VOLVO C70
Owner's manual
Web Edition
Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual. We also urge you and your passengers to wear seat belts at all times in this (or any other) vehicle. And, of course, please do not operate a
vehicle if you may be affected by alcohol, medication or any impair- ment that could hinder your ability to drive. Your Volvo is designed to meet all applicable federal safety and emission standards. If you have any questions regarding your vehicle, please contact your Volvo retailer or see the section "Contacting Volvo" in this manual's "Introduction" chapter for information on get- ting in touch with Volvo in the United States and Canada.
Contents
Important information............................... 10
Environment.............................................. 14
0000 Introduction
Important warnings................................... 15 01
01 Safety
Occupant safety........................................ 18
Seat belts.................................................. 20
Supplemental Restraint System............... 23
Occupant Weight Sensor (OWS).............. 28
Side impact protection airbags................. 31
Door Mounted Inflatable Curtain system
(DMIC) ...................................................... 33
Whiplash Protection System..................... 34
Roll-over Protection system (ROPS) ........ 36
Crash mode.............................................. 37
Child safety............................................... 38
Child restraint systems............................. 40
Infant seats............................................... 42
Convertible seats...................................... 44
Booster cushions...................................... 46
ISOFIX/LATCH lower anchors.................. 47
Child restraint registration and recalls...... 48
0202 Instruments and controls
Instrument overview.................................. 52
Instrument panel....................................... 54
Indicator and warning symbols................. 56
Symbols – instrument panel..................... 58
Information display................................... 61
12-volt sockets......................................... 63
Lighting panel........................................... 64
Left-side steering wheel lever................... 67
Trip computer........................................... 69
Cruise control*.......................................... 71
Right-side steering wheel lever................. 73
Steering wheel adjustment, Hazard warn-
ing flashers................................................ 75
Power windows......................................... 76
Mirrors....................................................... 77
Personal settings...................................... 80
HomeLink® Wireless Control System*..... 82
* Option/accessory, for more information, see Introduction.
Contents
General information.................................. 88
Air vents.................................................... 90
Electronic Climate Control ....................... 91
Front seats................................................ 98
Power retractable hard top .................... 106
Interior lighting........................................ 111
Storage compartments........................... 113
0303 Climate Air distribution........................................... 94 0404 Interior
Trunk ...................................................... 117 0505 Locks and alarm
Remote key and key blade..................... 122
Valet locking ........................................... 126
Keyless drive*.......................................... 128
Locking and unlocking............................ 132
Alarm*..................................................... 134
* Option/accessory, for more information, see Introduction.
Contents
0606 Starting and driving
General information................................ 140
Fuel requirements................................... 143
Ignition switch......................................... 146
Starting the vehicle................................. 147
Starting the vehicle with keyless drive*... 149
Automatic transmission.......................... 150
Shiftlock override.................................... 152
Brake system.......................................... 153
Parking brake.......................................... 156
Stability system....................................... 157
Towing.................................................... 159
Jump starting.......................................... 162
Towing a trailer....................................... 163
Detachable trailer hitch........................... 165
Transporting loads.................................. 166
Blind Spot Information System (BLIS)*... 167
Rear park assist*..................................... 171
Washing and cleaning the car................. 206
Paint touch up......................................... 210
0707 Wheels and tires Tire Pressure Monitoring System (TPMS) 201 0808 Car care
General information................................ 176
Tire inflation............................................. 179
Inflation pressure—U.S. models ............ 181
Inflation pressure—Canadian models .... 182
Tire designations..................................... 183
Glossary of tire terminology.................... 185
Vehicle loading........................................ 186
Uniform tire quality gradings................... 188
Snow chains, snow tires, studded tires.. 189
Temporary spare..................................... 190
Wheel nuts.............................................. 191
Spare tire and jack ................................. 192
Tire Sealing System* .............................. 194
Changing a wheel................................... 199
* Option/accessory, for more information, see Introduction.
Contents
Introduction ............................................ 242
Audio functions....................................... 243
Radio functions....................................... 248
CD player................................................ 256
Audio menu............................................. 259
Volvo maintenance.................................. 214
Maintaining your car............................... 215
Hood....................................................... 217
Engine compartment............................... 218
Engine oil................................................ 219
Fluids...................................................... 221
Wiper blades........................................... 223
Battery..................................................... 224
Replacing bulbs...................................... 226
0909 Maintenance and servicing Fuses...................................................... 233 1010 Audio
Bluetooth® hands-free connection......... 260 1111 Specifications
Label information.................................... 268
Dimensions and weights......................... 270
Fuel, oils, and fluids................................ 273
Engine oil................................................ 274
Engine specifications.............................. 275
Electrical system..................................... 277
Three-way catalytic converter................. 279
Overview of information and warning sym-
bols......................................................... 280
Volvo programs....................................... 282
Contents
Index....................................................... 284
1212 Index
Contents
Introduction
Important information
Contacting Volvo
In the USA:
Volvo Cars of North America, LLC
Customer Care Center
1 Volvo Drive,
P.O. Box 914
Rockleigh, New Jersey 07647
1-800-458-1552
www.volvocars.us
In Canada:
Volvo Cars of Canada Corp
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
www.volvocanada.com
10
About this manual • Before you operate your vehicle for the first
time, please familiarize yourself with the information found in the chapters "Instru- ments and controls" and "Starting and driving."
• Information contained in the balance of the manual is extremely useful and should be read after operating the vehicle for the first time.
• The manual is structured so that it can be
used for reference. For this reason, it should be kept in the vehicle for ready access. Footnotes Certain pages of this manual contain informa- tion in the form of footnotes at the bottom of the page. This information supplements the text that the footnote number refers to (a letter is used if the footnote refers to text in a table). Display texts There are several displays in the driver’s field of vision that show messages generated by various systems and functions in the vehicle. These texts are indicated in the Owner’s Man- ual by being in slightly larger type than the sur- rounding text and are printed in gray, (for example: Doors automatic lock).
Decals There are various types of decals in the vehicle whose purpose is to provide important infor- mation in a clear and concise way. The impor- tance of these decals is explained as follows, in descending order of importance. Risk of injury
G031590
Black ISO symbols on a yellow warning back- ground, white text/image on a black back- ground. Decals of this type are used to indicate potential danger. Ignoring a warning of this type could result in serious injury or death.
Risk of damage to the vehicle
Information
White ISO symbols and white text/image on a black or blue warning background and space for a message. If the information on decals of this type is ignored, damage to the vehicle could result.
White ISO symbols and white text/image on a black background. These decals provide gen- eral information.
NOTE
The decals shown in the Owner’s Manual are examples only and are not intended to be reproductions of the decals actually used in the vehicle. The purpose is to give an indi- cation of how they look and their approxi- mate location in the vehicle. The applicable information for your particular vehicle can be found on the respective decals in the vehicle.
Introduction
Important information
Types of lists used in the manual Procedures Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual.
If there is a series of illustrations associated with step-by-step instructions, each step in the procedure is numbered in the same way as the corresponding illustration. Lists in which letters are used can be found with series of illustrations in cases where the order in which the instructions are car- ried out is not important. Arrows with or without numbers are used to indicate the direction of a movement. If there are no illustrations associated with a step-by-step list, the steps in the procedure are indicated by ordinary numbers. Position lists
Red circles containing a number are used in general overview illustrations in which certain components are pointed out. The corresponding number is also used in the position list's description of the various components.
11
Introduction
Important information
Bullet lists Bullets are used to differentiate a number of components/functions/points of information that can be listed in random order. For example: • Coolant • Engine oil Continued `` `This symbol can be found at the lower right corner of an odd-numbered (right-hand) page to indicate that the current topic is continued on the following page.
Options and accessories Optional or accessory equipment described in this manual is indicated by an asterisk. Optional or accessory equipment may not be available in all countries or markets. Please note that some vehicles may be equipped dif- ferently, depending on special legal require- ments. Contact your Volvo retailer for additional infor- mation.
12
NOTE
WARNING
• All information, illustrations and specifi-
cations contained in this manual are based on the latest product information available at the time of publication.
• Volvo reserves the right to make model changes at any time, or to change spec- ifications or design without notice and without incurring obligation.
• Do not export your Volvo to another
country before investigating that coun- try's applicable safety and emission control requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.
WARNING
If your vehicle is involved in an accident, unseen damage may affect its drivability and safety.
CALIFORNIA proposition 65
Engine exhaust, some of its constituents,
and certain vehicle components contain or
emit chemicals known to the state of Cali-
fornia to cause cancer, and birth defects or
other reproductive harm. In addition, certain
fluids contained in vehicles and certain
products of component wear contain or
emit chemicals known to the State of Cali-
fornia to cause cancer, and birth defects or
other reproductive harm.
WARNING
Certain components of this vehicle such as air bag modules, seat belt pretensioners, adaptive steering columns, and button cell batteries may contain Perchlorate material. Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/hazardouswaste/ perchlorate.
Shiftlock (automatic transmission) When your vehicle is parked, the gear selector is locked in the P (Park) position. To release the selector from this position, turn the ignition key to position II (or start the engine), depress the brake pedal, press the button on the front side of the gear selector and move the selector from P (Park).
Keylock (automatic transmission) When you switch off the ignition, the gear selector must be in the P (Park) position before the remote key can be removed from the igni- tion switch.
Anti-lock Brake System (ABS) The ABS system in your vehicle performs a self-diagnostic test when the vehicle first rea- ches the speed of approximately 12 mph (20 km/h). The brake pedal will pulsate several times and a sound may be audible from the ABS control module. This is normal.
Fuel filler door Press the button on the light switch panel (see the illustration on page 66) when the vehicle is at a standstill to unlock the fuel filler door. Please note that the fuel filler door will remain unlocked until the vehicle begins to move for- ward. An audible click will be heard when the fuel filler door relocks.
Fuel filler cap The fuel filler door, located on the right rear quarter panel, is connected to your vehicle's central locking system.
Points to keep in mind • Do not export your Volvo to another coun-
try before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be dif- ficult or impossible to comply with these requirements. Modifications to the emis- sion control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.
• All information, illustrations and specifica- tions contained in this manual are based on the latest product information available at the time of publication. Please note that some vehicles may be equipped differ- ently, depending on special legal require- ments. Optional equipment described in this manual may not be available in all mar- kets.
• Volvo reserves the right to make model
changes at any time, or to change specifi- cations or design without notice and with- out incurring obligation.
Introduction
Important information
Vehicle event data (Black box) Your vehicle's driving and safety systems employ computers that monitor, and share with each other, information about your vehi- cle's operation. One or more of these comput- ers may store what they monitor, either during normal vehicle operation or in a crash or near- crash event. Stored information may be read and used by: • Volvo Car Corporation • service and repair facilities • law enforcement or government agencies • others who may assert a legal right to
know, or who obtain your consent to know such information.
13
Recycling As part of Volvo’s commitment to the environ- ment, it is essential for the vehicle to be recy- cled in an environmentally sound way. Almost the entire vehicle can be recycled and for that reason, the vehicle’s final owner is requested to contact a Volvo retailer for information about approved and certified recycling facilities.
Introduction
Environment
Volvo and the environment Volvo is committed to the well being of its cus- tomers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environ- mental impact. Volvo's environmental activities are based on a holistic view, which means we consider the overall environmental impact of a product throughout its complete life cycle. In this context, design, production, product use, and recycling are all important considerations. In production, Volvo has partly or completely phased out several chemicals including CFCs, lead chromates, asbestos, and cadmium; and reduced the number of chemicals used in our plants 50% since 1991. Volvo was the first in the world to introduce into production a three-way catalytic converter with a Lambda sond, now called the heated oxygen sensor, in 1976. The current version of this highly efficient system reduces emissions of harmful substances (CO, HC, NOx) from the exhaust pipe by approximately 95 – 99% and the search to eliminate the remaining emis- sions continues. Volvo is the only automobile manufacturer to offer CFC-free retrofit kits for the air conditioning system of all models as far back as the 1975 model 240. Advanced elec- tronic engine controls and cleaner fuels are bringing us closer to our goal. In addition to
14
continuous environmental refinement of con- ventional gasoline-powered internal combus- tion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles.
When you drive a Volvo, you become our part- ner in the work to lessen the car's impact on the environment. To reduce your vehicle's environmental impact, you can: • Maintain proper air pressure in your tires. Tests have shown decreased fuel econ- omy with improperly inflated tires.
• Follow the recommended maintenance schedule in your Warranty and Service Records Information booklet.
• Drive at a constant speed whenever pos-
sible.
• See a trained and qualified Volvo service technician as soon as possible for inspec- tion if the check engine (malfunction indi- cator) light illuminates, or stays on after the vehicle has started.
• Properly dispose of any vehicle-related
waste such as used motor oil, used batter- ies, brake pads, etc.
• When cleaning your vehicle, please use
genuine Volvo car care products. All Volvo car care products are formulated to be environmentally friendly.
Driver distraction A driver has a responsibility to do everything possible to ensure his or her own safety and the safety of passengers in the vehicle and oth- ers sharing the roadway. Avoiding distractions is part of that responsibility. Driver distraction results from driver activities that are not directly related to controlling the vehicle in the driving environment. Your new Volvo is, or can be, equipped with many fea- ture-rich entertainment and communication systems. These include hands-free cellular tel- ephones, navigation systems, and multipur- pose audio systems. You may also own other portable electronic devices for your own con- venience. When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction. For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety. Never use these devi- ces or any feature of your vehicle in a way that distracts you from the task of driving safely. Distraction can lead to a serious accident. In addition to this general warning, we offer the following guidance regarding specific newer features that may be found in your vehicle • Never use a hand-held cellular telephone while driving. Some jurisdictions prohibit
cellular telephone use by a driver while the vehicle is moving.
• If your vehicle is equipped with a naviga- tion system, set and make changes to your travel itinerary only with the vehicle parked.
• Never program your audio system while the vehicle is moving. Program radio pre- sets with the vehicle parked, and use your programmed presets to make radio use quicker and simpler.
• Never use portable computers or personal digital assistants while the vehicle is mov- ing.
Accessory installation • We strongly recommend that Volvo owners
install only genuine, Volvo-approved accessories, and that accessory installa- tions be performed only by a trained and qualified Volvo service technician.
• Genuine Volvo accessories are tested to
ensure compatibility with the performance, safety, and emission systems in your vehi- cle. Additionally, a trained and qualified Volvo service technician knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult a trained and qualified Volvo serv- ice technician before installing any acces- sory in or on your vehicle.
Introduction
Important warnings
• Accessories that have not been approved
by Volvo may or may not be specifically tested for compatibility with your vehicle. Additionally, an inexperienced installer may not be familiar with some of your car's systems.
• Any of your car's performance and safety systems could be adversely affected if you install accessories that Volvo has not tes- ted, or if you allow accessories to be instal- led by someone unfamiliar with your vehi- cle.
• Damage caused by unapproved or
improperly installed accessories may not be covered by your new vehicle warranty. See your Warranty and Service Records Information booklet for more warranty information. Volvo assumes no responsi- bility for death, injury, or expenses that may result from the installation of non-gen- uine accessories.
15
Occupant safety...................................................................................... 18
Seat belts................................................................................................ 20
Supplemental Restraint System.............................................................. 23
Occupant Weight Sensor (OWS)............................................................. 28
Side impact protection airbags............................................................... 31
Door Mounted Inflatable Curtain system (DMIC) ................................... 33
Whiplash Protection System................................................................... 34
Roll-over Protection system (ROPS) ...................................................... 36
Crash mode............................................................................................ 37
Child safety............................................................................................. 38
Child restraint systems........................................................................... 40
Infant seats.............................................................................................. 42
Convertible seats.................................................................................... 44
Booster cushions.................................................................................... 46
ISOFIX/LATCH lower anchors................................................................. 47
Child restraint registration and recalls.................................................... 48
16
SAFETY
01 Safety
01
Occupant safety
Volvo's concern for safety Safety is Volvo's cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy- absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation. We will not compromise our commitment to safety. We continue to seek out new safety features and to refine those already in our cars. You can help. We would appreciate hearing your suggestions about improving automobile safety. We also want to know if you ever have a safety concern with your car. Call us in the U.S. at: 1-800-458-1552 or in Canada at: 1-800-663-8255.
Occupant safety reminders How safely you drive doesn't depend on how old you are but rather on: • How well you see. • Your ability to concentrate. • How quickly you make decisions under
stress to avoid an accident.
The following suggestions are intended to help you cope with the ever changing traffic envi- ronment.
• Never drink and drive. • If you are taking any medication, consult your physician about its potential effects on your driving abilities.
• Take a driver-retraining course. • Have your eyes checked regularly. • Keep your windshield and headlights
clean.
• Replace wiper blades when they start to
leave streaks.
• Take into account the traffic, road, and
weather conditions, particularly with regard to stopping distance.
Reporting safety defects in the U.S. If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Volvo Cars of North Amer- ica, LLC. If NHTSA receives similar complaints, it may open an investiga- tion, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
However, NHTSA cannot become
involved in individual problems
between you, your retailer, or Volvo
Cars of North America, LLC. To con-
tact NHTSA, you may either call the
Auto Safety Hotline toll-free at
1-888-327-4236
(TTY: 1-800-424-9153) or write to:
NHTSA, U.S. Department of Trans-
portation, Washington D.C. 20590.
You can also obtain other information
about motor vehicle safety from:
http://www.safercar.gov
Volvo strongly recommends that if
your vehicle is covered under a serv-
ice campaign, safety or emission
recall or similar action, it should be
completed as soon as possible.
Please check with your local retailer
or Volvo Cars of North America, LLC
if your vehicle is covered under these
conditions.
NHTSA can be reached at:
Internet:
18
http://www.nhtsa.gov Telephone: 1-888-DASH-2-DOT (1-888-327-4236).
Reporting safety defects in Canada If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans- port Canada in addition to notifying Volvo Cars of Canada Corp. To contact Transport Canada, call (800) 333-0510, or (613) 993-9851 if you are calling from the Ottawa region.
01 Safety
Occupant safety
01
19
01 Safety
01
Seat belts
Using seat belts
Adjusting the seat belt Seat belts should always be worn by all occu- pants of your vehicle. Children should be prop- erly restrained, using an infant, car, or booster seat determined by age, weight and height. Volvo also believes no child should sit in the front seat of a vehicle. Most states and provinces make it mandatory for occupants of a vehicle to use seat belts.
Seat belt pretensioners All seat belts are equipped with pretensioners that reduce slack in the belts. These preten- sioners are triggered in situations where the front or side impact airbags deploy, and in cer-
20
tain impacts from the rear. The front seat belts also include a tension reducing device which, in the event of a collision, limits the peak forces exerted by the seat belt on the occupant.
Buckling a seat belt Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far.
NOTE
The seat belt is easiest to reach by grasping it near the lower seat belt guide, not over the shoulder.
The seat belt retractor will lock up in the fol- lowing situations: • if the belt is pulled out rapidly • during braking and acceleration • if the vehicle is leaning excessively • when driving in turns • if the Automatic Locking Retractor/Emer- gency Locking Retractor (ALR/ELR) is acti- vated
NOTE
Each seat belt (except for the driver's belt) is equipped with the ALR/ELR function, which is designed to help keep the seat belt taut. ALR/ELR activates if the seat belt is pulled out as far as possible. If this is done, a sound from the seat belt retractor will be audible, which is normal, and the seat belt will be pulled taut and locked in place. This function is automatically disabled when the seat belt is unbuckled and fully retracted.
See also page 39 for information about using a seat belt's ALR/ELR function to anchor a child seat.
When wearing the seat belt remember: • The belt should not be twisted or turned. • The lap section of the belt must be posi- tioned low on the hips (not pressing against the abdomen).
• Make sure that the shoulder belt is rolled up into its retractor and that the shoulder and lap belts are taut.
Unbuckling the seat belt • To remove the seat belt, press the red sec-
tion on the seat belt receptacle. Before exiting the vehicle, check that the seat belt retracts fully after being unbuckled. If nec- essary, guide the belt back into the retrac- tor slot.
WARNING
Never use a seat belt for more than one occupant. Never wear the shoulder portion of the belt under the arm, behind the back or otherwise out of position. Such use could cause injury in the event of an accident. As seat belts lose much of their strength when exposed to violent stretching, they should be replaced after any collision, even if they appear to be undamaged.
WARNING
• Never repair the belt yourself; have this
work done by a trained and qualified Volvo service technician only.
• Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection avail- able to you in the event of a collision. • The seat back should not be tilted too far back. The shoulder belt must be taut in order to function properly.
• Do not use child safety seats or child
booster cushions/backrests in the front passenger's seat. We also recommend that children who have outgrown these devices sit in the rear seat with the seat belt properly fastened.
Seat belt guides
Seat belt use during pregnancy
01 Safety
Seat belts
01
Seat belt guides (on both front seats) These guides are designed to help provide easier access to the seat belts. A belt can be taken out of the guide and slid to the rearmost part of the lower seat belt anchorage rod to make it easier for passengers to enter or exit the rear seat.
The seat belt should always be worn during pregnancy. But it is crucial that it be worn in the correct way. The diagonal section should wrap over the shoulder then be routed between the breasts and to the side of the belly. The lap section should lay flat over the thighs and as low as possible under the belly. It must never be allowed to ride upward. Remove all slack from the belt and insure that it fits close to the body without any twists. As a pregnancy progresses, pregnant drivers should adjust their seats and steering wheel such that they can easily maintain control of the vehicle as they drive (which means they must be able to easily operate the foot pedals and
``
21
Seat belt maintenance Check periodically that the seat belts are in good condition. Use water and a mild deter- gent for cleaning. Check seat belt mechanism function as follows: attach the seat belt and pull rapidly on the strap.
01 Safety
01
Seat belts
steering wheel). Within this context, they should strive to position the seat with as large a distance as possible between their belly and the steering wheel.
Child seats Please refer to page 40 for information on securing child seats with the seat belts.
Seat belt reminder
Seat belt reminder light in ceiling console The seat belt reminder consists of an audible signal, an indicator light near the rearview mir- ror and a symbol in the instrument panel that alert all occupants of the vehicle to fasten their
22
seat belts. The audible signal and warning light will be on for a total of 6 seconds from the time the ignition is switched on, regardless of whether or not the seat belts are fastened. If the front seat belts are unbuckled while the vehicle is in motion, the audible signal and warning light will be active for a total of 6 sec- onds.
Rear seats The seat belt reminder in the rear seat has two additional functions: • It provides information about which seat belts are fastened in the rear seat. A mes- sage will appear in the information display when a belt is being used. This message will disappear after approximately 6 sec- onds or can be erased by pressing the READ button on the left steering wheel lever.
• It also provides a reminder if one of the
occupants of the rear seat has unbuckled his/her seat belt while the vehicle is in motion. A visual and audible signal will be given. These signals will stop when the seat belt has been re-buckled or can be stopped by pressing the READ button. The message in the information display can always be accessed, even if it has been erased, by pressing the READ button to display stored messages.
Where applicable, a text message will also be displayed when the SRS warning light illumi- nates. If this warning symbol is not functioning properly, the general warning symbol illumi- nates and either SRS AIRBAG SERVICE URGENT or SRS AIRBAG SERVICE REQUIREDwill be displayed.
WARNING
• If the SRS warning light stays on after the engine has started or if it illuminates while you are driving, have the vehicle inspected by a trained and qualified Volvo service technician as soon as possible.
• Never try to repair any component or part of the SRS yourself. Any interfer- ence in the system could cause mal- function and serious injury. All work on these systems should be performed by a trained and qualified Volvo service technician.
Supplemental Restraint System (SRS)
SRS warning light As an enhancement to the three-point seat belts, your Volvo is equipped with a Supple- mental Restraint System (SRS). Volvo's SRS consists of seat belt pretensioners, front air- bags, side impact airbags, the occupant weight sensor, and door-mounted inflatable curtains. All of these systems are monitored by the SRS control module. An SRS warning light in the instrument panel (see the illustration) illu- minates when the ignition key is turned to posi- tion I, II, or III, and will normally go out after approximately 7 seconds if no faults are detected in the system.
01 Safety
Supplemental Restraint System
01
WARNING
If your vehicle has been subjected to flood conditions (e.g. soaked carpeting/standing water on the floor of the vehicle) or if your vehicle has become flood-damaged in any way, do not attempt to start the vehicle or put the key in the ignition before discon- necting the battery (see below). This may cause airbag deployment which could result in personal injury. Have the vehicle towed to a trained and qualified Volvo service tech- nician for repairs. Automatic transmission Before attempting to tow the vehicle, use the following procedure to override the shiftlock system to move the gear selector to the neutral position: 1. Switch off the ignition for at least
10 minutes and disconnect the battery.
2. Wait at least one minute. 3.
Insert the key in the ignition and turn it to position II.
4. Press firmly on the brake pedal. 5. Move the gear selector from Park (P) to the Neutral (N) position, see page 152, for information on manually overriding the shiftlock system.
``
23
01 Safety
01
Supplemental Restraint System
The front airbag system
The front airbags supplement the three-point seat belts. For these airbags to provide the protection intended, seat belts must be worn at all times. The front airbag system includes gas genera- tors surrounded by the airbags, and decelera- tion sensors that activate the gas generators, causing the airbags to be inflated with nitrogen gas.
Location of the passenger's side front airbag As the movement of the seats' occupants com- presses the airbags, some of the gas is expel- led at a controlled rate to provide better cush- ioning. Both seat belt pretensioners also deploy, minimizing seat belt slack. The entire process, including inflation and deflation of the airbags, takes approximately one fifth of a sec- ond. The location of the front airbags is indicated by SRS AIRBAG embossed on the steering wheel pad and above the glove compartment, and by decals on both sun visors and on the front and far right side of the dash.
24
• The driver's side front airbag is folded and
located in the steering wheel hub.
• The passenger's side front airbag is folded
behind a panel located above the glove compartment.
WARNING
• The airbags in the vehicle are designed to be a SUPPLEMENT to-not a replace- ment for-the three-point seat belts. For maximum protection, wear seat belts at all times. Be aware that no system can prevent all possible injuries that may occur in an accident.
• Never drive a vehicle with your hands on the steering wheel pad/airbag housing. • The front airbags are designed to help
prevent serious injury. Deployment occurs very quickly and with consider- able force. During normal deployment and depending on variables such as seating position, one may experience abrasions, bruises, swellings, or other injuries as a result from deployment of one or both of the airbags.
• When installing any accessory equip- ment, make sure that the front airbag system is not damaged. Any interfer- ence in the system could cause mal- function.
Front airbag deployment • The front airbags are designed to deploy during certain frontal or front-angular col- lisions, impacts, or decelerations, depend- ing on the crash severity, angle, speed and object impacted. The airbags may also deploy in certain non-frontal collisions where rapid deceleration occurs.
• The SRS sensors, which trigger the front airbags, are designed to react to both the impact of the collision and the inertial forces generated by it, and to determine if the intensity of the collision is sufficient for the seat belt pretensioners and/or airbags to be deployed.
However, not all frontal collisions activate the front airbags. • If the collision involves a nonrigid object
(e.g., a snow drift or bush), or a rigid, fixed object at a low speed, the front airbags will not necessarily deploy.
• Front airbags do not normally deploy in a side impact collision, in a collision from the rear or in a rollover situation.
• The amount of damage to the bodywork does not reliably indicate if the airbags should have deployed or not.
NOTE
• Deployment of front airbags occurs only one time during an accident. In a colli- sion where deployment occurs, the air- bags and seat belt pretensioners acti- vate. Some noise occurs and a small amount of powder is released. The release of the powder may appear as smoke-like matter. This is a normal characteristic and does not indicate fire. • Volvo's front airbags use special sen- sors that are integrated with the front seat buckles. The point at which the air- bag deploys is determined by whether or not the seat belt is being used, as well as the severity of the collision.
• Collisions can occur where only one of the airbags deploys. If the impact is less severe, but severe enough to present a clear injury risk, the airbags are trig- gered at partial capacity. If the impact is more severe, the airbags are triggered at full capacity.
Should you have questions about any compo- nent in the SRS system, please contact a trained and qualified Volvo service technician or Volvo customer support: In the USA
01 Safety
Supplemental Restraint System
01
Volvo Cars of North America, LLC
Customer Care Center
1 Volvo Drive
P.O. Box 914
Rockleigh, New Jersey 07647
1-800-458-1552
www.volvocars.us
In Canada
Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
1-800-663-8255
www.volvocanada.com
``
25
01 Safety
01
Supplemental Restraint System
WARNING
• Do not use child safety seats or child
booster cushions/backrests in the front passenger's seat. We also recommend that occupants under 4 feet 7 inches (140 cm) in height who have outgrown these devices sit in the rear seat with the seat belt fastened1.
• Never drive with the airbags deployed. The fact that they hang out can impair the steering of your vehicle. Other safety systems can also be damaged. • The smoke and dust formed when the airbags are deployed can cause skin and eye irritation in the event of pro- longed exposure.
1 See also the Occupant Weight Sensor information on page 28.
26
Passenger's side airbag decal
Airbag decal on the outside of both sun visors
01 Safety
Supplemental Restraint System
01
WARNING
WARNING
• Children must never be allowed in the
front passenger's seat.
• Occupants in the front passenger's seat must never sit on the edge of the seat, sit leaning toward the instrument panel or otherwise sit out of position.
• The occupant's back must be as upright
as comfort allows and be against the seat back with the seat belt properly fastened.
• Feet must be on the floor, e.g., not on
the dash, seat or out of the window.
• No objects or accessory equipment,
e.g. dashboard covers, may be placed on, attached to, or installed near the air bag hatch (the area above the glove compartment) or the area affected by airbag deployment.
• There should be no loose articles, e.g. coffee cups, on the floor, seat, or dash- board area.
• Never try to open the airbag cover on the steering wheel or the passenger's side dashboard. This should only be done by a trained and qualified Volvo service technician.
• Failure to follow these instructions can result in injury to the vehicle occupants.
27
01 Safety
01
Occupant Weight Sensor (OWS)
Disabling the passenger's side front airbag
Occupant Weight Sensor (OWS) indicator light Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the rear seat of any vehi- cle with a passenger's side front airbag, and be properly restrained. Children should always be seated in child restraints appropriate for their size and weight. See also the child safety rec- ommendations on page 38. The Occupant Weight Sensor (OWS) is designed to meet the regulatory requirements of Federal Motor Vehicle Safety Standard (FMVSS) 208 and is designed to disable (will
28
The OWS uses a PASSENGER AIRBAG OFF indicator lamp which will illuminate and stay on to remind you that the passenger's side front airbag is disabled. The PASSENGER AIRBAG OFF indicator lamp is located in the overhead console, near the base of the rearview mirror.
NOTE
When the ignition is switched on, the OWS indicator light will go on for up to 10 seconds while the system performs a self-diagnostic test.
However, if a fault is detected in the system: • The OWS indicator light will stay on • The SRS warning light (see page 23) will
come on and stay on
The message PASS. AIRBAG OFF SERVICE URGENTwill be displayed in the information display.
not inflate) the passenger's side front airbag under certain conditions. The OWS works with sensors that are part of the front passenger's seat and seat belt. The sensors are designed to detect the presence of a properly seated occupant and determine if the passenger's side front airbag should be enabled (may inflate) or disabled (will not inflate). The OWS will disable (will not inflate) the pas- senger's side front airbag when: • the front passenger's seat is unoccupied, or has small/medium objects in the front seat,
• the system determines that an infant is
present in a rear-facing infant seat that is installed according to the manufacturer's instructions,
• the system determines that a small child is present in a forward-facing child restraint that is installed according to the manufac- turer's instructions,
• the system determines that a small child is
present in a booster seat,
• a front passenger takes his/her weight off
of the seat for a period of time,
• a child or a small person occupies the front
passenger's seat.
WARNING
If a fault in the system is detected and indi- cated as explained on the preceding page, be aware that the passenger's side front air- bag will not deploy in the event of a collision. In this case, the SRS system and Occupant Weight Sensor should be inspected by a trained and qualified Volvo service techni- cian as soon as possible.
WARNING
• Never try to open, remove, or repair any components in the OWS system. This could result in system malfunction. Maintenance or repairs should only be carried out by an a trained and qualified Volvo service technician.
• The front passenger's seat should not
be modified in any way. This could reduce pressure on the seat cushion, which might interfere with the OWS sys- tem's function.
The OWS is designed to disable (will not inflate) the passenger's side front airbag when a rear facing infant seat, a forward-facing child restraint, or a booster seat is detected. The PASSENGER AIRBAG OFF indicator lamp will illuminate and stay on to remind you that the
passenger's side front airbag is disabled (see the following table).
Passenger's seat occu- pancy status
OWS indica- tor light sta- tus
Passenger's side front airbag sta- tus
Passenger's side front airbag disa- bled
Passenger's side front airbag disa- bled
OWS indica- tor light
lights
up
OWS indica- tor light
lights
up
OWS indica- tor light
is not
lit
Passenger's side front airbag ena- bled
Seat unoc- cupied
Seat occu- pied by low weight occupant/ objectA
Seat occu- pied by heavy occu- pant/object
A Volvo recommends that children always be properly
restrained in appropriate child restraints in the rear seats. Do not assume that the passenger's side front airbag is disabled unless the PASSENGER AIRBAG OFF indicator lamp is lit. Make sure the child restraint is properly installed. If there is any doubt as to the status of the passenger's side front air- bag, move the child restraint to the rear seat.
The OWS is designed to enable (may inflate) the passenger's side front airbag in the event of a collision anytime the system senses that a
01 Safety
Occupant Weight Sensor (OWS)
01
person of adult size is sitting properly in the front passenger's seat. The PASSENGER AIRBAG OFF indicator lamp will be off and remain off. If a person of adult size is sitting in the front passenger's seat, but the PASSENGER AIRBAG OFF indicator lamp is on, it is possible that the person isn't sitting properly in the seat. If this happens: 1. Turn the vehicle off and ask the person to place the seatback in an upright position.
2. Have the person sit upright in the seat,
centered on the seat cushion, with the per- son's legs comfortably extended.
3. Restart the vehicle and have the person
4.
remain in this position for about two minutes. This will allow the system to detect that person and enable the pas- senger's frontal airbag. If the PASSENGER AIRBAG OFF indicator lamp remains on even after this, the person should be advised to ride in the rear seat. This condition reflects limitations of the OWS classification capability. It does not indicate OWS malfunction.
Modifications If you are considering modifying your vehicle in any way to accommodate a disability, for
``
29
01 Safety
01
Occupant Weight Sensor (OWS)
example by altering or adapting the driver's or
front passenger's seat(s) and/or airbag sys-
tems, please contact Volvo at:
In the USA
Volvo Cars of North America, LLC
Customer Care Center
1 Volvo Drive
P.O. Box 914
Rockleigh, New Jersey 07647
1-800-458-1552
In Canada
Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road North York, Ontario
M2H 2N7
1-800-663-8255
30
WARNING
WARNING
• No objects that add to the total weight
on the seat should be placed on the front passenger's seat. If a child is seated in the front passenger's seat with any additional weight, this extra weight could cause the OWS system to enable the airbag, which might cause it to deploy in the event of a collision, thereby injuring the child.
• The seat belt should never be wrapped around an object on the front passeng- er's seat. This could interfere with the OWS system's function.
• The front passenger's seat belt should never be used in a way that exerts more pressure on the passenger than normal. This could increase the pressure exer- ted on the weight sensor by a child, and could result in the airbag being enabled, which might cause it to deploy in the event of a collision, thereby injuring the child.
Keep the following points in mind with respect to the OWS system. Failure to follow these instructions could adversely affect the system's function and result in serious injury to the occupant of the front passenger's seat: • The full weight of the front seat passen- ger should always be on the seat cush- ion. The passenger should never lift him/herself off the seat cushion using the armrest in the door or the center console, by pressing the feet on the floor, by sitting on the edge of the seat cushion, or by pressing against the backrest in a way that reduces pressure on the seat cushion. This could cause OWS to disable the passenger's side front airbag.
• Do not place any type of object on the front passenger's seat in such a way that jamming, pressing, or squeezing occurs between the object and the front seat, other than as a direct result of the correct use of the Automatic Locking Retractor/Emergency Locking Retrac- tor (ALR/ELR) seat belt, see page 39.
• No objects should be placed under the front passenger's seat. This could inter- fere with the OWS system's function.
Side impact airbags – front seats only
Driver's side SIPS airbag
Location of the side impact (SIPS) airbag As an enhancement to the structural side impact protection built into your car, the car is also equipped with Side Impact Protection System (SIPS) airbags. The SIPS airbag system is designed to help increase occupant protection in the event of certain side impact collisions. The SIPS air- bags are designed to deploy only during cer- tain side-impact collisions, depending on the crash severity, angle, speed and point of impact.
Passenger's side SIPS airbag
01 Safety
Side impact protection airbags
01
NOTE
SIPS airbag deployment (one airbag) occurs only on the side of the vehicle affected by the impact. The airbags are not designed to deploy in all side impact situations.
Components in the SIPS airbag system This SIPS airbag system consists of gas gen- erators and side airbag modules built into the outboard sides of both front seat backrests.
``
31
01 Safety
01
Side impact protection airbags
WARNING
• The SIPS airbag system is a supple-
ment to the structural Side Impact Pro- tection System and the three-point seat belt system. It is not designed to deploy during collisions from the front or rear of the car or in rollover situations.
• The use of seat covers on the front seats may impede SIPS airbag deployment. • No objects, accessory equipment or
stickers may be placed on, attached to or installed near the SIPS airbag system or in the area affected by SIPS airbag deployment.
• Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician.
• In order for the SIPS airbag to provide
its best protection, both front seat occupants should sit in an upright posi- tion with the seat belt properly fastened. • Failure to follow these instructions can result in injury to the occupants of the vehicle in the event of an accident.
32
01 Safety
Door Mounted Inflatable Curtain system (DMIC)
01
WARNING
• The DMIC system is a supplement to
the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the vehicle. It only provides protection for the occu- pants of the front seats.
• There is a risk of injury if the driver or
front seat passenger leans on or against the door panel when the DMIC deploys. • Never install or mount any equipment on the insides of the doors, door pillars, or side panels. This could impede the function of the DMIC system.
• Never try to open or repair any compo- nents of the DMIC system. This should be done only by a trained and qualified Volvo service technician.
The DMIC is a supplement to the structural side impact protection. These inflatable curtains are concealed in the upper section of both doors. • The Inflatable Curtain (DMIC) and the Side
Impact Airbag System (SIPS airbag) will both deploy in certain side impacts.
• DMIC deployment can occur regardless of whether the power retractable hard top is up or down.
WARNING
In order for the DMIC to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened; adults using the seat belt and children using the proper child restraint system. Only adults should sit in the front seats. Children must never be allowed in the front passenger seat. See page 39 for guidelines. Failure to follow these instructions can result in injury to the vehicle occupants in an accident.
33
01 Safety
01
Whiplash Protection System
Whiplash Protection System (WHIPS) – front seats only
The WHIPS system consists of specially designed hinges and brackets on the front seat backrests designed to help absorb some of the energy generated in a collision from the rear (when the vehicle is "rear-ended"). In the event of a collision of this type, the hinges and brackets of the front seat backrests are designed to change position slightly to allow the backrest/head restraint to help support the occupant's head before moving slightly rear- ward. This movement helps absorb some of the forces that could result in whiplash.
WARNING
WARNING
• The WHIPS system is designed to sup-
plement the other safety systems in your car. For this system to function properly, the three-point seat belt must be worn. Please be aware that no sys- tem can prevent all possible injuries that may occur in an accident.
• The WHIPS system is designed to func- tion in certain collisions from the rear, depending on the crash severity, angle and speed.
• Occupants in the front seats must never sit out of position. The occupant's back must be as upright as comfort allows and be against the seat back with the seat belt properly fastened.
• If your car has been involved in a rear- end collision, the front seat backrests must be inspected by a trained and qualified Volvo service technician, even if the seats appear to be undamaged.
34
Certain components in the WHIPS sys- tem may need to be replaced.
• Do not attempt to service any compo-
nent in the WHIPS system yourself.
WARNING
Boxes, suitcases, etc. wedged behind the front seats could impede the function of the WHIPS system.
01 Safety
Whiplash Protection System
01
35
NOTE
If ROPS has deployed, the system should be inspected by a trained and qualified Volvo service technician.
WARNING
• The rear seat of the Volvo C70 is
intended for two occupants, and only two rear seat belts are provided. The center section of the seat should never be used to seat a passenger.
• No objects should be placed over the roll bars or behind the rear seat head restraints.
• All repairs or maintenance to the ROPS system should only be performed by a trained and qualified Volvo service tech- nician.
01 Safety
01
Roll-over Protection system (ROPS)
Introduction
Deployed ROPS roll bars The ROPS system consists of two roll bars located behind the rear seat head restraints, and a sensor that monitors the roll or pitch angle of the vehicle. If the vehicle rolls or pitches beyond a preset angle, or in the event of a rear-end collision of sufficient force, the roll bars are automatically deployed (raised). The ROPS system is designed to function regardless of whether the power retractable hard top is up or down. By design, the tops of the roll bars are equipped with a point in order to pierce the rear window if the top is up.
36
Driving after a collision
fuel lines, sensors for one of the safety sys- tems, the brake system, etc.
WARNING
• Never attempt to repair the vehicle
yourself or to reset the electrical system after the vehicle has displayed CRASH MODE SEE MANUAL. This could result in injury or improper system func- tion.
• Restoring the vehicle to normal operat-
ing mode should only be done by a trained and qualified Volvo service tech- nician.
• After CRASH MODE SEE MANUAL has been displayed, if you detect the odor of fuel vapor, or see any signs of fuel leakage, do not attempt to start the vehicle. Leave the vehicle immediately.
Attempting to start the vehicle If damage to the vehicle is minor and there is no fuel leakage, you may attempt to start the vehicle. To do so: 1. Remove the ignition key or optional keyless
drive start control, see page 149.
2. Reinsert the key or start control in the igni- tion switch. The vehicle will then attempt to reset CRASH MODE to normal mode.
If the vehicle has been involved in a collision, the text CRASH MODE SEE MANUAL may appear in the information display. This indi- cates that the vehicle's functionality has been reduced. This text can only be shown if the display is undamaged and the vehicle's electrical system is intact. CRASH MODE is a feature that is triggered if one or more of the safety systems (for example, front or side airbags, an inflatable curtain, or one or more of the seat belt pretensioners) has deployed. The collision may have damaged an important function in the vehicle, such as the
01 Safety
Crash mode
01
3. Try to start the vehicle.
Moving the vehicle If the electrical system is able to reset system status to normal (CRASH MODE SEE MANUAL will no longer be displayed), the vehicle may be moved carefully from its pres- ent position, if for example, it is blocking traffic. It should, however, not be moved farther than is absolutely necessary.
WARNING
Even if the vehicle appears to be drivable after CRASH MODE has been set, it should not be driven or towed (pulled by another vehicle). There may be concealed damage that could make it difficult or impossible to control. The vehicle should be transported on a flatbed tow truck to a trained and quali- fied Volvo service technician for inspection/ repairs.
37
01 Safety
01
Child safety
Children should be seated safely Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car. Your car is also equipped with ISOFIX/LATCH attachments, which make it more convenient to install child seats. Some restraint systems for children are designed to be secured in the vehicle by lap belts or the lap portion of a lap-shoulder belt. Such child restraint systems can help protect children in cars in the event of an accident only if they are used properly. However, children could be endangered in a crash if the child restraints are not properly secured in the vehi- cle. Failure to follow the installation instructions for your child restraint can result in your child striking the vehicle's interior in a sudden stop. Holding a child in your arms is NOT a suitable substitute for a child restraint system. In an accident, a child held in a person's arms can be crushed between the vehicle's interior and an unrestrained person. The child could also be injured by striking the interior, or by being ejec- ted from the vehicle during a sudden maneuver or impact. The same can also happen if the infant or child rides unrestrained on the seat. Other occupants should also be properly
restrained to help reduce the chance of injuring or increasing the injury of a child. All states and provinces have legislation gov- erning how and where children should be car- ried in a car. Find out the regulations existing in your state or province. Recent accident sta- tistics have shown that children are safer in rear seating positions than front seating positions when properly restrained. A child restraint sys- tem can help protect a child in a vehicle. Here's what to look for when selecting a child restraint system: • It should have a label certifying that it
meets applicable Federal Motor Vehicle Safety Standards (FMVSS 213) – or in Can- ada, CMVSS 213.
• Make sure the child restraint system is
approved for the child's height, weight and development – the label required by the standard or regulation, or instructions for infant restraints, typically provide this infor- mation.
• In using any child restraint system, we urge you to carefully look over the instructions that are provided with the restraint. Be sure you understand them and can use the device properly and safely in this vehicle. A misused child restraint system can result in increased injuries for both the infant or child and other occupants in the vehicle.
When a child has outgrown the child safety seat, you should use the rear seat with the standard seat belt fastened. The best way to help protect the child here is to place the child on a cushion so that the seat belt is properly located on the hips (see the illustration on page 46). Legislation in your state or province may mandate the use of a child seat or cushion in combination with the seat belt, depending on the child's age and/or size. Please check local regulations. A specially designed and tested booster cush- ion and backrest can be obtained from your Volvo retailer. USA: for children weighing 33–80 lbs. (15– 36 kg) and 38–54 inches (97–137 cm) in height Canada: for children weighing 40–80 lbs. (18– 36 kg) and 40–54 inches (102–137 cm) in height
WARNING
Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children under 4 feet 7 inches (140 cm) in height who have outgrown these devices sit in the rear seat with the seat belt fastened.
38
Automatic Locking Retractor/ Emergency Locking Retractor (ALR/ ELR) To make child seat installation easier, each seat belt (except for the driver's belt) is equip- ped with a locking mechanism to help keep the seat belt taut.
When attaching the seat belt to a child seat: 1. Attach the seat belt to the child seat
according to the child seat manufacturer's instructions.
2. Pull the seat belt out as far as possible. 3.
Insert the seat belt latch plate into the buckle (lock) in the usual way.
4. Release the seat belt and pull it taut around
the child seat.
A sound from the seat belt retractor will be audible at this time and is normal. The belt will now be locked in place. This function is auto- matically disabled when the seat belt is unlocked and the belt is fully retracted.
WARNING
Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children who have outgrown these devices sit in the rear seat with the seat belt properly fastened.
Volvo's recommendations Why does Volvo believe that no child should sit in the front seat of a car? It's quite simple really. A front airbag is a very powerful device designed, by law, to help protect an adult. Because of the size of the airbag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly bel- ted or strapped into a child safety seat. Volvo has been an innovator in safety for over sev- enty-five years, and we'll continue to do our part. But we need your help. Please remember to put your children in the back seat, and buckle them up.
Volvo has some very specific recommendations: • Always wear your seat belt. • Airbags are a SUPPLEMENTAL safety device which, when used with a three- point seat belt can help reduce serious injuries during certain types of accidents.
01 Safety
Child safety
01
Volvo recommends that you do not dis- connect the airbag system in your vehicle. • Volvo strongly recommends that everyone
in the vehicle be properly restrained.
• Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a front passenger side airbag. • Drive safely!
39
01 Safety
01
Child restraint systems
Child restraints
Convertible seat
G008170
Infant seat There are three main types of child restraint systems: infant seats, convertible seats, and booster cushions. They are classified accord- ing to the child's age and size. The following section provides general infor- mation on securing a child restraint using a three-point seat belt. Refer to page 47 for information on securing a child restraint using ISOFIX/LATCH lower anchors.
WARNING
A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the Passenger airbag off symbol near the rear- view mirror is illuminated (on vehicles equip- ped with Occupant Weight Sensor). If the severity of an accident were to cause the airbag to inflate, this could lead to serious injury or death to a child seated in this posi- tion.
Booster cushion
WARNING
Always refer to the child restraint manufac- turer's instructions for detailed information on securing the restraint.
40
WARNING
• When not in use, keep the child restraint system secured or remove it from the passenger compartment to help pre- vent it from injuring passengers in the event of a sudden stop or collision.
• A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible. • The following text is mandated by
