) button, the screen changes as ▼ shown on the next page. Press the INFO ( / ) button until you see the setup you want to customize, then press the SEL/RESET button to enter your selection.

▲ ▼

If you do not make any changes, select ‘‘EXIT.’’ The display returns to the normal display.

If you want the settings as they were when the vehicle left the factory, select DEFAULT ALL, as described on page

.96

When you want to change the vehicle control settings, press the INFO ( / ) button to select CHANGE SETTINGS, then press the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:47:48 31TK8600_104

Multi-Information Display

METER SETUP (See page 100.)

POSITION SETUP (See page 109.)

LIGHTING SETUP (See page 112.)

DOOR SETUP (See page 119.)

99

: Press the INFO ( ) button. : Press the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:47:55 31TK8600_105

Multi-Information Display

Meter Setup Here are the four custom settings for the meter setup:

LANGUAGE SELECTION ADJUST OUTSIDE TEMP. DISPLAY TRIP A RESET WITH REFUEL ELAPSED TIME RESET

Each time you press the INFO ( / ▲ ) button, the screen changes as ▼ shown in the illustration. Press the INFO ( / ) button until you see the setting you want to customize, then press the SEL/RESET button to enter your selection.

▲ ▼

100

: Press the INFO ( ) button. : Press the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:48:02 31TK8600_106

LanguageSelection

Multi-Information Display

There are three selectable languages: English, French, and Spanish. To choose the language you want, follow these instructions:

You can choose this item to customize from ‘‘METER SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to see the selections.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

CONTINUED

101

2011 Odyssey10/07/17 09:48:08 31TK8600_107

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If you fail to enter your selection, you will see ‘‘SETTING INCOMPLETE’’ on the display, then the display goes back to the previous display. Repeat the setup.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

102

2011 Odyssey10/07/17 09:48:15 31TK8600_108

AdjustOutsideTemp.Display If you sometimes find that the temperature reading is a few degrees above or below the actual temperature, you can adjust it by following these instructions:

Multi-Information Display

U.S. model is shown.

You can choose this item to customize from ‘‘METER SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Adjust the outside temperature value by pressing the INFO ( / ) button repeatedly. Press the SEL/RESET button to set the desired value.

▲ ▼

Press the SEL/RESET button to see the selections.

CONTINUED

103

2011 Odyssey10/07/17 09:48:21 31TK8600_109

Multi-Information Display

U.S. model is shown.

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If you fail to enter your selection, you will see ‘‘SETTING INCOMPLETE’’ on the display, then the display goes back to the previous display. Repeat the setup.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

104

2011 Odyssey10/07/17 09:48:28 31TK8600_110

TripAResetwithRefuel

Multi-Information Display

To cause Trip A and average fuel for trip A to reset every time you refuel your vehicle, follow these instructions:

You can choose this item to customize from ‘‘METER SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to see the selections.

Select ON or OFF by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/ RESET button.

▲ ▼

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

CONTINUED

105

2011 Odyssey10/07/17 09:48:32 31TK8600_111

Multi-Information Display

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘TRIP A RESET with REFUEL’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

106

2011 Odyssey10/07/17 09:48:41 31TK8600_112

ElapsedTimeReset There are three elapsed time reset choices you can make:

−

IGN OFF The elapsed time is reset when you turn the ignition switch to the LOCK (0) position.

TRIP A when Trip A is reset.

−

The elapsed time is reset

TRIP B when Trip B is reset.

−

The elapsed time is reset

Multi-Information Display

You can choose this item to customize from ‘‘METER SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to see the selections.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

CONTINUED

107

2011 Odyssey10/07/17 09:48:46 31TK8600_113

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘ELAPSED TIME RESET’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

108

2011 Odyssey10/07/17 09:48:52 31TK8600_114

Position Setup You can customize the MEMORY POSITION LINK setting in position setup.

While ‘‘POSITION SETUP’’ is shown, press the SEL/RESET button to enter the customize mode.

Each time you press the INFO ( / ▲ ) button, the screen changes as ▼ shown in the illustration. Press the INFO ( / ) button until you see the setting you want to customize, then press the SEL/RESET button to enter your selection.

▲ ▼

Multi-Information Display

CONTINUED

109

: Press the INFO (

▲ ▼

) button.

: Press the SEL/RESET button.

2011 Odyssey10/07/17 09:49:00 31TK8600_115

Multi-Information Display

MemoryPositionLink If ‘‘MEMORY POSITION LINK’’ is ‘‘ON,’’ the driver’s seat and outside mirrors move to the positions stored in the memory when you open the driver’s door, using the remote transmitter.

MemoryPositionSetup

190

to set the driving Refer to page position memory. Also refer to page 150

for remote transmitter use.

You can choose this item to customize from ‘‘POSITION SETUP’’ by pressing the INFO ( / ▲ ▼

) button repeatedly.

Press the SEL/RESET button to see the selections.

Select ON or OFF by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/ RESET button.

▲ ▼

110

2011 Odyssey10/07/17 09:49:05 31TK8600_116

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘MEMORY POSITION LINK’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

111

2011 Odyssey10/07/17 09:49:12 31TK8600_117

Multi-Information Display

Lighting Setup Here are the three custom settings for the lighting setup:

INTERIOR LIGHT DIMMING TIME HEADLIGHT AUTO OFF TIMER AUTO LIGHT SENSITIVITY

While ‘‘LIGHTING SETUP’’ is shown, press the SEL/RESET button to enter the customize mode.

Each time you press the INFO ( / ▲ ) button, the screen changes as ▼ shown in the illustration. Press the INFO ( / ) button until you see the setting you want to customize, then press the SEL/RESET button to enter your selection.

▲ ▼

112

: Press the INFO ( ) button. : Press the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:49:20 31TK8600_118

InteriorLightDimmingTime

Multi-Information Display

The interior lights fade out when you close all doors and tailgate. To change how long the lights stay on before they fade out, follow these instructions:

You can choose this item to customize from ‘‘LIGHTING SETUP’’ by pressing the INFO ( / ▲ ▼

) button repeatedly.

Press the SEL/RESET button to see the selections.

Select the desired setting (15 sec, 30
sec, or 60 sec) by pressing the INFO ( / ) button, then enter your ▲ ▼ selection by pressing the SEL/ RESET button.

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

CONTINUED

113

2011 Odyssey10/07/17 09:49:24 31TK8600_119

Multi-Information Display

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘INTERIOR LIGHT DIMMING TIME’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

114

2011 Odyssey10/07/17 09:49:31 31TK8600_120

HeadlightAutoOffTimer The headlights, parking lights, side marker lights, taillights, and license plate lights go off after the selected time when you remove the key from the ignition switch and close the driver’s door. To change how long the lights stay on before they go off, follow these instructions:

Multi-Information Display

You can choose this item to customize from ‘‘LIGHTING SETUP’’ by pressing the INFO ( / ▲ ▼

) button repeatedly.

Press the SEL/RESET button to see the selections.

Select the desired setting (60 sec, 30
sec, 15 sec or 0 sec) by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/ RESET button.

▲ ▼

CONTINUED

115

2011 Odyssey10/07/17 09:49:36 31TK8600_121

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘HEADLIGHT AUTO OFF TIMER’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

116

2011 Odyssey10/07/17 09:49:45 31TK8600_122

Multi-Information Display

AutoLightSensitivity The headlights automatically come on when the headlight switch is in the AUTO position and the ambient light reaches a changeable level. You can select the auto light sensitivity from the following five levels: MAX The headlights come on when it is bright. HIGH The headlights come on when it is somewhat bright.

−

−

−

MID The headlights come on when it is as bright as sunset or sunrise.

−

LOW The headlights come on when it is somewhat dark.

−

MIN The headlights come on when it is dark.

You can choose this item to customize from ‘‘LIGHTING SETUP’’ by pressing the INFO ( / ▲ ▼

) button repeatedly.

Press the SEL/RESET button to see the selections.

Select the desired setting (MAX, HIGH, MID, LOW or MIN) by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

CONTINUED

117

2011 Odyssey10/07/17 09:49:50 31TK8600_123

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘AUTO LIGHT SENSITIVITY’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

118

2011 Odyssey10/07/17 09:50:00 31TK8600_124

Door Setup Here are the seven custom settings for the door setup:

AUTO DOOR LOCK AUTO DOOR UNLOCK KEY AND REMOTE UNLOCK MODE PSD (POWER SLIDING DOORS) KEYLESS OPEN MODE PTG (POWER TAILGATE) KEYLESS OPEN MODE KEYLESS LOCK ACKNOWLEDGMENT SECURITY RELOCK TIMER

While ‘‘DOOR SETUP’’ is shown, press the SEL/RESET button to enter the customize mode.

Multi-Information Display

U.S. models only

CONTINUED

119

: Press the INFO ( ) button. : Press the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:50:08 31TK8600_125

Multi-Information Display

Each time you press the INFO ( / ▲ ) button, the screen changes as ▼ shown in the illustration. Press the INFO ( / ) button, until you see the setting you want to customize, then press the SEL/RESET button to enter your selection.

▲ ▼

AutoDoorLock There are three settings you can choose from:

−

OFF The auto door lock mode is deactivated all the time.

−

WITH VEH SPD The doors lock when the vehicle speed reaches about 10 mph (about 15 km/h).

SHIFT FROM P The doors lock whenever you move the shift lever out of Park.

−

120

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to enter the selecting mode.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:50:14 31TK8600_126

Multi-Information Display

When your selection is entered, you will see the above display for several seconds, and then the display goes back to ‘‘CUSTOMIZE MENU.’’

If you fail to enter your selection, you will see the above display for several seconds, and the display goes back to ‘‘CUSTOMIZE MENU.’’ Repeat the setup.

To exit ‘‘AUTO DOOR LOCK,’’ press the INFO button until you see ‘‘EXIT,’’ then press the SEL/RESET button.

CONTINUED

121

2011 Odyssey10/07/17 09:50:23 31TK8600_127

Multi-Information Display

AutoDoorUnlock There are five possible settings:

−

OFF deactivated all the time.

The auto door unlock is

DRIVER DOOR With SHIFT to P − The driver’s door unlocks when you move the shift lever to Park with the brake pedal depressed.

ALL DOORS With SHIFT to P All the doors unlock when you move the shift lever to Park with the brake pedal depressed.

−

DRIVER DOOR With IGN OFF − The driver’s door unlocks when you turn the ignition switch to the LOCK (0) position.

ALL DOORS With IGN OFF All the doors unlock when you turn the ignition switch to the LOCK (0) position.

−

122

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to enter the selecting mode.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:50:29 31TK8600_128

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘AUTO DOOR UNLOCK’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

CONTINUED

123

2011 Odyssey10/07/17 09:50:35 31TK8600_129

Multi-Information Display

KeyandRemoteUnlockMode To select whether the driver’s door unlocks or all the doors and the tailgate unlock when you push the UNLOCK button on the remote transmitter or use the key on the driver’s door lock, follow these instructions.

124

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to enter the selecting mode.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:50:41 31TK8600_130

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘KEY AND REMOTE UNLOCK MODE’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

CONTINUED

125

2011 Odyssey10/07/17 09:50:48 31TK8600_131

Multi-Information Display

PSD(PowerSlidingDoors)Keyless OpenMode You can customize the power sliding doors setting so that the power sliding doors can’t be opened without unlocking them first from the outside.

There are two settings you can choose from:

−

The sliding door

ANYTIME unlocks and opens when you press and hold the sliding door button on the remote transmitter for 1 second. The front door on the same side also unlocks at the same time.

WHEN UNLOCKED In this mode, you must unlock the sliding door before opening it.

−

126

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to see the selections.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:50:54 31TK8600_132

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘PSD KEYLESS OPEN MODE’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

CONTINUED

127

2011 Odyssey10/07/17 09:51:04 31TK8600_133

Multi-Information Display

PTG(PowerTailgate)KeylessOpen Mode U.S.modelsonly You can customize the power tailgate setting not to open without unlocking the tailgate lock first by remote transmitter from the outside. There are two settings you can choose from: ANYTIME The tailgate unlocks − and opens when you press and hold the tailgate button on the remote transmitter for 1 second. The tailgate will automatically relock when you close it when the doors are locked. WHEN UNLOCKED In this mode, you must unlock the tailgate before opening it. In addition, the tailgate will not automatically relock when you close it. OnCanadianmodels See page the power tailgate keyless open mode.

for how to customize

165

−

128

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button to see the selections.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:51:10 31TK8600_134

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘PTG KEYLESS OPEN MODE’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

CONTINUED

129

2011 Odyssey10/07/17 09:51:16 31TK8600_135

Multi-Information Display

KeylessLockAcknowledgment When you push the LOCK button on the remote transmitter, some exterior lights flash, and a beeper sounds when you push the LOCK button again within 5 seconds to verify that the doors and the tailgate are locked and the security system has set (see page customize the exterior lights not to flash and the beeper not to sound.

). You can

479

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button. The display changes as shown above.

Select ON or OFF by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/ RESET button.

▲ ▼

130

2011 Odyssey10/07/17 09:51:23 31TK8600_136

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘KEYLESS LOCK ACKNOWLEDGMENT’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

CONTINUED

131

2011 Odyssey10/07/17 09:51:29 31TK8600_137

Multi-Information Display

SecurityRelockTimer If you unlock the doors and the tailgate with the remote transmitter, but do not open any of the doors or the tailgate within 30 seconds, the doors and the tailgate automatically relock and the security system sets.

You can change this relock time from 30 seconds to 60 or 90 seconds.

132

You can choose this item to customize from ‘‘DOOR SETUP’’ by pressing the INFO ( / ) button repeatedly.

▲ ▼

Press the SEL/RESET button, then press the INFO button.

Select the desired setting by pressing the INFO ( / ) button, then enter your selection by pressing the SEL/RESET button.

▲ ▼

2011 Odyssey10/07/17 09:51:35 31TK8600_138

Multi-Information Display

When your selection is successfully completed, the display changes as shown above, and then goes back to the customize item screen.

If the ‘‘SETTING INCOMPLETE’’ message appears, go back to ‘‘SECURITY RELOCK TIMER’’ and repeat the procedure again.

To exit this mode without changing the settings, select ‘‘EXIT’’ by pressing the INFO button, then press the SEL/RESET button. The display goes back to the customize item screen.

133

2011 Odyssey10/07/19 15:50:55 31TK8600_139

Controls Near the Steering Wheel

REMOTE AUDIO CONTROLS (P.411)

＊

HEADLIGHT/TURN SIGNAL/ FOG LIGHTS (P.136)

＊

VEHICLE STABILITY ASSIST (VSA) OFF SWITCH (P.571) BLIND SPOT INFORMATION SYSTEM (BSI) OFF SWITCH ＊ (P.585) POWER SLIDING DOOR SWITCHES (P.169)

＊

POWER TAILGATE SWITCH ＊ (P.163) PARKING SENSOR SYSTEM SWITCH ＊ (P.486) VOICE CONTROL BUTTONS ＊ (P.496, 517)

CRUISE CONTROL BUTTONS (P.480)

WINDSHIELD WIPERS/WASHERS (P.135)

HORN ＊

HAZARD WARNING BUTTON (P.142)

PASSENGER AIRBAG OFF INDICATOR (P.33)

SEAT HEATER SWITCHES (P.189)

＊

AUDIO SYSTEM (P.234) REAR ENTERTAINMENT SYSTEM ＊ (P.414, 442)

AUXILIARY INPUT JACK (P.412)

BLUETOOTH HANDSFREELINK BUTTONS

STEERING WHEEL ADJUSTMENTS (P.143)

MULTI-INFORMATION BUTTONS (P.83)

＊

COOL BOX SWITCH ＊ (P.209)

(P.496, 517) Vehicle with navigation system is shown.

＊

To use the horn, press the center pad of the steering wheel. If equipped

1 : ＊ 2 : ＊ 134

2011 Odyssey10/07/17 09:51:52 31TK8600_140

Windshield Wipers

ADJUSTMENT RING

1. 2. 3. 4. 5. 6.

MIST OFF INT LO Low speed HI High speed Windshield washers

Intermittent

− − −

Windshield Wipers and Washers

MIST The wipers run at high speed until you release the lever.

−

OFF

−

The wipers are not activated.

−

INT The length of the wipe interval is varied automatically according to vehicle’s speed.

Vary the delay by turning the adjustment ring. If you turn it to the shortest delay ( position), the wipers change to low speed operation when the vehicle speed exceeds 12 mph (20 km/h).

LO

−

The wipers run at low speed.

HI

−

The wipers run at high speed.

−

Pull the

Windshield Washer wiper control lever toward you, and hold it. The washers spray until you release the lever. The wipers run at low speed, then complete one more sweep after you release the lever.

Push the right lever up or down to select a position.

135

2011 Odyssey10/07/17 09:52:04 31TK8600_141

Windshield Wipers and Washers, Turn Signal and Headlights

Rear Window Wiper and Washer

Rotate the switch counterclockwise also to spray the window washer and turn the wiper on.

Turn Signal and Headlights

When you shift the transmission to the reverse position with the front windshield wiper activated, the rear wiper operates automatically even if the rear wiper switch is off.

When the wiper control lever is positioned as follows:

1.

2.

3.

OFF When you turn the wiper switch to the ‘‘OFF’’ position, the wiper will return to its parked position. Rotate the switch clockwise to turn the rear window wiper ON. The wiper operates every 7
seconds after completing two sweeps. Hold past ON to activate the rear window wiper a few times and to spray the rear window washer.

136

−

INT operates intermittently.

The rear window wiper

LO or HI operates continuously.

−

The rear window wiper

The rear window washer uses the same fluid reservoir as the wind- shield washer.

1. 2. 3. 4. 5. 6. 7. 8. 9.

＊

Turn signal Off Parking and indicator lights AUTO Headlights on High beams Flash high beams Fog lights off Fog lights on

＊

＊

＊

If equipped

2011 Odyssey10/07/17 09:52:10 31TK8600_142

−

Turn Signal Push down on the lever to signal a left turn and up to signal a right turn. To signal a lane change, push lightly on the lever, and hold it. The lever will return to center when you release it or complete a turn.

−

Turning the ’’ position turns

Headlights On switch to the ‘‘ on the parking lights, taillights, instrument panel lights, side-marker lights, and rear license plate lights.

Turning the switch to the ‘‘ position turns on the headlights.

’’

’’ or ‘‘

When the light switch is in the ‘‘ ’’ position, the lights on indicator comes on as a reminder. This indicator stays on if you leave the light switch on and turn the ignition switch to the ACCESSORY (I) or the LOCK (0) position.

Turn Signal and Headlights

If you leave the lights on with the key removed from the ignition switch, you will hear a reminder chime when you open the driver’s door.

−

High Beams To switch from low beams to high beams, push the left lever forward until you hear a click. The high beam indicator will come on (see page ). Pull it back to return to low beams. To flash the high beams, pull the lever back lightly, then release it. The high beams will stay on as long as you hold the lever back.

73

CONTINUED

137

2011 Odyssey10/07/17 09:52:17 31TK8600_143

Headlights

−

OnallmodelsexceptLX AUTO The automatic lighting feature turns on the headlights, all other exterior lights, and the instrument panel lights when it senses low ambient light.

To turn on the automatic lighting, turn the light switch to the AUTO position. The lights will come on automatically when the outside light level becomes low (at dusk, for example). The lights on indicator comes on as a reminder. The lights and indicator turn off automatically when the system senses high ambient light.

The lights turn off automatically when you turn the ignition switch to the LOCK (0) position. To turn them on again, either turn the ignition switch to the ON (II) position, or turn the light switch to the

position.

138

LIGHT SENSOR

Even with the automatic lighting feature turned on, we recommend that you turn on the lights manually when driving at night or in a dense fog, or when you enter dark areas such as long tunnels or parking facilities.

OnTouringmodels To change the ‘‘AUTO LIGHT SENSITIVITY’’ setting, see page

.117

The automatic lighting feature is controlled by a sensor located on top of the dashboard. Do not cover this sensor or spill liquids on it.

2011 Odyssey10/07/17 09:52:25 31TK8600_144

Fog Lights OnTouringmodels

Turn the fog lights on and off by turning the switch next to the headlight switch.

Headlights

You can use the fog lights only when the headlights are on low beam. With the light switch in the AUTO position, you can also use the fog lights when the headlights turn on automatically. They will go off when the headlights turn off, or the daytime running lights are on.

Daytime Running Lights With the headlight switch off, the daytime running lights come on when you turn the ignition switch to the ON (II) position and release the parking brake. They remain on until you turn the ignition switch off, even if you set the parking brake.

When the headlights are on, the daytime running lights are off.

OnTouringmodels If you see a ‘‘CHECK DRL SYSTEM’’ message on the multi- information display, there is a problem with the daytime running light system. Take your vehicle to a dealer to have it checked.

When the multi-information display shows a ‘‘DRL OFF’’ message, the daytime running lights are off. Follow the procedure in the left column to turn them on.

139

2011 Odyssey10/07/17 09:52:33 31TK8600_145

Headlights, Instrument Panel Brightness

Automatic Lighting Off Feature This feature turns off the headlights, all other exterior lights, and the instrument panel lights within 15
seconds after you remove the key and close the driver’s door.

If you turn the ignition switch to the LOCK (0) position with the headlight switch on, but do not open the door, the lights turn off after 10
minutes (3 minutes, if the switch is in the ‘‘AUTO’’ position).

Instrument Panel Brightness

OnTouringmodels To change the ‘‘HEADLIGHT AUTO OFF TIMER’’ setting, see page

115

’’ or ‘‘

The automatic lighting off feature activates if you leave the headlight switch in the ‘‘ position or if the lights are turned on by setting the switch in the ‘‘AUTO’’ position (if equipped), and you remove the key, then open and close the driver’s door.

’’

The lights will turn on again when you unlock or open the driver’s door. If you unlock the door, but do not open it within 15 seconds, the lights will go off. With the driver’s door open, you will hear a lights on reminder chime.

SELECT/RESET KNOB

You can change the instrument panel brightness only when the light switch is on.

Turn the knob on the lower part of the instrument panel to adjust the brightness.

140

2011 Odyssey10/07/17 09:52:40 31TK8600_146

Except Touring model is shown.

Touring model is shown.

BRIGHTNESS LEVEL

BRIGHTNESS LEVEL

The level of brightness is shown on the display while you adjust it. It goes out 5 seconds after you finish adjusting.

You will hear a beep when maximum or minimum brightness is reached. You will also hear a beep when the maximum level is canceled by turning the knob a click to the left.

To reduce glare at night, the instrument panel illumination dims when you turn the light switch to

or

. Turning the select/

reset knob to the right until you hear a beep will cancel the reduced brightness.

Instrument Panel Brightness

If you do not insert the key in the ignition switch after opening the driver’s door, the illumination turns off about 30 seconds after you close the door.

If you insert the key but do not turn the ignition switch to the ON (II) position, the illumination turns off in about 10 seconds.

141

2011 Odyssey10/07/17 09:52:49 31TK8600_147

Hazard Warning Button, Rear Window Defogger

Hazard Warning Button

Rear Window Defogger

Except U.S. LX model

U.S. LX model

Push the button between the center vents to turn on the hazard warning lights (four-way flashers). This causes all outside turn signals and both indicators in the instrument panel to flash. Use the hazard warning lights if you need to park in a dangerous area near heavy traffic, or if your vehicle is disabled.

The rear window defogger clears fog, frost, and thin ice from the window. Push the defogger button to turn it on and off. Pushing this button also turns the mirror heaters on and off. The indicator in the button comes on to show the defogger is on. If you do not turn it off, the defogger will shut itself off after 10 to 30 minutes (depending on the ambient temperature). It also shuts off when you turn off the ignition switch. You

142

have to turn it on again when you restart the vehicle.

OnLXmodels The defogger will shut itself off within about 20 minutes.

Make sure the rear window is clear and you have good visibility before starting to drive.

The defogger wires on the inside of the rear window can be accidentally damaged. When cleaning the glass, always wipe side-to-side.

Ifequipped Pushing this button also turns the mirror heaters on or off. For more information, see page

199

2011 Odyssey10/07/17 09:52:56 31TK8600_148

Make any steering wheel adjustments before you start driving.

Adjusting the steering wheel position while driving may cause you to lose control of the vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the vehicle is stopped.

Steering Wheel Adjustments

3.

Push the lever up to lock the steering wheel in position.

4.

Make sure you have securely locked the steering wheel in place by trying to move it up, down, in, and out.

143

LEVER

1.

Push the lever under the steering column all the way down.

2.

Move the steering wheel up or down, and in or out, so it points toward your chest, not toward your face. Make sure you can see the instrument panel gauges and indicators.

2011 OdysseyEX-L and Touring models KEY NUMBER TAG

VALET KEY (Gray)

MASTER KEYS WITH REMOTE TRANSMITTER

10/07/17 09:53:02 31TK8600_149

Keys and Locks

LX models KEY NUMBER TAG

MASTER KEYS WITH REMOTE TRANSMITTER

VALET KEY (Gray)

EX models KEY NUMBER TAG

VALET KEY (Gray)

MASTER KEYS WITH REMOTE TRANSMITTER

The master key fits all the locks on your vehicle. The valet key works only in the ignition and the door locks. You can keep the glove box locked when you leave your vehicle and the valet key at a parking facility.

You should have received a key number tag with your keys. You will need this key number if you ever
