2013 Subaru Impreza Owners Manual

Download PDF Manual
Foreword Congratulations on choosing a SUBARU vehicle. This Owner’s Manual has all the information necessary to keep your SUBARU in excellent condition and to properly maintain the emission control system for minimizing emission pollutants. We urge you to read this manual carefully so that you may understand your vehicle and its operation. For information not found in this Owner’s Manual, such as details concerning repairs or adjustments, please contact the SUBARU dealer from whom you purchased your SUBARU or the nearest SUBARU dealer. The information, specifications and illustrations found in this manual are those in effect at the time of printing. FUJI HEAVY INDUSTRIES LTD. reserves the right to change specifications and designs at any time without prior notice and without incurring any obligation to make the same or similar changes on vehicles previously sold. This Owner’s Manual applies to all models and covers all equipment, including factory installed options. Some explanations, therefore may be for equipment not installed in your vehicle. Please leave this manual in the vehicle at the time of resale. The next owner will need the information found herein. FUJI HEAVY INDUSTRIES LTD., TOKYO, JAPAN *C Copyright 2012 FUJI HEAVY INDUSTRIES LTD. is a registered trademark of FUJI HEAVY INDUSTRIES LTD. Black plate (1,1) 北米Model "A1140BE-A" EDITED: 2012/ 5/ 11 Black plate (2,1) This manual describes the following vehicle types. 4-door models 5-door models except XV CROSSTREK 1) 2) 3) XV CROSSTREK models 北米Model "A1140BE-A" EDITED: 2012/ 5/ 11 Black plate (3,1) Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22 & Models with HID headlights CAUTION High Intensity Discharge (HID) head- lights contain mercury. For that reason, it is necessary to remove HID headlights before vehicle dis- posal. Once removed, please reuse, recycle or dispose of the HID head- lights as hazardous waste. & Models without HID head- lights NOTE This vehicle does not contain mercury devices or parts. Warranties & Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of America, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: . SUBARU Limited Warranty . Emission Control Systems Warranty . Emissions Performance Warranty All warranty information, including details of coverage and exclusions, is in the “Warranty and Maintenance Booklet”. Please read these warranties carefully. & Warranties for Canada All SUBARU vehicles distributed by Subaru Canada, Inc. and sold at retail by an authorized SUBARU dealer in Canada come with the following warranties: . SUBARU Limited Warranty . Anti-Corrosion Warranty . Emission Control Warranty All warranty information, including details of coverage and exclusions, is in the “Warranty and Service Booklet”. Please read these warranties carefully. Black plate (3,1) How to use this Owner’s Manual & Using your Owner’s Manual Before you operate your vehicle, carefully read this manual. To protect yourself and extend the service life of your vehicle, follow the instructions in this manual. Failure to observe these instructions may result in serious injury and damage to your vehicle. is composed of This manual fourteen chapters. Each chapter begins with a brief table of contents, so you can usually tell at a glance if that chapter contains the information you want. Chapter 1: Seat, seatbelt and SRS airbags This chapter informs you how to use the seat and seatbelt and contains precau- tions for the SRS airbags. Chapter 2: Keys and doors This chapter informs you how to operate the keys, locks and windows. Chapter 3: Instruments and controls This chapter informs you about the opera- tion of indicators and how to use the instruments and other switches. instrument panel – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 2 Chapter 4: Climate control This chapter informs you how to operate the climate control. Chapter 5: Audio This chapter informs you how to operate your audio system. Chapter 6: Interior equipment This chapter informs you how to operate interior equipment. Chapter 7: Starting and operating This chapter informs you how to start and operate your SUBARU. Chapter 8: Driving tips This chapter informs you how to drive your SUBARU in various conditions and ex- plains some safety tips on driving. Chapter 9: In case of emergency This chapter informs you what to do if you have a problem while driving, such as a flat tire or engine overheating. Chapter 10: Appearance care This chapter informs you how to keep your SUBARU looking good. Chapter 11: Maintenance and service This chapter informs you when you need to take your SUBARU to the dealer for scheduled maintenance and informs you how to keep your SUBARU running properly. Chapter 12: Specifications This chapter informs you about dimen- sions and capacities of your SUBARU. Chapter 13: Consumer information and Reporting safety defects This chapter informs you about Uniform tire quality grading standards and Report- ing safety defects. Chapter 14: Index This is an alphabetical listing of all that’s in this manual. You can use it to quickly find something you want to read. find a number of WARNINGs, & Safety warnings You will CAUTIONs and NOTEs in this manual. These safety warnings alert you to poten- tial hazards that could result in injury to you or others. Please read these safety warnings as well as all other portions of this manual care- fully in order to gain a better understand- ing of how to use your SUBARU vehicle safely. WARNING A WARNING indicates a situation in which serious injury or death could result if the warning is ignored. Black plate (4,1) CAUTION A CAUTION indicates a situation in which injury or damage to your vehicle, or both, could result if the caution is ignored. NOTE A NOTE gives information or sugges- tions how to make better use of your vehicle. & Safety symbol You will find a circle with a slash through it in this manual. This symbol means “Do not”, “Do not do this”, or “Do not let this happen”, depending upon the context. 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (5,1) & Abbreviation list You may find several abbreviations in this manual. The meanings of the abbrevia- tions are shown in the following list. Abbreviation Meaning A/C A/ELR ABS AKI ALR AT ATF AWD CVT DCCD DRL EBD ELR FWD GAW GAWR GPS Air conditioner Automatic/Emergency locking retractor Anti-lock brake system Anti knock index Automatic locking retractor Automatic transmission Automatic transmission fluid All-wheel drive Continuously variable trans- mission Driver’s control center differ- ential Daytime running light Electronic brake force distri- bution Emergency locking retractor Front-wheel drive Gross axle weight Gross axle weight rating Global positioning system Abbreviation Meaning Vehicle symbols GVW GVWR HID INT LATCH LED LSD MIL MMT MT OBD RON Gross vehicle weight Gross vehicle weight rating High intensity discharge Intermittent Lower anchors and tethers for children Light emitting diode Limited slip differential Malfunction indicator light Methylcyclopentadienyl man- ganese tricarbonyl Manual transmission On-board diagnostics Research octane number SI-DRIVE SUBARU Intelligent Drive SRS TIN TPMS Supplemental restraint sys- tem Tire identification number Tire pressure monitoring sys- tem There are some of the symbols you may see on your vehicle. For warning and indicator lights, refer to “Warning and indicator lights” F20. Mark Name WARNING CAUTION Power door lock Power door unlock Power window with automatic open and close function Passengers’ windows lock and unlock Fuel Front fog lights – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (6,1) Mark Name Mark Name Mark Name Hazard warning flasher Rear window washer Windshield defroster Engine hood Lights Trunk lid (4-door) Seat heater Child restraint top tether an- chorages Child restraint lower an- chorages Horn Windshield wiper Wiper intermittent Tail lights, license plate light and instrument panel illumi- nation Headlights Turn signal Rear window defogger/Out- side mirror defogger/Wind- shield wiper deicer Air recirculation Engine oil Washer Illumination brightness Door lock (transmitter) Fan speed Door unlock (transmitter) Instrument panel outlets Instrument panel outlets and foot outlets Trunk lid open (4-door) or rear gate unlock (5-door) (trans- mitter) Windshield washer Foot outlets Rear window wiper Windshield defroster and foot outlets 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 . The SRS airbags deploy with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries. Because the SRS airbag needs enough space for deploy- ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full vehicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat. For instructions and precautions, carefully read the following sections. . For the seatbelt system, refer to “Seat- belts” F1-12. . For the SRS airbag system, refer to “*SRS airbag (Supplemental Restraint System airbag)” F1-38. Safety precautions when driving & Seatbelt and SRS airbag WARNING . All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Other- wise, the possibility of serious injury becomes greater in the event of a sudden stop or acci- dent. . To obtain maximum protection in the event of an accident, the driver and all passengers in the vehicle should always wear seat- belts when the vehicle is moving. The SRS (Supplemental Restraint System) airbag does not do away with the need to fasten seatbelts. In combination with the seat- belts, it offers the best combined protection in case of a serious accident. Not wearing a seatbelt increases the chance of severe injury or death in a crash even when the vehicle has the SRS airbag. Black plate (7,1) & Child safety WARNING . Never hold a child on your lap or in your arms while the vehicle is moving. The passenger cannot protect the child from injury in a collision, because the child will be caught between the passen- ger and objects inside the vehi- cle. . While riding in the vehicle, in- fants and small children should always be placed in the REAR seat in an infant or child restraint system which is appropriate for the child’s age, height and weight. If a child is too big for a child restraint system, the child should sit in the REAR seat and be restrained using the seatbelts. According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seat- ing positions. Never allow a child to stand up or kneel on the seat. . Put children aged 12 and under in the REAR seat properly re- strained at all times in a child restraint device or in a seatbelt. – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (8,1) The SRS airbag deploys with considerable speed and force and can injure or even kill chil- dren, especially if they are 12 years of age and under and are not restrained or improperly re- strained. Because children are lighter and weaker than adults, their risk of being injured from deployment is greater. . NEVER INSTALL A REARWARD FACING CHILD SEAT IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. . Always turn the child safety locks to the “LOCK” position when children sit in the rear seat. Serious injury could result if a child accidentally opens the door and falls out. Refer to “Child safety locks” F2-17. . Always lock the passenger’s win- dows using the lock switch when children are riding in the vehicle. Failure to follow this procedure could result in injury to a child operating the power window. Re- fer to “Windows” F2-17. . Never leave unattended children, adults or animals in the vehicle. They could accidentally injure themselves or others through inadvertent operation of the ve- hicle. Also, on hot or sunny days, temperature in a closed vehicle could quickly become high en- ough to cause severe or possibly fatal injuries to them. . Help prevent children, adults or animals from locking themselves in the trunk. On hot or sunny days, the temperature in the trunk could quickly become high enough to cause death or serious heat-related injuries including brain damage to anyone locked inside, particularly for small chil- dren. . When leaving the vehicle, either close all windows and lock all doors. Also make certain that the trunk is closed. For instructions and precautions, carefully read the following sections. . For the seatbelt system, refer to “Seat- belts” F1-12. . For the child restraint system, refer to “Child restraint systems” F1-25. . For the SRS airbag system, refer to “*SRS airbag (Supplemental Restraint System airbag)” F1-38. & Engine exhaust gas (carbon monoxide) WARNING . Never inhale engine exhaust gas. Engine exhaust gas contains carbon monoxide, a colorless and odorless gas which is dan- gerous, or even lethal, if inhaled. . Always properly maintain the en- gine exhaust system to prevent engine exhaust gas from enter- ing the vehicle. . Never run the engine in a closed space, such as a garage, except for the brief time needed to drive the vehicle in or out of it. . Avoid remaining in a parked vehicle for a lengthy time while the engine is running. If that is unavoidable, then use the venti- lation fan to force fresh air into the vehicle. . Always keep the front ventilator inlet grille free from snow, leaves or other obstructions to ensure 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 the ventilation system al- that ways works properly. . If at any time you suspect that exhaust fumes are entering the vehicle, have the problem checked and corrected as soon as possible. If you must drive under these conditions, drive only with all windows fully open. . Keep the trunk lid or rear gate closed while driving to prevent exhaust gas from entering the vehicle. Black plate (9,1) & Drinking and driving & Drugs and driving WARNING WARNING Drinking and then driving is very dangerous. Alcohol in the blood- stream delays your reaction time and impairs your perception, judg- ment and attentiveness. If you drive after drinking – even if you drink just a little – it will increase the risk of being involved in a serious or fatal accident, injuring or killing yourself, your passengers and others. In if you are injured in the addition, accident, alcohol may increase the severity of that injury. Please don’t drink and drive. the most Drunken driving is one of frequent causes of accidents. Since alco- hol affects all people differently, you may have consumed too much alcohol to drive safely even if the level of alcohol in your blood is below the legal limit. The safest thing you can do is never drink and drive. However if you have no choice but to drive, stop drinking and sober up comple- tely before getting behind the wheel. There are some drugs (over the counter and prescription) that can delay your reaction time and impair your perception, judgment and at- tentiveness. If you drive after taking them, it may increase your, your passengers’ and other persons’ risk of being involved in a serious or fatal accident. If you are taking any drugs, check with your doctor or pharmacist or read the literature that accompanies the medication to determine if the drug you are taking can impair your driving ability. Do not drive after taking any medications that can make you drowsy or otherwise affect your ability to safely operate a motor vehicle. If you have a medical condition that requires you to take drugs, please consult with your doctor. Never drive if you are under the influence of any illicit mind-altering drugs. For your own health and well-being, we urge you not to take illegal drugs in the first place and to seek treatment if you are addicted to those drugs. – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (10,1) & Driving when tired or sleepy WARNING When you are tired or sleepy, your reaction time will be delayed and your perception, judgment and at- tentiveness will be impaired. If you drive when tired or sleepy, your, your passengers’ and other per- sons’ chances of being involved in a serious accident may increase. Please do not continue to drive but instead find a safe place to rest if you are tired or sleepy. On long trips, you should make periodic rest stops to refresh yourself before continuing on your journey. When possible, you should share the driving with others. & Modification of your vehicle CAUTION Your vehicle should not be modified other than with genuine SUBARU parts and accessories. Other types of modifications could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from modification may not be cov- ered under warranties. wish to operate the controls of the navigation system, take the vehicle off the road and stop it in a safe place. first & Car phone/cell phone and driving CAUTION Do not use a car phone/cell phone while driving; it may distract your attention from driving and can lead to an accident. If you use a car phone/cell phone, pull off the road and park in a safe place before using your phone. In some States/ Provinces, only hands-free phones may legally be used while driving. & Driving vehicles equipped with navigation system WARNING Do not allow the monitor to distract your attention from driving. Also, do not operate the controls of the navigation system while driving. The loss of attention to driving could lead to an accident. If you & Driving with pets Unrestrained pets can interfere with your driving and distract your attention from driving. In a collision or sudden stop, unrestrained pets or cages can be thrown around inside the vehicle and hurt you or your passengers. Besides, the pets can be hurt under these situations. It is also for their own safety that pets should be properly restrained in your vehicle. Re- strain a pet with a special traveling harness which can be secured to the rear seat with a seatbelt or use a pet carrier which can be secured to the rear seat by through the carrier’s routing a seatbelt handle. Never restrain pets or pet carriers in the front passenger’s seat. For further information, consult your veterinarian, local animal protection society or pet shop. 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 & Tire pressures Check and, the pressure of each tire (including the spare) at least once a month and before any long journey. if necessary, adjust Check the tire pressure when the tires are cold. Use a pressure gauge to adjust the tire pressures to the values shown on the tire placard. For detailed information, refer to “Tires and wheels” F11-21. WARNING Driving at high speeds with exces- sively low tire pressures can cause the tires to deform severely and to rapidly become hot. A sharp in- crease in temperature could cause tread separation, and destruction of the tires. The resulting loss of vehicle control could lead to an accident. General information & California proposition 65 warning WARNING Engine exhaust, some of its consti- tuents, and certain vehicle compo- nents contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addi- tion, certain fluids in vehicles and certain components of product wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. & California Perchlorate Advi- sory Certain vehicle components such as air- bag modules, seatbelt pretensioners and keyless entry transmitter batteries may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/ hazardouswaste/perchlorate. Black plate (11,1) & Noise from under the vehicle NOTE You may hear a noise from under the vehicle approximately 5 to 10 hours after the engine is turned off. However, this does not indicate a malfunction. This noise is caused by the operation of the fuel evaporation leakage check- ing system and is normal. The noise will stop after approximately 15 min- utes. & Event data recorder This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road ob- stacle, data that will assist in understand- ing how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as: . How various systems in your vehicle were operating; . Whether or not the driver and passen- ger safety belts were buckled/fastened; . How far (if at all) the driver was – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 10 depressing the accelerator and/or brake pedal; and, . How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely ac- quired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the informa- tion if they have access to the vehicle or the EDR. Black plate (12,1) 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (1,1) Table of contents Seat, seatbelt and SRS airbags Keys and doors Instruments and controls Climate control Audio Interior equipment Starting and operating Driving tips In case of emergency Appearance care Maintenance and service Specifications Consumer information and Reporting safety defects Index 10 11 12 13 14 北米Model "A1140BE-A" Edited: 2012/ 1/ 30 12 Illustrated index & Exterior Black plate (14,1) 1) Engine hood (page 11-5) 2) Wiper switch (page 3-69) 3) Headlight switch (page 3-63) 4) Replacing bulbs (page 11-37) 5) Moonroof (page 2-24) 6) Outside mirrors (page 3-78) 7) Door locks (page 2-3) 8) 9) 10) Snow tires (page 8-10) 11) Fog light switch (page 3-67) 12) Tie-down hooks (page 9-12) 13) Towing hook (page 9-12) Tire pressure (page 11-23) Flat tires (page 9-5) 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (15,1) 13 Fuel filler lid and cap (page 7-4) 1) Rear window defogger (page 3-80) 2) 3) Child safety locks (page 2-17) 4) 5) 6) Rear gate (page 2-23) 7) Tie-down hole (page 9-12) Trunk lid (page 2-20) Towing hook (page 9-12) – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 14 & Interior ! Passenger compartment area Black plate (16,1) 1) Lower anchorages for child restraint system (page 1-32) 2) Seatbelt (page 1-12) 3) Front seat (page 1-2) 4) Rear seat (page 1-7) 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 0 Black plate (17,1) 15 1) Power windows (page 2-17) 2) Door locks (page 2-3) 3) Outside mirror switch (page 3-78) 4) Glove box (page 6-5) 5) 6) Shift lever (MT) (page 7-16)/Select lever Front power supply socket (page 6-7) (CVT) (page 7-18) 7) Parking brake lever (page 7-32) 8) Cup holder (page 6-6) 9) Center console (page 6-5) – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 16 & Instrument panel Black plate (18,1) 1) Illumination brightness control (page 3-66) 2) Vehicle Dynamics Control OFF switch (page 7-30) 3) Audio control buttons (page 5-30) 4) Combination meter (page 3-5) 5) Cruise control (page 7-37) 6) Information display (page 3-23)/Multi function display (page 3-28) 7) Hazard warning flasher switch (page 3-5) 8) Audio (page 5-1) 9) Climate control (page 4-1) 10) Tilt/telescopic steering (page 3-81) 11) Horn (page 3-82) 12) SRS airbag (page 1-38) 13) Multi function display control switches (page 3-28) 14) Hands-free switches (page 5-34) 15) Fuse box (page 11-35) 16) Hood lock release knob (page 11-5) 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 & Light control and wiper control levers/switches Black plate (19,1) 17 1) Windshield wiper (page 3-68) 2) Mist (page 3-69) 3) Windshield washer (page 3-70) 4) Rear window wiper and washer switch (page 3-70) 5) Wiper intermittent (page 3-69) time control switch 6) Wiper control lever (page 3-69) Light control switch (page 3-63) 7) 8) Fog light switch (page 3-67) 9) Headlight ON/OFF/AUTO (page 3-63) 10) Headlight flasher High/Low beam change (page 3-64) 11) Turn signal lever (page 3-66) – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 18 & Combination meter ! U.S.-spec. models Black plate (20,1) Tachometer (page 3-7) Trip meter and odometer (page 3-6) 1) 2) 3) Select lever/gear position indicator (page 3-21) 4) Speedometer (page 3-6) 5) Information display selection knob (page 3-23) 6) ECO gauge (page 3-8) Fuel gauge (page 3-8) 7) Trip meter A/B selection and trip meter 8) reset knob (page 3-7) The illustration above is a typical example. For some models, the combination meter may be slightly different than that shown in the illustration. 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 ! Except U.S.-spec. models Black plate (21,1) 19 Tachometer (page 3-7) Trip meter and odometer (page 3-6) 1) 2) 3) Select lever/gear position indicator (page 3-21) 4) Speedometer (page 3-6) 5) Information display selection knob (page 3-23) 6) ECO gauge (page 3-8) Fuel gauge (page 3-8) 7) Trip meter A/B selection and trip meter 8) reset knob (page 3-7) The illustration above is a typical example. For some models, the combination meter may be slightly different than that shown in the illustration. – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 20 & Warning and indicator lights Mark Name Page Seatbelt warning light 3-9 Front passenger’s seatbelt warning light SRS airbag system warning light Front passenger’s frontal airbag ON indi- cator Front passenger’s frontal airbag OFF in- dicator CHECK ENGINE warning light/Malfunc- tion indicator light Coolant temperature low indicator light/ Coolant temperature high warning light 3-9 3-11 3-11 3-11 3-12 3-13 Charge warning light 3-14 Oil pressure warning light Engine oil level warn- ing light 3-14 3-14 Black plate (22,1) Mark Name AT OIL TEMP warning light (CVT models) Page 3-15 ABS warning light 3-16 Mark Name High beam indicator light Automatic headlight beam leveler warning light (if equipped) Page 3-22 3-22 Brake system warning light Door open warning light AWD warning light (AWD CVT models) Power steering warn- ing light Hill start assist warn- ing light/Hill start assist OFF indicator light Vehicle Dynamics Control warning light/ Vehicle Dynamics Control operation indi- cator light Vehicle Dynamics Control OFF indicator light Turn signal indicator lights 3-17 3-18 3-19 3-19 3-18 3-19 3-21 3-22 Front fog light indicator light (if equipped) 3-22 Security indicator light 3-21 Headlight indicator light (if equipped) Cruise control indica- tor light Cruise control set in- dicator light 3-22 3-22 3-22 Low fuel warning light 3-18 Low tire pressure warning light (U.S.-spec. models) Windshield washer fluid warning light 3-15 3-14 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Function settings Black plate (23,1) 21 A SUBARU dealer can change the settings of the functions shown in the following table to meet your personal requirements. Contact the nearest SUBARU dealer for details. If your vehicle is equipped with a multi function display, the settings for some of these functions can be changed using the display. For details, refer to “Multi function display (Non-US vehicles only; if equipped)” F3-28. Item Alarm system Function Alarm system Possible settings Operation/Non-operation Default setting Operation Monitoring start delay time (after closure of doors) 0 second/30 seconds 30 seconds Impact sensor operation (only models with shock sensors (dealer option)) Operation/Non-operation Non-operation Passive arming Operation/Non-operation Non-operation Dome light and map lights illumination (models with moonroof) ON/OFF OFF Dome light illumination (models without moonroof) Remote keyless entry system Hazard warning flasher Key lock-in prevention Audible signal Key lock-in prevention Operation/Non-operation Operation/Non-operation Operation/Non-operation Operation Operation Operation Defogger and deicer system for models with the automatic climate control system Rear window defogger, outside mirror defogger and windshield wiper deicer Operation for 15 minutes/ Continuous operation Operation for 15 minutes Dome light Operation of dome light/map light OFF delay timer OFF/Short/Normal/Long Long Map light for models with a moonroof Battery drainage prevention function Battery drainage prevention function Seatbelt warning Sounds a chime while driving Operation/Non-operation Operation/Non-operation Operation Operation Auto on/off headlights (if equipped) Sensitivity of the operation of the auto on/off headlights Low/Normal/High/Very high Normal 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (2,1) — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — Left Page Model "ALL_MODEL_MEMO" EDITED: 2007/ 6/ 22 Front seats........................................................... Forward and backward adjustment ...................... Reclining the seatback ........................................ Seat cushion height adjustment (driver’s seat) ..... Head restraint adjustment (if equipped)................ Seat heater (if equipped) .................................... Rear seats............................................................ Armrest (if equipped)........................................... Head restraint adjustment.................................... Folding down the rear seatback........................... 1-2 1-3 1-3 1-4 1-4 1-6 1-7 1-7 1-8 1-9 Seatbelts ............................................................. 1-12 Seatbelt safety tips............................................. 1-12 Emergency Locking Retractor (ELR) ................... 1-13 Automatic/Emergency Locking Retractor (A/ELR) ............................................................ 1-13 Seatbelt warning light and chime ........................ 1-13 Fastening the seatbelt ........................................ 1-13 Seatbelt maintenance ......................................... 1-20 Front seatbelt pretensioners ............................. 1-21 Seatbelt with shoulder belt pretensioner ............. 1-21 Seatbelt with shoulder belt and lap belt pretensioners................................................... 1-22 System monitors ................................................ 1-24 Black plate (1,1) Seat, seatbelt and SRS airbags System servicing ............................................... Precautions against vehicle modification ............ Child restraint systems ..................................... Where to place a child restraint system.............. Choosing a child restraint system ...................... Installing child restraint systems with A/ELR seatbelt ........................................................... Installing a booster seat..................................... Installation of child restraint systems by use of lower and tether anchorages (LATCH) .............. Top tether anchorages ....................................... *SRS airbag (Supplemental Restraint System airbag)................................................ Models with SRS airbags and lap/shoulder restraints for driver, front passenger, and window-side rear passengers........................... SUBARU advanced frontal airbag system ........... SRS side airbag and SRS curtain airbag............. SRS airbag system monitors.............................. SRS airbag system servicing ............................. Precautions against vehicle modification ............ 1-24 1-24 1-25 1-26 1-27 1-27 1-31 1-32 1-35 1-38 1-38 1-42 1-53 1-63 1-64 1-65 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 If the front seatbacks are not used in the upright position in a collision, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death. . The SRS airbags deploy with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries. Because the SRS airbag needs enough space for deploy- ment, the driver should always sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full vehicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat. 1-2 Seat, seatbelt and SRS airbags Front seats WARNING . Never adjust the seat while driv- ing to avoid the possibility of loss of vehicle control and of personal injury. . Before adjusting the seat, make sure the hands and feet of rear seat passengers and cargo are clear of the adjusting mechan- ism. . After adjusting the seat, push it slightly to make sure it is se- curely locked. If the seat is not securely locked, it may move or the seatbelt may not operate properly. . Do not put objects under the front seats. They may interfere with front seat locking and cause an accident. . Seatbelts provide maximum re- straint when the occupant sits well back and upright in the seat. To reduce the risk of sliding under the seatbelt in a collision, the front seatbacks should be always used in the upright posi- tion while the vehicle is running. Black plate (26,1) WARNING Put children aged 12 and under in the rear seat properly restrained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially if they are 12 years of age and under and are not restrained or improperly restrained. Because chil- dren are lighter and weaker than adults, their risk of being injured from deployment is greater. For that reason, we strongly recommend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly re- strained at all times in a child 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 restraint device or in a seatbelt, whichever is appropriate for the child’s age, height and weight. Se- cure ALL types of child restraint devices (including forward facing child seat) in the REAR seats at all times. NEVER INSTALL A REARWARD FA- CING CHILD SEAT IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. According to accident statistics, children are safer when properly restrained in the rear seating posi- tions than in the front seating posi- tions. For instructions and precau- tions concerning child restraint sys- tems, refer to “Child restraint sys- tems” F1-25. Black plate (27,1) & Forward and backward ad- justment & Reclining the seatback Seat, seatbelt and SRS airbags 1-3 Pull the lever upward and slide the seat to the desired position. Then release the lever and try to move the seat back and forth to make sure that it is securely locked into place. Pull the reclining lever up and adjust the seatback to the desired position. Then release the lever and make sure the seatback is securely locked into place. The seatback placed in a reclined position can spring back upward with force when the lever is pulled. While operating the lever to return the seatback, hold the seatback lightly so that it may be raised back gradually. – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (28,1) 1-4 Seat, seatbelt and SRS airbags & Seat cushion height adjust- ment (driver’s seat) & Head restraint adjustment (if equipped) WARNING To prevent the passenger from slid- ing under the seatbelt in the event of a collision, always put the seatback in the upright position while the vehicle is in motion. Also, do not place objects such as cushions between the passenger and the seatback. If you do so, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death. 1) When the lever is pushed down, the seat is lowered. 2) When the lever is pulled up, rises. the seat The height of the seat can be adjusted by moving the seat cushion adjustment lever up and down. WARNING . Never drive the vehicle with the head restraints removed because they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear. Also, never install the head restraints the opposite way round. Doing so will prevent the head restraints from func- tioning as intended. Therefore, when you remove the head re- straints, you must reinstall all head restraints correctly to pro- tect vehicle occupants. . All occupants, including the dri- ver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to mini- mize the risk of neck injury in the event of a crash. The head restraints for the driver’s seat and front passenger’s seat are adjustable in the following ways. 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 ! Head restraint height adjustment are located on the top of the seatback until the head restraint locks. ! Head restraint angle adjustment Black plate (29,1) Seat, seatbelt and SRS airbags 1-5 again to the preferred angle. 1) Head restraint 2) Release button Each head restraint should be adjusted so that is closest to the top of the occupant’s ears. the head restraint the center of To raise: Pull the head restraint up. To lower: Push the head restraint down while pressing the release button on the top of the seatback. To remove: While pressing the release button, pull out the head restraint. To install: Install the head restraint into the holes that The angle of the head restraint can be adjusted in several steps. While maintain- ing a suitable driving posture, adjust the head restraint to a position where the back of your head is as close to the head restraint as possible. To tilt: the head restraint by hand to the Tilt preferred position. A click will be audible when the head restraint is locked. To return: Tilt the head restraint once as far forward as it can go. The head restraint will automatically return to the fully upright position. Then, adjust the head restraint 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 1-6 Seat, seatbelt and SRS airbags Seat heater (if equipped) The seat heater is equipped in the front seats. The seat heater operates when the igni- tion switch is either in the “ACC” or “ON” position. CAUTION . There is a possibility that people with delicate skin may suffer slight burns even at low tempera- tures if they use the seat heater for a long period of time. When using the heater, always be sure to warn the persons concerned. . Do not put anything on the seat which insulates against heat, such as a blanket, cushion, or similar items. This may cause the seat heater to overheat. NOTE Use of the seat heater for a long period of time while the engine is not running can cause battery discharge. Black plate (30,1) depending on the temperature. Selecting the “HI” position will cause the seat to heat up quicker. To turn off the seat heater, lightly press the opposite side of the current position. The indicator located on the switch illumi- nates when the seat heater is in operation. When the vehicle’s interior is warmed enough or before you leave the vehicle, be sure to turn the switch off. LO – Normal heating 1) HI – Rapid heating 2) 3) Off A) B) Right-hand side Left-hand side To turn on the seat heater, push the “LO” or “HI” position on the switch, as desired, 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Rear seats WARNING Seatbelts provide maximum re- straint when the occupant sits well back and upright in the seat. Do not put cushions or any other materials between occupants and seatbacks or seat cushions. If you do so, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or death. Black plate (31,1) Seat, seatbelt and SRS airbags 1-7 & Armrest (if equipped) WARNING Never stack luggage or other cargo higher than the top of the seatback because it could tumble forward and injure passengers in the event of a sudden stop or accident. To lower the armrest, pull on the top edge of the armrest. WARNING To avoid the possibility of serious injury, passengers must never be allowed to sit on the center armrest while the vehicle is in motion. – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 1-8 Seat, seatbelt and SRS airbags & Head restraint adjustment Both the rear window side seats and the rear center seat are equipped with head restraints. WARNING . Never drive the vehicle with the head restraints removed because they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear. Therefore, when you have removed the head re- straints, you must reinstall all head restraints to protect vehicle occupants. . All occupants, including the dri- ver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to mini- mize the risk of neck injury in the event of a crash. Black plate (32,1) ! Rear windows side seating position tion. 1) Head restraint 2) Release button To remove: While pressing the release button, pull out the head restraint. To install: Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks. ! Rear center seating position CAUTION The head restraint is not intended to be used at the lowest position. Before sitting on the seat, raise the head restraint to the extended posi- 1) Incorrect (retracted position) 2) Correct (extended position) 1) Head restraint 2) Release button 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 folds down. . Never allow passengers to ride on the folded rear seatback or in the cargo area or trunk. Doing so may result in serious injury or death. . Secure all objects and especially long items properly to prevent them from being thrown around inside the vehicle and causing serious injury during a sudden stop, a sudden steering maneu- ver or a rapid acceleration. . When you return the seatback to its original position, shake the seatback slightly to confirm that it is securely fixed in place. If the seatback is not securely fixed in place, the seatback may sud- denly fold down in the event of sudden braking, or objects may move out from the cargo area or trunk, which could cause serious injury or death. To raise: Pull the head restraint up. To lower: Push the head restraint down while pressing the release button on the top of the seatback. To remove: While pressing the release button, pull out the head restraint. To install: Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks. When the rear-center seating position is occupied, raise the head restraint to the extended position. When the rear center seating position is not occupied, lower the head restraint to improve rearward visibi- lity. & Folding down the rear seat- back WARNING . When you fold down the seat- back, check that there are no passengers or objects on the rear seat. Not doing so creates a risk of injury or property da- mage if the seatback suddenly Black plate (33,1) Seat, seatbelt and SRS airbags 1-9 WARNING When the seatback is returned to its original position, observe the follow- ing precautions. Failure to do so may lead to serious injury or an – CONTINUED – 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 Black plate (34,1) 1-10 Seat, seatbelt and SRS airbags accident because the operation effi- ciency of the seatbelt is inhibited. . The seatbelt should not pass behind the securing hook for the seatback. . The seatbelt should not be in the seatback and it caught should be fully visible. ! 4-door models may tear the strap. To return the seatback to its original position, raise the seatback until it locks into place and make sure that it is securely locked. In order to enable lock release of the seatback from the trunk side, adjust the lock release strap as follows. Unlock the seatback by pulling the lock release strap and then fold the seatback down. CAUTION Do not operate the seatback with the lock release strap pulled. Doing so 1. Pull the lock release strap behind the seatback out from its holder. 2. Install the strap on the seatback and raise the seatback until it locks into place. Make sure that the seatback is securely locked. 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 In this case, unlock the seatback by pulling the strap down and then fold the seatback forward from the trunk. ! 5-door models Lock release knob 1) Unlocked 2) A) Unlocking marker in red Locked When the seatback is locked, the lock release knob is automatically pulled into the seatback and the unlocking marker, which is red colored and attached to the bottom of the lock release knob, will no longer be visible. Unlock the seatback by pulling the lock release knob and then fold the seatback down. To return the seatback to its original position, raise the seatback until it locks into place and make sure that it is securely locked referring to the following descrip- tion. Black plate (35,1) Seat, seatbelt and SRS airbags 1-11 WARNING After returning the seatback to its original position, confirm that the unlocking marker of the lock release knob is no longer visible. Failure to do so could lead to serious injury or death in the event of an accident. 北米Model "A1140BE-A" EDITED: 2012/ 6/ 20 1-12 Seat, seatbelt and SRS airbags Seatbelts & Seatbelt safety tips WARNING . All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Other- wise, the possibility of serious injury becomes greater in the event of a sudden stop or acci- dent. . All belts should fit snugly in order to provide full restraint. Loose fitting belts are not as effective in preventing or reducing injury. . Each seatbelt is designed to support only one person. Never use a single belt for two or more persons – even children. Other- wise, in an accident, serious injury or death could result. . Replace all seatbelt assemblies including retractors and attach- ing hardware worn by occupants of a vehicle that has been in a serious accident. The entire as- sembly should be replaced even if damage is not obvious. . Put children aged 12 and under in Black plate (36,1) the rear seat properly restrained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially if they are 12 years of age and under and are not restrained or improperly restrained. Because children are lighter and weaker than adults, their risk of being injured from deployment is greater. For that
