For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip- ment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle. All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustration may differ from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.
18
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle. This vehicle should not be modified with non-genuine Toyota products. Mod- ification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addi- tion, damage or performance problems resulting from the modification may not be covered under warranty.
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle could affect electronic systems such as the multiport fuel injection system/sequen- tial multiport fuel injection system, electronic throttle control system, cruise control system, vehicle stability control system, SRS airbag system and seat belt pretensioner system, be sure to check with your Toyota dealer for pre- cautionary measures or special instructions regarding installation.
19
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate. Your vehicle has components that may contain perchlorate. These compo- nents may include airbag, seat belt pretensioners, and wireless remote con- trol batteries.
20
Vehicle control and operation data recording
Your Toyota is equipped with sophisticated computers that record certain information about your vehicle’s operation, such as: • Engine speed • Accelerator status • Brake status • Vehicle speed • Shift position The data recorded varies according to the grade level and options the vehi- cle is equipped with. The computers do not record conversations, sound or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if
the vehicle is leased In response to an official request by the police, a court of law or a govern- ment agency
• For research purposes where the data is not tied to a specific vehicle or
•
vehicle owner
21
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as: • How various systems in your vehicle were operating; • Whether or not the driver and passenger safety belts were buckled/fas-
• How far (if at all) the driver was depressing the accelerator and/or brake
tened;
pedal; and,
• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situ- ation occurs; no data are recorded by the EDR under normal driving condi- tions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.
22
● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle)
is obtained
• Officially requested by the police or other authorities • For use by Toyota in a lawsuit • Ordered by a court of law However, if necessary, Toyota will: • Use the data for research on vehicle safety performance • Disclose the data to a third party for research purposes without disclosing
information about the specific vehicle or vehicle owner
23
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others. Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents. Driver distraction: Always give your full attention to driving. Anything that dis- tracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.
■General precautions regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the cigarette lighter, the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
24
Symbols used throughout this manual
Cautions & Notices
CAUTION
This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.
NOTICE
This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
25
Symbols used in illustrations
Safety symbol The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action (pushing, turn- ing, etc.) used to operate switches and other devices. Indicates the outcome of an opera- tion (e.g. a lid opens).
26
TABLE OF CONTENTS
1 Before driving
Adjusting and operating features such as door locks, mirrors, and steering column.
2 When driving
Driving, stopping and safe-driving information.
3 Interior features
Air conditioning and audio systems, as well as other interior features for a comfortable driving experience.
4 Maintenance
and care
Cleaning and protecting your vehicle, performing do-it- yourself maintenance, and maintenance information.
5 When trouble
arises
What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident.
6 Vehicle
specifications
Detailed vehicle information.
7 For owners
Reporting safety defects for U.S. owners, and seat belt and SRS airbag instructions for Canadian owners.
Index
Alphabetical listing of information contained in this manual.
1-1. Key information Keys
The following keys are provided with the vehicle.
Vehicles with smart key system
Electronic keys • Operating
system (→P. 30)
the smart key
• Operating
the wireless
remote control function (→P. 42)
Mechanical keys Key number plate
Vehicles without smart key system
Master keys Operating the wireless remote control function (→P. 42) Key number plate
Using the mechanical key (vehicles with smart key system)
Take out the mechanical key.
After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the smart key system does not oper- ate properly, you will need the mechanical key.
28
1-1. Key information
■When required to leave a key to the vehicle with a parking attendant
(Vehicles with smart key system) Lock the glove box as circumstances demand. (→P. 350) Remove the mechanical key for your own use and provide the attendant with the electronic key only.
■Key number plate
Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 504)
■When riding in an aircraft
When bringing a key onto an aircraft, make sure you do not press any but- tons on the key while inside the aircraft cabin. If you are carrying a key in your bag etc., ensure that the buttons are not likely to be pressed acciden- tally. Pressing a button may cause the key to emit radio waves that could interfere with the operation of the aircraft.
NOTICE
■To prevent key damage
●Do not disassemble the key. ●Do not subject the keys to strong shocks, expose them to high tempera-
tures by placing them in direct sunlight, or get them wet.
●Do not expose the keys to electromagnetic materials or attach any mate-
rial that blocks electromagnetic waves to the key surface.
29
1-2. Opening, closing and locking the doors and trunk Smart key system∗
The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.)
Electronic key
Electronic key
Electronic key
Locks and unlocks the doors (→P. 31) Unlocks the trunk (→P. 31) Starts and stops the engine (→P. 154)
30
∗: If equipped
1
1-2. Opening, closing and locking the doors and trunk
Unlocking and locking the doors
Grip the driver’s door handle to unlock the door. Grip the passen- ger’s door handle to unlock all the doors.*
Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after is locked.
the door
*: The door unlock settings can be
changed. (→P. 35)
Press the lock button to lock the door.
Unlocking the trunk
Press the button to unlock the trunk.
31
1-2. Opening, closing and locking the doors and trunk
Antenna location and effective range
■ Antenna location
Antennas outside cabin Antenna outside trunk Antenna inside trunk Antennas inside cabin
32
1
1-2. Opening, closing and locking the doors and trunk
■ Effective range (areas within which the electronic key is
detected)
the electronic key
When locking or unlocking the doors The system can be operated when is within about 3 ft. (1 m) of an outside door handles. (Only the doors detecting the key can be operated.) When starting the engine or changing “ENGINE START STOP” switch modes The system can be operated when is inside the vehicle. When unlocking the trunk The system can be operated when is within about 3 ft. (1 m) of the trunk release button.
the electronic key
the electronic key
33
1-2. Opening, closing and locking the doors and trunk
■Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)
■Conditions affecting operation
The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly. (Way of coping: →P. 505) ●When the electronic key battery is depleted ●Near a TV tower, electric power plant, gas station, radio station, large dis- play, airport or other facility that generates strong radio waves or electri- cal noise
●When carrying a portable radio, cellular phone, cordless phone or other
wireless communication devices
●When the electronic key has come into contact with, or is covered by a
metallic object
●When multiple electronic keys are in the vicinity ●When carrying or using the electronic key together with the following
devices that emit radio waves • Another vehicle’s electronic key • A wireless key that emits radio waves • Personal computer
●If window tint with a metallic content or metallic objects are attached to
the rear window
34
1
1-2. Opening, closing and locking the doors and trunk
■Switching the door unlock function
It is possible to set which doors the entry function unlocks. STEP 1
Turn the “ENGINE START STOP” switch off.
STEP 2
When the indicator on the key surface is turned off, push and hold for approximately 5 seconds while pushing the
, or
button on the key.
The setting changes each time an operation is performed, as shown below. (Wait for at least 5 seconds after each operation to continue an operation.)
Relevant doors
Unlocking doors
Beep
Hold the driver’s door handle to unlock only the driver’s door Hold a passenger’s door handle to unlock all the doors
Hold a door handle to unlock all doors
Beeps twice
Beeps twice
STEP 3
Unlock the doors using the wireless remote control and open one of the doors. If a door is not opened within 60 second after doors will be locked again and the alarm will automatically be set. In case that the alarm is triggered, immediately stop the alarm. (→P. 99)
is pressed, the
35
1-2. Opening, closing and locking the doors and trunk
■Battery-saving function
In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. ●When the entry function has not been used for 2 weeks or more ●When the electronic key has been left within approximately 3 ft. (1 m) of
the vehicle for 10 minutes or more
The system will resume operation when... ●The vehicle is locked using the door handle lock switch ●The vehicle is locked/unlocked using the wireless remote control function
(→P. 42) or the mechanical key (→P. 505)
■Electronic key battery depletion
●The standard battery life is 1 to 2 years. (The battery becomes depleted even if the electronic key is not used.) If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted. Replace the battery when necessary. (→P. 440)
●If the battery becomes low, an alarm will sound in the cabin when the
engine stops. (→P. 38)
●To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the following electrical appliances that produce a magnetic field. • TVs • Personal computers • Recharging cellular phones or cordless phones • Table lamps
■To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle. Depending on the position and holding condition of the electronic key, the key may not be detected correctly and the system may not operate properly. (The alarm may go off accidentally, or the door lock prevention may not func- tion.)
36
1
1-2. Opening, closing and locking the doors and trunk
■Note for the smart key system
●Even when the electronic key is within the effective range (detection
areas), the system may not operate properly in the following cases. • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
• The electronic key is near the ground or in a high place, or too close to
the rear bumper center when the trunk is unlocked.
• The electronic key is on the instrument panel, rear package tray or floor, or in the glove box when the engine is started or “ENGINE START STOP” switch modes are changed.
●As long as the electronic key is within the effective range, the doors may
be locked or unlocked by anyone.
●Even if the electronic key is not inside the vehicle, it may be possible to
start the engine if the electronic key is near the window.
●The doors may unlock if a large amount of water splashes on the door handle, such as in the rain or in a car wash when the electronic key is within the effective range. (The doors will automatically be locked after approximately 60 seconds if the doors are not opened and closed.)
●Gripping the door handle when wearing a glove may not unlock the door. ●If the wireless remote control is used to lock the doors when the elec- tronic key is near the vehicle, there is a possibility that the door may not be unlocked by the entry function. (Use the wireless remote control to unlock the doors.)
●A sudden approach to the effective range or door handle operation may prevent the doors from being unlocked. In this case, return the door han- dle to the original position and check that the doors unlock before pulling the door handle again.
■When the vehicle is not driven for extended periods
To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2
m) of the vehicle.37
1-2. Opening, closing and locking the doors and trunk
■Security feature
If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the theft deterrent system automatically locks the vehicle again.
■Alarms and warning indicators
A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures according to which warning light comes on. (→P. 479) The following table describes circumstances and correction procedures when only alarms are sounded.
Alarm
Situation
Exterior alarm sounds once for 2 seconds
Tried to lock the doors using the entry function while the electronic key is still inside the passenger compartment Tried to exit the vehicle with the electronic key and lock the doors without first turning the “ENGINE START STOP” switch OFF
Closed the trunk while the electronic key is still inside and all doors are locked
Exterior alarm sounds once for 10 seconds
Tried to lock the vehicle using the entry function while a door is open
Correction procedure Retrieve the elec- tronic key from the passenger compart- ment and lock the doors again.
Turn the “ENGINE START STOP” switch OFF and lock the doors again.
Retrieve the elec- tronic key from the trunk and close the trunk lid. Close all of the doors and lock the doors again.
38
1-2. Opening, closing and locking the doors and trunk
Alarm
Interior alarm sounds once
Interior alarm sounds continu- ously
Interior alarm rings continu- ously
Situation
The electronic key battery is low. Tried to open the door and exit the vehicle without shifting the shift lever to “P” Turned the “ENGINE START STOP” switch to ACCESSORY mode while the driver’s door is open (Opened the driver’s door when the “ENGINE START STOP” switch is in ACCESSORY mode.) Turned the “ENGINE START STOP” switch OFF while the driver’s door is open
Correction procedure Replace the battery. (→P. 440)
Shift the shift lever to “P”.
Turn the “ENGINE START STOP” switch OFF and close the driver’s door.
Close the driver’s door.
■If the smart key system does not operate properly
●Locking and unlocking the doors: Use the mechanical key. (→P. 505) ●Starting the engine: →P. 506
■When the electronic key battery is fully depleted
→P. 440
39
1-2. Opening, closing and locking the doors and trunk
■Customization that can be configured at Toyota dealer
Settings (e.g. smart key system) can be changed. (Customizable features →P. 545)
■Certification for the smart key system
For vehicles sold in the U.S.A.
FCC ID: HYQ14AAB FCC ID: HYQ13BZH FCC ID: HYQ14ABK FCC ID: HYQ13BZW FCC ID: HYQ14AEM NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC ID: NI4TMLF-1
NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.40
1
1-2. Opening, closing and locking the doors and trunk
CAUTION
■Caution regarding interference with electronic devices
●People with implanted pacemakers or cardiac defibrillators should keep
away from the smart key system antennas. (→P. 32) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
●Users of any electrical medical device other than implanted pacemakers and implanted cardiac defibrillators should consult the manufacturer of the device for information about its operation under the influence of radio waves. Radio waves could have unexpected effects on the operation of such medical devices.
Ask your Toyota dealer for details for disabling the entry function.
41
1-2. Opening, closing and locking the doors and trunk Wireless remote control
The wireless remote control can be used to lock and unlock the vehi- cle and the trunk from outside the vehicle.
Vehicles with smart key system
Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors. Unlocks the trunk (push and hold) Sounds alarm (push and hold) (→P. 102)
42
1
1-2. Opening, closing and locking the doors and trunk
Vehicles without smart key system
Locks all doors Sounds alarm (push and hold) (→P. 102) Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors. Unlocks the trunk (push and hold)
■Operation indicator
Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Trunk: A buzzer sounds to indicate that the trunk has been unlocked.
■Door lock buzzer (vehicles with smart key system)
If a door is not fully closed, a buzzer sounds continuously for 10 seconds if an attempt to lock the door is made. Fully close the door to stop the buzzer, and lock the vehicle once more.
43
1-2. Opening, closing and locking the doors and trunk
■Security feature
→P. 38
■When the key battery is fully depleted
→P. 440
■Conditions affecting operation Vehicles with smart key system
→P. 34
Vehicles without smart key system The wireless remote control function may not operate normally in the fol- lowing situations. ●Near a TV tower, radio station, electric power plant, airport or other
facility that generates strong radio waves
●When carrying a portable radio, cellular phone or other wireless com-
munication device
●When multiple wireless keys are in the vicinity ●When the wireless key has come into contact with, or is covered by a
metallic object
●When a wireless key (that emits radio waves) is being used nearby ●When the wireless key has been left near an electrical appliance such
as a personal computer
■Customization that can be configured at Toyota dealer
Settings (e.g. 2-step unlocking function, trunk unlocking function) can be changed. (Customizable features →P. 545)
44
1
1-2. Opening, closing and locking the doors and trunk
■Certification for wireless remote control
For vehicles sold in the U.S.A.
FCC ID: HYQ14AAB FCC ID: HYQ13BZH FCC ID: HYQ14ABK FCC ID: HYQ13BZW FCC ID: HYQ14AEM FCC ID: NI4TMLF-1
NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.For vehicles sold in Jordan.
Type Approval Number: TRC/LPD/2009/4
NOTE: This device complies with the specifications mentioned in test reports No. (20071409200), (20071409300), and (20071409500) issued by Telefication B.V./The Netherlands. TRC WARNING: This Certificate does not apply to any modified or changed product nor does it authorize its holder to enter the subject equipment into Jordan without hav- ing a special permissions. If this occurs Jordan TRC has the right to impose any penalties stipulated in Jordan’s Telecommunications Law No. 13 of 1995 and its amendments and regulations of the Telecommunication Regulatory Commission.45
1-2. Opening, closing and locking the doors and trunk
For vehicles sold in the U.S.A.
NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. How- ever, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ●Reorient or relocate the receiving antenna. ●Increase the separation between the equipment and receiver. ●Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
For vehicles sold in Canada
NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.
46
1-2. Opening, closing and locking the doors and trunk Doors
The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry system (vehicles with smart key system)
→P. 31
■ Wireless remote control
→P. 42
■ Key
Vehicles with smart key system The doors can also be locked and unlocked with the mechanical key. (→P. 505) Vehicles without smart key system
Locks all doors Unlocks all doors Turning the key unlocks the driver’s door. Turning the key again unlocks the other doors.
47
1-2. Opening, closing and locking the doors and trunk
■ Door lock switch
Locks all doors Unlocks all doors
■ Inside lock button
Locks the door Unlocks the door The front doors can be opened by pulling the inside handles even if the lock buttons are in the lock position.
48
1
1-2. Opening, closing and locking the doors and trunk
Locking the front doors from the outside without a key
STEP 1
STEP 2
Move the inside lock button to the lock position. Close the door.
Vehicles with smart key system The door cannot be locked if the “ENGINE START STOP” switch is in the ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle. The key may not be detected correctly and the door may be locked. Vehicles without smart key system The door cannot be locked if either front door is open and the key is in the engine switch.
Rear door child-protector lock
The door cannot be opened from inside the vehicle when the locks are set.
These locks can be set to prevent children from opening the rear doors. Push down rear door switches to lock the rear doors.
49
1-2. Opening, closing and locking the doors and trunk
Automatic door locking and unlocking systems
The following functions can be set or canceled:
Function
Shift position linked door locking function Shift position linked door unlocking function Speed linked door lock- ing function
Driver’s door linked door unlocking function
Operation
Shifting the shift lever out of “P” locks all doors. Shifting the shift lever to “P” unlocks all doors. All doors are locked when the vehicle speed is approximately 12 mph (20 km/h) or higher.
Vehicles with smart key system
All doors are unlocked when the driver’s door is opened within 10 seconds after turning the “ENGINE START STOP” switch OFF.
Vehicles without smart key system
All doors are unlocked when the driver’s door is opened within 10 seconds after turning the engine switch to the “LOCK” position.
50
1
1-2. Opening, closing and locking the doors and trunk
■ Setting and canceling the functions
To switch between setting and canceling, follow the procedure below:
STEP 1
STEP 2
Vehicles with smart key system: Close all the doors and turn the “ENGINE START STOP” switch to IGNITION ON mode. (Perform Vehicles without smart key system: Close all the doors and turn the engine switch to the “ON” position. (Perform STEP 2
within 10 seconds.)within 10 seconds.)
STEP 2
Shift the shift lever to “P” or “N”, press and hold the driver’s door lock switch ( ) for about 5
seconds then release.or
to
corresponding
The shift lever and switch posi- tions the desired function to be set are shown as follows. Use the same procedure to can- cel the function.
51
1-2. Opening, closing and locking the doors and trunk
Function
Shift lever position
Switch position
Shift position linked door lock- ing function Shift position linked door unlocking function Speed linked door locking func- tion Driver’s door linked door unlock- ing function
“P”
“N”
When the setting or canceling operation is complete, all doors are locked and then unlocked.
52
1-2. Opening, closing and locking the doors and trunk
■Customization that can be configured at Toyota dealer
Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 545)
CAUTION
■To prevent an accident
Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●Always use a seat belt. ●Always lock all doors. ●Ensure that all doors are properly closed. ●Do not pull the inside handle of the doors while driving. ●Set the rear door child-protector when children are seated in the rear seat.
53
1-2. Opening, closing and locking the doors and trunk Trunk
The trunk can be opened using the trunk opener, smart key system or wireless remote control. ■ Opening the trunk from inside the vehicle
Push the opener switch.
■ Opening the trunk from outside the vehicle Entry system (vehicles with smart key system) →P. 31
Wireless remote control →P. 4254
1-2. Opening, closing and locking the doors and trunk
■Internal trunk release lever
the glow-in-the-dark
The trunk lid can be opened by pulling down on lever located on the inside of trunk lid. The lever will continue to glow for some time after the trunk lid is closed.
■In case the trunk opener is not actuated
STEP 1
STEP 2
Pull down the rear armrest and open the door behind it.
Pull the loop of wire to unlock the trunk lid.
This is used in case the trunk lid cannot be unlocked due to a discharged bat- tery or other trouble.
55
1-2. Opening, closing and locking the doors and trunk
CAUTION
■Caution while driving
●Keep the trunk lid closed while driving.
If the trunk lid is left open, it may hit near-by objects while driving or lug- gage in the trunk may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard. Make sure to close the trunk lid before driving.
●Before driving the vehicle, make sure that the trunk lid is fully closed. If the trunk lid is not fully closed, it may open unexpectedly while driving, caus- ing an accident.
●Never let anyone sit in the trunk. In the event of sudden braking or a colli-
sion, they are susceptible to death or serious injury.
56
1
1-2. Opening, closing and locking the doors and trunk
CAUTION
■When children are in the vehicle Observe the following precautions. Failure to do so may result in death or serious injury. ●Do not allow children to enter the trunk.
If a child is accidentally locked in the trunk, they could overheat or suffo- cate.
●Do not allow a child to open or close the trunk lid.
Doing so may cause the trunk lid operate unexpectedly, or cause the child’s hands, head, or neck to be caught by the closing trunk lid.
■Using the trunk
Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in seri- ous injury. ●Remove any heavy loads, such as snow and ice, from the trunk lid before opening it. Failure to do so may cause the trunk lid to fall closed again after it is opened.
●When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.
●If anyone is in the vicinity, make sure they are safe and let them know that
the trunk is about to open or close.
●Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.
57
1-2. Opening, closing and locking the doors and trunk
CAUTION
●The trunk lid may fall if it is not opened fully. It is more difficult to open or close the trunk lid on an incline than on a level surface, so beware of the trunk lid unexpectedly opening or closing by itself. Make sure that the trunk lid is fully open and secure before using the trunk.
●When closing the trunk lid, take extra care to prevent your fingers etc. from being caught.
●When closing the trunk lid, make sure to press it lightly on its outer surface. If the trunk handle is used to fully close the trunk lid, it may result in hands or arms being caught.
●Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to fall closed again after it is opened.
58
1
1-3. Adjustable components (seats, steering wheel, mirrors) Front seats
Active head restraint
Seat leg support switch* Seat position fore/aft switch Seat cushion (front) angle switch* Vertical height switch* Seatback angle switch Lumbar support switch*
*: if equipped
When a front seatback receives a strong impact during a rear- end collision, the head restraint moves slightly forward and upward to provide support for the occupants head.
59
1-3. Adjustable components (seats, steering wheel, mirrors)
■Active head restraint
Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may cause the head restraint inner structure to appear. This does not indicate a problem.
Inner structure
During rear-end collision
CAUTION
■Reclining adjustment
Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
60
1-3. Adjustable components (seats, steering wheel, mirrors) Rear seats
To adjust the seat back angle, pull the lock release lever.
■ Keep the flap area clear
Flap area
Do not place objects on the flap area. If objects are left in the gap, the reclining seatback will not lock properly, and may move unexpectedly.
61
1-3. Adjustable components (seats, steering wheel, mirrors)
CAUTION
■Reclining adjustment
Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
62
1-3. Adjustable components (seats, steering wheel, mirrors) Driving position memory system∗
Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be entered into the computer’s mem- ory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked. Two different driving positions can be entered into memory. ■ Entering a position to memory STEP 1
Vehicles with smart key system: Turn the “ENGINE START STOP” switch to IGNITION ON mode. Vehicles without smart key system: Turn the engine switch to the “ON” position. Adjust the driver’s seat and outside rear view mirrors to the desired positions.
STEP 2
STEP 3
STEP 3Push the “SET” button, then within 3 seconds, push button “1” or “2” until the signal beeps.
If the selected button has already been preset, the previ- ously recorded position will be overwritten.
∗: If equipped 63
1-3. Adjustable components (seats, steering wheel, mirrors)
■ Recalling the memorized position STEP 1
Vehicles with smart key system: Turn the “ENGINE START STOP” switch to IGNITION ON mode. Vehicles without smart key system: Turn the engine switch to the “ON” position.
STEP 2
Push button “1” or “2” to recall the memorized position.
64
1-3. Adjustable components (seats, steering wheel, mirrors)
Linking driving position memory with door unlock operation (vehicles with smart key system)
Memorized driving positions can be recalled when you unlock the driver’s door using the entry function or wireless remote control and open the driver’s door. ■ Setting the linked door unlock operation STEP 1
Set the driving positions into the memory system using the “1” or “2” buttons. (→P. 63) Turn the “ENGINE START STOP” switch OFF, then close the driver’s door.
STEP 2
STEP 3
Push the “1” or “2” button on the driver’s side and the button on the wireless remote control at the same time for about 1 sec- ond until you hear a beep.
STEP 4
Open one of the doors. If a door is not opened within 60 seconds after doors will be locked again and the alarm will automatically be set. In case that the alarm is triggered, immediately stop the alarm. (→P. 99)
is pressed, the
65
1-3. Adjustable components (seats, steering wheel, mirrors)
■ Canceling the linked door unlock operation STEP 1
Close the driver’s door with the “ENGINE START STOP” switch OFF. Push the “SET” button and the button on the wireless remote control at the same time for about 1 second until you hear 2 beeps.
STEP 2
■Retained accessory power
Memorized positions can be activated up to 180 seconds after the driver’s door is opened and another 60 seconds after it is closed again, even if the “ENGINE START STOP” switch or the engine switch is OFF.
■If any position memory button is pushed while the adjustments are
being made The operation will stop. To reactivate the system, push the desired button (“1” or “2”) again.
■If the battery is disconnected
The memorized positions must be reset because the computer’s memory is erased when the battery is disconnected.
CAUTION
■Seat adjustment caution
Take care during seat adjustment that the seat does not strike the rear pas- senger. If this happens, you can stop the movement by pressing another seat posi- tion memory button.
66
1-3. Adjustable components (seats, steering wheel, mirrors) Head restraints
Head restraints are provided for all seats.
Front seats
Lock release button
Rear seats
Up Down Push and hold the lock release button when lowering the head restraint.
Up Down Push and hold the lock release button when lowering the head restraint.
67
1-3. Adjustable components (seats, steering wheel, mirrors)
■Removing the head restraints
Pull the head restraint up while pushing the lock release button.
■Installing the head restraints
Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.
■Adjusting the height of the head restraints
Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
■Adjusting the center rear seat head restraint
Always raise the head restraint one level from the stowed position when using.
68
1
1-3. Adjustable components (seats, steering wheel, mirrors)
CAUTION
■Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ●Use the head restraints designed for each respective seat. ●Adjust the head restraints to the correct position at all times. ●After adjusting the head restraints, push down on them and make sure
they are locked in position.
●Do not drive with the head restraints removed.
69
1-3. Adjustable components (seats, steering wheel, mirrors) Seat belts
Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts
Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoul- der. Position the lap belt as low as possible over the hips. Adjust the position of the seatback. Sit up straight and well back in the seat. Do not twist the seat belt.
■ Fastening and releasing the seat belt
Fastening the belt Push the tab into the buckle until a clicking sound is heard. Releasing the belt Press the release button.
Release button
70
1-3. Adjustable components (seats, steering wheel, mirrors)
■ Adjusting the height of the belt (front seats)
Down Up Move the height adjuster up and down as needed until you hear a click.
Seat belt comfort guide (outside rear seats)
If the shoulder belt sits close to a person’s neck, use the seat belt comfort guide.
STEP 1
STEP 2
Pull the comfort guide from the pocket.
Slide the belt past the slot of the guide.
The elastic must be behind the seat belt.
71
1-3. Adjustable components (seats, steering wheel, mirrors)
STEP 3
Buckle, position and release the seat belt.
Seat belt pretensioners (front seats)
The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
The pretensioner may not acti- vate in the event of a minor frontal impact, a side impact or a rear impact.
72
1-3. Adjustable components (seats, steering wheel, mirrors)
■Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend, and you can move around fully.
■Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then retracted even slightly, the belt is locked in that position and cannot be extended. This feature is used to hold the child restraint system (CRS) firmly. To free the belt again, fully retract the belt and then pull the belt out once more. (→P. 133)
■Pregnant women
Obtain medical advice and wear the seat belt in the proper way. (→P. 70) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants. Extend the shoulder belt com- pletely over the shoulder and position the belt across the chest. Avoid belt contact over the rounding of the abdominal area. If the seat belt is not worn properly, not only a pregnant woman, but also the fetus could suffer death or serious injury as a result of sudden braking or a collision.
73
1-3. Adjustable components (seats, steering wheel, mirrors)
■People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (→P. 70)
■Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult size. ●Use a child restraint system appropriately for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. (→P. 125) ●When the child becomes large enough to properly wear the vehicle’s
seat belt, follow the instructions on P. 70 regarding seat belt usage.
■Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent colli- sions.
■Seat belt extender
If your seat belts cannot be fastened securely because long enough, a personalized seat belt extender is available from your Toyota dealer free of charge.
they are not
74
1-3. Adjustable components (seats, steering wheel, mirrors)
CAUTION
Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failing to do so may cause death or serious injury. ■Wearing a seat belt
●Ensure that all passengers wear a seat belt. ●Always wear a seat belt properly. ●Each seat belt should be used by one person only. Do not use a seat belt
for more than one person at the same time, including children.
●Toyota recommends that children should be seated in the rear seat and
always use a seat belt and/or an appropriate child restraint system.
●Do not recline the seat any more than necessary to achieve a proper seat- ing position. The seat belt is most effective when the occupants are sitting up straight and well back in the seats.
●Do not wear the shoulder belt under your arm. ●Always wear your seat belt low and snug across your hips.
■Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (→P. 71)
75
1-3. Adjustable components (seats, steering wheel, mirrors)
CAUTION
■Seat belt pretensioners
●Do not place anything, such as a cushion, on the front passenger’s seat. Doing so will disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the seat belt pretensioner for the front passenger’s seat may not activate in the event of a collision.
●If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer.
■Child restraint lock function belt
Do not allow children to play with the child restraint lock function belt.
■Seat belt damage and wear
●Do not damage the seat belts by allowing the belt, plate or buckle to be
jammed in the door.
●Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from injury.
●Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer.
●Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there is no obvious damage.
●Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
76
1-3. Adjustable components (seats, steering wheel, mirrors)
CAUTION
■Using a seat belt comfort guide
●Make sure the belt is not twisted and that it lies flat. The elastic cord must
be behind the belt and the guide must be on the front.
●To reduce the chance of injury in case of a sudden stop, sudden swerve or accident while driving, remove and store the comfort guide in its pocket when it is not in use.
●Always make sure the shoulder belt is positioned across the center of the shoulder. The belt should be kept away from the neck, and should not fall off the shoulder. Failure to observe these precautions could reduce the effectiveness of the seat belt in an accident, causing death or serious injury.
■Using a seat belt extender
●Do not wear the seat belt extender, if you can fasten the seat belt without
the extender.
●Do not use the seat belt extender when installing a child restraint system, because the belt will not securely hold the child restraint system, increas- ing the risk of death or injury in the event of a collision.
●The personalized extender may not be safe on another vehicle, when used by another person, or at a different seating position other than the one originally intended.
NOTICE
■When using a seat belt extender
When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself.
77
1-3. Adjustable components (seats, steering wheel, mirrors) Steering wheel
The steering wheel can be adjusted to a comfortable position. ■ To change the angle
Hold the steering wheel, press the tilt lock release lever, and adjust to the ideal position by moving the steering wheel vertically.
When the steering wheel is in a low position, it will spring up as you release the lock release lever.
■ To change the column length
the
telescopic
Hold the steering wheel and press lock release lever, and adjust to the ideal position by moving the steering wheel horizontally.
After adjustment, pull the lever up the steering wheel.
to secure
78
1-3. Adjustable components (seats, steering wheel, mirrors)
CAUTION
■After adjusting the steering wheel
Make sure that the steering wheel is locked. Otherwise, the steering wheel may move suddenly, possibly causing an accident and resulting in death or serious injury.
