2003 Pontiac Bonneville Owners Manual

change your oil at 3,000 miles (5 000 km) since your last oil change. Remember to reset the oil life system whenever the oil is changed. See Engine Oil on page 5-15 for information on resetting the system. @ Whenever the tires are rotated, the Check Tire Pressure §ystem must be reset. +A good time to check your brakes is during tire rotation. See Brake System Inspection on page 6-23. 3,000 Miles (5 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

6,000 Miles (IO 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first). An Emission Control Service. (See footnote *.)

-...A n-+-+:-- -- n - 4 - 4 - I wlalc LII ~ a . page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

r?-- -I-:-- I UGG

I 11 G 11 I ~ J G ~ L I V I I a1 IU

I I v L a u v I I V I I

4:--

9,000 Miles (15 000 km) U Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

6-7

12,000 Miles (20 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire lnspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

15,000 Miles (25 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Inspect engine air cleaner filter if you are driving in

dusty conditions. Replace filter if necessary. An Emission Control Service. (See footnote t.)

18,000 Miles (30 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire lnspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote @-) (See footnote +-)

21,000 Miles (35 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

6-8

24,000 Miles (40 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire lnspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

27,000 Miles (45 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

30,000 Miles (50 000 km) Cl Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Replace engine air cleaner filter. An Emission

Control Service.

0 For supercharged engines only: Check the supercharger oil level and add the proper supercharger oil as needed (or every 36 months, whichever occurs first). See Part D: Recommended Fluids and Lubricants on page 6-24. An Emission Control Service. (See footnote t.)

D Rotate tires. See Tire lnspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

33,000 Miles (55 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

36,000 Miles (60 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

39,000 Miles (65 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

42,000 Miles (70 000 km)

Change engine oil and filter (or every 3 months, whichever occurs first). An Emission Control Service. (See footnote *.) Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

45,000 Miles (75 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Inspect engine air cleaner filter if you are driving in

dusty conditions. Replace filter if necessary. An Emission Control Service. (See footnote t.)

48,000 Miles (80 000 km) D Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

50,000 Miles (83 000 km) 0 Change automatic transaxle fluid and filter if the

vehicle is mainly driven under one or more of these conditions:

- In heavy city traffic where the outside

temperature regularly reaches 90°F (32°C) or higher. !n ! i ! ! y c!r mnllnt2innns terr2in.

- When doing frequent trailer towing. - Uses such as found in taxi, police or delivery

service.

If you do not use your vehicle under any of these conditions, change the fluid and filter at 100,000 miles (166 000 km).

6-9

51,000 Miles (85 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

54,000 Miles (90 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire lnspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

57,000 Miles (95 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

60,000 Miles (100 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Replace engine air cleaner filter. An Emission

Control Service.

0 For supercharged engines only: Check the supercharger oil level and add the proper supercharger oil as needed (or every 36 months, whichever occurs first). See Part D: Recommended Fluids and Lubricants on page 6-24. An Emission Control Service. (See footnote f.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

63,000 Miles (105 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

66,000 Miles (110 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

69,000 Miles (1 15 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

6-1 0

72,000 Miles (120 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

75,000 Miles (125 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *,)

0 Inspect engine air cleaner filter if you are driving in

dusty conditions. Replace filter if necessary. An Emission Control Service. (See footnote t.)

78,000 Miles (130 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service (See footnote *.)

Cl Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

81,000 Miles (135 000 km) i3 Change engine oii and fiiier {or every 3 i ~ ~ ~ i f h ~ ,

whichever occurs first). An Emission Control Service. (See footnote *.)

84,000 Miles (140 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire lnspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

87,000 Miles (145 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

90,000 Miles (150 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

U Replace engine air cleaner filter. An Emission

Control Service.

0 For supercharged engines only: Check the supercharger oil level and add the proper supercharger oil as needed (or every 36 months, whichever occurs first). See Part D: Recommended Fluids and Lubricants on page 6-24. An Emission Control Service. (See footnote t.)

Q Rotate tips. See T i m

I I I G I

I n nor); n 2nd Rotatigr? gr?

I ~ ~ ~ V L I ~ I

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

6-1 1

93,000 Miles (155 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

96,000 Miles (160 000 km) Q Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

99,000 Miles (165 000 km) 0 Change engine oil and filter (or every 3 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

100,000 Miles (166 000 km) 0 Inspect spark plug wires. An Emission Control

Service.

0 Replace spark plugs. An Emission Control Service.

6-13

0 Change automatic transaxle fluid and filter if the

vehicle is mainly driven under one or more of these conditions:

- In heavy city traffic where the outside

temperature regularly reaches 90°F (32°C) or higher.

- In hilly or mountainous terrain. - When doing frequent trailer towing. - Uses such as found in taxi, police or delivery

service.

If you haven’t used your vehicle under severe service conditions listed previously and, therefore, haven’t changed your automatic transaxle fluid, change both the fluid and filter. 150,000 Miles (240 000 km) 0 Drain, flush and refill cooling system (or every

60 months since last service, whichever occurs first). See Engine Coolant on page 5-26 for what to use. Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test the cooling system and pressure cap. An Emission Control Service. 0 Inspect engine accessory drive belt. An Emission

Control Service.

Long Trip/Highway Scheduled Maintenance The services shown in this schedule up to 100,000 miles (166 000 km) should be repeated after 100,000 miles (1 66 800 km) at the same intervals for the life of this vehicle. The services shown at 150,000 miles (240 000 km) should be repeated at the same interval after 150,000 miles (240 000 km) for the life of this vehicle. See Part B: Owner Checks and Services on page 6-18 and Part C: Periodic Maintenance Inspections on page 6-22.

t The U.S. Environmental Protection Agency or the California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of the vehicle 's useful life. We, however, urqe that all recommended maintenance services be performed at the indicated intervals and the maintenance be recorded. * If your vehicle has the GM Oil Life SystemTM, a computer system lets you know when to change the engine oil and filter. This is based on engine revolutions aiid eiigifie telvpei-atdre, and ncf c:: ml?eage. Based

on driving conditions, the mileage at which an oil change will be indicated can vary considerably. For the oil life system to work properly, you must reset the system every time the oil is changed. When the system has calculated that oil life has been diminished, it wil! indicate that an oil change is necessary. An ENGINE OIL CHANGE SOON message will come on. Change your oil as soon as possible within the next two times you stop for fuel. It is possible that, if you are driving under the best conditions, the oil life system may not indicate that an oil change is necessary for over a year. However, your engine oil and filter must be changed at least once a year and at this time the system must be reset. It is also important to check your oil regularly and keep it at the proper level. If the system is ever reset accidentally, you must change your oil at 3,000 miles (5 000 km) since your last oil change. Remember to reset the oil life system whenever the oil is changed. See Engine Oil on page 5-75 for information on resetting the system. @ Whenever the tires are rotated, the Check Tire Pressure System must be reset. + A good time to check your brakes is during tire rotation. See Brake System Inspection on page 6-23.

6-1 3

7,500 Miles (12 500 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

15,000 Miles (25 000 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

22,500 Miles (37 500 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

30,000 Miles (50 000 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

0 Replace engine air cleaner filter. An Emission Control

Service.

0 For supercharged engines only: Check the supercharger oil level and add the proper supercharger oil as needed (or every 36 months, whichever occurs first). See Part D: Recommended Fluids and Lubricants on page 6-24. An Emission Control Service. (See footnote t.)

37,500 Miles (62 500 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

6-1 4

45,000 Miles (75 000 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

50,000 Miles (83 000 km) 0 Change automatic transaxle fluid and filter if the

vehicle is mainly driven under one or more of these conditions:

- In heavy city traffic where the outside

temperature regularly reaches 90°F (32°C) or higher.

- In hilly or mountainous terrain. - When doing frequent trailer towing. - Uses such as found in taxi, police or delivery

service. I f I m r r An nnt I I c n I , /'" U" S . " . conditions, change the fluid and filter at 100,000 miles ( I 66 000 km).

yehjde ~~.ncfer 2n1/ nf thpcp J -. -..---

U"V

52,500 Miles (87 500 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @I.) (See footnote +.)

60,000 Miles (100 000 km) Cl Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 For supercharged engines only: Check the supercharger oil level and add the proper supercharger oil as needed (or every 36 months, whichever occurs first). See Part D: Recommended Fluids and Lubricants on page 6-24. An Emission Control Service. (See footnote t.)

0 Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information (See footnote @.) !See footnote +.)

0 Replace engine air cleaner filter. An Emission Control

Service.

6-1 5

67,500 Miles (112 500 km) 0 Change engine oil and filter (or every 12 months.

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

75,000 Miles (125 000 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

d Rotate tires. See Tire Inspection and Rotation on page 5-65 for proper rotation pattern and additional information. (See footnote 62.) (See footnote +.)

82,500 Miles (137 500 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

6-1 6

90,000 Miles (150 000 km) 0 Change engine oil and filter (or every 12 months

whichever occurs first). An Emission Control Service. (See footnote *.)

c7 Replace engine air cleaner filter. An Emission

Control Service.

0 For supercharged engines only: Check the supercharger oil level and add the proper supercharger oil as needed (or every 36 months, whichever occurs first). See Part D: Recommended Fluids and Lubricants on page 6-24. An Emission Control Service. (See footnote t.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

97,500 Miles (162 500 km) 0 Change engine oil and filter (or every 12 months,

whichever occurs first). An Emission Control Service. (See footnote *.)

0 Rotate tires. See Tire Inspection and Rotation on

page 5-65 for proper rotation pattern and additional information. (See footnote @.) (See footnote +.)

100,000 Miles (166 000 km) 0 Inspect spark plug wires. An Emission Control

Service.

0 Replace spark plugs. An Emission Control Service. 0 Change automatic transaxle fluid and filter if the

vehicie is mainly driven under one or more of these conditions:

- In heavy city traffic where the outside

temperature regularly reaches 90°F (32°C) or higher.

150,000 Miles (240 000 km) 0 Drain, flush and refill cooling system (or every

60 months since last service, whichever occurs first). See Engine Coolant on page 5-26 for what to use. Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test the cooling system and pressure cap. An Emission Control Service. tl Inspect engine accessory drive belt. An Emission

Control Service.

- In hilly or mountainous terrain. - When doing frequent trailer towing. - Uses such as found in taxi, poiice or delivery

service.

0 If you haven’t used your vehicle under severe service

conditions listed previously and, therefore, haven’t changed your automatic transaxle fluid, change both the fluid and filter.

6-1 7

Part B: Owner Checks and Services Listed in this part are owner checks and services which should be perFormed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Part D. At Each Fuel Fill It is important for you or a service station attendant to perform these underhood checks at each fuel fill. Engine Oil Level Check Check the engine oil level and add the proper oil if necessary. See Engine Oil on page 5-75 for further details.

Engine Coolant Level Check Check the engine coolant level and add DEX-COOL@ coolant mixture if necessary. See Engine Coolant on page 5-26 for further details. Windshield Washer Fluid Level Check Check the windshield washer fluid level in the windshield washer tank and add the proper fluid if necessary. See Windshield Washer Fluid on page 5-40 for further details. At Least Once a Month Tire Inflation Check Make sure tries are inflated to the correct pressures. Don’t forget to check your spare tire. See Tires on page 5-62 for further details. Cassette Tape Player Service Clean cassette tape player. Cleaning should be done every 50 hours of tape play. See Audio System(s) on page 3-77 for further details.

6-1 8

Automatic Transaxle Check Check the transaxle fluid level; add if needed. See Automatic Transaxle Fluid on page 5-23. A fluid loss may indicate a problem. Check the system and repair if needed.

At Least Once a Year Key Lock Cylinders Service Lubricate the key lock cylinders with the lubricant specified in Part D.

Lubricate all hinges and latches, including those for the hood, rear compartment, glove box door, console door and any folding seat hardware. Part D tells you what to use. More frequent lubrication may be required when exposed to a corrosive environment.

At Least Twice a Year Restraint System Check Make sure the safety belt reminder light and all your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired. Have any torn or frayed safety belts replaced. Also look for any opened or broken air bag coverings, and have them repaired or replaced. (The air bag system does not need regular maintenance.) Wiper Blade Check Inspect wiper blades for wear or cracking. Replace blade inserts that appear worn or damaged or that streak or miss areas of the windshield. Also see “Windshield Wiper and Wiper Blades” under Cleaning the Outside of Your Vehicle on page 5-85. Weatherstrip Lubrication Silicone grease on weatherstrips will make them last longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth, During very cold, damp weather more frequent application may be required. See Part D: Recommended Fluids and Lubricants on page 6-24.

6-1 9

Starter Swit+ ?heck

Automatic Transaxle Shift Lock Control System Check

When you are doing this check, the vehicle could move suddenly. If it does, you or others could be injured. Follow the steps below.

When you are doing this check, the vehicle could move suddenly. If it does, you or others could be injured. Follow the steps below.

Before you start, be sure you have enough room around the vehicle. Firmly apply both the parking brake and the regular brake. See Parking Brake on page 2-31 if necessary. Do not use the accelerator pedal, and be ready to turn off the engine immediately if it starts. Try to start the engine in each gear. The starter should work only in PARK (P) or NEUTRAL (N). If the starter works in any other position, your vehicle needs service.

1.

2.

3.

Before you start, be sure you have enough room around the vehicle. It should be parked on a level surface. Firmly apply the parking brake. See Parking Brake on page 2-31 if necessary. Be ready to apply the regular brake immediately if the vehicle begins to move. With the engine off, turn the key to the ON position, but don’t start the engine. Without applying the regular brake, try to move the shift lever out of PARK (P) with normal effort. If the shift lever moves out of PARK (P), your vehicle needs service.

1.

2.

3.

6-20

ignition Transaxle Lock Check While parked, and with the parking brake set, try to turn the ignition key to OFF in each shift lever position.

The key should turn to OFF only when the shift lever is in PARK (P).

0 The key should come out only Parking Brake and Automatic Transaxle Park (P) Mechanism Check

in OFF.

this check, your vehicle

When you are g could begin to move. You or others could be injured and property could be damaged. Make sure there is room in front of your vehicle in case it begins to roll. Be ready to apply the regular brake at once should the vehicle begin to move.

Park on a fairly steep hill, with the vehicle facing downhill. Keeping your foot on the regular brake, set the parking brake.

To check the parking brake’s holding ability: With the engine running and transaxle in NEUTRAL (N), slowly remove foot pressure from the regular brake pedal. Do this until the vehicle is held by the parking brake only. To check the PARK (P) mechanism’s holding ability: With the engine running, shift to PARK (P). Then release the parking brake followed by the regular brake.

Underbody Flushing Service At least every spring, use plain water to flush any corrosive materials from the underbody. Take care to clean thoroughly any areas where mud and other debris can collect.

6-2 1

Exhaust System Inspection Inspect the complete exhaust system. Inspect the body near the exhaust system. Look for broken, damaged, missing or out-of-position parts as well as open seams, holes, loose connections or other conditions which could cause a heat build-up in the floor pan or could let exhaust fumes into the vehicle. See Engine Exhaust on page 2-36. Fuel System Inspection Inspect the complete fuel system for damage or leaks.

Part C: Periodic Maintenance Inspections

Listed in this part are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your dealer’s service department or other qualified service center dc these jobs. Make sure any necessary repairs are completed at once. Proper procedures to perform these services may be found in a service manual. See Service Publications Ordering Information on page 7-9.

Steering, Suspension and Front Drive Axle Boot and Seal Inspection

Inspect the front and rear suspension and steering system for damaged, loose or missing parts, signs of wear or lack of lubrication. Inspect the power steering lines and hoses for proper hook-up, binding, leaks, cracks, chafing, etc. Clean and then inspect the drive axle boot seals for damage, tears or leakage. Replace seals if necessary.

6-22

Brake System Inspection Inspect the complete system. Inspect brake lines and hoses for proper hook-up, binding, leaks, cracks, chafing, etc. Inspect disc brake pads for wear and rotors for surface condition. Inspect other brake parts, including calipers, parking brake, etc. You may need to have your brakes inspected more often if your driving habits or conditions result in frequent braking.

Engine Cooling System Inspection Inspect the hoses and have them replaced if they are cracked, swollen or deteriorated. Inspect all pipes, fittings and clamps; replace as needed. Clean the outside of the radiator and air conditioning condenser. To help ensure proper operation, a pressure test of the cooling system and pressure cap is recommended at least once a year. Throttle System Inspection Inspect the throttle system for interference or binding, and for damaged or missing parts. Replace parts as needed. Replace any components that have high effort or excessive wear. Do not lubricate accelerator and cruise control cables.

6-23

Part D: Recommended Fluids and Lubricants Fluids and lubricants identified below by name, part number or specification may be obtained from your dealer.

Usaae

Fluid/Lubricant

Engine Oil

Engine Coolant

Automatic

Institute Certified

the American Engine oil with Petroleum for Gasoline Engines starburst symbol of the proper viscosity. To determine the preferred viscosity for your vehicle's engine, see Engine Oil on page 5- 75. 50/50 mixture of clean, drinkable water and use only DEX-COOL Coolant. See Engine Coolant on Daae 5-26. , " Delco Supreme 11 Brake Fluid or

Hydraulic

Brake System equivalent DOT-3 brake fluid.

DEXRON@-Ill

Usage

Washer Solvent

Parking Brake Cab'e Guides equivalent) or

Fluid/Lubricant

GM Optikleen Washer Solvent or equivalent. Chassis Lubricant (GM Part No. US. 12377985, in Canada 88901242, or

lubricant meeting

requirements of NLGI #2, Category LB or GC-LB.

Steering Fluid (GM Part in Canada

No. US. 1052884, 993294, or equivalent).

Transmission Fluid. Multi-Purpose Lubricant, Superlube (GM Part No. Canada 10953474, or equivalent). Supercharger Oil (GM Part No. U.S. 12345982, in Canada 1095351 3). See Supercharger Oil on page 5-21.

U.S. 12346241, in

Power GM Power Steering System Automatic Transaxle Key Lock Cylinders

Supercharger

6-24

Usage

Floor Shift Linkage

Hood Latch Assembly, Secondary Latch, Pivots, Spring Anchor and Release

Pawl

Hood and Door Hinges

Fluid/Lubricant

Lubridate Lubricant Aerosol (GM Part No. U.S. 12346293, 992723, or equivalent) or lubricant meeting requirements Category L5 or GC-L5.

in Canada

of NLGl #2,

Weatherstrip ‘Onditioning

Dielectric Silicone Grease (GM Part No. US. 12345579, in Canada 1974984, or equivalent).

Lubriplate Lubricant Aerosol (GM Part No. U.S. 12346293, in Canada 992723, or equivalent) or lubricant meeting requirements Category LB or GC-L5.

of NLGl #2,

Multi-Purpose Lubricant, Superlube (GM Part No. Canada 10953474, or equivalent).

U.S. 12346241, in

6-25

Part E: Maintenance Record

After the scheduled services are performed, record the date, odometer reading and who performed the service and any additional information from “Owner Checks and Services” or “Periodic Maintenance” on the following record pages. Also, you should retain all maintenance receipts.

Maintenance Record

6-26

Maintenance Record (cont’d)

6-27

Maintenance Record (cont’d)

6-28

Section 7 Customer Assistance Information

Customer Assistance

Customer Satisfaction Procedure Customer Assistance for Text Telephone

Information ...................... 7.2 ...................... 7.2

(TTY) Users ............................................ 7.3 7.3

Customer Assistance GM Mobility Program for Persons with

............................

Disabilities .................................................. 7.4 ......... 7.5

Roadside Assistance Program

Off ices

.........

Courtesy Transportation ................................... 7.6 Reporting Safety Defects to the United States Government ...............................................

Reporting Safety Defects to the Canadian

Government

............................................... 7.8 ....... Reporting Safety Defects to General Motors 7.9 Service Publications Ordering Information ........... 7.9

7-8

7- 1

Customer Assistance information

Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and to Pontiac. Normally, any concerns with the sales transaction or the operation of your vehicle will be resolved by your dealer’s sales or service departments. Sometimes, however, despite the best intentions of all concerned, misunderstandings can occur. If your concern has not been resolved to your satisfaction, the following steps should be taken: STEP ONE: Discuss your concern with a member of dealership management. Normally, concerns can be quickly resolved at that level. If the matter has already been reviewed with the sales, service or parts manager, contact the owner of the dealership or the general manager. STEP TWO: If after contacting a member of dealership management, it appears your concern cannot be resolved by the dealership without further help, contact the Pontiac Customer Assistance Center by calling 1-800-762-2737. In Canada, contact GM of Canada Customer Communication Centre in Oshawa by calling 1-800-263-3777 (English) or 1-800-263-7854 (French).

7-2

We encourage you to call the toll-free number in order to give your inquiry prompt attention. Please have the following information available to give the Customer Assistance Representative:

Vehicle Identification Number (This is available from the vehicle registration or title, or the plate at the top left of the instrument panel and visible through the windshield.) Dealership name and location Vehicle delivery date and present mileage

if you

When contacting Pontiac, please remember that your concern will likely be resolved at a dealer’s facility. That is why we suggest you follow Step One first have a concern. STEP THREE: Both General Motors and your dealer are committed to making sure you are completely satisfied with your new vehicle. However, if you continue to remain unsatisfied after following the procedure outlined in Steps One and Two, you should file with the GM/BBB Auto Line Program to enforce any additional rights you may have. Canadian owners refer to your Warranty and Owner Assistance Information booklet for information on the Canadian Motor Vehicle Arbitration Plan (CAMVAP).

The BBB Auto Line Program is an out of court program administered by the Council of Better Business Bureaus to settle automotive disputes regarding vehicle repairs or the interpretation of the New Vehicle Limited Warranty. Although you may be required to resort to this informal dispute resolution program prior to filing a court action, use of the program is free of charge and your case will generally be heard within 40 days. If you do not agree with the decision given in your case, you may reject it and proceed with any other venue for relief available to you. You may contact the BBB using the toll-free telephone number or write them at the following address: BBB Auto Line Council of Better Business Bureaus, Inc. 4200 Wilson Boulevard Suite 800 Arlington, VA 22203-1 804 Telephone: 1-800-955-51 00 This program is available In all 50 states ana tne uistrict of Columbia. Eligibility is limited by vehicle age, mileage and other factors. General Motors reserves the right to change eligibility limitations and/or discontinue its participation in this program.

Customer Assistance for Text Telephone (TTY) Users To assist customers who are deaf, hard of hearing, or speech-impaired and who use Text Telephones (TTYs), Pontiac has TTY equipment available at its Customer Assistance Center. Any TTY user can communicate with Pontiac by dialing: 1 -800-833-PONT (7668). (TTY users in Canada can dial 1-800-263-3830.) Customer Assistance Off ices Pontiac encourages customers to call the toll-free number for assistance. If a U.S. customer wishes to write to Pontiac, the letter should be addressed to Pontiac’s Customer Assistance Center. United States Pontiac-GMC Customer Assistance Center P.O. Box 33172 Detroit. MI 48232-51 72 1-800-762-2737 or 1-800-833-7668 (For Text Telephone devices (TTYs)) Roadside Assistance: 1 -800-ROADSIDE (762-3743) Fax Number: 31 3-381 -0022

7-3

From Puerto Rico: 1-800-496-9992 (English) 1 -800-496-9993 (Span ish) Fax Number: 31 3-381 -0022 From U.S. Virgin Islands: 1-800-496-9994 Fax Number: 31 3-381 -0022 Canada General Motors of Canada Limited Customer Communication Centre, 163-005 1908 Colonel Sam Drive Oshawa, Ontario L1H 8P7 1-800-263-3777 (English) 1 -800-263-7854 (French) 1-800-263-3830 (For Text Telephone devices (TTYs)) Roadside Assistance: 1-800-268-6800 All Overseas Locations Please contact the local General Motors Business Unit.

Mexico, Central America and Caribbean Islands/Countries (Except Puerto Rico and U.S. Virgin Islands) General Motors de Mexico, S. de R.L. de C.V. Customer Assistance Center Paseo de la Reforma # 2740 Col. Lomas de Bezares C.P. 11 910, Mexico, D.F. 01 -800-508-0000 Long Distance: 01 1-52-53 29 0 800 GM Mobility Program for Persons with Disabilities

This program, available to qualified applicants, can reimburse you up to $1,000 toward aftermarket driver or passenger adaptive equipment you may require for your vehicle (hand controls, wheelchair/scooter lifts, etc.).

7-4

This program can also provide you with free resource information, such as area driver assessment centers and mobility equipment installers. The program is available for a limited period of time from the date of vehicle purchase/lease. See your dealer for more details or call the GM Mobility Assistance Center at 1-800-323-9935. Text telephone (TTY) users, call 1-800-833-9935. GM of Canada also has a Mobility Program. Call 1-800-GM-DRIVE (463-7483) for details. All TTY users call 1-800-263-3830. Roadside Assistance Program Security While You Travel 1-800- ROA DSlD E ( I -800- 762-3743) As the proud owner of a new Pontiac vehicle, you are automatically enrolled in the Pontiac Roadside Assistance program. This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road. Pontiac’s Roadside Assistance toll-free number is staffed by a team of technically trained advisors, who are available 24 hours a day, 365 days a year. We take anxiety out of uncertain situations by providing minor repair information over the phone or making arrangements to tow your vehicle to the nearest Pontiac dealer.

We will provide the following services for 3 years/36,000 miles (60 000 km), at no expense to you:

Fuel delivery Lock-out service (identification required) Tow to nearest dealership for warranty service Change a flat tire

0 Jump starts We have quick, easy access to telephone numbers of the following additional services depending on your needs:

Hotels Glass replacement 0 Tire repair facilities

Rental vehicle or taxis Airports or train stations Police, fire departments or hospitals

in many insiances, mecnanicai iaiiures dre cuverei under Pontiac’s comprehensive warranty. However, when other services are utilized, our advisors will explain any payment obligations you might incur.

7-5

For prompt and efficient assistance when calling, please provide the following information to give the advisor:

Location of vehicle Telephone number of your location Vehicle model, year and color Mileage of vehicle Vehicle Identification Number (VIN) Vehicle license plate number

Pontiac reserves the right to limit services or reimbursement to an owner or driver when, in Pontiac’s judgement, the claims become excessive in frequency or type of occurrence. While we hope you never have the occasion to use our service, it is added security while traveling for you and your family. Remember, we’re only a phone call away. Pontiac Roadside Assistance: 1 -800-ROADSIDE or 1-800-762-3743, text telephone (TTY) users, call 1-888-889-2438. Canadian Roadside Assistance Vehicles purchased in Canada have an extensive Roadside Assistance program accessible from anywhere in Canada or the United States. Please refer to the Warranty and Owner Assistance Information book.

7-6

Courtesy Transportation Pontiac has always exemplified quality and value in its offering of motor vehicles. To enhance your ownership experience, we and our participating dealers are proud to offer Courtesy Transportation, a customer support program for new vehicles. The Courtesy Transportation program is offered to retail purchase/lease customers in conjunction with the Bumper-to-Bumper coverage provided by the New Vehicle Limited Warranty. Several transportation options are available when warranty repairs are required. This will reduce your inconvenience during warranty repairs. Plan Ahead When Possible When your vehicle requires warranty service, you should contact your dealer and request an appointment. By scheduling a service appointment and advising your service consultant of your transportation needs, your dealer can help minimize your inconvenience. If your vehicle cannot be scheduled into the service department immediately, keep driving it until it can be scheduled for service, unless, of course, the problem is safety-related. If it is, please call your dealership, let them know this, and ask for instructions. If the dealer requests that you simply drop the vehicle off for service, you are urged to do so as early in the work day as possible to allow for same day repair.

Transportation Options Warranty service can generally be completed while you wait. However, if you are unable to wait Pontiac helps minimize your inconvenience by providing several transportation options. Depending on the circumstances, your dealer can offer you one of the following: Shuttle Service Participating dealers can provide you with shuttle service to get you to your destination with minimal interruption of your daily schedule. This includes a one way shuttle ride to a destination up to 10 miles from the dealership. Public Transportation or Fuel Reimbursement If your vehicle requires overnight warranty repairs, reimbursement up to $30 per day (five days maximum) may be available for the use of public transportation such as tax1 or bus. In addition, snoulci you arrange transportation through a friend or relative, reimbursement for reasonable fuel expenses up to $10 per day (five day maximum) may be available. Claim amounts should reflect actual costs and be supported by original receipts.

Courtesy Rental Vehicle When your vehicle is unavailable due to overnight warranty repairs, your dealer may arrange to provide you with a courtesy rental vehicle or reimburse you for a rental vehicle you obtained, at actual cost, up to a maximum of $30.00 per day supported by receipts. This requires that you sign and complete a rental agreement and meet state, local and rental vehicle provider requirements. Requirements vary and may include minimum age requirements, insurance coverage, credit card, etc. You are responsible for fuel usage charges and may also be responsible for taxes, levies, usage fees, excessive mileage or rental usage beyond the completion of the repair. Generally it is not possible to provide a like-vehicle as a courtesy rental. Additional Program lnformation Courtesy Transportation is available during the Bumper-to-Bumper warranty coverage period, but it is nnnt p-? fhe b!p\!! \/phi~!p Limited \A!zrpntt\~ , .V . A separate booklet entitled Warranty and Owner Assistance lnformation furnished with each new vehicle provides detailed warranty coverage information.

I ’

7-7

Courtesy Transportation is available only at participating dealers and all program options, such as shuttle service, may not be available at every dealer. Please contact your dealer for specific information about availability. All Courtesy Transportation arrangements will be administered by appropriate dealer personnel. Canadian Vehicles: For warranty repairs during the Complete Vehicle Coverage period of the General Motors of Canada New Vehicle Limited warranty, alternative transportation may be available under the Courtesy Transportation Program. Please consult your dealer for details. General Motors reserves the right to unilaterally modify, change or discontinue Courtesy Transportation at any time and to resolve all questions of claim eligibility pursuant to terms and conditions described herein at its sole discretion. Reporting Safety Defects to the United States Government If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying General Motors.

If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer or General Motors. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington, D.C. area) or write to: NHTSA, U.S. Department of Transportation Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the hotline.

Reporting Safety Defects to the Canadian Government

If you live in Canada, and you believe that your vehicle has a safety defect, you should immediately notify Transport Canada, in addition to notifying General Motors of Canada Limited. You may write to: Transport Canada 330 Sparks Street Tower C Ottawa, Ontario K1A ON5

7-8

Transmission, Transaxle, Transfer Case Unit Repair Manual This manual provides information on unit repair service procedures, adjustments, and specifications for GM transmissions, transaxles, and transfer cases. RETAIL SELL PRICE: $50.00 Service Bulletins Service Bulletins give technical service information needed to knowledgeably service General Motors cars and trucks. Each bulletin contains instructions to assist in the diagnosis and service of your vehicle. In Canada, information pertaining to Product Service Bulletins can be obtained by contacting your General Motors dealer or by calling 1-800-GM-DRIVE (1 -800-463-7483).

orting Safety Defects to General

Motors

In addition to notifying NHTSA (or Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call us at i-800-762-2737, or write: Pontiac-GMC Customer Assistance Center P.O. Box 33172 Detroit, MI 48232-5172 In Canada, please call us at 1-800-263-3777 (English) or 1-800-263-7854 (French). Or, write: General Motors of Canada Limited Customer Communication Centre, 163-005 1908 Colonel Sam Drive Oshawa, Ontario LIH 8P7

Service Publications Ordering Information Service Manuals Service Manuals have the diagnosis and repair information on engines, transmission, axle, suspension, brakes; electrical; steering: body, etc. RETAIL SELL PRICE: $120.00

7-9

Owner’s Information Owner publications are written specifically for owners and intended to provide basic operational information about the vehicle. The owner’s manual will include the Maintenance Schedule for all models. In-Portfolio: Includes a Portfolio, Owner’s Manual, and Warranty Booklet. RETAIL SELL PRICE: $35.00 Without Portfolio: Owner’s Manual only RETAIL SELL PRICE: $25.00 Current and Past Model Order Forms Service Publications are available for current and past model GM vehicles. To request an order form, please specify year and model name of the vehicle.

ORDER TOLL FREE: 1-800-551 -41 23 Monday-Friday 8:OO AM - 6:OO PM Eastern Time For Credit Card Orders Only (VISA-Mastercard-Discover), visit Helm, Inc. on the World Wide Web at: www.helminc.com Or you can write to: Helm, Incorporated P. 0. Box 07130 Detroit, MI 48207 Prices are subject to change without notice and without incurring obligation. Allow ample time for delivery. Note to Canadian Customers: All listed prices are quoted in U.S. funds. Canadian residents are to make checks payable in US. funds.

7-1 0

A

........................................... Accessory Inflator ................................. Accessory Power Outlets ....................................... Adding Washer Fluid Additional Program Information ........................... Additives. Fuel ................................................. Add-on Electrical Equipment ............................ Adjusting the Speakers (Balance/Fade) Air Bag

5-72 3-23 5-41 7-7 5-6 5-91 ...... 3.75. 3-85

Air Bag Systems

Inflate? ....................

Readiness Light .......................................... ............................................. ....................

3-40 1-47 How Does an Air Bag Restrain? 1-52 Servicing Your Air Bag-Equipped Vehicle ......... 1-55 What Makes an Air Bag 1-52 What Will You See After an Air Bag Inflates? .. 1-53 Inflate? ................... 1-51 When Should an Air Bag Where Are the Air Bags? .............................. 1-50 Air Cleaner/Filter, Engine ................................. 5-22 All Overseas Locations ...................................... 7-4 Aluminum or Chrome-Plated Wheels .................. 5-86 AM ............................................................... 3-99 ......................................... a- I U I A r ~ i e ~ ~ ~ ~ a , ulversiiy ................ 3-101 Antenna, XM Satellite Radio System 4-7 Anti-lock Brake System (ABS) Anti-Lock Brake, System Warning Light .............. 3-43 Appearance Care ............................................ 5-82 .................................... 5-85 ............................... 5-88

Care of Safety Belts Chemicai Paint Spotting

............................

0 a n *

Appearance Care (cont.)

Cleaning the Inside of Your Vehicle ................ 5-82 .............. 5-85 Cleaning the Outside of Your Vehicle Finish Damage ............................................ 5-87 GM Vehicle Care/Appearance Materials .......... 5-88 Sheet Metal Damage ................................... 5-87 Underbody Maintenance ............................... 5-87 Weatherstrips .............................................. 5-85 Ashtrays ........................................................ 3-24 ............................................. 3-71 Audio System(s) Audio Systems

3-98 Audio Steering Wheel Controls ...................... Care of Your Cassette Tape Player ............... 3-100 Care of Your CD Player .............................. 3-101 Care of Your CDs ...................................... 3-100 Chime Levei Adjustment ............................. 3-101 Diversity Antenna System ............................ 3-1 01 3-82 Radio with Cassette and CD ......................... 3-72 Radio with CD ............................................ Setting the Time .......................................... 3-71 3-98 Theft-Deterrent Feature ................................ 3-94 Trunk-Mounted CD Chanuer .......................... Understanding Radio Reception ..................... 3-99 XM Satellite Radio Antenna System .............. 3-101 3-28 3-64 4-36 3-28

Automatic Climate Control System ..................... Automatic Door Locks ..................................... Automatic Level Control ................................... Automatic Operation ....................................

Automatic Transaxle

Fluid .......................................................... 5-23 Operation ................................................... 2-28 Automatic Transaxle Check .............................. 6-1 9 Automatic Transaxle Shift Lock Control

System Check ......................................... 6-20

Bulb Replacement (cont.)

Headlamp Aiming ........................................ Headlamps ................................................. Replacement Bulbs ...................................... Taillamps. Turn Signal. Stoplamps and

Back-up Lamps ........................................ ...........................................

Buying New Tires

5-52 5-56 5-60

5-59 5-67

Backing Up ................................................. Battery .......................... ......................... Battery Load Management ............................ Battery Replacement ......................................... Battery Warning Light ...................................... ......................... Before Leaving on a Long Trip Body Lubrication Service .................................. Boost Gage ................................................... Brake

4-40 5-44 3-20 2-9 3-41 4-22 6-1 9 3-54

Parking ...................................................... 2-31 System Inspection ....................................... 6-23 System Warning Light .................................. 3-42 Brake Fluid .................................................... 5-42 ................................................... Brake Wear 5-43 Brakes .......................................................... 5-42 Braking ........................................................... 4-6 Braking in Emergencies ..................................... 4-9 Break-In, New Vehicle ..................................... 2-25 Bulb Replacement ........................................... 5-56 Front Turn Signal and Parking Lamps ............. 5-57 Halogen Bulbs ............................................ 5-56

3-70 Calibrating the Compass .................................. California Fuel .................................................. 5-6 Canada ........................................................... 7-4 Canadian Owners ................................................ ii Canadian Roadside Assistance ........................... 7-6 Capacities and Specifications .......................... 5-1 00 Carbon Monoxide ................... 4-26, 4-36, 2-16, 2-36 Care of

Safety Belts ............................................ 5-85

Care of Your

Cassette Tape Player ................................. 3-100 CD Player ................................................. 3-101 CDS ......................................................... 3-100 ................................. Cassette Tape Messages 3-91 Cassette Tape Player Service ........................... 6-18 CD Adapter Kits ............................................. 3-92 ............................ CD Changer, Trunk-Mounted 3-94 ........................... Center Console Storage Area 2-46 Center Front Passenger Position, Safety Belts .... 1-19 Chains, Tires .................................................. 5-71

3-69

Cleaning (cont.)

Changing Your Zone Number ............................ Check

Engine Light Gages Warning Light Tire Pressure System

................................... ................................... Checking Coolant ......................................... Checking Checking Things Under the Hood .... Checking Your Restraint Systems ...................... Chemical Paint Spotting ................................... Child Restraints

............................................... 3-46 3-51 5-64 5-28 ... 5-16 ... 5-12 1-56 5-88

Oil ......................

Engine

............................... Child Restraint Systems Infants and Young Children ........................... Lower Anchorages and Top Tethers for

Children (LATCH System)

.......................... Older Children ............................................. Securing a Child Restraint Designed for the ........................................

LATCH System

Securing a Child Restraint in a Rear Seat

Position .................................................. Securing a Child Restraint in the Right Front Seat Position ...........................................

Location .................

I U ~ J duap ........................................ -r-- C*" -.- Top Strap Anchor Where to Put the Restraint ........................... Chime Level Adjustment ................................. ............................ Choosing Your Zone Number Cigarette Lighter ......................................... Cleaning

Inside of Your Vehicle

..................................

1-33 1-29

1-39 1-27

1-41

1-41

1-44 ... 1 3? ... 1-38 1-36 3-101 3-69 3-24

5-82

Outside of Your Vehicle ................................ Underbody Maintenance ............................... Weatherstrips ..............................................

5-85 5-87 5-85 ............ 5-85 Cleaning Exterior LampdLenses .... Climate Control System ................................ 3-25 Automatic ................................................... 3-28 Climate Controls Personalization .................... 3-33 Outlet Adjustment ........................................ 3-32 ................. 3-81, 3-93, 3-97 5-81 3-70 3-68 2-33 2-22 4-6 2-46

Compact Disc Messages ........................................ Compact Spare Tire Compass Accuracy .......................................... Compass, Electronic ........................................ Console Shift Lever ......................................... Content Theft-Deterrent .................................... Control of a Vehicle .......................................... Convenience Net ............................................ Coolant

............................ Engine Temperature Gage Heater, Engine ............................................ Cooling System .............................................. ............................................. Courtesy Lamps ................................................ Crl I ; c n Cnntrnl Current and Past Model Order Forms Customer Assistance Information

3-45 2-27 5-32 3-16 3-!Q ................ 7-10

VIUIL)" V V I I . , " ,

Courtesy Transportation .................................. Customer Assistance for Text Telephone (TTY) Users ....................................................... Customer Assistance Off ices ........................... Customer Satisfaction Procedure .....................

7-6

7-3 7-3 7-2

Customer Assistance Information (cont.) GM Mobility Program for Persons with

Disabilities ................................................ 7-4 Reporting Safety Defects to General Motors ...... 7-9 Reporting Safety Defects to the Canadian

Government .............................................. Reporting Safety Defects to the United States Government .............................................. .........................

7-8 Roadside Assistance Program 7-5 Service Publications Ordering Information ......... 7-9

7-8

Daytime Running Lamps .................................. Defensive Driving ............................................. Defogging and Defrosting ......................... Delayed Entry Lighting ..................................... Delayed Exit Lighting ....................................... Delayed Locking ..................................... Dinghy Towing ................................................ Diversity Antenna .......................................... Doing Your Own Service Work Dolly Towing .................................................. Door

3-14 4-2 3.26. 3-31 3-17 3-17 2.12. 3-66 4-33 3-1 01 5-3 4-33

...........................

Ajar Light ................................................... 3-52 Central Door Unlocking System ..................... 2-1 1 Delayed Locking .......................................... 2-1 2

Door (cont.)

Locks ........................................................ Power Door Locks ....................................... Programmable Automatic Door Locks Rear Door Security Locks .............................

2-10 2-11 ............. 2-13 2-15

Driver

Position, Safety Belt ..................................... Driver ID ....................................................... Driver Information Center (DIC) ......................... DIC Controls and Displays ............................ .......................... DIC Vehicle Personalization DIC Warnings and Messages ........................ Driver Identifier DIC Display ..........................

1-12 3-67 3-57 3-57 3-62 3-60 3-61

Driving

At Night ..................................................... 4-16 City ........................................................... 4-20 Defensive ..................................................... 4-2 Drunken ....................................................... 4-3 Freeway ..................................................... 4-21 ......... 4-24 Hill and Mountain Roads ............. 4-17 In Rain and on Wet Roads Winter ........................................... ..... 4-26 Driving On Grades .......................................... 4-41 Ice .................................... Driving on Snow or 4-27 Driving Through Deep Standing Water ............... 4-19 Driving Through Flowing Water ......................... 4-19 ....................................... 4-39 Driving with a Trailer

.......................

Electrical System

Add-on Equipment ...................................... 5-91 Fuses and Circuit Breakers ........................... 5-92 Headlamp Wiring ......................................... 5-91 Power Windows and Other Power Options ...... 5-91 .................. 5-95 Removing the Rear Seat Cushion 5-91 Windshield Wiper Fuses 3-68 2-18

............................... Electronic Compass ......................................... ..................... Emergency Trunk Release Handle Emissions Inspection and Maintenance

Programs ...................................................

3-48

Engine

Air Cleaner/Filter ......................................... 5-22 Battery ....................................................... 5-44 ............ 3-46 Check and Service Engine Soon Light Coolant ...................................................... 5-26 Coolant Heater ............................................ 2-27 ........................... Coolant Temperature Gage 3-45 Cooling System Inspection ............................ 6-23 Engine Compartment Overview ...................... 5-1 4 Exhaust ..................................................... 2-36 Oil ............................................................. 5-15 Overheating ................................................ 5-29 Starting ...................................................... 2-26 Supercharger Oil ......................................... 5-21 Engine Compartment Fuse Block ...................... 5-92 Engine Coolant Level Check ............................. 6-18 Engine Cooling When Trailer Towing .................. 4-42

......................

.......................... 5-19 Engine Oil Additives ......, Engine Oil Level Check ..... 6-18 Entry Lighting ................................................. 3-17 Erasing HomeLink@ Buttons .............................. 2-45 Express-Down Window .................................... 2-20 Extender, Safety Belt ....................................... 1-26 Exterior Lamps ............................................... 3-13 ... 3-16 Exterior Lighting Battery Saver ...............

FabridCarpet ......................... Filter

.............

... 5-82

Engine Air Cleaner ......................................

5-22 Finding a PTY Station (RDS and XMTM) ..... 3-75, 3-85 Finding a Station .................................... 3-73, 3-83 Finish Care .................................................... 5-86 Finish Damage ............................................... 5-87 Flash-To-Pass .................................................. 3-8 Flat Tire ........................................................ 5-72 ......................................... Flat Tire, Changing 5-73 !=!zid

Automatic Transaxle ..................................... Power Steering ........................................... Windshield Washer ...................................... FM Stereo ..................................................... Fog Lamps .................................................... Following Distance .......................................... Footnotes ................................................

5-23 5-40 5-40 3-99 3-15 4-40 6-7, 6-13

Front Reading Lamps ...................................... 3-19 Front Storage Area ......................................... 2-46 Fuel ............................................................... 5-5 Additives ...................................................... 5-6 California Fuel .............................................. 5-6 Filling a Portable Fuel Container .................... 5-1 1 ........................................... Filling Your Tank 5-8 Fuels in Foreign Countries .............................. 5-7 Gage ......................................................... 3-53 Gasoline Octane ........................................... 5-5 Gasoline Specifications .................................. 5-6 System Inspection ....................................... 6-22 .............................................. 5-10

Fuel Door Lock Fuses

Fuses and Circuit Breakers ........................... Windshield Wiper .........................................

Gage

Boost ......................................................... Check Gages Warning Light .......................... Engine Coolant Temperature ......................... Fuel .......................................................... Oil Pressure ............................................... Speedometer .............................................. Tachometer ................................................. Voltmeter Gage ........................................... Garage Door Opener .......................................

5-92 5-91

3-54 3-51 3-45 3-53 3-49 3-38 3-39 3-41 2-42

Gasoline

Octane ........................................................ Specifications ...............................................

5-5 5-6 Gate Operator and Canadian Programming ........ 2-44 Glass Surfaces ............................................... 5-84 Glove Box ..................................................... 2-46 GM Mobility Program for Persons with

Disabilities ................................................

7-4

Hazard Warning Flashers ................................... Head Restraints ............................................... Headlamp

3-5 1-6

Aiming ....................................................... 5-52 .................... Headlamp High/Low-Beam Changer 3-8 Headlamp Horizontal Aiming ............................. 5-54 Headlamp Vertical Aiming ................................. 5-54 Headlamp Wiring ............................................ 5-91 Headlamps .................................................... 5-56 Bulb Replacement ....................................... 5-56 Front Turn Signal and Parking Lamps ............. 5-57 5-56 Halogen Bulbs ............................................ Headlamps On Reminder ................................... 3-8 Head-Up Display (HUD) ................................... 3-21 Heated Seats ................................................... 1-4 Highway Hypnosis ........................................... 4-23 Hill and Mountain Roads .................................. 4-24 Hitches .......................................................... 4-38

HomeLink@ Transmitter. Programming ................ 2-43 HomeLink@ Transmitter .................................... 2-42 Hood

................................ Checking Things Under Release ..................................................... Horn ............................................................... How to Add Coolant to the Coolant

5-12 5-1 3 3-6

Recovery Tank ............................................

5-34 How to Add Coolant to the Radiator .................. 5-36 How to Add Fluid ............................................ 5-26 How to Check ................................................ 5-24 How to Check and Add Oil ............................... 5-22 How to Check Power Steering Fluid .................. 5-40 How to Use This Manual ii How to Wear Safety Belts Properly ................... 1-12 4-1 9 Hydroplaning ..................................................

......................................

Infants and Young Children. Restraints Inflation .. Tire Pressure .................................. Inspection

............... 1-29 5-62

Brake System ............................................. Engine Cooling System ................................ Exhaust System .......................................... Fuel System ............................................... Part C - Periodic Maintenance ....................... Steering, Suspension and Front Drive Axle

Boot and Seal ......................................... Throttle System ...........................................

Instrument Panel

Cluster ....................................................... Overview ..................................................... Instrument Panel Brightness ............................. Interior Lamps ................................................ Interior Plastic Components ...........................

6-23 6-23 6-22 6-22 6-22

6-22 6-23

3-35 3-4 3-16 3-16 5-84
