Designated seating positions.
Outward Facing Sidewall: The side of an asymmetrical tire that has a particular side that faces outward when mounted on a vehicle. The side of the tire that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same moldings on the other sidewall of the tire. Passenger (P-Metric) Tire: A tire used on passenger cars and some light duty trucks and multipurpose vehicles. Recommended Inflation Pressure: Vehicle manufacturer's recommended tire inflation pressure as shown on the tire placard. See Tire Pressure on page 10‑44 and Vehicle Load Limits on page 9‑10.
Vehicle Care
10-43
Radial Ply Tire: A pneumatic tire in which the ply cords that extend to the beads are laid at 90 degrees to the centerline of the tread. Rim: A metal support for a tire and upon which the tire beads are seated. Sidewall: The portion of a tire between the tread and the bead. Speed Rating: An alphanumeric code assigned to a tire indicating the maximum speed at which a tire can operate. Traction: The friction between the tire and the road surface. The amount of grip provided. Tread: The portion of a tire that comes into contact with the road.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (44,1)
10-44
Vehicle Care
Treadwear Indicators: Narrow bands, sometimes called wear bars, that show across the tread of a tire when only 1.6 mm (1/16 in) of tread remains. See When It Is Time for New Tires on page 10‑51. UTQGS (Uniform Tire Quality Grading Standards): A tire information system that provides consumers with ratings for a tire's traction, temperature, and treadwear. Ratings are determined by tire manufacturers using government testing procedures. The ratings are molded into the sidewall of the tire. See Uniform Tire Quality Grading on page 10‑54.
Vehicle Capacity Weight: The number of designated seating positions multiplied by 68 kg (150 lbs) plus the rated cargo load. See Vehicle Load Limits on page 9‑10. Vehicle Maximum Load on the Tire: Load on an individual tire due to curb weight, accessory weight, occupant weight, and cargo weight. Vehicle Placard: A label permanently attached to a vehicle showing the vehicle capacity weight and the original equipment tire size and recommended inflation pressure. See “Tire and Loading Information Label” under Vehicle Load Limits on page 9‑10.
Tire Pressure Tires need the correct amount of air pressure to operate effectively. Notice: Neither tire underinflation nor overinflation is good. Underinflated tires, or tires that do not have enough air, can result in:
. Tire overloading and
overheating which could lead to a blowout.
. Premature or
irregular wear. . Poor handling. . Reduced fuel economy.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (45,1)
Overinflated tires, or tires that have too much air, can result in:
. Unusual wear. . Poor handling. . Rough ride. . Needless damage from
road hazards.
The Tire and Loading Information label on the vehicle indicates the original equipment tires and the correct cold tire inflation pressures. The recommended pressure is the minimum air pressure needed to support the vehicle's maximum load carrying capacity. For additional information regarding how much weight the vehicle can carry, and an example of the Tire and Loading Information label, see Vehicle Load Limits on page 9‑10.
How the vehicle is loaded affects vehicle handling and ride comfort. Never load the vehicle with more weight than it was designed to carry.
When to Check Check the tires once a month or more. Do not forget the compact spare tire, if the vehicle has one. The cold compact spare should be at 420 kPa (60 psi). See Compact Spare Tire on page 10‑73.
How to Check Use a good quality pocket-type gauge to check tire pressure. Proper tire inflation cannot be determined by looking at the tire. Check the tire inflation pressure when the tires are cold, meaning the vehicle has not been driven for at least three hours or no more than 1.6 km (1 mi).
Vehicle Care
10-45
Remove the valve cap from the tire valve stem. Press the tire gauge firmly onto the valve to get a pressure measurement. If the cold tire inflation pressure matches the recommended pressure on the Tire and Loading Information label, no further adjustment is necessary. If the inflation pressure is low, add air until the recommended pressure is reached. If the inflation pressure is high, press on the metal stem in the center of the tire valve to release air. Recheck the tire pressure with the tire gauge. Return the valve caps on the valve stems to prevent leaks and keep out dirt and moisture.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (46,1)
10-46
Vehicle Care
Tire Pressure Monitor System The Tire Pressure Monitor System (TPMS) uses radio and sensor technology to check tire pressure levels. The TPMS sensors monitor the air pressure in your tires and transmit tire pressure readings to a receiver located in the vehicle. Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been equipped with a tire pressure monitoring system (TPMS) that illuminates a low tire
pressure telltale when one or more of your tires is significantly under‐inflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly under‐inflated tire causes the tire to overheat and can lead to tire failure. Under‐inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle's handling and stopping ability. Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver's responsibility to maintain correct tire pressure, even if under‐inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated. This sequence will continue upon subsequent vehicle start‐ups as long as the malfunction exists. When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. See Tire Pressure Monitor Operation on page 10‑47 for additional information.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (47,1)
Vehicle Care
10-47
The low tire pressure warning light may come on in cool weather when the vehicle is first started, and then turn off as the vehicle is driven. This could be an early indicator that the air pressure is getting low and must be inflated to the proper pressure. A Tire and Loading Information label shows the size of the original equipment tires and the correct inflation pressure for the tires when they are cold. See Vehicle Load Limits on page 9‑10, for an example of the Tire and Loading Information label and its location. Also see Tire Pressure on page 10‑44.
Federal Communications Commission (FCC) Rules and with Industry Canada Standards See Radio Frequency Statement on page 13‑16 for information regarding Part 15 of the Federal Communications Commission (FCC) Rules and with Industry Canada Standards RSS-GEN/210/220/310.
Tire Pressure Monitor Operation This vehicle may have a Tire Pressure Monitor System (TPMS). The TPMS is designed to warn the driver when a low tire pressure condition exists. TPMS sensors are mounted onto each tire and wheel assembly, excluding the spare tire and wheel assembly. The TPMS sensors monitor the air pressure in the tires and transmit the tire pressure readings to a receiver located in the vehicle.
When a low tire pressure condition is detected, the TPMS illuminates the low tire pressure warning light located on the instrument cluster. If the warning light comes on, stop as soon as possible and inflate the tires to the recommended pressure shown on the Tire and Loading Information label. See Vehicle Load Limits on page 9‑10. The low tire pressure warning light comes on at each ignition cycle until the tires are inflated to the correct inflation pressure.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (48,1)
10-48
Vehicle Care
The TPMS can warn about a low tire pressure condition but it does not replace normal tire maintenance. See Tire Inspection on page 10‑50, Tire Rotation on page 10‑50 and Tires on page 10‑38. Notice: Tire sealant materials are not all the same. A non-approved tire sealant could damage the TPMS sensors. TPMS sensor damage caused by using an incorrect tire sealant is not covered by the vehicle warranty. Always use only the GM-approved tire sealant available through your dealer or included in the vehicle. Factory-installed Tire Inflator Kits use a GM-approved liquid tire sealant. Using non-approved tire sealants could damage the TPMS sensors. See Tire Sealant and Compressor Kit on page 10‑59 for information regarding the inflator kit materials and instructions.
TPMS Malfunction Light The TPMS will not function properly if one or more of the TPMS sensors are missing or inoperable. When the system detects a malfunction, the low tire warning light flashes for about one minute and then stays on for the remainder of the ignition cycle. The malfunction light comes on at each ignition cycle until the problem is corrected. Some of the conditions that can cause this to come on are: . One of the road tires has been
replaced with the spare tire. The spare tire does not have a TPMS sensor. The malfunction light should go off after the road tire is replaced and the sensor matching process is performed successfully. See "TPMS Sensor Matching Process" later in this section.
The TPMS sensor matching process was not done or not completed successfully after rotating the tires. The malfunction light should go off after successfully completing the sensor matching process. See "TPMS Sensor Matching Process" later in this section. . One or more TPMS sensors
are missing or damaged. The malfunction light should go off when the TPMS sensors are installed and the sensor matching process is performed successfully. See your dealer for service.
. Replacement tires or wheels do not match the original equipment tires or wheels. Tires and wheels other than those recommended could prevent the TPMS from functioning properly. See Buying New Tires on page 10‑52.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (49,1)
. Operating electronic devices or being near facilities using radio wave frequencies similar to the TPMS could cause the TPMS sensors to malfunction.
If the TPMS is not functioning properly, it cannot detect or signal a low tire condition. See your dealer for service if the TPMS malfunction light comes on and stays on. TPMS Sensor Matching Process Each TPMS sensor has a unique identification code. The identification code needs to be matched to a new tire/wheel position after rotating the tires or replacing one or more of the TPMS sensors. The TPMS sensor matching process should also be performed after replacing a spare tire with a road tire containing the TPMS sensor. The malfunction light should go off at the next ignition cycle. The sensors are matched to the tire/wheel positions, using a TPMS relearn tool, in the following
order: driver side front tire, passenger side front tire, passenger side rear tire, and driver side rear. See your dealer for service or to purchase a relearn tool. There are two minutes to match the first tire/wheel position, and five minutes overall to match all four tire/wheel positions. If it takes longer, the matching process stops and must be restarted. The TPMS sensor matching process is: 1. Set the parking brake. 2. Turn the ignition to ON/RUN with
the engine off.
3. Use the MENU button to select the Vehicle Information menu in the Driver Information Center (DIC).
4. Use the thumbwheel to scroll to
the Tire Pressure Learn menu item screen.
Vehicle Care
10-49
5. Press and hold the SET/CLR
button to begin the sensor matching process.
6. The horn sounds twice to signal
the receiver is in relearn mode and the TIRE LEARN message displays on the DIC screen.
7. Start with the driver side
front tire.
8. Place the relearn tool against
the tire sidewall, near the valve stem. Then press the button to activate the TPMS sensor. A horn chirp confirms that the sensor identification code has been matched to this tire and wheel position.
9. Proceed to the passenger side
front tire, and repeat the procedure in Step 8.
10. Proceed to the passenger side
rear tire, and repeat the procedure in Step 8.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (50,1)
10-50
Vehicle Care
11. Proceed to the driver side rear tire, and repeat the procedure in Step 8. The horn sounds two times to indicate the sensor identification code has been matched to the driver side rear tire, and the TPMS sensor matching process is no longer active. The TIRE LEARN message on the DIC display screen goes off.
12. Turn the ignition to LOCK/OFF. 13. Set all four tires to the
recommended air pressure level as indicated on the Tire and Loading Information label.
Tire Inspection We recommend that the tires, including the spare tire, if the vehicle has one, be inspected for signs of wear or damage at least once a month.
Replace the tire if: . The indicators at three or
more places around the tire can be seen.
. There is cord or fabric
showing through the tire's rubber.
. The tread or sidewall is
cracked, cut, or snagged deep enough to show cord or fabric.
. The tire has a bump, bulge,
or split.
. The tire has a puncture, cut, or other damage that cannot be repaired well because of the size or location of the damage.
Tire Rotation Tires should be rotated every 12 000 km (7,500 mi). See Maintenance Schedule on page 11‑3. Tires are rotated to achieve a uniform wear for all tires. The first rotation is the most important. Any time unusual wear is noticed, rotate the tires as soon as possible and check the wheel alignment. Also check for damaged tires or wheels. See When It Is Time for New Tires on page 10‑51 and Wheel Replacement on page 10‑56.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (51,1)
Vehicle Care
10-51
Lightly coat the center of the wheel hub with wheel bearing grease after a wheel change or tire rotation to prevent corrosion or rust build-up. Do not get grease on the flat wheel mounting surface or on the wheel nuts or bolts.
When It Is Time for New Tires Factors such as maintenance, temperatures, driving speeds, vehicle loading, and road conditions affect the wear rate of the tires.
Reset the Tire Pressure Monitor System. See Tire Pressure Monitor Operation on page 10‑47. Check that all wheel nuts are properly tightened. See “Wheel Nut Torque” under Capacities and Specifications on page 12‑2.
{ WARNING
Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident. When changing a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle. In an emergency, a cloth or a paper towel can be used; however, use a scraper or wire brush later to remove all rust or dirt.
Use this rotation pattern when
rotating the tires.
Do not include the compact
spare tire in the tire rotation.
Adjust the front and rear tires
to the recommended inflation
pressure on the Tire and
Loading Information label after
the tires have been rotated. See
Tire Pressure on page 10‑44
and Vehicle Load Limits on
page 9‑10.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (52,1)
10-52
Vehicle Care
to be replaced due to wear before they may need to be replaced due to age. Consult the tire manufacturer for more information on when tires should be replaced. Vehicle Storage Tires age when stored normally mounted on a parked vehicle. Park a vehicle that will be stored for at least a month in a cool, dry, clean area away from direct sunlight to slow aging. This area should be free of grease, gasoline, or other substances that can deteriorate rubber. Parking for an extended period can cause flat spots on the tires that may result in vibrations while driving. When storing a vehicle for at least a month, remove the tires or raise the vehicle to reduce the weight from the tires.
Buying New Tires GM has developed and matched specific tires for the vehicle. The original equipment tires installed were designed to meet General Motors Tire Performance Criteria Specification (TPC Spec) system rating. When replacement tires are needed, GM strongly recommends buying tires with the same TPC Spec rating. GM's exclusive TPC Spec system considers over a dozen critical specifications that impact the overall performance of the vehicle, including brake system performance, ride and handling, traction control, and tire pressure monitoring performance. GM's TPC Spec number is molded onto the tire's sidewall near the tire size. If the tires have an all‐season tread design, the TPC Spec number
Treadwear indicators are one way to tell when it is time for new tires. Treadwear indicators appear when the tires have only 1.6 mm (1/16 in) or less of tread remaining. See Tire Inspection on page 10‑50 and Tire Rotation on page 10‑50 for more information. The rubber in tires ages over time. This also applies for the spare tire, if the vehicle has one, even if it is never used. Multiple conditions including temperatures, loading conditions, and inflation pressure maintenance affect how fast aging takes place. Tires will typically need
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (53,1)
will be followed by MS for mud
and snow. See Tire Sidewall
Labeling on page 10‑38 for
additional information.
GM recommends replacing
all the tires at the same time.
Uniform tread depth on all
tires will help to maintain the
performance of the vehicle.
Braking and handling
performance may be adversely
affected if all the tires are not
replaced at the same time. See
Tire Inspection on page 10‑50
and Tire Rotation on page 10‑50
for information on proper tire
rotation.
Vehicle Care
10-53
{ WARNING
{ WARNING
Tires could explode during improper service. Attempting to mount or dismount a tire could cause injury or death. Only your dealer or authorized tire service center should mount or dismount the tires.
{ WARNING
Mixing tires of different sizes, brands, or types may cause loss of control of the vehicle, resulting in a crash or other vehicle damage. Use the correct size, brand, and type of tires on all wheels.
Using bias-ply tires on the vehicle may cause the wheel rim flanges to develop cracks after many miles of driving. A tire and/or wheel could fail suddenly and cause a crash. Use only radial-ply tires with the wheels on the vehicle.
If the vehicle tires must be replaced with a tire that does not have a TPC Spec number, make sure they are the same size, load range, speed rating, and construction (radial) as the original tires.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (54,1)
10-54
Vehicle Care
Vehicles that have a tire pressure monitoring system could give an inaccurate low‐pressure warning if non‐TPC Spec rated tires are installed. See Tire Pressure Monitor System on page 10‑46. The Tire and Loading Information label indicates the original equipment tires on the vehicle. See Vehicle Load Limits on page 9‑10 for the label location and more information about the Tire and Loading Information label.
Different Size Tires and Wheels If wheels or tires are installed that are a different size than the original equipment wheels and tires, vehicle performance, including its braking, ride and handling characteristics, stability, and resistance to rollover
may be affected. If the vehicle has electronic systems such as antilock brakes, rollover airbags, traction control, and electronic stability control, the performance of these systems can also be affected.
{ WARNING
If different sized wheels are used, there may not be an acceptable level of performance and safety if tires not recommended for those wheels are selected. This increases the chance of a crash and serious injury. Only use GM specific wheel and tire systems developed for the vehicle, and have them properly installed by a GM certified technician.
See Buying New Tires on page 10‑52 and Accessories and Modifications on page 10‑3.
Uniform Tire Quality Grading Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example:
Treadwear 200 Traction AA Temperature A The following information relates to the system developed by the United States National Highway Traffic Safety Administration (NHTSA), which grades tires by treadwear, traction, and temperature performance. This applies only to vehicles sold in the United States. The grades are molded on the sidewalls of most passenger car tires. The Uniform Tire Quality Grading (UTQG) system does not apply to deep tread, winter tires, compact spare tires, tires
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (55,1)
with nominal rim diameters of 10 to 12 inches (25 to 30 cm), or to some limited-production tires. While the tires available on General Motors passenger cars and light trucks may vary with respect to these grades, they must also conform to federal safety requirements and additional General Motors Tire Performance Criteria (TPC) standards. All Passenger Car Tires Must Conform to Federal Safety Requirements In Addition To These Grades.
Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire
graded 150 would wear one and a half (1½) times as well on the government course as a tire graded 100. The relative performance of tires depends upon the actual conditions of their use, however, and may depart significantly from the norm due to variations in driving habits, service practices and differences in road characteristics and climate.
Traction – AA, A, B, C The traction grades, from highest to lowest, are AA, A, B, and C. Those grades represent the tire's ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
Vehicle Care
10-55
Warning: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics.
Temperature – A, B, C The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (56,1)
10-56
Vehicle Care
The grade C corresponds to a level of performance which all passenger car tires must meet under the Federal Motor Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law. Warning: The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure.
Wheel Alignment and Tire Balance The tires and wheels were aligned and balanced at the factory to provide the longest tire life and best overall performance. Adjustments to wheel alignment and tire balancing will not be necessary on a regular
basis. However, check the alignment if there is unusual tire wear or if the vehicle is pulling to one side or the other. If the vehicle vibrates when driving on a smooth road, the tires and wheels might need to be rebalanced. See your dealer for proper diagnosis.
Wheel Replacement Replace any wheel that is bent, cracked, or badly rusted or corroded. If wheel nuts keep coming loose, the wheel, wheel bolts, and wheel nuts should be replaced. If the wheel leaks air, replace it. Some aluminum wheels can be repaired. See your dealer if any of these conditions exist. Your dealer will know the kind of wheel that is needed. Each new wheel should have the same load-carrying capacity, diameter, width, offset, and be mounted the same way as the one it replaces.
Replace wheels, wheel bolts, wheel nuts, or Tire Pressure Monitor System (TPMS) sensors with new GM original equipment parts.
{ WARNING
Using the wrong replacement wheels, wheel bolts, or wheel nuts can be dangerous. It could affect the braking and handling of the vehicle. Tires can lose air, and cause loss of control, causing a crash. Always use the correct wheel, wheel bolts, and wheel nuts for replacement.
Notice: The wrong wheel can also cause problems with bearing life, brake cooling, speedometer or odometer calibration, headlamp aim, bumper height, vehicle ground clearance, and tire or tire chain clearance to the body and chassis.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (57,1)
WARNING (Continued)
parts. The area damaged by the tire chains could cause loss of control and a crash. Use another type of traction device only if its manufacturer recommends it for the vehicle's tire size combination and road conditions. Follow that manufacturer's instructions. To avoid vehicle damage, drive slow and readjust or remove the traction device if it contacts the vehicle. Do not spin the wheels. If traction devices are used, install them on the front tires.
Vehicle Care
10-57
If a Tire Goes Flat It is unusual for a tire to blow out while driving, especially if the tires are maintained properly. See Tires on page 10‑38. If air goes out of a tire, it is much more likely to leak out slowly. But if there is ever a blowout, here are a few tips about what to expect and what to do: If a front tire fails, the flat tire creates a drag that pulls the vehicle toward that side. Take your foot off the accelerator pedal and grip the steering wheel firmly. Steer to maintain lane position, and then gently brake to a stop, well off the road, if possible.
Used Replacement Wheels
{ WARNING
Replacing a wheel with a used one is dangerous. How it has been used or how far it has been driven may be unknown. It could fail suddenly and cause a crash. When replacing wheels, use a new GM original equipment wheel.
Tire Chains
{ WARNING
Do not use tire chains. There is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause damage to the brakes, suspension, or other vehicle
(Continued)
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (58,1)
10-58
Vehicle Care
A rear blowout, particularly on a curve, acts much like a skid and may require the same correction as used in a skid. Stop pressing the accelerator pedal and steer to straighten the vehicle. It may be very bumpy and noisy. Gently brake to a stop, well off the road, if possible.
{ WARNING
Driving on a flat tire will cause permanent damage to the tire. Re-inflating a tire after it has been driven on while severely underinflated or flat may cause a blowout and a serious crash. Never attempt to re-inflate a tire that has been driven on while severely underinflated or flat. Have your dealer or an authorized tire service center repair or replace the flat tire as soon as possible.
{ WARNING Lifting a vehicle and getting under it to do maintenance or repairs is dangerous without the appropriate safety equipment and training. If a jack is provided with the vehicle, it is designed only for changing a flat tire. If it is used for anything else, you or others could be badly injured or killed if the vehicle slips off the jack. If a jack is provided with the vehicle, only use it for changing a flat tire.
If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place, well off the road, if possible. Turn on the hazard warning flashers. See Hazard Warning Flashers on page 6‑4.
{ WARNING
Changing a tire can be dangerous. The vehicle can slip off the jack and roll over or fall causing injury or death. Find a level place to change the tire. To help prevent the vehicle from moving:
1. Set the parking brake firmly. 2. Put an automatic
transmission in P (Park) or a manual transmission in 1 (First) or R (Reverse).
3. Turn off the engine and do not restart while the vehicle is raised.
4. Do not allow passengers to
remain in the vehicle. 5. Place wheel blocks on
both sides of the tire at the opposite corner of the tire being changed.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (59,1)
Vehicle Care
10-59
The following information explains how to repair or change a tire.
{ WARNING
Overinflating a tire could cause the tire to rupture and you or others could be injured. Be sure to read and follow the tire sealant and compressor kit instructions and inflate the tire to its recommended pressure. Do not exceed the recommended pressure.
Tire Sealant and Compressor Kit
{ WARNING
Idling a vehicle in an enclosed area with poor ventilation is dangerous. Engine exhaust may enter the vehicle. Engine exhaust contains carbon monoxide (CO) which cannot be seen or smelled. It can cause unconsciousness and even death. Never run the engine in an enclosed area that has no fresh air ventilation. For more information, see Engine Exhaust on page 9‑22.
This vehicle may come with a jack and spare tire or a tire sealant and compressor kit. To use the jacking equipment to change a spare tire safely, follow the instructions below. Then see Tire Changing on page 10‑67. To use the tire sealant and compressor kit, see Tire Sealant and Compressor Kit on page 10‑59. When the vehicle has a flat tire (B), use the following example as a guide to assist you in the placement of wheel blocks (A).
A. Wheel Block B. Flat Tire
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (60,1)
10-60
Vehicle Care
{ WARNING Storing the tire sealant and compressor kit or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store the tire sealant and compressor kit in its original location.
If this vehicle has a tire sealant and compressor kit, there may not be a spare tire or tire changing equipment, and on some vehicles there may not be a place to store a tire. The tire sealant and compressor can be used to temporarily seal punctures up to 6 mm (0.25 in) in the tread area of the tire. It can also be used to inflate an underinflated tire.
If the tire has been separated from the wheel, has damaged sidewalls, or has a large puncture, the tire is too severely damaged for the tire sealant and compressor kit to be effective. See Roadside Assistance Program on page 13‑5. Read and follow all of the tire sealant and compressor kit instructions. The kit includes:
D. Tire Sealant Canister E. On/Off Button F. Slot on Top of Compressor G. Pressure Deflation Button H. Pressure Gauge
Power Plug
I. J. Air Only Hose Tire Sealant Read and follow the safe handling instructions on the label adhered to the tire sealant canister (D).
A. Sealant Canister Inlet Valve B. Sealant/Air Hose C. Base of Sealant Canister
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (61,1)
Vehicle Care
10-61
Check the tire sealant expiration date on the tire sealant canister. The tire sealant canister (D) should be replaced before its expiration date. Replacement tire sealant canisters are available at your local dealer. There is only enough sealant to seal one tire. After usage, the tire sealant canister must be replaced. Using the Tire Sealant and Compressor Kit to Temporarily Seal and Inflate a Punctured Tire When using the tire sealant and compressor kit during cold temperatures, warm the kit in a heated environment for five minutes. This will help to inflate the tire faster.
If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard warning flashers. See Hazard Warning Flashers on page 6‑4. See If a Tire Goes Flat on page 10‑57 for other important safety warnings. Do not remove any objects that have penetrated the tire. 1. Remove the tire sealant
canister (D) and compressor from its storage location. See Storing the Tire Sealant and Compressor Kit on page 10‑66.
2. Remove the air only hose (J)
and the power plug (I) from the bottom of the compressor.
3. Place the compressor on the
ground near the flat tire.
4. Attach the air only hose (J) to
the sealant canister inlet valve (A) by turning it clockwise until tight.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (62,1)
10-62
Vehicle Care
If the vehicle only has a cigarette lighter, use the cigarette lighter. Do not pinch the power plug cord in the door or window.
9. Start the vehicle. The vehicle
must be running while using the air compressor.
10. Press the on/off button (E) to
turn the tire sealant and compressor kit on. The compressor will inject sealant and air into the tire. The pressure gauge (H) will initially show a high pressure while the compressor pushes the sealant into the tire. Once the sealant is completely dispersed into the tire, the pressure will quickly drop and start to rise again as the tire inflates with air only.
5. Slide the base of the tire sealant
7. Attach the sealant/air hose (B) to
canister (C) into the slot on the top of the compressor (F) to hold it upright. Make sure the tire valve stem is positioned close to the ground so the hose will reach it.
6. Remove the valve stem cap from the flat tire by turning it counterclockwise.
the tire valve stem by turning it clockwise until tight.
8. Plug the power plug (I) into the
accessory power outlet in the vehicle. Unplug all items from other accessory power outlets. See Power Outlets on page 5‑5. If the vehicle has an accessory power outlet, do not use the cigarette lighter.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (63,1)
11.
Inflate the tire to the recommended inflation pressure using the pressure gauge (H). The recommended inflation pressure can be found on the Tire and Loading Information label. See Tire Pressure on page 10‑44. The pressure gauge (H) may read higher than the actual tire pressure while the compressor is on. Turn the compressor off to get an accurate pressure reading. The compressor may be turned on/off until the correct pressure is reached.
Notice: If the recommended pressure cannot be reached after approximately 25 minutes, the vehicle should not be driven farther. The tire is too severely damaged and the tire sealant and compressor kit cannot inflate the tire. Remove the power plug from the accessory power outlet and unscrew the inflating hose from
the tire valve. See Roadside Assistance Program on page 13‑5. 12. Press the on/off button (E) to
turn the tire sealant and compressor kit off. The tire is not sealed and will continue to leak air until the vehicle is driven and the sealant is distributed in the tire. Therefore, Steps 13 through 21 must be done immediately after Step 12. Be careful while handling the tire sealant and compressor kit as it could be warm after usage.
13. Unplug the power plug (I) from the accessory power outlet in the vehicle.
14. Turn the sealant/air hose (B) counterclockwise to remove it from the tire valve stem.
15. Replace the tire valve
stem cap.
Vehicle Care
10-63
16. Remove the tire sealant
canister (D) from the slot on top of the compressor (F). 17. Turn the air only hose (J)
counterclockwise to remove it from the tire sealant canister inlet valve (A).
18. Turn the sealant/air hose (B)
clockwise onto the sealant canister inlet valve (A) to prevent sealant leakage.
19. Return the air only hose (J)
and power plug (I) back to their original storage location.
20.
If the flat tire was able to inflate to the recommended inflation pressure, remove the maximum speed label from the sealant canister and place it in a highly visible location.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (64,1)
10-64
Vehicle Care
Do not exceed the speed on this label until the damaged tire is repaired or replaced.
21. Return the equipment to its
22.
original storage location in the vehicle. Immediately drive the vehicle 8 km (5 mi) to distribute the sealant in the tire.
23. Stop at a safe location and
check the tire pressure. Refer to Steps 1 through 10 under “Using the Tire Sealant and Compressor Kit without Sealant to Inflate a Tire (Not Punctured).” If the tire pressure has fallen more than 68 kPa (10 psi) below the recommended inflation pressure, stop driving the vehicle. The tire is too severely damaged and the tire sealant cannot seal the tire. See Roadside Assistance Program on page 13‑5.
If the tire pressure has not dropped more than 68 kPa (10 psi) from the recommended inflation pressure, inflate the tire to the recommended inflation pressure.
Using the Tire Sealant and Compressor Kit without Sealant to Inflate a Tire (Not Punctured) The kit includes:
24. Wipe off any sealant from the
wheel, tire, or vehicle.
25. Dispose of the used tire
sealant canister (D) at a local dealer or in accordance with local state codes and practices.
26. Replace it with a new canister
available from your dealer.
27. After temporarily sealing a tire
using the tire sealant and compressor kit, take the vehicle to an authorized dealer within 161 km (100 mi) of driving to have the tire repaired or replaced.
A. Sealant Canister Inlet Valve B. Sealant/Air Hose C. Base of Sealant Canister D. Tire Sealant Canister E. On/Off Button
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (65,1)
F. Slot on Top of Compressor G. Pressure Deflation Button H. Pressure Gauge
Power Plug
I. J. Air Only Hose If a tire goes flat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard warning flashers. See Hazard Warning Flashers on page 6‑4.
See If a Tire Goes Flat on page 10‑57 for other important safety warnings. 1. Remove the compressor from its storage location. See Storing the Tire Sealant and Compressor Kit on page 10‑66.
2. Remove the air only hose (J)
and the power plug (I) from the bottom of the compressor.
3. Place the compressor on the
ground near the flat tire. Make sure the tire valve stem is positioned close to the ground so the hose will reach it.
4. Remove the valve stem cap from the flat tire by turning it counterclockwise.
5. Attach the air only hose (J) to
the tire valve stem by turning it clockwise until tight.
6. Plug the power plug (I) into the
accessory power outlet in the vehicle. Unplug all items from other accessory power outlets.
Vehicle Care
10-65
See Power Outlets on page 5‑5. If the vehicle has an accessory power outlet, do not use the cigarette lighter. If the vehicle only has a cigarette lighter, use the cigarette lighter. Do not pinch the power plug cord in the door or window.
7. Start the vehicle. The vehicle
must be running while using the air compressor.
8. Press the on/off button (E) to
9.
turn the tire sealant and compressor kit on. The compressor will inflate the tire with air only. Inflate the tire to the recommended inflation pressure using the pressure gauge (H). The recommended inflation pressure can be found on the Tire and Loading Information label. See Tire Pressure on page 10‑44.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (66,1)
10-66
Vehicle Care
The pressure gauge (H) may read higher than the actual tire pressure while the compressor is on. Turn the compressor off to get an accurate pressure reading. The compressor may be turned on/off until the correct pressure is reached.
Notice: If the recommended pressure cannot be reached after approximately 25 minutes, the vehicle should not be driven farther. The tire is too severely damaged and the tire sealant and compressor kit cannot inflate the tire. Remove the power plug from the accessory power outlet and unscrew the inflating hose from the tire valve. See Roadside Assistance Program on page 13‑5. 10. Press the on/off button (E) to
turn the tire sealant and compressor kit off. Be careful while handling the compressor as it could be warm after usage.
11. Unplug the power plug (I) from the accessory power outlet in the vehicle.
12. Turn the air only hose (J)
counterclockwise to remove it from the tire valve stem.
13. Replace the tire valve
stem cap.
14. Return the air only hose (J)
and power plug (I) back to their original storage location.
15. Return the equipment to its
original storage location in the vehicle.
The tire sealant and compressor kit has accessory adapters located in a compartment on the bottom of its housing that can be used to inflate air mattresses, balls, etc.
Storing the Tire Sealant and Compressor Kit The tire sealant and compressor kit is located in the rear storage area. 1. Lift the trim cover.
2. Remove the tire sealant
canister (A) and the compressor (B).
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (67,1)
Vehicle Care
10-67
To store the tire sealant canister and compressor: 1. Attach the sealant/air hose to
the sealant canister inlet valve. 2. Return the sealant canister and the compressor to their original storage location.
Tire Changing
Removing the Spare Tire and Tools The compact spare tire and tools are located in the storage compartment in the rear of the vehicle. To access the spare tire and tools: 1. Open the trunk or liftgate. See Trunk (Sedan) on page 2‑8 or Liftgate (Hatchback) on page 2‑10.
2. Lift the trim cover.
3. Turn the retainer
counterclockwise and remove it from the compact spare.
4. Remove the compact spare tire.
See Compact Spare Tire on page 10‑73 for more information.
A. Extension B. Jack C. Wheel Wrench D. Strap
5. The jack and tools are stored below the spare tire. Remove them from their container and place them near the tire being changed.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (68,1)
10-68
Vehicle Care
Removing the Flat Tire and Installing the Spare Tire 1. Do a safety check before
proceeding. See If a Tire Goes Flat on page 10‑57.
2. Remove the wheel cover, if the
vehicle has one, to reach the wheel bolts.
3. Turn the wheel nuts
counterclockwise to loosen them. Do not remove them yet.
4. Place the jack at the position
marked with a half circle.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (69,1)
6. Turn the wheel wrench
clockwise until the lift head is firmly contacting the proper lifting point nearest the flat tire.
{ WARNING
Getting under a vehicle when it is lifted on a jack is dangerous. If the vehicle slips off the jack, you could be badly injured or killed. Never get under a vehicle when it is supported only by a jack.
Vehicle Care
10-69
{ WARNING Raising the vehicle with the jack improperly positioned can damage the vehicle and even make the vehicle fall. To help avoid personal injury and vehicle damage, be sure to fit the jack lift head into the proper location before raising the vehicle.
7. Turn the wheel wrench
clockwise to raise the vehicle. Raise the vehicle far enough off the ground so there is enough room for the compact spare tire to fit underneath the wheel well.
5.
Insert the jack handle into the jack and the wheel wrench onto the end of the jack handle.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (70,1)
10-70
Vehicle Care
8. Turn the wheel nuts counterclockwise to remove them.
9. Remove the flat tire.
{ WARNING
Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident. When changing a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle. In an emergency, a cloth or a paper towel can be used; however, use a scraper or wire brush later to remove all rust or dirt.
{ WARNING
Never use oil or grease on bolts or nuts because the nuts might come loose. The vehicle's wheel could fall off, causing a crash.
12. Reinstall the wheel nuts.
Tighten each nut by hand until the wheel is held against the hub.
13. Lower the vehicle by
turning the wheel wrench counterclockwise. Lower the jack completely.
10. Remove any rust or dirt from
the wheel bolts, mounting surfaces, and spare wheel.
11. Place the compact spare tire
on the wheel-mounting surface.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (71,1)
Vehicle Care
10-71
Notice: Improperly tightened wheel nuts can lead to brake pulsation and rotor damage. To avoid expensive brake repairs, evenly tighten the wheel nuts in the proper sequence and to the proper torque specification. See Capacities and Specifications on page 12‑2 for the wheel nut torque specification.
{ WARNING
Wheel nuts that are improperly or incorrectly tightened can cause the wheels to become loose or come off. The wheel nuts should be tightened with a torque wrench to the proper torque specification after replacing. Follow the torque specification supplied by the aftermarket manufacturer when using accessory locking wheel nuts. See Capacities and Specifications on page 12‑2 for original equipment wheel nut torque specifications.
14. Tighten the wheel nuts firmly in
a crisscross sequence, as shown.
Notice: Wheel covers will not fit on the vehicle's compact spare. If you try to put a wheel cover on the compact spare, the cover or the spare could be damaged.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (72,1)
10-72
Vehicle Care
Storing a Flat or Spare Tire and Tools
{ WARNING
Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place.
Storing the Flat Tire and Tools 1. Return the jack and tools to their
original storage location.
2. Replace the trim cover. 3. Place the flat tire, lying flat, in the rear storage compartment.
If the vehicle is a sedan the flat tire should be against the back of the rear seats. If the vehicle is a hatchback the flat tire should be against the back of the trunk.
Sedan
4. Attach one end of the strap to a cargo tie-down in the rear of the vehicle.
Hatchback
5. Route the strap through the
wheel, as shown.
6. Attach the other end of the strap
to the other cargo tie-down in the rear of the vehicle.
7. Tighten the strap.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (73,1)
Storing the Compact Spare Tire and Tools Reverse the instructions for removing the spare tire and tools to store the compact spare tire. The compact spare tire is for temporary use only. Replace the compact spare tire with a full-size tire as soon as you can. See Compact Spare Tire on page 10‑73.
Compact Spare Tire { WARNING Driving with more than one compact spare tire at a time could result in loss of braking and handling. This could lead to a crash and you or others could be injured. Use only one compact spare tire at a time.
If this vehicle has a compact spare tire, it was fully inflated when the vehicle was new; however, it can lose air after a time. Check the inflation pressure regularly. It should be 420 kPa (60 psi). Stop as soon as possible and check that the spare tire is correctly inflated after installing the spare on the vehicle. The compact spare is designed to perform well at speeds up to 105 km/h (65 mph) for distances up to 5 000 km (3,000 mi), so a trip can be completed and the full-size tire repaired or replaced when possible. However, the compact spare tire will last longer and be in good shape if it is replaced as soon as possible.
Vehicle Care
10-73
Notice: When the compact spare is installed, do not take the vehicle through an automatic car wash with guide rails. The compact spare can get caught on the rails which can damage the tire, wheel, and other parts of the vehicle. Do not use the compact spare on other vehicles. Do not mix the compact spare tire or wheel with other wheels or tires. They will not fit. Keep the spare tire and its wheel together. Notice: Tire chains will not fit the compact spare. Using them can damage the vehicle and can damage the chains too. Do not use tire chains on the compact spare.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (74,1)
10-74
Vehicle Care
Jump Starting For more information about the vehicle battery, see Battery on page 10‑23. If the battery has run down, try to use another vehicle and some jumper cables to start your vehicle. Be sure to use the following steps to do it safely.
{ WARNING
Batteries can hurt you. They can be dangerous because:
. They contain acid that can
burn you.
. They contain gas that can
explode or ignite.
. They contain enough electricity to burn you.
If you do not follow these steps exactly, some or all of these things can hurt you.
Notice: Ignoring these steps could result in costly damage to the vehicle that would not be covered by the warranty. Trying to start the vehicle by pushing or pulling it will not work, and it could damage the vehicle.
The jump start positive post (A) and negative post (C) are on the battery of the vehicle providing the jump start.
The jump start positive post (B) and negative post (D) are on the battery on the driver side of the vehicle. The positive jump start connection is under a trim cover. Open the cover door to expose the terminal. 1. Check the other vehicle. It must
have a 12-volt battery with a negative ground system.
Notice: Only use a vehicle that has a 12-volt system with a negative ground for jump starting. If the other vehicle does not have a 12-volt system with a negative ground, both vehicles can be damaged. 2. Position the two vehicles so that
they are not touching.
3. Set the parking brake firmly and
put the shift lever in P (Park) with an automatic transmission, or Neutral with a manual transmission. See Shifting Into Park (Automatic Transmission) on page 9‑20 with an automatic
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (75,1)
transmission, or Parking on page 9‑22 with a manual transmission.
Notice: If any accessories are left on or plugged in during the jump starting procedure, they could be damaged. The repairs would not be covered by the vehicle warranty. Whenever possible, turn off or unplug all accessories on either vehicle when jump starting the vehicle. 4. Turn the ignition to LOCK/OFF.
Turn off all lights and accessories in both vehicles, except the hazard warning flashers if needed.
{ WARNING
An electric fan can start up even when the engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric fan.
Vehicle Care
10-75
{ WARNING
{ WARNING
Using a match near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the battery has enough water. You do not need to add water to the battery installed in your new vehicle. But if a battery has filler caps, be sure the right amount of fluid is there. If it is low, add water to take care of that first. If you do not, explosive gas could be present. Battery fluid contains acid that can burn you. Do not get it on you. If you accidentally get it in your eyes or on your skin, flush the place with water and get medical help immediately.
Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running.
5. Connect one end of the red
positive (+) cable to the positive (+) terminal (B) on the discharged battery.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (76,1)
Always connect and remove the jumper cables in the correct order, making sure that the cables do not touch each other or other metal.
10-76
Vehicle Care
6. Connect the other end of the
red positive (+) cable to the positive (+) terminal of the good battery (A).
7. Connect one end of the black
negative (–) cable to the negative (–) terminal of the good battery (C).
8. Connect the other end of the
black negative (–) cable to the negative (–) terminal (D) on the discharged battery.
9. Start the engine in the vehicle with the good battery and run the engine at idle speed for at least four minutes.
10. Try to start the vehicle that
Jumper Cable Removal
had the dead battery. If it will not start after a few tries, it probably needs service.
Notice: If the jumper cables are connected or removed in the wrong order, electrical shorting may occur and damage the vehicle. The repairs would not be covered by the vehicle warranty.
A. Good Battery or Remote Positive (+) and Remote Negative (–) Terminals
B. Dead Battery Positive (+) and
Negative (–) Terminals
To disconnect the jumper cables from both vehicles: 1. Disconnect the black
negative (−) cable from the vehicle that had the dead battery.
2. Disconnect the black
negative (−) cable from the vehicle with the good battery.
3. Disconnect the red positive (+) cable from the vehicle with the good battery.
4. Disconnect the red positive (+)
cable from the other vehicle.
5. Return the cover over the positive (+) terminal to the original position.
Chevrolet Sonic Owner Manual - 2012 - CRC - 11/9/11
Black plate (77,1)
Recreational Vehicle Towing Recreational vehicle towing means towing the vehicle behind another vehicle, such as a motor home. The two most common types of recreational vehicle towing are known as dinghy towing and dolly towing. Dinghy towing is towing the vehicle with all four wheels on the ground. Dolly towing is towing the vehicle with two wheels on the ground and two wheels up on a device known as a dolly.
Towing
Towing the Vehicle Notice: To avoid damage, the disabled vehicle should be towed with all four wheels off the ground. Care must be taken with vehicles that have low ground clearance and/or special equipment. Always flatbed on a car carrier. Consult your dealer or a professional towing service if the disabled vehicle must be towed. See Roadside Assistance Program on page 13‑5. To tow the vehicle behind another vehicle for recreational purposes, such as behind a motor home, see “Recreational Vehicle Towing” in this section.
Vehicle Care
10-77
Here are some important things to consider before recreational vehicle towing: . What is the towing capacity
of the towing vehicle? Be sure to read the tow vehicle manufacturer's recommendations.
. What is the distance that will be
traveled? Some vehicles have restrictions on how far and how long they can tow.
