2016 Chevrolet Cruze Owners Manual

Download PDF Manual
2k16_CS6_Chevrolet_Cruze_Limited_23289323A.ai 1 5/14/2015 10:22:48 AM 2k16_CS6_Chevrolet_Cruze_Limited_23289323A.ai 1 5/14/2015 10:22:48 AM CM MY CY CMY Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Contents Introduction . . . . . . . . . . . . . . . . . . . . . . 2 In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Keys, Doors, and Windows . . . . . 24 Seats and Restraints . . . . . . . . . . . 47 Storage . . . . . . . . . . . . . . . . . . . . . . . . . 91 Instruments and Controls . . . . . . . 93 Lighting . . . . . . . . . . . . . . . . . . . . . . . 128 Infotainment System . . . . . . . . . . 134 Climate Controls . . . . . . . . . . . . . . 163 Driving and Operating . . . . . . . . . 170 Vehicle Care . . . . . . . . . . . . . . . . . . 219 Service and Maintenance . . . . . 306 Technical Data . . . . . . . . . . . . . . . . 320 Customer Information . . . . . . . . . 323 Reporting Safety Defects . . . . . . 333 OnStar . . . . . . . . . . . . . . . . . . . . . . . . 336 Index . . . . . . . . . . . . . . . . . . . . 346 Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Introduction Introduction The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CHEVROLET, the CHEVROLET Emblem, and CRUZE are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division where it appears in this manual. This manual describes features that may or may not be on the vehicle because of optional equipment that was not purchased on the vehicle, model variants, country specifications, features/applications that may not be available in your region, or changes subsequent to the printing of this owner manual. Refer to the purchase documentation relating to your specific vehicle to confirm the features. Keep this manual in the vehicle for quick reference. Canadian Vehicle Owners A French language manual can be obtained from your dealer, at www.helminc.com, or from: Propriétaires Canadiens On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse suivante: Helm, Incorporated Attention: Customer Service 47911 Halyard Drive Plymouth, MI 48170 USA Using this Manual To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found. Litho in U.S.A. Part No. 23289323 B Second Printing ©2015 General Motors LLC. All Rights Reserved. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Danger, Warning, and Caution Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them. { Danger Danger indicates a hazard with a high level of risk which will result in serious injury or death. { Warning Warning indicates a hazard that could result in injury or death. Caution Caution indicates a hazard that could result in property or vehicle damage. A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.” Symbols The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or information relating to a specific component, control, message, gauge, or indicator. M : Shown when the owner manual has additional instructions or information. * : Shown when the service manual has additional instructions or information. 0 : Shown when there is more information on another page — “see page.” Introduction Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the Index. 9 : Airbag Readiness Light # : Air Conditioning ! : Antilock Brake System (ABS) % : Audio Steering Wheel Controls or OnStar® (if equipped) $ : Brake System Warning Light " : Charging System I : Cruise Control ` : Do Not Puncture ^ : Do Not Service B : Engine Coolant Temperature O : Exterior Lamps _ : Flame/Fire Prohibited # : Fog Lamps . : Fuel Gauge + : Fuses Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Introduction 3 : Headlamp High/Low-Beam Changer j : LATCH System Child Restraints * : Malfunction Indicator Lamp : : Oil Pressure } : Power / : Remote Vehicle Start > : Safety Belt Reminders 7 : Tire Pressure Monitor d : Traction Control/StabiliTrak® a : Under Pressure M : Windshield Washer Fluid Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- In Brief Steering Wheel Controls . . . . . . . 19 Cruise Control . . . . . . . . . . . . . . . . . 20 Driver Information Center (DIC) . . . . . . . . . . . . . . . . . 20 Side Blind Zone Alert (SBZA) . . . . . . . . . . . . . . . . . . 20 Rear Vision Camera (RVC) . . . . 21 Rear Cross Traffic Alert (RCTA) System . . . . . . . . . . . . . . . . . . . . . . . 21 Parking Assist . . . . . . . . . . . . . . . . . 21 Power Outlets . . . . . . . . . . . . . . . . . 21 Performance and Maintenance Traction Control/Electronic Stability Control . . . . . . . . . . . . . . 21 Tire Pressure Monitor . . . . . . . . . . 22 Engine Oil Life System . . . . . . . . 22 Driving for Better Fuel Economy . . . . . . . . . . . . . . . . . . . . . 22 Roadside Assistance Program . . . . . . . . . . . . . . . . . . . . . . 23 In Brief Instrument Panel Instrument Panel Overview . . . . . . 6 Initial Drive Information Initial Drive Information . . . . . . . . . . 8 Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . 8 Remote Vehicle Start . . . . . . . . . . . 8 Door Locks . . . . . . . . . . . . . . . . . . . . . 9 Windows . . . . . . . . . . . . . . . . . . . . . . . . 9 Seat Adjustment . . . . . . . . . . . . . . . 10 Heated Seats . . . . . . . . . . . . . . . . . . 11 Head Restraint Adjustment . . . . 11 Safety Belts . . . . . . . . . . . . . . . . . . . . 12 Passenger Sensing System . . . 12 Mirror Adjustment . . . . . . . . . . . . . . 12 Steering Wheel Adjustment . . . . 13 Interior Lighting . . . . . . . . . . . . . . . . 14 Exterior Lighting . . . . . . . . . . . . . . . 14 Windshield Wiper/Washer . . . . . . 15 Climate Controls . . . . . . . . . . . . . . . 15 Transmission . . . . . . . . . . . . . . . . . . 17 Vehicle Features Radio(s) . . . . . . . . . . . . . . . . . . . . . . . 17 Satellite Radio . . . . . . . . . . . . . . . . . 18 Portable Audio Devices . . . . . . . . 18 Bluetooth® . . . . . . . . . . . . . . . . . . . . . 19 Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- In Brief Instrument Panel Instrument Panel Overview Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 1. Exterior Lamp Controls 0 128 11. Climate Control Systems 0 163 ii ii (If Front Fog Lamps 0 131 Equipped). Instrument Panel Illumination Control 0 131 2. Air Vents 0 168 3. Headlamp High/Low-Beam ii ii ii Changer 0 128 Turn Signal Lever. See Turn and Lane-Change Signals 0 130 Driver Information Center (DIC) Buttons. See Driver Information Center (DIC) 0 112 Instrument Cluster 0 100 ii ii 4. 5. Driver Information Center (DIC) ii (If Equipped). Automatic Climate Control System 0 165 Heated Front Seats 0 50 Equipped). (If Equipped). (If ii ii 12. Traction Control/Electronic Stability Control 0 199 ii 13. Shift Lever. See Automatic or Manual ii Transmission 0 192 Transmission 0 196 14. Parking Brake 0 198 15. Power Outlets 0 97 16. Hazard Warning Flashers ii ii ii 0 130 ii 17. Trunk Release Button. See In Brief ii 21. Cruise Control 0 201 22. Instrument Panel Fuse Block 0 253 ii ii 23. Data Link Connector (DLC) (Out of View). See Malfunction Indicator Lamp (Check Engine Light) 0 104 ii 24. Hood Release. See Hood 0 222 ii 0 112 ii 6. Steering Wheel Controls 0 94 7. Windshield Wiper/Washer ii 18. 0 95 Infotainment 0 134 ii 8. 9. Light Sensor. See Automatic ii Headlamp System 0 129 10. Passenger Airbag Status ii Indicator 0 103 ii ii Trunk 0 37 Ignition Switch or Keyless Ignition Button (If Equipped). See Ignition Positions (Keyless Access) 0 181 Positions (Key Access) 0 183 or Ignition ii 19. Horn 0 95 20. Steering Wheel Adjustment ii ii 0 94 ii Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- In Brief Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual. Remote Keyless Entry (RKE) System The RKE transmitter may work up to 60 m (195 ft) away from the vehicle. ii Press the key release button to extend the key blade. The key can be used for the ignition, if equipped, and all locks. Press K to unlock the driver door or all doors. Press Q to lock all doors. Lock and unlock feedback can be personalized. See Vehicle Personalization 0 122 Press and hold Y to open the trunk. Press and hold 7 briefly to initiate vehicle locator. Press and hold 7 for at least three seconds to sound the panic alarm. Press 7 again to cancel the panic alarm. See Keys 0 24 Entry (RKE) System Operation 0 26 and Remote Keyless ii ii Remote Vehicle Start If equipped, the engine can be started from outside of the vehicle. Starting the Vehicle 1. Press and release Q on the 2. RKE transmitter. Immediately press and hold / for at least four seconds or until the turn signal lamps flash. 3. Start the vehicle normally after entering. When the vehicle starts, the parking lamps will turn on. Remote start can be extended. Canceling a Remote Start To cancel a remote start, do one of the following: . Press and hold / until the parking lamps turn off. . Turn on the hazard warning flashers. . Turn the vehicle on and then off. See Remote Vehicle Start 0 32 ii Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Door Locks To lock or unlock the vehicle from outside, use the key in the door or use the Remote Keyless Entry (RKE) transmitter. From inside the vehicle, use the power door lock switch. See Door Locks 0 34 Keyless Access ii from the driver door, the first press unlocks that door; press again within five seconds to unlock all passenger doors. See Remote Keyless Entry (RKE) System Operation 0 26 This feature may be configured. See Vehicle Personalization 0 122 Power Door Locks ii ii In Brief Windows { Warning Children could be seriously injured or killed if caught in the path of a closing window. Never leave keys in a vehicle with children. When there are children in the rear seat, use the window lockout button to prevent operation of the windows. See Keys 0 24 ii If equipped, use the Keyless Access system to lock and unlock the door. When the doors are locked and the RKE transmitter is within 1 m (3 ft) of the driver door handle, press the lock/unlock button. When unlocking K : Press to unlock the doors. Q : Press to lock the doors. See Power Door Locks 0 35 ii Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 10 In Brief ii Press the switch down to open the window. Pull the front of the switch up to close it. See Power Windows 0 43 The switches work when the ignition is in ON/RUN, ACC/ACCESSORY, or in Retained Accessory Power (RAP). See Retained Accessory Power (RAP) 0 188 2. Slide the seat to the desired Reclining Seatbacks position and release the handle. 3. Try to move the seat back and forth to be sure it is locked in place. Seat Height Adjuster ii Seat Adjustment Manual Front Seats If available, move the lever up or down to manually raise or lower the seat. See Seat Adjustment 0 48 ii To adjust a manual seat: 1. Pull the handle at the front of the seat. To recline the seatback: 1. Lift the lever. 2. Move the seatback to the desired position, then release the lever to lock the seatback in place. 3. Push and pull on the seatback to make sure it is locked. To return the seatback to an upright position: 1. Lift the lever fully without applying pressure to the seatback, and the seatback returns to the upright position. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 2. Push and pull on the seatback to make sure it is locked. See Reclining Seatbacks 0 49 Power Driver Seat ii See Power Seat Adjustment 0 49 Rear Seats The rear seatbacks can be folded. For detailed instructions, see Rear Seats 0 52 ii ii Heated Seats To adjust a power driver seat, if equipped: . Move the seat forward or rearward by sliding the control forward or rearward. . Raise or lower the front part of the seat cushion by moving the front of the control up or down. . Raise or lower the entire seat by moving the rear of the control up or down. If available, the controls are on the center stack. The engine must be running to operate the heated seats. Press L or M to heat the driver or passenger seat cushion and seatback. In Brief 11 Press the control once for the highest setting. With each press of the control, the heated seat will change to the next lower setting, and then the off setting. Three lights indicate the highest setting and one light the lowest. See Heated Front Seats 0 50 ii Head Restraint Adjustment Do not drive until the head restraints for all occupants are installed and adjusted properly. To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position. See Head Restraints 0 47 Adjustment 0 48 and Seat ii ii Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 12 In Brief Safety Belts Passenger Sensing System Refer to the following sections for important information on how to use safety belts properly: . Safety Belts 0 53 . How to Wear Safety Belts ii Properly 0 55 ii . Lap-Shoulder Belt 0 55 . Lower Anchors and Tethers for Children (LATCH System) 0 78 ii ii United States Canada The passenger sensing system turns off the front outboard passenger frontal airbag and knee airbag under certain conditions. No other airbag is affected by the passenger sensing system. See Passenger Sensing System 0 66 important information. ii for The passenger airbag status indicator will be visible on the instrument panel when the vehicle is started. See Passenger Airbag Status Indicator 0 103 ii Mirror Adjustment Exterior To adjust the mirrors: 1. Turn the selector switch to L (Left) or R (Right) to choose the driver or passenger mirror. 2. Move the control to adjust the mirror. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 3. Turn the selector switch to the O position to deselect the mirror. See Power Mirrors 0 41 If the vehicle has heated mirrors, see Heated Mirrors 0 42 ii ii Vehicles with a manual mirror adjustment have controls next to each mirror. See Manual Mirrors 0 41 ii Interior Mirror Adjustment Adjust the rearview mirror to view the area behind the vehicle. Manual Rearview Mirror If equipped with a manual rearview mirror, push the tab forward for daytime use and pull it for nighttime use to avoid glare from the headlamps from behind. See Manual Rearview Mirror 0 42 ii Automatic Dimming Rearview Mirror If equipped with an automatic dimming rearview mirror, the mirror will automatically reduce the glare of headlamps from behind. The dimming feature comes on each time the vehicle is started. See Automatic Dimming Rearview Mirror 0 42 ii In Brief 13 Steering Wheel Adjustment To adjust the steering wheel: 1. Pull the lever down. 2. Move the steering wheel up or down. 3. Pull or push the steering wheel closer or away from you. 4. Push the lever up to lock the steering wheel in place. Do not adjust the steering wheel while driving. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 14 In Brief Interior Lighting Dome Lamps Reading Lamps The reading lamps are in the overhead console. m or n : Press the button near each lamp to turn it on or off. Instrument Panel Illumination Control The dome lamp controls are in the headliner. * : Press to turn the lamps off, even when a door is open. I : Press to turn the lamps on automatically when a door is opened. + : Press to turn on the dome lamps. This feature controls the brightness of the instrument panel controls and infotainment display screen. The thumbwheel is located to the left of the steering column on the instrument panel. D : Turn the thumbwheel up or down and hold, to brighten or dim the instrument panel controls and infotainment display screen. Exterior Lighting The exterior lamp control is to the left of the steering column on the instrument panel. O : Briefly turn to this position to turn the automatic lamp control off or on again. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- AUTO : Turns the headlamps on automatically at normal brightness, together with the parking lamps, taillamps, license plate lamps, instrument panel lights, and sidemarker lamps. ; : Turns on the parking lamps including all lamps, except the headlamps. 5 : Turns on the headlamps together with the parking lamps and instrument panel lights. A warning chime sounds if the driver door is opened when the ignition switch is off and the headlamps are on. # : If equipped with fog lamps, press to turn the lamps on or off. See: . Exterior Lamp Controls 0 128 . Front Fog Lamps 0 131 ii ii Windshield Wiper/Washer The windshield wiper/washer lever is on the right side of the steering column. With the ignition in ACC/ ACCESSORY or ON/RUN/START, move the lever to select the wiper speed. HI : Use for fast wipes. LO : Use for slow wipes. In Brief 15 INT : Move the lever up to INT for intermittent wipes, then turn the x INT band up for more frequent wipes or down for less frequent wipes. OFF : Use to turn the wipers off. 1X : For a single wipe, briefly move the lever down. For several wipes, hold the lever down. n L : Pull the lever toward you to spray windshield washer fluid and activate the wipers. See Windshield Wiper/Washer 0 95 ii Climate Controls The heating, cooling, defrosting, and ventilation for the vehicle can be controlled with these systems. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 16 In Brief Vehicles without Air Conditioning Vehicles with Air Conditioning Automatic Climate Control System 1. Temperature Control 2. Bi-level Air Mode 3. Floor Air Mode 4. Vent Air Mode 5. Fan Control 6. Driver and Passenger Heated Seats (If Equipped) 7. Defrost 8. Defog 9. Rear Window Defogger 1. Temperature Control 2. Bi-level Air Mode 3. Floor Air Mode 4. Vent Air Mode 5. Fan Control 6. Driver and Passenger Heated Seats (If Equipped) 7. Defrost 8. Air Conditioning 9. Defog 10. Recirculation 11. Rear Window Defogger 1. Temperature Control 2. Rear Window Defogger 3. AUTO (Automatic Operation) 4. Defrost 5. Fan Control 6. Driver and Passenger Heated Seats (If Equipped) 7. Air Conditioning 8. MODE (Air Delivery Mode) 9. Recirculation 10. Power Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- See Climate Control Systems 0 163 or Automatic Climate Control (If Equipped). System 0 165 ii ii Transmission Manual Mode Driver Shift Control (DSC) allows the automatic transmission to be shifted similar to a manual transmission. Electronic Range Select (ERS) allows for the selection of a range of gears. See Manual Mode 0 194 ii Up‐Shift Light Vehicle Features In Brief 17 If the vehicle has a manual transmission, it will have an up-shift light that indicates when to shift to the next higher gear for the best fuel economy. See Manual Transmission 0 196 ii Radio(s) O : Press to turn the system on and off. Turn to increase or decrease the volume. BAND : Press to choose between FM, AM, or SiriusXM®, if equipped. MENU/SEL : Turn to select radio stations. Press to select a menu. g : Press to seek the previous station or track. l : Press to seek the next station or track. Buttons 1 to 6 : Press to save and select favorite stations. INFO : Press to show available information about the current station or track. For more information about these and other radio features, see Operation 0 137 ii Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 18 In Brief Storing a Favorite Station Stations from all bands can be stored in the favorite lists in any order. Up to six stations can be stored in each favorite page and the number of available favorite pages can be set. To store the station to a position in the list, press the corresponding numeric button 1 to 6 until a beep is heard. See “Storing a Station as a Favorite” in AM-FM Radio 0 140 Setting the Clock ii Adjusting the Time or Date To set the time and date for the radio with navigation: 1. Press CLOCK. 2. Select Set Time or Set Date. 3. Turn the MENU/SEL knob to adjust the highlighted number. 4. Press the MENU/SEL knob to select the next number. 5. To save the settings, press BACK on the radio faceplate. variety of programming and commercial-free music, coast to coast, and in digital-quality sound. A fee is required to receive the SiriusXM service. Refer to: . www.siriusxm.com or call 1-866-635-2349 (U.S.). . www.xmradio.ca or call 1-877-209-0079 (Canada). See Satellite Radio 0 142 ii Portable Audio Devices Some vehicles have a 3.5 mm (1/8 in) auxiliary input and a USB port in the center console. External devices such as iPods®, MP3 players, CD changers, and USB drives may be connected, depending on the audio system. See Auxiliary Devices 0 147 ii Setting the 12/24 Hour Format To set the 12/24 hour format for the radio with navigation: 1. Press CLOCK. 2. Highlight 12/24 Hour Format. 3. Press the MENU/SEL knob to select the 12 hour or 24 hour display format. 4. To save the settings, press BACK on the radio faceplate. For detailed instructions on setting the clock for the vehicle's specific audio system, see Clock 0 96 ii Satellite Radio If equipped, vehicles with a SiriusXM® satellite radio tuner and a valid SiriusXM satellite radio subscription can receive SiriusXM programming. SiriusXM Satellite Radio Service SiriusXM is a satellite radio service based in the 48 contiguous United States and 10 Canadian provinces. SiriusXM satellite radio has a wide Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Bluetooth® The Bluetooth® system allows users with a Bluetooth-enabled mobile phone to make and receive hands-free calls using the vehicle audio system and controls. The Bluetooth-enabled mobile phone must be paired with the in-vehicle Bluetooth system before it can be used in the vehicle. Not all phones will support all functions. See Bluetooth (Infotainment Controls) 0 151 Recognition) 0 154 (Overview) 0 149 or Bluetooth (Voice or Bluetooth ii ii ii In Brief 19 $ / i : Press to silence the vehicle speakers only. Press again to turn the sound on. For vehicles with OnStar or Bluetooth systems, press to reject an incoming call, or to end a current call. _ SRC ^ : Press to select a source or turn to change favorite stations. Press _ or ^ to select AM, FM, CD, or MP3 track. Turn _ or ^ to select the next or previous saved favorite radio stations. + x − : Press + to increase the volume. Press − to decrease the volume. For more information, see Steering Wheel Controls 0 94 ii ii Steering Wheel Controls For vehicles with audio steering wheel controls, some audio controls can be adjusted at the steering wheel. b / g : For vehicles with a Bluetooth, OnStar, or navigation system, press to interact with those systems. See Bluetooth (Infotainment Controls) 0 151 Bluetooth (Voice Recognition) 0 154 or Bluetooth (Overview) 0 149 , or the OnStar Overview 0 336 infotainment manual. or ii ii ii Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 20 In Brief Cruise Control If equipped with cruise control: 1 : Press to turn the cruise control system on and off. A white indicator comes on in the instrument cluster when cruise is turned on. RES/+ : If there is a set speed in memory, move the thumbwheel up briefly to resume to that speed or hold upward to accelerate. If cruise control is already active, use to increase vehicle speed. 2. w / x : Use the band to scroll through the items in each menu. 3. MENU: Press to display the DIC menus. This button is also used to return to or exit the last screen displayed on the DIC. See Driver Information Center (DIC) 0 112 ii Side Blind Zone Alert (SBZA) If equipped, SBZA will detect moving vehicles in the next lane over in the vehicle's side blind zone area. When this happens, the SBZA display will light up in the corresponding outside side mirror and will flash if the turn signal is on. See Side Blind Zone Alert (SBZA) 0 207 ii SET/− : Move the thumbwheel down briefly to set the speed and activate cruise control. If cruise control is already active, use to decrease speed. * : Press to disengage cruise control without erasing the set speed from memory. See Cruise Control 0 201 ii Driver Information Center (DIC) The DIC display is in the center of the instrument cluster. It shows the status of many vehicle systems. The controls for the DIC are on the turn signal lever. 1. SET/CLR: Press to set, or press and hold to clear, the menu item displayed. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Rear Vision Camera (RVC) If equipped, RVC displays a view of the area behind the vehicle, on the infotainment system display, when the vehicle is shifted into R (Reverse). See Rear Vision Camera (RVC) 0 203 ii Rear Cross Traffic Alert (RCTA) System If equipped, the RCTA system uses a triangle with an arrow displayed on the RVC screen to warn of traffic behind your vehicle that may cross your vehicle's path while in R (Reverse). In addition, beeps will sound. See “Rear Cross Traffic Alert (RCTA)” under Rear Vision Camera (RVC) 0 203 ii Parking Assist If equipped, Rear Parking Assist (RPA) uses sensors on the rear bumper to assist with parking and avoiding objects while in R (Reverse). It operates at speeds less than 8 km/h (5 mph) and uses audible beeps to provide distance and system information. Keep the sensors on the vehicle's rear bumper clean to ensure proper operation. See Parking Assist 0 205 ii Power Outlets The accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. There is one accessory power outlet located on the center floor console and one on the rear of the center floor console. These outlets are powered when the key is in ON/ RUN or ACC/ACCESSORY, or until the driver door is opened within 10 minutes of turning off the vehicle. See Retained Accessory Power (RAP) 0 188 See Power Outlets 0 97 ii ii In Brief 21 Performance and Maintenance Traction Control/ Electronic Stability Control The Traction Control System (TCS) limits wheel spin. The system turns on automatically every time the vehicle is started. The StabiliTrak system assists with directional control of the vehicle in difficult driving conditions. The system also turns on automatically every time the vehicle is started. . To turn off traction control, press and release the g button on the center console. The traction off light i illuminates. . To turn off both traction control and StabiliTrak, press and hold the g button, until the traction off light i and the StabiliTrak OFF light g illuminate. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 22 In Brief . Press and release the g button again to turn on both systems. See Traction Control/Electronic Stability Control 0 199 ii Tire Pressure Monitor This vehicle may have a Tire Pressure Monitor System (TPMS). The low tire pressure warning light alerts to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and Loading Information label. See . The Vehicle Load Limits 0 177 warning light will remain on until the tire pressure is corrected. ii The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This may be an early indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure. The TPMS does not replace normal monthly tire maintenance. Maintain the correct tire pressures. See Tire Pressure Monitor System 0 263 ii Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays the CHANGE ENGINE OIL SOON DIC message when it is necessary to change the engine oil and filter. Remember, the Oil Life display must be reset after each oil change. It will not reset itself. Also, be careful not to reset the Oil Life display accidentally at any time other than when the oil has just been changed. It cannot be reset accurately until the next oil change. To reset the engine oil life system press the SET/CLR button while the Oil Life display is active. Resetting the Oil Life System 1. Using the DIC MENU button and thumbwheel, scroll until you reach REMAINING OIL LIFE on the DIC (: % for Canada). 2. Press the SET/CLR button to reset the oil life at 100%. When prompted, use the thumbwheel to highlight YES or NO. Press the SET/CLR button to confirm. Be careful not to reset the oil life display accidentally at any time other than after the oil is changed. It cannot be reset accurately. See Engine Oil Life System 0 229 ii Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- In Brief 23 Roadside Assistance Program U.S.: 1-800-243-8872 TTY Users (U.S. Only): 1-888-889-2438 Canada: 1-800-268-6800 As the owner of a new Chevrolet, you are automatically enrolled in the Roadside Assistance program. See Roadside Assistance Program 0 327 ii . Avoid fast starts and accelerate smoothly. . Brake gradually and avoid abrupt stops. . Avoid idling the engine for long periods of time. . When road and weather conditions are appropriate, use cruise control. . Always follow posted speed limits or drive more slowly when conditions require. . Keep vehicle tires properly inflated. . Combine several trips into a single trip. . Replace the vehicle's tires with the same TPC Spec number molded into the tire's sidewall near the size. . Follow recommended scheduled maintenance. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Keys, Doors, and Windows 24 Keys, Doors, and Windows Keys and Locks Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . 26 Remote Keyless Entry (RKE) System Operation . . . . . . . . . . . . 26 Remote Vehicle Start . . . . . . . . . . 32 Door Locks . . . . . . . . . . . . . . . . . . . . 34 Power Door Locks . . . . . . . . . . . . . 35 Delayed Locking . . . . . . . . . . . . . . . 35 Automatic Door Locks . . . . . . . . . 35 Lockout Protection . . . . . . . . . . . . . 36 Safety Locks . . . . . . . . . . . . . . . . . . . 36 Doors Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Vehicle Security Vehicle Security . . . . . . . . . . . . . . . . 38 Vehicle Alarm System . . . . . . . . . 38 Immobilizer . . . . . . . . . . . . . . . . . . . . 40 Immobilizer Operation . . . . . . . . . 40 Exterior Mirrors Convex Mirrors . . . . . . . . . . . . . . . . 41 Manual Mirrors . . . . . . . . . . . . . . . . . 41 Power Mirrors . . . . . . . . . . . . . . . . . . 41 Folding Mirrors . . . . . . . . . . . . . . . . . 42 Heated Mirrors . . . . . . . . . . . . . . . . . 42 Interior Mirrors Interior Rearview Mirrors . . . . . . . 42 Manual Rearview Mirror . . . . . . . . 42 Automatic Dimming Rearview Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 42 Windows Windows . . . . . . . . . . . . . . . . . . . . . . . 43 Power Windows . . . . . . . . . . . . . . . 43 Sun Visors . . . . . . . . . . . . . . . . . . . . . 45 Roof Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 45 Keys and Locks Keys { Warning Leaving children in a vehicle with an ignition key or Remote Keyless Entry (RKE) transmitter is dangerous and children or others could be seriously injured or killed. They could operate the power window or other controls or make the vehicle move. The windows will function with the key in the ignition or with the RKE transmitter in the vehicle, and children or others could be caught in the path of a closing window. Do not leave children in a vehicle with the ignition key or an RKE transmitter. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Keys, Doors, and Windows 25 Warning (Continued) impacted, and airbags may not deploy. To reduce the risk of unintentional rotation of the ignition key, do not change the way the ignition key and Remote Keyless Entry (RKE) transmitter, if equipped, are connected to the provided key rings. If the vehicle is equipped with a keyed ignition, the ignition key, key rings, and RKE transmitter, if equipped, are designed to work together. As a system, it reduces the risk of unintentionally moving the key out of the RUN position. If replacements or additions are required, see your dealer. Limit added items to a few essential keys or small, light items no larger than an RKE transmitter. Interference from radio-frequency identification (RFID) tags may prevent the key from starting the vehicle. Keep RFID tags away from the key when starting the vehicle. The key that is part of the Remote Keyless Entry (RKE) transmitter can be used for the ignition and all locks if the vehicle is a Key access vehicle. If the vehicle has the keyless ignition, the key can be used for the locks. { Warning If the key is unintentionally rotated while the vehicle is running, the ignition could be moved out of the RUN position. This could be caused by heavy items hanging from the key ring, or by large or long items attached to the key ring that could be contacted by the driver or steering wheel. If the ignition moves out of the RUN position, the engine will shut off, braking and steering power assist may be (Continued) Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 26 Keys, Doors, and Windows With an active OnStar subscription, an OnStar Advisor may remotely unlock the vehicle. See OnStar Overview 0 336 ii Remote Keyless Entry (RKE) System See Radio Frequency Statement 0 333 If there is a decrease in the RKE operating range: . Check the distance. The ii transmitter may be too far from the vehicle. . Check the location. Other vehicles or objects may be blocking the signal. . Check the transmitter's battery. See “Battery Replacement” later in this section. If the transmitter is still not working correctly, see your dealer or a qualified technician for service. Press the button on the RKE transmitter to extend the key. Press the button and the key blade to retract the key. If it becomes difficult to turn the key, inspect the key blade for debris. Periodically clean with a brush or pick. See your dealer if a new key is needed. If locked out of the vehicle, see Roadside Assistance Program 0 327 ii Remote Keyless Entry (RKE) System Operation The Keyless Access system allows for vehicle entry when the transmitter is within range. See “Keyless Access Operation” later in this section. The transmitter functions may work up to 60 m (195 ft) away from the vehicle. Keep in mind that other conditions, such as those previously stated, can impact the performance of the transmitter. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Keys, Doors, and Windows 27 ii Q (Lock) : Press to lock all doors. The turn signal indicators may flash and/or the horn may sound on the second press to indicate locking. See Vehicle Personalization 0 122 If the driver door is open when Q is pressed, all doors and the driver door will immediately unlock, if Unlocked Door Anti Lock Out is enabled through the vehicle personalization. If the passenger door is open when Q is pressed, all doors lock. Pressing Q may also arm the alarm system. See Vehicle Alarm System 0 38 K (Unlock) : Press to unlock the driver door or all doors. See Vehicle Personalization 0 122 The turn signal indicators may flash to indicate unlocking. See Vehicle Personalization 0 122 Pressing K will disarm the alarm system. See Vehicle Alarm System 0 38 ii ii ii ii Y (Remote Trunk Release) : Press and hold to release the trunk. 7 (Vehicle Locator/Panic Alarm) : Press and hold briefly to initiate vehicle locator. The exterior lamps flash and the horn chirps three times. Press and hold 7 for at least three seconds to sound the panic alarm. The horn sounds and the turn signals flash for 30 seconds, or until 7 is pressed again or the vehicle is started. / (Remote Vehicle Start) : If equipped, press and release Q and then immediately press and hold / for at least four seconds to start the engine from outside the vehicle using the RKE transmitter. See Remote Vehicle Start 0 32 The RKE transmitter buttons will not operate when the key is in the ignition. ii Keyless Access Operation The Keyless Access system allows for the doors and trunk to be locked and unlocked without pressing the RKE transmitter button. The RKE transmitter must be within 1 m (3 ft) of the door being opened. If the vehicle has this feature, there will be a button on the outside door handles. Keyless Access can be programmed to unlock all doors on the first lock/unlock press from the driver door. See Vehicle Personalization 0 122 ii Keyless Unlocking/Locking from the Driver Door When the doors are locked and the RKE transmitter is within range of the door handle, pressing the lock/ unlock button on the driver door handle will unlock the driver door. If the lock/unlock button is pressed again within five seconds, all passenger doors will unlock. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 28 Keys, Doors, and Windows Keyless Unlocking/Locking from the Passenger Doors When the doors are locked and the RKE transmitter is within range of the door handle, pressing the lock/ unlock button on a passenger door handle will unlock all doors. Pressing the lock/unlock button will cause all doors to lock if any of the following occur: . The lock/unlock button was used to unlock all doors. . Any vehicle door has been opened and all doors are now closed. Passive Locking If equipped with Keyless Access, the vehicle will lock several seconds after all doors are closed if the vehicle is off and at least one RKE transmitter has been removed or none remain in the vehicle. If other electronic devices interfere with the RKE transmitter signal, the vehicle may not detect the RKE transmitter inside the vehicle. If passive locking is enabled, the doors may lock with the RKE transmitter inside the vehicle. Do not leave the RKE transmitter in an unattended vehicle. To customize the doors to automatically lock when exiting the vehicle, see Vehicle Personalization 0 122 ii Temporary Disable of Passive Locking Feature Temporarily disable the passive locking by pressing and holding K on the interior door switch with a door open for at least four seconds, or until three chimes are heard. Passive locking will then remain disabled until Q on the interior door is pressed, or until the vehicle is turned on. Keyless Trunk Opening Press the touch pad on the rear of the trunk above the license plate to open the trunk when the RKE transmitter is in range. Key Access To access a vehicle with a dead transmitter battery, see Door Locks 0 34 ii Driver Side Shown, Passenger Similar Pressing the lock/unlock button will cause all doors to lock if any of the following occur: It has been more than five seconds since the first lock/ unlock button press. . Two lock/unlock button presses were used to unlock all doors. . Any vehicle door has been opened and all doors are now closed. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- Keys, Doors, and Windows 29 Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Any remaining transmitters will need to be reprogrammed. Each vehicle can have up to eight transmitters matched to it. Programming with a Recognized Transmitter (Key Vehicles Only) To program a new key: 1. Insert the original, already programmed key in the ignition and turn the key to the ON/ RUN position. 2. Turn the key to LOCK/OFF, 3. and remove the key. Insert the new key to be programmed and turn it to the ON/RUN position within five seconds. The security light will turn off once the key has been programmed. 4. Repeat Steps 1–3 if additional keys are to be programmed. If a key is lost or damaged, see your dealer to have a new key made. Programming without a Recognized Transmitter (Key Vehicles Only) Program a new key to the vehicle when a recognized key is not available. Canadian regulations require that owners see their dealer. If there are no currently recognized keys available, follow this procedure to program the first key. This procedure will take approximately 30 minutes to complete for the first key. The vehicle must be off and all of the keys you wish to program must be with you. 1. Insert the new vehicle key into the ignition. 2. Turn to ON/RUN. The security light will come on. 3. Wait 10 minutes until the security light turns off. 4. Turn the ignition to LOCK/OFF. 5. Repeat Steps 2–4 two more times. After the third time, turn to ON/RUN; the key is learned and all previously known keys will no longer work with the vehicle. Remaining keys can be learned by following the procedure in “Programming with a Recognized Transmitter (Key Vehicles Only).” Programming with a Recognized Transmitter (Keyless Access Vehicles Only) A new transmitter can be programmed to the vehicle when there is one recognized transmitter. To program, the vehicle must be off and all of the transmitters, both currently recognized and new, must be with you. Chevrolet Cruze Limited Owner Manual 9282844) - 2016 - crc - 9/3/15 (GMNA-Localizing-U.S./Canada- 30 Keys, Doors, and Windows The Driver Information Center (DIC) displays READY FOR REMOTE #2, 3, 4 or 5. 3. Remove the recognized key and place the new transmitter into the transmitter slot. 4. Press the ENGINE START/ STOP button. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter. 5. Remove the transmitter from the transmitter pocket and press K. To program additional transmitters, repeat Steps 3–5. When all additional transmitters are programmed, press and hold the ENGINE START/ STOP button for 12 seconds to exit programming mode. Replace the plastic trim piece from the small storage area. Programming without a Recognized Transmitter (Keyless Access Vehicles Only) If there are no currently recognized transmitters available, follow this procedure to program up to five transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters you wish to program must be with you. 1. Insert the vehicle key of the transmitter into the key lock cylinder on the outside of the driver door and turn the key to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays REMOTE LEARN PENDING, PLEASE WAIT. 2. Wait for 10 minutes until the DIC displays PRESS ENGINE START BUTTON TO LEARN and then press the ENGINE START/STOP button. 1. Remove the plastic trim piece from the small storage area next to the accessory power outlet toward the front of the console, to access the transmitter slot. Press the button on the recognized transmitter to extend the key blade. Insert the key blade into the transmitter slot. Insert the vehicle key of the new transmitter into the key lock cylinder on the outside of the driver door and turn the key to the unlock position five times within 10 seconds. 2. Chevrolet Cruze Limited Owner Manual
