Foreword Congratulations on choosing a SUBARU vehicle. This Owner’s Manual has all the information necessary to keep your SUBARU in excellent condition and to properly maintain the emission control system for minimizing emission pollutants. We urge you to read this manual carefully so that you may understand your vehicle and its operation. For information not found in this Owner’s Manual, such as details concerning repairs or adjustments, please contact the SUBARU dealer from whom you purchased your SUBARU or the nearest SUBARU dealer.
The information, specifications and illustrations found in this manual are those in effect at the time of printing. FUJI HEAVY INDUSTRIES LTD. reserves the right to change specifications and designs at any time without prior notice and without incurring any obligation to make the same or similar changes on vehicles previously sold. This Owner’s Manual applies to all models and covers all equipment, including factory installed options. Some explanations, therefore may be for equipment not installed in your vehicle.
Please leave this manual in the vehicle at the time of resale. The next owner will need the information found herein.
FUJI HEAVY INDUSTRIES LTD., TOKYO, JAPAN
*C Copyright 2010 FUJI HEAVY INDUSTRIES LTD.
is a registered trademark of FUJI HEAVY INDUSTRIES LTD.
Black plate (1,1)
北米Model "A1110BE-C" EDITED: 2010/ 11/ 17
Black plate (2,1)
This manual describes the following vehicle types.
1) 2) 3) 4)
4-door non-turbo models 5-door non-turbo models and OUTBACK 4-door turbo models 5-door turbo models
北米Model "A1110BE-C" EDITED: 2010/ 11/ 17
Black plate (3,1)
Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22
& Models with HID headlights
CAUTION
High Intensity Discharge (HID) head- lights contain mercury. For that reason, it is necessary to remove HID headlights before vehicle dis- posal. Once removed, please reuse, recycle or dispose of the HID head- lights as hazardous waste.
& Models without HID head-
lights
NOTE This vehicle does not contain mercury devices or parts.
Warranties & Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of America, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: . SUBARU Limited Warranty . Emission Control Systems Warranty . Emissions Performance Warranty
All warranty information, including details of coverage and exclusions, is in the “Warranty and Maintenance Booklet”. Please read these warranties carefully.
& Warranties for Canada All SUBARU vehicles distributed by Subaru Canada, Inc. and sold at retail by an authorized SUBARU dealer in Canada come with the following warranties: . SUBARU Limited Warranty . Anti-Corrosion Warranty . Emission Control Warranty
All warranty information, including details of coverage and exclusions, is in the “Warranty and Service Booklet”. Please read these warranties carefully.
Black plate (3,1)
How to use this Owner’s Manual & Using your Owner’s Manual Before you operate your vehicle, carefully read this manual. To protect yourself and extend the service life of your vehicle, follow the instructions in this manual. Failure to observe these instructions may result in serious injury and damage to your vehicle.
is composed of
This manual fourteen chapters. Each chapter begins with a brief table of contents, so you can usually tell at a glance if that chapter contains the information you want.
Chapter 1: Seat, seatbelt and SRS airbags This chapter informs you how to use the seat and seatbelt and contains precau- tions for the SRS airbags. Chapter 2: Keys and doors This chapter informs you how to operate the keys, locks and windows. Chapter 3: Instruments and controls This chapter informs you about the opera- tion of indicators and how to use the instruments and other switches.
instrument panel
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
2
Chapter 4: Climate control This chapter informs you how to operate the climate control. Chapter 5: Audio This chapter informs you how to operate your audio system. Chapter 6: Interior equipment This chapter informs you how to operate interior equipment. Chapter 7: Starting and operating This chapter informs you how to start and operate your SUBARU. Chapter 8: Driving tips This chapter informs you how to drive your SUBARU in various conditions and ex- plains some safety tips on driving. Chapter 9: In case of emergency This chapter informs you what to do if you have a problem while driving, such as a flat tire or engine overheating. Chapter 10: Appearance care This chapter informs you how to keep your SUBARU looking good. Chapter 11: Maintenance and service This chapter informs you when you need to take your SUBARU to the dealer for scheduled maintenance and informs you how to keep your SUBARU running properly.
Chapter 12: Specifications This chapter informs you about dimen- sions and capacities of your SUBARU. Chapter 13: Consumer information and Reporting safety defects This chapter informs you about Uniform tire quality grading standards and Report- ing safety defects. Chapter 14: Index This is an alphabetical listing of all that’s in this manual. You can use it to quickly find something you want to read.
find a number of WARNINGs,
& Safety warnings You will CAUTIONs and NOTEs in this manual. These safety warnings alert you to poten- tial hazards that could result in injury to you or others. Please read these safety warnings as well as all other portions of this manual care- fully in order to gain a better understand- ing of how to use your SUBARU vehicle safely.
WARNING
A WARNING indicates a situation in which serious injury or death could result if the warning is ignored.
Black plate (4,1)
CAUTION
A CAUTION indicates a situation in which injury or damage to your vehicle, or both, could result if the caution is ignored.
NOTE A NOTE gives information or sugges- tions how to make better use of your vehicle.
& Safety symbol
You will find a circle with a slash through it in this manual. This symbol means “Do not”, “Do not do this”, or “Do not let this happen”, depending upon the context.
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (5,1)
& Abbreviation list You will find several abbreviations in this manual. The meanings of the abbrevia- tions are shown in the following list.
Abbreviation
Meaning
A/C
A/ELR
ABS
AKI
ALR
AT
ATF
AWD
DCCD
DRL
EBD
ELR
FWD
GAW
GAWR
GVW
GVWR
HID
Air conditioner
Automatic/Emergency locking retractor
Anti-lock brake system
Anti knock index
Automatic locking retractor
Automatic transmission
Automatic transmission fluid
All-wheel drive Driver’s control center differ- ential
Daytime running light
Electronic brake force distri- bution
Emergency locking retractor
Front-wheel drive
Gross axle weight
Gross axle weight rating
Gross vehicle weight
Gross vehicle weight rating
High intensity discharge
Abbreviation
Meaning
Vehicle symbols
INT
LATCH
LED
LSD
MIL
MMT
MT
OBD
RON
Intermittent
Lower anchors and tethers for children
Light emitting diode
Limited slip differential
Malfunction indicator lamp
Methylcyclopentadienyl man- ganese tricarbonyl
Manual transmission
On-board diagnostics
Research octane number
SI-DRIVE
SUBARU Intelligent Drive
SRS
TIN
TPMS
VDC
Supplemental restraint sys- tem
Tire identification number
Tire pressure monitoring sys- tem Vehicle dynamics control
There are some of the symbols you may see on your vehicle. For warning and indicator lights, refer to “Warning and indicator lights” F24.
Mark
Name
WARNING
CAUTION
Power door lock (turbo mod- els)
Power door unlock (turbo models)
Power door lock and unlock (non-turbo models)
Power window with automatic open (all models) and close (if equipped) function
Passengers’ windows lock and unlock
Fuel
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (6,1)
Mark
Name
Mark
Name
Mark
Name
Front fog lights
Rear window wiper
Windshield defroster and foot outlets
Hazard warning flasher
Rear window washer
Windshield defroster
Engine hood
Lights
Trunk lid (4-door)
Seat heater
Child restraint top tether an- chorages
Child restraint lower an- chorages
Horn
Wiper intermittent
Windshield washer
Tail lights, license plate light and instrument panel illumi- nation
Headlights
Turn signal
Rear window defogger/Out- side mirror defogger/Wind- shield wiper deicer
Air recirculation
Engine oil
Washer
Illumination brightness
Door lock (transmitter)
Fan speed
Door unlock (transmitter)
Instrument panel outlets
Instrument panel outlets and foot outlets
Trunk lid open (4-door) or rear gate unlock (5-door) (trans- mitter)
Windshield wiper mist (for single wipe)
Foot outlets
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
. The SRS airbags deploy with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries. Because the SRS airbag needs enough space for deploy- ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full vehicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat.
For instructions and precautions, carefully read the following sections. . For the seatbelt system, refer to “Seat- belts” F1-11. . For the SRS airbag system, refer to “*SRS airbag (Supplemental Restraint System airbag)” F1-35.
Safety precautions when driving & Seatbelt and SRS airbag
WARNING
. All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Other- wise, the possibility of serious injury becomes greater in the event of a sudden stop or acci- dent.
. To obtain maximum protection in the event of an accident, the driver and all passengers in the vehicle should always wear seat- belts when the vehicle is moving. The SRS (Supplemental Restraint System) airbag does not do away with the need to fasten seatbelts. In combination with the seat- belts, it offers the best combined protection in case of a serious accident. Not wearing a seatbelt increases the chance of severe injury or death in a crash even when the vehicle has the SRS airbag.
Black plate (7,1)
& Child safety
WARNING
. Never hold a child on your lap or in your arms while the vehicle is moving. The passenger cannot protect the child from injury in a collision, because the child will be caught between the passen- ger and objects inside the vehi- cle.
. While riding in the vehicle,
in- fants and small children should always be placed in the REAR seat in an infant or child restraint system which is appropriate for the child’s age, height and weight. If a child is too big for a child restraint system, the child should sit in the REAR seat and be restrained using the seatbelts. According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seat- ing positions. Never allow a child to stand up or kneel on the seat. . Put children aged 12 and under in the REAR seat properly re- strained at all times in a child restraint device or in a seatbelt.
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (8,1)
The SRS airbag deploys with considerable speed and force and can injure or even kill chil- dren, especially if they are 12
years of age and under and are not restrained or improperly re- strained. Because children are lighter and weaker than adults, their risk of being injured from deployment is greater.. NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG.
. Always turn the child safety locks to the “LOCK” position when children sit in the rear seat. Serious injury could result if a child accidentally opens the door and falls out. Refer to “Child safety locks” F2-21.
. Always lock the passenger’s win- dows using the lock switch when children are riding in the vehicle. Failure to follow this procedure could result in injury to a child operating the power window. Re- fer to “Windows” F2-21.
. Never leave unattended children, adults or animals in the vehicle. They could accidentally injure themselves or others through inadvertent operation of the ve- hicle. Also, on hot or sunny days, temperature in a closed vehicle could quickly become high en- ough to cause severe or possibly fatal injuries to them.
. Help prevent children, adults or animals from locking themselves in the trunk. On hot or sunny days, the temperature in the trunk could quickly become high enough to cause death or serious heat-related injuries including brain damage to anyone locked inside, particularly for small chil- dren.
. When leaving the vehicle, either close all windows and lock all doors. Also make certain that the trunk is closed.
For instructions and precautions, carefully read the following sections. . For the seatbelt system, refer to “Seat- belts” F1-11. . For the child restraint system, refer to “Child restraint systems” F1-21.
. For the SRS airbag system, refer to “*SRS airbag (Supplemental Restraint System airbag)” F1-35.
& Engine exhaust gas (carbon
monoxide)
WARNING
. Never inhale engine exhaust gas. Engine exhaust gas contains carbon monoxide, a colorless and odorless gas which is dan- gerous, or even lethal, if inhaled. . Always properly maintain the en- gine exhaust system to prevent engine exhaust gas from enter- ing the vehicle.
. Never run the engine in a closed space, such as a garage, except for the brief time needed to drive the vehicle in or out of it.
. Avoid remaining in a parked vehicle for a lengthy time while the engine is running. If that is unavoidable, then use the venti- lation fan to force fresh air into the vehicle.
. Always keep the front ventilator inlet grille free from snow, leaves or other obstructions to ensure
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
the ventilation system al-
that ways works properly.
. If at any time you suspect that exhaust fumes are entering the vehicle, have the problem checked and corrected as soon as possible. If you must drive under these conditions, drive only with all windows fully open. . Keep the trunk lid or rear gate closed while driving to prevent exhaust gas from entering the vehicle.
Black plate (9,1)
& Drinking and driving
& Drugs and driving
WARNING
WARNING
Drinking and then driving is very dangerous. Alcohol in the blood- stream delays your reaction time and impairs your perception, judg- ment and attentiveness. If you drive after drinking – even if you drink just a little – it will increase the risk of being involved in a serious or fatal accident, injuring or killing yourself, your passengers and others. In if you are injured in the addition, accident, alcohol may increase the severity of that injury. Please don’t drink and drive.
the most Drunken driving is one of frequent causes of accidents. Since alco- hol affects all people differently, you may have consumed too much alcohol to drive safely even if the level of alcohol in your blood is below the legal limit. The safest thing you can do is never drink and drive. However if you have no choice but to drive, stop drinking and sober up comple- tely before getting behind the wheel.
There are some drugs (over the counter and prescription) that can delay your reaction time and impair your perception, judgment and at- tentiveness. If you drive after taking them, it may increase your, your passengers’ and other persons’ risk of being involved in a serious or fatal accident.
If you are taking any drugs, check with your doctor or pharmacist or read the literature that accompanies the medication to determine if the drug you are taking can impair your driving ability. Do not drive after taking any medications that can make you drowsy or otherwise affect your ability to safely operate a motor vehicle. If you have a medical condition that requires you to take drugs, please consult with your doctor.
Never drive if you are under the influence of any illicit mind-altering drugs. For your own health and well-being, we urge you not to take illegal drugs in the first place and to seek treatment if you are addicted to those drugs.
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (10,1)
& Driving when tired or sleepy
WARNING
When you are tired or sleepy, your reaction time will be delayed and your perception, judgment and at- tentiveness will be impaired. If you drive when tired or sleepy, your, your passengers’ and other per- sons’ chances of being involved in a serious accident may increase.
Please do not continue to drive but instead find a safe place to rest if you are tired or sleepy. On long trips, you should make periodic rest stops to refresh yourself before continuing on your journey. When possible, you should share the driving with others.
& Modification of your vehicle
CAUTION
Your vehicle should not be modified other than with genuine SUBARU parts and accessories. Other types of modifications could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or
performance problems resulting from modification may not be cov- ered under warranties.
wish to operate the controls of the navigation system, take the vehicle off the road and stop it in a safe place.
first
& Car phone/cell phone and
driving
CAUTION
Do not use a car phone/cell phone while driving; it may distract your attention from driving and can lead to an accident. If you use a car phone/cell phone, pull off the road and park in a safe place before using your phone. In some States/ Provinces, only hands-free phones may legally be used while driving.
& Driving vehicles equipped
with navigation system
WARNING
Do not allow the monitor to distract your attention from driving. Also, do not operate the controls of the navigation system while driving. The loss of attention to driving could lead to an accident. If you
& Driving with pets Unrestrained pets can interfere with your driving and distract your attention from driving. In a collision or sudden stop, unrestrained pets or cages can be thrown around inside the vehicle and hurt you or your passengers. Besides, the pets can be hurt under these situations. It is also for their own safety that pets should be properly restrained in your vehicle. Re- strain a pet with a special traveling harness which can be secured to the rear seat with a seatbelt or use a pet carrier which can be secured to the rear seat by through the carrier’s routing a seatbelt handle. Never restrain pets or pet carriers in the front passenger’s seat. For further information, consult your veterinarian, local animal protection society or pet shop.
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
& Tire pressures Check and, the pressure of each tire (including the spare) at least once a month and before any long journey.
if necessary, adjust
Check the tire pressure when the tires are cold. Use a pressure gauge to adjust the tire pressures to the values shown on the tire placard. For detailed information, refer to “Tires and wheels” F11-31.
WARNING
Driving at high speeds with exces- sively low tire pressures can cause the tires to deform severely and to rapidly become hot. A sharp in- crease in temperature could cause tread separation, and destruction of the tires. The resulting loss of vehicle control could lead to an accident.
& California proposition 65
warning
WARNING
Engine exhaust, some of its consti- tuents, and certain vehicle compo- nents contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addi- tion, certain fluids in vehicles and certain components of product wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
& California Perchlorate Advi-
sory
Certain vehicle components such as air- bag modules, seatbelt pretensioners and keyless entry transmitter batteries may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/ hazardouswaste/perchlorate.
Black plate (11,1)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (2,1)
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Left Page
Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22
Black plate (1,1)
Table of contents
Seat, seatbelt and SRS airbags
Keys and doors
Instruments and controls
Climate control
Audio
Interior equipment
Starting and operating
Driving tips
In case of emergency
Appearance care
Maintenance and service
Specifications
Consumer information and Reporting safety defects
Index
10
11
12
13
14
北米Model "A1110BE-C" Edited: 2010/ 11/ 17
12
Illustrated index & Exterior
Black plate (14,1)
1) Engine hood (page 11-5) 2) Headlight switch (page 3-32) 3) Replacing bulbs (page 11-47) 4) Wiper switch (page 3-38) 5) Moonroof (page 2-29) 6) Door locks (page 2-4) 7) 8) 9) Snow tires (page 8-10) 10) Front fog light switch (page 3-36) 11) Tie-down hooks (page 9-14) 12) Towing hook (page 9-14)
Tire pressure (page 11-33) Flat tires (page 9-6)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (15,1)
13
Fuel filler lid and cap (page 7-4)
1) Rear window defogger (page 3-48) 2) 3) Child safety locks (page 2-21) 4) 5) 6) Rear gate (page 2-27) 7)
Tie-down hook (page 9-14) Trunk lid (page 2-25)
Towing hook (page 9-14)
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
14
& Interior ! Passenger compartment area
Black plate (16,1)
1)
Lower anchorages for child restraint system (page 1-29) 2) Seatbelt (page 1-11) 3) Parking brake lever (page 7-40) 4) Front seat (page 1-2) 5) Rear seat (page 1-7)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (17,1)
15
1) Center console (page 6-5) 2) Cup holder (page 6-5) 3) 4) Glove box (page 6-5)
Front power supply socket (page 6-8)
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
16
& Instrument panel
Black plate (18,1)
1) Door locks (page 2-4) 2) Outside mirror switch (page 3-47) 3)
Illumination brightness control (page 3-33)
Light control switch (page 3-31)
4) Headlight beam leveler (page 3-34) 5) 6) Combination meter (page 3-6) 7) Wiper control lever (page 3-36) 8) Hazard warning flasher switch (page 3-5) 9) Audio (page 5-1) 10) Shift lever (MT) (page 7-15/page 7-17)/
Select lever (AT) (page 7-22)
11) Climate control (page 4-1) 12) Cruise control (page 7-44) 13) Horn (page 3-51) 14) SRS airbag (page 1-35) 15) Tilt/telescopic steering (page 3-50) 16) Hands-free switches (page 5-46) 17) Audio control buttons (page 5-42) 18) Fuse box (page 11-45) 19) Vehicle Dynamics Control OFF switch
(page 7-37)/Vehicle Dynamics Control mode switch (page 7-36)
20) Hood lock release knob (page 11-5) 21) Power windows (page 2-21)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
& Light control and wiper control levers/switches
Black plate (19,1)
17
1) Windshield wiper (page 3-38) 2) Mist (page 3-38) 3) Windshield washer (page 3-39) 4) Rear window wiper and washer switch
(page 3-39)
5) Wiper
intermittent
(page 3-38)
time control switch
6) Wiper control lever (page 3-36) Light control switch (page 3-31) 7) 8) Fog light switch (page 3-36) 9) Headlight ON/OFF (page 3-32) 10) Headlight
change (page 3-32)
flasher High/Low beam
11) Turn signal (page 3-33)
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
18
& Combination meter ! U.S.-spec. models (STI)
Black plate (20,1)
Fuel gauge (page 3-10) Tachometer (page 3-9)
1) 2) 3) Speedometer (page 3-8) 4)
Trip meter A/B selection and trip meter reset knob (page 3-8)
5) Odometer/Trip meter (page 3-8) Temperature gauge (page 3-11) 6)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
! U.S.-spec. models (turbo models except STI)
Black plate (21,1)
19
Fuel gauge (page 3-10) Tachometer (page 3-9)
1) 2) 3) Speedometer (page 3-8) 4)
Trip meter A/B selection and trip meter reset knob (page 3-8)
5) Odometer/Trip meter (page 3-8) 6) Select lever/gear position indicator
(AT models) (page 3-26) Temperature gauge (page 3-11)
7)
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
20
! U.S.-spec. models (non-turbo models)
Black plate (22,1)
Tachometer (page 3-9)
1) 2) Speedometer (page 3-8) Fuel gauge (page 3-10) 3) Trip meter A/B selection and trip meter 4) reset knob (page 3-8)
5) Odometer/Trip meter (page 3-8) 6) Select lever/gear position indicator
(AT models) (page 3-26)
7) Coolant
temperature warning/indicator
light (page 3-17)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
! Except U.S.-spec. models (STI)
Black plate (23,1)
21
Fuel gauge (page 3-10) Tachometer (page 3-9)
1) 2) 3) Speedometer (page 3-8) 4)
Trip meter A/B selection and trip meter reset knob (page 3-8)
5) Odometer/Trip meter (page 3-8) Temperature gauge (page 3-11) 6)
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
22
! Except U.S.-spec. models (turbo models except STI)
Black plate (24,1)
Fuel gauge (page 3-10) Tachometer (page 3-9)
1) 2) 3) Speedometer (page 3-8) 4)
Trip meter A/B selection and trip meter reset knob (page 3-8)
5) Odometer/Trip meter (page 3-8) 6) Select lever/gear position indicator
(AT models) (page 3-26) Temperature gauge (page 3-11)
7)
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
! Except U.S.-spec. models (non-turbo models)
Black plate (25,1)
23
Tachometer (page 3-9)
1) 2) Speedometer (page 3-8) Fuel gauge (page 3-10) 3) Trip meter A/B selection and trip meter 4) reset knob (page 3-8)
5) Odometer/Trip meter (page 3-8) 6) Select lever/gear position indicator
(AT models) (page 3-26)
7) Coolant
temperature warning/indicator
light (page 3-17)
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
24
& Warning and indicator lights
Mark
Name
Mark
Name
Page
Seatbelt warning light
3-14
Front passenger’s seatbelt warning light
SRS airbag system warning light
Front passenger’s frontal airbag ON indi- cator Front passenger’s frontal airbag OFF in- dicator
CHECK ENGINE warning light/Malfunc- tion indicator lamp
Coolant temperature low indicator light (non-turbo models)/ Coolant temperature high warning light (non-turbo models)
3-14
3-15
3-16
3-16
3-16
3-17
Charge warning light
3-18
Oil pressure warning light
3-18
Black plate (26,1)
Page
3-18
3-19
Mark
Name
High beam indicator light
Page
3-26
Front fog light indicator light (if equipped)
3-27
AT OIL TEMP warning light (AT models)
Rear differential oil temperature warning light (STI)
ABS warning light
3-21
Security indicator light
3-25
Brake system warning light
Door open warning light
AWD warning light (AT models)
Hill start assist warn- ing light (if equipped)/ Hill start assist OFF indicator light (STI)
Vehicle Dynamics Control operation indi- cator light
Vehicle Dynamics Control warning light/ Vehicle Dynamics Control OFF indicator light/Traction Control OFF indicator light (STI)
3-21
3-23
3-23
3-22
3-23
3-23
Turn signal indicator lights
3-26
Headlight indicator light (if equipped)
Cruise control indica- tor light
Cruise control set in- dicator light
3-27
3-26
3-27
Low fuel warning light
3-22
Low tire pressure warning light (U.S.-spec. models)
SPORT mode indica- tor light (AT models)
Shift-up indicator light (STI)
Driver’s control center differential auto indi- cator light (STI)
3-19
3-25
3-26
3-27
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Mark
Name
Auto [+] mode indica- tor light (STI)
Auto [−] mode indica- tor light (STI)
Driver’s control center differential indicator and warning lights (STI)
REV indicator light (STI)
Sport (S) mode indi- cator light (STI)
Intelligent (I) mode in- dicator light (STI)
Sport Sharp (S#) mode indicator light (STI)
Page
3-27
3-27
3-27
3-28
3-26
3-26
3-26
Black plate (27,1)
25
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (28,1)
26
Function settings
A SUBARU dealer can change the settings of the functions shown in the following table to meet your personal requirements. Contact the nearest SUBARU dealer for details. If your vehicle is equipped with the genuine SUBARU navigation system, the settings for some of these functions can be changed using the navigation monitor. For details, please refer to the Owner’s Manual supplement for the navigation system.
Item Alarm system
Function Alarm system
Monitoring start delay time (after closure of doors)
Impact sensor operation (only models with shock sensors (dealer option))
Possible settings Operation/Non-operation Operation
Default setting
0 second/30 seconds
30 seconds
Operation/Non-operation Non-operation
Passive arming
Operation/Non-operation Non-operation
Dome light and map lights illumination (models with moonroof)
ON/OFF
OFF
Remote keyless entry system
Hazard warning flasher
Dome light illumination (models without moonroof)
Audible signal
Key lock-in prevention
Horn chirp confirmation
Operation/Non-operation Operation
Operation/Non-operation Operation
Operation/Non-operation Operation
ON/OFF
ON
Page 2-16
2-18
2-20
2-19
2-16
2-8
2-11
2-7
7-12
Key lock-in prevention
Remote engine start system (dealer option)
Defogger and deicer system for models with the automatic climate control system
Dome light
Map light for models with a moonroof
Rear window defogger, outside mirror defogger and windshield wiper deicer
Operation for 15 minutes/ Continuous operation
Operation for 15 minutes 3-48
Operation of dome light/map light OFF delay timer
OFF/Short/Normal/Long
Long
6-2, 6-3
Battery drainage prevention function Battery drainage prevention function
Operation/Non-operation Operation
2-5
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (29,1)
Item Seatbelt warning
Function Sounds a chime while driving
Possible settings Operation/Non-operation Operation
Default setting
Page 3-14
27
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (2,1)
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
Left Page
Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22
Front seats........................................................... Forward and backward adjustment ...................... Reclining the seatback ........................................ Seat cushion height adjustment (driver’s seat) ..... Head restraint adjustment (if equipped)................ Active head restraint (if equipped) ....................... Seat heater (if equipped) .................................... Type A seat heater .............................................. Type B seat heater .............................................. Rear seats............................................................ Armrest (if equipped)........................................... Head restraint adjustment.................................... Folding down the rear seatback...........................
1-2
1-3
1-3
1-4
1-4
1-5
1-6
1-6
1-6
1-7
1-8
1-8
1-9
Seatbelts ............................................................. 1-11
Seatbelt safety tips............................................. 1-11
Emergency Locking Retractor (ELR) ................... 1-12
Automatic/Emergency Locking Retractor(A/ELR) ............................................................ 1-12
Seatbelt warning light and chime ........................ 1-12
Fastening the seatbelt ........................................ 1-12
Seatbelt maintenance ......................................... 1-19Black plate (1,1)
Seat, seatbelt and SRS airbags
Front seatbelt pretensioners............................. System monitors ............................................... System servicing ............................................... Precautions against vehicle modification ............ Child restraint systems ..................................... Where to place a child restraint system.............. Choosing a child restraint system ...................... Installing child restraint systems with A/ELR
seatbelt ........................................................... Installing a booster seat..................................... Installation of child restraint systems by use of
lower and tether anchorages (LATCH) .............. Top tether anchorages .......................................
*SRS airbag (Supplemental Restraint
System airbag)................................................ Models with SRS airbags and lap/shoulder restraints for driver, front passenger, and window-side rear passengers........................... SUBARU advanced frontal airbag system ........... SRS side airbag and SRS curtain airbag............. SRS airbag system monitors.............................. SRS airbag system servicing ............................. Precautions against vehicle modification ............
1-19
1-20
1-20
1-21
1-21
1-22
1-241-24
1-271-29
1-311-35
1-35
1-39
1-49
1-55
1-57
1-57北米Model "A1110BE-C" EDITED: 2010/ 11/ 17
If the front seatbacks are not used in the upright position in a collision, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death. . The SRS airbags deploy with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries. Because the SRS airbag needs enough space for deploy- ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full vehicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat.
1-2 Seat, seatbelt and SRS airbags
Front seats
WARNING
. Never adjust the seat while driv- ing to avoid the possibility of loss of vehicle control and of personal injury.
. Before adjusting the seat, make sure the hands and feet of rear seat passengers and cargo are clear of the adjusting mechan- ism.
. After adjusting the seat, push it slightly to make sure it is se- curely locked. If the seat is not securely locked, it may move or the seatbelt may not operate properly.
. Do not put objects under the front seats. They may interfere with front seat locking and cause an accident.
. Seatbelts provide maximum re- straint when the occupant sits well back and upright in the seat. To reduce the risk of sliding under the seatbelt in a collision, the front seatbacks should be always used in the upright posi- tion while the vehicle is running.
Black plate (32,1)
WARNING
Put children aged 12 and under in the rear seat properly restrained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially if they are 12 years of age and under and are not restrained or improperly restrained. Because chil- dren are lighter and weaker than adults, their risk of being injured from deployment is greater. For that reason, we strongly recommend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly re- strained at all times in a child
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
restraint device or in a seatbelt, whichever is appropriate for the child’s age, height and weight. Se- cure ALL types of child restraint devices (including forward facing child seat) in the REAR seats at all times. NEVER INSTALL A REARWARD FA- CING CHILD SEAT IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. According to accident statistics, children are safer when properly restrained in the rear seating posi- tions than in the front seating posi- tions. For instructions and precau- tions concerning child restraint sys- tems, refer to “Child restraint sys- tems” F1-21.
Black plate (33,1)
& Forward and backward ad-
justment
& Reclining the seatback
Seat, seatbelt and SRS airbags 1-3
Pull the lever upward and slide the seat to the desired position. Then release the lever and try to move the seat back and forth to make sure that it is securely locked into place.
Pull the reclining lever up and adjust the seatback to the desired position. Then release the lever and make sure the seatback is securely locked into place. The seatback placed in a reclined position can spring back upward with force when the lever is pulled. While operating the lever to return the seatback, hold the seatback lightly so that it may be raised back gradually.
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
Black plate (34,1)
1-4 Seat, seatbelt and SRS airbags
& Seat cushion height adjust-
ment (driver’s seat)
& Head restraint adjustment (if
equipped)
WARNING
To prevent the passenger from slid- ing under the seatbelt in the event of a collision, always put the seatback in the upright position while the vehicle is in motion. Also, do not place objects such as cushions between the passenger and the seatback. If you do so, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death.
1) When the lever is pushed down, the seat
is lowered.
2) When the lever is pulled up,
rises.
the seat
The height of the seat can be adjusted by moving the seat cushion adjustment lever up and down.
1) Head restraint 2) Release button
Both the driver’s seat and the front passenger’s seat are equipped with head restraints. The head restraint should be adjusted so that is closest to the top of the occupant’s ears.
the head restraint
the center of
To raise: Pull the head restraint up. To lower: Push the head restraint down while pressing the release button on the top of the seatback.
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
To remove: While pressing the release button, pull out the head restraint. To install: Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks.
WARNING
. Never drive the vehicle with the head restraints removed because they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear. Therefore, when you remove the head restraints, you must reinstall all head re- straints to protect vehicle occu- pants.
. All occupants, including the dri- ver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to mini- mize the risk of neck injury in the event of a crash.
& Active head restraint (if
equipped)
The front seats of your vehicle are equipped with active head restraints. They automatically tilt forward slightly in the event the vehicle is struck from the rear, decreasing the amount of rearward head movement and thus reducing the risk of whiplash. For maximum effectiveness, the head restraint should be adjusted so that the center of the head restraint is closest to the top of the occupant’s ears.
CAUTION
. Each active head restraint
is effective only when its height is properly adjusted and driver/pas- senger sits in the correct posi-
Black plate (35,1)
Seat, seatbelt and SRS airbags 1-5
tion on the seat.
. If your vehicle is involved in a rear-end collision, have an authorized SUBARU dealer in- spect the active head restraints. . The active head restraints may not operate in the event the vehicle experiences only a slight impact in the rear.
. The active head restraints may be damaged if they are pushed hard from behind or subjected to shock. As a result, they may not function if the vehicle suffers a rear impact.
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
1-6 Seat, seatbelt and SRS airbags
Seat heater (if equipped)
& Type A seat heater
The seat heater is equipped in the front seats.
The seat heater operates when the igni- tion switch is either in the “Acc” or “ON” position.
CAUTION
. There is a possibility that people with delicate skin may suffer slight burns even at low tempera- tures if they use the seat heater for a long period of time. When using the heater, always be sure to warn the persons concerned. . Do not put anything on the seat which insulates against heat, such as a blanket, cushion, or similar items. This may cause the seat heater to overheat.
NOTE Use of the seat heater for a long period of time while the engine is not running can cause battery discharge.
LO – Normal heating
1) HI – Rapid heating 2) 3) OFF – Off A) B) Right-hand side
Left-hand side
Black plate (36,1)
To turn on the seat heater, push the “LO” or “HI” position on the switch, as desired, depending on the temperature. Selecting the “HI” position will cause the seat to heat up quicker.
To turn off the seat heater, lightly press the opposite side of the current position.
The indicator located on the switch illumi- nates when the seat heater is in operation. When the vehicle’s interior is warmed enough or before you leave the vehicle, be sure to turn the switch off.
& Type B seat heater
Each seat heater has four levels of adjustment. To use the heater in the right-hand seat, turn the “R” adjustment dial forward until the “ ” mark reaches the
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
desired position. To activate the heater in the left-hand seat, turn the “L” adjustment dial forward until the “ ” mark reaches the desired position. Each heater warms the seat most quickly with the “ ” mark on the in the furthest-forward adjustment dial position. An indicator to the for each seat heater adjustment dial illuminates when that seat heater is activated. When the vehicle’s interior is warmed enough or before you leave the vehicle, to the always turn the adjustment dial ” most rearward position so that mark reaches to the “OFF” position.
light next
the “
Black plate (37,1)
Seat, seatbelt and SRS airbags 1-7
Rear seats
WARNING
Never stack luggage or other cargo higher than the top of the seatback because it could tumble forward and injure passengers in the event of a sudden stop or accident.
WARNING
Seatbelts provide maximum re- straint when the occupant sits well back and upright in the seat. Do not put cushions or any other materials between occupants and seatbacks or seat cushions. If you do so, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death.
– CONTINUED –
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
1-8 Seat, seatbelt and SRS airbags
& Armrest (if equipped)
To lower the armrest, pull on the top edge of the armrest.
WARNING
To avoid the possibility of serious injury, passengers must never be allowed to sit on the center armrest while the vehicle is in motion.
& Head restraint adjustment Both the rear window side seats and the rear center seat are equipped with head restraints.
WARNING
. Never drive the vehicle with the head restraints removed because they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear. Therefore, when you remove the head restraints, you must reinstall all head re- straints to protect vehicle occu- pants.
. All occupants, including the dri- ver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to mini- mize the risk of neck injury in the event of a crash.
Black plate (38,1)
! Rear windows side seating position
1) Head restraint 2) Release button
To remove: While pressing the release button, pull out the head restraint. To install: Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks. ! Rear center seating position
CAUTION
The head restraint is not intended to be used at the lowest position. Before sitting on the seat, raise the head restraint to the click position.
北米Model "A1110BE-C" EDITED: 2010/ 12/ 17
To raise: Pull the head restraint up. To lower: Push the head restraint down while pressing the release button on the top of the seatback. To remove: While pressing the release button, pull out the head restraint. To install: Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks.
When the rear-center seating position is occupied, raise the head restraint to an appropriate position depending on your sitting height. When the rear center seat- ing position is not occupied, lower the head restraint to improve rearward visibi- lity.
& Folding down the rear seat-
back
WARNING
. After returning the rear seatback to its original position, be certain to place all of the seatbelts and the tab attached to the seat cushion above the seat cushion.
1) When not used (lowest position)
