then allows full inflation of the air bags. B240B03L A fully inflated air bag, in combination with a properly worn seat belt, slows the driver's or the passenger's forward motion, reducing the risk of head and chest injury. After complete inflation, the air bag immediately starts deflating, enabling the driver to maintain forward visibility and the ability to steer or operate other con- trols. B240B05L WARNING (cid:129) Do not install or place any acces- sories (drink holder, cassette holder, sticker, etc.) on the front passenger's panel above the glove box in a vehicle with a pas- senger's air bag. Such objects may become dangerous projec- tiles and cause injury if the pas- senger's air bag inflates. (cid:129) When installing a container of liq- uid air freshener inside the vehi- cle, do not place it near the instrument cluster nor on the instrument panel surface. It may become dangerous projec- tiles and cause injury if the pas- senger's air bag inflates. 3 31 Safety system of your vehicle WARNING (cid:129) If an air bag deploys, there may be a loud noise followed by a fine dust released in the vehicle. These conditions are normal and are not hazardous - the air bags are packed in this fine powder. The dust generated during air bag deployment may cause skin or eye irritation as well as aggra- vate asthma for some persons. Always wash all exposed skin areas thoroughly with lukewarm water and a mild soap after an accident in which the air bags were deployed. (Continued) (Continued) (cid:129) The SRS can function only when the ignition key is in the "ON" position. If the SRS "AIR BAG" warning light does not illuminate, or continuously remains on after illuminating for about 6 seconds when the ignition key is turned to the ON position, or after the engine is started, comes on while driving, the SRS is not working properly. If this occurs, have your vehicle immediately inspected by an authorized Hyundai dealer. (cid:129) Before you replace a fuse or dis- connect a battery terminal, turn the ignition key to the LOCK position and remove the ignition key. Never remove or replace the air bag related fuse(s) when the ignition key is in the ON position. Failure to heed this warning will cause the SRS AIR BAG warning light to illuminate. OHD036012N Occupant classification system Your vehicle is equipped with an occu- pant classification system in the front passenger's seat. The occupant classification system is designed to detect the presence of a properly-seated front passenger and determine if the passenger's front air bag should be enabled (may inflate) or not. The driver's front air bag is not affected or controlled by the occupant classifica- tion system. 32 If the front passenger seat is occupied by a person that the system determines to be of adult size, and he/she sits properly (sitting upright with the seatback in an upright position, centered on the seat cushion with their seat belt on, legs com- fortably extended and their feet on the floor), the "PASSENGER AIR BAG OFF" indicator will be turned off and the front passenger's air bag will be able to inflate, if necessary, in frontal crashes. You will find the "PASSENGER AIR BAG OFF" indicator on the center facia panel. This system detects the conditions 1~4 in the following table and activates or deactivates front passenger air bag based on these conditions. Safety system of your vehicle Condition and operation in the front passenger occupant classification system Condition detected by the occupant classi- fication system 1. Adult *1 2. Child*2 or child restraint system*3 3. Unoccupied 4. There is a malfunction in the system Indicator/Warning light Devices "PASSENGER AIR BAG OFF" indicator light SRS warning light Front passen- ger air bag Side air bag Curtain air bag Off On On Off Off Off Off On Activated Activated Activated Deactivated Activated Activated Deactivated Deactivated Activated Activated Activated Activated *1) The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture. *2) Do not allow children to ride in the front passenger seat. When a larger child who has outgrown a child restraint system sits in the front passenger seat, the system may recognize him/her as an adult depending on his/her physique or posture. *3) Never install a child restraint system on the front passenger seat. WARNING Riding in an improper position or placing weight on the front passenger's seat when it is unoccupied by a passenger adversely affects the occupant classification system (OCS). (Continued) 3 33 Safety system of your vehicle (Continued) OVQ036013N - Never put a heavy load in the front passenger seat or seatback pocket. 1KMN3663 - Never sit with hips shifted towards the front of the seat. 1KMN3665 - Never place feet on the dash- board. OVQ036014N - Never place feet on the front pas- senger seatback. 1KMN3662 - Never excessively recline the front passenger seatback. 1KMN3664 - Never lean on the center console. - Never sit on one side of the front passenger seat. 34 If the "PASSENGER AIR BAG OFF" indi- cator is still on, ask the passenger to move to the rear seat. WARNING Do not allow a passenger to ride in the front seat when the “PASSEN- GER AIR BAG OFF” indicator is illu- minated, because the air bag will not deploy in the event of a crash. If the "PASSENGER AIR BAG OFF" indicator remains illuminated after the passenger repositions them- selves properly and the car is restarted, we recommend that pas- senger move to the rear seat because the passenger's front air bag will not deploy. Front seat passengers must stay properly seated to avoid serious injury from a deploying air bag. Safety system of your vehicle ✽✽ NOTICE The "PASSENGER AIR BAG OFF" indicator illuminates for about 4 sec- onds after the ignition key is turned to the "ON" position or after the engine is started. If the front passenger seat is occupied, the occupant classification sensor will then classify the front pas- senger after several more seconds. WARNING Do not put a heavy load in the front passenger seatback pocket or on the front passenger seat. Do not hang onto the front passenger seat. Do not hang any items such as seatback table on the front passen- ger seatback. Do not place feet on the front passenger seatback. Do not place any items under the front passenger seat. Any of these could interfere with proper sensor opera- tion. Proper position B990A01O When an adult is seated in the front pas- senger seat, if the "PASSENGER AIR BAG OFF" indicator is on, turn the igni- tion key to "LOCK" and ask the passen- ger to sit properly (sitting upright with the seat back in an upright position, centered on the seat cushion with their seat belt on, legs comfortably extended and their feet on the floor). Restart the engine and have the person remain in that position. This will allow the system to detect the person and to enable the passenger air bag. 3 35 (Continued) (cid:129) Do not modify or replace the front passenger seat. Don't place any- thing on or attach anything such as a blanket or after market seat heater to the front passenger seat. This can adversely affect the occupant classification system. (cid:129) Do not sit on sharp objects such as tools when occupying the front passenger seat.This can adverse- ly affect the occupant classifica- tion system. (cid:129) Do not use accessory seat covers on the front seats. (Continued) Safety system of your vehicle CAUTION If the occupant classification sys- tem is not working properly, the SRS air bag warning light on the instrument panel will illuminate because the passenger's front air bag is connected with the occupant classification system. If there is a malfunction of the occupant classi- fication system, the "PASSENGER AIR BAG OFF" indicator will not illu- minate and the passenger's front air bag will inflate in frontal impact crashes even if there is no occu- pant in the front passenger's seat.If the SRS air bag warning light does not illuminate when the ignition key is turned to the "ON" position, remains illuminated after approxi- mately 6 seconds when the ignition key is turned to the "ON" position, or if it illuminates while the vehicle is being driven,have an authorized Hyundai dealer inspect the occu- pant classification system and the SRS air bag system as soon as pos- sible. 36 WARNING (cid:129) Even though your vehicle is equipped with the occupant clas- sification system, never install a child restraint system in the front passenger's seat. A deploying air bag can forcefully strike a child resulting in serious injuries or death. Any child under 13 years of age should ride in the rear seat. Children for child restraints should use the avail- able lap/shoulder belts. No mat- ter what type of crash, children of all ages are safer when restrained in the rear seat. large too is indicator (cid:129) If the "PASSENGER AIR BAG OFF" illuminated when the front passenger's seat is occupied by an adult and he/she sits properly (sitting upright with the seatback in an upright position, centered on the seat cushion with their seat belt on, legs comfortably extended and their feet on the floor), have that person sit in the rear seat. (Continued) if (Continued) (cid:129) Accident statistics show that chil- dren are safer they are restrained in the rear, as opposed to the front seat. It is recommend- ed restraints be secured in a rear seat, including an infant riding in a rear-facing infant seat, a child riding in a for- ward-facing child seat and an older child riding in a booster seat. that child (cid:129) Air bags can only be used once – have an authorized Hyundai deal- er replace the air bag immediately after deployment. (cid:129) A smaller-stature adult who is not seated correctly (for example: seat excessively reclined, leaning on the center console, or hips shifted forward in the seat) can cause a condition where the advanced frontal air bag system senses less weight than if the occupant were seated properly (sitting upright with the seatback in an upright position, centered on the seat cushion with their seat belt on, legs comfortably extended and their feet on the floor). (Continued) Safety system of your vehicle (Continued) This condition can result in an adult potentially being misclassi- fied and illumination of the "PAS- SENGER AIR BAG OFF" indicator. Driver’s front air bag OHD036023 Driver's and passenger's front air bag is equipped with a Your vehicle Supplemental Restraint (Air bag) System. The indications of the system's presence are the letters "SRS AIR BAG" embossed on the air bag pad cover in the steering wheel and the passenger's side front panel pad above the glove box. The SRS consists of air bags installed under the pad covers in the center of the steering wheel and the passenger's side front panel above the glove box. 3 37 Safety system of your vehicle Passenger’s front air bag OHD036024 The purpose of the SRS is to provide the vehicle's driver and/or the front passen- ger with additional protection than that offered by the seat belt system alone in case of a frontal impact of sufficient severity. The SRS uses sensors to gath- er information about the driver's seat position, the driver's and front passen- ger's seat belt usage and impact severi- ty. 38 The driver's seat track position sensors, which are installed on the seat track, determine if the seat is fore or aft of a ref- erence position. The seat belt buckle sensors determine if the driver and front passenger's seat belts are fastened. These sensors provide the ability to con- trol the SRS deployment based on how close the driver's seat is to the steering wheel, whether or not the seat belts are fastened, and how severe the impact is. The advanced SRS offers the ability to control the air bag inflation with two lev- els. A first stage level is provided for mod- erate-severity impacts. A second stage level is provided for more severe impacts. According to the impact severity, seating position and seat belt usage, the SRSCM(SRS Control Module) controls the air bag inflation. Failure to properly wear seat belts can increase the risk or severity of injury in an accident. Additionally, your vehicle is equipped with an occupant classification system in the front passenger's seat. The occupant classification system detects the pres- ence of a passenger in the front passen- ger's seat and will turn off the front pas- senger's air bag under certain condi- tions. For more detail, see "Occupant Classification System" in this section. CAUTION AIR BAG If a seat track position sensor or an occupant classification system is not working properly, the SRS air bag warning light on the instru- ment panel will illuminate because the SRS air bag warning light is connected with the seat track posi- tion sensor and the occupant clas- sification system.If the SRS air bag warning light does not illuminate when the ignition key is turned to the "ON" position, remains illumi- nated after approximately 6 sec- onds when the ignition key is turned to the "ON" position,or if it illuminates while the vehicle is being driven, have an authorized Hyundai dealer inspect the advanced SRS air bag system as soon as possible. WARNING (cid:129) Modification to the seat structure can adversely affect the seat track position sensor and cause the air bag to deploy at a different level than should be provided. (cid:129) Do not place any objects under- neath the front seats as they could damage the seat track posi- tion sensor or interfere with the occupant classification system. (cid:129) Do not place any objects that may cause magnetic fields near the front seat. These may cause a malfunction of the seat track position sensor. ✽✽ NOTICE • Be sure to read information about the SRS on the labels provided on the sun visor and in the glove box. • Advanced air bags are combined with pre-tensioner seat belts to help pro- vide enhanced occupant protection in frontal crashes. Front air bags are not intended to deploy in collisions in which sufficient protection can be provided by the pre-tensioner seat belt. • If you are considering modification of your vehicle due to a disability, please contact the Hyundai Customer Assistance Center at 1-800-633-5151. Safety system of your vehicle WARNING Always use seat belts and child restraints – every trip, every time, everyone! Air bags inflate with considerable force and in the blink of an eye. Seat belts help keep occupants in proper position to obtain maximum benefit from the air bag. Even with advanced air bags, improperly and unbelted occupants can be severely injured when the air bag inflates. Always follow the precautions about seat belts, air bags and occupant safety contained in this manual. To reduce the chance of serious or fatal injuries and receive the maxi- mum safety benefit from your restraint system: (cid:129) Never place a child in any child or booster seat in the front seat. (cid:129) ABC – Always Buckle Children in the back seat. It is the safest place for children of any age to ride. (cid:129) Front and side air bags can injure occupants improperly positioned in the front seats. (Continued) 3 39 Safety system of your vehicle (Continued) (cid:129) Move your seat as far back as practical from the front air bags, while still maintaining control of the vehicle. (cid:129) You and your passengers should never sit or lean unnecessarily close to the air bags. Improperly positioned drivers and passen- gers can be severely injured by inflating air bags. (cid:129) Never lean against the door or center console – always sit in an upright position. (cid:129) Do not allow a passenger to ride in the front seat when the “PAS- SENGER AIR BAG OFF” indicator is illuminated, because the air bag will not deploy in the event of a moderate or severe frontal crash. (Continued) 40 (Continued) (cid:129) Air bags can only be used once – have an authorized Hyundai deal- er replace the air bag immediate- ly after deployment. (cid:129) The SRS is designed to deploy the front air bags only when an impact is sufficiently severe and when the impact angle is less than 30° from the forward longitu- dinal axis of the vehicle. Additionally, the air bags will only deploy once. Seat belts must be worn at all times. in side-impact, (cid:129) Front air bags are not intended to rear- deploy impact or rollover crashes. In addition, front air bags will not deploy in frontal crashes below the deployment threshold. (Continued) (Continued) (cid:129) No objects should be placed over or near the air bag modules on the steering wheel, instrument panel, and the front passenger's panel above the glove box, because any such object could cause harm if the vehicle is in a crash severe enough to cause the air bags to deploy. (cid:129) Never place covers, blankets or aftermarket seat warmers on the passenger seat as these may interfere with the occupant clas- sification system. (cid:129) Do not tamper with or disconnect SRS wiring or other components of the SRS system. Doing so could result in injury, due to acci- dental deployment of the air bags or by rendering the SRS inopera- tive. (cid:129) If the SRS air bag warning light remains illuminated while the vehicle is being driven, have an authorized Hyundai dealer inspect the air bag system as soon as possible. (Continued) Rear impact Side impact 1VQA2087 Rollover 1JBA3514 1JBA3522 (Continued) (cid:129) Even though your vehicle is equipped with the occupant clas- sification system, do not install a child restraint system in the front passenger seat position. A child restraint system must never be placed in the front seat.The infant or child could be severely injured or killed by an air bag deployment in case of an accident. be always (cid:129) Children younger than 13 years must properly restrained in the rear seat. Never allow children to ride in the front passenger seat. If a child over 13 must be seated in the front seat, he or she must be properly belted and the seat should be moved as far back as possible. (cid:129) For maximum safety protection in all types of crashes, all occu- pants including the driver should always wear their seat belts whether or not an air bag is also provided at their seating position to minimize the risk of severe injury or death in the event of a crash. Do not sit or lean unneces- sarily close to the air bag while the vehicle is in motion. (Continued) Safety system of your vehicle (Continued) (cid:129) Sitting improperly or out of posi- tion can result in serious or fatal injury in a crash. All occupants should sit upright with the seat back in an upright position, cen- tered on the seat cushion with their seat belt on, legs comfort- ably extended and their feet on the floor until the vehicle is parked and the ignition key is removed. (cid:129) The SRS air bag system must deploy very rapidly to provide protection in a crash. If an occu- pant is out of position because of not wearing a seat belt, the air bag may forcefully contact the occupant causing serious or fatal injuries. 3 41 Safety system of your vehicle OUN026109/OUN026110 B990B02LZ Side air bag (if equipped) Your vehicle is equipped with a side air bag in each front seat. The purpose of the air bag is to provide the vehicle's driv- er and/or the front passenger with addi- tional protection than that offered by the seat belt alone. 42 The side air bags are designed to deploy only during certain side-impact collisions, depending on the crash severity, angle, speed and point of impact. The side air bags are not designed to deploy in all side impact situations. WARNING (cid:129) The side air bag is supplemental to the driver's and the passen- ger's seat belt systems and is not a substitute for them. Therefore your seat belts must be worn at all times while the vehicle is in motion. The air bags deploy only in certain side impact conditions severe enough to cause signifi- cant injury to the vehicle occu- pants. (cid:129) For best protection from the side air bag system and to avoid being injured by the deploying side air bag, both front seat occupants should sit in an upright position with the seat belt properly fas- tened. The driver's hands should be placed on the steering wheel at the 9:00 and 3:00 positions. The passenger's arms and hands should be placed on their laps. (Continued) (Continued) (cid:129) Do not use any accessory seat covers. (cid:129) Use of seat covers could reduce or prevent the effectiveness of the system. (cid:129) Do not install any accessories on the side or near the side air bag. (cid:129) Do not place any objects over the air bag or between the air bag and yourself. (cid:129) Do not place any objects (an umbrella, bag, etc.) between the front door and the front seat. Such objects may become dan- gerous projectiles and cause injury if the supplemental side air bag inflates. (cid:129) To prevent unexpected deploy- ment of the side air bag that may result in personal injury, avoid impact to the side impact sensor when the ignition key is on. (cid:129) If seat or seat cover is damaged, have the vehicle checked and repaired by an authorized Hyundai dealer. Inform them that your vehicle is equipped with side air bags and an occupant classification system. The curtain air bags are designed to deploy only during certain side impact collisions, depending on the crash sever- ity, angle, speed and impact. The curtain air bags are not designed to deploy in all side impact situations, collisions from the front or rear of the vehicle or in most rollover situations. WARNING (cid:129) In order for side and curtain air bags to provide its best protec- tion, both front seat occupants and both outboard rear occu- pants should sit in an upright position with the seat belts prop- erly fastened. Importantly, chil- dren should sit in a proper child restraint system in the rear seat. (cid:129) When children are seated in the rear outboard seats, they must be seated the proper child restraint system. Make sure to put the child restraint system as far away from the door side as possible, and secure the child restraint system in a locked posi- tion. in (Continued) OHD036125 OUN026090 Curtain air bag (if equipped) Curtain air bags are located along both sides of the roof rails above the front and rear doors. They are designed to help protect the heads of the front seat occupants and the rear outboard seat occupants in cer- tain side impact collisions. Safety system of your vehicle (Continued) (cid:129) Do not allow the passengers to lean their heads or bodies onto doors, put their arms on the doors, stretch their arms out of the window, or place objects between the doors and passen- gers when they are seated on seats equipped with side and/or curtain air bags. (cid:129) Never try to open or repair any components of the side curtain air bag system. This should only be done by an authorized Hyundai dealer. Failure to follow the above men- tioned instructions can result in injury or death to the vehicle occu- pants in an accident. 3 43 Safety system of your vehicle Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection. These include rear impacts, second or third collisions in multiple impact accidents, as well as low speed impacts. In other words, just because your vehicle is damaged and even if it is totally unusable, don’t be surprised that the air bags did not inflate. Air bag collision sensors (1) SRS control module (2) Front impact sensor OHD036026/OHD036028/OHD036029/OHD036030 (3) Side impact sensor (if equipped) 44 Safety system of your vehicle WARNING (cid:129) Do not hit or allow any objects to impact the locations where air bag or sensors are installed. This may cause unexpected air bag deployment, which could result in serious personal injury or death. (cid:129) If the installation location or angle of the sensors is altered in any way, the air bags may deploy when they should not or they may not deploy when they should, causing severe injury or death. Therefore, do not try to perform maintenance on or around the air bag sensors. Have the vehicle checked and repaired by an authorized Hyundai dealer. (Continued) (Continued) (cid:129) Problems may arise if the sensor installation angles are changed due to the deformation of the front bumper, body or B pillar where side collision sensors are installed. Have the vehicle checked and repaired by an authorized Hyundai dealer. (cid:129) Your vehicle has been designed to absorb impact and deploy the air bag(s) in certain collisions. Installing aftermarket bumper guards or replacing a bumper with non-genuine parts may adversely affect your vehicle’s collision and air bag deployment performance. 1JBA3513 Air bag inflation conditions Front air bag Front air bags are designed to inflate in a frontal collision depending on the intensi- ty, speed or angles of impact of the front collision - generally from an area a little to the left to a little to the right of straight ahead. 3 45 Safety system of your vehicle Although the front air bags (driver’s and front passenger’s air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of colli- sions if the front impact sensors detect a sufficient impact. Side air bags (side and/or curtain air bags) are designed to inflate only in side impact collisions, but they may inflate in other collisions if the side impact sensors detect a sufficient impact. If the vehicle chassis is impacted by bumps or objects on unimproved roads or sidewalks, air bags may deploy. Drive carefully on unimproved roads or on sur- faces not designed for vehicle traffic to prevent unintended air bag deployment. 1JBA3516 1JBA3515 Air bag non-inflation conditions (cid:129) In certain low-speed collisions the air bags may not deploy. The air bags are designed not to deploy in such cases because they may not provide benefits beyond the protection of the seat belts in such collisions. OUN026090 Side and/or air bags (if equipped) Side and/or curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the strength, speed or angles of impact resulting from a side impact collision or rollover. 46 Safety system of your vehicle 1VQA2087 (cid:129) Frontal air bags are not designed to inflate in rear collisions, because occu- pants are moved backward by the force of the impact. In this case, inflat- ed air bags would not be able to pro- vide any additional benefit. 1JBA3516 (cid:129) Front air bags may not inflate in side impact collisions, because occupants move to the direction of the collision, and thus in side impacts, frontal air bag deployment would not provide addi- tional occupant protection. However, side or curtain air bags may inflate depending on the intensity, vehi- cle speed and angles of impact. 1JBA3521 (cid:129) In a slant or angled collision, the force of impact may direct the occupants in a direction where the air bags would not be able to provide any additional bene- fit, and thus the sensors may not deploy any air bags. 3 47 Safety system of your vehicle 1JBA3517 (cid:129) Just before impact, drivers often brake heavily. Such heavy braking lowers the front portion of the vehicle causing it to “ride” under a vehicle with a higher ground clearance. Air bags may not inflate in this "under-ride" situation because deceleration forces that are detected by sensors may be signifi- cantly reduced by such “under-ride” collisions. 1JBA3522 (cid:129) Air bags may not inflate in rollover acci- dents because air bag deployment would not provide protection to the occupants. However, side and/or curtain air bags may inflate when the vehicle is rolled over by a side impact collision, if the vehicle is equipped with side air bags and curtain air bags. 1JBA3518 (cid:129) Air bags may not inflate if the vehicle collides with objects such as utility poles or trees, where the point of impact is concentrated to one area and the full force of the impact is not deliv- ered to the sensors. 48 (cid:129) In order to help provide protection in a severe collision, the air bags must inflate rapidly. The speed of air bag inflation is a consequence of the extremely short time in which a collision occurs and the need to get the air bag between the occupant and the vehicle structures before the occupant impacts those structures. This speed of inflation reduces the risk of serious or life- threatening injuries in a severe collision and is thus a necessary part of air bag design. However, air bag inflation can also cause injuries which normally can include facial abrasions, bruises and broken bones, and sometimes more severe injuries because the inflation speed also causes the air bags to expand with a great deal of force. (cid:129) There are even circumstances under which contact with the steer- ing wheel air bag can cause fatal injuries, especially if the occupant is positioned excessively close to the steering wheel. How does the air bag system operate (cid:129) Air bag only operates when the ignition switch is turned to ON or START posi- tion. (cid:129) Air bags inflate instantly in the event of serious frontal or side collision (if equipped with side air bag or curtain air bag) in order to help protect the occupants from serious physical injury. (cid:129) There is no single speed at which the air bags will inflate. Generally, air bags are designed to inflate by the severity of a collision and its direction. These two factors deter- mine whether the sensors send out an electronic deployment/inflation signal. (cid:129) Air bag deployment depends on a number of factors including vehicle speed, angles of impact and the densi- ty and stiffness of the vehicles or objects which your vehicle hits in the collision. Though, factors are not limit- ed to those mentioned above. (cid:129) The front air bags will completely inflate and deflate in an instant. It is virtually impossible for you to see the air bags inflate during an accident. It is much more likely that you will sim- ply see the deflated air bags hanging out of their storage compartments after the collision. Safety system of your vehicle WARNING (cid:129) To avoid severe personal injury or death caused by deploying air bags in a collision, the driver should sit as far back from the steering wheel air bag as possi- ble (at least 10 inches (250 mm) away). The front passenger should always move their seat as far back as possible and sit back in their seat. (cid:129) Air bag inflates instantly in an event of collision, passengers may be injured by the air bag expansion force if they are not in proper position. (cid:129) Air bag inflation may cause injuries which normally include facial or bodily abrasions, injuries by the broken glasses or burns by the explosives. 3 49 Safety system of your vehicle Noise and smoke When the air bags inflate, they make a loud noise and they leave smoke and powder in the air inside of the vehicle. This is normal and is a result of the igni- tion of the air bag inflator. After the air bag inflates, you may feel substantial dis- comfort in breathing due to the contact of your chest to both the seat belt and the air bag, as well as from breathing the smoke and powder. We strongly urge you to open your doors and/or win- dows as soon as possible after impact in order to reduce discomfort and pre- vent prolonged exposure to the smoke and powder. Though smoke and powder are non- toxic, it may cause irritation to the skin (eyes, nose and throat etc). If this is the case, wash and rinse with the cold water immediately and consult the doctor if the symptom persists. 50 WARNING When the air bags deploy, the air bag related parts in steering wheel and/or instrument panel and/or in both sides of the roof rails above the front and rear doors are very hot. To prevent injury, do not touch the air bag storage area’s internal components immediately after an air bag has inflated. 1JBH3051 Installing a child restraint on a front passenger’s seat is forbidden Never place a rear-facing child restraint in the front passenger’s seat. If the air bag deploys, it would impact the rear-fac- ing child restraint, causing serious or fatal injury. In addition, do not place front-facing child restraint in the front passenger’s seat either. If the front passenger air bag inflates, it would cause serious or fatal injuries to the child. Safety system of your vehicle When the ignition switch is turned ON, the indicator light should illuminate for approximately 6 seconds, then go off. Have the system checked if: (cid:129) The light does not turn on briefly when you turn the ignition ON. (cid:129) The light stays on after illuminating for approximately 6 seconds. (cid:129) The light comes on while the vehicle is in motion. WARNING (cid:129) Never put child restraint in the front passenger’s seat. If the front passenger air bag inflates, it would cause serious or fatal injuries. (cid:129) When children are seated in the rear outboard seats in which side air bags are equipped, be sure to put the child restraint system as far away from the door side as possible, and secure the child restraint system to be locked in position. Inflation of side or curtain air bag could cause serious injury or death due to the expansion impact. AIR BAG Air bag warning light The purpose of air bag warning light in your instrument panel is to alert you of a potential problem with your air bag - Supplemental Restraint System (SRS). 3 51 Safety system of your vehicle SRS Care The SRS is virtually maintenance-free and so there are no parts you can safely service by yourself. If the SRS "AIR BAG" warning light does not illuminate, or con- tinuously remains on, have your vehicle immediately inspected by an authorized Hyundai dealer. Any work on the SRS system, such as removing, installing, repairing, or any work on the steering wheel must be per- formed by an authorized Hyundai dealer. Improper handling of the SRS system may result in serious personal injury. WARNING (cid:129) Do not install a child restraint system in the front passenger seat position. A child restraint system must never be placed in the front seat. The infant or child could be severely injured by an air bag deployment in case of an accident. (cid:129) Modification to SRS components or wiring, including the addition of any kind of badges to the pad covers or modifications to the body structure, can adversely affect SRS performance and lead to possible injury. (cid:129) For cleaning the air bag pad cov- ers, use only a soft, dry cloth or one which has been moistened with plain water. Solvents or cleaners could adversely affect the air bag covers and proper deployment of the system. (cid:129) No objects should be placed over or near the air bag modules on the steering wheel, instrument panel, and the front passenger's panel above the glove box, because any such object could cause harm if the vehicle is in a crash severe enough to cause the air bags to inflate. (Continued) 52 (Continued) (cid:129) If the air bags inflate, they must be replaced by an authorized Hyundai dealer. (cid:129) Do not tamper with or disconnect SRS wiring, or other components of the SRS system. Doing so could result in injury, due to acci- dental inflation of the air bags or by rendering the SRS inopera- tive. (cid:129) If components of the air bag sys- tem must be discarded, or if the vehicle must be scrapped, certain safety precautions must be observed. An authorized Hyundai dealer knows these precautions and can give you the necessary information. Failure to follow these precautions and proce- dures could increase the risk of personal injury. (cid:129) If your car was flooded and has soaked carpeting or water on flooring, you shouldn't try to start the engine; have the car towed to an authorized Hyundai dealer. Additional safety precautions (cid:129) Never let passengers ride in the cargo area or on top of a folded- down back seat. All occupants should sit upright, fully back in their seats with their seat belts on and their feet on the floor. (cid:129) Passengers should not move out of or change seats while the vehicle is moving. A passenger who is not wear- ing a seat belt during a crash or emer- gency stop can be thrown against the inside of the vehicle, against other occupants, or out of the vehicle. (cid:129) Each seat belt is designed to restrain one occupant. If more than one person uses the same seat belt, they could be seriously injured or killed in a collision. (cid:129) Do not use any accessories on seat belts. Devices claiming to improve occupant comfort or reposition the seat belt can reduce the protection provided by the seat belt and increase the chance of serious injury in a crash. (cid:129) Passengers should not place hard or sharp objects between them- selves and the air bags. Carrying hard or sharp objects on your lap or in your mouth can result in injuries if an air bag inflates. (cid:129) Keep occupants away from the air bag covers. All occupants should sit upright, fully back in their seats with their seat belts on and their feet on the floor. If occupants are too close to the air bag covers, they could be injured if the air bags inflate. (cid:129) Do not attach or place objects on or near the air bag covers. Any object attached to or placed on the front or side air bag covers could interfere with the proper operation of the air bags. (cid:129) Do not modify the front seats. Modification of the front seats could interfere with the operation of the sup- plemental restraint system sensing components or side air bags. (cid:129) Do not place items under the front seats. Placing items under the front seats could interfere with the operation of the supplemental restraint system sensing components and wiring har- nesses. (cid:129) Never hold an infant or child on your lap. The infant or child could be seri- ously injured or killed in the event of a crash. All infants and children should be properly restrained in appropriate child safety seats or seat belts in the rear seat. Safety system of your vehicle WARNING (cid:129) Sitting improperly or out of posi- tion can cause occupants to be shifted too close to a deploying air bag, strike the interior struc- ture or be thrown from the vehicle resulting in serious injury or death. (cid:129) Always sit upright with the seat- back in an upright position, cen- tered on the seat cushion with your seat belt on, legs comfort- ably extended and your feet on the floor. Adding equipment to or modify- ing your air bag-equipped vehicle If you modify your vehicle by changing your vehicle's frame, bumper system, front end or side sheet metal or ride height, this may affect the operation of your vehicle's air bag system. 3 53 Safety system of your vehicle (if equipped) (if equipped) (if equipped) (if equipped) Air bag warning label Air bag warning labels required by the U.S. National Highway Traffic Safety Administration (NHTSA) are attached to alert driver and passengers of potential risks of the air bag system. OHD036027/OHD036117L/1VQA2097/OHD036121L/OHD036122L 54 Keys / 4-2 Remote keyless entry / 4-3 Theft-alarm system / 4-6 Door locks / 4-8 Trunk / 4-12 Windows / 4-14 Hood / 4-18 Fuel filler lid / 4-20 Features of your vehicle Sunroof / 4-23 Steering wheel / 4-28 Mirrors / 4-30 Instrument cluster / 4-38 Hazard warning flasher / 4-50 Lighting / 4-51 Wipers and washers / 4-54 Interior light / 4-56 Defroster / 4-59 Manual climate control system / 4-60 Automatic climate control system / 4-69 Windshield defrosting and defogging / 4-77 Storage compartment / 4-80 Interior features / 4-82 Audio system / 4-87 WARNING Use only Hyundai original parts for the ignition key in your vehicle. If an aftermarket key is used, the igni- tion switch may not return to ON after START. If this happens, the starter will continue to operate causing damage to the starter motor and possible fire due to excessive current in the wiring. Features of your vehicle KEYS OHD046100L OHD046101L Record your key number The key code number is stamped on the bar code tag attached to the key set. Should you lose your keys, this number will enable an authorized Hyundai dealer to duplicate the keys easily. Remove the bar code tag and store it in a safe place. Also, record the code number and keep it in a safe and handy place, but not in the vehicle. Key operations Used to start the engine, lock and unlock the doors. WARNING - Ignition key Leaving children unattended in a vehicle with the ignition key is dan- gerous even if the key is not in the ignition. Children copy adults and they could place the key in the igni- tion. The ignition key would enable children to operate power windows or other controls, or even make the vehicle move, which could result in serious bodily injury or even death. Never leave the keys in your vehicle with unsupervised children. 24 REMOTE KEYLESS ENTRY (IF EQUIPPED) Unlock (2) Driver's door is unlocked if the unlock button is pressed once. The hazard warning lights will blink twice to indicate that the driver's door is unlocked. All doors are unlocked if the unlock but- ton is pressed twice within 4 seconds. The hazard warning lights will blink twice again to indicate that all doors are unlocked. After depressing this button, the doors will be locked automatically unless you open any door within 30 seconds. OHD046102N Remote keyless entry system operations Lock (1) All doors are locked if the lock button is pressed. If all doors are closed, the hazard warn- ing lights blink once to indicate that all doors are locked. However, if any door remains open, the hazard warning lights don’t blink. After this, if all doors are closed, the hazard warning lights blink. Trunk lid open (3) The trunk lid opens if this button is pressed (more than 0.5 second). Alarm (4) The horn sounds and hazard warning lights flash for about 30 seconds if this button is pressed. To stop the horn and lights, press any button on the transmit- ter. Features of your vehicle weak. Transmitter precautions ✽✽ NOTICE The transmitter will not work if any of following occur: • The ignition key is in ignition switch. • You exceed the operating distance limit (about 30 feet [10 m]). • The battery in the transmitter is • Other vehicles or objects may be blocking the signal. • The weather is extremely cold. • The transmitter is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the transmitter. When the transmitter does not work correctly, open and close the door with the ignition key. If you have a problem with the transmitter, contact an author- ized Hyundai dealer. 4 3 Features of your vehicle CAUTION Keep the transmitter away from water or any liquid. If the keyless entry system is inoperative due to exposure to water or liquids,it will not be covered by your manufactur- er vehicle warranty. Operational distance may vary depend- ing upon the area the transmitter is used in. For example, if the vehicle is parked near police stations, government and public offices, broadcasting stations, mil- itary installations, airports, or transmit- ting towers, etc. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interfer- ence received, including interference that may cause undesired operation. CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 44 OHD046103 Battery replacement Transmitter uses a 3 volt lithium battery which will normally last for several years. When replacement is necessary, use the following procedure. 1. Insert a slim tool into the slot and gen- tly pry open the transmitter center cover (1). 2. Replace the battery with new one. When replacing the battery, make sure the battery positive “+” symbol faces up as indicated in the illustration. 3. Install the battery in the reverse order of removal. For replacement transmitters, see an authorized Hyundai dealer for repro- gramming. CAUTION The keyless entry system transmit- ter is designed to give you years of trouble-free use, however it can malfunction if exposed to moisture or static electricity. If you are unsure how to use your transmitter or replace the battery, contact an authorized Hyundai dealer. CAUTION (cid:129) Using the wrong battery can cause the transmitter to malfunc- tion. Be sure to use the correct battery. (cid:129) To avoid damaging the transmit- ter, don't drop it, get it wet, or expose it to heat or sunlight. Features of your vehicle 4 5 Features of your vehicle THEFT-ALARM SYSTEM (IF EQUIPPED) Armed stage Disarmed stage Theft-alarm stage This system is designed to provide pro- tection from unauthorized entry into the car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Theft-alarm" stage, and the third is the "Disarmed" stage. If trig- gered, the system provides an audible alarm with blinking of the hazard warning lights. Armed stage Park the car and stop the engine. Arm the system as described below. 1. Remove the ignition key from the igni- tion switch. 2. Make sure that all doors, the engine hood and trunk lid are closed and latched. 3. Lock the doors using the transmitter of the keyless entry system. After completion of the steps above, the hazard warning lights will blink once to indicate that the system is armed. If any door, trunk lid or engine hood remains open, the hazard warning lights won’t operate and theft-alarm will not arm. After this, if all doors, trunk lid and engine hood are closed, the hazard warning lights blink once. The system can be armed by locking the doors with the key from the front doors or trunk lid. However, the hazard warning lights are not operated. (cid:129) Do not arm the system until all pas- sengers have left the vehicle. If the system is armed while a passen- ger(s) remains in the vehicle, the alarm may be activated when the remaining passenger(s) leave the vehicle. If any door, trunk lid or engine hood is opened within 30 seconds after entering the armed stage, the system is disarmed to prevent unnecessary alarm. 64 Withheld alarm If the trunk lid is opened with the trans- mitter during the armed stage, the alarm will not be activated but the armed state will be maintained for the doors and hood. Theft-alarm stage The alarm will be activated if any of the following occurs while the system is armed. (cid:129) A front or rear door is opened without using the ignition key or transmitter. (cid:129) The trunk lid is opened without using the ignition key or transmitter. (cid:129) The engine hood is opened. The siren will sound and the hazard warning lights will blink continuously for 27 seconds, and repeat the alarm 3 times unless the system is disarmed. To turn off the system, unlock the doors with the ignition key or transmitter. Features of your vehicle Disarmed stage The system will be disarmed when the doors are unlocked by depressing the unlock button on the transmitter or unlocked with the ignition key. After depressing unlock button, the haz- ard warning lights will blink twice to indi- cate that the system is disarmed. After depressing unlock button, if any door is not opened within 30 seconds, the system will be rearmed. ✽✽ NOTICE • Avoid trying to start the engine while the alarm is activated. The vehicle starting motor is disabled during the theft-alarm stage. If the system is not disarmed with the ignition key or transmitter, insert the key into the ignition switch, turn the ignition switch to the ON position and wait for 30 seconds. Then the system will be disarmed. • If you lose your keys, consult your authorized Hyundai dealer. 4 7 Features of your vehicle DOOR LOCKS Unlock Lock OHD046001 Operating door locks from out- side the vehicle (cid:129) Turn the key toward rear of vehicle to unlock and toward front of vehicle to lock. (cid:129) If you lock/unlock the door with a key, all vehicle doors will lock/unlock auto- matically. (cid:129) From the driver’s door, turn the key to the right once to unlock the driver’s door and once more within 4 seconds to unlock all doors. (if equipped) 84 (cid:129) Doors can also be locked and unlocked with the transmitter key (if equipped). (cid:129) Once the doors are unlocked, they may be opened by pulling the door handle. (cid:129) When closing the door, push the door by hand. Make sure that doors are closed securely. ✽✽ NOTICE In cold and wet climates, door lock and door mechanisms may not work proper- ly due to freezing conditions. ✽✽ NOTICE If the door is locked/unlocked multiple times in rapid succession with either the vehicle key or door lock switch, the sys- tem may stop operating temporarily in order to protect the circuit and prevent damage to system components. OHD046002 (cid:129) To lock a door without the key, push the inside door lock button (1) or central door lock switch (2) (if equipped) to the “Lock” position and close the door (3). (cid:129) If you lock the door with the central door lock switch, all vehicle doors will lock automatically. (if equipped) ✽✽ NOTICE Always remove the ignition key, engage the parking brake, close all windows and lock all doors when leaving your vehicle unattended. Features of your vehicle (cid:129) Front doors cannot be locked if the ignition key is in the ignition switch and any front door is open. Driver’s door WARNING - Door lock mal- function If a power door lock ever fails to function while you are in the vehi- cle, try one or more of the following techniques to exit: (cid:129) Operate the door unlock feature repeatedly (both electronic and manual) while simultaneously pulling on the door handle. (cid:129) Operate the other door locks and handles, front and rear. (cid:129) Lower a front window and use the key to unlock the door from out- side. OHD046004 With central door lock switch (if equipped) It is operated by depressing the door lock switch. If the “Lock” position is switched when any door is open, the door will remain locked when closed. 4 9 Unlock Lock OHD046003 Operating door locks from inside the vehicle With the door lock button (cid:129) To unlock a door, push the door lock button (1) to the “Unlock” position. The red mark (2) on the button will be visi- ble. (cid:129) To lock a door, push the door lock but- ton (1) to the “Lock” position. If the door is locked properly, the red mark (2) on the door lock button will not be visible. (cid:129) To open a door, pull the door handle (3) outward. (cid:129) If the inner door handle of the front door is pulled when the door lock but- ton is in lock position, the button is unlocked and door opens. (if equipped) Features of your vehicle (cid:129) When pushing down on the front por- tion (1) of the switch, all vehicle doors will lock. (cid:129) When pushing down on the rear por- tion (2) of the switch, all vehicle doors will unlock. (cid:129) However, if the key is in the ignition switch and any front door is open, the doors will not lock when the front por- tion of central door lock switch is pressed. WARNING - Doors (cid:129) The doors should always be fully closed and locked while the vehi- cle is in motion to prevent acci- dental opening of the door. Locked doors will also discour- age potential intruders when the vehicle stops or slows. (cid:129) Be careful when opening doors and watch for vehicles, motorcy- cles, bicycles or pedestrians approaching the vehicle in the path of the door. Opening a door when something is approaching can cause damage or injury. WARNING - Unlocked vehicles Leaving your vehicle unlocked can invite theft or possible harm to you or others from someone hiding in your vehicle while you are gone. Always remove the ignition key, engage the parking brake, close all windows and lock all doors when leaving your vehicle unattended. WARNING - Unattended children An enclosed vehicle can become extremely hot, causing death or severe injury to unattended chil- dren or animals who cannot escape the vehicle. Furthermore, children might operate features of the vehi- cle that could injure them, or they could encounter other harm, possi- bly from someone gaining entry to the vehicle. Never leave children or animals unattended in your vehicle. 10 Impact sensing door unlock sys- tem (if equipped) All doors will be automatically unlocked when the impact is delivered to impact sensors while the ignition switch ON. However, the doors may not be unlocked when there are some problems of mechanical door lock system or battery. Speed sensing door lock system (if equipped) When the speed of the vehicle keeps above 20 km/h for 1 second, it will auto- matically lock all doors. For activation of this feature, contact an authorized Hyundai dealer. Features of your vehicle 3. Close the rear door. To open the rear door, pull the outside door handle (1). Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle (2) until rear door child safety lock is unlocked ( ). WARNING - Rear door locks If children accidentally open the rear doors while the vehicle is in motion, they could fall out and be severely injured or killed. To pre- vent children from opening the rear doors from the inside, the rear door safety locks should be used when- ever children are in the vehicle. 4 11 OHD046005 Child-protector rear door lock The child safety lock is provided to help prevent children from accidentally open- ing the rear doors from inside the vehicle. The rear door safety locks should be used whenever children are in the vehi- cle. 1. Open the rear door. 2. Push the child safety lock located on the rear edge of the door to the “Lock” position. When the child safety lock is in the “Lock ( )” position, rear door will not open even though the inner door handle is pulled inside the vehi- cle. Features of your vehicle TRUNK Closing the trunk To close, lower the trunk lid, then press down on it until it locks. To be sure the trunk lid is securely fastened, always check by trying to pull it up again. WARNING The trunk lid should be always kept completely closed while the vehicle is in motion. If it is left open or ajar, poisonous exhaust gases may enter the car and serious illness or death may result. See additional warnings concerning exhaust gases in section 5, “Engine exhaust can be dangerous!”. OHD046007 OHD046006 Opening the trunk With remote trunk lid release To open the trunk lid without using the key, push the trunk lid release button. With the key To open the trunk lid, insert the key and turn it clockwise to unlock. The trunk compartment light will illuminate when the trunk lid is opened. 12 OHD046008 Emergency trunk safety release Your vehicle is equipped with an emer- gency trunk release cable located inside the trunk. The lever glows in the dark when the trunk lid is closed. If someone is inadvertently locked in the trunk, pulling this handle will release the trunk latch mechanism and open the trunk. WARNING No one should be allowed to occu- py the trunk of the vehicle at any time. If the trunk is partially or total- ly latched and the person is unable to get out, severe injury or death could occur due to lack of ventila- tion, exhaust fumes and rapid heat build-up, or because of exposure to cold weather conditions. The trunk is also a highly dangerous location in the event of a crash because it is not a protected occupant space but merely a part of the vehicle’s crush zone. CAUTION (cid:129) If a person is locked in the trunk, they can pull the emergency release to open the trunk lid. (cid:129) We recommend that cars be kept locked and keys be kept out of the reach of children, and that parents teach their children about the dangers of playing in trunks. Features of your vehicle 4 13 Features of your vehicle WINDOWS Power windows (if equipped) (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window up*/down* (Driver’s window) (7) Power window lock switch *: if equipped ✽✽ NOTICE In cold and wet climates, power win- dows may not work properly due to freezing conditions. OHD046009 14 The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door’s window. However, the driver has a power window lock switch which can block the operation of passenger windows. The power windows can be operated for approximately 30 seconds after the igni- tion key is removed or turned to the ACC or LOCK position. However, if the front doors are opened, the power windows cannot be operated even within the 30 seconds after the ignition key removal. While driving, if you notice buffeting and pulsation (wind shock) with either side window open, you should open the oppo- site window slightly to reduce the condi- tion. CAUTION (cid:129) To prevent the power window system from the possibility of damage,do not open or close two windows at the same time. This will also ensure the longevity of the fuse. (Continued) (Continued) (cid:129) Never try to operate the main switch on the driver's door and the individual door window switch in opposing directions at the same time.If this is done,the window will stop and cannot be opened or closed. WARNING - Windows (cid:129) Always double check to make sure all arms, hands, head and other obstructions are safely out of the way before closing a win- dow. (cid:129) Do not allow children to play with the power windows. Keep the dri- ver’s door power window lock switch in the LOCK position (depressed). Serious injury can result from unintentional window operation by the child. (cid:129) Do not extend face or arms out- side through the window opening while driving. Features of your vehicle Window opening and closing The driver’s door has a master power window switch that controls all the win- dows in the vehicle. (cid:129) To open or close a window, press down or pull up the front portion of the corre- sponding switch to the first detent posi- tion (5). Auto down window (if equipped) (driver’s window) Depressing the power window switch momentarily to the second detent posi- tion (6) completely lowers the driver’s window even when is released. To stop the window at the desired position while the window is in operation, pull up the switch momentarily to the opposite direction of the window movement. the switch 4 15 Features of your vehicle
