08 Maintenance and specifications

Washing the car The following points should be kept in mind when washing and cleaning the car: • The car should be washed at regular inter- vals since dirt, dust, insects and tar spots adhere to the paint and may cause dam- age. To help prevent corrosion, it is partic- ularly important to wash the car frequently in the wintertime.

• Avoid washing your car in direct sunlight. Doing so may cause detergents and wax to dry out and become abrasive. To avoid scratching, use lukewarm water to soften the dirt before you wash with a soft sponge, and plenty of sudsy water.

• Bird droppings: Remove from paintwork as soon as possible. Otherwise the finish may be permanently damaged.

• A detergent can be used to facilitate the

softening of dirt and oil.

• Dry the car with a clean chamois and

remember to clean the drain holes in the doors and rocker panels.

• Tar spots can be removed with tar remover

after the car has been washed.

• A stiff-bristle brush and lukewarm soapy

water can be used to clean the wiper blades. Frequent cleaning of the wind- shield and wiper blades improves visibility

considerably and also helps prolong the service life of the wiper blades.

• Wash off the dirt from the underside (wheel

housings, fenders, etc).

• In areas of high industrial fallout, more fre-

quent washing is recommended.

NOTE

When washing the car, remember to remove dirt from the drain holes in the doors and sills.

CAUTION

• During high pressure washing, the

spray mouthpiece must never be closer to the vehicle than 13" (30 cm). Do not spray into the locks.

• Dirt, snow, etc., on the headlights can reduce lighting capacity considerably. Clean the headlights regularly, for example when refueling. Special moonroof cautions: • Always close the moonroof and sun shade before washing your vehicle.

• Never use abrasive cleaning agents on

the moonroof.

• Never use wax on the rubber seals

around the moonroof.

Vehicle care

Exterior components Volvo recommends the use of special cleaning products, available at your Volvo retailer, for cleaning colored plastic, rubber, or ornamental components such as chromed strips on the exterior of your vehicle. The instructions for using these products should be followed care- fully. Solvents or stain removers should not be used.

CAUTION

• Avoid waxing or polishing plastic or rub-

ber components

• Polishing chromed strips can wear

away or damage the surface

• Polishes containing abrasive sub-

stances should not be used

Automatic car wash • We do NOT recommend washing your car in an automatic wash during the first few months (because the paint will not have hardened sufficiently).

• An automatic wash is a simple and quick

way to clean your car, but it is worth remembering that it may not be as thor- ough as when you yourself go over the car with sponge and water. Keeping the under- body clean is most important, especially in the winter. Some automatic washers do

08

``

313

08 Maintenance and specifications

Vehicle care

not have facilities for washing the under- body.

CAUTION

• Before driving into an automatic car

wash, turn off the optional rain sensor to avoid damaging the windshield wipers. • Make sure that side view mirrors, auxil- iary lamps, etc, are secure, and that any antenna(s) are retracted or removed. Otherwise there is risk of the machine dislodging them.

• Chromed wheels: Clean chrome-

plated wheels using the same deter- gents used for the body of the vehicle. Aggressive wheel-cleaning agents can permanently stain chrome-plated wheels.

WARNING

• When the vehicle is driven immediately after being washed, apply the brakes, including the parking brake, several times in order to remove any moisture from the brake linings.

• Engine cleaning agents should not be

used when the engine is warm. This constitutes a fire risk.

Exterior lighting Condensation may form temporarily on the inside of the lenses of exterior lights such as headlights, fog lights, or taillights. This is nor- mal and the lights are designed to withstand moisture. Normally, condensation will dissi- pate after the lights have been on for a short time.

Polishing and waxing • Normally, polishing is not required during the first year after delivery, however, wax- ing may be beneficial.

• Before applying polish or wax the vehicle must be washed and dried. Tar spots can be removed with kerosene or tar remover. Difficult spots may require a fine rubbing compound.

• After polishing use liquid or paste wax. • Several commercially available products

contain both polish and wax.

• Waxing alone does not substitute for pol-

ishing a dull surface.

• A wide range of polymer-based waxes can be purchased today. These waxes are easy to use and produce a long-lasting, high- gloss finish that protects the bodywork against oxidation, road dirt and fading.

• Do not polish or wax your vehicle in direct sunlight (the surface of the vehicle should not be warmer than 113 °F (45 °C).

CAUTION

Volvo does not recommend the use of long- life or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc. These coatings have not been tested by Volvo for compatibility with your vehicle's clear coat. Some of them may cause the clear coat to soften, crack, or cloud. Damage caused by application of paint protection coatings may not be cov- ered under your vehicle's paint warranty.

Cleaning the interior Only use cleaning agents and car care prod- ucts recommended by Volvo. Clean regularly and follow the instructions included with the car care product.

Upholstery care Fabric Clean with soapy water or a detergent. For more difficult spots caused by oil, ice cream, shoe polish, grease, etc., use a clothing/fabric stain remover. Consult your Volvo retailer. AlcanteraTM suede-like material Suede-like upholstery can be cleaned with a soft cloth and mild soap solution.

08

314

08 Maintenance and specifications

3. Dampen the stain thoroughly with the

sponge. Let the sponge absorb the stain, do not rub.

4. Dry the stain with soft paper towels or a towel, and allow the leather to dry com- pletely.

Protecting leather upholstery 1. Put a small amount of protectant cream on a cloth and apply a thin coating of cream to the upholstery with light circular move- ments.

2. Allow the leather to dry for 20 minutes. This will help the leather resist staining and protect against sunlight's harmful UV rays.

Leather care Volvo's leather upholstery is manufactured with a protectant to repel soiling. Over time, sunlight, grease and dirt can break down the protection. Staining, cracking, scuffing, and fading can result. Volvo offers an easy-to-use, non-greasy leather care kit formulated to clean and beau- tify your vehicle's leather, and to renew the protective qualities of its finish. The cleaner removes dirt and oil buildup. The light cream protectant restores a barrier against soil and sunlight. Volvo also offers a special leather softener that should be applied after the cleaner and pro- tectant. It leaves leather soft and smooth, and reduces friction between leather and other fin- ishes in the vehicle. Volvo recommends cleaning, protecting and conditioning your vehicle's leather two to four times a year. Ask your Volvo retailer about Leather Care Kit 951 0251 and Leather Soft- ener 943 7429. Cleaning leather upholstery 1. Pour leather cleaner on a damp sponge and squeeze it until the cleaner foams.

2. Apply the foam to the stain by moving the

sponge with circular movements.

Vehicle care

CAUTION

• Under no circumstances should gaso- line, naphtha or similar cleaning agents be used on the plastic or the leather since these can cause damage.

• Take extra care when removing stains such as ink or lipstick since the coloring can spread.

• Use solvents sparingly. Too much sol-

vent can damage the seat padding.

• Start from the outside of the stain and

work toward the center.

• Sharp objects (e.g. pencils or pens in a pocket) or Velcro fasteners on clothing may damage the textile upholstery.

• Clothing that is not colorfast, such as

new jeans or suede garments, may stain the upholstery.

Cleaning the seat belts Clean only with lukewarm water and a mild soap solution.

Cleaning floor mats The floor mats should be vacuumed or brushed clean regularly, especially during winter when they should be taken out for drying. Spots on textile mats can be removed with a mild deter- gent. For best protection in winter, Volvo rec-

08

``

315

08 Maintenance and specifications

Vehicle care

ommends the use of Volvo rubber floor mats. Consult your Volvo retailer.

Spots on interior plastic, metal, or wood surfaces Cleaning interior plastic components should be done with a cleaning agent specially designed for this purpose. Consult your Volvo retailer.

Touching up paintwork

Paint code on the model plate1
Paint damage requires immediate attention to avoid rusting. Make it a habit to check the finish regularly, for instance washing the vehicle. Touch-up if necessary.

1 see page 320 for the location of the model plate.

08

316

Paint repairs require special equipment and skill. Contact your Volvo retailer for any exten- sive damage. Minor scratches can be repaired by using Volvo touch-up paint.

Color code Make sure you have the right color. The color code number is stated on the model plate.

Minor stone chips and scratches Material: • Primer – can • Paint – touch-up pen • Brush • Masking tape If the stone chip has not gone down to the bare metal and an undamaged color coat remains, you can add paint immediately after removing dirt.

NOTE

When touching up the vehicle, it should be clean and dry. The surface temperature should be above 60 °F (15 °C).

Minor scratches on the surface If the stone chip has not penetrated down to the metal and an undamaged layer of paint remains, the touch-up paint can be applied as soon as the spot has been cleaned.

Repairing stone chips

1. Place a strip of masking tape over the dam- aged surface. Pull the tape off so that any loose flakes of paint adhere to it.

2. Thoroughly mix the primer and apply it with

a small brush.

3. When the primer surface is dry, the paint

can be applied using a brush. Mix the paint thoroughly; apply several thin paint coats and let dry after each application.

08 Maintenance and specifications

Vehicle care

4.

If there is a longer scratch, you may want to protect surrounding paint by masking it off

5. After a few days, polish the touched-up

areas. Use a soft rag and a small amount of polish.

08

317

Label information.................................................................................. 320
Specifications........................................................................................ 322
Overview of information and warning symbols..................................... 328
Volvo programs..................................................................................... 331

318

SPECIFICATIONS

09 Specifications

09

Label information

Location of labels

320

Vehicle Identification Number (VIN). The VIN plate is located on the top left surface of the dashboard. The Vehicle Identification Number (VIN) should always be quoted in all correspondence concern- ing your vehicle with the retailer and when ordering parts. Vehicle Emission Control Information. Your Volvo is designed to meet all appli- cable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.

List of labels

Model plate. Vehicle Identification Number (VIN). Codes for color and upholstery, etc. The model plate is located on the rear side of the B-pillar (the pillar between the front and rear passenger doors) and the rear pas- senger's door must be open in order to see it. Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Min- istry of Transport (CMVSS) standards (Canada). Your Volvo is designed to meet all applicable safety standards, as evi- denced by the certification label on the driver's side B-pillar (the structural mem- ber at the side of the vehicle, at the rear of the driver's door opening). For further infor- mation regarding these regulations, please consult your Volvo retailer. Tire inflation pressures. This label indicates the correct inflation pressures for the tires that were on the vehicle when it left the factory. Cana- dian models have the upper decal; U.S. models have the lower one.

09 Specifications

Label information

09

321

09 Specifications

09

Specifications

Dimensions–S60

Pos itio

Dimension

Height

Load height

Dimension

Pos itio

Track, front

in

(mm)

58.4
(1484)

465

in

(mm)

62.5
(1588) A/ 62.1
(1578)

Pos itio

Dimension

Wheelbase

Length

Load length, floor, seat- back down

Load length, floor

in

(mm)

109.3
(2776)

182.2
(4628)

68.9
(1749)

38.0
(965)

322

09 Specifications

Specifications

09

Dimension

Pos itio

Track, rear

in

(mm)

62.4
(1585) A/

Dimension

Pos itio

Load width, floor

in

(mm)

62.0
(1575)

36.2
(919)

Pos itio

Dimension

Width

Width encl. door mirrors

in

(mm)

73.4
(1865)

82.6
(2097)

A with 16" wheels B with 17" wheels

Weights Category

Gross vehicle weight

Capacity weight

Permissible axle weights, front

Permissible axle weights, rear

Curb weight

Max. roof load

USA

5050 lbs

1200 lbs

2755 lbs

2490 lbs

3760-3800

165 lbs

Canada

2290 kg

545 kg

1250 kg

1130 kg

1710-1730

75 kg

``

323

09 Specifications

09

Specifications

Category

Max. trailer weights

USA

Without brakes: 1650 lbs With brakes, 1 7/8” ball: 2,000 lbs With brakes, 2” ball: 3,300 lbs

Canada

Without brakes: 750 kg With brakes, 1 7/8” ball: 900 kg With brakes, 2” ball: 1500 kg

Max. tongue weight

165 lbs

75 kg

Engine specifications Specification/Model

Engine designation

Output (kW/rps)

Output (hp/rpm)

Torque (Nm/rps)

Torque (ft. lbs./rpm)

No. of cylinders

Bore (in/mm)

Stroke (in/mm)

Displacement

Compression ratio

324

3.0T

B6304T4

224/93

300/5600

440/35 – 70

325/2100 – 4200

3.23/82

3.67/93.2

2.95 liters (175 cu. in.)

9.3:1

Engine oil Engine oil must meet the minimum ILSAC specification GF-4, API SL, or ACEA A1/B1. Lower quality oils may not offer the same fuel economy, engine performance, or engine pro- tection. Volvo recommends Castrol. Depending on your driving habits, premium or synthetic oils may provide superior fuel econ- omy and engine protection. Consult your Volvo retailer for recommendations on premium or synthetic oils. Oil additives must not be used. Synthetic oil is not used when the oil is changed at the normal maintenance services. This oil is only used at customer request, at additional charge. Please consult your Volvo retailer.

Oil viscosity Incorrect viscosity oil can shorten engine life under normal use. SAE 5W-30 will provide

Oil volume Engine model

09 Specifications

Specifications

09

good fuel economy and engine protection. See the viscosity chart.

American Petroleum Institute (API) symbol

Viscosity chart Extreme engine operation Synthetic oils meeting SAE 0W-30 or 0W-40
and complying with oil quality requirements are recommended for driving in areas of sustained temperature extremes (hot or cold), when tow- ing a trailer over long distances, and for pro- longed driving in mountainous areas.

The API Service Symbol "donut" is divided into three parts: • The upper section describes the oil's per-

formance level.

• The center identifies the oil's viscosity. • The lower section indicates whether the oil

has demonstrated energy-conserving properties in a standard test in comparison to a reference oil.

Oil volume between MIN and MAX

Volume (incl. filter)

3.0T (6 cyl.)

B6304T2

1.27 US qts (1.2 liters)

7.18 US qts (6.8 liters)

``

325

09 Specifications

09

Specifications

Other fluids and lubricants Fluid

Transmission oilA

Coolant

System

Volume

Specification

Automatic (TF-80SC)

5.8 US qts (5.5 liters)

Transmission fluid BOT 341

3.0T

9.4 US qts. (8.9 liters)

Coolant with corrosion inhibitor mixed with water (50/50 mix), see packaging.

Refrigerant: R134a (HFC134a), PAG oil

DOT 4+

Power steering fluid WSS M2C204-A2 or equivalent product.

Use a washer antifreeze recom- mended by Volvo, mixed with water.

Air conditioning

All models

1.7 lbs (770 g)

Brake fluid

Power steering

Washer fluid

Fuel tank volume

0.63 US qts (0.6 liters)

1.26 US qts (1.2 liters)

6.8 US qts (6.5 liters) 4.7 US qts (4.5 litersB)

18.5 US gallons (70 liters)

A Under normal driving conditions the transmission oil does not need changing during its service life. However, it may be necessary under adverse driving conditions. B Models without headlight washers

326

Electrical system

General information 12 volt system with a voltage-regulated alter- nator. Single pole system in which the chassis and engine block are used as conductors. The negative terminal is connected to the chassis.

Performance, battery

Engine

Voltage (V)

3.0T

12

Cold start capacity (A)

520 – 700

Reserve capacity (min)

100 – 135

WARNING

PROPOSITION 65 WARNING! Battery posts, terminals, and related acces- sories contain lead and lead compounds, chemicals known to the state of California to cause cancer and reproductive harm. Wash hands after handling.

CAUTION

If the battery is replaced, replace it with a battery of the same cold start capacity and reserve capacity as the original (see the decal on the battery).

09 Specifications

Specifications

09

327

09 Specifications

09

Overview of information and warning symbols

Introduction The symbols in the vehicle's various displays are divided into three main categories: • Warning symbols • Indicator symbols • Information symbols The following tables list the most common symbols, their meaning and the pages in this manual that provide more detailed information.

Warning symbol The red warning symbol lights up to indicate a problem related to safety and/or drivability. A message will also appear in the main instruments panel's display.

Information symbol The information symbol lights up and a text message is displayed to provide the driver with necessary information about one of the vehicle's systems.

Symbols in the main instrument panel

Warning symbols Symbol

Description

Low oil pressure

Parking brake

SRS airbags

Seat belt reminder

Generator not charg- ing

Fault in the brake system

Pag

78

78

78

78

78

79

Warning symbol

79

A Canadian models

Indicator symbols Symbol

Description

Fault in the Active Bending Light (ABL)*system

Malfunction indicator light

Anti-lock brake sys- tem (ABS)

Rear fog light on

Stability system (DSTC), Trailer Stabil- ity Assist*

Tire pressure monitor- ing sensor (TPMS)

Low fuel level

Information symbol, see text in information display

Pag

77

77

77

77

77

77

77

77

328

* Option/accessory, for more information, see Introduction.

09 Specifications

Overview of information and warning symbols

09

Symbol

Description

High beam indicator

Left turn signal indica- tor

Right turn signal indi- cator

A Canadian models

Other information symbols Symbol Description

Adaptive Cruise Con- trol *

Adaptive Cruise Con- trol *

Adaptive Cruise Con- trol *, Distance Alert*

Adaptive Cruise Con- trol *, Distance Alert*

Pag

76

76

76

Pa ge

145, 151

145, 151

145, 151, 153

145, 151, 153

Symbol

Description

Adaptive Cruise Con- trol *

Adaptive Cruise Con- trol *, Distance Alert*

Adaptive Cruise Con- trol *, Distance Alert*

Pa ge

145, 151

145, 151, 153

145, 151, 153

Adaptive Cruise Con- trol*

145, 151

Radar sensor*

Camera*

148

165

Symbol

Description

Collision Warning with Full Auto-brake and Pedestrian Detection*

Pa ge

167

Driver Alert System*

169

Active Bending Lights (ABL)*

Fuel filler door (arrow indicates it is on right side of vehicle)

Rain sensor*

91

76

96

Driver Alert System*

170

Driver Alert System*, Lane Departure Warn- ing*

Driver Alert System*, Lane Departure Warn- ing*

172

172

* Option/accessory, for more information, see Introduction.

329

``

09 Specifications

09

Overview of information and warning symbols

Information symbols in the ceiling console Symbol

Description

Seat belt reminder

Occupant Weight Sen- sor

22

29

Information symbols in the center console display Symbol

Description

Audio files

CD folder

Video files

Bluetooth-connected cell phone

BluetoothTM hands- free

HD radio

Park Assist*

Pa ge

212

212

212

222

222

204

175

330

* Option/accessory, for more information, see Introduction.

Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional informa- tion, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial: In the U.S. 1-800-638-6586 (1-800-63- VOLVO) In Canada 1-800-263-0475

Technician certification In addition to Volvo factory training, Volvo sup- ports certification by the National Institute for Automotive Service Excellence (A.S.E.). Certi- fied technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These pro- fessional technicians are best able to analyze vehicle problems and perform the necessary maintenance procedures to keep your Volvo at peak operating condition.

09 Specifications

Volvo programs

09

331

10 Index

1, 2, 3 ...

10

12-volt sockets........................................ 188

ABS (anti-lock brake system).................. 115
Accessory installation warning.................. 14
Active chassis system............................. 140
Active yaw control................................... 138
Adaptive brake lights............................... 114
Adaptive cruise control.................... 143, 145
Airbags

disconnecting the front passenger’s side................................................. 29, 30
front...................................................... 25
inflatable curtain................................... 35
side impact........................................... 33
Air conditioning........................................ 134
Air distribution.......................................... 130
Air distribution table................................. 136
Air vents................................................... 131
All Wheel Drive......................................... 113
Anti-freeze....................................... 240, 292

332

Anti-lock brake system............................ 114
warning light......................................... 76
Anti-lock Brake System (ABS)................. 115
Approach lighting................................ 56, 94
Audio system

AUX/USB sockets............................... 215
Bluetooth(cid:159) devices............................. 218
Bluetooth(cid:159) hands-free system........... 221
Bluetooth streaming audio................. 218
general functions................................ 199
getting started.................................... 194
HD digital radio................................... 204
introduction......................................... 192
media player....................................... 211
menus................................................. 233
overview.............................................. 192
radio functions.................................... 202
Sirius satellite radio............................ 206
sound settings.................................... 200
steering wheel keypad........................ 197
voice control....................................... 229
Auto-dim rearview mirror......................... 101
Automatic locking retractor....................... 40
Automatic transmission

Geartronic................................... 111, 112
general description..................... 111, 112

oil........................................................ 326
shiftlock override................................ 112
Axle weight.............................................. 267

Battery

changing............................................. 303
maintenance............................... 302, 303
remote key, replacing........................... 59
specifications...................................... 327
warning symbols................................. 302

Blind Spot Information System (BLIS)....................................... 182, 183, 184
Bluetooth cell phone connection............. 221
Booster cushions....................................... 47
Brake lights.............................................. 114
Brake system

checking fluid level............................. 292
emergency brake assistance.............. 115
fluid..................................................... 326
general information............................. 114
warning light......................................... 78

Bulbs

headlights........................... 294, 295, 296
introduction......................................... 294
license plate lights.............................. 298
specifications...................................... 299
trunk lighting....................................... 298

Camera, Park Assist................................ 178
Capacity weight....................................... 267
Catalytic converter................................... 245
Cell phone, hands-free connection......... 221
Cell phone voice control.......................... 229
Central locking system, introduction......... 54
Chains...................................................... 270
Check engine light..................................... 76
Child restraints

recalls and registration......................... 50
Child restraint systems.............................. 41
booster cushions.................................. 47
convertible seats.................................. 45
infant seats........................................... 43
ISOFIX/LATCH anchors........................ 48
top tether anchors................................ 49

Child safety.......................................... 39, 40
booster cushions.................................. 47
child restraint systems.......................... 41
convertible seats.................................. 45
infant seats........................................... 43
Child safety locks...................................... 51
City Safety™............................................ 156
Climate system........................................ 134
air distribution............................. 130, 136
air vents.............................................. 131
Interior Air Quality System.................. 130
introduction......................................... 129
passenger compartment filter............ 130
refrigerant........................................... 129
Clock, setting............................................. 80
Cold weather driving................................ 240
Collision warning system................. 162, 163
Compass in rearview mirror..................... 102
Conserving electrical current................... 239
Controls, center console.......................... 233
Convertible seats....................................... 45
Coolant............................................ 292, 326
Cooling system, general information....... 239
Corner Traction Control........................... 138
Courtesy lighting.................................. 93, 94

10 Index

Crash event data....................................... 11
Crash mode............................................... 38
Cruise control.................................. 141, 142
adaptive.............................................. 143
Curb weight............................................. 267
Current, conserving................................. 239

10

Defroster.................................................. 134
Detachable key blade.......................... 59, 61
Disconnecting the front passenger’s air- bag....................................................... 29, 30
Dome lighting....................................... 93, 94
Door mirrors............................................. 100
Driver alert............................................... 169
Driver distraction warning.......................... 14
Driving economically................................ 238
Driving in cold weather............................ 240
Driving through water.............................. 239

333

10 Index

Eyelets for anchoring loads..................... 247

ECC................................................. 134, 135
Economical driving.................................. 238
Electric parking brake.............................. 116
Electronic Climate Control....... 132, 134, 135
air distribution table............................ 136
Interior Air Quality System.................. 135
Emergency locking retractor...................... 40
Emergency starting.................................. 109
Emergency towing........................... 253, 254
Emission inspection readiness................ 287
Engine

overheating........................................... 79
specifications...................................... 324
starting................................................ 108
switching off....................................... 109
Engine compartment overview................ 289
Engine Drag Control (EDC)...................... 138
Engine oil

checking............................................. 290
low pressure warning light.............. 77, 78
specifications...................................... 325
volumes.............................................. 325
Environment............................................... 13

10

334

Federal Clean Air Act............................... 286
Fluid specifications.................................. 326
Fog lights

front/rear............................................... 92
Four C (active chassis system)................ 140
Front airbags.............................................. 25

disconnecting passenger’s side air- bag.................................................. 29, 30
Front park assist.............................. 175, 177
Front seats........................................... 83, 85
Fuel filler cap........................................... 245
Fuel filler door, opening........................... 244
Fuel level warning light.............................. 77
Fuel requirements............................ 242, 243
Fuel tank volume..................................... 326
Fuses............................... 305, 306, 309, 312

Gasoline requirements............................. 243
Gas tank volume...................................... 326
Gauges...................................................... 75
Geartronic................................................ 112
Geartronic automatic transmission.. 111, 112
Generator warning light............................. 78
Glossary of tire terminology..................... 266
Grocery bag holder.................................. 248
Gross vehicle weight............................... 267

Hazard warning flashers............................ 92
HD digital radio........................................ 204
Headlights

Active Bending Lights........................... 91
changing bulbs........................... 295, 296
high/low beams.................................... 90
high beam flash.................................... 90
Headlight washers..................................... 97
Head restraints, rear seat.......................... 86
Heated oxygen sensors........................... 246

Infotainment system................................ 192
AUX/USB sockets............................... 215
Bluetooth(cid:159) devices............................. 218
Bluetooth® hands-free system........... 221
general functions................................ 199
getting started.................................... 194
media player....................................... 211
menus................................................. 233
radio functions.................................... 202
sound settings.................................... 200
voice control....................................... 229
Inspection readiness................................ 287
Instrument lighting..................................... 90
Instrument overview............................ 74, 75
Instrument panel...................................... 122
Interior Air Quality System....................... 130
Interior lighting..................................... 93, 94
iPod(cid:159) connector (audio system)............. 215
ISOFIX/LATCH anchors............................. 48

Heated rear seats.................................... 133
High beams................................................ 90
indicator light........................................ 77
Hoisting the vehicle................................. 287
Home safe lighting..................................... 94
Hood, opening/closing............................ 289
Horn........................................................... 89

Ignition modes........................................... 81
Immobilizer................................................ 55
Important information.................................. 8
Indicator lights......................... 75, 76, 77, 78
Infant seats................................................ 43
Inflatable Curtain........................................ 35
Inflation pressure..................................... 261
Inflation pressure tables.......................... 263
Information and warning symbols, table of.............................................................. 328
Information lights..................... 75, 76, 77, 78
Information symbol.................................... 77

10 Index

Jack

attaching............................................. 279
location of........................................... 278
Jump starting........................................... 109

Key blade................................. 54, 59, 61, 62
private locking...................................... 61
valet locking.......................................... 61

Keyless drive

general description............................... 62
starting the vehicle............................. 108

Labels

list of................................................... 321
location of........................................... 320
LATCH anchors......................................... 48
Leather care............................................. 315
Lighting panel............................................ 90
Load anchoring eyelets........................... 247

10

335

10 Index

10

Loading the vehicle.......................... 247, 267
roof loads............................................ 249
Locking...................................................... 65
Locking the vehicle.................................... 56
Locks, child safety..................................... 51
Low beams................................................ 90
Low fuel level warning light........................ 77
Low oil pressure warning light................... 78

Main instrument panel............................. 122
Maintenance............................................ 286
hoisting the vehicle............................. 287
performed by the owner..................... 287
Malfunction indicator light......................... 76
Media player (infotainment system)......... 211
Messages in the instrument panel........... 122
Mirrors

defroster............................................. 101
power door......................................... 100
rearview, auto-dim function................ 101
retractable........................................... 100
vanity.................................................. 188

336

Moonroof................................................. 103
Motor oil

checking............................................. 290
specifications...................................... 325
volumes.............................................. 325
MY CAR................................................... 124

Occupant safety........................................ 18
Occupant weight sensor...................... 29, 30
Octane recommendations....................... 243
Odometer, trip........................................... 80
Oil

checking............................................. 290
specifications...................................... 325
volumes.............................................. 325
On Call Roadside Assistance.................. 331
Overhead courtesy lighting.................. 93, 94
Overheating, engine................................... 79
Oxygen sensors, heated.......................... 246

Paint, touching up.................................... 316
Park assist....................................... 175, 177
Park Assist Camera................................. 178
Parking brake

electric, applying/releasing................. 116
warning light......................................... 78
Parking lights............................................. 92
Personal Car Communicator, unique func- tions........................................................... 57
Polishing.................................................. 314
Power front seat

memory function................................... 84
with keyless drive................................. 85
Power mirrors.......................................... 100
defroster............................................. 101
Power moonroof...................................... 103
Power steering

fluid..................................................... 293
speed-dependent............................... 140
Power steering fluid................................. 326
Power windows......................................... 98
Pregnancy, using seat belts during........... 22
Private locking........................................... 61

10 Index

PROPOSITION 65 WARNING.. 109, 304, 327

Radio

Sirius satellite radio............................ 206
Radio functions........................................ 202
HD digital radio................................... 204
Rain sensor................................................ 96
READ button............................................ 122
Rear fog light............................................. 92
Rear park assist............................... 175, 177
Rear seats

center head restraint............................. 86
folding................................................... 86
heated................................................. 133

Rearview mirror

auto-dim function............................... 101
compass............................................. 102
Rear window defroster............................ 101
Recalls, child restraints.............................. 50
Refrigerant............................................... 326
Refueling.......................................... 242, 243
fuel filler cap....................................... 245

fuel filler door...................................... 244
fuel tank volume................................. 326
Registering child restraints........................ 50
Remote control

private locking...................................... 61
Remote key................................................ 54
approach lighting.................................. 56
immobilizer........................................... 55
key blade.................................. 54, 59, 61
key memory.......................................... 55
locking the vehicle................................ 56
Personal Car Communicator.......... 56, 57
replacing the battery............................. 59
unlocking the vehicle............................ 56

Remote key/PCC

common functions................................ 56
Reporting safety defects............................ 19
Roadside Assistance............................... 331
Roof loads............................................... 249

Safety, occupant........................................ 18
Safety defects, reporting........................... 19

Seat belt

reminder................................................ 22

Seat belts

Automatic locking retractor/Emergency locking retractor.................................... 40
buckling................................................ 20
maintenance......................................... 21
pretensioners........................................ 20
reminder................................................ 21
reminder warning light.......................... 78
securing child restraint sys- tems.......................................... 43, 45, 47
unbuckling............................................ 21
use during pregnancy........................... 22
using..................................................... 20
Seats, front.......................................... 83, 84
Side door mirrors..................................... 100
Side impact airbags................................... 33
Sirius satellite radio.................................. 206
Snow chains............................................ 270
Snow tires................................................ 270
Spare tire................................................. 271
Speed-dependent steering...................... 140
Spin control............................................. 138
SRS............................................................ 24

10

337

10 Index

Stability system............................... 138, 139
Corner Traction Control (CTC)............ 138
Engine Drag Control (EDC)................. 138
indicator light........................................ 77
Starting the engine.................................. 108
with keyless drive............................... 108

Starting the vehicle

after a crash (crash mode).................... 38
Start inhibitor (immobilizer)........................ 55
Steering wheel

adjusting............................................... 89
horn....................................................... 89
keypad.................................. 89, 124, 197
Stone chips, touching up......................... 316
Storage spaces........................................ 186
Studded tires........................................... 270
Sunroof (moonroof).................................. 103
Sun shade.................................................. 99
Supplemental restraint system.................. 24
warning light......................................... 78
Symbols, overview................................... 328

10

338

Temporary spare tire............................... 271
Three-way catalytic converter................. 245
Tire designations..................................... 264
Tire Pressure Monitoring System.... 281, 282
indicator light........................................ 77
Tires......................................................... 258
age...................................................... 258
changing from summer to winter........ 259
glossary of terms................................ 266
improving economy............................ 258
inflation pressure................................ 261
inflation pressure tables..................... 263
load ratings......................................... 262
rotation............................................... 259
snow................................................... 270
spare................................................... 271
specifications...................................... 262
speed ratings...................................... 262
storing................................................. 259
studded............................................... 270
tire pressure monitoring system......... 281
tread wear indicator............................ 260
uniform tire quality grading................. 269

Top tether anchors (child restraint sys- tems).......................................................... 49

Touching up paint.................................... 316
Towing a trailer................................ 250, 251
trailer hitch.......................................... 251
Towing the vehicle........................... 253, 254
Traction control........................................ 138
Trailer towing................................... 250, 251
trailer hitch.......................................... 251

Transmission

general description..................... 111, 112
oil........................................................ 326
shiftlock override................................ 112
Tread wear indicator................................ 260
Trip computer.......................................... 137
Trip odometers.......................................... 80
Trips, long distance................................. 239
Trunk

changing bulbs................................... 298
driving with it open............................. 238
Turn signals............................................... 93
indicator lights...................................... 77

U

Uniform Tire Quality Grading................... 269
Unlocking the vehicle.......................... 56, 65
Upholstery care....................................... 314

Valet locking.............................................. 61
Vanity mirror............................................ 188
changing bulbs................................... 299
Vehicle Event Data..................................... 11
Vehicle loading................................ 247, 267
roof loads............................................ 249
Vehicle maintenance................................ 286
performed by the owner..................... 287
Vehicle weights........................................ 323
Voice control

cell phones......................................... 229
Volvo and the environment........................ 13
Volvo maintenance.................................. 286
Volvo On Call Roadside Assistance........ 331
Volvo programs....................................... 331

Warning flashers, hazard........................... 92
Warning lights.......................... 75, 76, 77, 78
Warning symbol......................................... 79
Warning system, collision................ 162, 163
Warranties................................................ 286
Washer fluid..................................... 301, 326
Washers

headlight............................................... 97
windshield............................................. 96
Water, driving through............................. 239
Waxing..................................................... 314
Weights.................................................... 323
Wheels..................................................... 258
changing..................................... 278, 279
storing................................................. 259
Whiplash Protection System..................... 36
Windows

power.................................................... 98

Windshield

rain sensor............................................ 96
washers................................................ 97
wipers/washers..................................... 96
Windshield washer fluid................... 301, 326

10 Index

Windshield wipers.................................... 300
Wiper blades

replacing windshield wipers............... 300

10

339

10 Index

10

340

Kdakd8Vg8dgedgVi^dcIE&'((.JH68VcVYV!6I&%'%!Eg^ciZY^cHlZYZc!<ŽiZWdg\'%&%!8deng^\]i©'%%%"'%&%Kdakd8Vg8dgedgVi^dc

VOLVO S60

Owner's manual

Web Edition

Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual. We also urge you and your passengers to wear seat belts at all times in this (or any other) vehicle. And, of course, please do not operate a

vehicle if you may be affected by alcohol, medication or any impair- ment that could hinder your ability to drive. Your Volvo is designed to meet all applicable federal safety and emission standards. If you have any questions regarding your vehicle, please contact your Volvo retailer or see the section "Contacting Volvo" in this manual's "Introduction" chapter for information on get- ting in touch with Volvo in the United States and Canada.

Contents

Important information................................. 8
Environment.............................................. 13

0000 Introduction Important warnings................................... 14 01

01 Safety Occupant safety........................................ 18
Reporting safety defects........................... 19
Seat belts ................................................. 20
Supplemental Restraint System (SRS) .... 24
Occupant Weight Sensor ......................... 29
Side impact protection (SIPS) airbags ..... 33
Inflatable Curtain (IC) ............................... 35
Whiplash Protection System – WHIPS..... 36
Crash mode.............................................. 38
Child safety............................................... 39
Child restraint systems............................. 41
Infant seats............................................... 43
Convertible seats...................................... 45
Booster cushions...................................... 47
ISOFIX/LATCH lower anchors.................. 48
Top tether anchors.................................... 49
Child restraint registration and recalls...... 50
Child safety locks...................................... 51

Remote key and key blade....................... 54
Valet locking ............................................. 61
Keyless drive............................................. 62
Locks........................................................ 65
Alarm......................................................... 70

0202 Locks and alarm

0303 Your driving environment Parking brake.......................................... 116 0404 Comfort and driving pleasure

Instruments and controls.......................... 74
Ignition modes.......................................... 81
Seats......................................................... 83
Steering wheel.......................................... 89
Lighting..................................................... 90
Wipers and washers................................. 96
Power windows......................................... 98
Mirrors..................................................... 100
Compass*............................................... 102
Power moonroof*.................................... 103
HomeLink® Wireless Control System*... 105
Starting the engine.................................. 108
Transmission........................................... 111
Brakes..................................................... 114

Menus and messages............................. 122
My Car ................................................... 124
Climate system....................................... 129
Trip computer......................................... 137
Stability system....................................... 138
Active chassis system–Four C*............... 140
Cruise control.......................................... 141
Adaptive Cruise Control (ACC)*.............. 143
Distance Alert* ....................................... 153
City Safety™ .......................................... 156
Collision warning with Full Auto-brake and Pedestrian Detection*............................. 162
Driver Alert System* ............................... 169
Park assist*............................................. 175
Rear Park Assist Camera (PAC)* ............ 178
Blind Spot Information System*.............. 182
Passenger compartment convenience... 186

Contents

Introduction............................................. 192
Getting started ....................................... 194
General infotainment functions .............. 199
Radio....................................................... 202
Media player........................................... 211
AUX/USB sockets................................... 215
Bluetooth(cid:159) media ................................... 218
Bluetooth® hands-free connection ........ 221
Cell phone voice control......................... 229
Infotainment system menus ................... 233

0505 Infotainment

* Option/accessory, for more information, see Introduction.

Contents

specifications

Driving recommendations....................... 238
Refueling................................................. 242
Loading................................................... 247
Towing a trailer....................................... 250

0606 During your trip Emergency towing.................................. 253 0707 Wheels and tires

Tire Pressure Monitoring System (TPMS) 281 0808 Maintenance and

General information ............................... 258
Tire inflation............................................. 261
Inflation pressure ................................... 263
Tire designations .................................... 264
Glossary of tire terminology ................... 266
Vehicle loading ....................................... 267
Uniform Tire Quality Grading ................. 269
Snow chains, snow tires, studded tires . 270
Temporary Spare ................................... 271
Tire Sealing System................................ 272
Changing a wheel .................................. 278

Volvo maintenance.................................. 286
Maintaining your car............................... 287
Hood and engine compartment.............. 289
Engine oil................................................ 290
Fluids...................................................... 292
Replacing bulbs...................................... 294
Wiper blades and washer fluid................ 300
Battery..................................................... 302
Fuses...................................................... 305
Vehicle care............................................. 313

Index....................................................... 332

Label information.................................... 320
Specifications......................................... 322
Overview of information and warning sym- bols......................................................... 328

0909 Specifications Volvo programs....................................... 331 1010 Index

Contents

Introduction

Important information

Contacting Volvo In the USA: Volvo Cars of North America, LLC Customer Care Center 1 Volvo Drive, P.O. Box 914
Rockleigh, New Jersey 07647
1-800-458-1552
www.volvocars.us

In Canada: Volvo Cars of Canada Corp National Customer Service 175 Gordon Baker Road North York, Ontario M2H 2N7
1-800-663-8255
www.volvocanada.com

About this manual • Before you operate your vehicle for the first

time, please familiarize yourself with the information found in the chapters "Your Driving Environment" and "During Your Trip."

• Information contained in the balance of the manual is extremely useful and should be read after operating the vehicle for the first time.

• The manual is structured so that it can be

used for reference. For this reason, it should be kept in the vehicle for ready access. Footnotes Certain pages of this manual contain informa- tion in the form of footnotes at the bottom of the page. This information supplements the text that the footnote number refers to (a letter is used if the footnote refers to text in a table). Display texts There are several displays in the driver’s field of vision that show messages generated by various systems and functions in the vehicle. These texts are indicated in the Owner’s Man- ual by being in slightly larger type than the sur- rounding text and are printed in gray, (for example: Doors automatic lock).

Decals There are various types of decals in the vehicle whose purpose is to provide important infor- mation in a clear and concise way. The impor- tance of these decals is explained as follows, in descending order of importance. Risk of injury

G031590

Black ISO symbols on a yellow warning back- ground, white text/image on a black back- ground. Decals of this type are used to indicate potential danger. Ignoring a warning of this type could result in serious injury or death.

Risk of damage to the vehicle

Information

White ISO symbols and white text/image on a black or blue warning background and space for a message. If the information on decals of this type is ignored, damage to the vehicle could result.

White ISO symbols and white text/image on a black background. These decals provide gen- eral information.

NOTE

The decals shown in the Owner’s Manual are examples only and are not intended to be reproductions of the decals actually used in the vehicle. The purpose is to give an indi- cation of how they look and their approxi- mate location in the vehicle. The applicable information for your particular vehicle can be found on the respective decals in the vehicle.

Introduction

Important information

Types of lists used in the manual Procedures Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual.

If there is a series of illustrations associated with step-by-step instructions, each step in the procedure is numbered in the same way as the corresponding illustration. Lists in which letters are used can be found with series of illustrations in cases where the order in which the instructions are car- ried out is not important. Arrows with or without numbers are used to indicate the direction of a movement. If there are no illustrations associated with a step-by-step list, the steps in the procedure are indicated by ordinary numbers. Position lists

Red circles containing a number are used in general overview illustrations in which certain components are pointed out. The corresponding number is also used in the position list's description of the various components.

Introduction

Important information

Bullet lists Bullets are used to differentiate a number of components/functions/points of information that can be listed in random order. For example: • Coolant • Engine oil Continued `` `This symbol can be found at the lower right corner of an odd-numbered (right-hand) page to indicate that the current topic is continued on the following page.

Options and accessories Optional or accessory equipment described in this manual is indicated by an asterisk. Optional or accessory equipment may not be available in all countries or markets. Please note that some vehicles may be equipped dif- ferently, depending on special legal require- ments. Contact your Volvo retailer for additional infor- mation.

10

NOTE

WARNING

• All information, illustrations and specifi-

cations contained in this manual are based on the latest product information available at the time of publication.

• Volvo reserves the right to make model changes at any time, or to change spec- ifications or design without notice and without incurring obligation.

• Do not export your Volvo to another

country before investigating that coun- try's applicable safety and emission control requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.

WARNING

If your vehicle is involved in an accident, unseen damage may affect its drivability and safety.

CALIFORNIA proposition 65
Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the state of Cali- fornia to cause cancer, and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of Cali-
