2002 Mercedes-benz E Class Wagon Owners Manual

E-Class

Operator’s Manual

E 320

Our company and staff congratulate you on the purchase of your new Mercedes-Benz. Your selection of our product is a demonstration of your trust in our company name. Further, it exemplifies your desire to own an automobile that will be as easy as possible to operate and provide years of service. Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time:

• Please read this manual carefully before putting it aside. Then return it to your vehicle where it will be handy for

your reference.

• Please abide by the recommendations contained in this manual. They are designed to acquaint you with the

operation of your Mercedes-Benz.

• Please abide by the warnings and cautions contained in this manual. They are designed to help improve the safety

of the vehicle operator and occupants.

We extend our best wishes for many miles of safe, pleasurable driving. DaimlerChrysler AG

Introduction

Product information .......................... 7
Operator’s manual ............................. 8
Where to find it ................................ 13
Reporting Safety Defects ................ 15

Instruments and controls

Instruments and controls ............... 18
Center console ..............................20
Overhead control panel ............... 21

Operation

Vehicle keys ......................................24
Start lock-out ....................................26
General notes on the

central locking system ...............26
Central locking system ...................27

Radio frequency and infrared remote control ...............27
Opening and closing windows and sliding/pop-up roof from outside ..................................30

Panic button ..................................31
Mechanical keys ...........................31
Doors ................................................. 32
Central locking switch .................... 34
Automatic central locking .............. 35
Emergency unlocking

in case of accident ...................... 35
Tailgate .............................................. 36
Antitheft alarm system ................... 39
Tow-away alarm ................................41
Power seats front ............................. 42
Front seat head restraints .............. 48
Rear seat head restraints ............... 49
Multicontour seat .............................51
Seat heater ........................................ 52
Seat ventilation ................................ 55
Seat belts and

integrated restraint system ....... 57
Seat belts .......................................... 57
Seat belt nonusage

warning system .......................... 58

BabySmartTM airbag

deactivation system ................... 65

Contents

Self-test BabySmartTM without special child seat installed .........65

Supplemental restraint system

(SRS) .............................................66

Emergency tensioning retractor

(ETR) .............................................67
Airbags ..............................................68
Safety guidelines for the seat belt, emergency tensioning retractor and airbag ....................................75

Infant and child

restraint systems .........................77
Steering wheel adjustment ............ 81
Rear view mirrors ............................82
Instrument cluster ...........................86
Multifunction steering wheel,

multifunction display .................92

Trip and main odometer, FSS

and engine oil level display .......96
Audio systems ..................................97
Radio ..............................................97
CD player .......................................98
Cassette player .............................99

Contents

Telephone ........................................100
Telephone book ..........................100
Redialing ..................................... 102
Incoming call .............................. 104
Navigation system ..........................105
Trip computer .................................106
Malfunction message memory .... 108
Individual settings ..........................110
Setting the audio volume ...............113
Flexible service system (FSS) .......114
Engine oil level indicator ...............117
Engine oil consumption .................118
Exterior lamp switch ......................119
Night security Illumination .........120
Headlamp cleaning system .......... 121
Combination switch ......................122
Rear window wiper / washer .......124
Hazard warning flasher switch ...125
Automatic climate control ............126
Display and controls ..................128
Basic setting ................................129
Special settings ..........................129
Defogging windows ....................129

Defrosting ................................... 129
Rear window defroster ...............130
Air distribution ...........................130
Air volume ...................................130
Air recirculation .........................131
Dust filter .....................................131
Activated charcoal filter ............132
Residual engine heat utilization ............................132
Front center console compartment ventilation ...........133
Rear passenger compartment adjustable air outlet ...................134

Audio and telephone,

operation .....................................135
Power windows ...............................154
Sliding / pop-up roof ......................157
Interior lighting ..............................159
Entrance lamps,

exit lamps in doors ....................159

Reading lamps

rear compartment ......................160
Sun visors ........................................161

Illuminated vanity mirrors ........... 161
Interior ............................................ 162
Armrest, rear bench ...................... 162
Cup holder

in rear bench armrest .............. 162
Glove box ......................................... 163

Cup holder and coin holder in glove box lid ........................... 163

Storage compartment above

ashtray in center console ........ 164

Storage compartments

in center console ....................... 164
Cup holder in center console ....... 165
Ashtrays .......................................... 166
Lighter ............................................. 168
Split rear bench seat ..................... 169
Rear-facing bench seat ..................175
Loading instructions ..................... 177
Cargo tie-down rings ..................... 178
Parcel net

in front passenger footwell .....179
Cellular telephone .........................179
Garage door opener ....................... 180

Driving

Control and operation

of radio transmitters ................186

The first 1 000 miles

(1 500 km) .................................187
Maintenance ...................................187
Tele Aid ........................................... 188
Catalytic converter ........................ 198
Emission control ............................ 199
Steering lock ...................................200
Starting and turning

off the engine ............................202
Automatic transmission ...............203
Parking brake ................................. 212
Driving instructions ...................... 213
Drive sensibly - Save Fuel ......... 213
Drinking and Driving ................ 213
Pedals ........................................... 213
Power assistance ........................ 214
Brakes .......................................... 214
Driving off ................................... 215

Parking .........................................216
Tires ..............................................216
Snow chains ................................219
Winter driving instructions ......219
Block heater ................................ 221
Deep water .................................. 221
Passenger compartment ........... 221
Traveling abroad ........................ 221
Cruise control ................................ 222
Brake assist system

(BAS) .......................................... 225

Antilock brake system

(ABS) .......................................... 227

Four wheel electronic traction

system (4MATIC) ...................... 229

Electronic stability program

(ESP) ........................................... 230

Parking assist

(Parktronic) ............................... 234

What you should know

at the gas station ...................... 239

Check regularly and

before a long trip ...................... 241

Instrument cluster display

Malfunction and indicator lamps

in the instrument cluster .........244
On-board diagnostic system .....244
Check engine malfunction indicator lamp .............................244
Brake warning lamp ..................245
Supplemental restraint system (SRS) indicator lamp ..................246
Fuel reserve and fuel cap placement warning ....................246
Electronic stability program (ESP) — warning lamp ...............247
BAS / ESP malfunction indicator lamp .............................247
ABS malfunction indicator lamp .............................248
Seat belt warning lamp .............248

Malfunction and indicator lamp

in the center console ................249
AIRBAG OFF indicator lamp .....249

Contents

Contents

Malfunction and warning

messages in the multifunction display ...............250
DISPLAY DEFECTIVE ................251
BATTERY / ALTERNATOR .........252
ABS-SYSTEM ...............................253
BRAKE ASSIST ...........................253
BRAKE LINING WEAR ..............254
BRAKE FLUID .............................254
PARKING BRAKE .......................255
ENGINE FAN ...............................255
COOLANT (coolant level) ..........256
COOLANT TEMP. ........................257
LIGHTING SYSTEM ....................258
LIGHT SENSOR ...........................259
REMOVE KEY .............................259
STEERING GEAR OIL .................260
ENGINE OIL LEVEL ................... 261
WASHER FLUID ..........................262
ELEC. STABIL. PROG. (Electronic stability program) ..263
TELE AID .....................................263

Practical hints

First aid kit ..................................... 266
Fuses ............................................... 267
Electrical outlet ............................. 269
Hood ................................................ 270
Checking engine oil level ............. 273
Automatic transmission

fluid level ....................................274
Coolant level ....................................274
Adding coolant ........................... 275

Windshield and headlamp

washer system ...........................276
Windshield and headlamp washer fluid mixing ratio .........276

Spare wheel, vehicle tools,

storage compartment ............... 277
Vehicle jack .................................... 278
Wheels ............................................ 279
Tire replacement ....................... 279
Rotating wheels ......................... 280
Spare wheel .................................... 281
Spare wheel bolts ...................... 281

Changing wheels ...........................282
Tire inflation pressure ..................287
Battery .............................................289
Jump starting ..................................291
Towing the vehicle .........................294
Transmission selector lever,

manually unlocking ..................296
Exterior lamps ................................297
Headlamp assembly ...................298
Taillamp assemblies ..................301

Changing batteries

in the electronic main key ......304
Synchronizing remote control ............................306
Emergency engine shut-down .....306
Emergency operation of

sliding / pop-up roof .................307

Manual release for

fuel filler flap .............................308
Replacing wiper blade insert .......308
Roof rack ..........................................311

Index

Index ................................................336

Vehicle care

Cleaning and care

of the vehicle ............................. 314
Power washer .............................. 315
Tar stains ..................................... 315
Paintwork, painted body components ................................. 315
Engine cleaning .......................... 316
Vehicle washing ......................... 316
Ornamental moldings ................ 316
Headlamps, taillamps, turn signal lenses ...................... 316
Cleaning the parktronic system sensors ........................... 317
Window cleaning / glass sunroof ............................... 317
Wiper blades ............................... 317
Light alloy wheels ...................... 318
Instrument cluster ..................... 318
Steering wheel and gear selector lever ...................... 318
Cup holder ................................... 318
Seat belts ..................................... 318

Headliner .....................................318
Upholstery ...................................319
Hard plastic trim items ..............319
Plastic and rubber parts ............319

Technical data

Spare parts service ....................... 322
Warranty coverage ........................ 322
Identification labels ...................... 323
Layout of poly-V-belt drive ........... 324
Technical data ................................ 325
Fuels, coolants, lubricants

etc. - capacities ......................... 328
Engine oils ...................................... 330
Engine oil additives ...................... 330
Air conditioner refrigerant .......... 330
Brake fluid ...................................... 330
Premium unleaded gasoline ........ 331
Fuel requirements ........................ 331
Gasoline additives ......................... 332
Coolants .......................................... 332
Consumer information ................. 334

Contents

Product information

Kindly observe the following in your own best interest: We recommend using Mercedes-Benz original parts as well as conversion parts and accessories explicitly approved by us for your vehicle model. We have tested these parts to determine their reliability, safety and their special suitability for Mercedes-Benz vehicles. We are unable to make an assessment for other products and therefore cannot be held responsible for them, even if in individual cases an official approval or authorization by governmental or other agencies should exist. Use of such parts and accessories could adversely affect the safety, performance or reliability of your vehicle. Please do not use them. Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on permissible technical modifications, and where proper installation will be performed.

Introduction

Introduction

Operator’s manual This Operator’s Manual contains a great deal of useful information. We urge you to read it carefully and familiarize yourself with the vehicle before driving. For your own safety and longer service life of the vehicle, we urge you to follow the instructions and warnings contained in this manual. Ignoring them could result in damage to the vehicle or personal injury to you or others. Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty. Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment, your authorized Mercedes-Benz Center will be glad to demonstrate the proper procedures.

Service and warranty information The Service and Warranty Information Booklet contains detailed information about the warranties covering your Mercedes-Benz, including: • New Car Limited Warranty, • Emission System Warranty, • Emission Performance Warranty, • California, Maine, Massachusetts, and Vermont Emission Control System Warranty

(California, Maine, Massachusetts, and Vermont only),

• State Warranty Enforcement Laws (Lemon Laws).

Important notice for California retail buyers of Mercedes-Benz automobiles Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price or lease price, if Mercedes-Benz USA, LLC and/or its authorized repair or service facilities fail to fix one ore more substantial defects or malfunctions in the vehicle that are covered by its express warranty after a reasonable number of repair attempts. During the period of 18 months from original delivery of the vehicle or the accumulation of 18 000 miles on the odometer of the vehicle, whichever occurs first, a reasonable number of repair attempts is presumed for a retail buyer or lessee if one or more of the following occurs: (1) the same substantial defect or malfunction results in a condition that is likely to cause death or serious bodily injury if the vehicle is driven, that defect or malfunction has been subject to repair two or more times, and you have directly notified Mercedes-Benz USA, LLC in writing of the need for its repair and have given us a direct opportunity to perform a repair ourselves, (2) the same substantial defect or malfunction of a less serious nature than category (1) has been subject to repair four or more times and you have directly notified us of the need for its repair and given us the opportunity to repair ourselves, or (3) the vehicle is out of service by reason of repair of the same or different substantial defects or malfunctions for a cumulative total of more than 30 calender days. Written notification should be sent to us, not a dealer, at Mercedes-Benz USA, LLC, Customer Assistance Center, One Mercedes Drive, Montvale, NJ 07645-0350.

Maintenance The Service Booklet describes all the necessary maintenance work which should be performed at regular intervals. Always have the Service Booklet with you when you take the vehicle to your authorized Mercedes-Benz Center for service. The service advisor will record each service in the booklet for you.

Introduction

Introduction

10

Roadside assistance The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown. Calls to the toll-free Roadside Assistance number:

1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada)

will be answered by Mercedes-Benz Customer Assistance Representatives 24 hours a day, 365 days a year. For additional information refer to the Mercedes-Benz Roadside Assistance Program brochure in your glove box.

Change of address or ownership If you change your address, be sure to send in the “Change of Address Notice” found in the Service and Warranty Information Booklet, or simply call the Mercedes-Benz Customer Assistance Center (in the USA) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100. It is in your own interest that we can contact you should the need arise. If you sell your Mercedes, please leave all literature with the vehicle to make it available to the next operator. If you bought this vehicle used, be sure to send in the “Notice of Purchase of Used Car” found in the Service and Warranty Information Booklet, or call the Mercedes-Benz Customer Assistance Center (in the USA) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.

Operating your vehicle outside the USA or Canada If you plan to operate your vehicle in foreign countries, please be aware that: • Service facilities or replacement parts may not be readily available, • unleaded gasoline for vehicles with catalytic converters may not be available; the use of leaded fuels will damage

the catalysts,

• gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage. Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details, consult your authorized Mercedes-Benz Center or write to:

In the USA: Mercedes-Benz USA, LLC European Delivery Department One Mercedes Drive Montvale, NJ 07645-0350

In Canada: Mercedes-Benz Canada, Inc. European Delivery Department 849 Eglinton Avenue East Toronto, Ontario M4G 2L5

Introduction

11

Introduction

12

We continuously strive to improve our product, and ask for your understanding that we reserve the right to make changes in design and equipment. Therefore, information, illustrations and descriptions in this Operator’s Manual might differ from your vehicle. Optional equipment is also described in this manual, including operating instructions wherever necessary. Since they are special-order items, the descriptions and illustrations herein may vary slightly from the actual equipment of your vehicle. If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized Mercedes-Benz Center will be glad to inform you of correct care and operating procedures. The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.

Where to find it

The Operator’s Manual is divided into eight sections: • Instruments and controls: An overview of all the controls that can be operated from the driver’s seat. • Operation: Information on the vehicle’s equipment and its operation. • Driving: Important information on driving. • Instrument cluster display: Displays and indicator lamps on the instrument cluster with brief instructions. • Practical hints: Assistance and instructions in the event of an emergency. • Car care: Instructions on caring for your vehicle. • Technical data: All the important technical data for your vehicle as well as consumer information such as fuels,

coolants, lubricants etc. is contained here.

• Index: Key terms to help you find a topic quickly.

Other documents may also be supplied, depending on your vehicle’s equipment.

Explanation of color used:

Warning notices for the protection of yourself and others appear on red background.

Introduction

13

Introduction

14

Problems with your vehicle If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is not handled to your satisfaction, please discuss the problem with the Mercedes-Benz Center management, or if necessary contact us at the following addresses:

In the USA:

In Canada:

Customer Assistance Center Mercedes-Benz USA, LLC One Mercedes Drive Montvale, NJ 07645-0350 Customer Relations Department Mercedes-Benz Canada, Inc. 849 Eglinton Avenue East Toronto, Ontario, M4G 2L5

For the USA only: The following text is published as required of manufacturers under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”.

Reporting Safety Defects If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Mercedes-Benz USA, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or Mercedes-Benz USA, LLC. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-888-327-4236 or write to: NHTSA, U.S. Department of Transportation, Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from the Hotline.

Introduction

15

Instruments and controls

Instruments and controls ............... 18
Center console ..............................20
Overhead control panel ............... 21

Contents – Instruments and controls

17

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

18

Instruments and controls

10

13

14

14

12

11

20

21 22

23

16 17 18

15

19

24

25

26

P68.10-2410-29

1 Parking assist warning indicators, see page 236
2 Side defroster outlet 3 Side air outlet, adjustable 4 Air volume control for side air outlet 5 Exterior lamp switch, see page 119
6 Parking brake release, see page 212
7 Hood lock release, see page 270
8 Combination switch, see page 122
9 Cruise control switch, see page 222
10 Instrument cluster, see page 86
11 Multifunction steering wheel, see page 92
Horn (with electronic key in steering lock position 1 or 2) Airbag, see page 68

12 Steering lock with ignition/starter switch,

see page 200

13 Voice recognition system switch, see separate

operating instructions

14 Center air outlets, adjustable

15 Air volume control for center air outlets 16 Left front seat heater switch, see page 52

Left front seat ventilation switch, see page 55

17 Headlamp washer switch, see page 121
18 Rear window wiper and washer switch, see page 124
19 Hazard warning flasher switch, see page 125
20 Central locking switch, see page 34
21 Tow-away alarm switch, see page 41

Indicator lamp for antitheft alarm system, see page 39

22 Right front seat heater switch, see page 52

Right front seat ventilation switch, see page 55

23 Glove box (illuminated with electronic key in

steering lock position 1 or 2)

24 Automatic climate control, see page 126

Rear window defroster switch Activated charcoal filter switch

25 Audio system, see page 135
26 Storage/eyeglasses compartment, see page 164

Instruments and controls

19

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Center console

20

P68.20-2258-27

1 Ashtray with lighter, see page 166
2 ESP control switch, see page 232
3 Power window switches, front doors, see page 154
4 Power window safety switch, rear doors,

see page 155

5 Airbag Off indicator lamp, see page 249
6 Power window switches, rear doors, see page 154
7 Parktronic system deactivation switch, see page 238
8 Mirror adjustment switch, see page 82

Overhead control panel

1 Interior lighting, see page 159
2 Sliding/pop-up roof, see page 157
3 Rear view mirror, see page 82
4 Garage door opener, see page 180
5 Tele Aid (emergency call system), see page 188
6 Hands-free microphone for Tele Aid, telephone and

voice recognition system

Instruments and controls

21

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Contents – Operation

Operation

Vehicle keys ......................................24
Start lock-out ....................................26
General notes on the

central locking system ...............26
Central locking system ...................27

Radio frequency and infrared remote control ...............27
Opening and closing windows and sliding/pop-up roof from outside ..................................30
Panic button .................................. 31
Mechanical keys ........................... 31
Doors ..................................................32
Central locking switch ....................34
Automatic central locking ..............35
Emergency unlocking

in case of accident ......................35
Tailgate ..............................................36
Antitheft alarm system ...................39
Tow-away alarm ................................ 41
Power seats front .............................42
Front seat head restraints ..............48

22

Rear seat head restraints ............... 49
Multicontour seat .............................51
Seat heater ........................................ 52
Seat ventilation ................................ 55
Seat belts and

integrated restraint system ....... 57
Seat belts .......................................... 57
Seat belt nonusage

warning system .......................... 58

BabySmartTM airbag

deactivation system ................... 65
Self-test BabySmartTM without special child seat installed ......... 65

Supplemental restraint system

(SRS) ............................................. 66

Emergency tensioning retractor

(ETR) ............................................. 67
Airbags .............................................. 68
Safety guidelines for the seat belt, emergency tensioning retractor and airbag .................................... 75

Infant and child

restraint systems ........................ 77
Steering wheel adjustment .............81
Rear view mirrors ........................... 82

Instrument cluster ...........................86
Multifunction steering wheel,

multifunction display .................92

Trip and main odometer, FSS

and engine oil level display .......96
Audio systems ..................................97
Radio ..............................................97
CD player .......................................98
Cassette player .............................99
Telephone ........................................ 100
Telephone book .......................... 100
Redialing .....................................102
Incoming call ..............................104
Navigation system .......................... 105
Trip computer ................................. 106
Malfunction message memory ....108
Individual settings ..........................110
Setting the audio volume ..............113
Flexible service system (FSS) .......114
Engine oil level indicator ...............117
Engine oil consumption .................118
Exterior lamp switch ......................119
Night security Illumination .........120
Headlamp cleaning system .......... 121

Combination switch ......................122
Rear window wiper / washer .......124
Hazard warning

flasher switch ............................125
Automatic climate control ............126
Display and controls ..................128
Basic setting ................................129
Special settings ..........................129
Defogging windows ....................129
Defrosting ....................................129
Rear window defroster .............. 130
Air distribution ........................... 130
Air volume ................................... 130
Air recirculation ......................... 131
Dust filter .................................... 131
Activated charcoal filter ............ 132
Residual engine heat utilization ........................... 132

Front center console compartment ventilation ...........133
Rear passenger compartment adjustable air outlet ...................134

Audio and telephone,

operation .....................................135
Power windows ...............................154
Sliding / pop-up roof ......................157
Interior lighting ..............................159
Entrance lamps,

exit lamps in doors ....................159

Reading lamps

rear compartment ......................160
Sun visors ........................................161
Illuminated vanity mirrors ...........161
Interior .............................................162
Armrest, rear bench .......................162
Cup holder

in rear bench armrest ...............162

Glove box ......................................... 163

Cup holder and coin holder in glove box lid ........................... 163

Storage compartment above

ashtray in center console ........ 164

Storage compartments

in center console ....................... 164
Cup holder in center console ....... 165
Ashtrays .......................................... 166
Lighter ............................................. 168
Split rear bench seat ..................... 169
Rear-facing bench seat ..................175
Loading instructions ..................... 177
Cargo tie-down rings ..................... 178
Parcel net

in front passenger footwell .....179
Cellular telephone .........................179
Garage door opener ....................... 180

Contents – Operation

23

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

24

Vehicle keys Included with your vehicle are 2 electronic keys with integrated radio frequency and infrared remote controls plus removable mechanical key. The locking tabs for the mechanical key portion of the two electronic keys are a different color to help distinguish it.

Warning! When leaving the vehicle always remove the electronic key from the steering lock, and lock your vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause serious personal injury.

Electronic key

P80.35-2030-26

The electronic key has an integrated radio frequency and infrared remote control, plus removable mechanical key. The remote control (1) operates all locks on the vehicle. The mechanical key (2) works only in the driver’s door, tailgate, and storage compartment locks.

When using the mechanical key (2) for lock operations, it can be removed by sliding it out of the remote control. To do so, move locking tab (3) to the right and slide the mechanical key (2) in direction of arrow (4). The remote control transmitter is located in the electronic key. The infrared receivers are located in the front door handles.

Notes: Remove the mechanical key from the electronic key when using valet parking service. To prevent access to storage compartments lock them separately and retain the mechanical key. See page 36 for separate locking of tailgate and page 163 for locking of glove box.

Obtaining replacement keys Your vehicle is equipped with a theft deterrent locking system requiring a special key manufacturing process. For security reasons, replacement keys can only be obtained from your authorized Mercedes-Benz Center.

Central locking system

25

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

Start lock-out

26

Important! Removing the electronic key from the steering lock activates the start lock-out. The engine cannot be started. Inserting the electronic key in the steering lock deactivates the start lock-out.

Note: In case the engine cannot be started (vehicle’s battery is in order), the system is not operational. Contact an authorized Mercedes-Benz Center or call 1-800-FOR- MERCedes (in the USA), or 1-800-387-0100 (in Canada).

General notes on the central locking system If the electronic key is inserted in the steering lock, the vehicle cannot be locked or unlocked with the remote control. If the vehicle cannot be locked or unlocked: • Aim transmitter eye at a receiver of either front door handle. Check the batteries of the electronic key, see page 304, or synchronize the remote control, see page 306.

• Use the mechanical key to unlock the vehicle. To

start engine, insert the electronic key in the steering lock. There could be a slight delay until the electronic key can be turned in the steering lock.

Important! When unlocking the driver’s door with the mechanical key, the exterior lamps will flash and the alarm will sound. To cancel the alarm, insert the electronic key in the steering lock or press button Œ or ‹ on the electronic key.

Central locking system

Radio frequency and infrared remote control The electronic key has an integrated radio frequency and infrared remote control. Due to the extended operational range of the remote control, it could be possible to unintentionally lock or unlock the vehicle by pressing the transmit button. If one of the transmit buttons is pressed, the battery check lamp lights up briefly – indicating that the batteries are in order. See page 304 for checking batteries. The vehicle doors, tailgate and fuel filler flap can be centrally locked and unlocked via remote control. Opening and closing the windows and sliding / pop-up roof remotely can only be done with the infrared portion of the remote control. Aim transmitter eye at a receiver (6 or 7), press and hold transmit button Œ or ‹. If the electronic key is inserted in steering lock, the vehicle cannot be locked or unlocked with the remote control.

P80.35-2033-26

1 Transmit button

‹ Locking Œ Unlocking

2 Lamp for battery check (see page 304 for changing

batteries if it does not light up briefly)

3 PANIC button 4 Transmitter eye 5 Locking tab for mechanical key

Central locking system

27

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

28

6 Infrared receiver in driver’s door handle

7 Infrared receiver in front passenger door handle

P80.30-2137-26

P80.30-2138-26

Locking and unlocking with remote control

Unlocking: Press transmit button Œ. All turn signal lamps blink once to indicate that the vehicle is unlocked. The remote control can be programmed for two kinds of unlocking modes (see below): Selective unlocking mode – Press transmit button Œ once to unlock driver’s door and fuel filler flap. Press transmit button Œ twice to unlock all doors, fuel filler flap, and tailgate. Global unlocking mode – Press transmit button Œ once to unlock all doors, fuel filler flap, and tailgate.

Notes: If the tailgate was previously locked separately, it will remain locked, see page 36. The presently active unlocking mode (selective or global) can only be determined by unlocking the vehicle with the remote control (see below for changing mode).

If within 40 seconds of unlocking with the remote control, neither door nor tailgate is opened, the electronic key is not inserted in the steering lock, or the central locking switch is not activated, the vehicle will automatically lock.

Locking: Press transmit button ‹ once. All turn signal lamps blink three times to indicate that the vehicle is locked. If they do not blink three times, a door or tailgate is not properly closed.

Note: If the vehicle cannot be locked or unlocked by pressing the transmit button, then it may be necessary to change the batteries in the electronic key (if ok, battery check lamp in electronic key will light briefly when pressing transmit button) or to synchronize the remote control, see pages 304 and 306.

Central locking system

29

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

30

Choosing global or selective mode on remote control Press and hold transmit buttons ‹ and Œ simultaneously for five seconds to reprogram the remote control. Battery check lamp will blink two times indicating the completed mode change.

The windows and sliding/pop-up roof begin to close after approximately 1 second. To interrupt closing procedure, release transmit button. Ensure that all side windows and the sliding/pop-up roof are properly closed before leaving the vehicle.

Opening and closing windows and sliding/pop-up roof from outside (summer opening/convenience feature) Aim transmitter eye of remote control at a door receiver.

Summer opening: Continue to press transmit button Πafter unlocking the vehicle. The windows and sliding/pop-up roof begin to open after approximately 1 second. To interrupt opening procedure, release transmit button.

Convenience feature: Continue to press transmit button ‹ after locking the vehicle.

Warning! Never operate the windows or sliding/pop-up roof if there is the possibility of anyone being harmed by the opening or closing procedure. In case the procedure causes potential danger, the procedure can be immediately halted by releasing the remote control button. To reverse direction of movement press Œ for opening or ‹ for closing.

Note: If the windows and sliding/pop-up roof cannot be operated automatically by pressing the transmit button of the remote control then it may be necessary to change the batteries in the electronic key (if ok, battery check lamp in electronic key will light briefly when transmitting), or to synchronize the remote control, see page 304 and 306.

Panic button

P80.35-2034-26

To activate press and hold button (1) for at least one second. An audible alarm and blinking exterior lamps will operate for approximately 3 minutes. To deactivate press button (1) again, or insert electronic key in steering lock.

Note: For operation in the USA only: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any unauthorized modification to this device could void to the user’s authority to operate the equipment.

Mechanical keys The mechanical keys work only in the driver’s door, tailgate, and storage compartment locks.

Notes: The mechanical key does not operate the central locking system or antitheft alarm system. The fuel filler flap cannot be locked or unlocked with the mechanical key. If the fuel filler flap cannot be opened, see page 308.

Central locking system

31

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

Doors

32

1 Opening – pull handle 2 Unlocking driver’s door 3 Locking driver’s door 4 Individual door from inside:

Push lock button down to lock.

Important! The mechanical key does not operate the central locking system or antitheft alarm system.

P72.10-2240-26

5 Front door from inside: Pull handle to unlock.

When you lock the driver’s door with the mechanical key, the door lock button should move down. Each individual door must be locked with the respective door lock button – the driver’s door can only be locked when it is closed.

If the vehicle has previously been locked from the outside, opening a door from the inside will trigger the alarm. When opening a door while the central locking system is in the: • selective unlocking mode, only that individual door is unlocked. The remaining doors, the tailgate and fuel filler flap remain locked.

• global unlocking mode, all doors, the tailgate and

fuel filler flap are unlocked.

Notes: In case of a malfunction in the central locking system the doors can be locked and unlocked individually. To lock, push down lock buttons and turn mechanical key in driver’s door lock to position 3. In addition lock the tailgate.

To unlock, pull inside door handles or turn mechanical key in driver’s door lock to position 2. Rear doors can only be opened from inside by first pulling up on the door lock button. When unlocking the driver’s door with the mechanical key, the exterior lamps will flash and the alarm will sound. To cancel the alarm, insert the electronic key in the steering lock or press button Œ or ‹ on the electronic key.

Central locking system

33

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

34

Central locking switch

1 Locking 2 Unlocking The central locking switch is located in the center console. The doors and tailgate can only be locked with the central locking switch, if front doors are closed. If the vehicle was previously locked with the central locking switch, while in the selective remote control mode, only the door opened from the inside is unlocked.

If the vehicle was previously locked with the central locking switch, while in the global remote control mode, the complete vehicle is unlocked when a front door is opened from the inside.

Notes: If the vehicle was previously locked with the remote control, the doors and tailgate cannot be unlocked with the central locking switch. The fuel filler flap cannot be locked or unlocked with the central locking switch. If the vehicle has previously been locked from the outside, opening a door from the inside will trigger the alarm. To cancel the alarm, insert the electronic key in the steering lock or press button Œ or ‹ on the electronic key.

Warning! When leaving the vehicle always remove the electronic key from the steering lock, and lock your vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause serious personal injury.

Automatic central locking The central locking switch also operates the automatic central locking. With the automatic central locking system activated, the doors and trunk are locked at vehicle speeds of approximately 9 mph (15 km/h) or more. The fuel filler flap remains unlocked.

To activate: With electronic key in steering lock position 2 hold upper portion of switch (1) for a minimum of 5 seconds.

To deactivate: With electronic key in steering lock position 2 hold lower portion of switch (2) for a minimum of 5 seconds.

Notes: If doors are unlocked with the central locking switch after activating the automatic central locking, and neither door is opened, then the doors remain unlocked even at vehicle speeds of approximately 9 mph (15 km/h) or more.

If a door is opened from the inside at speeds of approximately 9 mph (15 km/h) or less with the automatic central locking activated, the door will again be automatically locked at speeds of approximately 9 mph (15 km/h) or more.

Important! When towing the vehicle, or with the vehicle on a dynamometer test stand, please, note the following: With the automatic central locking activated and the electronic key in steering lock position 2, the vehicle doors will lock if the left front wheel as well as the right rear wheel spin at vehicle speeds of approximately 9 mph (15 km/h) or more. To prevent the vehicle door locks from locking, deactivate the automatic central locking.

Emergency unlocking in case of accident The doors unlock automatically a short time after a strong deceleration is detected, such as in a collision (this is intended to aid rescue and exit). Driving on rough roads may cause the vehicle to unlock. If necessary, the vehicle can be locked again with the central locking switch, see page 34.

Central locking system

35

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

Tailgate

36

The lock is located in the license plate recess.

0 Neutral position 1 Unlocking 2 Locking

3 Recessed handle 4 Lock button

5 Grip molding 6 Lock 7 Recessed handle

To close the tailgate, pull down on inside grip (8) and press down on outside grip molding (5) until the tailgate latch engages. It is not necessary to slam the tailgate closed, a power-assisted mechanism will draw the tailgate quietly and automatically.

Central locking system

37

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Central locking system

38

Important! In case of danger, the closed tailgate can be opened with the inside or outside handle. Only drive with the tailgate closed as otherwise exhaust fumes may enter the vehicle interior.

Warning! To prevent possible personal injury, always keep hands and fingers away from the tailgate opening when closing the tailgate. Be especially careful when small children are around. To prevent personal injury, never activate the closing assist mechanism by tampering with the tailgate latch. In case the closing procedure causes potential danger, the closing procedure can be immediately halted by pulling the outside recessed handle.

Notes: In case of a malfunction in the central locking system the tailgate can be locked and unlocked individually. To unlock, turn mechanical key in lock to position 1, or push lock button to position 1, see page 36. To lock, turn mechanical key in lock to position 2, or push lock button to position 2, see page 36. The rear compartment lamp will be switched off by the contact switch only if the tailgate is fully closed. When opening the tailgate completely, always make sure that there is sufficient overhead clearance. When unlocking the tailgate with the mechanical key, the exterior lamps will flash and the alarm will sound. To cancel the alarm, insert the electronic key in the steering lock or press button Œ or ‹ on the electronic key. If the fuel filler flap cannot be opened, see page 308.

Antitheft alarm system

1 Indicator lamp in switch located in center console

The antitheft alarm is automatically armed or disarmed with the remote control by locking or unlocking the vehicle. The antitheft alarm is armed within approximately 15 seconds after locking the vehicle. A blinking lamp (1) indicates that the alarm is armed.

Operation: Once the alarm system has been armed, the exterior vehicle lamps will flash and an alarm will sound when someone: • opens a door, • opens the tailgate, • opens the hood, • attempts to raise the vehicle.

Antitheft alarm system

39

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Antitheft alarm system

40

The alarm will last approximately 3 minutes in form of flashing exterior lamps. At the same time an alarm will sound for 30 seconds. The alarm will stay on even if the activating element (a door, for example) is immediately closed. If the alarm stays on for more than 20 seconds, an emergency call is initiated automatically. See Tele Aid on page 188.

Notes: When you unlock the driver’s door with the mechanical key, the exterior lamps will flash and the alarm will sound. To cancel the alarm, insert the electronic key in the steering lock or press button Œ or ‹ on the electronic key.

Tow-away alarm

The switch is located in the center console.

1 Press to switch off 2 Indicator lamp Once the alarm system has been armed, the exterior vehicle lamps will flash and an alarm will sound when someone attempts to raise the vehicle.

The alarm will last approximately 3 minutes in form of flashing exterior lamps. At the same time an alarm will sound for 30 seconds. The alarm will stay on even if the vehicle is immediately lowered. To cancel the alarm, insert the electronic key in the steering lock or press button Œ or ‹ on the electronic key. If the alarm stays on for more than 20 seconds, an emergency call is initiated automatically. See Tele Aid on page 188. To prevent triggering the tow-away alarm feature, switch off the tow-away alarm before towing the vehicle, or when parking on a surface subject to movement, such as a ferry or auto train. To do so, turn electronic key in steering lock to position 0 or 1, or remove electronic key from steering lock. Press tow-away alarm switch (1). The indicator lamp (2) illuminates briefly. Exit vehicle, and lock vehicle with the remote control. The tow-away alarm remains switched off until the vehicle is locked again with the electronic key, at which time it is automatically reactivated.

Tow-away alarm

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

41

Instruments and controls

Seats

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Power seats front

Warning! Do not adjust the driver’s seat while driving. Adjusting the seat while driving could cause the driver to lose control of the vehicle. Never ride in a moving vehicle with the backrest reclined. Sitting in an excessively reclined position can be dangerous. You could slide under the seat belt in a collision. If you slide under it, the belt would apply force at the abdomen or neck. That could cause serious or even fatal injuries. The backrest and seat belt provide the best restraint when the wearer is in an upright position and the belt properly positioned on the body. Never place hands under seat or near any moving parts while a seat is being adjusted.

42

When leaving the vehicle always remove the electronic key from the steering lock, and lock your vehicle. The power seats can also be operated with the driver’s or front passenger door open. Do not leave children unattended in the vehicle or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause serious personal injury.

To operate the front power seat adjustment switches, turn electronic key in steering lock to position 1 or 2 (with the driver’s or front passenger’s door open, the power seats can also be operated with the electronic key removed or in steering lock position 0).

5

P54.00-2074-26

The slide switches are located in each front door.

We recommend to adjust the power seat in the following order:

1 Seat, up/down

Press the switch (up/down direction) until comfortable seating position with still sufficient headroom is reached.

2 Seat adjustment, fore/aft

Press the switch (fore/aft direction) until a comfortable seating position is reached that still

allows you to reach the accelerator/brake pedal safely. The position should be as far rearward as possible, consistent with ability to properly operate controls.

3 Seat cushion tilt

Press the switch in the direction of the arrow until your legs are lightly supported.

4 Backrest tilt

Press the switch in the direction of the arrow until your arms are slightly angled when holding the steering wheel. 5 Head restraint

The height of the head restraint is adjusted automatically with the seat so that the back of the head is supported approximately at ear level. Adjust the head restraint using the switch if the preset position does not support the back of your head approximately at ear level. Adjust the head restraint angle by hand.

Note: Your vehicle is equipped with power head restraints, do not try to raise or lower them manually.

43

Seats

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Instruments and controls

Seats

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Synchronizing head restraints If the power supply was interrupted (battery disconnected or empty), the head restraints are no longer adjusted automatically. To resynchronize the adjustment feature, turn electronic key in steering lock to position 2, move the seat completely forward and the head restraint fully down, and hold respective buttons for approximately two seconds.

44

Caution! Do not remove head restraints except when mounting seat covers. For removal refer to Head Restraints, Front, see page 48. Whenever restraints have been removed be sure to reinstall them before driving.

Memory function

6 Memory button 7 Position buttons

Storing positions into memory Three sets of seat/head restraint/steering wheel and exterior rear view mirror positions may be programmed into memory. After the seat/head restraint/steering wheel and exterior rear view mirrors are positioned, push memory button (6), release, and within 3 seconds push position button “1”. A second and third set of positions for the same seat/head restraint/steering wheel and exterior rear view mirrors can be programmed into memory by pushing first memory button (6) and then “2”, respectively “3”.

P54.00-2075-26

Note: For instructions on adjustment of steering wheel and mirrors, see Page 81 and 82.

Warning! Do not activate the memory function while driving. Activating the memory function while driving could cause the driver to lose the control of the vehicle.

45

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Seats

Instruments and controls

Instruments and controls

Seats

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Recalling positions from memory To recall a seat/head restraint/steering wheel and exterior rear view mirror position, push and hold position button “1”, “2” or “3” until seat/head restraint/ steering wheel and exterior rear view mirror movement has stopped. The seat/head restraint/steering wheel and exterior rear view mirror movement stops when the position button is released.

Caution! Do not operate the power seats using the memory button if the seat backrest is in an excessively reclined position. Doing so could cause damage to front or rear seats. First move the backrest to an upright position.

46

Important! Prior to operating the vehicle, the driver should adjust the seat height for proper vision as well as fore/aft placement and backrest angle to ensure adequate control, reach, operation, and comfort. The head restraint should also be adjusted for proper height. See also airbag section for proper seat positioning. In addition, also adjust the steering wheel to ensure adequate control, reach, operation, and comfort. Both the inside and outside rear view mirrors should be adjusted for adequate rearward vision. Fasten seat belts. Infants and small children should be seated in a properly secured restraint system that complies with U.S. Federal Motor Vehicle Safety Standard 213 and Canadian Motor Vehicle Safety Standard 213.1. All seat, head restraint, steering wheel, and rear view mirror adjustments as well as fastening of seat belts should be done before the vehicle is put into motion.

Warning! Children 12 years old and under must never ride in the front seat, except in a Mercedes-Benz authorized BabySmartTM compatible child seat, which operates with the BabySmartTM system installed in the vehicle to deactivate the passenger- side front airbag when it is properly installed. Otherwise they will be struck by the airbag when it inflates in a crash. If this happens, serious or fatal injury can result.

According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seating positions. Infants and small children must ride in the back seats and be seated in an appropriate infant or child restraint system, which is properly secured with the vehicle’s seat belt, fully in accordance with the child seat manufacturer’s instructions. A child’s risk of serious or fatal injuries is significantly increased if the child restraints are not properly secured in the vehicle and the child is not properly secured in the child restraint.

Seats

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

47

Instruments and controls

Seats

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Front seat head restraints
