2016 Buick Regal Owners Manual

2k16_CS6_Buick_Regal_23179974A_COVER.pdf 1 7/20/2015 9:54:55 AM

CM

MY

CY

CMY

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . 2
In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keys, Doors, and Windows . . . . . 26
Seats and Restraints . . . . . . . . . . . 48
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 94
Instruments and Controls . . . . . . . 97
Lighting . . . . . . . . . . . . . . . . . . . . . . . 148
Infotainment System . . . . . . . . . . 154
Climate Controls . . . . . . . . . . . . . . 155
Driving and Operating . . . . . . . . . 161
Vehicle Care . . . . . . . . . . . . . . . . . . 219
Service and Maintenance . . . . . 306
Technical Data . . . . . . . . . . . . . . . . 320
Customer Information . . . . . . . . . 324
Reporting Safety Defects . . . . . . 334
OnStar . . . . . . . . . . . . . . . . . . . . . . . . 338
Index . . . . . . . . . . . . . . . . . . . . 348

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Introduction

Introduction

The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, BUICK, the BUICK Emblem, and REGAL are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Buick Motor Division wherever it appears in this manual.

This manual describes features that may or may not be on the vehicle because of optional equipment that was not purchased on the vehicle, model variants, country specifications, features/applications that may not be available in your region, or changes subsequent to the printing of this owner manual. Refer to the purchase documentation relating to your specific vehicle to confirm the features. Keep this manual in the vehicle for quick reference.

Canadian Vehicle Owners

Propriétaires Canadiens A French language manual can be obtained from your dealer, at www.helminc.com, or from: On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse savant: Helm, Incorporated Attention: Customer Service 47911 Halyard Drive Plymouth, MI 48170

Using this Manual To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found.

Litho in U.S.A. Part No. 23179974 A First Printing

©2015 General Motors LLC. All Rights Reserved.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Danger, Warning, and Caution Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them.

{ Danger

Danger indicates a hazard with a high level of risk which will result in serious injury or death.

{ Warning

Warning indicates a hazard that could result in injury or death.

Caution

Caution indicates a hazard that could result in property or vehicle damage.

A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.”

Symbols The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or information relating to a specific component, control, message, gauge, or indicator. M : Shown when the owner manual has additional instructions or information. * : Shown when the service manual has additional instructions or information. 0 : Shown when there is more information on another page — “see page.”

Introduction

Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the Index. 9 : Airbag Readiness Light # : Air Conditioning ! : Antilock Brake System (ABS) g : Audio Steering Wheel Controls or OnStar® (if equipped) $ : Brake System Warning Light " : Charging System I : Cruise Control ` : Do Not Puncture ^ : Do Not Service B : Engine Coolant Temperature O : Exterior Lamps

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Introduction

g : First Responder _ : Flame/Fire Prohibited # : Fog Lamps . : Fuel Gauge + : Fuses 3 : Headlamp High/Low-Beam Changer ( : Heated Steering Wheel j : LATCH System Child Restraints * : Malfunction Indicator Lamp

: : Oil Pressure O : Power / : Remote Vehicle Start > : Safety Belt Reminders 7 : Tire Pressure Monitor d : Traction Control/StabiliTrak® a : Under Pressure M : Windshield Washer Fluid

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

In Brief

Instrument Panel

Instrument Panel . . . . . . . . . . . . . . . . 6

Initial Drive Information

Initial Drive Information . . . . . . . . . . 8
Remote Keyless Entry (RKE)

System . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Vehicle Start . . . . . . . . . . . 9
Door Locks . . . . . . . . . . . . . . . . . . . . . 9
Trunk Release . . . . . . . . . . . . . . . . . 10
Windows . . . . . . . . . . . . . . . . . . . . . . . 10
Seat Adjustment . . . . . . . . . . . . . . . 10
Memory Features . . . . . . . . . . . . . . 11
Heated Seats . . . . . . . . . . . . . . . . . . 12
Head Restraint Adjustment . . . . 12
Safety Belts . . . . . . . . . . . . . . . . . . . . 12
Passenger Sensing System . . . 13
Mirror Adjustment . . . . . . . . . . . . . . 13
Steering Wheel Adjustment . . . . 14
Interior Lighting . . . . . . . . . . . . . . . . 14
Exterior Lighting . . . . . . . . . . . . . . . 15
Windshield Wiper/Washer . . . . . . 15
Climate Controls . . . . . . . . . . . . . . . 16
Transmission . . . . . . . . . . . . . . . . . . 16

Vehicle Features

Performance and Maintenance

In Brief

Infotainment System . . . . . . . . . . . 17
Steering Wheel Controls . . . . . . . 17
Cruise Control . . . . . . . . . . . . . . . . . 17
Driver Information

Center (DIC) . . . . . . . . . . . . . . . . . 18

Forward Collision Alert (FCA)

Traction Control/Electronic

Stability Control . . . . . . . . . . . . . . 23
Tire Pressure Monitor . . . . . . . . . . 23
Engine Oil Life System . . . . . . . . 24
Driving for Better Fuel

Economy . . . . . . . . . . . . . . . . . . . . . 24

System . . . . . . . . . . . . . . . . . . . . . . . 18

Roadside Assistance

Program . . . . . . . . . . . . . . . . . . . . . . 25

Front Automatic Braking (FAB)

System . . . . . . . . . . . . . . . . . . . . . . . 18

Lane Departure

Warning (LDW) . . . . . . . . . . . . . . . 19
Lane Change Alert (LCA) . . . . . . 19
Rear Vision Camera (RVC) . . . . 19
Rear Cross Traffic Alert (RCTA)

System . . . . . . . . . . . . . . . . . . . . . . . 19
Parking Assist . . . . . . . . . . . . . . . . . 19
Power Outlets . . . . . . . . . . . . . . . . . 20
Universal Remote System . . . . . 20
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 20

eAssist Features

eAssist® Overview . . . . . . . . . . . . . 21
High Voltage Safety

Information . . . . . . . . . . . . . . . . . . . 22

Automatic Engine Start/Stop

Feature . . . . . . . . . . . . . . . . . . . . . . . 22
Regenerative Braking . . . . . . . . . . 22
Battery . . . . . . . . . . . . . . . . . . . . . . . . . 22
Service . . . . . . . . . . . . . . . . . . . . . . . . 23

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

In Brief

Instrument Panel

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

1. Exterior Lamp Controls 0 148.

5.

Fog Lamps 0 151 (If Equipped). Instrument Panel Illumination Control 0 151.

2. Air Vents 0 159. 3. Turn Signal Lever. See Turn

and Lane-Change Signals 0 150.

4. Cruise Control 0 194 (If

Equipped). Adaptive Cruise Control 0 196
(If Equipped). Heated Steering Wheel 0 98 (If Equipped). Forward Collision Alert (FCA) System 0 207 (If Equipped).

Instrument Cluster (Uplevel Cluster) 0 107 or Instrument Cluster (Base Level Cluster) 0 103. Driver Information Center Display. See Driver Information Center (DIC) (Base Level Cluster) 0 124 or Driver Information Center (DIC) (Uplevel Cluster) 0 126.

6. Steering Wheel Controls 0 98

(If Equipped). Driver Information Center (DIC) Controls. See Driver Information Center (DIC) (Base Level Cluster) 0 124 or Driver Information Center (DIC) (Uplevel Cluster) 0 126.

7. Windshield Wiper/Washer 0 99. 8.

Infotainment 0 154.

In Brief

9. Traction Control/Electronic

Stability Control 0 191. Hazard Warning Flashers 0 150. GS/Sport Buttons (If Equipped). See Selective Ride Control 0 193. Parking Assist Button (If Equipped). See Assistance Systems for Parking or Backing 0 204. Lane Departure Warning (LDW) 0 212 (If Equipped).

10. Light Sensor. See Automatic

Headlamp System 0 149.

11. Passenger Safety Belt

Reminder Light. See Safety Belt Reminders 0 112.

12. Heated Front Seats 0 54 (If

Equipped).

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

In Brief

13. Electric Parking Brake Switch.

See Parking Brake 0 189. 14. Shift Lever. See Automatic

Transmission 0 184 or Manual Transmission 0 186.

15. Dual Automatic Climate Control

16.

System 0 155. Ignition Positions (Keyless Access) 0 173 or Ignition Positions (Key Access) 0 174.

17. Horn 0 99. 18. Steering Wheel Adjustment

0 98.

19. Hood Release. See Hood

0 222.

20. Data Link Connector (DLC)

(Out of View). See Malfunction Indicator Lamp (Check Engine Light) 0 114. Instrument Panel Storage 0 94.

21.

Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual.

Remote Keyless Entry (RKE) System The RKE transmitter may work up to 60 m (197 ft) away from the vehicle.

With Remote Start Shown

Press the button to extend the key. The key can be used for all locks. This key is also used for the ignition, if the vehicle does not have pushbutton start. K : Press to unlock the driver door or all doors. Q : Press to lock all doors. Lock and unlock feedback can be personalized. Y : Press and hold to release the trunk.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

7 : Press and release to initiate vehicle locator. Press and hold for at least three seconds to sound the panic alarm. Press again to cancel the panic alarm. See Keys 0 26 and Remote Keyless Entry (RKE) System Operation 0 28.

Remote Vehicle Start If equipped, the engine can be started from outside of the vehicle. Starting the Vehicle 1. Press and release Q on the

2.

RKE transmitter. Immediately press and hold / for at least four seconds or until the turn signal lamps flash.

3. Start the vehicle normally after

entering.

When the vehicle starts, the parking lamps will turn on. Remote start can be extended.

Canceling a Remote Start To cancel a remote start, do one of the following: . Press and hold / until the

parking lamps turn off.

. Turn on the hazard warning

flashers.

. Turn the vehicle on and then off. See Remote Vehicle Start 0 34.

Door Locks To lock or unlock the door from outside the vehicle, press Q or K on the Remote Keyless Entry (RKE) transmitter or use the key in the driver door. From inside the vehicle pull once on the door handle to unlock it. Pulling the door handle again unlatches it. Pushing down the manual lock knob on the driver door will lock all doors. Pushing down the manual lock knob on a passenger door will lock that door only. See Door Locks 0 35 for additional information.

In Brief

Power Door Locks

K : Press to unlock the doors. Q : Press to lock the doors.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

10

In Brief

Trunk Release

Windows

Seat Adjustment

Manual Seats

To open the trunk: . Press | on the driver door. . Press and hold Y on the

Remote Keyless Entry (RKE) transmitter.

. Press the touch pad on the trunk

under the vehicle emblem after unlocking all doors.

See Trunk 0 38.

The power window switches are on the driver door. Each passenger door has a switch that controls only that window. Press the switch to lower the window. Pull the front of the switch up to raise it. See Power Windows 0 45.

1. Seatback Recline Lever 2. Height Adjustment Switch 3. Seat Position Handle

To adjust the seat position: 1. Pull the handle (3) under the

front of the seat cushion.

2. Slide the seat to the desired

position and release the handle (3).

3. Try to move the seat back and

forth to be sure it is locked in place.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Press and hold the top or bottom of the switch (2) to raise or lower the seat. Release the switch (2) when the desired height is reached. To raise or recline the seatback, use the lever (1) on the outboard side of the seat. See Seat Adjustment 0 50 and Reclining Seatbacks 0 51. Power Seats

To adjust a power seat, if equipped: . Move the seat forward or

rearward by sliding the control (1) forward or rearward. . Raise or lower the front or rear

part of the seat cushion by moving the front or rear of the control (1) up or down.

. Raise or lower the entire seat by

moving the control (1) up or down.

See Power Seat Adjustment 0 51. To raise or recline the seatback, tilt the top of the control (2) forward or rearward. See Reclining Seatbacks 0 51. Press and hold the top or bottom of the control (3) to increase or decrease lumbar support. See Lumbar Adjustment 0 51.

1. Seat Adjustment Control 2. Reclining Seatbacks 3. Lumbar Adjustment

In Brief

11

Memory Features

If equipped, the MEM, 1, and 2
buttons on the outboard side of the driver seat are used to manually store and recall the driver seat and outside mirror positions. See Memory Seats 0 53 and Vehicle Personalization 0 139.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

12

In Brief

Heated Seats

If equipped, the buttons are part of the climate control system on the center stack. To operate, the ignition and the climate control system must be on. If the climate control system is off, press the O button to turn it on.

Press M or L to heat the driver or passenger seat.

Press the button once for the highest setting. With each press of the button, the seat will change to the next lower setting, and then to the off setting. The lights near the heated seat symbol on the display indicate three for the highest setting and one for the lowest. See Heated Seats 0 12.

Head Restraint Adjustment Do not drive until the head restraints for all occupants are installed and adjusted properly. To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position. See Head Restraints 0 49 and Seat Adjustment 0 50.

Safety Belts

Refer to the following sections for important information on how to use safety belts properly: . Safety Belts 0 57. . How to Wear Safety Belts

Properly 0 58.

. Lap-Shoulder Belt 0 59. . Lower Anchors and Tethers for Children (LATCH System) 0 81.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Passenger Sensing System

The passenger sensing system turns off the front outboard passenger frontal airbag under certain conditions. No other airbag is affected by the passenger sensing system. The passenger airbag status indicator will be visible on the instrument panel when the vehicle is started. See Passenger Sensing System 0 68 for important information.

Mirror Adjustment

Exterior Mirrors

In Brief

13

Interior Mirrors

Adjustment Adjust the rearview mirror for a clear view of the area behind your vehicle.

Automatic Dimming Rearview Mirror The mirror automatically dims to reduce the glare of headlamps from behind. The dimming feature comes on when the vehicle is started. See Automatic Dimming Rearview Mirror 0 44.

To adjust a mirror: 1. Move the selector switch to L (Left) or R (Right) to choose the driver or passenger mirror. 2. Press the arrows on the control pad to move each mirror in the desired direction.

3. Return the selector switch to

the center position. See Power Mirrors 0 43.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

14

In Brief

Folding Mirrors The outside mirrors can be folded inward to prevent damage when going through an automatic car wash. To fold, pull the mirror toward the vehicle. Push the mirror outward to return it to the original position.

Steering Wheel Adjustment

3. Pull or push the steering wheel

closer or away from you.

4. Pull the lever up to lock the

steering wheel in place.

Do not adjust the steering wheel while driving.

Interior Lighting

Dome Lamps The interior lamps control in the overhead console controls both the front and rear interior lamps.

Reading Lamps There are front and rear reading lamps.

The front reading lamps are in the overhead console.

To adjust the steering wheel: 1. Pull the lever down. 2. Move the steering wheel up

or down.

( : Turns the lamps off. H : Turns the lamps on when any door is opened. ' : Keeps the lamps on all the time.

The rear reading lamps are in the headliner. # or $ : Press to turn each lamp on or off.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

For more information, see Dome Lamps 0 152.

Exterior Lighting

The exterior lamp control is on the instrument panel on the outboard side of the steering wheel. O : Turns off the exterior lamps. The knob returns to the AUTO position after it is released. Turn to O again to reactivate the AUTO mode. In Canada, the headlamps will automatically reactivate when the vehicle is shifted out of P (Park) on automatic transmission vehicles, and when the parking brake is released on manual transmission vehicles.

AUTO : Automatically turns the exterior lamps on and off, depending on outside lighting. ; : Turns on the parking lamps including all lamps, except the headlamps. 2 : Turns on the headlamps together with the parking lamps and instrument panel lights. See: . Exterior Lamp Controls 0 148
. Daytime Running Lamps (DRL)

0 149

. Fog Lamps 0 151, If Equipped.

Windshield Wiper/Washer

The windshield wiper/washer lever is on the right side of the steering column.

In Brief

15

With the ignition in ACC/ ACCESSORY or ON/RUN/START, move the lever to select the wiper speed. HI : Use for fast wipes. LO : Use for slow wipes.

INT : Move the lever up to INT for intermittent wipes, then turn the x INT band up for more frequent wipes or down for less frequent wipes. OFF : Use to turn the wipers off. 1X : For a single wipe, briefly move the lever down. For several wipes, hold the lever down. n L : Pull the lever toward you to spray windshield washer fluid and activate the wipers. See Windshield Wiper/Washer 0 99.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

16

In Brief

Climate Controls

The heating, cooling, and ventilation for the vehicle can be controlled with this system.

10. Rear Window Defogger 11. Power See Dual Automatic Climate Control System 0 155.

Transmission

Automatic Transmission

1. Driver and Passenger Temperature Controls 2. Heated Front Seats (If

Equipped)

3. Defrost 4. Air Delivery Mode Controls

5. Fan Control 6. SYNC (Synchronized

Temperature)

7. AUTO (Automatic Operation) 8. Recirculation 9. A/C (Air Conditioning)

Manual Mode Driver Shift Control (DSC) allows you to shift an automatic transmission similar to a manual transmission. To use the DSC feature:

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

1. Move the shift lever to the left

from D (Drive) into the side gate marked with (+) and (−).

2. Press the shift lever forward to

upshift or rearward to downshift.

See Automatic Transmission 0 184.

Vehicle Features

Cruise Control

In Brief

17

Infotainment System See the infotainment manual for information on the radio, audio players, phone, navigation system, and voice or speech recognition. It also includes information on settings.

Steering Wheel Controls The infotainment system can be operated by using the steering wheel controls. See "Steering Wheel Controls" in the infotainment manual.

5 : Press to turn cruise control on or off. A white indicator comes on in the instrument cluster when cruise is turned on. RES+ : If there is a set speed in memory, press the control up briefly to resume to that speed or hold upward to accelerate. If cruise control is already active, use to increase vehicle speed.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

18

In Brief

SET− : Press the control down briefly to set the speed and activate cruise control. If cruise control is already active, use to decrease vehicle speed. * : Press to disengage cruise control without erasing the set speed from memory. See Cruise Control 0 194 and Adaptive Cruise Control 0 196 (if equipped).

Driver Information Center (DIC) The DIC display is in the instrument cluster. It shows the status of many vehicle systems.

Forward Collision Alert (FCA) System If equipped, FCA may help avoid or reduce the harm caused by front-end crashes. FCA provides a green indicator, V, when a vehicle is detected ahead. This indicator displays amber if you follow a vehicle much too closely. When approaching a vehicle ahead too quickly, FCA provides a red alert and rapidly beeps. See Forward Collision Alert (FCA) System 0 207.

Front Automatic Braking (FAB) System If the vehicle has Adaptive Cruise Control (ACC), it also has FAB, which includes Intelligent Brake Assist (IBA). When the system detects a vehicle ahead in your path that is traveling in the same direction that you may be about to crash into, it can provide a boost to braking or automatically brake the

y or z : Press to move up or down in a list. S or T : Press S to open application menus on the left. Press T to open interaction menus on the right. V : Press to open a menu or select a menu item. Press and hold to reset values on certain screens. See Driver Information Center (DIC) (Base Level Cluster) 0 124 or Driver Information Center (DIC) (Uplevel Cluster) 0 126.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

vehicle. This can help avoid or lessen the severity of crashes when driving in a forward gear. See Front Automatic Braking (FAB) System 0 209.

Lane Departure Warning (LDW) If equipped, LDW may help avoid unintentional lane departures at speeds of 56 km/h (35 mph) or greater. LDW uses a camera sensor to detect the lane markings. The LDW light, @, is green if a lane marking is detected. If the vehicle departs the lane without using a turn signal in that direction, the light will change to amber and flash. In addition, beeps will sound. See Lane Departure Warning (LDW) 0 212.

Lane Change Alert (LCA) If equipped, the LCA system is a lane-changing aid that assists drivers with avoiding lane change crashes that occur with moving vehicles in the side blind zone (or

spot) areas or with vehicles rapidly approaching these areas from behind. The LCA warning display will light up in the corresponding outside side mirror and will flash if the turn signal is on. The Side Blind Zone Alert (SBZA) system is included as part of the LCA system. See Side Blind Zone Alert (SBZA) 0 210 and Lane Change Alert (LCA) 0 210.

Rear Vision Camera (RVC) If equipped, RVC displays a view of the area behind the vehicle on the center stack display when the vehicle is shifted into R (Reverse) to aid with parking and low-speed backing maneuvers. See Assistance Systems for Parking or Backing 0 204.

Rear Cross Traffic Alert (RCTA) System If equipped, the RCTA system uses a triangle with an arrow displayed on the RVC screen to warn of traffic

In Brief

19

behind your vehicle that may cross your vehicle's path while in R (Reverse). In addition, beeps will sound. See Assistance Systems for Parking or Backing 0 204.

Parking Assist If equipped, Rear Parking Assist (RPA) uses sensors on the rear bumper to assist with parking and avoiding objects while in R (Reverse). It operates at speeds less than 8 km/h (5 mph). RPA may display a warning triangle on the RVC screen and a graphic on the instrument cluster to provide the object distance. In addition, multiple beeps may occur if very close to an object. The vehicle may also have the Front Parking Assist system. See Assistance Systems for Parking or Backing 0 204.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

20

In Brief

Power Outlets The accessory power outlet can be used to plug in electrical equipment, such as a cell phone or MP3 player. There are two 12-volt accessory power outlets located: . On the center stack next to the

ashtray. Inside the center console.

The outlet is powered when the ignition is in ON/RUN or ACC/ ACCESSORY, or until the driver door is opened within 10 minutes of turning off the vehicle. See Retained Accessory Power (RAP) 0 180. Open the protective cover to use the accessory power outlet. See Power Outlets 0 100.

Universal Remote System

Sunroof

If equipped, this system provides a way to replace up to three remote control transmitters used to activate devices such as garage door openers, security systems, and home automation devices. Read the instructions completely before attempting to program the Universal Remote system. Because of the steps involved, it may be helpful to have another person available to assist with programming the Universal Remote system. See Universal Remote System 0 144.

For vehicles with a sunroof, the sunroof only operates when the ignition is in ON/RUN or ACC/ ACCESSORY or in Retained Accessory Power (RAP). See Retained Accessory Power (RAP) 0 180. To open or close the sunroof, press switch (1) to the first detent position.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

To express open or close the sunroof with the safety function enabled, press the open or close sunroof switch (1) to the second detent position and release. To stop the movement, press the switch again. To automatically tilt or close the sunroof, press the tilt open or close sunroof switch (2). If an object is in the path of the sunroof while it is closing, the anti-pinch feature will detect the object and stop the sunroof. The sunroof will then return to the full-open or vent position. The sunroof glass panel cannot be opened or closed if the vehicle has an electrical failure. See Sunroof 0 46.

eAssist Features

eAssist® Overview If the vehicle has eAssist, there are several additional features that contribute to increased efficiency. Vehicles with eAssist have an automatic engine start/stop feature. This feature saves fuel by shutting the engine off when the vehicle is stopped. When the engine shuts off automatically, all the accessories will continue to operate normally. In very hot or cold conditions, the engine will only shut off automatically part of the time. See Starting the Engine 0 176. There are two air conditioning settings available. The comfort setting maximizes cabin comfort. The eco setting maximizes efficiency allowing more frequent, and longer engine stops than the comfort setting. See Dual Automatic Climate Control System 0 155.

In Brief

21

This vehicle has a Hill Start Assist (HSA) feature, which may be useful when the vehicle is stopped on a grade. See Hill Start Assist (HSA) 0 191. Vehicles with eAssist have a slightly different instrument cluster, which includes an AUTO STOP indicator on the tachometer. See Instrument Cluster (Uplevel Cluster) 0 107 or Instrument Cluster (Base Level Cluster) 0 103. The eAssist system uses a high voltage battery, which is cooled with air drawn from the vehicle interior.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

22

In Brief

The cold air intake for the battery is located behind the rear seat, on the filler panel. Do not cover the intake. See Battery - North America 0 242.

High Voltage Safety Information Vehicles with eAssist have a standard 12-volt battery and a high voltage battery. Only a trained service technician with the proper knowledge and tools should inspect, test, or replace the high voltage battery. See your dealer if the high voltage battery needs service. In emergency situations, first responders can cut the two clearly labeled cut points in the engine compartment to disable the high voltage battery and air bag systems — do not cut the high voltage cable.

Automatic Engine Start/ Stop Feature Vehicles with eAssist have an automatic engine start/stop feature. After the engine is started and has reached operating temperature, the

auto stop feature may cause the engine to turn off when the brake pedal is applied and the vehicle comes to a complete stop. When the brake pedal is released, or the accelerator pedal is applied, the engine will restart. The engine will continue to run until the next auto stop. To restart the engine during the auto stop, release the brake pedal or press the accelerator pedal. The engine starts immediately. The vehicle continues to run until the next stop. AUTO STOP on the tachometer signifies that the engine is in auto stop mode. See Tachometer 0 110
for more information. A chime will sound when the driver door is opened while in auto stop mode. Remember to shift to P (Park) and turn the ignition to LOCK/OFF before exiting the vehicle. See Starting the Engine 0 176.

Regenerative Braking Regenerative braking takes some of the energy from the moving vehicle and turns it into electrical energy. This energy is then stored in the vehicle's high voltage battery system, contributing to increased fuel efficiency. The system works whenever the accelerator pedal is released, and increases the energy captured as more brake pedal is applied.

Battery This vehicle has a standard 12-volt battery. Refer to the replacement number on the original battery label when a new standard 12-volt battery is needed. Vehicles with eAssist also have a high voltage battery. Only a trained service technician with the proper knowledge and tools should inspect, test, or replace the high voltage battery. See your dealer if the high voltage battery needs service. See Battery - North America 0 242.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Service Never try to do your own service on eAssist components. You can be injured and the vehicle can be damaged if you try to do your own service work. Service and repair of these high voltage components should only be performed by a trained service technician with the proper knowledge and tools. See Doing Your Own Service Work 0 221.

Performance and Maintenance

Traction Control/ Electronic Stability Control The traction control system limits wheel slip. The system turns on automatically every time the vehicle is started. The StabiliTrak system assists with directional control of the vehicle in difficult driving conditions. The system turns on automatically every time the vehicle is started. . To turn off traction control, press

and release g on the center stack. i illuminates and the appropriate DIC message is displayed. See Ride Control System Messages 0 136.

. Press and release g again to

turn on traction control.

In Brief

23

. To turn off both traction control

and StabiliTrak, press and hold g, on the center stack, until i and g illuminate in the instrument cluster and the appropriate DIC message is displayed. See Ride Control System Messages 0 136.

. Press and release g to turn on

both systems.

See Traction Control/Electronic Stability Control 0 191.

Tire Pressure Monitor This vehicle may have a Tire Pressure Monitor System (TPMS).

The low tire pressure warning light alerts to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

24

In Brief

the tires to the recommended pressure shown on the Tire and Loading Information label. See Vehicle Load Limits 0 169. The warning light will remain on until the tire pressure is corrected. The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This may be an early indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure. The TPMS does not replace normal monthly tire maintenance. Maintain the correct tire pressures. See Tire Pressure Monitor System 0 264.

Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays the CHANGE ENGINE OIL SOON message when it is time to change the engine oil and filter. The oil life system should be reset to 100% only following an oil change.

Resetting the Oil Life System 1. Using the DIC controls on the

right side of the steering wheel, display REMAINING OIL LIFE on the DIC. See Driver Information Center (DIC) (Base Level Cluster) 0 124 or Driver Information Center (DIC) (Uplevel Cluster) 0 126. When remaining oil life is low, the CHANGE ENGINE OIL SOON message will appear on the display. See Engine Oil Messages 0 133.

2. Press V on the DIC controls

and hold down for a few seconds to clear the CHANGE ENGINE OIL SOON message and reset the oil life at 100%. Be careful not to reset the oil life display accidentally at any time other than after the oil is changed. It cannot be reset accurately until the next oil change.

See Engine Oil Life System 0 230.

Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. . Avoid fast starts and accelerate

smoothly.

. Brake gradually and avoid

abrupt stops.

. Avoid idling the engine for long

periods of time.

. When road and weather

conditions are appropriate, use cruise control.

. Always follow posted speed

limits or drive more slowly when conditions require.

. Keep vehicle tires properly

inflated.

. Combine several trips into a

single trip.

. Replace the vehicle's tires with

the same TPC Spec number molded into the tire's sidewall near the size.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

In Brief

25

. Follow recommended scheduled

maintenance.

Roadside Assistance Program U.S.: 1-800-252-1112
TTY Users (U.S. Only): 1-888-889-2438
Canada: 1-800-268-6800
New Buick owners are automatically enrolled in the Roadside Assistance Program. See Roadside Assistance Program 0 328.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

26
Keys, Doors, and Windows

Exterior Mirrors

Convex Mirrors . . . . . . . . . . . . . . . . 43
Power Mirrors . . . . . . . . . . . . . . . . . . 43
Folding Mirrors . . . . . . . . . . . . . . . . . 44
Heated Mirrors . . . . . . . . . . . . . . . . . 44

Interior Mirrors

Interior Rearview Mirrors . . . . . . . 44
Automatic Dimming Rearview

Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 44

Windows

Windows . . . . . . . . . . . . . . . . . . . . . . . 44
Power Windows . . . . . . . . . . . . . . . 45
Sun Visors . . . . . . . . . . . . . . . . . . . . . 46

Roof

Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 46

Keys and Locks

Keys

{ Warning

Leaving children in a vehicle with an ignition key or Remote Keyless Entry (RKE) transmitter is dangerous and children or others could be seriously injured or killed. They could operate the power window or other controls or make the vehicle move. The windows will function with the key in the ignition or with the RKE transmitter in the vehicle, and children or others could be caught in the path of a closing window. Do not leave children in a vehicle with the ignition key or an RKE transmitter.

Keys and Locks

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Remote Keyless Entry (RKE)

System . . . . . . . . . . . . . . . . . . . . . . . 28

Remote Keyless Entry (RKE)

System Operation . . . . . . . . . . . . 28
Remote Vehicle Start . . . . . . . . . . 34
Door Locks . . . . . . . . . . . . . . . . . . . . 35
Power Door Locks . . . . . . . . . . . . . 36
Delayed Locking . . . . . . . . . . . . . . . 36
Automatic Door Locks . . . . . . . . . 36
Lockout Protection . . . . . . . . . . . . . 37
Safety Locks . . . . . . . . . . . . . . . . . . . 37

Doors

Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Vehicle Security

Vehicle Security . . . . . . . . . . . . . . . . 40
Vehicle Alarm System . . . . . . . . . 40
Immobilizer . . . . . . . . . . . . . . . . . . . . 41
Immobilizer Operation (Key

Access) . . . . . . . . . . . . . . . . . . . . . . 41

Immobilizer Operation (Keyless

Access) . . . . . . . . . . . . . . . . . . . . . . 42

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

27

If the vehicle has the keyless ignition, the key can be used for the locks.

Warning (Continued)

impacted, and airbags may not deploy. To reduce the risk of unintentional rotation of the ignition key, do not change the way the ignition key and Remote Keyless Entry (RKE) transmitter, if equipped, are connected to the provided key rings.

{ Warning

If the key is unintentionally rotated while the vehicle is running, the ignition could be moved out of the RUN position. This could be caused by heavy items hanging from the key ring, or by large or long items attached to the key ring that could be contacted by the driver or steering wheel. If the ignition moves out of the RUN position, the engine will shut off, braking and steering power assist may be (Continued)

If the vehicle is equipped with a keyed ignition, the ignition key, key rings, and RKE transmitter, if equipped, are designed to work together. As a system, it reduces the risk of unintentionally moving the key out of the RUN position. If replacements or additions are required, see your dealer. Limit added items to a few essential keys or small, light items no larger than an RKE transmitter. The key that is part of the RKE transmitter can be used for the ignition and all locks if the vehicle is a Key Access vehicle.

Press the button on the RKE transmitter to extend the key. Press the button and the key blade to retract the key. If the vehicle has an ignition and it becomes difficult to turn the key, inspect the key blade for debris. Periodically clean with a brush or pick. See your dealer if a new key is needed.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

28

Keys, Doors, and Windows

Remote Keyless Entry (RKE) System Operation The Keyless Access system allows for vehicle entry when the transmitter is within 1 m (3 ft). See “Keyless Access Operation” later in this section. The transmitter functions may work up to 60 m (197 ft) away from the vehicle. Keep in mind that other conditions, such as those previously stated, can impact the performance of the transmitter.

If locked out of the vehicle, see Roadside Assistance Program 0 328. With an active OnStar subscription, an OnStar Advisor may remotely unlock the vehicle. See OnStar Overview 0 338.

Remote Keyless Entry (RKE) System See Radio Frequency Statement 0 334. If there is a decrease in the RKE operating range: . Check the distance. The

transmitter may be too far from the vehicle.

. Check the location. Other vehicles or objects may be blocking the signal.

. Check the transmitter's battery. See “Battery Replacement” later in this section. If the transmitter is still not working correctly, see your dealer or a qualified technician for service.

With Remote Start Shown K(Unlock) : Press to unlock the driver door or all doors. See Vehicle Personalization 0 139. The turn signal indicators may flash to indicate unlocking. See Vehicle Personalization 0 139. Pressing K will disarm the theft-deterrent system. See Vehicle Alarm System 0 40. Q(Lock) : Press to lock all doors. The turn signal indicators may flash and/or the horn may sound on the second press to indicate locking. See Vehicle Personalization 0 139.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

29

If the driver door is open when Q is pressed, all doors lock and then the driver door will immediately unlock , if enabled through vehicle personalization. See Vehicle Personalization 0 139. If the passenger door is open when Q is pressed, all doors lock. Pressing Q may also arm the theft-deterrent system. See Vehicle Alarm System 0 40. Y (Remote Trunk Release) : Press and hold to release the trunk. 7 (Vehicle Locator/Panic Alarm) : Press and release one time to initiate vehicle locator. The exterior lamps flash and the horn chirps three times. Press and hold 7 for at least three seconds to sound the panic alarm. The horn sounds and the turn signals flash for about 30 seconds until 7 is pressed again or the vehicle is started.

/ (Remote Vehicle Start) : If equipped, press and release Q and then immediately press and hold / for at least four seconds to start the engine from outside the vehicle using the RKE transmitter. See Remote Vehicle Start 0 34. The RKE transmitter buttons will not operate when the key is in the ignition Keyless Access Operation Some vehicles have a Keyless Access system that lets you lock and unlock the doors and access the trunk without removing the RKE transmitter from your pocket, purse, briefcase, etc. The RKE transmitter should be within 1 m (3 ft) of the door or trunk being opened. If equipped, there will be buttons on the outside door handles. The Keyless Access can be programmed to unlock all doors on the first lock/unlock press from the driver door. See Vehicle Personalization 0 139.

Keyless Unlocking/Locking from the Driver Door When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the driver door handle, pressing the lock/unlock button on the driver door handle will unlock the driver door. If the lock/unlock button is pressed again within five seconds, all passenger doors will unlock. Pull the door handle to unlatch the door.

Driver Side Shown, Passenger

Similar

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

30

Keys, Doors, and Windows

Pressing the lock/unlock button will cause all doors to lock if any of the following occur:

It has been more than five seconds since the first lock/ unlock button press.

. Two lock/unlock button presses

were used to unlock all doors. . Any vehicle door has opened and all doors are now closed.

Keyless Unlocking/Locking from the Passenger Doors When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the passenger door handle, pressing the lock/unlock button on the passenger door handle will unlock all doors. Pressing the lock/unlock button will cause all doors to lock if any of the following occur: . The lock/unlock button was used

to unlock all doors.

. Any vehicle door has opened and all doors are now closed.

Passive Locking If equipped with Keyless Access, this feature will lock the vehicle several seconds after all doors are closed, if the vehicle is off and at least one RKE transmitter has been removed from the interior or none remain in the interior. If other electronic devices interfere with the RKE transmitter signal, the vehicle may not detect the RKE transmitter inside the vehicle. If passive locking is enabled, the doors may lock with the RKE transmitter inside the vehicle. Do not leave the RKE transmitter in an unattended vehicle. To customize the doors to automatically lock when exiting the vehicle, see Vehicle Personalization 0 139.

Temporary Disable of Passive Locking Feature Temporarily disable the passive locking by pressing and holding K on the interior door switch with a door open for at least four seconds, or until three chimes are heard.

Passive locking will then remain disabled until Q on the interior door is pressed, or until the vehicle is turned on.

Keyless Trunk Opening Press the touch pad under the emblem to open the trunk if the RKE transmitter is within 1 m (3 ft).

Key Access To access a vehicle with a weak transmitter battery, see Door Locks 0 35. Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Any remaining transmitters will need to be reprogrammed. Each vehicle can have up to eight transmitters matched to it.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

31

Programming with a Recognized Transmitter (Key Vehicles Only) To program a new key: 1.

Insert the original, already programmed key in the ignition and turn the key to the ON/ RUN position.

2. Turn the key to LOCK/OFF,

3.

and remove the key. Insert the new key to be programmed and turn it to the ON/RUN position within five seconds. The security light will turn off once the key has been programmed.

4. Repeat Steps 1–3 if additional

keys are to be programmed.

If a key is lost or damaged, see your dealer to have a new key made.

Programming without a Recognized Transmitter (Key Vehicles Only) Program a new key to the vehicle when a recognized key is not available. Canadian regulations require that owners see their dealer.

If there are no currently recognized keys available, follow this procedure to program the first key. This procedure will take approximately 30 minutes to complete for the first key. The vehicle must be off and all of the keys you wish to program must be with you. 1.

Insert the new vehicle key into the ignition.

2. Turn to ON/RUN. The security

light will come on.

3. Wait 10 minutes until the

security light turns off.

4. Turn the ignition to LOCK/OFF. 5. Repeat Steps 2–4 two more

times. After the third time, turn to ON/RUN; the key is learned and all previously known keys will no longer work with the vehicle.

Remaining keys can be learned by following the procedure in “Programming with a Recognized Transmitter (Key Vehicles Only).”

Programming with a Recognized Transmitter (Keyless Access Vehicles Only) A new transmitter can be programmed to the vehicle when there is one recognized transmitter. To program, the vehicle must be off and all of the transmitters, both currently recognized and new, must be with you.

1. Place the recognized

transmitter(s) in the cupholder. The cupholder liner will need to be pulled out to access the transmitter pocket.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

32

2.

Insert the vehicle key of the new transmitter into the key lock cylinder located on the outside of the driver door and turn the key counterclockwise to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays READY FOR REMOTE #2, 3, 4 or 5.

3. Place the new transmitter into the transmitter pocket with the buttons facing up. The transmitter pocket is located inside the center console cupholder.

4. Press the ENGINE START/

STOP button. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter. 5. Remove the transmitter from

the transmitter pocket and press K. To program additional transmitters, repeat Steps 3–5.

2. Wait for 10 minutes until the

DIC displays PRESS ENGINE START BUTTON TO LEARN and then press the ENGINE START/STOP button. The DIC display will again show REMOTE LEARN PENDING, PLEASE WAIT.

3. Repeat Step 2 two additional times. After the third time all previously known transmitters will no longer work with the vehicle. Remaining transmitters can be relearned during the next steps. The DIC display should now show READY FOR REMOTE # 1.

When all additional transmitters are programmed, press and hold the ignition for 12 seconds to exit programming mode. Reinstall the rubber cupliner.

Programming without a Recognized Transmitter (Keyless Access Vehicles Only) If there are no currently recognized transmitters available, follow this procedure to program up to eight transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters you wish to program must be with you. 1.

Insert the vehicle key of the transmitter into the key lock cylinder located on the outside of the driver door and turn the key to the unlock position, counterclockwise, five times within 10 seconds. The Driver Information Center (DIC) displays REMOTE LEARN PENDING, PLEASE WAIT.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

33

6. Remove the transmitter from

the transmitter pocket and press K. To program additional transmitters, repeat Steps 4–6. When all additional transmitters are programmed, press and hold the ENGINE START/ STOP button for 12 seconds to exit programming mode.

Starting the Vehicle with a Low Transmitter Battery If the transmitter battery is weak or if there is interference with the signal , the DIC may display NO REMOTE DETECTED or NO REMOTE KEY WAS DETECTED PLACE KEY IN TRANSMITTER POCKET THEN START YOUR VEHICLE when you try to start the vehicle. The REPLACE BATTERY IN REMOTE KEY message may also be displayed at this time. To start the vehicle: 1. Remove the cupholder liner

from the center console cupholder.

4. Place the new transmitter into the transmitter pocket with the buttons facing up. The transmitter pocket is located inside the center console cupholder. The cupholder liner will need to be pulled out to access the transmitter pocket.

5. Press the ENGINE START/

STOP button. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter.

2. Place the transmitter in the transmitter pocket with the buttons facing up.

3. With the vehicle in P (Park) or

N (Neutral), press the brake pedal and the ENGINE START/ STOP button. See Starting the Engine 0 176 for additional information about the vehicle's keyless ignition with pushbutton start. Replace the transmitter battery as soon as possible.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

34

Keys, Doors, and Windows

Battery Replacement Replace the battery if the REPLACE BATTERY IN REMOTE KEY message displays in the DIC. See Key and Lock Messages 0 134.

Caution

When replacing the battery, do not touch any of the circuitry on the transmitter. Static from your body could damage the transmitter.

The battery is not rechargeable. To replace the battery: 1. Press the button on the

transmitter to extend the key. 2. Remove the battery cover by

prying it with a finger.

3. Remove the battery by pushing

4.

on the battery and sliding it toward the key blade. Insert the new battery, positive side facing up. Push the battery down until it is held in place. Replace with a CR2032
or equivalent battery.

5. Snap the battery cover back on

to the transmitter.

Remote Vehicle Start If equipped, this feature allows the engine to be started from outside the vehicle. / (Remote Vehicle Start) : This button will be on the RKE transmitter if the vehicle has remote start. The climate control system will use the previous settings during a remote start. The rear defog may come on during remote start based on cold ambient conditions. The rear fog indicator light does not come on during remote start. If the vehicle has heated seats, they may come on during a remote start. See Heated Front Seats 0 54. Laws in some local communities may restrict the use of remote starters. For example, some laws require a person using remote start to have the vehicle in view. Check local regulations for any requirements.

Other conditions can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System 0 28.

Starting the Vehicle To start the engine using the remote start feature: 1. Press and release Q.

2.

Immediately press and hold / for at least four seconds or until the turn signal lamps flash. The turn signal lamps flashing confirms the request to remote start the vehicle has been received.

When the engine starts, the parking lamps will turn on and remain on as long as the engine is running. The doors will be locked and the climate control system may come on. The engine will continue to run for 10 minutes. Repeat the steps for a 10-minute time extension. Remote start can be extended only once. Start the vehicle before driving.

Buick Regal Owner Manual 9159380) - 2016 - crc - 6/8/15

(GMNA-Localizing-U.S./Canada/Mexico-

Keys, Doors, and Windows

35

Extending Engine Run Time The engine run time can also be extended by another 10-minutes, if during the first 10 minutes Steps 1–2 are repeated while the engine is still running. An extension can be requested, 30 seconds after starting. This provides a total of 20 minutes. The remote start can only be extended once. When the remote start is extended, the second 10-minute period is added on to the first 10 minutes and the engine will run for a total of 20 minutes. A maximum of two remote starts, or a remote start with an extension, are allowed between ignition cycles. The vehicle's ignition must be changed to ON/RUN/START and then back to OFF before the remote start procedure can be used again.

Canceling a Remote Start To cancel a remote start, do one of the following:

. Aim the RKE transmitter at the vehicle and press and hold / until the parking lamps turn off.

. Turn on the hazard warning

flashers.

. Turn the vehicle on and then off.

Conditions in Which Remote Start Will Not Work . The key is in the ignition (Key Access) or if the key is in the vehicle (Keyless Access).

. The hood is not closed. . The hazard warning flashers

are on.

. The malfunction indicator lamp

is on.

. The engine coolant temperature

is too high.

. The oil pressure is low. . Two remote vehicle starts, or a

single remote start with an extension, have already been used.

. The vehicle is not in P (Park).

Door Locks

{ Warning Unlocked doors can be dangerous.
