Sommer\ Corporate\ Media\ AG ’ Operator’s Manual R-Class Ê9/t-qMË 2515841381 Order No. 6515 1803 13 Part No. 251 584 13 81 USA Edition B, 2006 R 350 R 500 Our company and staff congratulate you on the purchase of your new Mercedes-Benz. Your selection of our product is a demon- stration of your trust in our company name. Furthermore, it exemplifies your de- sire to own an automobile that will be as easy as possible to operate and provide years of service. Your Mercedes-Benz represents the ef- forts of many skilled engineers and crafts- men. To help assure your driving pleasure, and also the safety of you and your passen- gers, we ask you to make a small invest- ment of time: 앫 Please read this manual carefully, then return it to your vehicle where it will be handy for your reference. 앫 Please follow the recommendations contained in this manual. They are de- signed to acquaint you with the opera- tion of your Mercedes-Benz. 앫 Please pay attention to the warnings and cautions contained in this manual. They are designed to help improve the safety of the vehicle operator and oc- cupants. We extend our best wishes for many miles of safe, pleasurable driving. Mercedes-Benz USA, LLC A DaimlerChrysler Company At a glance .......................................... 21 Cockpit................................................. 22 Instrument cluster ................................ 24 Multifunction steering wheel ................ 28 Center console ..................................... 29 Upper part ...................................... 29 Lower part ...................................... 30 Overhead control panel ........................ 31 Storage compartments......................... 32 Door control panel................................ 34 Introduction .......................................... 9 Product information................................ 9 Operator’s Manual............................... 10 Service and warranty information .. 10 Important notice for California retail buyers and lessees of Mercedes-Benz automobiles .......... 11 Maintenance .................................. 12 Roadside Assistance ...................... 12 Change of address or ownership.... 13 Operating your vehicle outside the USA or Canada......................... 13 Where to find it.................................... 14 Symbols............................................... 15 Operating safety .................................. 16 Proper use of the vehicle ............... 16 Problems with your vehicle.................. 17 Reporting safety defects...................... 18 Reporting safety defects ................ 18 Vehicle data recording......................... 19 Information regarding electronic recording devices........................... 19 Contents Getting started................................... 35 Unlocking ............................................. 36 Unlocking with the SmartKey ......... 36 Unlocking with Keyless-Go* ........... 37 Starter switch positions.................. 38 Adjusting.............................................. 42 Seats .............................................. 42 Steering wheel................................ 45 Mirrors............................................ 47 Driving.................................................. 50 Fastening the seat belts ................. 50 Starting the engine ......................... 53 Parking brake ................................. 56 Driving ............................................ 56 Switching on headlamps................. 58 Turn signals .................................... 58 Windshield wipers........................... 59 Rear window wiper/washer............ 61 Problems while driving.................... 62 Parking and locking.............................. 64 Parking brake ................................. 65 Switching off headlamps................. 65 Turning off the engine..................... 66 Releasing seat belts........................ 67 Locking........................................... 67 Contents Safety and Security .......................... 69 Occupant safety................................... 70 Air bags .......................................... 71 Seat belts ....................................... 77 Preventive occupant safety* (PRE-SAFE®) ................................... 81 Children in the vehicle.................... 82 Blocking of rear door window operation........................................ 93 Panic alarm.......................................... 95 Activating ....................................... 96 Deactivating ................................... 96 Driving safety systems......................... 97 ABS ................................................ 97 BAS ................................................ 99 ESP®............................................... 99 EBP............................................... 102 4-ETS............................................ 102 Anti-theft systems.............................. 104 Immobilizer................................... 104 Anti-theft alarm system................ 104 Tow-away alarm ........................... 106 Controls in detail............................. 109 Locking and unlocking....................... 110 SmartKey ..................................... 110 SmartKey with KEYLESS-GO* ...... 114 Opening the doors from the inside 121 Opening the tailgate..................... 122 Closing the tailgate ...................... 124 Automatic central locking ............ 130 Locking and unlocking from the inside ..................................... 131 Seats ................................................. 132 Easy-entry/exit feature* .............. 132 Lumbar support............................ 136 Multicontour seat*....................... 136 Rear seats .................................... 137 Seat heating*............................... 141 Memory function* ............................. 144 Storing positions into memory ..... 145 Recalling positions from memory. 145 Storing exterior rear view mirror parking position ........................... 146 Lighting.............................................. 147 Exterior lamp switch..................... 147 Combination switch ..................... 151 Corner-illuminating front fog lamps* ......................................... 152 Hazard warning flasher ................ 153 Interior lighting ............................ 154 Door entry lamps ......................... 157 Cargo compartment lamp ............ 157 Instrument cluster ............................. 158 Instrument cluster illumination .... 158 Trip odometer .............................. 159 Tachometer.................................. 159 Outside temperature indicator..... 159 Control system .................................. 161 Multifunction display.................... 161 Multifunction steering wheel........ 162 Menus.......................................... 164 Standard display menu ................ 168 AUDIO menu ................................ 170 NAV* menu.................................. 172 AIRMATIC*/Compass menu ........ 172 Vehicle status message memory menu............................................ 173 Settings menu.............................. 174 Vehicle configuration ................... 191 Trip computer menu..................... 192 TEL menu* ................................... 194 Contents Automatic transmission..................... 197 Gear selector lever....................... 197 Shifting procedure ....................... 199 Transmission positions................. 200 Gear ranges ................................. 202 Driving tips................................... 203 Automatic shift program .............. 204 Steering wheel gearshift control .. 205 Emergency operation (Limp Home Mode) ...................... 207 Good visibility .................................... 208 Headlamp cleaning system* ........ 208 Rear view mirrors......................... 208 Power folding exterior rear view mirrors* ....................................... 211 Sun visors .................................... 212 Rear door window sunshade* ...... 214 Third-row sunshade*.................... 214 Rear window defroster ................. 215 Climate control .................................. 216 Deactivating the climate control system ......................................... 220 Operating the climate control system in automatic mode........... 221 Setting the temperature................ 222 Adjusting air distribution............... 222 Adjusting air volume ..................... 222 Front defroster.............................. 223 Air recirculation mode .................. 224 Air conditioning............................. 226 Residual heat and ventilation........ 227 Rear climate control ..................... 228 3-zone automatic climate control* ..... 230 Deactivating the climate control system .......................................... 234 Operating the climate control system in automatic mode............ 235 Setting the temperature................ 236 Adjusting air distribution............... 236 Adjusting air volume ..................... 237 Front defroster.............................. 238 Maximum cooling MAX COOL ....... 239 Air recirculation mode .................. 239 Air conditioning............................. 241 Using driver-side settings for all temperature zones........................ 242 Residual heat and ventilation........ 243 Rear automatic climate control..... 244 Power windows .................................. 248 Opening and closing ..................... 248 Synchronizing the door windows .. 251 Summer opening feature .............. 251 Convenience closing feature......... 252 Power tilt/sliding sunroof* ................ 255 Opening and closing ..................... 255 Synchronizing ............................... 258 Panorama roof with power tilt/sliding panel*............................... 259 Roller sunblinds for the panorama roof with power tilt/sliding panel ........................... 259 Opening and closing the panorama roof with power tilt/sliding panel ........................... 260 Synchronizing the panorama roof with power tilt/sliding panel......... 262 Driving systems.................................. 264 Cruise control ............................... 264 AIRMATIC* ................................... 269 Parktronic* (Parking assist).......... 274 Contents Loading.............................................. 279 Roof rack*.................................... 279 Loading instructions..................... 280 Cargo tie-down rings .................... 281 Hooks........................................... 282 Expanding cargo compartment .... 283 Cargo compartment cover blind*. 288 Partition net* ............................... 290 Useful features .................................. 294 Storage compartments................. 294 Parcel nets ................................... 298 Cup holders.................................. 299 Ashtrays* ..................................... 302 Cigarette lighter* ......................... 305 Power outlets ............................... 306 Rear center console* ................... 308 Telephone*................................... 310 Tele Aid* ...................................... 311 Garage door opener* ................... 320 Compass ...................................... 327 Floormats* ................................... 328 Infrared reflecting windshield*..... 328 Operation ......................................... 329 The first 1000 miles (1500 km) ......... 330 Driving instructions............................ 331 Drive sensibly – save fuel............. 331 Drinking and driving ..................... 331 Pedals .......................................... 331 Power assistance ......................... 331 Brakes.......................................... 332 Driving off .................................... 333 Parking......................................... 334 Tires ............................................. 334 Hydroplaning................................ 335 Tire traction.................................. 335 Tire speed rating .......................... 336 Winter driving instructions ........... 337 Standing water............................. 338 Passenger compartment .............. 338 Driving abroad.............................. 339 Control and operation of radio transmitters ................................. 339 Catalytic converter....................... 340 Emission control .......................... 340 Coolant temperature.................... 341 At the gas station .............................. 342 Refueling...................................... 342 Check regularly and before a long trip ....................................... 343 Engine compartment ......................... 345 Hood ............................................ 345 Engine oil ..................................... 346 Transmission fluid level................ 350 Coolant level ................................ 351 Windshield/rear window washer system and headlamp cleaning system*....................................... 352 Tires and wheels................................ 353 Important guidelines .................... 353 Tire care and maintenance........... 354 Direction of rotation..................... 356 Loading the vehicle...................... 356 Recommended tire inflation pressure....................................... 363 Checking tire inflation pressure ... 365 Tire labeling ................................. 375 Load identification ....................... 380 DOT, Tire Identification Number (TIN) ............................................. 380 Maximum tire load ....................... 382 Maximum tire inflation pressure .. 382 Uniform Tire Quality Grading Standards (U.S. vehicles) ............. 383 Tire ply material ........................... 385 Tire and loading terminology........ 385 Rotating tires ............................... 388 Winter driving .................................... 390 Winter tires .................................. 390 Block heater (Canada only) .......... 391 Snow chains................................. 391 Maintenance...................................... 392 Clearing the maintenance service indicator....................................... 393 Maintenance service term exceeded ..................................... 393 Calling up the maintenance service indicator........................... 393 Resetting the maintenance service indicator........................... 394 Vehicle care....................................... 395 Cleaning and care of the vehicle .. 395 Practical hints .................................. 403 What to do if … ................................... 404 Lamps in instrument cluster ......... 404 Lamp in center console................. 414 Vehicle status messages in the multifunction display..................... 416 Where will I find ...? ............................ 454 First aid kit.................................... 454 Vehicle tool kit.............................. 454 Spare wheel .................................. 457 Unlocking/locking in an emergency .. 459 Unlocking the vehicle.................... 459 Locking the vehicle ....................... 460 Fuel filler flap ................................ 461 Opening/closing in an emergency..... 462 Power tilt/sliding sunroof* ........... 462 Replacing SmartKey batteries ............ 463 SmartKey ...................................... 463 SmartKey with KEYLESS-GO* ....... 464 Replacing bulbs .................................. 465 Bulbs............................................. 465 Replacing bulbs for front lamps .... 468 Replacing bulbs for rear lamps ..... 472 Contents Replacing wiper blades ...................... 475 Front wiper blades........................ 475 Rear wiper blade........................... 476 Flat tire............................................... 478 Preparing the vehicle .................... 478 Mounting the spare wheel ............ 479 Battery ............................................... 487 Disconnecting, removing, reinstalling and reconnecting the battery.................................... 489 Charging the battery..................... 495 Jump starting...................................... 496 Towing the vehicle.............................. 499 Installing towing eye bolts ............ 501 Stranded vehicle........................... 502 Fuses.................................................. 503 Main fuse box ............................... 504 Fuse box in cargo compartment ... 504 Fuse box in passenger compartment................................ 505 Contents Technical data.................................. 507 Parts service ...................................... 508 Warranty coverage............................. 509 Loss of Service and Warranty Information Booklet...................... 509 Identification labels............................ 510 Layout of poly-V-belt drive ................. 512 Engine................................................ 513 Rims and tires.................................... 514 Same size tires............................. 516 Spare wheel (collapsible tire) ....... 517 Electrical system................................ 518 Main Dimensions ............................... 519 Weights.............................................. 520 Fuels, coolants, lubricants, etc. ......... 521 Capacities .................................... 521 Engine oils.................................... 523 Engine oil additives ...................... 523 Air conditioning refrigerant .......... 523 Brake fluid.................................... 523 Premium unleaded gasoline ......... 524 Fuel requirements ........................ 524 Gasoline additives........................ 525 Coolants....................................... 525 Windshield washer and headlamp cleaning* system ......................... 528 Technical terms............................... 529 Index................................................. 535 Introduction Product information Product information 왔 Please observe the following in your own best interest: We recommend using Genuine Mercedes-Benz Parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and special suitability for Mercedes-Benz vehicles. We are unable to make an assessment for other products and therefore cannot be held responsible for them, even if in indi- vidual cases an official approval or authori- zation by governmental or other agencies should exist. Use of such parts and acces- sories could adversely affect the safety, performance or reliability of your vehicle. Please do not use them. Genuine Mercedes-Benz Parts as well as conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Light Truck Center where you will receive comprehen- sive information, also on permissible tech- nical modifications, and where proper installation will be performed. Introduction Operator’s Manual This Operator’s Manual contains a great deal of useful information. We urge you to read it carefully and familiarize yourself with the vehicle before driving. For your own safety and longer service life of the vehicle, we urge you to follow the in- structions and warnings contained in this manual. Ignoring them could result in dam- age to the vehicle or personal injury to you or others. Vehicle damage caused by fail- ure to follow instructions is not covered by the Mercedes-Benz Limited Warranty. Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your authorized Mercedes-Benz Light Truck Center will be glad to demonstrate the proper procedures. We continuously strive to improve our product, and ask for your understanding that we reserve the right to make changes in design and equipment. Therefore, infor- mation, illustrations and descriptions in this Operator’s Manual might differ from your vehicle. Optional equipment is also described in this manual, including operating instruc- tions wherever necessary. Since they are special-order items, the descriptions and illustrations herein may vary slightly from the actual equipment of your vehicle. If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized Mercedes-Benz Light Truck Center will be glad to inform you of correct care and operating proce- dures. The Operator’s Manual and Maintenance Booklet are important documents and should be kept with the vehicle. Service and warranty information The Service and Warranty Information Booklet contains detailed information about the warranties covering your Mercedes-Benz, including: 앫 New Light Truck Limited Warranty, 앫 Emission System Warranty, 앫 Emission Performance Warranty, 앫 California, Maine, Massachusetts, and Vermont Emission Control System Warranty (California, Maine, Massachusetts, and Vermont only), 앫 State Warranty Enforcement Laws (Lemon Laws). 10 (1) the same substantial defect or mal- function results in a condition that is likely to cause death or serious bodily injury if the vehicle is driven, that de- fect or malfunction has been subject to repair two or more times, and you have directly notified Mercedes-Benz USA, LLC in writing of the need for its repair, (2) the same substantial defect or mal- function of a less serious nature than category (1) has been subject to repair four or more times and you have direct- ly notified us in writing of the need for its repair, or Important notice for California retail buyers and lessees of Mercedes-Benz automobiles Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price or lease price, if Mercedes-Benz USA, LLC and/or its au- thorized repair or service facilities fail to fix one or more substantial defects or mal- functions in the vehicle that are covered by its express warranty after a reasonable number of repair attempts. During the pe- riod of 18 months from original delivery of the vehicle or the accumulation of 18 000 miles (approx. 29 000 km) on the odometer of the vehicle, whichever occurs first, a reasonable number of repair at- tempts is presumed for a retail buyer or lessee if one or more of the following oc- curs: Introduction Operator’s Manual (3) the vehicle is out of service by reason of repair of the same or different sub- stantial defects or malfunctions for a cumulative total of more than 30 calendar days. Written notification should be sent to us, not a dealer, at Mercedes-Benz USA, LLC, Customer Assistance Center, One Mercedes Drive, Montvale, NJ 07645-0350. 11 Additional charges may be applicable for a breakdown location determined not to be a reasonably accessible roadside location as determined by our authorized technician and tow service provider. For additional information refer to the Mercedes-Benz Roadside Assistance Program brochure in your vehicle literature portfolio. Introduction Operator’s Manual Maintenance Roadside Assistance The Maintenance Booklet describes all the necessary maintenance work which should be performed at regular intervals. Always have the Maintenance Booklet with you when you take the vehicle to your authorized Mercedes-Benz Light Truck Center for service. The service advisor will record each service in the booklet for you. The Mercedes-Benz Roadside Assistance Program provides factory-trained technical help in the event of a breakdown. Calls to the toll-free Roadside Assistance number 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Cus- tomer Assistance Representatives 24 hours a day, 365 days a year. Roadside Assistance will be provided in ac- cordance with standard program guide- lines which include providing service to the vehicle up to a reasonable distance from a paved roadway. We will make every effort to assist in a breakdown situation, howev- er, the accessibility of your vehicle will be determined by our authorized Mercedes-Benz Light Truck Center techni- cian or the tow service provider on a case-by-case basis and may be a factor in our ability to respond. 12 Operating your vehicle outside the USA or Canada If you plan to operate your vehicle in for- eign countries, please be aware that: 앫 service facilities or replacement parts may not be readily available, 앫 unleaded gasoline for vehicles with cat- alytic converters may not be available; the use of leaded fuels will damage the catalysts, 앫 gasoline may have a considerably low- er octane rating, and improper fuel can cause engine damage. Change of address or ownership If you change your address, be sure to send in the “Change of Address Notice” found in the Service and Warranty Informa- tion Booklet, or simply call the Mercedes-Benz Customer Assistance Center (in the USA) at 1-800-FOR-MERCedes, or Customer Ser- vice (in Canada) at 1-800-387-0100. It is in your own interest that we can contact you should the need arise. If you sell your Mercedes, please leave all literature with the vehicle to make it avail- able to the next operator. If you bought this vehicle used, be sure to send in the “Notice of Purchase of Used Truck” found in the Service and Warranty Information Booklet, or call the Mercedes-Benz Customer Assistance Cen- ter (in the USA) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100. Introduction Operator’s Manual 13 Introduction Where to find it Where to find it This Operator’s Manual is designed to pro- vide comprehensive support information for you, the vehicle operator. Each section has its own reference color. At a glance Here you will find an overview of all the controls that can be operated from the driver’s seat. Getting started Here you will find all the information you need for your first drive. You should read this section first if this is your first Mercedes-Benz vehicle or if you are rent- ing or borrowing this vehicle. Safety and Security Here you will find descriptions of the safety and security features of your vehicle. 14 Controls in detail Here you will find detailed information about the equipment installed on your ve- hicle. This section expands on the “Getting started” section and also describes techni- cal innovations. If you are already familiar with the basic functions of your vehicle, this section will be of particular interest to you. Operation Here you will find all the information you need for the proper operation of your vehi- cle. Practical hints This section provides fast assistance for dealing with problems you may encounter. Technical data All important technical data for your vehi- cle can be found in this section. Indexes The glossary provides explanations of the most important technical terms. The table of contents and the index are de- signed to help you find information quickly and easily. The following publications are part of your vehicle documentation: 앫 this Operator’s Manual 앫 the Maintenance Booklet Separate operating instructions will be provided as required depending on the equipment options installed in your vehi- cle. Introduction Symbols Symbols Trademarks: 앫 ESP® and PRE-SAFE® are registered trademarks of DaimlerChrysler. 앫 HomeLink® is a registered trademark of Prince, a Johnson Controls Company. The following symbols are found in this Operator’s Manual: Optional equipment is identified with an asterisk. Since standard equipment varies between models, the descriptions and illustrations in this manual may differ slightly from the actual equipment of your vehi- cle. Warning! 왘 This symbol points to instructions for you to follow. Warning notices draw your attention to haz- ards that may endanger your health or life, or the health or life of others. 왘 A number of these symbols appearing in succession indicates a multiple-step procedure. Highlights hazards that may result in damage to your vehicle. 컄 Page 컄컄 Helpful hints or further information you may find useful. -> This symbol tells you where to look for further information on a topic. This continuation symbol marks an interrupted procedure which will be continued on the next page. In the glossary of technical terms, this symbol is used to in- dicate cross-references to term definitions. Display Words appearing in the multi- function display are printed in the type shown here. 15 Introduction Operating safety Warning! Warning! Proper use of the vehicle Work improperly carried out on electronic components and associated software could cause them to cease functioning. Because the vehicle’s electronic components are in- terconnected, any modifications made may produce an undesired effect on other sys- tems. Electronic malfunctions could seriously impair the operating safety of your vehicle. See an authorized Mercedes-Benz Light Truck Center for repairs or modifications to electronic components. Other improper work or modifications on the vehicle could also have a negative impact on the operating safety of the vehicle. Some safety systems only function while the engine is running. You should therefore nev- er turn off the engine while driving. Heavy blows against the vehicle underbody or tires/wheels, for example when running over an obstacle, road debris or a pothole, may cause serious damage and impair the operating safety of your vehicle. If you feel a sudden significant vibration or ride distur- bance, or you suspect that damage to your vehicle has occurred, you should turn on your hazard warning flashers, carefully slow down, and drive with caution to an area which is a safe distance from the road. Inspect the vehicle underbody and tires/wheels for possible damage. If the ve- hicle appears unsafe, have it towed to the nearest authorized Mercedes-Benz Light Truck Center or other qualified maintenance or repair facility for further inspection or re- pairs. Proper use of the vehicle requires that you are familiar with the following information and rules: 앫 the safety precautions in this manual 앫 the “Technical data” section in this manual 앫 traffic rules and regulations 앫 motor vehicle laws and safety stan- dards Warning! Various warning labels are attached to your vehicle. These warning labels are intended to make you and others aware of various risks. You should not remove any of these warning labels unless explicitly instructed to do so by information on the label itself. Re- moval of any of these labels may cause you and others to be unaware of certain risks which may result in an accident and/or per- sonal injury. 16 Introduction Problems with your vehicle 왔 Problems with your vehicle If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact an authorized Mercedes-Benz Light Truck Center to have the problem diagnosed and corrected if required. If the matter is not handled to your satisfaction, please discuss the problem with the Mercedes-Benz Light Truck Center management, or if necessary contact us at one of the following addresses: In the USA: Customer Assistance Center Mercedes-Benz USA, LLC One Mercedes Drive Montvale, NJ 07645-0350 In Canada: Customer Relations Department Mercedes-Benz Canada, Inc. 98 Vanderhoof Avenue Toronto, Ontario, M4G 4C9 17 Introduction Reporting safety defects For the USA only: The following text is published as required of manufacturers under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”. Reporting safety defects If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or Mercedes-Benz USA, LLC. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-888-327-4236 (or 366-0123 in Washington, D.C. area) or write to: NHTSA, U.S. Department of Transportation, Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline. 18 Introduction Vehicle data recording 왔 Vehicle data recording Information regarding electronic recording devices (Including notice pursuant to California Code § 9951) Please note that your vehicle is equipped with devices that can record vehicle systems data and, if equipped with the Tele Aid* system, may transmit some data in certain accidents. This information helps, for example, to diagnose vehicle systems after a collision and to continuously improve vehicle safety. DaimlerChrysler may access the information and share it with others 앫 for safety research or vehicle diagnosis purposes 앫 with the consent of the vehicle owner or lessee 앫 in response to an official request by law enforcement or other government agency 앫 for use in dispute resolution involving DaimlerChrysler, its affiliates or sales/service organization and/or 앫 as otherwise required or permitted by law. Please check the Tele Aid* subscription service agreement for details regarding the information that may be recorded or transmitted via that system. 19 20 At a glance Cockpit Instrument cluster Multifunction steering wheel Center console Overhead control panel Storage compartments Door control panel 21 At a glance Cockpit 22 At a glance Cockpit Item Page Item 1 Cruise control lever 2 Instrument cluster 3 Multifunction steering wheel 4 Horn 5 Steering wheel gearshift buttons 6 Gear selector lever for automatic transmission 7 Front Parktronic* warning indicators 8 Overhead control panel 9 Glove box release Glove box lock 265 24 28 206 53 276 31 294 295 a Glove box b Electrical outlet c Center console d Starter switch e Steering wheel adjustment, manual f Steering wheel adjustment, 46 electrical* g Hood lock release h Parking brake pedal j Remote tailgate switch 345 65 123 Page 294 307 29 38 45 Item k Parking brake release l Headlamp washer switch* m Exterior lamp switch n Door control panel o Combination switch 앫 Turn signals 앫 Windshield wipers 앫 High beam 앫 Rear window wiper Page 56 208 147 34 58 59 58 61 23 At a glance Instrument cluster 24 Item Page Item 1 L Left turn signal indicator lamp 2 To dim instrument cluster illumination 3 Reset button 4 To brighten instrument clus- ter illumination 5 K Right turn signal indicator lamp 6 Clock 158 158 158 7 Speedometer with: - Antilock Brake System (ABS) indicator lamp Page 404 ; Brake warning lamp, 405 USA only 3 Brake warning lamp, 405 Canada only v Electronic Stability 409 Program (ESP®) warning lamp At a glance Instrument cluster Item ’ Variable speed limiter indicator lamp1 l Distance warning lamp1 H Combination low tire pressure/TPMS mal- function telltale* Page 412 1 Warning lamp without function. It illuminates when the ignition is on. It should go out when the engine is running. 25 At a glance Instrument cluster 26 Item Page Item 8 Multifunction display with: a Fuel gauge with: Trip odometer Main odometer 9 Tachometer with: < Seat belt telltale 1 Supplemental Restraint System (SRS) indicator lamp 159 161 77, 410 70, 411 ? Engine malfunction in- 407 dicator lamp, USA only ± Engine malfunction in- 407 dicator lamp, Canada only A High beam headlamp 151 indicator Fuel tank reserve warning lamp 4 Fuel filler flap indica- tor: The fuel filler flap is located on the rear right-hand side b Multifunction display with: Outside temperature display or Digital speedometer (depending on selected setting in the control system) Gear position indicator Gear range indicator Selected program mode indicator Page 409 342 161 161 179 199 199 199 At a glance Instrument cluster 27 Page 161 162 Item Page 4 Moving within a menu: Press button j for next display k for previous display 5 Menu systems: Press button è for next menu ÿ for previous menu Item 1 Multifunction display Operating the control system 2 Telephone* Press button s to take a call t to end a call 3 Selecting the submenu or setting the volume: Press button æ up/to increase ç down/to decrease At a glance Multifunction steering wheel 28 왔 Center console Upper part Item Page Item 1 Modular COMAND System, see separate operating in- structions 2 Climate control 3-zone automatic climate control* 3 Seat heating*, front passen- ger side 4 Vehicle level control switch* 5 Program mode selector switch for automatic trans- mission 216 230 141 272 204 At a glance Center console 6 Front passenger front air bag indicator lamp 7 Hazard warning flasher 8 Alarm system indicator lamp Page 89, 414 153 105 9 Parking assist (Parktronic 277 system)* deactivation switch a Electronic Stability Program 101 (ESP®) switch b Adaptive damping system 269 (ADS)* switch c Seat heating*, driver’s side 141 29 Item 1 Storage compartment 2 Armrest storage tray re- lease 3 Armrest storage compart- ment release 4 Storage compartment Ashtray with cigarette lighter* 5 Cup holder 6 Card, ticket holder Bottle opener Page 296 296 296 296 303 299 300 300 At a glance Center console Lower part 30 왔 Overhead control panel At a glance Overhead control panel Item a Interior rear view mirror b Reading lamp, front passen- ger side Page 208 154 c Vehicles with telephone* 311 installed: Hands-free microphone for TeleAid* (emergency call system) and telephone* d Garage door opener* e Reading lamp, driver’s side f Front left interior lamp lens 320 154 154 Page 154 154 154 154 154 154 255 259 314 311 Item 1 Left reading lamp on/off 2 Rear interior lighting on/off 3 Automatic interior lighting 4 Front interior lighting on/off 5 Right reading lamp on/off 6 Front right interior lamp lens 7 Tilt/sliding sunroof* switch Tilt/sliding panel* switch 8 Tele Aid* (emergency call system) button 9 Vehicles without telephone* installed: Hands-free microphone for TeleAid* (emergency call system) 31 At a glance Storage compartments 32 At a glance Storage compartments Item Page Item 1 Parcel net in front passen- ger footwell 2 Glove box/CD-changer* 3 Door pocket 4 Parcel net on front passen- ger seat backrest 5 Door pocket 6 Cup holder 7 Third-row storage compart- ment Page 298 294 298 302 298 8 Parcel net in cargo compart- 299 ment 9 First aid kit, vehicle tool kit, 454 spare wheel a Third-row storage compart- 298 ment b Cup holder c Door pocket d Parcel net on driver’s seat backrest e Door pocket f Storage compartment in center console g Storage compartment in center console Ashtray* h Cupholders j Front armrest storage com- partments k Cup holders* l Rear armrest storage com- partment* m Cup holders 302 Rear storage compartment Rear seat ashtray* 298 296 296 303 298 296 302 297 301 297 304 33 At a glance Door control panel 34 Item 1 Door handle 2 Central locking/unlocking switch 3 Exterior rear view mirror ad- justment 4 Selection buttons for exteri- or rear view mirror adjust- ment Power-folding exterior rear view mirrors* 5 Switches for opening/clos- ing front and rear door win- dows 6 Rear side window override switch 7 Hinged quarter window switch* 8 Remote tailgate release switch, Tailgate opening system* Page 121 131 48 48 211 248 94 250 123, 124 Getting started Unlocking Adjusting Driving Parking and locking 35 Getting started Unlocking The “Getting started” section provides an overview of the vehicle’s most basic func- tions. First-time Mercedes-Benz owners should pay special attention to the infor- mation given here. If you are already familiar with the basic functions described here, the “Controls in detail” section will provide you with further information. The corresponding page references are located at the end of each segment. Unlocking with the SmartKey SmartKey 1 ‹ Lock button 2 Š Unlock button* for tailgate 3 Œ Unlock button 4 Â Panic button (컄 page 95) 36 Warning! When leaving the vehicle, always remove the SmartKey from the starter switch, take it with you, and lock the vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsuper- vised use of vehicle equipment may cause an accident and/or serious personal injury. 왘 Press unlock button Œ on the SmartKey. All turn signal lamps flash once. The ve- hicle unlocks. The locking knobs in the doors move up. The anti-theft alarm system is disarmed. The locator light- ing comes on if the feature is enabled in the control system (컄 page 183). 왘 Enter the vehicle and insert the SmartKey in the starter switch. For more information, see “Locking and unlocking” (컄 page 110). Getting started Unlocking To unlock the vehicle, the SmartKey with KEYLESS-GO must be outside the vehicle, no further than approximately 3 feet (1 meter) away from the respec- tive door. Warning! When leaving the vehicle, always take the SmartKey with KEYLESS-GO* with you, and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment may cause an accident and/or serious personal injury. 왘 Grasp an outside door handle or the tailgate handle. All turn signal lamps flash once. The ve- hicle unlocks. The locking knobs in the doors move up. The anti-theft alarm system is disarmed. The locator light- ing comes on if the feature is enabled in the control system (컄 page 183). If the vehicle has been parked for more than 72 hours, you must pull an outside door handle in order to activate the KEYLESS-GO function. 왘 Enter the vehicle. For more information, see “SmartKey with KEYLESS-GO*” (컄 page 114). Unlocking with Keyless-Go* With the KEYLESS-GO function, you can lock or unlock the vehicle without using the remote control buttons on the SmartKey and start the engine without in- serting the SmartKey into the starter switch. SmartKey with KEYLESS-GO* 1 ‹ Lock button 2 Š Unlock button* for tailgate 3 Œ Unlock button 4 Â Panic button (컄 page 95) 37 Getting started Unlocking Starter switch positions SmartKey Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you and lock the vehicle. Do not leave children unat- tended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehi- cle equipment may cause an accident and/or serious personal injury. 38 Starter switch 0 For removing SmartKey 1 Power supply for some electrical con- sumers, such as seat adjustment 2 Ignition (power supply for all electrical consumers) and driving position All lamps (except high beam headlamp indicator lamp and turn signal indicator lamps unless activated) in the instru- ment cluster come on. If a lamp in the instrument cluster fails to come on when the ignition is switched on, have it checked and replaced if necessary. If a lamp in the instrument cluster re- mains on after starting the engine or comes on while driving, refer to “Lamps in instrument cluster” (컄 page 404). 3 Starting position When you switch on the ignition, the in- dicator and warning lamps (except high beam headlamp indicator lamp and turn signal indicator lamps unless acti- vated) in the instrument cluster come on. The indicator and warning lamps (except high beam headlamp indicator lamp and turn signal indicator lamps if activated) will go out when the engine is running. This indicates that the re- spective systems are operational. When the SmartKey is removed from the starter switch and the automatic transmission is in a position other than P, the automatic transmission automatically shifts to P. ! If the SmartKey cannot be turned in the starter switch, the battery may not be sufficiently charged. 앫 Check the battery and charge it if necessary (컄 page 487). 앫 Get a jump start (컄 page 496). To prevent accelerated battery dis- charge or a completely discharged bat- tery, always remove the SmartKey from the starter switch when the engine is not in operation. SmartKey with KEYLESS-GO* Vehicles equipped with the KEYLESS-GO feature are supplied with a SmartKey with integrated KEYLESS-GO function and a re- movable KEYLESS-GO start/stop button. With the KEYLESS-GO start/stop button inserted and the SmartKey with KEYLESS-GO present in the vehicle, press- ing the KEYLESS-GO start/stop button 앫 without the brake pedal depressed corresponds to the various starter switch positions (컄 page 40) 앫 with the brake pedal firmly depressed will start the engine (컄 page 54) If you wish or should there be a need to in- sert the SmartKey with KEYLESS-GO in the starter switch, the KEYLESS-GO start/stop button can be easily removed by pulling it out of the starter switch. Getting started Unlocking The KEYLESS-GO start/stop button does not need to be removed from the starter switch when you leave the vehi- cle. However, always take the SmartKey with KEYLESS-GO with you when you leave the vehicle. As long as the SmartKey with KEYLESS-GO is in the vehicle, the vehicle’s electrical sys- tems can be switched on or the engine can be started using the KEYLESS-GO start/stop button. 39 Getting started Unlocking 1 KEYLESS-GO start/stop button 2 Starter switch KEYLESS-GO start/stop button 3 USA only 4 Canada only 40 The SmartKey with KEYLESS-GO must be located in the vehicle. 왘 Insert KEYLESS-GO start/stop button 1 into starter switch 2 (if not inserted already). 왘 Make sure the automatic transmission is set to P. 왘 Do not depress the brake pedal. Position 0 Before you press the KEYLESS-GO start/stop button, the vehicle’s on-board electronics have status 0 (as with SmartKey removed). Position 1 왘 Press the KEYLESS-GO start/stop but- ton once. This supplies power for some electrical consumers, such as seat adjustment. If you now press the KEYLESS-GO start/stop button 앫 once more, the ignition (position 2) is switched on 앫 twice more, the power supply is again switched off Ignition (or Position 2) 왘 Press the KEYLESS-GO start/stop but- ton twice. This supplies power for all electrical consumers. All lamps (except high beam headlamp indicator lamp and turn signal indicator lamps unless activated) in the instru- ment cluster come on. If a lamp in the instrument cluster fails to come on when the ignition is switched on, have it checked and replaced if necessary. If a lamp in the instrument cluster re- mains on after starting the engine or comes on while driving, refer to “Lamps in instrument cluster” (컄 page 404). For information on starting the engine using the KEYLESS-GO start/stop button, see “Starting with KEYLESS-GO*” (컄 page 54). For more information on KEYLESS-GO, see “SmartKey with KEYLESS-GO*” (컄 page 114). If you now press the KEYLESS-GO start/stop button once more, the pow- er supply is again switched off. When you switch on the ignition, the in- dicator and warning lamps (except high beam headlamp indicator lamp and turn signal indicator lamps unless acti- vated) in the instrument cluster come on. The indicator and warning lamps (except high beam headlamp indicator lamp, and turn signal indicator lamps if activated) will go out when the engine is running. This indicates that the re- spective systems are operational. Getting started Unlocking 41 Getting started Adjusting Warning! All seat, head restraint, steering wheel, and rear view mirror adjustments, as well as fas- tening of seat belts, must be done before the vehicle is put into motion. Seats Warning! Do not adjust the driver’s seat while driving. Adjusting the seat while driving could cause the driver to lose control of the vehicle. Never ride in a moving vehicle with the seat back in an excessively reclined position as this can be dangerous. You could slide un- der the seat belt in a collision. If you slide under it, the belt would apply force at the ab- domen or neck. That could cause serious or fatal injuries. The seat backrest and seat belts provide the best restraint when the wearer is in a nearly upright position and belts are properly positioned on the body. 42 Your seat must be adjusted so that you can correctly fasten your seat belt (컄 page 50). Never place hands under the seat or near any moving parts while a seat is being ad- justed. Warning! When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Even with the SmartKey or the SmartKey with KEYLESS-GO* removed from the starter switch or the SmartKey with KEYLESS-GO* removed from the vehicle, the power seats can be operated when the respective door is open. Therefore, do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equip- ment may cause an accident and/or seri- ous personal injury. Warning! According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seat- ing position. Thus, we strongly recommend that children be placed in the rear seats whenever possible. Regardless of seating position, children 12 years old and under must be seated and properly secured in an appropriate infant or toddler restraint, or booster seat recommended for the size and weight of the child. For additional informa- tion, see “Children in the vehicle” (컄 page 82). A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint. Seat adjustment The seat adjustment switch is located on the entry side of each front seat base. 1 Head restraint height* 2 Seat cushion tilt 3 Seat height 4 Backrest tilt 5 Seat fore and aft adjustment Getting started Adjusting 왘 Switch on the ignition (컄 page 38). or 왘 Open the respective door (vehicles with memory function*). The seat can be adjusted with the re- spective door opened. or 왘 Open a front door (vehicles without memory function*). The seat can be adjusted within 3 minutes after either front door has been opened. When adjusting the seat backrest tilt and head restraint height, make sure the sun visor is folded up (컄 page 212). If the head restraint is in the uppermost position, it could hit and damage the sun visor. The memory function* (컄 page 144) lets you store the settings for the seat position together with the settings for the steering wheel column and the ex- terior rear view mirrors. Seat fore and aft adjustment 왘 Press the switch forward or backward in direction of arrow 5. Adjust the seat to a comfortable seat- ing position that still allows you to reach the accelerator/brake pedal safely. The position should be as far to the rear as possible, consistent with ability to properly operate controls. When moving the seat, make sure there are no items in the footwell or be- hind the seat. Otherwise you could damage the seat. 43 Getting started Adjusting Seat height 왘 Press the switch up or down in the direction of arrow 3. Seat cushion tilt 왘 Press the switch up or down in direction of arrow 2 until your upper legs are lightly supported. Seat backrest tilt 왘 Press the switch forward or backward in direction of arrow 4 until your arms are slightly angled when holding the steering wheel. 44 Vehicles with memory function*: 왘 Press switch (컄 page 43) up or down in direction of arrow 1. Vehicles without memory function*: 1 Head restraint 2 Release button Head restraint height Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint so that the center of the head restraint supports the back of the head at eye level. This will reduce the poten- tial for injury to the head and neck in the event of an accident or similar situation. Do not drive the vehicle without the seat head restraints. Head restraints are intend- ed to help reduce injuries during an acci- dent. Do not attempt to remove front seat head restraints. They can only be re- moved by qualified technicians. We recommend that you have this work carried out by an authorized Mercedes-Benz Light Truck Center. Raising: 왘 Manually adjust the height of head restraint 1 by pulling it upward. If head restraint 1 is fully retracted, push release button 2 in direction of arrow and pull head restraint 1 up- ward. Lowering: 왘 To lower head restraint 1, push release button 2 in direction of arrow and press down on head restraint 1. Head restraint tilt Steering wheel Getting started Adjusting Manually adjust the angle of the head restraint. 왘 Push or pull on the lower edge of the head restraint cushion. Adjust the head restraint in such a way that it is as close to the head as possi- ble. For more information, see “Seats” (컄 page 132). Steering wheel adjustment, manual Warning! Only adjust the steering wheel with the vehi- cle at a standstill and make sure the steer- ing wheel is securely locked in place before driving off. Driving without the steering wheel adjust- ment locked may cause an unexpected steering wheel movement which could cause the driver to lose control of the vehi- cle. Make sure the steering wheel is secure- ly locked by trying to move it up and down, and in and out before driving off. 45 Getting started Adjusting The handle for steering wheel adjustment is located on the lower left of the steering column. 왘 To unlock the steering column, pull handle out to its stop limit. 왘 Move steering wheel to the desired po- sition. Make sure your legs can move freely and that all displays (including malfunc- tion and indicator lamps) on the instru- ment cluster are clearly visible. 46 왘 Push handle back to its original posi- Steering wheel adjustment, electrical* tion to relock the steering column. The steering column is locked into po- sition again. 왘 Make sure the steering column is se- curely locked by trying to move the steering wheel up and down as well as in and out before driving off. Warning! Do not adjust the steering wheel while driv- ing. Adjusting the steering wheel while driv- ing could cause the driver to lose control of the vehicle. When leaving the vehicle, always remove the SmartKey or SmartKey with KEYLESS-GO* from the starter switch, take it with you, and lock the vehicle. Even with the SmartKey or SmartKey with KEYLESS-GO* removed from the starter switch or the SmartKey with KEYLESS-GO* removed from the vehicle, the steering wheel adjustment feature can be operated when the driver’s door is open. Therefore, do not leave children unattended in the ve- hicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause an accident and/or serious personal injury. The stalk for steering wheel adjustment is located on the lower left of the steering column. 1 Adjusting steering column, in or out 2 Adjusting steering column, up or down 왘 Switch on the ignition (컄 page 38). or 왘 Open the driver’s door. Adjusting steering column in or out 왘 Move stalk forward or back in direction of arrow 1 until a comfortable steer- ing wheel position is reached with your arms slightly bent at the elbow. Adjusting steering column up or down 왘 Move stalk up or down in direction of arrow 2. Make sure your legs can move freely and that all displays (including malfunc- tion and indicator lamps) on the instru- ment cluster are clearly visible. The memory function (컄 page 144) lets you store the settings for the steering wheel column together with the set- tings for seat positions and the exterior rear view mirrors. Getting started Adjusting Mirrors Adjust the interior and exterior rear view mirrors before driving so that you have a good view of the road and traffic condi- tions. Warning! In case of an accident, liquid electrolyte may escape the mirror housing if the mirror glass breaks. Electrolyte has an irritating effect. Do not al- low the liquid to come into contact with eyes, skin, clothing, or respiratory system. In case it does, immediately flush affected area with water, and seek medical help if necessary. Electrolyte drops coming into contact with the vehicle paint finish can only be completely removed while in their liquid state and by applying plenty of water. 47 Getting started Adjusting Interior rear view mirror 왘 Manually adjust the interior rear view The buttons are located on the driver’s door. mirror. For more information, see “Rear view mir- rors” (컄 page 208). Exterior rear view mirrors Warning! Exercise care when using the
