2009 Hyundai Santa FE Owners Manual

Download PDF Manual
OWNER'S MANUAL A030A01A-AAT Operation Maintenance Specifications All information in the Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time as part of our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and expla- nations of optional as well as standard equipment. As a result, you may find material in this manual that does not apply to your specific vehicle. F1 EN hma cover.qxd 11/27/2006 5:07 PM Page 2 WARRANTIES FOR YOUR HYUNDAI VEHICLE Please consult your Owner's Handbook & Warranty Information booklet for your vehicle's spe- cific warranty coverage. RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 7. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals. When the vehicle is used in severe driving conditions, more frequent main- tenance is required for some operations. Maintenance requirements for severe operating conditions are also included in Section 7. A070A01A-AAT CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your Hyundai should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S. Department of Transportation and other federal or state agencies. A080A01S-AAT TWO-WAY RADIO OR CELLULAR TELEPHONE INSTALLATION Your vehicle is equipped with electronic fuel injection and other electronic components. It is possible for an improperly installed/adjusted two-way radio or cellular telephone to adversely affect electronic systems. For this reason, we recommend that you carefully follow the radio manufacturer's instruc- tions or consult your Hyundai dealer for precautionary measures or special instructions if you choose to install one of these devices. F2 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning. WARNING: CAUTION: This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded. Follow the advice provided with the caution. NOTE: This indicates that interesting or helpful information is being provided. F3 A110A01A-AAT VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS Your Hyundai vehicle is equipped with many high technology, electronically controlled systems that help to ensure your vehicle operates properly and provides the performance that you expect. These systems utilize computers to monitor the operation of various systems and components and help to control their operation. These computerized system operations are wide-ranging and involve components to reduce emissions, to continuously evaluate the readiness of the air bag and seat belt pretensioner systems, to determine when the air bag and seat belt pre-tensioner systems should be deployed and then to activate the deployment, and if equipped, to operate anti-lock braking, traction control and electrical stability control to assist the driver to control the vehicle in difficult driving situations. These systems electronically store information that is useful to service technicians when they need to diagnose and repair these systems. Additional information is stored only when a crash occurs that results in the deployment of the air bags or seat belt pre-tensioners. This type of data storage is done by devices called event data recorders(EDR). After a crash event, the air bag and seat belt pre-tensioner computer system, known as the Supplemental Restraint System Control Module (SRSCM) or Air bag Control Unit (ACU), may record some information about the condition of the vehicle and how it was being operated. This information consists of data related to seat belt usage and if there was diagnostic information in the air bag or seat belt systems at the time that a crash occurred, and if the ACU sensed that a crash of sufficient severity occurred to require seat belt pre-tensioner or air bag deployment. To retrieve this information, special equipment is needed and access to the vehicle or the device that stores the data is required. Hyundai will not access information about a crash event or share it with others except: o in response to an official request of police or similar government office, or o with the consent of the vehicle owner or, if the vehicle is leased, with the consent of the lessee, or o as part of Hyundai’s defense of litigation, or o as required by law. F4 A040A01A-AAT FOREWORD Thank you for choosing Hyundai. We are pleased to welcome you to the growing number of discriminating people who drive Hyundais. The advanced engineering and high-quality construction of each Hyundai we build is something of which we're very proud. Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car. The manufacturer also recommends that all service and maintenance on your car be performed by an authorized Hyundai dealer. Hyundai dealers are prepared to provide high-quality service, maintenance and any other assistance that may be required. A050A04A-AAT HYUNDAI MOTOR COMPANY Note: Because future owners will also need the information included in this manual, if you sell this Hyundai, please leave the manual in the vehicle for their use. Thank you. CAUTION: Severe engine and transaxle damage may result from the use of poor quality fuels and lubricants that do not meet Hyundai specifications. You must always use high quality fuels and lubricants that meet the specifications listed on Page 9-4 in the Vehicle Specifications section of the Owner's Manual and which also appear in the Service Station Information on the back cover of the Owner's Manual. Copyright 2008 Hyundai Motor Company. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of Hyundai Motor Company. F5 A100A03A-AAT Guide to Hyundai Genuine Parts 1. What are Hyundai Genuine Parts? Hyundai Genuine Parts are the same parts used by Hyundai Motor Company to manufacture vehicles. They are de- signed and tested for the optimum safety, performance, and reliability to our cus- tomers. 2. Why should you use genuine parts? Hyundai Genuine Parts are engineered and built to meet rigid manufacturing requirements. Using imitation, counter- feit or used salvage parts is not covered under the Hyundai New Vehicle Lim- ited Warranty or any other Hyundai warranty. In addition, any damage to or failure of Genuine Hyundai Parts caused by the installation or failure of an imita- tion, counterfeit or used salvage part is not covered by any Hyundai Warranty. 3. How can you tell if you are purchasing Hyundai Genuine Parts? Look for the Hyundai Genuine Parts Logo on the package (see below). Hyundai Genuine Parts exported to the United States are packaged with labels written only in English. Hyundai Genuine Parts are only sold through Hyundai Dealerships. authorized To find the closest authorized dealer call 1-800-826-CARS A100A03L A100A01L A100A02L A100A04L F6 SECTION TABLE OF CONTENTS FEATURES OF YOUR HYUNDAI DRIVING YOUR HYUNDAI WHAT TO DO IN AN EMERGENCY CORROSION PREVENTION & APPEARANCE CARE VEHICLE MAINTENANCE REQUIREMENTS DO-IT-YOURSELF MAINTENANCE EMISSION CONTROL SYSTEMS CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS VEHICLE SPECIFICATIONS INDEX 10 F7 INSTRUMENTS AND CONTROLS B250A01CM-AAT F8 OCM008001N 1. Steering Wheel ......................................................... 1-118 2. Horn and Driver's Air bag ................................ 1-119, 1-44 Instrument Cluster ........................................................ 1-62 3. 4. Ignition Switch ................................................................ 1-7 5. Hazard Warning Switch ............................................... 1-83 6. Front Window Defroster Switch ................................ 1-141 7. Digital Clock ................................................................. 1-84 8. Rear Window Defroster Switch (If installed) ................ 1-83 9. Passenger Air bag Off Indicator ................................... 1-52 10. Rear Air Conditioning Switch (If installed) ............... 1-141 11. Passenger's Air bag ..................................................... 1-51 12. Multi-Function Light Switch ......................................... 1-75 13. Hood Release Lever ................................................ 1-115 14. Parking Brake Pedal (If installed) ............................. 1-108 15. Windshield Wiper/Washer Switch ............................... 1-78 16. Heating/Air Conditioning Control Panel ................... 1-125 17. Cigarette Lighter .......................................................... 1-85 18. Center Console Box .................................................... 1-96 19. Shift Lever (If installed) ................................................ 2-10 20. Power Outlet ................................................................ 1-86 21. Ashtray ......................................................................... 1-85 22. Glove Box .................................................................... 1-95 23. Audio System (If installed) ........................................ 1-147 CAUTION: When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel surface. If there is any leakage from the air freshener onto these areas (Instrument cluster, instrument panel or air ventilator), it may damage these parts. If the liquid from the air freshener does leak onto these areas, wash them with water immediately. F9 YOUR VEHICLE AT A GLANCE B255A01CM-AAT INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Turn Signal Indicator Lights ABS Service Reminder Indicator Electronic Stability Control (ESC) Indicator Lights Malfunction Indicator Light Cruise Indicator Light Cruise SET Indicator Light High Beam Indicator Light AWD System Warning Light Low Oil Pressure Warning Light AWD Lock Indicator Light Parking Brake/Brake Fluid Level Warning Light Immobilizer Warning Light (If Installed) Charging System Warning Light Low Windshield Washer Fluid Level Warning Light Door Ajar Warning Light Tail Gate Open Warning Light Low Fuel Level Warning Light Seat Belt Warning Light TPMS (Tire pressure monitoring system) malfunc- tion indicator Low tire pressure telltale SRS (Air bag) Service Reminder Indicator (SRI) Low tire pressure position telltale * More detailed explanations of these items will be found beginning on page 1-64. F10 FEATURES OF YOUR HYUNDAI Fuel Recommendations ................................................ 1-2 Breaking in Your New Hyundai ..................................... 1-3 Keys .............................................................................. 1-3 Door .............................................................................. 1-7 Power Windows .......................................................... 1-14 Seats ........................................................................... 1-16 Seat Belts.................................................................... 1-27 Child Restraint System ............................................... 1-33 Supplemental Restraint (AIR BAG) system ................ 1-43 Instrument Cluster and Indicator Lights ...................... 1-62 Warning and Indicator Lights ...................................... 1-64 Multi-Function Light Switch ......................................... 1-75 Windshield Wiper and Washer Switch ........................ 1-78 Sunroof ....................................................................... 1-89 Mirror ........................................................................... 1-97 Luggage Compartment .............................................. 1-109 Hood Release ........................................................... 1-115 Cruise Control ........................................................... 1-120 Heating and Cooling Control ..................................... 1-125 Antenna ..................................................................... 1-142 Stereo Sound System ............................................... 1-144 Audio System ............................................................ 1-147 1FEATURES OF YOUR HYUNDAI FUEL RECOMMENDATIONS B010A02CM-AAT Use Unleaded Gasoline UNLEADED FUEL ONLY WARNING: o Do not "top off" after the nozzle auto- matically shuts off when refueling. o Tighten the cap until it clicks, other- wise the " " light will illuminate. o Always check that the fuel cap is installed securely to prevent fuel spill- age in the event of an accident. OCM051001R Unleaded gasoline with a Pump Octane Rating of 87(Research Octane Number 91) or Higher must be used. B010B01A-AAT What About Gasohol? Gasohol (a mixture of 90% unleaded gaso- line and 10% ethanol or grain alcohol) may be used in your Hyundai. However, if your engine develops driveability prob- lems, the use of 100% unleaded gasoline is recommended. Fuels with unspecified quantities of alcohol, or alcohols other than ethanol, should not be used. B010C01A-AAT Use of MTBE Hyundai recommends that fuels contain- ing MTBE (Methyl Tertiary Butyl Ether) over 15.0% vol. (Oxygen Content 2.7% weight) should not be used in your Hyundai. Fuel containing MTBE over 15.0% vol. (Oxygen Content 2.7% weight) may re- duce vehicle performance and produce vapor lock or hard starting. B010D01A-AAT Do Not Use Methanol Fuels containing methanol (wood alco- hol) should not be used in your Hyundai. This type of fuel can reduce vehicle perfor- mance and damage components of the fuel system. CAUTION: Your Hyundai's New Vehicle Limited War- ranty may not cover damage to the fuel system and any performance problems that are caused by the use of fuels con- taining methanol or fuels containing MTBE (Methyl Tertiary Butyl Ether) over 15.0% vol. (Oxygen Content 2.7% weight.) FEATURES OF YOUR HYUNDAI KEYS B030A01A-AAT OMC025001 For greater convenience, the same key operates all the locks in your Hyundai. However, because the doors can be locked without a key, carrying a spare key is recommended in case you accidentally lock one key inside the car. B010E01A-AAT Gasolines for Cleaner Air To help contribute to cleaner air, Hyundai recommends that you use gasolines treated with detergent additives, which help prevent deposit formation in the en- gine. These gasolines will help the engine run cleaner and enhance performance of the Emission Control System. BREAKING IN YOUR NEW HYUNDAI B020A01S-AAT During the First 1,200 Miles (2,000 Km) No formal "break-in" procedure is required with your new Hyundai. However, you can contribute to the economical operation and durability of your Hyundai by observ- ing the following recommendations dur- ing the first 1,200 miles (2,000 km). B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to: o Observe all regulations regarding reg- avoid hard stops. istration and insurance. o Determine that acceptable fuel is avail- able. o Don't drive faster than 55 MPH (88 km/ h). o While driving, keep your engine speed (rpm, or revolutions per minute) be- tween 2,000 rpm and 4,000 rpm. o Use moderate acceleration. Don't start quickly or depress the accelerator pedal fully. o For the first 200 miles (300 km), try to o Don't lug the engine (in other words, don't drive so slowly in too high a gear that the engine "bucks"-shift to a lower gear). o Whether going fast or slow, vary your speed from time to time. o Don't let the engine idle longer than 3 minutes at one time. o Don't tow a trailer during the first 1,200 miles (2,000 km) of operation. 1FEATURES OF YOUR HYUNDAI B030B01NF-GAT Record Your Key Number B030B01MC A code number is attached on the number tag that came with the keys to your Hyundai. This key number tag should not be left with the keys but kept in a safe place, not in the vehicle. The key number should also be recorded in a place where it can be found in an emergency. If you need additional keys, or if you should lose your keys, your authorized Hyundai dealer can make new keys if you can supply the key number. IMMOBILIZER SYSTEM B880A01TG-AAT (If Installed) The immobilizer system is an anti-theft device, designed to deter automobile theft. NOTE: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, in- cluding interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's au- thority to operate the equipment. B880B03MC-GAT Keys B885B01JM All of the locks fitted to the vehicle are operated by the same key. However, since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the key does not become locked inside the vehicle by mistake. NOTE: If you make your own duplicate key, you will not be able to cancel the system or start the engine. ! CAUTION: o When starting the engine, do not use the key with other immobilizer keys around. Otherwise the engine may not start or may stop soon after it starts. Keep each keys separately not to have any malfunction after you re- ceive your new vehicle. o Do not install the metal accessories near the key or ignition switch. The engine may not start for the metal accessories may interrupt the tran- sponder signal from normally trans- mitting. ! WARNING: In order to prevent theft of your vehicle, do not leave spare keys anywhere in your vehicle. Your immobilizer password is a customer unique password and should be kept confidential. Do not leave this number anywhere in your vehicle. B880C01NF-GAT Key Numbers FEATURES OF YOUR HYUNDAI If you need additional keys or if you should lose your keys, your authorized Hyundai dealer can make new keys if you can supply the key number and master key. OMC025002 The vehicle key number is recorded on a number tag attached to the keys when the vehicle is first delivered to you. The key number should be recorded and kept in a safe place in case the need to order further keys arises. New keys are available from any Hyundai dealer by quoting the relevant key number. In the interest of security, the number tag attached to the keys which bears the key number should be removed from the key string after you receive your new vehicle. In addition, key numbers cannot be pro- vided by Hyundai for security reasons. 1FEATURES OF YOUR HYUNDAI B880D01CM-AAT "Limp Home" Mode and Related Procedures Immobillizer warning indicator HNF2011 If the immobilizer warning indicator blinks for five seconds when the ignition key is turned to the "ON" position, this indicates the immobilizer system requires service. The engine cannot be started without us- ing the procedure below. The following procedure describes how to start the engine using the limp home func- tion (0, 1, 2, 3 as a sample password). NOTE: You can get a limp home password when the vehicle is first delivered to you. If you do not have a password, consult your authorized Hyundai dealer. 1. To activate the password, turn the igni- tion key "ON" and "OFF" according to the digit numbers. The immobilizer indi- cator will blink along with the operation of the ignition key. For example, turn the ignition key once for digit number "1", and twice for "2", and so on. For the digit number "0", you must cycle the ignition key 10 times. 2. Wait for 3~10 seconds. 3. You may set the remaining number of digits by following steps 1 and 2. 4. If all of the four password digits have been successfully entered, turn the ig- nition key "ON" and check that the im- mobilizer indicator illuminates. From this time, you have to start your engine within 30 seconds. If you try to start your engine after 30 seconds, your engine will not start. NOTE: If the engine stalls while driving in the "limp home" mode, you can start your engine within 2.5 seconds without re- entering the password. If the immobilizer indicator blinks for five seconds, you must re-enter the password (steps 1~4). After performing the limp home activation procedure, consult with your authorized Hyundai dealer as soon as possible. CAUTION: o If the password is entered incorrectly three consecutive times, wait for about one hour to perform the limp home activation procedure again. o If you cannot start your engine using the limp home activation procedure, have your vehicle towed by an autho- rized Hyundai dealer. B030C01CM-AAT Illuminated Ignition Switch (If installed) B030C01E-1 Whenever either front door is opened, the ignition switch will be illuminated for your convenience, provided the ignition switch is not in the "ON" position. The light will go off approximately 30 sec- onds after closing the door or when the ignition switch is turned on. DOOR LOCKS B040A01CM-AAT WARNING: o Unlocked doors can be dangerous. Before you drive away (especially if there are children in the car), be sure that all the doors are securely closed and locked so that the doors cannot be opened from the inside. o Before opening the door, always look for and avoid oncoming traffic. FEATURES OF YOUR HYUNDAI B040B01O-AAT Locking, unlocking front doors with a key LOCK UNLOCK OCM052005 o The door can be locked or unlocked with a key. o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key toward the rear. NOTE: The driver's door can be unlocked by turning the key once toward the rear. If you wish to unlock all doors, turn the key again toward the rear within 4 seconds. 1FEATURES OF YOUR HYUNDAI B040C02Y-AAT Locking from the Outside OCM051002L The doors can be locked without a key. To lock the doors from the outside, first push the inside lock switch to the "LOCK" posi- tion, so that the red mark on the switch is not visible, then close the door. The door will not lock if the key is left in the ignition switch when the front doors are closed. This is normal operation. NOTE: o When locking the door this way, be careful not to lock the door with the key left in the vehicle. o To discourage theft, always remove the ignition key, close all windows and lock all doors when leaving your ve- hicle unattended. B040D01NF-AAT Locking from the Inside UNLOCK LOCK OCM052006 To lock the doors from the inside, simply close the door and push the lock switch to the "LOCK" position. NOTE: o When the door is locked, the red mark on the switch is not visible. o The driver's and front passenger's doors can be opened by pulling the inside door handle even if the inside lock switch is pushed to the "LOCK" position. ! WARNING: Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can be opened and you may be ejected from the vehicle and can be injured or killed. FEATURES OF YOUR HYUNDAI B040E04A-AAT Child-Protector Rear Door Lock B040G01CM-AAT Central Door Locks UNLOCK LOCK (If installed) LOCK UNLOCK OCM052009 Your Hyundai is equipped with left and right side "child-protector" rear door locks. When the lock mechanism is engaged, the rear door cannot be opened from the in- side. Its use is recommended whenever there are small children in the rear seat. To engage the child-protector feature so that the door cannot be opened from the inside, move the child-protector lever to " position and close the door. Move the " " position when normal the lever to the " door operation is desired. To open the door from the outside, pull the outside door handle. OCM052007E The central door locking switch is located on the driver's and front passenger's (if installed) armrest. It is operated by de- pressing the door lock switch. If any door is open when the switch is depressed to the "LOCK" position, the door will remain locked when closed. NOTE: o Depressing the front portion of the driver's or front passenger's (if in- stalled) door lock switch "will lock", all vehicle doors. o Depressing the rear portion of these switches "will unlock", all vehicle doors. 1FEATURES OF YOUR HYUNDAI 10 o The driver's and front passenger's doors can be opened by pulling the inside door handle even if the front portion of the driver's or front passenger's (if installed) central door locking switch has been depressed to lock the doors. ! WARNING: o Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can be opened and you may be ejected from the vehicle and can be injured or killed. o If the door is locked/unlocked multiple times in rapid succession with either the vehicle key or door lock switch, the system may stop operating tem- porarily in order to protect the circuit and prevent damage to system com- ponents. B070F01CM-AAT Keyless Entry System (If installed) NOTE: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, in- cluding interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's au- thority to operate the equipment. Locking doors 1. Close all doors. 2. Push the "LOCK ( transmitter. )" button on the 3. At the same time all doors lock, the turn signal lights will blink once to indicate that the system is armed. Unlocking doors 1. Push the "UNLOCK ( the transmitter. )" button on 2. At the same time the driver's door un- locks, the turn signal lights will blink twice to indicate that the system is dis- armed. NOTE: If you wish to unlock all doors, press the "UNLOCK" button on the transmitter again within 4 seconds. NOTE: The transmitter will not work if any of following occur: - The ignition key is in ignition switch. - You exceed the operating distance limit (10 m). - The battery in the transmitter is weak. - Other vehicles or objects may be blocking the signal. - The weather is extremely cold. - The transmitter is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the transmitter. When the transmitter does not work correctly, open and close the door with the ignition key. If you have a problem with the transmitter, contact an autho- rized Hyundai Dealer. NOTE: Keep the transmitter away from water or any liquid. If the keyless entry system is inoperative due to exposure to water or liquids, it will not be covered by your manufacturer vehicle warranty. FEATURES OF YOUR HYUNDAI 11 THEFT-ALARM SYSTEM B070A01A-AAT (If installed) B075B01CM-AAT Armed Stage This system is designed to provide protec- tion from unauthorized entry into the car. This system is operated in three stages : the first is the "Armed" stage, the second is the "Alarm" stage and the third is the "Dis- armed" stage. If triggered, the system pro- vides an audible alarm with blinking of the turn signal lights. HMR Park the car and stop the engine. Arm the system as described below. 1) Remove the ignition key from the igni- tion switch. 2) Make sure that the hood and tail gate are closed and latched. 3) Lock the doors using the transmitter of the keyless entry system or key or cen- tral door lock switch. After completion of the steps above, the turn signal lights will blink once and the system will be armed after 30 seconds. The system can also be armed by locking the doors with the key; however, the turn signal lights are not operated. 1FEATURES OF YOUR HYUNDAI 12 If any door, tailgate or engine hood is opened within 30 seconds after entering the armed stage, the system is disarmed to prevent unnecessary alarm. NOTE: If any door, tailgate or engine hood re- mains open, the system will not be armed. If all doors, tailgate and engine hood are closed, after pressing the "Lock" button on the transmitter, the turn signal lights blink once indicating the system is armed. NOTE: If the "LOCK" button is pressed once more within 4 seconds after pushing the "LOCK" button on the transmitter, the siren will sound once to indicate that the system is armed. CAUTION: Do not arm the system until all passen- gers have left the car. If the system is armed while a passenger(s) remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car. B075C01CM-AAT Alarm Stage The alarm will be activated if any of the following occurs while the car is parked and the system is armed. 1) A front or rear door is opened without using the transmitter or the ignition key. 2) The tail gate is opened without using the transmitter. 3) The engine hood is opened. The siren will sound and the turn signal lights will blink continuously for about 30 seconds (This will repeat 3 times). To turn off the system, unlock the door or tail gate using the transmitter or the ignition key. CAUTION: Avoid trying to start the engine while the system is armed. B075D01CM-AAT Disarmed Stage If the follwing conditions are met, the sys- tem will be disarmed. o When the doors are unlocked with the transmitter or the ignition key. After depressing unlock button, you must open the doors within 30 seconds or all doors will automatically lock again and theft-alarm system will be armed. o When the ignition switch is in the "ON" position. The turn signal lights will blink twice when the door is unlocked with the transmitter. The alarm will be deactivated when: o The lock/unlock button on the transmit- o The doors are unlocked with the igni- ter is pressed. tion key. o The ignition switch is in the "ON" posi- tion for 30 seconds. NOTE: When the system is disarmed while the "DOOR" button of the interior light is depressed, the interior light will illumi- nate for 30 seconds. FEATURES OF YOUR HYUNDAI 13 Battery Case OCM052004 2. Remove the old battery from the case and note the polarity. Make sure the polarity of the new battery is the same (+side facing down), then insert it in the transmitter. B070E01CM-AAT Panic Warning PANIC B070E01CM-AAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pushes on the button to lock or unlock the doors, and the LED will not light. Replace the battery as soon as possible. Battery type : CR2032 Replacement instructions: OCM052002A 1. Push the "PANIC" button on the back- side of the transmitter. 2. At the same time, the alarming horn will sound and the turn signal lights will blink continuously for 30±3 seconds. 3. To turn off the system, push any button on the transmitter. Coin OCM052003 1. Carefully separate the case with a coin as shown in the illustration. 1. Driver's door power window switch 2. Front passenger's door power window switch 3. Rear passenger's door power window switch (left side) 4. Rear passenger's door power window switch (right side) 5. Window lock switch 1FEATURES OF YOUR HYUNDAI 14 WINDOWS B060D01NF-GAT OCM052011 POWER WINDOWS B060A01CM-AAT Open Close OCM051003L The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's armrest and control the front and rear win- dows on both sides of the vehicle. The windows may be opened by depressing the appropriate window switch and closed by pulling up the switch. To open the win- dow on the driver's side, press the switch halfway down. The window moves as long as the switch is operated. To fully open the driver's window automatically, press the switch fully down. In automatic operation, the window will fully open even if you let go of the switch. To stop at the desired open- ing, pull up and release the switch. OCM052013 In order to prevent operation of the pas- senger front and rear windows, a window lock switch is provided on the armrest of the driver's door. To disable the power windows, press the window lock switch. To revert to normal operation, press the win- dow lock switch a second time. NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK" posi- tions, or removed from the ignition switch. If the driver's door is opened during this 30 second period, the power windows can no longer be operated with- out the ignition key turned to the "ON" position. FEATURES OF YOUR HYUNDAI 15 Close Open OCM052012 WARNING: o Passengers can be injured in their head, hands or other body parts are trapped by a closing window. Always check for obstructions before raising any windows. o Never leave any child unattended in the vehicle. Even very your children may inadvertently cause the vehicle to move, entangle themselves in the window, otherwise injure themselves or others. o Do not attempt to operate the main switch on another door in opposing directions at the same time. If this is done, the window will stop and cannot be opened or closed. 1FEATURES OF YOUR HYUNDAI 16 SEATS B080A02A-AAT Adjustable Front Seats ! WARNING: o Never adjust the driver’s seat while the vehicle is moving. Any sudden or unexpected movement of the seat could cause you to lose control of the vehicle resulting in an accident. Only adjust the driver’s seat when the ve- hicle is stationary. o Do not sit or lean unnecessarily close to the air bag. Position the seat so that you can sit as far back as possible from the air bag and still comfortably reach all controls. B080B04A-AAT Front Seat Adjusting seat forward and rearward WARNING: After adjusting the seat, always check that it is securely locked into place by attempting to move the seat forward or rearward without using the lock release lever. Sudden or unexpected move- ment of the driver's seat could cause you to lose control of the vehicle result- ing in an accident. HNF2032 To move the seat toward the front or rear, pull the lock release lever upward. This will release the seat on its track so you can move it forward or rearward to the desired position. When you find the position you want, release the lever and slide the seat forward or rearward on its track until it locks into the desired position and cannot be moved further. B080C03A-AAT Adjusting Seatback Angle HNF2033 To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outside edge of the seat. Now lean back until the desired seatback angle is achieved. To lock the seatback into position, release the recliner control lever. ! WARNING: Riding with a reclined seatback in- creases your chance of serious or fatal injuries in the event of a collision or sudden stop. The protection of your re- straint system (seat belts and air bags) is greatly reduced by reclining your seat. Seat belts must be snug against your hips and chest to work properly. The more the seatback is reclined, the greater the chance that an occupant's hips will slide under the lap belt or the occupant's neck will strike the shoulder belt. Driv- ers and passengers should always sit well back in their seats, properly belted, and with the seatbacks upright. FEATURES OF YOUR HYUNDAI 17 B080D01CM-AAT Adjustable Headrests (2) (1) HJM2044 Headrests are designed to help reduce the risk of neck injuries. To raise the head- rest, pull it up. To lower the headrest, push it down while pressing the lock knob. To remove the headrest, raise it as far as it can go then press the release button while pulling upward. This should only be done when the seat is not occupied. To reinstall the headrest, put the headrest poles(1) into the holes while pressing the release button(2). Then adjust it to the appropriate height. ! WARNING: Make sure the headrest locks in position after adjusting it to properly protects the occupants. 1FEATURES OF YOUR HYUNDAI 18 WARNING: B080D01JM o For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the head- rest is at the same height of the center of gravity of an occupant's head. Gen- erally, the center of gravity of most people's head is similar with the height of the top of their eyes. Also, adjust the headrest as close to your head as possible. For this reason, the use of a cushion that holds the body away from the seatback is not recommended. ! WARNING: o Do not operate vehicle with the head- rests removed as injury to the occu- pants may occur in the event of an accident. Headrests may provide pro- tection against neck injuries when properly adjusted. o Do not adjust the headrest position of the driver's seat while the vehicle is in motion. B081D01CM-AAT Adjusting Headrest Forward and Rearward OMG035101 The headrest may be adjusted forward to three different positions by pulling the head- rest forward. To adjust the headrest rear- ward, pull it fully forward to the farthest position and release it. Adjust the headrest so that it properly supports the head and neck. B083D01NF-AAT Active Headrests (If Installed) B080E01Y-AAT Lumbar Support Control (Driver's Seat Only) (If Installed) B080F01NF-GAT Seat Height Adjustment (Driver's Seat Only) FEATURES OF YOUR HYUNDAI 19 HNF2041-1 The active headrest is designed to move forward and upward during a rear impact. This helps to prevent the driver's and front passenger's heads from moving backward and thus helps prevent neck injuries. HNF2039 To adjust the lumbar support, turn the handle on the outboard or left side of the seat. To increase the amount of lumbar support, pull the lever forward. To de- crease it, push the lever toward the rear. 1. Minimum support 2. Maximum support HNF2034 To raise or lower the seat, raise or lower the control lever to the desired seat height. 1FEATURES OF YOUR HYUNDAI 20 B090A02TG-AAT Front Power Seats The front seats can be adjusted appropri- ately by using the control knob on the seat. Before driving, adjust the seat to the proper position so as to easily control the steering wheel, pedals and switches on the instru- ment panel. B090B01CM-AAT Adjusting Seat Forward and Rearward B090D01CM-AAT Adjusting Seatback Angle CAUTION: Do not operate two knobs at the same time. WARNING: o Never adjust a driver’s seat while the vehicle is moving. Any sudden or unexpected movement of the seat could cause you to lose control of the vehicle resulting in an accident. Only adjust the driver’s seat when the ve- hicle is stationary. o Do not sit or lean unnecessarily close to the air bag. Position the seat so that you can sit as far back as possible from the air bag and still comfortably reach all controls. OCM052026 Push the control knob forward or back- ward to move the seat forward or backward to the desired position. Release the con- trol knob and the seat will remain at that position. OCM052027 Push the upper portion of the control knob forward or backward to recline the seatback to the desired position. Release the con- trol knob and the seatback will remain in that position. ! WARNING: Riding with a reclined seatback in- creases your chance of serious or fatal injuries in the event of a collision or sudden stop. The protection of your restraint system (seat belts and air bags) is greatly reduced by reclining your seat. Seat belts must be snug against your hips and chest to work properly. The more the seatback is re- clined, the greater the chance that an occupant's hips will slide under the lap belt or the occupant's neck will strike the shoulder belt. Drivers and passengers should always sit well back in their seats, properly belted, and with the seatbacks upright. FEATURES OF YOUR HYUNDAI 21 B090C01Y-AAT Seat Cushion Height Adjustment (Driver's seat only) B090E01TG-AAT Lumbar Support Control (Driver's seat only) (If Installed) HNF2038 Move the front portion of the control knob up or down to raise or lower the front part of the seat cushion. Move the rear portion of the control knob up or down to raise or lower the rear part of the seat cushion. OCM052024 To adjust the lumbar support, press the control switch on the outboard side of the seat cushion. To increase the amount of lumbar support, press the front portion of the switch. To decrease lumbar support, press the rear portion of the switch. 1FEATURES OF YOUR HYUNDAI 22 B100A01CM-AAT Seat Warmer (If installed) The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" position, push either of the switches to warm the driver's seat or the passenger's seat. During mild weather or under conditions where the operation of the seat warmer is not needed, keep the switches in the "OFF" position. Each time you push the button, the tem- perature setting of the seat is changed as follows : OFF → HIGH → LOW OCM052145-1 NOTE: o The seat warmer will not operate if the ambient temperature is warm. o If the seat warmer doesn't work when ambient temperature is lower than 70°F (21°C), it should be checked at an authorized dealer. B085A01JM-GAT Rear Seat Adjusting seatback angle ! WARNING: Do not turn on the seat warmers if the seat is occupied by someone who can- not monitor the temperature and turn off the seat warmer if it becomes too warm. The seat warmers should not be turned on when children, the elderly, ill people, and sleeping people occupy the seat. Seatback folding lever OCM052030 To recline the seatback, pull the seatback folding lever and release it after the de- sired seatback angle is achieved. When you recline the seatback to the de- sired position, always be sure it has locked into position. CAUTION: When reclining the seatback, you should adjust the seatback folding lever while you are standing. FEATURES OF YOUR HYUNDAI 23 3rd Row Seat (If Installed) 1. Move the 2nd row seatback to the for- 2. Lower the headrest to the lowest posi- ward position. tion. 3. To fold down the seatback, pull the seatback folding lever and then push down the seatback. B085B02CM-AAT Folding Rear Seatback 2nd row seat For convenience, the seatbacks and seat cushions may be folded down and up. OCM052031 NOTE: Before folding the seatback, place the rear seat belt buckles in the buckle pouch on the seat cushion. OCM052032 1. Lower the headrest to the lowest posi- tion. 2. Pull the seatback folding lever then push down the seatback. 3. Be sure it has locked into position by listening for an audible "Click". CAUTION: Be careful not to overload seatback. Overloading may cause damage to the seatback. 4. To return the seatback to its normal position, pull the seatback folding lever and reverse the above procedure. When you return the seatback to its upright position, always be sure it is locked into position by pulling and pushing on the top of the seatback. 4. To return the seatback to its normal position, reverse the above procedure. OCM052037 1FEATURES OF YOUR HYUNDAI 24 CAUTION: When return the seatback to upright position, you always lift and pull it by folding lever. In the case of a lift and a pull by grip the edge of seatback, it may cause damage to the seatback board. Double-folding the rear seat (2nd row) (if installed) To fold the rear seat forward to increase the cargo area: OCM052033 OCM052032 1. Lower the headrest to the lowest posi- tion. 2. Pull the seatback folding lever then push down the seatback. 3. Pull the seat cushion release lever and then fold up the seat cushion. OCM052034 FEATURES OF YOUR HYUNDAI 25 ! WARNING: o The purpose of the fold-down rear seat back is to allow you to carry more cargo objects than could otherwise be accommodated. Never allow pas- sengers to sit on the cargo area while the car is moving. This is not a proper seating position and no seat belts are available for use when the seat back is folded down. This could result in serious injury or death in case of an accident or a sudden stop. Objects should not extend higher than the top of the front seatbacks. This could allow cargo to slide for- ward and cause injury or damage during sudden stops. 2nd row seat 3rd row seat (If installed) WARNING: o Never allow passengers to sit on the 3rd row seat when the 2nd row seat is double-folded. This could result in se- rious injury or death in case of an accident or a sudden stop. o Do not allow passengers to fold up and down the seatback and seat cush- ion while the car is moving. OCM052036L CAUTION: When returning the rear seatbacks to the upright position, remember to return the rear shoulder belts to their proper position. Routing the safety belt webbing through the rear safety belt guides will help keep the belts from being trapped behind or under the seats. ! WARNING: o When you return the rear seatback to its upright position after being folded down, be careful not to damage the seatbelt webbing or buckle. Do not allow the seatbelt webbing or buckle to get caught or pinched in the rear seat. o When you return the rear seatback to its upright position, be sure it is locked into position by attempting to move it. o Never attempt to fold or return the seat to an upright position while the vehicle is moving. 1FEATURES OF YOUR HYUNDAI 26 B611A01Y-AAT Rear seat arm rest B085D02TG-AAT Adjustable Headrests ! WARNING: Lock knob OCM028035N This arm rest is located in the center of the rear seat back. B080D01TG-1 Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. To lower it, push it down while pressing the lock knob. To remove the headrest, raise it as far as it can go then press the lock knob while pulling upward. This should only be done when the seat is not occupied. B080D02TG-1 o For maximum effectiveness in case of an accident the headrest should be adjusted so the middle of the headrest is at the same height as the top of the occupant's eyes. For this reason, the use of a cushion that holds the body away from the seatback is not recom- mended. o Do not operate vehicle with the head- rests removed as injury to the occu- pants may occur in the event of an accident. Headrests may provide pro- tection against neck injuries when properly adjusted. ! B140A01B-AAT REAR SEAT WARNING OCM015004L For the safety of all passengers, luggage or other cargo should not be piled higher than the top of the seatback. SEAT BELTS B150A03S-AAT Seat Belt Precautions WARNING: All occupants of the vehicle must wear their seat belts at all times. Seat belts and child restraints reduce the risk of serious or fatal injuries for all occupants in the event of a collision or sudden stop. Without a seat belt, occupants could be shifted too close to a deploying air bag, strike the interior structure or be thrown from the vehicle. Properly worn seat belts greatly reduce these hazards. Even with advanced air bags, unbelted occu- pants can be severely injured by a de- ploying air bag. Always follow the pre- cautions about seat belts, air bags and occupant safety contained in this manual. FEATURES OF YOUR HYUNDAI 27 B150B04Y-AAT Infant or Small Child All 50 states have child restraint laws. You should be aware of the specific require- ments in your state. Child and/or infant safety seats must be properly placed and installed in the rear seat. Information about the use of these restraints begins on page 1-33. ! WARNING: Every person in your vehicle needs to be properly restrained at all times, includ- ing infants and children. Never hold a child in your arms or lap when riding in a vehicle. The violent forces created dur- ing a crash will tear the child from your arms and throw the child against the interior. Always use a child restraint appropriate for your child's height and weight. 1FEATURES OF YOUR HYUNDAI 28 NOTE: Small children are best protected from injury in an accident when properly re- strained in the rear seat by a child re- straint system that meets the require- ments of the Federal Motor Vehicle Safety Standards. Before buying any child restraint system, make sure that it has a label certifying that it meets Fed- eral Motor Vehicle Safety Standard 213. The restraint must be appropriate for your child's height and weight. Check the label on the child restraint for this information. See page 1-33. B150C02A-AAT Larger Children Children who are too large for child re- straint systems should always occupy the rear seat and use the available lap/shoul- der belts. The lap portion should be fas- tened snug on the hips and as low as possible. Check belt fit periodically. A child's squirming could put the belt out of position. Children are afforded the most safety in the event of an accident when they are restrained by a proper restraint system in the rear seat. If a larger child (over age 13) must be seated in the front seat, the child should be securely re- strained by the available lap/shoulder belt and the seat should be placed in the rearmost position. Children under the age of 13 should be restrained securely in the rear seat. NEVER place a child under the age of 13 in the front seat. NEVER place a rear facing child seat in the front seat of a vehicle. B150D01A-AAT Pregnant Women The use of a seat belt is recommended for pregnant women to lessen the chance of injury in an accident. When a seat belt is used, the lap belt portion should be placed as low and snugly as possible on the hips, not across the abdomen. For specific rec- ommendations, consult a physician. B150E01A-AAT Injured Person A seat belt should be used when an injured person is being transported. When this is necessary, you should consult a physician for recommendations. B150F01A-AAT One Person Per Belt Two people (including children) should never attempt to use a single seat belt. This could increase the severity of injuries in case of an accident. B150G02A-AAT Do Not Lie Down To reduce the chance of injuries in the event of an accident and to achieve maxi- mum effectiveness of the restraint system, all passengers should be sitting up and the front seats should be in an upright position when the car is moving. A seat belt cannot provide proper protection if the person is lying down in the rear seat or if the front seat is in a reclined position. WARNING: Riding with a reclined seatback in- creases your chance of serious or fatal injuries in the event of a collision or sudden stop. The protection of your restraint system (seat belts and air bags) is greatly reduced by reclining your seat. Seat belts must be snug against your hips and chest to work properly. The more the seatback is re- clined, the greater the chance that an occupant's hips will slide under the lap belt causing serious internal injuries or the occupant's neck could strike the shoulder belt. Drivers and passengers should always sit well back in their seats, properly belted (see page 1-31), and with the seatbacks upright. FEATURES OF YOUR HYUNDAI 29 B160A02A-AAT Care of Seat Belts Seat belt systems should never be disas- sembled or modified. In addition, care should be taken to assure that seat belts and belt hardware are not damaged by seat hinges, doors or other abuse. WARNING: When you return the rear seatback to its upright position after the rear seatback was folded down, be careful not to dam- age the seat belt webbing or buckle. Be sure that the webbing or buckle does not get caught or pinched in the rear seat. A seat belt with damaged webbing or buckle will not be as strong and could possibly fail during a collision or sudden stop, resulting in serious injury. 1FEATURES OF YOUR HYUNDAI 30 B160B01A-AAT Periodic Inspection It is recommended that all seat belts be inspected periodically for wear or damage of any kind. Parts of the system that are damaged should be replaced as soon as possible. B160C01A-AAT Keep Belts Clean and Dry Seat belts should be kept clean and dry. If belts become dirty, they can be cleaned by using a mild soap solution and warm wa- ter. Bleach, dye, strong detergents or abra- sives should not be used because they may damage and weaken the fabric. B160D01A-AAT When to Replace Seat Belts Entire in-use seat belt assembly or assem- blies should be replaced if the vehicle has been involved in an accident. This should be done even if no damage is visible. Additional questions concerning seat belt operation should be directed to your Hyundai Dealer. B170A06A-AAT Height Adjustable Front Seat Shoulder Belt To adjust the height of the seat belt anchor, lower or raise the height adjuster into an appropriate position. To raise the height adjuster, pull it up. To lower it, push it down while pressing the height adjuster button. Release the button to lock the anchor into position. Try sliding the height adjuster to make sure that it has locked into the posi- tion. WARNING: o Adjust the shoulder belt height when you sit well back in the seat. o When adjusting the shoulder belt height, grip the height adjuster button securely and slide the height adjuster up or down. OCM052307 You can adjust the height of the shoulder belt anchor to one of the 4 positions for maximum comfort and safety. If the height of the adjusting seat belt is too near your neck, you will not be getting the most effective protection. The shoulder portion should be adjusted so that it lies across your chest and midway over your shoulder nearest the door and not your neck. FEATURES OF YOUR HYUNDAI 31 If there is a sudden stop or impact, how- ever, the belt will lock into position. It will also lock if you try to lean forward too quickly. NOTE: o If you are not able to pull out the seat belt from the retractor, firmly pull the belt out and release it. Then you will be able to pull the belt out smoothly. o If the driver's seat belt is not fastened when the ignition key is in the "ON" position, the seat belt warning light will flash and the warning chime will sound for approximately six seconds. See page 1-66. ! WARNING: o Verify the shoulder belt anchor is locked into position at the appropriate height. Never position the shoulder belt across your neck or face. Im- properly positioned seat belts can cause serious injuries in an accident. o Failure to replace seat belts after an accident could leave you with dam- aged seat belts that will not provide protection in the event of another collision leading to personal injury or death. Replace your seat belts after being in an accident as soon as pos- sible. B180A01CM-AAT SEAT BELT-Driver's 3-Point System with Emergency Locking Retractor To fasten your belt B180A01NF To fasten your seat belt, pull it out of the retractor and insert the metal tab into the buckle. There will be an audible "click" when the tab locks into the buckle. The seat belt automatically adjusts to the proper length only after the lap belt portion is adjusted manually so that it fits snugly around your hips. If you lean forward in a slow, easy motion, the belt will extend and let you move around. 1FEATURES OF YOUR HYUNDAI 32 B190A01CM-AAT SEAT BELTS-Front Passenger and Rear Seat 3-Point System with Convertible Locking Retractor Convertible retractor type seat belts are installed in the rear seat positions to help accommodate the installation of child re- straint systems. Although a convertible re- tractor is also installed in the front passen- ger seat position, Hyundai strongly recom- mends that children always be seated in the rear seat. NEVER place any infant restraint system in the front seat of the vehicle. This type of seat belt combines the fea- tures of both an emergency locking retrac- tor seat belt and an automatic locking retractor seat belt. To fasten your seat belt, pull it out of the retractor and insert the metal tab into the buckle. There will be an audible "click" when the tab locks into the buckle. When not securing a child restraint, the seat belt operates in the same way as the driver's seat belt (Emergency Locking Retractor Type). It automatically adjusts to the proper length only after the lap belt portion of the seat belt is adjusted manu- ally so that it fits snugly around your hips. When the seat belt is fully extended from the retractor to allow the installation of a child restraint system, the seat belt opera- tion changes to allow the belt to retract, but not to extend (Automatic Locking Retrac- tor Type). See page 1-39. NOTE: Although the convertible retractor pro- vides the same level of protection for seated passengers in either emergency or automatic locking modes, it is recom- mended that seated passengers use the emergency locking feature for improved convenience. The automatic locking function is intended to facilitate child restraint installation. To convert from the automatic locking feature to the emergency locking operation mode, al- low the unbuckled seat belt to fully re- tract. ! WARNING: o For maximum restraint system pro- tection, the seat belts must always be used whenever the car is moving. o Children age 12 and younger must always be properly restrained in the rear seat. Never allow children to ride in the front passenger seat. If a child over 13 must be seated in the front seat, he/she must be properly belted and the seat should be moved as far back as possible. o Never wear the shoulder belt under your arm or behind your back. An improperly positioned shoulder belt can cause serious injuries in a crash. The shoulder belt should be positioned midway over your shoulder across your collarbone. o Avoid wearing twisted seat belts. A twisted belt can't do its job as well. In a collision, it could even cut into you. Be sure the belt webbing is straight and not twisted. o Be careful not to damage the belt webbing or hardware. If the belt web- bing or hardware is damaged, replace it. B200A01A-AAT Adjusting Your Seat Belt B210A01A-AAT To Release the Seat Belt B210A01NF The seat belt is released by pressing the release button in the locking buckle. When it is released, the belt should automatically draw back into the retractor. If this does not happen, check the belt to be sure it is not twisted, then try again. B200A01NF WARNING: You should place the lap belt portion as low as possible and snugly across your hips, not on your waist. If the lap belt is located too high on your waist, it may increase the chance of injury in the event of a collision. Both arms should not be under or over the belt. Rather, one should be over and the other under, as shown in the illustration. Never wear the seat belt under the arm nearest the door. FEATURES OF YOUR HYUNDAI CHILD RESTRAINT SYSTEM 33 B230A01CM-AAT Children riding in the car should sit in the rear seat and must always be properly restrained to minimize the risk of injury in an accident, sudden stop or sudden ma- neuver. According to accident statistics provided by the National Highway Traffic Safety Administration (NHTSA), children are safer when properly restrained in the rear seats than in the front seat. Larger children not in a child restraint should use one of the seat belts provided. All 50 states have child restraint laws. You should be aware of the specific require- ments in your state. Child and/or infant safety seats must be properly placed and installed in the rear seat. You must use a commercially available child restraint sys- tem that meets the requirements of the Federal Motor Vehicle Safety Standards (FMVSS). Child restraint systems are de- signed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/ shoulder belt, or by a LATCH system (if installed). Children could be injured or killed in a crash if their restraints are not properly secured. For small children and babies, a child seat or infant seat must be used. Before buying a particular child restraint system, make sure it fits your car seat and seat belts, and fits your child. Follow all the instructions provided by the manufacturer when installing the child restraint system. 1FEATURES OF YOUR HYUNDAI 34 ! WARNING: o A child restraint system must be placed in the rear seat. Never install a child or infant seat on the front passenger's seat. Should an accident occur and cause the passenger side air bag to deploy, it could severely injure or kill an infant or child seated in an infant or child seat. Thus only use a child restraint in the rear seat of your vehicle. o A safety belt or child restraint system can become very hot if it is left in a closed vehicle on a sunny day, even if the outside temperature does not feel hot. Be sure to check the seat cover and buckles before placing a child there. o When the child restraint system is not in use, store it in the luggage compart- ment or fasten it with a safety belt so that it will not be thrown forward in the case of a sudden stop or an accident. o Children may be seriously injured or killed by an inflating air bag. All chil- dren, even those too large for child restraints, must ride in the rear seat. ! WARNING: To reduce the chance or serious or fatal injuries: o Children of all ages are safer when restrained in the rear seat. A child riding in the front passenger seat can be forcefully struck by an inflating air bag resulting in serious or fatal inju- ries. o Always follow the instructions for in- stallation and use of the child restraint maker. o Always make sure the child seat is secured properly in the car and your child is securely restrained in the child seat. WARNING: o Never hold a child in your arms or lap when riding in a vehicle. The violent forces created during a crash will tear the child from your arms and throw the child against the car’s interior. o Never put a seat belt over yourself and a child. During a crash, the belt could press deep into the child caus- ing serious internal injuries. o Never leave children unattended in a vehicle – not even for a short time. The car can heat up very quickly, resulting in serious injuries to chil- dren inside. Even very young chil- dren may inadvertently cause the vehicle to move, entangle themselves in the windows, or lock themselves or others inside the vehicle. o Never allow two children, or any two persons, to use the same seat belt. o Children often squirm and reposition themselves improperly. Never let a child ride with the shoulder belt under their arm or behind their back. Al- ways properly position and secure children in rear seat.
