D Do not install a child restraint sys- tem on the rear seat if it interferes with the front seats. Otherwise, the child or front seat occupant(s) may be killed or seriously injured in case of sud- den braking or a collision.

D If the driver’s seat position does not allow sufficient space for safe the child installation, install re- straint system on the rear right seat.

77

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

CAUTION

D After inserting the tab, make sure the tab and buckle are locked and that the lap and shoulder portions of the belt are not twisted.

D Do not insert coins, clips, etc. in the buckle as this may prevent your child from properly latching the tab and buckle.

D If the seat belt does not function it cannot protect your normally, child from death or serious injury. Contact your Toyota dealer immedi- ately. Do not the child restraint system on the seat until the seat belt is fixed.

install

1. Run the lap and shoulder belt through or around the infant seat following the instructions provided by its manufactur- er and insert the tab into the buckle taking care not to twist the belt. Keep the lap portion of the belt tight.

78

2. Fully extend the shoulder belt to put it in the lock mode. When the belt is then retracted even slightly, it cannot be extended.

the

To hold infant seat securely, make sure the belt is in the lock mode before letting the belt retract.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

3. While pressing the infant seat

firmly against the seat cushion and seatback, let the shoulder belt retract as far as it will go to hold the infant seat secure- ly.

CAUTION

Push and pull the child restraint sys- tem in different directions to be sure it is secure. Follow all the installation instructions provided by its manufac- turer.

4. To remove the infant seat, press the buckle release button and allow the belt to retract completely. The belt will move to work for an adult or older child passen- ger.

freely again and be ready

79

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

6. While pressing

the convertible seat firmly against the seat cushion and seatback, let the shoulder belt retract as far as it will go to hold the convert- ible seat securely.

CAUTION

Push and pull the child restraint sys- tem in different directions to be sure it is secure. Follow all the installation instructions provided by its manufac- turer.

7. Put a child on the child restraint sys- tem and secure the child, complying with the instructions provided by the child restraint system manufacturer.

Install the child restraint system on the front passenger seat only when it is un- avoidable. Your vehicle is equipped with a front passenger occupant classification system. In order to activate the occupant classification system correctly, install the forward−facing child restraint system on the front passenger seat in the following order: 1. Turn the ignition key to the “ON” posi-

tion.

2. Move the front passenger seat to the

rearward position.

3. Put the child restraint system on the front passenger seat without putting your weight on front passenger seat.

the

4. Insert the seat belt tab into the seat

belt buckle.

5. Fully extend the shoulder belt to put it in the lock mode. When the belt is then retracted even slightly, it cannot be extended. To hold the seat securely, make sure the belt is in the lock mode before letting the belt retract.

(B) CONVERTIBLE SEAT INSTALLATION A convertible seat must be used in for- ward−facing or rear−facing position de- pending on the age and size of the the child. When manufacturer’s the applicable age and size of the child as well as directions the child restraint system.

installing, follow instructions about

installing

for

80

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

light

indicator

illuminated when the ignition key

The “AIRBAG OFF” indicator light should be is “ON” and the child is in the child restraint system after following these procedures. The “AIRBAG OFF” indi- cates the SRS front passenger airbag and side airbag on the passenger side will not deploy. If the “AIRBAG ON” indicator light is illuminated, remove the child restraint system and reinstall it with the ignition key in the “ACC” or “LOCK” position. If the “AIRBAG ON” indicator light is illumi- nated when the ignition key is turned to the “ON” position, then the SRS front pas- senger airbag and side airbag on the pas- senger side may deploy in an accident. Do not drive the vehicle in this condition. Remove the child restraint system and contact your Toyota dealer.

’04Camry_U (L/O 0307)

CAUTION

the

D Never install a rear−facing child re- straint system on the front passen- ger seat. A forward−facing child re- straint system should only be installed on front passenger seat when unavoidable. If you must install the child restraint system on the front passenger seat, put the seat in its most rearward position, and install the forward−facing child restraint system in the proper or- der. Otherwise, the front passenger occupant classification system can not detect the presence of the child restraint system and the front pas- senger airbag and side airbag on the front passenger seat could deploy.

D Never install a rear−facing child re- straint system on the front passen- ger seat even if the “AIRBAG OFF” indicator light is illuminated. In the event of an accident, the impact of the rapid inflation of the front pas- senger airbag could cause death or serious if the rear−facing child restraint system is installed on front passenger seat.

injury to the child

the

81

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

D On vehicles with side airbags and curtain shield airbags, do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front or rear pillar or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint system. It is dangerous if the side airbag and curtain shield airbag in- flate, and the impact could cause death or serious injury to the child.

Move seat fully back

the

D A forward−facing child restraint sys- tem should be allowed to be installed on front passenger seat only when it is unavoidable. Always move the seat as far back as possible even if the “AIRBAG OFF” indicator light is illuminated, because the front passenger airbag could considerable speed and the child may be killed or seriously in- jured.

force. Otherwise,

inflate with

82

the

lock mechanism of

D Do not install a child restraint sys- tem on the rear seat if it interferes with the front seats. Otherwise, the child or front seat occupant(s) may be killed or seriously injured in case of sud- den braking or a collision.

D If the driver’s seat position does not allow sufficient space for safe the child installation, install re- straint system on the rear right seat.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

CAUTION

D After inserting the tab, make sure the tab and buckle are locked and that the lap and shoulder portions of the belt are not twisted.

D Do not insert coins, clips, etc. in the buckle as this may prevent your child from properly latching the tab and buckle.

D If the seat belt does not function it cannot protect your normally, child from death or serious injury. Contact your Toyota dealer immedi- ately. Do not the child restraint system on the seat until the seat belt is fixed.

install

2. Fully extend the shoulder belt to put it in the lock mode. When the belt is then retracted even slightly, it cannot be extended.

To hold the convertible seat securely, make sure the belt is in the lock mode before letting the belt retract.

83

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

1. Run the lap and shoulder belt through or around the convertible seat following its the instructions manufacturer and into the buckle taking care not to twist the belt. Keep the lap portion of the belt tight.

provided insert the

by tab

’04Camry_U (L/O 0307)

3. While pressing

the convertible seat firmly against the seat cushion and seatback, let the shoulder belt retract as far as it will go to hold the convert- ible seat securely.

CAUTION

Push and pull the child restraint sys- tem in different directions to be sure it is secure. Follow all the installation instructions provided by its manufac- turer.

4. To remove the convertible seat, press the buckle release button and allow the belt to retract completely. The belt will move to work for an adult or older child passen- ger.

freely again and be ready

84

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

(C) BOOSTER SEAT INSTALLATION A booster seat must be used in for- ward−facing position only.

’04Camry_U (L/O 0307)

D Do not allow the child to lean his/ her head or any part of his/her body against the door or the area of the seat, front or rear pillar or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint system. It is dan- gerous if the side airbag and cur- tain shield airbag inflate, and the impact could cause death or seri- ous injury to the child.

Move seat fully back

CAUTION

the

D A forward−facing child restraint sys- to be tem should be allowed front passenger installed on seat only when it is unavoidable. Always move the seat as far back as possible even if the “AIRBAG OFF” indicator light is illuminated, because the front passenger airbag considerable could speed and the child may be killed or seriously in- jured.

force. Otherwise,

inflate with

85

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

CAUTION

D Always make sure the shoulder belt is positioned across the center of child’s shoulder. The belt should be kept away from child’s neck, but not falling off child’s shoulder. Otherwise, the child may be killed or seriously injured in case of sud- den braking or a collision.

D If the seat belt does not function normally, it cannot protect your child from death or serious injury. Contact your Toyota dealer immedi- ately. Do not the child restraint system on the seat until the seat belt is fixed.

install

could

D Both high−positioned lap belts and cause loose−fitting belts death or serious to sliding under the lap belt during a collision or other unintended event. Keep the lap belt positioned as low on a child’s hips as possible.

injuries due

D For child’s safety, do not place the

shoulder belt under child’s arm.

D After inserting the tab, make sure the tab and buckle are locked and that the lap and shoulder portions of the belt are not twisted.

D Do not insert coins, clips, etc. in the buckle as this may prevent your child from properly latching the tab and buckle.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

1. Sit the child on a booster seat. Run the lap and shoulder belt through or around the booster seat and across the child following the instructions provided by its manufacturer and insert the tab into the buckle taking care not to twist the belt.

Make sure the shoulder belt is correctly across the child’s shoulder and that the lap belt is positioned as low as possible on child’s hips. See “Seat belts” on page 45 in this Section for details.

86

’04Camry_U (L/O 0307)

—Using a top strap

Symbol

Anchor brackets

2. To remove the child restraint system, the buckle release button and

press allow the belt to retract.

Follow the procedure below for a child restraint system that requires the use of a top strap.

Use the anchor bracket on the package tray behind the rear seat to attach the top strap. Anchor brackets are rear seating position. This symbol indicates the location of the anchor brackets.

for each

installed

87

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

TO USE THE ANCHOR BRACKET: 1. Outside anchor brackets only—

Remove the head restraint.

2. Open the lid of the anchor bracket.

88

3. Securely

fasten

the child restraint

system with the seat belt. Latch bracket and tighten the top strap.

the hook onto

the anchor

instructions

For the child re- straint system, see “Child restraint” on page 74 in this Section.

install

to

CAUTION

Make sure the top strap is securely latched, and check that the child re- straint system is secure by pushing and pulling it in different directions. Follow all the installation instructions provided by its manufacturer.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

—Installation with child restraint lower anchorages

4. Replace the head restraint and lift it

up to the uppermost lock position.

specifications

Lower anchorages for the child restraint systems complying with the FMVSS225
or CMVSS210.2 are installed in the rear seat. The anchorages are installed in the clear- ance between the seat cushion and seat- back of both outside rear seats. Child restraint systems complying with the FMVSS225 or CMVSS210.2 specification can be fixed to these anchorages. In this case, it is not necessary to fix the child restraint system with a seat belt on the vehicle.

Canada only

Type A

89

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

RESTRAINT

For owners in Canada The symbol on a child restraint system indicates the presence of a lower connec- tor system. CHILD INSTALLATION Type A— 1. Widen

the the clearance between seat cushion and seatback a little and confirm the position of the low- er anchorages near the button on the seatback.

SYSTEM

2. Latch the hooks of lower straps onto the anchorages and tighten the lower straps. Type B— 1. Widen

the the clearance between seat cushion and seatback a little and confirm the position of the low- er anchorages near the button on the seatback.

2. Latch the buckles onto the anchor-

ages.

it should be anchored. (For

If your child restraint system has a top strap, the installation of the top strap, see “—Using a top strap” on page 87 in this Section.)

Canada only

Type B

90

the installation details, refer

For to the instruction manual equipped with each product.

CAUTION

D When using the lower anchorages for the child restraint system, be sure that there are no irregular ob- jects around the anchorages or that the seat belt is not caught.

D Push and pull the child restraint system in different directions to be sure is secure. Follow all the installation instructions provided by its manufacturer.

it

the

lock mechanism of

D Do not install a child restraint sys- tem on the rear seat if it interferes with the front seats. Otherwise, the child or front seat occupant(s) may be killed or seriously injured in case of sud- den braking or a collision.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

SECTION 1− 4

OPERATION OF INSTRUMENTS AND CONTROLS Steering wheel and Mirrors Tilt steering wheel Power adjustable pedals Outside rear view mirrors Anti−glare inside rear view mirror Auto anti−glare inside rear view mirror Vanity mirrors

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

92
92
93
94
95
96

91

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Tilt steering wheel

Power adjustable pedals (some models with an automatic transmission)

CAUTION

D Do not adjust the steering wheel while the vehicle is moving. Doing so may cause the driver to mishan- dle the vehicle and an accident may occur resulting in death or serious injuries.

D After adjusting the steering wheel, try moving it up and down to make sure it is locked in position.

To change the steering wheel angle, hold the steering wheel, push down the lock the steering wheel to the desired angle and return the lever to its original position.

release

lever,

tilt

To adjust the position of the accelerator and brake pedals, push the switch. The ignition key must be in the “ON” posi- tion with the automatic transmission selec- tor lever in the “P” position. To move the pedals toward the front of the vehicle: Push the switch. To move Push the “Ɯ” side of the switch. The accelerator and brake pedals will move simultaneously as long as you hold the switch.

the “Ɲ” side of

the pedals back

toward you:

92

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Outside rear view mirrors—

When you set your driving position: 1. Set the parking brake firmly. 2. Move the accelerator and brake pedals

to the front most position.

3. Adjust the seat position and steering wheel angle properly. “Front seats” on page 38 and “Tilt steering wheel” on page 92.)

(See

4. Move the pedals toward you until you

can fully depress the brake pedal.

5. After adjusting, depress the pedals a

few times to get used to the feel.

CAUTION

D Never put your foot on the acceler- ator pedal while the pedals are moving. It may cause racing of the engine or sudden acceleration.

D Make sure that you can fully de- press the brake pedal before driv- ing. Otherwise, you may not be able to hold down the brake pedal firmly in an emergency stop.

Adjust the mirror so that you can just see the side of your vehicle in the mir- ror. Be careful when judging the size or dis- tance of any object seen in the outside rear view mirror on the passenger’s side because it is a convex mirror. Any object seen in a convex mirror will look smaller and farther away than when seen in a flat mirror. On some models, when you push the rear window defogger switch, the heater panels in the outside rear view mirrors will quick- ly clear the mirror surface. (See “Rear window and outside rear view mirror de- foggers” on page 105 in Section 1−5.)

CAUTION

D Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious inju- ries.

D Since the mirror surfaces can get hot, do not touch them when the defogger switch is on.

NOTICE

The outside rear view mirrors are fixed in place. Do not try to fold the mirrors. It may damage the mirrors.

93

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

—Power rear view mirror control

Anti−glare inside rear view mirror

NOTICE

If ice should jam the mirror, do not operate the control or scrape the mir- ror face. Use a spray de−icer to free the mirror.

To adjust a mirror, use the switches. 1. Master switch—To select the mirror to

be adjusted Push (right).

the switch to “L” (left) or “R”

2. Control switch—To move

the mirror Push the switch in the desired direc- tion.

Mirrors can be adjusted when the key is in the “ACC” or “ON” position.

94

Adjust the mirror so that you can just see the rear of your vehicle in the mir- ror. To reduce glare from the headlights of the vehicle behind you during night driving, operate the lever on the lower edge of the mirror. Daylight driving—Lever at position 1
The reflection in the mirror has greater clarity at this position. Night driving—Lever at position 2
Remember that by reducing glare you also lose some rear view clarity.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

CAUTION

Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the ve- hicle and an accident may occur re- sulting in death or serious injuries.

’04Camry_U (L/O 0307)

Auto anti−glare inside rear view mirror

Adjust the mirror so that you can just see the rear of your vehicle in the mir- ror. This mirror is equipped with auto anti− glare function. The function is designed to reduce glare from the headlights of the vehicle behind you during night driving. When inserted and turned on, the inside rear view mirror al- ways turns on in the automatic function mode. The indicator illuminates to show you that the function is on.

ignition key

the

is

to reduce

In automatic function mode, if the mirror detects light from the headlights of the the mirror surface vehicle behind you, darkens slightly the reflected light. To turn off the automatic function, push the “MIRROR” switch. To turn on the automatic function again, push the “MIRROR” switch. Adjust it before driving so that the rear view is in the best condition. When the inside air temperature is low, it for the mirror to may take little longer darken to the detection of headlights.

in response

CAUTION

Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the ve- hicle and an accident may occur re- sulting in death or serious injuries.

95

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Vanity mirrors

To use the vanity mirror, swing down the sun visor and open the cover. Vanity lights (type B only)— The lights come on when you open the cover. To adjust the brightness of the lights, slide the switch.

To ensure correct functioning of an anti−glare mirror sensor located on the back side of the mirror, do not touch or cover the sensor with your finger or a piece of cloth, etc.

Type A

96

Type B

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

SECTION 1− 5

OPERATION OF INSTRUMENTS AND CONTROLS Lights, Wipers and Defogger Headlights and turn signals Emergency flashers Instrument panel light control Front fog lights Interior light Ignition switch light Personal lights Windshield wipers and washer Rear window and outside rear view mirror defoggers

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

98
101
102
102
103
103
104
104
105

97

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Headlights and turn signals (without automatic light control system)

Position 2— The lights automatically turn off after 30
seconds when any of the door or trunk lid is opened and closed with the ignition key in the “ACC” or “LOCK” position. If you want to turn off the lights immedi- ately, push the “LOCK” button on the wire- less remote control transmitter twice. The lights also can be turned off immediately by pushing the “LOCK” button on the wire- less remote control transmitter with all the doors locked and the trunk lid closed. If any of the door or trunk lid is kept opened, the lights automatically turn off after 20 minutes. To turn on the lights again, turn the igni- tion key to the “ON” position or actuate the headlight switch. If you are going to park for over one week, make sure the headlight switch is in the “DRL” or “DRL OFF” position.

NOTICE

To prevent the battery from being dis- charged, do not leave the lights on for a long period when the engine is not running.

Daytime running light (DRL) system Daytime Running Light (DRL) system can make it easier for others to see the front of your vehicle during the day. The DRL system can be helpful in many different driving conditions, but they can be espe- cially helpful the short periods after dawn and before sunset. The DRL system will make your headlights come on at a reduced brightness when: D The light switch is in the “DRL” posi-

in

tion.

D The ignition is on with the engine run-

ning.

D The parking brake is released. To turn on the other exterior lights and instrument panel lights, twist the knob to the position 1. Twist the knob to the position 2 to turn the headlights for night driving. To turn off the DRL system, twist the knob to the position 3 (“DRL OFF”) or turn the ignition switch off.

to full intensity

tail,

license plate,

HEADLIGHTS To turn on the following lights: Twist the headlight/turn signal lever knob. Position 1—Parking, side marker and instrument panel lights Position 2—Headlights and all of above Automatic light cut off system Position 1— The lights automatically turn off when the driver’s door is opened with the ignition key in the “ACC” or “LOCK” position.

the

98

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Headlights and turn signals (with automatic light control system)

High−Low beams—For high beams, turn the headlights on and push the lever away from you (position 1). Pull the lever to- ward you (position 2) for low beams. The headlight high beam light indicator (blue light) on the instrument panel will tell you that the high beams are on. Flashing the high beam headlights (position 3)—Pull the way back. The high beam headlights turn off when you release the lever. You can flash the high beam headlights with the knob turned to “DRL” or “DRL OFF”.

the lever all

TURN SIGNALS To signal a turn, push the headlight/ turn signal lever up or down to position 1. The key must be in the “ON” position. The lever automatically returns after you make a turn, but you may have to return it by hand after you change lanes. To signal a lane change, move the lever up or down to the pressure point (position 2) and hold it. If the turn signal indicator lights (green lights) on the instrument panel flash faster than normal, a front or rear turn signal bulb is burned out. See “Replacing light bulbs” on page 301 in Section 7−3.

tail,

license plate,

HEADLIGHTS To turn on the following lights: Twist the headlight/turn signal lever knob. Position 1—Parking, side marker and instrument panel lights Position 2—Headlights and all of above Position 3 (“AUTO”)—Headlights and/or all of the lights in the position 1
They automatically turn on or off depend- ing on the darkness of the surroundings. Manually twist the knob to the position 2
to turn on the headlights if they are need- ed immediately when entering a dark tun- nel, parking structure, etc.

the

99

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Daytime running light (DRL) system Daytime Running Light (DRL) system can make it easier for others to see the front of your vehicle during the day. The DRL system can be helpful in many different driving conditions, but they can be espe- cially helpful the short periods after dawn and before sunset. The DRL system will make your headlights come on at a reduced brightness when: D The ignition is on with the engine run-

in

ning.

D The headlight switch is off. D The parking brake is released. To turn on the other exterior lights and instrument panel lights, twist the knob to the position 1. Twist the knob to the position 2 to turn the headlights for night driving.

to full intensity

Position 2 or position 3 with the head- lights on— The lights automatically turn off after 30
seconds when any of the door or trunk lid is opened and closed with the ignition key in the “ACC” or “LOCK” position. If you want to turn off the lights immedi- ately, push the “LOCK” button on the wire- less remote control transmitter twice. The lights also can be turned off immediately by pushing the “LOCK” button on the wire- less remote control transmitter with all the doors locked and the trunk lid closed. If any of the door or trunk lid is kept opened, the lights automatically turn off after 20 minutes. To turn on the lights again, turn the igni- tion key to the “ON” position or actuate the headlight switch. If you are going to park for over one week, make sure the headlight switch is off.

NOTICE

To prevent the battery from being dis- charged, do not leave the lights on for a long period when the engine is not running.

top of

the driver’s side

The automatic light control sensor is on the instrument panel. Do not place anything on the instrument panel, and/or do not affix anything on the windshield to block this sensor. Automatic light cut off system Position 1 or position 3 with the tail lights on— The lights automatically turn off when the driver’s door is opened with the ignition key in the “ACC” or “LOCK” position.

100

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Emergency flashers

High−Low beams—For high beams, turn the headlights on and push the lever away from you (position 1). Pull the lever to- ward you (position 2) for low beams. The headlight high beam light indicator (blue light) on the instrument panel will tell you that the high beams are on. Flashing the high beam headlights (position 3)—Pull the way back. The high beam headlights turn off when you release the lever. You can flash the high beam headlights with the knob turned to “OFF”.

the lever all

TURN SIGNALS To signal a turn, push the headlight/ turn signal lever up or down to position 1. The key must be in the “ON” position. The lever automatically returns after you make a turn, but you may have to return it by hand after you change lanes. To signal a lane change, move the lever up or down to the pressure point (position 2) and hold it. If the turn signal indicator lights (green lights) on the instrument panel flash faster than normal, a front or rear turn signal bulb is burned out. See “Replacing light bulbs” on page 301 in Section 7−3.

flashers,

turn on

the emergency

To push the switch. All the turn signal lights will flash. To turn them off, push the switch once again. Turn on the emergency flashers to warn other drivers if your vehicle must be stopped where it might be a traffic hazard. Always pull as far off the road as pos- sible. The turn signal light switch will not work when the emergency flashers are operat- ing.

101

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Instrument panel light control

Front fog lights

NOTICE

To prevent the battery from being dis- charged, do not leave the switch on longer than necessary when the en- gine is not running.

To adjust the brightness of the instru- ment panel lights, turn the dial.

To turn on the front fog lights, twist the band of the headlight and turn sig- nal switch lever. They will come on only when the headlights are on low beam.

102

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Interior light

Ignition switch light

ILLUMINATED ENTRY SYSTEM When the switch is in the “DOOR” posi- tion and any door is opened, the light will come on. After all the doors are closed, the light remains on for about 15 seconds before fading out. However, in the following cases, the light go off immediately. D All the doors are closed when the igni- tion key is in the “ACC” or “ON” posi- tion.

To turn on the interior light, slide the switch. The interior light switch has the following positions: “ON”—Keeps the light on all the time. “OFF”—Turns the light off. “DOOR”—Turns light on when any door is opened. The light goes off when all the doors are closed.

the

D The ignition key is turned to the “ACC”, the side

“START” after all

“ON” or doors are closed.

D All the doors are closed and locked. When all the doors are unlocked using either the key or the wireless remote con- trol transmitter simultaneously, the interior light will come on and remain on for about 15 seconds before fading out. To prevent the battery being discharged, the light will automatically turn off when the key is removed and the door is left opened with the switch at the “DOOR” position for 20 minutes or more.

For easy access to the ignition switch, the ignition switch light comes on when any of the doors are opened. The light remains on for about 15 seconds after all the doors are closed. However, in the following cases, the light goes off immediately. D All the doors are closed when the igni- tion key is in the “ACC” or “ON” posi- tion.

D The ignition key is turned to the “ACC”, the side

“START” after all

“ON” or doors are closed.

D All the doors are closed and locked.

103

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

When all the doors are unlocked using either the key or the wireless remote con- trol transmitter simultaneously, the ignition switch light will come on and remain on for about 15 seconds before fading out. To prevent the battery being discharged, the light will automatically turn off when the key is removed and the door is left opened for 20 minutes or more.

’04Camry_U (L/O 0307)

Personal lights

Windshield wipers and washer

To turn on the front personal lights, push the lenses. To turn the lights off, push the lenses once again.

To turn on the windshield wipers, move the lever to the desired setting. The key must be in the “ON” position.

Lever position

Speed setting

Position 1

Position 2

Position 3

Intermittent

Slow

Fast

For a single sweep of push the lever up and release it.

the windshield,

104

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

to

the

increase

interval adjuster: The

With “INT TIME” band lets you adjust the wiping time inter- val when the wiper lever is in the intermit- tent position (position 1). Twist the band upward time between sweeps, and downward to decrease it. To squirt washer fluid, pull the lever toward you. If the windshield wipers are off, they will operate a couple of times after the washer squirts. For instructions on adding washer fluid, see “Adding washer fluid” on page 301 in Section 7−3. In freezing weather, warm the windshield with the defroster before using the washer. This will help prevent fluid from freezing on your windshield, which can block your vision.

the washer

NOTICE

Do not operate the wipers if the wind- shield the glass.

It may scratch

is dry.

’04Camry_U (L/O 0307)

Rear window and outside rear view mirror defoggers

When waxing your vehicle, make sure that the washer nozzles do not become blocked. If a nozzle becomes blocked, contact your Toyota dealer to have the vehicle serviced.

NOTICE

If a nozzle becomes blocked, do not try to clear it with a pin or other object. The nozzle will be damaged.

With manual air conditioning controls

With automatic air conditioning controls

105

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

If the outside rear view mirrors are heavi- ly coated with ice, use a spray de−icer before operating the switch.

NOTICE

When cleaning the inside of the rear window, be careful not to scratch or damage the heater wires or connec- tors.

To defog or defrost the rear window, push the switch. The key must be in the “ON” position. The thin heater wires on the inside of the rear window will quickly clear the sur- faces. An indicator light will illuminate to indicate the defogger is operating. On some models, heater panels in the outside rear view mirrors will also quickly clear the surfaces. Push the switch once again to turn the defogger off. The system will automatically shut off af- ter the defogger has operated about 15
minutes.

CAUTION

Since the mirror surfaces can get hot do not touch them when the defogger switch is on.

turn

Make sure you the defoggers off when the surfaces are clear. Leaving the defoggers on for a long time could cause the battery to discharge, especially during stop−and−go driving. The defoggers are not designed for drying rain water or for melting snow.

106

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

SECTION 1− 6

OPERATION OF INSTRUMENTS AND CONTROLS Gauges, Meters and Service reminder indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel gauge Engine coolant temperature gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tachometer Odometer and two trip meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Service reminder indicators and warning buzzers

108
108
109
109
111

107

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Fuel gauge

Engine coolant temperature gauge

On inclines or curves, due to the move- ment of fuel in the tank, the fuel gauge needle may fluctuate or the low fuel level warning light may come on earlier than usual. If the fuel tank is completely empty, the malfunction indicator lamp comes on. Fill the fuel tank immediately. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Toyota dealer as soon as possible.

indicates

The gauge the approximate quantity of the fuel remaining in the tank when the ignition switch is on. Nearly full—Needle at “F” Nearly empty—Needle at “E” It is a good idea to keep the tank over 1/4 full. The gauge remains on for about 10 min- utes after the ignition switch is off. If the fuel level approaches “E” or the low fuel level warning light comes on, fill the fuel tank as soon as possible.

108

The gauge indicates the engine coolant temperature when the ignition switch is on. The engine operating temperature will vary with changes in weather and engine load. If the needle moves into the red zone, your engine is too hot. If your vehicle overheats, stop your vehicle and allow the engine to cool. Your vehicle may overheat during severe operating conditions, such as: D Driving up a long hill on a hot day. D Reducing speed or stopping after high

speed driving.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Tachometer

Odometer and two trip meters

D Idling for a long period with the air conditioning on in stop−and−go traffic.

D Towing a trailer.

NOTICE

z Do not remove the thermostat

in the engine cooling system as this may cause the engine to overheat. The thermostat is designed to con- trol the flow of coolant to keep the temperature of the engine within the specified operating range.

z Do not continue driving with an overheated engine. See “If your ve- hicle overheats” on page 242 in Section 4.

The tachometer indicates engine speed in thousands of rpm (revolutions per minute). Use it while driving to select correct shift points and to prevent en- gine lugging and over−revving. Driving with the engine running too fast causes excessive engine wear and poor fuel economy. Remember, in most cases the slower the engine speed, the greater the fuel economy.

NOTICE

Do not let the indicator needle get into the red zone. This may cause severe engine damage.

trip meters when

This meter displays the odometer and two ignition switch is on. 1. Odometer—Shows

total distance

the

the

the vehicle has been driven.

2. Two

trip meters—Show

two different distances independently driven since the last time each trip meter was set to zero. You can use one trip meter to calculate the to measure the distance on each trip. All trip meter data is cancelled if the elec- trical power source is disconnected.

fuel economy and

the other

109

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

3. Trip meter reset knob—Resets the two trip meters to zero, and also change the meter display. To change the meter display, quickly push and release the knob. The meter display changes in the order from the odometer to trip meter A to trip meter then back B, the odometer each time you push. To reset the trip meter A to zero, dis- play the meter A reading, then push and hold the knob until the meter is set to zero. The same process can be applied for resetting the trip meter B. This display remains on for about 10 min- utes after the ignition switch is off.

to

110

’04Camry_U (L/O 0307)

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

Service reminder indicators and warning buzzers

If the indicator or buzzer comes on...

Do this.

(a)

(b)

(c)

(d)

(e)

(f)

(g)

or

If parking brake is off, stop immediately and contact Toyota dealer.

(indicator and buzzer)

Fasten driver’s seat belt.

Fasten front passenger’s seat belt.

Stop and check.

Take vehicle to Toyota dealer.

Stop and check.

Fill up tank.

111

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

If the indicator or buzzer comes on...

Do this.

or

Take vehicle to Toyota dealer. If brake system warning light is also on, stop immediately and contact Toyota dealer.

Close all doors.

Take vehicle to Toyota dealer immediately.

Add washer fluid.

Take vehicle to Toyota dealer.

Replace engine oil.

Key reminder buzzer

Remove key.

(h)

(i)

(j)

(k)

(l)

(m)

(n)

112

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

(a) Brake System Warning Light This light comes on in the following cases when the ignition key is in the “ON” posi- tion. D When the parking brake is applied... Vehicles with anti−lock brake system— This light comes on for a few seconds when to the “ON” position even after the parking brake is released. D When the brake fluid level is low...

ignition key

turned

the

is

CAUTION

It is dangerous to continue driving normally when the brake fluid level is low.

Have your vehicle checked at your Toyota dealer in the following cases: D The light does not come on even if the parking brake is applied when the igni- tion key is in the “ON” position.

Vehicles with anti−lock brake system— D The light does not come on even if the ignition key is turned on with the park- ing brake released.

’04Camry_U (L/O 0307)

A warning light turning on briefly during operation does not indicate a problem.

(b) Driver’s Seat Belt Reminder Light

and Buzzer

CAUTION

If either of the following conditions occurs, immediately stop your vehicle at a safe place and contact your Toyota dealer. D The

light does not turn off even after the parking brake is released while the engine is running. In this case, the brakes may not work properly and your stopping distance will become longer. De- press the brake pedal firmly and bring the vehicle to an immediate stop.

Vehicles with anti−lock brake sys- tem— D The brake system warning light re- mains on together with the “ABS” warning light. In this case, not only the anti−lock brake system will fail but also the vehicle will become extremely un- stable during braking.

to

reminder

remind you

light and buzzer

This buckle up the driver’s seat belt. Once the ignition key is turned to “ON”, the flashes and buzzer sounds if the driver’s seat belt is not fas- tened. Unless the driver fastens the belt, the light keeps flashing and the buzzer stops after about 4 to 8 seconds. (c) Front Passenger’s Seat Belt Re-

light

minder Light

This light reminds you to buckle up the front passenger’s seat belt. Once the ignition key is turned to “ON”, the reminder light flashes if a passenger sits in the front passenger seat and does not fasten the seat belt. If luggage or other load is placed on the front passenger seat, depending on its weight, the reminder light may come on.

113

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

(d) Discharge Warning Light This light warns that the battery is being discharged. If it comes on while you are driving, there is a problem somewhere in the charging system. The engine ignition will continue to oper- the battery ate, however, until is dis- charged. Turn off the air conditioning, blower, radio, etc., and drive directly to the nearest Toyota dealer or repair shop.

NOTICE

Do not continue driving if the engine drive belt is broken or loose.

(e) Malfunction Indicator Lamp This lamp comes on when the ignition key is turned to the “ON” position and goes off after the engine starts. This means that the warning light system is operating properly. If the lamp remains on, or the lamp comes on while driving, first check the followings. D Empty fuel tank

If the fuel tank is empty, refuel immedi- ately.

114

D Loose fuel tank cap

If the fuel tank cap is loose, securely tighten it.

These cases are temporary malfunctions. The malfunction indicator lamp will go off after taking several driving trips. If the lamp will not go off even after the several trips, contact your Toyota dealer as soon as possible. If the fuel tank is not empty or the fuel tank cap is not loose... D There is a problem somewhere in the engine, emission control system, elec- tronic throttle control system, automatic transmission electrical system or warn- ing light system itself.

Contact your Toyota dealer as soon as possible to service the vehicle. If the engine speed does not increase with the accelerator pedal depressed down, there may be a problem somewhere in your electronic throttle control system. At this time, vibration may occur. Howev- er, if you depress the accelerator pedal more firmly and slowly, you can drive your vehicle at low speeds. Have your vehicle checked by your Toyota dealer as soon as possible.

Even if the abnormality of the electronic throttle control system is corrected during low speed driving, the system may not be recovered until the engine is stopped and the to “ACC” or ignition key “LOCK” position.

turned

is

CAUTION

Be especially careful to prevent erro- neous pedal operation.

if

inspection

Emissions inspection and maintenance (I/M) programs Your vehicle may not pass a state emission the malfunction indicator lamp remains on. Contact your Toyota dealer to check your vehicle’s emission and OBD (On−Board Diagnostics) system before taking your vehicle for the inspection. For details, see “Emissions Inspection and Maintenance (I/M) programs” on page 272
in Section 6.

system

control

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

(f) Low Engine Oil Pressure Warning

Light

This light warns that the engine oil pres- sure is too low. If it flickers or stays on while you are driving, pull off the road to a safe place and stop the engine immediately. Call a Toyota dealer or qualified repair shop for assistance. The flicker when the engine is idling or it may come on briefly after a hard stop. There is no cause for concern if it then goes out when the engine is accelerated slightly. The light may come on when the oil level is extremely is not designed to indicate low oil level, and the oil level must be checked using the level dipstick.

light may occasionally

low. It

NOTICE

the Do not drive warning light on—even for one block. It may ruin the engine.

the vehicle with

’04Camry_U (L/O 0307)

(g) Low Fuel Level Warning Light This light comes on when the fuel level in the tank becomes nearly empty. Fill up the tank as soon as possible. On inclines or curves, due to the move- ment of fuel in the tank, the low fuel level warning light may come on earlier than usual. (h) “ABS” Warning Light Vehicles without vehicle stability control system— The light comes on with the ignition key turned to the “ON” position. If the anti− lock brake system works properly, the light turns off after a few seconds. There- after, if the system malfunctions, the light comes on again. When the “ABS” warning light is on (and the brake system warning light is off), the anti−lock brake system does not operate, but the brake system still operates con- ventionally. When the “ABS” warning light is on (and the brake system warning light is off), the anti−lock brake system does not operate so that the wheels could lock up during a sudden braking or braking on slippery road surfaces.

If either of the following conditions oc- curs, this indicates a malfunction some- where in the components monitored by the warning light system. Contact your Toyota dealer as soon as possible to service the vehicle. D The light does not come on when the ignition key is turned to the “ON” posi- tion, or remains on.

D The light comes on while you are driv-

ing.

A warning light turning on briefly during operation does not indicate a problem.

CAUTION

If the “ABS” warning light remains on together with the brake system warn- ing light, immediately stop your ve- hicle at a safe place and contact your Toyota dealer. In this case, not only the anti−lock brake system will fail but also the vehicle will become extremely unsta- ble during braking.

115

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

the

the systems malfunctions,

Vehicles with vehicle stability control sys- tem— The light comes on when the ignition key is turned to the “ON” position. If the anti− lock brake system and the brake assist system work properly, the light turns off after a few seconds. Thereafter, if either of light comes on again. When the “ABS” warning light is on (and the brake system warning light is off), the anti−lock brake system, the brake assist system, traction control system and the vehicle stability control system do not op- erate, but the brake system still operates conventionally. When the “ABS” warning light is on (and the brake system warning light is off), the anti−lock brake system does not operate so that the wheels could lock up during a sudden brake or braking on slippery road surfaces.

116

’04Camry_U (L/O 0307)

the following conditions If either of occurs, indicates a malfunction this somewhere in the parts monitored by the warning light. Contact your Toyota dealer as soon as possible to service the vehicle. D The light does not come on when the ignition key is turned to the “ON” posi- tion, or remains on.

D The light comes on while you are driv-

ing.

A warning light turning on briefly during operation does not indicate a problem.

CAUTION

If the “ABS” warning light remains on together with the brake system warn- ing light, immediately stop your ve- hicle at a safe place and contact your Toyota dealer. In this case, not only the anti−lock brake system will fail but also the vehicle will become extremely unsta- ble during braking.

(i) Open Door Warning Light This light remains on until all the doors are completely closed.

light system monitors

(j) SRS Warning Light This light will come on when the igni- tion key is turned to the “ON” position. After about 6 seconds, the light will go off. This means the systems of the air- bag and front seat belt pretensioner are operating properly. This warning the airbag sensor assembly, front airbag sen- sors, side and curtain shield airbag sen- sors, curtain shield airbag sensors, driv- er’s seat position sensor, driver’s seat belt buckle switch, front passenger occupant classification system, “AIRBAG ON” indi- cator light, “AIRBAG OFF” indicator light, front passenger’s seat belt buckle switch, seat belt pretensioner assemblies, inflat- ors, warning light, interconnecting wiring and power sources. If either of the following conditions occurs, this indicates a malfunction somewhere in the parts monitored by the warning light system. Contact your Toyota dealer as soon as possible to service the vehicle. D The light does not come on when the ignition key is turned to the “ON” posi- tion or remains on for more than about 6 seconds.

D The light comes on while driving.

2004 CAMRY from Jul. ’03 Prod. (OM33616U)

’04Camry_U (L/O 0307)

(k) Low Windshield Washer Fluid Level

Warning Light

The light warns that the windshield washer fluid level is too low. Add washer fluid at your earliest opportunity. (For instructions, see “Adding washer fluid” on page 301 in Section 7−3.) (l) “VSC” Warning Light The light warns that there is a problem somewhere in the vehicle stability control system or traction control system. The light will come on when the ignition key is turned to “ON”, and will go off after about a few seconds. If the light comes on, the vehicle stability control system and traction control system do not work. However, as conventional braking operates when applied, there is no problem to continue your driving. In the following cases, contact your Toyota dealer: D The light does not come on after the

ignition is turned to on.

D The light is left on after the ignition is

turned to on.

D The light comes on while driving.

The “TRAC OFF” indicator light will come on when the “VSC” warning light comes on even if the “TRAC OFF” switch is not pushed. (m) Engine Oil Replacement Reminder

Light (for vehicles sold in U.S.A.)

then flashes

This light reminds you when to replace the engine oil. This light will come on when the ignition key is turned to “ON” and will go off after about a few seconds.
