Chevrolet Cruze Owner Manual - 2012


Black plate (1,1)


2012 Chevrolet Cruze Owner Manual M


In Brief . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Instrument Panel . . . . . . . . . . . . . . 1-2
Initial Drive Information . . . . . . . . 1-4
Vehicle Features . . . . . . . . . . . . . 1-15
Performance and


Maintenance . . . . . . . . . . . . . . . . 1-19


Keys, Doors, and


Windows . . . . . . . . . . . . . . . . . . . . 2-1
Keys and Locks . . . . . . . . . . . . . . . 2-2
Doors . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Vehicle Security. . . . . . . . . . . . . . 2-14
Exterior Mirrors . . . . . . . . . . . . . . . 2-15
Interior Mirrors . . . . . . . . . . . . . . . . 2-17
Windows . . . . . . . . . . . . . . . . . . . . . 2-18
Roof . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21


Seats and Restraints . . . . . . . . . 3-1
Head Restraints . . . . . . . . . . . . . . . 3-2
Front Seats . . . . . . . . . . . . . . . . . . . . 3-3
Rear Seats . . . . . . . . . . . . . . . . . . . . 3-8
Safety Belts . . . . . . . . . . . . . . . . . . 3-10
Airbag System . . . . . . . . . . . . . . . . 3-19
Child Restraints . . . . . . . . . . . . . . 3-33


Storage . . . . . . . . . . . . . . . . . . . . . . . 4-1
Storage Compartments . . . . . . . . 4-1
Additional Storage


Features . . . . . . . . . . . . . . . . . . . . . 4-2


Instruments and Controls . . . . 5-1
Controls . . . . . . . . . . . . . . . . . . . . . . . 5-2
Warning Lights, Gauges, and


Indicators . . . . . . . . . . . . . . . . . . . . 5-7
Information Displays . . . . . . . . . . 5-23
Vehicle Messages . . . . . . . . . . . . 5-28
Vehicle Personalization . . . . . . . 5-34


Lighting . . . . . . . . . . . . . . . . . . . . . . . 6-1
Exterior Lighting . . . . . . . . . . . . . . . 6-1
Interior Lighting . . . . . . . . . . . . . . . . 6-5
Lighting Features . . . . . . . . . . . . . . 6-6


Infotainment System . . . . . . . . . 7-1
Introduction . . . . . . . . . . . . . . . . . . . . 7-2
Radio . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Audio Players . . . . . . . . . . . . . . . . 7-18
Phone . . . . . . . . . . . . . . . . . . . . . . . . 7-23
Trademarks and License


Agreements . . . . . . . . . . . . . . . . . 7-35


Climate Controls . . . . . . . . . . . . . 8-1
Climate Control Systems . . . . . . 8-1
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 8-6


Chevrolet Cruze Owner Manual - 2012


Black plate (2,1)


2012 Chevrolet Cruze Owner Manual M


Driving and Operating . . . . . . . . 9-1
Driving Information . . . . . . . . . . . . . 9-2
Starting and Operating . . . . . . . 9-15
Engine Exhaust . . . . . . . . . . . . . . 9-27
Automatic Transmission . . . . . . 9-29
Manual Transmission . . . . . . . . . 9-33
Brakes . . . . . . . . . . . . . . . . . . . . . . . 9-35
Ride Control Systems . . . . . . . . 9-37
Cruise Control . . . . . . . . . . . . . . . . 9-40
Object Detection Systems . . . . 9-42
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 9-44
Towing . . . . . . . . . . . . . . . . . . . . . . . 9-48
Conversions and


Add-Ons . . . . . . . . . . . . . . . . . . . . 9-55


Vehicle Care . . . . . . . . . . . . . . . . . 10-1
General Information . . . . . . . . . . 10-2
Vehicle Checks . . . . . . . . . . . . . . . 10-4
Headlamp Aiming . . . . . . . . . . . 10-29
Bulb Replacement . . . . . . . . . . 10-29
Electrical System . . . . . . . . . . . . 10-35
Wheels and Tires . . . . . . . . . . . 10-42
Jump Starting . . . . . . . . . . . . . . . 10-80
Towing . . . . . . . . . . . . . . . . . . . . . . 10-83
Appearance Care . . . . . . . . . . . 10-86


Service and Maintenance . . . 11-1
General Information . . . . . . . . . . 11-1
Maintenance Schedule . . . . . . . 11-3
Special Application


Services . . . . . . . . . . . . . . . . . . . . 11-9


Additional Maintenance


and Care . . . . . . . . . . . . . . . . . . . 11-10


Recommended Fluids,


Lubricants, and Parts . . . . . . 11-13
Maintenance Records . . . . . . . 11-16


Technical Data . . . . . . . . . . . . . . . 12-1
Vehicle Identification . . . . . . . . . 12-1
Vehicle Data . . . . . . . . . . . . . . . . . . 12-2


Customer Information . . . . . . . 13-1
Customer Information . . . . . . . . 13-1
Reporting Safety Defects . . . . 13-13
Vehicle Data Recording and


Privacy. . . . . . . . . . . . . . . . . . . . 13-14
Index . . . . . . . . . . . . . . . . . . . . . i-1


Chevrolet Cruze Owner Manual - 2012


Black plate (3,1)


This manual describes features that may or may not be on your specific vehicle either because they are options that you did not purchase or due to changes subsequent to the printing of this owner manual. Please refer to the purchase documentation relating to your specific vehicle to confirm each of the features found on your vehicle. For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division wherever it appears in this manual. Keep this manual in the vehicle for quick reference.


Introduction


iii


Canadian Vehicle Owners


Propriétaires Canadiens A French language copy of this manual can be obtained from your dealer or from: On peut obtenir un exemplaire de ce guide en français auprès du concessionnaire ou à l'adresse suivante: Helm, Incorporated P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
Numéro de poste 6438 de langue française www.helminc.com


The names, logos, emblems, slogans, vehicle model names, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CHEVROLET, the CHEVROLET Emblem, and CRUZE are trademarks and/or service marks of General Motors LLC, its subsidiaries, affiliates, or licensors.


Litho in U.S.A. Part No. 20935335 A First Printing


©2011 General Motors LLC. All Rights Reserved.


Chevrolet Cruze Owner Manual - 2012


Black plate (4,1)


iv


Introduction


Using this Manual To quickly locate information about the vehicle, use the Index in the back of the manual. It is an alphabetical list of what is in the manual and the page number where it can be found.


Danger, Warnings, and Cautions Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them. Danger indicates a hazard with a high level of risk which will result in serious injury or death. Warning or Caution indicates a hazard that could result in injury or death.


{ WARNING


These mean there is something that could hurt you or other people.


Notice: This means there is something that could result in property or vehicle damage. This would not be covered by the vehicle's warranty.


A circle with a slash through it is a safety symbol which means “Do Not,” “Do not do this,” or “Do not let this happen.”


Symbols The vehicle has components and labels that use symbols instead of text. Symbols are shown along with the text describing the operation or information relating to a specific component, control, message, gauge, or indicator. M : This symbol is shown when you need to see your owner manual for additional instructions or information. * : This symbol is shown when you need to see a service manual for additional instructions or information.


Chevrolet Cruze Owner Manual - 2012


Black plate (5,1)


Vehicle Symbol Chart Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the Index. 9 : Airbag Readiness Light # : Air Conditioning ! : Antilock Brake System (ABS) % : Audio Steering Wheel Controls or OnStar® $ : Brake System Warning Light


" : Charging System I : Cruise Control B : Engine Coolant Temperature O : Exterior Lamps # : Fog Lamps . : Fuel Gauge + : Fuses 3 : Headlamp High/Low-Beam Changer j : LATCH System Child Restraints


Introduction


* : Malfunction Indicator Lamp : : Oil Pressure } : Power / : Remote Vehicle Start > : Safety Belt Reminders 7 : Tire Pressure Monitor d : Traction Control/Stabilitrak® M : Windshield Washer Fluid


Chevrolet Cruze Owner Manual - 2012


Black plate (6,1)


vi


Introduction


2 NOTES


Chevrolet Cruze Owner Manual - 2012


Black plate (1,1)


In Brief


Instrument Panel


Instrument Panel Overview . . . . 1-2


Initial Drive Information


Initial Drive Information . . . . . . . . 1-4
Remote Keyless Entry (RKE)


System . . . . . . . . . . . . . . . . . . . . . . 1-4
Remote Vehicle Start . . . . . . . . . 1-5
Door Locks . . . . . . . . . . . . . . . . . . . 1-6
Seat Adjustment . . . . . . . . . . . . . . 1-7
Heated Seats . . . . . . . . . . . . . . . . . 1-9
Head Restraint Adjustment . . . . 1-9
Safety Belts . . . . . . . . . . . . . . . . . . . 1-9
Passenger Sensing


System . . . . . . . . . . . . . . . . . . . . . 1-10
Mirror Adjustment . . . . . . . . . . . . 1-10


Steering Wheel


Adjustment . . . . . . . . . . . . . . . . . 1-11
Interior Lighting . . . . . . . . . . . . . . 1-11
Exterior Lighting . . . . . . . . . . . . . 1-12
Windshield Wiper/Washer . . . . 1-13
Climate Controls . . . . . . . . . . . . . 1-14
Transmission . . . . . . . . . . . . . . . . 1-15


Vehicle Features


Radio(s) . . . . . . . . . . . . . . . . . . . . . 1-15
Satellite Radio . . . . . . . . . . . . . . . 1-16
Portable Audio Devices . . . . . . 1-17
Bluetooth® . . . . . . . . . . . . . . . . . . . 1-17
Steering Wheel Controls . . . . . 1-17
Cruise Control . . . . . . . . . . . . . . . 1-18
Navigation System . . . . . . . . . . . 1-18
Driver Information


Center (DIC) . . . . . . . . . . . . . . . 1-18
Ultrasonic Parking Assist . . . . 1-19
Power Outlets . . . . . . . . . . . . . . . 1-19


In Brief


1-1


Performance and Maintenance


Traction Control


System (TCS) . . . . . . . . . . . . . . 1-19
StabiliTrak® System . . . . . . . . . 1-20
Tire Pressure Monitor . . . . . . . . 1-20
Tire Sealant and


Compressor Kit . . . . . . . . . . . . . 1-20
Engine Oil Life System . . . . . . 1-21
Driving for Better Fuel


Economy . . . . . . . . . . . . . . . . . . . 1-21


Roadside Assistance


Program . . . . . . . . . . . . . . . . . . . . 1-22
OnStar® . . . . . . . . . . . . . . . . . . . . . 1-22


Chevrolet Cruze Owner Manual - 2012


Black plate (2,1)


1-2


In Brief


Instrument Panel


Instrument Panel Overview


Chevrolet Cruze Owner Manual - 2012


Black plate (3,1)


In Brief


1-3


A. Exterior Lamp Controls on


H. Windshield Wiper/Washer on


R. Steering Wheel Adjustment on


page 6‑1. Front Fog Lamps on page 6‑4
(If Equipped). Instrument Panel Illumination Control on page 6‑5.


B. Air Vents on page 8‑6. C. Headlamp High/Low-Beam


Changer on page 6‑2. Turn and Lane‐Change Lever. See Turn and Lane-Change Signals on page 6‑4. Driver Information Center (DIC) Buttons. See Driver Information Center (DIC) on page 5‑23. Instrument Cluster on page 5‑8.


D. E. Horn on page 5‑3. F. Driver Information Center (DIC)


on page 5‑23.


I.


J. K.


page 5‑3. Infotainment on page 7‑2. Satellite Radio on page 7‑14
(If Equipped). Infotainment Display Screen. Instrument Panel Storage on page 4‑1.


L. Light Sensor. See Automatic


Headlamp System on page 6‑3. M. Passenger Airbag. See Where Are the Airbags? on page 3‑21.


N. Hood Release. See Hood on


page 10‑4.


O. Data Link Connector (DLC)


(Out of View). See Malfunction Indicator Lamp on page 5‑13. Instrument Panel Fuse Block on page 10‑40.


P.


G. Steering Wheel Controls on


Q. Cruise Control on page 9‑40.


page 5‑2.


page 5‑2.


S. Driver Airbag. See Where Are


T.


the Airbags? on page 3‑21. Ignition Switch or Keyless Ignition Button (If Equipped). See Ignition Positions (Key Access) on page 9‑15 or Ignition Positions (Keyless Access) on page 9‑18.


U. Driver Knee Airbag. See Where Are the Airbags? on page 3‑21.


V. Power Door Locks on


page 2‑11.


W. Hazard Warning Flashers on


page 6‑3.


X. Shift Lever. See Automatic


Transmission on page 9‑29 or Manual Transmission on page 9‑33.


Y. Traction Control System (TCS)


on page 9‑37. StabiliTrak® System on page 9‑38.


Chevrolet Cruze Owner Manual - 2012


Black plate (4,1)


1-4


In Brief


Z. Climate Control Systems on


page 8‑1 (If Equipped). Automatic Climate Control System on page 8‑3
(If Equipped). Heated Front Seats on page 3‑7
(If Equipped).


AA. Passenger Airbag Status


Indicator on page 5‑12.


AB. Passenger Knee Airbag. See


Where Are the Airbags? on page 3‑21.


Initial Drive Information This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual.


Remote Keyless Entry (RKE) System The Remote Keyless Entry (RKE) transmitter will work up to 20 m (65 ft) away from the vehicle.


RKE Transmitter with Remote


Start Shown


Press the key release button to extend the key blade. The key can be used for the ignition and all locks. Press K to unlock the driver door or all doors. Press Q to lock all doors. Lock and unlock feedback can be personalized. See Vehicle Personalization on page 5‑34.


Chevrolet Cruze Owner Manual - 2012


Black plate (5,1)


In Brief


1-5


Press and hold V briefly to open the trunk. Press and hold 7 briefly to locate the vehicle. Press and hold 7 for at least two seconds to sound the panic alarm. Press 7 again to cancel the panic alarm. See Keys on page 2‑2 and Remote Keyless Entry (RKE) System Operation on page 2‑3.


Remote Vehicle Start For vehicles with this feature, the engine can be started from outside the vehicle. Starting the Vehicle 1. Aim the RKE transmitter at


the vehicle.


2. Press and release Q. 3.


Immediately after completing Step 2, press and hold / until the turn signal lamps flash, or for about two seconds if the vehicle is not in view.


When the engine starts, the parking lamps will turn on and remain on as long as the engine is running. The doors will be locked and the climate control system may come on.


The engine will continue to run for 10 minutes. Repeat the steps for a 10-minute time extension. Remote start can be extended only once. Canceling a Remote Start To cancel a remote start, do one of the following: . Aim the RKE transmitter at the vehicle and press and hold / until the parking lamps turn off. Turn on the hazard warning flashers. Turn the vehicle on and then off.


See Remote Vehicle Start on page 2‑9.


Chevrolet Cruze Owner Manual - 2012


Black plate (6,1)


1-6


In Brief


Door Locks To lock or unlock the vehicle from outside, use the Remote Keyless Entry (RKE) transmitter or the key. From inside the vehicle, use the power door lock switch. See Door Locks on page 2‑10.


Power Door Locks


The power door lock switch is on the instrument panel. K : Press to unlock the doors. Q : Press to lock the doors. See Power Door Locks on page 2‑11. Safety Locks The rear door safety locks prevent passengers from opening the rear doors from inside the vehicle.


Press o { to activate the safety locks on the rear doors. The LED light (A) comes on when activated. The rear door power windows are also disabled. Press o { again to deactivate the lockout switch. If the LED light flashes, the feature may not be working properly. See Safety Locks on page 2‑12.


Chevrolet Cruze Owner Manual - 2012


Black plate (7,1)


Seat Adjustment


Manual Front Seats


Seat Height Adjuster


Seat Cushion Tilt Feature


In Brief


1-7


If available, move the lever up or down to manually raise or lower the seat.


Six-Way Manual Seat Shown,


Four-Way Similar


If available, move the lever up or down to raise or lower the front of the seat cushion.


To adjust a manual seat: 1. Pull the handle at the front of


the seat.


2. Slide the seat to the desired


position and release the handle.


3. Try to move the seat back


and forth to be sure it is locked in place.


Chevrolet Cruze Owner Manual - 2012


Black plate (8,1)


1-8


In Brief


Reclining Seatbacks


To recline the seatback: 1. Lift the lever. 2. Move the seatback to the


desired position, then release the lever to lock the seatback in place.


3. Push and pull on the seatback to


make sure it is locked.


To return the seatback to an upright position: 1. Lift the lever fully without applying pressure to the seatback, and the seatback returns to the upright position.


2. Push and pull on the seatback to


make sure it is locked.


See Reclining Seatbacks on page 3‑5. Power Driver Seat


To adjust a power driver seat, if equipped: . Move the seat forward or


rearward by sliding the control forward or rearward.


. Raise or lower the front part of the seat cushion by moving the front of the control up or down.


. Raise or lower the entire seat by moving the rear of the control up or down.


See Power Seat Adjustment on page 3‑4. Rear Seats The rear seatbacks can be folded. For detailed instructions, see Rear Seats on page 3‑8.


Chevrolet Cruze Owner Manual - 2012


Black plate (9,1)


Heated Seats


On vehicles with heated front seats, the controls are on the center console. The engine must be running to operate the heated seats.


Press L or M to heat the driver or passenger seat cushion and seatback. Press the control once for the highest setting. With each press of the control, the heated seat will change to the next lower setting,


and then the off setting. Three lights indicate the highest setting and one light the lowest. See Heated Front Seats on page 3‑7 for more information.


Head Restraint Adjustment Do not drive until the head restraints for all occupants are installed and adjusted properly. To achieve a comfortable seating position, change the seatback recline angle as little as necessary while keeping the seat and the head restraint height in the proper position. For more information see Head Restraints on page 3‑2 and Seat Adjustment on page 3‑3.


In Brief


1-9


Safety Belts


Refer to the following sections for important information on how to use safety belts properly: . Safety Belts on page 3‑10. . How to Wear Safety Belts


Properly on page 3‑11. Lap-Shoulder Belt on page 3‑12. Lower Anchors and Tethers for Children (LATCH System) on page 3‑41.


Chevrolet Cruze Owner Manual - 2012


Black plate (10,1)


1-10


In Brief


Passenger Sensing System


United States


Canada


The passenger sensing system turns off the front outboard passenger frontal airbag and knee airbag under certain conditions. No other airbag is affected by the passenger sensing system. See Passenger Sensing System on page 3‑26 for important information.


The passenger airbag status indicator will be visible on the instrument panel when the vehicle is started. See Passenger Airbag Status Indicator on page 5‑12.


Mirror Adjustment


Exterior


2. Move the control to adjust


the mirror.


3. Turn the selector switch to the


O position to deselect the mirror.


See Power Mirrors on page 2‑16. If the vehicle has heated mirrors, see Heated Mirrors on page 2‑16.


Controls for the outside power mirrors are on the driver door. 1. Turn the selector switch to


L (left) or R (right) to choose the driver or passenger mirror.


Vehicles with a manual mirror adjustment have controls next to each mirror. See Manual Mirrors on page 2‑16.


Chevrolet Cruze Owner Manual - 2012


Black plate (11,1)


Interior Adjust the inside rearview mirror by moving it up and down or side to side. Adjust the mirror to avoid glare from the headlamps behind you. Push the tab forward for daytime use and pull it for nighttime use. See Manual Rearview Mirror on page 2‑17. The vehicle may have an automatic dimming inside rearview mirror. Automatic dimming reduces the glare of lights from behind the vehicle. The dimming feature and indicator light come on each time the vehicle is started. See Automatic Dimming Rearview Mirror on page 2‑17.


Steering Wheel Adjustment


Interior Lighting


Dome Lamps


In Brief


1-11


To adjust the steering wheel: 1. Pull the lever (A) down. 2. Move the steering wheel up


or down.


3. Pull or push the steering wheel


closer or away from you.


4. Push the lever (A) up to lock the


steering wheel in place.


Do not adjust the steering wheel while driving.


The dome lamp controls are located in the headliner. ( : Press to turn the lamps off, even when a door is open. H : Press to turn the lamps on automatically when a door is opened. ' : Press to turn on the dome lamps.


Chevrolet Cruze Owner Manual - 2012


Black plate (12,1)


1-12


In Brief


Reading Lamps


Instrument Panel Illumination Control


Exterior Lighting


The reading lamps are located in the overhead console. # or $ : Press the button near each lamp to turn it on or off.


This feature controls the brightness of the instrument panel controls and infotainment display screen. The thumbwheel is located to the left of the steering column on the instrument panel. D (Instrument Panel Brightness): Turn the thumbwheel up or down and hold, to brighten or dim the instrument panel controls and infotainment display screen.


The exterior lamps control is located on the instrument panel to the outboard side of the steering column. O : Briefly turn to this position to turn the automatic light control off or on again. AUTO: Turns the headlamps on automatically at normal brightness, together with the parking lamps, taillamps, license plate lamps, sidemarker lamps, and instrument panel lights.


Chevrolet Cruze Owner Manual - 2012


Black plate (13,1)


; : Turns on the parking lamps, taillamps, license plate lamps, sidemarker lamps, and instrument panel lights. 5 : Turns on the headlamps, parking lamps, taillamps, license plate lamps, sidemarker lamps, and instrument panel lights. A warning chime sounds if the driver door is opened when the ignition switch is off and the headlamps are on. # : For vehicles with fog lamps, press to turn the lamps on or off. For more information, see: . Exterior Lamp Controls on


page 6‑1.


. Daytime Running Lamps (DRL)


on page 6‑2. Front Fog Lamps on page 6‑4.


Windshield Wiper/Washer


In Brief


1-13


The windshield wiper lever is on the side of the steering column. With the ignition in ACC/ACCESSORY or ON/RUN, move the windshield wiper lever to select the wiper speed. 2: Fast wipes. 1: Slow wipes.


3 : Turn the band up for more frequent wipes or down for less frequent wipes. 9 : Turns the windshield wipers off. 3 : Briefly move the wiper lever down for a single wipe or hold down for several wipes. Windshield Washer Pull the windshield wiper lever to spray windshield washer fluid and activate the wipers. See Windshield Wiper/Washer on page 5‑3.


Chevrolet Cruze Owner Manual - 2012


Black plate (14,1)


1-14


In Brief


Climate Controls The heating, cooling, defrosting, and ventilation for the vehicle can be controlled with these systems.


Vehicles without Air Conditioning


G. Rear Window Defogger H. Defog I. Defrost


Vehicles with Air Conditioning


G. Rear Window Defogger H. Recirculation I. Defog J. Air Conditioning K. Defrost


Automatic Climate Control System


A. Temperature Control B. Bi-level Air Mode C. Floor Air Mode D. Vent Air Mode E. Fan Control F. Driver and Passenger Heated


Seats (If Equipped)


A. Temperature Control B. Bi-level Air Mode C. Floor Air Mode D. Vent Air Mode E. Fan Control F. Driver and Passenger Heated


Seats (If Equipped)


A. Temperature Control B. Rear Window Defogger C. AUTO (Automatic Operation) D. Defrost E. Fan Control


Chevrolet Cruze Owner Manual - 2012


Black plate (15,1)


F. Driver and Passenger Heated


Seats (If Equipped)


G. Power H. Recirculation I. MODE (Air Delivery Mode) J. AQS (Air Quality Sensor) K. Air Conditioning See Climate Control Systems on page 8‑1 or Automatic Climate Control System on page 8‑3
(If Equipped).


Transmission


Vehicle Features


In Brief


1-15


Manual Mode Driver Shift Control (DSC) allows the automatic transmission to be shifted similar to a manual transmission. Electronic Range Select (ERS) allows for the selection of a range of gears. See Manual Mode on page 9‑31. Up‐Shift Light


If the vehicle has a manual transmission, it will have an up-shift light that indicates when to shift to the next higher gear for the best fuel economy. See Manual Transmission on page 9‑33.


Radio(s) O : Press to turn the system on and off. Turn to increase or decrease the volume. BAND: Press to choose between FM, AM, or XM™, if equipped. MENU: Turn to select radio stations. Press to select a menu. g : Press to seek the previous station or track. l : Press to seek the next station or track. Buttons 1 to 6: Press to save and select favorite stations. INFO: Press to show available information about the current station or track. For more information about these and other radio features, see Operation on page 7‑6.


Chevrolet Cruze Owner Manual - 2012


Black plate (16,1)


1-16


In Brief


Storing a Favorite Station Stations from all bands can be stored in the favorite lists in any order. Up to six stations can be stored in each favorite page and the number of available favorite pages can be set. To store the station to a position in the list, press the corresponding numeric button 1 to 6 until a beep is heard. For more information, see “Storing a Station as a Favorite” in AM-FM Radio on page 7‑12. Setting the Clock


Adjusting the Time The clock menu can be only be used with the radio on while in ON/ RUN or ACC/ACCESSORY. 1. Press the CONFIG button and


select Time Settings.


2. Select Set Time. 3. Turn the MENU knob to adjust


the highlighted number.


XM Satellite Radio Service XM is a satellite radio service based in the 48 contiguous United States and 10 Canadian provinces. XM satellite radio has a wide variety of programming and commercial-free music, coast to coast, and in digital-quality sound. A fee is required to receive the XM service. For more information refer to: . www.xmradio.com or call


1-800-929-2100 (U.S.). . www.xmradio.ca or call


1-877-438-9677 (Canada).


For more information, see Satellite Radio on page 7‑14.


4. Press the MENU knob to select


the next number.


5. To save the time and return to the Time Settings menu, press the BACK button at any time or press the MENU knob after adjusting the minutes.


Setting the 12/24 Hour Format 1. Press the CONFIG button and


select Time Settings.


2. Highlight 12/24 Hour Format. 3. Press the MENU knob to select


the 12 hour or 24 hour display format.


See Clock on page 5‑5.


Satellite Radio Vehicles with an XM™ sxatellite radio tuner and a valid XM satellite radio subscription can receive XM programming.


Chevrolet Cruze Owner Manual - 2012


Black plate (17,1)


In Brief


1-17


$ / i : Press to silence the vehicle speakers only. Press again to turn the sound on. For vehicles with OnStar or Bluetooth systems, press to reject an incoming call, or to end a current call. _ SRC ^ : Turn _ or ^ to select a radio band or audio source. Press _ or ^ to select the next or previous favorite radio station, CD, or MP3 track. Press SRC to change between radio and CD or DVD.


+ x −: Press + to increase or − to decrease the volume. For more information, see Steering Wheel Controls on page 5‑2.


Portable Audio Devices Some vehicles have a 3.5 mm (1/8 in) auxiliary input and a USB port located in the center console. External devices such as iPods®, laptop computers, MP3 players, CD changers, and USB storage devices may be connected, depending on the audio system. For more information, see Auxiliary Devices on page 7‑20.


Bluetooth® The Bluetooth system allows users with a Bluetooth-enabled cell phone to make and receive hands-free calls using the vehicle audio system, microphone, and controls. The Bluetooth-enabled cell phone must be paired with the in-vehicle Bluetooth system before it can be used in the vehicle. Not all phones will support all functions.


See Bluetooth (Overview) on page 7‑23 or Bluetooth (Infotainment Controls) on page 7‑25 or Bluetooth (Voice Recognition) on page 7‑29.


Steering Wheel Controls


For vehicles with audio steering wheel controls, some audio controls can be adjusted at the steering wheel. b / g : Press to interact with the available Bluetooth, OnStar, or navigation system.


Chevrolet Cruze Owner Manual - 2012


Black plate (18,1)


1-18


In Brief


Cruise Control


For vehicles with cruise control: 1 : Press to turn the cruise control system on and off. RES/+ : Move the thumbwheel up to resume a previously set speed or to accelerate. SET/− : Move the thumbwheel down to set a speed or to make the vehicle decelerate.


* : Press to disengage cruise control without erasing the set speed from memory. See Cruise Control on page 9‑40.


Navigation System If the vehicle has a navigation system, there is a separate navigation system manual that includes information on the radio, audio players, and navigation system. The navigation system provides detailed maps of most major freeways and roads. After a destination has been set, the system provides turn-by-turn instructions for reaching the destination. In addition, the system can help locate a variety of points of interest (POIs), such as banks, airports, restaurants, and more. See the navigation system manual for more information.


Driver Information Center (DIC) The DIC display is located in the center of the instrument panel cluster. It shows the status of many vehicle systems. The controls for the DIC are located on the turn signal lever.


A. SET/CLR: Press to set or clear


the menu item when it is displayed.


B. w x: Use the thumbwheel to


scroll through the items in each menu.


Chevrolet Cruze Owner Manual - 2012


Black plate (19,1)


Power Outlets The accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. There is one accessory power outlet located on the center floor console and one on the rear of the center floor console. These outlets are powered when the key is in ON/ RUN or ACC/ACCESSORY, or until the driver door is opened within 10 minutes of turning off the vehicle. See Retained Accessory Power (RAP) on page 9‑23. See Power Outlets on page 5‑5.


C. MENU: Press to display the


Trip/Fuel menu and the Vehicle Information menu. This button is also used to return to or exit the last screen displayed on the DIC.


For more information, see Driver Information Center (DIC) on page 5‑23.


Ultrasonic Parking Assist If available, Ultrasonic Rear Parking Assist (URPA) uses sensors on the rear bumper to detect objects while parking the vehicle. It operates at speeds less than 8 km/h (5 mph). URPA uses audible beeps to provide distance and system information. Keep the sensors on the vehicle's rear bumper clean to ensure proper operation. See Ultrasonic Parking Assist on page 9‑42 for more information.


In Brief


1-19


Performance and Maintenance


Traction Control System (TCS) The traction control system limits wheel spin. The system is on when the vehicle is started.


To turn off traction control, press and release g located on the console. i illuminates and the appropriate DIC message displays. See Vehicle Messages (Canada Base Level) on page 5‑28 or Vehicle Messages (Canada Uplevel and United States) on page 5‑28.


. Press and release g again to turn traction control back on.


For more information, see Traction Control System (TCS) on page 9‑37.


Chevrolet Cruze Owner Manual - 2012


Black plate (20,1)


1-20


In Brief


StabiliTrak® System The StabiliTrak system assists with directional control of the vehicle in difficult driving conditions. The system is on when the vehicle is started.


To turn off both Traction Control and StabiliTrak, press and hold g until g and i illuminate and the appropriate DIC message displays. See Vehicle Messages (Canada Base Level) on page 5‑28 or Vehicle Messages (Canada Uplevel and United States) on page 5‑28. . Press g again to turn on both


systems.


For more information, see StabiliTrak® System on page 9‑38.


Tire Pressure Monitor This vehicle may have a Tire Pressure Monitor System (TPMS).


The TPMS warning light alerts you to a significant loss in pressure of one of the vehicle's tires. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and Loading Information label. See Vehicle Load Limits on page 9‑10. The warning light will remain on until the tire pressure is corrected. During cooler conditions, the low tire pressure warning light may appear when the vehicle is first started and then turn off. This may be an early


indicator that the tire pressures are getting low and the tires need to be inflated to the proper pressure. The TPMS does not replace normal monthly tire maintenance. It is the driver’s responsibility to maintain correct tire pressures. See Tire Pressure Monitor System on page 10‑50.


Tire Sealant and Compressor Kit This vehicle may come with a spare tire and tire changing equipment or a tire sealant and compressor kit. The kit can be used to temporarily seal small punctures in the tread area of the tire. See Tire Sealant and Compressor Kit on page 10‑65 for complete operating information. If the vehicle came with a spare tire and tire changing equipment, see If a Tire Goes Flat on page 10‑63.


Chevrolet Cruze Owner Manual - 2012


Black plate (21,1)


Engine Oil Life System The engine oil life system calculates engine oil life based on vehicle use and displays the CHANGE ENGINE OIL SOON DIC message or Code 82 DIC message when it is necessary to change the engine oil and filter. Remember, the Oil Life display must be reset after each oil change. It will not reset itself. Also, be careful not to reset the Oil Life display accidentally at break="2" any time other than when the oil has just been changed. It cannot be reset accurately until the next oil change. To reset the engine oil life system press the SET button while the Oil Life display is active.


Resetting the Oil Life System 1. Using the DIC MENU button and


thumbwheel, scroll until you reach REMAINING OIL LIFE on the DIC (oil can symbol with % sign for Canada).


2. Press the SET button to reset


the oil life at 100%. When prompted, use the thumbwheel to highlight YES or NO. Press the SET/CLEAR button to confirm.


Be careful not to reset the oil life display accidentally at any time other than after the oil is changed. It cannot be reset accurately. See Engine Oil Life System on page 10‑12.


Driving for Better Fuel Economy Driving habits can affect fuel mileage. Here are some driving tips to get the best fuel economy possible. . Avoid fast starts and accelerate


smoothly.


. Brake gradually and avoid


abrupt stops.


In Brief


1-21


. Avoid idling the engine for long


periods of time.


. When road and weather


conditions are appropriate, use cruise control.


. Always follow posted speed


limits or drive more slowly when conditions require.


. Keep vehicle tires properly


inflated.


. Combine several trips into a


single trip.


. Replace the vehicle's tires with


the same TPC Spec number molded into the tire's sidewall near the size. Follow recommended scheduled maintenance.


Chevrolet Cruze Owner Manual - 2012


Black plate (22,1)


1-22


In Brief


Roadside Assistance Program U.S.: 1-800-243-8872
TTY Users: 1-888-889-2438
Canada: 1-800-268-6800
As the owner of a new Chevrolet, you are automatically enrolled in the Roadside Assistance program. See Roadside Assistance Program on page 13‑6 for more information.


Roadside Assistance and OnStar If you have an active OnStar subscription, press the Q button and the current GPS location will be sent to an OnStar advisor who will assess your problem, contact Roadside Assistance, and relay your exact location to get the help you need.


Online Owner Center The Online Owner Center is a complimentary service that includes online service reminders, vehicle maintenance tips, online owner manual, special privileges, and more. Sign up today at: www.chevyownercenter.com (U.S.) or www.gm.ca (Canada).


OnStar®


For vehicles with an active OnStar subscription, OnStar uses several innovative technologies and live Advisors to provide a wide range of safety, security, navigation, diagnostics, and calling services.


Automatic Crash Response In a crash, built‐in sensors automatically alert an OnStar Advisor who is immediately connected to the vehicle to see if you need help. How OnStar Service Works Q : Push this blue button to connect to a specially trained OnStar Advisor to verify your account information and to answer questions. ] : Push this red emergency button to get priority help from specially trained OnStar Emergency Advisors. X : Push this button for hands‐free, voice‐activated calling and to give voice commands for Hands‐Free Calling and Turn‐by‐Turn Navigation.


Chevrolet Cruze Owner Manual - 2012


Black plate (23,1)


Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Vehicle Diagnostics, Remote Door Unlock, Roadside Assistance, Turn‐by‐Turn Navigation, and Hands‐Free Calling are available on most vehicles. Not all OnStar services are available on all vehicles. For more information, see the OnStar Owner's Guide; visit www.onstar.com (U.S.) or www.onstar.ca (Canada); contact OnStar at 1-888-4-ONSTAR (1‐888‐466‐7827) or TTY 1‐877‐248‐2080; or push the Q button to speak with an OnStar Advisor 24 hours a day, seven days a week. For a full description of OnStar services and system limitations, see the OnStar Owner's Guide in the glove box.


OnStar service is subject to the OnStar Terms and Conditions included in the OnStar Glove Box Kit. OnStar service requires wireless communication networks and the Global Positioning System (GPS) satellite network. Not all OnStar services are available everywhere or on all vehicles at all times. OnStar service cannot work unless the vehicle is in a place where OnStar has an agreement with a wireless service provider for service in that area, and the wireless service provider has coverage, network capacity, reception, and technology compatible with OnStar's service. Service involving location information about the vehicle cannot work unless GPS signals are available, unobstructed, and compatible with the OnStar hardware. The vehicle must have a working electrical system and adequate battery power for the OnStar equipment to operate.


In Brief


1-23


OnStar service may not work if the OnStar equipment is not properly installed or you have not maintained it even if the vehicle is in good working order and in compliance with all government regulations. If you try to add, connect, or modify any equipment or software in the vehicle, OnStar service may not work. Other problems beyond OnStar's control may prevent service to you, such as hills, tall buildings, tunnels, weather, electrical system design and architecture of the vehicle, damage to important parts of the vehicle in a crash, or wireless phone network congestion or jamming. See Radio Frequency Statement on page 13‑16 for information regarding Part 15 of the Federal Communications Commission (FCC) rules and Industry Canada Standards RSS-GEN/210/220/310.


Chevrolet Cruze Owner Manual - 2012


Black plate (24,1)


1-24


In Brief


OnStar Steering Wheel Controls This vehicle may have Talk/Mute buttons that can be used to interact with OnStar Hands-Free calling. See Steering Wheel Controls on page 5‑2 for more information. On some vehicles, the Talk/Mute buttons can be used to dial phone extensions. See the OnStar Owner's Guide for more information.


Your Responsibility Increase the volume of the radio if the OnStar Advisor cannot be heard. If the light next to the OnStar buttons is red, the system may not be functioning properly. Push Q and request a vehicle diagnostic. If the light appears clear (no light appears), your OnStar subscription has expired and all services have been deactivated. Push Q to confirm that the OnStar equipment is active.


Chevrolet Cruze Owner Manual - 2012


Black plate (1,1)


Keys, Doors, and Windows


Keys and Locks


Keys . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Remote Keyless Entry (RKE)


System . . . . . . . . . . . . . . . . . . . . . . 2-3


Remote Keyless Entry (RKE)


System Operation . . . . . . . . . . . 2-3
Remote Vehicle Start . . . . . . . . . 2-9
Door Locks . . . . . . . . . . . . . . . . . . 2-10
Power Door Locks . . . . . . . . . . . 2-11
Automatic Door Locks . . . . . . . 2-11
Safety Locks . . . . . . . . . . . . . . . . . 2-12


Keys, Doors, and Windows


2-1


Doors


Trunk . . . . . . . . . . . . . . . . . . . . . . . . 2-12


Vehicle Security


Vehicle Security . . . . . . . . . . . . . . 2-14
Vehicle Alarm System . . . . . . . 2-14
Immobilizer . . . . . . . . . . . . . . . . . . 2-14
Immobilizer Operation . . . . . . . 2-14


Exterior Mirrors


Convex Mirrors . . . . . . . . . . . . . . 2-15
Manual Mirrors . . . . . . . . . . . . . . . 2-16
Power Mirrors . . . . . . . . . . . . . . . . 2-16
Folding Mirrors . . . . . . . . . . . . . . . 2-16
Heated Mirrors . . . . . . . . . . . . . . . 2-16


Interior Mirrors


Manual Rearview Mirror . . . . . . 2-17
Automatic Dimming


Rearview Mirror . . . . . . . . . . . . 2-17


Windows


Windows . . . . . . . . . . . . . . . . . . . . . 2-18
Power Windows . . . . . . . . . . . . . 2-18
Sun Visors . . . . . . . . . . . . . . . . . . . 2-20


Roof


Sunroof . . . . . . . . . . . . . . . . . . . . . . 2-21


Chevrolet Cruze Owner Manual - 2012


Black plate (2,1)


2-2


Keys, Doors, and Windows


Keys and Locks


Keys


{ WARNING


Leaving children in a vehicle with the ignition key is dangerous for many reasons. Children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keys in the ignition and children could be seriously injured or killed if caught in the path of a closing window. Do not leave the keys in a vehicle with children.


{ WARNING


Leaving children in a vehicle with the Remote Keyless Entry (RKE) transmitter is dangerous for many reasons; children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the RKE transmitter in the vehicle and they could be seriously injured or killed if caught in the path of a closing window. Do not leave the RKE transmitter in a vehicle with children.


The key that is part of the Remote Keyless Entry (RKE) transmitter can be used for the ignition and all locks if the vehicle is a key access vehicle. If the vehicle has the keyless ignition, the key can be used for the locks.


Chevrolet Cruze Owner Manual - 2012


Black plate (3,1)


Keys, Doors, and Windows


2-3


With an active OnStar subscription, an OnStar Advisor may remotely unlock the vehicle. See OnStar® on page 1‑22.


Remote Keyless Entry (RKE) System See Radio Frequency Statement on page 13‑16 for information regarding Part 15 of the Federal Communications Commission (FCC) rules and Industry Canada Standards RSS-GEN/210/220/310. If there is a decrease in the RKE operating range: . Check the distance. The


transmitter may be too far from the vehicle.


. Check the location. Other vehicles or objects may be blocking the signal.


. Check the transmitter's battery.


See “Battery Replacement” later in this section. If the transmitter is still not working correctly, see your dealer or a qualified technician for service.


Remote Keyless Entry (RKE) System Operation The transmitter functions will work up to 20 m (65 ft) away from the vehicle. On vehicles with remote start the distance will be greater. Keep in mind that other conditions, such as those previously stated, can impact the performance of the transmitter.


Press the button on the RKE transmitter to extend the key. Press the button and the key blade to retract the key. See your dealer if a new key is needed. Notice: If the keys get locked in the vehicle, it may have to be damaged to get them out. Always carry a spare key. If locked out of the vehicle, see Roadside Assistance Program on page 13‑6.


Chevrolet Cruze Owner Manual - 2012


Black plate (4,1)


2-4


Keys, Doors, and Windows


Pressing Q may also arm the theft-deterrent system. See Vehicle Alarm System on page 2‑14. K (Unlock): Press to unlock the driver door or all doors. See “Door Unlock Options” under Vehicle Personalization on page 5‑34. The turn signal indicators may flash and/or the horn may sound to indicate unlocking. See “Unlock Feedback” under Vehicle Personalization on page 5‑34. Pressing K will disarm the theft-deterrent system. See Vehicle Alarm System on page 2‑14. V (Remote Trunk Release): Press and hold briefly to open the trunk. 7 (Vehicle Locator/Panic Alarm): Press and hold briefly to locate the vehicle. The exterior lamps flash and the horn chirps. Press and hold 7 for at least two seconds to sound the panic alarm. The horn sounds and the


turn signals flash for 30 seconds, or until 7 is pressed again or the vehicle is started. / (Remote Vehicle Start): For vehicles with this feature, press Q and then press and hold / within five seconds to start the engine from outside the vehicle using the RKE transmitter. See Remote Vehicle Start on page 2‑9 for additional information. The buttons on the keys are disabled when there is a key is in the ignition, if equipped. Keyless Access Operation Some vehicles have a keyless access system that lets you lock and unlock the doors and access the trunk without removing the RKE transmitter from your pocket, purse, briefcase, etc. The RKE transmitter should be within 1 m (3 ft) of the door or trunk being opened. If the vehicle has this feature, there will be a body colored touch pad on the outside front door handles.


Q (Lock): Press to lock all doors. The turn signal indicators may flash and/or the horn may sound to indicate locking. See “Locking Feedback” under Vehicle Personalization on page 5‑34. If the driver door is open when Q is pressed, all doors lock except the driver door, if enabled through the vehicle personalization. If the passenger door is open when Q is pressed, all doors lock.


Chevrolet Cruze Owner Manual - 2012


Black plate (5,1)


Keys, Doors, and Windows


2-5


Keyless Unlocking With the RKE transmitter within 1 m (3 ft), approach the front door and pull the handle to unlock and open the door. If the transmitter is recognized, the door will unlock and open. Entering any door other than the driver door will always cause all of the doors to unlock. This is not customizable. To customize which doors unlock when the driver door is opened, see “Door Unlock Options” under Vehicle Personalization on page 5‑34.


Keyless Locking If the vehicle has the keyless access system, this feature allows you to select whether the doors automatically lock during normal vehicle exit. When the vehicle is turned off and all doors become closed, the vehicle will determine how many keyless access transmitters remain in the vehicles interior. If at least one keyless access transmitter has been removed from the interior of the vehicle, the doors will lock after eight seconds. If there are two keyless access transmitters in the vehicle and one is removed, the other will be locked in. A person approaching the outside of the locked vehicle without an authorized keyless access transmitter will not be able to open the door, even with the transmitter in the vehicle.


Lock Sensor


When all doors are closed and the ignition is off, the vehicle can be locked by pressing this area on the door handle. This feature will be available for several minutes after the vehicle has been turned off.


Keyless Trunk Opening Lift up on the touch pad located above the license plate to open the trunk if the RKE transmitter is within range.


Chevrolet Cruze Owner Manual - 2012


Black plate (6,1)


2-6


Keys, Doors, and Windows


Programming Transmitters to the Vehicle Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed through your dealer. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Any remaining transmitters will need to be reprogrammed. Each vehicle can have up to five transmitters matched to it.


Programming with a Recognized Transmitter (Keyless Access Vehicles Only) A new transmitter can be programmed to the vehicle when there is one recognized transmitter. To program, the vehicle must be off and all of the transmitters, both currently recognized and new, must be with you.


1. Remove the plastic trim piece


from the small storage area next to the accessory power outlet towards the front of the console, to access the transmitter slot. Push the button on the recognized transmitter to extend the key blade. Insert the key blade into the transmitter slot. Insert the vehicle key of the new transmitter into the key lock cylinder located on the outside of the driver door and turn the key to the unlock position five times within 10 seconds.


2.


The Driver Information Center (DIC) displays READY FOR REMOTE #2, 3, 4 or 5.


3. Remove the recognized key and


place the new transmitter into the transmitter slot.


4. Press the ignition. When the


transmitter is learned, the DIC will show that it is ready to program the next transmitter.


5. Remove the transmitter from the transmitter pocket and press K. To program additional transmitters, repeat Steps 3
through 5. When all additional transmitters are programmed, press and hold the ignition for 10 seconds to exit programming mode. Replace the plastic trim piece from the small storage area.


Chevrolet Cruze Owner Manual - 2012


Black plate (7,1)


Keys, Doors, and Windows


2-7


The DIC displays will again show REMOTE LEARN PENDING, PLEASE WAIT.


3. Repeat Step 2 two additional times. After the third time all previously known transmitters will no longer work with the vehicle. Remaining transmitters can be relearned during the next steps. The DIC display should now show READY FOR REMOTE # 1.


Programming without a Recognized Transmitter (Keyless Access Vehicles Only) If there are no currently recognized transmitters available, follow this procedure to program up to five transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters you wish to program must be with you. 1.


Insert the vehicle key of the transmitter into the key lock cylinder located on the outside of the driver door and turn the key to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays REMOTE LEARN PENDING, PLEASE WAIT. 2. Wait for 10 minutes until the


DIC displays PRESS ENGINE START BUTTON TO LEARN and then press the ignition.


4. Remove the plastic trim piece


from the small storage area next to the accessory power outlet towards the front of the console, to access the transmitter slot. Push the button on the recognized transmitter to extend the key blade. Insert the key blade into the transmitter slot.


5. Press the ignition. When the transmitter is learned the DIC will show that it is ready to program the next transmitter.


6. Remove the transmitter from the


transmitter slot and press K. To program additional transmitters, repeat Steps 4
through 6. When all additional transmitters are programmed, press and hold the ignition for 10 seconds to exit programming mode. Replace the plastic trim piece from the small storage area.


Chevrolet Cruze Owner Manual - 2012


Black plate (8,1)


2-8


Keys, Doors, and Windows


Starting the Vehicle with a Low Transmitter Battery If the transmitter battery is weak, the DIC may display NO REMOTE DETECTED when you try to start the vehicle. The REPLACE BATTERY IN REMOTE KEY message may also be displayed at this time.


Battery Replacement Replace the battery if the REPLACE BATTERY IN REMOTE KEY message displays in the DIC. See “Replace Battery in Remote Key” under Key and Lock Messages on page 5‑31. The battery is not rechargeable. To replace the battery: 1. Push the button on the


transmitter to extend the key blade.


To start the vehicle: 1. Remove the plastic trim piece


from the small storage area next to the accessory power outlet towards the front of the console, to access the transmitter slot.


2. Push the button on the


recognized transmitter to extend the key blade. Insert the key blade into the transmitter slot. 3. With the vehicle in P (Park) or


N (Neutral), press the brake pedal and the ignition button. See Starting the Engine on page 9‑20 for additional information about the vehicle's keyless ignition with pushbutton start. Replace the transmitter battery as soon as possible.


2. Remove the battery cover by


prying it with a finger.


Chevrolet Cruze Owner Manual - 2012


Black plate (9,1)


Keys, Doors, and Windows


2-9


3. Remove the battery by pushing


4.


on the battery and sliding it toward the key blade. Insert the new battery, positive side facing up. Push the battery down until it is held in place. Replace with a CR2032 or equivalent battery.


5. Snap the battery cover back on


to the transmitter.


Remote Vehicle Start The vehicle may have this feature that allows you to start the engine from outside the vehicle. / (Remote Vehicle Start): This button will be on the RKE transmitter if the vehicle has remote start. Vehicles with an automatic climate control system will default to a heating or cooling mode depending on the outside temperature during a remote start. A vehicle without automatic climate control will default to the last used heating or


cooling mode. Once the key is turned to ON/RUN, the climate control system will turn on at the setting the vehicle was last set to. If the vehicle has heated seats, they may come on during a remote start. See Heated Front Seats on page 3‑7 for more information. Laws in some local communities may restrict the use of remote starters. For example, some laws require a person using remote start to have the vehicle in view. Check local regulations for any requirements. There are other conditions which can affect the performance of the transmitter. See Remote Keyless Entry (RKE) System on page 2‑3 for additional information.


Starting the Vehicle To start the engine using the remote start feature: 1. Aim the RKE transmitter at


the vehicle.


2. Press and release Q.


3.


Immediately after completing Step 2, press and hold / until the turn signal lamps flash, or for about two seconds if the vehicle is not in view.


When the engine starts, the parking lamps will turn on and remain on as long as the engine is running. The doors will be locked and the climate control system may come on. The engine will continue to run for 10 minutes. Repeat the steps for a 10-minute time extension. Remote start can be extended only once. Insert the key and turn it to ON/RUN before driving.


Extending Engine Run Time For a 10-minute extension, repeat Steps 1 through 3 while the engine is still running. The remote start can be extended once. When the remote start is extended, the second 10 minutes will start immediately.


Chevrolet Cruze Owner Manual - 2012


Black plate (10,1)


2-10


Keys, Doors, and Windows


For example, if the engine has been running for five minutes, and 10 minutes are added, the engine will run for a total of 15 minutes. A maximum of two remote starts, or a single start with an extension, are allowed between ignition cycles. After this, the vehicle's ignition switch must be turned to ON/RUN and then back to LOCK/OFF using the key, before the remote start procedure can be used again.


Loading...
x
