Before driving


Introduction


Instrumentation


Controls and features


Seating and safety restraints


Starting and driving


Starting


Driving


Roadside emergencies


Servicing


Maintenance and care


Capacities and specifications


Customer assistance


Reporting safety defects


Index


Contents


18


66


98


102


121


144


192


203


215


216


All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2000 Ford Motor Company


Introduction


The following warning may be required by California law: CALIFORNIA Proposition 65 Warning


WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to


the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.


ICONS Indicates a safety alert. Read the following section on Warnings.


Indicates vehicle information related to recycling and other environmental concerns will follow. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards protecting the environment. Indicates a message regarding child safety restraints. Refer to Seating and safety restraints for more information.


Indicates that this Owner Guide contains information on this subject. Please refer to the Index to locate the appropriate section which will provide you more information.


Introduction


WARNINGS Warnings provide information which may reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment.


BREAKING-IN YOUR VEHICLE There are no particular breaking-in rules for your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in.


INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing. Ford may change the contents without notice and without incurring obligation.


EMISSION WARRANTY The New Vehicle Limited Warranty includes Bumper to Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.


Introduction


SPECIAL NOTICES


Notice to owners of pickup trucks and utility type vehicles


Utility vehicles have a significantly higher rollover rate than other types of vehicles.


Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or an accident. Be sure to read Driving off road in the Driving chapter as well as the “Four Wheeling” supplement included with 4WD and utility type vehicles.


Using your vehicle as an ambulance If your light truck is equipped with the Ford Ambulance Preparation Package, it may be utilized as an ambulance. Ford urges ambulance manufacturers to follow the recommendations of the Ford Incomplete Vehicle Manual, Ford Truck Body Builder’s Layout Book and the QVM guidelines as well as pertinent supplements. For additional information, please contact the Truck Body Builders Advisory Service 1–877–840–4338. Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance usage without the preparation package could cause high underbody temperatures, overpressurized fuel and a risk of spraying fuel which could lead to fires.


Introduction


If your vehicle is equipped with the Ford Ambulance Preparation Package, it will be indicated on the Certification label. The label is located on the driver’s side door pillar or on the rear edge of the driver’s door. You can determine whether the ambulance manufacturer followed Ford’s recommendations by directly contacting that manufacturer. Ford Ambulance Preparation Package is only available on certain 7.3L Diesel engine equipped vehicles.


Notice to owners of diesel-powered vehicles Read the 7.3 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for information regarding correct operation and maintenance of your diesel-powered light truck.


Notice to owners of natural gas fueled vehicles Before you drive your vehicle, be sure to read the “Natural Gas Vehicle Owner’s Guide Supplement.” This book contains important operation and maintenance information.


Introduction


These are some of the symbols you may see on your vehicle.


Vehicle Symbol Glossary


Safety Alert


See Owner’s Guide


Fasten Safety Belt


Air Bag-Front


Air Bag-Side


Child Seat


Child Seat Installation Warning


Child Seat Tether Anchorage


Brake System


Anti-Lock Brake System


Brake Fluid - Non-Petroleum Based


Traction Control


Master Lighting Switch


Hazard Warning Flasher


Fog Lamps-Front


Fuse Compartment


Fuel Pump Reset


Windshield Wash/Wipe


Rear Window Defrost/Demist


Power Window Lockout


Windshield Defrost/Demist


Power Windows Front/Rear


Introduction


Vehicle Symbol Glossary


Child Safety Door Lock/Unlock


Interior Luggage Compartment Release Symbol


Panic Alarm


Engine Oil


Engine Coolant


Engine Coolant Temperature


Do Not Open When Hot


Battery


Avoid Smoking, Flames, or Sparks


Battery Acid


Explosive Gas


Fan Warning


Power Steering Fluid


Maintain Correct Fluid Level


MAX MIN


Emission System


Engine Air Filter


Passenger Compartment Air Filter


Jack


Check fuel cap


Instrumentation


Instrument cluster


(pg. 10)


Speed control*


(pg. 50)


Headlamp control


(pg. 18)


*if equipped


Turn signal and


wiper/washer control


(pg. 54)


Driver air bag


(pg. 83)


Instrumentation


Auxiliary power point


(pg. 26)


Climate control system


(pg. 19)


Gearshift (includes overdrive button)


(pg. 108)


Audio system


(pg. 27)


Instrumentation


WARNING LIGHTS AND CHIMES


50 60


80


100


70


40


60


30


40


0 0 0 0 0 0


120


20
10


20 km/h


MPH


0 0 0 0


140


80
90
100


160


BRAKE


18


SERVICE


ENGINE SOON


Brake system warning Momentarily illuminates when the ignition is turned to the ON position to indicate a system check. Also illuminates if the parking brake is engaged. If the brake warning lamp does not illuminate at these times, seek service immediately. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately.


BRAKE


Anti-lock brake system (ABS) Momentarily illuminates when the ignition is turned to the ON position to indicate a system check. If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released.


ABS


Service engine soon Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II). The OBD II system protects the environment by ensuring that your vehicle continues to meet


SERVICE ENGINE SOON


10


Instrumentation


government emission standards. The OBD II system also assists the service technician in properly servicing your vehicle. The Service Engine Soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. If it comes on after the engine is started, one of the engine’s emission control systems may be malfunctioning. The light may illuminate without a driveability concern being noted. The vehicle will usually be drivable and will not require towing. WhatyoushoulddoiftheServiceEngineSoonlightilluminates Light turns on solid: This means that the OBD II system has detected a malfunction. Temporary malfunctions may cause your Service Engine Soon light to illuminate. Examples are: 1. The vehicle has run out of fuel. (The engine may misfire or run poorly.) 2. Poor fuel quality or water in the fuel. 3. The fuel cap may not have been properly installed and securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Service Engine Soon light should turn off. (A driving cycle consists of a cold engine startup followed by mixed city/highway driving.) No additional vehicle service is required. If the Service Engine Soon light remains on, have your vehicle serviced at the first available opportunity. Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity.


Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.


11


Instrumentation


Transmission control indicator light (TCIL) Illuminates when the Transmission Control Switch (TCS), refer to Overdrive control in the Controls and Features chapter, has been pushed turning the transmission overdrive function OFF. When the TCIL (the word OFF on the gear shift) light is on, the transmission does not operate in the overdrive mode, refer to the Driving chapter for transmission function and operation. The light may also flash steadily if a transmission malfunction is detected. If the light does not come on when the Transmission Control Switch is depressed or if the light flashes steadily, have your vehicle serviced as soon as possible, damage to the transmission could occur.


OVERDRIVE


Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts. For more information, refer to the Seating and safety restraints chapter.


Charging system Illuminates when the ignition is turned to the ON position and the engine is off. The light also illuminates when the battery is not charging properly, requiring electrical system service.


Air bag readiness Momentarily illuminates when the ignition is turned ON. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately.


12


Instrumentation


Turn signal Illuminates when the left or right turn signal or the hazard lights are turned on. If one or both of the indicators stay on continuously, check for a burned-out turn signal bulb. Refer to Bulbs in the Maintenance and care chapter.


High beams Illuminates when the high beam headlamps are turned on.


very high


Oil pressure/Engine coolant This light will come on when the key is in the ON position and the: † engine coolant temperature is † engine oil pressure is low The light serves as a notice that a system needs your attention and to check the engine coolant temperature gauge and the engine oil pressure gauge. Refer to Engine coolant temperature gauge and Engine oil pressure gauge in this chapter for more information.


Safety belt warning chime/buzzer Sounds to remind you to fasten your safety belts. For information on the safety belt warning chime, refer to the Seating and safety restraints chapter.


Belt minder chime Sounds intermittently to remind you to fasten your safety belts. For information on the safety belt minder chime, refer to the Seating and safety restraints chapter.


13


Instrumentation


Supplemental restraint system (SRS) warning chime For information on the SRS warning chime, refer to the Seating and safety restraints chapter.


Key-in-ignition warning chime/buzzer Sounds when the key is left in the ignition in the OFF/LOCK or ACC position and the driver’s door is opened.


Headlamps on warning chime (if equipped) Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened.


GAUGES


50 60


80


100


70


40


60


30


40


0 0 0 0 0 0


120


20
10


20 km/h


MPH


0 0 0 0


140


80
90
100


160


Speedometer Indicates the current vehicle speed.


40


18


50 60


80


100


70


60


30


40


0 0 0 0 0 0


120


20 km/h


MPH


0 0 0 0


140


80
90
100


160


20
10


14


Instrumentation


Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or after refueling. The ignition should be in the OFF position while the vehicle is being refueled. When the gauge first indicates empty, there is a small amount of reserve fuel in the tank. When refueling the vehicle from an empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.


Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine immediately and let the engine cool. Refer to Engine coolant in the Maintenance and care chapter.


Never remove the coolant reservoir cap while the engine is running or hot.


This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. If the gauge enters the red section, the oil pressure/engine coolant and Check Engine/Service Engine Soon indicators illuminate, refer to What you should know about fail-safe cooling in the Maintenance and care chapter.


15


Instrumentation


Engine oil pressure gauge This shows the engine oil pressure in the system. Sufficient pressure exists as long as the needle remains in the normal range (the area between the “L” and “H”). If the gauge indicates low pressure, stop the vehicle as soon as safely possible and switch off the engine immediately. Check the oil level. Add oil if needed (refer to Engine oil in the Maintenance and care chapter). If the oil level is correct, have your vehicle checked at your dealership or by a qualified technician.


Battery voltage gauge This shows the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the vehicle’s electrical system checked as soon as possible.


Odometer Registers the total kilometers (miles) of the vehicle.


20
10


16


18


40


60


30


40


50 60


80


100


70


0 0 0 0 0 0


120


20 km/h


MPH


0 0 0 0


140


80
90
100


160


Instrumentation


Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control.


40


50 60


80


100


70


60


30


40


0 0 0 0 0 0


120


20
10


20 km/h


MPH


0 0 0 0


140


80
90
100


160


17


Controls and features


HEADLAMP CONTROL † Pull the headlamp control toward you to the first position to turn on the parking lamps, tail lamps, license plate lamps and marker lamps.


† Pull the headlamp control toward you to the outer position to turn on the headlamps (in addition to the previous lamps).


Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: † the ignition must be in the ON position and † the headlamp control is in the OFF or Parking lamps position.


Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System


does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.


High beams Push forward to activate. Pull toward you to deactivate.


18


Controls and features


Flash to pass Pull toward you to activate and release to deactivate.


PANEL DIMMER CONTROL To adjust the brightness of the instrument panel: † Rotate


clockwise/counterclockwise when the headlamp control is in the parking lamp or low-beam position.


To turn on the courtesy lamp, cargo lamps or the dome lamp: † Rotate fully counterclockwise. The dome lamp will not illuminate if the control switch is in the OFF position.


CLIMATE CONTROL SYSTEM


Heater only system (if equipped)


FAN


HI


LO


OFF


MIX


FLR


VENT


COOL


WARM


Fanspeedcontrol Controls the volume of air circulated in the vehicle.


FAN


HI


LO


19


Controls and features


Temperaturecontrolknob Controls the temperature of the airflow inside the vehicle. On heater-only systems, the air cannot be cooled below the outside temperature.


Modeselectorcontrol Controls the direction of the airflow to the inside of the vehicle.


COOL


WARM


OFF


MIX


FLR


VENT


† VENT-Distributes outside air through the instrument panel registers. † FLR-Allows for maximum heating. Distributes outside air through the † OFF-Outside air is shut out and the fan will not operate. For short


floor ducts.


periods of time only, use this mode to prevent undesirable odors from entering the vehicle. † MIX-Distributes outside air through the floor ducts and the windshield †


-Distributes outside air through the windshield defroster ducts.


defroster ducts.


It can be used to clear ice or fog from the windshield.


Operatingtips † In humid weather conditions, place the climate control system in


DEF before driving. This will reduce fogging on your windshield. Once the windshield has been cleared, operate the climate control system as desired.


† To reduce humidity buildup inside the vehicle in cold weather


conditions, do not drive with the climate control system in the OFF position.


† Under normal weather conditions, your vehicle’s climate control system should be left in any position other than MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” through the outside air inlet duct.


20


Controls and features


† Under snowy or dirty weather conditions, your vehicle’s climate control system should be left in the OFF position when the vehicle is parked. This allows the climate control system to be free from contamination of outside pollutants.


airflow to the rear seats (if equipped).


† Do not place objects under the front seat that will interfere with the † Remove any snow, ice or leaves from the air intake area at the base of the windshield.


† Do not place objects over the defroster outlets. These objects can block airflow and reduce your ability to see through your windshield. Avoid placing small objects on top of the instrument panel. These objects may fall down into the defroster outlets and block airflow, in addition to damaging the climate control system.


Do not place objects on top of the instrument panel, as these objects may become projectiles in a collision or sudden stop.


Manual heating and air conditioning system (if equipped)


FAN


HI


LO


OFF


VENT


NORM


A/C


MAX A/C


FLR


MIX


COOL


WARM


21


Controls and features


Fanspeedcontrol Controls the volume of air circulated in the vehicle.


Temperaturecontrolknob Controls the temperature of the airflow inside the vehicle.


Modeselectorcontrol Controls the direction of the airflow to the inside of the vehicle.


FAN


HI


LO


COOL


WARM


OFF


VENT


NORM


A/C


MAX A/C


FLR


MIX


The air conditioning compressor can operate in all modes except VENT and FLR. However, the air conditioning will only function if the outside temperature is about 6°C (43°F) or higher. Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you have stopped the vehicle. † MAX A/C-Uses recirculated air to cool the vehicle. MAX A/C is noisier than NORM A/C but more economical and will cool the inside of the vehicle faster. Airflow will be from the instrument panel registers. This mode can also be used to prevent undesirable odors from entering the vehicle.


22


Controls and features † NORM A/C-Uses outside air to cool the vehicle. It is quieter than MAX A/C but not as economical. Airflow will be from the instrument panel registers. † VENT-Distributes outside air through the instrument panel registers.


However, the air will not be cooled below the outside temperature because the air conditioning does not operate in this mode. † OFF-Outside air is shut out and the fan will not operate. For short


periods of time only, use this mode to prevent undesirable odors from entering the vehicle. † FLR-Allows for maximum heating by distributing outside air through the floor ducts. However, the air will not be cooled below the outside temperature because the air conditioning does not operate in this mode.


† MIX-Distributes outside air through the windshield defroster ducts and the floor ducts. Heating and air conditioning capabilities are provided in this mode. For added customer comfort, when the temperature control knob is anywhere in between the full hot and full cold positions, the air distributed through the floor ducts will be slightly warmer than the air sent to the windshield defroster ducts. If the temperature is about 6°C (43°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging.


-Distributes outside air through the windshield defroster ducts. It can be used to clear ice or fog from the windshield. If the temperature is about 6°C (43°F) or higher, the air conditioner will automatically dehumidify the air to reduce fogging.


† DEF


Operatingtips † In humid weather conditions, place the climate control system in DEF before driving. This will reduce fogging on your windshield. Once the windshield has been cleared, operate the climate control system as desired.


† To reduce humidity buildup inside the vehicle in cold weather


conditions, don’t drive with the climate control system in the OFF or MAX A/C position.


† To reduce humidity buildup inside the vehicle in warm weather


conditions, don’t drive with the climate control system in the OFF position.


23


Controls and features † Under normal weather conditions, your vehicle’s climate control system should be left in any position other than MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” through the outside air inlet duct. † Under snowy or dirty weather conditions, your vehicle’s climate control system should be left in the OFF position when the vehicle is parked. This allows the climate control system to be free from contamination of outside pollutants.


† If your vehicle has been parked with the windows closed during warm weather conditions, the air conditioner will perform more efficiently in cooling the vehicle if driven for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle. Once the vehicle has been “aired out”, operate the climate control system as desired. † Do not put objects under the front seat that will interfere with the † Remove any snow, ice or leaves from the air intake area at the base of the windshield.


airflow to the back seats.


† Do not place objects over the defroster outlets. These objects can block airflow and reduce your ability to see through your windshield. Avoid placing small objects on top of the instrument panel. These objects may fall down into the defroster outlets and block airflow, in addition to damaging the climate control system.


Do not place objects on top of the instrument panel, as these objects may become projectiles in a collision or sudden stop.


To aid in side window defogging/demisting in cold weather conditions: 1. Select MIX 2. Set the temperature control to full heat 3. Set the fan speed to HI


24


Controls and features


4. Direct the outer panel vents towards to side windows To increase airflow to the outer panel vents, close the central panel vents.


Auxiliary heater and air conditioner (if equipped) If your vehicle is equipped with a factory installed auxiliary unit, the main climate control panel will include separate controls for the front fan speed and the rear fan speed. In conjunction with the front fan speed control, an additional fan speed control is located overhead between the second and third row seating.


HI


REAR


LO


REAR CTRL OFF


HI


OFF


The fan speed of the auxiliary unit can be controlled either by the front seat using the front auxiliary control or by the rear seat passengers using the rear auxiliary control, but not both. To control the auxiliary unit using the rear control, the front control must be in the REAR position. Air temperature and air distribution are dependent upon the mode that is selected on the main climate control panel: † MAX A/C-Distributes recirculated air conditioning through the † NORM A/C-Distributes recirculated air conditioning through the † VENT-Distributes recirculated ambient air through the overhead vents


overhead vents of the rear compartment.


overhead vents of the rear compartment.


of the rear compartment.


25


vents


Controls and features † OFF-No air, cooled, ambient, or heated, is distributed through any † FLR-Distributes heated air through the floor vents of the rear † MIX-Distributes heated air through the floor vents of the rear †


(Defrost)-Distributes heated air through the floor vents of the


compartment.


compartment.


rear compartment.


AUXILIARY POWER POINT


Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty.


The auxiliary power point is located on the instrument panel. A second power point (if equipped) is located behind the driver’s seat on the upper trim panel. Do not plug optional electrical accessories into the cigarette lighter. Use the power point.


26


Controls and features


USING YOUR AUDIO SYSTEM


AM/FM Stereo (with 2 speakers)


VOL PUSH ON


TONE


CLK


TONE VOL


ST DX FM


12


SEEK


TUNE


AM/FM


AM/FMStereo(with4speakersandfadecapability)


VOL PUSH ON


TONE


CLK


TONE VOL


ST DX FM


12


SEEK


TUNE


AM / FM STEREO


AM/FM


27


Controls and features


Volume/powercontrol Press the control to turn the audio system on or off.


Turn the control to raise or lower volume.


VOL PUSH ON


VOL PUSH ON


If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. AM/FMselect The AM/FM select control works in radio mode.


AM/FM


AM/FMselectinradiomode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. Tuneadjust The tune control works in radio mode. Tuneadjustinradiomode † Press


to move to the next


SEEK


TUNE


frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.


28


† Press


to move to the next frequency up the band (whether or not


a listenable station is located there). Hold for quick movement.


Controls and features


Seekfunction The seek function control works in radio mode. Seekfunctioninradiomode † Press


to find the next listenable station down the frequency band.


† Press


to find the next


listenable station up the frequency band.


SEEK


TUNE


Radiostationmemorypreset The radio is equipped with four station memory preset controls. These controls can be used to select up to four preset AM stations and eight FM stations (four in FM1 and four in FM2). Settingmemorypresetstations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.


Bassadjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the TONE control once, then use the volume knob to adjust the desired level.


TONE


CLK


VOL PUSH ON


29


Controls and features


Trebleadjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Press the TONE control twice, then use the volume knob to adjust the desired level.


Speakerbalanceadjust Speaker sound distribution can be adjusted between the right and left speakers. Press the TONE control three times, then use the volume knob to adjust the desired level.


Speakerfadeadjust(ifequipped) Speaker sound can be adjusted between the front and rear speakers. Press the TONE control four times, then use the volume knob to adjust the desired level.


Settingtheclock Press CLK to toggle between listening frequencies and clock mode. To set the hour, press and hold the CLK control until CLOCK SET appears in the display and press the SEEK control:


30


VOL PUSH ON


VOL PUSH ON


VOL PUSH ON


TONE


CLK


TONE


CLK


TONE


CLK


TONE


CLK


† †


to decrease hours and to increase hours.


To set the minute, press and hold the CLK control until CLOCK SET appears in the display and press the TUNE control:


Controls and features


SEEK


TUNE


SEEK


TUNE


TONE


CLK


SEEK


SEEK


to decrease minutes and to increase minutes.


† † The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for ten seconds, when the radio is turned on, and then revert to clock information. Anytime that the media is changed, (new radio station, etc.), the media information will again display for ten seconds before reverting back to the clock. In media mode, the media information will always be displayed.


TUNE


TUNE


31


Controls and features


AM/FM stereo cassette


VOL - PUSH ON


AM


FM


BASS


TREB


FM1


ST


SEEK


TUNE


SCAN


EJ


BAL


FADE


CLK


TAPE AMS


SIDE REW


1 - 2
FF


Volume/powercontrol Press the control to turn the audio system on or off.


VOL - PUSH ON


Turn the control to raise or lower volume.


VOL - PUSH ON


If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.


32


AM/FMselect The AM/FM select control works in radio and tape modes.


Controls and features


AM


FM


AM/FMselectinradiomode This control allows you to select AM or FM frequency bands. Press the AM control to select from AM selections, and press the FM control to select from FM1 or FM2 memory preset stations. AM/FMselectintapemode Press this control to stop tape play and begin radio play. Tuneadjust The tune control works in radio mode. Tuneadjustinradiomode † Press


to move to the next


frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.


SEEK


TUNE


† Press


to move to the next frequency up the band (whether or not


a listenable station is located there). Hold for quick movement.


Seekfunction The seek function control works in radio mode. Seekfunctioninradiomode † Press


to find the next listenable station down the frequency band.


† Press


to find the next


listenable station up the frequency band.


SEEK


TUNE


33


Controls and features


Scanfunction The scan function works in radio mode.


SCAN


Scanfunctioninradiomode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode. Radiostationmemorypreset The radio is equipped with six station memory preset controls. These controls can be used to select up to six preset AM stations and twelve FM stations (six in FM1 and six in FM2). Settingmemorypresetstations 1. Select the frequency band with the AM or the FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.


Bassadjust The bass adjust control allows you to increase or decrease the audio system’s bass output.


BASS


34


Trebleadjust The treble adjust control allows you to increase or decrease the audio system’s treble output.


Speakerbalanceadjust Speaker sound distribution can be adjusted between the right and left speakers.


Speakerfadeadjust Speaker sound can be adjusted between the front and rear speakers.


Tapeselect † To enter tape mode while in radio


mode, press the TAPE AMS control.


Controls and features


TREB


BAL


FADE


CLK


TAPE AMS


35


Controls and features


CLK


TAPE AMS


AutomaticMusicSearch The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection. To activate the feature, momentarily depress the TAPE AMS button. Then, press either REW (for the beginning of the current selection) or FF (to advance to the next selection). The tape deck stops and returns to play mode when the AMS circuit senses a blank section on the tape. In order to ensure proper operation of the AMS feature, the tape MUST have a blank section of at least four seconds duration between programs. Rewind The rewind control works in tape mode. To rewind in tape mode, press the REW control. Fastforward The fast forward control works in tape mode. † In the tape mode, tape direction will automatically reverse when the end of the tape is reached.


SIDE 1 - 2
REW FF


SIDE REW


1 - 2
FF


Tapedirectionselect Press SIDE and 1–2 at the same time to play the alternate side of a tape.


Ejectfunction Press the control to stop and eject a tape.


36


SIDE REW


1 - 2
FF


EJ


Controls and features


control to activate (and deactivate) Dolbyt noise


DolbyT noisereduction Dolbyt noise reduction operates only in tape mode. Dolbyt noise reduction reduces the amount of hiss and static during tape playback. Press the reduction. Dolbyt noise reduction is manufactured under license from Dolbyt Laboratories Licensing Corporation. “Dolbyt” and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. Settingtheclock Press CLK to toggle between listening frequencies and clock mode while in radio mode. To set the hour, press and hold the CLK control and press the SEEK control:


CLK


TAPE AMS


† †


to decrease hours and to increase hours.


To set the minute, press and hold the CLK control and press the TUNE control:


SEEK


TUNE


SEEK


TUNE


CLK


TAPE AMS


37


Controls and features


† †


to decrease minutes and to increase minutes.


SEEK


TUNE


SEEK


TUNE


The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information. Anytime that the media is changed, (new radio station, etc.), the media information will again display for 10 seconds before reverting back to the clock. In media mode, the media information will always be displayed.


Premium AM/FM Stereo/Cassette/Single CD


VOL PUSH ON


DISC


FM 1
AMC


BL


ST


RF


EJ


MUTE


AUTO


CLK


DOLBY B NR


EJ


TAPE


CD


SCAN


BASS


TREB


FF


SIDE 1-2


SEL


BAL


FADE


COMP


SHUFFLE


AM


FM


SEEK


TUNE


REW


38


Controls and features


VOL - PUSH ON


Volume/powercontrol Press the control to turn the audio system on or off. Audio power can also be turned on by pressing the AM/FM select control or the tape/CD select control. Audio power is turned off by using the volume/power control.


Turn control to raise or lower volume.


VOL - PUSH ON


If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. AM/FMselect The AM/FM select control works in radio, tape and CD modes.


AM


FM


AM/FMselectinradiomode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FMselectintapemode Press this control to stop tape play and begin radio play. AM/FMselectinCDorCDchangermode(ifequipped) Press this control to stop CD play and begin radio play. Tuneadjust The tune control works in radio mode.


39


Controls and features


Tuneadjustinradiomode † Press


to move to the next


frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly.


† Press


to move to the next


SEEK


TUNE


SEEK


TUNE


frequency up the band (whether or not a listenable station is located there). Hold for quick movement.


Seekfunction The seek function control works in radio, tape or CD mode. Seekfunctioninradiomode † Press


to find the next listenable station down the frequency band.


to find the next


listenable station up the frequency band.


† Press


SEEK


TUNE


SEEK


TUNE


Seekfunctionintapemode † Press to listen to the previous selection on the tape. † Press to listen to the next selection on the tape. SeekfunctionforCDorCDchanger(ifequipped) † Press


to seek to the previous


track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.


† Press


to seek forward to the


SEEK


TUNE


SEEK


TUNE


next track of the current disc. After the last track has been completed, the first track of the current disc will automatically replay.


40


Controls and features


Scanfunction The scan function works in radio, tape or CD mode.


SCAN


Scanfunctioninradiomode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the control again to stop the scan mode. Scanfunctionintapemode Press the SCAN control to hear a short sampling of all selections on the tape. (The tape scans in a forward direction. At the end of the tape’s first side, direction automatically reverses to the opposite side of the tape.) To stop on a particular selection, press the control again. ScanfunctioninCDorCDchangermode(ifequipped) Press the SCAN control to hear a short sampling of all selections on the CD. (The CD scans in a forward direction, wrapping back to the first track at the end of the CD.) To stop on a particular selection, press the control again. Radiostationmemorypreset The radio is equipped with six station memory preset controls. These controls can be used to select up to six preset AM stations and twelve FM stations (six in FM1 and six in FM2). Settingmemorypresetstations


AM


FM


1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station.


REW


FF


SIDE 1-2


COMP


SHUFFLE


3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.


41


Controls and features


AUTO


Autosetmemorypreset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Startingautosetmemorypreset 1. Select a frequency using the AM/FM select controls. 2. Press the AUTO control. 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing. If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available. These stations are temporarily stored in the memory preset controls (until deactivated) and are accessed in the same manner of your original presets. To deactivate autoset and return to your audio system’s manually set memory stations, press the AUTO control again. Bassadjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Press the BASS control then press: † to decrease the bass output †


to increase the bass output.


CLK


BASS


TREB


and


SEL


Trebleadjust The treble adjust control allows you to increase or decrease the audio system’s treble output.


BASS


TREB


42


Press the TREB control then press: † to decrease the treble output †


to increase the treble output.


and


Speakerbalanceadjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control then press: † †


to shift sound to the left and to shift sound to the right.


Speakerfadeadjust Speaker sound can be adjusted between the front and rear speakers. Press the FADE control then press: † †


to shift the sound to the


to shift the sound to the rear.


front and


Controls and features


SEL


BAL


FADE


SEL


BAL


FADE


SEL


Tape/CDselect † To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.


TAPE


CD


43


Controls and features † To begin CD play (if CD(s) are loaded), press the CD control. The first track of the disc will begin playing. If returning from radio or tape mode, CD play will begin where it stopped last.


TAPE


CD


With the dual media audio system, press the CD control to toggle between single CD and CD changer play (if equipped). Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur. Rewind The rewind control works in tape and CD modes. † In tape mode, radio play will


REW


continue until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. † In CD mode, pressing the REW control rewinds the CD within the


current track.


Fastforward The fast forward control works in tape and CD modes. † In the tape mode, tape direction will automatically reverse when the end of the tape is reached.


FF


† In CD mode, pressing the control fast forwards the CD within the


current track.


Tapedirectionselect Press SIDE 1–2 to play the alternate side of a tape.


Ejectfunction Press the EJ control to stop and eject a tape.


44


SIDE 1-2


EJ


Controls and features


Press the EJ control to stop and eject a CD.


EJ


are trademarks of Dolbyt Laboratories Licensing


control to activate (and deactivate) the Dolbyt noise


DolbyT noisereduction Dolbyt noise reduction operates in tape mode. Dolbyt noise reduction reduces the amount of hiss and static during tape playback. Press the reduction. Dolbyt noise reduction is manufactured under license from Dolbyt Laboratories Licensing Corporation. “Dolbyt” and the double-D symbol Corporation. Compressionadjust Compression adjust brings soft and loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shufflefeature The shuffle feature operates in CD mode (if equipped) and plays all tracks on the current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks on the current disc are played. Press the SHUFFLE control to start this feature. Random order play will continue until the SHUFFLE control is pressed again.


COMP


SHUFFLE


45


AUTO


CLK


SEEK


TUNE


SEEK


TUNE


AUTO


CLK


SEEK


TUNE


SEEK


TUNE


Controls and features


Settingtheclock To set the hour, press and hold the CLK control and press SEEK:


† †


to decrease hours and to increase hours.


To set the minute, press and hold the CLK control and press TUNE:


to decrease minutes and to increase minutes.


† † If your vehicle has a separate clock module, (other than the digital radio display), the CLK button will not function in the above manner.


46


Controls and features


AUTO


The CLK button will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time).

Loading...
x
