Handbook
On-line handbook
Select one of the following means of access to view your handbook on-line...
Referring to the handbook on-line also gives you access to the latest information available, easily identified by the bookmark, associated with this symbol:
Find your handbook on the CITROËN website, under "MyCITROËN".
This personal and customisable space allows you to establish direct and special contact with the manufacturer.
If the "MyCITRoËn" function is not available on the CITRoËn public website for your country, you can find your handbook at the following address: http://service.citroen.com/ddb/
Select:
the language, the vehicle, its body style, the print edition of your handbook appropriate for the date of registration of your vehicle.
Scan this code for direct access to your handbook.
This handbook has been designed to help to make the most of your C4 Picasso in all circumstances and in complete safety. Take the time to read through it so as to familiarise yourself with your vehicle.
This handbook covers all of the variations in equipment available across the whole C4 Picasso range. Your vehicle will be fitted with only some of the equipment described in this document, depending on its trim level, version and the specification for the country in which it was sold.
key
safety warning additional information
The descriptions and illustrations are given as indications only. Automobiles CITROËN reserves the right to modify the technical characteristics, equipment and accessories without having to update this edition of the guide.
This document forms an integral part of your vehicle. Remember to pass it on to the new owner in the event of the sale of the vehicle.
CITRoËn has a presence on every continent, a complete product range, bringing together technology and a permanent spirit of innovation, for a modern and creative approach to mobility. We thank you and congratulate you on your choice.
contributes to the protection of the environment
Key This key will enable you to identify the special features of your vehicle:
C4 Picasso
Grand C4 Picasso
Grand C4 Picasso with 5 seats
Grand C4 Picasso with 7 seats
at the wheel of your new vehicle, getting to know each system, each control, each setting, makes your trips, your journeys more comfortable and more enjoyable.
Happy motoring!
overview
access
Driving
Eco-driving
Monitoring
7-inch touch screen tablet Instrument panels Indicator and warning lamps Adjustment buttons Setting the date and time Trip computer
Electronic key - remote control "Keyless Entry and Starting" Central locking Doors Boot Motorised tailgate Alarm Electric windows
Comfort
11
20
25
44
47
48Front seats Rear seats Seat modularity Mirrors Steering wheel adjustment Ventilation Heating Dual-zone manual air conditioning Dual-zone automatic air conditioning Front demist - defrost Rear screen demist - defrost Scented air freshener Interior fittings Rear multimedia
Driving recommendations Starting-switching off the engine with the electronic key Starting-switching off the engine with the "Keyless Entry and Starting" system Electric parking brake Hill start assist 5-speed manual gearbox 6-speed manual gearbox Electronic gearbox (ETG6) Automatic gearbox Gear shift indicator Stop & Start Display of inter-vehicle time Memorising speeds Speed limiter Cruise control Active cruise control Collision risk alert Lane departure warning system blind spot sensors Parking sensors Reversing camera 360 Vision Park Assist
123
124
126
130
137
138
138
139
143
148
149
152
156
157
160
163
171174
175
178
180
181
18351
54
61
62
64
65
68
7173
80
87
89
91
92
94
95
97
102103
104
106
115Contents Visibility
Practical information
Technical data
Lighting controls Automatic illumination of headlamps Automatic headlamp dipping Daytime running lamps Headlamp adjustment Directional lighting Wiper controls Screenwash Automatic rain sensitive wipers Courtesy lamps Panoramic sunroof Interior mood lighting
191
196
197
199
200
202
203
205
206
208
209
210Safety
211
direction indicators 211
Hazard warning lamps 211
Horn 212
Emergency or assistance call 212
Warning triangle 213
Under-inflation detection 216
ESC system 220
Seat belts 225
Airbags 231
Child seats Deactivating the passenger's front airbag 233
242
ISOFIX mountings 250
Child lockTemporary puncture repair kit Changing a wheel Snow chains Changing a bulb Changing a fuse 12 V battery Energy economy mode Changing a wiper blade Towing the vehicle Towbar with quickly detachable towball Towing a trailer Roof bars Very cold climate screen accessories
Checks
bonnet Petrol engines Diesel engines Fuel Misfuel prevention (Diesel) Running out of fuel (Diesel) Checking levels Checks adblue® additive and SCR system (BlueHDi Diesel)
251
259
269
270
279
286
289
290
291293
295
297
299
300303
304
305
306
307
309
310
314316
Petrol engines Petrol weights Diesel engines Diesel weights Dimensions Identification markings
323
325
327
330
333
335Audio and telematics
Emergency or assistance 7-inch touch screen tablet
336
339Alphabetical index
Contents Exterior
Electronic key / "Keyless Entry and
51-60
Starting" system
- opening / closing - anti-theft protection - back-up control - battery
Boot - opening / closing - emergency release Motorised tailgate
rear lamps
Changing bulbs - - 3rd brake lamp - number plate lamps -
foglamps
Panoramic sunroof Roof bars accessories
209
297-298
300-30164-67
65-67
274-278
Parking sensors Reversing camera 360 Vision Park Assist Towbar Towing (advice) Towbar with quickly detachable
178-179
180
181-182
183-190
295-296
291-292tow ball
293-294
ESC: ABS, EBA, ASR, DSC 216-219
Tyre under-inflation detection 213-215
Tyre pressures 335
Temporary puncture repair kit 251-258
Changing a wheel 259-268
- Snow chainstools spare wheel removing / refitting
269
Wipers, screenwash Changing a wiper blade
203-207
290199
Exterior welcome lighting 199
Door mirror spotlamps Cornering lighting 201
Directional lighting 202
Manual headlamp height adjustment 200
Changing bulbs 270-274
- front lamps - foglamps - direction indicator repeaters Very cold climate screen299
Door mirrors
Doors - opening / closing - emergency control Central locking Alarm Electric windows
89-90
62-63
61
68-70
71-72Fuel tank, misfuel
prevention
306-308
Overview Interior
3rd row rear seats Seat modularity /
configurations
rings, hooks storage box
C4 Picasso boot fittings - - - boot lamp Grand C4 Picasso boot fittings - - boot lamp concertina boards Luggage cover roller Warning triangle adblue® additive
rings
Interior fittings Side blinds Rear multimedia
113-114
114
115-116Seat belts
220-224
Front fittings Mats
106-112
11185-86
87-88
117
119
120-121
212
316-3222nd row rear seats Child seats ISOFIX child seats Child lock
80-83
231-241, 249
242-249
250Front seats - manual - electric
73-79
Airbags Deactivating the passenger's
225-230
front airbag
226, 232-233
.Overview Instruments and controls
Courtesy lamps Rear view mirror Panoramic sunroof Emergency or assistance call
208
90
209
336Instrument panels Lighting dimmer Warning lamps Indicators service indicator - oil level indicator
20-24
45
25-39
40-43Touch screen tablet (satellite navigation, multimedia
audio system, Bluetooth telephone)
11-19, 339-401
13-17
Equipment settings 47
Setting the date/time 92-93
Ventilation Heating 94
Dual-zone manual air conditioning 95-96
Dual-zone automatic airconditioning
Demisting / defrosting
97-102
102-103Electric parking brake
130-136
Automatic gearbox Electronic gearbox Gear shift indicator
143-147
139-142
148Door mirrors Electric windows, deactivating
89-90
71-72Opening the bonnet
303
Dashboard fuses
279-283
5/6-speed manual gearbox Gear shift indicator
138
148Overview Instruments and controls (cont.)
Lighting controls direction indicators
191-199
211Manual headlamp beam height
adjustment
200
Memorising speeds Speed limiter Cruise control Active cruise control
156
157-159
160-162
163-170Black panel Modes Courtesy lamp
46
24
208Wiper and screenwash
controls
Trip computer
203-207
48-50Hazard warning lamps
211
START/STOP button
124-129
Steering wheel adjustment Horn
91
211Steering mounted controls
342, 343
.Overview Maintenance - Technical data
Running out of fuel, Diesel
309
12V battery Load reduction, economy mode Engine compartment
286-288
289279-280, 284-285
fuses
Petrol weights Diesel weights
325-326
330-332310-313
coolant screenwash/headlamp wash fluid
Checking levels - oil - brake fluid - Checking components - air filter - passenger compartment filter - oil filter - electric parking brake - brake pads / discs
314-315
Changing bulbs
front rear
270-278
Opening the bonnet Under the bonnet, petrol Under the bonnet, diesel Petrol engines Diesel engines adblue® additive
303
304
305
323-324
327-329
316-322Identification markings Dimensions
335
333-334Overview Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
Optimise the use of your gearbox
With a manual gearbox, move off gently and change up without waiting. During acceleration change up early.
With an automatic or electronic gearbox, give preference to automatic mode and avoid pressing the accelerator pedal heavily or suddenly.
The gear shift indicator invites you engage the most suitable gear: as soon as the indication is displayed in the instrument panel, follow it straight away. For vehicles fitted with an electronic or automatic gearbox, this indicator appears only in manual mode. Drive smoothly Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. These practices contribute towards a reduction in fuel consumption and Co2 emissions and also helps reduce the background traffic noise.
If your vehicle has cruise control, make use of the system at speeds above 25 mph (40 km/h) when the traffic is flowing well.
Control the use of your electrical equipment Before moving off, if the passenger compartment is too warm, ventilate it by opening the windows and air vents before using the air conditioning. Above 30 mph (50 km/h), close the windows and leave the air vents open. Remember to make use of equipment that can help keep the temperature in the passenger compartment down (sunroof and window blinds...). Switch off the air conditioning, unless it has automatic regulation, as soon as the desired temperature is attained. Switch off the demisting and defrosting controls, if not automatic. Switch off the heated seat as soon as possible.
Switch off the headlamps and front foglamps when the level of light does not require their use.
Avoid running the engine before moving off, particularly in winter; your vehicle will warm up much faster while driving.
As a passenger, if you avoid connecting your multimedia devices (film, music, video game...), you will contribute towards limiting the consumption of electrical energy, and so of fuel. Disconnect your portable devices before leaving the vehicle.
.Eco-driving Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the bottom of the boot, as close as possible to the rear seats. Limit the loads carried in the vehicle and reduce wind resistance (roof bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference. Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations on maintenance Check the tyre pressures regularly, when cold, referring to the label in the door aperture, driver's side. Carry out this check in particular: - - - Don't forget the spare wheel and the tyres on any trailer or caravan.
before a long journey, at each change of season, after a long period out of use.
Have your vehicle serviced regularly (engine oil, oil filter, air filter, passenger compartment filter...) and observe the schedule of operations recommended in the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system is faulty your vehicle becomes polluting; go to a CITROËN dealer or a qualified workshop without delay to have the emissions of nitrous oxides brought back to the legal level. When refuelling, do not continue after the third cut-off of the nozzle to avoid any overflow.
At the wheel of your new vehicle, it is only after the first 1 800 miles (3 000 kilometres) that you will see the fuel consumption settle down to a consistent average.
10
Eco-driving General operation Recommendations It is necessary to press firmly, particularly for "flick" gestures (scrolling through lists, moving the map...). A light wipe is not enough. The tablet does not recognise pressing with more than one finger. This technology allows use at all temperatures and when wearing gloves. Do not use pointed objects on the touch screen tablet. Do not touch the tablet screen with wet hands. Uses a soft clean cloth to clean the tablet touch screen.
7-inch touch screen tablet
The 7-inch touch screen tablet gives access to: - - menus for adjusting settings for vehicle
the heating/air conditioning controls,
- -
functions and systems, audio and display configuration menus, audio system and telephone controls and the display of associated information,
and, depending on equipment, allows: -
the display of alert messages and the visual parking sensors information, the permanent display of the time and the ambient temperature (a blue warning lamp appears when there is a risk of ice), access to the controls for the navigation system and Internet services, and the display of associated information.
-
-
For reasons of safety, the driver should only carry out operations that require close attention, with the vehicle stationary. Some functions are not accessible when driving.
Principles Use the buttons on either side of the screen for access to the menus, then press the virtual buttons in the touch screen. Each menu is displayed over one or two pages (primary page and secondary page).
Use this button to go to the secondary page.
Use this button to return to the primary page.
After a few moments with no action on the secondary page, the primary page is displayed automatically.
Use this button for access to additional information and to the settings for certain systems.
Use this button to confirm.
Use this button to quit.
11
1Monitoring Touch screen tablet menus
1. access the the "Air conditioning" menu. Allows adjustment of the various settings for temperature, air flow... See the sections on "Heating", "Manual air conditioning" and "Automatic air conditioning".
2. access to the "Driving assistance" menu.
allows certain functions to be switched on and off and their settings adjusted.
See the Audio and telematics section.
3. access to the "Media" menu. 4. access to the "Navigation"* menu.
See the Audio and telematics section.
5. access to the "Configuration" menu.
Allows configuration of the display and the system.
See the Audio and telematics section.
6. access to the "Connected services*" menu. 7. access to the "Telephone" menu. 8. Volume / mute.
See the "Audio and telematics" section.
See the Audio and telematics section.
12
* Depending on equipment.
Monitoring "Driving assistance" menu
State of adjustable systems Some systems have a dedicated button, to which is associated an indicator lamp. Illumination of this lamp indicates whether the system is activated or deactivated compared to the default (factory) setting. Green indicator: you have switched on the corresponding system. Orange indicator: you have switched off the corresponding system.
Operating fault In the event of a fault with one of these systems, the indicator lamp in the activation/ deactivation button flashes for a few moments. An alert symbol is displayed to the right of the button symbol, then, in the case of systems that are activated by default, the orange indicator comes on permanently. Every time the button is pressed, the indicator flashes for a few moments.
Example:
● Function not activated.
● Operating fault alert.
then
13
1Monitoring The functions accessible in this menu are detailed in the tables below.
Button
Corresponding function Speed settings
Comments Memorisation of speeds for use with the speed limiter or cruise control.
Under-inflation initialisation
Reinitialisation of the under-inflation system.
Diagnostic
List of current alerts.
14
Monitoring Button
Corresponding function
Comments
Vehicle settings
Access to other functions with settings that can be adjusted. The functions are grouped together under three tabs: "Driving assistance" ● "Automatic rear wiper in reverse": activation of rear wiper linked to reverse gear. ● "Auto mirror dipping in reverse": automatic dipping of door mirrors in reverse.
See the "Visibility" section.
See the "Comfort" section.
See the "Visibility" section.
"Lighting" ● "Guide-me-home lighting": utomatic guide-me-home lighting. ● "Welcome lighting": exterior welcome lighting. ● "Adaptive lighting": cornering lighting / directional lighting. ● "Mood lighting": mood lighting.
See the "Visibility" section.
See the "Visibility" section.
See the "Visibility" section.
"Vehicle access" ● "Tailgate motorisation": automatic operation of the tailgate. ● "Driver plip action": selective unlocking of the driver's door.
See the "Access" section.
See the "Access" section.
15
1Monitoring Button
Corresponding function Lane departure warning
Comments Activation/Deactivation of the function.
Parking sensors
Activation/Deactivation of the function.
Automatic headlamps
Activation/Deactivation of the function.
Park Assist
Activation/Deactivation of the function.
Stop & Start
Activation/Deactivation of the function.
Blind spot monitoring
Activation/Deactivation of the function.
360 vision
Activation/Deactivation of the function then choice of options.
Active cruise control
Choice of the standard cruise control or the active cruise control.
16
Monitoring The state of a function, a few examples:
Button
Function
Activated
Deactivated
Park Assist
Blind spot monitoring
Stop & Start
Parking sensors
17
1Monitoring "Configuration" menu The functions available through this menu are detailed in the table below.
Button
Corresponding function Audio settings
Comments Adjustment of volume, balance...
Colour schemes
Choice of a colour scheme.
Interactive help
Simplified instructions.
Turn off screen
Turns the screen off.
Brightness
Adjustment of brightness.
18
Monitoring Button
Corresponding function System settings
Time/Date
Languages
Comments Choice of units: - -
temperature (°Celsius or °Fahrenheit) distance and fuel consumption (l/100 km, mpg or km/l).
Setting the date and time.
Choice of language used for the touch screen tablet and the type 2 instrument panel: French, English, Italian, Spanish, German, Dutch, Portuguese, Polish, Turkish, Russian. Choice of language used for the touch screen tablet only: Serb, Croat, Hungarian.
Screen settings
Adjustment of the display settings (scrolling of text, animations...)
Calculator
Calendar
Displays the calculator.
Displays the calendar.
19
1Monitoring Type 1 instrument panel
Dials and screens 1. Rev counter (x 1 000 rpm or tr/min),
graduation according to engine (petrol or Diesel).
2. Gear shift indicator, selector position
and gear for an electronic or automatic gearbox.
3. Digital speedometer (mph or km/h). 4. Cruise control or speed limiter settings.
5. Fuel gauge. 6. Service indicator, then total mileage
recorder (miles or km). These functions are displayed in turn when the ignition is switched on.
7. Trip mileage recorder (miles or km). 8. Repeat of air conditioning settings.
Control buttons A. Main lighting dimmer buttons. B. Recall servicing information.
Reset the function selected to zero (service indicator or trip recorder).
20
Monitoring Type 2 instrument panel
This instrument panel is presented in the form of a 12-inch panoramic HD screen. It can be personalised. Depending on the display mode selected, some information can be hidden. See the "Personalisation of the instrument panel" section.
Dials and screens 1. Rev counter (x 1000 tr/min or rpm)
("DIALS" mode).
2. Gear shift indicator, position of the selector
lever and the gear with an electronic or automatic gearbox.
3. Digital speedometer (mph or km/h). 4. Cruise control or speed limiter setting. 5. Fuel gauge.
6. Total distance recorder (miles or km). 7. Trip distance recorder (miles or km). 8. Repeat of the air conditioning settings. 9. Repeat of the current media or telephone
information.
10. Repeat of the navigation information. 11. Ambient temperature (a blue warning lamp
comes on if there is a risk of ice).
Control button A. Recall servicing information.
Recall the remaining driving range with the SCR system and the AdBlue® additive. Reset the function selected to zero (service indicator or trip recorder).
21
1Monitoring Display zones
Personalisation of the type 2 instrument panel You can modify the appearance of the instrument panel, by choosing: - -
a colour scheme, a display mode.
Choice of display mode Each mode corresponds to the type of information displayed in the configurable area.
Choosing the language This depends on the setting in the touch screen tablet. Certain languages are not available for the type 2 instrument panel; English is selected by default. Choosing a colour scheme It depends on the colour scheme chosen for the touch screen tablet. To modify it with the vehicle stationary: F select the "Configuration" menu of the
touch screen tablet,
F press the "Color schemes" button, F choose a colour scheme, F confirm.
The system restarts to take account of the modifications to the touch screen tablet and the instrument panel.
Whatever the display mode or colour scheme chosen, the instrument panel contains -
a fixed display zone A with: ● the speedometer, ● the warning lamps, ● the fuel gauge, ● the various repeated information and
alert messages.
a configurable display zone B.
-
Most of the warning lamps do not have a fixed position. The warning and indicator lamps in the left hand column are displayed from top to bottom in order of importance. For certain functions that have indicator lamps for both on and off, there is just one dedicated location.
22
-
"DIALS": permanent display of the trip computer, rev counter and coolant temperature indicator.
Monitoring -
"MEDIA": display of information related to the media being played or the radio.
-
"NAVIGATION": display of information related to the navigation in progress (map and instructions).
-
"PHOTOS": display of the photo selected in the "Media" menu of the touch screen tablet.
23
1Monitoring -
"DRIVING": used for the display of the inter-vehicle time and information related to the active cruise control. The recommended speed is displayed in the central part. The driver remains responsible for observing the driving regulations.
To modify the display mode of the instrument panel: F
turn the wheel on the left of the steering wheel to display and run through the different modes in the right hand part of the instrument panel,
F once the selected display mode appears in the central window, it is applied after a few moments.
24
Monitoring Associated warnings The switching on of certain warning lamps may be accompanied by an audible signal and a message. The warning lamps may come on continuously (fixed) or flash.
Indicator and warning lamps Visual indicators informing the driver of the status of a system (operation or deactivation indicator lamp) or the existence of a fault (warning lamp).
When the ignition is switched on Certain warning lamps come on for a few seconds in the instrument panel when the vehicle's ignition is switched on. When the engine is started, these same warning lamps should go off. If they remain on, before moving off, refer to the information on the warning lamp concerned.
Certain warning lamps may come on in one of two modes: fixed (continuous) or flashing. Only by relating the type of illumination to the operation of the vehicle can it be determined whether the situation is normal or a fault has occurred. In the event of a fault, the illumination of the warning lamp may be accompanied by a message. Refer to the tables on the following pages for more information.
The position of the warning lamps in the type 2 instrument panel depends on the colour scheme selected.
25
1Monitoring Operation indicator lamps If one of the following indicator lamps comes on in the instrument panel, this confirms that the corresponding system has come into operation.
Warning / indicator lamp State
Cause
Action / Observations
Left-hand direction indicator
Right-hand direction indicator
Sidelamps
Dipped beam headlamps
Main beam headlamps
flashing with buzzer.
The lighting stalk is pushed down.
flashing with buzzer.
The lighting stalk is pushed up.
fixed.
fixed.
fixed.
The lighting stalk is in the "Sidelamps" position.
The lighting stalk is in the "Dipped beam headlamps" position.
The lighting stalk is pulled towards you.
Pull the stalk to return to dipped beam headlamps.
26
Monitoring Warning / indicator lamp State
Cause
Action / Observations
The camera, located in the door mirror, manages the operation of main beam, depending on the ambient lighting and driving conditions. Pulling the lighting stalk again to deactivate. For more information on this function, refer to the Visibility section.
Automatic headlamp dipping
fixed.
fixed.
The lighting control stalk is in the "aUTo" position, pulled towards you, and the function is activated ("Driving assistance" menu). The system is in dipped beam mode as there is sufficient ambient light and/or the traffic conditions do not allow illumination of main beam.
The lighting control stalk is in the "aUTo" position, pulled towards you, and the function is activated ("Driving assistance" menu). The system is in main beam mode as the ambient lighting and traffic conditions allow it.
Front foglamps
fixed.
The front foglamps are switched on using the ring on the lighting control stalk.
Turn the ring on the lighting control stalk rearward twice to switch off the front foglamps.
Rear foglamps
fixed.
The rear foglamps are on.
Turn the ring on the stalk rearward to switch off the rear foglamps.
For more information on the lighting controls, refer to the corresponding section.
27
1Monitoring Warning / indicator lamp State
Cause
Action / Observations
Diesel engine pre-heating
fixed.
The "START/STOP" switch has been pressed (ignition on).
Electric parking brake
fixed.
The electric parking brake is applied.
Wait until the indicator lamp goes off before starting. Once it goes off, starting is immediate, on condition that you maintain pressure on the brake pedal for an electronic or automatic gearbox, or the clutch pedal is pressed fully down for a manual gearbox. The period of illumination of the indicator lamp is determined by the ambient conditions (up to about thirty seconds in extreme conditions). If the engine does not start, switch the ignition off and then on, wait until the indicator lamp goes off again, then start the engine.
Release the electric parking brake to switch off the warning lamp: with your foot on the brake pedal, briefly push the electric parking brake control lever. Observe the safety recommendations. For more information on the electric parking brake, refer to the corresponding section.
Blind spot sensors
fixed.
Park Assist
fixed.
The blind spot monitoring function has been activated.
For more information, refer to the corresponding section.
The Park Assist function has been activated.
For more information, refer to the corresponding section.
28
Monitoring Warning / indicator lamp State
Cause
Action / Observations
Automatic wiping
fixed.
The wiper control is pushed downwards.
Automatic front wiping is activated. To deactivate automatic wiping, operate the control stalk downwards or put the stalk into another position.
Passenger airbag system
fixed.
The control switch, located at the passenger's end of the dashboard, is in the "ON" position. The passenger's front airbag is activated. In this case, do not install a rearward facing child seat on the front passenger seat.
Turn the control switch to the "OFF" position to deactivate the front passenger's airbag. In this case you can install a rearward facing child seat.
Stop & Start
fixed.
When the vehicle stops (red lights, traffic jams, ...) the Stop & Start system has put the engine into STOP mode.
The warning lamp goes off and the engine restarts automatically in START mode, as soon as you want to move off.
flashes for a few seconds, then goes off.
STOP mode is temporarily unavailable. or START mode is invoked automatically.
For more information on special cases with STOP mode and START mode, refer to the "Stop & Start" section.
29
1Monitoring Deactivation indicator lamps If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally. This is may be accompanied by an audible signal and the display of a message.
Warning / indicator lamp State
Cause
Action / Observations
Passenger's airbag system
fixed.
Dynamic stability control (DSC/ASR)
fixed.
The control switch, located at the right hand end of the dashboard is set to the OFF position. The passenger's front airbag is deactivated.
Set the control to the "ON" position to activate the passenger's front airbag. In this case, do not fit a child seat in the rearward- facing position.
The button, located on the centre console, is pressed. Its indicator lamp is on. The DSC/ASR is deactivated. DSC: dynamic stability control. ASR: anti-slip regulation.
Press the button to activate the DSC/ASR. Its indicator lamp goes off. The DSC/ASR system is activated automatically when the vehicle is started. If deactivated, the system is reactivated automatically from around 30 mph (50 km/h).
Stop & Start
fixed.
The Stop & Start has been deactivated.
Reactivate the function via the "Driving assistance" menu.
30
Monitoring Warning lamps When the engine is running or the vehicle is being driven, illumination of one of the following warning lamps indicates a fault which requires action on the part of the driver. Any fault resulting in the illumination of a warning lamp must be investigated further using the associated message. If you encounter any problems, contact a CITROËN dealer or a qualified workshop.
Warning / indicator lamp State
Cause
Action / Observations
STOP
fixed, associated with another warning lamp, accompanied by an audible signal and a message.
Illumination of this warning lamp is related to a serious fault detected with the braking or power steering systems, the electrical system, or with engine lubrication or cooling or a puncture.
Stop as soon as it is safe to do so as the engine may cut out. Park, switch off the ignition and call a CITROËN dealer or a qualified workshop.
31
1Monitoring Warning / indicator lamp State
Cause
Action / Observations
Service
temporarily, accompanied by a message.
One or more minor faults for which there is no specific warning lamp have been detected.
Identify the cause of the fault using the message displayed in the screen. You can deal with some problems yourself, such as a door open or the start of saturation of the particle filter (as soon as the traffic conditions allow, regenerate the filter by driving at a speed of at least 40 mph (60 km/h), until the warning lamp goes off). For any other problems, such as a fault with the tyre under inflation detection system, contact a CITROËN dealer or a qualified workshop.
fixed, accompanied by a message.
One or more major faults for which there is no specific warning lamp have been detected.
Identify the cause of the fault using the message displayed in the screen; you must then contact a CITROËN dealer or a qualified workshop.
The servicing interval has been exceeded.
Only on BlueHDi Diesel versions. Your vehicle must be serviced as soon as possible.
fixed, associated with the flashing and then fixed display of the service indicator spanner.
32
Monitoring Warning / indicator lamp State
Cause
Action / Observations
Electric parking brake
flashing.
When driving: the electric parking brake is not fully released.
Fully release the parking brake by a quick press on the control lever. If the warning persist, stop as soon as it is safe to do so. Contact a CITROËN dealer or a qualified workshop.
Electric parking brake fault
fixed.
fixed.
Deactivation of the automatic functions of the electric parking brake
When stationary: parking brake applied, the system does guarantee immobilisation of the vehicle (when parking on a very steep slope, for example).
Secure the immobilisation of the vehicle by engaging a gear with a manual or electronic gearbox, by placing the gear selector in position P with an automatic gearbox, or by fitting a chock to one of the wheels.
The electric parking brake has a fault. Contact a CITROËN dealer or a qualified workshop
without delay. The parking brake can be released manually. For more information on the electric parking brake, refer to the corresponding section.
The "automatic application" (on switching off the engine) and "automatic release" functions are deactivated or faulty. In the event of a fault, illumination of this warning lamp is accompanied by a message.
To reactivate the automatic functions, refer to the "Electric parking brake" section. Contact a CITROËN dealer or a qualified workshop if automatic application / release is not possible. The parking brake can be released manually. For more information on the electric parking brake, refer to the corresponding section.
33
1Monitoring Warning / indicator lamp State
Cause
Action / Observations
Braking
fixed.
The brake fluid level has dropped significantly.
You must stop as soon as it is safe to do so. Top up with brake fluid listed by CITROËN. If the problem persists, have the system checked by a CITROËN dealer or a qualified workshop.
fixed, associated with the ABS warning lamp.
The electronic brake force distribution (EBFD) system has a fault.
You must stop as soon as it is safe to do so. Have it checked by a CITROËN dealer or a qualified workshop.
Anti-lock Braking System (ABS)
fixed.
Electronic stability programme (DSC/ASR)
Engine autodiagnosis system
flashing.
fixed.
flashing.
fixed.
The anti-lock braking system has a fault.
The vehicle retains conventional braking. drive carefully at reduced speed and contact a CITROËN dealer or a qualified workshop without delay.
The DSC/ASR regulation is operating.
The system optimises traction and improves the directional stability of the vehicle.
Unless it has been deactivated (button pressed and its indicator lamp on) the DSC/ASR system has a fault.
The engine management system has a fault.
Have it checked by a CITROËN or a qualified workshop.
Risk of destruction of the catalytic converter. Have it checked by a CITROËN dealer or a qualified workshop.
The emission control system has a fault.
The warning lamp should go off when the engine is started. If it does not go off, contact a CITROËN dealer or qualified workshop without delay.
34
Monitoring Warning / indicator lamp State
Cause
Action / Observations
Low fuel level
fixed, accompanied by an audible signal and a message.
When it first comes on there remains approximately 6 litres of fuel in the tank. You are then using the fuel reserve.
You must refuel as soon as possible to avoid running out of fuel. Until sufficient fuel is added, this warning lamp will come on every time the ignition is switched on, accompanied by an audible signal and a message. This audible signal and message are repeated with increasing frequency as the drops towards "0". Fuel tank capacity: approximately 57 litres (petrol) or 55 litres (Diesel). never continue to drive until you run out of fuel as this could damage the emission control and injection systems.
Seat belt(s) not fastened / unfastened
fixed or flashing accompanied by an audible signal.
Airbags
on temporarily.
a seat belt has not been fastened or has been unfastened.
Pull the strap then insert the tongue in the buckle.
This lamp comes on for a few seconds when you turn on the ignition, then goes off.
This lamp should go off when the engine is started. If it does not go off, contact a CITROËN dealer or a qualified workshop.
fixed.
One of the airbag or seat belt pretensioner systems has a fault.
Have it checked by a CITROËN dealer or a qualified workshop.
Passenger airbag system
flashing.
The passenger airbag system has a fault.
Do not have a passenger seated in the front passenger seat. Have it checked by a CITROËN dealer or a qualified workshop.
35
1Monitoring Warning / indicator lamp State
Cause
Action / Observations
Directional headlamps
Door(s) open*
flashing.
The directional headlamps system has a fault.
Have it checked by a CITROËN dealer or a qualified workshop.
A door or the boot is still open.
Close the door or boot.
fixed, associated with a message identifying the door, if the speed is below 6 mph (10 km/h).
fixed, associated with a message identifying the door, and accompanied by an audible signal if the speed is above 6 mph (10 km/h).
Battery charge
fixed.
The battery charging circuit has a fault (dirty or loose terminals, slack or cut alternator belt, ...).
The warning lamp should go off when the engine is started. If it does not go off, contact a CITROËN dealer or a qualified workshop.
Maximum coolant temperature
fixed.
The temperature of the cooling system is too high.
Engine oil pressure
fixed.
There is a fault with the engine lubrication system.
Stop as soon as it is safe to do so. Wait until the engine has cooled down before topping up the level, if necessary. If the problem persists, contact a CITROËN dealer or qualified workshop.
You must stop as soon it is safe to do so. Park, switch off the ignition and contact a CITROËN dealer or a qualified workshop.
* Only with the type 1 instrument panel.
36
Monitoring Warning / indicator lamp State
Cause
Action / Observations
Under-inflation
fixed, accompanied by an audible signal and a message.
The pressure in one or more tyres is too low.
Check the tyre pressures as soon as possible. This check should preferably be carried out when the tyres are cold. You must reinitialise the system after the adjustment of one or more tyre pressures and after changing one or more wheels. For more information, refer to the "Under-inflation detection" section.
flashing then fixed, accompanied by the Service warning lamp.
The system has fault: the tyre pressures are no longer monitored.
Check the tyre pressures as soon as possible. Have the system checked by a CITROËN dealer or a qualified workshop.
Foot on the brake pedal*
fixed.
The brake pedal is not pressed.
flashing.
Foot on the clutch*
fixed.
* Only with the type 1 instrument panel.
With an electronic gearbox, if you hold the vehicle on an incline using the accelerator for too long, the clutch overheats.
In the STOP mode of Stop & Start, changing to START mode is refused because the clutch pedal is not fully down.
With an electronic gearbox, press the brake pedal to start the engine (lever in position N). If you wish to release the parking brake without pressing the brake pedal, this warning lamp will remain on. With an automatic gearbox, press the brake pedal to move the gear selector out of position P.
Use the brake pedal and/or the parking brake.
You must declutch fully to allow the change to engine START mode.
37
1Monitoring Warning / indicator lamp State
Cause
Action / Observations
AdBlue® additive (BlueHDi Diesel)
fixed, on switching on the ignition, accompanied by an audible signal and a message indicating the remaining driving range.
flashing associated with the SERVICE warning lamp, accompanied by an audible signal and a message indicating the remaining driving range.
flashing, associated with the SERVICE warning lamp, accompanied by an audible signal and a message indicating that starting is prevented.
The remaining driving range is between 350 miles (600 km) and 1500 miles (2400 km).
Have the adblue® additive tank topped up as soon as possible: go to a CITROËN dealer or a qualified workshop, or carry out this operation yourself by referring to the corresponding section.
The remaining driving range is between 0 and 350 miles (600 km).
You must top-up the adblue® additive tank to avoid a breakdown: go to a CITROËN dealer or a qualified workshop, or carry out this operation yourself by referring to the corresponding section.
The adblue® tank is empty: the starting inhibition system required by legislation prevents starting of the engine.
To be able to start the engine, you must top-up the adblue® additive tank: go to a CITROËN dealer or a qualified workshop, or carry out this operation yourself by referring to the corresponding section. It is essential to add at least 3.8 litres of AdBlue® to the additive tank.
38
Monitoring Warning / indicator lamp State
Cause
SCR emissions control system (BlueHDi Diesel)
fixed, on switching on the ignition, associated with the SERVICE and engine diagnostic warning lamps, accompanied by an audible signal and a message.
flashing, on switching on the ignition, associated with the SERVICE and engine diagnostic warning lamps, accompanied by an audible signal and a message indicating the remaining driving range.
flashing, on switching on the ignition, associated with the SERVICE and engine diagnostic warning lamps, accompanied by an audible signal and a message.
A fault with the SCR emissions control system has been detected.
After confirmation of the fault with the emissions control system, you can drive for up to 650 miles (1 100 km) before the engine starting inhibition system is triggered.
You have exceeded the authorised driving limit following confirmation of a fault with the emissions control system: the engine starting inhibition system prevents starting of the engine.
Action / Observations
This alert disappears once the exhaust emissions return to normal levels.
Contact a CITRoËn dealer or a qualified workshop without delay, to avoid a breakdown.
To be able to start the engine, you must call on a CITRoËn dealer or a qualified workshop.
39
1Monitoring Service indicator System which informs the driver when the next service is due, in accordance with the manufacturer's service schedule. The point at which the service is due is calculated from the last indicator zero reset, according to the mileage covered and the time elapsed since the last service. For BlueHDi Diesel versions, depending on the country of sale, the degree of deterioration of the engine oil may also be taken into account.
Between 600 miles (1 000 km) and 1 800 miles (3 000 km) remain before the next service is due For 5 seconds after the ignition is switched on, the spanner symbolising the service operations comes on. The distance recorder display line indicates the distance remaining before the next service is due. Example: 1 700 miles (2 800 km) remain before the next service is due. For 5 seconds after the ignition is switched on, the screen indicates:
Less than 600 miles (1 000 km) remain before the next service is due Example: 560 miles (900 km) remain before the next service is due. For 5 seconds after the ignition is switched on, the screen indicates:
5 seconds after the ignition is switched on, the distance recorder resumes its normal operation. The spanner remains on to indicate that a service must be carried out soon.
5 seconds after the ignition is switched on, the spanner goes off; the distance recorder resumes its normal operation. The screen then indicates the total and trip distances.
More than 1 800 miles (3 000 km) remain before the next service is due When the ignition is switched on, no service information appears in the screen.
40
Monitoring Therefore, the spanner may come on if you have exceeded the period since the last service, as indicated in the manufacturer's service schedule. For blueHdi diesel versions, the spanner may also come on early, according to the level of deterioration of the engine oil, which depends on the driving conditions in which the vehicle is used.
Service overdue For 5 seconds after the ignition is switched on, the spanner flashes to indicate that the service must be carried out as soon as possible. Example: the service is overdue by 186 miles (300 km). For 5 seconds after the ignition is switched on, the screen indicates:
5 seconds after the ignition is switched on, the distance recorder resumes its normal operation. The spanner remains on. With blueHdi diesel versions, the Service warning lamp also comes on when the ignition is switched on.
41
1Monitoring Service indicator zero reset
After each service, the service indicator must be reset to zero. If you have carried out the service on your vehicle yourself: F switch off the ignition, F press and hold the trip distance recorder
zero reset button,
F switch on the ignition; the distance recorder
Following this operation, if you wish to disconnect the battery, lock the vehicle and wait at least five minutes for the zero reset to be registered.
Retrieving the service information You can access the service information at any time. F Press the trip distance recorder zero reset
button. The service information is displayed for a
