ACCESSORY, or Retained Accessory Power (RAP) to operate the sunroof. See Retained Accessory Power (RAP) 0 205. On vehicles with a sunroof, the switch is on the overhead console.

Open/Close : Press and hold e or g to open or close the sunroof.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Express-open : Press e to the second detent to express-open the sunroof. Vent : Press and release g to vent the sunroof. See Sunroof 0 46.

Performance and Maintenance

Traction Control/ Electronic Stability Control The Traction Control System (TCS) limits wheel spin. The system turns on automatically every time the vehicle is started. StabiliTrak assists with directional control of the vehicle in difficult driving conditions. The system turns on automatically every time the vehicle is started. . To turn off TCS, press and release Y on the console behind the shift lever. i illuminates.

. Press Y again to turn TCS

back on.

. To turn off both TCS and

StabiliTrak, press and hold Y on the console behind the shift lever until i and g illuminate.

In Brief

23

. Press Y again to turn on both

systems.

See Traction Control/Electronic Stability Control 0 219.

Tire Pressure Monitor This vehicle may have a Tire Pressure Monitor System (TPMS).

The low tire pressure warning light alerts to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and Loading Information label. See Vehicle Load Limits 0 196. The warning light will remain on until the tire pressure is corrected.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

24

In Brief

The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This may be an early indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure. The TPMS does not replace normal monthly tire maintenance. Maintain the correct tire pressures. See Tire Pressure Monitor System 0 283.

Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays the CHANGE ENGINE OIL SOON message when it is time to change the engine oil and filter. The oil life system should be reset to 100% only following an oil change.

Resetting the Oil Life System 1. Display the REMAINING OIL LIFE on the DIC. See Driver Information Center (DIC) 0 119.

2. Press and hold SEL on the DIC

while the Oil Life display is active. The oil life will change to 100%.

The oil life system can also be reset as follows: 1. Turn the ignition to ON/RUN

with the engine off.

2. Fully press and release the

accelerator pedal three times within five seconds.

See Engine Oil Life System 0 249.

Car Wash Guidelines

Caution

Some automatic car washes can cause damage to the vehicle, wheels and ground effects. Automatic car washes are not recommended, due to lack of clearance for the undercarriage and/or wide rear tires and wheels. See "Washing the Vehicle" under Exterior Care 0 306.

Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. . Avoid fast starts and accelerate

smoothly.

. Brake gradually and avoid

abrupt stops.

. Avoid idling the engine for long

periods of time.

. When road and weather

conditions are appropriate, use cruise control.

. Always follow posted speed

limits or drive more slowly when conditions require.

. Keep vehicle tires properly

inflated.

. Combine several trips into a

single trip.

. Replace the vehicle's tires with

the same TPC Spec number molded into the tire's sidewall near the size.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

In Brief

25

. Follow recommended scheduled

maintenance.

Roadside Assistance Program U.S.: 1-800-243-8872
TTY Users (U.S. Only): 1-888-889-2438
Canada: 1-800-268-6800
New Chevrolet owners are automatically enrolled in the Roadside Assistance Program. See Roadside Assistance Program 0 338.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Keys, Doors, and Windows

26
Keys, Doors, and Windows

Keys and Locks

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Remote Keyless Entry (RKE)

System . . . . . . . . . . . . . . . . . . . . . . . 27

Remote Keyless Entry (RKE)

System Operation . . . . . . . . . . . . 27
Remote Vehicle Start . . . . . . . . . . 33
Door Locks . . . . . . . . . . . . . . . . . . . . 34
Power Door Locks . . . . . . . . . . . . . 36
Delayed Locking . . . . . . . . . . . . . . . 36
Automatic Door Locks . . . . . . . . . 37
Lockout Protection . . . . . . . . . . . . . 37

Doors

Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Vehicle Security

Vehicle Security . . . . . . . . . . . . . . . . 39
Vehicle Alarm System . . . . . . . . . 39
Immobilizer . . . . . . . . . . . . . . . . . . . . 40
Immobilizer Operation . . . . . . . . . 40

Exterior Mirrors

Convex Mirrors . . . . . . . . . . . . . . . . 41
Power Mirrors . . . . . . . . . . . . . . . . . . 42
Heated Mirrors . . . . . . . . . . . . . . . . . 42

Automatic Dimming Mirror . . . . . 42
Reverse Tilt Mirrors . . . . . . . . . . . . 42

Interior Mirrors

Interior Rearview Mirrors . . . . . . . 43
Manual Rearview Mirror . . . . . . . . 43
Automatic Dimming Rearview

Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 43

Windows

Windows . . . . . . . . . . . . . . . . . . . . . . . 43
Power Windows . . . . . . . . . . . . . . . 44
Sun Visors . . . . . . . . . . . . . . . . . . . . . 45

Roof

Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 46

Keys and Locks

Keys

{ Warning

Leaving children in a vehicle with a Remote Keyless Entry (RKE) transmitter is dangerous and children or others could be seriously injured or killed. They could operate the power windows or other controls or make the vehicle move. The windows will function with the RKE transmitter in the vehicle, and children or others could be caught in the path of a closing window. Do not leave children in a vehicle with an RKE transmitter.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Keys, Doors, and Windows

27

. Check the transmitter's battery. See “Battery Replacement” later in this section. If the transmitter is still not working correctly, see your dealer or a qualified technician for service.

Remote Keyless Entry (RKE) System Operation The Keyless Access system allows for vehicle entry when the transmitter is within range. See “Keyless Access Operation” later in this section. The RKE transmitter may work up to 60 m (197 ft) away outside the vehicle. Other conditions can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System 0 27.

To remove the key, press the button on the side of the transmitter near the bottom, and pull the key out. Never pull the key out without pressing the button. See your dealer if a new key is needed. If locked out of the vehicle, see Roadside Assistance Program 0 338. With an active OnStar subscription, an OnStar Advisor may remotely unlock the vehicle. See OnStar Overview 0 348.

Remote Keyless Entry (RKE) System See Radio Frequency Statement 0 344. If there is a decrease in the RKE operating range: . Check the distance. The

transmitter may be too far from the vehicle.

. Check the location. Other vehicles or objects may be blocking the signal.

The key, inside the Remote Keyless Entry (RKE) transmitter, can be used for all locks.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

28

Keys, Doors, and Windows

Pressing Q may also arm the alarm system. See Vehicle Alarm System 0 39. K : Press to unlock the driver door or all doors. See Vehicle Personalization 0 133. The turn signal indicators may flash and/or the horn may sound to indicate unlocking. See Vehicle Personalization 0 133. Pressing K will disarm the alarm system. See Vehicle Alarm System 0 39. / : If equipped, press and release Q and then immediately press and hold / for at least four seconds to start the engine from outside the vehicle using the RKE transmitter. See Remote Vehicle Start 0 33. X : Press twice quickly to release the trunk. 7 : Press and release to initiate vehicle locator. The exterior lamps flash and the horn chirps three times.

Press and hold 7 for at least three seconds to sound the panic alarm. The horn sounds and the turn signals flash until 7 is pressed again or the ignition is placed in ON/ RUN/START. Keyless Access Operation The Keyless Access system lets you lock and unlock the doors and access the trunk without removing the RKE transmitter from your pocket, purse, briefcase, etc. The RKE transmitter should be within 1 m (3 ft) of the door or trunk being opened. If equipped, there will be buttons on the outside door handles. Keyless Access can be programmed to unlock all doors on the first lock/unlock press from the driver door. See Vehicle Personalization 0 133.

Keyless Unlocking/Locking from the Driver Door When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the driver door handle, pressing

With Remote Start Shown

Q : Press to lock all doors. The turn signal indicators may flash and/or the horn may sound to indicate locking. See Vehicle Personalization 0 133. If the passenger door is open when Q is pressed, all doors lock. If the driver door is open when Q is pressed, all doors lock and the driver door will immediately unlock, if enabled through vehicle personalization.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

the lock/unlock button on the driver door handle will unlock the driver door. If the lock/unlock button is pressed again within five seconds, the passenger door will unlock. Pull the door handle to unlatch the door.

Driver Side Shown, Passenger

Side Similar

Pressing the lock/unlock button will cause all doors to lock if any of the following occur:

It has been more than five seconds since the first lock/ unlock button press.

. Two lock/unlock button presses

were used to unlock all doors.

Keys, Doors, and Windows

29

. Any vehicle door has opened and all doors are now closed.

Keyless Unlocking/Locking from the Passenger Door When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the passenger door handle, pressing the lock/unlock button on the passenger door handle will unlock all doors. Pressing the lock/unlock button will cause all doors to lock if any of the following occur: . The lock/unlock button was used

to unlock all doors.

. Any vehicle door has opened and all doors are now closed.

Passive Locking With Keyless Access the vehicle will lock several seconds after all doors are closed if the vehicle is off and at least one transmitter has been removed or none remain in the vehicle. If other electronic devices interfere with the RKE transmitter signal, the vehicle may not detect the RKE

transmitter inside the vehicle. If passive locking is enabled, the doors may lock with the RKE transmitter inside the vehicle. Do not leave the RKE transmitter in an unattended vehicle. To customize the doors to automatically lock when exiting the vehicle, see “Remote Lock, Unlock, Start” under Vehicle Personalization 0 133.

Temporary Disable of the Passive Locking Feature Temporarily disable passive locking by pressing and holding K on the interior door switch with a door open for at least four seconds, or until three chimes are heard. Passive locking will then remain disabled until Q on the interior door is pressed, or until the vehicle is turned on.

Keyless Trunk Opening When the doors are locked, press the touch pad to open the trunk if the RKE transmitter is within 1 m (3 ft).

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

30

Keys, Doors, and Windows

Keyed Access To access a vehicle with a weak transmitter battery, see Door Locks 0 34. Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Any remaining transmitters will need to be reprogrammed. Each vehicle can have up to eight transmitters matched to it.

Programming with a Recognized Transmitter A new transmitter can be programmed to the vehicle when there is one recognized transmitter. To program, the vehicle must be off and all of the transmitters, both currently recognized and new, must be with you.

1. Place the recognized

transmitter(s) in the rear cupholder in the center console.

2. Remove the key lock cylinder cap on the driver door handle. See Door Locks 0 34. Insert the vehicle key of the new transmitter into the key lock cylinder on the driver door handle and turn the key to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays READY FOR REMOTE #2, 3, 4 or 5, 6,7, or 8

3. Replace the recognized

transmitter with a new transmitter. Place the new transmitter in the rear cupholder in the center console.

4. Press ENGINE START/STOP.

When the transmitter is learned, the DIC will show that it is ready to program the next transmitter.

5. Remove the transmitter from

the transmitter pocket and press K or Q. To program additional transmitters, repeat Steps 3–5.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Keys, Doors, and Windows

31

When all additional transmitters are programmed, press and hold ENGINE START/STOP for 12 seconds to exit programming mode.

6. Put the key back into the

transmitter.

Programming without a Recognized Transmitter If there are no currently recognized transmitters available, follow this procedure to program up to eight transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters to be programmed must be with you. 1. Remove the key lock cylinder cap on the driver door handle. See Door Locks 0 34. Insert the vehicle key of the transmitter into the key lock cylinder on the driver door handle and turn the key to the unlock position five times within 10 seconds.

The Driver Information Center (DIC) displays REMOTE LEARN PENDING, PLEASE WAIT.

2. Wait for 10 minutes until the

DIC displays PRESS ENGINE START BUTTON TO LEARN and then press ENGINE START/STOP. The DIC display will again show REMOTE LEARN PENDING, PLEASE WAIT.

3. Repeat Step 2 two additional times. After the third time, all previously known transmitters will no longer work with the vehicle. Remaining transmitters can be relearned during the next steps. The DIC display should now show READY FOR REMOTE # 1.

4. Place the new transmitter into

the rear cupholder in the center console.

5. Press ENGINE START/STOP.

When the transmitter is learned, the DIC will show that it is ready to program the next transmitter.

6. Remove the transmitter from the cupholder and press K or Q. To program additional transmitters, repeat Steps 4–6.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

32

Keys, Doors, and Windows

When all additional transmitters are programmed, press and hold ENGINE START/STOP for 12 seconds to exit programming mode.

7. Put the key back into the

transmitter.

Starting the Vehicle with a Low Transmitter Battery If the transmitter battery is weak or if there is interference with the signal, the DIC may display NO REMOTE DETECTED or NO REMOTE KEY WAS DETECTED PLACE KEY IN TRANSMITTER POCKET THEN START YOUR VEHICLE. See Key and Lock Messages 0 128.

To start the vehicle:

Caution

When replacing the battery, do not touch any of the circuitry on the transmitter. Static from your body could damage the transmitter.

The battery is not rechargeable. To replace the battery:

1. Place the transmitter in the rear

cupholder in the center console.

2. With the vehicle in P (Park) or

N (Neutral), press the brake pedal and ENGINE START/STOP. Replace the transmitter battery as soon as possible. Battery Replacement Replace the battery if the REPLACE BATTERY IN REMOTE KEY message displays in the DIC. See Key and Lock Messages 0 128.

1. Press the button on the side of

the transmitter and pull the key out.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

2. Separate the two halves of the

transmitter using a flat tool inserted into the area near the key slot.

Keys, Doors, and Windows

33

3. Remove the battery by pushing

4.

on the battery and sliding it toward the bottom of the transmitter. Insert the new battery, positive side facing the back cover. Push the battery down until it is held in place. Replace with a CR2032 or equivalent battery.

5. Snap the battery cover back on

to the transmitter.

Remote Vehicle Start If equipped, this feature allows the engine to be started from outside the vehicle. / : This button will be on the RKE transmitter if equipped with remote start. The climate control system will use the previous settings during a remote start. The rear defog and heated seats, if equipped, may also come on. See “Remote Start Auto Heated Seats” under Heated and Ventilated Front Seats 0 53 and Vehicle Personalization 0 133.

Laws in some local communities may restrict the use of remote starters. For example, some laws may require a person using remote start to have the vehicle in view. Check local regulations for any requirements. Other conditions can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System 0 27.

Starting the Engine Using Remote Start To start the engine using the remote start feature: 1. Press and release Q. 2.

Immediately after completing Step 1, press and hold / for at least four seconds or until the turn signal lamps flash. The turn signal lamps flashing confirms the request to remote start the vehicle has been received. When the engine starts, the parking lamps will turn on and remain on as long as the

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

34

Keys, Doors, and Windows

engine is running. The vehicle's doors will be locked and the climate control system may come on. The engine will continue to run for 10 minutes. After 30 seconds, repeat the steps for a 10-minute time extension. Remote start can be extended only once.

Start the vehicle before driving. If the vehicle is low on fuel, do not use the remote start feature. The vehicle may run out of fuel.

Extending Engine Run Time The engine run time can also be extended by another 10 minutes, if during the first 10 minutes Steps 1 and 2 are repeated while the engine is still running. An extension can be requested, 30 seconds after starting. This provides a total of 20 minutes. The remote start can only be extended once.

When the remote start is extended, the second 10-minute period is added on to the first 10 minutes for a total of 20 minutes. A maximum of two remote starts, or a remote start with an extension, are allowed between ignition cycles. The vehicle's ignition must be changed to ON/RUN/START and then back to OFF before the remote start procedure can be used again.

Canceling a Remote Start To cancel a remote start, do one of the following: . Press and hold / until the

parking lamps turn off.

. Turn on the hazard warning

flashers.

. Turn the vehicle on and then off.

Conditions in Which Remote Start Will Not Work The remote start will not operate if: . The RKE transmitter is in the

vehicle.

. The hood is not closed.

. The hazard warning flashers

are on.

. There is an emission control

system malfunction.

. The engine coolant temperature

is too high.

. The oil pressure is low. . Two remote vehicle starts, or a

single remote start with an extension, have already been used.

. The vehicle is not in P (Park).

Door Locks

{ Warning Unlocked doors can be dangerous.

. Passengers, especially

children, can easily open the doors and fall out of a moving vehicle. The chance of being thrown out of the vehicle in a crash is increased if the doors are

(Continued)

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Keys, Doors, and Windows

35

Warning (Continued)

not locked. So, all passengers should wear safety belts properly and the doors should be locked whenever the vehicle is driven.

. Young children who get into

unlocked vehicles may be unable to get out. A child can be overcome by extreme heat and can suffer permanent injuries or even death from heat stroke. Always lock the vehicle whenever leaving it.

. Outsiders can easily enter through an unlocked door when slowing or stopping the vehicle. Lock the doors to help prevent this from happening.

To lock or unlock the doors from outside the vehicle: . Press Q or K on the Remote

Keyless Entry (RKE) transmitter.

. Use the key in the driver door.

The key cylinder is covered with a cap.

To lock or unlock the doors from inside the vehicle: . Press Q or K on the power door

lock switch.

. Pulling an interior door handle will unlock the door. Pulling the door handle again unlatches it.

Keyless Access If equipped, the RKE transmitter must be within 1 m (3 ft) of the door being opened. Press the button on the door handle to open. See “Keyless Access Operation” in Remote Keyless Entry (RKE) System Operation 0 27.

Key Cylinder Access To access the key lock cylinder: 1. Pull the door handle to the

open position.

2.

Insert the key into the slot on the bottom of the cap and pry outward.

3. Move the cap rearward and

remove.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

36

Keys, Doors, and Windows

Replace the cap by snapping the two tabs (7) at the back of the cap (8) between the seal (5) and the metal base (6).

Move the cap forward and press to snap the cap in place.

Free-Turning Locks The door lock cylinder turns freely when either the wrong key is used, or the correct key is not fully inserted. The free turning door lock feature prevents the lock from being forced open. To reset the lock, turn it to the vertical position with the correct key fully inserted. Remove the key and insert it again. If this does not reset the lock, turn the key halfway around in the cylinder and repeat the reset procedure.

Power Door Locks

Q : Press to lock the doors. K : Press to unlock the doors.

Delayed Locking This feature delays the locking of the doors until five seconds after all doors are closed. When Q is pressed on the power door lock switch while the door is open, a chime will sound three times indicating delayed locking is active.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Keys, Doors, and Windows

37

Lockout Protection can be manually overridden with the driver door open by pressing and holding Q on the power door lock switch.

Unlocked Door Anti-Lockout If Unlocked Door Anti-Lockout is turned on and the vehicle is off, the driver door is open, and locking is requested, all the doors will lock and only the driver door will unlock. The Unlocked Door Anti-Lockout feature can be turned on or off using the vehicle personalization menus. See Vehicle Personalization 0 133.

The doors will lock automatically five seconds after all doors are closed. If a door is reopened before that time, the five-second timer will reset when all doors are closed again. Press Q on the door lock switch again or press Q on the RKE transmitter to lock the doors immediately. This feature can also be programmed. See Vehicle Personalization 0 133.

Automatic Door Locks When the doors are closed, the ignition is on, and the shift lever is moved out of P (Park) for automatic transmissions, or the vehicle speed is above 13 km/h (8 mph) for manual transmissions, the doors will lock. To unlock the doors: . Press K on a power door lock

switch.

If equipped with an automatic transmission, shift the transmission into P (Park). If equipped with a manual transmission, turn the vehicle off when parked.

Automatic door unlocking can be programmed through the Driver Information Center (DIC). See Vehicle Personalization 0 133.

Lockout Protection If the vehicle is in ACC/ ACCESSORY or ON/RUN/START and the power door lock switch is pressed with the driver door open, all the doors will lock and only the driver door will unlock. If the vehicle is off and locking is requested while a door is open, when all doors are closed the vehicle will check for RKE transmitters inside. If an RKE transmitter is detected and the number of RKE transmitters inside has not reduced, the driver door will unlock and the horn will chirp three times.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

38

Keys, Doors, and Windows

Doors

Trunk

{ Warning

Exhaust gases can enter the vehicle if it is driven with the liftgate, trunk/hatch open, or with any objects that pass through the seal between the body and the trunk/hatch or liftgate. Engine exhaust contains carbon monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. If the vehicle must be driven with the liftgate, or trunk/hatch open:

. Close all of the windows. . Fully open the air outlets on

or under the instrument panel.

. Adjust the climate control

system to a setting that brings in only outside air and set the fan speed to the (Continued)

Warning (Continued)

highest setting. See “Climate Control Systems” in the Index. If the vehicle has a power liftgate, disable the power liftgate function.

For more information about carbon monoxide, see Engine Exhaust 0 208.

Trunk Release To open the trunk from outside of the vehicle, press X twice quickly on the Remote Keyless Entry (RKE) transmitter or press the touch pad in the area above the license plate after unlocking all doors. For automatic transmissions, the vehicle must be in P (Park). For manual transmissions, the vehicle must be off, or stationary with the parking brake set. For Keyless Access, the RKE transmitter must be within 1 m (3 ft) of the trunk.

From inside the vehicle, press | on the lower portion of the driver door. Emergency Trunk Release Handle

Caution

Do not use the emergency trunk release handle as a tie-down or anchor point when securing items in the trunk as it could damage the handle.

Chevrolet Camaro Owner Manual (GMNA-Localizing-U.S./Canada/Mexico- 9234742) - 2016 - crc - 8/6/15

Keys, Doors, and Windows
