Light alloy wheels Mercedes-Benz approved Wheel Care should be used for regular cleaning of the light alloy wheels. If possible, clean wheels once a week with Mercedes- Benz approved Wheel Care, using a soft bristle brush and a strong spray of water. Follow instructions on container.

Note: Use only acid-free cleaning materials. The acid could lead to corrosion.

J_OM_215.book Seite 387 Mittwoch, 30. Mai 2001 2:01 14

Instrument cluster Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moistened in lukewarm solution. Do not use scouring agents.

Cup holder Use a gentle dishwashing detergent or mild detergent for delicate fabrics as a washing solution. Wipe with a cloth moistened in lukewarm solution. Do not use scouring agents.

Steering wheel and gear selector lever Wipe with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care.

Note: For ease of cleaning, the cup holder between the front seats can be removed by pulling it up when in its closed position.

Cleaning and care of the vehicle

387

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

J_OM_215.book Seite 388 Mittwoch, 30. Mai 2001 2:01 14

Instruments and controls

Operation

Driving

Instrument cluster display

Practical hints

Car care

Technical

data

Index

Cleaning and care of the vehicle

388

Seat belts The webbing must not be treated with chemical cleaning agents. Use only clear, lukewarm water and soap. Do not dry the webbing at temperatures above 176°F (80°C) or in direct sunlight.

Warning! Do not bleach or dye seat belts as this may severely weaken them. In a crash they may not be able to provide adequate protection.

Headliner and shelf below rear window Clean with soft bristle brush, or use a dry-shampoo cleaner in case of excessive dirt.

Leather upholstery Using aftermarket seat covers or wearing clothing that have the tendency to give off coloring (e.g. when wet etc.) may cause the upholstery to become permanently discolored. By lining the seats with a proper intermediate cover, contact-discoloration will be prevented. Wipe leather upholstery with a damp cloth and dry thoroughly or clean with Mercedes-Benz approved Leather Care. Exercise particular care when cleaning perforated leather as its underside should not become wet.

Hard plastic trim items Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure.

Plastic and rubber parts Do not use oil or wax on these parts.
